QuickSpecs
HPE Online Double Conversion Rackmount
Uninterruptible Power System

Overview

1
HPE Online Double Conversion Rackmount Uninterruptible Power System
Does your IT workload require high availability power protection?
The HPE Online Double Conversion Rackmount Uninterruptible Power System
enables high system availability by eliminating transfer time to battery power for all connected IT equipment. HPE Enhanced Battery Management technology improves battery service life by up to 50% while monitoring battery health and providing advanced notice when replacement is required. Scale system runtime from minutes to hours by adding up to four Extended Runtime Modules.
The HPE Online Double
etwork Management Module that provides access to the UPS and its embedded web-based user interface, allowing you to monitor and manage individual UPS systems. With Eaton® Intelligent Power Manager software, users can centralize remote monitoring and management of multiple HPE UPS systems and seamlessly integrate them into virtualization
, to manage virtual machines
and extend battery runtime.
HPE Line Interactive Single Phase Uninterruptible Power Systems (UPS)
(UPS)
Conversion UPS includes a 1GbE N
and hyperconverged platforms, such as VMware and HPE SimpliVity
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
2
Models
R5000 UPS Models
HPE G2 R5000/L6-30P 24A/208V Outlets (2) L6-20R (2) L6-30R/3U NA/JP UPS
Q7G09A
HPE G2 R5000/L6
Q7G10A
R6000 UPS Models
HPE G2 R6000/60309 3
Q7G11A
R8000 UPS Models
HPE G2 R8000/Hardwire/208V Outlets (4) L6-20 (2) L6-30/6U Rackmount NA/JP UPS
Q7G12A
HPE G2 R8000/Hardwire/230V Outlets (6) C19 (2) IEC 32A/6U Rackmount INTL UPS
Q7G13A
Front View R5000 UPS (Q7G09A and Q7G10A)/ R6000 UPS (Q7G11A)
1.
Escape Button
4.
Enter/Select button
2.
Scroll up button
5.
Power button
3.
Scroll down button
-30P 24A/208V Outlets (4) C19 (1) L6-30R/3U NA/JP UPS
-wire 32A/230V Outlets (4) C13 (4) C19 (1) IEC 32A/3U Rackmount INTL UPS
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
3
Rear View R5000 UPS (Q7G09A)
1.
Remote Power Off
8.
20A L6-20R receptacles
2.
1GbE UPS Network Management Module
9.
Circuit Breakers for L6-20R receptacles
3.
Contacts (for reporting status of UPS)
10.
RS232 Serial Communications Port
4.
Remote On/Off
11.
USB Serial Communications Port
5.
Chassis ground terminal
12.
Power from ERM
6.
Input power line cord with NEMA L6-30 plug
13.
Battery Detection (ERM)
7.
30A L6-30R receptacles
Rear View R5000 UPS (Q7G10A)
1.
Remote Power Off
8.
30A L6-30R receptacle
2.
1GbE UPS Network Management Module
9.
Circuit Breakers for C19 receptacles
3.
Contacts (for reporting status of UPS)
10.
RS232 Serial Communications Port
4.
Remote On/Off
11.
USB Serial Communications Port
5.
IEC C19 receptacles
12.
Power from ERM
6.
Chassis ground terminal
13.
Battery Detection (ERM)
7.
Input power line cord with NEMA L6-30 plug
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
4
Rear View R6000 UPS (Q7G11A)
1.
Remote Power Off
8.
IEC 32A receptacle
2.
1GbE UPS Network Management Module
9.
IEC C13 receptacles
3.
Contacts (for reporting status of UPS)
10.
20A Circuit Breaker for load segments 1 & 2, respectively
4.
Remote On/Off
11.
RS232 Serial Communications Port
5.
IEC C19 receptacles
12.
USB Serial Communications Port
6.
Chassis ground terminal
13.
Power from ERM
7.
Input power cord with 3-pin IEC 32A plug
14.
Battery Detection (ERM)
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
5
Front View R8000 UPS (Q7G12A and Q7G13A)
1.
Escape Button
4.
Enter/Select button
2.
Scroll up button
5.
Power button
3.
Scroll down button
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
6
Rear View R8000 UPS (Q7G12A)
1.
Remote Power Off
8.
Chassis ground terminal
2.
Battery Detection (ERM)
9.
Hardwire input power
3.
1GbE UPS Network Management Module
10.
Circuit Breakers for L6-20R receptacles
4.
USB Serial Communications Port
11.
20A L6-20R receptacles
5.
Remote On/Off
12.
30A L6-30R receptacles
6.
Contacts (for reporting status of UPS)
13.
Power from ERM
7.
RS232 Serial Communications Port
14.
Circuit Breakers for L6-30R receptacles
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Overview
7
Rear View R8000 UPS (Q7G13A)
1.
Remote Power Off
8.
Chassis ground terminal
2.
Battery Detection (ERM)
9.
Hardwire input power
3.
1GbE UPS Network Management Module
10.
Circuit Breakers for C19R receptacles
4.
USB Serial Communications Port
11.
16A C19R receptacles
5.
Remote On/Off
12.
Circuit Breakers for IEC receptacles
6.
Contacts (for reporting status of UPS)
13.
32A IEC receptacles
7.
RS232 Serial Communications Port
14.
Power from ERM
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System

Standard Features

8
HPE Online Double Conversion UPS Technology
The HPE Online Double Conversion UPS operates by using online double conversion technology that converts incoming AC
The conversion to DC power supports a constant interface
Availability
Enhanced Battery Management technology that uses an advanced, three-stage charging technique that increases
overload or fault has occurred.
Manageability
ships standard with
cols with all connected
Next-generation intuitive LCD interface that provides a graphical display of all critical UPS information in a single view
Serviceability
when
allow trained users to perform upgrades and replacements of the batteries reducing Mean Time
Flash upgradeable firmware allow users to conveniently install firmware maintenance releases remotely using FTP
Consolidate and Centralize UPS Management with Eaton Intelligent Power Manager
tested for interoperability, Eaton's Intelligent Power Manager®
virtual environment,
Initiate live migration of virtual machines (VMs) to automatically and transparently migrate them during power
machines, and shut down unused servers to
et of capabilities to
enhance HPE solution performance.
power to DC power, and then back to AC power when exiting the UPS. with the UPS battery, isolating output power from input power 100% of the time and ensuring zero transfer time to battery power.
battery service life by up to 50%
Scale system runtime from hours to minutes by adding up to 4 Extended Runtime Modules (ERM) per UPS
Internal bypass guarantees that connected loads will continue to have access to utility power in the event a system
Access the embedded UPS user interface using the HPE 1GbE Network Management Module that each model
Use HPE Power Protector to manage individual UPS systems and communicate shutdown proto
servers
Enhanced Battery Management closely monitors battery health to provide advanced notice (up to 30 days)
batteries need replacement
Hot-swappable batteries
to Repair while improving system uptime and access to power when battery maintenance is required
HPE and Eaton are collaborating to bring increased value. Lab­(IPM) software provides the tools needed to monitor and manage power equipment in your physical or keeping IT devices up and running during a power or environmental event.
Remotely monitor and manage multiple HPE power devices across your network from a single interface
Ensure availability and data integrity of HPE SimpliVity hyperconverged systems
o Provides a complete view of both the IT and power infrastructure in a single console o Dynamically move VMs with automated policies based on environmental conditions
Recover VMs in the correct sequence based on criticality
Mitigate equipment overheating and power anomalies through integration with HPE OneView:
o Communicate actions to the HPE server via HPE iLO
Seamlessly integrate with VMware®, and other leading virtualization platforms
o Trigger preventive actions such as power capping based on environmental conditions o
disruptions to unaffected devices
o Suspend non-critical virtual machines, consolidate critical virtual
extend battery runtime
o Gracefully shutdown computers, VMs and host servers during an extended power outage
Eaton IPM offers three levels of licenses: Monitor, Basic and Gold. IPM Gold provides the most complete s
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Standard Features
9
Features
IPM Monitor
IPM Basic
IPM Gold
Supported UPS nodes
Up to 500
Up to 500
Up to 500
Supported rack PDU nodes
Up to 200
Up to 200
Up to 200
Auto discovery
Mass firmware upgrade tool
Mass node-settings configuration tool
Send email notifications
Monitor third-party devices
Event-based PDU outlet control
Virtualized host shutdown
Power capping of HPE servers
Targeted VM migration
Targeted VM graceful shutdown
Shares data with VMware’s vRealize Operations
 Trigger actions from third-party devices
The Eaton IPM Monitor is available via free download:
https://powerquality.eaton.com/products-services/power-management/software-drivers/intelligent-pm.asp
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System

Configuration Information

10
UPS Network Module
All HPE G2 Online Double Conversion UPS The HPE UPS Network Module enables you to monitor and manage power environments through comprehensive control of HPE UPSs. The HPE UPS Management Module can support either a single UPS configuration or provide additional power protection with support for dual redundant UPS configuration for no
failure. The additional serial ports will provide greater
power management control and flexible monitoring.
The management module can be configured to send alert traps to HPE Systems Insight Manager and other SNMP management programs or used as a standalone management system. This flexibility enables you to monitor and manage UPSs through the network. To facilitate day
The HPE UPS Network Module provides remote management of a UPS by connecting the UPS directly to the network. Configuration & Management of the UPS from anywhere and at any time via a standard
Extended Runtime Modules (ERM)
HPE G2 R5000/6000 3U Extended Runtime Module
Q7G14A
HPE G2 R8000 3U Extended Runtime Module
Q7G15A
Extended Runtime Modules increase the available runtime for the larger rack mounted UPS units to allow customers to ensure all of their applications can be gracefully shutdown in the event of a power failure.
NOTE: #0D1 will appear after the part number on the sales order if HPE factory integration is indicated. (Up to 4 ERMs can be
chosen)
3U/6U UPS ERM Shipping Kit
HPE 3U/6U Rack/Tower UPS Shipping Kit
Q9Z44A
HPE G2 Online Double Conversion UPS models require
NOTE: The shipping kit consists of a heavy duty shelf and required mounting hardware for attaching the UPS or ERM to the
rack. This kit is an option that is only required if the UPS and or ERM are going to be mounted into a rack that will be shipped via transport. One of these kits is required per unit, whether UPS or ERM.
Jumper Cord Options
HPE 2m 16A C19-C20 Jumper Cord
AF574A
HPE 1.2m 16A C19-C20 Jumper Cord
AF575A
Note: Standard, non-locking IEC jumper cable for worldwide use.
HPE C19/C20 WW 16A 0.7m Black Locking Jumper Cord
Q0R19A
HPE C19/C20 WW 16A 1.2m Black Locking Jumper Cord
Q0P71A
HPE C19/C20 WW 16A 2m Black Locking Jumper Cord
Q0P72A
HPE C19/C20 WW 16A 2.5m Black Locking Jumper Cord
Q0P73A
HPE C19/C20 WW 16A 0.7m 6pc Black Locking Jumper Cord
Q0R15A
HPE C19/C20 WW 16A 1.2m 6pc Black Locking Jumper Cord
Q0R16A
HPE C19/C20 WW 16A 2m 6pc Black Locking Jumper Cord
Q0R17A
HPE C19/C20 WW 16A 2.5m 6pc Black Locking Jumper Cord
Q0R18A
Note: Locking IEC jumper cable that will lock to server, switch, or PDU input power outlet. Compatible, but will not lock to UPS.
HPE 3.6m C19-NEMA L6-20P NA/JP Power Cord
AF593A
Note: NEMA to IEC jumper cord that can connect to L6-20 receptacles on NA/JPN models.
models include the 1GbE UPS Network Module as standard.
-single-point-of-
-to-day maintenance tasks, the embedded management software provides detailed system logs.
web browser.
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System

Service and Support

11
Warranty
When you need it, use outstanding HPE support services for your whole data center environment. With HPE Pointnext operational services, have the security of knowing that your HPE UPS will be covered at the same service level and coverage period as your HPE server. HPE G2 Online Double Conversion UPSs are backed by a 3-year warranty, which covers depot repair of the UPS, or direct replacement of the UPS. Also, standard on all HPE UPS units is our exclusive 30
Failure Warranty, which ensures
t
ee of
charge under the warranty. This warranty is offered worldwide.
Service and Support HPE Technology Services
HPE Technology Services offers you consultants and support experts to solve your most complex infrastructure problems. We help keep your business running, boost availability and avoid downtime.
Protect your business beyond warranty with HPE Pointnext operatio
When you buy HPE Options, it's also a good time to think about what level of service you may need. HPE Pointnext operational services provide total care and support expertise with committed response choices designed to meet your IT and busines
For ProLiant servers and storage systems, this service covers HPE-branded hardware options qualified for the server, purchased at the same time or afterward, internal to the enclosure, also including PDU, ITAC, and UPS products (less than 12 kVA). These items will be covered at the same service level and for the same coverage period as the server unless the maximum supported lifetime and/or the maximum usage limitation has been exceeded. Coverage of the UPS battery is not included; standard warranty terms and conditions apply.
For more information To learn more on services for HPE Options, please contact your Hewlett Packard Enterprise sales representative or Hewlett Packard Enterprise Authorized Channel Partner. Or visit: https://www.hpe.com/us/en/services/operational.html
-day Battery Pre-
hat when customers receive notification from HPE Power Manager Software that the battery may fail, the battery is replaced fr
nal services
s need.
https://www.hpe.com/us/en/support.html or
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Technical
Specifications
12
Model Matrix - HPE G2 R5000, R6000, and R8000 UPS Models
Model
Part Number
Operating
Voltage Settings
Power Out
(VA/Watts)
Input Connection
Output
Connection
Breaker Amp Rating/ Single of Double Pole
4x C-13
1x IEC 32A
Supports switchable load segments: LS1: 2x C-13, 2x C-19; LS2: 2x C-13, 2x C-19
Runtime Tables R5000 UPS – Models Q7G09A, Q7G10A
25%
50%
75%
100%
Internal Battery
27
11
5.3
3.2
+ 1 ERM
103
48
27
20
+ 2 ERM
175
88
53
38
+ 3 ERM
262
123
83
54
+ 4 ERM
377
167
109
80
NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions. Runtime given in minutes. Assumes 0.9 PF.
R6000 UPS – Model Q7G11A
25%
(Minutes)
50%
75%
100%
Internal Battery
22
8.5
4.5
3
+ 1 ERM
85
38
24
16
+ 2 ERM
147
71
45
28
+ 3 ERM
214
104
62
47
+ 4 ERM
287
133
90
58
NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions. Runtime given in minutes. Assumes 0.9 PF.
R5000 Q7G09A
200 5000VA / 4500W
208 5000VA / 4500W
L6-30P
(10ft power cord)
2x L6-20R 2x L6-30R
20A / Double Pole
200 5000VA / 4500W
R5000 Q7G10A
208 5000VA / 4500W
R6000* Q7G11A 230V 6000VA / 5400W
200 8000VA / 7200W
R8000 Q7G12A
208 8000VA / 7200W
R8000 Q7G13A 230V 8000VA / 7200W
Load
(Minutes)
(Minutes)
L6-30P
(10ft power cord)
IEC 32A
(10ft power cord)
Terminal Block
(Hardwire)
Terminal Block
(Hardwire)
4x C-19
1x L6-30R
4x C-19
4x L6-20R 2x L6-30R
6x C-19
2x IEC 32A
(Minutes)
20A / Double Pole
16A / Single Pole
20A/2 pole for 4x L6-20R 30A/2 pole for 2x L6-30R
16A/1pole for 6x C19
32A/1pole for 2x IEC 32A
(Minutes)
Load
(Minutes)
(Minutes)
(Minutes)
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Technical Specifications
13
R8000 UPS – Model Q7G12A
25%
50%
75%
100%
Internal Battery
35
16 9 5
+ 1 ERM
85 36
23
16
+ 2 ERM
140
+ 3 ERM
173
86
53
36
+ 4 ERM
220
118
72
50
NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions.
R8000 UPS – Model Q7G13A
25%
(Minutes)
50%
(Minutes)
75%
(Minutes)
100%
(Minutes)
Internal Battery
28
12
6.5
3.5
+ 1 ERM
72
29
18
12
+ 2 ERM
112
51
29
21
+ 3 ERM
151
73
46
29
+ 4 ERM
185
95
58
42
NOTE: Backup times are estimated for typical applications. Actual performance will depend on load and battery conditions. Runtime given in minutes. Assumes 0.9 PF.
Load
(Minutes)
Runtime given in minutes. Assumes 0.9 PF.
Load
(Minutes)
(Minutes)
65 36 27
(Minutes)
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Technical Specifications
14
Electrical Input
Voltage Range
200 – 250VAC
Frequency
40/60 Hz (if 50Hz input)
Online Efficiency Mode
92.8% (R5000 models)
94.5% (R6000, R8000 models)
High Efficiency Mode
98% all models
Electrical Output
On battery Regulation
-10% to +6% of nominal voltage
Voltage Wave Form
Sinusoidal
Connections
See Model Matrix
Output protection
Firmware overload sensing and control
Battery
Type
Maintenance-free, rechargeable, valve regulated lead-acid batteries
Extended Runtime Modules
Add up to 4 ERM’s per UPS model
Backup Time
See Runtime Tables
Recharge Time
<4 hours to charge 90% usable capacity. <24 hours for complete recharge
Voltage
R5KVA, R6KVA = 180VDC
Communications
Serial Ports
RS232 (via RJ45 connector to DB9) and USB ports (ships with communication cables)
Network Communication
Includes HPE 1GbE Network Management Module
LCD Interface
LCD Display and Button Interface on front panel
Management Software
HPE Power Protector and HPE Intelligent Power Manager included via free download
Environmental and
Operating Temperature
0°C to 40°C (32°F to 104°F )
Non-operating Temperature
-15°C to 40°C (5°F to 104°F) (with battery)
-15°C to 50°C (5°F to 122°F) (without battery)
Operating Humidity
0% to 95% (non-condensing)
Storage Humidity
5% to 90% (non-condensing)
Operating Altitude
Up to 1500 m above sea level
Audible Noise
<45dB at 1m (MX ref.) for R5000/6000 models <48dB at 1m (EXRT ref.) for R8000 models
Safety Markings
NA/JPN: UL/cUL, FCC Class A, NOM,VCCI INTL: CE, TUV, C-tick, EAC, KCC, BSMI
Safety Certifications
UL1778, UL60950-1; CSA22.2 No.107.3-05,; EN609501-, EN62040-1 EMC Markings
FCC-A; CISPR 22; VCCI A; CE, BSMI, C-TICK
Emissions
FCC CFR 47, Part 15 Class A, EN50091-2
Immunity 6; IEC 61000-4-11
Surge Suppression
Conforms to IEEE 587B and ANSI C62.41
RPO/ROO
The Normally Closed (NC) RPO shuts off power to all UPS outlets when
closed
The Normally Open (NO) ROO initiates a UPS Power On function when closed. Opening the terminals again will shut off the UPS
R8KVA = 240VDC
Safety
IEC62040-1-1, IEC 60950-1
EN 55024; EN 50091-2 consisting of IEC 61000-4-2 thru IEC 61000-4-
opened. The UPS must be manually restarted once the terminals are again. There is a preinstalled jumper in the RPO terminals.
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System
Technical Specifications
15
Environment-friendly Products and Approach - End-of-life Management and Recycling
, in many geographic areas, for
The EU WEEE Directive (2012/19/EU) requires manufacturers to provide treatment information for each product type for use by
. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs our products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site
Page
QuickSpecs
HPE Online Double Conversion Rackmount Uninterruptible Power System

Summary of Changes

16
Date
Version History
Action
Description of Change
02-Apr-2019
Version 1
New
New QuickSpecs.
Sign up for updates
© Copyright 2019 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pr Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

a00062176enw - 16376 - Worldwide - V1 - 02-April-2019

oducts and services.
Page
Loading...
