Hunter 28547 User Manual
Marine II Outdoor
Marine II Outdoor
Marine II Outdoor
Light Kit
Light Kit
Light Kit
Owner’s Guide and Installation Manual
Manual De Propietario
English Español
Form# 43552-01
20140415
©2014 Hunter Fan Co.
Table Of Contents
1 • Installing the Light Kit on a
Removable Switch Housing . . . . . . . 4
2 • Installing the Light Kit on a Non-
Removable Switch Housing........5
3 • Installing the Light Kit on the Hunter
Original .........................7
4 • Installing the Light Kit on a Fan with
a Removable Switch Housing Cap..8
5 • Installing the Bulbs, Chain, and
Globe .............................9
Welcome
Your new Hunter® light kit is an addition to your home or office that
will provide comfort and performance for many years. is installation
and operation manual gives you complete instructions for installing
and operating your light kit.
We are proud of our work. We appreciate the opportunity to supply
you with the best products available anywhere in the world.
Before installing your light kit, for your records and warranty assistance,
record information from the carton and Hunter nameplate label.
Cautions and Warnings
• READ THIS ENTIRE MANUAL CAREFULLY BEFORE BEGINNING
INSTALLATION. SAVE THESE INSTRUCTIONS.
• Use only Hunter replacement parts.
• To reduce the risk of personal injury, install this light fixture only on
Hunter® fan types A through Z. Note: e fan type can be found on
the ceiling fan package or on the nameplate label located on top of
the motor housing of the ceiling fan.
• To avoid possible electrical shock, before installing light fixtures,
disconnect the power by turning off the circuit breakers both to
the outlet box and to its associated wall switch location. If you
cannot lock the circuit breakers in the off position, securely fasten a
prominent warning device, such as a tag, to the service panel.
• Connect house wiring to the fan before attaching the light fixture to
the fan.
• All wiring must be in accordance with national and local electrical
codes and ANSI/NFPA 70. If you are unfamiliar with wiring, use a
qualified electrician.
6 • Troubleshooting....................10
© 2014 Hunter Fan Company
2
43552-01 • 04/15/14 • Hunter Fan Company
Installation Methods of Hunter® Ceiling Fans Type A-Z
Your ® light kit can be installed in one of three
ways. e steps in this manual include instructions for
all three installation methods: Installation on fans with
removeable switch housings, fans with non-removeable
switch housings, and e Hunter Original.
Preparing the Light Kit:
Removable Switch Housing
1. Disconnect power by turning off the circuit breakers
both to the outlet box and to its associated wall switch
location.
Non-removable Switch Housing
e Hunter Original
Removable Switch Housing Cap
3
43552-01 • 04/15/14 • Hunter Fan Company
