Ameo User Manual

!”T§==Mobile===

Please Read Before Proceeding

THE DEVICE IS NOT FULLY CHARGED WHEN YOU TAKE IT OUT OF THE

BOX

DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.

YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER CASING.

PRIVACY RESTRICTIONS

Some countries require full disclosure of recorded telephone conversations, and stipulate that you must inform the person with whom you are speaking that the conversation is being recorded. Always obey the relevant laws and regulations of your country when using the recording feature of your Pocket PC Phone. COPYRIGHT INFORMATION Copyright © 2006 High Tech Computer Corp. All Rights Reserved.

, , , ExtUSB and VueFLO are trademarks and/or

service marks of High Tech Computer Corp.

Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, ActiveSync, Excel, Internet Explorer, MSN, Hotmail, Outlook, PowerPoint, Word, and Windows Media are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.

Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.

miniSD is a trademark of SD Card Association.

Java, J2ME and all other Java-based marks are trademarks or registered trademarks of Sun Microsystems, Inc. in the United States and other countries.

Macromedia, Flash, Macromedia Flash, Macromedia Flash Lite and Reader are trademarks and/or registered trademarks of Macromedia Netherlands, B.V. or Adobe Systems Incorporated.

ArcSoft MMS Composer™ Copyright © 2003-2006, ArcSoft, Inc. and its licensors. All Rights Reserved. ArcSoft and the ArcSoft logo are registered trademarks of ArcSoft, Inc. in the United States and/or other countries.

Sprite Backup is a trademark or service mark of Sprite Software.

Licenced by QUALCOMM Incorporated under one or more of the following patents:

4,901,307 ; 5,490,165 ; 5,056,109 ; 5,504,773 ; 5,101,501 ; 5,778,338 ; 5,506,8655,109,390 ; 5,511,073 ; 5,228,054 ; 5,535,239 ; 5,710,784 ; 5,267,261 ; 5,544,196 5,267,262 ; 5,568,483 ; 5,337,338 ; 5,659,569 5,600,754 ; 5,414,796 ; 5,657,420 5,416,797

All other company, product and service names mentioned herein are trademarks, registered trademarks or service marks of their respective owners. HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages resulting from furnishing this material. The information is provided “as is” without warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content of this document at any time without prior notice. No part of this document may be reproduced or transmitted in any form or by any means, electronic or mechanical, including photocopying, recording or storing in a retrieval system, or translated into any language in any form without prior written permission of HTC.

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages. Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product. To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

ELECTRICAL SAFETY

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION

CAUTION:

electric shock to your device. This product equipped with a USB Cable for connecting with desk-top or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT

• Use the correct external power source

Connecting to an improperly grounded equipment can result in an

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorised service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

This product should be operated only with the following designated power

supply unit(s):

1. Delta, Model ADP-5FH X

2. Tamura, Model JHA050100Uabb

3. Phihong, Models PSAA05X-050 and PSC05R-050

Car

Adapter

1. Phihong, Model CLM10D-050

2. Hwa Ying, Model AP-03

• Handle battery packs carefully

This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures higher than 60˚C (140˚F).

WARNING: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. TO

REDUCE RISK OF FIRE OR BURNS, DO NOT DISASSEMBLE, CRUSH, PUNCTURE, SHORT EXTERNAL CONTACTS, EXPOSE TO TEMPERATURE ABOVE 60˚C (140˚F), OR DISPOSE OF IN FIRE OR WATER. REPLACE ONLY WITH SPECIFIED BATTERIES. RECYCLE OR DISPOSE OF USED BATTERIES ACCORDING TO THE LOCAL REGULATIONS OR REFERENCE GUIDE SUPPLIED WITH YOUR PRODUCT.

NOTE: This product should be operated only with the following designated Battery Pack(s).

1. HTC, Model ATHE160

2. SANYO, Model ATHE160

SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window

sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

PREVENTION OF HEARING LOSS

CAUTION: Permanent hearing loss may occur if earphones or

headphones are used and prolonged listening at high volume.

NOTE: For France, mobile headphones, earphones, and wired remote controller (listed

below) for this device have been tested to comply with the Sound Pressure Level requirement laid down in NF EN 50332-1:2000 and/or NF EN 50332-2:2000 standards as required by French Article L. 5232-1.

1. Earphone, manufactured by HTC or Cotron, Models CHM-60STV07004, CH60ST006 and CH-60ST007.

Wired Remote Controller, manufactured by HTC, Model RC W100.

SAFETY IN AIRCRAFTS

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on board an aircraft, remember to turn off the phone by switching to Flight Mode.

ENVIRONMENT RESTRICTIONS

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

EXPLOSIVE ATMOSPHERES

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or

fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

ROAD SAFETY

Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the case of emergency. In some countries, using hands-free devices as an alternative is allowed.

SAFETY PRECAUTIONS FOR RF EXPOSURE

•• Avoid using your device near metal structures (for example, the steel frame of

a building).

•• Avoid using your device near strong electromagnetic sources, such as

microwave ovens, sound speakers, TV and radio.

• Use only original manufacturer-approved accessories, or accessories that do

not contain any metal.

•• Use of non-original manufacturer-approved accessories may violate your

local RF exposure guidelines and should be avoided.

INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS

This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics. If you use any other personal medical device, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information.

Turn the phone OFF in health care facilities when any regulations posted in these areas instruct you to do so. Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.

HEARING AIDS

Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may want to consult your service provider, or call the customer service line to discuss alternatives.

NONIONIZING RADIATION

This product should be operated in the suggested normal condition only to ensure the radiative performance and safety of the interference. As with other mobile radio transmitting equipment, users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is recommended that no part of the human body be allowed to come too close to the antenna during operation of the equipment.

General Precautions

• Heed service markings

Except as explained elsewhere in the Operating or Service documentation, do not service any product yourself. Service needed on components inside the device should be done by an authorised service technician or provider.

• Damage requiring service

Unplug the product from the electrical outlet and refer servicing to an authorised service technician or provider under the following conditions:

• Liquid has been spilled or an object has fallen into the product.

• The product has been exposed to rain or water.

• The product has been dropped or damaged.

• There are noticeable signs of overheating.

• The product does not operate normally when you follow the operating

instructions.

• Avoid hot areas

The product should be placed away from heat sources such as radiators, heat registers, stoves, or other products (including but not limited to amplifiers) that produce heat.

• Avoid wet areas

Never use the product in a wet location.

• Avoid using your device after a dramatic change in temperature

When you move your device between environments with very different temperature and/or humidity ranges, condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the moisture to evaporate before using the device.

NOTE: When taking the device from low-temperature conditions into a warmer

environment or from high-temperature conditions into a cooler environment, allow the device to acclimate to room temperature before turning on the power.

• Avoid pushing objects into product

Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are provided for ventilation. These openings must not be blocked or covered.

• Mounting Accessories

Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the manufacturer.

• Avoid unstable mounting

Do not place the product with an unstable base.

• Use product with approved equipment

This product should be used only with personal computers and options identified as suitable for use with your equipment.

• Adjust the volume

Turn down the volume before using headphones or other audio devices.

• Cleaning

Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning, but NEVER use water to clean the LCD screen.

• For magnetic devices

Please avoid putting any media that contains magnets, e.g. magnetic card, credit cards, bank cards, audio/video tape or magnetic memory devices, directly on the device or keyboard without any distance.

It is highly recommended to put the media containing magnets in a security distance of at least 5 cm. If you carry your wallet or billfold which contains magnetic cards next to the device or its keyboard, information stored on these cards could be destroyed.

Please make sure that there is an adequate distance from the device or its keyboard other magnetic sensitive devices, e.g., a mechanical watch or measure instruments

• For pacemakers

The functionality of pacemakers can be interfered by the device and its keyboard. Always keep the device and its keyboard in a fair distance to your pacemaker, which at least will be 5 cm. In any case, please do not carry the device and/or its keyboard in the front pockets of your shirt or coat.

For information about other medical active implants, please contact the producer or a doctor to ensure such active implants will not be interfered by magnetic field.

Contents

Chapter 1 Getting Started 17

1.1 Getting to Know Your Ameo and Its Accessories ................ 18

1.2 About the

1.3 Starting Up .......................................................................

1.4 The

1.5 The Subdisplay ................................................................. 33

1.6 Using the Programs .......................................................... 33

1.7 Device Settings ................................................................. 37

Chapter 2 Entering and Searching for Information 41

2.1 Using the Hardware Keyboard ........................................... 42

2.2 Entering Information .........................................................44

2.3 Using

2.4 Using

2.5 Using

2.6 Using

2.7 Using

2.8 Using

2.9 Searching for Information ................................................. 49

USIM/SIM Card and Battery .............................. 24

Today Screen ............................................................. 28

the On-screen Keyboard .......................................... 45

Letter Recognizer ................................................... 45

Block Recognizer .................................................... 46

Transcriber .............................................................46

Symbol Pad ............................................................. 48

Notes to Draw, Write, and Record Voice Notes ......... 49

Chapter 3 Using Phone Features 51

3.1 Using the Phone ............................................................... 52

3.2 Making a Call .................................................................... 54

3.3 Receiving a Call ................................................................ 56

3.4 Making a Video Call ..........................................................

3.5 Receiving a Video Call ......................................................

3.6 Smart Dialing ....................................................................

3.7 In-call Options ..................................................................

3.8 Additional Dialing Information ...........................................

3.9 Setting Up Bluetooth SIM Access for Car Kit Phones .......... 67

Chapter 4 Synchronising Information and Setting Up Email Security 69

4.1 Setting Up ActiveSync ....................................................... 70

4.2 Synchronising Information ................................................74

4.3 Synchronising via Bluetooth .............................................. 79

4.4 Synchronising Music, Video, and Pictures ......................... 80

4.5 Setting Up E-mail Security ................................................. 82

Chapter 5 Managing Your Ameo 85

5.1 Personalising Your Ameo .................................................. 86

5.2 Adding and Removing Programs .......................................

5.3 Managing Memory ............................................................

5.4 Copying

5.5 Backing Up Data ............................................................. 100

5.6 Protecting Your Ameo .....................................................

5.7 Using Anti-Virus to Scan Viruses ......................................

5.8 Resetting Your

Files .................................................................... 99

Ameo ......................................................108

104

106

Chapter 6 Getting Connected 111

6.1 Connecting to the Internet ............................................... 112

6.2 Using

6.3 Internet Explorer Mobile .................................................. 116

6.4 Using

6.5 Using Bluetooth ..............................................................

6.6 Using Wi-Fi .....................................................................

6.7 Using

6.8 Using Spb GPRS Monitor ................................................ 134

6.9 Using

VueFLO ................................................................. 115

Comm Manager .................................................... 119

120

129

Internet Sharing .................................................... 133

Terminal Services Client ........................................ 139

Chapter 7 Exchanging Messages and Using Outlook 141

7.1 E-mail and Text Messages ............................................... 142

7.2 Picture Messages ........................................................... 152

7.3 Calendar ........................................................................ 158

7.4 Contacts ......................................................................... 160

7.5 Tasks ............................................................................. 165

7.6 Notes .............................................................................. 167

7.7 Voice Recorder ............................................................... 170

Chapter 8 Using GPS 173

8.1 Guidelines and Preparation for Using GPS ...................... 174

8.2 Downloading Satellite Data

8.3 Using

8.4 GPS Controls ..................................................................

GPS Software ........................................................ 178

via QuickGPS ....................... 176

178

Chapter 9 Experiencing Multimedia 179

9.1 Using Camera ................................................................. 180

9.2 Using Pictures & Videos .................................................. 195

9.3 Using Windows Media Player Mobile ............................... 200

9.4 Using Streaming Media ................................................... 207

Chapter 10 Using Other Applications 209

10.1 Word Mobile ................................................................... 210

10.2 Excel Mobile ................................................................... 211

10.3 Viewing Slide Shows with PowerPoint Mobile .................. 212

10.4 Using Adobe Reader LE .................................................. 213

10.5 Using MIDlet Manager .................................................... 216

10.6 Using ZIP ........................................................................ 220

10.7 Using Voice Speed Dial ...................................................221

10.8 Using

JETCET Print ......................................................... 223

Appendix 225

A.1 Regulatory Notices ......................................................... 226

A.2 PC Requirement to Run ActiveSync 4.2 ........................... 231

A.3 Specifications .................................................................

232

Index 237

Chapter 1

Getting Started

1.1 Getting to Know Your Ameo and Its Accessories

1.2 About the USIM/SIM Card and Battery

1.3 Starting Up

1.4 The Today Screen

1.5 The Subdisplay

1.6 Using the Programs

1.7 Device Settings

!”T§==Mobile===

Getting St arted

1.1 Getting to Know Your Ameo and Its

Accessories

Getting St arted

No. Item Function

1 Navigation Control/CENTRE

OK button

Press this multi-directional control up, down, left, or right to move through menus and program instructions; carry out the selection by pressing the CENTRE OK button.

2 Notification LED 1 This LED shows battery charging status.

3 Touch Screen Tap the screen with the stylus to write, draw, or

make a selection.

4 Notification LED 2 This LED shows the GSM/UMTS standby/

network status (Green). and GPS indicator (amber)

5 Notification LED 3 This LED shows the following:



A blinking Blue light for Bluetooth system notification of powered-up and ready to transmit radio frequency signal.



A blinking Green light for Wi-Fi status.



When both Bluetooth and Wi-Fi are enabled, their lights blink alternately.

6 Notification LED 4 This LED shows messages and notifications.

7 Second Camera lens Use for video call conversations or to take self

photos.

8 OK Button Press to confirm your data entries, or to exit the

program in use.

9 START Button Press to open the Start menu.

10 OPERA BROWSER/VueFLO

Button

Press to launch the Opera Browser. Depending on the Web browser selected in VueFLO settings, press this button to activate VueFLO when browsing the Web.

11 Battery Compartment Open this compartment to insert the SIM/USIM

card, miniSD card and battery.

12 Keyboard Connector Attach the copper part of the keyboard to this

to be able to use the keyboard. See "Using the Hardware Keyboard" in chapter 2 to learn how to attach the keyboard to the main unit.

Getting St arted

No. Item Function

14 Stylus Use the stylus to write, draw, or select items on the

touch screen.

15 CAMERA Button Press to launch the Camera; press again to take

a photo or video clip, depending on the specified capture mode. When shooting still images, press halfway to activate autofocus. once autofocus is activated, press all the way to take the shot.

16 Speaker Listen to audio files and voice calls.

17 COMM MANAGER/VOICE

RECORDER button

Press to open Comm Manager. Comm Manager lets you easily turn on/off your Ameo’s connections (such as Bluetooth and Wi-Fi), ringer, phone, etc. Press and hold to open the Voice Notes program.

18 POWER Button



Press to turn off the display temporarily. This switches your Ameo to Sleep mode. You can still receive calls and messages when your Ameo is in Sleep mode.



Press and hold (for about 5 seconds) to turn off the power completely. All functions including the phone will be unavailable for use.

19 Volume Slider



Slide up or down to adjust the speaker volume.



During a call, slide up or down to adjust the earpiece volume.

20 VGA Out/USB host Use this connection to output the contents on the

screen to an external device using the provided VGA out cable. This also acts as a USB 1.1 host to connect USB peripherals.

21 HTC ExtUSB™ port Use this connector to synchronise data by connecting

the provided USB Sync cable or to recharge the battery via the provided AC adapter. You can also connect the provided USB stereo headset for handsfree conversation or for listening to audio media.

22 3.5 mm Earphone Jack Lets you listen to audio media, use a hand-free kit or

plug in a microphone.

Getting St arted

No. Item Function

23 Car Antenna Connector Connect your Ameo to the car antenna while in a car

to have better reception quality.

24 RESET Button With the stylus, press the RESET button to soft-reset

your Ameo.

25 Camera lens Use to take still photos and record video clips.

26 Flash Light When turned on, it illuminates your subject and

allows you to capture clear photos or video even in a dark environment. It also flashes when a photo is taken.

27 GPS Antenna Connector If you need better GPS signal reception, you can

connect an external GPS antenna.

No. Item Function

QWERTY keyboard This is similar to a standard PC keyboard. Connect to

the device to use the keyboard (Please see chapter 2). This also acts as a protective cover for the Ameo screen.

Accessories

Getting St arted

No. Accessory Function

1 AC adapter Recharges the battery.

2 USB Sync cable Connects your Ameo to a PC and synchronises data.

3 Stereo headset Provides a volume control slider and a Send/End

button. Press the Send/End button to pick up a call or put a call on hold; press and hold the button to end the call.

4 VGA Out cable Connects your Ameo to an external viewing device’s

input cable. You can output the contents on the Ameo's screen to an external viewing device.

5 Carrying Case Acts as a protective carrying case for your Ameo.

6 Combo Stylus This Stylus doubles as a writing pen. Simply click the

top of the stylus to switch between the two functions.

7 Extra Stylus Use to tap items onscreen..

Getting St arted

1.2 About the USIM/SIM Card and Battery

Always turn off your Ameo before installing/replacing the battery and USIM/SIM card. Follow the instructions in the Quick Start Guide to install a 3G USIM (Universal Subscriber Identity Module) or a SIM (Subscriber Identity Module) card provided by your local network service provider and to install the battery. The USIM/SIM card contains your phone number, service details, and phonebook/message memory. Your Ameo supports both 1.8V and 3V USIM/SIM cards. Some legacy SIM cards will not function with your Ameo. You should consult with your service provider for a replacement SIM card. There may be fees for this service. Your Ameo contains a rechargeable Li-ion battery. The Ameo is designed to use only manufacturer-specified original batteries and accessories. Battery performance depends on many factors, including T-Mobile’s network configuration, signal strength, the temperature of the environment in which you operate your Ameo, the features and/or settings you select and use, items attached to connecting ports, and your voice, data, and other program usage patterns. Battery life estimates (approximations):



Standby time: Up to 300 hours for GSM Up to 300 hours for UMTS



Talk time (Screen off): Up to 5.5 hours for GSM Up to 4.5 hours for UMTS

Warning! To reduce risk of fire or burns:



Do not attempt to open, disassemble, or service the battery pack.



Do not crush, puncture, short external contacts, or dispose of in fire or water.



Do not expose to temperatures above 60oC (140oF).



Replace only with the battery pack designated for this product.



Recycle or dispose of used battery as stipulated by local regulation.

To check the battery power

Do one of the following:



Tap the battery level icon ( ) on the Today screen.



Alternatively, tap Start > Settings > Systems tab > Power.

Getting St arted

Battery powe r information

Charge the battery

The battery in the box is shipped partially charged. Before you start using your Ameo, it is recommended that you install and charge the battery. Some batteries perform best after several full charge/discharge cycles. You can charge the battery in two ways:



Charging the Ameo’s battery by using the power adapter.



Connecting your Ameo to a PC via the provided USB Sync cable.

Warning!  Do not remove the battery from the Ameo while you are charging it using the AC



or car adapter.

As a safety precaution, the battery stops charging when it overheats. Your Ameo will use the power from the AC or car adapter to function.

Low battery

When the low-battery warning appears, do the following:



Immediately save your current data.



Connect the power adapter to charge the battery.



Turn off your Ameo.

Getting St arted

1.3 Starting Up

Turn your Ameo on and off

To turn on your Ameo, press and hold the POWER button. When you turn on your Ameo for the first time, a Quick Start Wizard will guide you through the calibration process and the setup of regional settings, date and time, password, Outlook e-mail, and POP3/IMAP4 e-mail accounts. For more information about touch screen calibration, see “Calibrate your Ameo”. For information about setting up Outlook e-mail and POP3/IMAP4 e-mail accounts, see Chapter 7. To turn off your Ameo, press and hold the POWER button for a few seconds. A message will then be displayed, prompting you whether or not to turn off the Ameo completely.

Switching your Ameo to Sleep mode

Quickly pressing the POWER button turns off the display temporarily and switches your Ameo to Sleep mode. Sleep mode suspends your Ameo to a low power state while the display is off in order to save battery power. Your Ameo also automatically goes into Sleep mode when you leave the Ameo idle after a certain amount of time. When the keyboard is attached to the LCD screen, pressing the POWER button toggles between turning on and off the subdisplay screen.

To specify the timeout period before your Ameo goes into Sleep mode

1. Tap Start > Settings > System tab > Power > Advanced tab.

2. Under

3. Select the battery timeout period, then tap

You will still be able to receive messages and calls while your Ameo is in Sleep mode. Pressing the POWER button again or new incoming calls/messages will wake up your Ameo.

On battery power, make sure the Turn off device if not used for

check box is selected.

OK.

Getting St arted

Calibrate the Ameo

Calibrating the Ameo screen involves tapping the centre of a cross with the stylus as the cross moves around the screen. This process ensures that when you tap the screen with your stylus, the tapped item is activated. If your Ameo does not accurately respond to screen taps, follow these steps to re-calibrate it:

1. Tap Start > Settings > System tab > Screen.

2. On the

General tab, tap Align Screen, then follow the on-screen instructions

to complete the calibration.

Manage screen settings

The Ameo’s display has two orientation modes: Landscape and Portrait. Portrait mode allows you to get a better view or a better operation of certain programs, while Landscape mode may be optimal for viewing lengthy files.



To change the orientation, tap on the Today screen. Alternatively, you can tap Start > Settings > System tab > Screen, and select the orientation you want.



To smooth the edges of screen fonts for many programs, on the ClearType tab, select the Enable ClearType check box.



To increase the readability or to see more content on the screen, on the Text Size tab, adjust the text size by moving the slider.

Getting St arted

1.4 The Today Screen

The Today screen displays important information, such as upcoming appointments and status indicators. You can tap a section on the screen to open the associated program.



To access the Today screen, tap Start > Today.



To customise the Today screen display, including the background image, tap

Start > Settings > Personal tab > Today.

6 7

2 5124

1 Tap to open the Start menu.

2 Tap to view connectivity status.

3 Indicates the radio signal strength. Tap to configure the phone settings.

4 Tap to adjust device/ringer volume.

5 Displays the current time. Tap to check the current date and upcoming appointments.

Tap and hold to change the clock mode to Analog or Digital.

6 Displays the current date and time. Tap to set up date, time, alarm, and more.

7 Tap to set owner information.

Tap

to lock the Ameo. The icon changes to

Tap Unlock on the Today screen to unlock again.

Getting St arted

9 Your day at a glance with reminders. Tap to open the related program: messages,

tasks, and appointments.

10 This Quick Launch Panel provides shortcut icons to frequently-used programs.

11 Tap to open Contacts.

12 Tap to open Calendar.

Indicators

The following are some of the status icons that you may see on the Ameo.

Icon Description

New e-mail or text messages; SMS notification of voice mail

New Picture Message (MMS)

There are more notifications. Tap the icon to view all.

Speakerphone on

Dialing while no USIM/SIM card is inserted

Voice call in progress

Calls are forwarded

Call on hold

Missed call

Maximum signal strength

No signal

Phone is turned off

No phone service

Searching for phone service

Getting St arted

Icon Description

3G UMTS network available

UMTS connecting

UMTS in use

GPRS available

GPRS connecting

GPRS in use

EDGE available

EDGE connecting

EDGE in use

Roaming

Connection is active

Connection is not active

Synchronisation in progress

Synchronisation error

ActiveSync notification

Wi-Fi function enabled, but device not connected to a wireless network yet

Wireless network(s) detected

Connecting to wireless network (arrows moving); Connected to wireless network

Icon Description

Synchronising via Wi-Fi

Sound on

Sound off

Alarm

No USIM/SIM card inserted

VueFLO activated

Battery is fully charged

Battery power is very low

Battery charging

Bluetooth headset detected

QuickGPS update notification

Anti-Virus update notification

GPRS Monitor currently active

Sprite Backup notification

Serial USB connection active

Getting St arted

Note The USB to PC ( ) icon appears on the Today Screen when your Ameo is

connected to your computer and you enable a serial USB connection between them. For more information about USB to PC, see “Device Settings” later in this chapter.

Getting St arted

The Start menu

The Start menu, located at the top left corner of the Today screen, displays a list of programs. You can start a program by scrolling through the programs list and then pressing the CENTRE OK button, or by tapping a program with the stylus.

4 5

Tap to start a recently-used program.

Tap to switch to the Today screen.

Tap to start a program. The items displayed in the Start menu can be customised by

tapping Start > Settings > Personal tab > Menus.

Tap to view and select more programs that are installed on your Ameo.

Tap to change Ameo settings.

Getting St arted

1.5 The Subdisplay

The Subdisplay lets you view notifications, music info, weather, temperature and time on a designated area on the LCD screen when the keyboard is attached to the LCD screen of the main unit. The Subdisplay is automatically activated when the keyboard is pressed against the LCD screen.

Note Weather, world time and temperature information are only available if the

WorldMate® software is installed.

For more information regarding the Subdisplay, please refer to the Quick Start Guide.

1.6 Using the Programs

The following are some of the programs that are already installed on your Ameo.

Icon Description

ActiveSync Synchronises information between your Ameo and a PC or the Exchange Server.

Adobe Reader LE Allows you to view PDF files.

Anti-Virus Can be installed to your Ameo from the CD. Allows you to scan

your Ameo for possible virus infections and remove them.

Bluetooth Explorer Searches for other Bluetooth devices that have file sharing enabled and allows you to access their Bluetooth shared folder.

Calculator Lets you perform basic arithmetic and calculations, such as addition, subtraction, multiplication, and division.

Calendar Allows you to keep track of your appointments and create meeting requests.

Call register Allows you to keep track of your appointments and create meeting requests.

Getting St arted

Icon Description

Camera Snaps photos or shoots video clips with accompanying audio.

Comm Manager Allows you to manage the Ameo’s connection (including

Wi-Fi, Bluetooth, and ActiveSync), disconnect data services (such as GPRS), turn the phone on or off, and enable or disable the Direct Push function.

Contacts Allows you to keep track of your friends and colleagues.

Email Setup Allows you to select your email provider from a list and

simplifies the procedure to set up email accounts.

Excel Mobile Creates new workbooks or lets you view and edit Excel workbooks.

File Explorer Enables you to organise and manage files on your Ameo.

Games Lets you play two pre-installed games: Bubble Breaker and Solitaire.

Help Enables you to see Help topics for a program on your Ameo.

Internet Sharing Allows you to connect your notebook computer to the

Internet using your Ameo's data connection.

Internet Explorer Mobile Allows you to browse Web and WAP sites as well as download new programs and files from the Internet.

JETCET Print Allows you to print documents, image files, emails, Web pages and more from your Ameo.

Messaging Allows you to send and receive e-mail, Picture Messages, and text messages.

MIDlet Manager Enables you to download and install Java applications, such as games and tools, on your Ameo.

Notes Allows you to create handwritten or typed notes, drawings, and recordings.

Icon Description

Phone Lets you make and receive calls, switch between calls, and set up conference calling.

Pictures & Videos Lets you view, organise, and sort picture and video files on your Ameo or a storage card. Captured photos are stored in the My Pictures folder, and video clips are saved in the My Videos folder of your Ameo.

PowerPoint Mobile Lets you view PowerPoint slides and presentations.

QuickGPS Downloads satellite data over the Internet via ActiveSync, Wi-Fi

or GPRS to speed up the time for determining your current GPS position.

SAPSettings Enables Bluetooth Remote SIM access on your Ameo. This allows you to use a car kit phone that supports the SIM Access Profile (SAP) to access the SIM card on your Ameo via Bluetooth and make or receive phone calls. You can also download SIM contacts from your Ameo onto the car kit phone.

Spb GPRS Monitor Can be installed to your Ameo from the Applications CD. It measures the amount of data transfers that you have made via the GPRS or GSM network connection, and calculates network usage costs.

Search Enables you to search contacts, data, and other information on your Ameo.

SIM Manager Allows you to manage the contacts that are stored on your SIM card. You can also use this program to copy SIM contents to Contacts on your Ameo.

Sprite Backup Provides you with a quick and easy way to make backups of your data.

STK (SIM Tool Kit) Service Allows you to access information and other services offered by T-Mobile.

Streaming Media Allows you to stream live or on-demand video.

Getting St arted

Tasks Allows you to keep track of your tasks.

Getting St arted

Icon Description

Terminal Services Client Allows you to log on a PC running Terminal Services or Remote Desktop, and use all of the programs available on that PC from your Ameo.

Voice Recorder Allows you to record a voice clip and quickly send it through Picture Message or e-mail, beam it or set it as a ringtone.

Voice Speed Dial Allows you to record voice tags so that you can dial a phone number or launch programs simply by speaking a word.

Windows Media Player Mobile Lets you play back video and audio files.

Word Mobile Lets you create, view, and edit Word documents.

ZIP Enables you to save memory and free up storage space on your Ameo

by compressing files in the conventional ZIP format.

Getting St arted

1.7 Device Settings

You can adjust the Ameo settings to suit the way you work. To see all available settings, tap Start > Settings, then tap the Personal, System, and Connections tabs located at the bottom of the screen.

Personal tab

Icon Description

Buttons Assigns a program or function to a hardware button.

Input Sets options for each of the input methods.

Lock Sets a password for your Ameo.

Menus Sets what programs will appear in the Start menu.

Owner Information Allows you to enter your personal information on your

Ameo.

Phone Allows you to customise phone settings such as ring tone, set a PIN number for your SIM card, and more.

Soft Key Allows you to associate programs with the left and right Soft Keys.

Sounds & Notifications Enables sounds for events, notifications, and more,

and allows you to set the type of notification for different events.

Today Allows you to customise the appearance and the information to be displayed on the Today screen.

Voice Speed Dial Allows you to create voice tags for voice dialing contacts and SIM contacts as well as for launching programs.

Getting St arted

System tab

Icon Description

About Allows you to specify a name for your Ameo. Also shows the Windows Mobile version and copyright information.

Backlight Sets the backlight timeout and brightness.

Certificates Shows information about certificates that are installed on your

Ameo.

Clear Storage Removes all your data and files from the memory and/or the Microdrive, then resets your Ameo to factory default settings.

Clock & Alarms Switches the Ameo clock to the date and time of your locale or to a visiting time zone when you're traveling. Alarms can also be set at specified days and times of a week.

Device Information Shows information about the firmware version, hardware, identity, and the duration of calls made on your Ameo.

Error Reporting Enables or disables the Ameo's error reporting function. When this function is enabled and a program error occurs, technical data about the state of the program and your computer will be logged in a text file and delivered to Microsoft's technical support if you choose to send it.

Format Microdrive Lets you erase all data and quickly format the Microdrive in your Ameo.

GPS Configures GPS connection settings.

Instant Email Instant Email lets you access your email acounnts using your

Ameo. You can install Instant Email from the provided miniSD card in your Ameo box. To use this service, you must be subscribed to the Instant Email service from T-Mobile.

Key Lock Locks the buttons on your Ameo except for the POWER button when your Ameo is in Sleep mode. This ensures you will not switch the Ameo on by accident and consume unnecessary power.

Icon Description

Memory Shows the Ameo memory allocation status and memory card information. Also allows you to stop currently running programs.

Microphone AGC Adjusts the volume of your voice automatically when you are recording.

Power Shows the current battery level. Also allows you to set the timeout for turning off the display (switching device to Sleep mode) to conserve battery power.

Regional Settings Sets the regional format for displaying numbers, currency, date, and time on your Ameo.

Remove Programs Lets you remove programs that you installed on your Ameo.

Screen Allows you to change the screen orientation, re-calibrate the screen, and change the screen text size.

TV Out Allows you to output the contents you are viewing on the Ameo screen to an external display device.

VueFLO Opens the VueFLO settings where you can adjust the sensitivity level of VueFLO and choose the Web browser where VueFLO can be enabled. VueFLO lets you scroll through Web pages by simply tilting your Ameo. In VueFLO, tap Tutorial to learn how to use VueFLO.

X-Button Enables the “X” button to end running programs.

Getting St arted

Connections tab

Icon Description

Beam Enables your Ameo to receive incoming Bluetooth beams.

Bluetooth Turns Bluetooth on, sets your Ameo to visible mode, and allows

you to scan for other Bluetooth devices.

Connections Sets up one or more types of modem connections for your Ameo, such as phone dial-up, GPRS, Bluetooth, and more, so that your Ameo can connect to the Internet or a private local network.

CSD Line Type Sets the line type to use when making a circuit switch data (CSD) connection. Normally, you do not need to change the setting unless you encounter a problem establishing a connection.

GPRS Setting Sets the GPRS authentication method. Consult T-Mobile first before changing this setting.

SMS Service Enables sending of SMS text messages via a data connection, such as GPRS or a circuit-switched connection.

USB to PC Sets the USB connection between your Ameo and PC. You can set it to ActiveSync to help with problems connecting ActiveSync.

Wi-Fi Allows your Ameo to scan for available wireless networks.

Wireless LAN Shows information about the active wireless network, and

allows you to customise Wi-Fi settings.

Chapter 2

Entering and Searching for Information

2.1 Using the Hardware Keyboard

2.2 Entering Information

2.3 Using the On-screen Keyboard

2.4 Using Letter Recognizer

2.5 Using Block Recognizer

2.6 Using Transcriber

2.7 Using Symbol Pad

2.8 Using Notes to Draw, Write, and Record Voice Notes

2.9 Searching for Information

!”T§==Mobile===

Entering a nd Searching for Information

2.1 Using the Hardware Keyboard

Your Ameo provides you with a QWERTY keyboard, which is similar to a standard keyboard on your PC. To use the QWERTY keyboard, attach the main unit to the keyboard (as shown in the image). The main unit securely attaches itself to the keyboard through a magnet. To separate the main unit from the keyboard, simply pull them apart.

Note When separating the keyboard from the main unit, please do so in a gentle way.

Warning! Please avoid placing credit cards, diskettes, audio or video cassettes or any other

form of magnetic data carriers near the device or the keyboard as this could otherwise lead to loss of data stored on such objects. Other magnetic sensitive devices like a mechanical wristwatch should also not be placed near the device or keyboard.

Entering a nd Searching for Information

You can do the following with the QWERTY keyboard:



To type lowercase letters, press the keys using your thumbs or fingers.



To use all uppercase letters, press first, then press . To change back to all lowercase letters, press these buttons again.



To use a single uppercase letter, press and then press the corresponding key.



To enter a number or symbol (labeled in blue colour), press and then press the corresponding key.



To open the Symbol Pad, press and then press .



Press the Left/Right SOFT KEY / to perform the command shown in the label above the key.



Press to verify your data entries or exit the program in use.



Press to open the Start menu.



Press the arrow keys / / / for directional movement.



To type accented characters (like á, ã, ç, ê, í, ó,

and then, hold

and at the same time press the space bar

ü, etc), press the letter key first

several times until you find the correct character you need.



Press to open the Messaging program.



Press to answer a call, make a call or send a message. Press and hold to toggle between enabling and disabling the speakerphone.



Press to end a call or cancel a message.



Press to turn the screen back on if the device is set to sleep mode.



Press to open the Opera Browser.

Entering a nd Searching for Information

2.2 Entering Information

When you start a program or select a field that requires text or numbers, the Input Panel icon becomes available on the menu bar. Tap the Input Selector arrow (that appears next to the Input Panel icon) to open a menu where you can select a text input method and customise input options. After selecting a text input method, the corresponding Input Panel is then displayed and you can use it to enter text. To toggle between showing and hiding the Input Panel, simply tap the Input Panel icon.

Icon Input method

On-screen keyboard

Letter Recognizer or Block Recognizer

Symbol Pad

Transcriber

Input Panel (Keyboard)

Input Select or arrow

Input Panel icon

Note Some text input methods may not be available in certain language versions of the

device.

Entering a nd Searching for Information

2.3 Using the On-screen Keyboard

The on-screen Keyboard is available when text entry is possible. You can enter text by tapping keys on the keyboard that are displayed on the screen.

To enter text using the on-screen Keyboard

1. In a program, tap the

2. Enter text by tapping keys on the on-screen Keyboard.

Input Selector arrow, and tap Keyboard.

To enlarge the on-screen Keyboard

1. Tap the

Input Selector arrow, then tap Options.

2. In the Input method list, select Keyboard.

3. Tap Large keys.

2.4 Using Letter Recognizer

With Letter Recognizer, you can write individual letters, numbers, and punctuation, which are then converted into typed text.

To use Letter Recognizer

1. From a program, tap the

2. Write characters, numbers, and symbols in the designated writing area.



Enter capital letters by writing in the ABC (left) area of the box.



Enter lower case letters by writing in the abc (middle) area of the box.



Enter numbers by writing in the 123 (right) area of the box.



Enter punctuation and symbols by tapping in either area of the box and then writing the desired character.

Note Letter Recognizer is available when text entry is possible.

Tip For help with writing characters, tap the question mark near the writing area.

Input Selector arrow, and tap Letter Recognizer.

Entering a nd Searching for Information

2.5 Using Block Recognizer

With Block Recognizer, you use a single stroke to write letters, numbers, symbols, and punctuation, which are then converted into typed text.

To use Block Recognizer

1. From a program, tap the

2. Write characters, numbers, and symbols in the designated writing area.



Enter letters by writing in the abc (left) area of the box.



Enter numbers by writing in the 123 (right) area of the box.



Enter symbols and punctuation by tapping in either area of the box and then writing the desired character.

Note Block Recognizer is available when text entry is possible.

Tip For help with writing characters with Block Recognizer, tap the question mark near

the writing area.

2.6 Using Transcriber

Transcriber is a handwriting recognition program that allows you to write in cursive, print, or a combination of both. Transcriber works transparently in the background of programs, recognising words with its integrated dictionary. When Transcriber is turned on, it interprets stylus movement anywhere on the screen as handwriting input. For more information about using Transcriber, see Help on your Ameo.

To start Transcriber

1. Start a program that accepts user input, such as Word Mobile.

2. Tap the

introductory screen appears.

Input Selector arrow, and tap Block Recognizer.

Input Selector arrow, and tap Transcriber. The Transcriber

Entering a nd Searching for Information

To write using Transcriber

1. In a program, position the cursor where you want text to appear.

2. Use the stylus to write anywhere on the screen. The handwriting will be

converted to text shortly after you lift the stylus from the screen.

To enter punctuation and symbols

Transcriber comes with an on-screen keyboard that provides an easy way to add punctuation or a special symbol to existing text.



From a program, tap on the Transcriber toolbar.

The keyboard remains visible until you tap the button again.



Tips

To reposition the keyboard, tap and hold the title bar, then drag to the desired

location.



When no text is selected, you can also open the keyboard by doing the

gesture. For more information about using Transcriber gestures, see Help on your Ameo.

To edit text

1. In a program, draw a line across the text you want to edit.

2. After you lift the stylus from the screen, the line will disappear and the

selected text will be highlighted.

3. Do either of the following:



Rewrite the text.



Use gestures to capitalize letters, insert a space, and so on. For information about using Transcriber gestures, see Help on your Ameo.

Entering a nd Searching for Information

2.7 Using Symbol Pad

Symbol Pad provides a comprehensive list of common symbols such as parentheses, brackets, currency signs, and more, as well as punctuation marks and special characters.

To open the Symbol Pad and select a symbol

1. Create or open a document, such as a Word document.

2. To open the Symbol Pad:



Tap the Input Selector arrow, then tap Symbol Pad; or



Using the hardware keyboard, press and then press .

3. To browse through the pages of symbols, tap

Pad screen.

4. Tap a symbol to select it and close the Symbol Pad. The selected symbol will

then be inserted in your document.

Tap a symbol to select it.

When using t he Navigation Contr ol or the hardw are keyboard, press UP, DOWN, LEFT, or RIGHT to navigat e through the available symbols o nscreen, then press ENTER to sel ect a symbol.

Tap to displ ay the previous page of symbols.

Tap to displ ay the next page of symbols.

Tap to close the Symbol Pad wit hout selecting any symbol.

This indicat es the current page and the total number of sy mbol pages.

Input Select or arrow

Symbol Pad i con

/ on the Symbol

Entering a nd Searching for Information

2.8 Using Notes to Draw, Write, and Record

Voice Notes

Using Notes, you can draw directly on the screen, or write on the screen and save notes in your own handwriting. You can also create a stand-alone recording (voice note) or you can add a recording to a note. For more information on what you can do with Notes, see “Notes” in Chapter 7.

2.9 Searching for Information

You can search for files and other items stored in My Documents folder or on an installed storage card of your Ameo. You can search by file name or by words located in the item. For example, you can search in e-mail messages, notes, appointments, contacts, and tasks, as well as in online Help.

To search for a file or an item

1. Tap

Start > Programs > Search.

2. In the Search for ﬁeld, you can:

• Enter the ﬁle name, word, or other information you want to search for.

• Tap the down arrow icon ( ), and from the list, select one item that you

have looked for before.

3. In the

Type ﬁeld, you can tap the down arrow icon ( ) and select a data

type from the list to help narrow your search.

4. Tap Search. The system start searching the matched ﬁles in My Documents

folder and subfolders.

Results list, tap the item you want to open.

5. In the

Note The symbol is displayed next to the names of files saved on a storage card or

the Microdrive.

Entering a nd Searching for Information

Chapter 3

Using Phone Features

3.1 Using the Phone

3.2 Making a Call

3.3 Receiving a Call

3.4 Making a Video Call

3.5 Receiving a Video Call

3.6 Smart Dialing

3.7 In-call Options

3.8 Additional Dialing Information

3.9 Setting Up Bluetooth SIM Access for Car Kit Phones

!”T§==Mobile===

Using Phon e Features

3.1 Using the Phone

Like a standard mobile phone, you can use your Ameo to make, receive, and keep track of calls and send SMS/Picture Messages. You can also dial directly from Contacts, and easily copy phonebook entries from your SIM card to Contacts on your Ameo.

The Phone screen

From the Phone screen, you can access Call History, Speed Dial, and Phone settings. To open the Phone screen, tap Start > Phone.

Enter your PIN

Most SIM cards are preset with a PIN (personal identification number) that is provided by T-Mobile. You need to enter the PIN whenever you use your Ameo.

1. Enter the preset PIN assigned byT-Mobile.

2. Tap

Enter.

Note If your PIN is entered incorrectly three times, the SIM card will be blocked. If this

happens, you can unblock it with the PUK (PIN Unblocking Key) obtained from T-Mobile.

Turn the phone function on and off

In many countries, you are required by law to turn off your phone while on board an aircraft. To turn off the phone function, do one of the following:



Tap the Comm Manager icon ( ) on the Today screen. On the Comm Manager screen, tap the Phone button to turn off the phone function.

To resume call function, turn on the phone function by tapping the Phone

button again on the Comm Manager screen.



Tap the Flight Mode button in Comm Manager. This disables all wireless radios on your Ameo, which include the phone function, Bluetooth, and Wi-Fi.

To resume call function, tap the Flight Mode button again in Comm Manager.

This also restores the previous state of Bluetooth, but keeps Wi-Fi disabled.

Using Phon e Features

Adjust the device volume

1. Tap the Speaker icon ( ).

2. Under

Note To adjust the conversation phone volume, you must do it during a call. Adjusting

Volume, do the following:



Adjust the phone volume ( slider to the desired volume level.



Tap On or Off to change both the system and ringer volume settings.

Volume adjus tment

the volume at another time will affect the ring, notification, and MP3 sound levels.

) or device volume ( ) by moving the

Using Phon e Features

3.2 Making a Call

With your Ameo, you can make a call from Phone, Contacts, Speed Dial, Call History, and SIM Manager.

IMPORTANT You need to have a wired or Bluetooth headset connected to your Ameo to

talk to or to hear the other party.

Make a call from Phone

1. Tap Start > Phone.

2. On the Phone screen, tap the desired phone number, and tap Talk.

Talk button

Phone screen

Tip If you tap a wrong number, tap the Back arrow (

subsequent digit of a number. To erase the entire number, tap and hold the Back arrow.

) to erase each

Make a call from Contacts

Tap Start > Contacts, then do one of the following:



Tap the desired contact in the contacts list, and tap the phone number that you want to call.



Tap and hold the desired contact, and on the shortcut menu, tap Call Work, Call Home, or Call Mobile.

Using Phon e Features

To choose one of the numbers of a contact to dial

By default, the mobile telephone number (m) of a contact is dialed when you make a call from Contacts. However, you can specify that a different phone number is dialed instead.

1. Tap Start > Contacts.

2. Use the NAVIGATION CONTROL to select a contact.

2. Press NAVIGATION right or left. The letters representing the number will

change as you scroll through them.

Make a call from Call History

1. On the Phone screen, tap Call History.

2. Scroll to the desired contact or phone number, and tap Call.

Make a call from Speed Dial

Use Speed Dial to call frequently-used numbers with a single tap. For example, if you assign a contact to the location 2 in Speed Dial, you can simply tap and

hold on the Phone screen to dial the contact’s number. Before you can create a Speed Dial entry, the number must already exist in Contacts.

To create a Speed Dial entry

1. On the Phone screen, tap

2. Tap

Menu > New.

3. Tap a contact. Select the phone number that you want to add to Speed Dial.

4. In the Location box, select an available location for the new Speed Dial entry.

Note Location 1 is generally reserved for your voice mail, and Speed Dial will designate

the next available location by default. If you want to place a phone number in a position that is already occupied, the new number will replace the number that is already there.

Speed Dial.

Tips



To create a Speed Dial entry from Contacts, tap and hold the contact name, tap Add to Speed Dial, then select the phone number for which to create a Speed Dial and an available location for the new Speed Dial entry.

Using Phon e Features



To delete a Speed Dial entry, in the Speed Dial list, tap and hold the desired entry, and tap Delete.

Make a call from SIM Manager

SIM Manager allows you to view the contents of your SIM card, transfer SIM phonebook entries to Contacts on your Ameo, and make a call from your SIM card.

To call a SIM contact

1. Tap

Start > Programs > SIM Manager. Wait for your SIM card contents to

load.

2. Tap and hold the name or phone number of the person you want to call, and

tap Call.

3.3 Receiving a Call

When you receive a phone call, a message will appear, giving you the option to either answer or ignore the incoming call.

IMPORTANT You need to have a wired or Bluetooth headset connected to your Ameo to

talk to or to hear the other party.

To answer or reject an incoming call



To answer the call, tap Answer.



To reject the call, tap Ignore.

To end a call

Once an incoming or outgoing call is in progress, you can tap End on the Ameo to hang up.

Using Phon e Features

3.4 Making a Video Call

Your Ameo allows you to make video calls when you are within a 3G network coverage area. You need to use a 3G enable SIM card to make video calls.

IMPORTANT You need to have a wired or Bluetooth headset connected to your Ameo to

talk to or to hear the other party.

To make a video call

• On the Phone keypad, tap the phone number to call, then tap to

start a video call.

• From Contacts, tap and hold the desired contact, and tap Video Call.

• From Call History, tap and hold the desired phone number or contact, and

tap Video Call.

Note The other party’s image will appear on the screen about 3 to 5 seconds after a

connection is established, depending on the signal strength. The streaming images quality may also be influenced by the signal.

When the video call is unsuccessful, a message pops up asking you if you want to try again, make a voice call instead, or send an SMS/Picture Message.

Change Video Call settings

While on a video call, you can change certain settings such as the size of the image, brightness of the image, the camera to use, and more. The following shows the Video Call screen and control buttons during an ongoing call.

Using Phon e Features

1 Status area. Displays the T-Mobile name, the other party's information, and call timer.

2 Image display area. Displays your image and the other party's image, depending on

the selected Swap Image setting.

3 Brightness Control. Tap to adjust the camera’s brightness.

4 Camera On/Off. Tap to toggle between turning on/off the camera. When the camera

is turned off, the image displayed depends on the Video Call options you have set. See “Set up Video Call Options” for details.

5 Audio Mute/Unmute. Tap to mute/unmute audio.

6 Main/Second camera. Tap to toggle between using the Main (back) and Second

(front) camera.

7 Swap Image. Tap continuously to cycle through the available image display options.

8 End. Tap to end the video call.

Using Phon e Features

Swap Image options

Both parties

(My video small)

Both parties

(My video large)

Both parties (equal)

Other party only

Set up video call options

The other party's image is large while your image is small. This is the default setting.

The other party's image is small while your image is large.

Both your image and the other party appear the same size.

Only the other party's image is displayed.

On the Phone screen, or on the screen of the ongoing video call, tap Menu > Video Call Options. You can set the following options:

Video Call O ptions: General tab Video Call O ptions: Services ta b

Using Phon e Features

General tab

• Show still image. Select the image you want to display when you turn off the

camera.

• Preset (female). Displays a female picture provided by your service

provider.

• Preset (male). Displays a male picture provided by your service provider.

• Custom image. Lets you use an image from file as your display picture.

When this option is selected, the File Name box and the Browse button will be enabled, allowing you to select an image file.

• Last video frame. Uses the last video frame before you stopped the

camera as your display image.



Video screen preference. To change how your image and the other party’s image are displayed on the screen, select your preference from the Video screen preference list or tap the Swap Image button on the Video Call screen.



Camera options:

• Flip the 2nd camera video. Select this check box if you are going to

show a text document to the other party using the second camera.

• Switch camera off when answering video call. Select this check box to

not send a video feed of yourself to the other party. Instead, the option you selected in Show still image will be displayed.



Display info:

• Show call timer. Select this check box to display the call period in the

status area.

Using Phon e Features

• Show phone number and name. Select this check box to display the

other party’s phone number and name in the status area.

Services tab

To set up further calling options for Video Call, tap the Services tab. On the Services screen, select the desired service from the list, then tap Get Settings to access its settings.

3.5 Receiving a Video Call

IMPORTANT You need to have a wired or Bluetooth headset connected to your Ameo to

talk to or to hear the other party.

To answer or reject an incoming video call

• To answer the video call, tap Answer.

• To reject the video call, tap Ignore.

To end a video call

Once an incoming or outgoing video call is in progress, you can tap End to hang up.

Using Phon e Features

3.6 Smart Dialing

Smart Dialing is a program that makes it easy for you to dial a phone number. When you start entering numbers or characters, Smart Dialing will automatically search and sort the contact entries on the SIM card, in Contacts, and the phone numbers in Call History (including incoming, outgoing, and missed calls). You can then select the desired number or contact from the filtered list to dial.

Start Smart Dialing

Open the Phone screen, then tap the keys on the Phone keypad that correspond to the phone number or contact you want to call. When you start entering a number or letter, the Smart Dialing panel will appear automatically on the Phone screen. You can change the panel size according to your needs by tapping the arrow icon .

Tap

to minimize or expand the Smar t Dialing panel

Minimized Sm art Dialing panel Expanded Sma rt Dialing panel

Tips on using Smart Dialing

Smart Dialing starts looking for numbers or contacts that match the sequence you have entered. Below are some tips on how to use Smart Dialing to quickly find a desired phone number or contact.

Using Phon e Features

To find a phone number



Simply enter the first one or two digits to find a phone number in Call History.



Enter the first three digits or more if you want to find a phone number from the saved contacts on your Ameo and SIM card.

To find a contact name

You can just enter the first letter of a contact’s first name or surname. Smart Dialing will search for the letter starting from the first character of a contact name as well as from the character that appears after a space, dash, or underscore in a contact name. For example, if you tap number “2” which is associated with [a, b, c] on the Phone keypad, contact names such as the following will be considered matches: “Ben Miller”, “George Adams”, “John-Carter”, “Carter, Ellen”, “Dixon, Allan”, “Thomas_Clark”, “JaneCampbell”. If the matching list is long and you want to narrow down the search further, enter another letter. Using the same example above, if you continue to tap “3” which is associated with [d, e, f], the matching list will be narrowed down to the following names: “Ben Miller”, “George Adams”, “Carter, Ellen”, “Dixon, Allan”.

Make a call or send a text message using Smart Dialing

1. Begin entering the ﬁrst few numbers or characters.

2. In the Smart Dialing panel, browse the list by tapping the arrows

( / ) or pressing NAVIGATION up or down to select the desired contact or phone number. When a contact is selected, it expands to also show the corresponding phone number.

3. The highlighted item will move one line when you press NAVIGATION up or

down; the highlighted item will scroll one page when you tap the arrows.

4. Do one of the following:



When the correct contact is selected, tap Talk to make a voice call.



To call a different phone number associated with the selected contact, tap and hold the selected contact, and tap the phone number you want to call.

Using Phon e Features

Tap and hold the contact to pop up the shortcut me nu



To send a text message to the selected contact, tap and hold the contact, and tap Send Text Message.

Tip

To view or edit information associated with the selected contact, tap the contact’s name on the shortcut menu (applies only to entries stored in Contacts on your Ameo).

Set up Smart Dialing

1. On the Phone screen, tap Menu > Smart Dialing Options.

2. On the

Options tab, select the Enable Smart Dialing check box.



Select the Automatically expand selected contact check box to enable a contact’s name and phone number to be displayed when the contact is selected in the matching list.



Select the Enable drag-scroll check box to scroll in the matched list by dragging.



Select the Enable double-click for dialing check box to make a voice call by double-tapping the item in the matched list.



Select the Expand panel when using hardware keyboard check box to automatically expand the Smart Dialing panel when you are using the hardware keyboard to input.



In Scroll unit, you can set the amount of scrolling when tapping the

arrows ( / ).

Using Phon e Features

3.7 In-call Options

To put a call on hold

Your Ameo notifies you when you have another incoming call, and gives you the choice of rejecting or accepting the call. If you are already on a call and accept the new call, you can choose to switch between the two callers, or set up a conference call between all three parties.

1. Tap

Answer to take the second call, and put the ﬁrst one on hold.

2. To end the second call and return to the ﬁrst call, tap

To switch between two calls



Tap Swap.

To set up a conference call

1. Either put a call on hold, and dial a second number; or, accept a second

incoming call when you already have one in progress.

2. Tap

Conference.

Note Not all service providers support conference calling. Contact your service provider

for details.

The built-in Speakerphone on your Ameo allows you to talk hands-free or lets other people listen to the conversation.

Warning! To avoid damage to your hearing, do not hold your Ameo against your ear when

the Speakerphone is turned on.

End on the Ameo.

Using Phon e Features

To mute a call

You can turn off the microphone during a call, so that you can hear the caller but the caller cannot hear you.



During a call, tap Mute.



When the microphone is turned off, the mute icon (

) appears on the

screen. Tap Unmute to turn on the microphone again.

3.8 Additional Dialing Information

Make an emergency call



Enter the international emergency number for your locale, and tap Talk.

Tip Additional emergency numbers may be included in your SIM card. Contact your

service provider for details.

Make an international call

1. Tap and hold on the Phone keypad until the + sign appears. The +

replaces the international preﬁx of the country that you are calling.

2. Enter the full phone number you want to dial, and tap Talk. The full phone

number includes country code, area code (without the leading zero, if any) and phone number.

Using Phon e Features

3.9 Setting Up Bluetooth SIM Access for Car Kit

Phones

Bluetooth car kits that support the SIM Access Profile (SAP) can connect to your Ameo and access its SIM card via Bluetooth. Once a SAP connection has been established, you can download SIM contacts from your Ameo to the car kit phone. You can also use the car kit phone to answer and make calls using your Ameo’s SIM card.

Notes  To enable downloading contacts onto the car kit, ensure that all contacts on the

Ameo are stored in the SIM card and not in the Ameo memory. Configure the car kit to download contacts only from the SIM card.



Contact T-Mobile to find out which car kit phone models are compatible with your Ameo.

1. On your Ameo, make sure that Bluetooth is turned on and set to visible

mode. For information about turning on Bluetooth and enabling visible mode, see “Bluetooth modes” in Chapter 6.

2. Tap

Start > Programs > SAPSettings.

3. On the BT Remote SIM Access screen, select the Remote SIM Access check

box then tap Done.

4. Connect the car kit phone to your Ameo via Bluetooth. To learn how to

connect, consult your car kit phone’s manual.

5. If this is the ﬁrst time you are pairing the car kit phone with your Ameo, enter

the car kit’s passcode on your Ameo.

6. A pop-up message should appear on your Ameo saying that a connection

has been established between your Ameo and car kit phone. Tap OK.

7. On the BT Remote SIM Access screen, tap

Note You will not be able to make/receive calls, send/receive messages or perform

related activities on your Ameo when the SIM Access Profile connection is active. You’ll be able to do all these from the car kit phone during this time. After the connection is disconnected, you will be able to use your Ameo as before.

Done.

Using Phon e Features

Chapter 4

Synchronising Information and Setting Up Email Security

4.1 Setting Up ActiveSync

4.2 Synchronising Information

4.3 Synchronising via Bluetooth

4.4 Synchronising Music, Video, and Pictures

4.5 Setting Up E-mail Security

!”T§==Mobile===

Synchronis ing Information and Setting U p Email Security

4.1 Setting Up ActiveSync

Microsoft ActiveSync synchronises information on your Ameo with information on your PC, such as Microsoft Outlook content. ActiveSync can also synchronise over a wireless or cellular network with Microsoft Exchange Server, if your company or service provider is running Microsoft Exchange Server with Exchange ActiveSync. Specifically, you can use ActiveSync to:



Synchronise information such as Outlook E-mail, Contacts, Calendar, or Tasks information, as well as media files such as pictures, video, and music between your Ameo and your PC.



Synchronise Outlook E-mail, Contacts, Calendar appointments, and Tasks on your Ameo directly with Exchange Server so that you can stay up-to-date even when your PC is turned off.



Copy files between your Ameo and your PC without synchronising.



Select which types of information are synchronised and specify how much information is synchronised. For example, you can choose how many weeks of past Calendar appointments to synchronise.



Add and remove programs on your Ameo. For details, see Chapter 5, “Adding and Removing Programs.”

To install and set up ActiveSync on the computer

1. Install ActiveSync on your PC, as described in the Getting Started CD.

2. After ActiveSync is installed, the Synchronisation Setup Wizard automatically

starts when you connect your Ameo to the PC. The wizard will guide you to create a synchronisation relationship between your computer and Ameo. Click Next.

3. Do not select the

Exchange Server check box if you want to synchronise your Ameo with a computer. Just click Next, then skip to step 8.

4. If you want to synchronise your Ameo with Exchange Server, select the

Synchronise directly with a server running Microsoft Exchange Server check box, then click Next.

5. On the Exchange server credentials screen, enter the Exchange server

address, your user name and password, and the domain name.

Synchronise directly with a server running Microsoft

Synchronis ing Information and Setting U p Email Security

If you do not know the Exchange server address and the domain name,

check with your network administrator, or do the following to ﬁnd them in your computer: a. In Outlook, click Tools > E-mail Accounts.

Select View or change existing e-mail accounts.

b. c.

Double-click Microsoft Exchange Server.

On the Exchange Server Settings screen, you will see the Exchange

Server name.

Synchronis ing Information and Setting U p Email Security

e. To check the domain name, click Start > Settings > Control Panel, then

double-click System.

In the System Properties dialog box, click the Computer Name tab. You

will then see the domain name.

6. On your Ameo, you also need to enter the Exchange server settings. For

information about this, see “Synchronise Outlook information with Exchange Server.”

7. On the Synchronisation Setup Wizard, click

Next.

Synchronis ing Information and Setting U p Email Security

8. Select the information types to synchronise between your Ameo and computer.

If you want to synchronise your Ameo with both your computer and Exchange

Server, do the following: a. For the Contacts, Calendar, E-mail, and Tasks items, choose whether to

synchronise them with the computer or with the Exchange Server. These items cannot be synchronised to both.

Select the check boxes of the other information types if you want to

synchronise them with your computer.

In formation types on the PC and Exchange Server

9. Click Next and then click Finish.

When you finish the wizard, ActiveSync synchronises your Ameo automatically. Once synchronisation completes, you can disconnect your Ameo from your PC.

Synchronis ing Information and Setting U p Email Security

4.2 Synchronising Information

When you connect your Ameo to the PC using a USB cable or a Bluetooth connection, ActiveSync will immediately synchronise. While your Ameo is connected, ActiveSync synchronises every time you make a change on either the PC or your Ameo.

To manually start and stop synchronisation

1. Connect your Ameo to the PC:



To synchronise Outlook information and other local information on the PC, including media files, connect your Ameo to the PC using Bluetooth or a USB cable.



If you are synchronising directly with Exchange Server, you can use this connection to the PC to "pass through" to the network, or you can synchronise without connecting to the PC over a cellular network.

2. In ActiveSync, tap Sync. To end synchronisation before it completes, tap

Stop.

Note ActiveSync 4.2 utilizes a network type of connection with Windows Mobile powered

devices, since this allows faster data transfer than a serial USB connection. When the PC is connected to the Internet or a local network, in some cases, the PC may disconnect the ActiveSync connection with your Ameo in favor of the Internet or network connection. If this happens, tap Start > Settings > Connections tab

> USB to PC and select ActiveSync then clear the Enable advanced network functionality check box. This makes ActiveSync utilize a serial USB connection

with your Ameo.

Synchronise Outlook information with the computer

If you have set up a synchronisation relationship between your Ameo and the PC, synchronisation keeps Outlook information up-to-date on both your Ameo and PC. You can also set up your Ameo to synchronise with more than one PC or with a combination of one or more PCs and Exchange Server. When synchronising with multiple computers, the items that you synchronise will appear on all of the computers with which they are synchronised. For example, if you have set up synchronisation with two PCs (PC1 and PC2), which have different items, and

Synchronis ing Information and Setting U p Email Security

you synchronise Contacts and Calendar on your Ameo with both computers, the result is as follows:

Location New state

PC1

PC2

Pocket PC Phone

Note Outlook e-mail can be synchronised with only one computer.

All Outlook contacts and calendar appointments that were on PC2 are now also on PC1. All Outlook contacts and calendar appointments that were on PC1 are now also on PC2. All Outlook contacts and calendar appointments from both PC1 and PC2 are on your Ameo.

To change which information is synchronised

ActiveSync synchronises a limited amount of information by default to save storage space on your Ameo. You can change the amount of information that is synchronised by performing the following steps.

Note Before changing synchronisation settings on your Ameo, disconnect it from your

PC.

1. In ActiveSync on your Ameo, tap Menu > Options.

2. Do one or both of the following:



Select the check box for any items you want to synchronise. If you cannot select a check box, you might have to clear the check box for the same information type elsewhere in the list.



Clear the check box for any items you want to stop synchronising.



To stop synchronising with one PC completely, tap the PC and tap

Delete.

Note To change available synchronisation settings, select the type of information and tap

Settings.

Synchronis ing Information and Setting U p Email Security

Synchronise Outlook information with Exchange Server

You can set up synchronisation with Exchange Server on your Ameo, if it is available to you through your company or T-Mobile. However, you should first gather information, such as Exchange Server name, domain name, your user name, and password, and then carry on with the steps. (For information about how to check the Exchange server name and domain on your PC, see “To install and set up ActiveSync on the computer.”)

Note Before changing synchronisation settings on your Ameo, disconnect it from your

PC.

To synchronise directly with Exchange Server

1. Do one of the following:



Tap Start > Messaging, then tap Menu > Tools > New Account. On the E-mail Setup screen, select Outlook E-mail in the Your e-mail provider list, then tap Next.



In ActiveSync on your Ameo, tap not yet set up synchronisation with Exchange Server, this appears as Add Server Source.

2. In Server address, enter the name of the server running Exchange Server,

and tap Next.

3. Enter your user name, password, and domain, and tap Next. To change the

rules for resolving synchronisation conﬂicts, tap

4. Select the check boxes for the types of information items that you want to

synchronise with Exchange Server.

5. To change available synchronisation settings, select the type of information,

and tap Settings.

Finish.

6. Tap

Menu > Configure Server. If you have

Advanced.

Synchronis ing Information and Setting U p Email Security

Schedule synchronisation with Exchange Server

You can schedule information to be synchronised automatically between your Ameo and the Exchange Server, or schedule synchronisation at regular time intervals. Choose between these two methods, depending on your e-mail volume and which method you think is more cost-effective.

To receive e-mails and synchronise other information instantly Direct Push technology (push e-mail feature) enables you to receive new e-mails

on your Ameo as soon as they arrive in your Inbox on the Exchange Server. With this feature, items such as contacts, calendar and tasks are also immediately updated onto your Ameo when these items have been changed or new entries have been added on the Exchange Server. To make Direct Push work, you need to have a GPRS connection on your Ameo. The Direct Push feature works for your Ameo only if it is connected to a private network (corporate network) that is using Microsoft Exchange Server Service Pack 2 (SP2) with Exchange ActiveSync. You need to perform a full synchronisation between your Ameo and the Exchange Server first before Direct Push can be enabled.

Using Comm Manager to enable Direct Push

1. On the Today screen, tap the

2. On the Comm Manager screen, tap the

button will turn to , which indicates that you will receive e-mails as they arrive. When the button is in the state, you need to manually retrieve your e-mails.

Using ActiveSync to enable Direct Push

1. In ActiveSync on your Ameo, tap

2. Select

As items arrive in the Peak times and Off-peak times boxes.

Comm Manager icon ( ).

Microsoft Direct Push button. The

Menu > Schedule.

Synchronis ing Information and Setting U p Email Security

Note When both the GPRS and Wi-Fi connections are turned on at the same time, the

Direct Push feature will always use GPRS, for which you could be charged per your T-Mobile’s service plan.

To schedule synchronisation at regular time intervals

You can set how often to synchronise during Peak times (which usually refer to your working hours) when e-mail volume is high, as well as Off-peak times when e-mail volume is low.

1. In ActiveSync on your Ameo, tap

2. Select a shorter time interval in the Peak times box for you to be able to

receive e-mails more frequently.

3. Select a longer interval in the Off-peak times box.

Tip To set the days and hours that make up your peak and off-peak times, tap Adjust

peak times to fit your schedule.

Menu > Schedule.

Synchronis ing Information and Setting U p Email Security

4.3 Synchronising via Bluetooth

You can connect and synchronise your Ameo with the PC using Bluetooth.

To synchronise with a computer via Bluetooth

1. Follow the instructions in ActiveSync Help on the computer for conﬁguring

Bluetooth on your computer to support ActiveSync.

2. On your Ameo, tap

3. Tap Menu > Connect via Bluetooth. Make sure the Bluetooth function of

both your Ameo and the computer are turned on, and they are within close range.

4. If this is the ﬁrst time you have connected to this computer via Bluetooth,

you must ﬁrst complete the Bluetooth wizard on your Ameo and set up a Bluetooth partnership between your Ameo and the computer. For more information about creating a Bluetooth partnership, see “Bluetooth partnerships” in Chapter 6.



Notes

To preserve battery power, turn off Bluetooth when not in use.



To connect and synchronise your Ameo with a computer via Bluetooth, your computer must have a Bluetooth adapter or dongle.

Start > Programs > ActiveSync.

Synchronis ing Information and Setting U p Email Security

4.4 Synchronising Music, Video, and Pictures

If you want to carry your music or other digital media along with you while you travel, ActiveSync works with Windows Media Player Mobile to synchronise music, video, and pictures with your Ameo. Other than selecting the Media information type in ActiveSync to be synchronised, all media synchronisation settings must be set in Windows Media Player Mobile. Before media can be synchronised, you must do the following:



Install Windows Media Player Version 10 on the PC. (Windows Media Player 10 works only in Windows XP or later versions).



Connect your Ameo to the PC with a USB cable. If your Ameo is currently connected using Bluetooth, you must end that connection before media can be synchronised.



Insert a storage card into your Ameo (128MB or larger is recommended).



Set up a sync partnership between the storage card and Windows Media Player Mobile.

Change Media synchronisation settings

Once you select the Media information type in ActiveSync to be synchronised, any of your favourite music, video, and picture files in Windows Media Player playlists can be synchronised. All you have to do is set up synchronisation in Windows Media Player for those media files.

To set up a sync relationship with a storage card

1. On the computer, open Windows Media Player.

2. Click the

3. Select the storage card.

Sync tab.

Synchronis ing Information and Setting U p Email Security

4. Click Set up Sync.

5. Choose whether to synchronise automatically or manually.

For more information about Windows Media Player Mobile on your Ameo, see “Using Windows Media Player Mobile” in Chapter 9.

Synchronis ing Information and Setting U p Email Security

4.5 Setting Up E-mail Security

Windows Mobile on your Ameo protects your Outlook e-mails through Secure/ Multipurpose Internet Mail Extension (S/MIME), which allows you to digitally sign your messages as well as encrypt them. Using authorisation keys and certificates, S/MIME allows you to digitally sign your e-mail messages to prove your identity to the recipients. Authorisation keys are also used when encrypting messages to improve privacy and prevent undue tampering or hacking of your messages. You can encrypt a message with or without a certificate. However, to read an encrypted message, you need a valid certificate to decrypt it.

Note S/MIME encryption and digital signatures for Windows Mobile-based devices

are available only with Exchange Server 2003 Service Pack 2 or a later version that supports S/MIME. If you are not using one of these products, or have not yet synchronised, these options are unavailable.

Digitally sign and encrypt all messages

ActiveSync allows you to set up S/MIME e-mail encryption and signing. You must obtain a valid certificate to sign and encrypt e-mail messages successfully.

1. Tap Start > Programs > ActiveSync.

2. Tap

Menu > Options.

3. Select the

Options screen, tap Advanced.

E-mail information type, and tap Settings. On the E-mail Sync

4. Do one or both of the following:

Synchronis ing Information and Setting U p Email Security



To sign all your outgoing e-mail messages so that recipients can be certain that the messages were sent by you and have not been altered in any way, select the Sign all outgoing e-mail messages check box.



To encrypt all your outgoing e-mail messages so that the contents of your messages are protected from being viewed by anyone other than the intended recipients, select the Encrypt all outgoing e-mail messages check box.

Choose Certificate to select a certiﬁcate for signing or encrypting

5. Tap

outgoing e-mail messages.

You can select certiﬁcates to sign or encrypt e-mail messages individually

if you do not choose to sign or encrypt all outgoing e-mail. For information about signing and encrypting individual messages, see “Individually sign and encrypt a message” in Chapter 7.

Synchronis ing Information and Setting U p Email Security

Chapter 5

Managing Your Ameo

5.1 Personalising Your Ameo

5.2 Adding and Removing Programs

5.3 Managing Memory

5.4 Copying Files

5.5 Backing Up Data

5.6 Protecting Your Ameo

5.7 Using Anti-Virus to Scan Viruses

5.8 Resetting Your Ameo

!”T§==Mobile===

Managing Y our Ameo

5.1 Personalising Your Ameo

Customise the Today screen

The Today screen shows your upcoming appointments, active tasks, and information about incoming messages. You can customise the Today screen on your Ameo.

To customise the Today screen

1. Tap

Start > Settings > Personal tab > Today.

2. On the

3. On the

Tip To change the order of items displayed on the Today screen, tap the item, and tap

To add a custom background image

You can use one of your own pictures as the background image on the Today screen. Be aware that pictures can affect the readability of text on the Today screen.

1. Tap

2. Select the

3. Tap the ﬁle name of the picture you want to use.

4. Tap OK.

To set options for displaying appointments on the Today screen

If you have a large number of appointments, you may want to specify the kind of appointments that are displayed on the Today screen.

1. Tap

2. Tap the Items tab.

3. Select

4. Do any of the following:

Appearance tab, select the desired theme for the background of the

Today screen.

Items tab, select the items you want to appear on the Today screen.

Move Up or Move Down.

Start > Settings > Personal tab > Today.

Use this picture as the background check box, and tap Browse

to view a list of your picture ﬁles.

Start > Settings > Personal tab > Today.

Calendar and tap Options.



Select Next appointment to show only the next appointment in your schedule, or Upcoming appointments to show multiple appointments.

Managing Y our Ameo



Clear the Display all day events check box if you do not want to display all-day events.

To set options for displaying tasks on the Today screen

If you have a large number of tasks, you may want to specify the kind of tasks that are displayed on the Today screen.

Start > Settings > Personal tab > Today.

1. Tap

2. Tap the

Items tab.

3. Select Tasks and tap Options.

4. Do any of the following:



Under Display number of, select the type of tasks you want to appear on the Today screen.



In the Category list, select whether to display only tasks assigned to a specific category or to display all tasks.

Customise the Start menu

You can choose which items appear in the Start menu.

1. Tap

Start > Settings > Personal tab > Menus.

2. Select the check boxes of the items you want to appear in the

Start menu.

You can select up to seven items.

Tip You can also create folders and shortcuts to appear on the Start menu. In

ActiveSync on your PC, click Explore. In the Mobile Device window, doubleclick My Windows Mobile-Based Device > Windows > Start Menu, then create the folders and shortcuts that you want. You will see the added items after you synchronise.

Why is the device name important?

The device name is used to identify the device in the following situations:



Synchronising with a PC



Connecting to a network



Restoring information from a backup

Managing Y our Ameo

Note If you synchronise multiple devices with the same PC, each device must have a

unique name.

To change the device name

1. Tap Start > Settings > System tab > About.

2. Tap the

Device ID tab.

3. Enter a name.

Note The device name must begin with a letter, consist of letters from A to Z, numbers

from 0 to 9, and cannot contain spaces. Use the underscore character to separate words.

Set Date / Time / Regional Options

You can set up the correct date, time, and regional settings according to your use.

To set the time and date

1. Tap

Start > Settings > System tab > Clock & Alarms > Time tab.

2. Select the correct time zone and change the date or time.

Note During synchronisation, the time on your Ameo is updated with the time on your PC.

To set an alarm

1. Tap

Start > Settings > System tab > Clock & Alarms > Alarms tab. <Description> and enter a name for the alarm.

2. Tap

3. Tap the day of the week for the alarm. You can select multiple days by

tapping each desired day.

4. Tap the time to open a clock and set the time for the alarm.

5. Tap the alarm icon (

choose a ﬂashing light, a single sound, or a repeating sound.

6. If you choose to play a sound, tap the list next to the Play sound check box

and tap the sound you want.

) to specify the type of alarm you want. You can

Managing Y our Ameo

To set the time and date for a different location

If you visit or communicate with someone in a particular time zone often, you can select it as your visiting time zone.

Start > Settings > System tab > Clock & Alarms > Time tab.

1. Tap

2. Tap Visiting.

3. Select the correct time zone and change the time or date.

To change regional settings

The style in which numbers, currency, dates, and times are displayed is specified in regional settings.

1. Tap Start > Settings > System tab > Regional Settings.

2. On the Region tab, select your region from the list.

Note This does not change the Operating System language of your Ameo.

3. The region you select determines which options will be available on the other

tabs.

4. To customise settings further, tap the appropriate tabs and select the desired

options.

Personal and system settings

To format the Microdrive

Your Ameo comes with a built-in 8GB Microdrive® that gives you additional storage space for your files. Use Format Microdrive to delete all the files in the Microdrive and to format it.

Start > Settings > Systems tab > Format Microdrive.

1. Tap

2. Enter

1234 in the box and tap Continue.

To use TV Out

TV Out lets you output the contents you are viewing on the Ameo screen to an external display device (e.g. projector). This is useful when you are doing a presentation or when you are sharing your videos or photos with people.

Managing Y our Ameo

To connect the Ameo to an external display device

1. Turn off the external viewing device and unplug the power cord from the wall

socket.

2. Take out the VGA cable from the box. Connect the external viewing device’s

cable to the bigger end of the VGA cable.

3. Connect the smaller end of the VGA cable to the VGA port on the Ameo.

4. Plug in the power cable of the external viewing device to a wall socket and

turn it on.

To enable TV Out

1. On the Today screen, tap

Start > Settings > System tab > TV Out.

2. On the TV Out Settings screen, choose On on the drop-down menu.

3. Choose the

Connection that you are using to output.

Managing Y our Ameo



Select VGA-out if you are doing a presentation such as a Powerpoint presentation and you are outputting it to a projector.



Select Composite & S-Video if you are going to output a video to the external viewing device. Choose the Video standard to use when outputting (e.g. If your video is in the NTSC video standard and you select PAL, TV Out will convert your video to PAL before outputting.)

4. Tap

OK.

Notes  Audio output is not supported.



If you are connecting to a device that requires a Composite or S-Video connection, it is recommended that you contact the distributor orT-Mobile first and inquire about the compatible accessory needed. An improper connection may result in the Ameo being damaged.

You can output to other external viewing devices as long as the external viewing device’s cable can be plugged into the VGA out cable of the Ameo.

To disable TV Out

1. On the Today screen, tap

2. On the

TV Out Settings screen, choose Off on the drop-down menu.

Start > Settings > System tab > TV Out.

3. Turn off the external viewing device and then unplug the power cord.

4. Disconnect the VGA cable’s smaller end from the Ameo and then disconnect

the external viewing device’s cable from the VGA out cable.

Playing videos

TV Out does not support the playback of audio. It is recommended to turn up the volume of the Ameo when playing back video with audio on an external viewing device.

To configure the “X” button to shut down programs

You can configure the button to shut down running programs and free up the memory space that is occupied by them.

1. Tap

Start > Settings > System tab, then tap X-Button.

2. Select the

Enable the “X” button to end running programs check box.

Managing Y our Ameo

3. Choose the action for shutting down programs (by tapping the “X” button,

tapping and holding the button, or both).

OK.

4. Tap

Note When the Enable the “X” button to end running programs check box is not

selected, tapping the “X” button will only close a program screen. The program is not ended and continues to run in the background.

To reassign programs or shortcuts to program buttons

Your Ameo may come with programs already assigned to hardware buttons. You can customise these buttons to open the programs you use most, or to perform certain shortcuts such as changing the screen orientation, opening the Today screen, or opening Input Panel.

Start > Settings > Personal tab > Buttons.

1. Tap

2. A list of buttons and their current assignments are displayed on the

Program

Buttons tab.

3. Tap the button you want to reassign. To help you identify the buttons, there

are numbers and icons representing the original function of the button.

Assign a program box, tap the program or shortcut you want to assign.

4. In the

5. Tap

OK.

To increase or decrease the size of text on the screen

Start > Settings > System tab > Screen > Text Size tab.

1. Tap

2. Move the slider to increase or decrease the text size.

To choose how to be notified about events or actions

1. Tap

Start > Settings > Personal tab > Sounds & Notifications.

2. On the

Sounds tab, choose how you want to be notiﬁed by selecting the

appropriate check boxes.

3. On the

Notifications tab, in Event, tap an event name and choose how you want to be notiﬁed by selecting the appropriate check boxes. You can choose from several options, such as a special sound, a message, or a ﬂashing light.

Managing Y our Ameo

Tip Turning off sounds and the flashing light helps conserve battery power.

To find the operating system version number



Tap Start > Settings > System tab > About.

The version of the operating system on your Ameo is shown near the top of the About screen.

To get detailed device information



Tap Start > Settings > System tab > About.

The Version tab displays important device information, including the type of processor and the amount of memory that is installed.

To make the battery last longer



Tap the battery icon ( ) on the Today screen. On the Advanced tab of the Power settings screen, you can specify when your Ameo turns off the display to conserve battery power. For optimum conservation, specify 3 minutes or less.



Use the AC adapter to plug your Ameo into external power whenever possible, especially when using a miniSD card or when using a modem or other peripherals.



Adjust the backlight settings.

To adjust the brightness of the backlight

1. On the Today screen, tap

2. On the

Brightness tab, move the slider right to increase the brightness, or left

Start > Settings > System tab > Backlight.

to decrease the brightness.

To set the backlight to dim after a time delay

1. On the Today screen, tap

2. Tap the

3. Select the

Battery power tab, or the External power tab.

Turn off backlight if device is not used for check box, and

Start > Settings > System tab > Backlight.

specify the time delay.

Managing Y our Ameo

Phone settings

You can customise phone settings, such as the ring type and ring tone to be used for incoming calls, and the keypad tone to be used when entering phone numbers. Open the Phone program to customise these settings.

To change the ring tone

1. On the Phone screen, tap

2. In the

Ring tone list, tap the sound you want to use.

Tip To use custom *.wav, *.mid, *.mp3, or *.wma files as ring tones, use ActiveSync on

your PC to copy the files to the /Windows/Rings folder on your Ameo. Next, select the sound from the Ring tone list. For more information about copying files to your Ameo, see ActiveSync Help on your PC.

Menu > Options > Phone tab.

To change the ring type

You can change the way that you are notified of incoming calls.

1. On the Phone screen, tap

Menu > Options > Phone tab.

2. In the Ring type list, tap the desired option.

To change the keypad tone

You can change the tone you hear when entering a phone number on the keypad. If set to Long tones, the tone is heard continuously for as long as the number on the keypad is pressed. Use this setting if you are having trouble accomplishing tasks that rely on tones from your phone such as accessing messages from an answering machine. If set to Short tones, the tone is heard only for one or two seconds. If set to Off, no tone will be heard.

1. From the Phone keypad, tap Keypad list, tap the option you want.

2. In the

Menu > Options > Phone tab.

Managing Y our Ameo

Phone services

Phone services, such as Call Waiting, enable you to choose how to handle all incoming calls on your Ameo.

To choose the services

1. Tap

Start > Settings > Personal tab > Phone > Services tab.

2. Select the service you want to use, then tap Get Settings.

Networks

You can view available mobile phone networks, determine the order in which your Ameo accesses another network if the current one is unavailable, and specify whether you want to change networks manually or automatically. For more information about network settings, see Help on your Ameo.

To change phone network settings

1. Tap

Start > Settings > Personal tab > Phone > Network tab.

2. By default, your Ameo displays the current network as offered by your service

provider. You can customise to set your preferred network.

To set preferred networks

Start > Settings > Personal tab > Phone > Network tab. By default,

1. Tap

the Network selection ﬁeld is set to Automatic. However, you can set it to

Manual to choose your own network at any point of time.

Set Networks.

2. Tap

3. Select the networks on the Phone: Preferred networks screen and sort them

according to your preference.

4. Tap

OK.

Managing Y our Ameo

5.2 Adding and Removing Programs

Before you purchase additional programs for your Ameo, you should note the model name of your Ameo, the version of Windows Mobile software running on it, and the type of processor. This information will help you select a program that is compatible with your Ameo. For more information, see “To get detailed device information” and “To find the operating system version number” in this chapter. Programs available for purchase usually include a Setup program (commonly named "setup.exe") that you must first run on your PC. You can then use ActiveSync to add programs to your Ameo, or add a program directly from the Internet.

To add programs

1. Download the program to your PC (or insert the CD or disk that contains the

program into your PC). You may see a single *.exe ﬁle, a *.zip ﬁle, a Setup. exe ﬁle, or several versions of ﬁles for different device types and processors. Be sure to select a program designed for your Ameo.

2. Read any installation instructions or documentation that comes with the

program. Many programs provide special installation instructions.

3. Connect your Ameo to the PC.

4. Double-click the *.exe ﬁle.



If the executable file is an installation wizard, follow the instructions on the screen. The wizard will automatically install the program to your Ameo.



If an installation wizard does not start, you will see an error message stating that the program is valid but that it is designed for a different type of computer. You will need to copy this program directly to your Ameo. If you cannot find any installation instructions for the program, use ActiveSync to copy the program file to the Program Files folder on your Ameo.

To remove programs

You can only remove programs that you installed. Programs that come with your Ameo cannot be removed.

Start > Settings > System tab > Remove Programs.

1. Tap

Managing Y our Ameo

2. In the Programs in storage memory list, select the program you want to

remove, and tap Remove.

Yes. If another conﬁrmation message appears, tap Yes again.

3. Tap

5.3 Managing Memory

You may need to stop a program if it becomes unstable or the program memory is low.

To see how much memory is available



Tap Start > Settings > System tab > Memory.



On the Main tab, the amount of memory allocated to file and data storage versus program storage is displayed, as well as the amount of memory in use versus the available memory.

To see available storage card or Microdrive memory

You can see how much memory is available on the Microdrive or a miniSD card that is inserted in your Ameo.

Start > Settings > System tab > Memory.

1. Tap

2. Tap the Storage Card tab.

3. Tap the list box and then select the storage media whose information you

want to see.

Try the following to free memory on your Ameo:



Close programs you are not currently using.



Move e-mail attachments to a storage card.



Move files to a storage card. Tap Start > Programs > File Explorer. Tap and hold the file, and tap Cut. Browse to the storage card folder and tap Menu > Edit > Paste.



Delete unnecessary files. Tap Start > Programs > File Explorer. Tap and hold the file, and tap Delete.

Managing Y our Ameo



Delete large files. To find your largest files, tap Start > Programs > Search. In the Type list, tap Larger than 64 KB, and tap Search.



In Internet Explorer Mobile, delete temporary Internet files and clear history information. For more information, see “Internet Explorer Mobile” in Chapter 6.



Remove programs you no longer use.



Reset your Ameo.To close a program

Tapping the button in a program may just close the program screen. In this case, the program continues to run in the background. You can end running programs manually by following these steps:

1. Tap

Start > Settings > System tab > Memory > Running Programs tab.

2. In the

Running Programs List, tap the program you want to end, and tap

Stop.

Tips  In most programs, you can also use the keyboard shortcut CTRL+Q to close the

program.



You can configure the “X” button to directly shut down running programs. For more information, see “To configure the “X” button to shut down programs”.

Managing Y our Ameo

5.4 Copying Files

You can copy files to your PC using ActiveSync, or copy files to a storage card you insert into your Ameo. Your Ameo has an expansion slot for inserting a miniSD card. Using ActiveSync, you can copy or move information from the PC to your Ameo and vice versa. Copying a file results in separate versions of a file on your Ameo and PC. Because the files are not synchronised, changes made to one file will not affect the other.

Note If you want to automatically update information on both your Ameo and PC,

synchronise the information instead. For more information about copying and synchronising files, see ActiveSync Help on your PC.

To copy files to a storage card or Microdrive

1. Make sure a miniSD card is properly inserted into your Ameo.

2. Tap Start > Programs > File Explorer and navigate to the appropriate folder.

3. Tap and hold the ﬁle you want to copy, and tap

4. Tap the folder list (labeled

My Documents by default) and tap Storage Card

or Microdrive.

Menu > Edit > Paste.

5. Tap

To copy a file between your Ameo and the PC

1. Connect your Ameo to the PC.

2. In ActiveSync, click Explore, which opens the Mobile Device folder of your

Ameo.

3. To copy a ﬁle from your Ameo to your PC:

a. In the Mobile Device folder, go to the file that you want to copy. b. Right-click the file, then click Copy. c. Locate the destination folder on your PC. Right-click the folder, then click

Paste.

4. To copy a ﬁle from your PC to your Ameo:

a. On your PC, navigate to the folder that contains the file you want to copy. b. Right-click the file, then click Copy. c. Right-click the destination folder under Mobile Device, then click Paste.

Copy.

100

Managing Y our Ameo

To automatically save files on a storage card or Microdrive

In the Word Mobile or Notes programs, you may find it helpful to save all new documents, notes, and workbooks directly on a storage card.

1. From the program ﬁle list, tap Menu > Options or Menu > Tools > Options. Save to box, select the storage card or the Microdrive to automatically

2. In the

save new ﬁles on the storage card or Microdrive.

3. Tap

OK.

Note In the file or note list, a symbol is displayed next to the names of files saved on a

storage card/Microdrive.

5.5 Backing Up Data

Use Sprite Backup to back up data, which includes settings, files, contacts, and all other information, to a storage card or to a designated folder on your Ameo. This section describes the basics on how to install Sprite Backup and use it to back up and restore data on your Ameo. For more information about this program, see Help on your Ameo:

To install Sprite Backup

1. Make sure your Ameo is connected to your computer via a USB cable.

2. Install Sprite Backup on your Ameo from the PC using the Application

CD. Follow the on-screen instructions on your computer to complete the installation.

3. After the installation is completed, the Setup Wizard on your computer will

set up Sprite Backup on your Ameo. Follow the on-screen instructions to complete the setup.

HTC Athena Ameo User Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
