HTC Arrive Quick Start Guide

Download

1/20/11

Basics Guide

www.sprint.com

Tip: Looking for something? If you don’t see it in the headings

listed here, try the Index on page 122.

1. Device Basics . . . . . . . . . . . . . . . . . . . . . . . . 1

Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Turning Your Device On and Off . . . . . . . . . . . . . . 4

Hubs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

What Do the Icons on My Device Mean? . . . . . . 6

Battery and Charger . . . . . . . . . . . . . . . . . . . . . . . . 8

Displaying Your Phone Number . . . . . . . . . . . . . 10

Making and Answering Calls . . . . . . . . . . . . . . . . 11

Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

2. Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Personalization Settings . . . . . . . . . . . . . . . . . . . . 19

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Display Settings . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Location Settings . . . . . . . . . . . . . . . . . . . . . . . . . 22

Airplane Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

TTY Use With Sprint Service . . . . . . . . . . . . . . . 23

Security Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Email and Account Settings . . . . . . . . . . . . . . . . 27

Date & Time Settings . . . . . . . . . . . . . . . . . . . . . . 31

3. Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

About the People Hub . . . . . . . . . . . . . . . . . . . . . 32

Viewing Your Contacts and Their Feeds . . . . . . 32

Adding a New People Entry . . . . . . . . . . . . . . . . 33

Saving a Phone Number . . . . . . . . . . . . . . . . . . . 34

Viewing Contact Information . . . . . . . . . . . . . . . . 34

Merging Entries in People . . . . . . . . . . . . . . . . . . 35

Editing an Entry in People . . . . . . . . . . . . . . . . . . 36

Finding Entries in People . . . . . . . . . . . . . . . . . . . 38

Your Me Tile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

4. Calendar & Tools . . . . . . . . . . . . . . . . . . . 39

Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Microsoft Office Mobile 2010 . . . . . . . . . . . . . . . . 43

5. Voice Services . . . . . . . . . . . . . . . . . . . . . 45

Automatic Speech Recognition (ASR) . . . . . . . . 45

6. Camera & Multimedia . . . . . . . . . . . . . . . . 47

Taking Pictures and Capturing Videos . . . . . . . . 47

Viewing Pictures and Videos Using the 

Pictures Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50

Getting Your Media Files to Your Device 

Using Zune . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Using the Music + Videos Hub . . . . . . . . . . . . . . 52

7. Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Turning Bluetooth On and Off . . . . . . . . . . . . . . 55

Connecting a Bluetooth Headset or Car Kit . . 55

Disconnecting From a Bluetooth Device . . . . . 56

8. Sprint Service: The Basics . . . . . . . . . . . 57

Voicemail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

Text Messaging (SMS) and Multimedia 

Messaging (MMS) . . . . . . . . . . . . . . . . . . . . . . . . 59

Caller ID . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Call Waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63

Making a 3-Way Call . . . . . . . . . . . . . . . . . . . . . . 64

Call Forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . 64

9. Web and Data Services . . . . . . . . . . . . . 66

Ways of Connecting to the Internet . . . . . . . . . . 66

Connecting Using Wi-Fi . . . . . . . . . . . . . . . . . . . . 66

Getting Started With Data Services . . . . . . . . . . 68

Using Internet Explorer Mobile . . . . . . . . . . . . . . 69

Using Bing Search . . . . . . . . . . . . . . . . . . . . . . . . 73

Email . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74

Downloading Applications and Games 

From Marketplace . . . . . . . . . . . . . . . . . . . . . . . . . 80

HTC Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Weather . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Sprint Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

10. Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Signing Into Xbox LIVE . . . . . . . . . . . . . . . . . . . . . 85

Games Hub . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86

Downloading and Installing 

Xbox LIVE Extras . . . . . . . . . . . . . . . . . . . . . . . . . . 86

11. GPS Navigation . . . . . . . . . . . . . . . . . . . . . 87

GPS and Location Services . . . . . . . . . . . . . . . . . 87

TeleNav GPS Navigator . . . . . . . . . . . . . . . . . . . . 87

Bing Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

12. Important Safety Information . . . . . . . . . 92

Important Health Information and 

Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . 92

General Precautions . . . . . . . . . . . . . . . . . . . . . . . 99

Additional Safety Information . . . . . . . . . . . . . . 102

Regulatory Agency Identifications . . . . . . . . . . 108

Federal Communication Commission 

Interference Statement . . . . . . . . . . . . . . . . . . . . 109

SAR Information . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Telecommunications & Internet 

Association (TIA) Safety Information . . . . . . . . . 113

WEEE Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114

RoHS Compliance . . . . . . . . . . . . . . . . . . . . . . . . 115

Owner’s Record . . . . . . . . . . . . . . . . . . . . . . . . . . 115

Basics Guide Proprietary Notices . . . . . . . . . . . 116

13. Manufacturer’s Warranty . . . . . . . . . . . . 117

Manufacturer’s Warranty . . . . . . . . . . . . . . . . . . . 118

Privacy Restrictions . . . . . . . . . . . . . . . . . . . . . . 120

Weather Disclaimer . . . . . . . . . . . . . . . . . . . . . . 120

Warranty Disclaimer . . . . . . . . . . . . . . . . . . . . . . 120

Limitation of Damages . . . . . . . . . . . . . . . . . . . . . 121

Index. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Consejo: Para encontrar en guía para usuarios en español,

Important Privacy Message – Sprint’s policies often do not

apply to third-party applications. Third-party applications may access your personal information or require Sprint to disclose your customer information to the third-party application provider. To find out how a third-party application will collect, access, use, or disclose your personal information, check the application provider’s policies, which can usually be found on their website. If you aren’t comfortable with the third-party application’s policies, don’t use the application.

por favor visita a

Support > Devices.

To find a user guide in Spanish, please visit

www.sprint.com and click Support > Devices.

www.sprint.com y haz clic en

⽧ Your Device (page 2)

1. Device Basics

⽧ Turning Your Device On and Off (page 4)

⽧ Hubs (page 5)

⽧ What Do the Icons on My Device Mean? (page 6)

⽧ Battery and Charger (page 8)

⽧ Displaying Your Phone Number (page 10)

⽧ Making and Answering Calls (page 11)

⽧ Entering Text (page 15)

Your new HTC ArriveTM and Sprint can get you to everything you love easier and faster. With glance and go access through the Start screen and live tiles, you’ll be able to see your upcoming appointments, recent activity by contacts, new photos, and more. Use the information in this section to get to know your device better.

Tip: Device Software Upgrades – Updates to your device’s

software may become available from time to time. Each time you connect your device to your computer and start the Zune software, you’ll be notified of any new updates.

Device Basics

1. Device Basics 1

Your Device

3 4 5

Key Functions

1. Earpiece lets you hear the caller and automated

prompts.

2. Hardware keyboard slides out from the left side of

the device.

3. BACK ( ) takes you back one screen from where

you are. Your device remembers all the apps and websites you’ve visited since the last time your screen was locked.

Tip: Back works differently when you’re in Internet Explorer

Mobile. If you’re browsing the Web and press Back, you’ll return to the previous Web page you visited, rather than the previous app.

4. START ( ) takes you back to the Start screen. If

you press and hold , you’ll activate Automatic Speech Recognition (ASR).

5. Microphone allows other callers to hear you clearly

when you are speaking to them.

6. SEARCH () allows you to search information

anywhere on your device. If you press from the Start screen or in Internet Explorer, your device will search the Web. If you press in a Hub or

21. Device Basics

application, it will search the application. For

example, in People, it searches for contacts; in Maps, it lets you search for locations, addresses, or businesses.

7. CAMERA activates the camera to take still photos

or to capture video.

8. Touchscreen displays all the information needed to

operate your device. It lets you select, navigate, enter information, and control everything by touch.

9. Notification LED provides the device status or

notification information. It also acts as a proximity sensor and automatically deactivates the touchscreen when you hold the device near your face during a call. When activated, the proximity sensor does not affect the device’s 3G, 4G, or  Wi-Fi connection.

10. Charger/Accessory Jack allows you to connect the

device charger or the USB cable (included). CAUTION! Inserting an accessory into the incorrect jack may damage the device.

11. Volume Button allows you to adjust the ringer or

media volume or adjust the voice volume during a call.

Device Basics

1. Device Basics 3

12.

Camera Lens lets you take pictures and videos.

13. Speaker lets you hear the different ringers and

sounds. The speaker also lets you hear the caller’s voice in speakerphone mode.

14 . Flash helps illuminate subjects in low-light

environments when the camera is focusing and capturing a photo or video.

15. 3.5 mm Headset Jack allows you to plug in the

included stereo headset or an optional headset for convenient, hands-free conversations. CAUTION! Inserting an accessory into the incorrect jack may damage the device.

16. Power Button lets you turn the device or screen on

or off.

41. Device Basics

Turning Your Device On and Off

Turning Your Device On

䊳 Press at the top of the device.

Turning Your Device Off

䊳 Press and hold for about two seconds.

Note: When the screen is locked and you press , it will

only turn off the screen and not the device. You will need to unlock the screen first before you press and hold to turn the device off. See “Turning the Screen Off When Not in Use (Sleep Mode)” for details.

Turning the Screen Off When Not in Use (Sleep Mode)

To save battery power, the device automatically turns off the screen after a certain period of time when you leave it idle. You will still be able to receive messages and calls while the device’s screen is off.

You can also turn off and lock the screen by pressing

. Pressing again or receiving an

incoming call will turn on your device screen and show the lock screen.

To unlock the screen:

䊳 Touch the wallpaper anywhere and slide your

finger towards the top of the device.

Note: If you have set up a screen lock password, you will be

prompted to enter it. For more information on how to create and enable a screen lock, see “Protecting Your Device With a Password” on page 24.

Hubs

Simplify your everyday tasks with Hubs. Instead of going in and out of various apps, Hubs automatically tie together related experiences. For example, in the People Hub, not only can you see all your contacts, but you can also check status updates from your Facebook friends. Check out the other cool Hubs on your device such as Office, Pictures, Music + Videos, and more.

Device Basics

1. Device Basics 5

What Do the Icons on My Device Mean?

Status Bar

Airplane mode is turned on

You can tell a lot about your device by checking the icons in its status bar.

Simply tap the top of the screen to show the status icons. The status icons disappear after a few seconds.

Here are some of the icons you might see and what they mean:

Status Bar

Signal strength

Battery is charging

Battery is full

Battery state unknown

61. Device Basics

Roaming

Calls are being forwarded based on the network settings

3G data service

1xRTT data service

Wi-Fi enabled but not connected to a Wi-Fi network

Connected to a Wi-Fi network

Connected to a Bluetooth headset

Ringer set to vibrate

Ringer set to silent

Tip: always displays connection status, not signal strength.

To find out how to view Wi-Fi network signal strength, see “Turning Wi-Fi On and Connecting to a Wireless Network” on page 66.

Notification LED

The Notification LED located at the right end of the earpiece provides information on the device status or pending notifications.

LED Status Indication

Solid green Battery is fully charged (when the

Solid red Battery is charging.

Flashing red Battery is low. (Battery power is below

Flashing green You have a pending notification (for

device is connected to the AC adapter or a computer).

14% .)

example, a new message or a missed call).

Note: The indicators are listed in order of priority. For

example, if your device is connected to a power adapter and is charging the battery, the LED will be solid red and will not switch to a flashing green light even if there is a pending notification.

1. Device Basics 7

Device Basics

Battery and Charger

WARNING: Use only Sprint-approved or HTC-approved

Sprint-approved or HTC-approved batteries and accessories can be found at Sprint Stores or through HTC; or call available at

About the Battery

Your device uses a rechargable battery. How long the battery lasts before it needs recharging depends on how you use your device, including the device features and accessories you use. For example, always leaving your Bluetooth connection on, long phone calls, and frequent Web browsing all use more power. Poor signal strength from your mobile network and extreme temperatures can also drain your battery quickly.

81. Device Basics

batteries and chargers with your device. The failure to use an Sprint-approved or  HTC-approved battery and charger may increase the risk that your device will overheat, catch fire, or explode, resulting in serious bodily injury, death, or property damage.

1-866-866-7509 to order. They’re also

www.sprint.com.

Battery Capacity

Your device is equipped with a rechargeable battery. The battery provides up to 6 hours of continuous talk time.

Note: Long backlight settings, searching for service, vibrate

mode, browser use, and other variables may reduce the battery’s talk and standby times.

Tip: Watch your device’s battery level indicator and charge

the battery before it runs out of power.

Removing the Battery

1. Make sure the power is off so that you don’t lose

any stored numbers or messages.

2. Remove the battery compartment cover.

䡲 With your device turned off, hold your device

securely with the front facing down.

䡲 Slide the back of the device to the right.

䡲 With your thumb or finger, lift up the back cover

from the small notch at the side of the device.

3. Lift the battery out at the notch at the lower left

edge of the battery compartment.

WARNING: Do not handle a damaged or leaking Li-Ion

battery as you can be burned.

Charging the Battery

Keeping track of your battery’s charge is important. If your battery level becomes too low, your device automatically turns off, and you will lose any information you were just working on.

1. Device Basics 9

Device Basics

Always use a Sprint-approved or HTC-approved desktop charger, travel charger, or vehicle power adapter to charge your battery.

Tip: With the Sprint-approved Li-ion battery, you can recharge

the battery before it becomes completely run down.

1. Insert the small end of the USB cord into the

charger/accessory jack on the lower left side of your device.

2. Insert the larger end of the USB cord into the AC

adapter.

3. Plug the AC adapter in to an electrical outlet to

start charging the battery.

While the battery is charging, you will see a solid red Notification LED. If the device is on and not in sleep mode, you will also see the charging battery icon ( ). Once fully charged, you will see a solid green Notification LED and a full battery icon ( ) in the status bar.

10 1. D evice Basic s

Displaying Your Phone Number

䊳 Ta p Phone on the Start screen, tap , and

then tap

call settings. You’ll see the following

information:

Setting Description

My phone number

Voicemail number

International assist

Long tones

Displays your phone number

Shows the current voicemail service being used. Tap to change the voicemail number.

Turn international assist on or off.

Turn long tones on or off.

Making and Answering Calls

Making Calls

There are several convenient methods to make a call from your device.

Calling Using the Phone Dialer

You can dial a number directly in the Phone’s dialer.

1. Press and then tap to open the Phone

application.

2. Tap to display the dialpad.

3. Dial the number you want and then tap call.

Calling a Number From People

1. Press and then tap People.

2. Ta p call [number type] to place the call (for

example, tap number).

call mobile to call the contact’s mobile

Calling a Number in a Text Message

You can quickly call a number in the body of a text message, or place a call to the sender.

1. Press , and then tap Messaging.

2. Tap a conversation to view messages.

3. Tap a number to place a call.

䡲 To call a number in the message, tap it and then

tap

call number.

䡲 To place a call to the sender, tap the number next

to “Call back at” and then tap

call.

Calling a Number in an Email Message

1. Press , tap Email, and then tap a message to

view it.

2. Tap a phone number in the message and then tap

call number. Available phone numbers will be

underlined.

1. Device Basics 11

Device Basics

Receiving Calls

When you receive a phone call from a contact, the incoming call screen appears and displays the caller ID icon, name, and phone number of the calling party. When you receive a phone call from someone who is not stored in People, only the default caller ID icon and phone number appear on the incoming call screen.

Note: If your device is turned off, all calls automatically go to

voicemail.

Answering an Incoming Call

䢇 If the display is on, tap answer. 䢇 If the display is off, when the lock screen appears,

slide up from the bottom of the lock screen, and then tap

answer.

Muting the Ringer

To mute the ringer without rejecting the call, you can do any of the following:

䢇 Press the volume button up or down. 䢇 Press . 䢇 Place the device face down on a level surface.

12 1. Device Basics

Note: If your device is already facing down, the device will still

ring when there are subsequent incoming calls.

Rejecting an Incoming Call

䢇 If the display is on, tap ignore. 䢇 When the lock screen appears, slide up from the

bottom of the lock screen, and then tap

ignore.

Ending a Call

䊳 Ta p end call.

Missed Call Notification

When you do not answer an incoming call, you will see the missed call icon with the number of missed calls on the lock screen.

You will also see the number of missed calls on the Phone tile.

Calling Emergency Numbers

You can place calls to 911 without entering the device password (if one has been set) or if your account is restricted.

To call the 911 emergency number when the device’s screen is locked with a screen lock:

1. On the enter your password screen, tap emergency

call.

2. Tap , and then tap call.

To call the 911 emergency number normally or when your account is restricted:

1. If the screen is locked, touch the wallpaper and

slide it upward to unlock the screen.

2. Press and tap to open the Phone

application.

3. Tap , tap , and then tap call.

4. Tap end call to hang up.

Enhanced 911 (E911) Information

This device features an embedded Global Positioning System (GPS) chip necessary for utilizing E911 emergency location services where available.

When you place an emergency 911 call, the GPS feature of your device seeks information to calculate your approximate location. Depending on several variables, including availability and access to satellite signals, it may take up to 30 seconds or more to determine and report your approximate location.

Important: Always report your location to the 911 operator

when placing an emergency call.

designated emergency call takers, known as Public Safety Answering Points (PSAPs), may not be equipped to receive GPS location information from your device.

Some

1. Device Basics 13

Device Basics

In-Call Options

When a call is in progress, use the onscreen buttons to mute or unmute the microphone or to turn the speakerphone on or off. You can choose whether to add a call, place the call on hold, and more.

Switching Between Calls

If you’re already on a call and accept another call, you can choose to switch between the two calls.

1. When you receive another call, tap answer to

accept the second call, and to put the first call on hold.

2. To switch between the calls, tap the bar at the top

of the screen.

3. To end the current call and return to the other call,

tap

end call.

14 1. D evi ce Bas ics

Turning the Speakerphone On or Off During a Call

1. Ta p .

2. Tap speaker. Tap speaker again to turn off the

speakerphone.

WARNING: Make sure you don’t have the device against

your ear when you have the speakerphone on. It may damage your hearing.

Muting the Microphone During a Call

1. Ta p .

2. Tap mute. Tap mute again to turn on the

microphone.

Ending a Call

䊳 On the screen, tap end call.

Tip: If the phone display is off, press to turn on the

screen so you can tap end call.

Entering Text

Using the Slideout Hardware Keyboard

Your device comes with a hardware QWERTY keyboard, which is similar to a standard keyboard on a computer. To use the keyboard, slide the screen panel to the right to reveal the keyboard. The screen panel will pop up at an angle for comfortable viewing.

In most applications, the screen orientation automatically switches to landscape mode when the keyboard is opened. Certain applications and Hubs, such as the Start screen, the main People Hub, and the applications list, will remain in portrait mode.

Important: The screen angle is non-adjustable. Do not try to

adjust the screen past its maximum angle. Doing so will damage the device.

Entering Text

You can do the following with the hardware keyboard:

䢇 To type numbers and lowercase letters, press the

keys using your thumbs or fingers.

䢇 Press the following keys to enter uppercase letters,

special characters, or symbols:

䡲 Shift key ()

● Press once to capitalize the next letter you

select.

● Press and hold to lock the key and type a

series of uppercase letters (this works just like the Caps Lock key on your computer keyboard). Press it again to unlock the key.

1. Device Basics 15

Device Basics

䡲 Function key ()

● To enter the symbol or punctuation mark that

is shown at the upper right corner of a key, press , and then press the corresponding key.

● Press and hold to lock the key and type a

series of special characters. Press it again to unlock the key.

䡲 To open the Symbol Pad, press ( ). This allows

you to enter symbols and numbers using the onscreen keyboard.

䡲 Press ( ) to insert a hard return when typing. 䡲 Press the arrow keys ( , , , or ) for

directional movement.

䡲 To delete the previous character, press ( ).

Press and hold to continue deleting.

䡲 Press ( ) and then tap an icon to insert a

smiley.

䡲 For special characters, press a letter and then

press ( ) to select the character from the onscreen menu. For example, press “a” and then

16 1. Device Basics

press ( ) and then tap an option to enter æ, à, and more.

Using the Onscreen Keyboard

When you start an application or select a box that requires you to enter text or numbers, you will see the onscreen keyboard.

Changing to Landscape Orientation

When entering text, you can choose to use the landscape orientation of the onscreen keyboard by turning the device sideways. This pops up a larger keyboard that lets you type easily using two thumbs

Note: The landscape orientation keyboard is not supported in

all applications.

Entering Text

To enter text using the onscreen keyboard, tap the letters or numbers you want to enter.

After entering your text, press to close the keyboard. To open and use it again, tap a text box.

Depending on the app you’re in, you might see a slightly different keyboard layout. Use the following keys while entering text:

Shift key. Tap to capitalize the next letter you

enter. Press and hold or tap twice to turn on caps lock.

Numeric key. Tap to switch to the numeric and

symbol keyboard.

More key. While in the numeric and symbol

keyboard, tap to show more symbols.

Alphabet key. Tap to switch to the alphabetic

keyboard.

Language key. Tap to switch to a different

language keyboard. Available keyboard languages depend on the phone version you have. This key may not be show on devices with only one keyboard language.

Enter key. Tap to create a new line.

Backspace key. Tap to delete the previous

character. Press and hold to delete multiple characters.

Smiley key. Tap to enter smileys. (Only available

when writing a text or picture message).

Tip: To quickly add a period, tap Space twice.

Note: To enter accented or special characters such as æ or

à, tap and hold the associated letter key to display a list of options, and then tap the desired symbol.

1. Device Basics 17

Device Basics

Moving the Cursor

1. While entering text, press and hold the text box. A

floating cursor appears.

2. Drag the cursor to the position that you want, and

then release your finger.

Predictive Text

The keyboard has predictive text to help you type quickly and accurately. Predictive text input is enabled by default, and word suggestions are displayed as you type.

To enter a word in predictive mode, do any of the following:

䢇 If you see the word you want in bold, you can simply

tap the space bar to insert the word into your text.

䢇 If you see the word you want shown in the

suggestions before you have finished typing the entire word, tap the word to insert it into your text.

䢇 Slide left on the suggestion bar to see more words.

18 1. Device Basics

Changing Predictive Text Settings

You can choose whether to allow text suggestions, correct misspelled words, insert a space after selecting a suggestion, reset text suggestions, and more.

1. Press and tap .

2. Tap Settings > keyboard.

3. Select or clear any of the check boxes you want to

change.

Tip: To remove all the words you’ve added to your suggestion

list, flick up and tap reset text suggestions.

⽧ Personalization Settings (page 19)

2. Settings

⽧ Sound Settings (page 20)

⽧ Display Settings (page 22)

⽧ Location Settings (page 22)

⽧ Airplane Mode (page 23)

⽧ TTY Use With Sprint Service (page 23)

⽧ Security Settings (page 24)

⽧ Email and Account Settings (page 27)

⽧ Date & Time Settings (page 31)

Personalization Settings

Changing Your Theme

Feeling a little blue? You can change the theme of your phone to match your mood for the day.

1. Press and tap .

2. Ta p Settings > theme.

3. Select the Background and Accent color to fit your

mood by tapping their respective boxes.

Changing Your Lock Screen Wallpaper

Browse the collection of wallpapers available on your device or choose from photos that you have taken with the camera.

1. Press and tap .

2. Ta p Settings > lock & wallpaper > change wallpaper.

3. Choose whether to select from Wallpapers, Camera

Roll, or any other stored photo album.

4. Select the photo you want to use as your lock

screen wallpaper.

Settings

2. Settings 19

If the photo you selected is bigger than the allowable wallpaper size, crop the photo first. Drag the photo and position the part that you want to be your wallpaper inside the crop box, and then  tap .

Sound Settings

Phone Ring Tone

Select a default ring tone for incoming calls.

Selecting the Default Ring Tone

Your device provides a variety of ring tones that you can set as the default ring tone of your device.

1. Press and tap .

2. Tap Settings > ringtones & sounds.

3. Tap th e Ringtone box.

4. Listen to a ringtone by tapping the play icon

beside its name.

5. Tap the name of the ringtone that you want to use.

20 2. Settings

Notification Sound

You can choose a sound that you want for notifications of new text messages, voicemail, email, and more.

Selecting the Default Notification Sound

Your device provides a variety of sounds that you can set as the default sound for notifications.

1. Press and tap .

2. Tap Settings > ringtones & sounds.

3. Tap the box of the notification you want to change

(

New text message, New voicemail, or New email),

and then choose the sound to use for that notification.

Adjusting the Device’s Volume Settings

Adjust your device’s volume settings to suit your needs and your environment.

Press the VOLUME UP or VOLUME DOWN button to adjust the volume to your desired level. The volume bar

appears on top of the screen and shows the volume level.

You can adjust the ringer volume in standby mode (or the earpiece volume during a call) by pressing the volume button up or down.

On the volume bar, tap the icon on the right to quickly switch to ring or vibrate. If you want to have silent as an option, you need to turn off vibrate on your phone.

Vibrate

To set your device to vibrate instead of making any sounds:

1. Press and tap .

2. Ta p Settings > ringtones & sounds.

3. Tap the Vibrate On/Off switch on the right to turn

vibrate off and on.

With vibrate on, your device will go to vibrate mode when you lower the sound volume down to zero. When vibrate is off, the phone will go into silent mode when you set the volume to zero.

Silence All

The Silence All option allows you to mute all sounds without turning your device off.

To activate Silence All:

䊳 Press the VOLUME DOWN button in standby mode

until the volume bar shows that the sound volume is zero. If your device is set to vibrate, it will still vibrate in Silence All mode.

To deactivate Silence All:

䊳 Press the volume button up repeatedly to select a

volume level.

Controlling Keypress Sound

You can set the device to play a sound when you are using the phone keypad or tapping the screen.

1. Press and tap .

2. Ta p Settings > ringtones & sounds.

3. Tap the Play a sound for Key press check box to

select or clear it.

2. Settings 21

Settings

Display Settings

Changing the Screen Timeout Period

After a period of inactivity, the device screen turns off to conserve battery power. You can set the idle time before the screen turns off.

1. Press and tap .

2. Tap Settings > lock & wallpaper.

3. Tap th e Screen time-out box, and then select the

time before the screen turns off.

Tip: To turn off and lock the screen quickly, press .

Adjusting the Brightness

By default, the screen brightness automatically adjusts depending on the surrounding lighting conditions.

To manually adjust screen brightness:

1. Press and tap .

2. Tap Settings > brightness.

22 2. Settings

3. Tap th e Automatically adjust On/Off switch to turn it

off.

4. Select the Level to use.

Location Settings

Your device is equipped with a Location feature for use in connection with location-based services.

The Location feature allows the network to detect your position. Turning Location off will hide your location from everyone except 911.

Note: With Location activated on the device, the network to

detect your position using GPS technology, making some Sprint applications and services easier to use. Tur ni ng Location off will disable the GPS location function for all purposes except 911, but will not hide your general location based on the cell site serving your call. No application or service may use your location without your request or permission.  GPS-enhanced 911 is not available in all areas.

To disable your device’s Location setting feature:

1. Press and tap .

2. Ta p Settings > location.

3. Tap the Location services On/Off switch to turn 

it off.

3. Tap the Status On/Off switch to turn it on or off.

Tip: When you disable airplane mode, the call function is

turned back on and the previous state of Bluetooth and Wi-Fi is restored.

TTY Use With Sprint Service

Airplane Mode

Airplane Mode allows you to use many of your device’s features, including the Pictures Hub, Camera, and Music + Videos, when you are on an airplane or in any other area where making or receiving calls or data is prohibited. When you set your device to Airplane Mode, all wireless radios on your device are turned off, including the call function, data services, Bluetooth, and Wi-Fi.

Note: While Airplane mode is enabled, it is still possible to

turn Bluetooth and Wi-Fi on and off through Settings.

To turn Airplane Mode on or off in Settings:

1. Press and tap .

2. Ta p Settings > airplane mode.

A TTY (also known as a TDD or Text Telephone) is a telecommunications device that allows people who are deaf, hard of hearing, or who have speech or language disabilities to communicate by telephone.

Your device is compatible with select TTY devices. Please check with the manufacturer of your TTY device to ensure that it is compatible with digital cell phones. Your HTC Arrive and TTY device will connect via a special cable that plugs into your device's headset jack. If this cable was not provided with your TTY device, contact your TTY device manufacturer to purchase the connector cable.

To turn TTY Mode on or off:

1. Press and tap .

2. Ta p Settings > ease of access.

2. Settings 23

Settings

Select the desired TTY/TDD mode by choosing one of the options.

Note: When enabled, TTY mode may impair the audio

quality of non-TTY devices connected to the headset jack.

To access the state Telecommunications Relay Service (TRS) for assistance with TTY calls:

1. Press and tap > .

2. Tap , ta p call, and then tap to

reach an operator.

WARNING: 911 Emergency Calling

Sprint recommends that TTY users make emergency calls by other means, including Telecommunications Relay Services (TRS), analog cellular, and landline communications. Wireless TTY calls to 911 may be corrupted when received by public safety answering points (PSAPs), rendering some communications unintelligible. The problem encountered appears related to TTY equipment or software used by PSAPs. This matter has been brought to the attention of the FCC, and the wireless industry and the PSAP community are currently working to resolve this.

24 2. Settings

For additional information about Sprint Relay Services and TTY compatability, call Sprint Relay Customer Service at 800-676-3777 or visit

www.sprintrelay.com.

Security Settings

Protecting Your Device With a Password

You can secure your device by requiring a password every time your device is turned on or every time it wakes up from sleep mode (screen is off).

To create and enable the screen unlock password:

1. Press and tap .

2. Tap Settings > lock & wallpaper.

3. Tap th e Password On/Off switch.

4. Enter the 4-digit numeric password in both the

New password and Confirm password boxes.

5. Tap done.

To disable the screen lock:

1. Press and tap .

2. Tap Settings > lock & wallpaper.

3. Tap the Password On/Off switch.

4. Enter your password.

If you fail to enter the correct password after five attempts, you will be prompted to wait for one minute before you can try again.

Protecting Your Device Through the Web

It’s a nightmare when you lose your device, especially if there’s sensitive information on it. Now, by going to

www.windowsphone.live.com on your computer, you can

find your device’s location, lock it, make it ring, and even erase the contents on your device through a Web browser.

To set up device protection:

1. Press and tap .

2. Ta p Settings > find my phone.

3. Tap the Find My Phone options you wish to use.

4. Sign in to your Windows Live account, or create

one if you do not yet have one associated with your device.

Important: In order to find and control your device from your

Note: Make sure to sign in to Windows Live on your

computer’s Web browser, your device must be connected to the Internet through a Wi-Fi or data connection.

computer using the same Windows Live ID you used on the device.

Updating Your Device’s System Software

From time to time, system software updates for your device may be available. Your device will automatically check and notify you if an update is available. You can download and install the update to your device using the Zune software.

Depending on the type of update, the update may erase all your personal data and customized settings, and it could also remove any programs you have installed. Make sure that you have used the Zune software to synchronize the information and files you want to keep. See “Getting Your Media Files to Your Device Using Zune” on page 52 for more information.

Note: Checking and downloading system software updates

may incur additional data transfer fees.

2. Settings 25

Settings

To check for phone system software updates:

1. Press and tap .

2. Tap Settings > phone update.

3. If an update is available and you want to learn

more and install it on your device, connect your device to your computer using the USB cable that came with your device.

4. On your computer, run the Zune software if it

doesn’t start automatically.

5. In the Zune software, select Settings > Phone >

Update.

Note: If you have not installed the Zune software on your

computer, you’ll be prompted to download and install it before you can check for software updates for your device.

26 2. Settings

Resetting Your Device

Resetting the device deletes all data, including downloaded applications, and resets the device back to its initial state — the state before you turned on the device for the first time.

Important: Make sure to back up important data you have

To reset the device using Settings:

1. Press and tap .

2. Tap Settings > about.

3. Tap reset your phone, tap yes, and then tap yes

To reset the device using the device keys:

1. With the device turned off, press and hold the

2. Wait for the screen to show the instructions on how

3. Follow the insructions on the screen to reset your

on the device before you reset it.

again.

VOLUME UP and DOWN buttons, and then briefly press .

to do the factory reset, and then release the volume button.

device.

Security Features for Data Services

Enabling and Disabling Data Services

You can disable data services without turning off your device; however, you will not have access to all data services, including Web and messaging. Disabling data services will avoid any charges associated with these services. While signed out, you can still place or receive phone calls, check voicemail, and use other voice services. You may enable data services again at any time.

To enable or disable data services:

1. Press and tap .

2. Ta p Settings > cellular.

3. Tap the Data connection On/Off switch.

Email and Account Settings

Setting Up Your Accounts

Set up your Windows Live, Google, Microsoft Outlook, Facebook, and other accounts so you can sync information and receive updates from these accounts on your device.

Note: You may have signed in to your Windows Live account

when you initially configured your device.

1. Press and tap .

2. Ta p Settings > email & accounts.

3. Tap add an account, and then tap the type of

account you want to set up.

4. Enter your email address and password, and then

tap

Manually Synchronizing Your Accounts

1. Press and tap .

2. Ta p Settings > email & accounts.

2. Settings 27

Settings

Press and hold the account you want to synchronize and then tap

Note: You can also tap from an account page (for

example, the Hotmail inbox) to sync an account.

sync.

Deleting an Account

1. Press and tap .

2. Tap Settings > email & accounts.

3. Press and hold an account name and then tap

delete.

What You Can Do With Your Windows Live Account

Using Windows Live on your device lets you access the things you care about anywhere you are and on any computer or your device. When you sign in to your device with a Windows Live ID, your pictures, contacts, OneNote notes, calendar, and email will be synchronized:

䢇 on your device 䢇 on your PC

28 2. Settings

䢇 on the Web (using any computer with an Internet

connection)

After you sign in, you can quickly capture things while you’re away from your computer and then share, organize, edit, or archive them for later. Items you might access this way include pictures, notes, appointments, contacts, grocery lists, story ideas, quotes, and other things to remember.

Note: If you already have an Xbox LIVE or Zune account,

you’ll get more from your device if you sign in using one of those accounts.

The first Windows Live ID that is used to sign in to your device cannot be deleted without performing a factory rese t.

Features of Windows Live

Here’s an overview of the things you can do when you connect with Windows Live.

䢇 Share pictures on SkyDrive

You can share your pictures by posting them on Windows Live, by manually selecting the photos you’d like to share, or by automatically sharing all

new pictures that you take. Then you can edit and organize them using Windows Live Photo Gallery.

Note: If you set up more than one Windows Live account on

your device, photos in those additional accounts will not be sychronized with your device.

䢇 Keep track of your device with Find My Phone

As soon as you sign in to your device using your Windows Live ID, you’ll be signed up for Find My Phone. If you lose your phone, you can go to the Find My Phone website (

www.windowsphone.live.com)

from your computer to ring your device, lock the screen and display a message, erase sensitive data on the device, or find the device on a map.

䢇 Use OneNote to capture your thoughts

If you use OneNote already, you can sync your notebooks to your device and edit them on the go, with the changes you make immediately visible on your PC or any other computer with a Web connection.

If you haven’t used OneNote before, you can use it to take notes, keep track of lists (like grocery lists), or even write longer passages of text (like a poem or

letter). You can add pictures and voice notes to your OneNote notebooks.

䢇 Schedule your life with Windows Live calendar

When you sign in to your device using your Windows Live ID, you get a free, full-featured calendar. Add appointments, meetings, tasks, dates, or plans to your Windows Live calendar and then you can see them from your device and any computer that can access the Web.

䢇 Back up your contacts

When you add a new contact to your device, you can also add it to your Windows Live account.

Your Google Account and Exchange ActiveSync

Synchronize your device with your Google Account so you can access your Gmail as well as your Google contacts and calendar appointments right on your device.

Note: You need to be signed in to your Google account to

synchronize Google Apps.

2. Settings 29

Settings

You can also synchronize your device with your company’s Microsoft Exchange Server to access your Exchange Server account’s email, contacts, and calendar appointments.

Note: You need to have an Exchange ActiveSync account

set up on your device. See “Adding Your Exchange ActiveSync Account” on page 75.

To select which items to synchronize:

1. Press and tap .

2. Tap Settings > email & accounts.

3. Tap Google to choose the synchronization settings

for your Google account or tap

Outlook to choose

settings for your Exchange ActiveSync account.

4. Tap th e Download new content box to choose how

often you want your device to download new email messsages.

5. Tap th e Download email from box to choose the

time range of email messsages to download.

30 2. Settings

6. Under Contents to sync, choose the items (email,

contacts, or calendar) that you want to synchronize or remove from your device.

7. Tap to apply your selected settings.

To stop synchronization:

䊳 When the device is synchronizing, press to stop

synchronization.

Your Facebook Account

If you set up a Facebook account when you first turned on your device, you can quickly log in and synchronize information such as status messages and friends lists between your device and your Facebook account on the Web.

Note: You need to have an existing Facebook account to

access it from your device.

Logging in to Your Facebook Account

If you previously skipped the sign-in process, follow the steps below to log in to your Facebook account.

1. Press and tap .

2. Ta p Settings > email & accounts > add an account >

Facebook.

3. Enter the email address and password that you

use for signing in to Facebook.

4. Tap sign in.

Date & Time Settings

3. Tap the Set automatically On/Off switch to turn off

automatic date and time setting.

4. Select values for Time zone, Time, and Date.

Note: You can also choose to display the time in a 24-hour

format by tapping the

24-hour clock On/Off switch.

Setting Local Date, Time Zone, and Time

By default, your device automatically uses the  network-provided date, time zone, and time. However, you can set the date, time zone, and time manually if you need to.

1. Press and tap .

2. Ta p Settings > date & time.

Settings

2. Settings 31

⽧ About the People Hub (page 32)

3. Contacts

⽧ Viewing Your Contacts and Their Feeds (page 32)

⽧ Adding a New People Entry (page 33)

⽧ Saving a Phone Number (page 34)

⽧ Viewing Contact Information (page 34)

⽧ Merging Entries in People (page 35)

⽧ Editing an Entry in People (page 36)

⽧ Finding Entries in People (page 38)

⽧ Your Me Tile (page 38)

32 3. Contacts

About the People Hub

When you set up your email and other accounts on your device, your contacts are imported automatically into your People Hub. You’ll be able to see contacts from your Windows Live, Facebook, and other email accounts like Gmail and Outlook (Microsoft Exchange ActiveSync).

Viewing Your Contacts and Their Feeds

If you set up your device to synchronize with any of your Windows Live, Gmail, Facebook, and Exchane ActiveSync accounts, you will see all your contacts from these accounts in your People Hub. To find out how to set up your device to synchronize with these accounts, see “Setting Up Your Accounts” on page 27.

From People, you can choose to communicate with your contacts through phone, messaging, and email. You can also view their Windows Live and Facebook feeds.

To open the People Hub:

䊳 On the Start screen, tap People.

all of the People Hub, you’ll see all contacts that

In you’ve created on your device as well as contacts that are synchronized with your email and Facebook accounts.

If you’re signed in to your Windows Live and/or Facebook accounts, swipe to the left to see updates from your friends.

Adding a New People Entry

1. On the Start screen, tap People.

2. In all of the People Hub, tap .

3. Select the Account, for example, Windows Live. This

determines which account the contact will sync with.

4. Enter information by tapping an item.

5. Tap when you’re done.

Tip: ICE - In Case of Emergency

To make it easier for emergency personnel to identify important contacts, you can list your local emergency contacts under “ICE” in your phone’s Contacts list. For example, if your mother is your primary emergency contact, list her as “ICE-Mom” in your Contacts. To list more than one emergency contact, use “ICE1-___,” “ICE2-___,” etc.

3. Contacts 33

Contacts

Saving a Phone Number

Viewing Contact Information

Your device stores contact entries in the People Hub and automatically sorts People entries alphabetically.

To save a phone number:

1. Press and tap to open the Phone

application.

2. Tap to display the dialpad and then enter the

phone number by tapping the keys on the keypad.

3. Tap save. (This button appears after tapping one

digit.)

4. Tap search or new contact. Tap .

5. Tap name and then use the keyboard to enter the

new contact name. When finished, tap , and then tap to save the new entry.

– or –

Tap an existing contact name, tap , and then tap

to save the new number.

34 3. Contacts

When you tap a contact on the People Hub, the profile screen opens, showing you the person’s contact details. You can call, send a text message, or send an email to the contact from the profile screen.

Slide your finger left to see what’s new with that contact. You’ll only see updates when you are signed in to your Windows Live and/or Facebook accounts and the person is also your friend in Windows Live and/or Facebook.

Merging Entries in People

Merge duplicated entries in People to avoid clutter and confusion. If the same contact appears in your Phone Hub, Gmail, and Facebook accounts, you can merge the contact information into one entry.

The device automatically merges entries that it finds to have similar data. If you need to manually merge entries or break the link between entries, follow the procedures below.

3. At the bottom of the screen, tap . The link icon

may look a little different if the contact is already linked to other contacts.

4. Do one of the following:

䡲 Under suggested links (if available), tap the

contact to link to that contact’s account.

– or –

䡲 Ta p choose a contact to select a contact to link to

from your People list.

Contacts

Manually Merging Entries in People

If you have the same contacts stored in your phone and online accounts such as Windows Live and Facebook, your phone will try to link them as one automatically. If it doesn’t, you can manually link them so that you won’t have duplicated entries in your contacts list.

1. On the Start screen, tap People.

2. In all of the People Hub, tap the name of the

contact you want to link.

Unlinking Entries

1. On the Start screen, tap People.

2. In all of the People Hub, tap the name of the

contact whose contact information link you want to break.

3. Tap at the bottom of the entry, tap the profile

you want to unlink, and then tap

unlink.

3. Contacts 35

Editing an Entry in People

Changes that you make to entries in the People Hub will be synchronized with their associated accounts.

Displaying an Entry in People

1. On the Start screen, tap People.

2. In all of the People Hub, tap the name of the

contact you want to view.

Adding a Number or an Email Address to an Entry in People

1. Display an entry in People. (See “Displaying an

Entry in People” for details.)

2. Scroll down the screen and tap .

3. Tap nex t to phone or email and enter the new

number or address.

4. Tap to save the changes.

36 3. Contacts

Editing an Entry in People

1. Display an entry in People. (See “Displaying an

Entry in People” on page 36 for details.)

2. Scroll down the screen and tap .

3. Tap the information you want to edit.

4. Edit the information using the keypad.

5. Tap to save the changes.

Selecting a Ringer Type for an Entry

Assign a ringer type to an entry in People so you can identify the caller by the ringer type. See “Sound Settings” on page 20.

1. Display an entry in People. (See “Displaying an

Entry in People” on page 36 for details.)

2. Scroll down the screen and tap ringtone.

3. Select a ring tone from the list by tapping it.

4. Tap to save the changes.

Assigning a Picture to an Entry

Assign a picture to display when a specified contact calls you.

1. Display an entry in People. (See “Displaying an

Entry in People” on page 36 for details.)

2. Scroll down the screen and tap .

3. Tap the picture at the top-left corner of the screen.

If no picture is assigned, you will see the box.

4. Tap a photo or an album, or tap to use your

device’s camera to take a new picture.

䡲 If you selected an album or a photo, crop the

selected picture if needed, tap tap .

– or –

䡲 If you selected the camera, take the picture, crop if

necessary, and then tap .

add photo in

crop , and then

Adding Additional Information to an Entry

You can add additional information to an entry in People.

1. Display an entry in People. (See “Displaying an

Entry in People” on page 36 for details.)

2. Sc roll down the screen and tap .

3. Tap other.

4. Tap the type of information you want to add such

address, website, or birthday.

5. Tap to save the changes.

Note: When adding pictures or other information to an entry,

you may be prompted to select an entry type if the person is linked to more than one account.

Deleting an Entry

1. On the Start screen, tap People.

2. In all of the People Hub, tap and hold the name of

the contact you want to delete.

3. In the menu that appears, tap delete.

3. Contacts 37

Contacts

Finding Entries in People

Your Me Tile

Finding Contacts by Name

1. On the Start screen, tap People.

2. Scroll through all the entries.

– or –

At the top of the People press the button), enter the first letter or letters of a name (such as “dav” for “Dave”). The more letters you enter, the more your search narrows.

3. To display an entry, tap it.

38 3. Contacts

all screen, press (or

When you sign in to your Windows Live or Facebook account, your Me tile is automatically created on the Start screen. Tap your Me tile on the Start screen (or in all of the People Hub) and check status updates you have posted, comments you have received, and pictures that you have uploaded to your Windows Live or Facebook accounts.

⽧ Calendar (page 39)

4. Calendar & Tools

⽧ Calculator (page 43)

⽧ Microsoft Office Mobile 2010 (page 43)

Calendar

Use Calendar to create and manage events, meetings, and appointments. Your Calendar helps organize your time and reminds you of important events. Depending on your synchronization settings, your device’s Calendar stays in sync with your Windows Live, Exchange ActiveSync (Outlook), and Google calendars.

Adding an Appointment to the Calendar

You can create appointments that appear on your phone only, or appointments that sync with your online account calendars such as in Windows Live or Exchange Server.

1. On the Start screen, tap Calendar.

2. In day or agenda view, tap .

3. If you have more than one calendar, select an

Account in which to add the appointment.

Note: You can create multiple Google Calendars only in

Google Calendar on the Web. After creating them in Google Calendar on the Web, you’ll be able to see them in the Calendar application on your device. For more information about creating and managing multiple Google Calendars, visit the Google website:

http://calendar.google.com.

4. Enter the appointment details.

5. Scroll down to the bottom of the screen and tap

more details to set a reminder, appointment

recurrence, notes, and more.

6. Tap to save the appointment.

Calendar & Tools

4. Calendar & Tools 39

The Calendar tile on the Start screen will show your upcoming appointment.

Editing an Appointment

1. On the Start screen, tap Calendar.

2. In day or agenda view, press and hold the

appointment, and then tap

edit to open it.

3. Make your changes to the appointment.

4. Tap to save the changes.

Appointment Reminders

When your device is turned on and you have an appointment scheduled, your device alerts you and displays the appointment summary.

Note: If you did not set a reminder when you created the

appointment, no reminder will appear.

40 4. Calendar & Tools

To view, dismiss, or snooze the reminder:

䊳 On the reminder message, tap snooze to snooze or

dismiss to dismiss the appointment reminder.

Viewing Appoinments

When you open Calendar, it displays the day view by default. You can also display the Calendar in agenda or month view.

Day and Agenda Views

Day view displays a list of the appointments of one day. Agenda view lists all your appointments in chronological order.

The color bars on the right side of the appointments in Agenda view indicate the type of calendar the appointments are included in. To find out what each color represents, tap and then tap

Change the color by tapping the color box.

When in Day view, slide up or down the screen to view earlier or later days.

calendars.

Month View

In Month view, you’ll see text on the days that have appointments. To switch to Month view, tap .

When in Month view:

䢇 Tap a day to view the appointments of that day. 䢇 Slide your finger up or down the screen to view

earlier or later months.

Tip: To change from month to day or agenda view, 

press .

Deleting an Appointment

There are two ways to delete an appointment.

䢇 In day or agenda view, press and hold an

appointment and then tap

䢇 While viewing an appointment, tap .

delete.

If the appointment repeats, you’ll be asked whether you want to delete just that occurrence or all occurrences in your calendar.

Displaying and Synchronizing Calendars

You can choose which calendars to show or hide on your device’s Calendar, and which ones to keep synchronized.

If you choose to display multiple calendars, a different color will be assigned to each one.

4. Calendar & Tools 41

Calendar & Tools

To hide a calendar:

1. In day or agenda view, tap and then tap

calendars.

2. Tap th e on switch for the calendar that you want to

hide.

The calendars are kept synchronized on your device, whether or not you hide them.

42 4. Calendar & Tools

Choosing Which Calendars to Synchronize With Your Device

You can choose which calendars to keep synchronized on your device or which ones to stop synchronizing.

Stop Synchronizing a Calendar

1. On the Start screen, tap .

2. Tap Settings > email & accounts.

3. Tap the account whose calendar you want to stop

synchronizing with your device.

4. Clear the Calendar check box.

5. Tap .

Calculator

Microsoft Office Mobile 2010

Your device comes with a built-in calculator.

1. Press and tap .

2. Ta p Calculator.

3. Enter numbers or formulas using the onscreen

keys.

Note: To switch to a scientific calculator, turn your device

sideways to your left. The scientific calculator lets you perform more complex calculations with square root, logarithmic, and trigonometric functions.

4. Tap enter for the result.

The Microsoft Office Hub consists of the following apps:

䢇 Microsoft OneNote Mobile 2010 lets you keep track of

stuff at home, school, or work; your big ideas, shopping lists, meeting notes, projects, and more.

䢇 Microsoft Word Mobile 2010 lets you create and edit

documents on your device.

䢇 Microsoft Excel Mobile 2010 lets you create, view, and

edit Excel spreadsheets on your device.

䢇 Microsoft PowerPoint Mobile 2010 lets you view (not

create) and edit slideshow presentations on your device.

䢇 SharePoint Workspace lets you view, edit, and

download documents stored on Microsoft SharePoint Server 2010.

Note: You can put your Office documents onto your device

from your computer using Zune or you can send the files as email attachments to one of the email accounts you have set up on your device. For more information about using Zune, see “Getting Your Media Files to Your Device Using Zune” on page 52.

4. Calendar & Tools 43

Calendar & Tools

Using Microsoft Office Mobile

1. Press and tap .

2. Tap Office.

3. Select the Office app you want to use. Scroll left to

see the other Office apps.

Tip: For information on using the Microsoft Office Mobile

features, tap options in the Hub. You can also go to

www.windowsphone.com

44 4. Calendar & Tools

Welcome to Office or any of the Explore

for more details.

⽧ Automatic Speech Recognition (ASR) (page 45)

5. Voice Services

Automatic Speech Recognition (ASR)

You can use your device’s built-in automatic speech recognition (ASR) software to dial any phone number or a contact in your People list, search the Web, or launch an application. All you have to do is to talk into your device, and ASR will recognize your voice and complete tasks by itself.

Activating ASR

1. Press and hold on your device.

2. If this is your first time to use ASR, the screen will

first display some suggestions on what commands

you can use. When you’re ready to issue a command, tap

speak.

Available ASR commands include:

䡲 Call <Name or Phone number> to call an entry in

your People list or any phone number, whether it belongs to a stored contact or not. (See “Making a Voice Call With ASR” on page 46.)

䡲 Find <Word or Phrase> or Search for <Word or

Phrase> to search for information on the Web. (See “Searching the Web With ASR” on page 46.)

䡲 Open <Application Name> or Start <Application

Name> to open an application in your device.

3. The screen then displays “Listening...” and your

device prompts you to say the name of the command you want to use. Speak the command and then tap for your device to execute your command.

Tip: Use ASR in a quiet environment so it can accurately

recognize your commands.

go or just wait a couple of seconds

Voice Services

5. Voice Services 45

Making a Voice Call With ASR

1. Press and hold on your device.

2. Wait until you see the word “Listening...” appear on

the screen.

3. Say “Call [contact name]” to call a person stored in

your People list.

– or –

If the contact has more than one phone number, say “Call [contact name, phone number type]” to be specific. (For example, say “Call David, mobile”.)

– or –

Say “Call [number]” to dial a spoken phone number.

Note: When dialing a phone number, numbers can be three

digits (for example, 911), seven digits (for example,  555-1234), or ten digits (for example, 222-555-1234).

4. Tap go on the screen to confirm or press on the

device to cancel the command; or choose from a menu if ASR is not sure what you would like to do.

46 5. Voice Services

Searching the Web With ASR

You can search for information on the Web by saying “Find” or “Search for” followed by the word or phrase you want to look for.

1. Press and hold on your device.

2. Wait until you see the word “Listening...” appear on

the screen.

3. Say “Find [word]” or “Find [phrase]”.

– or –

Say “Search for [word]” or “Search for [phrase]”.

4. Tap go on the screen to confirm or press on the

device to cancel the command; or choose from a menu if ASR is not sure what you would like to do.

⽧ Taking Pictures and Capturing Videos (page 47)

6. Camera & Multimedia

⽧ Viewing Pictures and Videos Using the Pictures

Hub (page 50)

⽧ Getting Your Media Files to Your Device Using

Zune (page 52)

⽧ Using the Music + Videos Hub (page 52)

Taking Pictures and Capturing Videos

Your device comes with a 5.0 megapixel camera with an autofocus feature that lets you capture sharp pictures and videos.

Camera & Multimedia

Opening the Camera

䊳 To open the camera, press the camera button on

the lower right hand corner of your device.

– or –

䊳 On the Start screen, tap , and then tap Camera.

When you open the camera app for the first time, it will ask you if you want to share the location of your device. This will add a location tag to your captured photos so you’ll know where they were taken.

6. Camera & Multimedia 47

Viewfinder Screen

The camera displays in landscape view only. You’ll find the following controls on the viewfinder screen:

Tap to switch between Photo and Video modes.

Tap to zoom in or out.

Tap to open the camera settings.

48 6. Camera & Multimedia

Zooming

Before taking a photo or video, you can first use the onscreen zoom buttons to zoom in or out of your subject. Simply press the + or - onscreen buttons to zoom in or out.

Tak ing a Photo

1. On the Start screen, tap , and then tap Camera,

or press the camera button on the lower right side of the device.

䡲 To adjust the zoom before you take the picture,

press + to zoom in or - to zoom out.

䡲 To adjust the camera settings before you take the

picture, tap and then select settings such as camera flash mode.

2. Frame your subject on the viewfinder screen.

3. Press the camera button to take the photo.

䡲 Your device will automatically save the picture

and return to camera mode.

䡲 For options on the picture you just took, swipe the

screen from left to right and tap .

Camera Flash FAQ

Why doesn’t the Camera flash turn on?

The flash quickly consumes battery power. To save battery power, the camera disables the flash (even when you have set the camera flash mode to or

Flash on) when one of the following occurs:

䢇 You have an incoming call. The flash will be disabled

temporarily when you have an incoming call. After the call ends, you’ll be able to use the flash again. If you have set the flash to

Flash on, it turns back on

after you answer and end the call.

䢇 Your device’s battery level reaches 20% or lower.

Recharge the battery so that the camera can have enough battery power to use the flash.

䢇 Cold weather may lower battery performance which

affects the flash. To make sure the camera has

enough battery life to power up the flash, keep your device warm. When not in use, put the device inside your jacket to keep it warm, and try to avoid sudden temperature changes that may affect battery performance.

Auto flash

Capturing a Video

1. On the Start screen, tap , and then tap Camera,

or press the camera button on the lower right side of the device.

2. On the viewfinder screen, tap to switch to video

mode.

䡲 To adjust the zoom before you record the video,

press + to zoom in or - to zoom out.

䡲 To adjust the video settings before you record the

video, tap and then select settings such as video light mode and resolution.

3. Frame your subject on the screen.

4. Press the camera button to start capturing video.

Press it again to stop capturing.

䡲 Your device will automatically save the video and

return to video mode.

䡲 For options on the video you just captured, swipe

the screen from left to right and press and hold the video.

6. Camera & Multimedia 49

Camera & Multimedia

After Capturing

After capturing a photo or video, slide your finger from left to right to see the photo or video you’ve just captured. Press and hold the photo or video to display additional options.

Camera Settings

To check and change your camera settings, tap on the viewfinder screen, and then tap an item.

Closing Camera

On the camera screen, press or .

Viewing Pictures and Videos Using the Pictures Hub

Using the Pictures Hub, you can view photos and watch videos that you’ve taken with your device’s camera, downloaded, or synchronized with your device. You can also take a look at your photos and your friends’ photos that are on your Windows Live and Facebook accounts.

50 6. Camera & Multimedia

Opening the Pictures Hub

䊳 To open the Pictures Hub, tap Pictures on the Start

screen.

After opening the Pictures Hub, slide to the left to check out recent photos and photos on Facebook and Windows Live.

Viewing Photos and Videos

1. Choose how you want to browse through your

photos and videos (all, date, favorites).

2. Select an album to view.

3. Tap a photo or video to view it in full screen.

Viewing Photos and Videos in Landscape Orientation

䢇 The photo orientation adjusts to how you hold your

device. Turn your device sideways to view a photo in landscape mode.

䢇 Video is always displayed in landscape mode when

you play it. Use the onscreen controls to play, pause, or stop the video.

Zooming In or Out on a Photo

There are two ways you can zoom in or out of a photo:

䊳 Tap the screen twice quickly to zoom in, then tap

the screen twice quickly again to zoom out.

– or –

You can also use pinch and spread to zoom.

Sharing Your Photos on the Web

Using the Pictures Hub, you can share your photos on Facebook and upload your photos to your Windows Live SkyDrive.

Sharing Photos on Facebook

You must be logged in to your Facebook account to be able to upload photos.

1. On the Start screen, tap Pictures.

2. Ta p all.

3. Tap the album where the photo you want to share

is stored.

4. Press and hold the photo you want to send, and

then tap

share > upload to Facebook.

Uploading a Photo to Your SkyDrive

You must be logged in to your Windows Live account to be able to upload photos.

1. On the Start screen, tap Pictures.

2. Ta p all.

3. Tap the album where the photo you want to share

is stored.

4. Press and hold the photo you want to send, and

then tap

5. If you want to enter a caption, tap the caption box,

and then enter your caption.

share > upload to SkyDrive.

6. Camera & Multimedia 51

Camera & Multimedia

Getting Your Media Files to Your Device Using Zune

You’ll need the Zune® software to get your music, videos, and podcasts from your computer to your device. If you don’t have the Zune software on your computer yet, go to install it.

Setting Up Zune to Synchronize Your Computer and Device

1. Connect your device to your computer using the

supplied USB cable. Zune automatically opens on your computer, if you haven’t already opened it.

2. Wait for Zune to recognize your device, and then

follow the onscreen instructions to set it up.

Choosing Items to Synchronize With Your Device

After setting up Zune on your computer, choose what you want to sync with your device.

52 6. Camera & Multimedia

www.zune.net to download and

1. Connect your device to your computer using the

supplied USB cable. Zune automatically opens on your computer, if you haven’t opened it already.

2. Click collection on top of the Zune screen.

3. Choose the type of media (for example, Music) you

want to sync to your device.

4. Choose the items you want to sync with your

device, and then drag them to the phone icon at the bottom-left corner of the Zune screen.

Using the Music + Videos Hub

The Music + Videos Hub is your gateway to your media collection. Listen to your music, watch your videos, check out your podcasts, listen to the radio, and go to the Marketplace to buy music all in the Music + Videos Hub.

Opening the Music + Videos Hub

To open the Music + Videos Hub, tap Music + Videos on the Start screen.

Listening to Music

Get your music into your phone by following the steps in “Choosing Items to Synchronize With Your Device”.

1. On the Start screen, tap Music + Videos.

2. In zune, tap music.

3. Slide your finger left or right to browse your music

according to the category you want.

4. Tap the title of the song you want to listen to.

While listening, you can press and hold to rewind or press and hold to fast forward.

Buy additional music by visiting the Marketplace.

Turning Repeat or Shuffle On

While playing a song, tap the album cover to loop or shuffle the songs in the album. You can also rate the album.

Controlling Music Playback from the Status Bar

When you exit the music player, you can still control music playback from the status bar. To show the playback controls on the status bar, press the VOLUME UP or VOLUME DOWN button.

6. Camera & Multimedia 53

Camera & Multimedia

Watching Videos

The screen automatically switches to landscape mode when you play a video.

Get your videos into your device by following the procedure in “Choosing Items to Synchronize With Your Device” on page 52.

1. On the Start screen, tap Music + Videos.

2. In zune, tap videos.

3. Slide your finger left or right to browse through

your videos according to the category you want.

4. Tap the title of the video you want to watch.

54 6. Camera & Multimedia

Listening to the Radio

You can use the Radio to listen to FM radio stations on your device. You will first need to connect a wired headset to the audio jack of your device. FM Radio uses the stereo headset as the FM radio antenna.

Listening to an FM Station

1. On the Start screen, tap Music + Videos.

2. In zune, tap radio.

3. Slide your finger left or right to go to the radio

station you want to listen to.

4. Add the radio station to your favorites by 

tapping .

Tip: Access your favorite radio stations by tapping .

The radio station plays in the background even if you exit the radio screen. If you do not want to continue to listen to the radio, tap before exiting. To resume play, tap .

⽧ Turning Bluetooth On and Off (page 55)

7. Bluetooth

⽧ Connecting a Bluetooth Headset or Car Kit (page 55)

⽧ Disconnecting From a Bluetooth Device (page 56)

Turning Bluetooth On and Off

By default, your device’s Bluetooth feature is set to Off. Turning Bluetooth on makes your phone “discoverable” by other in-range Bluetooth devices.

1. Press and tap .

2. Ta p Settings > Bluetooth.

3. Tap the Status On/Off switch to turn on Bluetooth.

Note: Turn off Bluetooth when not in use to conserve battery

power, or in places where using a wireless device is prohibited, such as aboard an aircraft and in hospitals.

Connecting a Bluetooth Headset or Car Kit

You can listen to music over a Bluetooth stereo headset, or have hands-free conversations using a compatible Bluetooth headset or car kit. Follow the same steps to set up stereo audio and hands-free devices.

To listen to music with your headset or car kit, it must support the A2DP Bluetooth profile.

Make sure that the headset is discoverable, so that your device can find the headset. Refer to the instructions that came with the headset to find out how to set it to discoverable mode.

1. Press and tap .

2. Ta p Settings > Bluetooth.

3. If the Bluetooth swtch is off, tap the Status On/Off

switch to turn on Bluetooth. Your device will start to scan for devices within range.

4. When you see the name of your headset

displayed, tap the name. Your device then automatically tries to pair with the headset.

7. Bl ue to ot h 55

Bluetooth

If automatic pairing fails, enter the passcode supplied with your headset.

When the Bluetooth headset or car kit establishes a connection to your device, the Bluetooth connected icon is displayed in the status bar for a brief moment. Depending on the type of headset or car kit you have connected, you can then start using the headset or car kit to listen to music or make and receive phone calls.

Note: Due to different specifications and features of other

Bluetooth-compatible devices, display and operations may be different, and functions such as transfer or exchange may not be possible with all Bluetoothcompatible devices.

56 7. Bluetooth

Disconnecting From a Bluetooth Device

To disconnect a Bluetooth device:

1. Press and tap .

2. Tap Settings > Bluetooth.

3. On the list of Bluetooth devices, tap the device to

disconnect from it. Tap the device again on the list to connect to it.

To unpair from a Bluetooth device:

You can make your device forget its pairing connection with another Bluetooth device. To connect to the other device again, you may need to enter or confirm a passcode again.

1. Press and tap .

2. Tap Settings > Bluetooth.

3. On the list of Bluetooth devices, press and hold the

device to unpair.

4. Tap delete.

⽧ Voicemail (page 57)

8. Sprint Service: The Basics

⽧ Text Messaging (SMS) and Multimedia

Messaging (MMS) (page 59)

⽧ Caller ID (page 63)

⽧ Call Waiting (page 63)

⽧ Making a 3-Way Call (page 64)

⽧ Call Forwarding (page 64)

Voicemail

Setting Up Your Voicemail

Your device automatically transfers all unanswered calls to your voicemail, even if your device is in use or turned off. You should set up your Sprint Voicemail and personal greeting as soon as your device is activated.

1. On the Start screen, tap to open the Phone

application.

2. Tap at the bottom of the screen.

3. Your device will automatically connect with Sprint

Voicemail service. Follow the voice prompts to:

䡲 Create your password. 䡲 Record your name announcement. 䡲 Record your greeting.

4. When you’re done, tap end call.

Note: Voicemail Password

Sprint strongly recommends that you create a password when setting up your voicemail to protect against unauthorized access. Without a password, anyone who has access to your phone is able to access your voicemail messages.

8. Sprint Service: The Basics 57

Sprint Service

Voicemail Notification

There are several ways your device alerts you to a new message:

䢇 By displaying a voicemail icon and the number of

new missed calls on the Phone tile.

䢇 By flashing the notification LED (see “Notification

LED” on page 7).

䢇 By displaying a message in the status bar on top of

the screen.

58 8. Sprint Service: The Basics

Note: When you are roaming off the Nationwide Sprint

Network, you may not receive notification of new voicemail messages. Sprint recommends that you periodically check your voicemail by dialing your area code + your wireless phone number. When your voicemail answers, press and enter your passcode. Roaming rates apply when you access voicemail while roaming off the Nationwide Sprint Network.

Your device accepts messages even when it is turned off. However, your device notifies you of new messages only when it is turned on and you are in a Sprint service area.

Retrieving Your Voicemail Messages

You can review your messages directly from your wireless device or from any other touch-tone phone.

Using Your Device

1. On the Start screen, tap to open the Phone

application.

2. Tap at the bottom of the screen to dial your

voicemail box.

Using Another Phone to Access Messages

1. Dial your wireless phone number.

2. When your voicemail answers, press *.

3. Enter your passcode.

Tip: When you call voicemail from another phone, you first

hear the header information (date, time, and sender information) for the message. To skip directly to the message, press 4 during the header.

To erase a voicemail message, press 7 after listening to it.

Text Messaging (SMS) and Multimedia Messaging (MMS)

With Text Messaging (SMS), you can send and receive instant text messages between your wireless device and another messaging-ready phone.

Multimedia messages, or MMS, can contain text and pictures.

Note: See your service plan for applicable charges for 

Text Messaging and Multimedia Messaging.

Composing Text Messages

1. On the Start screen, tap to open the Messaging

application.

2. Tap to create a new message.

3. Fill in one or more recipients. You can:

䡲 Enter complete phone numbers or email

messages directly in the to separate recipients.

䡲 Enter the first few letters of a contact name. As

you enter, matching names with mobile phone numbers from your stored contacts are displayed. Tap a contact that you want.

䡲 Tap to the right of the recipient field, and then

tap the contact that you want and choose which phone number to send to.

8. Sprint Service: The Basics 59

To field. Use a semicolon

Sprint Service

Tap the “type a message” box and then start composing your message.

Note: A counter appears below your text message when you

are about to reach the 160-cha racter limit. If you continue typing and go over this limit, a new message is created. Depending on the total length, your text message will be sent as two or more messages, but the recipient will receive and see it as a single message.

5. When done, tap to send the text message.

Sending a Multimedia Message (MMS)

To send a multimedia message, start by creating a new text message, and then attach a photo in the message.

1. Create and compose your text message. (See

“Composing Text Messages” on page 59.)

2. To attach a photo, you can:

䡲 Tap and then choose a photo you want to

send.

– or –

60 8. Sprint Service: The Basics

䡲 Instead of choosing a photo, tap on the

choose picture page to take a photo using the camera and insert it as the attachment.

3. Tap to send the message.

New Messages Notification

Note: You can attach photos only to a multimedia message.

No other file types may be attached.

When you receive a new message, your device plays an alert sound (if set) and displays a message bar at the top of the screen. The Messaging tile on the Start screen also displays the number of new messages.

To change the alert sound for new text and multimedia messages, see “Sound Settings” on page 20 for details.

Viewing and Replying to Messages

Viewing Text and Multimedia Messages

䊳 Tap the message bar at the top of the screen that

shows the new message you’ve just received.

– or –

On the Start screen, tap to open the Messaging application and view all your messages. When you open the Messaging application, you will see the conversations screen where all your sent and received text and multimedia messages are grouped into conversations by contact name or phone number. Scroll the list of conversations by swiping your finger up or down the screen, and then tap a contact or phone number whose messages you want to read.

Note: If a message contains a link to a Web page, tap the link

to open it in Internet Explorer.

If a message contains a phone number, tap the number, edit it if needed, and then tap call to dial the number.

Saving a Photo From a Multimedia Message

1. While viewing a mutimedia message, tap the

photo in the message.

2. Press and hold the opened photo, and then tap

save to phone.

The photo will be saved in the Saved Pictures album on your device.

Replying to a Message

1. On the conversations screen, tap a contact (or

phone number) to view the exchange of messages with that contact.

2. Tap the text box at the bottom of the screen and

enter your response.

3. Tap to send your message.

8. Sprint Service: The Basics 61

Sprint Service

Forwarding a Message

1. On the conversations screen, tap a contact (or

phone number) to view the exchange of messages with that contact.

2. Press and hold the message you want to forward

and then tap

forward on the options menu.

3. Fill in the recipient’s name.

4. Tap to send the message.

Deleting Messages

Deleting a Whole Conversation

䊳 On the conversations screen, press and hold a

contact (or phone number) whose messages you want to delete, and then tap again to confirm.

– or –

While viewing the exchange of messages with a contact (or phone number), tap at the lowerright side of the screen, and then tap

conversation. Tap delete again to confirm.

62 8. Sprint Service: The Basics

delete. Tap delete

delete

Deleting a Single Message

1. On the conversations screen, tap a contact (or

phone number) to view the exchange of messages with that contact.

2. Press and hold the message you want to delete

and then tap

3. When prompted to confirm, tap delete.

delete on the options menu.

Caller ID

Call Waiting

Caller ID identifies a caller before you answer the device by displaying the number of the incoming call. If you do not want your number displayed when you make a call, follow these steps.

1. On the Start screen, tap to open the Phone

application.

2. Tap to display the dial keypad.

3. Tap .

4. Enter a phone number.

5. Tap call.

To permanently block your number, call Sprint Customer Service.

When you’re on a call, Call Waiting alerts you to incoming calls by sounding two beeps. Your device’s screen informs you that another call is coming in and displays the caller’s phone number (if it is available and you are in digital mode).

To respond to an incoming call while you’re on a call:

䊳 Ta p answer. (This puts the first caller on hold and

answers the second call.)

To switch back to the first caller:

䊳 If you see a “TAP TO SWAP” notification message

at the top of the screen, tap that message.

– or –

Tap and then tap the

Tip: For those calls where you don’t want to be interrupted,

you can temporarily disable Call Waiting by pressing 

before placing your call. Call Waiting is

automatically reactivated once you end the call.

flash button.

8. Sprint Service: The Basics 63

Sprint Service

Making a 3-Way Call

Call Forwarding

With 3-Way Calling, you can talk to two people at the same time. When using this feature, the normal airtime rates will be charged for each of the two calls.

1. On the Start screen, tap to open the Phone

application.

2. Tap to display the dial keypad.

3. Enter a number and tap call.

4. Once you have established the connection, 

tap , tap the number of the second participant. (This puts the first caller on hold and dials the second number.)

add call button, and dial the

5. When you’re connected to the second party, 

tap and tap the

If one of the people you called hangs up during your call, you and the remaining caller stay connected. If you initiated the call and are the first to hang up, all callers are disconnected.

To end the three-way call, tap

merge calls button.

end call.

64 8. Sprint Service: The Basics

Call Forwarding lets you forward all your incoming calls to another phone number – even when your device is turned off. You can continue to make calls from your device when you have activated Call Forwarding.

Note: You are charged a higher rate for calls you have

forwarded.

To activate Call Forwarding:

1. On the Start screen, tap to open the Phone

application.

2. Tap to display the dial keypad.

3. Tap .

4. Enter the area code and phone number to which

you want your calls forwarded.

5. Tap call. (You will hear a tone to confirm the

activation of Call Forwarding.)

To deactivate Call Forwarding:

1. On the Start screen, tap to open the Phone

application.

2. Tap to display the dial keypad.

3. Tap .

4. Tap call. (You will hear a tone to confirm the

deactivation.)

Sprint Service

8. Sprint Service: The Basics 65

⽧ Ways of Connecting to the Internet (page 66)

9. Web and Data Services

⽧ Connecting Using Wi-Fi (page 66) ⽧ Getting Started With Data Services (page 68) ⽧ Using Internet Explorer Mobile (page 69) ⽧ Using Bing Search (page 73) ⽧ Email (page 74) ⽧ Downloading Applications and Games From

Marketplace (page 80)

⽧ HTC Hub (page 80) ⽧ Weather (page 82) ⽧ Sprint Zone (page 84)

66 9. Web and Data Services

Ways of Connecting to the Internet

Your device’s networking capabilities allow you to wirelessly access the Internet or your corporate network through one of the following connections:

䢇 Wi-Fi 䢇 Data Services

Connecting Using Wi-Fi

Wi-Fi provides wireless Internet access over distances of up to 300 feet. To use your device’s Wi-Fi, you need access to a wireless access point or “hotspot.”

Note: The availability and range of the Wi-Fi signal depends

on a number of factors, including infrastructure and other objects through which the signal passes.

Turning Wi-Fi On and Connecting to a Wireless Network

1. On the Start screen, tap .

2. Tap Settings > Wi-Fi.

3. Tap the On/Off switch to turn Wi-Fi on.

Your device will then scan for available wireless networks and display them. You will see the network names, type of security (open or secure network), and signal strength of the detected networks.

4. Tap a wireless network to connect. If you selected

an open network, you will be automatically connected to the network. If you selected a network that is secured with WEP, enter the password, and tap

Note: Depending on the network type and its security

settings, you may also need to enter more information.

You cannot manually add a Wi-Fi profile.

When your device is connected to a wireless network, the Wi-Fi icon ( ) appears for a brief moment on the status bar and tells you the approximate signal strength (number of bands displayed). When the Wi-Fi icon disappears, simply tap the status bar to display the icon again so you can see the current signal strength.

done.

The next time your device connects to a previously accessed secured wireless network, you will not be prompted to enter the password or other security information again, unless you reset your device to its factory default settings.

Connecting to Another Wi-Fi Network

1. On the Start screen, tap .

2. Ta p Settings > Wi-Fi.

3. Detected wireless networks are displayed on the

Wi-Fi settings screen. Tap another wireless network to connect to it.

Web and Data

9. Web and Data Services 67

Getting Started With Data Services

With your Sprint service, you are ready to start enjoying the advantages of data services. This section will help you learn the basics of using your data services, including launching a data connection.

Launching a Web Connection

䊳 On the Start screen, tap to open Internet

Explorer. (Your data connection starts and you will be asked to sign in with your 10-digit Sprint phone number.)

Data Connection Status and Indicators

Your device displays the current status of your data connection through indicators at the top of the screen. The following symbols are used:

Your device is connected to the Sprint 3G data network.

Your device is connected to the Sprint 1xRTT data network.

68 9. Web and Data Services

If you do not see an indicator, your device does not have a current data connection.

Turning the Data Connection On or Off

Turning your data connection off can help optimize your battery life. It can also save money on data charges. However, when your data connection is turned off, you may not always receive automatic updates to your email and other synchronized information.

1. On the Start screen, tap .

2. Tap Settings > cellular.

3. Tap the data connection’s On/Off switch.

Using Internet Explorer Mobile

Surf the Web and open several Web pages at once using Internet Explorer Mobile. You will need an active data connection or Wi-Fi connection to access the Internet.

Opening Internet Explorer Mobile

䊳 On the Start screen, tap .

– or –

On the Start screen, tap and then tap .

Browser Options

Although the home page offers a broad and convenient array of sites and services for you to browse, not all sites are represented, and certain functions, such as going directly to specific websites, are not available. For these and other functions, you will need to choose from the browser options. These additional options expand your use of the Web on your device.

Note: Rotate your device to portrait mode to access browser

options.

To choose from the browser options:

䊳 Tap at the lower-right side of the browser

screen in portrait mode.

Options available include:

䢇 add : Allows you to add the current website

address (URL) as a favorite.

䢇 favorites : Allows you to access and manage your

favorite websites.

䢇 tabs : Allows you to open additional browser

windows.

䢇 forward: Returns you to a previously viewed page

(after having pressed ).

䢇 share page: Lets you send a website address in a text

message or email.

䢇 find on page: Allows you to find specific text on a Web

page.

䢇 pin to start: Allows you to add the current website as

a tile on the Start screen for quick one-tap access.

䢇 settings: Opens the browser settings.

9. Web and Data Services 69

Web and Data

Going to a Website

1. On the browser screen, tap the address box at the

top of the screen.

2. Enter the website address using the keyboard. As

you enter the address, matching website addresses will appear on the screen. Tap an address to go directly to that website or continue entering the website address.

3. Tap on the onscreen keyboard.

Changing the Screen Orientation

The device automatically changes the screen orientation depending on how you are holding your device.

Browsing Full Versions of Web Pages

Some websites display a mobile version of their pages to phone Web browsers. You can choose to view the full version of all pages, even for these sites.

䊳 While viewing a Web page in portrait orientation,

tap on the browser screen, tap select the

Desktop version option.

70 9. Web and Data Services

settings, and

Navigating on a Web Page

Panning on a Web Page

䊳 Slide your finger on the screen in any direction to

navigate and view other areas of the Web page.

Zooming In or Out on a Web Page

䊳 Tap the screen twice quickly to zoom in; tap the

screen twice quickly again to zoom out.

– or –

Spread or pinch the screen to zoom in or out.

Opening a New Browser Tab

Open multiple browser tabs to make it easier for you to switch from one website to another. You can open up to six browser tabs.

1. While viewing a Web page in portrait orientation,

tap .

2. Tap . A new browser tab opens and goes to the

home page that is set.

Switching Between Browser Tabs

Tap to cl os e the Web page.

Tap to display the Web page in full screen.

1. While viewing a Web page in portrait orientation,

tap .

2. Select the website you want to view by tapping the

tab that shows a thumbnail preview of the website.

Finding Text In a Web Page

1. While viewing a Web page in portrait orientation,

tap on the browser screen.

2. Ta p find on page.

3. Enter the search item and then tap on the

onscreen keyboard.

4. Tap or to go to the next or previous

matching item on the Web page.

Selecting Links in Web Pages

Links can be selected as shown below.

Link What to do

Web page address (URLs)

Email address

䢇 Tap the link to open the Web page. 䢇 Press and hold the link to open a menu

that allows you to open the Web page as a new tab, copy the link, or share the link in a text message or email.

䢇 Tap to send an email message to the

email address.

9. Web and Data Services 71

Web and Data

The browser also recognizes some phone numbers and addresses that allow you to call the phone number or locate the address in Bing Maps™. Recognized phone numbers and addresses are highlighted in color.

Link What to do

Location

address

number

Tip: Zoom in on the Web page when links are too small for

Tap the address to open Bing Maps and locate the address.

Phone

Tap to open the Phone application to call the phone number.

tapping directly on the screen.

Managing Favorites and Previously Visited Web Pages

Save links to your favorite sites and check your browsing history to easily go back to the websites you have visited before. You can also pin sites to the Start screen for quick, one-tap access.

72 9. Web and Data Services

To add a website to your favorites list:

1. While viewing a Web page in portrait orientation,

tap .

2. Edit the Name if needed, and then tap ok.

To open a saved favorite:

1. While viewing a Web page in portrait orientation,

tap .

2. Under favorites, scroll through the list of Web

favorites and tap the one you want to open.

To edit or delete a favorite:

1. While viewing a Web page in portrait orientation,

tap .

2. Scroll through the list of Web favorites and then

press and hold the one you want to edit or delete.

3. Tap edit to enter a new name or address for the

website, or tap your favorites list.

delete to remove the website from

To pin a website to the Start screen:

1. While viewing a Web page in portrait orientation,

tap on the browser screen.

2. Ta p pin to start.

To share a website link:

1. While viewing a Web page in portrait orientation,

tap on the browser screen.

2. Ta p share page.

3. Choose how to share the link:

䡲 Ta p Messaging to send the link in a text message.

– or –

䡲 Tap an email account to send the link in an email.

To view a previously visited page:

1. While viewing a Web page in portrait orientation,

tap .

2. Slide left to display the history.

3. Scroll through the list of previously visited sites and

then tap the one you want to revisit.

To clear the list of previously visited pages:

1. While viewing a Web page in portrait orientation,

tap .

2. Slide left to display the history and then tap .

3. Tap delete.

Using Bing Search

Find all kinds of information on the Web using Bing Search.

Searching the Web

1. Press the Search button ( ) on your device.

Note: If you press the Search button while you’re in your email

account inbox or an application such as People, you'll need to press it again to search the Web. Otherwise you'll be searching information within the application.

2. In the search box, type a word or phrase.

3. Tap on the onscreen keyboard.

9. Web and Data Services 73

Web and Data

Search results are then displayed on your screen. Swipe left or right across the screen to narrow or broaden the search results to

web, local, or news.

Email

Your device allows you to stay connected and access email messages 24 hours a day anywhere on the Nationwide Sprint Network. On your device, you can set up all your personal email accounts such as your Windows Live or Hotmail account and your other

74 9. Web and Data Services

POP3/IMAP email accounts. You can also set up your Exchange ActiveSync account that you use at work.

Depending on the type of email account, other information such as your contacts and calendar can also be synchronized with your device.

Adding Your Windows Live Account

When you first turned on your device, you were prompted to sign in with your Windows Live account. If you did not sign in or you have several Windows Live accounts, follow the steps below to set up your primary Windows Live account or additional accounts.

Note: If you have several Windows Live accounts and you are

not certain which one to use, visit the windowsphone website at the following address for help information:

http://www.microsoft.com/windowsphone/en-us/ howto/wp7/start/which-windows-live-id-should-iuse.aspx.

1. Do one of the following:

䡲 If you haven’t set up any accounts yet, tap Email

setup on the Start screen.

䡲 On the Start screen, tap and then tap 

Settings > email & accounts > add an account.

2. Ta p Windows Live.

3. If you haven't signed in with a Windows Live ID yet

during setup, you’ll see the Before you sign in screen. Tap

next.

4. Enter your Windows Live ID and password.

5. Tap sign in.

Note: The first Windows Live account that you set up cannot

be deleted from your device unless you reset your device. See “Resetting Your Device” on page 26.

If you set up additional Windows Live accounts on your device, photos in these accounts will not be synchronized to your device.

Adding Your Gmail, Yahoo! Mail, or Other POP3/IMAP Email Account

1. Do one of the following:

䡲 If you haven’t set up any accounts yet, tap Email

setup on the Start screen.

䡲 On the Start screen, tap and then tap 

Settings > email & accounts > add an account.

2. Tap the type of account you want to set up.

Note: If you don’t see the account type that you want, tap

other account or advanced setup. You will be asked

to enter more details. You should get all pertinent information for the email account such as incoming and outgoing server settings before you proceed.

3. Enter your email address and password.

4. Tap sign in.

Adding Your Exchange ActiveSync Account

If you synchronize your device with your Exchange ActiveSync account, you can read, manage, and send email in the same easy way as with your personal email account.

1. Do one of the following:

䡲 If you haven’t set up any accounts yet, tap Email

setup on the Start screen.

䡲 On the Start screen, tap and then tap

Settings > email & accounts > add an account.

2. Ta p Outlook.

9. Web and Data Services 75

Web and Data

Enter the Exchange ActiveSync account details and then tap

Note: Your corporate Exchange Server must support auto-

detect for the device to automatically set up the Exchange ActiveSync account. If your corporate Exchange Server does not support auto-detect, you will need to enter your Exchange Server settings. Ask your Exchange Server administrator for details.

Creating Another Email Account

䊳 If you are in the Inbox of an email account, tap

and then tap

add email account.

Viewing Your Email Inbox

After you set up an email account, a new tile is created on the Start screen for your account.

To open an email account:

䊳 Tap the email account’s tile on the Start screen.

– or –

If you don’t see the tile, tap on the Start screen, and then tap the account in the applications list.

76 9. Web and Data Services

To filter your email messages:

䊳 Slide your finger left or right to check only your

unread, flagged, or urgent email.

Composing and Sending Email

1. On the Start screen or the applications list, tap the

email account that you want to use to send your email.

2. On the email account Inbox, tap to create a

new email.

3. Fill in one or more recipients. You can:

䡲 Enter email addresses directly in the To field. If

you’re sending the email to several recipients, separate the email addresses with a comma. As you enter email addresses, any matching addresses from your contacts list are displayed. Tap a match to enter the address directly.

䡲 Tap to the right of the recipient field, and then

select a contact to whom you want to send your email. Tap again to add more recipients.

4. Enter the subject, and then tap the space below

the subject line to compose your message.

5. To add an attachment, tap . You can only attach

photos.

6. Tap to send the message immediately.

– or –

> Save to save the message to your drafts

Tap folder first if you want to send it later.

Resuming a Draft Email Message

1. On the email account Inbox, tap and then tap

drafts.

2. Tap the message you last composed to edit it.

3. Tap to send the message.

Setting the Priority for Your Email Message

1. While composing your email, tap and then tap

priority.

2. Choose the type of priority for your email.

If you choose will appear to the right of the subject line.

high or low priority, the priority type

9. Web and Data Services 77

Web and Data

Viewing and Replying to Email

1. On the Start screen or the applications list, tap the

email account you want to use.

2. On the email account Inbox, tap the message you

want to view.

3. Tap and then tap reply, reply all, or forward.

4. Edit your message and tap to send it.

Managing Your Email Inbox

Refreshing an Email Account

Whatever your automatic synchronization settings are, you can also synchronize your sent and received email messages manually at any time.

䊳 While in the account you want to synchronize,

tap .

Deleting an Email Message

1. On the email account Inbox, press and hold the

message you want to delete.

2. On the options menu, tap delete.

78 9. Web and Data Services

Deleting or Moving Multiple Email Messages

1. On the email account inbox, tap or tap the area

to the left of a message and then tap the check boxes of email messages you want to delete or move to another folder.

2. Tap to delete them or tap to move them to

a different folder.

Tip: You can also mark selected messages as read or

unread. Tap

unread.

and then tap mark as read or mark as

Flagging an Email Message (Gmail and Exchange ActiveSync Only)

For your Gmail or Exchange ActiveSync account, you can flag email messages to help you keep track of them.

1. On the Start screen or the applications list, tap

Google Mail to open your Gmail account or Outlook to open your Exchange ActiveSync

account.

2. On the email account inbox, press and hold the

message you want to flag.

3. On the options menu, tap set flag.

Changing Email Account Settings

1. On the Start screen or the applications list, tap the

email account whose settings you want to change.

2. Tap at the lower-right side of the screen and

tap

settings.

3. Tap sync settings.

4. Choose how frequent to download new email and

other settings and then tap .

5. Choose if you want to add a signature to your sent

messages.

6. After you have finished changing the settings,

tap .

Deleting an Email Account

1. On the Start screen, tap .

2. Ta p Settings > email & accounts.

3. Press and hold the email account you want to

delete.

4. On the options menu, tap delete, and then tap

delete again to confirm.

9. Web and Data Services 79

Web and Data

Downloading Applications and Games From Marketplace

On Windows® Marketplace, it’s easy to download and purchase new applications, games, and music that fit your needs and make your device truly personal. A wide range of free and premium programs is available, from games to powerful business applications. You can also preview and purchase songs on the Marketplace.

To access Marketplace on your device:

1. On the Start screen, tap Marketplace.

2. Browse through available apps, games, and music.

When you find something you want, tap

install (for free items), and follow the onscreen

instructions to purchase and download your item.

80 9. Web and Data Services

buy or

Important: Sprint’s policies often do not apply to third-party

applications. Third-party applications may access your personal information or require Sprint to disclose your customer information to the thirdparty application provider. To find out how a thirdparty application will collect, access, use, or disclose your personal information, check the application provider’s policies, which can usually be found on their website. If you aren’t comfortable with the third-party application’s policies, don’t use the application.

HTC Hub

In the HTC Hub, you’ll find applications from HTC that are preinstalled on your device and other applications that are available for download. Open the HTC Hub from time to time to check for new applications and updates.

Opening the HTC Hub

䊳 Ta p HTC Hub on the Start screen or the

applications list.

The HTC Hub main screen displays your current date, time, and location, as well as the weather for your location. Tap the weather image to open the Weather application and check for more weather forecasts. To find out more about checking weather, see “Weather” on page 82.

You’ll also see a list of featured applications from HTC. Tap to refresh the feature list. To check for more applications to download, tap .

What’s in the HTC Hub

These are some of the applications that the HTC Hub offers. Some are already preinstalled on your device, while others are available for download.

Sound Enhancer

Get that surround sound feeling when you’re watching videos or listening to music on your device.

YouTu be

Browse, search, and watch YouTube videos right on your device.

Photo Enhancer

Photos need a bit of touch-up? Use one of the available photo enhancements to touch up your photos.

Notes

Scribble short reminders to yourself.

9. Web and Data Services 81

Web and Data

Stocks

Get instant updates to stocks you care about.

Calculator

Hold your device upright and you get a basic calculator. Turn your device to the side and you get a scientific calculator.

Flashlight

Use the camera flash at the back of your device as a flashlight.

Lists

Keep track of to-do’s or make a shopping list with this application.

Love

He loves me, he loves me not, he loves me! See whether that special someone is feeling the same way as you are.

Attentive Phone

Make your device smarter by allowing it to respond in a natural way to your actions and environment. This application will give you control over special features such as pocket mode, flip to mute ringer, and more.

82 9. Web and Data Services

Converter

Carry a convenient, multipurpose conversion tool in your hand. Convert area, currency, temperature, weight, and more.

Weather

On your device, you can check the current weather as well as weather information for the next four days of the week. You can check the weather forecasts for your city and other cities around the globe as well. If you consented to turn location service on, you’ll see the weather of your current location right on the weather clock in HTC Hub.

Note: Turn location services on your device so that you’ll be

able to check your current location’s weather in HTC Hub. Go to

Location services switch if it’s not on.

Settings > location, and then tap the

Checking the Weather

1. Ta p HTC Hub on the Start screen.

The weather for your current location is displayed on the weather clock in HTC Hub.

2. Tap the weather image to open the Weather

screen.

3. To check the weather in other cities, you can:

䡲 Swipe your finge r up or d own the screen to ch eck

the weather in other cities.

䡲 Tap and then tap a city to check its weather.

Adding a City

1. On the Weather screen, tap .

2. Enter the location you want to add on the text box.

As you enter text, the list is filtered to show the possible locations based on the letters you entered.

3. Tap the city to select it.

Changing the Order of Cities

1. On the Weather screen, tap and then tap edit

locations.

2. Press and hold at the end of the item you want

to move. When the row is highlighted, drag it to its new position, and then release.

3. Tap done.

9. Web and Data Services 83

Web and Data

Changing Weather Options

1. On the Weather screen, tap and then tap

settings.

2. Choose the settings that you want.

Sprint Zone

Get the latest news, applications, and tips and tricks for your device in the Sprint Zone.

To open Sprint Zone:

䊳 Ta p Sprint Zone on the Start screen or the

applications list.

84 9. Web and Data Services

⽧ Signing Into Xbox LIVE (page 85)

10. Games

⽧ Games Hub (page 86)

⽧ Downloading and Installing Xbox LIVE Extras (page 86)

Join in and play Xbox LIVE® games right on your device. Download games from Windows Phone Marketplace, then either play solo or use the Xbox LIVE service to play with your friends wherever they are.

Signing Into Xbox LIVE

If you already signed in with a Windows Live ID that is associated with a gamertag (your Xbox LIVE player ID) when you first turned on and set up your device, then you’re also signed into Xbox LIVE and you can start accessing and playing games in the Games Hub.

If you haven’t signed in yet, follow the steps below to log into Xbox LIVE.

1. Press and tap Games to open the Games Hub.

2. Swipe your finger horizontally across the screen to

go to

Xbox LIVE. Then tap Join Xbox LIVE to play

with friends.

3. When you see the “Windows Live ID required”

message, tap

4. Follow the onscreen instructions to sign in using

your Windows Live ID or create a new Windows Live ID if you don’t have one yet.

10. Games 8 5

Games

Games Hub

After successfully signing into Xbox LIVE, you’ll see the following in the Games Hub:

collection

spotlight

Xbox LIVE

requests

86 10. Games

Lists games you can download and try out on your device. Tap one to download it from Windows Phone Marketplace and install it on your device. To choose from more games, tap bottom of the list.

Games that you’ve already purchased or downloaded are also listed. Tap a game to open it and start playing.

Shows links to news, tips, and all kinds of information on Xbox LIVE.

Displays your profile such as your gamertag and avatar.

Displays new game invitations and also alerts to notify that it’s your turn to play. Tap one to accept an invitation or play your turn. You can also invite others to play with you.

Get more games at the

Downloading and Installing Xbox LIVE Extras

If you’d like to change your gamertag or dress up your avatar from your device, you need to download and install Xbox LIVE Extras from Windows Phone Marketplace. This free application also allows you to track your achievements in your games and connect with your Xbox LIVE friends.

䊳 In the Xbox LIVE screen of the Games Hub, just tap

anywhere on the screen and follow the onscreen instructions to download and install Xbox LIVE Extras.

1. On the Start screen, tap .

11. GPS Navigation

2. Ta p Settings > location.

3. Tap the Location services switch if it’s not on.

⽧ GPS and Location Services (page 87)

⽧ TeleNav GPS Navigator (page 87)

⽧ Bing Maps (page 88)

GPS and Location Services

Your device’s built-in GPS capability allows you to get voice-guided, turn-by-turn directions using

Navigator. In addition, you can use Bing Maps to view

maps, get textual directions to a destination, find an address or place, and more.

Tel eNa v GP S

Turning on Location Services

Before using TeleNav GPS Navigator and Bing Maps, check and make sure your device’s location services setting is turned on.

TeleNav GPS Navigator

TeleNav GPS Navigator™ gives you turn-by-turn directions onscreen and over speakerphone.

Note: Depending on your service plan, TeleNav GPS

Navigator may require a monthly subscription.  Contact Sprint for information and pricing.

Registering TeleNav GPS Navigator

Before you can use TeleNav GPS Navigator, your device and service must be registered.

1. Ta p Tele Nav GPS Na v on the Start screen or the

applications list.

2. Follow the onscreen instructions to register your

device.

11. GPS Na vig at ion 87

GPS Navigation

Note: If it’s your first time to open and use TeleNav GPS

Navigator, you’ll see a message prompting you whether to allow the application to access your current location and provide voice-guided turn-by-turn directions based on your location.

Using TeleNav GPS Navigator

After opening TeleNav GPS Navigator, choose an option and follow the onscreen instructions to get directions, view maps, or access additional services and options.

䢇 drive to lets you enter an address (by either speaking

it or by entering it on the keypad) or select from categories such as recent places, my favorites, or business to search for turn-by-turn directions.

䢇 search provides a categorized list of locations such

as gas stations, grocery stores, and hospitals to help find local businesses and services.

䢇 maps & traffic lets you view the map and get traffic

information for your current location. You can also search for any other location (same categories as

drive to) and view it on the map.

88 11. GPS Navigation

䢇 tools & extras provides additional information and

services such as weather, commute alerts, available movies, and more. You can also choose your preferred settings for GPS navigation.

Bing Maps

Use Bing Maps to view maps, check real-time traffic situations, and receive detailed directions to your destination. You can also use it to search for a location such as an address, landmark, or name of businesses.

Note: You need an active mobile data or Wi-Fi connection to

use Bing Maps.

To find your location with Bing Maps, you need to enable location services. To learn how, see “Turning on Location Services” on page 87.

The Bing Maps application does not cover every country or city.

Getting Around Maps

Viewing Your Location on the Map

1. On the Start screen, tap .

2. Ta p Maps.

Note: If this is your first time to open Bing Maps, you’ll be

prompted whether to allow Maps to access and use your location. Tap

3. Tap .

Moving Around the Map

Drag your finger in any direction across the screen to view other areas on the map.

Zooming In or Out of the Map

To zoom in, place your thumb and index fingers on top of the area that you want to zoom in, and then spread your fingers across the map. Pinch your thumb and index finger on the map to zoom out.

You can also double-tap the map to zoom in on a spot. Double-tap again to zoom in even closer.

allow.

Getting Information About a Location

You can easily find out about the address and other information about a location that you see on the map.

1. Press and hold a location on the map.

2. A balloon opens over the location with the address.

Tap the balloon to see more information.

GPS Navigation

You can then choose to get directions to the location, pin the location to the Start screen, share the location via text message or email, and more.

11. GPS Navigation 89

Viewing Traffic Conditions

Traffic information is available only in certain areas. You can choose to show real-time traffic conditions on the map.

䊳 While viewing a map, tap and then tap show

traffic.

On the map, traffic information is shown on roadways in different colors, depending on driving speeds and conditions.

Switching to Aerial View

View satellite imagery by switching to aerial view.

䊳 While viewing a map, tap and then tap aerial

view on.

To switch back to map view, tap again and then tap

aerial view off.

Clearing the Map

After you get directions or search on a map, you can clear away the various markers that such activities have drawn on the map.

䊳 Tap and then tap clear map.

90 11. GPS Navigation

Searching For an Address or Place

1. While viewing a map, tap .

2. In the search box, enter an address, zip code,

landmark, business name or type, or city, and then tap on the onscreen keyboard.

3. Search results will be displayed as markers on the

map. Tapping a marker will display a balloon that shows a location that matches your search. You can tap the balloon to see that location’s address, rating, nearby places, and reviews, if available.

Tip: To see the search results as a list, tap and then tap

results list.

Getting Directions

Get detailed directions to your destination. Bing Maps can provide directions for travel by foot or car.

1. While viewing a map, tap .

2. In the Start text box, use your current location as

the starting point, or enter another location from where you want to start.

End text box, enter your destination and then

In the tap on the onscreen keyboard.

Tip: Tapping Start or End reverses the starting or ending

locations in the text boxes.

3. Tap to see walking directions or tap to view

driving directions.

4. In the list of directions to your destination, you can:

䡲 Scroll the list to view the complete directions. 䡲 Tap a direction to see it highlighted on the map.

GPS Navigation

11. GPS Na vig at ion 91

This User Guide contains important operational and

12. Imp ortant Safety

Information

safety information that will help you safely use your device. Failure to read and follow the information

provided in this guide may result in serious bodily injury, death, or property damage.

⽧ Important Health Information and Safety

Precautions (page 92)

⽧ General Precautions (page 99)

⽧ Additional Safety Information (page 102)

⽧ Regulatory Agency Identifications (page 108)

⽧ Federal Communication Commission Interference

Statement (page 109)

⽧ SAR Information (page 112)

⽧ Telecommunications & Internet Association (TIA) Safety

Information (page 113)

⽧ WEEE Notice (page 114)

⽧ RoHS Compliance (page 115)

⽧ Owner’s Record (page 115)

⽧ Basics Guide Proprietary Notices (page 116)

92 12. Important Safety Information

Important Health Information and Safety Precautions

When using this product, the safety precautions below must be taken to avoid possible legal liabilities and damages.

Retain and follow all product safety and operating instructions. Observe all warnings in the operating instructions on the product.

To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following precautions.

Electrical Safety

This product is intended for use when supplied with power from the designated battery or power supply unit. Other usage may be dangerous and will invalidate any approval given to this product.

Safety Precautions for Proper Grounding Installation

CAUTION: Connecting to an improperly grounded

equipment can result in an electric shock to your device.

This product is equipped with a USB cable for connecting with desktop or notebook computer. Be sure your computer is properly grounded (earthed) before connecting this product to the computer. The power supply cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with all local codes and ordinances.

Safety Precautions for Power Supply Unit

䢇 Use the correct external power source

A product should be operated only from the type of power source indicated on the electrical ratings label. If you are not sure of the type of power source required, consult your authorized service provider or local power company. For a product that operates from battery power or other sources, refer to the operating instructions that are included with the product.

This product should be operated only with the following designated power supply unit(s). 

AC Adapter HTC, Model TC U250

䢇 Handle battery packs carefully

This product contains a Lithium-ion polymer or Lithium-ion battery. There is a risk of fire and burns if the battery pack is handled improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture, short external contacts or circuits, dispose of in fire or water, or expose a battery pack to

temperatures higher than 140°F (60

12. Important Safety Information 93

°C).

Important Safety Information

WARNING: Danger of explosion if battery is incorrectly

Note: This product should be operated only with the following

replaced. To reduce risk of fire or burns, do not disassemble, crush, puncture, short external contacts, expose to temperatures above 140°F (60°C), or dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries according to the local regulations or reference guide supplied with your product.

designated Battery Pack(s). 

HTC, Model RHOD160.

94 12. Important Safety Information

Take Extra Precautions

䢇 Keep the battery or device dry and away from water

or any liquid as it may cause a short circuit.

䢇 Keep metal objects away so they don’t come in

contact with the battery or its connectors as it may lead to short circuit during operation.

䢇 The device should only be connected to products

that bear the USB-IF logo or have completed the USB-IF compliance program.

䢇 Do not use a battery that appears damaged,

deformed, or discolored, or the one that has any rust on its casing, overheats, or emits a foul odor.

䢇 Always keep the battery out of the reach of babies

and small children, to avoid swallowing of the battery. Consult the doctor immediately if the battery is swallowed.

䢇 Only use the battery with a charging system that has

been qualified with the system per this standard, IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of fire, explosion, leakage or other hazard.

䢇 Replace the battery only with another battery that has

been qualified with the system per this standard, IEEE-Std-1725-2006. Use of an unqualified battery may present a risk of fire, explosion, leakage or other hazard.

䢇 Avoid dropping the device or battery. If the device or

battery is dropped, especially on a hard surface, and the user suspects damage, take it to a service center for inspection.

䢇 If the battery leaks:

䡲 Do not allow the leaking fluid to come in contact

with skin or clothing. If already in contact, flush the affected area immediately with clean water and seek medical advice.

䡲 Do not allow the leaking fluid to come in contact

with eyes. If already in contact, DO NOT rub; rinse with clean water immediately and seek medical advice.

䡲 Take extra precautions to keep a leaking battery

away from fire as there is a danger of ignition or explosion.

Safety Precautions for Direct Sunlight

Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.

Prevention of Hearing Loss

CAUTION: Permanent hearing loss may occur if

earphones or headphones are used at high volume for prolonged periods of time.

Safety in Aircraft

Due to the possible interference caused by this product to an aircraft’s navigation system and its communications network, using this device’s phone function on board an airplane is against the law in most countries. If you want to use this device when on

12. Important Safety Information 95

Important Safety Information

board an aircraft, remember to turn off your phone by switching to airplane mode.

Environmental Restrictions

Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could cause an explosion or fire resulting in bodily injury or even death.

Explosive Atmospheres

When in any area with a potentially explosive atmosphere or where flammable materials exist, the product should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at refueling points such as service or gas stations, and are reminded of the need to observe

96 12. Important Safety Information

restrictions on the use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas, below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals or particles, such as grain, dust, or metal powders.

Road Safety

Full attention must be given to driving at all times in order to reduce the risk of an accident. Using a phone while driving (even with a hands-free device) causes distraction and can lead to an accident. You must comply with local laws and regul ations rest ricting the use of wireless devices while driving.

Safety Precautions for RF Exposure

䢇 Avoid using your phone near metal structures (for

example, the steel frame of a building).

䢇 Avoid using your phone near strong electromagnetic

sources, such as microwave ovens, sound speakers, TV and radio.

HTC Arrive Quick Start Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Table of Contents

1. Device Basics

Your Device

Key Functions

Turning Your Device On and Off

Turning Your Device On

Turning Your Device Off

Turning the Screen Off When Not in Use (Sleep Mode)

Hubs

What Do the Icons on My Device Mean?

Notification LED

Battery and Charger

About the Battery

Removing the Battery

Charging the Battery

Displaying Your Phone Number

Making and Answering Calls

Making Calls

Receiving Calls

Missed Call Notification

Calling Emergency Numbers

In-Call Options

Entering Text

Using the Slideout Hardware Keyboard

Using the Onscreen Keyboard

2. Settings

Personalization Settings

Changing Your Theme

Sound Settings

Phone Ring Tone

Notification Sound

Adjusting the Device’s Volume Settings

Vibrate

Silence All

Controlling Keypress Sound

Display Settings

Changing the Screen Timeout Period

Adjusting the Brightness

Location Settings

TTY Use With Sprint Service

Airplane Mode

Security Settings

Protecting Your Device With a Password

Protecting Your Device Through the Web

Updating Your Device’s System Software

Resetting Your Device

Security Features for Data Services

Email and Account Settings

Setting Up Your Accounts

Manually Synchronizing Your Accounts

Deleting an Account

What You Can Do With Your Windows Live Account

Your Google Account and Exchange ActiveSync

Your Facebook Account

Date & Time Settings

Setting Local Date, Time Zone, and Time

3. Contacts

About the People Hub

Viewing Your Contacts and Their Feeds

Adding a New People Entry

Saving a Phone Number

Viewing Contact Information

Merging Entries in People

Manually Merging Entries in People

Unlinking Entries

Editing an Entry in People

Displaying an Entry in People

Adding a Number or an Email Address to an Entry in People

Editing an Entry in People

Selecting a Ringer Type for an Entry

Assigning a Picture to an Entry

Adding Additional Information to an Entry

Deleting an Entry

Finding Entries in People

Your Me Tile

4. Calendar & Tools
