User guide

HTC One® M9

2 Contents

Contents

Features you'll enjoy

Personalization 10 Imaging 11 Sound 13

Unboxing

HTC One M9 14 Slots with card trays 15 nano SIM card 15 Storage card 16 Charging the battery 19 Switching the power on or off 19

Phone setup and transfer

Setting up your new phone for the first time 21 Transferring content from an Android phone 21 Transferring content from an iPhone 22 Transferring contacts from your old phone through Bluetooth 22 Other ways of getting contacts and other content 23 Transferring photos, videos, and music between your phone and computer 24 Using Quick Settings 24 Getting to know your settings 25 Updating your phone's software 26 Getting apps from Google Play 27 Downloading apps from the web 28 Uninstalling an app 28

Your first week with your new phone

Basics 29 HTC Sense Home widget 39 Motion Launch 41 Lock screen 46 Notifications 48 Working with text 50

Personalizing

Themes 54 More ways to personalize 57

HTC BlinkFeed

What is HTC BlinkFeed? 64 Turning HTC BlinkFeed on or off 65

3 Contents

Restaurant recommendations 65 Ways of adding content on HTC BlinkFeed 66 Customizing the Highlights feed 67 Saving articles for later 67 Posting to your social networks 68 Removing content from HTC BlinkFeed 68

Camera

Camera basics 69 Selfies and people shots 74 Split Capture 76 Panoramic shots 77 Other camera features 79 Camera settings 80

Gallery

Viewing photos and videos in Gallery 82 Adding photos or videos to an album 85 Copying or moving photos or videos between albums 85 Tagging photos and videos 85 Searching for photos and videos 86 Finding matching photos 87 Viewing Pan 360 photos 87 Changing the video playback speed 88 Trimming a video 88 Saving a photo from a video 88 Viewing a Zoe in Gallery 89 One Gallery 89

Photo Editor

Basics 90 Editing continuous shots 92 Creative effects 94

HTC Print Studio

What is HTC Print Studio? 100 Choosing the type of photo gift 100 Creating your photo gift 100 Placing your order 101

Video chat and phone calls

Video chat 102 Phone calls 103

Messages

Sending a text message (SMS) 109 Sending a multimedia message (MMS) 109 Sending a group message 110 Resuming a draft message 110

4 Contents

Replying to a message 110 Forwarding a message 111 Moving messages to the secure box 111 Blocking unwanted messages 112 Copying a text message to the nano SIM card 112 Deleting messages and conversations 112

Entertainment

HTC BoomSound with Dolby Audio 114 HTC Music 115 FM Radio 118 HTC Connect 118

Power and storage management

Battery 123 Phone storage 126 File Manager 128

Sync, backup, and reset

Online sync 130 Backup 131 HTC Sync Manager 133 Reset 135

Contacts

Your contacts list 137 Setting up your profile 138 Adding a new contact 138 Editing a contact’s information 139 Getting in touch with a contact 140 Importing or copying contacts 140 Merging contact information 141 Sending contact information 142 Contact groups 142 Private contacts 143

Calendar and Email

Viewing the Calendar 145 Scheduling or editing an event 146 Choosing which calendars to show 146 Sharing an event 147 Accepting or declining a meeting invitation 147 Dismissing or snoozing event reminders 148 Checking your mail 149 Sending an email message 150 Reading and replying to an email message 150 Managing email messages 151 Searching email messages 152 Working with Exchange ActiveSync email 152 Adding an email account 153

5 Contents

What is Smart Sync? 154

Google Search and apps

Google Now 155 Google Search 157 Google Chrome 158 Google Drive 159 Google Maps 161 YouTube 163

Other apps

HTC Dot View 165 Scribble 167 Clock 169 Weather 170 Voice recorder 170

Internet connections

Turning the data connection on or off 171 Managing your data usage 171 Wi-Fi connection 173 Connecting to VPN 174 Using HTC One M9 as a Wi-Fi hotspot 175 Sharing your phone's Internet connection by USB tethering 176

Wireless sharing

Bluetooth 177 NFC 179

Settings and security

Turning location services on or off 181 Airplane mode 181 Scheduling when to turn data connection off 182 Automatic screen rotation 182 Setting when to turn off the screen 182 Screen brightness 182 Touch sounds and vibration 183 Changing the display language 183 Glove mode 183 Accessibility settings 184 Turning Magnification gestures on or off 184 Installing a digital certificate 184 Pinning the current screen 185 Disabling an app 185 Assigning a PIN to a nano SIM card 185 Navigating HTC One M9 with TalkBack 186

Trademarks and copyrights

6 Contents

Index

7 About this guide

About this guide

In this user guide, we use the following symbols to indicate useful and important information:

This is a note. A note often gives additional information, such as what happens when you choose to do or not to do a certain action. A note also provides information that may only be applicable to some situations.

This is a tip. A tip gives you an alternative way to do a particular step or procedure, or lets you know of an option that you may find helpful.

This indicates important information that you need in order to accomplish a certain task or to get a feature to work properly.

This provides safety precaution information, that is, information that you need to be careful about to prevent potential problems.

Some apps may not be available in all regions or with your mobile operator.

8 Important RF Notice

Important RF Notice

This device was tested for compliance with the applicable FCC and Industry Canada specific absorption rate (SAR) limits for radio frequency (RF) exposure during typical body-worn operations. To ensure that RF exposure levels remain at or below the tested levels, use a belt-clip, holster, or similar accessory that maintains a minimum separation distance of 1.0 cm between your body and the device, with either the front or back of the device facing towards your body. Such accessories should not contain any metallic components. Body-worn accessories that do not meet these specifications may not ensure compliance with applicable SAR limits and their use should be avoided.

9 Important note on recoverable data

Important note on recoverable data

Files and other data that have been deleted, cleared, removed, or erased from your device may still be recoverable by third-party data recovery software. Even a factory reset may not permanently erase all data from your phone, including personal information.

10 Features you'll enjoy

Features you'll enjoy

Personalization

Designed with you in mind, HTC One M9 is filled with innovations that help it to adapt to your life.

Themes

Make HTC One M9 feel more personal by customizing how it looks with your own photos and then mix and match with different sets of icons, sounds, color schemes, and more. See What is the

Themes app? on page 54.

HTC Sense Home

HTC BlinkFeed

Your Home screen adapts to your needs at home, at work, and on the go. New lock screen notifications make it easier to find what you've missed, see upcoming events, get restaurant recommendations, and more. See What is the HTC Sense Home

widget? on page 39 and HTC BlinkFeed Notifications on page

47.

Get your favorite topics, news, social media, and more conveniently delivered to one place on your phone. Even get suggestions for points of interests and places to eat! See What is

HTC BlinkFeed? on page 64.

11 Features you'll enjoy

Imaging

Made to help you capture your memories to share with family and friends. Bokeh

When using Bokeh mode with the main camera, you can focus on any object by just tapping it, which blurs the background for an artistic effect. See Changing the focus in Bokeh mode on page

73.

Split Capture

Use Split Capture mode to record yourself and the action in front of you. This mode uses both the front and back cameras to capture a split-screen photo or video. You can even resize the split windows. See

Using Split Capture mode on page 76.

HTC UltraPixel front camera

Take high-quality selfies with the 4MP HTC UltraPixel™ front camera even in low-light conditions. Also enjoy using the variety of selfie-friendly features with the Camera app.

§ Live Makeup – Before taking your selfie, use Live Makeup to smoothen your skin. See

Applying skin touch-ups with Live Makeup on page 75.

§ Instant selfie shots – Flash a smile, and the camera instantly captures your smiling face. Or, Just say "Cheese"! See Using Auto Selfie on page 75 and Using Voice Selfie on page 75.

§ Photo Booth – Take 4 selfies and the camera automatically merges them into a single picture. See Taking selfies with Photo Booth on page 76.

12 Features you'll enjoy

One Gallery

One Gallery lets you view all your photos and videos that are stored on HTC One M9 as well as on favored online services right from the Gallery app. You can also find similar photos and videos using Image match or by searching with keywords or tags. See One Gallery on page 89.

Photo Editor

The Photo Editor app enhances your photos, from basic edits to elegant effects!

Make a photo surreal. Blend in shapes, elements, and prismatic effects. See

Prismatic on page 96.

Superimpose one image onto another and create a unique composition only you can imagine! See Double Exposure on page

97.

Enhanced video calling

Face Fusion uses two photos such as your selfie and a photo of your favorite celebrity to merge your looks together. See Face Fusion on page 98.

Face Tracking can detect not just you but also the people around you during a video call. Your caller will see up to 4 faces that are within your camera’s field of vision.

Also, you can share what you're looking at on your phone screen to the person you're chatting with. See Video chat and phone

calls on page 102.

13 Features you'll enjoy

Zoe

Use the Zoe™ app to create stories using your photos and videos combined with your own soundtrack. Right from this app, you can engage with the Zoe community to share your content and remix with other people's content. There's also the Zoe website that's accessible from your computer web browser where everyone can view shared content.

To find out how to use the Zoe app, go to www.zoe.com/help. To visit the Zoe website, go to

www.zoe.com.

Sound

Discover audio bliss on HTC One M9 through its built-in speakers, headphones, or wireless speakers.

HTC BoomSound with Dolby Audio

Hear what you've been missing. HTC BoomSound™ gives you a rich, authentic sound experience, whether you’re listening to music, watching a video, or playing a game. To find out more, see

Toggling modes in HTC BoomSound on page 114 and Using HTC BoomSound with headphones on

page 114.

HTC Connect

Simply swipe up the screen with three fingers to stream music or video from HTC One M9 to your speakers or TV. Control the volume and playback with your phone! You can even enjoy your favorite music on multiple speakers. See What is HTC Connect? on page 118.

14 Unboxing

Unboxing

HTC One M9

1. POWER

2. VOLUME

3. microSD™ card slot with eject hole

4. Front camera

5. Proximity sensor

6. IR sensor

7. Dual speakers

8. Notification LED

9. nano SIM card slot with eject hole

10. USB connector

11. 3.5mm headset jack

™

You need a 4G/LTE services. Check with your operator for details.

§ If you want to use a case or screen protector, don’t cover and block the proximity sensor. Purchase a case or screen protector designed for HTC One M9.

§ Avoid liquid or dust from entering the microphone hole to prevent damage to the microphone.

§ Avoid connecting third-party headsets or accessories with metallic charms that dangle near the

headset jack. Using these may affect signal reception.

plan to use your operator's 4G/LTE network for voice calls and data

15 Unboxing

Slots with card trays

With HTC One M9 facing up, the nano SIM slot is on the left side and the microSD slot on the right side. There are trays inside the slots that are used for inserting your cards.

When inserting the eject tool into the tray eject holes to remove the card trays, make sure not to press on the trays to avoid damaging the eject mechanism inside the slots.

Also, if you want to use a protective case, make sure to buy a case that's designed for HTC One M9 and that doesn't block the trays.

nano SIM card

HTC One M9 uses a nano SIM card. Use a standard nano SIM card only. Inserting a modified card that is thicker than the standard

nano SIM card may cause the card to not fit properly or damage the card slot.

Inserting a nano SIM card

1. Hold the phone face down.

2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—

into the tray eject hole next to the nano SIM card slot.

3. Push the tip all the way into the hole until the tray ejects, and then pull the tray out.

16 Unboxing

4. Place the nano SIM card into the tray, with the gold contacts facing up and cut-off corner

facing out.

5. Insert the card tray back into the slot.

Removing a nano SIM card

Make sure to switch off HTC One M9 before removing the card.

1. Hold the phone face down.

2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—

into the tray eject hole next to the nano SIM card slot.

3. Push the tip all the way into the hole until the card tray ejects.

4. Pull the card tray out, and remove the nano SIM card.

5. Make sure that you insert the empty card tray back into the slot.

Storage card

Use a storage card to store your photos, videos, and music. When you need to free up phone storage space, you can also move certain apps to the storage card, if the apps support this feature.

The storage card is optional and sold separately.

§ Moving apps to the storage card doesn't back up the apps. If you do a factory reset, your phone loses the apps. You'll need to reinstall them.

§ When you remove the storage card and insert it in another phone, the apps on the storage card won't be installed automatically to the other phone. You'll need to reinstall them.

17 Unboxing

Inserting the microSD card

1. Hold the phone face up.

2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—

into the tray eject hole next to the microSD card slot.

3. Push the tip all the way into the hole until the microSD card tray ejects.

4. Pull the microSD card tray out, and place the microSD card—contacts facing down—into the

tray.

5. Insert the microSD card tray back into the slot.

Unmounting the storage card

When you need to remove the storage card while HTC One M9 is on, unmount the storage card first to prevent corrupting or damaging the files in the storage card.

1. From the Home screen, tap > Settings > Storage.

2. Tap Unmount SD card.

18 Unboxing

Removing the microSD card

Make sure to unmount your microSD card before removing it.

1. Hold the phone face up and the top panel facing you.

2. Insert the tip of the tray eject tool that came with your phone—or a small bent paperclip—

into the tray eject hole next to the microSD card slot.

Use the tray eject tool that came with your phone.

3. Push the tip all the way into the hole until the microSD card tray ejects.

4. Pull the microSD card tray out, and remove the microSD card.

After removing the microSD card, make sure that you insert the empty microSD card tray back into the slot.

19 Unboxing

Charging the battery

Before you turn on and start using HTC One M9, it is recommended that you charge the battery.

§ If the battery has been discharged for several days, you may need to charge HTC One M9 for several minutes before powering it on.

§ Use only the adapter and the USB cable that came with HTC One M9 to charge the battery. When the battery power is too low, make sure to use the power adapter to charge, not the USB cable connection with your computer.

1. Insert the small end of the USB cable into the USB connector.

2. Insert the other end of the USB cable into the power adapter.

3. Plug in the power adapter to an electrical outlet to start charging the battery.

§ As a safety precaution, the battery may stop charging to avoid overheating.

§ Avoid charging the battery in hot environments.

§ When you're using the web browser and charging the battery, HTC One M9 may become

warmer. This is normal.

§ To conserve energy, unplug the power adapter from the electrical outlet after you finish charging.

Switching the power on or off

Switching the power on

Press the POWER button until HTC One M9 vibrates.

When you turn on HTC One M9 for the first time, you’ll need to set it up.

20 Unboxing

Switching the power off

1. If the display is off, press the POWER button to turn it back on.

2. Press and hold the POWER button for a few seconds.

3. Tap Power off on the options menu.

21 Phone setup and transfer

Phone setup and transfer

Setting up your new phone for the first time

When you switch on your new phone for the first time, you’ll be asked to set it up.

1. Use AT&T Ready2Go to import contacts, setup email accounts, and more.

2. Then complete the process with the HTC Setup wizard.

Some features that need to connect to the Internet such as location-based services and auto-sync of your online accounts may incur extra data fees. To avoid incurring data fees, disable these features under Settings.

Transferring content from an Android phone

On your old Android® phone, download the HTC Transfer Tool and use it to transfer your content to your new HTC phone. The types of locally stored content on your old phone that the tool can transfer include contacts, messages, calendar events, web bookmarks, music, photos, and videos. Some settings can also be transferred.

§ You need Android version 2.2 or later to use the HTC Transfer Tool on your old phone.

§ If your old phone has Android version 2.1 or an earlier version, you need to use Bluetooth

transfer. For details, see Transferring contacts from your old phone through Bluetooth on page

22.

1. Go to Settings, and then tap Get content from another phone.

2. Choose whether to transfer from an old HTC Android phone or other Android phone.

3. Tap Full transfer, and then tap Next.

4. Follow the steps shown on your new phone to download the HTC Transfer Tool from

Google Play™ to your old phone, install it, and open the tool.

5. When you see a PIN on your old phone, make sure the same PIN also appears on your new

phone before you continue.

If the PIN code doesn't appear, this may mean that your old phone is unable to connect to your new phone. If this happens, try another transfer method.

6. On your old phone, choose the types of content you want to transfer, and then tap Start or Transfer.

22 Phone setup and transfer

7. Wait for the transfer to finish.

8. Tap Done on both phones.

Transferring content from an iPhone

If you have an iPhone®, it's fast and easy to transfer your contacts, messages, and other content when you use HTC Sync Manager.

To find out how, see Transferring iPhone content and apps to your HTC phone on page 135. If you only need to migrate your contacts, you can also use Bluetooth transfer. For details, see

Transferring contacts from your old phone through Bluetooth on page 22.

Transferring iPhone content through iCloud

If you have an iCloud® account, sync iPhone content to your iCloud storage, and then transfer the content to HTC One M9. You can transfer the following types of content from iCloud: contacts, bookmarks, text messages, messages from iMessage®, calendar events, and photos.

1. From the Home screen, tap > Settings > Get content from another phone.

2. Tap iPhone > Import from iCloud backup.

3. Follow the steps shown onscreen to back up your iPhone content to your iCloud storage.

4. Enter your iCloud email address and password, and then tap Sign in.

5. Choose the iPhone backup that you want to transfer to HTC One M9, and then tap Next.

6. Choose the types of content you want to transfer, and then tap Import.

7. Wait for the transfer to finish, and then tap Done.

Only some contact details can be transferred, such as the contact name, photo, postal address, email address, birthdate, anniversary date, and notes.

Transferring contacts from your old phone through Bluetooth

Use Bluetooth if you only need to transfer contacts from an iPhone, a phone that has Android version 2.1 (or earlier version), or other types of phones.

1. From the Home screen, tap > Settings > Get content from another phone.

2. Choose whether to transfer from an Android phone, iPhone, or other phone types.

3. If you chose to transfer from an Android phone, tap Quick transfer.

Or to transfer from iPhone, tap Transfer contacts over Bluetooth.

23 Phone setup and transfer

4. On your old phone, turn Bluetooth on.

5. Follow the onscreen instructions on your old and new phones to pair them and start the data

transfer.

§ Depending on the capabilities of your old phone, you may be able to transfer not only contacts but also other data such as calendar events and text messages through Bluetooth.

§ Use your iCloud storage or HTC Sync Manager to transfer more types of content from an iPhone.

Other ways of getting contacts and other content

There are different ways you can individually add contacts and other content to HTC One M9.

Sync with your computer

Google® Account Google contacts are imported to HTC One M9 after you sign in to your

Social network accounts

Microsoft® Exchange ActiveSync

Outlook.com account Sync personal contacts from your Microsoft Outlook.com account. Phone contacts You can create contacts locally on HTC One M9, if you don't prefer to

nano SIM card Copy all your nano SIM contacts to HTC One M9.

Use HTC Sync Manager to sync contacts, documents, playlists, and more between HTC One M9 and your computer running a Windows® or Mac OS® operating system.

You can also use it to transfer your iTunes® backup that contains contacts, messages, and other content from an iPhone from your computer to HTC One M9.

Google Account. You can also create more Google contacts right from HTC One M9.

HTC One M9 syncs your work contacts from the Microsoft Exchange ActiveSync Server in your workplace.

store them on your online accounts.

Importing contacts with AT&T Ready2Go

Easily import contacts to HTC One M9 through AT&T Ready2Go.

1. Open the AT&T Ready2Go app.

2. Tap Get Started.

3. Sign in to your Google and email accounts.

4. If you want, you can also sign in to your social network accounts or to AT&T services.

5. In the Contacts screen, choose the accounts that you want to import contacts from.

6. After completing the setup, tap Exit.

24 Phone setup and transfer

Transferring photos, videos, and music between your phone and computer

Here are ways you can transfer your media from or to your computer.

§ Connect HTC One M9 to your computer. Your computer will recognize it just like any removable USB drive, and you can copy your media between them.

§ Download and use the HTC Sync Manager software on your computer. You can set it up to automatically get music, photos, and videos off HTC One M9 to your computer. You can also sync playlists from your computer to the phone.

If you have an iPhone, you can also connect it and transfer camera roll photos to your computer using HTC Sync Manager. Then reconnect HTC One M9 and copy them over.

§ Use cloud storage services to put your media in one place so you can manage them anywhere —on your computer, HTC One M9, and other mobile devices.

Using Quick Settings

In the Quick Settings panel, easily turn settings such as Wi-Fi® and Bluetooth on or off.

1. Do any of the following:

§ With two fingers, swipe down from the status bar.

§ Swipe down twice from the status bar.

2. To turn a setting on or off, just tap its tile.

3. To change the options for a setting, press and hold its tile. Or tap .

25 Phone setup and transfer

Customizing Quick Settings

You can remove, replace, or rearrange the tiles in Quick Settings.

1. With two fingers, swipe down from the top of the screen to open Quick Settings.

2. Tap and do one of the following:

§ In the Quick Settings list, press and hold next to the item you want to move and drag it to rearrange the list.

§ Under Hidden items, press and hold and drag it up to make it available in Quick Settings.

There is a limit to the number of tiles that can be shown in Quick Settings. You may need to remove an existing item to make space for another one. To remove an item, drag it below Hidden items.

Getting to know your settings

Want to change the ringtone, set up a Wi-Fi connection, or add your accounts? Do this and more in Settings.

1. Open Settings either from the Notifications panel or the Apps screen.

§ Swipe down from the status bar, and then tap .

§ From the Home screen, tap to switch to the Apps screen, and then tap Settings.

2. Here are some of the basic settings you can change:

§ Tap the On/Off switch next to an item such as Wi-Fi to turn it on or off. Tap the item itself to configure its settings.

§ Tap Sound & notification to set a ringtone, choose a sound profile, and configure incoming call sound settings.

§ Tap Personalize to change the wallpaper, add apps and widgets to the Home screen, and more.

§ Tap Accounts & sync to add and sign in to your different accounts, such as email, social networks, and more.

§ Tap Security to help secure HTC One M9, for example with a screen lock.

Tap

in Settings to quickly find options and settings.

26 Phone setup and transfer

Updating your phone's software

HTC One M9 can check and notify you if there’s a new update available. You can also choose to automatically download updates or manually check if there's an available update.

Visit www.htc.com/us/go/htc-software-updates/ for news and details about your phone's software updates.

Checking for AT&T updates manually

Use your phone’s data connection to manually check for and download AT&T updates for your phone.

A data connection must be active before checking for AT&T updates.

1. From the Home screen, tap , and then find and tap Settings.

2. Tap AT&T software update > Check for updates.

Checking your system software version

Before installing a system software update, you can check first what Android and HTC Sense versions you have on your phone.

1. From the Home screen, tap > Settings > About.

2. Tap Software information.

Installing app updates from Google Play

Some HTC apps and third-party apps get updated with improvements and bug fixes through Google Play. You can manually update apps or set your phone to automatically download and install app updates when available.

1. From the Home screen, tap , and then find and tap Play Store.

2. Tap to open the slideout menu.

3. Tap My apps.

You'll see a list of apps installed on your phone.

4. Under Updates, tap an app.

5. Tap Update.

6. Tap Accept.

In Play Store, tap update your apps.

> Settings > Auto-update apps to choose how you want Google Play to

27 Phone setup and transfer

Getting apps from Google Play

Google Play is the place to go to find new apps for HTC One M9. Choose from a wide variety of free and paid apps ranging from productivity apps, entertainment, to games.

You need a Google Wallet™ account to buy paid apps or to make in-app purchases. If you already have a Google Account, just add Google Wallet by signing in with your existing username and password at wallet.google.com.

Finding and installing an app

When you install apps and use them on HTC One M9, they may require access to your personal information or access to certain functions or settings. Download and install only apps that you trust.

Be cautious when downloading apps that have access to functions or a significant amount of your data on HTC One M9. You’re responsible for the results of using downloaded apps.

1. From the Home screen, tap , and then find and tap Play Store.

2. Browse or search for an app.

3. When you find the app that you like, tap it and read its description and user reviews.

4. To download or purchase the app, tap Install (for free apps) or the price button (for paid

apps).

5. Tap Accept.

Apps sometimes get updated with improvements or bug fixes. To automatically download updates, after installing the app, tap > Auto-update.

To open the app, go to the Apps screen and tap the app.

Restoring apps from Google Play

Upgraded to a new phone, replaced a lost one, or performed a factory reset? Restore apps that you previously downloaded.

1. From the Home screen, tap , and then find and tap Play Store.

2. Tap to open the slideout menu.

3. Tap My apps, swipe to the All tab, and then tap the app you want to restore.

4. Install the app.

For more details, refer to the Google Play help.

28 Phone setup and transfer

Downloading apps from the web

You can download apps directly from websites.

§ Apps downloaded from websites can be from unknown sources. To help protect HTC One M9 and your personal data, we strongly recommend that you only download from websites you trust.

§ Before you can install the downloaded app, make sure that you've set HTC One M9 to allow installation of third-party apps in Settings > Security > Unknown sources.

1. Open the browser, and then go to the website where you can download the app you want.

2. Follow the website's download instructions for the app.

After installing the app, make sure to go back to Settings > Security and clear the Unknown sources option.

Uninstalling an app

If you no longer need an app that you've downloaded and installed, you can uninstall it.

Most of the preloaded apps cannot be uninstalled.

From the Apps screen, press and hold the app you want to remove, and then drag it to Uninstall.

If you purchased an app in Play Store, you can uninstall it for a refund within a limited time. To know more about the refund policy for paid apps, refer to the Google Play help.

29 Your first week with your new phone

Your first week with your new phone

Basics

HTC Sense Home

After you've turned on and set up HTC One M9 for the first time, you'll see the Home screen.

§ Set up the HTC Sense Home widget to experience the convenience of a Home screen that automatically adjusts when you're at home, work, or outdoors. See What is the HTC Sense

Home widget? on page 39.

§ Swipe right and you'll find HTC BlinkFeed®. You can customize HTC BlinkFeed to show posts from your social networks, headlines from your favorite news media, and more. For details, see What is HTC BlinkFeed? on page 64.

§ Swipe left and you’ll discover space for adding your favorite widgets, apps, and more so they’re just a tap away. You can also add panels. For details, see Adding or removing a widget

panel on page 60.

§ You can change the apps on the launch bar at the bottom of the Home screen. See Launch bar on page 58.

While you're in another screen or app, press

to return to the last Home screen you visited.

Onscreen navigation buttons

HTC One M9 has onscreen navigation buttons at the bottom of the screen which rotate when you change the orientation.

Standard navigation buttons

Back

Home

Recent apps

30 Your first week with your new phone

Fourth navigation button options

Hide navigation bar

Turn off screen

Auto rotate

Notifications

Quick settings

See Adding a fourth navigation button on page 30.

Adding a fourth navigation button

You can add a fourth navigation button to make it easier to turn the display off, toggle auto-rotate, and more.

1. From the Home screen, tap > Settings > Personalize.

2. Tap Change navigation buttons.

3. Tap a fourth navigation button to add it. To have only three navigation buttons, make sure

none of the fourth button options are selected.

4. Tap Done to save and apply your customization.

Rearranging the navigation buttons

Right-handed or left-handed? Customize the placement of the navigation buttons to fit what's most comfortable for you.

1. From the Home screen, tap > Settings > Personalize.

2. Tap Change navigation buttons.

3. Rearrange the navigation buttons by dragging next to the button names. The resulting

order from top to bottom in the list will be the corresponding order from left to right on the navigation bar.

4. Tap Done to save and apply your customization.

31 Your first week with your new phone

Sleep mode

Sleep mode saves battery power by putting HTC One M9 into a low power state while the display is off. It also stops accidental button presses when HTC One M9 is in your bag.

Switching to Sleep mode

To turn off the display and switch to Sleep mode, you can:

§ Briefly press the POWER button.

§ Double-tap the lock screen.

HTC One M9 also automatically goes into Sleep mode when it’s left idle for a while. You can change the time before HTC One M9 sleeps by setting the screen timeout. For details, see Setting when to

turn off the screen on page 182.

Waking up from Sleep mode

§ Press the POWER button.

§ Use Motion Launch™ to wake up and unlock your phone directly to an app or screen. See

What is Motion Launch? on page 41.

Unlocking the screen

Swipe up to unlock the screen. If you've set up a screen lock, you'll be asked to provide your credentials before HTC One M9

unlocks.

If you've set an event reminder or an alarm, you can snooze or dismiss the event or alarm right from the lock screen. Just drag or up.

Motion gestures

Use motion gestures to mute HTC One M9, lower the ring volume, and more.

Lift phone to auto answer a call

To automatically answer an incoming call, lift the phone and look at the screen first to see who's calling before you hold it to your ear.

You can turn this feature on or off. Go to Settings, tap Call, and then select or clear Auto answer calls.

32 Your first week with your new phone

Flip to mute

If your phone is facing up when a call comes in, turn the phone over to mute it.

If you go to Settings and then tap Sound & notification > Flip to mute, you can set your phone to:

Pick up to lower volume

Mute once

Mute always

In a business meeting or restaurant, pick HTC One M9 up when a call comes in to lower the ring volume automatically.

You can turn this feature on or off. Go to Settings, tap Sound & notification, and then select or clear Quiet ring on pickup.

Mute only once after flipping the phone. While the phone is still facing down, it will ring again when there are other incoming calls.

After flipping the phone to mute a call, keep it always muted while it's still facing down when there are other incoming calls.

Increase ring volume automatically while phone is in your pocket or bag

Pocket mode makes HTC One M9 recognize when your phone is in your bag or pocket and raise the ring volume so that you can hear it in noisy environments.

You can turn this feature on or off. Go to Settings, tap Sound & notification, and then select or clear Pocket mode.

33 Your first week with your new phone

Rotate HTC One M9 for a better view

For many screens, you can automatically change the screen orientation from portrait to landscape by turning HTC One M9 sideways.

When entering text, you can turn HTC One M9 sideways to bring up a bigger keyboard.

Touch gestures

Use touch gestures to get around the Home screen, open apps, scroll through lists, and more.

Tap

§ Tap the screen with your finger when you want to select onscreen items such as application and settings icons, or press onscreen buttons.

Press and hold

§ After you've scrolled down a long list or screen (in apps such as Mail and Contacts), tap the status bar to jump straight to the top of your screen.

To open the available options for an item (for example, a contact or link in a webpage), just press and hold the item.

34 Your first week with your new phone

Swipe or slide

Quickly swipe your finger horizontally across the screen to go to other Home screen panels. Swipe vertically to scroll through a list, document, and more.

Drag

Press and hold your finger with some pressure before you start to drag. While dragging, don't release your finger until you have reached the target position.

Flick

Flicking the screen is similar to swiping, except that you need to swipe your finger in light, quicker strokes, such as when moving right and left on the Home screen, or flicking through a contacts or message list.

35 Your first week with your new phone

Press and flick

Slide with two fingers

On the Home screen, you can easily move a widget or icon from one screen to another.

Press and hold the widget or icon with one finger, and flick the screen to the new location with another finger.

In some apps, like Gallery, Messages, Mail, or the web browser, slide two fingers apart to zoom in when viewing a picture or text.

Slide two fingers together to zoom out of the picture or text.

36 Your first week with your new phone

Two-finger swipe

Swipe down from the status bar using two fingers to access Quick Settings.

Three-finger swipe

§ Swipe up the screen with three fingers and HTC Connect streams music or video from HTC One M9 to your speakers or TV respectively. You can also share streaming media from apps such as YouTube®.

§ Swipe down to disconnect from your speakers or TV.

Media gesture is turned on in Settings by default, which makes the three-finger gesture work for sharing media.

Three-finger tap

While using the Car app, tap the screen with three fingers to activate the voice command mode.

37 Your first week with your new phone

This feature may not be available in all languages.

Opening an app

§ Tap an app on the launch bar at the bottom of the Home screen.

§ Tap to go to the Apps screen, and then tap the app you want to use.

§ On the Apps screen, tap , and then enter the name of the app you're looking for.

Opening an app or folder from the lock screen

On the lock screen, drag an app or folder icon up to unlock the screen and directly go to the app or folder.

The shortcuts on the lock screen are the same ones on your Home screen's launch bar. To change the lock screen shortcuts, replace the apps or folders on the launch bar.

If you've set up another security layer like a screen lock pattern or PIN, you'll be asked to provide your credentials first before HTC One M9 opens the app or folder.

Sharing content

Have something to share, such as a photo or video?

§ In an app, just tap the share icon: or .

§ If you don't see the icon, tap > Share.

Switching between recently opened apps

When you're multitasking and using different apps on HTC One M9, you can easily switch between the apps you've recently opened.

Press to see recently-opened apps.

§ To switch back to an app, just tap it.

§ To remove an app from the list in grid view, drag it up.

If you're using the card view, drag it left or right.

§ Tap > Settings > Layout, and then choose between card or

grid view.

38 Your first week with your new phone

Refreshing content

In some apps, you can easily refresh content that's synced or downloaded from the Web with a simple finger gesture.

1. While viewing content such as weather or Mail inbox, scroll to the top of the screen.

2. Pull down with your finger, and then release to refresh.

Capturing your phone's screen

Want to show off your high game score or write a blog post about HTC One M9 features? It's easy to take a picture of the screen and share it from Gallery.

Press and hold POWER and VOLUME DOWN at the same time. The image is saved in the Screenshots album in Gallery.

You can also share the image when you see and tap under the screenshot notification. If you don't see , slide two fingers apart on the screenshot notification.

in the status bar. Open the Notifications panel

39 Your first week with your new phone

HTC Sense Home widget

What is the HTC Sense Home widget?

Get quick access to apps, shortcuts and folders you use most frequently based on where you are. With the HTC Sense Home widget, HTC One M9 continually adapts to how you use it. For example, apps you use most frequently for work, will show up when you're at your office. The HTC Sense Home widget changes depending on whether you're at home, work, or somewhere else.

Setting up the HTC Sense Home widget

Setting up the HTC Sense Home widget is quick and easy.

§ If you don't see the HTC Sense Home widget, add it to your Home screen. See Adding Home

screen widgets on page 59.

§ Make sure you turn on location services in your phone settings. See Turning location services on

or off on page 181.

1. On the setup screen of the HTC Sense Home widget, tap Tap to personalize > Let's explore.

2. Tap where you are to finish setting up the widget.

3. On the widget, tap > > Personalize HTC Sense Home.

4. Select all the options on the screen, and then press .

Setting your home and work locations

You can change the address for your home and work locations if you ever move to a new home or change your job.

1. On the Home screen, swipe right or left until you see the HTC Sense Home widget.

2. Tap > > Set locations.

3. Tap the address area to search for the address you want to set.

4. When you've found the address on the map, tap Done.

40 Your first week with your new phone

Manually switching locations

The HTC Sense Home widget automatically changes locations based on where you are. You can also manually change the location in the HTC Sense Home widget.

For the HTC Sense Home widget to change locations automatically, you need to make sure that location services is turned on. See Turning location services on or off on page 181.

1. On your Home screen, slide right or left until you see the HTC Sense Home widget.

2. Tap , and then tap the location you want.

Pinning and unpinning apps

Pinning apps, shortcuts, or folders to the HTC Sense Home widget ensures they stay on the widget. Items in the HTC Sense Home widget will have one of two states: pinned or unpinned. Unpinned

items will be automatically changed to more frequently used items.

1. On the Home screen, swipe right or left until you see the HTC Sense Home widget.

2. Do one of the following:

§ To pin an item, press and hold it until you see .

§ To unpin an item, press and hold it until the unpinning progress bar has completed.

Adding apps to the HTC Sense Home widget

Add your favorite apps, shortcuts, or folders to the HTC Sense Home widget.

1. From the Home screen, tap .

2. Press and hold the app, shortcut, or folder you want to add to the widget.

3. Drag the item to where you want in the HTC Sense Home widget.

The app, shortcut or folder will be added to the HTC Sense Home widget and pinned in place.

Turning smart folders on and off

Smart folders are folders in the HTC Sense Home widget that dynamically change contents depending on the apps you download and use. If you don't want to see recently downloaded or recommended apps, you can turn off the smart folders.

1. On the Home screen, swipe right or left until you see the HTC Sense Home widget.

2. Tap , and then tap > Show/hide smart folders.

41 Your first week with your new phone

3. Select the smart folders you want to show or hide.

4. Tap OK.

Motion Launch

What is Motion Launch?

Motion Launch is a combination of a motion gesture followed by a finger gesture. With Motion Launch, you don't have to reach for the POWER button to wake up HTC One M9. Using a combination of simple gestures, you can wake up to your Home screen, HTC BlinkFeed, and more.

See the following:

§ Waking up to the lock screen on page 41

§ Waking up and unlocking on page 42

§ Waking up to the Home widget panel on page 42

§ Waking up to HTC BlinkFeed on page 43

§ Auto launching the camera with Motion Launch Snap on page 44

§ Making a call with Quick call on page 44

Turning Motion Launch gestures on or off

Choose the Motion Launch gestures you want on or off in Settings.

1. With two fingers, swipe down from the top of the screen to open Quick Settings.

2. Tap > Display & gestures or Display, gestures & buttons.

3. Tap Motion Launch gestures.

4. Select the Motion Launch gestures you want.

Waking up to the lock screen

Go from sleep mode to the lock screen without reaching for the POWER button.

If you've set up a screen lock with credentials, you'll be asked to provide your credentials first before HTC One M9 unlocks.

42 Your first week with your new phone

1. Lift the phone in portrait orientation.

2. Immediately double-tap the screen.

Make sure you're not touching the screen when the phone vibrates.

Waking up and unlocking

Go from sleep mode and unlock HTC One M9 to the last screen you were using without reaching for the POWER button.

If you've set up a screen lock with credentials, you'll be asked to provide your credentials first before HTC One M9 unlocks.

1. Lift the phone in portrait orientation.

2. Immediately swipe up from the bottom half of the screen.

Make sure you're not touching the screen when the phone vibrates.

Waking up to the Home widget panel

Go from sleep mode to the Home widget panel without reaching for the POWER button.

If you've set up a screen lock with credentials, you'll be asked to provide your credentials first before HTC One M9 unlocks.

43 Your first week with your new phone

1. Lift the phone in portrait orientation.

2. Immediately swipe left from the right side of the screen.

Make sure you're not touching the screen when the phone vibrates.

Waking up to HTC BlinkFeed

Go from sleep mode to HTC BlinkFeed without reaching for the POWER button.

If you've set up a screen lock with credentials, you'll be asked to provide your credentials first before HTC One M9 unlocks.

1. Lift the phone in portrait orientation.

2. Immediately swipe right from the left side of the screen.

Make sure you're not touching the screen when the phone vibrates.

44 Your first week with your new phone

Auto launching the camera with Motion Launch Snap

When the screen is off, you can wake up the phone directly to the Camera app.

§ Press and hold the VOLUME UP or VOLUME DOWN button, and then lift the phone in landscape orientation.

§ Or first lift the phone in landscape orientation, and then press the VOLUME UP or VOLUME DOWN button right away.

If you've set up a screen lock with credentials, you'll be asked to provide your credentials when you exit the Camera app.

Making a call with Quick call

When the screen is off and HTC One M9 is in sleep mode, easily make a call by just swiping and using voice commands.

§ This feature may not be available in all languages.

§ Make sure Motion Launch gestures and Quick call are turned on in Settings > Display &

gestures > Motion Launch gestures.

§ If you've set a screen lock with credentials, you'll be asked to provide your credentials first before you can make the call.

1. Lift the phone in portrait orientation.

2. Immediately swipe down from the top half of the screen.

45 Your first week with your new phone

3. When you see the microphone icon on the screen, hold the phone close to your mouth, and

then say "Call" and the contact name. For example, say "Call Jennifer".

4. You can then do one of the following:

§ If there are several contacts with the same first name, say the full name of the contact you want to call.

§ If a contact has several phone numbers, you'll see the following:

1.[full name] Home

2.[full name] Mobile

3.[full name] Work

Just say the item number of the one you want to call. For example, say "2" to call the second one.

Or say the full name and type of phone number as shown on the screen. For example, say "Jennifer Singer Mobile".

§ If you're asked to confirm, say "Yes" or "No".

§ To cancel the call, say "Cancel".

Bypassing the screen lock for Quick call

If you've set a screen lock with credentials, you can set HTC One M9 to skip the security screen so you can immediately place calls with Quick call.

1. With two fingers, swipe down from the top of the screen to open Quick Settings.

2. Tap > Display & gestures or Display, gestures & buttons.

3. Tap Motion Launch gestures.

4. Select the Bypass Security screen option.

46 Your first week with your new phone

Lock screen

Setting a screen lock

Help protect your personal information and help prevent others from using HTC One M9 without your permission.

Choose to set a screen lock pattern, numeric PIN, or other means of securing your phone. You'll be asked to unlock the screen every time HTC One M9 is turned on or when it’s idle for a certain period of time.

1. From the Home screen, tap > Settings > Security.

2. Tap Screen lock.

3. Select a screen lock option and set up the screen lock.

4. Tap Lock phone after, then specify the idle time before the screen is locked.

You can also clear Make pattern visible or Make passwords visible if you don’t want your screen lock to display as you enter it onscreen.

Setting up Smart Lock

Set up your phone to detect your face or another trusted device before you can unlock the screen.

1. From the Home screen, tap > Settings > Security.

2. Tap Screen lock, and then select and set up a screen lock.

This will be your backup screen lock method.

3. On the Security screen, tap Smart Lock.

4. Confirm your screen lock.

5. Choose what you want your phone to detect before it unlocks.

6. Follow the onscreen instructions.

7. Tap Lock phone after, and then specify the idle time before the screen is locked.

To help make Smart Lock more reliable and more secure, you can to train HTC One M9 to recognize your face in different situations, such as when you're wearing glasses or sporting a beard.

Tap Smart Lock, confirm your screen lock, then tap Trusted face > Improve face matching. Follow the onscreen instructions.

Turning lock screen notifications on or off

You can choose to turn lock screen notifications on or off.

1. From the Home screen, tap > Settings > Sound & notification.

2. Tap When device is locked > Don't show notifications at all.

If you change your mind later, you can tap notifications on.

Show all notification content to turn lock screen

47 Your first week with your new phone

Interacting with lock screen notifications

Besides seeing notifications on the lock screen, you can also interact with them.

1. Tap twice on a notification to go directly to the related app.

2. To see the entire list of notifications on the lock screen, swipe down on the lock screen. You

can tap on a blank area of the screen to return to the lock screen.

3. Swipe left or right on the notification to remove it.

4. Press and hold a notification to see more related information.

5. Tap

to prioritize or block notifications from the related app.

HTC BlinkFeed Notifications

From time to time, you'll see HTC BlinkFeed notifications, such as a suggestion for a nearby restaurant or a recommended article.

1. Double-tap the notification to see the full notification.

For restaurant recommendations, tap or the notification text.

2. Tap the notification again to get more information about the restaurant recommendation or

to read the article in HTC BlinkFeed.

If you don't want to see restaurant recommendations on your lock screen, go to HTC BlinkFeed, and then tap > > Settings > Notification on lock screen. Then clear the Meal time bundle option.

Changing lock screen shortcuts

To change apps (or other shortcuts) on the lock screen, change the ones on the launch bar. To find out how, see Launch bar on page 58.

Changing the lock screen wallpaper

Use the home wallpaper, or use any photo you've taken with the camera as the lock screen wallpaper.

1. From the Home screen, tap

2. Under Lock screen, tap Change wallpaper.

3. In the pop-up menu, tap Use home screen wallpaper or tap Use custom wallpaper to select

a photo from Gallery.

> Settings > Personalize.

Turning the lock screen off

Rather not have to unlock your phone every time you wake it up? You can turn the lock screen off in Settings.

1. From the Home screen, tap

2. Tap Screen lock > No lock screen.

To turn the lock screen on again, in Security settings, tap Screen lock > Lock screen.

> Settings > Security.

48 Your first week with your new phone

Notifications

Notifications panel

Notification icons inform you of new messages, calendar events, alarms, and activities in progress such as files downloading.

When you see notification icons, open the Notifications panel to check out details of the notifications that you've received.

To open the Notifications panel, slide down from the top of the screen.

§ Some notifications allow you to take immediate action. For example, tap a missed call notification to return the call or reply with a text message.

§ Tap the notification icon on the left to open the corresponding app.

§ To dismiss just one notification in the list, drag it left or right. To dismiss all notifications and

close the Notifications panel, tap .

If you have several notifications, scroll through the list screen to see them all.

You can change what app notifications you want to receive. See Managing app notifications on page 49.

49 Your first week with your new phone

Managing app notifications

You can set the priority of app notifications or completely block notifications for apps you don't want to be notified about.

1. From the Home screen, tap > Settings > Sound & notification.

2. Tap App notifications, and then tap the app you want manage.

You can also press and hold a notification in the notifications panel, and then tap .

3. Tap the On/Off switch next to Block or Priority depending on what you want to do.

Settings for app notifications are applied to notifications in the Notifications panel and the lock screen.

Notification LED

The notification LED shows a:

§ Solid green light when HTC One M9 is connected to the power adapter or a computer and the battery is fully charged.

§ Flashing green light when you have a pending notification.

§ Solid orange light when the battery is being charged.

§ Flashing orange light when the battery level reaches very

low.

Choosing when to flash the notification LED

You can change when to flash and which apps will flash the LED when there are new notifications.

1. From the Home screen, tap > Settings > Sound & notification.

2. Under Notification, tap Flash notifications. Choose whether to always flash the LED or flash

it only when the screen is off.

3. Tap App light notifications. Choose which app notifications you want the LED to flash for.

In other apps, check their settings to find out if they have an option for flashing the LED.

50 Your first week with your new phone

Working with text

Selecting, copying, and pasting text

In HTC apps such as Mail and Messages, you can select and copy text, and then paste or share it.

1. Press and hold on a word.

2. Drag the start and end anchors to highlight the surrounding text you want to select.

3. After you have selected the text you want to copy, tap .

The selected text is then copied to the clipboard.

4. In a text entry field (for example while composing an email), press and hold at the point

where you want to paste the text.

5. Tap or Paste.

Sharing text

1. After you have selected the text you want to share, tap .

2. Choose where to paste and share the selected text, such as in an email message or social

network status update.

The HTC Sense keyboard

Typing is fast and accurate with the HTC Sense keyboard.

§ Word prediction also saves typing time. As you type, you'll see word suggestions that you can choose from. You can even add words to the word prediction dictionary. See Entering text

with word prediction on page 52.

§ You can type words by just speaking. See Entering text by speaking on page 53.

§ Turn on the Trace keyboard so you can type words by just sliding your finger from one letter

to another. See Using the Trace keyboard on page 53.

§ Just swipe right to access the numeric and symbol keyboard. Or swipe left to switch between languages.

§ The keys have secondary numbers, punctuation symbols, or other characters that you can insert without having to switch to the numeric and symbol keyboard.

For example, just press and hold a key on the first row to insert a number.

51 Your first week with your new phone

§ Choose from a wide selection of emoji.

§ Show or hide navigational arrow keys on the keyboard. If you enable the arrow keys in

Settings, they'll only appear on the portrait keyboard.

Entering text

The onscreen keyboard becomes available when you tap a text field in an app. Tap the keys on the onscreen keyboard to enter letters and numbers, as well as punctuation marks

and symbols.

§ Tap to enter an uppercase letter. Tap twice to turn on caps lock.

§ Press and hold keys with gray characters at the top to enter numbers, symbols, or accented

letters. Some keys have multiple characters or accents associated with them.

§ Swipe right to show number and symbol keys. To return to the main keyboard, swipe left.

§ Press to close the onscreen keyboard.

To open the keyboard settings, press and hold the comma key if you see

above the key. Or go

to Settings > Language & keyboard > HTC Sense Input.

Selecting a keyboard layout

Choose a keyboard layout that suits your typing style.

1. Go to Settings, and then tap Language & keyboard > HTC Sense Input.

2. Tap Keyboard selection > Keyboard types.

3. Select the keyboard layout that you want to use.

Choosing and switching between keyboard languages

If multiple keyboard languages are available on HTC One M9, you can choose which languages to enable in the onscreen keyboard.

1. Go to Settings, and then tap Language & keyboard > HTC Sense Input.

2. Tap Keyboard selection, and then choose the languages you want.

To change the keyboard language, do any of the following:

§ Swipe left on the onscreen keyboard (not available if you're using trace keyboard).

§ Tap the language key, for example, , until you see the keyboard language you want to use.

§ Press and hold the language key, and then drag your finger to the keyboard language you

want to use.

52 Your first week with your new phone

Entering text with word prediction

Ever started typing something you weren't sure how to spell? With word prediction, you'll see suggested words displayed just above the keyboard.

Word prediction and next word prediction are enabled by default.

To enter text in word prediction mode, do any of the following:

§ Tap the space bar to insert a highlighted word in the suggestion list.

§ Tap a word from the suggestion list.

§ Tap the arrow next to the suggestion list to see more choices.

In some keyboard languages such as English and Spanish, if you've accidentally chosen a wrong word from the suggestion list, you can go back and change it by tapping the word and selecting another suggestion.

Setting a second language for word prediction

You can set the word prediction to be bilingual. As you type, you’ll get word suggestions in the languages that you’ve selected.

This feature is available only for Latin-based languages.

1. Go to Settings, and then tap Language & keyboard > HTC Sense Input.

2. Tap Keyboard selection > Bilingual prediction, and then choose the language you want.

Adding words to the dictionary

For certain keyboard languages such as English and Spanish, you can add frequently-used names and acronyms to the word prediction dictionary to easily find them in the suggestion list.

This feature is available only for Latin-based languages.

Go to Settings, and then tap Language & keyboard > HTC Sense Input.

2. Tap Personal dictionary > .

3. Enter a word.

4. Tap OK.

While you're entering text using the Standard keyboard layout, tapping a suggested word that’s not in the dictionary (usually the first word shown in the suggestion list) automatically stores it.

53 Your first week with your new phone

Editing or deleting words in the dictionary

1. Go to Settings, and then tap Language & keyboard > HTC Sense Input.

2. Tap Personal dictionary.

§ To edit a word, tap the item in the list.

§ To delete items from the dictionary, tap > Delete. Select the words you want to

remove, and then tap Delete.

Using the Trace keyboard

Instead of tapping the keys on the onscreen keyboard, you can "trace" to type words.

This feature is available only for Latin-based languages.

1. Turn on the Trace keyboard in Settings > Language & keyboard > HTC Sense Input.

2. On the onscreen keyboard, slide your finger from one letter to the next to enter a word.

3. Lift your finger when the word is completed.

4. If you want to continue entering text, slide your finger over the letters again to enter the next

word.

If the word that appears after you traced isn't the one you want, you can:

§ Tap a word from the suggestion list.

§ Tap the arrow next to the suggestion list to see more choices.

Entering text by speaking

No time to type? Try speaking the words to enter them.

1. Tap an area where you want to enter text.

2. On the onscreen keyboard, press and hold .

3. When you see the animated microphone button and the words "Speak now", say the words

you want to enter.

To set the voice input language, tap the language bar above the microphone button. You can choose one or more languages. Available languages may vary.

4. If a word doesn't match what you've spoken and it's underlined, tap the underlined word to

delete it or to see more choices.

5. Enter punctuation marks by saying the name (for example, say "comma").

54 Personalizing

Personalizing

Themes

What is the Themes app?

Themes brings a quick and easy way for you to customize HTC One M9 with wallpapers, sounds, icons, and more.

Downloading themes

Find and download pre-made themes that make it easy for you to personalize your HTC One M9.

1. From the Home screen, tap , and then find and tap Themes.

2. Tap Get Started.

3. Sign in with your preferred account.

4. On the Recommended screen, swipe left or right under each category to browse

Bookmarking themes

While browsing themes, you can bookmark them you so that you can easily find them later.

1. From the Home screen, tap , and then find and tap Themes.

2. Browse the categories to find something you like.

3. Tap the item and then tap . You'll find the bookmark in My themes. See Finding your

themes on page 56.

You can remove the bookmark by tapping

again.

55 Personalizing

Creating your own theme from scratch

You can create and customize your own theme and even share it for others to download.

1. From the Home screen, tap , and then find and tap Themes.

2. Tap > Choose Home image to set the main wallpaper for your theme.

3. Select an image from Gallery or take a photo with Camera.

4. Move or enlarge the crop box to the area of the image you want to include and tap Done.

5. Tap Next.

6. Swipe up or down to the pre-defined style to select for your theme. If you don't want to customize your theme further, tap Next to save your theme.

7. Tap Edit, then tap any of the categories you want to customize, and experiment with the

settings until you're satisfied.

8. When you're ready, tap Preview to see what your theme will look like.

9. Tap Finish, then name your theme and tap OK to save your theme. To apply the theme right away, make sure you select the Apply this theme now option.

Editing a theme

After creating a theme, you can still edit it.

1. From the Home screen, tap , and then find and tap Themes.

2. Tap > My themes > My current theme.

3. Make the changes you want to the theme.

4. Tap Save to update the current theme.

Mixing and matching themes

After selecting a theme, you can mix and match parts from other themes such as sounds, icons, wallpapers. and more.

To mix and match themes, you need to first download theme components from the catalog.

From the Home screen, tap , and then find and tap Themes.

2. Tap > My themes > My current theme.

3. Tap Color and select a color scheme.

4. Tap any of the other categories you want to change.

5. Tap an item in the category. If the category is empty, tap and choose one of the

collections to select from.

6. Tap Apply to apply the change to your current theme.

56 Personalizing

7. Tap until you see the mix and match screen. Continue making changes until you're satisfied with the result.

8. Tap Save copy to save your new theme, or if you're editing a theme that you copied tap Save to save the changes.

Finding your themes

Themes you created or downloaded can be found in your theme collection. You'll also find the themes you bookmarked.

1. From the Home screen, tap , and then find and tap Themes.

2. Tap > My themes.

Sharing themes

Share themes, wallpapers, icons, and more with friends and family.

1. From the Home screen, tap , and then find and tap Themes.

2. Browse to the theme you want to share and tap it to view the details.

3. While viewing the details page of any item in the catalog, tap to share.

Deleting a theme

You can delete a theme if you no longer want to keep it on your phone.

1. From the Home screen, tap , and then find and tap Themes.

2. Tap > My themes, and then swipe to the My collection tab.

3. Tap > Remove.

4. Tap the themes you want to remove from your collection.

5. Tap Delete.

If the theme you deleted is currently applied, it will still be applied to HTC One M9 until another theme is applied.

57 Personalizing

More ways to personalize

Personalization settings

Aside from using Themes, you can also make HTC One M9 look and sound the way you want in Settings.

§ Choose a ringtone and other sounds that you like to use. See Ringtones, notification sounds,

and alarms on page 57.

§ Personalize your Home screen with a different wallpaper. See Home wallpaper on page 57.

§ For the lock screen, you can use the same wallpaper as your Home screen or choose a

different wallpaper. See Changing the lock screen wallpaper on page 47.

§ Change the fonts. See Changing the display font on page 58.

§ Change the apps on the launch bar. See Launch bar on page 58.

§ Populate your Home screen with widgets and shortcuts. See Adding Home screen widgets on

page 59 and Adding Home screen shortcuts on page 59.

§ Need another widget panel? See Adding or removing a widget panel on page 60.

§ Set HTC BlinkFeed or a widget panel as your main Home screen. See Changing your main

Home screen on page 61.

§ Organize your apps. See Arranging apps on page 62.

Ringtones, notification sounds, and alarms

1. From the Home screen, tap > Settings > Personalize.

2. Under Sound, choose different sounds for your ringtone, system notification, and alarm.

Go to the Messages, Mail, and Calendar apps to choose sounds for new messages, email, and event reminders respectively.

Want alarms to ring louder but notifications to be more discreet? In Settings, tap Sound &

notification > Volumes and set the volume levels for each sound type.

Home wallpaper

Choose from the available wallpapers, or use any photo you've taken with the camera.

1. Press and hold an empty space on a widget panel.

2. In the pop-up menu, tap Change Home screen wallpaper.

3. Choose from where you want to select a wallpaper.

To use a photo you captured with the camera, tap Gallery, choose and crop a photo, and then tap Done.

58 Personalizing

Changing the display font

You can change the font style and size of the display font or you can download new fonts online.

1. From the Home screen, tap > Settings > Personalize.

2. Under Font, tap Font style and choose one of the built-in fonts or tap to go online and

download new fonts.

3. Tap Font size to choose the size of the font.

Downloading fonts

You must be logged on to your HTC Account to download fonts.

1. From the Home screen, tap > Settings > Personalize.

2. Under Font, tap Font style and then tap .

3. Tap to select a category.

4. Select a font style, and then tap Download.

5. Tap Apply.

Launch bar

The launch bar gives you one-touch access to commonly used apps (and other shortcuts). You can replace the apps on the launch bar with the ones you often use.

1. Press and hold the app you want to replace, and then drag it out to .

2. Tap to go to the Apps screen.

3. Press and hold an app, and then drag it to the empty slot on the launch bar.

§ You can also group apps on the launch bar into a folder. See Grouping apps on the widget panel

and launch bar on page 62.

§ The apps (or other shortcuts) on the lock screen are the same as the ones on the launch bar.

59 Personalizing

Adding Home screen widgets

Widgets make at-a-glance important information and media content easily available. Choose from a selection of widgets and add the most useful ones to your Home screen.

1. Press and hold an empty space on a widget panel.

2. In the pop-menu, tap Add apps and widgets.

3. Tap > Widgets.

4. Scroll through the widgets, or tap to search for a specific widget.

Some widgets are available in different styles and sizes.

5. Press and hold and then drag the widget to a widget panel you want to add it to.

You can also add widgets that allow you to quickly switch on or off certain settings such as Wi-Fi and Bluetooth.

Changing the settings of a widget

You can modify basic settings of some widgets (for example, the Contacts widget).

1. Press and hold a widget on your Home screen, and then drag it to .

2. Customize the widget settings.

Resizing a widget

Some widgets can be resized after you've added them to your Home screen.

1. Press and hold a widget on the Home screen, and then release your finger. If a border

appears, that means the widget is resizable.

2. Drag the sides of the border to enlarge or shrink the widget size.

Adding Home screen shortcuts

Place apps you often use on any widget panel of your Home screen. You can also add shortcuts to frequently used settings, bookmarked webpages, and more.

1. Press and hold an empty space on a widget panel.

2. In the pop-up menu, tap Add apps and widgets.

3. Tap > Apps or Shortcuts.

60 Personalizing

4. Scroll through the apps or shortcuts, or tap to search for one.

5. Press and hold and then drag an app or a shortcut to a widget panel you want to add it to.

To add an app from the Apps screen, press and hold the app, and then drag it to a widget panel.

Editing Home screen panels

Adding or removing a widget panel

§ You won't be able to add a new widget panel if you've already reached the maximum limit.

§ HTC BlinkFeed always appears as the first panel (if it's not removed). A widget panel cannot be

added before HTC BlinkFeed.

1. Press and hold an empty space on a widget panel.

2. In the pop-up menu, tap Manage home screen pages.

3. To add a new widget panel, swipe left until you see the icon, and then tap it.

4. To remove a widget panel, swipe left or right until you see the panel, and then tap Remove.

5. When done, press .

Arranging widget panels

A widget panel cannot be moved and inserted before HTC BlinkFeed.

1. On HTC BlinkFeed or any widget panel, slide two fingers together to customize the Home

screen.

2. Press and hold a widget panel thumbnail, and then drag it left or right to the position that you

want.

3. When you're done arranging widget panels, press .

61 Personalizing

Moving a widget or icon

You can easily move a widget or icon from one widget panel to another.

1. Press and hold the widget or icon with one finger.

2. With another finger, flick left or right to rotate the screen to another widget panel.

3. Release the widget or icon.

Removing a widget or icon

1. Press and hold the widget or icon you want to remove, and then drag it to .

2. When the widget or icon turns red, lift your finger.

Changing your main Home screen

Set HTC BlinkFeed or a widget panel as your main Home screen.

1. Press and hold an empty space on a widget panel.

2. In the pop-up menu, tap Manage home screen pages.

3. Swipe left or right until you see the panel that you want to use as your main Home screen.

4. Tap Set as home.

5. Press .

Pressing go to your main Home screen.

from an app will first return you to the last panel you were in. Just press again to

62 Personalizing

Grouping apps on the widget panel and launch bar

1. Press and hold an app, and then drag it over to another app to automatically create a folder.

2. Tap the folder to open it.

3. Tap the folder window’s title bar, and then enter a new folder name.

4. Add more apps into the folder. Tap , select your apps, and then tap Done.

You can also add shortcuts to settings or information to a folder. Add a shortcut first to a widget panel, and then drag it over to the folder.

Removing items from a folder

1. On the launch bar or widget panel, tap a folder to open it.

2. Press and hold an app or shortcut in the folder, and then drag it out to .

Arranging apps

On the Apps screen, you can rearrange the apps and change the layout.

1. From HTC BlinkFeed or any widget panel, tap .

2. Tap , and then choose how to arrange apps, such as alphabetically. If you want to group apps into folders or rearrange them, select Custom.

3. Tap > Grid size to choose whether to display more or fewer apps per page.

Moving apps and folders

1. On the Apps screen, tap > Custom.

2. Tap > Rearrange apps.

3. Press and hold an app or folder, and then do one of the following:

§ Drag the app or folder to another position on the same page. Wait until you see the occupying icon move away before releasing your finger.

§ Drag the app or folder to the or arrow to move it to another page.

4. When you're done moving apps and folders, tap .

Grouping apps into a folder

1. On the Apps screen, tap > Custom.

2. Tap > Rearrange apps.

63 Personalizing

3. Press and hold an app, and then drag it over to another app to automatically create a folder.

4. To add more apps, drag each app over to the folder.

5. To name the folder, open the folder, tap its title bar, and then enter a folder name.

6. When done, tap .

Removing apps from a folder

1. On the Apps screen, tap > Custom.

2. Tap > Rearrange apps.

3. Tap the folder to open it.

4. Press and hold an app, and then drag it out to the Apps screen. Wait until you see the

occupying icon move away before releasing your finger.

5. When you're done removing apps, tap .

Hiding or unhiding apps

1. On the Apps screen, tap > Hide/Unhide apps.

2. Select the apps you want to hide, or clear their check boxes to unhide them.

3. Tap Done.

64 HTC BlinkFeed

HTC BlinkFeed

What is HTC BlinkFeed?

Get the latest about your interests or stay in touch with friends right on HTC BlinkFeed. Set up which social networks, news sources, and more will appear.

§ Swipe up or down to browse stories on HTC BlinkFeed.

§ Tap tiles that have recommendations for points of interests

and restaurants to get directions, read reviews, and more.

§ Tap a tile to view the content or to comment on a post or status update.

§ While viewing a news article, swipe left or right to see more stories.

§ While in HTC BlinkFeed, you can press or or tap the status bar to scroll to the top.

§ Scroll to the top and pull down on the screen to manually refresh the stream.

§ Swipe right on HTC BlinkFeed to open the slideout menu where you can choose the type of feeds or add your custom topics to display.

You'll see the clock widget on HTC BlinkFeed if you've set HTC BlinkFeed as the main Home screen.

65 HTC BlinkFeed

Turning HTC BlinkFeed on or off

1. On the Home screen, slide two fingers together.

2. Tap .

3. Do one of the following:

§ To turn on HTC BlinkFeed, swipe right until you see BlinkFeed, then tap it.

§ To turn off HTC BlinkFeed, swipe to the thumbnail and then tap Remove.

Restaurant recommendations

Can't think of what to eat? Get recommendations for restaurants nearby in HTC BlinkFeed.

Make sure you've given HTC Sense Home permission to access your location. See Setting up the

HTC Sense Home widget on page 39.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Settings.

3. Tap Notification on lockscreen and make sure Meal time bundle is selected.

To get restaurant recommendations, you'll need to actively use HTC BlinkFeed daily. Restaurant recommendations will show up as a tile in HTC BlinkFeed and also on your lock screen.

66 HTC BlinkFeed

Viewing restaurant recommendations

View photos of the restaurant, get directions to the restaurant, and more.

1. When you see a restaurant recommendation tile, tap it to view more information.

2. You can do the following:

§ Tap the photo tile or View Photos to browse photos of the restaurant.

§ Tap the map icon or address to see the location in Google Maps™. From there, you can

get directions.

§ If you see a phone number, tap the phone number to call the restaurant.

§ If you see numbers at the bottom, tap on a number to see alternative restaurant

recommendations.

Ways of adding content on HTC BlinkFeed

Personalize HTC BlinkFeed to show articles and status updates from your favorite news sources, categories, editions, and apps.

Selecting feeds

Discover stories and articles on HTC BlinkFeed based on your interests, favorite categories, and popular news channels or websites.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Add content.

3. Choose a category.

4. Select one or more feed sources.

You can tap a name first to check out a particular feed, and then tap to add it to HTC BlinkFeed.

While browsing the Highlights feed, you may get recommendations for new stories or sources that may be of interest to you. Tap in a tile that says New to subscribe to its website or channel's feed.

Showing content from your apps and social networks

See your friends' posts in social networks or show content from your HTC apps right on HTC BlinkFeed.

You need to sign in to your social networks to see their feeds on HTC BlinkFeed.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Services & Apps, and then select the apps and social networks you like.

67 HTC BlinkFeed

Searching and adding a topic of interest

Looking for a more specific topic? Search for and select topics of interest to display them on HTC BlinkFeed.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap Search for content, and then enter the topic you're looking for.

3. Tap a result, and then tap to add it under Custom topics.

Subscribing to multiple regional editions

Want to keep up to date on current events in more than one region? You can show one or more editions of your choice on HTC BlinkFeed.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Add content.

3. Tap , and then select a locale or region.

4. Select the feed sources to add.

Customizing the Highlights feed

Go to the Highlights feed to see a mix of top trending articles and status updates from the feed sources you added. You can also set the Highlights feed to only show items from your favorite news sources, categories, and apps.

You cannot add custom topics and RSS to the Highlights feed.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Settings > Choose Highlights topics.

3. Select the feed sources you want to appear in Highlights.

Saving articles for later

Don't have time to read that potentially interesting article? You can bookmark articles to your reading list.

Do one of the following:

§ While viewing an article, tap

§ On HTC BlinkFeed, press and hold the tile of the article you want to bookmark. Then tap Read

later.

To access your reading list on HTC BlinkFeed, swipe right, and then tap News reading list in the slideout menu.

68 HTC BlinkFeed

Posting to your social networks

You can easily post a status update from HTC BlinkFeed.

You need to sign in to your social networks before you can post a status update from HTC BlinkFeed.

1. On HTC BlinkFeed, swipe right to open the slideout menu.

2. Tap > Compose, and then choose a social network.

3. Compose your status update and post it on your social network.

Removing content from HTC BlinkFeed

Whether it's a tile or an entire feed, you can remove content you don't want to see on HTC BlinkFeed.

§ To remove a tile, press and hold the tile you want to remove, and then tap Remove.

§ To remove a feed source, in the slideout menu, tap > Remove content, select one or more

items, and then tap Remove. To unsubscribe to a localized edition, tap on the Remove content screen. Tap Remove

editions, select one or more items, and then tap Remove.

69 Camera

Camera

Camera basics

Camera screen

Take great photos and videos with the camera.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap to see all controls on the Viewfinder screen.

Choose a scene to use for taking photos.

Choose a scene to use for recording videos.

Choose an ISO level or set it back to Auto. Higher ISO works best in low light conditions.

Choose an exposure setting. Higher exposure settings capture more light for your photos or videos.

Choose a white balance setting that matches your current lighting environment.

Choose from more basic and advanced camera settings.

Choosing a capture mode

Switch to a capture mode to use for taking photos or videos. On the Viewfinder screen, tap , and then tap a capture mode. You can also just swipe across the Viewfinder screen to switch between capture modes:

§ In landscape view, swipe from the top or bottom edge of the screen.

§ In portrait view, swipe from the left or right edge of the screen.

70 Camera

Zooming

§ Before taking a photo or video, slide two fingers apart to zoom in or together to zoom out.

§ When you're recording video, you can freely zoom in or out while recording.

Turning the camera flash on or off

Tap the flash icon to choose a flash setting. When using or , the camera intelligently sets the best flash brightness for your photo.

Taking a photo

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. Point the camera at what you want to capture. The camera adjusts the focus automatically as

you move it.

4. When you're ready to take the photo, tap .

Tips for capturing better photos

To get better captures with the Camera app, here are some tips on what to do while taking your shots.

Improving focus and sharpness

§ HTC One M9 has autofocus, which works best on a subject that is not moving too much. To change the focus, on the Viewfinder, tap the subject you want to focus on.

§ If the subject is moving, on the Viewfinder, press and hold the subject to lock the focus.

§ You can set the sharpness before taking a photo in the Camera settings, or manually adjust

the sharpness of a photo in Photo Editor. Generally, it is better to sharpen a blurry image rather than to reduce the sharpness in an

image.

Taking well-lit photos

§ HTC One M9 automatically adjusts the focus and exposure. If the image appears underexposed or that it appears dark on the Viewfinder, tap a part of the image that is in shadow. Conversely, tap a well-lit object in the image if the image seems to be overexposed. Focus on an object with a neutral tone for a balanced exposure. Keep in mind that tapping on another object may shift the focus from your subject.

§ If you are using the default settings and the photo still appears too dark, switch to Night scene, but place HTC One M9 on a level surface to keep it steady.

71 Camera

§ If there are parts of the image that are in shadows and others are in highlights, use HDR to capture multiple shots of different exposures and combine them into one shot. Keep HTC One M9 steady or place it on a level surface when using HDR.

§ When taking a panoramic photo, consider the whole scene and focus on an object that has a neutral tone to help keep the exposure balanced in the composite image.

Other tips

§ In Camera settings, tap Grid to help frame the subject better or improve the composition.

§ If taking photos under fluorescent or incandescent bulbs and the subject appears to be off-

color, tap and select the option that displays the closest color to the natural color of the subject.

§ In Camera settings, you can tap Image adjustments and adjust the contrast, saturation, and sharpness before taking the photo.

§ After capturing the photo, you can fine-tune the contrast, brightness, and other settings in Photo Editor.

, and then choose a white balance setting. Check the image on the Viewfinder

Recording video

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. When you're ready to start recording, tap .

4. Change focus to a different subject or area by just tapping it on the Viewfinder screen.

5. Tap the flash icon to turn the flash on or off.

6. Tap to pause the recording, and then tap to resume.

7. To stop recording, tap .

Setting the video resolution

1. Switch to Camera mode.

2. On the Viewfinder screen, tap to show the camera options.

3. Tap .

4. Tap Video Quality, and then choose a video resolution.

Taking a photo while recording a video—VideoPic

Use the Normal video scene when you want to take a photo while recording video.

1. On the Home screen, tap the camera icon to open the Camera app.

2. On the Viewfinder screen, tap to show the camera options. Make sure you see the icon which means the Normal video scene is selected.

3. Tap to start recording.

72 Camera

4. While recording, tap whenever you want to capture a still shot.

5. Tap to stop recording.

Using the volume buttons for taking photos and videos

In the Camera app, you can set the VOLUME buttons to function as the shutter release or zoom controls.

1. On the Home screen, tap the camera icon to open the Camera app.

2. On the Viewfinder screen, tap .

3. Tap > Volume button options.

4. Choose how you want to use the volume buttons when you're in the Camera app.

Closing the Camera app

To give you a full view of the Viewfinder screen, HTC One M9 replaces , , and with small dots.

Tap a dot to show these buttons again, and then tap or to close the Camera app and return to the Home screen or the previous screen.

Taking continuous camera shots

Do you want to take photos of moving subjects? Whether it’s your kid's football game or a car race, you can capture the action. Use the Auto scene when you want to take continuous camera shots.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. On the Viewfinder screen, tap to show the camera options. Make sure you see the icon which means the Auto scene is selected.

73 Camera

4. Press and hold the onscreen shutter button . The camera takes up to 20 consecutive shots of your subject.

5. Choose what you want to do with the continuous shots:

§ To keep just one photo, select the photo that you like the most, and then tap Best shot.

§ Tap Delete, select the unwanted shots, and then tap Delete to save only the remaining

shots.

§ To save the whole batch of shots, just press .

Changing the focus in Bokeh mode

Use Bokeh mode to focus on any object that you see on the Viewfinder screen and blur its background.

You need to be within a distance of 10 to 60 cm (4 in. to 2 ft) from the object you want to focus on.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap > Bokeh. If you don't see this mode, tap Add > Bokeh to add it first to the capture modes.

3. On the Viewfinder screen, tap the object you want to focus on.

4. When you're ready to take the photo, tap .

Tap the small image thumbnail to open the photo you've just taken in Gallery and see the bokeh effect.

74 Camera

Selfies and people shots

Tips for taking selfies and people shots

Do you want yourself, your family, and friends to look best in your shots? Here are some camera options you can adjust or select before taking selfies and people shots.

Portrait scene

Using the Portrait scene helps a little in smoothing the skin in your selfies and people shots.

1. Switch to Camera or Selfie mode. To find out how to switch between capture modes, see

Choosing a capture mode on page 69.

2. On the Viewfinder screen, tap to show the camera options.

3. Tap .

4. Tap to select the Portrait scene.

Live Makeup for selfies

Touch up your skin with Live Makeup before taking your selfie. See Applying skin touch-ups with

Live Makeup on page 75.

Angle of selfies

Do you want the angle of your shots to look exactly the same as how you see yourself on the Viewfinder screen?

1. Switch to Selfie mode. To find out how to switch between capture modes, see Choosing a

capture mode on page 69.

2. On the Viewfinder screen, tap to show the camera options.

3. Tap > Camera options.

4. Select the Save mirror image option.

Skin touch-ups for people shots

Beautify the skin of your subjects before taking their shots.

1. Switch to Camera mode. To find out how to switch between capture modes, see Choosing a

capture mode on page 69.

2. On the Viewfinder screen, tap to show the camera options.

3. Make sure you're using the scene setting.

4. Tap .

5. Tap Make-up level, and then adjust the skin smoothing level.

75 Camera

Applying skin touch-ups with Live Makeup

Touch up your skin before taking your selfie. Live Makeup smoothens your skin in real time.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Selfie or Photo booth mode. To find out how to switch between capture modes, see

Choosing a capture mode on page 69.

3. To change the skin smoothing level, drag the slider across the adjustment bar.

The adjustment bar is shown on the Viewfinder screen by default. To hide it, tap > , and then clear the Live Makeup option.

Using Auto Selfie

Keep still to take an auto selfie—or just smile! You just need to turn this feature on in the camera settings.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Selfie mode. To find out how to switch between capture modes, see Choosing a

capture mode on page 69.

3. On the Viewfinder screen, tap to show the camera options.

4. Tap > Camera options.

5. Select the Auto Selfie option, and then press .

6. Pose and frame yourself on the Viewfinder screen.

7. To take your selfie automatically, look at the front camera, and then:

§ Stay still until the white box turns green on the Viewfinder screen.

§ Or smile at the camera. Hold your smile for a few seconds until your shot is taken.

Using Voice Selfie

Voice Selfie lets you easily take photo or video selfies using voice control. You just need to turn this feature on in the camera settings.

This feature may not be available in all languages.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Selfie mode. To find out how to switch between capture modes, see Choosing a

capture mode on page 69.

3. On the Viewfinder screen, tap to show the camera options.

4. Tap > Camera options.

5. Select the Voice Selfie option, and then press .

76 Camera

6. Pose and frame yourself on the Viewfinder screen.

7. Look at the front camera, and then:

§ Say Cheese or Capture to take a photo selfie.

§ Say Action or Rolling to record a video selfie.

You can also use voice capture with the main camera. Switch to Camera mode, and then turn on Voice capture in the camera settings. Voice capture may not be available in all languages.

Taking photos with the self-timer

When you use the self-timer, the Camera app counts down before taking the shot. You can set the countdown time.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Choose a capture mode you want to use. To find out how to switch between capture modes,

see Choosing a capture mode on page 69.

3. On the Viewfinder screen, tap to show the camera options.

4. Depending on your selected capture mode, do one of the following:

§ Tap

§ Tap > Self-timer, and then drag the slider to set the countdown time.

5. To start the timer, tap . The camera takes the photo after the countdown.

if you see this icon, and then tap the countdown time that you want.

Taking selfies with Photo Booth

Take several selfies and combine them into a single picture.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap If you don't see this mode, tap Add > Photo booth to add it first to the capture modes.

3. On the Viewfinder screen, tap , and then choose a layout for your selfies.

4. To start capturing, tap .

The Camera app will take four selfies, capturing each shot every 2 seconds. You can change your pose for every shot.

> Photo booth.

Split Capture

Using Split Capture mode

Use the Split Capture mode to capture your selfie and the scenery in front of you. The split-screen shot can either be both photos or both videos.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap > Split Capture.

If you don't see this mode, tap Add > Split Capture to add it first to the capture modes.

77 Camera

3. Drag the handle at the middle of the Viewfinder screen to adjust the size of the windows.

4. Tap to toggle between the following options:

Synchronous shot Use the main and front cameras to capture both photos or both

videos at the same time.

Asynchronous

shot

5. When taking a synchronous shot, tap to take photos or to record videos with both

cameras.

6. When taking an asynchronous shot, tap to take a photo or to record a video with the main camera. Tap the button again to capture your selfie.

If you recorded video with the main camera, the video starts playing in its split window after you stop recording. After or while viewing the video, tap to record your video selfie.

If you need to retake the shot, tap to start over.

7. To save the split-screen shot, tap .

If the lengths of the recorded videos in an asynchronous shot are different, the longer video will continue playing in full screen after the shorter one has finished.

Separately capture photos or videos with the main and front cameras. You can record different lengths of videos.

Panoramic shots

Taking a panoramic photo

Get a wider shot of landscapes in one sweep.

Some camera features are not available when you’re in Sweep panorama mode, such as zooming.

On the Home screen, tap the camera icon to open the Camera app.

2. Tap

3. If Pan 360 is selected, tap > , and then tap to switch to Sweep panorama mode.

> Panorama.

78 Camera

4. When you're ready to take the shot, tap .

5. Pan left or right in either landscape or portrait view. Hold HTC One M9 as smoothly as you

can to automatically capture frames. You can also tap to stop capturing anytime.

The camera stitches the frames into a single photo.

Taking a Pan 360 photo

The world isn't flat and your photos shouldn't be either. Take a 360-degree panorama of what's around you.

Some camera features are not available when you’re in this mode, such as zooming.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap > Panorama.

3. On the Viewfinder screen, tap

to show the camera options.

4. Tap , and then tap to switch to Pan 360 mode.

5. Hold HTC One M9 at face level so you'll have more room to capture scenes above or below

you.

79 Camera

6. When you're ready to take the first shot, center the white box within the Viewfinder markers. The camera automatically captures the frame.

7. To take succeeding shots, pan HTC One M9 up, down, left, and right as smoothly as you can. As you pan in one direction, you'll see another white box. Center the white box again within

the Viewfinder markers.

Stand in the same spot even as you turn around to take more shots. For best results, remember to:

§ Avoid capturing scenes with moving objects.

§ Keep at least five meters distance from the scene.

8. Pan repeatedly until you get your desired frames or when you don't see any more boxes. To stop capturing anytime, tap .

Photos taken with Pan 360 are indicated by the icon in Gallery.

Other camera features

Using HDR

When shooting portraits against a bright background, use HDR, short for High Dynamic Range, to capture your subjects clearly. HDR brings out the details of both the highlights and shadows, even in high contrast lighting.

HDR works best when your subject is steady. The camera takes multiple shots at different exposure levels and combines them into one enhanced photo.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. On the Viewfinder screen, tap to show the camera options.

4. Tap , and then tap .

5. To take an HDR photo, tap .

80 Camera

Recording videos in slow motion

Relive high speed action bit by bit and add a touch of suspense to your videos.

Audio is recorded when you're in this scene, but will only be available when video is played back in normal speed.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. On the Viewfinder screen, tap to show the camera options.

4. Tap , and then tap .

5. Tap to start recording.

6. To stop recording, tap .

Camera settings

Manually adjusting camera settings

Want to have expert command of your camera settings for different environments or lighting conditions? You can manually adjust the values for settings like white balance, exposure, ISO, and more.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Switch to Camera mode, if you're not in this mode. See Choosing a capture mode on page 69

for details.

3. On the Viewfinder screen, tap to show the camera options.

4. Tap , and then tap .

5. Tap a setting, and then drag its slider to make adjustments.

6. To change a setting back to auto, tap .

81 Camera

7. When done, tap . To display the settings again, just tap .

8. When you're ready to take a photo, tap .

You can save your customized settings as a new capture mode. See Saving your settings as a

capture mode on page 81 for details.

Saving your settings as a capture mode

Save a scene or your custom settings as a new capture mode so you can conveniently use it anytime you need it.

1. On the Home screen, tap the camera icon to open the Camera app.

2. Tap , and then tap a capture mode you want to use.

Some capture modes may not support modifying the camera settings.

3. On the Viewfinder screen, tap to show the camera options.

4. Modify the settings as desired.

5. When done, tap > Save custom camera.

6. Enter a name, and then tap Save.

Tap on the Viewfinder screen, and then tap your created capture mode whenever you want to use it.

To remove a capture mode that you added, tap

, press and hold the mode, and then drag it to

the Delete option.

82 Gallery

Gallery

Viewing photos and videos in Gallery

Reminisce about good times. Use Gallery to view all your photos and videos. View them by time, album, or location. When viewing your photos and videos, the onscreen navigation buttons will be hidden. Tap anywhere on the screen to see Gallery controls and onscreen navigation buttons.

Viewing photos and videos organized by time

Switch to Timeline view when you want to view your photos and videos according to when they were taken.

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap > Timeline to switch to Timeline view.

You'll then see tab icons for switching between different layouts.

3. Tap to see your photos and videos individually arranged in a feed.

4. Tap to see your photos and videos in a grid layout.

5. Tap to see your photos and videos organized by events.

6. Tap to see your photos and videos organized by year, then tap a month to see the shots

you've taken at that time.

7. Tap a photo or video to see it in full screen.

You can also slide two fingers together or apart on the screen to scroll through the Timeline, feed, grid, and year layouts.

Viewing photos and videos by album

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap > Albums to switch to Albums view.

3. Tap a tile to open an album.

4. Tap a photo or video to see it in full screen.

83 Gallery

Viewing your favorite photos

Easily see all your favorite photos in one place. You can add photos to the My favorites album.

§ To add a photo, find and view the photo in full screen, tap the photo, and then tap >

Favorite.

§ To view these favorite photos, open the My favorites album.

§ To remove a photo from the My favorites album, press and hold the thumbnail and then tap

Remove.

Showing or hiding albums

Have too many albums cluttering up Gallery? You can choose to show or hide albums.

1. In Gallery, tap > Albums.

2. Tap > Show/hide albums.

3. Choose which albums you'd like to show or hide.

Renaming an album

If you have created albums to organize photos, you can rename these albums.

1. In Gallery, tap > Albums.

2. Press and hold the album that you want to rename.

3. Tap Rename.

Some albums, such as Camera shots and Highlights, cannot be renamed.

Viewing photos by location

Using Map view, you can view photos according to location.

Only photos with geo-tag info appear on the map.

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap > Locations to switch to Locations view.

You'll see tiles of photos taken at specific locations, with numbers that indicate how many photos were taken in each location.

3. Tap to display Map view.

84 Gallery

4. Zoom out or pan across the map until a numerical location indicator appears. The number in the location indicator shows how many photos were taken in that area.

5. Tap the location indicator to see the photos taken in that area.

Want to know where you took a particular photo? While viewing the photo in full screen, tap anywhere on the screen, and then tap > Show on map. (Show on map is available when you've enabled Geo-tag photos in Camera.)

Adding location information

Want to specify more than just the city? You can add names of points of interests (POI) to your photos too.

1. In Gallery, tap > Locations.

2. Tap a tile to open it.

3. Swipe to the Places tab.

4. Tap Tap to edit location > Add a new place.

5. Tap a point of interest to add a POI from Foursquare® or tap New place to manually enter a

new name.

6. Tap Save.

Changing location information

1. In Gallery, tap

> Locations.

2. Tap a tile to open it.

3. Swipe to the Places tab.

4. Find the grouping you want to rename, then tap and try one of the following:

Selecting another POI

1. Tap Edit location > Tap to edit location.

2. Tap a point of interest to add a POI from Foursquare or tap New place

to manually enter a new name.

3. Tap Save.

Renaming the location

1. Tap Rename this place.

You'll only see Rename this place if the name is stored on HTC One M9.

2. Enter a new name.

3. Tap Save.

85 Gallery

Adding photos or videos to an album

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap , and then choose how you want to view your photos and videos.

3. Open a group of photos and videos, such as an event in Timeline view or an album.

4. Tap > Add to album.

5. Select the photos or videos you want to add, and then tap Next.

6. Create an album or select an album that you've already created in Gallery. To create a new

album to move or copy to, tap .

To add a single photo or video to an album, press and hold the photo or video. Tap Add to album, and then select the destination album or create a new album.

Copying or moving photos or videos between albums

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap > Albums to switch to Albums view.

3. Tap a tile to open an album.

4. Tap > Move to or Copy to.

5. Select the photos or videos you want to move or copy and then tap Next.

6. Select an album to move or copy the photos or videos to. To create a new album to move or

copy to, tap .

Tagging photos and videos

Make your photos and videos easy to find by adding tags, such as short names or keywords.

1. From the Home screen, tap

2. Tap , and then choose how you want to view your photos and videos.

3. Tap a tile to open a group of photos and videos.

4. Tap > Add tag.

5. Select items that you'll tag with the same keywords, then tap Next.

, and then find and tap Gallery.

6. Type in a keyword, and then tap .

Or, to use an existing tag, just tap it below the text field.

7. Add more keywords when needed.

86 Gallery

8. If you need to remove a tag you've added, just tap the tag, and then tap OK.

9. Tap Save.

To tag a single photo or video, press and hold the photo or video. Tap Add tag, and then enter your keywords.

Viewing your tagged photos and videos

1. In Gallery, tap > Tags.

You'll see tiles of your used tags, with numbers that indicate how many photos and videos belong to each tag.

2. Tap a tile to open it and view tagged photos and videos.

Renaming a tag

You can rename a tag that you've already added to your photos and videos.

1. In Gallery, tap > Tags.

2. Find the tile of the tag you want to rename, then tap > Rename tag.

3. Type the new tag name in the text field, then tap .

4. Tap OK to save your changes.

Removing tags

1. In Gallery, tap > Tags.

2. Find the tile of the tag you want to modify.

3. To untag photos and videos, tap the tile, and then tap > Remove tag. Select the items, then tap Remove.

4. To completely delete a tag, tap in the tile, then tap Remove tag.

Deleting a tag will not delete any of your photos and videos.

Searching for photos and videos

You can search the Gallery using tags and photo locations.

1. From the Home screen, tap

2. Tap .

3. In the search field, type a tag or a location associated with the photo or video you're looking

for. You can also search for photo taken on a specific date. You must use the same date format as

that set in Settings > Date & time, such as 01/13/2015.

, and then find and tap Gallery.

87 Gallery

4. Tap .

5. Select what you want from the matching results.

Finding matching photos

Looking for photos of a specific person? Use Image match to find photos faster instead of browsing through Gallery.

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap , and then choose how you want to view your photos and videos.

3. Tap .

4. Tap Image match and find a photo that is visually similar to what you want to find.

5. Tap the photos that are most similar to what you want to find and do one of the following:

§ Tap Continue to refine the search.

§ Tap Finish to see the results.

6. On the Images matched screen, select all of the images you want to save to a new album, and then tap Save.

You can also find matching images while viewing a photo in full screen. Tap

> Image match.

Viewing Pan 360 photos

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap , and then choose how you want to view your photos and videos.

3. Tap a tile to open the thumbnail view.

4. When you see the Pan 360 photo you want, tap it to view in full screen. You can identify

Pan 360 photos by the icon on the thumbnail.

5. Tap to explore the Pan 360 photo.

6. Try any of the following:

§ Tilt HTC One M9 or drag your finger on the screen to pan the photo.

§ Tap the rotation indicator at the top left corner to re-center the photo.

§ Slide two fingers together or apart to zoom the photo.

§ Rotate two fingers to rotate the photo.

§ Tap to save the current view of the photo.

88 Gallery

Changing the video playback speed

Want to add a cinematic flair to your video by slowing down a particular scene? You can vary the playback speed of a selected section of a slow motion video.

You can only change the video playback speed of videos captured using the slow motion scene in the Camera app.

1. In Gallery, open the video you want to play in full screen. You can identify slow motion

videos by the icon on the thumbnail.

2. Tap to switch between normal and slow motion playback.

3. To adjust the playback speed of the video, tap > Edit > Adjust playback speed.

4. Frame the sequence you want to slow down by moving the left and right sliders.

5. Drag the slider up or down to choose how fast you want the sequence to play.

6. Tap to watch the result.

7. Tap Save.

The edited video is saved as a copy. The original video remains unedited.

Trimming a video

1. In Gallery, open the video you want to play in full screen.

2. Tap the onscreen controls to pause or resume playback, adjust the volume, and more.

Tap

The trimmed video is saved as a copy. The original video remains unedited.

to share the video on your home network.

3. To trim the video, tap > Edit.

4. Drag the trim sliders to the part where you want the video to begin and end.

5. Tap to preview your trimmed video.

6. Tap Save.

Saving a photo from a video

It's easy to save a still shot from a video. While you're watching a video in Gallery, tap You can also pause the playback and drag the slider to the image you want before tapping .

to capture a still shot.

89 Gallery

Viewing a Zoe in Gallery

When you view a group of photos and videos such as in an album, Gallery automatically composes a Zoe. A Zoe is a collection of photos and videos that Gallery has preselected, with added background music and special effects.

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap , and then choose how you want to view your photos and videos.

If you are in Timeline view, you need to go to the Events or Year tab.

3. Tap a tile to open a group of photos and videos. You'll then see a preview of the Zoe play automatically.

If you want to edit the Zoe in the Zoe app, tap the Zoe tile in portrait view. To learn more about the Zoe app, go to the Zoe Tips & Help page.

One Gallery

See all your photos and videos in one place. With One Gallery, you can view all the photos and videos that are stored on HTC One M9 as well as

on favored online services right from the Gallery app on your phone. What's more, you can easily find similar photos and videos using Image match or by searching with

keywords or tags. See Finding matching photos on page 87 and Searching for photos and videos on page 86.

Turning on One Gallery

One Gallery lets you view your Facebook, Flickr®, Google Drive™, and Dropbox pictures and videos in Gallery.

1. From the Home screen, tap , and then find and tap Gallery.

2. Tap > General Settings > One Gallery.

3. Tap Next and then select the online account you want to sign in with.

4. Choose the online services whose photos and videos you want to see in Gallery. One Gallery

will then sync with the accounts.

5. After the accounts have been synced, tap .

You'll then be able to see your online photos and videos in Gallery.

90 Photo Editor

Photo Editor

Basics

Choosing a photo to edit

You can select photos to edit from Photo Editor or Gallery.

1. From the Home screen, tap , and then find and tap Photo Editor.

2. Tap Gallery to open an existing photo on your phone, and then browse for the item to edit.

Or, tap Camera if you want to take a new photo to edit. A slideout menu appears where you can choose editing options.

You can also tap

while viewing a photo in full screen from the Gallery app.

Adjusting your photos

Use the available adjustment tools to crop, rotate, flip, or straighten photos.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Essentials > .

3. Choose to rotate, crop, flip, or straighten the photo.

4. Tap and make more adjustments, if needed.

5. Press to return to the Essentials screen.

6. Tap to save changes.

Except for when applying rotation, edited photos are saved as new photos. The original remains unedited.

Drawing on a photo

Scribble on your photos for fun or to highlight an interesting part.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Flair > .

3. Drag the stroke slider to adjust the stroke thickness.

4. Tap to open the toolbar, choose a pen type, and then tap to hide the toolbar.

91 Photo Editor

5. Choose a pen color from the color bar.

6. Draw on the photo.

You can tap to switch to full screen view.

7. To undo or redo an action, open the toolbar, and then tap or . Or, you can use the eraser from the toolbar to remove specific parts of your drawing.

8. Tap when done.

9. Tap , and then tap to toggle between the before and after photos.

10. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Applying photo filters

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Essentials.

3. Tap , and then choose one of the available filters.

4. Tap .

5. Tap , and then tap to toggle between the before and after photos.

6. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Creating and applying a custom filter

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Essentials.

3. Tap , and then scroll to the end of the predefined filters bar.

4. Tap Custom.

5. Make changes to the filter by adjusting the controls on exposure, saturation, white balance,

and more.

6. If you need to rearrange the order of your settings to achieve a particular effect, you can press and hold a setting and drag it to a new position.

Rearranging the settings may reset values to the default.

7. Tap .

8. Press to return to the Essentials screen.

9. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

92 Photo Editor

Retouching photos of people

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Touch up.

3. Choose a facial touch-up to apply, and then customize its settings.

4. Tap .

5. Tap , and then tap to toggle between the before and after photos.

6. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Fixing red eye in photos

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Essentials.

3. Tap , and then tap .

4. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Editing continuous shots

Always Smile

Finding it difficult to choose a group shot with the most smiles and the fewest blinks? Retouch a group shot so everyone looks their best in the photo.

This feature is available for burst shots captured with continuous shooting mode. You can identify burst shots by the icon on the thumbnail.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > . You'll see circles around any faces detected in the photo.

3. Select one face at a time and drag it sideways with your finger to select the expression you want.

4. Tap when done.

5. Tap , and then tap to toggle between the before and after photos.

6. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

93 Photo Editor

GIF creator

Create an animated gif that you can quickly upload and share.

This feature is available for burst shots captured with continuous shooting mode. You can identify burst shots by the icon on the thumbnail.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > . You'll see an animation of the frames.

3. Drag the trim sliders to the part where you want the animated gif to begin and end.

4. Tap .

5. On the next screen, you can choose the direction you want the animation to play, set the

speed of the animation, choose which frames you want to include, and more.

6. Tap when done.

7. Select the file quality of your animation, and then tap OK.

The animation is saved as a gif. You can identify a gif by the icon on the thumbnail in Gallery.

Sequence Shot

Hop, skip, or jump. Create a sequence shot to stitch a series of actions into one photo.

This feature is available for burst shots captured with continuous shooting mode. You can identify burst shots by the icon on the thumbnail.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > . You'll see frames that you can combine in one photo.

3. Select the frames that you want to include in the sequence shot.

4. Tap when done.

5. Tap , and then tap to toggle between the before and after photos.

6. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

94 Photo Editor

Object Removal

Did a pedestrian or passing car ruin your otherwise perfect shot of a famous landmark? Retouch the photo to remove unwanted people or objects.

This feature is available for burst shots captured with continuous shooting mode. You can identify burst shots by the icon on the thumbnail.

1. From Photo Editor, choose the photo you want to edit.

2. In the slideout menu that opens, tap Effects > . You'll see frames around areas in the

photo where objects have been automatically removed.

3. To retain an object, tap on its image on the film strip.

4. Tap when done.

5. Tap , and then tap to toggle between the before and after photos.

6. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Creative effects

Shapes

Add some pattern to your photo by adding and blending shapes.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Choose a shape to add to your photo.

4. Select a shape color by dragging the color slider.

5. Drag the shape to move it.

6. Drag your fingers apart or together on the shape to adjust its size.

7. Press and hold the shape with two fingers and then drag your fingers in a circular motion to

rotate it.

8. Tap to open the toolbar.

9. Tap , choose a different blending option for the selected layer, and then tap .

10. Tap > , and then drag the slider to adjust the shape's opacity.

11. If you want to adjust your photo to blend with the shape, tap to switch from the shape

layer to the photo layer.

95 Photo Editor

12. Tap a setting to adjust its values, and then tap .

13. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Photo Shapes

Photo Shapes lets you add a shape to your image and fill it with another photo.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Choose a second image to be the fill for your selected shape.

4. Choose a shape to add to your photo.

5. Tap to switch to the shape layer. You should see the shape layer icon .

6. Drag the shape mask to move it.

7. Drag your fingers apart or together on the shape mask to adjust its size.

8. Press and hold the shape mask with two fingers, and then drag your fingers in a circular

motion to rotate it.

9. Tap to return to the image layer , and then drag your fingers apart or together on the image to adjust the image size inside the mask.

10. Tap to open the toolbar.

11. Tap , choose a different blending option for the selected layer, and then tap .

12. Tap > , and then tap a setting to adjust its values.

96 Photo Editor

13. If you want to adjust your photo to blend with the image fill, tap to switch from the image

fill layer to the photo layer.

14. Tap a setting and drag the slider to adjust its values, and then tap .

15. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

Prismatic

Got a bright and colorful image? Use Prismatic effect for fresh crystal prism patterns.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Choose a prismatic pattern to apply to your photo.

4. Tap to switch to the shape layer. You should see the shape layer icon .

5. Drag the shape to move it.

6. Drag your fingers apart or together on the shape to adjust its size.

7. Press and hold the shape with two fingers, and then drag your fingers in a circular motion to

rotate it.

8. Tap to return to the image layer , and then drag your fingers apart or together on the image to adjust its size.

9. Tap to open the toolbar.

10. Tap , adjust the settings for your photo layer, and then tap .

11. Tap to save changes.

The edited photo is saved as a new photo. The original photo remains unedited.

97 Photo Editor

Double Exposure

With Double Exposure, combine and blend two photos and create something surreal.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Choose your second image. This will be your top layer .

4. Drag the layer to move it.

5. Drag your fingers apart or together on the layer to adjust its size.

6. Tap to open the toolbar.

7. Tap , choose a different blending option for the selected layer, and then tap .

8. Tap > , tap a setting, and then drag the slider to adjust its values.

9. If you want to adjust your background layer to blend with the top layer, tap to switch to

the background layer.

10. Tap a setting and drag the slider to adjust its values, and then tap .

The edited photo is saved as a new photo. The original photo remains unedited.

98 Photo Editor

Elements

Add animated elements to your photo.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Tap an element type to apply to your photo.

4. Tap to open the toolbar.

5. Tap , draw an animation path or area for the selected effect, and then tap .

6. Tap to adjust the animation speed and intensity.

7. Press and hold an area with two fingers, and then drag your fingers in a circular motion to

rotate the animation.

8. When you are satisfied with the result, tap and choose to save as a photo or video.

Face Fusion

Wonder what you would like if you shared the same features as another person? Face Fusion uses a person’s photo and a target face to merge the two photos into one.

To use Face Fusion, be sure that:

§ The faces in each photo have to be 100 x 100 pixels or larger in size.

§ Facial shots are without glasses and are not covered by hair, a hat, or any other item.

§ Subjects should look towards the camera for best results.

1. From Photo Editor, choose the photo you want to edit.

See Choosing a photo to edit on page 90 to find out how.

2. In the slideout menu that opens, tap Effects > .

3. Tap and then browse to the photo that you want to merge with.

99 Photo Editor

4. Drag the slider to apply Face Fusion to the image.

To choose another target face, just tap the thumbnail of the target person and browse to a new photo.

5. When you are satisfied with the result, tap and choose to save as a photo or video.

100 HTC Print Studio

HTC Print Studio

What is HTC Print Studio?

Need an idea for a personalized gift? HTC Print Studio lets you choose photos on HTC One M9 to create professional photo gifts that can

be purchased online and shipped to your family or friends.

Choosing the type of photo gift

Before selecting the photos that you will use to make your photo gift, choose the kind of gift you want to create.

1. From the Home screen, tap , and then find and tap HTC Print Studio.

2. If this is your first time using the app, tap Get started on the HTC Print Studio welcome

screen.

3. Tap and then select the photo gift you want to create.

If you have more than twelve photos in an event in Gallery, you'll see collections of photos taken at a specific time or place. Tap a collection to use its photos to create the gift.

4. Select the photos you want to use in Gallery, and then tap Next. You'll see an example of the front and back of the photo gift.

5. Tap Edit to create and edit your photo gift. See Creating your photo gift on page 100.

Creating your photo gift

After you've selected the type of photo gift that you want, you can start customizing it with photos, text, and more.

Use high resolution photos for the best results. Images that have a resolution that's too low for a good output—less than 200 dpi—will be marked by an exclamation point.

1. Depending on the type of selected photo gift, tap or to switch between the two views

of the photo gift.

2. To replace a photo on the photo gift, tap it, and then tap to expand the window at the bottom where you can choose from the group of preselected photos.

If what you want is not in the group of photos, scroll to the bottom and then tap to select a photo from Gallery.

HTC One M9 AT-T User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Features you'll enjoy

Personalization

Imaging

Sound

Unboxing

HTC One M9

Slots with card trays

nano SIM card

Inserting a nano SIM card

Removing a nano SIM card

Storage card

Inserting the microSD card

Unmounting the storage card

Removing the microSD card

Charging the battery

Switching the power on or off

Switching the power on

Switching the power off

Phone setup and transfer

Setting up your new phone for the first time

Transferring content from an Android phone

Transferring content from an iPhone

Transferring iPhone content through iCloud

Transferring contacts from your old phone through Bluetooth

Other ways of getting contacts and other content

Importing contacts with AT&T Ready2Go

Transferring photos, videos, and music between your phone and computer

Using Quick Settings

Customizing Quick Settings

Getting to know your settings

Updating your phone's software

Checking for AT&T updates manually

Checking your system software version

Installing app updates from Google Play

Getting apps from Google Play

Finding and installing an app

Restoring apps from Google Play

Downloading apps from the web

Uninstalling an app

Your first week with your new phone

Basics

HTC Sense Home

Onscreen navigation buttons

Adding a fourth navigation button

Rearranging the navigation buttons

Sleep mode

Switching to Sleep mode

Waking up from Sleep mode

Unlocking the screen

Motion gestures

Touch gestures

Opening an app

Opening an app or folder from the lock screen

Sharing content

Switching between recently opened apps

Refreshing content

Capturing your phone's screen

HTC Sense Home widget

What is the HTC Sense Home widget?

Setting up the HTC Sense Home widget

Setting your home and work locations

Manually switching locations

Pinning and unpinning apps

Adding apps to the HTC Sense Home widget

Turning smart folders on and off

Motion Launch

What is Motion Launch?

Turning Motion Launch gestures on or off

Waking up to the lock screen

Waking up and unlocking

Waking up to the Home widget panel

Waking up to HTC BlinkFeed

Auto launching the camera with Motion Launch Snap

Making a call with Quick call

Bypassing the screen lock for Quick call

Lock screen
