HTC PM-128 User Manual

PM-128

Drill Press Support

Support Pour

Perceuse à Colonne

OPERATORS MANUAL

GUIDE DE L’UTILISATEUR

Assembly • Operation • Parts List • Warnings • Warranty

Montage • Utilisation • Liste des pièces • Avertissements • Garantie

Caution: Read all instructions carefully.

SAVE THESE INSTRUCTIONS.

Refer to them often and use them to instruct others.

Attention: Lire attentivement toutes les instructions.

CONSERVER CES INSTRUCTIONS.

Veuillez les consulter fréquemment et les utiliser pour la formation.

Date Purchased / Date d’achat:

Where Purchased / Marchand:

Address / Adresse:

Congratulations

You have just purchased an HTC PM-128 Drill Press Support. This
product was specially designed to assist you in performing operations on
your drill press.

General Safety Instructions
for Power Tools

1. Know your power tool. Read and understand the Owner’s Manual and
observe the warnings and instruction labels affixed to the tool.

2. Properly ground all tools.

3. Keep guards in place.

4. Remove adjusting keys and wrenches.

5. Keep work area clean and dry.

6. Keep children away.

7. Never leave running machines/tools unattended.

8. Disconnect tools from service.

9. Regularly maintain tools.

10. Use correct tools for the job.

11. Never force a tool.

12. Wear safety apparel.

13. Wear safety glasses/goggles.

14. Never stand or sit on tools.

15. Replace damaged components immediately.

16. Think Safety. Safety is a combination of operator awareness, common
sense and alertness at all times.

Safety Instructions
for Drill Press Support

1. Be thoroughly acquainted with all safety and operational instructions
regarding your drill press in this manual and those from the machine
manufacturer.

2. Keep extensions within safe operating limits.

3. Line up support rollers with drill press table surface before use.

4. Use additional support(s) if workpiece exceeds the weight limits of this
unit or makes the drill press unstable or when working with long pieces.

5. Test the set-up for stability and safety before proceeding with the work.

Assembly Instructions

Tools needed: (2)1/2” wrenches, flat-head screwdriver or putty knife.

1. Unpack and make certain all parts and hardware are included and are
not damaged from shipment.

2. Install Column Clamps  and  as shown. This is the only step
you’ll need the wrenches. Use (2) long 5/16” – 18 bolts , (1) Lock
Nut  and the Large Threaded Hand Knob 
Nuts so that the Clamp Bolts are equally spaced.

3. For starters, adjust the Clamp to be 5” to 6” (12.5cm to 15cm) below
the drill press table.

. Adjust Clamp Bolts /
