M580
1 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . . 1 2 Getting Started . . . . . . . . . . . . . . . . . . . . . . 4
Your Phone at a Glance . . . . . . . . . . . . . . . . . . . . . . . .4 Keys and Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . .5 Inserting the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . .7 Inserting the microSD Card . . . . . . . . . . . . . . . . . . . . .8 Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . .8 Status Icons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 Using the Touch Screen . . . . . . . . . . . . . . . . . . . . . . .10
3 Text Entry . . . . . . . . . . . . . . . . . . . . . . . . . 12
Entering English . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 Entering Spanish. . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 Entering a Digit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
4 Voice Services. . . . . . . . . . . . . . . . . . . . . . 14
Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14 Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5 Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adding a Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . .16 Searching for a Contact . . . . . . . . . . . . . . . . . . . . . . .16
6 SMS & MMS . . . . . . . . . . . . . . . . . . . . . . . 17
Writing and Sending a Message . . . . . . . . . . . . . . . . .17 Reading a Message. . . . . . . . . . . . . . . . . . . . . . . . . . .17
7 @metro . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Accessing @metro App Store . . . . . . . . . . . . . . . . . . .18 Changing Your @metro Settings . . . . . . . . . . . . . . . .19 Using On-line Help . . . . . . . . . . . . . . . . . . . . . . . . . . .20
8 Media Applications . . . . . . . . . . . . . . . . . . 22
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22 Music Player . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23 Playing a Video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Picture Viewer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24 Recorder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
9 Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . 26
Bluetooth-based Data Transfer . . . . . . . . . . . . . . . . . .26 Using Bluetooth Headset . . . . . . . . . . . . . . . . . . . . . .26
10 Security . . . . . . . . . . . . . . . . . . . . . . . . . 28
Enabling/Disabling the Phone Lock. . . . . . . . . . . . . . .28 PIN and PUK. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28 Locking the Keypad . . . . . . . . . . . . . . . . . . . . . . . . . .29
11 TTY Operation . . . . . . . . . . . . . . . . . . . . . 30
Using the TTY Device . . . . . . . . . . . . . . . . . . . . . . . . .30 Setting the TTY Mode . . . . . . . . . . . . . . . . . . . . . . . . .30
12 Troubleshooting . . . . . . . . . . . . . . . . . . . . 32 13 Warnings and Precautions. . . . . . . . . . . . . 34
14 Futurewei Technologies, Inc. Limited
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
1 Copyright
Copyright © Huawei Technologies Co., Ltd. 2011. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written consent of Huawei Technologies Co., Ltd.
The product described in this manual may include copyrighted software of Huawei Technologies Co., Ltd and possible licensors. Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract, reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by applicable laws or such actions are approved by respective copyright holders under licenses.
Trademarks and Permissions
, HUAWEI, and
re trademarks or registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned are the property of their respective owners.
1
Notice
Some features of the product and its accessories described herein rely on the software installed, capacities and settings of local network, and may not be activated or may be limited by local network operators or network service providers, thus the descriptions herein may not exactly match the product or its accessories you purchase.
Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL
2
DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and will obtain all necessary governmental permits and licenses in order to export, re-export or import the product mentioned in this manual including the software and technical data therein.
DTS Envelo
Manufactured under license from DTS licensing Limited. DTS, the Symbol & DTS and the Symbol together are registered trademarks & DTS Envelo is a trademark of DTS, Inc. Product includes software. © DTS, Inc. All Rights Reserved.
3
2 Getting Started
Your Phone at a Glance
|
1 |
|
|
|
19 |
15 |
|
|
|
2 |
|
14 |
|
18 |
13 |
3 |
|
12 |
4 |
|
11 |
5 |
|
6 |
|
|
|
|
|
10 |
7 |
16 |
|
|
|
9 |
8 |
17 |
|
|
1 |
Earpiece |
2 |
Volume key |
|
|
|
|
4
3 |
Confirm key |
4 |
Right soft key |
|
|
|
|
|
|
5 |
Clear key |
6 |
End key |
|
|
|
|
|
|
7 |
Camera key |
8 |
# key |
|
|
|
|
|
|
9 |
* key |
10 |
Numeric keys |
|
|
|
|
|
|
11 |
Send key |
12 |
Speaker key |
|
|
|
|
|
|
13 |
Left soft key |
14 |
Navigation keys |
|
|
|
|
|
|
15 |
Screen |
16 |
Charger/Data cable |
|
connector |
||||
|
|
|
||
|
|
|
|
|
17 |
Speaker |
18 |
Main camera |
|
|
|
|
|
|
19 |
Headset jack |
|
|
|
|
|
|
|
Keys and Functions
Send key
• Make or answer a call.
• Access call logs in standby mode.
5
|
• Power on or power off the phone by pressing and |
|
|
holding it. |
|
End key |
• End or reject a call. |
|
|
• Return to the standby mode. |
|
|
• Lock the screen in the standby mode. |
|
|
|
|
Left soft |
Select the option displayed in the lower left corner of |
|
key |
the screen. |
|
|
|
|
Right soft |
Select the option displayed in the lower right corner |
|
key |
of the screen. |
|
|
|
|
Clear key |
Delete a character in editing mode or delete a |
|
selected item in an application. |
||
|
||
|
|
|
Speaker |
Press and hold to turn on or off the speaker mode. |
|
key |
||
|
||
|
|
|
* key |
Switch between the current mode and the Vibrate |
|
Only mode by pressing and holding it. |
||
|
||
|
|
|
# key |
Switch between text input methods when editing |
|
text. |
||
|
||
|
|
6
0 key
…
9 key
•Enter numbers, letters, and symbols.
•Call the voicemail in standby mode by pressing and holding the 1 key.
•Speed-dial phone numbers in standby mode by pressing and holding the desired key 2–9 after a phone numbers are assigned to the number key.
Confirm |
• Confirm a selection. |
|
key |
• Access Menu in standby mode. |
|
|
|
|
Volume |
Increase or decrease the volume. |
|
key |
||
|
||
|
||
Inserting the Battery |
||
1 |
2 |
7
Inserting the microSD Card
Charging the Battery
Before charging the battery with the travel charger, ensure that the battery is installed in your phone. Do not use a damaged battery or charger.
1.Connect the charger to a power outlet.
2.Connect the charger to the charger connector of the phone. The phone begins charging. When the battery icon changes to fully charged, it indicates that your phone is fully charged.
3.When the phone is fully charged, disconnect the charger from the phone and then from the power outlet.
8
Status Icons
|
|
Signal strength |
|
|
Roaming |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Call in progress |
|
|
Missed calls |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
New push message |
|
|
The memory for text |
|
|
|
|
||
|
|
received |
|
|
messages is full |
|
|
|
|
||
|
|
|
|
|
|
|
|
New text message |
|
|
New multimedia |
|
|
|
|
||
|
|
received |
|
|
message received |
|
|
|
|
||
|
|
|
|
|
|
|
|
The memory for |
|
|
New voicemail |
|
|
multimedia messages |
|
|
|
|
|
|
|
message received |
|
|
|
is full |
|
|
|
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
New emergency |
|
|
microSD card inserted |
|
|
|
|
||
|
|
message received |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Alarm clock enabled |
|
|
Bluetooth on |
|
|
|
|
||
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Bluetooth headset |
|
|
The phone is receiving |
|
|
|
|
||
|
|
connected |
|
|
date through Bluetooth |
|
|
|
|
||
|
|
|
|
|
|
9
|
|
The phone is sending |
|
|
Battery level |
|
|
|
|
||
|
|
data through Bluetooth |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Battery charging |
|
|
The battery power level |
|
|
|
|
||
|
|
|
|
is extremely low |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
The alert type is Ring. |
|
|
The alert type is |
|
|
|
|
||
|
|
|
|
Silence |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
The alert type is Ring |
|
|
The alert type is |
|
|
|
|
||
|
|
and Vibrate |
|
|
Vibrate Only |
|
|
|
|
||
|
|
|
|
|
|
|
|
Headset connected |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Using the Touch Screen
You can use your finger to select an item by tapping on the touch screen of your phone.
Touch Operations
•Tap: Select an item or display a menu by touching your finger to the screen.
•Drag: Move an object by moving your finger on the screen.
10
Screen Calibration
When operating the phone with the touch screen, if the phone cannot respond to your operation correctly, you can calibrate the screen as follows:
•Select Settings > Display > Screen Calibration to access the screen for calibration.
•Calibrate the screen by tapping the center of + displayed on the screen according to the instructions.
Note: During the calibration, tap the center of + accurately, to ensure that the phone can respond to your tap and text entry on the screen correctly after the calibration.
Dragging and Flicking
On following screens, you can perform some operations conveniently through dragging on the touch screen:
•On the standby screen, flick right or left to switch between the home screens.
•In the menu list, drag up or down to scroll. Then tap a submenu to select it.
•When viewing pictures, flick right or left to switch a picture to the next or previous one.
11
3 Text Entry
Entering English
Smart English Input Method
1.1.Based on the sequence of the word, press the key labeled with the desired letter once. Then the phone predicts the commonly used words according to the numeric sequence of key presses.
2.Select the desired word, and press Confirm key or 0 key to enter the word.
3.Press 1 key to enter a full stop or another commonly used punctuation. Press * key to display the symbol list. Then you can select and enter a symbol.
Note:
The indicator of the current input method is displayed in the upper left corner of the screen. You can press # key to change the input method.
Traditional English Input Method
The traditional text input method allows you to enter uppercase or lowercase English letters. You can press the key labeled with the desired letter once to enter the first letter on the key, twice to enter the second letter on the key, and so on.
12
•Press 1 key to enter a full stop or another commonly used punctuation.
•Press * key once to enter a space, twice to enter a carriage return, and three times to enter 0.
Entering Spanish
You can enter Spanish words using Spanish text input methods.
The traditional Spanish input method and the smart Spanish input method are similar to the traditional English input method and the smart English input method. For details, see "Entering English".
Entering a Digit
•In "123" input mode, press the key labeled with your desired digit.
•In "Abc" input mode, press a number key consecutively until the digit appears.
•In "En" input mode, press a number key and then press
Navigation keys to scroll to the digit and press Confirm key to enter it.
•In any text input mode, except the "123" input mode, press and hold a number key to enter the digit.
13
4 Voice Services
Making a Call
Dialing via Keypad
1.In standby mode, enter the phone number.
•To make an international call, press * key twice consecutively to enter the international long-distance code (+), and then enter the country code or region code, area code, and phone number in sequence.
•To dial an extension number, enter the phone number, press
*key three times consecutively to insert P or press * key four times consecutively to insert W, and then enter the extension number.
2.Press Send key to dial the number.
3.Press End key or tap to end the call.
Dialing via Contacts
Select > Contacts, Select a contact, and press Send key to make a call.
14
Dialing via Call Log
Select > Call Logs or press Send key to select the required number from call logs. Then press Send key to dial the number
Answering a Call
When there is an incoming call, you can press Send key to answer it, press End key to reject it.
•If the any-key answer function is enabled, you can press any key except End key and Right soft key to answer an incoming call.
•If the headset auto-answer function is enabled, when the headset is connected to the phone, the incoming call is answered automatically.
15
