HTC BKNV User Manual

Download

Touch HD

User Manual

www.htc.com

Please Read Before Proceeding

THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

In regard to HSDPA/WCDMA,the phone just supports Band I (UMTS 2100) & Band VIII (UMTS 900) and doesn’t support band frequency for US.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your PDA Phone.

INTELLECTUAL PROPERTY RIGHT INFORMATION

HTC, the HTC logo, HTC Innovation, ExtUSB, TouchFLO, HTC Touch HD, and HTC Care are trademarks and/or service marks of HTC Corporation.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, Windows XP, Windows Vista, ActiveSync, Windows Mobile Device Center, Internet Explorer, MSN, Hotmail, Windows Live, Outlook, Excel, PowerPoint, Word, OneNote and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

microSD is a trademark of SD Card Association.

Google is a registered trademark and Google Maps is a trademark of Google, Inc. in the United States and other countries.

YouTube is a trademark of Google, Inc.

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners.

HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice.

No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Disclaimers

THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other Products and services, including without limitation any express or implied warranty of merchantability, express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy, completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation will be error-free, or implied warranties arising from course of dealing or course of performance.

Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and its Providers make no express or implied warranties, guarantees or affirmations that weather information will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE COMMON SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION.

Limitation of Damages

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER REGARDLESS OF THE FORESEEABILITY THEREOF.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION: Connecting to an improperly grounded equipment can result in an

electric shock to your device.

This product is equipped with a USB Cable for connecting with desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

• Handle battery packs carefully

This product contains a Li-ion or Li-ion Polymer battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (140° F), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

• Take extra precautions

• Keep the battery or device dry and away from water or any liquid as it may

cause a short circuit.

• Keep metal objects away so they don’t come in contact with the battery or

its connectors as it may lead to short circuit during operation.

• Do not use a battery that appears damaged, deformed, or discolored, or

the one that has any rust on its casing, overheats, or emits a foul odor.

• Always keep the battery out of the reach of babies and small children, to

avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed.

• If the battery leaks:

• Do not allow the leaking fluid to come in contact with skin or clothing.

If already in contact, flush the affected area immediately with clean water and seek medical advice.

• Do not allow the leaking fluid to come in contact with eyes. If already

in contact, DO NOT rub; rinse with clean water immediately and seek medical advice.

• Take extra precautions to keep a leaking battery away from fire as

there is a danger of ignition or explosion.

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used at high volume for prolonged periods of time.

NOTE: For France, Earphone (listed below) for this device have been tested to comply with the Sound Pressure Level requirement laid down in the applicable NF EN 503321:2000 and/or NF EN 50332-2:2003 standards as required by French Article L. 5232-1.

• Earphone, manufactured by HTC, Model HS G335.

SAFETY IN AIRCRAFT

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off your phone by switching to Airplane Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where

blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using handsfree devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

• Avoid using your phone near metal structures (for example, the steel frame of

a building).

• Avoid using your phone near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories that do

not contain any metal.

• Use of non-original manufacturer-approved accessories may violate your

local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.

If you use any other personal medical device, consult the manufacturer of your device to determine if they are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

Your device has an internal antenna. This product should be operated in its normaluse position to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as result in non-compliance with local regulatory requirements in your country.

To assure optimal phone performance and ensure human exposure to RF energy is within the guidelines set forth in the relevant standards, always use your device only in its normal-use position. Contact with the antenna area may impair call quality and cause your device to operate at a higher power level than needed. Avoiding contact with the antenna area when the phone is IN USE optimizes the antenna performance and the battery life.

Antenna location

General Precautions

• Avoid applying excessive pressure to the device

Do not apply excessive pressure on the screen and the device to prevent damaging them and remove the device from your pants’ pocket before sitting down. It is also recommended that you store the device in a protective case and only use the device stylus or your finger when interacting with the touch screen. Cracked display screens due to improper handling are not covered by the warranty.

• Device getting warm after prolonged use

When using your device for prolonged periods of time, such as when you’re talking on the phone, charging the battery or browsing the web, the device may become warm. In most cases, this condition is normal and therefore should not be interpreted as a problem with the device.

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside the device should be done by an authorized service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorized service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen onto the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the operating

instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

NOTICE: When taking the device from low-temperature conditions into a warmer

environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identied as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

Contents

Chapter 1 Getting Started 23

1.1 Getting to Know Your Touch Phone and Accessories .....................................24

Left panel.....................................................................................................................................24

Right panel..................................................................................................................................24

Front panel.................................................................................................................................. 25

Back panel ...................................................................................................................................26

Top panel..................................................................................................................................... 27

Bottom panel..............................................................................................................................27

Accessories.................................................................................................................................. 28

1.2 Installing the SIM Card, Battery, and Storage Card........................................ 28

SIM card........................................................................................................................................ 28

Battery...........................................................................................................................................29

Storage card................................................................................................................................31

1.3 Charging the Battery ........................................................................................31

1.4 Starting Up ........................................................................................................ 32

Turn your device on and off..................................................................................................32

Auto configure the data connection settings ................................................................32

Switch to Sleep mode when not in use............................................................................33

1.5 Navigating Your Device .................................................................................... 34

Finger-touch control................................................................................................................34

Stylus.............................................................................................................................................36

On-screen navigation control ..............................................................................................36

1.6 Home Screen ..................................................................................................... 37

1.7 Status Icons ....................................................................................................... 38

1.8 Start Menu......................................................................................................... 41

1.9 Quick Menu....................................................................................................... 42

1.10 Adjusting the Volume .....................................................................................43

1.11 Using your Device as a USB Drive.................................................................. 44

Chapter 2 Using Phone Features 45

2.1 Using the Phone................................................................................................ 46

The Phone screen .....................................................................................................................46

Enter your PIN ............................................................................................................................46

2.2 Voice Call ...........................................................................................................47

Make a call...................................................................................................................................47

Answer a call............................................................................................................................... 48

End a call .....................................................................................................................................51

Call History ..................................................................................................................................52

Speed Dial ...................................................................................................................................52

Turn the phone function on and off..................................................................................53

2.3 Voice and Video over IP Calls ........................................................................... 54

Change the VoIP service settings........................................................................................54

Make a VoIP call......................................................................................................................... 56

Answer a VoIP call.....................................................................................................................57

End a VoIP call............................................................................................................................57

Make a VVoIP call ......................................................................................................................58

Answer a VVoIP call..................................................................................................................58

End a VVoIP call..........................................................................................................................59

Change the VVoIP call settings............................................................................................59

2.4 Smart Dial ..........................................................................................................62

Make a call or send a text message using Smart Dial..................................................63

2.5 Setting Up Bluetooth SIM Access for Car Kit Phones .....................................63

Chapter 3 TouchFLO™ 3D 65

3.1 About TouchFLO™ 3D ........................................................................................66

3.2 Using the TouchFLO 3D Home Screen .............................................................66

Home............................................................................................................................................. 68

People...........................................................................................................................................70

Messages .....................................................................................................................................72

Mail.................................................................................................................................................73

Internet......................................................................................................................................... 75

Photos and Videos....................................................................................................................75

Music .............................................................................................................................................77

Weather........................................................................................................................................ 80

Settings.........................................................................................................................................82

Programs......................................................................................................................................83

3.3 Finger Gestures................................................................................................. 84

Finger scrolling..........................................................................................................................84

Finger zooming .........................................................................................................................85

Finger panning ..........................................................................................................................85

Chapter 4 Entering Text 87

4.1 Entering Information........................................................................................ 88

4.2 Using the Full QWERTY..................................................................................... 89

4.3 Using the Compact QWERTY............................................................................ 91

4.4 Using the Phone Keypad ..................................................................................92

4.5 Using Multitap and T9 Modes.......................................................................... 93

Multitap mode...........................................................................................................................93

T9 mode .......................................................................................................................................93

4.6 Using Numeric and Symbol Mode ...................................................................95

4.7 Using Block Recognizer.................................................................................... 96

4.8 Using Letter Recognizer ...................................................................................96

4.9 Using Transcriber.............................................................................................. 97

Chapter 5 Synchronizing Information With Your Computer 99

5.1 About Synchronization ..................................................................................100

Ways to synchronize............................................................................................................. 100

5.2 Setting Up Windows Mobile® Device Center on Windows Vista® ................101

Set up synchronization in Windows Mobile Device Center.................................... 101

Use Windows Mobile Device Center ............................................................................... 103

5.3 Setting Up ActiveSync® on Windows® XP......................................................104

Install ActiveSync................................................................................................................... 104

Set up synchronization in ActiveSync............................................................................ 104

5.4 Synchronizing With Your Computer .............................................................. 105

Start and stop synchronization......................................................................................... 105

Change which information is synchronized ................................................................106

Troubleshoot sync connection problem....................................................................... 107

5.5 Synchronizing via Bluetooth ......................................................................... 107

5.6 Synchronizing Music and Video.....................................................................108

Chapter 6 Exchanging Messages 109

6.1 Messaging ....................................................................................................... 110

6.2 Text Messages ................................................................................................. 111

Create a new text message ................................................................................................ 111

Compose and send a text message ................................................................................ 112

Manage text messages ........................................................................................................ 112

6.3 Types of E-mail Accounts ................................................................................115

Set up your device to synchronize Outlook e-mail with the computer............. 115

Add an e-mail account......................................................................................................... 115

6.4 E-mail Setup Wizard........................................................................................116

Set up an Internet e-mail account ................................................................................... 116

Set up a custom domain e-mail........................................................................................ 118

6.5 Using E-mail.....................................................................................................119

Create a new e-mail message............................................................................................ 119

Compose and send an e-mail............................................................................................ 120

Filter the Inbox message list.............................................................................................. 121

View and reply to messages .............................................................................................. 121

Synchronize e-mails.............................................................................................................. 123

Customize e-mail settings ..................................................................................................124

Chapter 7 Working With Company E-mails and Meeting Appointments 127

7.1 Synchronizing with the Exchange Server .....................................................128

Set up an Exchange Server connection......................................................................... 128

Start synchronization ........................................................................................................... 129

7.2 Working With Company E-mails .................................................................... 130

Automatic synchronization through Direct Push...................................................... 130

Scheduled synchronization ............................................................................................... 131

Instant download through Fetch Mail ........................................................................... 131

Search for e-mails on the Exchange Server.................................................................. 132

Flag your messages............................................................................................................... 133

Out-of-office auto-reply ...................................................................................................... 134

7.3 Managing Meeting Requests .........................................................................134

7.4 Finding Contacts in the Company Directory.................................................136

Chapter 8 Internet 139

8.1 Ways of Connecting to the Internet............................................................... 140

Mobile WiMAX......................................................................................................................... 140

Wi-Fi............................................................................................................................................ 141

EDGE........................................................................................................................................... 145

Dial-up ....................................................................................................................................... 147

8.2 Starting a Data Connection............................................................................ 147

8.3 Using Opera Mobile™......................................................................................148

View web pages ..................................................................................................................... 150

Opera Mobile menu.............................................................................................................. 151

8.4 Using YouTube™ ..............................................................................................152

Browse for videos................................................................................................................... 153

Watching videos..................................................................................................................... 154

Bookmarks................................................................................................................................ 155

History........................................................................................................................................ 156

8.5 Using Windows Live™......................................................................................157

Set up Windows Live™.......................................................................................................... 157

The Windows Live™ interface ............................................................................................ 158

Windows Live™ Messenger ................................................................................................ 159

Launch Messenger and sign in .........................................................................................159

Add Windows Live™ contacts ............................................................................................ 160

8.6 Using RSS Hub.................................................................................................161

Subscribe to and organize news channels................................................................... 161

View and organize headlines............................................................................................. 164

View the news summary..................................................................................................... 165

8.7 Using Your Device as a Modem (Internet Sharing)....................................... 167

Set up your device as a WiMAX modem ........................................................................170

Chapter 9 Bluetooth 171

9.1 Bluetooth Modes ............................................................................................ 172

9.2 Bluetooth Partnerships ..................................................................................173

9.3 Connecting a Bluetooth Hands-free or Stereo Headset ..............................174

9.4 Beaming Information Using Bluetooth......................................................... 175

9.5 Printing Files via Bluetooth............................................................................177

Chapter 10 Navigating on the Road 179

10.1 Google™ Maps............................................................................................... 180

Open Google Maps ...............................................................................................................180

Search for a place of interest ............................................................................................. 181

10.2 Guidelines and Preparation for Using GPS................................................. 182

10.3 Downloading Satellite Data via QuickGPS .................................................184

Download options................................................................................................................. 185

Chapter 11 Experiencing Multimedia 187

11.1 Taking Photos and Videos ............................................................................188

Capture modes....................................................................................................................... 188

Camera controls ..................................................................................................................... 190

On-screen controls and indicators .................................................................................. 191

Menu Panel ..............................................................................................................................192

Zooming.................................................................................................................................... 194

The Review screen................................................................................................................. 195

Advanced Options................................................................................................................. 196

11.2 Viewing Photos and Videos Using Album...................................................199

Select a photo or video to view........................................................................................ 200

View an image......................................................................................................................... 201

Play back video....................................................................................................................... 205

Close Album............................................................................................................................. 205

11.3 Using Windows Media® Player Mobile ........................................................ 206

About the controls ................................................................................................................ 207

About the screens and menus.......................................................................................... 207

Synchronize video and audio files................................................................................... 208

Play media................................................................................................................................ 210

Playlists...................................................................................................................................... 211

Troubleshooting..................................................................................................................... 211

11.4 Using FM Radio .............................................................................................212

FM Radio controls.................................................................................................................. 212

Adjust the volume................................................................................................................. 213

Save presets............................................................................................................................. 213

FM Radio main menu ........................................................................................................... 214

11.5 Using Audio Booster..................................................................................... 215

Chapter 12 Programs 217

12.1 Programs on your Device............................................................................. 218

12.2 Adding and Removing Programs ................................................................221

12.3 Adobe® Reader® LE .......................................................................................222

12.4 Calendar ........................................................................................................223

Create appointments ........................................................................................................... 223

View appointments............................................................................................................... 225

Send appointments .............................................................................................................. 226

12.5 Contacts ........................................................................................................227

Add new contacts.................................................................................................................. 228

Organize and search contacts........................................................................................... 229

Share contact information.................................................................................................. 229

12.6 Comm Manager.............................................................................................230

12.7 Microsoft® Office Mobile.............................................................................. 232

12.8 Notes.............................................................................................................. 233

12.9 Java ................................................................................................................234

Install and launch MIDlets/MIDlet suites....................................................................... 234

Manage MIDlets/MIDlet suites.......................................................................................... 235

12.10 SIM Manager ...............................................................................................236

12.11 Tasks ............................................................................................................239

12.12 ZIP ................................................................................................................240

Chapter 13 Managing Your Device 243

13.1 Copying and Managing Files .......................................................................244

13.2 Settings on your Device ...............................................................................245

Personal tab............................................................................................................................. 245

System tab................................................................................................................................ 246

Connections tab..................................................................................................................... 248

13.3 Changing Basic Settings............................................................................... 250

Date and time.......................................................................................................................... 250

Regional settings ................................................................................................................... 250

Display settings ...................................................................................................................... 251

Device name............................................................................................................................ 251

Ringer settings........................................................................................................................ 252

Alarms and notifications .....................................................................................................253

Phone services ........................................................................................................................ 254

13.4 Using Connection Setup...............................................................................254

13.5 Using Task Manager...................................................................................... 256

13.6 Connecting to an External Display..............................................................258

Connect the device to an external display................................................................... 258

13.7 Protecting Your Device................................................................................. 259

Protect your SIM card with a PIN...................................................................................... 259

Protect your device with a password.............................................................................. 259

Encrypt files on your storage card................................................................................... 260

13.8 Managing Memory .......................................................................................261

13.9 Resetting Your Device................................................................................... 262

Soft reset................................................................................................................................... 262

Hard reset ................................................................................................................................. 262

Clear Storage........................................................................................................................... 263

13.10 Windows Update.........................................................................................264

13.11 Battery Saving Tips.....................................................................................265

Appendix 267

A.1 Specifications..................................................................................................268

A.2 Regulatory Notices .........................................................................................269

Index 277

Chapter 1

Getting Started

1.1 Getting to Know Your Touch Phone and Accessories

1.2 Installing the SIM Card, Battery, and Storage Card

1.3 Charging the Battery

1.4 Starting Up

1.5 Navigating Your Device

1.6 Home Screen

1.7 Status Icons

1.8 Start Menu

1.9 Quick Menu

1.10 Adjusting the Volume

1.11 Using your Device as a USB Drive

24 Getting Started

1.1 Getting to Know Your Touch Phone and Accessories

Left panel Right panel

VOLUME UP

During a call or when playing music, press this button to increase the volume.

VOLUME DOWN

During a call or when playing music, press this button to lower the volume.

Stylus

(See “Stylus” in this chapter for details.)

Getting Started 25

Front panel

Notification LED

Shows a flashing green light when there are new notifications.

Second Camera

Earpiece

Listen to a phone call from here.

Touch Screen

HOME

Press to return to the Home screen. See Chapter 3 for details.

TALK/SEND

Press to answer an

•

incoming call or dial a number. During a call, press

•

and hold to toggle the speakerphone on and off. Press and hold to use

•

Voice Speed Dial. (See Chapter 12 for details.)

Note By default, the device vibrates and plays a sound when you press any of the virtual

buttons — TALK/SEND, HOME, BACK and END. To disable any of these notifications, tap Start > Settings > Personal tab > Buttons > Virtual Buttons tab, then clear the Play a sound or the Vibrate the device check box according to your preference.

Use this camera for video call conversations or to take a self-portrait.

END

• Press to end a call or

return to the Home screen.

• Press and hold to lock

the device. (See “Long Press End Key” under “Settings on your Device” in Chapter 13 for details.)

BACK

Press to return to the previous screen.

26 Getting Started

Back panel

Speaker

Back Cover

5.0 Megapixel Camera

See “Taking Photos and Videos” in Chapter 11 for details.

Getting Started 27

Top panel

3.5 mm Audio Jack

Connect the supplied stereo headset for hands-free conversation or for listening to audio media.

Bottom panel

Sync Connector

Connect the supplied USB cable to synchronize information or plug in the AC adapter to recharge the battery.

POWER

Press to turn off the display temporarily. To turn off the power, press and hold for about 5 seconds. For more information, see “Starting Up” in this chapter.

Notification LED

Shows a flashing amber light when the battery level reaches 10% or lower. Shows a solid amber light when the battery is being charged.

Microphone

28 Getting Started

Accessories

The product package includes the following items and accessories:

Battery• Pouch• AC adapter• Quick Start Guide• Screen protector• Getting Started and Application discs• Stereo headset• Extra stylus• USB sync cable•

1.2 Installing the SIM Card, Battery, and Storage Card

Always turn off your device before installing or replacing the SIM card, battery, and storage card. You also need to remove the back cover before you can install these components.

To remove the back cover

Make sure your device is turned off.

Hold the device with both hands and the front panel facing down.

Push the back cover up with your thumb until it disengages from the device and then slide it up to remove.

SIM card

The SIM card contains your phone number, service details, and phonebook/ message memory. Your device supports both 1.8V and 3V SIM cards.

Note Some legacy SIM cards may not function with your device. You should consult with

your service provider for a replacement SIM card. There may be fees for this service.

Getting Started 29

To install the SIM card

Make sure your device is turned off.

Locate the SIM card slot, then insert the SIM card with its gold contacts facing down and its cut-off corner facing out the card slot.

Slide the SIM card completely into the slot.

To remove the SIM card

Remove the battery if it is installed.

Slide the SIM card out from the SIM card slot with your thumb.

Cut-off corner

Battery

Your device comes with a rechargeable Lithium-ion or Lithium-ion polymer battery and is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including network configuration, signal strength, the temperature of the environment in which you operate your device, the features and/or settings you select and use, items attached to connecting ports, and your voice, data, and other program usage patterns.

Battery life estimates (approximations):

Standby time: Up to 390 hours for GSM

•

Talk time: Up to 310 minutes for GSM

•

Video call time: Up to 120 minutes

•

Note Battery life is subject to network and phone usage.

Up to 450 hours for WCDMA

Up to 390 minutes for WCDMA

30 Getting Started

Warning! To reduce risk of fire or burns:

• Do not attempt to open, disassemble, or service the battery pack.

• Do not crush, puncture, short external contacts, or dispose of in fire or water.

• Do not expose to temperatures above 60

• Replace only with the battery pack designated for this product.

• Recycle or dispose of used battery as stipulated by local regulations.

To install the battery

Align the battery’s exposed copper contacts with the battery connectors inside the battery compartment.

Insert the contacts side of the battery first and then gently push the battery into place.

Replace the back cover.

To remove the battery

Make sure your device is turned off.

Remove the back cover.

The upper right side of the battery has a protruding grip. Lift the protruding grip to remove the battery.

C (140oF).

Battery grip

Getting Started 31

Storage card

To have additional storage for your images, videos, music, and files, you can purchase a microSD™ card and install it into the your device.

To install a microSD card

Insert the microSD card into the slot with its gold contacts facing down until it clicks into place.

Note To remove the microSD card, press

it to eject it from the slot.

Storage card slot

1.3 Charging the Battery

New batteries are shipped partially charged. Before you start using your device, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles.

To charge the battery

Connect the USB connector of the AC adapter to the sync connector on your device.

Plug in the AC adapter to an electrical outlet to start charging the battery.

Note Only the AC adapter and USB sync cable provided with your device must be used to

charge the device.

Charging is indicated by a solid amber light on the LED indicator under the POWER button. As the battery is being charged while the power is on, a charging icon also appears in the title bar of the Home screen. After the battery has been fully charged, a full battery icon appears in the title bar of the Home screen.

32 Getting Started

Warning! • Do not remove the battery from the device while you are charging it using

the AC or car adapter.

• As a safety precaution, the battery stops charging when it overheats.

1.4 Starting Up

After installing your SIM card and battery and charging the battery, you can now power on and start using your device.

Turn your device on and off

To turn on the power

Press the POWER button.

When you turn on your device for the first time, a Quick Start Wizard guides

you through the screen calibration process and the set up of date and time and password. For more information about these settings, see Chapter

13. After the Quick Start Wizard finishes, the device installs customization settings, then restarts.

Note After the device restarts, you may be prompted to set up an e-mail account. For

instructions on how to set up an e-mail account, see Chapter 6.

To turn off the power

Press and hold the POWER button for a few seconds.

Tap Yes when a message prompts you to choose whether or not to turn off the device completely.

Auto configure the data connection settings

The first time you power on your device, you will see a notification message from Connection Setup. Connection Setup automatically configures your device’s data connections, such as 3G/EDGE/GPRS, MMS, and WAP, so that you do not need to enter the settings manually for your device.

Getting Started 33

To automatically configure data connection settings

1. When you see the notification message from the

Connection Setup, tap Ye s .

Note If you do not see the notification message, tap

2. If your SIM card supports multiple network

operator profiles, a message will appear with network profile choices. Select the profile you want to use and tap OK.

3. Connection Setup then starts to configure your

device’s data connection settings.

4. After the Connection Setup completes the

configuration, tap Restart.

For more information about Connection Setup, see Chapter 13.

on the Title bar to display the message.

Switch to Sleep mode when not in use

Press and immediately release the POWER button to turn off the display temporarily and switch your device to Sleep mode. Sleep mode suspends your device to a low power state while the display is off in order to save battery power.

Your device automatically goes into Sleep mode when you leave the device idle after a certain period of time. You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER button again or incoming calls/messages will wake up your device.

34 Getting Started

1.5 Navigating Your Device

There are different ways you can navigate and interact with the interface of your device.

Finger-touch control

A quick and easy way to interact with the home screen and the whole interface of your device is by touch. Basically, the following are the types of actions, called finger gestures, you would use when interacting with your device:

Touch or tap

When selecting items on the screen, such as the Home screen tabs, Start menu, programs and settings icons, and large on-screen buttons, simply touch them with your finger. Apply some pressure with your finger pad when touching an item on the screen.

Tapping means to touch lightly and quickly with your finger pad or fingertip. On screens that display smaller-size items, you can more accurately select an item by tapping it with your fingertip.

Swipe

To swipe means to drag your finger vertically or horizontally across the screen. The following are some instances when you would use swiping:

•

Flipping on the Home screen

Swipe your finger vertically to flip through favorite contacts, messages, music albums, photos, and more. For more information, see “Using the TouchFLO 3D Home Screen” in Chapter 3.

Scrolling

•

When browsing the contacts list, web pages, documents, and certain selection lists on the Home screen (such as the All Programs list), slowly swipe your finger vertically across the screen to scroll. This allows you to scroll by page and to view the content or available selections as you scroll.

Getting Started 35

The direction of swiping resembles the way you move a printed document as you are reading it. For detailed instructions, see “Finger scrolling” in Chapter 3.

Slide

Sliding on the touch screen also involves dragging with your finger, but you need to press and hold your finger with some pressure before you start to drag. While dragging, do not release your finger until you have reached the target position.

The following are some instances when you would use sliding:

•

Switching between Home screen tabs

Slide your finger left and right to switch between the Home screen tabs. For more information, see “Using the TouchFLO 3D Home screen“ in Chapter 3.

Advancing playback

•

In players that have a progress bar, such as the Home screen’s Music tab and Windows Media® Player Mobile, slide your finger horizontally on their progress bar to advance forward or move backward in the music or video you are playing.

For more information about the Home screen’s Music tab, see “Music” in Chapter 3.

For more information about Windows Media® Player Mobile, see “Using Windows Media® Player Mobile” in Chapter 11.

Flick

Flicking the screen is similar to swiping, except that you need to swipe your finger in light, quicker strokes. This finger gesture is always in a vertical direction, such as when flicking the contacts list. See “Finger scrolling” in Chapter 3 for details.

Finger zooming and panning

In programs such as Album and Opera Mobile, you can use finger gestures when zooming and panning. See Chapter 3, 8 and 11 for details.

36 Getting Started

Stylus

You can use the stylus to navigate and interact with the touch screen. To use the stylus, pull it out from the stylus compartment at the bottom of the right panel of your device.

The stylus is magnetic and sticks to the side when held close to the device. This prevents you from accidentally losing or misplacing the stylus.

Basically, you tap with the stylus to open programs and select items on the screen, and you tap and hold on the screen to open a shortcut menu. You can also use the stylus the same way as what you do with finger gestures, such as swiping, sliding and flicking on the screen.

On-screen navigation control

When using the Full QWERTY, Compact QWERTY, and Phone Keypad onscreen input methods, you can touch the Navigation Control keys at the bottom of the keyboard for directional control. Touch the directional arrows to navigate up, down, left, and right on the screen.

Navigation Control keys

Getting Started 37

1.6 Home Screen

The default home screen of the device is the TouchFLO™ 3D Home screen which allows finger-touch access to the most important functions such as contacts, text messages, e-mail, Internet, and more.

For more information about using the TouchFLO 3D Home screen, see Chapter 3.

Signal strength

Connection status

Notification

Start menu

TouchFLO 3D Home screen

Adjust volume

Battery status

Quick menu

Open the Phone screen (See Chapter 2 for details)

Open the Programs tab.

38 Getting Started

1.7 Status Icons

When you touch or tap the icon area of the title bar, the System Status screen opens and displays larger status icons so you can touch them with your finger more easily and accurately.

Tip The System Status screen can be disabled in TouchFLO settings. See “Settings on your

Device” in Chapter 13 for details.

The following are some of the status icons that you may see on the device.

Icons that appear in this area

Vibrate mode

Sound on

Sound off

Icons that appear in this area

Battery charging

Battery full

Battery very low

Getting Started 39

Icons that appear in this area

Connection Setup

Multiple notifications; tap the icon to view all New text messages; SMS notification of voice mail

Sending MMS

Receiving MMS

MMS sent

Cannot send MMS

New incoming MMS

New Windows Live™ message

Missed call

Icons that appear in this area

Speakerphone on

Roaming

Alarm

Other wireless network(s) detected

Wired headset connected

Bluetooth on

Bluetooth visible mode on

Bluetooth stereo headset connected

40 Getting Started

Icons that appear in this area

GPRS available

EDGE available

HSPA available

WCDMA/UMTS available

Connected to a wireless network

Connection is active

Connection is not active

Synchronization in progress

Icons that appear in this area

GPRS connecting

GPRS in use

EDGE connecting

EDGE in use

HSPA connecting

HSPA in use

WCDMA/UMTS connecting

WCDMA/UMTS in use

Maximum signal strength

No signal

Phone is turned off

No phone service

Searching for phone service

Voice call in progress

Call on hold

Calls are forwarded

Dialing while no SIM card is inserted

No SIM card inserted

Getting Started 41

1.8 Start Menu

The Start menu, which can be opened from the top left corner of the screen, gives you access to all the programs and settings of your Windows Mobile-powered device. Touch or tap to select an item on the Start menu.

Open the Start menu.

Open a recently-used program.

When you are on another screen, touch or tap this item to return to the TouchFLO 3D Home screen.

Open a program.

Access more programs.

View and change settings.

View Help information for the current screen.

By default, the Start menu is displayed in a large size to make it easier for you to touch menu items with your finger when selecting them from the Start menu. The Start menu can also be displayed in a smaller size, if preferred. Tap Start > Settings > System tab > TouchFLO and then clear the Enable large Start menu check box to display a smaller Start menu.

42 Getting Started

1.9 Quick Menu

The Quick menu, which can be opened from the top right corner of the screen, shows the currently running programs. You can quickly switch between running programs, stop programs, and see how much program memory is being used.

Customize Task Manager settings. (See “Using Task Manager” in

Chapter 13.)

Touch this icon to open the Quick Menu.

Stop all currently running programs.

Shows the total percentage of program memory in use. Touch to open the Memory settings screen.

• To switch to a running program, touch the program name.

• To stop a running program, touch

Getting Started 43

1.10 Adjusting the Volume

Adjusting the system volume changes the volume level of sound notifications and audio/video playback, whereas adjusting the ring volume affects only the volume of the phone ring. The system volume and ring volume can be separately adjusted.

1. Touch the icon area in the title bar and then touch the Speaker icon (

the System Status screen.

2. To switch between the Ring Volume and System Volume screens, touch

Ring or System on top of the screen.

3. On either screens, you can do the following:

• To increase or decrease the volume level, drag your finger up or down the

volume bars. You can also press the VOLUME UP/DOWN buttons on the left panel of your device.

Volume bars

• TouchVibrate to switch both System and Ring to Vibrate mode.

• Touch Silent to mute both the system and ring volume.

) on

44 Getting Started

4. The System Volume or Ring Volume screen automatically closes. You can also

manually close the screen by touching the screen.

Note On certain screens that do not show the volume status icon on the title bar, you need

to use the VOLUME UP/DOWN buttons on the left panel of your device to adjust the volume. Also use these buttons to adjust the conversation phone volume during an ongoing call.

1.11 Using your Device as a USB Drive

To easily carry media and other files with you, you can use your device’s storage card as a USB flash drive. This allows you to copy files from your computer to the device’s internal storage and vice versa faster.

Note You need to have a storage card installed on your device to be able to use your device

as a disk drive.

To use the device’s storage card as a USB flash drive

Do any of the following:

•

Connect the device to your PC using the USB sync cable. When the Connect to PC screen appears, select Disk Drive, then tap Done.

•

Touch Start > Settings > Connections tab > USB to PC, select Disk Drive mode, then connect the device to your PC using the USB sync cable.

When Disk Drive mode is used:

•

You will not be able to use your device to access files from the storage card or run applications that are installed on the storage card while the device is connected to your PC.

•

Your PC will only connect to the device’s storage card. When you access your device from the PC, you will only see the contents of the device’s storage card.

Remember to change back to ActiveSync mode when you need to synchronize data between your device and your PC.

Chapter 2

Using Phone Features

2.1 Using the Phone

2.2 Voice Call

2.3 Voice and Video over IP Calls

2.4 Smart Dial

2.5 Setting Up Bluetooth SIM Access for Car Kit Phones

46 Using Phone Features

2.1 Using the Phone

Like a standard mobile phone, you can use your device to make, receive, and keep track of calls and send messages.

The Phone screen

To open the Phone screen, do one of the following:

• On the Home screen, tap Phone.

• Tap Start > Phone.

• Press the TALK/SEND button.TALK/SEND button.

TALK/SEND button

Enter your PIN

Most SIM cards are preset with a PIN (personal identification number) that is provided by your wireless service provider.

1. Enter the preset PIN assigned by your wireless service provider.

2. Tap Enter.

Note If you entered the wrong PIN three times, the SIM card will be blocked. If this happens,

you can unblock it with the PUK (PIN Unblocking Key) obtained from your wireless service provider.

Using Phone Features 47

2.2 Voice Call

Make a call

To make a call from the Phone screen

1. On the Home screen, tap Phone.

2. Tap the keys on the keypad to enter the

phone number.

Tip If you tapped a wrong number, tap to

erase each subsequent digit of a number. To erase the entire number, tap and hold

3. Tap Talk to place the call.

Tip When in a call, use the VOLUME UP/DOWN

buttons on the side of the device to adjust the phone volume.

Note After tapping 6 keys and the number you

are dialing is not in your contacts, a Save to Contacts? button will appear above the keypad. Tap it to save the number to your Contacts.

To make a call from Contacts

On the Home screen, tap Start > Contacts to open the Contacts screen.

Do one of the following:

• Tap the contact to open the contact details and then tap the phone number

you want to call.

• Tap and hold the contact you want to call and then from the menu, select

Call Work, Call Home, or Call Mobile.

To make a call from the TouchFLO 3D Home screen

Refer to Chapter 3 to learn how to make a call from the TouchFLO 3D Home screen.

48 Using Phone Features

To make an emergency call

Enter the international emergency number for your locale, and press the TALK/SEND button on your device.

Tip Additional emergency numbers may be included in your SIM card. Contact your

wireless service provider for details.

To make an international call

1. Tap and hold the number 0 key on the Phone screen until the plus (+) sign appears. The plus (+) sign replaces the international prefix of the country that you are calling.

2. Enter the full phone number you want to dial, and press the TALK/SEND

button on your device. The full phone number includes the country code, area code (without the leading zero, if any), and phone number.

To call voice mail

Number 1 is generally reserved for your voice mail. Tap and hold this button on the

Phone screen keypad to call voice mail and retrieve your voice mail messages.

Answer a call

When you receive a phone call, a message will appear, giving you the option to either answer or ignore the incoming call.

Using Phone Features 49

To answer or reject an incoming call

• To answer the call, tap Answer, or press the TALK/SEND button.

• To reject the call, tap Ignore, or press the END button.

• To mute the ringing sound without rejecting the call, tap Mute Ring.

Note When you answer a call and hold the device close to your ear, the display automatically

turns off. This helps prevent accidental screen presses during a phone call and also help to save battery power. To turn the display back on, briefly press the POWER button. The display also automatically turns on when the other party ends the call.

To reject a call and send a text message

When you reject a call, you can choose to automatically send a text message to the mobile phone of the caller.

1. On the Phone screen, tap Menu > Options > Advanced tab.

2. Select the Reject call with text message check box.

3. Change the default text message if needed, then tap OK.

50 Using Phone Features

When Reject call with text message is enabled, tap Send Text to reject the call and send the text message to the caller.

To put a call on hold

Your device notifies you when you have another incoming call, and gives you the option of rejecting or accepting the call. If you are already on a call and accept the new call, you can choose to switch between the two callers, or set up a conference call between all three parties.

1. Tap Answer to take the second call, and put the first one on hold.

2. To end the second call and return to the first call, tap End Call or press END

on your device.

To switch between two calls

During a call, tap

To set up a conference call

1. Either put a call on hold, and dial a second number; or, accept a second

incoming call when you already have one in progress.

Tip To dial a second number, tap on the screen.

2. Tap .

Note Not all mobile phone networks support conference calling. Contact your wireless

service provider for details.

To turn on and off the Speakerphone

During a call, tap speakerphone icon

Tip You can also tap and hold TALK/SEND to toggle between turning the speakerphone

on or off.

Warning! To avoid damage to your hearing, do not hold your device against your ear when

the speakerphone is turned on.

to toggle between turning on or off the speakerphone. The

appears in the title bar when the speakerphone is on.

Using Phone Features 51

To mute the microphone during a call

Tap to toggle between turning on or off the microphone. When the microphone is turned off, the mute icon

To open Notes while in a call

Tap

To vibrate the device when the call is established

You can set the device to vibrate once to alert you that the call has been established with the other party.

1. On the Phone screen, tap Menu > Options >Advanced tab.

2. Select the Vibrate device when connection is established check box and

then tap OK.

appears on the screen.

End a call

When a call is in progress, tap End Call or press END to hang up.

To add a new phone number to Contacts after a call

If the phone number of the person who called is not in Contacts, you can choose to save the number after you hang up.

1. On the Phone screen, tap Menu > Options > Advanced tab.

2. Select the Add new phone number to Contacts at end of call check box,

then tap OK.

When you enable this option, a pop-up message appears after you end the phone call and lets you add the phone number to Contacts.

52 Using Phone Features

To check a missed call

You will see the

icon in the title bar when you missed a call. To check who the

caller was, do one of the following:

• Tap the title bar, then tap

and then tap View.

• On the Phone screen, tap Menu > Call History and then tap

Call History

Use Call History to check for missed calls, dialed numbers, and calls received. To open the Call History screen, tap Menu > Call History on the Phone screen.

Speed Dial

Use Speed Dial to call frequently-used numbers with a single tap. For example, if you assign a contact to the location 2 in Speed Dial, you can tap and hold the

number 2 key on the Phone screen keypad to dial the contact’s number.

To create a Speed Dial entry

1. On the Phone screen, tap Menu > Speed Dial.

2. Tap Menu>New.

3. Tap a contact, then select the phone number of the contact that you want

assigned to the speed dial key.

4. In Location, select an available key to use as the speed dial key.

5. Tap OK.

Tips • To create a Speed Dial entry from Contacts or SIM card contacts, tap the contact,

select the number you want to add to Speed Dial, then tap Menu > Add to Speed Dial.

• To delete a Speed Dial entry, in the Speed Dial list, tap and hold the desired entry,

then tap Delete.

Using Phone Features 53

Turn the phone function on and off

In many countries, you are required by law to turn off the phone while on board an aircraft.

To enable or disable the phone function

1. Tap Start > Programs > Comm Manager.

2. On the Comm Manager screen, tap the Phone button to enable or disable

the phone function. When enabled, the ON indicator is activated.

To enable or disable Airplane Mode

Another way to turn off the phone function is to switch your device to Airplane Mode. When you enable Airplane Mode, all wireless radios on your device are

turned off, including the phone function, Bluetooth, WiMAX, and Wi-Fi.

1. Tap Start > Programs > Comm Manager.

2. On the Comm Manager screen, tap the Airplane Mode button to enable or

disable Airplane Mode. When enabled, the ON indicator is activated.

When you disable Airplane Mode, the phone function is turned back on and the previous state of Bluetooth, WiMAX and Wi-Fi are restored.

54 Using Phone Features

2.3 Voice and Video over IP Calls

Your device allows you to make Voice over IP (VoIP) and Voice and Video over IP (VVoIP) calls to your contacts with VoIP-capable handsets, IP phones, or computers

with VoIP application installed.

Note VoIP and VVoIP calling are charged services and have to be provisioned on your

mobile phone account. Contact your wireless service provider for details.

Change the VoIP service settings

Check your device to see if it is preconfigured with your wireless service provider’s VoIP profile. A VoIP profile contains all the settings you need to make a VoIP or VVoIP call. It also specifies your VoIP user ID — a phone number, name, or e-mail address — that identifies your device in the VoIP network.

Note If your device already has preset VoIP profile, it is recommended that you do not

change this profile. If you change the preset profile, your device may not be able to make and receive VoIP/VVoIP calls. Contact your wireless service provider before you change the VoIP profile.

To check the preset VoIP profile

1. Tap Start > Phone.

2. Tap Menu > VoIP Options. The VoIP Options screen then appears.

3. In the Profile tab, tap Settings.

To set the preferred connection to use for VoIP and VVoIP calls

You can set the preferred network connection to use when making a VoIP or VVoIP call.

1. Tap Start > Phone.

2. Tap Menu > VoIP Options. The VoIP Options screen then appears.

3. In the Network tab, select from the following options:

Using Phone Features 55

• WiMAX / WiFi Only. Select this option if

you only want to use your WiMAX or Wi-Fi network connection for all outgoing calls.

• GSM Only. Select this option if you only want

to use your cellular network (EDGE or GPRS) for all outgoing voice calls. Calls made over the cellular network may incur additional charges.

• WiMAX / WiFi Preferred. When selected,

your device will initially use the WiMAX or Wi-Fi network connection for all outgoing calls. If these wireless network connections are not available, the calls will be made over your cellular network.

• GSM Preferred. When selected, your device will initially use your cellular

network for all outgoing calls. If your cellular network is not available, the device will connect to an available WiMAX or Wi-Fi network to make the call.

4. Tap OK.

After setting your preferred network connection, you can now register your device with the wireless service provider’s VoIP service and start making voice or video over IP calls.

To register the device to the VoIP service

1. On the Home screen, slide to the Settings tab.

2. On the Settings screen, tap Communications > Wi-Fi or WiMAX to enable

the wireless function.

Note You cannot connect to a WiMAX and a Wi-Fi network simultaneously.

56 Using Phone Features

3. When your device is connected to a wireless network, tap Start > Phone.

4. Check the VoIP status icon on the top right

corner of the Phone screen. Refer to the following table for the status icons’ description.

Icon Description

Ready. Registration to the VoIP service is successful. You can now make

or receive voice or video over IP calls.

Registering. The device is registering with the VoIP service.

Not available. The device fails to register with the VoIP service or the

VoIP service is not available.

Make a VoIP call

To make a VoIP call from the Phone screen

1. Tap the keys on the keypad to enter the VoIP

phone number (VoIP user ID).

Tip If you tapped a wrong number, tap to erase

each subsequent digit of a number. To erase the entire number, tap and hold

2. Tap Talk to place the call.

Notes • While on a VoIP call, you can also hold the call,

mute the phone, turn the speakerphone on or off, or open notes, just like while you are in a regular voice call.

• You cannot use a Bluetooth headset to make or receive a VoIP call.

VoIP registration status icon

Using Phone Features 57

To make a VoIP call using the SIP URI

You can make a Voice over IP call to contacts outside the VoIP service’s domain if you know their Uniform Resource Identifier (URI). The URI is your contact’s phone number inside a Session Initiation Protocol (SIP) server, and resembles an e-mail address (for example, contactname@sipnetwork.com).

1. On the Phone screen, tap Menu > Dial SIP URI.

2. Enter the SIP URI of the contact using the

onscreen keyboard, then tapap Call.

Note To make a VVoIP call to the contact, tap

Menu > Video Call. See “Make a VVoIP call” in this

chapter for details.

Answer a VoIP call

When you receive a VoIP call, a message will appear, giving you the option to either answer or ignore the incoming call. Answer a VoIP call as you would answer a regular voice call.

Notes • You cannot make a voice call over your cellular network when a VoIP call is in

progress.

• The VoIP service does not support conference calling.

• When a VoIP call is in progress, the device will automatically reject all incoming

VoIP or VVoIP calls.

• When a VoIP call is in progress and your phone receives an incoming voice call, the device will give you the option to either end the current VoIP call and answer the incoming voice call or ignore the incoming voice call.

End a VoIP call

When a VoIP call is in progress, tap End Call or press END to hang up.

58 Using Phone Features

Make a VVoIP call

Video calls made over IP are called Voice and Video over IP calls or VVoIP calls.

Do one of the following to make a VVoIP call:

• On the Phone keypad, tap the VoIP phone

number to call, then tap Menu > Video Call to start a VVoIP call.

• If you want to video call a contact outside the

VoIP service’s domain, tap Menu > Dial SIP URI, enter the SIP URI of the contact, then tapap

Menu > Video CallCall to start a VVoIP call.

Notes • The other party’s image will appear on the

screen about 3 to 5 seconds after a connection is established, depending on the connection strength. The streaming images quality may also be influenced by the connection strength.

• You cannot use a Bluetooth headset to make or receive a VVoIP call.

Answer a VVoIP call

To answer or reject an incoming VVoIP call

• To answer the VVoIP call, tap Answer, or press TALK/SEND on your device.

• To reject the VVoIP call, tap Ignore, or press END on your device.

• To mute the ringing sound without rejecting the call, tap Mute Ring.

Notes • You cannot make a voice call over your cellular network when a VVoIP is in progress.

• When a VVoIP call is in progress, the device will automatically reject all incoming

VoIP or VVoIP calls.

• When a VVoIP call is in progress and your phone receives an incoming voice call, the device will give you the option to either end the current VVoIP call and answer the incoming voice call or ignore the incoming voice call.

Using Phone Features 59

End a VVoIP call

Once a VVoIP call is in progress, tap End Call or press END to hang up.

Change the VVoIP call settings

While on a VVoIP call, you can change certain settings such as the size of the image, brightness of the video image, the camera to use, and more.

The following shows the VVoIP call screen elements and control buttons during an ongoing VVoIP call.

1 Image display area. Displays your image

and the other party's image, depending on the selected Swap View setting.

2 Status area. Displays phone number or

contact name and call timer.

3 Camera. Tap to toggle between turning

on/off the camera. When the camera is turned off, the image displayed depends on the Video Call options you have set. See “VVoIP call options” for details.

4 Swap View. Tap to toggle between the two

view options. You can choose to have the other party’s image small or large.

5 Main/Second. Tap to toggle between using

the Main (back) and Second (front) camera.

60 Using Phone Features

Brightness

To adjust the brightness of the live image, tap Menu > Brightness while in a VVoIP call.

A brightness bar appears below the status area. Tap to make the live image brighter or tap to make it less bright. You can also move the slider left or right with your finger or stylus to adjust the brightness.

Note You cannot adjust the brightness for a still image.

VVoIP call options

On the Phone screen, or on the screen of the ongoing VVoIP call, you can also tap

Menu > Video Call Options and set the following options:

• Show still image. Select the image you want to display when you turn off the

camera.

• Preset (female). Displays a female picture in place of your image.

• Preset (male). Displays a male picture in place of your image.

• Custom image. Lets you use an image file as your display picture. WhenWhen

this option is selected, the is selected, the, the File Name box and the Browse button will be enabled, allowing you to select an image file., allowing you to select an image file.

• Last video frame. Uses the last video frame before you stopped the

camera as your display image.

Using Phone Features 61

• Video screen preference. Change how

your image and the other party’s image are displayed on the screen, select your preference from the Video screen preference list or tap the View button on the Video Call screen.

• Camera options:

• Flip the 2nd camera video. Select this

check box if you are going to show a text document to the other party using the second camera.

• Switch camera off when answering video

call. Select this check box to not send a

video feed of yourself to the other party when answering a video call. Instead, the option you selected in Show still image will be displayed.

• Switch camera off when making video call. Select this check box to not

send a video feed of yourself to the other party when making a video call. Instead, the option you selected in Show still image will be displayed.

• Display info:

• Show call timer. Select this check box to display the call period in the

status area.

• Show phone number or name. Select this check box to display the other

party’s phone number or name in the status area.

62 Using Phone Features

2.4 Smart Dial

Smart Dial makes it easy for you to dial a

phone number.

When you start entering a phone number or contact name, Smart Dial automatically searches and sorts the contact entries on the SIM card, in Contacts, and the phone numbers in Call History (including incoming, outgoing, and missed calls). You can then select the desired number or contact from the filtered list to dial.

To find a contact name or number

You can just enter the first letter of the name or number of a contact. Smart Dial will search for contact phone numbers and the first character of a contact name as well as from the character that appears after a space, dash, or underscore in a contact name. For example, if you tap number “2” on the phone keypad, which is associated with [a, b, and c] on the Phone keypad, contact names such as the following will be considered matches: “Ben Miller”, “George Adams”, “John-Carter”, “Carter, Ellen”, “Dixon, Allan”, “Thomas_Clark”, “JaneCampbell”.

If the matching list is long and you want to narrow down the search further, enter another letter. Using the same example above, if you continue to tap “3” which is associated with [d, e, f], the matching list will be narrowed down to the following names: “Ben Miller”, “George Adams”, “Carter, Ellen”, “Dixon, Allan”.

Smart Dial panel

Using Phone Features 63

Make a call or send a text message using Smart Dial

1. On the Home screen, tap Phone.

2. Begin entering the first few numbers or characters.

When you start entering a number or letter, the Smart Dial panel will display matches found.

Tip Tap to close the phone keypad and to see if there are more matching contacts.

3. In the Smart Dial panel, flick and slide your finger on the touch screen.

4. You can do one of the following:

• Tap the contact to call the selected contact.

• To send a text message to the selected contact, tap

Menu > Send Text Message.

2.5 Setting Up Bluetooth SIM Access for Car Kit Phones

Bluetooth car kits that support the SIM Access Profile (SAP) can connect to your device and access its SIM card via Bluetooth. Once a SAP connection has been established, you can download SIM contacts from your device to the car kit phone. You can also use the car kit phone to answer and make calls using your device’s SIM card.

Note To enable downloading contacts onto the car kit, ensure that all contacts on the

device are stored in the SIM card and not in the device memory. Configure the car kit to download contacts only from the SIM card.

1. On your device, make sure that Bluetooth is turned on and set to visible

mode. For information about turning on Bluetooth and enabling visible mode, see “Bluetooth Modes” in Chapter 9.

Note When you turn on Bluetooth while your device is connected to a WiMAX network,

a message appears prompting you to disconnect the WiMAX connection first. See “Mobile WiMAX” in Chapter 8 to know how to turn WiMAX on or off.

64 Using Phone Features

2. On the Home screen, slide to the Settings tab and then tap Menu >

Bluetooth Devices > SIM Access tab.

3. Select the Remote SIM Access check box, then tap OK.

4. Connect the car kit phone to your device via Bluetooth. To learn how to

connect, consult your car kit phone’s manual.

5. If this is the first time you are pairing the car kit phone with your device, enter

the car kit’s passcode on your device.

6. A pop-up message should appear on your device saying that a connection

has been established between your device and car kit phone. Tap OK.

7. On the Bluetooth screen, tap the SIM Access tab, then tap Connect.

Note You will not be able to make/receive calls, send/receive messages or perform related

activities on your device when the SIM Access Profile connection is active. You’ll be able to do all these from the car kit phone during this time. After the connection is disconnected, you will be able to use your device as before.

Chapter 3

TouchFLO™ 3D

3.1 About TouchFLO™ 3D

3.2 Using the TouchFLO 3D Home Screen

3.3 Finger Gestures

66 TouchFLO™ 3D

3.1 About TouchFLO™ 3D

TouchFLO™ 3D gives you touch control over your Windows Mobile-powered

device. TouchFLO 3D provides the following features:

A Home screen that allows finger-touch access to the most widely-used

•

functions, such as People, Messages, Mail, Music, Internet, and more

Allows you to use finger gestures to navigate screens

•

3.2 Using the TouchFLO 3D Home Screen

The TouchFLO 3D Home screen have the following tabs:

Home

People

Messages

Internet Photos and

Mail

Videos

ProgramsWeather

Music Settings

TouchFLO™ 3D 67

To switch between the tabs of the Home screen

Do one of the following:

Touch or tap the desired tab on the Home screen.

•

Press and hold your finger on the active tab, then slide your finger right or left

•

over the tabs. Release when you have selected the desired tab.

Note Apply some pressure when pressing and holding on the active tab to be able to

slide over the tabs.

68 TouchFLO™ 3D

Swipe left across the screen to move to the next tab, and swipe right across

•

the screen to move to the previous tab.

Home

The Home tab displays the current date, a flip-style clock, and an Alarm icon that indicates whether the alarm is on or off. Missed calls and your upcoming calendar appointments are also shown on the Home tab. To select an item on the Home tab, touch the item.

TouchFLO™ 3D 69

Touch the date or the flip clock to open the Clock & Alarms screen where you can set the date, time, and alarm. (See Chapter 13 for details.)

Touch this area to view details about missed calls in the Call History. (See Chapter 2 for details.)

One all-day appointment and up to two timed appointments can be displayed. Touch this area to create, edit or view an appointment. (See “Calendar” in Chapter 12 for details.)

Swipe upward on the screen to display the smaller digital clock and view more appointments.

Home tab with flip clock

Swipe downward on the screen to change back to the flip clock.

Home tab with smaller digital clock

70 TouchFLO™ 3D

People

On the People tab, you can add favorite contacts who you most frequently communicate with. This allows you to quickly make calls, send text messages, and send e-mails to your favorite contacts.

Tip You can add up to 15 favorite contacts on the People tab.

To add favorite contacts

You should already have created or synchronized contacts on your device before you can add them to the People tab.

1. On the Home screen, slide your finger to the People tab.

2. Touch the small or big Plus icon, or touch

Add Favorite.

3. On the Select a Contact screen, touch the

name of the desired contact.

Tips • To create a new contact, touch Menu >

New Contact. See “Contacts” in Chapter

12 for details.

• SIM contacts cannot be added as favorite contacts.

4. Select a phone number or e-mail address to

associate to the favorite contact.

Note If there is no picture associated with the

contact, the next screen prompts you to assign a picture to the contact.

5. To add another favorite contact, touch the small Plus icon ( ) at the right

side of the screen and repeat steps 3 and 4.

TouchFLO™ 3D 71

To choose from your favorite contacts

•

Do any of the following:

To flip through the contact pictures one at a time, swipe your finger up or down the screen.

On the picture strip at the right side of the People screen:

Touch the picture of the desired favorite

•

contact; or

Press and hold on the currently selected

•

contact picture to display a slide-out bar, and then slide up or down the picture strip. Release your finger when the desired favorite contact is selected.

72 TouchFLO™ 3D

After selecting a favorite contact, touch an icon below the contact name to

•

call or to compose and send a text or an e-mail message to the contact.

Touch to call the contact.

Touch to call the contact’s home phone.

Touch to call the contact’s work/office phone.

Touch to compose and send a text message.

Touch to compose and send an e-mail message.

The icons shown will depend on available contact information. For example, ( ) will be shown if the contact’s home phone is specified.

Touch the picture of the contact on the center screen to access his or her

•

contact card. On the contact card, you will see the last outgoing or incoming call as well as contact details such as phone numbers, e-mail address, and more.

Tips • On the People tab, touch All People to access SIM contacts and all contacts that

are stored on your device.

• To remove the current favorite contact, touch Menu > Remove Favorite.

Messages

On the Messages tab, you can read SMS text messages as they arrive and create a new SMS text message.

When there are new incoming text messages, the icon on the Messages tab will show the number of new messages. For example, message received.

indicates that there is a new

TouchFLO™ 3D 73

To view the entire message thread from the sender and reply, touch the message on the screen.

Touch this icon to create a new SMS text message.

To flip through received text messages, swipe your finger upward/ downward, touch the Up/Down arrow on the screen.

Touch All Messages to access all text messages in your inbox and other folders.

Touch Menu to remove the current message and access more options.

For more information about working with text messages, see “Text Messages” in Chapter 6.

Mail

The Mail tab is where you send and receive e-mail messages. Including Outlook E-mail, you can add up to four POP3/IMAP4 and web-based e-mail accounts in this tab.

To add an e-mail account

1. On the Home screen, slide your finger to the Mail tab.

2. If this is your first time to add an e-mail account, touch New Account on the

bottom-right side of the screen.

3. Set up your e-mail account using the E-mail Setup wizard.

4. To add another e-mail account, touch Menu > Accounts > New Account and

use the E-mail Setup wizard to set up your account.

74 TouchFLO™ 3D

For detailed instructions on setting up e-mail accounts using the E-mail Setup wizard, see Chapter 6.

To check e-mail

When there are new e-mails, the icon on the Mail tab and the respective icons of the e-mail accounts will show the number of newly received messages.

After selecting an e-mail

To browse through

•

received e-mails, swipe up or down on the envelope image.

Touch the e-mail

•

on the screen to open and read the message.

Touch Inbox to access all e-mail messages of the currently selected account.

account, touch this icon to create and send a new e-mail message.

These are your e-mail accounts. Touch an icon to select an e-mail account and view the new e-mails received in that account.

Touch Menu to access more options.

For more information about working with e-mails, see Chapter 6 and 7.

TouchFLO™ 3D 75

Internet

On the Internet tab, you can open Opera Mobile™ to browse the web and add web favorites for one-touch access to your favorite web sites.

Touch here to browse the web using Opera Mobile.

Touch All Bookmarks to open Opera Mobile and add, view or delete web favorites.

Swipe upward to scroll down the screen and access more web favorites, when available.

For more information about using Opera Mobile, see Chapter 8.

Photos and Videos

The Photos and Videos tab lets you visually flip through your photos and video clips and view them in full screen. From this tab, you can also activate the Camera so you can take pictures and record video clips.

The Photos and Videos tab displays pictures and video files from the current favorite album. By default, the Camera Shots album which stores the pictures and videos that you captured using the device camera is set as the favorite. You can change to another favorite album, if preferred.

76 TouchFLO™ 3D

To set an album as a Favorite

1. On the Photos and Videos tab, touch Album to open the Album program.

2. Touch Albums and then select one of the listed favorite albums.

3. Tap Menu > Set as Favorite. and then tap OK on the confirmation screen.

To view photos and videos

Touch here to take a photo.

Touch here to shoot

Touch the photo or video on the screen to view or play it in full screen.

Touch here to open the Album program. (See “Viewing Photos and Videos Using Album” in Chapter 11 for details.)

Tips • For more information about viewing in full screen, see “View an image” and “Play

back video” in Chapter 11. The file formats that can be viewed on the Photos and

Videos tab are the same as the Album program.

• To transfer media files from a computer and view them on the Photos and Videos

tab, copy or synchronize them to a folder under \My Device (the device memory) or \Storage Card (if a microSD card is installed).

video.

To flip through photos and videos, swipe upward/downward on the screen or touch the Up/Down arrow.

Touch Slideshow to view the photos as a slideshow. If a video is selected, touch Play.

TouchFLO™ 3D 77

Music

The Music tab allows you to visually browse through albums and music tracks and play music. The albums and music tracks that you see on the Music tab are from the

Now Playing list of the Library.

Note Your device searches for all music files that have the following audio formats: AMR-

NB/WB (.awb), MP3 (.mp3), WMA (.wma), AAC/AAC+/eAAC+ (.aac), and MPEG-4 (.m4a). It searches for music from the following locations: Device: \My Music (including all subfolders) \My Documents (including all subfolders) Storage Card: \Storage Card (including all subfolders)

To play music

On the Music tab, flip through albums and all the music in each album, then touch the Play icon on the middle-right side of the screen to start playback.

Swipe upward/ downward on the screen to flip through albums and the music or songs in an album.

Touch here to access the Library.

Touch here to go to the previous album or the previous music in the current album.

Touch here to play or pause.

Touch here to go to the next album or the next music in the current album.

Touch Menu to set music playback to Repeat, turn Shuffle on or off, and more.

78 TouchFLO™ 3D

To advance forward or backward in the music

Touch and hold on the thin bar below the album art to display the progress bar:

Drag your finger right or left on the progress bar to move forward or backward in the current music.

To set repeat and shuffle modes

Touch Menu > Repeat and choose whether to repeat once, repeat all, or do not repeat. To toggle shuffle mode on and off, touch Menu > Shuffle and then select Shuffle On or Shuffle Off.

The icons on the upper-right side of the Music tab show whether repeat and shuffle modes are enabled.

Repeat [One] Repeat [All] Shuffle [On]

To browse and play music in the Library

The Library organizes music into categories, such as Now Playing, Artists, Albums, Genres, All Songs, and more. When you add more albums or music tracks to your

device, go to the Library to locate and play the new albums or music tracks.

On the Music tab, touch Library to open the Library screen.

The tabs at the bottom of the Library screen correspond to the different

categories. To browse music under a certain category, slide to the tab that corresponds to the desired category.

Tap a music track to play it.

Note When you select a category in the Library such as Artists and play its music, the Now

Playing list will be replaced with the music tracks from that category.

TouchFLO™ 3D 79

To use playlists

You can group your favorite music into a playlist and then play back the playlist.

To create a new playlist:

•

Select the desired music on the Music tab or the Library.

Touch Menu > Add to Playlist.

Touch <New Playlist>, enter a Playlist name and then touch OK.

To add more music files to a playlist:

•

On the Playlists tab, touch a playlist to open it.

Touch Menu > Edit.

Touch Menu > Add.

Select the check boxes of the music you want to add to the playlist, or

touch Menu > Select All to choose all the music.

Touch OK three times and then touch Up to return to the Playlists tab.

To play back a playlist:

•

On the Playlists tab, touch a playlist to open it.

Touch the first song in the playlist. The Music tab starts playing the first

song. After each song, the next one in the playlist will be played.

Note Playlists are not automatically updated when music files have been deleted from

the device memory or storage card.

There are two types of playlists that can be shown on the Playlists tab:

•

Custom playlists. Playlists that are created on the Music tab.

•

Windows Media® Player playlists. Playlists that are in Windows Media®

Player Mobile’s Library (which is synchronized with Windows Media® Player on your computer). They are indicated by the Windows Media® Player icon (

). These playlists cannot be edited.

80 TouchFLO™ 3D

Windows Media® Player playlists

Custom playlists

Note If a Windows Media® Player playlist contains a combination of music, video and image

files, only music files in the playlist will be synchronized to your device and other media types will be filtered out.

Weather

The Weather tab shows you the current weather as well as weather information for the next five days of the week.

To add a city

The Weather tab can display weather information of your local city and other added cities. Follow the steps below to add a city on this tab.

Tip You can add up to 10 cities on the Weather tab.

On the Weather tab, touch Menu > Add Location.

The Select Country screen then appears. Flick your finger on the screen or use

the Quick Scroll bar on the right of the screen to choose the country.

TouchFLO™ 3D 81

You can also slowly scroll through the country list by dragging your finger upward on the screen. Touch the desired country to select it.

The Select City screen then appears. Flick your finger on the screen or use

the Quick Scroll bar on the right of the screen to choose the city. You can also slowly scroll through the city list by dragging your finger upward on the screen. Touch the desired city to select it.

To view weather information

Your device automatically connects to the Internet via the EDGE/GPRS data connection, WiMAX, or Wi-Fi to download and display weather information. The current temperature, temperature range, type of weather (sunny, cloudy, showers, or others), time of day (daytime or nighttime), and the weather information for the next four days of the week are shown on the Weather tab.

Shows the last weather update.

To switch between cities, swipe your finger upward/downward, or touch the Up/Down arrow on the screen.

Touch Menu to add or Touch this item to download the latest weather information.

delete a city, change the

temperature to Celsius

or Fahrenheit, and more.

82 TouchFLO™ 3D

To choose download options

1. On the Weather tab, touch Menu > Settings.

Tip You can also slide to the Settings tab and then touch Data.

2. You can choose from the following options:

Download weather automatically. When this option is selected, weather

•

information is automatically downloaded from the AccuWeather web site whenever you select the Weather tab, if the data has not been updated within the last three hours. Weather data is also downloaded every time an ActiveSync connection is established (through over-the-air or USB connections).

Clear this option if you prefer to manually download weather information.

Download weather when roaming. Select this option only if you want to

•

allow automatic download of weather data when roaming. This may incur additional costs.

Settings

The Settings tab allows you to synchronize information with your computer or the Exchange Server, change sound settings such as the ring tone, and choose a different wallpaper for the Home tab. You can also easily turn on and off the communications features of your device such as WiMAX, Wi-Fi, Bluetooth, and more.

TouchFLO™ 3D 83

Programs

The Programs tab allows you to add your favorite programs for one-touch access.

Touch a program icon to open the corresponding program.

Touch an empty slot to add a favorite program.

Touch All Programs to access all the programs of your device.

Touch Remove to choose which program to remove from the Programs tab.

When you have filled up the screen with programs, scroll down the Programs tab to access more empty slots and add more programs. To scroll down, press and hold on the screen and then drag your finger upward. You can add up to 18 favorite programs.

To scroll back up, press and hold on the screen and then drag your finger downward.

Note To replace a slot with another program, you must delete the occupying program

shortcut first and then add your desired program.

84 TouchFLO™ 3D

3.3 Finger Gestures

You can use finger gestures to scroll, zoom and pan on the touch screen.

Finger scrolling

Finger scrolling can be used to scroll up and down web pages, documents, and lists such as the contacts list, file list, message list, calendar appointments list, and more.

When finger scrolling, swipe or flick your finger on the touch screen.

To scroll up and down

To scroll down, swipe your finger upward on the touch screen.

•

To scroll up, swipe your finger downward on the touch screen.

To auto-scroll, flick your finger upward or downward on the touch screen.

•

Touch the screen to stop scrolling.

TouchFLO™ 3D 85

To scroll left and right

To scroll towards the right, swipe your finger to the left.

•

To scroll towards the left, swipe your finger to the right.

To auto-scroll, flick your finger left or right. Touch the screen to stop scrolling.

•

Finger zooming

The type of finger gesture to use when zooming varies in different programs.

•

To zoom in on a web page in Opera Mobile, tap your finger twice on the screen. See “Using Opera Mobile” in Chapter 8 for details.

•

To zoom in on a photo in Album, make a full-circle swipe on the touch screen. See “Viewing Photos and Videos Using Album” in Chapter 11 for details.

Finger panning

You can use finger panning to move to and view other parts of a zoomed photo, web page, document, or an e-mail. To pan, touch and hold on the touch screen and then drag your finger in any direction.

Tip To enable or mute finger scrolling and panning

sound, touch Start > Settings > System tab >

TouchFLO, and then select or clear the Enable sound when finger scrolling and panning check

box.

86 TouchFLO™ 3D

Chapter 4

Entering Text

4.1 Entering Information

4.2 Using the Full QWERTY

4.3 Using the Compact QWERTY

4.4 Using the Phone Keypad

4.5 Using Multitap and T9 Modes

4.6 Using Numeric and Symbol Mode

4.7 Using Block Recognizer

4.8 Using Letter Recognizer

4.9 Using Transcriber

88 Entering Text

4.1 Entering Information

When you start a program or select a field that requires text or numbers, the Input Panel icon becomes available on the menu bar.

Tap the Input Selector arrow (that appears next to the Input Panel icon) to open a menu where you can select a text input method and customize input options. After selecting a text input method, the corresponding Input Panel is displayed, which you can use to enter text.

Tip Select Other Input Methods to display more input methods.

To show or hide the Input Panel, tap the Input Panel icon.

Key when pressed

Input Panel (Compact QWERTY)

Input Selector arrow

Text input methods

Input Panel icon

Entering Text 89

Icon Input method Icon Input method

Full QWERTY

Compact QWERTY Transcriber

Phone Keypad Keyboard

Letter Recognizer or Block Recognizer

Notes • Some text input methods may not be available in certain language versions of the

device.

• When in landscape mode, the Compact QWERTY and Phone Keypad are not available.

4.2 Using the Full QWERTY

The Full QWERTY is a full on-screen QWERTY keyboard layout similar to a desktop PC keyboard.

Tip You can also use the Windows Mobile on-screen keyboard which also has a QWERTY

keyboard layout by selecting Keyboard (or Other Input Methods > Keyboard) on the Text input method menu.

90 Entering Text

• Tap to enter letters or symbols.

• Tap and hold to enter a punctuation mark, symbol, or number that appears on top of a key.

• Tap to enter an uppercase letter.

• Tap twice to turn on Caps Lock.

Displays the word candidate list in T9 mode. Tap a word to insert it into your text. Tap to add a word to the T9 dictionary.

Tap to delete the previous character.

Tap to create a new line.

Tap to toggle between using Normal or T9 mode.

Tap to open a keyboard layout that lets you easily enter numbers and symbols. See “Using Numeric and Symbol Mode” for details.

To enter text using the Full QWERTY

1. Start a program that accepts text input, such as Word Mobile.

2. Tap the Input Selector arrow, then tap Full QWERTY.

3. Start tapping keys on the keyboard as you would on a PC keyboard to enter

your text. To learn how to enter text using T9 mode, see “Using Multitap and T9 Modes” in this chapter.

Entering Text 91

4.3 Using the Compact QWERTY

The Compact QWERTY is a type of on-screen keyboard which features 20 keys. With its large, touch-friendly keys and enhanced features such as T9 predictive input, you can enter text faster and more accurately.

• Tap to enter letters or symbols.

• Tap and hold to enter a punctuation mark, symbol, or number that appears on top of a key.

• Tap to enter an uppercase letter.

• Tap twice to turn on Caps Lock.

Displays the word candidate list in T9 mode. Tap a word to insert it into your text. Tap to add a word to the T9 dictionary.

Tap to delete the previous character.

Tap to create a new line.

Tap to toggle between using

Multitap or T9 mode.

Tip You can tap and hold to immediately open the numeric keyboard.

To enter text using the Compact QWERT Y

Tap to open a keyboard layout that lets you easily enter numbers and symbols. See “Using Numeric and Symbol Mode” for details.

1. Start a program that accepts text input, such as Word Mobile.

2. Tap the Input Selector arrow, then tap Compact QWERTY.

3. Start tapping keys on the keyboard to enter your text. To learn how to enter text

using Multitap or T9 mode, see “Using Multitap and T9 Modes” in this chapter.

92 Entering Text

4.4 Using the Phone Keypad

The Phone Keypad is a 12-key on-screen keypad that has a layout similar to mobile phone keypads, plus some additional keys. The Phone Keypad has large keys and enhanced input features such as T9 predictive input, which makes it faster for you to enter text in your messages and documents.

Displays the word candidate list in T9

• Tap to enter letters or symbols.

• Tap and hold to enter a punctuation mark, symbol, or number that appears on top of a key.

• Tap to enter an

uppercase letter.

• Tap twice to turn

on Caps Lock.

Tap to open a keyboard layout that lets you easily enter numbers and symbols. See “Using Numeric and Symbol Mode” for details.

Tip You can tap and hold to immediately open the numeric keyboard.

To enter text using the Phone Keypad

1. Start a program that accepts text input, such as Word Mobile.

2. Tap the Input Selector arrow, then tap Phone Keypad.

3. Start tapping keys on the keyboard to enter your text. To learn how to enter text

using Multitap or T9 mode, see “Using Multitap and T9 Modes” in this chapter.

mode. Tap a word to insert it into your text. Tap

to add a word

to the T9 dictionary.

Tap to toggle between using Multitap or T9 mode.

Tap to delete the previous character.

Tap to create a new line.

Entering Text 93

4.5 Using Multitap and T9 Modes

When using the on-screen keyboards, you can choose to enter text using Multitap or T9 mode.

Multitap mode

In Multitap mode (for Compact QWERTY and Phone Keypad), enter a character by tapping a key until the desired character is displayed on the screen.

• To enter the first letter that shows on a key, tap the key once. To enter the

second letter, tap twice.

• To enter a punctuation mark, symbol, or number that appears on top of a key,

tap and hold the key.

T9 mode

T9 is a predictive text input mode which displays a word candidate list as you enter

the first few characters so you just select the word that you want.

To enter text using T9 mode

1. Start entering the first few letters of a word. As you enter each letter,

predicted words will appear above the keyboard.

2. Tap the desired word to immediately insert it to your text.

Note Navigate through the word candidate list if there are more words to choose from.

94 Entering Text

To add a word to the T9 dictionary

If the word that you have entered is not found in the dictionary, you can add it to the dictionary.

1. While in T9 mode, type a letter and then tap

on right side of the word

candidate list.

2. Type the word you want to add and then tap ADD.

Tap to cancel word addition.

To customize Touch Input settings

1. Tap the Input Selector arrow, then tap Touch Input Settings.

2. On the Touch Input Settings screen, select or clear the following options

according to your preferences:

• Spell Correction. Lets you correct typographical errors by selecting from

a list of possible words that reflect the characters of the keys you have tapped as well as characters of nearby keys.

• Word Completion in T9 mode. Lets you select from a list of possible

words based on the keys that you have tapped and on the words available in the dictionary.

• Word Completion in ABC mode. Lets you select from a list of possible

combinations based on the characters that appear on the keys that you tapped.

• Auto-Substitution. Automatically inserts an apostrophe when you type

common contracted words (for example, “dont” automatically becomes “don’t”).

3. Tap Done.

Entering Text 95

4.6 Using Numeric and Symbol Mode

Switch to Numeric and Symbol mode to let you easily enter numbers and common symbols such as parentheses, braces, currency signs, punctuation marks, special characters, and more. Numeric and Symbol mode is available when using the Full QWERTY, Compact QWERTY, and Phone Keypad.

Tap a number or symbol to insert it into your text.

Tap to go to the previous or next page of symbols.

See “To lock the keyboard in Numeric and Symbol mode.”

Tap to switch to the

Compact QWERTY and Phone Keypad

To switch to Numeric and Symbol mode

1. While using Full QWERTY, Compact QWERTY, or Phone Keypad, tap

2. Locate the number or symbol, then tap it to insert it into your text.

To lock the keyboard in Numeric and Symbol mode

You can lock the keyboard in Numeric and Symbol mode so you can continuously enter symbols and numbers.

1. Tap the Input Selector arrow and then tap Other Input Methods > Options.

2. In the Input Method tab, select a Touch input method in the Input method

list, then tap Options.

3. Clear the Turn on one-touch symbol entry check box.

numeric keyboard

Tap to switch back to the letter keyboard layout.

Full QWERTY

/ .

96 Entering Text

Tip In Compact QWERTY and Phone Keypad, tap / to toggle between locking

the keyboard in Numeric and Symbol mode and switching back to the letter keyboard layout after tapping a symbol or number.

4.7 Using Block Recognizer

With Block Recognizer, you use a single stroke to write letters, numbers, symbols, and punctuation, which are then converted into typed text.

To use Block Recognizer

1. From a program, tap the Input Selector arrow and then tap Other Input

Methods > Block Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

• Enter letters by writing in the abc (left) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter symbols and punctuation by tapping the left or right area of the box

(a gray dot appears), then writing the desired character.

Tip For help with writing characters, tap the question mark near the writing area.

4.8 Using Letter Recognizer

With Letter Recognizer, you can write individual letters, numbers, and punctuation marks, which are then converted into typed text.

To use Letter Recognizer

1. From a program, tap the Input Selector arrow and then tap Other Input

Methods > Letter Recognizer.

2. Write characters, numbers, and symbols in the designated writing area.

• Enter uppercase letters by writing in the ABC (left) area of the box.

Entering Text 97

• Enter lowercase letters by writing in the abc (middle) area of the box.

• Enter numbers by writing in the 123 (right) area of the box.

• Enter punctuation and symbols by writing the desired character in the

123 (right) area of the box.

Tip For help with writing characters, tap the question mark near the writing area.

4.9 Using Transcriber

Transcriber is a handwriting recognition program that enables you to write in

cursive, print, or a combination of both.

To write using Transcriber

1. Open a program that accepts user input, such as Word Mobile.

2. Tap the Input Selector arrow and then tap Other Input Methods >

Transcriber. The Transcriber introductory screen appears. Read the introduction and tap OK.

3. Position the cursor where you want text to appear.

4. Use the stylus to write anywhere on the screen. The handwriting will be

converted to text shortly after you lift the stylus from the screen.

To enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to add punctuation or a special symbol to existing text. To use this on-screen keyboard, tap

on the Transcriber toolbar.

The keyboard remains visible until you tap the button again.

Tips • To reposition the keyboard, tap and hold the title bar, then drag to the desired

location.

• When no text is selected, you can open the keyboard by using the a line straight down and then straight up). For more information about using Transcriber gestures, see Help on your device.

gesture (draw

98 Entering Text

To edit text

1. In a program, draw a line from left to right across the text you want to edit.

2. After you lift the stylus from the screen, the line disappears and the selected

text will be highlighted.

3. Do either of the following:

• Rewrite the text.

• Use gestures to capitalize letters, insert a space, and so on. For information

about using Transcriber gestures, see Help on your device.

Chapter 5

Synchronizing Information

With Your Computer

5.1 About Synchronization

5.2 Setting Up Windows Mobile® Device Center

on Windows Vista®

5.3 Setting Up ActiveSync® on Windows XP®

5.4 Synchronizing With Your Computer

5.5 Synchronizing via Bluetooth

5.6 Synchronizing Music and Video

100 Synchronizing Information With Your Computer

5.1 About Synchronization

You can take information from your computer wherever you go by synchronizing them to your device. The following types of information can be synchronized between your computer and your device:

• Microsoft® Office Outlook® information, which include Office Outlook e-

mail, contacts, calendar, tasks, and notes

• Notes, which are created using Microsoft® Office OneNote® 2007

• Media, such as pictures, music, and video

• Favorites, which are the bookmarked links to your favorite web sites

• Files, such as documents and other files

Before you can synchronize, you need to install and set up first the synchronization software on your computer. For more information, see “Setting Up Windows Mobile Device Center on Windows Vista®” and “Setting Up ActiveSync® on Windows® XP” in this chapter.

Note ActiveSync or Windows Mobile Device Center only synchronises data on your

computer and device. If you have installed a storage card and you want to back up files from the storage card, use Windows Explorer on your computer to copy files from the storage card to your computer.

Ways to synchronize

After you have installed the synchronization software on your computer, connect and synchronize your device with your computer by:

• Using the supplied USB sync cable.

Upon connecting the sync cable to your device and your computer, the synchronization process automatically starts.

• Using Bluetooth.

You must first set up a Bluetooth partnership between your device and your computer before you can synchronize information between them using

HTC BKNV User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
