QuickSpecs
HPE StoreEver MSL3040 Tape Library
Overview
Page 1
HPE StoreEver MSL3040 Tape Library
The highly scalable HPE StoreEver MSL3040 Tape Library provides small to mid-sized organizations with flexibility for long-term
records, video surveillance files or for business compliance.
HPE StoreEver MSL3040 Tape Library
21U Rack with 6 Expansion Modules
What's New
• New MSL3040 tape library with support for LTO-8, LTO-7 and LTO-6 FC and SAS drive upgrade kits and media
• MSL3040 now supports LTO-7 Type M media
data protection and retention of data storage assets. With its modular design and ability to reuse existing HPE MSL LTO upgrade
drive kits, you can cost-effectively store up to 8.16 PB compressed with LTO-8 media. The HPE StoreEver MSL3040 Tape
Library offers exceptional enterprise features and functionality as standard providing advanced security features and reliability. It
delivers a tape storage solution that addresses backup and long-term data management challenges such as storing medical
Industry leading scalability - from 32-slot Base Library Module to 272 slots in a
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Overview
Page 2
Key Features
• High scalability - pay as you grow with the fast, non-disruptive addition of Expansion Modules
Tape Libraries can repurpose their
o Achieve higher levels of availability with data path failover and control path failover.
MSL3040
Drive Technology
Supported
LTO-8 Ultrium 30750
LTO-6 Ultrium 6250
Maximum Number of
Drives
21 HH
Maximum Capacity
(2.5:1 compression)
960 TB (LTO-8, 32 slots)
Maximum Data Transfer
(Native)
22.5 TB/hr (21 LTO-8 drives)
Drive Interface
8 Gb/sec Fibre Channel
6 Gb/sec SAS
for expansion of tape slots.
o Start with an 32-slot 3U form-factor Base Library Module, and add up to 6 Expansion
Library Modules for a total of 272 slots in a 21U rack form factor
o 8.16PB of total maximum capacity with 272 slots and LTO-8 drives
o Performance scaling from 1 to 21 LTO HH Tape Drives and transfer rates of up to
300 MB/s per LTO-8 Tape Drive native.
• Cost Effective tape solution
o Existing customers of MSL2024, 4048, and 6480
existing LTO-8, LTO-7 and LTO-6 drives in the new MSL3040 to leverage their
investment
o Industry leading storage density to save rack space, floor space, power, cooling and
management costs –13 cartridge slots (390 TB) per 1U of rack space
o Great flexibility with up to 21 logical library partitions
o Customer installable, scalable and serviceable
• Enterprise-class manageability and reliability
o Manage multiple HPE Tape Libraries from a single pane of glass with HPE StoreEver
Command View Tape Library software. Download for free at:
http://www.hpe.com/storage/downloads/cvtl
o Intelligent, proactive and predictive reporting with HPE StoreEver TapeAssure
Advanced
• Advanced security features
o Using the HPE Encryption Kit get the simplest, lowest cost encryption and key
management solution available - no additional software required
o HPE Secure Manager License provides an additional level of security that lets you
control access to the tape library by authorizing specific servers
LTO-7 Ultrium 15000
8.16 PB (LTO-8, 272 slots)
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 3
High Scalability
Keep pace with data growth across the lifecycle with the MSL3040's scalability.
***Extra power supplies need to be factory integrated in order to be TAA compliant
Cost Effective Tape
Existing customers of MSL2024, 4048, and 6480 Tape Libraries can repurpose their existing LTO-8,
Partitioning
The MSL3040 Tape Library supports up to 21 logical partitions for greater flexibility and higher asset
utilization of the MSL library.
Management Console
The HPE StoreEver MSL3040 comes with web-based remote manageability so it can be easily
monitored and managed from across the room or across the globe. Functions included in the
Effortlessly address both short-term and long-term storage capacity and performance needs and
respond to unpredictable data growth, variance in service, or changes to backup window and retention
period. Scale-out architecture allows you to pay as you grow - simply add in new modules to boost
capacity and performance without investing in a whole new library.
The modular design of the MSL3040 includes a continuous robotics feature to provide in-box scaling
for higher performance, greater scalability, and higher reliability. Upgrades are fast and non-disruptive.
Scale vertically from 32 to 272* cartridge slots to store up to 8.16PB** in a single 19-inch rack. Several
drive options are available
• Add between 1 and 21 HPE StoreEver LTO-8 Ultrium 30750, LTO-7 Ultrium 15000, LTO-6
Ultrium 6250 FC or SAS tape drives
Scaling up with the MSL3040 couldn't be easier:
• Start with an empty Base Library
• Add a redundant power supply if required***
• Add between 1 and 3 LTO-8, LTO-7 or LTO-6 half-height tape drives and utilize up to 32
cartridge slots - a fully configured base unit with LTO-8 provides a max capacity of up to
960TB (assuming 2.5:1 compression)
• Then add between 1 and 6 empty expansion modules to the Base Library - each 3U
expansion module might require a power supply if further drives are to be installed in the
expansion. Redundant power supply needs to be added if required***.
• Expansion modules can be flexibly installed above or below the base library module*.
• You can then configure each expansion module with up to 3x LTO-8, LTO-7, or LTO-6 FC or
SAS tape drives and utilize up to 40 cartridge slots per expansion module*
NOTE:
*The lowest 8 slots of the library, whether part of the base library or an expansion, are inaccessible.
An expansion unit adds 40 slots to the base unit. If an expansion is installed underneath the base
unit the lowest 8 slots of the expansion unit become inaccessible.
**Assumes fully loaded with LTO-8 media cartridges at a 2.5:1 data compression ratio
Solution
LTO-7 and LTO-6 drives in the new MSL3040 to leverage their investment
Expansion modules are customer-installable; easy to configure and remove.
The MSL Tape Libraries are shipped as a rack-ready unit. The rack mount hardware included with the
library allows installation in a variety of HPE racks. For more information on the HPE rack offerings,
please see the following URL: http://www.hpe.com/info/rackandpower
Save rack space, floor space, and power and cooling costs with industry leading storage density. The
MSL3040 offers 13 cartridge slots per 1U of rack space providing up to 390 TBs per 1U of rack space
using LTO-8 drives.
utilization.
Partitioning allows each partitioned library to be presented to the host as an independent library,
separate from other partitions in the library. Hosts for each partition own independent sets of media
and can use ISV software that is different from the other partitions allowing maximum flexibility and
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 4
management tool include:
• IPv6 and IPv4 network protocol support
HPE Command View for
HPE Command View for Tape Libraries Software (CVTL) is a single pane of glass management
http://www.hpe.com/storage/cvtl
HPE TapeAssure
The HPE StoreEver MSL3040 Tape Library is available with HPE StoreEver TapeAssure Advanced -
monitoring of health and performance of tape drives and
investment by knowing how their library is being used. HPE StoreEver TapeAssure Advanced Software
likelihood of bottlenecks, failures and load balancing issues in the tape library environment. Analysis of
required for each tape library.
• Status information on the drive and system
• System configuration operations and reporting
• System error and status logs
• Library and drive firmware upgrade capabilities
• Diagnostic tests and information
• Cartridge movement for maintenance and management purposes
• Cleaning cartridge support
• Security and access control
• SNMP support for IP communication
• Partitioning and Encryption management
• HTTPS capable
Tape Libraries
platform which allows users to manage, monitor and configure all of their tape libraries through a
single console. It saves time by performing daily management and troubleshooting tasks from one
location. CVTL also provides remote management, diagnostics and configuration for all MSL Tape
Libraries from across the room or across the globe.
Key features include:
• View health summaries for the entire library environment
• View library & autoloader utilization by slots, media, and drives
• Search for media by barcode label
• Upgrade firmware for all libraries in an entire library environment
• View persistent event logs & drive support tickets for an entire library environment
Command View for Tape Libraries is also the centralized location for TapeAssure Advanced & Data
Verification functionality.
HPE StoreEver Command View for Tape Libraries can be downloaded for free from:
http://www.hpe.com/storage/downloads/cvtl
More information on Command View for Tape Libraries is available at:
Advanced
analytics software with automated, predictive
cartridges. TapeAssure Advanced reporting and analysis allows users to get the most out of their
is fully integrated with HPE StoreEver Command View for Tape Libraries to provide an intuitive, easy
to use dashboard for analysis of performance, health and utilization of tape drives and cartridges.
TapeAssure Advanced analytics features makes use of predictive forecasting to anticipate the
drive/tape utilization helps users to understand available capacity and performance which helps to
plan ahead.
For more information about TapeAssure Advanced, please visit
http://www.hpe.com/storage/tapeassure
NOTE: HPE StoreEver TapeAssure Advanced Software is licensed by tape library; one license is
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 5
HPE Data Verification
HPE StoreEver Data Verification Software proactively validates and scans, non-disruptively, the quality
HPE StoreEver Data Verification Software is only supported and licensed on the MSL3040 &
MSL6480 tape libraries. One license is required per 100 cartridge slots.
HPE Library and Tape
The MSL3040 Tape Library is supported with HPE Library and Tape Tools (L&TT). L&TT is a free
installation, ensure product reliability, perform diagnostics and achieve faster resolution of tape device
of utility functions. Performance tools assist in troubleshooting issues and system configuration checks
F
http://www.hpe.com/support/tapetools
Safeguarding data for
The HPE StoreEver MSL3040 Tape Library can provide the 'last line of defense' for your data.
increased data security regulations.
Data Encryption
The HPE MSL3040 Tape Library offers multiple options for data encryption, depending on the
of data stored LTO tape cartridges. Scanning and validating infrequently accessed tapes ensures a
successful restore is possible when critical business data is needed.
StoreEver Data Verification Software is fully integrated into the HPE StoreEver Command View for
Tape Libraries Software providing a single pane of glass management platform.
Key Features:
• Scan infrequently accessed LTO tapes to verify health of tape cartridges as well as the data stored
on those tapes.
o Improve reliability and reduce the risk of restore failure
• Scanning without interrupting host applications.
• Protect all tape cartridges, active and vaulted archived media, with the same license (per 100
cartridge slots)
• Receive proactive notification for needed media migration
• Fully integrated with Command View for Tape Libraries
Business Benefits:
• Ensures critical business data can be restored when most needed
• High Availability - No impact to backup operations
• Ease of Use - Single license for 100 cartridge slots
• Save Money - Migrate data only when necessary
For more information about Data Verification, please visit
http://www.hpe.com/storage/dataverification
NOTE:
Tools
diagnostic tool for all of HPE’s tape storage products. This robust diagnostic tool is designed for both
the experienced professional and the untrained administrator, and it allows customers to verify the
issues. L&TT performs firmware upgrades, verification of device operation, failure analysis and a range
warn of common host issues. It also provides seamless integration with HPE support by generating
and e-mailing test results and support tickets. HPE Support will require the use of L&TT to
troubleshoot most device issues, so it is recommended that a support ticket is pulled and the device
assessment test is run before calling.
HPE Library & Tape Tools can be downloaded from the following location:
http://www.hpe.com/storage/downloads/tapetools
or more information on L&TT, please visit:
Disaster Recovery
• Tape is inherently 'offline to threats' - tape's removable media is off-line to the threats from
viruses, hackers and cyber-attacks that online data on disk is susceptible to. It is also a logically
clean copy that won't be accidentally overwritten by mirroring software.
• LTO-8, LTO-7 and LTO-6 Ultrium tape drives include hardware based data encryption to
prevent unauthorized access to data at rest.
• LTO-8, LTO-7 and LTO-6 cartridges are available with write-once-read-many (WORM)
capability to prevent accidental overwriting of data archived on the tape.
Both WORM and hardware-based data encryption features help organizations with compliance to
.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 6
requirements for policy, regulation, compliance, and centralized key management.
data privacy, confidentiality, and integrity of your critical business data while supporting compliance
or damaged. The USB key server token will plug into the USB port
http://www.hpe.com/storage/DAPRcompatibility
Secure Manager License
HPE MSL3040 Secure Manager License is an optional software feature that provides an additional level
• allows a disable feature when switch zoning is desired
HPE Ultrium WORM
Critical to the success of data retention policies in highly regulated environments is the ability to store
and manage data in an unalterable state. Following stringent guidelines set forth by regulatory agencies
tape drives feature the ability to archive and store data in
ars in a secure, untampered state. Ultrium tape drives include support for both rewritable and WORM
prevent accidental or intentional overwriting of data
• HPE 1/8 G2 & MSL Encryption Kit
The HPE MSL Encryption Kit provides a library-enabled encryption solution that greatly enhances
requirements. While there are a wide range of encryption solutions available, the HPE MSL
Encryption Kit is intended to be an easy and affordable library-enabled solution for small
businesses.
The encryption kit includes two USB key server tokens, product documentation, and firmware
support. One encryption kit is needed per library, which must be physically accessible so that the
USB token can be inserted into the automation device. The second token will be used as a backup
token, in case the first one is lost
in the library and will generate and maintain encryption keys for the LTO-4 and later generation
drives. The USB key server token uses a hardware random number generator, password
authentication, and digital envelopes for strong encryption keys and security operations. The
encryption kit provides a self-contained solution for autoloaders and MSL libraries with no
additional software, PCs, or servers required or involved.
• KMIP
The HPE MSL3040 is capable of operation using the KMIP 1.2 protocol. One library encryption
license will be needed based on the KMIP protocol.
For more information on all supported key management servers, please visit:
of security that lets you control access to the tape library by authorizing specific servers to access the
library's drives and robotics. Secure Manager increases backup reliability by blocking disruptive traffic
from unauthorized hosts to the library, which is one of the main causes of failed or incomplete backups.
• Easily configure device-level SAN access settings
• Allow only authorized servers to access tape drives and critical data
• Manage access control from a single pane of glass, through the library itself
• Paths to robotics can be separated between two independent SANs for isolation purposes
Secure Manager allows you to:
• create host access groups
• add and modify host information
• map device access to specific hosts
such as the SEC and HIPPA, IT organizations must now integrate new solutions and policies that can
verify the integrity of stored data for periods that can extend well beyond seven years.
Every generation of LTO Ultrium since LTO-3
a read-only, non-rewriteable format that meets the most stringent regulatory guidelines. Using a
combination of integrated fail-safe features in the drive firmware, cartridge memory, and tape
formatting, LTO Ultrium provides the ability to archive large amounts of data for periods of up to 30
ye
media providing for a secure, long-term archiving solution into any data protection strategy. LTO
Ultrium WORM provides the following advantages:
• A single drive to support all backup and archiving needs
• Two distinctive tape cartridges to easily distinguish and manage both rewriteable and WORM
data cartridges
• A specially designed WORM data cartridge with multiple integrated fail-safe features to
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 7
• Support from many backup and archiving software vendors, providing the most comprehensive
and later LTO Ultrium products
High Availability
To make the most of your library performance, the MSL3040 offers high availability failover capability
6 Data Path
Both ports are connected and both are active but the driver selects between them and
ink breaks anywhere between the host and the drive, the host side driver switches
the need for
functional.
HPE Storage Media
Hewlett Packard Enterprise branded Linear Tape Open (LTO) Ultrium cartridges are designed,
and mainstream support in the industry
• The LTO open standard that offers greater choice and compatibility across all third-generation
utilizing LTO-8, LTO-7 and LTO-6 Tape Drives.
• Driver-based Data Path Failover (supports LTO-6 drives)
- This feature requires the HPE StoreEver MSL3040 High Availability LTO-
Failover License.
- SAN wide failure protection
-
uses them one at a time.
- If a l
to another path and recovers outstanding commands.
- Drivers handle errors before applications see them.
• Driver-based Control Path Failover (supports LTO-6 drives)
• .LTO-7 + driver-based Data and Control Path Failover (supports LTO-7 and later FC
drives):
- This feature requires the HPE StoreEver MSL3040 High Availability LTO-6 Control
Path Failover License.
- SAN wide failure protection
- Both the Control Path (CP) drive and the Control Path Failover (CPF) drive are
accessible from the same hosts.
- If the Control Path drive is lost, the library activates the Control Path Failover drive
and the host-based drivers find the robot on the new path.
- Drivers will handle errors before applications see them.
- LTO-7+ Path Failover supports Data Path and Control Path failover, unlocking
feature-sets with just one license enabled in the library.
- Both Drive paths are active; both ports are green and up in the library and the switch.
- The Driver-Based Failover technology has the failover intelligence in the driver that
runs on the server. Drivers on the host perform path and command failover recovery.
- Requires host driver support, in addition to minimal tape drive and library firmware
features, to manage multiple paths across multiple SAN. Presents a single drive or
library path to applications and automatically transfers commands to the new path if
the original path is lost.
- The transfer to the failover path is invisible to most applications, avoiding
user intervention.
- The Driver-Based Failover will only present one library path and one drive path to the
host for each library or drive that is attached to the host.
- If an LTO-8 or LTO-7 drive is enabled for Driver-Based Failover, it can still be seen by
hosts with a standard driver even though the Driver-Based Failover will not be
manufactured and tested to provide outstanding reliability for backing up, archiving and restoring your
data. We continuously monitor the quality of our branded tapes using what we believe is the industry’s
most comprehensive and forensic specification for quality and reliability. Using real life conditions and
both Hewlett Packard Enterprise and non-HPE drives, we supplement extensive in-process QA
parametric testing with ongoing drive based scrutiny, to make sure performance is excellent for any
combination of device, duty cycle and environment.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 8
Because HPE is a leading supplier of both LTO tape devices and media, we have the ability to re-create
All of these ongoing tests are intended to
and maximum dependability is to use HPE-branded Ultrium cartridges at all times.
LTO-7 Type M media
The MSL3040 Tape Library supports LTO-7 Type M media. This is the ability of an LTO-8 drive to
LTO-9 drives will not be backward compatible with LTO-7 Type M media.
Proven Reliability
With a rating of 2,000,000 robot load/unload cycles, the MSL Tape Libraries provides necessary high
products feature Data Rate Matching (DRM). This allows the tape drive to dynamically and continuously
for increased system reliability and uptime.
Data Rate Matching
Data Rate Matching combines sophisticated buffer management with variable tape drive motor speeds
needed.
LTO Ultrium Tape Drive
ATS data transfer rate range (native)
HPE LTO-8 Ultrium 30750
HP LTO-7 Ultrium 15000
101 to 300 MB/s
101 to 300 MB/s
HPE LTO-6 Ultrium 6250
54 to 160 MB/s
Longevity
Organizations need to be confident that their data in archive is still there when they need it. LTO tape
archive or DR.
LTO Ultrium
HPE LTO (Linear Tape Open) Ultrium Tape Drives use best of breed technology. By taking the best
many different scenarios mirroring how customers use their cartridges. And many of HPE’s protocols
are either unique in nature or scale, such as the HPE ‘Green Tape’, and HPE ‘Environmental Interchange’
tests, or far surpass industry standards, for example, HPE’s ‘Locate/Rewind/Append’ test. Since the
beginning of 2016, almost 700 million meters of media have been pulled and over 40 million gigabytes
of data have been written in HPE’s demanding GTT protocol.
ensure HPE LTO Ultrium media is the most reliable you can find. Your best choice for ease of support
write 9 TB (native) on a brand new LTO-7 cartridge instead of 6 TB (native) as specified by the LTO-7
format. LTO-7 Type M cartridges will be designated by an automation barcode label ending with the
last 2 characters “M8”.
label ending in “L7”. An LTO-8 cartridge has a capacity of 12 TB (native), and is indicated with an
automation barcode label ending in “L8”.
Only unused LTO-7 cartridges may be initialized as LTO-7 Type M. Once a cartridge is initialized as
Type M, it may not be changed back to a 6TB LTO-7 cartridge. Also, an LTO-7 Type M cartridge can
only be written and read in an LTO-8 drive; LTO-7 drives are not capable of reading LTO-7 Type M
cartridges.
LTO-7 Type M media supports existing LTO format features including data compression, encryption
and partitioning enabling LTFS. LTO-7 Type M media is not supported on WORM cartridges.
A standard 6TB LTO-7 cartridge is indicated with an automation barcode
reliability for today's demanding environment. To improve reliability and longevity, all HPE Ultrium
adjust the speed of the drive, to match the speed of the host or network. This increases performance,
reduces mechanical wear on the tape drive and extends tape life.
HPE Tape Libraries include redundancy features for high availability. Dual power supplies are available
to match the tape drive transfer rate to the host output. . This feature ensures that the tape drive
continues to stream data regardless of the environment, and brings three big advantages:
• It optimizes performance and maximizes overall efficiency, allowing the drive to respond
immediately to any data speed changes from the host.
• It minimizes rewinding and repositioning of the tape, significantly reducing physical wear and
increasing reliability.
• It minimizes the power requirements for the drive by reducing the number of repositions
media is specified with a 30 year shelf life in normal ambient conditions. HPE TapeAssure Advanced
also analyses the results of every tape use to ensure the availability of data placed in long-term storage,
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Product Highlights
Page 9
Technology
features from other tape technologies and combining them into a single new technology, Ultrium tape
compatibility with tape drives and media manufactured by other LTO vendors.
Micro Focus Data
Micro Focus Data Protector software automates high performance backup and recovery, from disk or
https://software.microfocus.com/en-us/software/data-protector
Compatibility
Hewlett Packard Enterprise's extensive compatibility testing program assures that your HPE MSL Tape
list of servers, workstations, operating systems, and backup software that support the MSL tape libraries,
http://www.hpe.com/storage/DAPRcompatibility.
drives are in a league of their own. The LTO Ultrium specification is an industry standard format; thus
data written on HPE Ultrium Tape Drives can be interchanged directly with LTO Ultrium Tape Drives
from other vendors.
HPE LTO tape drives and automation products are founded on the LTO open standard and adhere to
the published twelve-generation LTO format roadmap.
The LTO standard for backward compatibility up to generation seven is to write back one generation
and read back two generations. Eighth-generation LTO Ultrium drives read and write LTO -7 and LTO8 media.As part of the LTO open standard, all HPE tape drives and media offer the same standards of
Protector software
tape, over unlimited distances, to enable 24x7x365 business continuity and improve IT resource
utilization. Data Protector software responds to the pressure for lower IT costs and greater operational
efficiency, extensive scalability and features for continuous backup and recovery operations enable
growth with a single product. A superb solution, no other software can integrate better with the Hewlett
Packard Enterprise market-leading line of disk and tape family of products, as well as with other
heterogeneous storage infrastructures. Data Protector software fully integrates with the Hewlett
Packard Enterprise management solutions, allowing managing data protection as an essential element
of an overall IT service.
Data Protector software simplifies the use of complex backup and recovery procedures with the fastest
installation, automated routine tasks, and easy-to-use features. The centralized multi-site management
easily allows implementing multi-site changes, adapting in real time to changing business requirements.
Appropriate for medium and large companies in any industry, Data Protector software is the ideal
solution to reduce IT costs and complexity while remaining reliable and scalable to grow from single
server environments to the largest distributed enterprise infrastructures.
For further information, please visit:
Libraries work with leading servers, operating systems, and backup software applications - and not just
those sold by Hewlett Packard Enterprise. The MSL libraries work seamlessly in many environments,
making them especially suitable if you have a mixed system environment. For the complete and latest
reference the HPE Data Agile DAPR Compatibility Matrix (Formerly EBS) at:
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Service and Support and Warranty Information
Page 10
Service and Support
Protect your business beyond warranty with HPE Support Services
HPE
integrated portfolio of Services for storage help customers reduce costs, optimize data, streamline
storage management, and improve backup and recovery. HPE Support Services enable you to choose
the right service level, length of coverage and response time
solution, giving you full entitlement for the support for need for your IT and business.
Connect your devices
Unlock all of the benefits of your technology investment by connecting your products to HP Enterprise.
view of your environment. By connecting, you will receive 24x7monitoring, pre
call logging, and automatic parts dispatch. HPE Proactiv
Service customers will also benefit from proactive activities to help prevent issues and increase
optimization. All of these benefits are already available to you with your server storage and networking
products, secu
1
2 – HP CSC reports 2014 - 2015
Recommended Services
Optimized Care
HPE Proactive Care* with 24x7 coverage, three year Support Service + 20 Services credits
HPE Proactive Care gives customers an enhanced call exp
maintains IT stability by utilizing personalized proactive reports with recommendations and advice
when your products are connected to HPE. This Service combines three years’ proactive reporting and
advice with o
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3
Standard Care
HPE Proactive Care* with 24x7 coverage, three year Support Service + 10 Services credits
HPE Proactive Care gives customers an enhanced call experience plus helps preventing problems and
maintains IT stability by utilizing personalized proactive reports with recommendations and advice
when your products are connected to HPE. This Service combines three years’ proactive reporting and
advice with our 24x7 coverage, four hour hardware response time when there is a problem.
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf
Basic Care
HPE Foundation Care 24x7, three-year Support Service
HPE Foundation Care 24x7 gives you access to HPE 24 hours a day, seven days a week for assistance
on resolving issues.
Simplify your support experience and make HPE your first call to help resolve hardware or software
problems.
https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en
HPE Support Services
Services Credits offer flexible services and technical skills to meet your changing IT demands. With a
menu of serv
help you maintain peak performance of your IT. Offered as annual credits, you can plan your budgets
while proactively responding to your dynamic business.
NOTE: *HPE Proactive Care and HPE Proactive Care Advanced require that the customer connect their devices to make the
most of these services and receive all the deliverables.
Related Services
HPE Backup Recovery Efficiency Analysis - Assessment of how efficiently backup components are
being used as the amount of data to be backed up continues to grow exponentially via analysis
intelligence and a snapshot of your current backup environment.
http://h20195.www2.hpe.com/v2/GetPDF.aspx/4AA3-8490ENW.pdf
Pointnext delivers confidence, reduces risk and helps customers realize agility and stability. Our
as you purchase your new storage
Achieve up to 77%1 reduction in down time, near 100%2 diagnostic accuracy and a single consolidated
-failure alerts, automatic
e Care Service and HPE Datacenter Care
rely connected to HPE support.
- IDC
erience plus helps preventing problems and
Credits
ur 24x7 coverage, four hour hardware response time when there is a problem.
-8855ENW.pdf
This service includes need based Hardware onsite response within four hours.
ice that is tailored to suit your needs, you get additional resources and specialist skills to
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Service and Support and Warranty Information
Page 11
HPE
key to success for gaining a clear understanding of the role of increasingly diverse data protect
strategies.
HPE Installation and Startup Service for HPE StoreEver Storage Systems
of your
HPE Storage and Data Consultant Residency Services
with Hewlett Packard Enterprise resources who become your trusted advisor to p
are right for your storage and backup environment
HPE Storage Data Migration Service
discovery, assessment, planning, and design, completely customizable to your organization's st
area network (SAN) or network attached storage (NAS) environment and using innovative software to
help you migrate to HPE storage quickly and efficiently
http://h20195.www2.hpe.com/V2/GetPDF.aspx/4AA3-0774ENW.pdf
For more information
http://www.hpe.com/services/storage
HPE Support Service Services are sold by Hewlett Packard Enterprise and Hewlett Packard Enterprise
Author
are quoted using Hewlett Packard Enterprise order configuration tools.
Backup Recovery Impact Analysis - Focus placed on service requirements and design as the
ion
http://h20195.www2.hpe.com/V2/GetPDF.aspx/4AA4-1175ENW.pdf
- Installation and testing
hardware and software onsite, including configuration of the storage deployment
- Strategically augments current environment
rovide answers that
- End-to-end data migration service providing seamless
orage
ized Service Partners:
• Services for customers purchasing from Hewlett Packard Enterprise or an enterprise reseller
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Configuration Information
Page 12
Step 1 - Base Configuration
HPE StoreEver MSL3040
Base Module description
Part Number
HPE StoreEver MSL3040 Scalable Library Base Module
Q6Q62A
NOTES:
. Redundant power
Kit Contents:
http://www.backupexec.com/hpe
HPE StoreEver MSL3040 Scalable Library Expansion Module
Q6Q63A
NOTES:
Kit Contents:
• Module interconnect cable (expansion module only)
HPE StoreEver MSL3040 Upgrade Power Supply kit
Q6Q64A
NOTES:
• For the expansion module, neither the standard power supply nor the
• This product is TAA (Trade Agreements Act) compliant.
• The base module is 3U rack mountable.
• Base module enables 32 slots
• Standard power supply is included with the base module
supply is not included as standard, if required it needs to be added to the
order. This needs to be factory integrated, #0D1, in order to be TAA
compliant
• It does not contain any tape drives, up to 3 HH tape drives may be added
to the base module
• 2.5M PDU Power Cord, C13/C14, 10A
• Rack-mount hardware
• Getting started poster
• Power Supply
• Flyer for Veritas Backup Exec software*
NOTE: *Customers can download a fully functional 60-day trial of Backup Exec and
receive a 50% discount off Veritas MSRP.
Visit
for full details of the promotion.
• Expansion module activates 40 slots.
• This product is TAA (Trade Agreements Act) compliant.
• The expansion module is 3U rack mountable.
• It does not contain any tape drives, up to 3 HH tape drives may be added
to the expansion module. If drives are added to the expansion module then
a power supply is required. Standard or redundant power supplies are not
included. If needed, these will have to be added to the order. If TAA
compliance is required, power supplies need to be factory integrated,
#0D1.
• 2.5M PDU Power Cord, C13/C14, 10A
• Rack-mount hardware
• Getting started poster
• Redundant power supply is not included as standard with the base module,
if required it needs to be added to the order. This needs to be factory
integrated, #0D1, in order to be TAA compliant
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Configuration Information
Page 13
redundant are included. A power supply is only needed if tape drives need
power supplies need to be factory integrated, #0D1.
Factory Racking
Factory integrate MSL3040 Tape Library with other HPE products
HPE factory integration is indicated
#0D1
Step 2 - Select Generation & Quantity of LTO Ultrium Tape Drives
HPE StoreEver LTO-8
HPE StoreEver MSL LTO-8 Ultrium 30750 FC Drive Upgrade Kit
NOTE: This product is TAA (Trade Agreements Act) compliant.
Q6Q67A
HPE StoreEver LTO-8
HPE StoreEver MSL LTO-8 Ultrium 30750 SAS Drive Upgrade Kit
NOTE: This product is TAA (Trade Agreements Act) compliant.
Q6Q68A
HPE StoreEver LTO-7
HPE StoreEver MSL LTO-7 Ultrium 15000 FC Drive Upgrade Kit
#0D1 will appear after N7P36A on the sales order if HPE factory integration
NOTE: This product is TAA (Trade Agreements Act) compliant.
N7P36A
HPE StoreEver LTO-7
HPE StoreEver MSL LTO-7 Ultrium 15000 SAS Drive Upgrade Kit
#0D1 will appear after N7P37A on the sales order if HPE factory integration
NOTE: This product is TAA (Trade Agreements Act) compliant.
N7P37A
HPE StoreEver LTO-6
HPE StoreEver MSL LTO-6 Ultrium 6250 Fibre Channel Drive Upgrade Kit
C0H28A
NOTE: Half height LTO-6 FC tape drive. For use with the MSL2024, 4048, 3040 or
#0D1 will appear after C0H28A on the sales order if HPE factory integration
NOTE: This product is TAA (Trade Agreements Act) compliant.
HPE StoreEver LTO-6
HPE StoreEver MSL LTO-6 Ultrium 6250 SAS Drive Upgrade Kit
C0H27A
NOTE: Half height LTO-6 SAS tape drive. For use with the MSL2024, 4048, 3040
NOTE: #0D1 will appear after C0H27A on the sales order if HPE factory integration
to be installed in the expansion module. If TAA compliance is required,
such as HPE ProLiant Servers
NOTE: #0D1 will appear after the Tape Library part number on the sales order if
Ultrium 30750 FC Drive
Kit
Ultrium 30750 SAS
Drive Kit
Ultrium 15000 FC Drive
Kit
Ultrium 15000 SAS
Drive Kit
NOTE: Half height LTO-8 FC tape drive. For use with the MSL2024, 4048, 3040 or
6480 libraries. Drive kit includes a tape drive and documentation.
NOTE:
#0D1 will appear after Q6Q67A on the sales order if HPE factory
integration is indicated.
NOTE: Half height LTO-8 SAS tape drive. For use with the MSL2024, 4048, 3040
or 6480 libraries. Drive kit includes a tape drive and documentation.
NOTE:
#0D1 will appear after Q6Q68A on the sales order if HPE factory
integration is indicated.
NOTE: Half height LTO-7 FC tape drive. For use with the MSL2024, 4048, 3040 or
6480 libraries. Drive kit includes a tape drive and documentation.
NOTE:
is indicated.
NOTE: Half height LTO-7 SAS tape drive. For use with the MSL2024, 4048, 3040
or 6480 libraries. Drive kit includes a tape drive and documentation.
NOTE:
is indicated.
Ultrium 6250 FC
Drive Kit
6480 libraries. Drive kit includes a tape drive and documentation.
NOTE:
is indicated.
Ultrium 6250 SAS
Drive Kit
or 6480 libraries. Drive kit includes a tape drive and documentation.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Configuration Information
Page 14
is indicated.
NOTE:
Step 3 - Select Software Licenses
Select each option as required with quantities specified:
Software Licenses
Quantity
Description
Part Number
HPE StoreEver MSL
1 each
HPE StoreEver MSL TapeAssure Advanced LTU
One license needed per library and Command View TL must
NOTE:
TC406A
HPE StoreEver MSL
1 each
HPE StoreEver MSL TapeAssure Advanced E-LTU
One license needed per library and Command View TL must
NOTE:
TC406AAE
HPE StoreEver MSL3040
KMIP Key Manager LTU
1 each
HPE StoreEver MSL3040 KMIP Key Manager LTU
Q8K98A
HPE StoreEver MSL3040
LTU
1 each
HPE StoreEver MSL3040 KMIP Key Manager E-LTU
Q8K98AAE
HPE StoreEver MSL3040
Secure Manager LTU
1 each
HPE StoreEver MSL3040 Secure Manager LTU
NOTE:
Q8K99A
HPE StoreEver MSL3040
1 each
HPE StoreEver MSL3040 Secure Manager E-LTU
Q8K99AAE
HPE StoreEver MSL3040
LTU
1 each
HPE StoreEver MSL3040 LTO-7+ Ultrium Path Failover LTU
Q8L00A
HPE StoreEver MSL3040
LTU
1 each
HPE StoreEver MSL3040 LTO-7+ Ultrium Path Failover E-LTU
Q8L00AAE
HPE StoreEver High
Failover LTU
1 each
HPE StoreEver High Availability MSL3040 LTO-6 Control Path
Q8K96A
TapeAssure Advanced
LTU
TapeAssure Advanced
E-LTU
This product is TAA (Trade Agreements Act) compliant.
NOTE: Advanced analytics feature makes use of predictive
analytics to predict the likelihood of failures, bottlenecks and load
balancing issues in the tape infrastructure. It has unique
capabilities of analytics around drive health and life as well as
cartridge health and life.
NOTE:
be installed.
This is a paper license that will be mailed.
NOTE:
be installed.
This is an electronically delivered License.
KMIP Key Manager E-
Secure Manager E-LTU
LTO-7+ Path Failover
LTO-7+ Path Failover E-
NOTE: This is a paper license that will be mailed.
NOTE: This is an electronically delivered License.
This is a paper license that will be mailed.
NOTE: This is an electronically delivered License.
NOTE: This is a paper license that will be mailed.
NOTE: This is an electronically delivered License.
Availability MSL3040
LTO-6 Control Path
Failover LTU
NOTE: This is a paper license that will be mailed.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Configuration Information
Page 15
HPE StoreEver High
Failover E-LTU
1 each
HPE StoreEver High Availability MSL3040 LTO-6 Control Path
Q8K96AAE
HPE StoreEver High
6 Data Path Failover
LTU
1 each
HPE StoreEver High Availability MSL3040 LTO-6 Data Path Failover
Q8K97A
HPE StoreEver High
6 Data Path Failover
E-LTU
1 each
HPE StoreEver High Availability MSL3040 LTO-6 Data Path Failover
Q8K97AAE
Step 4 - Select Additional Accessories
Power Cords
Quantity
Description
Part Number
1 each
HPE C13 - C14 WW 250V 10Amp 2.5m Jumper Cord
the rack-mounted device to PDUs with IEC-320 receptacles.
142257-002
Quantity to
Regional Power Cord Options
Please select the correct power cord for your geographical location.
1 per base
HPE C13 - Nema 5-15P US/CA 110V 10Amp 1.83m Power Cord
AF556A
HPE C13 - CEE-VII EU 250V 10Amp 1.83m Power Cord
AF568A
HPE C13 - BS-1363A UK/HK/SG 250V 10Amp 1.83m Power Cord
AF570A
HPE C13 - DK-2.5A DK 250V 10Amp 1.83m Power Cord
AF566A
HPE C13 - SEV 1011 CH 250V 10Amp 1.83m Power Cord
AF565A
HPE C13 - CEI-23-50 IT/CL 250V 10Amp 1.83m Power Cord
AF571A
HPE C13 - SABS-164 ZA 250V 10Amp 2.5m Power Cord
AF567A
HPE C13 - CNS-690 TW 110V 13Amp 1.83m Power Cord
AF561A
HPE C13 - GB-1002 CN 250V 10Amp 1.83m Power Cord
AF557A
HPE C13 - JIS C8303 JP 100V 12Amp 2.0m Power Cord
AF572A
HPE C13 - AS3112-3 AU 250V 10Amp 2.5m Power Cord
AF569A
HPE C13 - IRAM -2073 AR 250V 10A 2.5m Power Cord
AF558A
HPE C13 - Nema 5-15P TH/PH 250V 10Amp 1.83m Power Cord
AF559A
HPE C13 - KSC- 8305 KR 250V 10Amp 1.83m Power Cord
AF560A
HPE C13 - SI-32 IL 250V 10Amp 1.83m Power Cord
AF564A
HPE C13 - IS-1293 IN 240V 6Amp LV 2.0m Power Cord
AF562A
HPE C13 - IS-1293 IN 240V 6Amp LV 2.0m Power Cord
AF562A
NOTE: This product can ONLY be used with an HPE approved power cord for your specific
cord could fracture resulting in the internal contacts being exposed, which potentially could subject
Availability MSL3040
LTO-6 Control Path
Availability MSL3040
LTO-
Availability MSL3040
LTO-
Failover E-LTU
NOTE: This is an electronically delivered License.
LTU
NOTE: This is a paper license that will be mailed.
E-LTU
NOTE: This is an electronically delivered License.
NOTE: This cord ships standard with each MSL3040 Base Tape
Library and Power Supply Upgrade Kit. It can be used to connect
order
module and
upgrade
power supply
NOTE: One PDU cord is shipped with each base module (above). If
regional power cords are preferred, order qty (1) for the base
module and one with each upgrade power supply purchased.
geographic region. Use of a non-HPE approved power cord may result in: 1) not meeting individual
country specific safety requirements; 2) insufficient conductor capacity that could result in
overheating with potential personal injury and/or property damage; and 3) an unapproved power
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Configuration Information
Page 16
the user to a shock hazard. Hewlett Packard Enterprise disclaims all liability in the event a non-HPE
approved power cord is used.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Related Options
Page 17
Redundant Power
HPE StoreEver MSL3040 Upgrade Power Supply kit
Q6Q64A
NOTES:
power supplies need to be factory integrated, #0D1.
Factory Racking
Factory integrate the MSL Tape Libraries with other Hewlett Packard Enterprise
Modules can be factory integrated up to 21U in a single rack.
#0D1
Encryption
HPE StoreEver 1/8 G2 Tape Autoloader and MSL Encryption Kit
backup software; doesn’t require ISV support.
AM495A
HPE StoreEver MSL3040 KMIP Key Manager LTU
NOTE:
Q8K98A
HPE StoreEver MSL3040 KMIP Key Manager E-LTU
NOTE: This is an electronically delivered License.
Q8K98AAE
FC Host Bus Adapters
The MSL Libraries are certified with a number of Fibre Channel Host Bus Adapters. For the most
http://www.hpe.com/storage/san/
SAS Host Bus Adapters
The MSL Libraries are certified with a number of SAS Host Bus Adapters and ProLiant Smart Array
http://www.hpe.com/servers/smartarray/
HBAs and SAS
HPE Smart Array P408e-p SR Gen10 (8 external lanes/4GB cache)
804405-B21
NOTE: Recommended for ProLiant Gen10 SAS tape automation connect.
HPE Smart Array E208e-p SR Gen10 (8 external lanes/No cache)
804398-B21
NOTE: Recommended for ProLiant Gen10 SAS tape automation connect.
HPE Smart Array P431/2GB FBWC 12Gb 2-ports Ext SAS Controller
698531-B21
NOTE: Recommended for ProLiant Gen9 SAS tape automation connect.
HPE H241 12Gb 2-ports Ext Smart Host Bus Adapter
NOTE:
726911-B21
HPE H221 PCIe 3.0 SAS Host Bus Adapter
729552-B21
Supply Upgrade Kit
• Redundant power supply is not included as standard with the base module,
if required it needs to be added to the order. This needs to be factory
integrated, #0D1, in order to be TAA compliant.
• For the expansion module, neither the standard power supply nor the
redundant are included. A power supply is only needed if tape drives need
to be installed in the expansion module. If TAA compliance is required,
products such as HPE ProLiant Servers
NOTE: #0D1 will appear after the Tape Library part number on the sales order if
HPE factory integration is indicated. One Base Module and up to 6 Expansion
NOTE: The Encryption Kit key server token will generate and retain encryption keys
for HPE LTO Ultrium tape drives in the library. Works independent of application or
Controllers
This is a paper license that will be mailed.
current list of supported FC HBAs, please reference the HPE Data Agile DAPR Compatibility Matrix
(Formerly EBS) and Design Guide located at:
http://www.hpe.com/go/DAPRcompatibility.
For more information on FC HBAs, see HPE StoreFabric Adapters at:
Controllers. For the most current list of supported devices, please reference the HPE Data Agile DAPR
Compatibility Matrix (Formerly EBS) and Design Guide located at:
http://www.hpe.com/storage/DAPRcompatibility.
For more information on HPE Smart Array RAID controllers, see Fibre HPE P-class RAID controllers at:
http://www.hpe.com/servers/smartarray/
For more information on HPE ProLiant (SAS) host bus adapters, see H-class HBA controllers at:
Recommended for ProLiant Gen9 SAS tape automation connect.
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Related Options
Page 18
NOTE: Recommended for ProLiant Gen8 SAS tape automation connect.
HPE H222 Host Bus Adapter
NOTE:
650926-B21
HPE Smart Array P411/256 2-ports Ext PCIe x8 SAS Controller
NOTE: Recommended for Proliant G6/G7 SAS tape automation connect.
462830-B21
HPE Smart Array P212/256 1-ports Int/1-ports Ext PCIe x8 SAS Controller
NOTE: Recommended for Proliant G6/G7 SAS tape automation connect.
462834-B21
Optical cables
OM4 LC-LC type cables
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 1m Cable
QK732A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 2m Cable
QK733A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable
QK734A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable
QK735A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable
QK736A
HPE Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable
QK737A
Allowed cable lengths:
External Cable type
Drive type
2Gb
4Gb
8Gb
OM2
All drive types
0.5m - 300m
0.5m - 150m
NA
OM3/OM4
All drive tapes
0.5m - 500m
0.5m - 380m
0.5m - 150m
NOTE: The lowest OM rating in a path from the drive to the switch or HBA will dictate the maximum
length of the connection path.
Cable Kits
HPE StoreEver 2m External Mini-SAS to 4x1 Mini-SAS Cable
ports.
AN975A
HPE StoreEver 4m External Mini-SAS to 4x1 Mini-SAS Cable
ports.
AN976A
HPE StoreEver External SAS to Mini-SAS Fanout Cable
connectors.
AH587A
HPE StoreEver Mini-SAS High Density to 4-lane Mini-SAS External Fanout 2m Cable
K2R09A
HPE StoreEver Mini-SAS High Density to 4-lane Mini-SAS External Fanout 4m Cable
K2R10A
HPE 2.0m External Mini SAS High Density to Mini SAS Cable
MSL SAS Tape Libraries to the HPE H241 Smart Host Bus Adapter.
716191-B21
HPE 4.0m External Mini SAS High Density to Mini SAS Cable
MSL SAS Tape Libraries to the HPE H241 Smart Host Bus Adapter.
716193-B21
Rack Cabinets
The MSL3040 libraries are supported in a variety of HPE Rack offerings, including the HPE Intelligent
Series Racks and the HPE 10000 G2 Series Racks.
NOTE: If ordering the #0D1 Factory Integration option, the MSL3040 Tape Libraries are certified to
Intelligent Series rack.
Media
HPE LTO-8 Ultrium 30TB RW Data Cartridge
Q2078A
Recommended for ProLiant Gen8 SAS tape automation connect.
(SAS)
NOTE: One cable is required for every four autoloaders or every four library drives.
Use this cable to connect HPE MSL SAS Tape Libraries to Mini-SAS (SFF8088)
NOTE: One cable is required for every four autoloaders or every four library drives.
Use this cable to connect HPE MSL SAS Tape Libraries to Mini-SAS (SFF8088)
NOTE: One cable is required for every four drives. Use this cable to connect HPE
MSL SAS Tape Libraries to legacy 3Gb SAS controllers with Infiniband (SFF8470)
NOTE: One cable is required for every tape drive. Use this cable to connect HPE
NOTE: One cable is required for every tape drive. Use this cable to connect HPE
ship with one base module and up to 6 expansion modules (up to 21U) installed in the HPE
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Related Options
Page 19
HPE LTO-8 Ultrium 30TB WORM Data Cartridge
Q2078W
HPE LTO-7 Ultrium 15TB RW Data Cartridge
C7977A
HPE LTO-7 Ultrium No Case 960 Tape Pallet
C7977AB
HPE LTO-7 Ultrium RW 960 Tape Pallet
C7977AD
HPE LTO-7 Ultrium 15TB Eco Case Data Cartridge 20 Pack
C7977AH
HPE LTO-7 Ultrium 15TB WORM Data Cartridge
C7977W
HPE LTO-6 Ultrium 6.25TB MP RW Data Cartridge
C7976A
HPE LTO-6 Ultrium 6.25TB MP WORM Data Cartridge
C7976W
HPE LTO-6 Ultrium 6.25TB BaFe RW Data Cartridge
C7976B
HPE LTO-6 Ultrium 6.25TB BaFe WORM Data Cartridge
C7976BW
HPE LTO-5 Ultrium 3TB RW Data Cartridge
C7975A
HPE LTO-5 Ultrium 3TB WORM Data Cartridge
C7975W
Bar Code Labels
HPE LTO-8 Ultrium RW Bar Code Label Pack
Q2015A
HPE LTO-7 Ultrium Type M RW Bar Code Label Pack
Q2016A
HPE LTO-7 Ultrium RW Bar Code Label Pack
Q2014A
HPE LTO-6 Ultrium RW Bar Code Label Pack
Q2013A
HPE LTO-5 Ultrium RW Bar Code Label Pack
Q2011A
HPE LTO-5 Ultrium WORM Bar Code Label Pack
Q2012A
Non-Custom Labeled Data Cartridges
sequence.
HPE LTO-8 Ultrium 30TB RW 20 Data Cartridges Non Custom Labeled with Cases
Q2078AN
HPE LTO-7 Ultrium Type M 22.5TB RW 20 Data Cartridges Non Custom Labeled with
Cases
Q2078MN
HPE LTO-7 Ultrium RW No Case Custom Labeled Data Cartridge 20 Pack
C7977AC
HPE LTO-7 Ultrium Non Custom Labeled Data Cartridge 20 Pack
C7977AN
HPE LTO-6 Ultrium 6.25TB MP RW Non Custom Labeled Data Cartridge 20 Pack
C7976AN
HPE LTO-6 Ultrium 6.25TB BaFe RW Non Custom Labeled Data Cartridges 20 Pack
C7976BN
HPE LTO-5 Ultrium Non-custom Labeled Data Cartridge 20 Pack
C7975AN
Custom Labeled Data Cartridges
printed on each label.
HPE LTO-8 Ultrium 30TB RW 20 Data Cartridges Custom Labeled with Cases
Q2078AL
HPE LTO-8 Ultrium 30TB WORM 20 Data Cartridges Custom Labeled with Cases
Q2078WL
HPE LTO-8 Ultrium 30TB RW 20 Data Cartridges Custom Labeled Library Pack
Q2078AC
HPE LTO-7 Ultrium Type M 22.5TB RW 20 Data Cartridges Custom Labeled with
Cases
Q2078ML
HPE LTO-7 Ultrium Type M 22.5TB RW 20 Data Cartridges Custom Labeled Library
Pack without Cases
Q2078MC
HPE LTO-7 Ultrium 15 TB RW RFID Custom Labeled Data Cartridge (20 pack)
7977AF
HPE LTO-7 Ultrium RW Custom Labeled Data Cartridge 20 Pack
C7977AL
HPE LTO-7 Ultrium WORM Custom Labeled Data Cartridge 20 Pack
C7977WL
HPE LTO-6 Ultrium 6.25TB MP RW Custom Labeled Data Cartridge 20 Pack
C7976AL
HPE LTO-6 Ultrium 6.25TB MP RW Custom Labeled Data Cartridge No Case 20 Pack
C7976AC
HPE LTO-6 Ultrium 6.25TB MP RFID RW Custom Labeled Data Cartridge 20 Pack
C7976AF
NOTE: Non-Custom labels will come pre-labeled with a pre-determined number
NOTE: Custom labeled products allow customers to customize a specific sequence
without Cases
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Related Options
Page 20
HPE LTO-5 RW Custom Labeled Data Cartridge 20 Pack
C7975AL
HPE LTO-5 RW Custom Labeled No Case Data Cartridge 20 Pack
C7975AC
HPE LTO-5 WORM Custom Labeled Cartridge 20 Pack
C7975WL
NOTE: For more information on LTO media, see: http://h18006.www1.hpe.com/storage/storagemedia.html?psn=storage
HPE Support Service
HPE 3Y FC NBD MSL 3040 Base Module SVC
H9XW8E
HPE 3Y FC SBD MSL 3040 Base Module SVC
H9XX0E
HPE 3Y FC 24x7 MSL 3040 Base Module SVC
H9XX5E
HPE 3Y FC CTR MSL 3040 Base Module SVC
H9XY1E
HPE 4Y FC 24x7 MSL 3040 Base Module SVC
H9XZ4E
HPE 4Y FC CTR MSL 3040 Base Module SVC
H9YA0E
HPE 5Y FC 24x7 MSL 3040 Base Module SVC
HA0R0E
HPE 5Y FC CTR MSL 3040 Base Module SVC
HA0R6E
HPE 1Y PW FC NBD MSL3040 Base SVC
HA0S2PE
HPE 1Y PW FC SBD MSL3040 Base SVC
HA0S4PE
HPE 1Y PW FC 24x7 MSL3040 Base SVC
HA0S7PE
HPE 1Y PW FC CTR MSL3040 Base SVC
HA0T1PE
HPE Installation Storage SVC
U4823E
Startup - MSL Tape Library
UA871E
Options
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Technical Specifications
Page 21
MSL3040
Drive Technology
LTO-8 Ultrium 30750
LTO-6 Ultrium 6250
Maximum Number of Drives
-
- Per fully expanded Library
3 HH (per Module)
Number of Slots
-
- Per fully expanded Library
32 (Base Module)/40 (Expansion Module)
Drive Interface
8 Gb Native Fibre Channel
Maximum
Capacity
Native
384 TB (LTO-8, 32 slots)
680 TB (LTO-6, 272 slots)
Compressed (2.5:1)
960 TB (LTO-8, 32 slots)
1.7 PB (LTO-6, 272 slots)
Maximum Transfer Rate
Native
3.24 TB/hour (with 3 LTO-8 drives)
Compressed (2.5:1)
30.2 TB/hr (with 21 LTO-6 drives)
MSL3040
Dimensions
Out-of-Box (HxWxD)
5.24 X 18.98 X 34.27 in (13.3 x 48.2 x 87.3 cm)
Shipping (HxWxD)
12.6 X 27.09 X 45.59 in (61.5 x 80.0 x 120.0 cm)
Weight
Out of box
55.34 lbs (25.1 kg)
Shipping
68.34 lbs (31 kg)
NOTE: The weight of each library varies somewhat based on the type and number of LTO tape
calculated by adding or subtracting the weight of a tape drive. An LTO-6 Ultrium 6250 drive weighs
LTO-7 Ultrium 15000
Per Module
Per Module
21 HH (per Library)
272 (per Library)
6 Gb/sec SAS
- Per Base Module
- Per Full Library
192 TB (LTO-7, 32 slots)
80 TB (LTO-6, 32 slots)
3.26PB (LTO-8, 272 slots)
1.63 PB (LTO-7, 272 slots)
- Per Module
- Per Library
480 TB (LTO-7, 32 slots)
200 TB (LTO-6, 32 slots)
8.16 PB (LTO-8, 272 slots)
4.08 PB (LTO-7, 272 slots)
- Per Module
- Per Library
3.24 TB/hour (with 3 LTO-7 drives)
1.73 TB/hour (with 3 LTO-6 drives)
22.5 TB/hr (with 21 LTO-8 drives)
22.5 TB/hr (with 21 LTO-7 drives)
14 TB/hr (with 21 LTO-6 drives)
- 3 HH drives Per Module
- 21 HH drives Per Library
drives contained in the configuration. Configurations with different numbers of tape drives can be
Up to 10.32 TB/hr (with 3 LTO-8 drives)
Up to 10.32 TB/hr (with 3 LTO-7 drives)
4.3 TB/hr (with 3 LTO-6 drives)
Up to 72.45 TB/hr (with 21 LTO-8 drives)
Up to 72.45 TB/hr (with 21 LTO-7 drives)
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Technical Specifications
Page 22
2.10 kg/4.63 lbs.
Reliability
MTBF (mean time between
failures)
125,000 hours (based on 1M MSBF)
MSBF (Mean swaps before
failure)
1,000,000
Average Cartridge Swap
Time (drive to slot, slot
to drive)
26 seconds (Base Unit)
Initialization Time
77 to 204 seconds
Inventory Time
50 seconds (average)
Base unit
Connectors
Mini-SAS (MSL SAS model only)
(1)RJ-45 Ethernet
Color Control Panel information
(on front panel)
Monochrome graphic display, 4 inch diagonal, 240 by 128 black
Management Interface
10/100/1000 Mbits/second, auto-configuring interface. RJ-45
connection. Https configurable.
Power
230 Watts (max)
Input Requirements
100-240 VAC, 3.7A Max., 50/60Hz
Relative Humidity
(non
Operating
20% to 80%
Shipping
20% to 90%
Temperature Range
(wet bulb)
Operating
50° to 95° F (10° to 35° C)
Shipping
-22° to 140° F (-30° to 60° C)
NOTE: Library operating temperature limits are based on the industry standard tape limit.
Altitude
Operating
13,000 ft (4000 m)
Shipping
35,000 ft (10,675 m)
-condensing)
LC Optical Fibre (MSL FC models only)
dots, 4/3 aspect ratio
QuickSpecs
HPE StoreEver MSL3040 Tape Library
Summary of Changes
Page 23
Date
Version History
Action
Description of Change
05-Mar-2018
From Version 2 to 3
Changed
Product Highlights and Related Options were revised.
05-Feb-2018
From Version 1 to 2
Changed
Product Highlights and Related Options were revised.
04-Dec-2017
Version 1
Created
All Content created.
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for HPE products and services are set forth in the
express warranty st
construed as constituting an additional warranty. HPE shall not be liable for technical or editorial errors or
omissions contained herein.
For tape drives and media, 1 GB = 1 bill
a00026511enw - 16082 - Worldwide - V3 - 5-March-2018
atements accompanying such products and services. Nothing herein should be
ion bytes. Actual formatted capacity is less.
Loading...
