Huawei Quidway S2008-EI, Quidway S2016-EI, Quidway S2403H-EI Specifications
Quidway® S2000-EI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
1
Quidway® S2000-EI Series Intelligent Access
Switches Product Specification
Software Specifications
Feature S2008-EI S2016-EI S2403H-EI
Performance
Switching
capacity
5.2Gbps 5.2Gbps 5.2Gbps
Throughput
1.19Mpps 2.53Mpps 3.87Mpps
Layer 2 Switching
MAC Address
4K MAC addresses
latency
<10µs
VLAN
512 VLANs (IEEE 802.1Q)
Support 4K VLAN Transparent Transfer
GVRP (GARP VLAN Registration Protocol)
Port-based VLAN
Link Aggregation Up to 4 maximum
aggregation groups, each
containing up to 8 ports
Up to 8 maximum
aggregation groups, each
containing up to 8 ports
Up to 12 maximum
aggregation groups, each
containing up to 8 ports
Traffic control
IEEE 802.3x full-duplex flow control
Back-pressure based flow control (half duplex)
STP/RSTP
IEEE 802.1D Spanning Tree Protocol (STP)
IEEE 802.1w Rapid Spanning Tree Protocol (RSTP)
Multicast
2K Multicast groups
IGMP (Internet Group Management Protocol) snooping on Layer 2 interfaces
GMRP (GARP Multicast Registration Protocol)
Network protocol
DHCP Snooping (Dynamic Host Configuration Protocol Snooping)
Support NTP (Network Time Protocol)
ARP
Convergence
Priority Queues
Four hardware queues per port
QoS(Quality of
Service)
Support flexible queuing algorithms:
• WRR (Weighted Round Robin)
• HQ+WRR (High-Priority Queuing + WRR)
Support bi-directional port rate-limiting with the granularity of 64kbit/s
Quidway® S2000-EI Series Intelligent Access Switches Product Specification
Copyright ©2007 Huawei Technologies Co., Ltd. All Rights Reserved.
http://www.huawei.com/products/datacomm/
2
Feature S2008-EI S2016-EI S2403H-EI
Security
Network Login
Hierarchical user management and password protection
Port-based and MAC-based 802.1X authentication
Local authentication server
PEAP/TLS (Protected Extensible Authentication Protocol/Transport Layer
Security)
Management
System
Configuration
and Management
CLI (Command Line Interface) configuration mode
Configuration via the console port
Local/remote configuration via Telnet
System configuration with SNMP v1, 2, and 3
RMON (Remote Monitoring) v1 1, 2, 3 and 9 groups of MIB
Quidway and iManager N2000 network management system
WEB management system
Hierarchical alarms
System log
HGMP (Huawei Group Management Protocol) v2
System
maintenance
Debugging information output
Ping and Tracert
Remote maintenance through Telnet
Hardware Specifications
Attribute S2008-EI S2016-EI S2403H-EI
Outline
dimensions (mm)
（H×W×D）
40 X 216 X 117 42 X 436 X 200 42 X 436 X 240
Weight
<2kg <=3kg <=3kg
Input voltage
AC: 100V～240V , 50/60Hz
AC: 100V～240V , 50/60Hz
DC: -40 ~ -60V
Maximum
system power
consumption
8W 12W 15W
Environment
Working temperature: 0~45℃
Storage temperature: -40 ~ 70℃
Relative humidity: 10%~90%, noncondensing
Fixed ports (1) 8 10/100M BASE-TX
Ethernet ports
(2) 1 console port
(1) 16 10/100M BASE-TX
Ethernet ports
(2) 1 Console port
(1) 25 10/100M BASE-TX
Ethernet ports
(2) 1 Console port
