Quidway

S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com

Quidway® S5100-EI series Intelligent and Resilient Switches Product Specification

Name S5124P-EI S5148P-EI S5126C-EI S5150C-EI

Fixed port

24 10/100/1000 Mbps electric ports

4 Gigabit SFP Combo ports

48 10/100/1000 Mbps electric ports

4 Gigabit SFP Combo ports

24 10/100/1000 Mbps electric ports

4 Gigabit SFP Combo ports

48 10/100/1000 Mbps electric ports

4 Gigabit SFP Combo ports

Extended slot

0 0 2 2

Extended module

N/A

(1) 1 port stack 10GE Module (2) 1 port Xenpak 10GE Module (3) 1 ports XFP 10GE module

Performance

Wire speed L2 switching

Port Switch capacity: 48Gbps

Throughput:

35.71Mpps

Port Switch capacity: 96Gbps

Throughput:

71.42Mpps

Port Switch capacity: 88Gbps

Throughput:

65.47Mpps

Port Switch capacity: 136Gbps

Throughput:

101.19 Mpps

Switching Fabric

48Gbps 96Gbps 88Gbps 136Gbps

Flash

16M 16M 16M 16M

Switching mode

Store and forward

Forwarding Latency

<40µs

Jumbo Frame

Support 9K

Attribute S5100-EI

MAC address table

Address self-learning IEEE 802.1D standard Up to 16K MAC addresses Up to 1k static MAC addresses Support black hole MAC addresses

VLAN

4k VLAN (IEEE802.1Q) Voice VLAN GVRP Support port-based VLAN

Page 2

Quidway

S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com

Attribute S5100-EI

Support protocol-based VLAN Support policy-based VLAN

Stack

For S5100-C-EI only: Up to 16 units in one stacking group Stacking ba ndwidth 40 Gbps Support HGMP V2 stack

Link aggregation

Support dynamic aggregation of Gigabit Ethernet (GE) ports Support dynamic aggregation of 10GE ports dynamic link aggregation through Link Aggregation Control Protocol (LACP) Support manual link aggregation Support static link aggregation Support up to 25 aggregation groups, each supporting 8 GE or 2 10GE ports Support load balancing and non-load balancing (when lack of hardware

aggregation resources)

Mirroring

Support traffic mirroring Support VLAN-based mirroring Support MAC address–based mirroring Support port mirroring Support multi-source port mirroring

STP/RSTP /MSTP

IEEE 802.1D Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanni ng Tree Protocol (RSTP) IEEE 802.1s Multiple Spanning Tree Protocol instances (MSTP) Support intra-domain maximum-weight spanning trees (up 16 spanning tree

instances) Support STP Root Guard Support BPDU Guard

Flow control

IEEE 802.3x (full duplex) Back-pressure based flow control (half duplex)

Broadcast storm suppression

Support port-based broadcast storm suppression

QinQ

Support VLAN-VPN or double tag Support port-based QinQ Support selective QinQ

Multicast

Support 1K multicast MAC addresses Support Internet Group Management Protocol (IGMP) Snoopingv1/v2 Up to 256 multicast groups in a VLAN, and up 1,024 multicast groups in the

entire system Support multicast VLANs Support dropping known multicast packets Support outbound packet filtering for known multicast packets Support manual configuration of multicast MAC addresses

Network Protocol

DHCP Snooping (Dynamic Host Configuration Protocol Snooping) DHCP Client ARP (Address Resolution Protocol)

Page 3

Quidway

S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com

Attribute S5100-EI

NTP (Network Time Protocol) BOOTP (Bootstrap Protocol)

Convergence

Quality of service (QoS)/

Access control list (ACL)

Packet tagging based on 802.1p or DSCP preference L2~L4 Packet filter providing filtering based on source/destination MAC

address, source/destination IP address, port, protocol, VLAN, VLAN range, MAC address range, or invalid frame

Mirroring remote ports (Support RSPAN) Support priority mapping Support priority marking Support traffic statistics Support port trust mode Each port supports eight queues Support SP/SDWRR/SP+SDWRR queue scheduling Support traffic shaping for ports and queues Support port-based/flow-based rate limiting, with the minimum granularity of 1

kbps Support numeral-expressed standard ACL Support numeral-expressed extended ACL Support numeral-expressed layer 2 ACL Support ACL application Support real-time update of ACL rules based on time range changes

Security

Network Login

Support hierarchical management and password protection of users Support Centralized MAC address authentication Support Port isolation Support MAC address black hole Support MAC Address Lea rning Limit Prevent unauthorized access to the network by binding of MAC and PORT Support SSH(Secure Shell) v2 Support Port security

Up to 256 users under a single port Support port-based and MAC address–based authentication Support MAC address authentication and Fabric synchronization Support Trunk port authentication Support IEEE 802.1X user authentication Version checking (802.1 X supplicant system) Guest VLAN

802.1 X PEAP/EAP/TLS/TTLS

802.1X

Automatic QoS ACL filtering Uplink speed limiting

AAA & Radius

Support AAA authentication Support RADIUS authentication

Page 4

Quidway

S5100-EI Series Intelligent and Resilient Switches Product Specification

http://datacomm.huawei.com

Attribute S5100-EI

Management/ Maintenance

System Configuration

and Management

Support CLI (Command Line Interface) configuration mode Support Configuration via the console port Support Local/Remote configuration via Telnet Support Remote configuration via modem dial-up Support System configuration with SNMP v1, 2 and 3 Support HGMP V2 Support RMON (Remote Monitoring) v1, 1/2/3/9 groups of MIBs Web-based network management

System Maintenance and debugging

Detailed alarm/debug information output Support Ping and Tracert Support remote maintenance via Telnet Modems and SSH Support NQA Support System log Hierarchical alarm management and alarm filtering Support DLDP (Device Link Detection Protocol) Loopback detection on ports Support VCT(Virtual Cable Test)

Information center

Exporting switch synchronization information Setting the format of time stamps to be sent to log hosts

Description S5124P-EI S5148P-EI S5126C-EI S5150C-EI

Outline dimension

43.6 × 260 × 440 mm (1.72 × 10.2 ×

17.3 in.)

43.6 × 300 × 440 mm (1.72 × 1 1.8 × 17.3 in.)

Weight

< 4 kg (< 8.8 lb) 4 kg (8.8 lb) 4 kg (8.8 lb) < 5 kg (< 11 lb)

Power supply

S5100-EI series support both AC and DC power inputs AC input: Rated voltage range: 100 VAC to 240 VAC, 50 Hz or 60 Hz Max voltage range: 90 VAC to 264 VAC, 47 Hz or 63 Hz DC input: Rated voltage range: -48 V to -60 V Max voltage range: -36 V to -72V

Maximum power consumption

39 W 78 W 54 W 97 W

MTBF (Years)

22.0 21.1 13.3 12.1

Noise parameter

46.7dBA 50.2dBA 50.1dBA 51.5dBA

Environment

Operation temperature: 0°C ~ 45°C Operating humidity: 5% to 85% non-condensing Relative humidity: 10% ~ 90%, non-condensing
