Humatech HI-150 User Manual

3) PM (Particulate Matter) display mode: Simultaneously displays

PM2.5 and PM10 measurement values.

4) VOC (Volatile Organic Compound) display mode

VOC concentration is displayed together with the ppm unit figures.

5) CO2 display mode

CO2 concentration is displayed in graph form.

The CO2 sensor applied to our product is CO2eq (CO2 equivalent),
which is calculated based on the H
when breathing in the fasting state.
It may react to other harmful gases in the surrounding environment.
If it shows a poor/unhealthy condition, use it as a ventilation
guideline for indoor air management.

**** In case of CO2 and VOC, the value is displayed after 15 ~ 60
seconds at power-on, after which the value is updated in every
second.

6) Temperature/Humidity mode

It shows temperature and humidity in one screen.

*** In case of temperature and humidity, the temperature/humidity
sensor is inside of the product and may cause a deviation of
5 ~ 10%.

2 concentration that occurs

④ Battery Status Display: This icon displays remaining battery status.

Specifications

Product
Model No.

PM

Portable Air Quality Monitor

Huma-i Black (HI-150)

Measurement range: 0~500㎍/㎥ (PM2.5/PM10)

Resolution: 1 ㎍/㎥

VOC

CO

2

Power Supply
Charge Mode
Dimension
Weight

Certifications

Measurement range: 0.000 ~10.000 ppm

Resolution: 0.001 ppm
Measurement range: 400 ~ 10,000 ppm

Resolution: 1 ppm

Rechargeable Li-Polymer Battery

USB micro 5Pin

3.6 X 1.6 X 1.5 inches (91 X 41 X 37mm)

0.13 pounds (60g)

FCC CE

Limited Warranty

1. Do not expose to direct sunlight or subject it to high temperature
and high humidity.
It may change appearance or cause malfunction.

2. Do not use for long periods in high concentration fine dust
environment.
Note that the measurement may not be smooth.

3. Do not disassemble the product if you’re not an authorized
engineer and/or a technician.
The disassembled products without authorization are out of
warranty in any case.

4. Do not allow drinks or water to enter the product.
It may cause malfunction, electric shock or fire.

5. This product may cause errors depending on the environment
(temperature, humidity, wind) and usage.

6. The measured values of this product are for personal use only and
are not responsible for the manufacturer and the seller.

Air Quality Monitor

TM

Portable Air Quality Monitor

for CO2, VOC,

Particulate Matter (PM2.5 & PM10),

Temperature and Humidity

User Manual

www.humatech.co.kr

Introduction – Huma-i Black (HI-150)

Thank you for purchasing our products.

Huma-i Black (HI-150) model is equipped with a Carbon Dioxide/VOC
sensor to measure CO
In addition, in-house designed built-in fine dust sensor module allows
you to measure fine dust and ultra-fine dust as well.

You can check the air quality around you anytime and anywhere with
Huma-i.

*** What is VOC?
It is a carcinogen causing nervous system trouble through skin contact
in the air or breathing inhalation. Benzene, formaldehyde, toluene,
xylene, ethylene, and acetaldehyde are collectively called.

2

and volatile organic compounds in real time.

Main functions

①

②

③

④

① Power and mode selection button

- Power Button

If you press the button for 1 second, it will be in power-on state.
It automatically switches to power-off state when not in use for

10 minutes to protect battery life.
The status LED will blink 1 minute before automatic power-off.
At this time, if you press the button lightly, it will be switched on

again for 10 minutes, and the mode will not change.

- Mode Selection Button

Each time you press the mode select button, the display mode
changes cyclically in the following order.

Integrated Display Mode (PM2.5 / VOC / CO
=> PM Mode (PM2.5 / PM10) => VOC Mode => CO

2

) => WHO Mode

=> Temperature/Humidity Mode

② Status Light

The status LED lets you know the status of CO2, VOC and fine
dust/ultra-fine dust.

Unit of measure

μg/㎥

(WHO

Guideline)

ppm (mg/㎥)

ppm

ultra-fine dust

fine dust

VOC

CO

2

Good

0~15

0~30

0.000 ~

0.220

GOOD

(400 ~

700)

Moderate

16~25

31~50

0.221 ~

0.660

MODERATE

(701 ~
1,000)

Poor

26~35

51~70

0.661 ~

2.200

POOR

(1,001 ~
2,000)

2

Mode

Unhealthy

2.201 ~

10.000

UNHEALTHY

(2,001 ~
10,000)

35~

70~

③ Display mode

1) Integrated display mode

It is shown in a step-by-step graph so that air quality can be
judged easier than difficult figures.

PM2.5

VOC

CO

2

GOOD

Good

PM2.5, VOC and CO
Graph with 4 steps shows the air quality - good, moderate,
poor and unhealthy

2) WHO mode (Icon mode)

You can easily recognize the good and poor state of find dust
by 4 kinds of icons.
In this mode, it automatically displays the worst between PM2.5
and PM10.

2 can be viewed in one screen.

Moderate

Poor

POOR

Unhealthy

Green : Moderate air quality.Blue : Good air quality.

65

Red : Unhealthy air quality.Yellow : Poor air quality.
