Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Quidway® S5600 Intelligent and Resilient Series

Switches Product Specification

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Fixed port

24 10/100/1000Base-T ports, 4 1000BASE-X SFP (Combo) ports, and 2 dedicate high speed stacking ports

48 10/100/1000Base-T, 4 1000BASE-X SFP (Combo) ports, and 2 dedicate high speed stacking ports

24 1000Base-X SFP ports, 4 10/100/1000BASE-T (Combo) , and 2 dedicate high speed stacking ports

Extended slot

1 1 1 1

Extended module

(1) 8 ports 1000Base-X SFP module (2) 1 port Xenpak 10GE module (3) 2 ports XFP 10GE module

Performance Wire speed L2/L3

switching

Port Switch capacity: 88Gbps Throughput: 65.47Mpps

Port Switch capacity: 136Gbps Throughput: 101.18Mpps

Port Switch capacity: 88Gbps Throughput: 65 .47Mpps

Switching Fabric

192Gbps 240Gbps 192Gbps

Flash

16M 16M 16M 16M 16M

POE

No Yes No Yes No

Switching mode

Store and forward

Forwarding Latency

<40µs

SDRAM

128M

Layer 2 feature MAC address

table

Address self-learning IEEE 802.1D standard Up to 16K MAC addresses Up to 1k static MAC addresses

Page 2

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

VLAN

4k VLAN (IEEE802.1Q) Voice VLAN GVRP Support Port-based VLAN Protocol-based VLAN Configure VLANs in batch

Stack

IRF(DDM, DRR, DLA) Stack up to 8 units in one stacking group Up to 448GE or 384GE and 16 10GE in one stacking group Stacking bandwidth 96Gbps RMON on IRF HGMP on IRF Peer fabric port testing

Link aggregation

Link aggregation through command lines Dynamic link aggregation through LACP Link aggregation across switches Up to 8 GE or 4 10GE ports in each aggregation group Up to 32 aggregation groups (each aggregation port must be of the same speed) Manual link aggregation through command lines

Mirroring

Many-to-one port mirroring (multiple monitored ports to one monitor port, N:1) Traffic mirroring

STP/RSTP/MSTP

IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol instances (MSTP) QinQ BPDU Tunnel

Flow control

IEEE 802.3x (full duplex) Back-pressure based flow control (half duplex)

Page 3

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Broadcast / Multicast / Unicast storm suppression

Port rate ratio(1% granularity) and PPS based on suppression

QinQ

VLAN-VPN or double tag

Layer 3 feature IP routing

Static routing 16K IP Routes RIPv1/v2 (Routing Information Protocol v1, v2) OSPF v2 (Open Shortest Path First ) 4 ECMP(Equal Cost Multi-Path) RIP equivalent route BGP4

Multicast

IGMP (Internet Group Management Protocol) v1 and v2 IGMP (Internet Group Management Protocol) snooping IGMP Group Limit on Interface 256 multicast groups Adding multicast MAC addresses manually Multicast source port suppression MVR(Multicast VLAN Registration)

PIM-DM PIM-SM MSDP(Multicast Source Discovery Protocol)

Network Protocol

VRRP (Virtual redundancy routing protocol) DHCP server DHCP Snooping (Dynamic Host Configuration Protocol Snooping) DHCP Relay (Dynamic Host Configuration Protocol Relay)

For detail information, please refer to S5600 Series Switch System Description.

Page 4

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

DHCP Client DHCP option 60 ARP (Address Resolution Protocol) NTP (Network Time Protocol) BOOTP (Bootstrap Protocol) UDP helper

Convergence Quality of service

(QoS)/ Access control list (ACL)

Support bi-directional port rate-limiting, Committed Access Rate (CAR), GE port with granularity of 64 Kbps and 10GE port with the granularity of 1 Mbps Eight output queues on each port Time-based QoS Packet redirection Three scheduling algorithms that can be set based on port and queue at the same time:

• SP (Strict Priority)

• WRR (Weighted Round Robin)

• SP + WRR Packet tagging based on 802.1p or DSCP preference L2~L4 Packet filter providing filtering based on source/destination MAC address, source/destination IP address, port, protocol, VLAN, VLAN range, MAC address range, or invalid frame QoS profile management, allowing QoS service scheme customization Mirroring remote ports (Support RSPAN) Flow statistics for ACL rules defined using the deny keyword Improvements made for the depth-first order of ACL matching DSCP (differentiated services code point) refined when defining ACL rules Delivering ACLs in RADIUS

Page 5

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Configuring synchronization for the queue schedule of aggregation ports Protocol packet priority Controlling Telnet users

Security Network Login

Support Centralized MAC address authentication Support Disconnect unauthorized device (DUD) authentication Support Port isolation Support MAC address black hole Support MAC Address Learning Limit Prevent unauthorized access to the network by binding of MAC, IP and PORT Support SSH(Secure Shell) V2 ( Automatic RSA public key configuring) Support Port security Support EAD (endpoint admission defense)

802.1X

Support IEEE 802.1X user authentication Version checking (802.1 X supplicant system) Guest VLAN Dynamic VLAN

802.1 X PEAP/EAP/TLS/TTLS Performing 802.1 X authentication and MAC address-based authentication simultaneously

802.1 X -trusted MAC address

802.1 X client checking

Page 6

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

AAA&Radius

Separated authentication, authorization, and accounting Authenticated users need to be authenticated again when the device restarts Delivering of trunk ports and hybrid ports in Tag VLAN is supported when performing

802.1x authentications The tag authentication method field is added to RADIUS protocol HWTACACS

Management/ Maintenance System

Configuration and Management

Support CLI (Command Line Interface) configuration mode Support Configuration via the console port Support Local/Remote configuration via Telnet Support Remote configuration via modem dial-up Support System configuration with SNMP v1, 2 and 3 Support SNMP Agent logging Support HGMP V2 Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs Support Quidway network management system Web-based network management

File system management and seven-segment display

Upgrading all the units of a fabric using the App (or BootROM, Web) files of a unit Setting an App file of a fabric or a unit of a fabric to be the primary/a secondary configuration file Specifying a fabric or a unit of a fabric to use the primary configuration file, a secondary configuration file, or no configuration file to start. Performing specific file-related operations for a fabric or a unit of a fabric, such as deleting files stored in the storage devices of an Ethernet switch, displaying the information about specified files or directories in the storage devices of an Ethernet switch, and clearing the recycle bin. Customizing the password for entering the BOOT menu

Page 7

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawe

i.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

Configuration file backup/recovery Seven-segment display, which indicates the progress of loading software using FTP/TFTP

System Maintenance and debugging

Detailed alarm/debug information output Support Ping and Tracert Support remote maintenance via Telnet Modems and SSH Support HWping Support System log Hierarchical alarm management and alarm filtering Support DLDP (Device Link Detection Protocol) Saving debugging information into Flash Displaying the information about all enabled types of debugging Displaying the statistics of MAC addresses of a switch Configuring Telnet users with specified source IP addresses/source ports Setting the Daylight Saving Time Loopback detection on ports Support VCT(Virtual Cable Test)

Information center

Exporting switch synchronization information Setting the format of time stamps to be sent to log hosts

Hardware configuration Outline

dimension (W×H×D)

440 mm × 43.6 mm × 420mm (17.32 in.× 1.72 in. × 16.54 in.)

Weight

7.1Kg 7.4Kg 7.1Kg

Power supply

Power module

PSL130-AD: 130 W system output, AC/DC input PSL480-AD24P: 24-port PoE power module, 180 W system output + 300 W PoE output (AC input); 180 W system output + 370 W PoE output (DC input) PSL180-AD: 180 W system output, AC/DC input

Page 8

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

PSL480-AD48P: 48-port PoE power module, 180 W system output + 300 W PoE output (AC input); 180 W system output + 740 W PoE output (DC input)

Input voltage

AC: Rated voltage: 100V to 240V, 50 Hz to 60Hz Maximum tolerance:90V to 264V, 50 Hz to 60Hz DC: Rated voltage: -48V to -60V Maximum tolerance: -36V to -72V

Input DC voltage of PoE power module

The S5624P-PWR/S5648P-PWR must use the external PoE PSU recommended by us as its DC input, but not the -48VDC power supply generally available in the equipment room. Otherwise, the device may be damaged DC input of the PoE power module: Rated voltage: –53.5 V Max voltage range: –52 to–55 V

RPS power

Supported

Maximum power consumption

S5624P: 170 W S5648P: 230 W S5624F: 170 W S5624P-PWR: 540 W S5648P-PWR: 600 W When with PoE power supply: S5624P-PWR: 540 W (DC input), 560 W (AC input) S5648P-PWR: 970 W (DC input), 640 W (AC input)

MTBF (Years)

32.30 32.30 23.99 23.99 23.89

Noise parameter

S5624P: 50.8 dBA S5648P: 51.4 dBA S5624F: 54.6 dBA

Page 9

Quidway® S5600 Intelligent and Resilient Series Switches Product Specification

http://www.huawei.com/products/datacomm/

Features S5624P S5624P-PWR S5648P S5648P-PWR S5624F

S5624P-PWR: 51.8 dBA S5648P-PWR: 52.2 dB

MTTR (hours)

<2 <2 <2 <2 <2

Environment

Operation temperature: 0°C ~ 45°C Storage temperature: -40°C ~ 70°C Operating humidity: 5% to 85% non-condensing Relative humidity: 10% ~ 90%, non-condensing
