Htc Love P3350 User Manual

www.htc.com

Pocket PC Phone

User Manual

Please Read Before Proceeding

THE BATTERY IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your Pocket PC Phone.

, , , ExtUSB, and RollR are trademarks and/or

service marks of High Tech Computer Corp.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, ActiveSync, Excel, Internet Explorer, MSN, Hotmail, Outlook, PowerPoint, Word, and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

microSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or Adobe Systems Incorporated.

ArcSoft MMS Composer™ Copyright © 2003-2006, ArcSoft, Inc. and its licensors. All Rights Reserved. ArcSoft & the ArcSoft logo are registered trademarks of ArcSoft, Inc. in the United States and/or other countries.

Sprite Backup is a trademark or service mark of Sprite Software.

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners.

HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in

an electric shock to your device.

This product equipped with an USB Cable for connecting with desk-top or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-ion Polymer battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY

REPLACED. TO REDUCE RISK OF FIRE OR BURNS, DO NOT DISASSEMBLE, CRUSH, PUNCTURE, SHORT EXTERNAL CONTACTS, EXPOSE TO TEMPERATURE ABOVE 60˚C (140˚F), OR DISPOSE OF IN FIRE OR WATER. REPLACE ONLY WITH SPECIFIED BATTERIES. RECYCLE OR DISPOSE OF USED BATTERIES ACCORDING TO THE LOCAL REGULATIONS OR REFERENCE GUIDE SUPPLIED WITH YOUR PRODUCT.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used and prolonged listening at high volume.

NOTE: For France, mobile headphones or earphones (manufactured by Merry, model number EMC220) for this device have been tested to comply with the Sound Pressure Level requirement laid down in NF EN 50332-1:2000 standard as required by French Article L. 5232-1.

SAFETY IN AIRCRAFTS

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off the phone by switching to Flight Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using hands-free devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your device near metal structures (for example, the steel

frame of a building).

• Avoid using your device near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories

that do not contain any metal.

• Use of non-original manufacturer-approved accessories may violate

your local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

This product should be operated in the suggested normal condition only to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

GENERAL PRECAUTIONS

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside the device should be done by an authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the

operating instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

NOTE: When taking the device from low-temperature conditions into a

warmer environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on the power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting Accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identified as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 15

1.1 Getting to Know Your Device and Its Accessories .......... 16

1.2 About the SIM Card and Battery ..................................... 20

1.3 Starting Up ........................................................................ 22

1.4 The Today Screen .............................................................. 24

1.5 Using the Programs .......................................................... 28

1.6 Device Settings ................................................................. 31

Chapter 2 Entering and Searching Information 35

2.1 Entering Information ....................................................... 36

2.2 Using the On-screen Keyboard ....................................... 37

2.3 Using Letter Recognizer ................................................... 37

2.4 Using Block Recognizer .................................................... 38

2.5 Using Transcriber .............................................................. 38

2.6 Using Notes to Draw, Write, and Record Voice Notes .... 40

2.7 Searching Information ..................................................... 40

Chapter 3 Using Phone Features 41

3.1 Using the Phone ............................................................... 42

3.2 Making a Call .................................................................... 44

3.3 Receiving a Call ................................................................. 46

3.4 Smart Dialing .................................................................... 47

3.5 In-call Options .................................................................. 50

3.6 Additional Dialing Information ....................................... 51

3.7 Setting Up Bluetooth SIM Access for Car Kit Phones ..... 52

Chapter 4 Synchronizing Information and

Setting Up E-mail Security 53

4.1 Setting Up ActiveSync ...................................................... 54

4.2 Synchronizing Information ............................................. 58

4.3 Synchronizing via Bluetooth ........................................... 63

4.4 Synchronizing Music, Video, and Pictures ...................... 63

4.5 Setting Up E-mail Security ............................................... 65

Chapter 5 Managing Your Pocket PC Phone 67

5.1 Personalizing Your Pocket PC Phone .............................. 68

5.2 Adding and Removing Programs .................................... 75

5.3 Managing Memory and Storage ..................................... 76

5.4 Copying Files ..................................................................... 78

5.5 Backing Up Data ............................................................... 80

5.6 Protecting Your Pocket PC Phone ................................... 83

5.7 Resetting Your Pocket PC Phone ..................................... 85

Chapter 6 Getting Connected 87

6.1 Connecting to the Internet .............................................. 88

6.2 Internet Explorer Mobile ................................................. 91

6.3 Using Comm Manager ...................................................... 94

6.4 Using Bluetooth ................................................................ 95

6.5 Using Wi-Fi ...................................................................... 104

6.6 Using Internet Sharing ................................................... 108

6.7 Using Spb GPRS Monitor ............................................... 109

6.8 Using Terminal Services Client ...................................... 114

Chapter 7 Exchanging Messages and

Using Outlook 117

7.1 E-mail and Text Messages .............................................. 118

7.2 MMS Messages ............................................................... 127

7.3 Pocket MSN ..................................................................... 134

7.4 Calendar .......................................................................... 135

7.5 Contacts .......................................................................... 137

7.6 Tasks ................................................................................ 142

7.7 Notes ............................................................................... 144

Chapter 8 Experiencing Multimedia 147

8.1 Using Camera .................................................................. 148

8.2 Using Pictures & Videos ................................................. 162

8.3 Using Windows Media Player Mobile ............................ 166

8.4 Using Media Hub ............................................................ 173

8.5 Using FM Radio ............................................................... 175

8.6 Using Audio Manager .................................................... 178

8.7 Using Audio Booster ...................................................... 185

Chapter 9 Using Other Applications 189

9.1 Word Mobile ................................................................... 190

9.2 Excel Mobile .................................................................... 191

9.3 Viewing Slide Shows with PowerPoint Mobile ............. 192

9.4 Using ClearVue PDF ........................................................ 193

9.5 Using MIDlet Manager ................................................... 194

9.6 Using ZIP ......................................................................... 197

9.7 Using Voice Speed Dial .................................................. 198

Appendix 201

A.1 Regulatory Notices .........................................................202

A.2 PC Requirement to Run ActiveSync 4.x ........................ 207

A.3 Specifications ................................................................. 208

Index 211

1.1 Getting to Know Your Device

and Its Accessories

1.2 About the SIM Card and Battery

1.3 Starting Up

1.4 The Today Screen

1.5 Using the Programs

1.6 Device Settings

Chapter 1

Getting Started

16 Getting Started

1.1 Getting to Know Your Device and Its Accessories

Getting Started 17

No. Item Function

1 Earpiece Listen to phone call from here.

2 Notification LED 1 This LED shows the following:

• A blinking Blue light for Bluetooth system

notification of powered-up and ready to transmit Bluetooth signal.

• A blinking Green light for Wi-Fi status.

• When both Bluetooth and Wi-Fi are enabled, their

lights blink alternately.

3 Notification LED 2 This LED shows Green and Amber lights for GSM/

GPRS/EDGE standby, message, and network status as well as for notification and battery charging status.

4 Touch Screen Tap the screen with the stylus to write, draw, or make

a selection.

5 Left and Right SOFT

KEYS

Press to execute the command shown in the label above the button.

6 MEDIA HUB Button Press to open Media Hub, a program launcher that

gives you quick access to multimedia programs on your device.

7 TALK Button Press to answer an incoming call or dial a number.

8 START Button Press to open the Start menu.

9 HTC RollR

HTC RollRTM is a proprietary device control that integrates the use of the Track Wheel and Trackball. Use it for scrolling, web browsing, camera zoom control and shutter release, and for mouse movement when in mouse mode.

Track Wheel

• Turn clockwise or counterclockwise to move

through items on the screen or in a menu.

• When using the Camera, use it for zooming.

Trackball

• Roll up, down, left, or right to move through

menus and program instructions; carry out the selection by pressing the Trackball.

• When using the Camera, use it as the shutter

release.

10 OK Button Press to confirm your data entries, or to exit the

program in use.

18 Getting Started

No. Item Function

11 COMM MANAGER

Button

Press to launch Comm Manager. Comm Manager lets you easily turn on/off your device's connections (such as Bluetooth and Wi-Fi), ringer, phone, etc.

12 END Button Press to end a call or to return to the Today screen.

24 26

Getting Started 19

No. Item Function

13 VOICE COMMAND

Button

Press to start Voice Speed Dial; press and hold to record a voice note.

14 Volume Slider • Slide up or down to adjust the speaker volume.

• During a call, slide up or down to adjust the

earpiece volume.

15 RESET Button With the stylus, press the RESET button to soft-reset

your device.

16 Speaker Listen to media from here. 17 Car Antenna

Connector

Connect your device to the car antenna while in a car to have better reception quality.

18 Camera Use the camera to take still photos and record video

clips.

19 Self-Portrait Mirror Turn the back side of your device to face yourself so

that your image reflects on the mirror when taking self-portrait shots.

20 Battery Cover Slide out to access the battery compartment. 21 POWER Button • Press and hold to turn on the device.

• Press to turn off the display temporarily. This

switches your device to Sleep mode. You can still receive calls and messages when your device is in Sleep mode.

• Press and hold (for about 5 seconds) to turn off

the power completely. All functions including the phone will be unavailable for use.

22 CAMERA Button Press to launch the Camera; press again to take a

photo or video clip, depending on the specified capture mode.

23 Stylus Use the stylus to write, draw, or select items on the

touch screen.

24 Microphone Speak into the microphone when receiving or

making a phone call or voice recording.

25 Sync Connector/

Earphone Jack

Use this connector to synchronize data by connecting the provided USB Sync cable or to recharge the battery via the provided AC adapter. You can also connect the provided USB stereo headset for hands-free conversation or for listening to FM radio and audio media. FM radio uses the stereo headset as an antenna.

26 Strap Holder Attach a strap for carrying your device.

20 Getting Started

Accessories

No. Accessory Function

1 AC adapter Recharges the battery.

2 USB Sync cable Connects your device to a PC and synchronizes data.

3 Stereo headset • Provides a volume control slider and a Send/End

button. Press the Send/End button to pick up a call or put a call on hold; press and hold the button to end the call.

• Make sure you connect this headset when using

the FM Radio since it uses the headset as an antenna.

1.2 About the SIM Card and Battery

Always turn off your device before installing/replacing the battery and SIM card. Follow the instructions in the Quick Start Guide to install a SIM (Subscriber Identity Module) card provided by your local network service provider and to install the battery.

The SIM card contains your phone number, service details, and phonebook/ message memory. Your device supports both 1.8V and 3V SIM cards. Some legacy SIM cards will not function with your device. You should consult with your service provider for a replacement SIM card. There may be fees for this service.

Your device contains a rechargeable Li-ion polymer battery. This device is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including your wireless service provider’s network configuration, signal strength, the temperature of the environment in which you operate your device, the

Getting Started 21

features and/or settings you select and use, items attached to connecting ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

• Standby time: Up to 150 - 200 hours.

• Talk time (Screen oﬀ): Up to 3.5 - 5 hours.

• Media playback time: Up to 8 hours for WMV;

Up to 12 hours for WMA.

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire

or water.

• Do not expose to temperatures above 60oC (140oF).

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulation.

To check the battery power

Do one of the following:

• Tap the battery level icon ( ) on the Quick Launcher.

• Alternatively, tap Start > Settings > Systems tab > Power.

Battery power information

22 Getting Started

Charge the battery

New batteries are partially charged. Before you start using your device, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles. You can charge the battery in two ways:

•

Charging the device’s battery by using the power adapter.

• Connecting your device to a PC via the provided USB Sync cable.

Warning! • Do not remove the battery from the device while you are charging it

using the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

Low battery

When the low-battery warning appears, do the following:

• Immediately save your current data.

• Synchronize with your PC or connect the power adapter to charge the

battery.

• Turn oﬀ your device.

1.3 Starting Up

Turn your device on and off

To turn on your device, press and hold the POWER button. When you turn on your device for the first time, a Quick Start Wizard will guide you through the calibration process and the setup of regional settings, date and time, password, Outlook e-mail, and POP3/IMAP4 e-mail accounts. For more information about touch screen calibration, see “Calibrate the device”. For information about setting up Outlook e-mail and POP3/IMAP4 e-mail accounts, see Chapter 7.

To turn off your device, press and hold the POWER button for a few seconds. A message will then be displayed, prompting you whether or not to turn off the device completely.

Getting Started 23

Switch your device to Sleep mode

Quickly pressing the POWER button turns off the display temporarily and switches your device to Sleep mode. Sleep mode suspends your device to a low power state while the display is off in order to save battery power. Your device also automatically goes into Sleep mode when you leave the device idle after a certain amount of time.

To specify the timeout period before your device goes into Sleep mode

1. Tap Start > Settings > System tab > Power > Advanced tab.

2. Under On battery power, make sure the Turn off device if not used

for check box is selected.

3. Select the battery timeout period, then tap OK.

You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER button again or new incoming calls/ messages will wake up your device.

Calibrate the device

Calibrating the device screen involves tapping the center of a cross with the stylus as the cross moves around the screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated. If your device does not accurately respond to screen taps, follow these steps to re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the General tab, tap Align Screen, then follow the on-screen

instructions to complete the calibration.

Manage screen settings

The device’s display has two orientation modes: Portrait and Landscape. Portrait mode allows you to get a better view or a better operation of certain programs, while Landscape mode may be optimal for viewing lengthy files.

• To change the orientation, tap Start > Settings > System tab >

Screen, and select the orientation you want.

• To smooth the edges of screen fonts for many programs, on the

ClearType tab, select the Enable ClearType check box.

• To increase the readability or to see more content on the screen, on

the Text Size tab, adjust the text size by moving the slider.

24 Getting Started

1.4 The Today Screen

The Today screen displays important information, such as upcoming appointments and status indicators. You can tap a section on the screen to open the associated program.

• To access the Today screen, tap Start > Today.

• To customize the Today screen display, including the background

image, tap Start > Settings > Personal tab > Today.

2 3 4 5

1 Tap to open the Start menu.

2 Tap to view connectivity status.

3 Indicates the radio signal strength. Tap to configure the phone settings.

4 Tap to adjust device/ringer volume.

5 Displays the current time. Tap to check the current date and upcoming

appointments. Tap and hold to change the clock mode to Analog or Digital.

6 Displays the current date. Tap to set up date, time, alarm, and more.

7 HTC Plus! – Info Panel. Displays the current date/time and your message

information. Tap the clock widget to set up date, time, alarm, and more. Tap the message widget to open Messaging.

Getting Started 25

8 HTC Plus! – Quick Launcher. Allows you to set shortcut to quickly access the

programs and the customization utilities (up to 10 items). The Quick Launcher contains two pages, and you can tap the arrow icon ( / ) to switch between the pages.

a b c d e

On the first page, tap the program icon to launce the associated program. The second page contains the customization utilities that allow you to:

a. Indicates the battery status. Tap to open the Power Settings screen.

b. Tap to adjust the brightness of the screen.

c. Tap to toggle the screen between portrait and landscape orientation.

d. Tap to lock the device.

e. Tap to toggle between enabling and disabling mouse mode. When mouse

mode is enabled, the Trackball pointer appears on the screen and allows you to use the Trackball just like a PC mouse.

Tip To configure the Quick Launcher, tap Start > Settings > Personal tab

> Today > HTC Plus! tab. Select the Quick Launcher item and tap Options to set up your personal Quick Launcher. The Quick Launcher

will change the layout according to your setting.

9 Tap to open Calendar.

10 Tap to open Calendar.

11 Tap to open Contacts.

Indicators

The following are some of the status icons that you may see on the device.

Icon Description

New e-mail or text messages; SMS notification of voice mail

New multimedia (MMS) message

New MSN message

There are more notifications. Tap the icon to view all.

26 Getting Started

Icon Description

Speakerphone on

Dialing while no SIM card is inserted

Voice call in progress

Calls are forwarded

Call on hold

Missed call

Maximum signal strength

No signal

Phone is turned off

No phone service

Searching for phone service

GPRS available

GPRS connecting

GPRS in use

EDGE available

EDGE connecting

EDGE in use

Roaming

Connection is active

Connection is not active

Synchronization in progress

Synchronization error

Getting Started 27

Icon Description

ActiveSync notification

Wi-Fi function enabled, but device not connected to a wireless network yet

Wireless network(s) detected

Connecting to wireless network (arrows moving); connected to wireless network

Synchronizing via Wi-Fi

Vibration mode

Sound on

Sound off

Alarm

No SIM card inserted

Battery is fully charged

Battery power is very low

Battery charging

Device is locked.

Device is unlocked.

Bluetooth headset detected

GPRS Monitor currently active

Sprite Backup notification

Serial USB connection active

Note The USB to PC ( ) icon appears on the Today Screen when your device

is connected to your computer and you enable a serial USB connection between them. For more information about USB to PC, see “Device Settings” later in this chapter.

28 Getting Started

The Start menu

The Start menu, located at the top left corner of the Today screen, displays a list of programs. You can start a program by scrolling through the programs list and then pressing the Trackball, or by tapping a program with the stylus.

1 Tap to switch to the Today screen.

2 Tap to start a program. The items

displayed in the Start menu can be customized by tapping Start >

Settings > Personal

tab > Menus.

3 Tap to start a recently-used program.

4 Tap to view and select more programs

that are installed on your device.

5 Tap to change device settings.

6 Tap to see a Help topic for the current

screen.

1.5 Using the Programs

The following are some of the programs that are already installed on your device.

Icon Description

ActiveSync Synchronizes information between your device and a PC or

the Exchange Server.

Audio Booster Enhances your music experience by providing you with controls for adjusting equalizer, 3D sound, treble, and bass settings.

Audio Manager Allows you to easily browse for music files by organizing music files into categories such as artists, album, etc. It has an integrated Music Player that lets you play back music files.

Bluetooth Explorer Searches for other Bluetooth devices that have file sharing enabled and allows you to access their Bluetooth shared folder.

Calculator Lets you perform basic arithmetic and calculations, such as addition, subtraction, multiplication, and division.

Calendar Allows you to keep track of your appointments and create meeting requests.

Getting Started 29

Icon Description

Camera Snaps photos or shoots video clips with accompanying audio.

ClearVue PDF Enables you to view PDF files on your device.

Comm Manager Allows you to manage the device’s connection

(including Wi-Fi, Bluetooth, and ActiveSync), disconnect data services (such as GPRS), turn the phone on or off, switch to ringer/vibration mode, and enable or disable the Direct Push function.

Contacts Allows you to keep track of your friends and colleagues.

Download Agent Provides information about the download status and

the downloaded content from the Internet.

Excel Mobile Creates new workbooks or lets you view and edit Excel workbooks.

File Explorer Enables you to organize and manage files on your device.

FM Radio Lets you listen to your favorite FM radio stations.

Games Lets you play two pre-installed games: Bubble Breaker and Solitaire.

Help Enables you to see Help topics for the current screen or program.

Internet Sharing Allows you to connect your notebook computer to the

Internet using your device's data connection.

Internet Explorer Mobile Allows you to browse Web and WAP sites as well as download new programs and files from the Internet.

Media Hub Gives you quick access to multimedia programs on your device, such as FM Radio, Audio Manager, and more.

Messaging Allows you to send and receive e-mail, MMS, and text messages.

MIDlet Manager Enables you to download and install Java applications, such as games and tools, on your device.

Notes Allows you to create handwritten or typed notes, drawings, and recordings.

30 Getting Started

Icon Description

Phone Lets you make and receive calls, switch between calls, and set up

conference calling.

Pictures & Videos Lets you view, organize, and sort picture and video files on your device or a storage card. Captured photos are stored in the My Pictures folder, and video clips are saved in the My Videos folder of your device.

Pocket MSN Lets you send and receive instant messages with your MSN Messenger contacts, as well as access your Hotmail account, if you have one.

PowerPoint Mobile Lets you view PowerPoint slides and presentations.

SAPSettings Enables Bluetooth Remote SIM access on your device. This

allows you to use a car kit phone that supports the SIM Access Profile (SAP) to access the SIM card on your device via Bluetooth and make or receive phone calls. You can also download SIM contacts from your device onto the car kit phone.

Search Enables you to search contacts, data, and other information on your device.

SIM Manager Allows you to manage the contacts that are stored on your SIM card. You can also use this program to copy SIM contents to Contacts on your device.

Spb GPRS Monitor Can be installed to your device from the CD. It measures the amount of data transfers that you have made via the GPRS or GSM network connection, and calculates network usage costs.

Sprite Backup Provides you with a quick and easy way to make backups of your data.

STK (SIM Tool Kit) Ser vice Allows you to access information and other services offered by your wireless service provider.

Tasks Allows you to keep track of your tasks.

Terminal Services Client Allows you to log on to a PC running Terminal

Services or Remote Desktop, and use all of the programs available on that PC from your mobile device.

Voice Speed Dial Allows you to record voice tags so that you can dial a phone number or launch programs simply by speaking a word.

Windows Media Player Mobile Lets you play back audio and video files.

+ 188 hidden pages
