QuickSpecs

HPE MSA 2042 SAN Storage

Overview

Page 1

HPE MSA 2042 Storage

HPE MSA 2042 Storage (SFF)

HPE MSA 2042 Storage (LFF)

The MSA 2042 further drives the MSA 800GB of flash capacity configuration and capacity Services SW License, customers can choose how to best utilize these SSDs to provide the optimal flash ac performance hungry applications

which works without user intervention to place the pages up to SSD for flash acceler real time manager.

2040 family into the world of flash acceleration with a new set of MSA models which includes

in all SFF and LFF configurations. In addition to including 2x400GB Mixed Use SSDs in the base

, the MSA 2042 also includes a rich set of software features as standard including 512 Snapshots, Remote Replication

Performance Tiering capabilities, all at a very attractive price compared to other hybrid configurations. The 800GB of SSD

can be used as Read Cache or as a start to building a fully tiered configuration. With the inclusion of the Advanced Data

hour-to-hour, day-to-day, and week-to-week. All done hands free and without any management overhead from the IT

• Starting at $10K, accelerate applications affordably

- The industry’s leading entry array, now with 800GB of SSD capacity standard

- Built-in, tiering dynamically moves hot data to flash and cold data to lower-cost media

• Set it and forget it

- Hands-free data tiering engine eliminates performance bottlenecks with zero admin required

- All-inclusive software suite and simple management tools for IT generalists & server admins

• Reduce risk with modern disaster recovery and business continuity

- 512 snapshots out-of-the-box for instant recovery

- Remote replication included for affordable application availability

• Grow flexibly now and into the future

- Data-in-place upgrades eliminate risky data migrations and costly drive investments

- Start small and scale as needed with any combination of SSD, Enterprise or Midline SAS drives

What’s new with the MSA 2042

• New MSA 2042 arrays based on write intensive (Mainstream Endurance) SSDs

• New SSF and LFF write intensive (Mainstream Endurance) SSDs

• Adding new higher capacity 900GB SAS 15K SF HDD

. Both Read Cache and Performance Tiering utilize a real-time tiering algorithm

most accessed data on the fastest medium at the right time. The MSA 2042 will dynamically move hot

ation and move cooler, more stagnant data back down to spinning media as workloads change in

celeration for their

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 2

HPE MSA 2042 Storage

Array

Access Type

Block

Form Factor

SFF or LFF

Number of controllers per array

Minimum/Maximum host ports

1/8

FC host connectivity

8/16Gb

iSCSI host connectivity

1Gb or 10GbI

SAS host connectivity

6/12Gb

Cache, per array

Max Read cache per array

8TB

Data (read/write) cache + system memory per array

12GB

Pool Capacity (with Large Pool Support)

562 TB (512 TiB)

RAID Levels supported: Virtual

RAID 1, 5, 6, 10

RAID Levels supported: Linear

RAID 0,1,3,5,6,10,50

Enclosures

Expansion Drive Enclosures

0-7 enclosures

LFF/SFF array/enclosure mixing

Supported

Maximum number of drives per array enclosure

24 SFF/12 LFF

Maximum number of drives per drive enclosure

25 SFF/12 LFF

Drive enclosure interface type

6Gb SAS

Drives

Maximum total HDDs per array

199 SFF / 96 LFF

Maximum total SSDs per array

199 SFF / 96 LFF

Number of SSDs embedded in base system

2 x 400GB SSDs

Max raw capacity per array enclosure

76.8 TB SFF / 120TB LFF

Max raw capacity per drive enclosure

80 TB SFF / 120TB LFF

Max raw capacity per array

637TB SFF / 960TB LFF

Supported Drive Capacities

SFF SSDs (Mixed Use)

400GB, 800GB, 1.6TB, 3.2TB

LFF SSDs

400GB, 800GB

SFF HDDs

15K SAS: 300GB, 450GB, 600GB

7.2K SAS: 1.0TB, 2.0TB

LFF HDDs (12G)

7.2K SAS: 2TB, 4TB, 6TB, 8TB

Software Features

Thin Technologies

Thin Provisioning, Space Reclamation, Thin Rebuild

Tiering

Performance Tier, Standard Tier, Archive Tier

Replication

Snapshots (512), Volume Copy, Remote Snaps

Quality of Service

Virtual Tier Affinity

Additional Features

Maximum number of volumes

512

Maximum number of snapshots

512

Maximum number of hosts

512

Maximum number of initiators

1024

10K SAS: 300GB, 600GB, 900GB, 1.2TB, 1.8TB

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 3

Customer self-installable

Yes

Customer self-repairable

Yes

Customer self-upgradeable

Yes

HPE MSA 2042 Storage

Power supplies

Management Ethernet port

Host connection ports FC, iSCSI,or SAS

5. Expansion port

CLI port (mini-USB)

MSA 2042 Storage

Descriptions

Part Number

Models based on

HPE MSA 2042 SAN Dual Controller LFF Storage

1,3

Q0F05A

HPE MSA 2042 SAN Dual Controller SFF Storage

1, 3

Q0F06A

HPE MSA 2042 SAS Dual Controller LFF Storage

1,4

Q0F07A

HPE MSA 2042 SAS Dual Controller SFF Storage

1 ,4

Q0F08A

Models based on

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drives LFF Storage

Q0F74A

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drives SFF Storage

Q0F72A

HPE MSA 2042 SAS Dual Controller with Mainstream Endurance Solid State Drives LFF Storage

Q0F75A

HPE MSA 2042 SAS Dual Controller with Mainstream Endurance Solid State Drives SFF Storage

Q0F73A

NOTES:

SSDs.

ENERGY STAR

ENERGY STAR certification for the HPE MSA 2042 Storage is pending.

(NEBS)

Mixed Use SSDs

Write Intensive SSDs

Certification

2,3,5

2,4,5

Includes an LFF or SFF Array Chassis, two MSA 2040 SAN or SAS controllers depending on model, two 400GB Mixed Use SSDs, one Advanced Data Services LTU.

Includes an LFF or SFF Array Chassis, two MSA 2040 SAN or SAS controllers

depending on model, two 400GB Write Intensive SSDs, one Advanced Data Services LTU

SFPs not included

SPFs not required

SSD naming convention has changed over time. Mainstream Endurance SSDs are

also known as Write Intensive SSDs and have a higher endurance than Mixed Use

Carrier-Grade Components

The HPE MSA 2042 Storage arrays are not NEBS compliant. The HPE MSA 2042 does not support DC power supplies.

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 4

to order the HPE MSA 2040 Carrier-Grade components.

to the HPE MSA 2040 Storage System.

For customers who require NEBS compliance, or who require DC power supplies, should consider the HPE MSA 2040 Storage arrays. Refer to the HPE MSA 2040 QuickSpecs on how

Encryption

Data at Rest Encryption is not supported on the HPE MSA 2042. If encryption is desired, refer

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 5

All MSA 2042 models offer a common set of valuable features:

• MSA 2042 comes standard with two 400GB flash drives which allow IT managers to accelerate application performance

Configuration Table for mixing SFPs

Configuration

Controller

Host Port 1 SFP

Host Port 2 SFP

Host Port 3 SFP

Host Port 4 SFP

Dual SAN

Controller A

16Gb FC

None

16Gb FC

8Gb FC

10GbE iSCSI

1GbE iSCSI

8Gb FC

None

16Gb FC

8Gb FC

10GbE iSCSI

1GbE iSCSI

10GbE iSCSI

None

10GbE iSCSI

1GbE iSCSI

None

10GbE iSCSI

1GbE iSCSI

Controller B

Match Controller A

NOTES: 1 SFP in Host Port 1 must match SFP in Host Port 2

SFP in Host Port 3 must match SFP in Host Port 4

All MSA 2042 models offer a common set of valuable features (cont):

• The two 400GB SSDs can be optionally deployed as read cache, as an SSD virtual disk group for tiered storage, or as a

Linear disk group.

- Deploy the two embedded SSDs as Read Cache to improve random read performance. A maximum of 2 SSD’s are

supported per pool providing a maximum of 4TB of read cache per controller

- Deploy the two embedded SSDs as tiered storage. The MSA 2042 can manage up to three tiers of storage:

Performance tier, Standard tier and Archive tier..

- The Performance Auto Tiering License necessary to create a SSD virtual disk group for both read and write

capabilities comes standard with all MSA 2042 models. No additional software license purchase is necessary

• All MSA 2042 models come standard with the Advanced Data Services (ADS) Software Suite LTU. Software titles

included in the ADS Software Suite include:

- HPE MSA 2042 Performance Automated Tiering LTU

- HPE MSA 512-Snapshot Software LTU

- HPE MSA Remote Snap Software LTU

• MSA 2042 controller architecture which maximizes performance

- Four host ports per controller

 MSA 2042 SAN controller supports 8 GB FC, 16 GB FC, 1GbE iSCSI or 10GbE iSCSI.  MSA 2042 SAS controller supports 6 GB and 12 GB SAS host connectivity.

- 6 GB transportable read/write cache per controller.

- Battery-free cache backup with super capacitors and compact flash

• MSA 2042 SAN Controller allows customers to create their own Combo Controller by mixing FC and iSCSI SFPs. Below are

the valid configurations for mixing SFPs:

Controller

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 6

• Storage Management Utility V3 (SMU). This new MSA management GUI brings a new modern look and feel to array

When capacity is added to a system, the user is

512 TiB capacity per virtual pool by

Application

The HPE MSA 2042 Storage is the ideal solution for customers running Oracle, Microsoft, SAP environments and

Learn more

To learn more about specific HPE Storage Solutions that are built with Oracle, Microsoft, SAP and Virtualization

management.

• Thin Provisioning allows storage allocation of physical storage resources only once they are consumed by an application.

Thin Provisioning also allows over-provisioning of physical without predicting storage capacity upfront.

• All models feature a wide variety of drives: High-performance SSD drives, enterprise-class SAS, and SAS Midline drives.

• The MSA 2042 will support a maximum of 7 disk enclosures (either LFF and/or SFF). Add-on enclosures can either be

D2700 SFF drive enclosures or MSA 2040 LFF disk enclosures.

• The MSA 2042 can grow incrementally to a maximum of 96 LFF or 199 SFF drives.

• Disks Groups can be spanned across multiple enclosures.

• Virtual Storage RAID levels 1, 5, 6, 10.

• Linear Storage RAID levels 0, 1, 3, 5, 6, 10, 50.

• Maximum hard drive counts vary by RAID levels: 2 drive max for RAID level 1; max of 16 drives for RAID levels 0, 3, 5, 6,

and 10; max of 32 drives for RAID level 50.

• Multiple Disk Groups can be aggregated into a single Storage Pool.

• The maximum LUN size is 140TB (128TiB)

• Storage Pools allow data on a given LUN to span across all drives in a pool.

also getting a performance benefit of the additional spindles.

• Snapshot enhancements for virtual storage, including performance improvements, hierarchical snapshots, and simplified

resource management. Administrators can monitor and optionally control snapshot space usage.

• Prioritize data by assigning appropriate affinity level (Performance, No Affinity or Archive)

• Large Pool Support is available with GL220 firmware or later. Customers can configure

enabling large pool support.

• Non-disruptive on-line controller code upgrade. Requires Multi-pathing software)

• Upgradable by design. Owners of an MSA P2000 G3 and an MSA 1040 array are able to do data-in-place controller

upgrades to the new MSA 2042 array. This unique ability protects the earlier investments in drives, and JBODs.

- Certain limitations are applicable. Please review the Upgrading to the HPE MSA 1040 or HPE MSA 2040/2042

Technical Whitepaper before upgrading your P2000 G3/MSA 1040 systems

storage pool resources allowing ease of growth for volumes

Solutions

those customers who are deploying virtual server technologies like VMware and Hyper-V. The MSA 2042 delivers enterprise functionality that enhances virtual environments, simplifies management, and reduces costs. Easy to deploy, scale and maintain, HPE MSA 2042 Arrays ensure that crucial business data remains available. Hewlett Packard Enterprise has developed best-in-class expertise in Oracle, Microsoft, SAP, and Virtualization Hypervisor technology through extensive testing with the HPE MSA 2042, HPE servers, and management software; high availability and disaster recovery solutions; and backup and recovery on the Oracle, Microsoft, and SAP application platforms. As a result, our customers can expect a wide range of operational and business benefits where they can:

Deploy IT assets across multiple locations. Incrementally grow storage without interruption. Enable high availability and disaster recovery capabilities for critical applications. Deploy a remote disaster recovery site.

environments in mind, visit the solution sites supporting each of these applications. HPE MSA Storage hyperlink to: http://www.hpe.com/storage/MSA

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 7

Product Technology

controller

SAS controller

MSA 2042 SAS controller supports 6Gb and 12Gb SAS host connectivity.

Modular

2U rack height. 12 LFF or 24 SFF drive bays. All MSA 2042 models come pre-configured with two controllers, two

NOTE: The MSA 2042 does not support single controller configurations.

Drives

The MSA 2042 controllers support both the MSA 3.5-inch LFF drives, and the MSA 2.5-inch SFF drives.

Optional

Just as the user has a choice of chassis for the array enclosure (LFF or SFF drive bays), so also do they have a choice of

drive bays and

SAS cables for connection to the MSA

SAN

Chassis

available

Disk Enclosures

MSA 2042 SAN controller supports 8Gb FC, 16Gb FC, 1GbE iSCSI or 10GbE iSCSI host connectivity. .

400GB SSDs, and an Advanced Data Services LTU

• Solid State Drives (SSDs) deliver exceptional performance for applications requiring high random read IOPs

performance.

• Serial Attached SCSI (SAS) enterprise-class drives are designed for high demand, 24x7 usage.

• SAS Midline drives are usually reserved for archival of data as they are relatively inexpensive and are

available in very large capacities.

expansion disk enclosures accommodating either drive size. Both the MSA 2040 and the D2700 disk enclosures can be hot-added to an operating array. SFF and LFF Array enclosures and Disk Enclosures can be mixed without limitations.

MSA 2040 3.5-inch Disk Enclosure. This 2U enclosure is designed to support twelve HPE Storage LFF accepts MSA dual-ported 12Gb SSD, SAS, and SAS MDL hard drives. The pre-configured MSA 2040 LFF Drive Enclosure has two I/O modules and supports the MSA 2042 dual controller arrays.

• The MSA 2040 LFF MSA Disk Enclosure can be attached to the MSA 2042 LFF or SFF storage models.

• Each MSA2040 LFF Disk Enclosure ships standard with two .5m mini-SAS to mini-SAS cables for connection to

the MSA 2042 array expansion port or existing disk enclosure cascade port.

• LFF and/or SFF Disk Enclosures can be mixed up to the maximum of 7 total Disk Enclosures

HPE D2700 Disk Enclosure This 2U enclosure is designed to support twenty five HPE Storage 2.5-inch SFF drive bays and accepts MSA dual ported 12Gb SSD, SAS, or SAS MDL hard drives. The pre-configuared D2700Disk Enclosure has two I/O modules and supports the MSA 2042 dual controller arrays.

• The D2700 Disk Enclosure can be attached to the MSA 2042 LFF or SFF storage models

• Each D2700 Disk Enclosure ships standard with a two .5m mini-SAS to mini-

2042 array expansion port or existing disk enclosure cascade port.

• LFF and/or SFF Disk Enclosures can be mixed up to the maximum of 7 total Disk Enclosures.

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 8

Scalability

The MSA 2042 array configurations are designed to allow an installation to begin with smaller capacity and be able to

Disk Group

A Disk Group is a collection of disks in a given redundancy mode (RAID 1, 5, 6, 10, 50). It is equivalent to a Vdisk in

Disk Groups can be allocated into a Storage Pool for use with the Virtual Storage features

LUNs

The MSA 2042 arrays support 512 volumes and up to 512 snapshots in a system. All of these volumes can be

storage

Storage

Storage Pools are comprised of one or more Disk Groups. LUNs are no longer be restricted to a single Vdisk as with

As volumes are expanded data automatically reflows to balance capacity utilization on all drives.

RAID 0, 1, 3,

In addition to the usual RAID levels, the MSA 2042 features several important additional levels. RAID 6 offers the

higher performance than RAID 5 through the addition of RAID 0, particularly during writes.

Performance

The performance figures provided here are for reference as many variables exist between array configurations,

MSA 2040 Array Performance 1

HPE MSA 2040 Converged SAN Controller with HDDs

HPE MSA 2040 Converged SAN Controller with Mainstrem Endurance SSDs

HPE MSA 2040 Converged SAN Controller with Mixed Use SSDs Protocol (host connect)

16 Gb Fibre Channel

MSA 2040 RAID 10 Performance Results 2

grow gradually as needed. The flexibility of SSD, SAS or SAS MDL drives technology, form factors, sizes, speeds, and costs per GB allows a system to easily fit in almost any budget.

• Large Form Factor configurations can scale up to 96TB SAS MDL, expandable to 768TB SAS MDL with the

addition of a maximum of seven MSA 2040 3.5-inch Disk Enclosures.

• Small Form Factor configurations can scale up to 76.8 TB SAS, expandable to 637 TB SAS. with the addition

of a maximum of seven HPE D2700 2.5-inch Disk Enclosures.

• Users may configure an MSA 2042 SFF array enclosure with LFF MSA 2040 3.5-inch disk enclosures. This is

an excellent option for a configuration that supports high-speed SFF SSDs or fast SFF enterprise-class SAS drives in the array enclosure, combined with economical LFF drives staged for archival purposes, all in the same array.

Linear Storage and utilizes the same proven fault tolerant technology used by Linear Storage. Disk Group RAID level and size can be created based on performance and/or capacity requirements. With GL200 or newer firmware multiple

mapped to LUNs. Maximum LUN sizes up to 140TB (128 TiB), the LUN capacity is size are dependent on the storage architecture: Linear vs. Virtualized. Thin Provisioning allows the user to create the LUNs independent of the physical

Pools

Linear Storage. A volume’s data on a given LUN can now span all disk drives in a pool. When capacity is added to a system, users will benefit from the performance of all spindles in that pool.

The MSA 2042 supports large, flexible Volumes with sizes up to 128TiB and facilitates seamless capacity expansion.

5, 6, 10, 50

highest level of RAID protection. It allocates two sets of parity data across drives and allows simultaneous write operations. It can withstand two simultaneous drive failures without downtime or data loss. RAID 10 is mirroring and striping without parity and allows large Disk Groups to be created with high performance and mirroring for fault tolerance. RAID 50 combines the block striping and parity of RAID 5 with the straight block striping of RAID 0, yielding

workloads, hard drive types, disk group setup parameters and host system setup. All performance information is measured using Linear Storage

Hewlett Packard Enterprise has traditionally published a set of end-to-end MSA performance specifications which feed into HPE Sizer tools which are based on conservative real-world configurations. For consistency, the MSA 2042 performance numbers have been documented in both Benchmark and End-to-End Performance tables. Configuration details are provided for both test scenarios. These numbers are subject to change without notice.

Benchmark Performance Results:

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 9

Random Reads (IOPs)

66,000

Random Writes (IOPs)

32,000

MSA 2040 RAID 1 SSD Performance Results 3

Random Reads (IOPs)

122,000

115,000

Random Writes (IOPs)

43,000

40,000

MSA 2040 RAID 5 Performance Results 4

Sequential Reads (MB/s)

6,300

Sequential Writes (MB/s)

5,200

Benchmark Setup Configurations

Performance numbers generated through the IO Meter performance software.

Dual Controller configuration, (192) 15k HDDs, RAID: 10, 6 drives per vDisk, block size: 8k, Average Latency under

Dual Controller configuration, (4) SSDs, RAID: 1, 2 drives per vDisk, block size: 8k (8k Aligned), Average Latency

Dual Controller configuration, (48) 15k HDD, RAID: 5, 12 drives per vDisk, block size: 256k, Average Latency under

Performance

HPE MSA

Converged

With HDD

HPE MSA

Converged

With SSD

HPE MSA

Converged

With HDD

HPE MSA

Converged

With SSD

HPE MSA

Converged

With HDD

HPE MSA

Converged

With SSD

HPE MSA

Converged

With HDD

HPE MSA

Converged

With SSD

Protocol (host connect)

16 Gb

Channel

16 Gb

Channel

iSCSI

SAS

MSA 2042 RAID 10 Performance Results **NOTE: RAID 1 was used for SSD testing

Random Reads IOPS

57,000

112,500

56,500

102,000

56,500

93,000

56,500

112,500

Random Writes IOPS

32,000

31,500

30,500

31,500

30,500

31,500

31,000

32,500

30ms, Windows Server 2012 host, 16Gb FC direct connect to array. Tested with GL210 firmware.

under 3ms, Windows Server 2012 R2 host, 16Gb FC direct connect to array. Tested with GL220 firmware.

30ms, Windows Server 2012 host, 16Gb FC direct connect to array. Sequential numbers are obtained using a single volume per vdisk and single sequential workload. Tested with GL210 firmware.

End-to-End Performance Figures Linear Storage: Guarantee Performance numbers are a guideline as established by tests using RAW I/O in an Operating System Agnostic test lab environment.

MSA 2042

Array

2042

SAN

Controller

Fibre

2042

SAN

Controller

Fibre

2042

SAN

Controller

10GbE

2042

SAN

Controller

10GbE

2042

SAN

Controller

1GbE

2042

SAN

Controller

1GbE

2042

Controller

12Gb

SAS

2042

SAS

Controller

12Gb

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 10

Random Mix 60/40 IOPS

45,000

57,500

44,500

54,500

44,500

54,500

44,500

58,000

Sequential Reads MB/s

5,000

4,700

860

4,720

Sequential Writes MB/s

2,400

2,300

850

2,300

MSA 2042 RAID 5 Performance Results **NOTE: RAID 1 was used for SSD testing

Random Reads IOPS

57,000

106,500

55,500

100,000

55,500

87,000

55,500

108,000

Random Writes IOPS

18,000

20,500

17,500

20,500

17,500

20,000

18,000

20,500

Random Mix 60/40 IOPS

30,000

37,500

29,500

37,500

29,500

36,500

29,500

37,000

Sequential Reads MB/s

4,900

4,700

860

4,700

Sequential Writes MB/s

4,000

3,600

850

4,100

MSA 2042 RAID 6 Performance Results **NOTE: RAID 1 was used for SSD testing

Random Reads IOPS

57,000

106,500

54,500

97,500

54,500

87,000

55,500

108,000

Random Writes IOPS

12,500

16,500

12,000

16,000

12,000

16,000

12,500

16,500

Random Mix 60/40 IOPS

23,000

31,500

22,500

31,000

22,500

30,500

23,000

32,000

Sequential Reads MB/s

4,900

4,600

860

4,500

Sequential Writes MB/s

3,900

3,500

850

3,800

dual controller configuration of 4 disk groups consisting of two disks per disk group, 200 GB and 400 GB volumes, and

5). For MSA 2042 Hard Disk Drive (HDD) results, 300 GB 15K SAS drives were used in a dual controller configuration of 16 disk groups consisting of twelve disks per disk group, 3.3 TB volumes, and 4 volumes per host. 4 hosts directly attached to the HPE MSA 2042 array were used in this test configuration (results cannot be expected with a single host).

NOTE: MSA 2042 tests with 1GbE iSCSI used 8 hosts directly attached to the HPE MSA 2042 array.

6). For MSA 2042 Solid State Drives (SSD) results, 200 GB and 400 GB Enterprise Mainstream SSDs were used in a

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 11

1 volume per host. 4 hosts directly attached to the HPE MSA 2042 array were used in this test configuration (results

comparisons.

Configuration and

HPE Storage Management Utility (SMU). Management access, out-of-band: WEB GUI, CLI. Interface

Telnet

Software and Documents

• All product documentation (CD can be used on ALL supported server Operating Systems.)

Hot Plug Expansion and

All MSA 2042 models support hot plug expansion and replacement of redundant controllers,

See https://www.hpe.com/h20195/V2/getpdf.aspx/4AA5-5032ENW.pdf?ver=1.0

levels of data protection, enables an almost instant recovery from data failure or corruption and offers

HPE Server Compatibility

NOTE:

protocol

The MSA 2042 supports most HPE ProLiant, BladeSystems and Integrity servers including

3rd Party server support

•

and listed on the

http://www.tsanet.com

cannot be expected with a single host).

NOTE: MSA 2042 tests with 1GbE iSCSI used 8 hosts directly attached to the HPE MSA 2042 array.

7). Sequential tests results were achieved with 256K block sizes and random tests were based on 8K block sizes.

NOTE: For sequential workloads with a queue depth greater than 1, each sequential stream is targeted to operate on a separate LBA range. Other types of sequential workloads that target specific LBA ranges may achieve higher results

8). All SAS results were measured using 6Gb SAS Host Bus Adapters. All configurations were tested with GL210 firmware.

9). All Fibre Channel results were measured using 16Gb FC Host Bus Adapters. All SAS results were measured using 6Gb SAS Host Bus Adapters. All 10GbE iSCSI results were measured using 10GbE iSCSI Host Bus Adapters. All 1GbE iSCSI results were measured using 1GbE network interface controllers (NICs)

NOTE: Number and type of applications, drive type and number of drives, operating system used, and the number of hosts will affect overall performance. This table is provided strictly as a test-lab comparison.

NOTE: These numbers reflect a full array configuration with the maximum number of front-end ports, disks, and controllers. The test results shown for the HPE MSA 2042 are designed to give a conservative reference point for

Management Tools

Support CD

Replacement Support

Snapshot and Clone

depends on

Types: USB 100/1000 Ethernet. Protocols Supported SNMP, SMI-S, SSL, SSH, SMTP, FTP, HTTP,

• Host Software Bundles (Win and Linux for both ProLiant x86, ProLiant x64 and Integrity

IA64servers.)

• CD updated quarterly on HPE.com with sustaining firmware updates

enclosures, fans, power supplies, and I/O modules for simple, fast installation and maintenance. Hot add expansion of disk enclosures is also supported.

All MSA 2042 arrays come standard with 512 snaps. This controller based functionality offers higher

alternative development testing of 'offline' production data and the ability to backup snapped/cloned data.

• HPE ProLiant DL, ML

• HPE c-Class Blade Servers

• Integrity servers, IA64

• Compatibility must be confirmed at: http://www.hpe.com/storage/spock

Supports most multi-vendor industry standard 32-bit and 64 bit Intel and AMD based (x86) servers. Hewlett Packard Enterprise requires the Third-Party Server to be logged Microsoft Windows Server Catalog.

• Hewlett Packard Enterprise recommends that the Third-Party Server Vendor is an active member

of TSANet. Refer to the TSANet website for details:

QuickSpecs

HPE MSA 2042 SAN Storage

Standard Features

Page 12

• Non-HPE servers will generally be supported if the HPE storage stack is used. This includes

OS Support

NOTE:

protocol

Refer to the Hewlett Packard Enterprise support statements for complete current OS version support

Web Browser support

•

management supports Microsoft Internet Explorer, Mozilla Firefox, and Google

supported HPE branded HBAs and drivers, and supported FC switches.

depends on

: http://www.hpe.com/storage/spock

• Microsoft Windows Server 2016

• Microsoft Windows Server 2012

• Microsoft Windows Server 2008 R2

• VMware

• HP-UX

• Red Hat Linux

• SuSE SLES Linux

Solaris

•

OpenVMS

•

MAC OS

•

The MSA 2042 arrays come integrated with web browser and CLI based software for storage and RAID management, setup, configuration, and troubleshooting. This reduces the cost of ownership by reducing the training and technical expertise necessary to install and maintain your HPE storage solution.

• The MSA 2042 supports target based management, and include a Web interface and a telnet

interface for management

• MSA 2042 customers have the option to use SMU v2(Linear Only) or SMU v3.

• Users taking advantage of virtualization features will be required to use SMU V3.

• The MSA 2042

Chrome.

QuickSpecs

HPE MSA 2042 SAN Storage

Software

Page 13

Advanced Data

All software for the MSA platform is now included as a standard feature on the MSA 2042 at no

Performance Tiering

Disk tiers are comprised of aggregating 1 or more Disk Groups of similar physical disks. The MSA

provided at no charge on the MSA 2042 platform

Snapshot and Volume

Hewlett Packard Enterprise does not provide warranty assistance for software products included

SP24 care packs.

Remote Snap Software

• HPE MSA Remote Snap software is available for both linear and virtual storage with GL220

underlying technology it creates multiple local recovery points which can be used for such

Services Software Suite

and Archive Tiering Software

extra charge. The MSA 2042 includes the Advanced Data Services Software Suite which includes the following software titles

1. HPE MSA 2040 Performance Automated Tiering LTU

2. HPE MSA 2040 512 Snapshot Software LTU

3. HPE MSA Remote Snap Software LTU

2042 supports 3 distinct tiers:

1. A Performance tier with SSDs

2. A Standard SAS tier with Enterprise SAS HDDs

3. An Archive tier utilizing Midline SAS HDDs.

The MSA 2042 supports sub-LUN tiering and automated data movement between tiers. The MSA 2042 automated tiering engine moves data between available tiers based on the access characteristics of that data. Frequently accessed “pages” will migrate to the highest available tier delivering maximum I/O´s to the application (Performance Tiering). The Performance Tiering functionality is provided at no charge on the MSA 2042.

Another feature to the MSA 2042 tiering engine is Archive Tiering where “cold” or not frequently accessed data can be moved to lower performance tiers. Pages are migrated between tiers automatically such that I/O’s are optimized in real-time. The Archive Tiering functionality is

Copy Software

• A 512 Snapshot license and Volume Copy are included with all MSA 2042 models as standard

• Snapshots create up to 512 point-in-time copies of data

• Volume Copies create up to 128 point-in-time copies of data

• Volume copies become standard volumes when they are complete

• Recovery is instant - revert data from any previous Snapshot or Volume Copy (volume copy is

available for both linear and virtual storage with GL220 firmware or later;).

• Backup 'snapped' data to disk, virtual tape, or physical tape without a backup window

• If telephone support and software updates are desired for bundled software functionalities, a

combination HW + SW support care pack must be purchased.

•

with our base hardware products. This would either be SupportPlus or SupportPlus24. The hardware warranty component of these services is accounted for in the pricing of the SP and

firmware or later. HPE MSA Remote Snap Software is array based software that provides remote replication on the HPE MSA 2042 Array products. HPE Remote Snap is a form of asynchronous replication which consists of replication of block-level data from a volume on a local system to a volume that may be on the same system or on a second independent system. This second system may be co-located with the first system or may be located at a remote site.

• HPE Remote Snap functionality is based on existing Snapshot technology offered by HPE MSA

SAN and SAS Array products. Snapshots are used to track the data to be replicated as well as to determine the differences in data updated on the master volume, minimizing the amount of data to be transferred.

• HPE Remote Snap replication technology provides the ability to accomplish key data

management and protection capabilities. First, because Remote Snap uses snapshots as the

QuickSpecs

HPE MSA 2042 SAN Storage

Software

Page 14

tasks as to complement daily backups; second, replication provides the ability to access data in

VMware Site Recovery

VMware vCenter Site Recovery Manager (SRM) is an extension to VMware vCenter that delivers

Site Recovery Adapter

The MSA 2042 SRA, a free-to-use plugin, is the program that integrates the VMware vCenter SRM

implementing and testing the disaster recovery between sites located across geographies. It enables

a remote site which could be used for dispersed operations; and third but definitely not least important replication allows for business continuance in the event of a failure on the primary site.

• In order to perform a replication, a snapshot of the volume to be replicated is taken, creating a

point-in-time image of the data. This point-in-time image is then replicated to the destination volume by copying the data represented by the snapshot via a transport medium such as TCP/IP (iSCSI) or Fibre Channel. The amount of data transferred is minimized though the use of snapshots whenever possible.

NOTE: A Remote Snap License is provided with the MSA2042. One license per array is required for replication. For example, if you have two MSA arrays performing replication (from Primary system to Remote System), you will need a total of 2 licenses.

Product Features

• Storage based asynchronous snapshot replication

• Initial copy of data can be performed locally, reducing burden on wide area networks

• Support of both Ethernet and Fibre Channel interconnects provides flexible options to the

application environments. Remote Snap is not supported on SAS models.

• Snapshot based replication technology means only changed data will be replicated to alternate

site

• Many to 1 replication (up to 4 nodes) - primary use case is to replicate from "many" branch

offices to the home office for the purpose of backing up data from the branches

• Advanced scheduler provides several options to IT administrators for business continuance

• Flexible architecture allows remote replication between MSA 2042 and/or MSA 2040, MSA

1040 or P2000 G3 supported arrays. Protects existing investments and enhances business continuity planning objectives.

• Replication Wizard (Linear only) simplifies the task of setting up and establishing replication

pairs from one unified, easy to use GUI.

• Snapshot based replication enables both local and remote recovery depending on the need.

Snapshot replication isolates problems to a specific point in time which can be selected by the administrator. Additionally snapshot replication supports longer distance replication.

• Multiple relationships provide greater storage flexibility and utilization.

• Bundled 512 Snapshots and Volume Copy integration provides better efficiencies by

combining the management and array technologies to create local copies.

• Fast application recovery with minimal or no transaction loss

• Creation of disaster tolerant copies of your critical business data

• No-single-point-of-failure solution to increase the availability of your customers data

Manager(SRM)

business-continuity and disaster-recovery solution that helps you plan, test, and execute the recovery of vCenter virtual machines. SRM can discover and manage replicated datastores, and automate migration of inventory from one vCenter to another. Site Recovery Manager integrates with the underlying replication product through a Storage Replication Adapter (SRA). The SRM is available only for linear storage.

(SRA)

with HPE MSA 2042 arrays. It enables full-featured use of the VMware SRM. It is a host-software component installed on a Microsoft Windows Server that enables disaster recovery management (DRM) software on the host to communicate and control certain aspects of the replication feature in storage systems connected to the server. It allows the VMware SRM software to automatically coordinate virtual machine failover and failback between a protected data center and a disaster recovery site by employing a disaster recovery solution called Remote Snap. A perfect combination of the Remote Snap replication and VMware SRM provides an unfailing automated solution for

QuickSpecs

HPE MSA 2042 SAN Storage

Software

Page 15

communication between the HPE MSA Remote Snap replication functionality that is embedded in

HPE OneView for

HPE OneView for VMware vCenter is a component within the HPE OneView plug-in for vCenter. It

http://h22168.www2.hpe.com/us/en/partners/vmware/

HPE StoreFront

HPE StoreFront Manager for Microsoft enables management and monitoring of HPE MSA Storage

Pools, and volumes

HPE MSA 2042 systems. Users are required to acquire Remote Snap license for their local and remote HPE MSA 2042 arrays to use the HPE MSA SRA.

Site Recovery Manager Requirements/Dependencies:

• Requires vSphere 5.1, 5.5 or above

• Supports SRM 5.1, 5.5 and 5.8

• Requires HPE MSA 2040 /P2000 SRA 5.8 or later Plug-in (downloadable from hpe.com)

• SRM works with Remote Snap linear mode

• Requires two MSA 2042 Remote Snap licenses (one for each site)

VMware vCenter

provides VMware administrators that are using VMware's vSphere management console (vCenter) with the ability to see how virtual machines are mapped to datastores and individual MSA 2042 volumes. By providing these clear relationships between VM's, datastores and storage, the VMware administrator's productivity increases, as does the ability to ensure quality of service. Roles for administrators can be defined on an individual basis, providing the ability to apply specific permissions for both view and control functions.

HPE OneView for VMware vCenter supports mixed array environments including MSA 2042, MSA 2040, MSA 1040, P2000, EVA, P4000, and the XP array series including the P9500.

When deployed with the MSA 2042 array, HPE OneView provides the following:

• Active Management functionality for the MSA 2042 array:

- Create/Expand/Delete a Datastore

• Monitors the health and status of the MSA 2042

• Displays LUN / volume connections from VMs and ESX servers to the arrays and provides

- Create a Virtual Machine from a template

- VMClone for linear storage

the location and attributes of the MSA 2042 within the SAN

• Identifies what storage features are available to allow administrators to match the features

available on the MSA 2042 to their requirements

• Provide a cluster-level view of the storage

HPE OneView for VMware vCenter is downloadable from Software

https://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?productNumbe

Depot: r=HPVPR

For more information on HPE OneView for VMware vCenter visit:

Manager for Microsoft

running in Microsoft Hyper-V environment with a single pane-of-glass view to events/alerts, capacity and health dashboards and detailed virtual infrastructure information. It integrates seamlessly with Microsoft System Center Operations Manager (SCOM) and provides Microsoft administrators the following:

It supports heterogeneous HPE Storage environment including HPE MSA, HPE StoreVirtual, HPE 3PAR StoreServ, HPE StoreOnce, HPE StoreEasy, HPE XP, HPE EVA and HPE StoreEver Storage.

When deployed with the MSA 2042 array, HPE StoreFront Manager provides the following:

• Monitors the health, events and alerts for the MSA 2042/2040/1040 – Linear and virtual

QuickSpecs

HPE MSA 2042 SAN Storage

Software

Page 16

•

em_Center

vStorage API for Array

The vStorage API for Array Integration (VAAI) is one of the storage application programming

storage array. With hardware offload, ESX/ESXi hosts perform certain operations faster and consume

UNMAP reclaims space that is no longer on a thinly provisioned VMFS volume

Provides detailed information on the VMs provisioned through MSA Storage

• Effortless installation and configuration using Powershell

HPE StoreFront Manager for Microsoft for MSA Storage is downloadable from Software Depot:

https://h20392.www2.hpe.com/portal/swdepot/displayProductInfo.do?productNumber=Syst

Integration (VAAI)

interface (API) sets in vSphere. VAAI is an API storage partners can leverage to enhance performance of virtual machine (VM) management operations by delegating these operations to the

less server CPU and memory resources, and also storage port and storage fabric bandwidth. VAAI includes high performance and scalable VM data path primitives.

Storage Hardware Primitives for VAAI

• Full Copy or Hardware Assisted Move

• Block Zeroing or Hardware Assisted Zeroing

• Hardware Assisted Locking or Atomic Test and Set (ATS)

QuickSpecs

HPE MSA 2042 SAN Storage

Warranty, Service and Support Information

Page 17

Warranty

Three-year limited warranty, parts exchange Next Business day delivery

one year warranty.

Solid State Drives

3/0/0 warranty; Customer Self Repair (CSR) subject to maximum usage and or maximum supported lifetime

device before reaching the device's write endurance limit.

Service and Support

Protect your business beyond warranty with HPE Support Services

service level, length of coverage and response time as you purchase your new storage solution, giving

you full entitlement for the support for need for your IT and business.

Connect your

Unlock all of the benefits of your technology investment by connecting your products to HP

All of these benefits are already available to you with your server storage and networking products, securely

Optimized Care

HPE Proactive Care with 6 hour call-to-repair commitment, three year Support Service

products are connected to HPE. This Service combines three years’ proactive reporting and advice with our

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Enclosures, Hard drives, and Options for the MSA 2042 carry their own warranty. Refer to Hewlett Packard Enterprise Limited Warranty Statement for more information.

The MSA 2042 has been designed with customer self-repairable parts to minimize repair time and provide greater flexibility in performing defective parts replacement. Please refer to Hewlett Packard Enterprise limited warranty Statement and parts replacement instructions for further details.

http://h20565.www2.hpe.com/hpsc/doc/public/display?sp4ts.oid=5211884&docId=emr_nac04770336&docLocale=en_US

Products included in various kits carry their own individual warranties.

NOTE: The warranty of the hard drive options purchased with the MSA 2042 models is different for SAS hard drives versus SAS MDL. SAS hard drive options have a three year warranty and SAS MDL have a

(SSD) Warranty

limitations, whichever occurs first. Maximum Supported Lifetime is the period in years set to equal the warranty for the device. Maximum usage limit is the maximum amount of data that can be written to the

HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and stability. Our integrated portfolio of Services for storage help customers reduce costs, optimize data, streamline storage management, and improve backup and recovery. HPE Support Services enable you to choose the right

devices

Enterprise. Achieve up to 77%1 reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, pre-failure alerts,

automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimizatio

connected to HPE support.

IDC whitepaper - The Business Value of Connected Support from HP, March 2015

HP CSC reports 2014 – 2015

HPE Proactive Care gives customers an enhanced call experience plus helps preventing problems and maintains IT stability by utilizing tailored, proactive reports with recommendations and advice when your

highest level of hardware support - HPE’s 24x7, six hour hardware call-to-repair. HPE is the only leading manufacturer who makes this level of coverage available as a standard service offering for your most valuable storage systems.

QuickSpecs

HPE MSA 2042 SAN Storage

Warranty, Service and Support Information

Page 18

Standard Care

HPE Proactive Care with 24x7 coverage, three year Support Service

Basic Care

HPE Foundation Care 24x7, three-year Support Service

Related Services

Choose from a rich portfolio of services to make the most of MSA 2042 SAN Storage so you can efficiently

The HPE Storage Efficiency Analysis provides customers with a view of

HPE Proactive Care gives customers an enhanced call experience plus helps preventing problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice when your products are connected to HPE. This Service combines three years’ proactive reporting and advice with our 24x7 coverage, four hour hardware response time when there is a problem.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

HPE Foundation Care 24x7 gives you access to HPE 24 hours a day, seven days a week for assistance on resolving issues. This service includes need based Hardware onsite response within four hours. Simplify your support experience and make HPE your first call to help resolve hardware or software problems.

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

and affordably consolidate, manage, and extract value from unstructured data.

HPE Services can help you discover needs and create a plan for simplifying the environment, reducing risk, and maximizing your storage investments

HPE MSA Family Disk Array Installation and Startup Service - Implement right from the start, as Hewlett Packard Enterprise experts install, test, and configure your hardware and software onsite. We deliver a tailored storage deployment properly integrated into your environment. http://h20195.www2.hpe.com/V2/GetPDF.aspx/4AA0-3048ENW.pdf

HPE Storage Data Migration Services - End-to-end data migration service providing seamless discovery, assessment, planning, and design, completely customizable to your organization's storage area network or network attached storage environment and using innovative software to help you migrate to HPE storage quickly and efficiently.

http://h20195.www2.hpe.com/V2/GetPDF.aspx/5982-4107en.pdf

HPE Storage Efficiency Analysis -

their storage infrastructure and operating environment; highlighting recommendations for improvements. The report provides extensive insight about the existing storage environment, opportunities for efficiency gains, asset aging and replacement through interaction with key decision makers

http://h20195.www2.hpe.com/V2/GetPDF.aspx/4aa3-9475enw.pdf

QuickSpecs

HPE MSA 2042 SAN Storage

Configuration

Page 19

Configuration Information

Step 1 - MSA 2042 - Base Configurations

Pre-Configured

HPEMSA 2042 SAN Dual Controller LFF Storage

1,2

Q0F05A

HPEMSA 2042 SAN Dual Controller SFF Storage

1,2

Q0F06A

HPEMSA 2042 SAS Dual Controller LFF Storage

1,3

Q0F07A

HPEMSA 2042 SAS Dual Controller SFF Storage

1,3

Q0F08A

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drives LFF Storage

Q0F74A

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drivess SFF Storage

Q0F72A

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drives SFF Storage

Q0F75A

HPE MSA 2042 SAN Dual Controller with Mainstream Endurance Solid State Drives SFF Storage

Q0F73A

NOTES:

known as Write Intensive SSDs, and have a higher endurance than Mixed Use SSDs

Step 2 – Choose Your SFP+ Module

SFP+

HPE MSA 2040 8Gb Short Wave Fibre Channel SFP+ 4-Pack Transceiver (Includes four x 8Gb SW FC SFPs)

C8R23A

HPE MSA 2040 16Gb Short Wave Fibre Channel SFP+ 4-Pack Transceiver (Includes four x 16Gb SW FC SFPs)

C8R24A

HPE MSA 2040 10Gb Short Range iSCSI Channel SFP+ 4-Pack Transceiver (Includes four x 10Gb SW iSCSI SFPs)

C8R25A

HPE MSA 2040 1Gb RJ-45 iSCSI Channel SFP+ 4-Pack Transceiver (Includes four x 1Gb RJ-45iSCSI SFPs)

C8S75A

NOTE:

For MSA 2042 10Gb iSCSI configuration user can use DAC cables instead of SFPs.

Step 3 – Select Your Drives.

MSA HDDs and SSDs drives are for use with MSA Storage Systems only.

Co-existence of Mainstream Endurance SSDs and Mixed Use SSDs in the same Disk Group is supported

HPE MSA 400GB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X95A

HPE MSA 800GB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X96A

HPE MSA 1.6TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X91A

Systems

Information

2,3,5

2,4,5

Includes an LFF or SFF Array Chassis, two MSA 2040 SAN or SAS controllers

depending on model, two 400GB Mixed Use SSDs, one Advanced Data Services LTU.

Includes an LFF or SFF Array Chassis, two MSA 2040 SAN or SAS controllers

depending on model, two 400GB Write Intensive SSDs, one Advanced Data Services LTU

SFPs not included

SPFs not required

SSD naming convention has changed over time. Mainstream Endurance SSDs are also

Modules

Customers can mix SSD, SAS, and SAS MDL drives in the same array enclosure and disk enclosure

SFF SSDs

MSA 2042 SAN Controllers do not ship with any SFPs MSA 2042 SAS controllers do not require SFP modules. Customer must select one of the above SFP options for SAN Controllers. Each MSA 2042 SAN controller can be configured with 2 or 4 SFPs. MSA SFPs are for use only with MSA 2042 SAN Controllers.

12G SFF SAS SSDs (Mixed Use)

QuickSpecs

HPE MSA 2042 SAN Storage

Configuration Information

Page 20

HPE MSA 3.2TB 12G SAS Mixed Use SFF (2.5in) 3yr Warranty Solid State Drive

N9X92A

12G SFF SAS SSDs (Mainstream Endurance)

HP MSA 200GB 12G ME SAS SFF (2.5in) Enterprise Mainstream 3yr Warranty Solid State Drive

K2Q45A

HP MSA 400GB 12G ME SAS SFF (2.5in) Enterprise Mainstream 3yr Warranty Solid State

J9F37A

HP MSA 800GB 12G ME SAS SFF (2.5in) Enterprise Mainstream 3yr Warranty Solid State Drive

J9F38A

HP MSA 1.6TB 12G ME SAS SFF (2.5in) Enterprise Mainstream 3yr Warranty Solid State Drive

J9F39A

SFF HDDs

12G SFF 15K SAS HDDs

HP MSA 300GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive

J9F40A

HP MSA 450GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive

J9F41A

HP MSA 600GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive

J9F42A

HPE MSA 00GB 12G SAS 15K SFF (2.5in) Enterprise 3yr Warranty Hard Drive

Q1H47A

12G SFF 10K SAS HDDs

HP MSA 300GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F44A

HP MSA 600GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F46A

HP MSA 900GB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F47A

HP MSA 1.2TB 12G SAS 10K SFF(2.5in) Dual Port Enterprise 3yr Warranty Hard Drive

J9F48A

HP MSA 1.8TB 12G SAS 10K SFF (2.5in) 512e Enterprise 3yr Warranty Hard Drive

J9F49A

12G SFF 7.2K SAS MDL HDDs

HP MSA 1TB 12G SAS 7.2K SFF (2.5in) 512e Midline 1yr Warranty Hard Drive

J9F50A

HP MSA 2TB 12G SAS 7.2K SFF (2.5in) 512e Midline 1yr Warranty Hard Drive

J9F51A

•

• Intense I/O environments require the use of enterprise-class SSD or SAS drives

LFF SSDs

12G LFF SAS SSDs (Mixed Use)

HPE MSA 400GB 12G SAS Mixed Use LFF (3.5in) Converter Carrier 3yr Wty Solid State Drive

P9M79A

HPE MSA 800GB 12G SAS Mixed Use LFF (3.5in) Converter Carrier 3yr Wty Solid State

P9M80A

12G LFF SAS SSDs (Mainstream Endurance)

HPE MSA 400GB 12G SAS ME LFF (3.5in) Ent Mainstream Converter Carrier 3yr Wty

Q0F76A

HPE MSA 400GB 12G SAS ME LFF (3.5in) Ent Mainstream Converter Carrier 3yr Wty Solid State Drive

Q0F77A

LFF HDDs

12G LFF 7.2K SAS Midline Drives

HPE MSA 10TB 12G SAS 7.2K LFF (3.5in) Midline 512e 1 yr Wty Hard Drive

P9M82A

HP MSA 8TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive

M0S90A

HP MSA 6TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive

J9F43A

HP MSA 4TB 12G SAS 7.2K LFF (3.5in) 512e Midline 1yr Warranty Hard Drive

K2Q82A

12G LFF 15K SAS HDDs (SFF Drives in LFF Converters)

HP MSA 300GB 12G SAS 15K LFF (3.5in) Converter Enterprise 3yr Warranty Hard Drive

J9V68A

HP MSA 450GB 12G SAS 15K LFF (3.5in) Converter Enterprise 3yr Warranty Hard Drive

J9V69A

HP MSA 600GB 12G SAS 15K LFF (3.5in) Converter Enterprise 3yr Warranty Hard Drive

J9V70A

•

Step 4 – Options

Drive

SAS MDL drives are designed for archival or reference data.

• SAS MDL drives should not be used in a heavy or intense I/O environment.

Drive

Solid State Drive

SAS MDL drives are designed for archival or reference data.

• SAS MDL drives should not be used in a heavy or intense I/O environment.

Intense I/O environments require the use of enterprise-class SSD or SAS drives

QuickSpecs

HPE MSA 2042 SAN Storage

Configuration Information

Page 21

Drive

HPE MSA 2040 Energy Star LFF Disk Enclosure

M0S96A

HPE D2700 Disk Enclosure

AJ941A

• Each drive enclosure includes two 0.5m MiniSAS to MiniSAS cables

SAS Cables

HP External Mini SAS 1m Cable ALL

407337-B21

HP External Mini SAS 2m Cable

407339-B21

• Connecting MSA 2042 Controller to a JBOD if a longer cable is desired.

AC Power Cords

HP ProLiant 12 ft Power Cord

227099-001

Power Cord, (Australia/China/New Zealand)

227098-001

Power Cord, (Central Europe)

157215-001

Power Cord, (United Kingdom/Hong Kong)

157216-001

Power Cord, (Switzerland)

157219-001

Power Cord, (Italy)

157217-001

Power Cord, (Denmark)

157218-001

Power Cord, (Japan)

139867-001

Power Cord, (South East Asia/India)

157220-001

• Two PDU cables: one 142263-008 (Black) and one 1422633-013 (Grey), ship

Step 5a - Choose Supported Options For Fibre Channel Infrastructure

PremierFlexOM4

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 5m Cable

QK734A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 15m Cable

QK735A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 30m Cable

QK736A

HP Premier Flex LC/LC Multi-mode OM4 2 fiber 50m Cable

QK737A

HP LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable

AJ833A

HP LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable

AJ834A

HPE LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable

AJ835A

HP LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable

AJ836A

M3 FC LC-LC

HP LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable

AJ837A

HP LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable

AJ838A

HP LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable

AJ839A

Step 5b - Choose Supported Options For SAS Infrastructure

Mini-SAS Cables

HP 1.0m External Mini SAS High Density to Mini SAS Cable

716189-B21

HP 2.0m External Mini SAS High Density to Mini SAS Cable

716191-B21

HP 4.0m External Mini SAS High Density to Mini SAS Cable

716193-B21

•

HP External 1.0m (3ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716195-B21

HP External 2.0m (6ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716197-B21

HP External 4.0m (13ft) Mini-SAS HD 4x to Mini-SAS HD 4x Cable

716199-B21

•

Enclosures

• Add up to 7 additional drive enclosures

• MSA 2040 LFF Disk Enclosure can be connected to either the MSA2042 SFF

or LFF dual controller systems.

• D2700 Disk Enclosure can be connected to either the MSA 2042 SFF or LFF

dual controller systems.

•

The D2600 Disk Enclosure is not supported on the MSA2042 storage system.

standard with all AC-powered enclosures

type cables

cables

These cables are used to connect 6Gb SAS initiator to MSA 2042 SAS controller.

•

These cables are not used for connecting to a disk enclosure

These cables are used to connect 12Gb SAS initiator to MSA 2042 SAS controller.

•

These cables are not used for connecting to a disk enclosure.

QuickSpecs

HPE MSA 2042 SAN Storage

Configuration Information

Page 22

Step 5c - Choose Supported Options For 10GbE Infrastructure

Copper Cable

HP BladeSystem c-Class 10GbE SFP+ to SFP+ 0.5m Direct Attach Copper Cable

487649-B21

HP BladeSystem c-Class 10GbE SFP+ to SFP+ 1m Direct Attach Copper Cable

487652-B21

HP BladeSystem c-Class 10GbE SFP+ to SFP+ 3m Direct Attach Copper Cable

487655-B21

HP BladeSystem c-Class 10GbE SFP+ to SFP+ 5m Direct Attach Copper Cable

537963-B21

HP BladeSystem c-Class 10GbE SFP+ to SFP+ 7m Direct Attach Copper Cable

487658-B21

DAC Cable

HPE X242 10G SFP+ to SFP+ 1m Direct Attach Copper Cable

J9281B

HPE X242 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

J9283B

HPE X242 10G SFP+ to SFP+ 7m Direct Attach Copper Cable

J9285B

HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable

JD095C

HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable

JD096C

HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable

JD097C

HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable

JG081C

HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable

JC784C

Step 6 – Software

Software

The following advanced virtualization functionalities are included as a standard feature on all new MSA 2042 SAN and SAS models.

HPE MSA 2042 Performance Automated Tiering LTU

Standard

HPE MSA 512-Snapshot Software LTU

Standard

HPE MSA Remote Snap Software LTU

Standard

QuickSpecs

HPE MSA 2042 SAN Storage

Technical Specifications

Page 23

MSA 2042

POWER REQUIREMENTS

Input Power

• 110VAC 3.32A, 344-390 W; 220VAC 1.61A,374-432W

Max Input Power

100-240 VAC, 50/60 Hz., 4.5-1.9A; 48-60 VDC 10.4A/8.3A

Heat Dissipation

1622 BTU/hr

TEMPERATURE AND HUMIDITY RANGES

Operating Temperature

41°F to 104°F (5°C to 40°C)

Shipping Temperature

-40°F to 158°F (-40°C to 70°C)

Operating Humidity

10% to 90% RH @ 104°F (40°C) non-condensing

Non-Operating Humidity

Up to 93% RH @ 104°F (40°C)

DECLARED ACOUSTIC NOISE LEVELS

Sound Power

A weighted sound power LWAd=6,75 B

Sound Pressure

A weighted sound pressure LpAm - 55dB

SHOCK AND VIBRATION

Shock, Operational

3G's for 11 milliseconds

Shock, Non-Operational

15G 11ms half sine

Vibration, Operational

5-500Hz, 0.14 Grms shaped

Vibration, NonOperational

3-365-3Hz, 1.22 Grms,z-axis,0.85 Grms, X&Y axis shaped spectrum

PHYSICAL

Height

3.5 in/ 8.9 cm

Depth (excluding cables)

controller handle)

SFF 24-bay array: 19.5 in / 49.5 cm LFF 12 Width (body only)

17.6 in / 44.7 cm (w/ ears 19 in / 48.26 cm)

Weight

controllers. No drives)

LFF chassis: 40.6 lbs. SFF chassis:

MSA 2042 Regulatory Info

Safety

UL 60950-1 (USA)

CAN/CSA-C22.2 No.60950-1-03 (Canada)

EN 60950-1 (European Union)

GS mark (Germany)

IEC 60950-1 (International)

CCC Mark (power supply only, China PRC)

Electromagnetic

VCCI:2008-04 Class A (Japan)

FCC 15:109(g) Class A (USA)

ICES-003:2004 Class A (Canada)

EN55022 : (European Union Class A); CISPR 22 (International Class A)

EN61000-3-2 : (Harmonics) (European Union)

EN61000-3-3 : (Flicker) (European Union)

Requirements (typical-running I/O) SFF/LFF arrays

(back of ear to back of

(Includes chassis and 2

Compatibility

-bay array: 22.5in. / 57.2 cm

38.7 lbs

QuickSpecs

HPE MSA 2042 SAN Storage

Technical Specifications

Page 24

EN 55024 (European Union, Immunity, Class A);CISPR 24 (International Immunity, Class A)

AS/NZS CISPR 22, Class A (Australia, New Zealand)

CNS 13438 Taiwan, Class A (Taiwan)

KN22 Class A (Emissions Class A); KN24 (Immunity) (S Korea)

RoHS and WEEE

RoHS-6/6 Compliance, China RoHS, WEEE

Country Approvals

United States ,Australia/New Zealand, Canada, China (PRC), European Union, Germany (GS Mark), Japan, South Korea, Taiwan

QuickSpecs

HPE MSA 2042 SAN Storage

Summary of Changes

Page 25

Date

Version History

Action

Description of Change

27-March-2017

From Version 3 to 4

Changed

TBD

13-Feb-2017

From Version 2 to 3

Changed

Changes made to the entire document

26-Sept-2016

From Version 1 to 2

Changed

Changes made to the entire document.

15-Aug-2016

Version 1

Created

Document Created

© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. shall not be liable for technical or edit

Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel is a US registered trademark of Intel Corporation. Unix is a registered trademark of The Open Group.

c05183822

orial errors or omissions contained herein.

Hewlett Packard Enterprise products and

Hewlett Packard Enterprise

- 15639 - Worldwide – V4 - 27-March-2017

HPE Q0F08A Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Software

Warranty, Service and Support Information

Configuration Information

Technical Specifications

Summary of Changes
