Huawei S7 104 User Manual
Ideos Tablet S7
Quick Start
Contents
1
Packing list.......................................................... 1 7
2
Getting to know your Tablet ................................ 1
3
Installation........................................................... 2
3.1
To remove the back cover...................................... 2
3.2
To install the SIM card............................................ 3
3.3
To install the battery............................................... 3
3.4
To install the back cover......................................... 3
4
Turning the Tablet on or off .................................4
4.1
To turn the Tablet on .............................................. 4
4.2
PIN protection........................................................ 4
4.3
To turn the Tablet off............................................... 4
5
Charging the battery ...........................................5
6
Using the touchscreen ........................................ 5
Locking and unlocking the screen ...................... 6
7.1
To lock the screen...................................................6
7.2
To unlock the screen...............................................6
8
Setting date and time ..........................................6
9
Installing or removing the microSD card .............7
10
For more help.................................................... 7
11
Warnings and Precautions ................................8
i
1 Packing list 2 Getting to know your Tablet
The product package contains the following items.
S7Tablet
1 S7 Tablet
2 Stylus
3 Battery
4 Power adapter
5 USB cable
6 Quick start
If the items in the product package are not consistent with
hose in the packing list, contact the vendor. The figures and
t
operation descriptions in this guide are provided only for
reference, see the actual product for details.
1 Ambient light sensor
Home
key 2
Menu
key 3
Back
End
key 4
key 9
5 LCD screen
6 microSD card slot
7 Dock interface
8 Microphone
10 Power interface
1
11 Micro USB interface
OFN
(Optical Finger Navigation) key 12
Call
14 Speaker
15 LED indicator
16 Camera lens
key 13
3 Installation
3.1 To remove the back cover
To remove the back cover, refer to the following figure and steps.
23
22
Power
18 Bracket
19 Stylus jack
20 Camera lens
22 Speaker
23 Headset jack
key 17
Volume Up/Down
1. Unfold the bracket.
2. Open and remove the back cover.
key 21
To prevent injury, properly place the back cover after you
emove the back cover because it may have sharp edges and
r
angles.
2
3.2 To install the SIM card
Before installing or removing the SIM card, power off the
Tablet.
Insert your SIM card into the SIM card slot as shown in the following
figure until the SIM card is completely in position.
3.3 To install the battery
To install the battery, refer to the following figure.
3.4 To install the back cover
To install the back cover, refer to the following figure and steps.
1. Install the back cover.
2. Fold the bracket.
3
