Huawei V735 User Manual

Make the most of now.

Vodafone 735 Mobile Phone

User Guide

Notice

Copyright © 2009 Huawei Technologies Co. Ltd.,

All Rights Reserved
Your phone is made exclusively for Vodafone by Huawei Technologies.
No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co. Ltd.,
Trademarks
VODAFONE, the Vodafone logos are trade marks of the Vodafone Group. Other product and company names mentioned herein may be trade marks of their respective owners.

Notice

The information in this manual is subject to change without notice. Every effort has been made in the preparation of this manual to ensure accuracy of the contents, but all statements, information, and recommendations in this manual do not constitute a warranty of any kind, expressed or implied.
Read the safety precautions and safety informations carefully to ensure that you use wireless device in a correct and safe manner.
Huawei Technologies Co. Ltd.,
Branch Address:
Huawei Technologies Deutschland GmbH, Am Seestern 24, Düsseldorf, Germany
Postal Code: 40547
Head Office Address:
Administration Building, Huawei Technologies Co. Ltd., Bantian, Longgang District, Shenzhen, P. R. China
Postal Code: 518129
Website: http://www.huawei.com

Safety Precautions

Read the Safety Information section of this user guide on page
43.
Do not use hand-held while driving
For body-worn operation maintain a separation of 1.5 cm
Small parts may cause a choking hazard
This device may produce a loud sound
Keep away from pacemakers and other personal medical devices
Do not use while re-fuelling
This device may produce a bright or flashing light
Do not dispose of in a fire
Avoid contact with magnetic media
Avoid Extreme Temperatures
Avoid contact with liquid, keep dry
Switch off when instructed in hospitals and medical facilities
Switch off when instructed in aircrafts and airports
Switch off in explosive environments
Do not try to disassemble
Do not rely on this device for emergency communications
Only use approved accessories
Contents
1.Introduction
Packing List . . . . . . . . . . . . . . . . . . . . 1
Your Phone . . . . . . . . . . . . . . . . . . . . 2
Security . . . . . . . . . . . . . . . . . . . . . . .10
Text Input . . . . . . . . . . . . . . . . . . . . . 11
2.Customized Settings
Phone Settings . . . . . . . . . . . . . . . .14
Display Settings . . . . . . . . . . . . . . .15
Network Settings . . . . . . . . . . . . . .15
3.Call Function
Managing Contacts . . . . . . . . . . .16
Viewing the Call Records . . . . . .18
Setting the Call Function . . . . . .18
Making or Ending a Call . . . . . . .20
Answering or Rejecting a Call . . 22
4.Message Function
Message . . . . . . . . . . . . . . . . . . . . . .23
Email . . . . . . . . . . . . . . . . . . . . . . . . . .24
5.Connection Function
Connectivity Settings . . . . . . . . .26
USB . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Bluetooth
®
. . . . . . . . . . . . . . . . . . .30
6.Entertainment Function
Music . . . . . . . . . . . . . . . . . . . . . . . . .35
Camera . . . . . . . . . . . . . . . . . . . . . . . .35
Web . . . . . . . . . . . . . . . . . . . . . . . . . . .36
Mobile TV . . . . . . . . . . . . . . . . . . . . .37
Video . . . . . . . . . . . . . . . . . . . . . . . . . .37
Games . . . . . . . . . . . . . . . . . . . . . . . .37
7.Business Function
Calendar Management . . . . . . . .38
Tool Applications . . . . . . . . . . . . . .39
File Management . . . . . . . . . . . . . .41
Application . . . . . . . . . . . . . . . . . . . .41
8.Safety Information
RF Exposure . . . . . . . . . . . . . . . . . . .43
Distraction . . . . . . . . . . . . . . . . . . . .46
Product Handling . . . . . . . . . . . . .47
Electrical Safety . . . . . . . . . . . . . . .50
Interference . . . . . . . . . . . . . . . . . . .51
Explosive environments . . . . . . .53
Environmental Protection . . . . .54
9.Appendix
Abbreviations . . . . . . . . . . . . . . . . .55
File Formats . . . . . . . . . . . . . . . . . . .56

1. Introduction

Your Phone can operate in virtually all countries, automatically switching between WCDMA 2100 and GSM/GPRS/EDGE 900/1800/1900 networks.

NOTE
: The services supported by your phone should be also supported by
the network from where you use the phone. For details, contact y our local Vodafone customer care centre. Note that you can also access informa­tion on Vodafone services at www.vodafone.com.

Packing List

Your phone package box contains the following:
1. One mobile phone
2. One charger connector
3. One Li-ion battery
4. One User Guide
5. One Quick Start Guide
6. One Stereo headset (Optional)
7. One USB cable
1

Your Phone

1
2
6
5
4
3

Your Phone

Appearance

1. Camera 2. Battery cover 3. Charger connector
4. Earpiece 5. Volume keys 6. Screen
/ Cable connector / Headset Jack
2
Your Phone
1
456
23

SIM Card and Memory Card

Load your SIM card before using your phone. And only unload the SIM card and the battery after power off your phone. To use the SIM card properly, please read the following instructions carefully.
NOTE
:
Keep the SIM card out of the reach of children.
The SIM card and its metal contacts can be easily damaged by scratching or bending. Ensure care when you carry , load or remove it.
Always disconnect the charger from the phone before loading or removing the SIM card.
To load or remove the SIM card, please according to the following figures.
3
Your Phone
Your phone supports a memory card (microSD) with a capacity up to 8 GB.
To load or remove the memory card, please remove the battery cove r. And then please according to the following figure.

Antenna

As with any radio transmitting device, av oid touching an antenna unneces­sarily when the antenna is in use. For example, avoid touching the cellular antenna during a phone call. Contact with a transmitting or receiving antenna affects the quality of the radio communication, may cause the device to operate at a higher power le vel than otherwise needed, and may reduce the battery life. The picture shows the antenna area marked in grey.
4
Your Phone

Charging the Battery

NOTE
:
When you charge the battery for the first time, please charge it for a minimum of 12 hours.
The battery discharges even while not being used. If you have not used it for a long time, please recharge it first.
The charging time depends on the environmental temperature and the age of the battery.
Do not strike, throw or cause any kind of violent shock to the battery, otherwise liquid leakage, body damage, ov erheating, fire or explosion may occur.
The battery can be recharged but eventually wears out. If the battery lasts for a shorter time period than usual after being charged normally, replace it with a battery of the same type.
Charge the battery by using the charger con nector and the USB cable supplied with your phone.
Before charging the battery, ensure that the battery has been properly loaded into your phone.
To charge the battery, first plug in the charger connector to a power socket, and then insert the plug of the cable into the connector of the phone as shown in the following figure.
5
Your Phone
2
1
NOTE
:
The plug of the cable is in trapezium shape. Reversely inserting the plug may damage the mobile phone and the charger. The connection methods of USB cable and headset are the same as the charger.
When the battery power level is very low, the phone makes alert sounds and displays a prompt. When the battery power level is too low, the phone will power off automatically.
When the battery is being charged, the charging indicator blinks continuously. When the charging indicator stops blinking, it indicates that the battery is full.

Keys

6
Your Phone
1
28
9
7 6
3 4
5
1. Scroll key
• Scroll through a menu.
• Access the corresponding shortcut menu in standby mode.
2. Left function key
3. Send key
• Activate the function indicated at the left of the prompt bar.
• Access the main menu in standby mode.
• Make or Answer a call.
• Enter the Calls screen in standby mode.
4. Music key Access the music menu in standby mode.
5. Number keys
Enter numbers or characters.
7
Your Phone
6. Clear key Delete a character before the cursor.
7. Power/End key
8. Right function key
9. OK key
• End an ongoing call or reject an incoming call.
• Return to the standby mode.
• Press and hold it to power on or power off the phone.
• Activate the function indicated at the right of the prompt bar.
• Access Vodafone live! in standby mode.
• Start the selected function in the menu.
• Access the main menu in standby mode.

Screen

1. Icon bar
2. Desktop
3. Prompt bar
8
Your Phone
1. Icon bar 2. Desktop 3. Prompt bar
The icon bar displays the phone status. The following table illustrates the icons that may appear on this bar.
Indicates signal strength. The normal profile is
activated.
Indicates power level of the battery.
The phone is currently in a GSM or WCDMA network.
The headset is plugged in.
Your PC connects to the Internet through your phone.
You are using the roaming service.
You have new text messages.
Bluetooth is enabled. You have new voice
mails.
Call line 2 is enabled currently.
You have new multimedia messages.
9

Security

Forwarding all incoming voice calls to line 1 or line 2.
Alarm clock is enabled. You have new Emails.
The phone is in a call.
You have new PUSH messages.

Security

Phone/SIM Card Security Settings

NOTE
:
For certain SIM cards, you need to enter the PIN2 code to use certain special functions.
If you enter a wrong PIN code or wrong PIN2 code for three consecu­tive attempts, the SIM card is locked. To unlock the SIM card, enter t he PIN Unblocking Key (PUK) code or PUK2 code.
The PIN code, PIN2 code, PUK code, or PUK2 code is provided together with the SIM card. For details, consult your service provider.
The initial phone password of the phone is 0000.
Select Settings > Security.
Reset your phone to the factory settings.
10

Text Input

Enable or disable the "Phone lock" and "PIN lock".
Modify the phone password and PIN code.
If your SIM card supports the Fixed Dialer Number (FDN) function, you can set the limit for phone numbers.

Digital Rights Management

Select Settings > License setting. Enter the correct phone password an d press OK key to confirm, and you can select roaming network or delete all licenses.
Digital Rights Management (DRM) can protect the digital content from piracy and protect the provider’s interests. The digital content includes Java applications and multimedia content such as images, audio and video. If the protected content cannot be accessed, it indicates that the corresponding license is overdue or used up.

Text Input

NOTE
: While entering text:
Press the * key to switch between input methods. Press and hold the * key to enable or disable the T9 input mode.
Press the # key to display the symbols list. Press and hold the # key to set the input language.
Press the clear key to delete the letter before the cursor.
Press repeatedly the * key and you will see "Abc", "abc" ,"ABC" or "123" on the upper left corner of the screen successively. It indicates the
11
Text Input
words to be entered will be in lower case, first letter capitalized or in upper case.
T9® Input Method
With the T9 input method, you can easily and quickly enter words. T9 is a predictive text entry mode. Press the relevant key that corresponds to the desired letter and T9 will offer you candidate words.
Press each key carrying the desired letter once, and then the predictive text scheme will present the candidate words composed by the letters you have entered in the drop-down menu.

Traditional Input Method

When T9 input method is off, you can use the traditional input method for entering alphabetic characters. Repeatedly press the key that carries the letter to be entered when it appears on the screen.

Number Input Method

In a text editing screen, press and hold the character/number keys to enter corresponding numeric characters.
You can also press successively the * key to switch to the "123" numeric input method, and enter corresponding numeric characters by pressing the character/number keys.
12
Text Input

Symbol Input Method

You can press the # key to display the symbols list and then select symbols to input.
You can also press the key with number 1 to input the commonly-used symbols in a text editing screen (except numeric input method).
13
