Hunter Fan 30240 User Manual

HEPAtechHEPAtechHEPAtech

Air Purifier System

Owner’s Guide

English

Form# 41900-01
20100609
©2010 Hunter Fan Co.

Model

30240

SAFETY INSTRUCTIONS

Save These Important Instructions

1. This Air Purifier is designed for use on a flat,
level surface and may not work properly on
an uneven surface. ALWAYS place this Air
Purifier on a firm, level surface. ALWAYS
place the Air Purifier at least six (6) inches
away from walls and three (3) feet from heat
sources such as stoves, radiators, or heaters.

2. Place the Air Purifier in an area that is out of
the reach of children.

3. Before using the Air Purifier, extend the cord
and inspect for any signs of damage. DO
NOT use the product if the cord has been
damaged.

4. To reduce the risk of electric shock, this
product has a polarized plug (one blade is
wider than the other) as a safety feature.
This plug will fit into a polarized outlet only
one way. If the plug does not fit fully into the
outlet, reverse the plug. If it still does not
fit, contact a qualified electrician. DO NOT
attempt to defeat or override this safety
feature.

5. ALWAYS UNPLUG the Air Purifier when it
is not in operation, while the filter is being
changed, and while it is being cleaned.

6. DO NOT tilt or move the Air Purifier while it
is in operation. Shut off and unplug before
moving.

7. DO NOT immerse the Air Purifier in water
as permanent damage will occur. Refer to
and follow the CLEANING AND FILTER
REPLACEMENT instructions.

quickly and effectively removing dust, smoke,
and pollen particles as small as .3 microns in
size. Room air is pulled in through the front grill
where larger particles and odors are caught on
the pre-filter. Smaller particles passing through
the pre-filter are caught on the main filter. The
ionizer helps remove the remaining particles
before being pushed back into the room through
the top vent.

USING YOUR AIR PURIFIER

1. Remove your air purifier from the box and
take it out of the clear plastic protective bag.

2. Place your HEPAtech™ Air Purification
System on a firm, flat surface.

3. Before turning the Air Purifier ‘on’, you need
to open the front grill. To release the front grill,
place your fingers behind the tabs and pull
forward.

4. The filter will be installed in the correct
position. Grasp the filter and pull it forward.
Remove the plastic wrapping and replace the
filter in the unit. The white filter material should
be facing outward (towards you) and the wire
mesh side should be hidden from view (inside
the unit).

5. Replace the front grill. Be sure that the bottom
tabs are in location first, and then push the top
of the grill forward until it is closed. The unit is
now ready for normal operation.

Note: This unit will not operate unless the door
is placed in the correct position.

8. DO NOT run the ionizer if tobacco smoke, air
fresheners, dripless wax candles, or grease
from cooking is present.

6. Plug the unit into a 120V electrical outlet.

INSTRUCTIONS

Thank you for purchasing the HEPAtech™ Air
Purification System from Hunter Fan Company.
You have purchased our latest development in
portable Air Purification Systems. This system
has been developed to improve the quality of
the air you breathe.

Our HEPAtech™ Air Purification System out
performs other air purification systems by

©2010 Hunter Fan Company 41900-01 20100609

2
