Huawei S7 301W User Guide

HUAWEI MediaPad

Quick Start

1 For More Help

For more help, go to http://www.huaweidevice.com to download the
To find the

User Guide

The figures in this guide are provided for your reference only. The appearance
and display features may vary slightly depending on the actual product version.

of your tablet quickly, enter MediaPad in the webpage search box.

2 MediaPad at a Glance

User Guide

.

187654321211109

1 Volume key 7 Speaker
2 Power button 8 Main camera
3 Light sensor 9 Microphone
4 Front camera 10 Micro-USB port
5 Headphone jack 11 HDMI port
6 Speaker 12 Charger port

1

3 Installing the microSD Card

1. Remove the battery cover.

2. Install the microSD card

3. Replace the battery cover.

Do not remove the cover for the main camera.

a

b

b

a

2

When charging your MediaPad's battery for the first time, charge it for at least 6
hours to ensure that your MediaPad displays the battery information correctly.

4 Switching Your MediaPad On or Off

Press and hold the Power button until your MediaPad vibrates to switch on your MediaPad.
The first time you switch on the tablet, complete the setup by following the on-screen
instructions.

To switch off your MediaPad, press and hold the Power button until the screen displays a
dialog box, and then touch

When the MediaPad is switched on or malfunctions, press and hold the Power
button for 10 seconds. After release, press and hold the Power button again until
your MediaPad vibrates, indicating that it is restarting.

OK

in the dialog box.

5 Locking the Screen

When your MediaPad is turned on, press the Power button to lock the screen.
If your MediaPad is idle for a preset period of time, the screen will lock

automatically.

6 Unlocking the Screen

1. Press the Power button to wake up the screen.

2. Drag the unlock icon to any point of the circle that is around the icon.

3

7 Navigation Icons

The following icons are commonly used on the Home screen or other application screens.
Touch the icons to perform more operations.

Touch... To...

Return to the previous screen.
Return to the Home screen.
Open the list of recently used applications.

8 Warnings and Precautions

To use the device properly and safely, read these warnings and precautions carefully and
strictly observe them during operation. Unless otherwise specified, the term "device" refers
to the device and its accessories.

Basic Requirements

During storage, transportation, and operation of the device, keep it dry and prevent
it from colliding with other objects.

Do not dismantle the device. In case of any fault, contact an authorized service
center for assistance or repair.

Without authorization, no organization or individual can change the mechanical,
safety, or performance design of the device.

When using the device, observe all applicable laws and regulations and respect the
legal rights of other people.

4

Environmental Requirements for Using the Device

Keep the device far from sources of heat and fire, such as a heater or a candle.
Keep the device far from electronic appliances that generate strong magnetic or

electric fields, such as a microwave oven or a refrigerator.
Place the device on a stable surface.
Place the device in a cool and well-ventilated indoor area. Do not expose the device

to direct sunlight.
Keep the ambient temperature between 0°C and 35°C while the device is being

charged. Keep the ambient temperature between 0°C to 35°C for using the device
powered by a battery.

Do not place any object (such as a candle or a water container) on the device. If any
foreign object or liquid enters the device, stop using the device immediately, power
it off, remove all the cables connected to it, and then contact an authorized service
center.

During thunderstorms, power off the device, and then remove all the cables
connected to it to prevent it from getting damaged due to lightning strikes.

Traffic Security

Observe local laws and regulations while using the device. In addition, if using the device
while driving a vehicle, comply with the following guidelines:

Concentrate on driving. Your first responsibility is to drive safely.
Do not talk on the device while driving. Use hands-free accessories.
When you have to make or answer a call, park the vehicle at the road side before

using your device.
RF signals may affect electronic systems of motor vehicles. For more information,

consult the vehicle manufacturer.
