USER MANUAL

4, 9 & 16 CHANNEL

NETWORK VIDEO RECORDER

INSTRUCTION MANUAL

To obtain the best performance and ensure device function correctly, please read this instruction manual carefully and completely.

FCC Compliance

USER-INSTALLER CAUTION: YOUR AUTHORITY TO OPERATE THIS FCC VERIFIED EQUIPMENT

COULD BE VOIDED IF YOU MAKE CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY RESPONSIBLE FOR COMPLIANCE TO PART 15 OF THE FCC RULES.

NOTE: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS.

OPERATION OF THIS EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH CASE THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.

THIS CLASS A DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS.

WARNINGS, CAUTIONS & COPYRIGHT

WARINGS

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MISTURE. DO NOT INSERT ANY METALLIC OBJECT THROUGH VENTILATION GRILLS.

CAUTION

Explanation of Graphical Symbols

The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of insinuated "dangerous voltage" within the products enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.

The exclamation point within an equilateral rhombus is intended to alert the user to the presence of important operating and maintenance (servicing) instruction in the literature accompanying the product.

USERS OF THE SYSTEM ARE RESPONSIBLE FOR CHECKING AND COMPLYING WITH ALL FEDERAL, STATE, AND LOCAL LAWS AND STATUTES COIPCERNING THE MONITORING AND RECORDING OF VIDEO AND AUDIO SIGNALS. ULTRAK SHALL NOT BE HELD RESPONSIBLE FOR THE USE OF THIS SYSTEM IN VIOLATION OF CURRENT LAWS AND STATUTES.

THE TRADEMARKS MENTIONED IN THE MANUAL ARE LEGALLY REGISTERED TO THEIR RESPECTIVE COMPANIES.

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK.

DO NOT REMOVE COVER (OR BACK).

NO USER-SERVICEABLE PARTS INSIDE.

REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

CAUTION

TABLE OF CONTENTS

1 INTRODUCTION...................................................................................................................... 4

1.1 FEATURE.......................................................................................................................4

1.2 SPECIFICATION..........................................................................................................4

2 HARDWARE OVERVIEW...................................................................................................... 8

2.1 FRONT PANEL .............................................................................................................8

2.2 BACK PANEL................................................................................................................9

2.3 ALARM TRIGGER..................................................................................................... 10

2.4 IR REMOTE CONTROL ........................................................................................... 12

2.5 PTZ (PAN, TILT AND ZOOM) CAMERA ............................................................... 13

3 SYSTEM SETUP .....................................................................................................................14

3.1 MENU SETUP INTERFACE(GUI)........................................................................... 14

3.2 LIVE VIEWING AND POP-UP MENU.................................................................... 16

3.3 CAMERA SETUP ........................................................................................................ 20

3.4 RECORD SETUP ........................................................................................................28

3.5 ALARM SETUP........................................................................................................... 30

3.6 NETWORK SETUP ....................................................................................................34

3.7 AUTHORITY SETUP .................................................................................................39

3.8 DISK MANAGEMENT............................................................................................... 41

3.9 SYSTEM SETUP .........................................................................................................43

3. EX DEBUG MESSAGE ...................................................................................................46

4 NVR PLAYBACK .................................................................................................................... 48

4.1 TIME SEARCH ...........................................................................................................50

4.2 EVENT SEARCH ........................................................................................................ 50

4.3 BACKUP....................................................................................................................... 51

4.4 SYSTEM LOG .............................................................................................................52

5 BACKUP PLAYBACK ...........................................................................................................53

5.1 MAIN SCREEN SETTING.........................................................................................53

5.2 PLAYBACK OPERATION........................................................................................ 56

6 NETWORK VIEWING & PLAYBACK............................................................................... 59

6.1 IP ADDRESS SETUP ON PC SITE........................................................................... 59

6.2 OPTIONAL MICROSOFT INTERNET EXPLORER SETUP.............................. 61

6.3 LOGIN ..........................................................................................................................63

6.4 REMOTE CONTROL................................................................................................. 64

6.5 CONFIGURE ............................................................................................................... 69

APPENDIX A: RECORDING TIME LAPSE (HOURS)............................................................. 82

APPENDIX B: HDD COMPATIBLE TABLE .............................................................................. 83

APPENDIX C: ERROR MESSAGE LIST.................................................................................... 85

1 INTRODUCTION

1.1 FEATURE

 Support 16-channel IP cameras input.

 Support H.264 / MPEG4 / MJPEG decoding.

 Real-time Display & Playback.

 Support 5 Megapixel IP Camera for each channel.

 Support HDDs x4

 Support e-SATA interface

 Support HDMI Video interface .

 Support CMS (Central Management System) control

 Audio Backup for all channels

 Graphic User Interface ( GUI ).

 Support time-point backup function under Ethernet remote control mode. User can

select any time period to process backup from remote side.

 Support time-search & event-search function under Ethernet remote control mode.

 Up to four online clients for independent remote control; individual live-time,

play-back & time-search function available

 Support PPPoE/ Static/ DHCP IP & DDNS.

 Powerful mobile surveillance function, support i-Phone & Android

1.2 SPECIFICATION

MODEL

HNR-16EE

System

Embedded Linux

connector

Ethernet

RJ-45, 10/100/1000 Mbps x1

VGA output

D-SUB output

HDMI output

USB 2.0

Front : 2 ports

Power

DC 12V, 5A

Video and Audio

Video input

16 channels

Audio input

16 channels

NVR Functions

Camera Name

Max. 20 characters

Screen Split Control

1, 4, 9, 16

Image Control

Contrast / Brightness / Saturation / Hue

Recording mode

Manual / Schedule / Alarm

Pre Recording

1~5 sec

Watermark

Support

Searching and Playback

Search Method

Date / Time / Event

Date/ Time / Event Search

Selectable on the calendar

Log Search

Through the log data to find the video event / time

Backup Type

USB

Remote Client Software

Monitoring Environment

Hunt CMS, Iprosecu M.V2 for I phone / I pad , Iprosecu A.M.V2

for Android phone / Android pad, Web site

IP cam Live View

16 Channels

Remote Search

Web site remote time / event search

System Monitoring and Recovery

Monitoring

Watchdog

Alarm

Alarm Input

8 inputs

Alarm output

2 outputs

Peripheral Devices

Audio in

3.5 Ø Earphone stereo jack

Audio out

3.5 Ø Earphone stereo jack

RS 485

2- pin terminal

Storage & Backup Devices

INTERNAL HDD SUPPORT

SATA HDD x 4

EXTERNAL USB BACKUP DEVICE (PAN DRIVE, HDD, BURNER)

USB x2

E-SATA

RAID

N/A

Networking

Type

Static/ DHCP/ PPPoE/DDNS

Environment

Operating Temp.

0 - 45 ℃ / 32~113 F

Humidity

0~80% RH (non-condensing)

Language

Type

English / Traditional Chinese / Simple Chinese / Russian / Italian / Japanese / Czech / France / Germany / Spanish / Portuguese

Physical

Color

Black

Dimensions (W x H x D)

360 x 60 x 311 mm

Weight

4 KG

* SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

2 HARDWARE OVERVIEW

2.1 FRONT PANEL

NVR OPERATION

NO.

LABEL

OPERATION

LED

Led Indicator

4321

76 8

10 11 12

USB Connector/ USB Mouse Connector

MIC IN

Microphone input(Phone Jack)

AUDIO OUT

Earphone output(Phone Jack)

2.2 BACK PANEL

NO.

LABEL

OPERATION

E-SATA

E-SATA interface

VIDEO OUT (VGA)

Connect to LCD monitor

POWER

Connect to power adapter (AC 12V/5A)

VIDEO OUT (HDMI)

HDMI video output

ETHERNET

RJ-45 connector

ALARM IN/ RELAY OUT/ RS-485

8 alarm in/ 1 relay out/ RS485

FAN

The fan louvers

2.3 ALARM TRIGGER

There are four types of alarms: Motion detection, Video Loss Alarm, External Alarm, and

Digital Input from Camera. Following are the possible action when alarm is triggered.

Every action is configurable (Ex. the screen display pattern, the relay triggered time.etc)

and will be explained in the later chapter.

A. When Motion detection happens:

a. The live screen pattern can be switch to single channel screen or split screen.

b. External relay/ built-in buzzer can be triggered.

c. Alarm timepoint can be recorded in the event list, and you can search for the event

in playback.

d. On the channel which the alarm triggered, the icon pops up to remind the user.

e. The pre/ post-alarm recording video can be sent to e-mail/ uploaded to FTP.

f. CGI can be sent to an http server.

B. When External Alarm or Digital Input from Camera happen:

a. External relay/ built-in buzzer can be triggered.

b. Alarm timepoint can be recorded in the event list, and you can search for the event

in playback.

c. On the channel which the alarm triggered, the icon pops up to remind the user.

d. The pre/ post-alarm recording video can be sent to e-mail/ uploaded to FTP.

e. CGI can be sent to an http server.

C. When Video Loss Alarm happens:

a. External relay/ built-in buzzer can be triggered.

b. Alarm timepoint can be recorded in the event list, and you can search for the event

in playback.

c. On the channel which the alarm triggered, the icon pops up to remind the user.

d. CGI can be sent to an http server.

D. Alarm in connecter

EX1：Connect GND & Alarm to external IR detector.

EX2：Connect N.O & COM to external siren.

Depending on the external device type,

You may connect N.C & COM to external device.

D+

RS-485: sends +/ receives +

D -

RS-485: sends -/ receives -

GND

Ground

ALARM IN 1-8

Alarm input

N.C

Relay: Normally close

N.O

Relay: Normally open

COM

Relay: Common

2.4 IR REMOTE CONTROL

ITEM

REC

Start recording on live view.

ID1~8

ID (corresponding with NVR ID)**

Call out/ close main menu.

ZOOM

2X Zoom in/ back to original size on single channel view.

PTZ

Call out/ close PTZ panel.

AUTO

Start/ end auto swap.

IPCAM

Call out/ close quick setup menu.

In any menu, use▲►▼◄ to switch the selected item or adjust value, and use “enter” to enter.

►

Call out/ close playback menu on live view.



Stop playback and call out playback panel under playback mode.

►►/◄◄

Fast forward/ Fast backward under playback mode.

Play/Playback frame by frame under playback mode.

COPY

Start recording the playback video to USB under playback mode.

Vol +/-

Adjust the audio volume.

CH +/-

Jump to next channel/ previous channel.

0~9

Press the number to jump to corresponding channel. (Ex. Press 1 and 6 to jump to CH.16)

DISPLAY

Display/ hide the channel number and IP address on live view.



RETURN

Jump to the channel users view before the current channel.

**Each NVR can setup its own ID number. The user

can control NVR via remote controller by pressing ID button to change to the same ID mode with NVR.

For example, if NVR ID is set as 1, users are only allowed to execute operations via remote controller after he press “ID1” button. Remote controller stays on current mode until users change it, so It’s no need to press the ID button every time users do operations. If the user press different ID number button from NVR, the remote controller cannot control NVR.

If you own several NVRs of the same model, use ID to make a distinction.

2.5 PTZ (PAN, TILT AND ZOOM) CAMERA

Following diagram for NVR connect between PTZ camera & joystick controller, for NVR to control PTZ camera please make sure the CAMERA ID, BANDRATE (default at 9600 bps) and RS-485 cable.

Under “Two Core” connection, controller can control speed dome without integrated protocol into NVR. Moreover, one keyboard can connect MAX 256 units of speed dome.

3 SYSTEM SETUP

3.1 MENU SETUP INTERFACE(GUI)

A. CAMERA SETUP B. RECORD SETUP

C. ALARM SETUP D. NETWORK SETUP

E. AUTHORITY SETUP F. DISK MANAGEMENT

G. SYSTEM SETUP H. EXIT

3.2 LIVE VIEWING AND POP-UP MENU

NOTE：*The pop-up menu can be activated by moving the mouse cruise to the

bottom of the live viewing screen.

*The captured images among this user manual are based on 16CH NVR

model, in 04CH and 09CH NVR models, please follow the real situation.

A. GUI MENU BAR

With live viewing mode, press this button to get into the GUI menu.

B. DISPLAY CONTROL

Within live-viewing or playback mode, use display control to switch the camera channel.

C. AUTO SWAP

Press it to start auto swap. The interval depends on the setting in IPCam Image Setup when it’s on single channel view. For split screen the switch dwell interval is 5 sec.

D. PTZ CONTROLLER

Within live-viewing mode, Clicks this button to get into the PTZ setup menu. User can right-click the button of the mouse to exit PTZ Setup.

NOTE： Only for the camera supported PTZ function.

PTZ CONTROL

Press the minimization icon then the control panel becomes smaller:

Move the mouse and the arrow will follow the mouse and change direction. In this mode user can click on the live view to control direction instead of the direction key on control panel.

If a fisheye camera is connected:

E-PTZ Steps:

(1) Select the channel number you want to setup, if there are several ones. (2) Select the View Mode, 360 degree or 180 degree. (3) Select the camera location, ceiling, desk, or wall. (4) Select split screen pattern

: 360 degree panorama view + sub screens x4

: 180 degree flat view + sub screens x2

: sub screens x4

(5) After you decide the screen pattern, use the fisheye channel list to select one of the

sub screens. (as the green circle on the picture above). The selected one will be indicated in a red frame.

(6) For the selected sub screen, use the 4-direction arrows and the “+” (zoom in) ”-”

(zoom out) icon for E-PTZ control.

(7) Control Mode: Select the E-PTZ moving mode, step by step or continuous. (8) The AutoPan, Stop, and Patrol buttons are invalid here if the fisheye camera doesn’t support those function.

E. DISK INFORMATION

With live viewing mode, press this button to display disk information.

F. DIGITAL ZOOM

In the live full screen mode, left-click the button of the mouse to pull a range to zoom in or zoom out the image. User can right-click the button of the mouse to disable this function. (NOTE: Using the mouse to operate digital zoom can zoom in to max. 16 times.) Moreover, user can also use ZOOM key on the front panel to perform this function. (First, click ZOOM Key and then click ▲▼◄► key to select zoom in or zoom out position. Finally, click ENTER key to complete the setting. Moreover, click ZOOM Key again can disable digital zoom function. Using the panel key to perform zoom in function is fixed at 2 times.)

G. AUDIO VOLUME

Press this button, and the audio volume control board will pop up.

H. BOARDCASTING

Press the bottom to enable or disable the one way audio. You can use microphone to

speak simultaneously to all the channels.

I. FULL SCREEN

Press the bottom for full-screen mode.

J. RECORD AND PLAYBACK CONTROL

Same as front panel controller and remote controller.

K. SOUND INPUT/ SOUND OUTPUT / PTZ CONTROL

There are little icon on the right top of the live vide of every channel. Click to

enable the two ways audio. Click to enable the sound output. Click to PTZ call out the control board. Note that if those functions are not support by the camera linked, you will not see the corresponding icons.

The sound options do not affect the audio recorded into playback video. As long as the audio setup is enabled, the playback video includes audio even the sound output here is turned off.

L. RECORDING STATUS

Beneath the date and time, it displays the current recording type:

Record mode: Schedule – NO REC period Record mode: Schedule – ALARM REC period

Record mode: Alarm trigger

Record mode: Manual – Stop Recording

Record mode: Schedule – FULL REC period Record mode: Manual – Recording

3.3 CAMERA SETUP

A. IPCam Setup

A-1. IPCam Quick Search

Press the “IPCam Quick Search” button and click “Search Device” button in the following, NVR will search the IPCAM devices which IP address are setup as the same domain as NVR IP address. Moreover, click the IPCam device which from the list can import the device information to the channel automatically without any manual key-in step. The IPCam has to be under the same LAN with NVR in order to connect successfully. Ex. If NVR IP address is 192.168.10.33, IP Cam IP address should be 192.168.10.X. You can edit IP Cam IP address here or on the IP Cam.

a. Normal Mode

Enable this channel. Key in the IP address, port, username, and password of

the device you prepare to connect. You can find the information on the IP Cam.

Click the “connect IPCAM” button, the message will show in “State” column

to tell you whether connection succeeds or not.

Note: To the camera connected via ONVIF protocol, the PTZ control function

is not supported. Note: To the camera connected via ONVIF protocol, the PTZ control function is not supported.

b. RSTP Mode

Under RTSP Mode, the NVR only support the IP address indication, the live video, and video recording. Other functions like motion detection are not supported.

Key in the IP address, port, username, and password of the device you

prepare to connect. You can find the information on the IP Cam.

To link to the IP camera, check the RTSP Path settings of your IP camera, and key in the corresponding values of two streams in “RTSP Path 1” and “RTSP Path 2”.

Note: When you select RTSP mode, make sure the substream resolution of

camera is VGA(640x480). Or you will receive the warning message when you try to connect with the camera:

Here we lists some RTSP setting for sample:

RTSP Path 1 (IPCam Main stream)

RTSP Path 2 (IPCam Sub stream)

Result

1920 x 1080

640 x 480

OK. NVR takes 1920x1080 streaming for single channel view, and 640x480 streaming for split screen.

1920 x 1080

N/A (Fill in nothing on "RTSP Path 2")

Error Message: ”Invalid Substream Resolution! Please modify IPCam.” NVR takes 1920x1080 streaming for both single channel view and split screen. However, it can only allow 640x480 resolution for split screen, so it shows error in return.

640 x 480

N/A (Fill in nothing on "RTSP Path 2")

OK. NVR takes 640x480 streaming for both single channel view and split screen.

N/A (Fill in nothing on "RTSP Path 1")

640 x 480

OK. NVR takes 640x480 streaming for both single channel view and split screen.

640 X480

1920 x 1080

OK. NVR takes 1920x1080 streaming for single channel view, and 640x480 streaming for split screen.

1920 x 1080

c. ROI

This function allows users to set up the channel as an attached channel. An attached channel is based on a normal/ RTSP channel has been set up, and can display the same live view as the normal/ RTSP channel. The attached channel is not physically linked to any camera, so it doesn't increase the bandwidth loading. Users cannot do camera setup (like motion detection or image adjustment) on attached channel.

1. Enable: Choose “ROI”.

2. Attached Channel: Select a connected normal/ RTSP channel in the drop-down menu.

3. Ratio: Use the arrows to adjust the zoom ratio, and press the red frame to

drag it to the area that you want it to show on the live view screen.

A-2. Connect IPCAM：After insert the IPCAM related information, click this button

to test the connection circumstances.

B. IPCam Video Setup

B-1. Resolution

Click drop down list to change the resolution of connecting device.

B-2. Quality

Click drop down list to change the image quality.

For H.264 IPCam above 1 Megapixel, the resolution options support “4Mbps, 3Mbps, 2Mbps, 1.5Mbps, 1Mbps”. For H.264 IPCam less than 1 Megapixel, the resolution options support” 2Mbps,

1.5Mbps, 1Mbps, 512Kbps, 256Kbps”

For MPEG IPCam, the resolution options support “Standard, Medium, Low”. (The highest resolution option is “standard” due to the chip performance limits of IPCam)

B-3. FrameRate

Click drop down list to change the frame rate of connecting device.

C. IPCam Image Setup

C-1. Display

Use the mouse to enable or disable the camera display on the screen or not.

C-2. Title

Use the mouse to setup the title of connecting IP device.

C-3. Contrast

Press ◄ or ► to change contrast level. The adjustment value is between 0~255

C-4. Brightness

Press ◄ or ► to change brightness level. The adjustment value is between 0~255

C-5. Hue

Press ◄ or ► to change hue level. The adjustment value is between 0~255

C-6. Saturation

Press ◄ or ► to change saturation level. The adjustment value is between 0~255

C-7. Sharpness

Press ◄ or ►/ mouse wheel to change sharpness level. The adjustment value is between 0~15

C-8. Switch Dwell

Press ◄ or ► to change auto switch second. The value is between 0~99 sec.

D. Motion Setup

D-1. Relay Dwell

Press ◄ or ► to change the relay time or disable relay function.

D-2. Buzzer Dwell

Press ◄ or ► to change the buzzer time or disable buzzer function.

D-3. Area1 Sensitivity

Press ◄ or ► to change the sensitivity of setup motion area in Area1. Click “Motion Area Setup” and drag a blue area for motion detection.

D-4. Area2 Sensitivity

Press ◄ or ► to change the sensitivity of setup motion area in Area2. Click “Motion Area Setup” and drag a green area for motion detection.

D-5. Area3 Sensitivity

Press ◄ or ► to change the sensitivity of setup motion area in Area3. Click “Motion Area Setup” and drag a red area for motion detection.

After dragging an area, right-click the mouse, select “Exit with saving” to

complete the area setup. Select “Enable All” to set up global motion detection. Select “Clean All” to clean the area of the current color in the view.

Select “Exit Without Saving” to go back to motion setup menu and the setting

you just changed will not be saved.

E. Mask Setup

The masked area will not show on the live video and video playback.

E-1. Area1

Tick the “Area1” box and click “Area Setup” to drag a blue area for masking.

E-2. Area2

Tick the “Area1” box and click “Area Setup” to drag a green area for masking.

E-3. Area3

Tick the “Area1” box and click “Area Setup” to drag a red area for masking.

After dragging an area, right-click the mouse, select “Exit with saving” to

complete the area setup. Select “Enable All” to set up global masking. Select “Clean All” to clean the area of the current color in the view.

Select “Exit Without Saving” to go back to mask setup menu and the setting you

just changed will not be saved.

F. IPCam Audio Setup

The channel ticked means the sound from camera will be recorded into the playback video. Vise versa. No sound will be recorded in the playback video of the channel which is not ticked.

G. Quick Setup

Other than “IPCAM Setup”, you can choose another way to complete the IP camera connection job: using Quick Setup.

G-1 Key in information manually

Here is the all-channel list. You can key in the IP address, port, and user name & password of the IP camera, and then assign the channel number. Tick “Enable” to connect with the IP camera.

G-2 IPCAM Quick Search

With Quick Search, you need not type the IP address. Click “IPCAM Quick Search” to enter the search menu.

The machine searches for all the IP devices under the LAN and list here. Find the IP camera you want to connect with, assign a channel number for it, and tick “Enable” so that this IP camera will be added to the all-channel list. Back to the all-channel list, you can key in the user name and password, and tuck “Enable” to connect with the camera. If you want to revise the IP setting of a camera, click “Edit”:

The IPCam has to be under the same LAN with NVR in order to connect successfully. Ex. If NVR IP address is 192.168.10.33, IP Cam IP address should be 192.168.10.X. You can edit IP Cam IP address here or on the IP Cam.

+ 58 hidden pages

Hunt Electronic HNR-16EE, HDR-04FE User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
