QuickSpecs

HPE ProLiant DL360 Gen10 Server

Overview

Page 1

HPE ProLiant DL360 Gen10 Server

Does your data center need a secure, performance driven dense server that you can confidently deploy for virtualization, database, or high-performance computing? The powerful 2P HPE ProLiant DL360 Gen10 is redefining dense compute by delivering security, a

The HPE ProLiant DL360 Gen10 Server supports the Intel® Xeon® Processor Scalable Family with up to 28 cores, plus 2666 MT/s HPE DDR4 SmartMemory supporting up to 3.0 HPE ProLiant DL360 Gen10 means business. Deploy this

platform for diverse workloads in space constrained environments

and maintain it with ease by automating the most essential server lifecycle management tasks with HPE OneView and HPE iLO 5.

8 SFF Front View – 8 SFF + 2 SFF Universal Media Bay option shown

Drive support label

Power On/Standby button and system power LED

Quick removal access panel

Health LED

Serial no. label pull tab

NIC status LED

Universal Media Bay Options:

UID button/LED

Option shown: +2 SFF SAS/SATA (total 10SFF)

USB 3.0 port

Option: +2 SFF NVMe drives

10.

iLO Service Port

Option: DVD-RW or DVD-ROM + Display port & USB 2.0 port Kit

11.

Standard 8 SAS/SATA/SSD drive bays

Option: +2 Dual uFF (4x M.2 cartridges)

Option: Display port + USB 2.0 port Kit + Blank

NOTE: Other options not shown.

NOTE: New! Rear drive option allows for an additional + 1 SFF or +1 Dual uFF (2x M.2 cartridges). NOTE: System Insight Display (SID) module will include #5-9 above (will not include #10 - iLO Service Port).

gility and unmatched expandability businesses want all packed in a dense 1U rack design.

TB max. With the added performance that 12 NVDIMMs and 10 NVMe brings, the

dense

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Overview

Page 2

Premium 10SFF NVMe Front View

Drive support label

NIC status LED

Quick removal access panel

UID button/LED

Serial no. label pull tab

USB 3.0 port

Power On/Standby button and system power LED

iLO Service Port

Health LED

10.

Max up to 10 NVMe drives (PCIe direct attached) or 8 SAS/SATA + 2 NVMe

NOTE: Other options not shown. NOTE: NOTE: System Insight Display (SID) module will include #4-8 above (will not include #9 - iLO Service Port).

4 LFF Front View – Standard 4 LFF shown

Drive support label

iLO Service Port

Quick removal access panel

USB 3.0 Port

Option: DVD-RW or DVD-ROM (blank shown)

UID button/LED

Serial no. label pull tab

10.

Power On/Standby button and system power LED

Option: Display port & USB 2.0 port Kit (blank shown)

11.

Health LED

Option: System insight Display (SID)* - standard shown

12.

NIC status LED

NOTE: *This option will lose #7 iLO Service Port.

13.

SAS/SATA/SSD drive bays

NOTE: New! Rear drive option allows for additional + 1 SFF or +1 Dual uFF (2x M.2 cartridges), will lose one FH PCIe slot.

New! Rear drive option allows for an additional + 1 SFF or +1 Dual uFF (2x M.2 cartridges).

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Overview

Page 3

Internal View - Standard for all DL360 Gen10

For 8 SFF or 4 LFF - Standard single rotor hot plug fans

11.

System Battery

- 1 CPU – 5 standard fans

12.

Optional: TPM 2.0

- 2 CPUs – 7 standard fans

13.

Primary (CPU1) PCIe 3.0 riser

*Option: High Performance fans

Standard: GPU power connector + 1x 16 and 1x 8

NOTE: *For 10 NVMe chassis - 7 High Performance

Optional: 2 SATA M.2 + 2x 16

Fans will be shipped for 1 or 2 processors.

*Optional: 2x 4 NVMe + 1x 16 and 1x 8

Option: Smart Storage Battery

NOTE: *Only available on 8 SFF.

Up to 2 processors (shown with standard heat sinks)

14.

Optional: Front Display port / USB 2.0

MicroSD card slot (Dual Micro-SD option available)

15.

FlexibleLOM (supports various NICs up to 25GbE)

Option: Chassis Intrusion Detection

16.

x4 SATA port 1

Hard Drive backplane power connector

17.

x4 SATA port 2

Dual internal USB 3.0 connector

18.

x2 SATA port 3

Smart Array Controller (Type -a shown)

19.

x1 SATA port 4

Up to 2 Power Supplies for redundant power

20.

Optical / SATA port 5

10.

Secondary (CPU2) PCIe 3.0 riser

21.

Front Power USB 3.0 connector

Option: Low Profile x16 or

22.

DDR4 DIMM slots

*Option: Full Height x16 (Lose slot 2 on Primary riser)

(Fully populated 24 DIMMs shown)

NOTE: *For 10 NVMe chassis – Secondary Riser is not available due to 10 x4 NVMe riser for PCIe direct attached.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Overview

Page 4

Rear View – Standard for all DL360 Gen10

Slot 1 PCIe 3.0

VGA port

Option: Rear Drive +1 SFF or 1 uFF SSD (2x M.2 cartridges)

Embedded 4x 1GbE Adapter

NOTE: Will lose one FH x16 PCIe slot1 with this option.

iLO Management Port

Slot 2 PCIe 3.0

Option: Serial Port

Option: Slot 3 PCIe 3.0 (Requires 2nd processor)

10.

USB 3.0 Ports

Power Supply 2

11.

Option: FlexibleLOM (Shown: 4x 1GbE)

Power Supply 1

NOTE: Supports Various NICs up to 25GbE.

What’s New

•

Smart Array P824i-p MR Gen10 (24 Internal Lanes/4GB Cache/CacheCade) 12G SAS PCIe Controller

• 240GB & 480GB SATA MU M.2 SFF SCM DS SSDs

• New SMB focused offers regionally released as "Smart Buy Express" in the U.S. and Canada, "Top Value" in Europe, and

"Intelligent Buy" in Asia Pacific and Japan

• HPE Specific Intelligent Systems Tuning Gold 6143 and Platinum 8165 Processors

• New AMD and NVIDIA Graphics card options

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Platform Information

Page 5

Platform Information

Form Factor

1U rack

Chassis Types

8 SFF with options supporting: +2 SFF or 2 NVMe or 2 Dual uFF (4x M.2 cartridges)

boot/storage: +1SFF or 1 Dual uFF (2x M.2 cartridges).

System Fans

Single rotor hot plug fans will be included

1 or 2 CPUs – Includes 7 high performance fans as standard

10 SFF NVMe Premium 4 LFF

NOTE: New Rear drive option available on all DL360 Gen10 chassis types for additional

For 4 LFF and 8 SFF chassis: 1 CPU – Includes 5 standard fans 2 CPUs – Includes 7 standard fans

NOTE: Optional High Performance Fan Kit available (includes 7 fans). NOTE: The DL360 Gen10 will support up to 7 fans with fan redundancy built in. One fan

rotor failure will place server in degraded mode but fully functional. Two fan rotor failures could provide warning and imminent server shutdown.

For 10 NVMe Premium chassis:

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 6

Standard Features

Processors – Up to 2 of the following depending on model.

NOTE:

Platinum 8180M Processor

2.5 GHz

38.50 MB

205W

3 @ 10.4 GT/s

2666 MT/s

1.5TB

Platinum 8180 Processor

2.5 GHz

38.50 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8176 Processor

2.1 GHz

38.50 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8170 Processor

2.1 GHz

35.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8168 Processor

2.7 GHz

33.00 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8165 Processor

2.3 GHz

33.00 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8164 Processor

2.0 GHz

35.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8160M Processor

2.1 GHz

33.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

1.5TB

Platinum 8160 Processor

2.1 GHz

33.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8158 Processor

3.0 GHz

24.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8156 Processor

3.6 GHz

16.50 MB

105W

3 @ 10.4 GT/s

2666 MT/s

768GB

NOTE:

- 48 lanes PCIe 3.0, advanced RAS.

Gold 6154 Processor

3.0 GHz

24.75 MB

200W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6152 Processor

2.1 GHz

30.25 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6150 Processor

2.7 GHz

24.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6148 Processor

2.4 GHz

27.50 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6146 Processor

3.2 GHz

24.75 MB

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6144 Processor

3.5 GHz

24.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6143 Processor

2.8 GHz

22.00 MB

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6142 Processor

2.6 GHz

22.00 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6140 Processor

2.3 GHz

24.75 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6136 Processor

3.0 GHz

24.75 MB

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6134M Processor

3.2 GHz

24.75 MB

130W

3 @ 10.4 GT/s

2666 MT/s

1.5TB

Gold 6134 Processor

3.2 GHz

24.75 MB

130W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6132 Processor

2.6 GHz

19.25 MB

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6130 Processor

2.1 GHz

22.00 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6128 Processor

3.4 GHz

19.25 MB

115W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6126 Processor

2.6 GHz

19.25 MB

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 5122 Processor

3.6 GHz

16.50 MB

105W

2 @ 10.4 GT/s

2666 MT/s

768GB

Gold 5120 Processor

2.2 GHz

19.25 MB

105W

2 @ 10.4 GT/s

2400 MT/s

768GB

NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.

This table covers the public Intel offering only.

Intel Xeon Models

CPU

Frequency

Cores L3 Cache Power UPI DDR4

Memory per

socket

Platinum 8153 Processor 2.0 GHz 16 22.00 MB 125W 3 @ 10.4 GT/s 2666 MT/s 768GB

Platinum Processors: 2 and 4 socket capable, 2S - 2UPI, 4S - 3UPI, 8S - 3UPI @ 10.4 GT/s. 6-Channel DDR4 @ 2666 MT/s. 768 GB max memory capacity (1.5 TB on select skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology Intel AVX-512 (2x 512-bit FMA).

Gold 6138 Processor 2.0 GHz 20 27.50 MB 125W 3 @ 10.4 GT/s 2666 MT/s 768GB

Gold 5118 Processor 2.3 GHz 12 16.50 MB 105W 2 @ 10.4 GT/s 2400 MT/s 768GB

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 7

Gold 5115 Processor

2.4 GHz

13.75 MB

85W

2 @ 10.4 GT/s

2400 MT/s

768GB

NOTE:

- 48 lanes PCIe 3.0, advanced RAS.

Silver 4116 Processor

2.1 GHz

16.50 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4114 Processor

2.2 GHz

13.75 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4112 Processor

2.6 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4110 Processor

2.1 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4108 Processor

1.8 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

NOTE:

- 48 lanes PCIe 3.0, standard RAS.

Bronze 3106 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768GB

Bronze 3104 Processor

1.7 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768GB

NOTE:

- 48 lanes PCIe 3.0, standard RAS.

Chipset

Intel C621 Chipset

NOTE: For more information regarding Intel® chipsets, please see the following URL: http://www.intel.com/products/server/chipsets/.

On System Management Chipset

HPE iLO 5 ASIC

NOTE: Read and learn more in the iLO QuickSpecs.

Memory

Type

HPE DDR4 SmartMemory Registered (RDIMM), Load Reduced (LRDIMM)

DIMM Slots Available

12 DIMM slots per processor, 6 channels per processor, 2 DIMMs per channel

Maximum capacity (LRDIMM)

3.0 TB

24 x 128 GB LRDIMM @ 2666 MT/s

Maximum capacity (RDIMM)

768 GB

24 x 32 GB RDIMM @ 2666 MT/s

Maximum capacity (NVDIMM)

192 GB

12 x 16 GB NVDIMM @ 2666 MT/s

NOTE: NVDIMMs can be mixed with RDIMMs only.

NOTE: Mixing of RDIMM and LRDIMM memory is not supported.

Gold Processors: 2 and 4 socket capable, 2S - 2UPI, 4S - 3UPI @ 10.4 GT/s. 6-Channel DDR4 @ 2400 MT/s (SKU 5122 - supports 2666 MT/s). 768 GB max memory capacity (1.5 TB on select skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512 (1x 512-bit FMA) (SKU 5122 - supports 2x

512 bit FMA).

Silver Processors: 2 socket capable, 2S - 2UPI @ 9.6 GT/s. 6-Channel DDR4 @ 2400 MT/s, 768 GB max memory capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512 (1x 512-bit FMA).

Bronze Processors: 2 socket capable, 2S - 2UPI @ 9.6 GT/s. 6-Channel DDR4 @ 2133 MT/s, 768 GB max memory capacity. Intel AVX-512 (1x 512-bit FMA).

NOTE: Maximum memory per socket is dependent on processor selection. Processors supporting 1.5 TB per CPU is indicated by the “M” in the processor model names (i.e. 8160M).

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 8

NOTE: For General Server Memory and NVDIMM Population Rules and Guidelines for Gen10 see details here: http://www.hpe.com/docs/memory-population-rules

Memory Protection

Advanced ECC

Advanced ECC uses single device data correction to detect and correct single and all multibit error

Online Spare

Memory online spare mode detects a rank that is degrading and switches operation to the spare rank.

NOTE: For more information see our Memory RAS feature technical whitepaper.

Expansion Slots

Primary

GPU Riser

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Processor

Slot Form Factor

PCIe 3.0

x16

CPU1

Full-height, 3/4 length (up to 9.5in)

PCIe 3.0

CPU1

Low Profile

Primary

SATA M.2 Riser

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Processor

Slot Form Factor

Primary

NVMe Riser

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Processor

Slot Form Factor

Secondary

Expansion

Technology

Bus

Connector

Processor

Slot Form Factor

Low Profile or

Full-height; 3/4 length (up to 9.5")

NOTE: If secondary full height kit is installed, then primary PCIe Slot #2 cannot be used. Only 2 full height slots are supported.

Storage Controllers

Software RAID

HPE Smart Array S100i SR Gen10 SW RAID

NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an additional

https://downloads.linux.hpe.com/SDR/project/lsrrb/

Essential RAID Controllers

HPE Smart Array E208i-a SR Gen10 Controller

HPE Smart Array E208i-a SR G10 LH Controller

that occurs within a single DRAM chip.

1 PCIe 3.0 x16 x16 CPU 1 Full-height; 3/4 length (up to 9.5in)

2 PCIe 3.0 x16 x16 CPU 1 Low Profile

1 PCIe 3.0 x16 x16 CPU 1 Full-height; 3/4 length (up to 9.5")

2 PCIe 3.0 x8 x8 CPU 1 Low Profile

Riser*

Slots #

3 PCIe 3.0 x16 x16 CPU 2

Width

controller will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.

NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled. NOTE: The S100i is a 14-port SATA controller, but only 12 ports are accessible as 2 are leveraged to support the 2 M.2

options on the Primary Riser.

NOTE: The S100i supports windows only. NOTE: For Linux users, HPE offers a solution that uses in-distro open-source software to create a two-disk RAID 1 boot

volume. For more information visit:

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 9

HPE Smart Array E208i-p SR Gen10 Controller

HPE Smart Array E208e-p SR Gen10 Controller

Performance RAID Controllers

HPE Smart Array P408i-a SR Gen10 Controller

HPE Smart Array P408i-a SR G10 LH Controller

HPE Smart Array P408i-p SR Gen10 Controller

HPE Smart Array P408e-p SR Gen10 Controller

HPE Smart Array P816i-a SR Gen10 Controller

HPE Smart Array P816i-a SR G10 LH Controller

NOTE: If GPGPU is needed then please order the LH controller (low profile heatsink) to allow GPU to fit in the chassis.

NOTE: For additional details, please see HPE Smart Array Gen10 Controllers Data Sheet.

Internal Storage Devices

Optical Drive

Available on 8 SFF and 4 LFF CTO Servers as an option (DVD-ROM or DVD-RW)

Hard Drives

None ship standard

Maximum Storage

STORAGE

CAPACITY

CONFIGURATION

Hot Plug SFF SAS HDD

26.4 TB

8+2+1 x 2.4 TB (with optional UMB + rear drive option)

Hot Plug SFF SATA HDD

22 TB

8+2+1 x 2.0 TB (with optional UMB + rear drive option)

Hot Plug SFF SAS SSD

168.3 TB

8+2+1 x 15.3 TB (with optional UMB + rear drive option)

Hot Plug SFF SATA SSD

42.24 TB

8+2+1 x 3.84 TB (with optional UMB + rear drive option)

Hot Plug SFF NVMe PCIe SSD

40 TB

10 x 4 TB NVMe

Hot Plug LFF SAS HDD

48 TB

4 x 12 TB

Hot Plug LFF SATA HDD

48 TB

4 x 12 TB

Hot Plug LFF SAS SSD

3.2 TB

4 x 800 GB

Hot Plug LFF SATA SSD

6.4 TB

4 x 1.6 TB

Power Supply

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% and 96% efficiency.

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Available in 94% efficiency. NOTE: 1600W Power supplies only support high line voltage (200 VAC to 240 VAC).

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less

NOTE: Also available in -48VDC and 227VAC/380VDC power inputs.

installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.

All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.

To review the power requirements for your selected system, please use the HPE Power Advisor Tool.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 10

For information on power specifications and technical content visit HPE Server power supplies.

Interfaces

Serial

1 port - Optional

Video

1 Front - Display port (optional 8 SFF and 4 LFF only) 1 Rear - VGA port (standard on all chassis types)

NOTE: Both ports are not active simultaneously.

Network Ports

4x 1GbE embedded NIC (standard on all chassis types)

1 FlexibleLOM slot available on all chassis types (supporting various NICs adapters)

iLO Remote Mgmt Port

1 Gb Dedicated

MicroSD Slot

1 MicroSD slot

NOTE: The MicroSD slot is not hot-pluggable, please power down server before removal.

USB 3.0

Up to 5 total: 1 front, 2 rear, 2 internal (standard on all chassis types) +1 optional USB 2.0 front (on 8 SFF and 4 LFF only)

SID (Systems Insight Display)

Optional for all chassis types

NOTE: Will lose iLO Service Port if selecting this option.

Operating Systems and Virtualization Software

Windows Server 2012 R2 (Most Recent Version)

Windows Server 2016 (Most Recent Version)

VMware ESXi 6.0 U3

VMware ESXi 6.5 and U1 upon release

Red Hat Enterprise Linux (RHEL) 6.9 and 7.3

SUSE Linux Enterprise Server (SLES) 11 SP4 and 12 SP2

ClearOS

NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information

on ClearOS, please visit http://www.hpe.com/servers/clearos.

CentOS

NOTE: For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and

http://www.hpe.com/info/ossupport

Industry Standard Compliance

•

Virtualization Software and latest listing of software drivers available for your server.

ACPI 6.1 Compliant

• PCIe 3.0 Compliant

• WOL Support

• Microsoft® Logo certifications

• PXE Support

• USB 3.0 Compliant

• USB 2.0 Compliant (only on optional Universal Media Bay)

• SMBIOS 3.1

• UEFI 2.6 (Unified Extensible Firmware Interface Forum)

• Redfish API

• IPMI 2.0

• Secure Digital 4.0

• TPM 1.2 and 2.0 support

• Advanced Encryption Standard (AES)

Triple Data Encryption Standard (3DES)

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 11

•

NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please visit: http://www.hpe.com/servers/ashrae.

Graphics

Integrated video standard

• 16 MB Video Memory

HPE iLO 5 on system management memory

• 4 Gbit DDR3 with ECC protection

HPE Server UEFI/Legacy ROM

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured

Class 2 implementation and support both UEFI Mode (default) and Legacy BIOS Mode.

NOTE: The UEFI System Utilities tool is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more

ProLiant Gen10 Server.

Embedded Management

HPE Integrated Lights-Out (HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and remote

UEFI

Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI). Learn more at http://www.hpe.com/servers/uefi.

SNMP v3

• TLS 1.2

• DMTF Systems Management Architecture for Server Hardware Command Line (SMASH CLP)

• Active Directory v1.0

• ASHRAE A3/A4

Energy Star

• Video modes up to 1920 x 1200 @ 60 Hz (32 bpp)

• 32 MB Flash

configuration than the legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI

information, please visit http://www.hpe.com/servers/uefi.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot and Secure Start enable for enhanced security

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

• Embedded UEFI Shell

• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant

• PXE boot support for IPv6 networks

• Workload Profiles for simple performance optimization

UEFI Boot Mode only:

• TPM 2.0 Support

• NVMe Boot Support

• Platform Trust Technology (PTT) can be enabled.

• iSCSI Software Initiator Support.

• HTTP/HTTPs Boot support as a PXE alternative.

• Boot support for option cards that only support a UEFI option ROM

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI. NOTE: UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the factory for your HPE

management with HPE iLO. Learn more at http://www.hpe.com/info/ilo.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 12

Intelligent Provisioning

Hassle free server and OS provisioning for one or more servers with Intelligent Provisioning. Learn more at http://www.hpe.com/servers/intelligentprovisioning.

iLO RESTful API

iLO RESTful API is Redfish API conformance and offers simplified server management

standards. Learn more at http://www.hpe.com/info/restfulapi.

Server Utilities

Active Health System

The HPE Active Health System (AHS) is an essential component of the iLO management

at http://www.hpe.com/servers/ahs.

Active Health System

Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed

visit: http://www.hpe.com/servers/ahsv.

Smart Update

Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware and driver updates of the Service Pack for ProLiant (SPP). Learn more at http://www.hpe.com/info/smartupdate.

iLO Amplifier Pack

Designed for large enterprise and service provider environments with hundreds of HPE

http://www.hpe.com/servers/iLOamplifierpack

HPE iLO Mobile Application

Enables the ability to access, deploy, and manage your server anytime from anywhere from

http://www.hpe.com/info/ilo/mobileapp

RESTful Interface Tool

RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API

http://www.hpe.com/info/resttool

Scripting Tools

Provision one to many servers using your own scripts to discover and deploy with Scripting

http://www.hpe.com/servers/stk

http://www.hpe.com/servers/powershell

HPE OneView Standard

HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting

http://www.hpe.com/info/oneview

HPE Systems Insight

Ideal for environments already using HPE SIM, it allows you to monitor the health of your

HPE servers. HPE SIM also integrates with Smart Update Manager to provide quick and

automation such as configuration and maintenance tasks based on modern industry

portfolio that provides continuous, proactive health monitoring of HPE servers. Learn more

Viewer

problem resolution with HPE self-repair recommendations, to learn more

servers, the iLO Amplifier Pack is a free, downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HPE servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more at

select smartphones and mobile devices. For additional information please visit:

to discover and deploy servers at scale. Learn more at

Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at

without additional fees. It can monitor multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-defined functionality is not available. Learn more at

Manager (HPE SIM)

HPE ProLiant Servers and HPE Integrity Servers. Also provides you with basic support for nonseamless firmware updates. Learn more at http://www.hpe.com/info/hpesim.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Standard Features

Page 13

Security

• UEFI Secure Boot and Secure Start support

• Immutable Silicon Root of Trust

• FIPS 140-2 validation (iLO 5 certification in progress)

•

• Configurable for PCI DSS compliance

• Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser

• Support for Commercial National Security Algorithms (CNSA)

• iLO Security Modes including a New iLO Advanced Premium Security License

• Granular control over iLO interfaces

• Smart card (PIV/CAC) and Kerberos based 2-factor Authentication

• Tamper-free updates – components digitally signed and verified

• Secure Recovery – recover critical firmware to known good state on detection of compromised FW

• Ability to rollback firmware

• Secure erase of NAND

• TPM (Trusted Platform Module) 1.2 option

• TPM (Trusted Platform Module) 2.0 option

• Bezel Locking Kit

•

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of HPE

one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response.

at: http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.

Common Criteria certification (iLO 5 certification in progress)

Chassis Intrusion detection option

Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a

Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Optional Features

Page 14

Server Management

HPE iLO Advanced

HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE

http://www.hpe.com/servers/iloadvanced

HPE iLO Advanced Premium

HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus

http://www.hpe.com/servers/ilopremium

HPE OneView Advanced

HPE OneView brings a new level of automation to infrastructure management by taking a

visit http://www.hpe.com/info/oneview.

HPE Insight Cluster

HPE Insight Cluster Management Utility is a HyperScale management framework that

and

infrastructure. Learn more at http://www.hpe.com/info/cmu.

Accelerator and GPGPU Information

Hewlett Packard Enterprise supports various accelerators on select HPE Proliant servers to support different workloads. The

as HPE Insight Cluster Management Utility.

Rack and Power Infrastructure

The story may end with servers, but it starts with the foundation that makes compute go – and business grow. We’ve reinvented

d simpler infrastructure to help you get the most out of your IT equipment. As

Learn more about HPE Racks, KVM, PDUs and UPSs at HPE Rack and Power Infrastructure.

ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and replay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality. Learn more about HPE iLO Advanced at

Security Edition

high-end security modes, unique security capabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanced Premium Security Edition at:

template driven approach to provisioning, updating, and integrating compute, storage, and networking infrastructure. It provides full-featured licenses which can be purchased for managing Gen8, Gen9 and Gen10 servers. To learn more

Management Utility (CMU)

includes software for the centralized provisioning, management and monitoring of nodes

accelerators enable seamless integration of GPU computing with HPE ProLiant servers for high-performance computing, large data center graphics, deep learning and virtual desktop deployments. These accelerators deliver all of the standard benefits of GPU computing while enabling maximum reliability and tight integration with system monitoring and management tools such

our entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In other words, we’ve created a stronger, smarter, an an industry leader, Hewlett Packard Enterprise is uniquely positioned to address the key concerns of power, cooling, cable management and system access.

HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and thermal management, flexible cable management, and a 10 year Warranty to support higher density computing.

HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°, include color-coded outlets and load segments and a low-profile design for optimal access to the rack and support for dense rack environments.

HPE Uninterruptible Power Systems are cost-effective power protection for any type workload. Some UPSs include options for remote management and extended runtime modules so you’re critical dense data center is covered in power outages.

HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a cost-effective KVM switch for your first rack and multiple connection IP switches with remote management and security capabilities to keep your data center rack up and running.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Optional Features

Page 15

One Config Simple (SCE)

SCE is a guided self-service tool to help sales and non-technical people provide customers with initial configurations in 3 to 5

https://h22174.www2.hpe.com/SimplifiedConfig/Welcome#

minutes. You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business Center or an Authorized Partner for assistance.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Service and Support

Page 16

HPE Pointnext - Service and Support

Protect your business beyond warranty with HPE Pointnext Operational Service

HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational

complex simple.

Connect your devices:

Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard Enterprise. Achieve up

http://www.hpe.com/services/getconnected

Recommended Services

HPE Proactive Care* with 6 hour call-to-repair commitment, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care

problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

HPE Proactive Care* with 24x7 coverage, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care

HPE Proactive Care* - Next Business Day service, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care

Services to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational Services focus on designing the transformation and creating a solution roadmap. Professional Services specializes in creative configurations with flawless and on-time implementation, and on-budget execution. Finally, operational services provides innovative new approaches like Flexible Capacity and Datacenter Care, to keep your business at peak performance. HPE is ready to bring together all the pieces of the puzzle for you, with an eye on the future, and make the

to 77%1 reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, pre-failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimization. All of these benefits are already available to you with your server storage and networking products, securely connected to HPE support.

1- IDC 2 – HP CSC reports 2014 – 2015

Learn more about getting connected at

helps prevent This Service combines three years’ proactive reporting and advice with our highest level of hardware support - HPE’s 24x7, six hour hardware call-to-repair. HPE is the only leading manufacturer who makes this level of coverage available as a standard service offering for your most valuable servers. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice This Service combines three years proactive reporting and advice with our 24x7 coverage, four hour hardware response time when there is a problem. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. This service combines three years of Hardware Support where an HPE authorized representative will arrive at the Customer's site during the onsite coverage window to begin hardware maintenance service the next coverage day after the service request has been logged. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

QuickSpecs

HPE ProLiant DL360 Gen10 Server

Service and Support

Page 17

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

*HPE Proactive Care and HPE Proactive Care Advanced require that the customer connect their devices to make the most of

these services and receive all the deliverables.

Parts and Materials

HPE will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in

Other related Services

HPE Server Hardware Installation

Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in

https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf

HPE Installation and Startup Service

Provides for the installation of your HPE hardware according to product specifications including options. The HPE service

type (Windows® or Linux).

HPE Datacenter Care service

HPE Datacenter Care helps improve IT stability and security, increase the value of IT, and enable agility and innovation. It is a

http://www.hpe.com/services/datacentercare

HPE GreenLake Flex Capacity

With HPE GreenLake Flex Capacity, you get the speed, scalability, and economics of the public cloud in the privacy of your data

compliance, and manage the cost of IT. And, you have the option to use the public cloud when needed.

DC for Hyperscale

Datacenter Care for Hyperscale is available for Service Providers and HPC customers who use a scale out approach to

support tailored to their operating model.

HPE Factory Express for Servers and storage

HPE Factory Express offers configuration, customization, integration and deployment services for HPE servers and storage

operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by HPE due to malfunction.

bringing your new hardware into operation in a timely and professional manner.

delivery technician will connect the product to a LAN as appropriate and enable remote support to allow for automatic case creation for hardware failures. Installation and start up services also includes the installation of one supported operating system

structured framework of repeatable, tested, and globally available services “building blocks.” You can deploy, operate, and evolve your datacenter wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with HPE via a single point of accountability for HPE and others’ products. For more information, visit

center. Gain the advantages of the public cloud—consumption-based payment, rapid scalability without worrying about capacity constraints. Reduce the “heavy lifting” needed to operate a data center. And retain the advantages that IT provides the business (i.e., control, security). Deliver the right user experience, choose the right technology for the business, manage privacy and

computing with a high volume homogenous infrastructure and resilient architecture can take advantage of this environment

products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

+ 37 hidden pages
