HPE ProLiant DL380 Gen10 Server

Overview

Page 1

HPE ProLiant DL380 Gen10 Server QuickSpecs

Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen10 delivers world-class performance with the right balance of expandability and scalability. Designed for supreme versati backed by a comprehensive warranty make it ideal for multiple environments from Containers to Cloud to Big Data. Standardize the industry’s most trusted compute platform.

Front View – SFF chassis with optional Universal Media bay with optical and 2 NVME plus 16 NVMe shown

Quick removal access panel

Optional Universal Media bay. 2 USB 2.0 and Display port optional)

Optional Optical drive. Requires Universal Media bay

Drive Bay 2. NVMe shown (8 SFF, 6SFF+2NVMe or 8 NVMe PCIe SSD optional)

Optional 2 SFF HDD, requires optional Universal Media bay

Power On/Standby button and system power LED button

8 SFF Drive Cage Bay

NIC status

Health LED

11.

iLO Front Service Port

10.

UID button

13.

Serial label pull tag

12.

USB 3.0

15.

Box 2

14.

Box 3

17.

Optional front display port (Via Universal Media Bay)

16.

Box 1

18.

Optional USB 2.0 (via Universal Media Bay)

lity and resiliency while being

standard (8 SFF bay or 6 SFF+2NVMe or 8NVMe

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 2

Front View – 8LFF chassis with Universal media bay and optional 2SFF and optical drive shown

UID button

Health LED

NIC status

Power On/Standby button and system power LED button

Front display port

iLO Front Service Port

Serial label pull tag

Optional optical drive shown (blank as standard)

Optional 2 SFF Drive bay, 2 NVMe shown

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 3

Internal View 8SFF chassis – with optional 2nd CPU, FlexLOM, Smart array shown

Fan cage shown with 6 standard Hot-plug fans (High Performance

2 Processors, heatsink showing

Optional HPE Smart Storage Battery

DDR4 DIMM slots. Shown fully populated in 24 slots (12 per processor)

MicroSD card slot (Optional Dual Micro-SD option)

Chassis intrusion detection connector

Internal USB 3.0 connector

(Under) Hot Plug redundant HPE Flexible Slot Power supplies

Optional HPE Smart Array (P408i-a shown)

11.

Embedded 4x1Gbe NIC

13.

Optional Flexible LOM slot

10.

Connection for second (optional) riser (Requires second CPU)

15.

Clear air baffle

12.

Primary PCIe riser, standard (Optional double wide GPU riser)

14.

X4 SATA ports (1, 2 and 3)

temperature fans optional)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 4

Rear View – With optional FlexLOM, Rear drives and Serial port shown.

Primary Riser. PCI Slots (Slots 1-3 top to bottom, riser shipped standard, not shown), optional 2SFF rear drives

Secondary Riser. PCI Slots (Slots 4-6top to bottom, not shown, requires second riser card, and second processor). Showing optional 2 SFF rear

Optional serial port

Tertiary Riser (Slots 7-8). Optional rear 2 SFF HDD (supported in 24 SFF or 12 LFF front end)

Power supply Power connection

Power supply Power LED

HPE Flexible Slot Power Supply bay 2 (800W shown)

Power supply Power connection

Power supply Power LED

10.

HPE Flexible Slot Power Supply bay 1 (800W shown)

11.

VGA connector

12.

Embedded 4 x 1GbE Network Adapter

13.

Dedicated iLO management port

14.

USB connectors 3.0 (2)

15.

Unit ID LED

16.

Optional FlexibleLOM ports (Shown: 4 x 1GbE)

What’s New:

• Greater chassis flexibility with up to 20 NVMe drives supported

• 4 LFF Mid-tray bringing total LFF storage capacity to over 190 TB

• HPE Persistent memory at over 1TB scale

• Expanded GPU support to 3xDW or 5xSW cards

• Additional boot/drive/rear options: SATA M.2; dual uFF SSD (2x M.2 cartridges)

• Intel® Xeon® Processor Scalable Family from 4 - 28 Cores; 85 - 205W; 1.8 - 3.6 GHz

• HPE DDR4 SmartMemory up to 2666 MT/s

• Security features: iLO 5 (Security Root of Trust); Chassis Intrusion Detection; TPM 2.0; digitally signed FW

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 5

Platform Information

Form Factor

2U rack

Chassis Types

8 SFF with optional Universal Media Bay, and optional SFF or NVMe options

the SFF chassis and replaces

leveraged to support the 2 M.2 options on the primary riser.

System Fans

Standard – fan types included

NOTE: High performance fan kits are required for rear drives or NVMe configurations.

24 SFF bay with 6SFF rear drive bay options with 30 SFF drive bays total 8 LFF with Universal Media Bay 12 LFF plus optional 4 LFF mid-plane or 3LFF + 2 SFF drives rear with 19 LFF drive bays total

NOTE: The 3 LFF rear drives will consume space for the secondary riser. NOTE: The 12 LFF chassis also supports 2 SFF rear which allows for the second riser. NOTE: The 8 NVMe drive option (826689-B21) can only be leveraged in

Box 1, 2 or 3, however there is a maximum of 20 NVMe drives supported with Partial population of Box1. NOTE: The Premium cage (826690-B21, 6 SAS/SATA+2 NVMe) can only be leveraged in the SFF chassis and replaces Box 1, 2 or 3. NOTE: The Universal Media Bay (826708-B21) not available with the LFF chassis or the 24 SFF front end, and can only be populated in Box1. NOTE: The 8 SFF can be upgraded with a drive cage to 16 or 24 SFF. For optimal upgrade Box2 should be populated second, with Box 3 the last to be populated for a field upgrade to 24 SFF. For CTO builds requiring 24 SFF pluse use the 24 SFF chassis (868704-B21). Note a field upgrade to 24 SFF will require a High Performance fan kit (867810-B21). NOTE: The 8 LFF chassis cannot be upgraded to 12 LFF front in the field; however the 4-LFF Mid plane (826686-B21) is supported, but will also require a performance fan kit (867810-B21). NOTE: All models come with the S100i Smart Array Controller with embedded software RAIS support for 12 drives. The S100i uses 14 embedded SATA ports, but only 12 ports are accessible as 2 are

NOTE: 1P models typically ship with 4 standard fans. The second processor option kit contains 2 additional fans.

NOTE: The 12 LFF and 24 SFF chassis ship with 6 High performance fans as standard. NOTE: High performance fan kit is available to meet ambient temperature environments.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 6

Standard Features

Processors – Up to 2 of the following depending on model.

Memory

socket

Platinum Processors

Platinum 8180 Processor

2.5 GHz

38.50 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8176M Processor

2.1 GHz

38.50 MB

165W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Platinum 8176 Processor

2.1 GHz

38.50 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8170M Processor

2.1 GHz

35.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Platinum 8170 Processor

2.1 GHz

35.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8168 Processor

2.7 GHz

33.00 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8164 Processor

2.0 GHz

35.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8160M Processor

2.1 GHz

33.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Platinum 8160 Processor

2.1 GHz

33.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8158 Processor

3.0 GHz

24.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8156 Processor

3.6 GHz

16.50 MB

105W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Platinum 8153 Processor

2.0 GHz

22.00 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold Processors

Gold 6154 Processor

3.0 GHz

24.75 MB

200W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6152 Processor

2.1 GHz

30.25 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6150 Processor

2.7 GHz

24.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6148 Processor

2.4 GHz

27.50 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6142M Processor

2.6 GHz

22.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Gold 6140M Processor

2.3 GHz

24.75 MB

140W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Gold 6140 Processor

2.3 GHz

24.75 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6138 Processor

2.0 GHz

27.50 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6136 Processor

3.0 GHz

24.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6134M Processor

3.2 GHz

24.75 MB

130W

3 @ 10.4 GT/s

2666 MT/s

1.5 TB

Gold 6134 Processor

3.2 GHz

24.75 MB

130W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6132 Processor

2.6 GHz

19.25 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6130 Processor

2.1 GHz

22.00 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6128 Processor

3.4 GHz

19.25 MB

115W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 6126 Processor

2.6 GHz

19.25 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768 GB

Gold 5120 Processor

2.2 GHz

19.25 MB

105W

2 @ 10.4 GT/s

2400 MT/s

768 GB

Gold 5118 Processor

2.3 GHz

16.50 MB

105W

2 @ 10.4 GT/s

2400 MT/s

768 GB

Gold 5115 Processor

2.4 GHz

13.75 MB

85W

2 @ 10.4 GT/s

2400 MT/s

768 GB

Silver Processors

Silver 4116 Processor

2.1 GHz

16.50 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768 GB

NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.

Intel Xeon Models

CPU

Frequency

Cores L3 Cache Power UPI DDR4

per

Platinum 8180M Processor 2.5 GHz 28 38.50 MB 205W 3 @ 10.4 GT/s 2666 MT/s 1.5 TB

Gold 6142 Processor 2.6 GHz 16 22.00 MB 150W 3 @ 10.4 GT/s 2666 MT/s 768 GB

Gold 5122 Processor 3.6 GHz 4 16.50 MB 105W 2 @ 10.4 GT/s 2666 MT/s 768 GB

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 7

Silver 4112 Processor

2.6 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768 GB

Silver 4110 Processor

2.1 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768 GB

Silver 4108 Processor

1.8 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768 GB

Bronze Processors

Bronze 3106 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768 GB

Bronze 3104 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768 GB

NOTE: Platinum – 8100 Series –2 Socket supports 2UPI, supports 6-Channel DDR4 @ 2666 MT/s providing up to 768GB

768GB memory capacity. Intel AVX-512(1x 512-bit FMA), 48 lanes PCIe 3.0, standard RAS supported.

Chipset

Intel C621 Chipset

NOTE: For more information regarding Intel® chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

On System Management Chipset

HPE iLO 5 ASIC

NOTE: Read and learn more in the iLO QuickSpecs.

Memory

One of the following depending on model

Type:

HPE DDR4 SmartMemory, Registered (RDIMM), Load Reduced (LRDIMM)

DIMM Slots Available

12 DIMM slots per processor, 6 channels per processor, 2 DIMMs per channel

Maximum capacity (LRDIMM)

1.5 TB

24 x 64 GB LRDIMM @ 2600 MHz

Maximum capacity (RDIMM)

768 GB

24 x 32 GB RDIMM @ 2600 MHz

NOTE: The maximum memory by socket is limited by the processor selection. NOTE: Mixing of RDIMM and LRDIMM memory is not supported.

Memory Protection

http://www.hpe.com/docs/memory-ras-feature.

Expansion Slots

Slots #

Technology

Bus

Width

Connector

Width

Slot Form Factor

Notes

PCIe 3.0

X8 Full-height,

half-length slot

Proc 1

PCIe 3.0

X16

X16 Full-height,

Proc 1

Silver 4114 Processor 2.2 GHz 10 13.75 MB 85W 2 @ 9.6 GT/s 2400 MT/s 768 GB

memory capacity (1.5 TB on select processor skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology supported. Intel AVX-512 (2x 512-bit FMA), 48 lanes PCIe 3.0, advanced RAS. NOTE: Gold – 5100, 6100 Series - 2 Socket supports 2UPI, supports 6-Channel DDR4 @ 2400 MHz (SKU 5122=supports

2666) providing up to 768GB memory capacity (1.5 TB on select skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA) (SKU 5122 supports 2x 512 bit FMA), 48 lanes PCIe 3.0, advanced RAS supported. NOTE: Silver – 4100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, 6-Channel DDR4 @ 2400 MHz providing up to 768 GB memory capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA), 48 lanes

PCIe 3.0, standard RAS supported. NOTE: Bronze – 3100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, supports 6-Channel DDR4 @ 2133 MHz providing up to

For details on the HPE Server Memory Options RAS feature, visit:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 8

full-length slot

PCIe 3.0

X8 Full-height,

half-length slot

Proc 1

NOTE: Bus Width Indicates the number of physical electrical lanes running to the connector.

Slots #

Technology

Bus

Width

Connector

Width

Slot Form Factor

Notes

PCIe 3.0

X8 Full-height,

Proc 2

PCIe 3.0

X16

X16 Full-height,

full-length slot

Proc 2

P408

PCIe 3.0

X8 Full-height,

half-length slot

Proc 2

NOTE: Bus Width Indicates the number of physical electrical lanes running to the connector.

NOTE: Max 8-PCIe slots are available on the DL380-Gen10.

Storage Controllers

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.

One of the following depending on model

Software RAID

HPE Smart Array S100i SR Gen10 SW RAID

NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an additional

options on the primary riser.

Essential RAID Controller

HPE Smart Array E208i-a SR Gen10 Controller

HPE Smart Array E208i-p SR Gen10 Controller

HPE Smart Array E208e-p SR Gen10 Controller

Performance RAID

HPE Smart Array P408i-a SR Gen10 Controller

HPE Smart Array P408i-p SR Gen10 Controller

HPE Smart Array P408e-p SR Gen10 Controller

HPE Smart Array P816i-a SR Gen10 Controller

NOTE: Performance RAID Controllers require the HPE Smart Storage Battery (875241-B21) which is sold separately.

Internal Storage Devices

One of the following depending on model

Optical Drive

Ships standard in Performance Models

Optional: DVD-ROM, DVD-RW

Hard Drives

None ship standard

NOTE: This riser also supports dual m.2 cards.

half-length slot

NOTE: When populating the second optional riser slot, the second processor must be installed. NOTE: This only calls out the Standard Riser, and Secondary riser included in WW Predefined skus. Please see riser section

for full list of risers.

controller will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.

NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled. NOTE: The S100i uses 14 embedded SATA ports, but only 12 ports are accessible as 2 are leveraged to support the 2 M.2

Controller

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 9

Maximum Internal Storage

CAPACITY

CONFIGURATION

Hot Plug SFF SAS

72.0 TB

24+6 x 2.4 TB* (with optional rear SFF drive cage)

Hot Plug SFF SATA

52.0 TB

24+2 x 2 TB (with optional SFF drive cage)

Hot Plug LFF SAS

197.68 TB

12+4+3 x 10 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug LFF SATA

197.68 TB

12+4+3 x 10 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug SFF SAS SSD

115.2 TB

24+6 x 3.84 TB (with optional rear SFF drive cage)

Hot Plug LFF SATA SSD

44.16 TB

12+4+3 x 1.92 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug SFF NVMe PCIe SSD

40 TB NVMe

20 x2 TB NVMe

NOTE: 2.4 TB SFF SAS drives coming 2H 2017.

Power Supply

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% and 96% efficiency. NOTE:

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency.

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less

For information on power specifications and technical content visit HPE Server power supplies.

Interfaces

Serial

Optional, rear

Display Port

1 (SFF 1 front, optional via Universal Media Bay, 826708-B21), 8 LFF chassis standard

FlexibleLOM Network Ports

4 x 1 Gb ports shipping standard with optional FlexibleLOM or stand up card

HPE iLO Remote Management Network Port

1 Gb Dedicated Front iLO Service Port

1 standard (Not available on 12 LFF chassis or when SID is ordered)

Micro SD Slot

1 Micro SD

NOTE: The Micro SD slot is not a hot-pluggable device. Customers should not attempt to plug an SD card into the SD slot

while the server is powered.

USB 3.0

Up to 5 total: 1 front, 2 rear, 2 internal (secure), 2 optional USB 2.0 front via Universal Media Bay, or standard on 8LFF chassis

SID (Systems Insight Display)

Optional

Also available in -48VDC and 227VAC/380VDC power inputs.

installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.

All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.

To review the power requirements for your selected system, please use the HPE Power Advisor Tool.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 10

NOTE: Not shipping as standard. Available as a CTO option or as a field upgrade (826703-B21).

Operating Systems and Virtualization Software Support for ProLiant Servers

Windows Server 2012 R2 (Most Recent Version)

Windows Server 2016 (Most Recent Version)

VMware ESXi 6.0 U3

VMware ESXi 6.5 and U1 upon release

Red Hat Enterprise Linux (RHEL) 6.9 and 7.3

SUSE Linux Enterprise Server (SLES) 11 SP4 and 12 SP2

ClearOS

HPE and ClearCenter will help you lower the cost of building on-premise solutions without sacrificing security and ease of use.

and growing. Whether you’re starting out or scaling, you decide what applications you need and pay as you grow.

NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost.

http://www.hpe.com/servers/clearos

CentOS

NOTE: CentOS not directly supported / Community Supported (Based on RHEL so RHEL testing and enablement applicable

http://h20566.www2.hpe.com/portal/site/hpsc/public/psi/home?sp4ts.oid=1010026818

Industry Standard Compliance

ACPI 6.1 Compliant

PCIe 3.0 Compliant

WOL Support

Microsoft® Logo certifications

PXE Support

VGA Display Port

NOTE: This support is on the optional Universal Media Bay.

USB 3.0 Compliant (internal)

USB 2.0 Compliant (external ports via SUV)

NOTE: This support is on the optional Universal Media Bay.

Energy Star

SMBIOS 3.1

UEFI 2.6

Redfish API

IPMI 2.0

Secure Digital 2.0

Advanced Encryption Standard (AES)

Triple Data Encrytion Standard (3DES)

SNMP v3

TLS 1.2

DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP)

Active Directory v1.0

ASHRAE A3/A4

HPE ProLiant servers with ClearOS give you a simple, secure, and affordable operating system with an intuitive web based graphical user interface that provides a cloud-like experience on- premise, and an Application Marketplace with over 100 apps

For more information on ClearOS, please visit

to CentOS) CentOS 6.9 / CentOS 7.3. NOTE: For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your server.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 11

NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please visit:

http://www.hpe.com/servers/ashrae.

UEFI (Unified Extensible Firmware Interface Forum)

NOTE: UEFI is the default for the DL380 Gen10. Legacy mode can be selected in the field or as a CTO option

(758959-B22).

Graphics

Integrated Video Standard

• Video modes up to 1920 x 1200@60Hz (32 bpp)

• 16MB Video Memory

HPE iLO 5 on system management memory

• 32 MB Flash

• 4 Gbit DDR 3 with ECC protection

HPE Server UEFI/Legacy ROM

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured

ProLiant Gen10 Server.

Embedded Management

HPE Integrated Lights-Out (HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and remote

UEFI

Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI). Learn more at http://www.hpe.com/servers/uefi.

Intelligent Provisioning

Hassle free server and OS provisioning for 1 or more servers with Intelligent Provisioning.

configuration than the legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI Class 2 implementation and support both UEFI Mode (default) and Legacy BIOS Mode.

NOTE: The UEFI System Utilities tool is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more information, please visit http://www.hpe.com/servers/uefi.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot and Secure Start enable for enhanced security

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

• Embedded UEFI Shell

• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant

• PXE boot support for IPv6 networks

• Workload Profiles for simple performance optimization

UEFI Boot Mode only:

• TPM 2.0 Support

• NVMe Boot Support

• Platform Trust Technology (PTT) can be enabled.

• iSCSI Software Initiator Support.

• HTTP/HTTPs Boot support as a PXE alternative.

• Boot support for option cards that only support a UEFI option ROM

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI. NOTE: UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the factory for your HPE

management with HPE iLO. Learn more at http://www.hpe.com/info/ilo.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 12

Learn more at http://www.hpe.com/servers/intelligentprovisioning.

iLO RESTful API

iLO RESTful API is Redfish API conformance and offers simplified server management

Server Utilities

Active Health System

The HPE Active Health System (AHS) is an essential component of the iLO management

Active Health System

Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed

http://www.hpe.com/servers/ahsv.

Smart Update

Keep your servers up to date with the HPE Smart Update solution by using Smart Update

(SPP). Learn more at http://www.hpe.com/info/smartupdate.

iLO Amplifier Pack

Designed for large enterprise and service provider environments with hundreds of HPE

Learn more at http://www.hpe.com/servers/iLOamplifierpack.

HPE iLO Mobile

Enables the ability to access, deploy, and manage your server anytime from anywhere from

http://www.hpe.com/info/ilo/mobileapp.

RESTful Interface Tool

RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers at scale. Learn more at http://www.hpe.com/info/resttool.

Scripting Tools

Provision one to many servers using your own scripts to discover and deploy with Scripting

http://www.hpe.com/servers/stk or http://www.hpe.com/servers/powershell.

HPE OneView Standard

HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting

http://www.hpe.com/info/oneview

HPE Systems Insight

Ideal for environments already using HPE SIM, it allows you to monitor the health of your HPE

http://www.hpe.com/info/hpesim

Security

UEFI Secure Boot and Secure Start support

Immutable Silicon Root of Trust

FIPS 140-2 validation (iLO 5 certification in progress)

automation such as configuration and maintenance tasks based on modern industry standards. Learn more at http://www.hpe.com/info/restfulapi.

portfolio that provides continuous, proactive health monitoring of HPE servers. Learn more at

http://www.hpe.com/servers/ahs.

Viewer

Application

problem resolution with HPE self-repair recommendations, to learn more visit:

Manager (SUM) to optimize the firmware and driver updates of the Service Pack for ProLiant

servers, the iLO Amplifier Pack is a free, downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HPE servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities.

select smartphones and mobile devices. For additional information please visit:

Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at

without additional fees. It can monitor multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-defined functionality is not available. Learn more at

Manager (HPE SIM)

ProLiant Servers and HPE Integrity Servers. Also provides you with basic support for non-HPE servers. HPE SIM also integrates with Smart Update Manager to provide quick and seamless firmware updates. Learn more at

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 13

Common Criteria certification (iLO 5 certification in progress)

Configurable for PCI DSS compliance

Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser

Support for Commercial National Security Algorithms (CNSA)

Tamper-free updates – components digitally signed and verified

Secure Recovery – recover critical firmware to known good state on detection of compromised firmware

Ability to rollback firmware

Secure erase of NAND/User data

TPM (Trusted Platform Module) 1.2 option

TPM (Trusted Platform Module) 2.0 option

Bezel Locking Kit option

Chassis Intrusion detection option

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of HPE

http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/

Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Care Pack services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response.

Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Optional Features

Page 14

Server Management

HPE iLO Advanced

HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE

and virtual folders. You can also activate the enhanced security and

http://www.hpe.com/servers/iloadvanced.

HPE iLO Advanced

HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus

http://www.hpe.com/servers/ilopremium

HPE OneView Advanced

HPE OneView brings a new level of automation to infrastructure management by taking a

http://www.hpe.com/info/oneview.

HPE Insight Cluster

HPE Insight Cluster Management Utility is a HyperScale management framework that

infrastructure. Learn more at http://www.hpe.com/info/cmu.

HPE Insight Control

HPE Insight Control is recommended for current implementation on HPE Servers to deploy,

management console. For more information, see http://www.hpe.com/info/insightcontrol.

Accelerator and GPGPU Information

Hewlett Packard Enterprise supports various accelerators on select HPE Proliant servers to support different workloads. The

as HPE Insight Cluster Management Utility.

Rack and Power Infrastructure

The story may end with servers, but it starts with the foundation that makes compute go – and business grow. We’ve reinvented

HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a

ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and replay, and GUI-based and scripted virtual media power management functionality. Learn more about HPE iLO Advanced at

Premium Security Edition

high-end security modes, unique security capabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanced Premium Security Edition at:

template driven approach to provisioning, updating, and integrating compute, storage, and networking infrastructure. It provides full-featured licenses which can be purchased for managing Gen8, Gen9 and Gen10 servers. To learn more visit

Management Utility (CMU)

includes software for the centralized provisioning, management and monitoring of nodes and

migrate, monitor, remote control, and optimize your IT infrastructure through a single, simple

accelerators enable seamless integration of GPU computing with HPE ProLiant servers for high-performance computing, large data center graphics, deep learning and virtual desktop deployments. These accelerators deliver all of the standard benefits of GPU computing while enabling maximum reliability and tight integration with system monitoring and management tools such

our entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In other words, we’ve created a stronger, smarter, and simpler infrastructure to help you get the most out of your IT equipment. As an industry leader, Hewlett Packard Enterprise is uniquely positioned to address the key concerns of power, cooling, cable management and system access.

HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and thermal management, flexible cable management, and a 10 year Warranty to support higher density computing.

HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°, include color-coded outlets and load segments and a low-profile design for optimal access to the rack and support for dense rack environments.

HPE Uninterruptible Power Systems are cost-effective power protection for any type workload. Some UPSs include options for remote management and extended runtime modules so you’re critical dense data center is covered in power outages.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Optional Features

Page 15

cost-effective KVM switch for your first rack and multiple connection IP switches with remote management and security

HPE Rack and Power Infrastructure.

One Config Simple (SCE)

SCE is a guided self-service tool to help sales and non-technical people provide customers with initial configurations in 3 to 5

https://h22174.www2.hpe.com/SimplifiedConfig/Welcome#

capabilities to keep your data center rack up and running.

Learn more about HPE Racks, KVM, PDUs and UPSs at

minutes. You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business Center or an Authorized Partner for assistance.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Service and Support

Page 16

HPE Pointnext - Service and Support

Protect your business beyond warranty with HPE Support Services

complex simple.

Connect your devices:

n. All

http://www.hpe.com/services/getconnected

Other related Services

https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf

HPE Education Services

and learn how to get the most from your technology investment. http://www.hpe.com/ww/learn

HPE Support Center

For more information: http://www.hpe.com/services

HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational Services to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational Services focus on designing the transformation and creating a solution roadmap. Professional Services specializes in creative configurations with flawless and on-time implementation, and on-budget execution. Finally, operational services provides innovative new approaches like Flexible Capacity and Datacenter Care, to keep your business at peak performance. HPE is ready to bring together all the pieces of the puzzle for you, with an eye on the future, and make the

Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard Enterprise. Reduce down time and improve diagnostic accuracy with a single consolidated view of your environment. By connecting, you will receiv 24x7monitoring, pre-failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimizatio of these benefits are already available to you with your server storage and networking products, securely connected to HPE support.

Learn more about getting connected at

HPE Server Hardware Installation

Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.

Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. Book on a class today

The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE business products. Submit support cases online, chat with HPE experts, access support resources or collaborate with peers. Learn more http://www.hpe.com/support/hpesc

HPE's Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you can get access to personalized IT support anywhere, anytime. HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE warranty, HPE Support Service or HPE contractual support agreement.

*HPE Support Center Mobile App is subject to local availability.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 17

Entry Models

[SKU Number]

868709-xx1

826564-xx1

Model Name

Entry LFF

Entry SFF

Processor

3106 (8-Core, 1.7 GHz, 85W)

Number of Processors

One processor

Memory

16 GB RDIMM DR 2600 MT/s (1x 16 GB)

limitation.

16 GB RDIMM DR 2600 MT/s (1x 16 GB)

limitation.

Network Controller

Embedded 4-Port 1GbE

Storage Controller

Embedded 14-Port S100i

NOTE:

Embedded 14-Port S100i

NOTE:

Hard Drive

None ship as standard

Internal Storage

8 LFF chassis, with 2 SFF bays optional

8 SFF Chassis (upgradeable to 24 SFF front)

Optical Drive Bay

Optional via Universal Media Bay (included)

Optional Universal Media Bay (826708-B21)

Optical Drive

None ship as standard

PCI-Express

3-slots (x8, x16, x8) as standard

Power Supply

1x 500W HPE FlexSlot Power Supply

Fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE iLO

(require licenses)

Energy Star

2.1 certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Slots

NOTE: running at 2133 MT/s due to Processor

SATA only.

NOTE: running at 2133 MT/s due to Processor

SATA only.

Advanced, HPE iLO Advanced Premium Security Edition, Insight Control and HPE OneView Advanced

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 18

Base Models

[SKU Number]

868710-xx1

826565-xx1

Model Name

Base LFF

Base SFF

Processor

4110 (8-Core, 2.1 GHz, 85W)

4114 (10-Core, 2.2 GHz, 85W)

Number of Processors

One processor

Memory

32 GB RDIMM DR 2600 MT/s (2x 16 GB)

limitation.

32 GB RDIMM DR 2600 MT/s (2x 16 GB)

limitation.

Network Controller

Embedded 4-Port 1GbE

Storage

P816i-a

NOTE: Smart Storage battery included.

P408i-a

NOTE: Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 LFF chassis, with 2 SFF bays optional

8 SFF Chassis (upgradeable to 24 SFF front)

Optical Drive Bay

Optional via Universal Media Bay (included)

Optional Universal Media Bay (826708-B21)

Optical Drive

None ship as standard

PCI-Express Slots

3-slots (x8, x16, x8) as standard

Power Supply

2x 800W HPE FlexSlot power supply

1x 500W HPE FlexSlot power supply

Fans

6-High Performance fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE

(require licenses)

Energy Star

2.1 certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response

Controller

NOTE: running at 2400 MT/s due to Processor

NOTE: 16-Port modular Smart Array.

NOTE: running at 2400 MT/s due to Processor

NOTE: 8-Port modular Smart Array.

iLO Advanced, HPE iLO Advanced Premium Security Edition, Insight Control and HPE OneView Advanced

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 19

Performance Models

High Performance Models

[SKU Number]

826566-xx1

826567-xx1

879938-xx1

Model Name

Performance

High-Perferformance

Processor

5118 (12-Core, 2.3 GHz, 105W)

6130 (16-Core, 2.1 GHz, 120W)

Number of Processors

Two processors

Memory

64 GB RDIMM DR 2666 MT/s (2x

due

to processor limitation.

64 GB RDIMM DR 2666 MT/s (2x

Network

Embedded 4-Port 1GbE, plus HPE

B21)

Embedded 4-Port 1GbE, plus HPE

Storage

P408i-a

included.

P408i-a

included.

P408i-a

included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24

Optical Drive Bay

Universal Media Bay (826708-

Universal Media Bay (826708-B21)

Optical Drive

DVD-RW

PCI-Express

6 total: 3-slots (x8, x16, x8 with

x16, x8)

6 total: 3-slots (x8, x16, x8 with

x16, x8)

6 total: 3-slots (x8, x16, x8 with

x16, x8)

Power Supply

2x 800W HPE FlexSlot power

supply

2x 800W HPE FlexSlot power

supply

2x 800W HPE FlexSlot power

supply

Fans

6-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download); HPE

Energy Star

2.1 certified

Form Factor

2U Rack

Warranty

3-3-3

Country Code Key

xx1 = B21

Worldwide

NOTE: The -B21 WW SKU is to be ordered in all countries other than Japan.

xx1 = 291

Japan

Controller

Slots

32 GB)

NOTE: running at 2400 MT/s

Ethernet 10/25 Gb 2-port

640FLR-SFP28 Adapter (817749-

NOTE: 8-Port modular Smart

Array.

NOTE: Smart Storage battery

SFF front)

B21)

m.2) as standard, plus 3 PCIe (x8,

32 GB)

Ethernet 10/25 Gb 2-port 640FLR-

SFP28 Adapter (817749-B21)

NOTE: 8-Port modular Smart

Array.

NOTE: Smart Storage battery

SFF front)

m.2) as standard, plus 3 PCIe (x8,

32 GB)

Ethernet 25 Gb 2-port 631FLR

Adapter (817709-B21)

NOTE: 8-Port modular Smart

Array.

NOTE: Smart Storage battery

SFF front)

m.2) as standard, plus 3 PCIe (x8,

iLO Advanced, HPE iLO Advanced Premium Security Edition, Insight Control and HPE OneView Advanced

(require licenses)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

- Factory Integrated Models

Page 20

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are

Step 1: Base Configuration (choose one of the following configurable models)

CTO Server

HPE ProLiant DL380

Server

HPE ProLiant DL380

Server

SKU Number

868706-B21

868705-B21

868703-B21

868704-B21

TAA SKU

875784-B21

875785-B21

875782-B21

875783-B21

Processor

Not included as standard

DIMM Slots

24-DIMM slots

Storage Controller

PCIe

Three standard in primary riser (with dual M.2 support)

Drive Cage included

Network Controller

Embedded 4x1GbE with optional HPe FlexLOM and optional Standup card

Fans

4-Standard

6-High Performance

4-Standard

6-Performance

Management

HPE iLO with Intelligent Provisioning (standard), iLO Advances and OneView (optional)

1x 3.0 standard plus iLo

front service port

None as standard

1x 3.0 standard plus iLo

front service port

1x 3.0 standard plus iLo

front service port

NOTE: HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government

CTO Server

8 SFF CTO Chassis

24 SFF CTO Chassis

8 LFF CTO Chassis

12 LFF CTO Chassis

Included Drive Cage

8 SFF SAS/SATA

3x 8 SFF SAS/SATA

8 LFF + UMB

12 LFF Chassis

Additional drive cages

Universal Media Bay

1 Optional

Not available

1 Included

Not available

ODD

1 Optional with UMB

Not available

1 Optional

Not available

8 SFF Drive Cage

Up to 2 Optional

Not available

8 NVME/SAS Bay

Up to 3 Optional

Not available

8 NVME Cage

Up to 3 Optional

Not available

2 SFF SAS/SATA (Front)

1 Optional with UMB

Not available

1 Optional

Not available

2 SFF SAS/SATA (Rear)

Not available

Up to 3 Optional

Not available

Up to 3 Optional

2 NVMe (Front)

1 Optional with UMB

Not available

1 Optional

Not available

4 LFF Mid-plane

Not available

1 Optional

3 LFF Rear

Not available

1 Optional

ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.

1. Factory Integrated Models must start with a CTO Server.

2. FIO indicates that this option is only available as a factory installable option.

3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered with the server.

4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.

Gen10 8 LFF CTO Server

Embedded SW RAID with 14 SATA ports, choice of HPE modular Smart Array and PCIe plug-in controller

Gen10 12 LFF CTO

Gen10 8 SFF CTO Server

Gen10 24 SFF CTO

8 LFF 12 LFF 8 SFF 24 SFF

USB

customers. These products are either manufactured or substantially transformed in a designated country. TAA compliance is only provided when HPE options are included as part of factory integrated orders (CTO).

NOTE: The HPE ProLiant DL380 Gen10 12 LFF CTO Server ships with the cable required for the P816i-a installation.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

- Factory Integrated Models

Page 21

NOTE: This aplies to CTO configurations, field upgrades may differ depending field configuration. NOTE:

Step 2a: Choose Required Options - Processors (only one of the following unless otherwise noted)

Please select one –L21 processor required below.

1P models typically ship with 4 standard fans. The second processor option kit contains 2 additional fans. 12 LFF and

memory speed may depend on the quantity and

below. All other will processors will ship with the Standard heat sink.

Processor Option Kits

Required Processor

HPE DL380 Gen10 Intel® Xeon-Platinum 8180M (2.5GHz/28-core/205W) FIO Processor Kit

874752-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8180 (2.5GHz/28-core/205W) FIO Processor Kit

871619-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8176M (2.1GHz/28-core/165W) FIO Processor Kit

874754-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8176 (2.1GHz/28-core/165W) FIO Processor Kit

871618-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8170M (2.1GHz/26-core/165W) FIO Processor Kit

874756-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8170 (2.1GHz/26-core/165W) FIO Processor Kit

871617-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8168 (2.7GHz/24-core/205W) FIO Processor Kit

869089-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinumn 8164 (2.0GHz/26-core/145W) FIO Processor Kit

869088-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8160M (2.1GHz/24-core/145W) FIO Processor Kit

874758-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8160 (2.1GHz/24-core/150W) FIO Processor Kit

869086-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8158 (3.0GHz/12-core/150W) FIO Processor Kit

869090-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8156 (3.6GHz/4-core/105W) FIO Processor Kit

871616-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8153 (2.0GHz/16-core/125W) FIO Processor Kit

826890-L21

HPE DL380 Gen10 Intel® Xeon-Gold 6154 (3.0GHz/18-core/200W) FIO Processor Kit

826888-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6152 (2.1GHz/22-core/140W) FIO Processor Kit

826886-L21

3x 8 NVMe option on SFF will only allow for partial population of Box1 to max 20 NVMe.

For second processor, please select the same processor model with –B21 from Core Options – HPE Processors section. For example: first processor, select 874752-L21 then for second processor, select 874752-B21.

NOTE:

24 SFF CTO Servers ship with 6 High performance fans as standard. High performance fan kit is available to meet ambient temperature environments are are required for rear drives or NVMe configurations. NOTE: Maximum memory capacity per processor is dependent on processor models. All processors support up to 768 GB max memory per processor except “M” model processors will support up to 1.5 TB max memory per processor.

NOTE: Mixing of 2 different processor models are NOT allowed. NOTE: DDR4 speed is the maximum memory speed of the processor. Actual

type of DIMMs installed.

NOTE: Processors with 130W or higher will ship with the High Performance heat sink plus SKUs 8156, 6128, 5122 as noted

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

- Factory Integrated Models

Page 22

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6150 (2.7GHz/18-core/165W) FIO Processor Kit

826884-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6148 (2.4GHz/20-core/150W) FIO Processor Kit

826882-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6142M (2.6GHz/16-core/150W) FIO Processor Kit

874760-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6142 (2.6GHz/16-core/150W) FIO Processor Kit

826880-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6140M (2.3GHz/18-core/135W) FIO Processor Kit

874762-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6140 (2.3GHz/18-core/150W) FIO Processor Kit

826878-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6138 (3.2GHz/20-core/125W) FIO Processor Kit

826876-L21

HPE DL380 Gen10 Intel® Xeon-Gold 6136 (3.0GHz/12-core/150W) FIO Processor Kit

826874-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6134M (3.2GHz/8-core/130W) FIO Processor Kit

873645-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6134 (3.2GHz/8-core/130W) FIO Processor Kit

826872-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6132 (2.6GHz/14-core/140W) FIO Processor Kit

826870-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6130 (2.1GHz/16-core/120W) FIO Processor Kit

826866-L21

HPE DL380 Gen10 Intel® Xeon-Gold 6128 (3.4GHz/6-core/115W) FIO Processor Kit

826864-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6126 (2.6GHz/12-core/120W) FIO Processor Kit

826862-L21

HPE DL380 Gen10 Intel® Xeon-Gold 5122 (3.6GHz/4-core/105W) FIO Processor Kit

826858-L21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 5120 (2.2GHz/14-core/105W) FIO Processor Kit

826856-L21

HPE DL380 Gen10 Intel® Xeon-Gold 5118 (2.3GHz/12-core/105W) FIO Processor Kit

826854-L21

HPE DL380 Gen10 Intel® Xeon-Gold 5115 (2.4GHz/10-core/85W) FIO Processor Kit

876562-L21

HPE DL380 Gen10 Intel® Xeon-Silver 4116 (2.1GHz/12-core/85W) FIO Processor Kit

826852-L21

HPE DL380 Gen10 Intel® Xeon-Silver 4114 (2.2GHz/10-core/85W) FIO Processor Kit

826850-L21

HPE DL380 Gen10 Intel® Xeon-Silver 4112 (2.6GHz/4-core/85W) FIO Processor Kit

873647-L21

HPE DL380 Gen10 Intel® Xeon-Silver 4110 (2.1GHz/8-core/85W) FIO Processor Kit

826846-L21

HPE DL380 Gen10 Intel® Xeon-Silver 4108 (1.8GHz/8-core/85W) FIO Processor Kit

826848-L21

HPE DL380 Gen10 Intel® Xeon-Bronze 3106 (1.7GHz/8-core/85W) FIO Processor Kit

873643-L21

HPE DL380 Gen10 Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W) FIO Processor Kit

873641-L21

NOTE: Processors above 130W use a High Performance Heatsink, along with the 8156, 6128 and 5122.

Step 2b: Choose Memory Options

Please select one or more memory from below.

http://www.hpe.com/docs/memory-ras-feature

For new Gen10 memory population rule whitepaper and optimal memory performance guidelines, please go to:

https://www.hpe.com/docs/memory-population-rules

For Gen10 memory speed table, please go to: https://www.hpe.com/docs/memory-speed-table For memory Reliability, Accessibility, Serviceability (RAS) features whitepaper like Gen10 Fast Fault Tolerance and legacy mirrored memory feature etc. please go to:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

- Factory Integrated Models

Page 23

NOTE: Memory DIMM availability with a server platform is dependent upon completion of certification testing. NOTE:

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815097-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815098-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Memory Kit

835955-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815100-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Memory Kit

815101-B21

Step 2c: Choose Power Supplies

Select one or two power supplies from below.

NOTE:

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

Step 3: Choose Additional Factory Integratable Options

One of the following from each list may be selected if desired at time of factory integration

HPE Unique Options

HPE DL38X Gen10 Slot 1/2 x16/x16 FIO Riser Kit

871674-B21

NOTE: Slot 1 or 2 in Primary location.

NOTE: Bus width x16, x16, Connector Width x16, x16.

HPE DL38X Gen10 x16/x16 GPU Slot2/3 FIO Riser Kit

871676-B21

NOTE: Primary Riser, Connector in slot 2 & 3 for GPU support.

NOTE:

HPE 4 NVMe Box 1 Instr Spec FIO

878186-B21

HPE DL38X Gen10 x8/x8/x8 1-port 2 NVMe Slim SAS FIO Riser Kit

871673-B21

NOTE: Supports 3x 8 and 1-port for NVMe.

NOTE: Bus width x8, x8, x8 Connector Width x8, x8, x8.

HPE DL38X Gen10 4-port 8 NVMe Slim SAS FIO Riser

867807-B21

NOTE: Riser supporting up to 8 NVMe drives in Primary location. NOTE: Bus width x8, x8, x8 Connector Width x8, x8, x8.

NOTE: This is a factory integrated only option.

for max 20 NVMe support.

HPE 2 NVMe Instr Spec FIO

878189-B21

NOTE: This is a factory integrated only option. NOTE: This will connect 2 SFF cage installed in the front of the chassis to NVMe.

HPE 6+2 NVMe Instr Spec FIO

878192-B21

NOTE: This is a factory integrated only option. NOTE:

HPE 8SFF Front Remove SPEC Perf FIO

873763-B21

NOTE: This is a factory integrated only option. NOTE: Will remove the Primary 8SFF cage in Box 3 of the 8SFF and replace with a Box blank.

The maximum memory speed is a function of the memory type, memory configuration, and processor model.

Mixing of 2 different power supplies is NOT allowed.

NOTE: Supports Full Height and Full length cards.

Bus width x16, x16, Connector Width x16, x16.

NOTE: Supports Full Height and half-length cards.

NOTE: This will connect a 8SFF NVMe cage to only be connected to 4 drives of the tertiary riser

Indicates the cage will also have an NVMe connection.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

- Factory Integrated Models

Page 24

HPE Riser Remove SPEC FIO

873766-B21

NOTE: This is a factory integrated only option.

HP Legacy FIO Mode Setting

758959-B22

NOTE: UEFI is the default, this FIO part can be used for CTO to enable Legacy mode.

HPE Insight Software

HPE Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Single Server FIO LTU

C6N36A

HPE Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle FIO E-LTU

C6N36ABE

HPE Converged Infrastructure Management Software

HPE OneView for ProLiant DL Server including 3yr 24x7 Support FIO Bundle Physical 1-server LTU

E5Y43A

HPE OneView w/o iLO including 3yr 24x7 Support 1-server FIO LTU

P8B31A

Step 4: Choose additional options for Factory Integration from Core and Additional Options sections below

NOTE: Will remove the Primary shipping PCIe riser.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 25

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional information. Note the Cabling Matrix can help to explain the cable routing for each option:

HPE Unique Options

HPE DL38X NVMe 8 Solid State Drive Express Bay Enablement Kit

826689-B21

NOTE: This option provides support for up to 8 NVMe drives, and can only be populated in Box 1, Box 2

HPE DL38X Gen10 Universal Media Bay Kit

826708-B21

NOTE: The HPE DL380 Gen10 Universal Media bay provides front Display Port and 2xUSB 2.0; plus

NOTE: This is a SFF model option only.

HPE DL38X Gen10 Premium 6 SFF SAS/SATA + 2 NVMe or 8 SFF SAS/SATA Bay Kit

826690-B21

NOTE: This kit can be supported in Box 1, 2 or 3 and provides support for up to 8 SFF SAS/SATA or 6

NOTE:

HPE DL38X Gen10 High Performance Temperature Fan Kit

867810-B21

NOTE: This kit is required for specific Ambient temperature environments, coming in 2H2017.

NOTE:

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

NOTE: 2 SFF in the rear is only supported with a 24 SFF model or 12 LFF model.

NOTE: If supporting NVMe drives the addition of the High Performance Fan kit (867810-B21) is required.

HPE DL38X Gen10 2SFF Premium HDD Front NVMe/SAS/SATA Kit

826687-B21

NOTE: For 2 SFF front in the Universal Media Bay (826708-B21).

NOTE: Required an additional riser to support for NVMe drives.

HPE DL38X Gen10 8LFF Front 2SFF SAS/SATA HDD Kit

867805-B21

NOTE: Adds support for 2 SFF in front of 8 LFF chassis (868706-B21).

HPE DL38X Gen10 8LFF Front 2NVMe HDD Bay Kit

873781-B21

NOTE: Adds support for 2 NVMe in front of 8 LFF chassis (868706-B21), required additional riser.

HPE DL38X Gen10 12Gb SAS Expander Card Kit with Cables

870549-B21

NOTE: SAS expander to enable 24 SFF field upgrade. NOTE:

HPE DL380 Gen10 SFF Systems Insight Display Kit

826703-B21

NOTE: Systems Insight Display no longer ships as standard but is available as a Factory Integrated or field upgrade option.

HPE DL38X Gen10 Rear Serial Cable Kit

873770-B21

HPE Processors

and Box 3 of the SFF chassis only, note Box 1 can only be partially populated with four drives.

NOTE: The HPE DL380 Gen10 High Performance fan kit is required for NVMe support (867810-B21). NOTE: The HPE DL38X Gen10 4-port 8 NVMe Slimline Riser (867807-B21) is requited to support this,

with the exception of in Box 1 when the HPE DL38X Gen10 x8/x8/x8 1-port two NVMe Slimline Riser Kit (871673-B21) is required. NOTE: There are limitations on GPU support with the NVMe bay installed.

support for 2x SFF front drives (826688-B21) or 2 NVME front drives (826687-B21, riser required) and ODD support (Not included); and can only be located in Box1 in either an 8 SFF or 8+8 SFF model.

SAS/SATA + 2 NVMe drives per Box. NOTE: With NVMe drives a specific riser is required.

When adding to Box 1 the addition of the High Performance Fan kit (867810-B21) is required.

NOTE: This kit is also required to support Passive GPUs. NOTE: This is required for NVMe configurations. NOTE: This kit provides maximum cooling for your Server.

This kit is required when Box 1, 2 and 3 are populated.

NOTE: In the rear this leaves 1x8 slot accessible. NOTE: With NVMe drives a specific riser is required.

NOTE: Can be leveraged for rear 2 SFF drive support.

Primary population in slot 2 or 3 of the primary riser.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 26

Processor Option Kits

HPE DL380 Gen10 Intel® Xeon-Platinum 8180M (2.5GHz/28-core/205W) Processor Kit

874752-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8180 (2.5GHz/28-core/205W) Processor Kit

871619-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8180 (2.5GHz/28-core/205W) Processor Kit

871619-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8176M (2.1GHz/28-core/165W) Processor Kit

874754-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8176 (2.1GHz/28-core/165W) Processor Kit

871618-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8170M (2.1GHz/26-core/165W) Processor Kit

874756-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8170 (2.1GHz/26-core/165W) Processor Kit

871617-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8168 (2.7GHz/24-core/205W) Processor Kit

869089-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8164 (2.0GHz/26-core/145W) Processor Kit

869088-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8160M (2.1GHz/24-core/145W) Processor Kit

874758-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8160 (2.1GHz/24-core/150W) Processor Kit

869086-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8158 (3.0GHz/12-core/150W) Processor Kit

869090-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Platinum 8156 (3.6GHz/4-core/105W) Processor Kit

871616-B21

HPE DL380 Gen10 Intel® Xeon-Platinum 8153 (2.0GHz/16-core/125W) Processor Kit

826890-B21

HPE DL380 Gen10 Intel® Xeon-Gold 6154 (3.0GHz/18-core/200W) Processor Kit

826888-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6152 (2.1GHz/22-core/140W) Processor Kit

826886-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6150 (2.7GHz/18-core/165W) Processor Kit

826884-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6148 (2.4GHz/20-core/150W) Processor Kit

826882-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6142M (2.6GHz/16-core/150W) Processor Kit

874760-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6142 (2.6GHz/16-core/150W) Processor Kit

826880-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6140M (2.3GHz/18-core/135W) Processor Kit

874762-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6140 (2.3GHz/18-core/150W) Processor Kit

826878-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6138 (3.2GHz/20-core/125W) Processor Kit

826876-B21

HPE DL380 Gen10 Intel® Xeon-Gold 6136 (3.0GHz/12-core/150W) Processor Kit

826874-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6134M (3.2GHz/8-core/130W) Processor Kit

873645-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6134 (3.2GHz/8-core/130W) Processor Kit

826872-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 27

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6132 (2.6GHz/14-core/140W) Processor Kit

826870-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6130 (2.1GHz/16-core/120W) Processor Kit

826866-B21

HPE DL380 Gen10 Intel® Xeon-Gold 6128 (3.4GHz/6-core/115W) Processor Kit

826864-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 6126 (2.6GHz/12-core/120W) Processor Kit

826862-B21

HPE DL380 Gen10 Intel® Xeon-Gold 5122 (3.6GHz/4-core/105W) Processor Kit

826858-B21

NOTE: Ships with Performance Heatsink.

HPE DL380 Gen10 Intel® Xeon-Gold 5120 (2.2GHz/14-core/105W) Processor Kit

826856-B21

HPE DL380 Gen10 Intel® Xeon-Gold 5118 (2.3GHz/12-core/105W) Processor Kit

826854-B21

HPE DL380 Gen10 Intel® Xeon-Gold 5115 (2.4GHz/10-core/85W) Processor Kit

876562-B21

HPE DL380 Gen10 Intel® Xeon-Silver 4116 (2.1GHz/12-core/85W) Processor Kit

826852-B21

HPE DL380 Gen10 Intel® Xeon-Silver 4114 (2.2GHz/10-core/85W) Processor Kit

826850-B21

HPE DL380 Gen10 Intel® Xeon-Silver 4112 (2.6GHz/4-core/85W) Processor Kit

873647-B21

HPE DL380 Gen10 Intel® Xeon-Silver 4110 (2.1GHz/8-core/85W) Processor Kit

826846-B21

HPE DL380 Gen10 Intel® Xeon-Silver 4108 (1.8GHz/8-core/85W) Processor Kit

826848-B21

HPE DL380 Gen10 Intel® Xeon-Bronze 3106 (1.7GHz/8-core/85W) Processor Kit

873643-B21

HPE DL380 Gen10 Intel® Xeon-Bronze 3104 (1.7GHz/6-core/85W) Processor Kit

873641-B21

NOTE: Up to two processors supported. Performance Models include two processors.

bo2: Intel® Turbo Boost Technology 2.0 provides more computing power when you need it with performance that

um memory speed of the processor. Actual memory speed may depend on the quantity and

NOTE: Processors above 130W use a High Performance Heatsink, along with the 8156, 6128 and 5122.

Memory Selection

Best product availability is limited to US, Canada, and Latin America at this time.

HPE Memory

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815097-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815098-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Memory Kit

815100-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Memory Kit

815101-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Memory Kit

835955-B21

NOTE: Memory DIMM availability with a server platform is dependent upon completion of certification

processor model.

HPE Optical Drives

HP 9.5mm SATA DVD-ROM JackBlack Gen9 Optical Drive

726536-B21

NOTE: The Universal Media Bay (826708-B21) is required for this option on a SFF model. No support in 12 LFF or 24 SFF models.

HP 9.5mm SATA DVD-RW JackBlack G9 Optical Drive

726537-B21

NOTE: The Universal Media Bay (826708-B21) is required for this option on a SFF model. No support in 12 LFF or 24 SFF models.

NOTE: HT indicates that the processor model supports Intel® Hyper-Threading Technology. NOTE: Tur

adapts to spikes in your workload and delivers more performance upside than then previous generation turbo technology. NOTE: DDR4 speed is the maxim type of DIMMs installed. NOTE: The xxxxxx-L21 is the first processor shipped, the xxxxxx-B21 is the 2nd processor and ships with 2 additional fans for factory of field installation. NOTE: Maximum memory per socket depends on the processor selected.

To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE recommends memory from the list located here: http://www.hpe.com/products/recommend.

testing.

NOTE: The maximum memory speed is a function of the memory type, memory configuration, and

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 28

HP Mobile USB Non Leaded System DVD RW Drive

701498-B21

NOTE: This is only supported on USB 3.0 ports.

HPE Drives

Enterprise - 12G SAS - SFF Drives

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870753-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872475-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870757-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

870763-B21

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872477-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870759-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

870765-B21

HPE 900GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD

785069-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872479-B21

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872481-B21

Midline - 12G SAS - SFF Drives

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty HDD

832514-B21

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD

765464-B21

HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD

765466-B21

Midline - 12G SAS - LFF Drives

HPE 1TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

846524-B21

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

818365-B21

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872485-B21

HPE 3TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

846528-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

818367-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861756-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872487-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

846514-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861754-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861590-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

819201-B21

HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

857644-B21

Midline - 6G SATA - SFF Drives

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

655710-B21

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765453-B21

HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765455-B21

Midline - 6G SATA - LFF Drives

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861691-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861676-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872489-B21

HPE 3TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

861693-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861678-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861752-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872491-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

846510-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861750-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819203-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

861594-B21

HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857648-B21

SSD Selection

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 29

To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE

http://ssd.hpe.com

Write Intensive - 6G SATA - SFF - Solid State Drives

HPE 400GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872355-B21

HPE 400GB SATA 6G Write Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872357-B21

HPE 800GB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872359-B21

HPE 800GB SATA 6G Write Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872361-B21

HPE 1.6TB SATA 6G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872363-B21

HPE 1.6TB SATA 6G Write Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872365-B21

Write Intensive - PCIe/NVMe - SFF - Solid State Drives

HPE 400GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty SSD

736936-B21

HPE 800GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty SSD

736939-B21

HPE 1.6TB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty SSD

764892-B21

HPE 2TB NVMe x4 Lanes Write Intensive SFF(2.5in) SCN 3yr Wty SSD

764894-B21

NOTE: An NVME (826689-B21 or 873781-B21) or Premium (826690-B21) drive cage are required to

NOTE: With NVMe support only 1x Double Wide Graphics card is supported.

Read Intensive - 6G SATA - SFF - Solid State Drives

HPE 150GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869374-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869376-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

868814-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869378-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

868818-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869384-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

868822-B21

HPE 1.6TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869386-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

868826-B21

HPE 3.8TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

868830-B21

Read Intensive - 6G SATA - LFF - Solid State Drives

HPE 480GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

869380-B21

HPE 1.6TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

869388-B21

Read Intensive - 6G SATA - M.2 - Solid State Drives

HPE 340GB SATA 6G Read Intensive M.2 2280 3yr Wty SSD

777264-B21

HPE 340GB SATA 6G Read Intensive 3yr Wty M.2 Kit

835563-B21

HPE 340GB SATA 6G Read Intensive 3yr Wty Dual M.2 Kit

835565-B21

NOTE: M.2 drives go in the Primary Riser and use S100i SATA controller only. NOTE:

Read Intensive - 6G SATA - M.2 - uFF - Solid State Drives

HPE 340GB SATA 6G Read Intensive UFF 3yr Wty Dual M.2 Kit

815605-B21

HPE 340GB SATA 6G Read Intensive UFF 3yr Wty M.2 Kit

815606-B21

NOTE: M.2 drives go in the Primary Riser and use S100i SATA controller only.

Read Intensive - NVMe - SFF - Solid State Drives

HPE 400GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty SSD

764904-B21

HPE 1.2TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty SSD

764906-B21

Mixed Use - 6G SATA - SFF - Solid State Drives

recommends SSDs from the list located here: http://www.hpe.com/products/recommend. Best product availability is limited to US, Canada, and Latin America at this time.

To further assist with configuration, HPE also offers an SSD Selector Tool located here:

support these drives in conjunction with a NVMe riser kit. NOTE: HPE has qualified the NVMe drive portfolio using the Operating System inbox drivers, full detail on the HPE Solid State Drive QuickSpecs.

M.2 supports Software RAID only.

NOTE: M.2 supports Software RAID only.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 30

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872344-B21

HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872346-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872350-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872348-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872352-B21

Mixed Use - NVMe - SFF - Solid State Drives

HPE 400GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty SSD

765034-B21

HPE 800GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty SSD

765036-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty SSD

765038-B21

HPE 2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty SSD

765044-B21

NOTE: An NVME (826689-B21 or 873781-B21) or Premium (826690-B21) drive cage is required to

NOTE: NVMe drives require the addition of the High Performance Fan kit (867810-B21).

Hard Drive Blank Kits

HPE Large Form Factor Hard Drive Blank Kit

666986-B21

HPE Small Form Factor Hard Drive Blank Kit

666987-B21

Hard Drive Kits

HPE DL38X Gen10 3LFF Rear SAS/SATA Drive Kit

826685-B21

NOTE: This is supported in the LFF model only. NOTE: 3 LFF rear drives will consume the 2nd riser expansion slot.

HPE DL38X Gen10 4LFF Midplane SAS/SATA HDD Kit

826686-B21

NOTE: Supported with both the 8 and 12 LFF model.

NOTE:

HPE DL38X Gen10 2SFF Premium HDD Front NVMe/SAS/SATA Kit

826687-B21

NOTE: Supports 2SFF SAS/SATA/NVMe in Universal Media bay (826708-B21).

NOTE: Drive cage can be used in the rear of the chassis, but will not support NVMe drives rear.

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

NOTE: Supports 2 SFF rear in Riser1 or 2 location – max 2 supported SFF model.

maximum of one in riser 1 location.

HPE DL38X NVMe 8 Solid State Drive Express Bay Enablement Kit

826689-B21

NOTE: This option provides support for up to 8NVMe drives, and can be populated in all Boxes in the 8 SFF

NOTE: NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE DL38X Gen10 Premium 6 SFF SAS/SATA + 2 NVMe or 8 SFF SAS/SATA Bay Kit

826690-B21

NOTE: This option provides supports up to 8 SAS/SATA SFF drives or a combination of 6 SAT/SATA and 2

1-port 2 NVMe Slimline Riser (867806-B21); or the HPE DL38X Gen10 2-port 4 NVMe Slim SAS Riser

NOTE: With NVMe support only 1x Double Wide Graphics card is supported. NOTE: Not supported by HPE Smart Array controllers.

NOTE: Ships with low profile HeatSink for installation. Supporting processors below 125W. NOTE: No support for the 8156, 6128 or the 5122 Processors. NOTE: With this mid-tray only single-wide (8.5-inch cards with connections or less) cards are supported. NOTE: This drive does support hot-swap drives.

This requires High Performance Fans (867810-B21).

NOTE: NVMe drives require the addition of the High Performance Fan kit (867810-B21). NOTE: NVMe drives require the addition of an NVMe capable riser.

NOTE: Supports 2 SFF rear in Riser1 or 2 location in LFF model. Note is 3 LFF rear option is selected

model. NOTE: A maximum of 20 NVMe drives only are supported., this will mean partial population (4 drives) when the 3rd cage is populated in Box 1. NOTE: This will require the HPE DL38X Gen10 4-port 8 NVMe Slimline Riser (867807-B21).

NVMe drives in the same cage, and can be populated in all Boxes in the SFF model.

NOTE: For support of the 2 NVMe drives this will require the addition of the HPE DL38X Gen10 x8/x8/x8

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 31

(867808-B21). NOTE: NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE DL38X Gen10 SFF Box1/2 Cage/Backplane Kit

826691-B21

NOTE: Supports 8 SAS/SAFA SFF drives in Box 1 or 2 to a max of 24 SFF SAS/SATA front.

HPE DL380 Gen10 LFF 1U SAS/SATA Kit

867805-B21

NOTE: For 2 SFF SAS/SATA in UMB on 8 LFF model only.

HPE DL38X Gen10 8LFF Front 2NVMe HDD Bay Kit

873781-B21

NOTE: Supports 2 NVMe in the Universal Media bay (included) on the 8 LFF model.

NOTE:

Media Bay Kits

HPE DL38X Gen10 Universal Media Bay Kit

826708-B21

NOTE: The Universal Media Bay offers front Display port 2x USB 2.0, plus ability to add optional Optical

NOTE: This is only compatible with the SFF model and can be populated in Box1 only.

HPE Networking

1 Gigabit Ethernet adapters

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE Ethernet 1Gb 2-port 332T Adapter

615732-B21

HPE Ethernet 1Gb 2-port 361T Adapter

652497-B21

HPE Ethernet 1Gb 4-port 366T Adapter

811546-B21

HPE Ethernet 10Gb 2-port 530T Adapter

656596-B21

HPE Ethernet 10Gb 2-port 535T Adapter

813661-B21

25 Gigabit Ethernet adapters

HPE Ethernet 4x25Gb 1-port 620QSFP28 Adapter

817762-B21

HPE Ethernet 10/25Gb 2-port 631SFP28 Adapter

817718-B21

HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter

817753-B21

NOTE: The DL380 Gen10 ships with 4x 1 Gb Embedded.

http://www.hpe.com/us/en/product-catalog/servers/server-adapters.hits-12.html

FlexibleLOM adapters

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE Ethernet 10Gb 2-port 530SFP Adapter

652503-B21

HPE FlexFabric 10Gb 2-port 533FLR-T Adapter

700759-B21

HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter

700751-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

HPE FlexFabric 10Gb 4-port 536FLR-T Adapter

764302-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10Gb 2-port 562SFP+ Adapter

727055-B21

HPE Ethernet 10/25Gb 2-port 631FLR-SFP28 Adapter

817709-B21

HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter

817749-B21

NOTE: The DL380 Gen10 chassis ships with 4x 1 Gb embedded.

NOTE:

NOTE: For support of the 2 NVMe drives this will require the addition of the HPE DL38X Gen10 x8/x8/x8

1-port 2 NVMe Slimline Riser (867806-B21); or the HPE DL38X Gen10 2-port 4 NVMe Slim SAS Riser (867808-B21).

NVMe drives require the addition of the High Performance Fan kit (867810-B21).

drive,and 2 SFF, either SAS/SATA or NVMe.

NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each adapter. NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic

environments must be purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

NOTE: Only one FlexibleLOM can be added to the server. These options are upgradeable and can be changed from the original configuration after the server is shipped.

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 32

environments must be purchased separately. Please see the related NIC QuickSpecs for Technical

http://www.hpe.com/us/en/product-catalog/servers/server-adapters.hits-12.html.

HPE InfiniBand

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter

764284-B21

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter

764285-B21

HPE InfiniBand EDR/Ethernet 100Gb 1-port 840QSFP28 Adapter

825110-B21

HPE InfiniBand EDR/Ethernet 100Gb 2-port 840QSFP28 Adapter

825111-B21

HPE I/O Expansion Options

NOTE: The Primary Riser shipping default in the chassis is a x8 FH, HL, x16 FH, FL and x8 FH, HL with m.2

NOTE: For a Secondary/Tertiary riser the second processor is required.

HPE DL38X Gen10 x16/x16 Riser Kit

826694-B21

NOTE: Slot 1 or 2 in Primary or Secondary location.

NOTE: Bus width x16, x16, Connector Width x16, x16.

HPE DL Gen10 x8/x16/x8 Riser Kit

870548-B21

NOTE: Slot 1 or 2 in Primary or Secondary location.

NOTE: Bus width x8, x16, x8, Connector Width x8, x16, x8.

HPE DL Gen10 x16/x16 GPU Riser Kit

826704-B21

NOTE: Primary or Secondary Riser, Connector in slot 2 & 3 for GPU support.

NOTE: Bus width x16, x16, Connector Width x16, x16.

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

NOTE: Premium bay supporting SFF SAS/SATA and NVMe.

NOTE: Will leave 1 x16 Connector available in bottom slot.

HPE DL38X Gen10 x8/x8/x8 1-port 2 NVMe Slim SAS Riser

867806-B21

NOTE: Supports NVMe drives in Primary or Secondary location.

HPE DL38X Gen10 2-port 4 NVMe Slim SAS Riser

867808-B21

NOTE: Supports up to 4 NVMe drives in Tertiary location. NOTE: Bus width x8, x8 Connector Width x8, x8.

HPE DL38X Gen10 4-port 8 NVMe Slim SAS Secondary Riser

873732-B21

NOTE: Riser supporting up to 8 NVMe drives in Secondary location. NOTE: Bus width x8, x8, x8, x8 Connector Width x8, x8, x8, x8.

HPE DL38X Gen10 2 x8 PCIe Tertiary Riser Kit

875780-B21

NOTE: Supports 2x 8 slots in the Tertiary location.

HPE DL38X Gen10 x16 Tertiary Riser Kit

826700-B21

NOTE: Supports 1x 16 slot in the Tertiary location.

NOTE: Bus width x16 Connector Width x16.

HPE Power Supplies

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard

Specifications and additional information:

support.

NOTE: Supports Full Height and Full length cards.

NOTE: No M.2 support on this riser. NOTE: Supports Full Height, Half- length cards; Full Height, Full-length cards and Full Height, Half- length

cards.

NOTE: Supports Full Height and Full length cards.

NOTE: Available in Primary or Secondary Riser location.

NOTE: Supports Full Height and half-length cards. NOTE: Bus width x8, x8, x8 Connector Width x8, x8, x8.

NOTE: Supports Full Height and full-length card.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 33

C-14 power inlet connector.

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

NOTE: Flex Slot Titanium power supplies support power efficiency of up to 96% and include a standard C-14 power inlet connector.

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

NOTE: Flex Slot universal power supplies support power efficiency of up to 94% and support both 277VAC/380VDC power inputs.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector.

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

NOTE: Flex Slot -48VDC power supplies support power efficiency of up to 94%.

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

NOTE: Flex Slot Platinum Plus power supplies support power efficiency of up to 94% and include a C-14 power inlet connector that can support HPE Power Discovery Services (blue connector).

GPGPU Information

number

Card

support

speed

DL380 configuration

with 2 SFF

Module2

NOTE: 1x 1400W PS recommended, but this card will work with 1x800W PS (per GPU). However check the power usage via

NOTE:

Part

Q0J62A

Q0V79A

Q0V80A

Q0E21A

Q0V77A

Q0V78A

Q0V76A

NVIDIA Tesla

M10 4 GB

NVIDIA Tesla

P4 8 GB

Module

HPE NVIDIA

Tesla P40 24

GB Module

NVIDIA Tesla

P100 PCIe 16

GB Module

NVIDIA Quadro

P2000 GPU

Module

NVIDIA Quadro

P4000 GPU

Module

NVIDIA Quadro

P6000 PCIe

GPU Adapter

16 SFF

Qty

Processor

2 All Gen2/3 35C 35C 35C 25C1 35C 35C 30C 30C1

5 All Gen3 35C 35C 35C 35C1 35C 35C1 35C 35C1

3 All Gen3 35C 35C 25C 25C1 25C 25C1 20C 20C1

2 All Gen3 30C 25C 30C 25C1 25C 25C1 20C 20C1

5 All Gen3 35C 35C 35C 35C1 35C 35C1 35C 35C1

2 All Gen3 35C 35C 35C 25C1 35C 35C1 35C 35C1

PCIe

8SFF 8LFF

+UMB

16 SFF

+ 8

NVMe

24 SFF

SFF+2

SFF rear

LFF

LFF+2

SFF rear

the HPE Power Advisor Tool located at http://www.hpe.com/info/hppoweradvisor. NOTE: Performance fans (867810-B21) are required for all GPU installations (Note theseship as standard with the 24SFF and 12LFF models).

NOTE: Mixing of GPUs is not supported. NOTE: With the Standard Primary Riser the top x8 PCIe Slot connector will not be accessible with the installation of a

doublewide GPU.

NOTE: The P100, M10, P6000 and P40 cards are not supported with Processors over 160W. NOTE: Only 2 SFF rear drives supported over Power Supply as would require Riser 1 and Riser 2 for GPU support.

4 LFF mid-tray will not support DW cards.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 34

NOTE: 1 Invalid configuration or no HW support may apply to multiple GPUs installed. HW limitation may not be a thermal limitation.

HPE Computation and Graphics Accelerators

HPE NVIDIA Quadro P2000 GPU Module

Q0V77A

HPE NVIDIA Quadro P4000 GPU Module

Q0V78A

NOTE: This required the HPE GPU 6px6p Y-Power Cable Kit 874212-B21.

HPE NVIDIA Quadro P6000 GPU Module

Q0V76A

NOTE: This required the HPE DL380 Gen10 8P Cable Kit 871828-B21.

NVIDIA Tesla M10 Quad GPU Module

Q0J62A

NOTE: This required the HPE DL380 Gen10 8P Cable Kit 871828-B21.

NOTE: Only 2x M10 can be supported (on any x16 slot 2, 5 or 7) due to system running out of PCIe lanes.

HPE NVIDIA Tesla P4 8GB Module

Q0V79A

HPE NVIDIA Tesla P40 24GB Module

Q0V80A

NOTE: This required the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21.

HPE NVIDIA Tesla P100 PCIE 16GB Module

Q0E21A

NOTE: This required the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21.

Graphics Cable Kits

HPE GPU 6px6p Y-Power Cable Kit

874212-B21

HPE DL380 Gen10 8-pin Cable Kit

871828-B21

HPE DL380 Gen10 8-pin Keyed Cable Kit

871829-B21

HPE DL380 Gen10 8x 6-pin Cable Kit

871830-B21

HPE Cooling Options

HPE DL38X Gen10 High Performance Temperature Fan Kit

867810-B21

NOTE: This kit is required for specific Ambient temperature environments, coming in 2H2017.

NOTE: For elevated ambient temperature support please see: http://www.hpe.com/servers/ashrae.

NOTE: High Performance fan kit consists of 6 fans, these will need to replace all the standard fans in the

unit, and fill all 6 fan cages.

NOTE: The 12 LFF and 24 SFF models (including field upgrades to 24 SFF) will already include 6 High

Performance fan kits. NOTE: The High Performance fan kit is needed to support certain Passive GPGPU (Graphics cards) configurations; or ASHRAE operating environments.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 35

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard

information.

HPE Insight Software

HPE Insight Control

HPE Insight Control including 1yr 24x7 Technical Support and Updates 1-server LTU

C6N27A

HPE Insight Control including 1yr 24x7 TSU E-LTU

C6N28ABE

HPE Insight Management Media Kit

C6N31A

NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single

NOTE: For additional license options please see the HPE Insight Control QuickSpecs.

NOTE: For additional license options please see the QuickSpecs at:

https://www.hpe.com/h20195/v2/GetHTML.aspx?docname=c04123391.

Embedded Management

HPE iLO Advanced

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates E-LTU

E6U59ABE

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates 1-server LTU

512485-B21

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates Flexible Quantity LTU

512486-B21

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates Tracking LTU

512487-B21

HPE iLO Advanced including 3yr 24x7 Technical Support and Updates E-LTU

E6U64ABE

HPE iLO Advanced including 3yr 24x7 Tech Support and Updates 1-server LTU

BD505A

HPE iLO Advanced including 3yr 24x7 Tech Support and Updates Flexible Quantity LTU

BD506A

HPE iLO Advanced including 3yr 24x7 Tech Support and Updates Tracking LTU

BD507A

HPE iLO Advanced Security

HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features

Q7E31A

HPE iLO Advanced Premium Security Flex Qty License with 1yr Support on Licensed Features

Q7E32A

HPE iLO Advanced Premium Security Edition Electronic License with 1yr Support on Licensed Features

Q7E32AAE

HPE iLO Advanced Premium Security AKA Tracking License with 1yr Support on Licensed Features

Q7E35A

HPE iLO Adv Security Upg Elc Lic 3yr Sup

Q7E12AAE

HPE iLO Advanced Premium Security Edition License with 3yr Support on Licensed Features

Q7E33A

HPE iLO Advanced Premium Security Flex Qty License with 3yr Support on Licensed Features

Q7E34A

HPE iLO Advanced Premium Security Edition Electronic License with 3yr Support on Licensed Features

Q7E34AAE

HPE iLO Advanced Premium Security AKA Tracking License with 1yr Support on Licensed Features

Q7E36A

HPE Converged Infrastructure Management Software

HPE OneView Physical Media Kit LTU

E5Y37A

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView including 3yr 24x7 Support Track 1-server LTU

E5Y36A

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional

activation key. NOTE: Customer will receive a license entitlement certificate. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24 x 7 HPE Software Technical Support and Update Service. NOTE: Licenses ship without media. The HPE Insight Control Media Kit can be ordered separately, or can be downloaded at: https://www.hpe.com/info/insightmanagement.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 36

HPE OneView Upgrade from Insight Management 3yr 24x7 Support 1-server LTU

F6Q91A

HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU

P8B24A

HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU

P8B25A

HPE OneView w/o iLO Advance including 3yr 24x7 Support Track 1-server LTU

E5Y40A

HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU

P8B26AAE

NOTE: Full licenses of HPE OneView Advanced also provide the right-to-use HPE Insight Control without

downloaded.

HPE PCIe Workload Accelerator Options

HPE 800GB NVMe Write Intensive HH/HL PCIe Workload Accelerator

803195-B21

HPE 1.6TB NVMe Write Intensive HH/HL PCIe Workload Accelerator

803197-B21

HPE 800GB NVMe Mixed Use HH/HL PCIe Workload Accelerator

803200-B21

HPE 1.6TB NVMe Mixed Use HH/HL PCIe Workload Accelerator

803202-B21

HPE 2.0TB NVMe Mixed Use HH/HL PCIe Workload Accelerator

803204-B21

HPE Security

HPE Gen10 2U Bezel Kit

867809-B21

HPE Bezel Lock Kit

875519-B21

HPE Gen10 Chassis Intrusion Detection Kit

867824-B21

NOTE: This provides a physical connection from the chassis board and hood and detects any physical

distribution, and operation.

HPE Trusted Platform Module 2.0 Kit

872108-B21

NOTE: HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy

NOTE: There is a FIO setting to allow this TPM module to operate in a TPM 1.2 mode (872108-B21).

HPE Smart Array Controllers

Performance RAID Controllers

which supports multiple devices and is sold separately.

HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular

804338-B21

additional charge. NOTE: Server provisioning (via 'HPE Insight Control server provisioning') is licensed as part of HPE OneView Advanced and provides multi-server OS and driver provisioning. Media kit #BD883A can be ordered for a physical copy of this software (USB flash drive). NOTE: Licenses ship without media. The HPE OneView Media Kit can be ordered separately, or can be

intrusion into the chassis, providing security during the entire supply chain process of shipping, receiving,

Mode. It is not compatible with HPE ProLiant Gen8 servers or earlier generation variants. NOTE: HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced with any other TPM module.

NOTE: All performance RAID controllers are supported by the HPE Smart Storage Battery (875241-B21),

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 37

Controller

NOTE: Does not occupy a PCIe expansion slot and includes SmartCache license. NOTE:

HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular Controller

804331-B21

NOTE: Does not occupy a PCIe expansion slot.

HPE Smart Array P408i-p SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS PCIe Plug-in Controller

830824-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

Essential RAID Controllers

HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular Controller

804326-B21

NOTE: Does not occupy a PCIe expansion slot.

HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804394-B21

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Cable Options

HPE DL380 SFF Smart Array HBA H200/P400 Series SAS Cable Kit

786092-B21

HPE DL380 Gen10 Mini SAS 3POS Cable Kit

826709-B21

HPE DL38X Gen10 2 Drive NVMe Slim SAS Cable Kit

871827-B21

NOTE: For details on cabling options, additional information available here: Cabling Matrix.

Optional Software

HPE Smart Array Secure Encryption/Data at Rest Encryption/per Server Entitlement E-LTU

Q2F26AAE

HPE SmartCache No Media 24x7 Technical Support 1-server LTU

D7S26A

HPE SmartCache No Media 24x7 Technical Support Flexible LTU

D7S27A

HPE SmartCache No Media 24x7 Technical Support E-LTU

D7S27AAE

NOTE: SmartCache is offered on HPE Smart Array performance RAID controllers and comes standard (no licensing is required) if the HPE Smart Array P816i-a SR Gen10 Controller is installed in the server.

Optional Upgrades

HPE 96W Smart Storage Battery (up to 20 Devices/145mm Cable) Kit

875241-B21

NOTE: Provides backup power for multiple HPE Smart Array controllers or other devices. Is required with performance RAID controllers.

HPE Tape Backup

NOTE: For the complete range of tape drives, autoloaders, libraries and media see:

http://www.hpe.com/storage/BURAcompatibility.

HPE Storage Options

Emulex Fibre Channel HBAs

HPE StoreFabric SN1200E 16Gb Single Port Fibre Channel Host Bus Adapter

Q0L13A

HPE StoreFabric SN1200E 16Gb Dual Port Fibre Channel Host Bus Adapter

Q0L14A

HPE StoreFabric SN1600E 32Gb Single Port Fibre Channel Host Bus Adapter

Q0L11A

HPE StoreFabric SN1600E 32Gb Dual Port Fibre Channel Host Bus Adapter

Q0L12A

QLogic Fibre Channel HBAs

HPE StoreFabric SN1100Q 16Gb Single Port Fibre Channel Host Bus Adapter

P9D93A

HPE StoreFabric SN1100Q 16Gb Dual Port Fibre Channel Host Bus Adapter

P9D94A

HPE StoreFabric SN1600Q 32Gb Single Port Fibre Channel Host Bus Adapter

P9M75A

HPE StoreFabric SN1600Q 32Gb Dual Port Fibre Channel Host Bus Adapter

P9M76A

The P816i-a cable ships in the 12LFF chassis only (868705-B21).

https://www.hpe.com/us/en/storage/storeever-tape-storage.html. For hardware and software

compatibility of Hewlett Packard Enterprise tape backup products

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 38

Converged Network Adapters

HPE StoreFabric CN1100R Dual Port Converged Network Adapter

QW990A

HPE StoreFabric CN1100R 10GBASE-T Dual Port Converged Network Adapter

N3U52A

HPE StoreFabric CN1200E 10Gb Converged Network Adapter

E7Y06A

HPE StoreFabric CN1200E 10GBASE-T Dual Port Converged Network Adapter

N3U51A

NOTE: For the complete listing of Fibre Channel Host Bus Adapters for Windows 2000, Windows Server 2003 and Linux,

https://www.hpe.com/us/en/product-catalog/storage/storage-adapters.hits-12.html

HPE Racks

NOTE: Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options

and rack specifications.

NOTE: Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications.

NOTE: Please see the HPE Standard Series Racks QuickSpecs for information on additional racks options and rack specifications.

HPE Power Distribution Units (PDUs)

NOTE: Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for information on these

products and their specifications.

NOTE: Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.

NOTE: Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs for information on these products and their specifications.

NOTE: Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications.

HPE Uninterruptible Power Systems (UPS)

NOTE: To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page.

NOTE: Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs for

information on these products and their specifications.

NOTE: Please see the HPE Line Interactive Single Phase UPS QuickSpecs for information on these products and their specifications.

HPE Rack Options

NOTE: Please see the HPE KVM Switches web page for information on these products and their

specifications.

Rail Kits

NOTE: Ball bearing and Easy Install rail kits contain telescoping rails which allow for in-rack serviceability.

ll Rack

use for any installation.

HP 2U Small Form Factor Easy Install Rail Kit

733660-B21

NOTE: Does not include CMA (733664-B21).

HP 2U Large Form Factor Easy Install Rail Kit

733662-B21

NOTE: Does not include CMA (733664-B21).

HP 2U Cable Management Arm for Easy Install Rail Kit

733664-B21

HPE 2U Small Form Factor Ball Bearing Rail Kit

720863-B21

please see:

NOTE: To assist in the installation of the server into the rack an optional installation tool is available by contacting your local services representative (695539-001). CAUTION: Hewlett Packard Enterprise recommends that a minimum of two people are required for a Server installations. Please refer to your installation instructions for proper tools and number of people to

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 39

NOTE: Does not include CMA (720865-B21).

HPE 2U Large Form Factor Ball Bearing Rail Kit

720864-B21

NOTE: Does not include CMA (720865-B21).

HPE 2U Cable Management Arm for Ball Bearing Rail Kit

720865-B21

HPE Other Options

HPE Rack LED Light Kit

BW939A

HP Kit LCD 1.83m Latch Display Port Cable

G7T29A

HPE USB and SD Options

HPE Enterprise Mainstream Flash Media Kits for Memory Cards

HPE 32GB microSD Mainstream Flash Media Kit

700139-B21

HPE 8GB microSD Enterprise Mainstream Flash Media Kit

726116-B21

HP 8GB USB Enterprise Mainstream Flash Media Drive Key Kit

737953-B21

HP Dual 8GB microSD Enterprise Midline USB Kit

741279-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 40

Memory Population guidelines

General Memory Population Rules and Guidelines:

Install DIMMs only if the corresponding processor is installed.

If only one processor is installed in a two-processor system, only half of the DIMM slots are available.

To maximize performance, it is recommended to balance the total memory capacity between all installed processors.

When two processors are installed, balance the DIMMs across the two processors.

White DIMM slots denote the first slot to be populated in a channel.

Mixing of DIMM types (UDIMM, RDIMM, and LRDIMM) is not supported.

The maximum memory speed is a function of the memory type, memory configuration, and processor model.

The maximum memory capacity is a function of the number of DIMM slots on the platform, the largest DIMM capacity qualified

on the platform, the number and model of installed processors qualified on the platform.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 41

For details on the HPE Server Memory Options Population Rules, visit:

http://www.hpe.com/docs/memory-population-rules

To realize the performance memory capabilities listed in this document, HPE DDR4 SmartMemory is required. For additional

HPE DDR4 SmartMemory QuickSpecs

DIMM Type

HPE SKU P/N

SKU Description

HPE 8GB 1Rx8 PC4-

2666V-R Kit

HPE 16GB 1Rx4 PC4-

2666V-R Kit

HPE 16GB 2Rx8

PC4-2666V-R Kit

HPE 32GB 2Rx4

PC4-2666V-R Kit

DIMM Rank ->

Single Rank (1R)

Dual Rank (2R)

DRAM depth [bit]

DIMM Native Speed (MT/s)

2666 MT/s

2 DIMM Per Channel

2666 MT/s

2400 MT/s

1 DIMM Per Channel

2133 MT/s

1 DIMM Per Channel

2666 MT/s

2400 MT/s

1 DIMM Per Channel

2133 MT/s

NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.

https://www.hpe.com/docs/memory-speed-table

DIMM Type

Load Reduced (LRDIMM)

HPE SKU P/N

SKU Description

64GB

128GB

DRAM depth [bit]

information, please see the

815097-B21 815098-B21 835955-B21 815100-B21

DIMM Capacity -> 8GB 16GB 16GB 32GB Voltage 1.2V 1.2V 1.2V 1.2V

DRAM Width [bit] x8 x4 x8 x4 DRAM Density 8Gb 8Gb 8Gb 8Gb CAS Latency 19-19-19 19-19-19 19-19-19 19-19-19

Intel Xeon®Platinum 81xx Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel

Intel Xeon®Platinum 41xx/51xx/61xx Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel

2 DIMM Per Channel

Intel Xeon®Platinum 31xx Processors Officially Supported Memory Speed (MT/s)

2 DIMM Per Channel 2133 MT/s

HPE Server Memory Speed (MT/s): Intel Xeon®Platinum 81xx Processors *

2 DIMM Per Channel

HPE Server Memory Speed (MT/s): Intel Xeon®Platinum 41xx/51xx/61xx Processors *

1 DIMM Per Channel

2 DIMM Per Channel

HPE Server Memory Speed (MT/s): Intel Xeon®Platinum 31xx Processors *

2 DIMM Per Channel

For details on the HPE Server Memory speed, visit:

815101-B21 815102-B21

HPE 64GB 4Rx4 PC4-2666V-L Kit HPE 128GB 8Rx4 PC4-2666V-L Kit DIMM Rank -> Quad Rank (4R) Octal Rank (8R) DIMM Capacity -> Voltage 1.2V 1.2V

DRAM Width [bit] x4 x4 DRAM Density 8Gb 8Gb

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 42

2666 MT/s

2400 MT/s

2133 MT/s

2666 MT/s

2 DIMM Per Channel

2400

2133 MT/s

NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.

https://www.hpe.com/docs/memory-speed-table

Standard and Maximum Memory Capacity (Pre-configured Models)

Pre Configured

Models

Maximum Memory Plus

Optional Memory

Standard Memory Replaced with

Optional Memory

3106

16 GB (1x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

4110

32 GB (2x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

4114

32 GB (2x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

5118

64 GB (2x32 GB RDIMM DR)

768 GB (24x 32 GB)

3072 GB (24x 128 GB)

6130

64 GB (2x32 GB RDIMM DR)

768 GB (24x 32 GB)

3072 GB (24x 128 GB)

NOTE: 128 GB coming 2H 2017.

DDR4 memory options part number decoder

NOTE: Capacity references are rounded to the common gigabyte (GB) values.

• 64GB = 65,536 MB

For more information on memory, please see the Memory Quickspecs: HPE DDR4 SmartMemory

CAS Latency 19-19-19 22-19-19 DIMM Native Speed (MT/s) 2666 2666

Intel Xeon® Platinum 81xx Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel 2 DIMM Per Channel

Intel Xeon® Gold/Silver 41xx/51xx/61xx Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel 2400 MT/s 2400 MT/s

2 DIMM Per Channel

Intel Xeon® Bronze 31xx Processors Officially Supported Memory Speed (MT/s)

1 DIMM Per Channel 2 DIMM Per Channel

HPE Server Memory Speed (MT/s): Intel Xeon® Platinum 81xx Processors *

1 DIMM Per Channel

2 DIMM Per Channel

HPE Server Memory Speed (MT/s): Intel Xeon® Gold/Silver41xx/51xx/61xx Processors *

1 DIMM Per Channel 2400 2400

HPE Server Memory Speed (MT/s): Intel Xeon® Bronze 31xx Processors *

1 DIMM Per Channel

2 DIMM Per Channel

For details on the HPE Server Memory speed, visit:

Standard Memory

• 8GB = 8,192 MB

• 16GB = 16,384 MB

• 32GB = 32,768 MB

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Storage

Page 43

8LFF chassis with Universal media bay and optional 2SFF and optical drive shown

12 LFF + 3 rear LFF drives

12 LFF + 2 rear SFF drives

6 rear SFF drives

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Storage

Page 44

24 SFF + rear 2 SFF drives

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 45

System Unit

Dimensions

8.73 x 44.55 x 67.94 cm

3.44 x 17.54 x 26.75 in

SFF Drives:

8.73 x 44.55 x 73.02 cm

LFF Drives:

Weight (approximate)

14.9 kg

Minimum: 8 SFF chassis with 1x SFF HDD and 7 HDD blanks, 2x Drive

(plus blank), 1x Smart Array, 1x Riser installed, cables for the above)

23.6 kg

51.5 lb

Maximum: 12 LFF hard drives (no rear drives), 2x processors, 2x power supplies, 1x Smart Array, 2x Risers installed)

Input Requirements

Rated Line Voltage

100 to 120 VAC

200 to 240 VAC

BTU Rating

Maximum

For 800W Power Supply: 3207 BTU/hr (at 100 VAC), 3071 BTU/hr (at 200 VAC), 3112 BTU/hr (at 240 VAC) for China Only

For 500W Power Supply: 1979 BTU/hr (at 100 VAC), 1911 BTU/hr (at 200 VAC), 1965 BTU/hr (at 240 VAC) for China Only

Power Supply Output

Rated Steady-State Power

For 1400W Power Supply: 1400W (at 240 VAC), 1400W (at 240 VAC)

For 800W Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W (at 240 VAC) input for China only

For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W (at 240 VAC) input for China only

Maximum Peak Power

For 1400W Power Supply: 1400W (at 200 to 240 1VAC), 1400W (at 240 VAC) input for China only

For 800W Power Supply: 800W (at 100 to 127 VAC), 800W (at 200 to 240 1VAC), 800W (at 240 VAC) input for China only

For 500W Power Supply: 500W (at 100 to 127 VAC), 500W (at 200 to 240 VAC), 500W (at 240 VAC) input for China only

System Inlet Temperature

Standard Operating

10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C

Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate

reduced if operating with a fan fault or above 30°C (86°F).

Extended Ambient

For approved hardware configurations, the supported system inlet range is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95°

3.44 x 17.54 x 28.75 in

(per power supply)

32.75 lb

Bay blanks, 1x processor including standard heatsink, 1x power supply

Temperature

per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight.

of change may be limited by the type and number of options installed.

System performance during standard operating support may be

Operating Temperature

to 104°F) at sea level with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

http://www.hpe.com/servers/ashrae

For approved hardware configurations, the supported system inlet range is extended to be: 40° to 45°C (104° to 113°F) at sea level with an altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

http://www.hpe.com/servers/ashrae

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 46

Non-operating

-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).

Relative Humidity

Operating

8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature, non-condensing.

(non-condensing)

Non-operating

5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing..

Altitude

Operating

3050 m (10,000 ft). This value may be limited by the type and number

m/min (1500 ft/min).

Non-operating

9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

Acoustic Noise

Listed are the declared A-Weighted sound power levels (L

) and declared average bystander

regarding the configurations listed below.

Idle

LWAd

4.7 B Entry

4.9 B Base

4.8 B Perf

LpAm

31 dBA Entry

34 dBA Base

33 dBA Perf

Operating

LWAd

4.7 B Entry

4.9 B Base

4.8 B Perf

LpAm

31 dBA Entry

34 dBA Base

33 dBA Perf

NOTE: Acoustics levels presented here are generated by the test configuration only. Acoustics

may result in increased sound levels.

Emissions Classification

To view the regulatory information for your product, view the Safety and Compliance Information

http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts

System performance may be reduced if operating in the extended ambient operating range or with a fan fault.

of options installed. Maximum allowable altitude change rate is 457

WAd

position A-Weighted sound pressure levels (L environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels. Please have your HPE representative provide information from the HPE EMESC website for further technical details

) when the product is operating in a 23°C ambient

pAm

levels will vary depending on system configuration. Values are subject to change without notification and are for reference only.

NOTE: Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.

NOTE: The Listed sound levels apply to standard shipping configurations. Additional options

(EMC) – Regulatory Information

for Server, Storage, Power, Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 47

QuickSpecs.

For information on the HPE Smart Array P408i-a SR Gen10 Controller please refer to their QuickSpecs.

For information on the HPE Smart Array P408i-p SR Gen10 Controller please refer to their QuickSpecs.

For information on the HPE Smart Array P408e-p SR Gen10 Controller please refer to their QuickSpecs.

For information on the HPE Smart Array P816i-a SR Gen10 Controller please refer to their QuickSpecs.

Environment-

End-of-life Management and

Hewlett Packard Enterprise offers end-of-life product return, trade-in,

For information on the HPE Smart Array E208i-a SR Gen10 Controller please refer to their

For information on the HPE Smart Array E208i-p SR Gen10 Controller please refer to their

For information on the HPE Smart Array E208e-p SR Gen10 Controller please refer to their

friendly Products and Approach

Recycling

and recycling programs, in many geographic areas, for our products.

Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Summary of Changes

Page 48

Date

Version History

Action

Description of Change

11-Jul-2017

Version 1

New

New QuickSpecs.

© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is subject t forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional war technical or editorial errors or omissions contained herein.

Intel® and Xeon® are registered trademarks of Intel Corporation in the U.S. and other countries.

Microsoft®, Windows®, and Windows S companies.

For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less

a00008180 - 15930 - Worldwide - V1 - 11-July-2017

o change without notice. The only warranties for Hewlett Packard Enterprise products and services are set

ranty. Hewlett Packard Enterprise shall not be liable for

erver® are U.S. registered trademarks of the Microsoft group of

HPE PERFDL380-006 Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Standard Features

Optional Features

Service and Support

Core Options

Additional Options

Memory

Storage

Technical Specifications

Summary of Changes

a00008180 - 15930 - Worldwide - V1 - 11-July-2017
