Hughes & Kettner CONTOUR User Manual

Manual 1.0

ConTour Series™

English

Wichtige Sicherheitshinweise!

Bitte vor Gebrauch lesen und für späteren Gebrauch
aufbewahren!

• Read all of these instructions!

• Save these instructions for later use!

•Follow all warnings and instructions marked on the product!

• Do not use this product near water, i.e. bathtub, sink, swimming pool,
wet basement, etc.

• Do not place this product on an unstable cart, stand or table. The
product may fall, causing serious damage to the product or to
persons!

• Slots and openings in the cabinet and the back or bottom are
provided for ventilation; to ensure reliable operation of the product
and to protect it from overheating, these openings must not be
blocked or covered. This product should not be placed in a built-in
installation unless proper ventilation is provided.

• This product should not be placed near a source of heat such as a
stove,
radiator, or another heat producing amplifier.

• Use only the supplied power supply or power cord. If you are not sure
of the type of power available, consult your dealer or local power
company.

• Do not allow anything to rest on the power cord. Do not locate this
product where persons will walk on the cord.

• Never break off the ground pin on the power supply cord.

• Power supply cords should always be handled carefully. Periodically
check cords for cuts or sign of stress, especially at the plug and the
point where the cord exits the unit.

• The power supply cord should be unplugged when the unit is to be
unused for long periods of time.

• If this product is to be mounted in an equipment rack, rear support
should be provided.

• This product should be used only with a cart or stand that is
recommended by HK AUDIO

®

.

• Never push objects of any kind into this product through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in risk of fire or electric shock. Never spill liquid of
any kind on the product.

• Do not attempt to service this product yourself, as opening or
removing covers may expose you to dangerous voltage points or
other risks. Refer all servicing to qualified service personnel.

• Clean only with dry cloth.

• Do not defeat the safety purpose of the polarized or grounding-type
plug.
A polarized plug has two blades with one wider than the other. A
grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong are provided for the safety. If the
provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.

• Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:

• When the power cord or plug is damaged or frayed.

• If liquid has been spilled into the product.

• If the product has been exposed to rain or water.

• If the product does not operate normally when the operating
instructions are followed.

• If the product has been dropped or the cabinet has been damaged.

• If the product exhibits a distinct change in performance, indicating a
need of service!

• Adjust only these controls that are covered by the operating instruc­tions since improper adjustment of other controls may result in da­mage and will often require extensive work by a qualified technician
to restore the product to normal operation.

• Exposure to extremely high noise levels may cause a permanent
hearing loss.

• Individuals vary considerably in susceptibility to noise induced
hearing loss, but nearly everyone will lose some hearing if exposed to
sufficiently intense noise for a sufficient time. The U.S. Government´s
Occupational Safety and Health Administration (OSHA) has specified
the following permissible noise level exposures:

Duration Per Day In Hours Sound LeveldBA, Slow Response

890
692
495
397
2 100
11/2 102
1 105
1/2 110
1/4 or less 115

• According to OSHA, any exposure in excess of the above permissible
limits could result in some hearing loss.

• Ear plug protectors in the ear canals or over the ears must be worn
when operating this amplification system in order to prevent a perma­nent hearing loss if exposure is in excess of the limits as set forth
above. To ensure against potentially dangerous exposure to high
sound pressure levels, it is recommended that all persons exposed to
equipment capable of producing high sound pressure levels such as
this amplification system be protected by hearing protectors while
this unit is in operation.

•Fuses: Replace with IEC 127 (5x 20 mms) type and rated fuse for best
performance only.

TO PREVENT THE RISK OF FIRE AND SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO MOISTURE OR RAIN. DO NOT OPEN
CASE;
NO USER SERVICE-ABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

Version 1.0 10/2004

• The unit has been built by HK AUDIO

®

in accordance with IEC 60065
and left the factory in safe working order. To maintain this condition
and ensure non-risk operation, the user must follow the advice and
warning comments found in the operating instructions. The unit
conforms to Protection Class 1 (protectively earthed).

• HK AUDIO

®

ONLY GUARANTEE THE SAFETY, RELIABILITY AND

EFFICIENCY OF THE UNIT IF:

• Assembly, extension, re-adjustment, modifications or repairs are
carried out by HK AUDIO

®

or by persons authorized to do so.

• The electrical installation of the relevant area complies with the
requirements of IEC (ANSI) specifications.

• The unit is used in accordance with the operating instructions.

• The unit is regularly checked and tested for electrical safety by a
competent technician.

WARNING:

• If covers are opened or sections of casing are removed, except where
this can be done manually, live parts can become exposed.

• If it is necessary to open the unit this must be insulated from all
power sources. Please take this into account before carrying out
adjustments, maintenance, repairs and before replacing parts.

• The appliance can only be insulated from all power sources if the
mains connection is unplugged.

• Adjustment, maintenance and repairs carried out when the unit has
been opened and is still live may only be performed by specialist
personnel who are authorized by the manufacturer (in accordance
with VBG 4) and who are aware of the associated hazards.

• Loudspeaker outputs which have the IEC 417/5036 symbol (Diagram
1, below) can carry voltages which are hazardous if they are made
contact with. Before the unit is switched on, the loudspeaker should
therefore only be connected using the lead recommended by the
manufacturer.

• Where possible, all plugs on connection cables must be screwed or
locked onto the casing.

• Replace fuses only with IEC127 type and specified ratings.

• It is not permitted to use repaired fuses or to short-circuit the fuse
holder.

• Never interrupt the protective conductor connection.

• Surfaces which are equipped with the "HOT" mark (Diagram 2,
below), rear panels or covers with cooling slits, cooling bodies and
their covers, as well as tubes and their covers are purposely designed
to dissipate high temperatures and should therefore not be touched.

• High loudspeaker levels can cause permanent hearing damage. You
should
therefore avoid the direct vicinity of loudspeakers operating at high
levels.
Wear hearing protection if continuously exposed to high levels.

MAINS CONNECTION:

• The unit is designed for continuous operation.

• The set operating voltage must match the local mains supply voltage.

• The unit is connected to the mains via the supplied power unit or
power cable.

• Power unit: Never use a damaged connection lead. Any damage must
be rectified by a competent technician.

•Avoid connection to the mains supply in distributor boxes together
with several other power consumers.

• The plug socket for the power supply must be positioned near the
unit and must be easily accessible.

PLACE OF INSTALLATION:

• The unit should stand only on a clean, horizontal working surface.

• The unit must not be exposed to vibrations during operation.

• Keep away from moisture and dust where possible.

• Do not place the unit near water, baths, wash basins, kitchen sinks,
wet areas, swimming pools or damp rooms. Do not place objects
containing liquid on the unit - vases, glasses, bottles etc.

• Ensure that the unit is well ventilated.

• Any ventilation openings must never be blocked or covered. The unit
must be positioned at least 20 cm away from walls. The unit may only
be fitted in a rack if adequate ventilation is ensured and if the manu­facturer's installation instructions are followed.

• Keep away from direct sunlight and the immediate vicinity of heating
elements and radiant heaters or similar devices.

• If the unit is suddenly moved from a cold to a warm location,
condensation can form inside it. This must be taken into account
particularly in the case of tube units. Before switching on, wait until
the unit has reached room temperature.

• Accessories: Do not place the unit on an unsteady trolley, stand,
tripod, base or table. If the unit falls down, it can cause personal
injury and itself become damaged. Use the unit only with the trolley,
rack stand, tripod or base recommended by the manufacturer or
purchased together with the unit. When setting the unit up, all the
manufacturer's instructions must be followed and the setup
accessories recommended by the manufacturer must be used. Any
combination of unit and stand must be moved carefully. A sudden
stop, excessive use of force and uneven floors can cause the
combination of unit and stand to tip over.

• Additional equipment: Never use additional equipment which has not
been recommended by the manufacturer as this can cause accidents.

•To protect the unit during bad weather or when left unattended for
prolonged periods, the mains plug should be disconnected. This
prevents the unit being damaged by lightning and power surges in
the AC mains supply.

Diagram 1 Diagram 2

• Das Gerät wurde von HK AUDIO®gemäß IEC 60065 gebaut und hat das
Werk in sicherheitstechnisch einwandfreiem Zustand verlassen. Um diesen
Zustand zu erhalten und einen gefahrlosen Betrieb sicherzustellen, muss
der Anwender die Hinweise und die Warnvermerke beachten, die in der Be­dienungsanleitung enthalten sind. Das Gerät entspricht der Schutzklasse I
(schutzgeerdet).

• DIE SICHERHEIT, ZUVERLÄSSIGKEIT UND LEISTUNG DES GERÄTES
WIRD VON HK AUDIO

®

NUR DANN GEWÄHRLEISTET, WENN:

• Montage, Erweiterung, Neueinstellung, Änderungen oder Reparaturen von
HK AUDIO

®

oder von dazu ermächtigten Personen ausgeführt werden.

• die elektrische Installation des betreffenden Raumes den Anforderungen
von IEC (ANSI)-Festlegungen entspricht.

• das Gerät in Übereinstimmung mit der Gebrauchsanweisung verwendet
wird.

WARNUNG:

•Wenn Abdeckungen geöffnet oder Gehäuseteile entfernt werden, außer
wenn dies von Hand möglich ist, können Teile freigelegt werden, die
Spannung führen.

•Wenn ein Öffnen des Gerätes erforderlich ist, muss das Gerät von allen
Spannungsquellen getrennt sein. Berücksichtigen Sie dies vor dem
Abgleich, vor einer Wartung, vor einer Instandsetzung und vor einem
Austausch von Teilen.

• Ein Abgleich, eine Wartung oder eine Reparatur am geöffneten Gerät unter
Spannung darf nur durch eine vom Hersteller autorisierte Fachkraft (nach
VBG 4) geschehen, die mit den verbundenen Gefahren vertraut ist.

• Lautsprecher-Ausgänge, die mit dem IEC 417/5036-Zeichen (Abb.1, s.
unten) versehen sind können berührungsgefährliche Spannungen führen.
Deshalb vor dem Einschalten des Gerätes Verbindung nur mit dem vom
Hersteller empfohlenen Anschlusskabel zum Lautsprecher herstellen.

• Alle Stecker an Verbindungskabeln müssen mit dem Gehäuse verschraubt
oder verriegelt sein, sofern möglich.

• Es dürfen nur Sicherungen vom Typ IEC 127 und der angegebenen
Nennstromstärke verwendet werden.

• Eine Verwendung von geflickten Sicherungen oder Kurzschließen des
Halters ist unzulässig.

• Niemals die Schutzleiterverbindung unterbrechen.

• Oberflächen, die mit dem "HOT"-Zeichen (Abb.2, s.unten) versehen sind,
Rückwände oder Abdeckungen mit Kühlschlitzen, Kühlkörper und deren
Abdeckungen, sowie Röhren und deren Abdeckungen können im Betrieb
erhöhte Temperaturen annehmen und sollten deshalb nicht berührt wer­den.

• Hohe Lautstärkepegel können dauernde Gehörschäden verursachen.
Vermeiden Sie deshalb die direkte Nähe von Lautsprechern, die mit hohen
Pegeln betrieben werden. Verwenden Sie einen Gehörschutz bei dauernder
Einwirkung hoher Pegel.

NETZANSCHLUSS:

• Das Gerät ist für Dauerbetrieb ausgelegt.

• Die eingestellte Betriebsspannung muss mit der örtlichen Netzspannung
übereinstimmen.

• Der Anschluss an das Stromnetz erfolgt mit dem mitgelieferten Netzteil
oder Netzkabel.

• Netzteil: Eine beschädigte Anschlussleitung kann nicht ersetzt werden.
Das Netzteil darf nicht mehr betrieben werden.

•Vermeiden Sie einen Anschluss an das Stromnetz in Verteilerdosen
zusammen mit vielen anderen Stromverbrauchern.

• Die Steckdose für die Stromversorgung muss nahe am Gerät angebracht
und leicht zugänglich sein.

AUFSTELLUNGSORT:

• Das Gerät sollte nur auf einer sauberen, waagerechten Arbeitsfläche ste­hen.

• Das Gerät darf während des Betriebs keinen Erschütterungen ausgesetzt
sein.

•Feuchtigkeit und Staub sind nach Möglichkeit fernzuhalten.

• Das Gerät darf nicht in der Nähe von Wasser, Badewanne, Waschbecken,
Küchenspüle, Nassraum, Swimmingpool oder feuchten Räumen betrieben
werden. Keine mit Flüssigkeit gefüllten Gegenstände -Vase, Gläser,
Flaschen etc. auf das Gerät stellen.

• Sorgen Sie für ausreichende Belüftung der Geräte.

•Eventuelle Ventilationsöffnungen dürfen niemals blockiert oder abgedeckt
werden. Das Gerät muß mindestens 20 cm von Wänden entfernt aufgestellt
werden. Das Gerät darf nur dann in ein Rack eingebaut werden, wenn für
ausreichende Ventilation gesorgt ist und die Einbauanweisungen des
Herstellers eingehalten werden.

•Vermeiden Sie direkte Sonneneinstrahlung sowie die unmittelbare Nähe
von Heizkörpern und Heizstrahlern oder ähnlicher Geräte.

•Wenn das Gerät plötzlich von einem kalten an einen warmen Ort gebracht
wird, kann sich im Geräteinnern Kondensfeuchtigkeit bilden. Dies ist insbe­sondere bei Röhrengeräten zu beachten. Vor dem Einschalten solange war­ten bis das Gerät Raumtemperatur angenommen hat.

• Zubehör: Das Gerät nicht auf einen instabilen Wagen, Ständer, Dreifuß,
Untersatz oder Tisch stellen. Wenn das Gerät herunterfällt, kann es Perso­nenschäden verursachen und selbst beschädigt werden. Verwenden Sie das
Gerät nur mit einem vom Hersteller empfohlenen oder zusammen mit
dem Gerät verkauften Wagen, Rack, Ständer, Dreifuß oder Untersatz. Bei
der Aufstellung des Gerätes müssen die Anweisungen des Herstellers be­folgt und muss das vom Hersteller empfohlene Aufstellzubehör verwendet
werden. Eine Kombination aus Gerät und Gestell muss vorsichtigt bewegt
werden. Plötzliches Anhalten, übermäßige Kraftanwendung und ungleich­mäßige Böden können das Umkippen der Kombination aus Gerät und Ge­stell bewirken.

• Zusatzvorrichtungen: Verwenden Sie niemals Zusatzvorrichtungen, die
nicht vom Hersteller empfohlen wurden, weil dadurch Unfälle verursacht
werden können

• Zum Schutz des Gerätes bei Gewitter oder wenn es längere Zeit nicht
beaufsichtigt oder benutzt wird, sollte der Netzstecker gezogen werden.
Dies verhindert Schäden am Gerät aufgrund von Blitzschlag und
Spannungsstößen im Wechselstromnetz.

Abb.1 Abb.2

Important Safety Instructions

Before connecting, read instructions

Important Advice on Safety!

Please read before use and keep for later use!

• L'appareil a été conçu par HK AUDIO®selon la norme IEC 60065 et a
quitté l'entreprise dans un état irréprochable. Afin de conserver cet
état et d'assurer un fonctionnement sans danger de l'appareil nous
conseillons à l'utilisateur la lecture des indications de sécurité con­tenues dans le mode d'emploi. L'appareil est conforme à la classifica­tion I (mise à terre de protection).

• SURETE, FIABILITE ET EFFICACITE DE L'APPAREIL NE SONT
GARANTIS PAR HK AUDIO®QUE SI:

• Montage, extension, nouveau réglage, modification ou réparation
sont effectués par HK AUDIO®ou par toute personne autorisée par
HK AUDIO®.

• L'installation électrique de la pièce concernée correspond aux normes
IEC (ANSI).

• L'utilisation de l'appareil suit le mode d'emploi.

AVERTISSEMENT:

•A moins que cela ne soit manuellement possible, tout enlèvement ou
ouverture du boîtier peut entrainer la mise au jour de pieces sous
tension.

• Si l'ouverture de l'appareil est nécessaire, celui-ci doit être coupé de
chaque source de courant. Ceci est à prendre en considération avant
tout ajustement, entretien, réparation ou changement de pieces.

• Ajustement, entretien ou réparation sur l'appareil ouvert et sous
tension ne peuvent être éffectués que par un spécialiste autorisé par
le fabricant (selon VBG4). Le spécialiste étant conscient des dangers
liés à ce genre de réparation.

• Les sorties de baffles qui portent le signe IEC 417/5036 (fig. 1, voir en
bas) peuvent être sous tension dangereuse. Avant de brancher
l'appareil utiliser uniquement le câble de raccordement conseillé par
le fabricant pour raccorder les baffles.

•Toutes les prises des câbles de raccordement doivent être, si possible,
vissées ou verrouillées sur le boîtier.

•L’utilisation de fusibles rafistolés ou court-circuites est inadmissible –
seulement: IEC127.

• L'utilisation de fusibles rafistolés ou court-circuites est inadmissible.

• Ne jamais interrompre la connexion du circuit protecteur.

• Il est conseillé de ne pas toucher aux surfaces pourvues du signe
"HOT" (fig. 2, voir en bas), aux parois arrières ou caches munis de
fentes d'aération, éléments d'aération et leurs caches ansi qu'aux
tubes et leurs caches.
Ces éléments pouvant atteindre des températures élévées pendant
l'utilisation de l'appareil.

• Les Niveaux de puissance élévés peuvent entrainer des lésions
auditives durables. Evitez donc la proximité de haut-parleurs utilisés à
haute puissance. Lors de haute puissance continue utilisez une
protection auditive.

BRANCHEMENT SUR LE SECTEUR:

• L'appareil est conçu pour une utilisation continue.

• La tension de fonctionnement doit concorder avec la tension secteur
locale.

• Le raccordement au réseau éléctrique s'effectue avec l'adaptateur ou
le cordon d´alimentation livré avec l'appareil.

• Adaptateur: Un câble de raccordement abimé ne peut être remplacé.
L'adaptateur est inutilisable.

•Evitez un raccordement au réseau par des boîtes de distribution
surchargées.

• La prise de courant doit être placée à proximité de l'appareil et facile
à atteindre.

LIEU D'INSTALLATION:

• L'appareil doit être placé sur une surface de travail propre et
horizontale.

• L'appareil en marche ne doit en aucun cas subir des vibrations.

•Evitez dans la mesure du possible poussière et humidité.

• L'appareil ne doit pas être placé à proximité d'eau, de baignoire,
lavabo, évier, pièce d'eau, piscine ou dans une pièce humide. Ne
placez aucun vase, verre, bouteille ou tout objet rempli de liquide sur
l'appareil.

• L'appareil doit être suffisamment aéré.

• Ne jamais recouvrir les ouvertures d'aération. L'appareil doit être
placé à 20 cm du mur au minimum. L'appareil peut être monté dans
un Rack si une ventilation suffisante est possible et si les conseils de
montage du fabricant sont suivis.

•Evitez les rayons de soleil et la proximité de radiateurs, chauffages
etc.

• Une condensation d'eau peut se former dans l'appareil si celui-ci est
transporté brusquement d'un endroit froid à un endroit chaud. Ceci
est particulièrement important pour des appareils à tubes. Avant de
brancher l'appareil attendre qu'il ait la température ambiante.

• Accessoires: L'appareil ne doit être placé sur un chariot, support,
trépied, bâti ou table instable. Une chute de l'appareil peut entrainer
aussi bien des dommages corporels que techniques. Utilisez
l'appareil uniquement avec un chariot, Rack, support, trépied ou bâti
conseillé par le fabricant ou vendu en combinaison avec l'appareil.
Les indications du fabricant pour l'installation de l'appareil sont à
suivre, et les accessoires d'installation conseillés par le fabricant sont
à utiliser. Un ensemble support et appareil doit être déplacé avec
précaution.
Des mouvements brusques et des revêtements de sol irreguliers
peuvent entrainer la chute de l´ensemble.

• Equipements supplémentaires: Ne jamais utiliser un équipement
supplémentaire n'ayant pas été conseillé par le fabricant, ceci
pouvant entrainer des accidents.

• Afin de protéger l'appareil pendant un orage ou s'il ne doit pas être
utilisé pendant un certain temps, il est conseillé d'enlever la prise au
secteur.
Ceci évite des dommages dûs à la foudre ou à des coups de tension
dans le
réseau à courant alternatif.

Fig. 1 Fig. 2

• L'apparecchio è stato costruito dalla HK AUDIO®secondo la normativa
europea IEC 60065 ed ha lasciato il nostro stabilimento in stato
ineccepibile. Per garantire il mantenimento di tale stato e un utilizzo
assolutamente privo di rischi l'utente è tenuto ad osservare le indicazio­ni e gli avvertimenti di sicurezza contenuti nelle istruzioni per l'uso.
L'apparecchio rispecchia il livello di sicurezza I (collegato a terra).

• Sicurezza, affidabilità e prestazioni dell'apparecchio vengono garantiti
dalla
HK AUDIO

®

solo ed esclusivamente se:

• Montaggio, ampliamento, rimessa a punto, modifiche e riparazioni
vengono eseguite dalla HK AUDIO

®

stessa o da personale da essa

autorizzato.

• Gli impianti elettrici nei locali prescelti per l'uso dell'apparecchio
rispondono alle normative stabilite dall'ANSI.

• L'apparecchio viene utilizzato come indicato nel libretto delle istruzioni
per l'uso.

Avvertimenti:

• In caso di apertura di parti di rivestimento o rimozione di parti
dell'involucro,
a meno che non si tratti di pezzi rimovibili semplicemente a mano,
possono venire alla luce parti dell'apparecchio conduttrici di tensione.

• Se l'apertura dell'apparecchio dovesse risultare necessaria è indispens­abile staccare precedentemente quest'ultimo da tutte le fonti di tensio­ne. Rispettare tale misura di prevenzione anche prima di un allineamen­to, di operazioni di manutenzione, della messa in esercizio o della
sostituzione di componenti
all'interno dell'apparecchio.

• Allineamento, operazioni di manutenzione o eventuali riparazioni
dell'apparecchio in presenza di tensione vanno eseguite esclusivamente
da personale specializzato ed autorizzato, in grado di eseguire tali
operazioni evitandone
i rischi connessi.

• Le uscite degli altoparlanti contrassegnate dai caratteri IEC 417/5036
(vedi illustrazione 1 a fondo pag.) possono essere conduttrici di tensione
pericolosa con cui evitare il contatto. Per questo motivo, prima di
accendere l'apparecchio, collegare quest'ultimo agli altoparlanti serven­dosi esclusivamente del cavetto d'allacciamento indicato dal produttore.

•Tutte le spine e i cavi di collegamento devono essere avvitati o fissati
all'involucro dell'apparecchio per quanto possibile.

• Utilizzare esclusivamente fusibili del tipo IEC 127 con la indicata
corrente nominale.

• L'utilizzo di fusibili di sicurezza non integri e la messa in corto circuito
del sostegno di metallo sono proibite.

• Non interrompere mai il collegamento con il circuito di protezione.

• Superfici contrassegnate dalla parola "HOT" (vedi illustrazione 2 a fondo
pag.), cosi come griglie di aerazione, dispositivi di raffreddamento e i
loro rivestimenti di protezione, oppure valvole e i relativi rivestimenti
protettivi possono surriscaldarsi notevolmente durante l'uso e per
questo motivo non vanno toccate.

• L'ascolto di suoni ad alto volume può provocare danni permanenti
all'udito. Evitate perciò la diretta vicinanza con altoparlanti ad alta
emissione di suono
e utilizzate cuffie protettive in caso ciò non sia possibile.

Alimentazione:

• L'apparecchio è concepito per il funzionamento continuo.

• La tensione di esercizio deve corrispondere alla tensione di rete a cui ci
si allaccia.

• L'allacciamento alla rete elettrica avviene tramite alimentatore o cavetto
d'alimentazione consegnato insieme all'apparecchio.

• Alimentatore: un cavo di connessione danneggiato non può essere
sostituito. L'alimentatore non può più essere utilizzato.

•Evitate un allacciamento alla rete di corrente utilizzando cassette di
distribuzione sovraccariche.

• La spina di corrente deve essere situata nelle vicinanze dell'apparecchio
e facilmente raggiungibile in qualsiasi momento.

Locali di collocamento:

• Opportuno collocare l'apparecchio su una superficie pulita e orizzontale.

• Non sottoporre l'apparecchio in funzione a scosse e vibrazioni.

• Proteggere l'apparecchio per quanto possibile da umidità e polvere.

• Non collocare l'apparecchio vicino ad acqua, vasche da bagno, lavandini,
lavelli da cucina, locali umidi o piscine. Non appoggiare recipienti
contenenti liquidi - vasi, bicchieri, bottiglie, ecc. - sull'apparecchio.

• Provvedere ad una buone aerazione dell'apparecchio.

•Eventuali aperture previste per la ventilazione dell'apparecchio non
vanno ne bloccate, ne mai coperte. L'apparecchio va collocato ad almeno
20 cm di distanza dalle pareti circostanti e può essere inserito tra altre
componenti di un impianto solo in caso di sufficiente ventilazione e
qualora le direttive di montaggio del produttore vengano rispettate.

•Evitare di esporre l'apparecchio ai raggi del sole e di collocarlo diretta­mente nelle vicinanze di fonti di calore come caloriferi, stufette, ecc.

• Se l'apparecchio viene trasportato rapidamente da un locale freddo ad
uno riscaldato può succedere che al suo interno si crei della condensa.
Ciò va tenuto in considerazione soprattutto in caso di apparecchi a
valvole. Attendere che l'apparecchio abbia assunto la temperatura
ambiente prima di accenderlo.

• Accessori: non collocare l'apparecchio su carrelli, supporti, treppiedi, su­perfici o tavoli instabili. Se l'apparecchio dovesse cadere a terra potrebbe
causare danni a terzi o danneggiarsi irreparabilmente. Utilizzate per il
collocamento dell'apparecchio supporti, treppiedi e superfici che siano
consigliate dal produttore o direttamente comprese nell'offerta di
vendita. Per il collocamento dell'apparecchio attenetevi strettamente alle
istruzioni del produttore, utilizzando esclusivamente accessori da esso
consigliati. L'apparecchio in combinazione ad un supporto va spostato
con molta attenzione. Movimenti bruschi o il collocamento su pavimenti
non piani possono provocare la caduta dell'apparecchio e del suo
supporto.

• Accessori supplementari: non utilizzate mai accessori supplementari che
non siano consigliati dal produttore, potendo essere ciò causa di inci­denti.

• Per proteggere l'apparecchio in caso di temporali o nel caso questo non
venisse utilizzato per diverso tempo si consiglia di staccarne la spina di
corrente.
In questo modo si evitano danni all'apparecchio dovuti a colpi di fulmine
o ad improvvisi aumenti di tensione nel circuito di corrente alternata.

Illustrazione 1 Illustrazione 2

• El aparato ha sido producido por HK AUDIO

®

según el IEC 60065 y salió
de la fábrica en un estado técnicamente perfecto. Para conservar este
estado y asegurar un funcionamiento sin peligros el usuario debe tener
en cuenta las indicaciones y advertencias contenidas en las instrucciones
de manejo.
El aparato corresponde a la clase de protección l (toma de tierra protegi­da).

• LA SEGURIDAD, LA FIABILIDAD Y EL RENDIMIENTO DEL APARATO
SOLO ESTAN GARANTIZADOS POR HK AUDIO

®

CUANDO:

• el montaje, la ampliación, el reajuste, los cambios o las reparaciones se
realicen por HK AUDIO

®

o por personas autorizadas para HK AUDIO®;

• la instalación eléctrica del recinto en cuestión corresponda a los
requisitos
de la determinación del IEC (ANSI);

• el aparato se use de acuerdo con las indicaciones de uso.

ADVERTENCIA:

• Si se destapan protecciones o se retiran piezas de la carcasa,
exceptuando si se puede hacer manualmente, se pueden dejar piezas al
descubierto que sean conductoras de tensión.

• Si es necesario abrir el aparato, éste tiene que estar aislado de todas las
fuentes de alimentación. Esto se debe tener en cuenta antes del ajuste,
de un entretenimiento, de una reparación y de una sustitución de las
piezas.

• Un ajuste, un entretenimiento o una reparación en el aparato abierto y
bajo tensión sólo puede ser llevado a cabo por un especialista auto­rizado por el productor (según VBG 4) que conozca a fondo los peligros
que ello conlleva.

• Las salidas de altavoces que estén provistas de la característica IEC
417/5036 (figura 1, véase abajo) pueden conducir tensiones peligrosas al
contacto. Por ello es indispensable que antes de poner en marcha el
aparato; la conexión se haya realizado únicamente con el cable de
empalmes recomendado por el productor.

• Las clavijas de contacto al final de los cables conectores tienen que estar
atornilladas o enclavadas a la carcasa, en tanto que sea posible.

• Sólo se pueden utilizar fusibles del tipo IEC 127 con la intensidad de
corriente nominal indicada.

• El uso de fusibles reparados o la puesta en cortocircuito del soporte es
inadmisible.

• El empalme del conductor de protección no se puede interrumpir en
ningún caso.

• Las superficies provistas de la característica "HOT" (figura 2, véase
abajo),
los paneles de fondo trasero o las protecciones con ranuras de ventila­ción, los cuerpos de ventilación y sus protecciones, así como las válvulas
electrónicas y sus protecciones pueden alcanzar temperaturas muy altas
durante el funcionamiento y por ello no se deberían tocar.

• Niveles elevados de la intensidad de sonido pueden causar continuos
daños auditivos; por ello debe evitar acercarse demasiado a altavoces
que funcionen
a altos niveles. En tales casos utilice protecciones auditivas.

ACOMETIDA A LA RED:

• El aparato está proyectado para un funcionamiento continuo.

• La tensión de funcionamiento ajustada tiene que coincidir con la tensión
de la red del lugar.

• La conexión a la red eléctrica se efectuará con la fuente de alimentación
o con el cable de red que se entreguen con el aparato.

•Fuente de alimentación: una linea de conexión dañada no se puede
sustituir.
La fuente de alimentación no puede volver a ponerse en funcionamiento.

•Evite una conexión de la red eléctrica a distribuidores con muchas tomas
de corriente.

• El enchufe para el suministro de corriente tiene que estar cerca del apa­rato
y ser de fácil acceso.

SITUACION:

• El aparato debería estar situado en una superficie limpia y totalmente
horizontal.

• El aparato no puede estar expuesto a ningún tipo de sacudidas durante
su funcionamiento.

• Se deben evitar la humedad y el polvo.

• El aparato no puede ponerse en funcionamiento cerca del agua, la
bañera, el lavamanos, la pila de la cocina, un recinto con tuberías de
agua, la piscina o en habitaciones húmedas. Tampoco se pueden poner
objetos llenos de líquido - jarrones, vasos, botellas, etc. - encima de él.

• Procure que el aparato tenga suficiente ventilación.

• Las aberturas de ventilación existentes no se deben bloquear ni tapar
nunca.
El aparato debe estar situado como mínimo a 20 cm de la pared. El apa­rato sólo se puede montar en un rack, si se ha procurado la suficiente
ventilación y se han cumplido las indicaciones de montaje del productor.

•Evite los rayos del sol directos así como la proximidad a radiadores, elec­tro-radiadores o aparatos similares.

• Si el aparato pasa repentinamente de un lugar frío a otro caliente, se pu­ede condensar humedad en su interior. Esto se debe tener en cuenta
sobretodo en los aparatos con válvulas electrónicas. Antes de poner en
marcha el aparato se debe esperar hasta que éste haya adquirido la tem­peratura ambiental.

• Accesorios: el aparato no se puede colocar encima de carros, estantes,
trípodes, soportes o mesas inestables. Si el aparato se cae puede causar
daños personales y se puede estropear. Coloque el aparato sólo en un
carro, rack, estante, trípode o soporte recomendado por el productor o
que se le haya vendido junto con el aparato. En la instalación se deben
seguir las indicaciones del productor así como utilizar los accesorios re­comendados por el mismo para colocarlo encima. El conjunto del apara­to con el pedestal se debe mover con mucho cuidado. Un paro brusco, la
aplicación de una fuerza desmesurada o un suelo irregular puede ocasio­nar la caida de todo el conjunto.

• Piezas adicionales: no utilice nunca piezas adicionales que no estén re­comendadas por el productor, ya que se podrían provocar accidentes.

• Para protejer el aparato de una tormenta o si no se supervisa ni utiliza
durante algún tiempo, se debería desconectar la clavija de la red. Así se
evitan daños en el aparato a causa de un rayo y golpes de tensión en la
red de corriente alterna.

Figura 1 Figura 2

Conseils de Securite Importants!

Priere de lire avant l'emploi et a conserver pour uti­lisation ulterieure!

Importanti avvertimenti di sicurezza!

Leggere attentamente prima dell'uso e conservare per
un utilizzo successivo:

¡Indicaciones de seguridad importantes!

¡Léanse antes de utilizar el aparato y guardense para
so uso posterior!

Table of Contents

A Notes on Rigging Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

1Warranty and Liability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2 Notes on Safety for the HK Audio CT 112 and CT 115 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.1 Responsibilities of the Operator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.2 Maintenance, Inspection and Repair of ConTour Series™ Rigging Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.3 Technical Specifications of ConTour Series™ Rigging Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5

2.4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2.5 Maximum Number of Flown CT 112/ CT 115 Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2.6 Structural Modifications of ConTour Series™ Rigging Hardware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2.7 Original HK AUDIO®Accessories: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

2.8 Initiation and Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

B ConTour Series™ Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1 CT 108 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.1 Directivity, CT 108 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.2 Adjusting Directivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.3 Specifications, CT 108 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

1.4 Technical Data, CT 108 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8

2 CT 112 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

2.1 Directivity, CT 112 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

2.2 Adjusting Directivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

2.3 Shape and Mode Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

2.4 Specifications, CT 112 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9

2.5 Technical Data, CT 112 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

3 CT 115 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.1 Directivity, CT 115 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.2 Adjusting Directivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.3 Shape and Mode Switches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.4 Specifications, CT 115 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

3.5 Technical Data, CT 115 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12

4 CT 118 Sub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

4.1 Optional Passive Crossover for the CT 118 Sub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

4.2 Specifications, CT 118 Sub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

4.3 Technical Data, CT 118 Sub: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

C Rigging ConTour Series™ CT 108/ CT 112/ CT 115 Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1.1 Flying Enclosures with Cables or Chains . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1.2 Mounting Yoke for CT 112 and CT of 115 Enclosures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15

1.3 MS/1, MS/2, MS/3 Mounting Set for the CT 108 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

D ConTour Series™ Controller Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

E Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

1ConTour Series™ Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

2 Replacing Loudspeakers and Voice Coils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

2.1 8", 12", 15" and 18" Speakers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

2.2 The Drivers’ Voice Coils . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

ConTour Series 1.0

Index of Figures:

Fig. 1: CT 108 7

Fig. 2: Vertical directivity CT 108 7

Fig. 3: Horizontal directivity CT 108 7

Fig. 4: CT 108 housing dimensions in [mm] 8

Fig. 5: Frequency response CT 108 8

Fig. 6: CT 112 9

Fig. 7: Vertical directivity CT 112 9

Fig. 8: Horizontal directivity CT 112 9

Fig. 9: Monitor and Shape switches 9

Fig. 10: CT 112 housing dimensions in [mm] 10

Fig. 11: Frequency response CT 112 10

Fig. 12: CT 115 11

Fig. 13: Vertical directivity CT 115 11

Fig. 14: Horizontal directivity CT 115 11

Fig. 15: Monitor and Shape switches 11

Fig. 16: CT 115 housing dimensions in [mm] 12

Fig. 17: Frequency response CT 115 12

Fig. 18: CT 118 Sub 13

Fig. 19: Passive crossover for the CT 118 Sub 13

Fig. 20: CT 118 Sub housing dimensions in [mm] 14

Fig. 21: Frequency response CT 118 Sub 14

Fig. 22: The rigging track in the lid 15

Fig. 23: Attaching the rigging cable 15

Fig. 24: Inserting studs 15

Fig. 25: Attaching mounting yokes to CT 112 and CT 115 enclosures 15

Fig. 26: Attaching the EB 10 eyebolt and arrest wire 15

Fig. 27 a, b: Attaching the MS/1 yoke to the CT 108 16

Fig. 28: MS/1 mounting yoke CT 108 16

Fig. 28: MS/2 pole mount 16

Fig. 30: MS/3 TV stud 16

Fig. 31: DSM 2060 Digital Controller 17

Fig. 32: CT 112 sans grille 18

5

Please read these instructions carefully before
you begin setting up the system!

1 Warranty and

Liability

HK AUDIO®shall not be held responsible for
damages due to improper use or non-compliance
with the safety specifications for setup and
operation.
All warranty and liability claims for personal injury
and property damages are excluded if attributable
to one or several of the following:

• non-compliance with operating manual
instructions, voiding product liability and
warranty claims

• unintended use of rigging frames

• non-compliance with operating manual instruc­tions regarding transportation, storage, initial
setup, operation, maintenance and repair

• unauthorized structural modifications perfor­med on rigging hardware

• unauthorized modification of the parameters in­dicated in the operating manual

• inadequate or improper repairs

2 Notes on Safety for

the HK Audio

®

CT 112

and CT 115

The ConTour Series™ Rigging System’s provisions
for use require that it be installed in accordance
with the following specifications. Before you
begin installation, ensure that the pick points (for
example, a chain hoist) on the stage roof or the
venue’s ceiling comply with BGV-C1 accident pre­vention regulations and that the safety standards
authority TÜV has certified them for the full load.
Prior to every installation, inspect all components
to ensure they are in good working order, taking
particular care to confirm that all Aeroquip tracks
and connecting components (cables, fittings) are
undamaged.

Use only the parts specified in this operating
manual! Be sure to protect cabinets against rain
and moisture when they are deployed outdoors.
These enclosures must be mounted in accordance
with the instructions stipulated in this installation
manual. Keep all documents pertaining to the
system in a safe place.

The principle requirement for safe handling and
trouble-free operation of this rigging system is a
thorough understanding of fundamental
operating safety and safety regulations.
This operating manual contains the most vital
instructions concerning the safe operation of
CT 112 and CT 115 enclosures.

2.1 Responsibilities of the Operator

As the operator, you are obligated to allow
only those persons to work with rigging frames
who are

• 16 years of age or older,

• physically and mentally able, familiar with the
basic rules of industrial safety and accident
prevention, and trained in the handling of
rigging systems.

Be sure to regularly review and confirm
personnel’s working safety awareness.
In addition, task personnel with specific responsi­bilities for setting up, putting into service,
operating, maintaining, and repairing equipment.
Ensure that personnel are trained to work with the

rigging system only under the supervision of a
proficient and experienced technician. Ensure also
that defects, flaws and other damage that could
impede safety are repaired immediately.

2.2 Maintenance, Inspection and Repair of
HK AUDIO®ConTour Series™
Rigging Hardware

Inspections

§ 39, VBG 9a of the German employers’ liability

insurance association’s accident prevention
regulations requires that load-bearing equipment
be inspected by a qualified expert and possible
defects be eliminated prior to initial commissio­ning by the recipient.

§ 40, VBG 9a requires that load-bearing equip-

ment be inspected at least annually for cracks.
When used in dynamic applications, equipment
must be inspected for cracks every six months.

Maintenance

You are authorized to replace easily serviceable
wearing or standard parts in accordance with the
manufacturer’s instructions. Use original parts for
this purpose.
Tighten screws and bolted connections whenever
necessary.

Repair

In the event that parts of the load-bearing
equipment have been deformed, it is up to the
manufacturer to determine if they are repairable.
Solely the manufacturer is authorized to perform
welding and repair work on load-bearing
equipment.

2.3 Technical Specifications of HK AUDIO

®

ConTour Series™ Rigging Hardware

Load-bearing capacity: 35 kg
Test load: 210 kg
Ambient temperature when in operation: min
–10° C, max + 60° C

A Notes on Rigging Safety

English

ConTour Series 1.0

Components:

Stud starter cable:
Steel-wire cable with a length of 270 mm,
including a stud and snap link for fastening the
speaker enclosure to the pick point on the stage
ceiling.

HK Audio®item number: 193 543

Arrest wire
Additional securing cable for flown CT 112/ CT 115
speakers; 4 mm in diameter, 100 cm in length,
including snap links

HK Audio®item number: 193643

EB 10 eyebolt

HK Audio®item number: 193673

2.4 Mounting

Attach the speaker enclosure to a pick point on
the Aeroquip track using a starter cable
comprising a snap link, a cable with the required
length, and a stud. One track is located on the
top of the housing for arraying the enclosure
vertically, and one is on the side for arraying the
enclosure horizontally.

Secure the speaker to prevent it from falling. To
this end, insert an HK AUDIO®EB 10 eyebolt into
the recessed thread on the rear of the CT 112 or
CT 115. Attach the arrest wire to the eyebolt and
transom.

Ensure the pick points are able to handle the
given load (a CT 112 with a starter cable weighs
approx. 27 kg; a CT 115 with a starter cable weighs
approx. 37 kg).

The position of the stud in the Aeroquip track
determines the cabinet’s angle of tilt. Since the
length of the cables used to attach the cabinets to
the rigging point (the ceiling of the venue, a
transom, a cross beam, etc.) will vary according
to the given venue’s mounting options, you must
adjust the length of the cables accordingly. If the
length of the HK AUDIO®starter cable does not
suffice, you can have cables made in the required
length by any certified cable manufacturer using
the following parts.

Snap link: Snap link with safety lock gate, 1 ton
load-carrying capacity, quality grade 8 (for
example: SOCS 6-8)
Stud: Aeroquip 5013 Series L Double Stud Fitting
(ISO 9788)

HK Audio®item number: 193195

Cable: Galvanized steel-wire cable, DIN 3060, Ø 6
mm, 1770 N/mm 2, sZ 6 x 19 + FE, calculated
breaking strength: 22.8 kN; minimum breaking
strength: 19.6 kN

2.5 Maximum Number of Flown CT 112/ CT 115
Enclosures

Mount no more than one CT 112 or CT 115
enclosure using this system. This applies to the
speaker in both vertical and horizontal array.

Caution: Flying more than one CT 112 / 115
cabinet in stacked array voids the operating
license!

2.6 Structural Modifications of ConTour Series™

Rigging Hardware

No structural modifications may be made without
the manufacturer’s consent. This also applies to
welding work performed on supporting parts.
Structural alterations require the manufacturer’s
written approval. Use original replacement and
wearing parts only.

2.7 Original HK AUDIO®Accessories:

Use original HK AUDIO®parts only! The safety
standards authority TÜV has not certified any
other parts for use! Always install parts in
accordance with these installation instructions!
Store all documents pertaining to the system in a
safe place!

2.8 Initiation and Operation

§ 39, VBG 9a of the German employers’ liability

insurance association‘s accident prevention
regulations requires that load-carrying equipment
be inspected by a qualified expert and possible
defects be eliminated prior to initial commissio­ning by the recipient.

§ 41 VBG 9a requires that load-carrying equip-

ment be subjected to a non-routine inspection
following damage, repair work and other
incidents that can affect load-carrying capacity.
