RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Overview

The HP StorageWorks MSL2024 Tape Library is the ideal entry-level tape library that provides tape library capacity and extensive features in the compact form of a tape autoloader. With compressed capacity (2:1) of up to 38.4 TB using, the MSL2024 can easily tackle backup and recovery jobs typically handled by mid-range tape libraries. Utilizing a 2U form factor, the MSL2024 provides a large amount of data storage without consuming a large amount of valuable rack space. The unique HP web-based management feature reduces the dependencies on local IT resources, allowing multiple sites to be supported centrally. The MSL2024 offers customers the choice of purchasing a library equipped with LTO Ultrium tape drives and either a SCSI, SAS or Fibre Channel interface. Each library includes two removable 12-slot magazines, and one user-configurable mail slot dedicated for import/export of data cartridges. A barcode reader is part of the standard configuration for facilitating media management.

What's New

What's NewWhat's New

Integration of the HP StorageWorks LTO-4 Ultrium 1760 SCSI Tape Drive. IPv6 network protocol support. Libraries can now be connected over both IPv6 and IPv4 networks. Libraries have obtained the IPv6 Ready, Phase-2 logo. Configure library into multiple partitions for maximum flexibility. LTO-4 Ultrium library-enabled encryption to protect your data from unauthorized access. HTTPS support for authenticated and encrypted transfers over the Internet.

Key Features

Key FeaturesKey Features

38.4 TB of compressed storage capacity (2:1) in a 2U form factor HP unique web-based remote management functionality Integrated barcode reader Removable magazines with one user-configurable mail slot Upgradeable from one to two LTO-4 Ultrium 1760, LTO-3 Ultrium 920 or LTO-2 448 tape drives Multiple interface choices available (SCSI, SAS or FC) Easy-to-enable AES 256-bit embedded hardware encryption with compression Customer replaceable components Extensive OS and software compatibility testing Proven high reliability

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 1

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Overview

Customer Benefits

Customer BenefitsCustomer Benefits

Family Comparison

Family ComparisonFamily Comparison

Drive Technology

Drive TechnologyDrive Technology

Number of Drives

Number of DrivesNumber of Drives Capacity

Capacity

CapacityCapacity (compressed 2:1)

(compressed 2:1)

(compressed 2:1)(compressed 2:1) Maximum Data Transfer

Maximum Data Transfer

Maximum Data TransferMaximum Data Transfer (compressed 2:1)

(compressed 2:1)

(compressed 2:1)(compressed 2:1) Drive Interface

Drive Interface

Drive InterfaceDrive Interface

Provides an amazing amount of backup and recovery storage without consuming valuable rack space. Allows a remote administrator to control, configure, monitor and troubleshoot the device, thus relieving the customer of requiring onsite IT resources. Standard bar code reader provides faster inventory times and facilitates tracking of media. Offers single cartridge or bulk loading of media, as well as providing for bulk storage of media off-site. Upgrade the performance of the tape library through the addition of a second LTO-4 Ultrium 1760, LTO-3 Ultrium 920 or LTO-2 Ultrium 448 tape drive. SCSI, SAS and FC interfaces provide options for installing the tape library into a SCSI, SAS or SAN environment. LTO-4 Ultrium configurations provide highest level of encryption security, with compression, for strong backup data privacy to secure confidential information and address compliance quickly. Encryption key management support via HP Data Protector Software and other ISV backup applications. Modular design of tape library allows for quick repair of unit to reduce product downtime. Works with industry-leading servers, operating systems and backup software. Provides reliable backups and automatically changes tapes with a robotics rating of 2 million Mean Swaps Between Failures (MSBF).

MSL2024 LTO-4

MSL2024 LTO-4MSL2024 LTO-4

Ultrium 1840 Tape

Ultrium 1840 TapeUltrium 1840 Tape

Library

LibraryLibrary

LTO-4 Ultrium

1840

38.4 TB 38.4 TB 19.2 TB 19.2 TB

864 GB/hr

4Gb Native Fibre

Channel

Ultra320 LVD SCSI

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

MSL2024 LTO-4

MSL2024 LTO-4MSL2024 LTO-4

Ultrium 1760 Tape

Ultrium 1760 TapeUltrium 1760 Tape

Library

LibraryLibrary

LTO-4 Ultrium

1760

1 or 2

1.152 TB/hr (2 drives)

Ultra320 LVD SCSI

3Gb/sec SAS

MSL2024 LTO-3

MSL2024 LTO-3MSL2024 LTO-3

Ultrium 960 Tape

Ultrium 960 TapeUltrium 960 Tape

Library

LibraryLibrary

LTO-3 Ultrium 960 LTO-3 Ultrium 920 LTO-2 Ultrium 448

576 GB/hr 864 GB/hr

4Gb Native Fibre

Channel

Ultra320 LVD SCSI

MSL2024 LTO-3

MSL2024 LTO-3MSL2024 LTO-3

Ultrium 920 Tape

Ultrium 920 TapeUltrium 920 Tape

Library

LibraryLibrary

1 or 2 1 or 2

(2 drives)

Ultra320 LVD SCSI

3Gb/sec SAS

MSL2024 LTO-2

MSL2024 LTO-2MSL2024 LTO-2

Ultrium 448 Tape

Ultrium 448 TapeUltrium 448 Tape

Library

LibraryLibrary

9.6 TB

345.6 GB/hr (2 drives)

Ultra160 LVD SCSI

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 2

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Product Highlights

Manageability

ManageabilityManageability

Easy Installation

Easy InstallationEasy Installation

The MSL2024 Tape Library allows web-based remote manageability; the unit can be monitored and managed from across the room or across the globe. Functions included in the management tool include:

Status information on the drive and system System configuration operations and reporting System error and status logs Library and drive firmware upgrade capabilities Diagnostic tests and information Cartridge movement for maintenance and management purposes Cleaning cartridge support Security and access control SNMP support for IP communications Partitioning and Encryption management

The MSL2024 Tape Library is shipped as a rack-ready unit. The rack mount hardware included with the library allows installation in a variety of HP racks which include the 10000 series, 9000 series, 5000 series and System/E racks.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Partitioning

PartitioningPartitioning

Proven Reliability

Proven ReliabilityProven Reliability

Data Privacy

Data PrivacyData Privacy

The MSL2024 now includes the ability to be configured as a partitioned library. The MSL2024 may be configured as up to one partition per drive; two partitions if two drives are installed. Partitioning allows each partitioned library to be presented to the host as an independent library, separate from other partitions in the library. Hosts for each partition own independent sets of media and can use ISV software that is different from the other partitions allowing maximum flexibility and utilization of the MSL2024.

With a rating of 2,000,000 robot load/unload cycles, the MSL2024 Tape Library provides necessary high reliability for today's demanding environment. To improve reliability and longevity, all HP Ultrium products feature Data Rate Matching (DRM). This allows the tape drive to dynamically and continuously adjust the speed of the drive, to match the speed of the host or network. This increases performance, reduces mechanical wear on the tape drive and extends tape life.

To greatly enhance data privacy, HP StorageWorks MSL2024 Tape Libraries are now available with LTO-4 Ultrium hardware encrypting tape drives for secure high performance backups meeting consortium specifications for LTO-4. HP Data Protector Software can enable the drive encryption and provide basic key management capabilities. Additional ISV supporting hardware encryption information is available on the HP StorageWorks Enterprise Backup Solution website at www.hp.com/go/ebs. The encryption on LTO-4 media occurs with or without compression, and without speed or capacity penalties. You can read LTO-2 and LTO-3 tapes, and write LTO-3 tapes, but hardware encryption is not supported in these formats.

LTO-4 uses the Advanced Encryption Standard (AES) with the longest and most secure keys -- 256 bits. AES-256 is implemented within Galois Counter Mode (GCM). This is a method of increasing AES security by efficiently adding Message Authentication Codes to ensure the integrity of the backup data stored on tape. The HP LTO-4 Ultrium Tape Drives are designed to be compliant with the emerging standard for tape drive security (IEEE 1619.1).

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 3

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Product Highlights

Encryption

EncryptionEncryption

The HP Secure Advantage portfolio is expanding to include a new offering intended for data protection in small to medium businesses. The HP StorageWorks 1/8 G2 & MSL LTO-4 Encryption Kit provides a library-enabled encryption solution that greatly enhances data privacy, confidentiality, and integrity of your critical business data while supporting compliance requirements. While there are a wide range of encryption solutions available, the HP StorageWorks 1/8 G2 & MSL LTO-4 Encryption Kit is intended to be an easy and affordable library-enabled solution for small businesses.

Protect the confidentiality and integrity of your data: The encryption kit includes two USB key server tokens, product documentation, and firmware support. One encryption kit is needed per library or autoloader and it must be physically accessible so that the USB token can be inserted into the automation device. One of the two tokens will plug into the USB port in the autoloader or library and will generate and maintain encryption keys for the LTO-4 drives/libraries. The USB key server token uses a hardware random number generator, a cryptographic module running on FIPS 140-2 Level 3 validated hardware, password authentication, and digital envelopes for strong encryption keys and security operations. The second USB token is intended to provide a backup to the first. The keys are transferred securely token-to-token for backup or export, with no exposure to insecure PCs, servers, or networks. The encryption kit provides a self-contained solution for MSL libraries with no additional software, PCs, or servers required or involved.

Protect IT resources and meet compliance requirements: With the HP StorageWorks 1/8 G2 & MSL LTO-4 Encryption Kit, users can enable or disable encryption, configure the USB key server tokens, restore encrypted data, as well as a variety of other tasks. In addition, the LTO-4 tape drives use the Advanced Encryption Standard (AES) with the longest and most secure keys -- 256 bits. AES-256 encryption is implemented using the Galois Counter Mode (GCM). This method adds Message Authentication Codes to ensure the integrity as well as privacy of the backup data stored on tape. The HP LTO-4 Ultrium Tape Drives are designed to be compliant with the emerging standard for tape media security (IEEE 1619.1).

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Serviceability

ServiceabilityServiceability

LTO Ultrium Technology

LTO Ultrium TechnologyLTO Ultrium Technology

Modular in construction, the MSL2024 Tape Library has easily replaceable components minimizing the Mean-Time-to-Repair on the unit. Replaceable components include the tape drive, the magazines, and the chassis (includes robotics, power supply, and controller board). HP StorageWorks Library and Tape Tools (L&TT) provides easy access to the MSL2024 error log, generates support tickets, and enables firmware downloads. L&TT can be downloaded for free at:

HP StorageWorks LTO (Linear Tape Open) Ultrium Tape Drives use best of breed technology. By taking the best features from other tape technologies and combining them into a single new technology, Ultrium tape drives are in a league of their own. Inclusion of innovative features such as Adaptive Tape Speed (ATS) ensure that Ultrium drives can meet the performance and reliability demands of a library environment. LTO technology is an open industry standard format; thus data written on HP StorageWorks Ultrium Tape Drives can be interchanged directly with Ultrium Tape Drives from other vendors.

http://www.hp.com/support/tapetools

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 4

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Product Highlights

Data Rate Matching

Data Rate MatchingData Rate Matching

HP Ultrium WORM

HP Ultrium WORMHP Ultrium WORM

Data Rate Matching combines sophisticated buffer management with The HP exclusive variable Adaptive Tape Speed technology, to allow the tape drive to match its transfer rate to the host speed dynamically and continuously across the wide range of transfer rates. This feature ensures that the tape drive continues to stream data regardless of the environment, and brings three big advantages:

It optimizes performance and maximizes overall efficiency, allowing the drive to respond immediately to any speed changes from the host It minimizes rewinding and repositioning of the tape, significantly reducing physical wear and increasing reliability It minimizes the power requirements for the drive by reducing the number of repositions needed

LTO Ultrium Tape Drive

LTO Ultrium Tape DriveLTO Ultrium Tape Drive HP LTO-4 Ultrium 1840 HP LTO-4 Ultrium 1760 HP LTO-3 Ultrium 960 HP LTO-3 Ultrium 920 HP LTO-2 Ultrium 448

Critical to the success of data retention policies in highly regulated environments is the ability to store and manage data in an unalterable state. Following stringent guidelines set forth by regulatory agencies such as the SEC and HIPPA, IT organizations must now integrate new solutions and policies that can verify the integrity of stored data for periods that can extend well beyond seven years.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

ATS data transfer rate range (native)

ATS data transfer rate range (native)ATS data transfer rate range (native) 40 to 120 MB/s 27 to 80 MB/s 35 to 80 MB/s 26 to 60 MB/s 10 to 24 MB/s

The LTO-4 Ultrium and LTO-3 Ultrium tape drives feature the ability to archive and store data in a nonrewriteable format that meets the most stringent regulatory guidelines. Using a combination of integrated fail-safe features in the drive firmware, cartridge memory, and tape formatting, the tape drives can archive large amounts of data for periods of up to 30 years in a secure, untampered state. Since all LTO-4 Ultrium and LTO-3 Ultrium tape drives include support for both rewritable and WORM media, IT organizations can now easily integrate a secure, long-term archiving solution into their current data protection strategy. As compared to other technologies that feature support for WORM storage, the tape drives offers the advantages of:

A single drive to support all backup and archiving needs Two distinctive tape cartridges to easily distinguish and manage both rewriteable and WORM data cartridges A specially designed WORM data cartridge with multiple integrated fail-safe features to prevent accidental or intentional overwriting of data High-capacity, low-cost HP WORM media that can store 1.6 TB (2:1 compression) of data on a single data cartridge Support from many backup and archiving software vendors, providing the most comprehensive and mainstream support in the industry The LTO open standard that offers greater choice and compatibility across all third- and fourthgeneration Ultrium products

NOTE:

While all HP LTO-4 Ultrium and LTO-3 Ultrium tape drives support LTO Ultrium WORM media,

NOTE:NOTE: some third- and fourth-generation LTO Ultrium tape drives from other manufacturers may not include read and write support for LTO Ultrium WORM media. For non-HP third- and fourth-generation LTO Ultrium tape drives, please check the manufacturers' specifications to ensure this support is provided if you are using your WORM media. If WORM support is not provided, the drive will eject the WORM tape cartridge immediately upon insertion into to the tape drive.

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 5

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Product Highlights

HP StorageWorks Library

HP StorageWorks LibraryHP StorageWorks Library and Tape Tools

and Tape Tools

and Tape Toolsand Tape Tools

HP Storage Media

HP Storage MediaHP Storage Media

The MSL2024 Tape Library is supported on the HP industry-leading diagnostic tool - HP StorageWorks Library and Tape Tools (L&TT). L&TT is a single, convenient program that is easy to install and simple to operate. L&TT's intuitive user interface eliminates the need for training and deploys in less than five minutes. This robust diagnostic tool is designed for both the experienced professional and the untrained administrator. It ensures product integrity through self-diagnostics and fast resolution to device concerns. Additional information on L&TT plus download information can be found at:

http://www.hp.com/support/tapetools

HP recommends that you use HP-branded cartridges in the MSL2024 Tape Library to assure the highest level of protection for your valuable data. The test program for HP media is the most thorough and comprehensive in the industry.

All HP cartridges must satisfy an exhaustive battery of additional tests that relate directly to real life situations, where real data and real businesses are at stake. The benefit of the HP brand specification for media is consistent quality. Through the testing of thousands of HP drives and HP cartridges, the ideal formulation for backup performance is defined and then continuously monitored. This hugely resourceintensive process is unique to HP and affords deep insight into the HP+HP backup solution for a wide range of environments and duty cycles. Your best choice for ease of support and maximum dependability is to use HP-branded Ultrium cartridges at all times.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Factory Express Portfolio

Factory Express PortfolioFactory Express Portfolio for Servers and Storage

for Servers and Storage

for Servers and Storagefor Servers and Storage

HP strongly encourages the use of bar code labels on tapes to track media and ensure optimum library performance and usability. Correctly labeling your media will allow the library to quickly determine media and drive compatibility.

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed. Customization must comply with all relevant product specifications and factory supported configurations. Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, and HP 9000 servers as well as MSA, VA7xxx, EVA, and XP disk arrays, rackable tape libraries and configurable network switches.

Type of service support varies by platform and product family. For more information on Factory Express services for your specific server model or storage device please contact your sales representative or go to:

http://www.hp.com/go/factory-express

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 6

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Compatibility

The HP extensive compatibility testing program assures that your HP StorageWorks MSL2024 Tape Library works with leading servers, operating systems, and backup applications - and not just those sold by HP. The MSL2024 works seamlessly in many environments, making them especially suitable if you have a mixed system environment. For the latest list of servers, workstations, operating systems, and backup software that support the MSL2024, check the HP StorageWorks Enterprise Backup Solution compatibility matrix at:

Server Compatibility

Server CompatibilityServer Compatibility

OS Support

OS SupportOS Support

Software Support

Software SupportSoftware Support

http://www.hp.com/go/ebs

The MSL2024 is supported on a wide range of HP systems. For details of which MSL2024 works with which systems, including third-party systems, reference the EBS compatibility matrix at:

http://www.hp.com/go/ebs

Reference the EBS compatibility matrix for the most up-to-date OS compatibility information at:

http://www.hp.com/go/ebs

Reference the EBS compatibility matrix for the most up-to-date software compatibility information at:

http://www.hp.com/go/ebs

for the latest hardware compatibility information.

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 7

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Service and Support, HP Care Pack, and Warranty Information

Warranty

WarrantyWarranty

Warranty Upgrade

Warranty UpgradeWarranty Upgrade Options

Options

OptionsOptions

HP Care Pack Information

HP Care Pack InformationHP Care Pack Information

The warranty for this product consists of 1-year parts exchange, next business day.

Response - Upgrade on-site response from next business day to same day 4-hours Coverage - Extend hours of coverage from 5 days x 9 hours to 7 days x 24 hours Duration - Select duration of coverage for a minimum period of 1 year or multiple years

HP Care Pack is defined as an upgrade to the product warranty attribute, available for a specific duration and hours of coverage.

HP Care Pack is not available for less than the products warranty duration. HP Care Pack is available for sale anytime during the warranty period for most products, but the commencement date will be the same as the warranty start date (delivery date to end user customer). Proof of purchase may be required. HP Care Pack services are prepaid.

For additional HP Care Pack (hardware & software) information, as well as orderable part numbers, please refer to the URL

http://www.hp.com/hps/carepack/

Hardware Product

Hardware ProductHardware Product Services

Services

ServicesServices

eSupport

eSupporteSupport

Installation services On-site Maintenance (includes warranty support) Response time upgrades during the warranty period Post-warranty coverage RAID setup and performance consulting via statement of work

For additional hardware installation and maintenance information, please refer to the URL listed below:

http://www.hp.com/hps/hardware/

HP eSupport is a portfolio of technology-based services that assist you with managing your business environment - from the desktop to the data center.

Support Portal The HP support portal provides one-stop access to the information, tools and services you need to manage the daily operations of your IT environment.

Features include:

Access to self-solve tools (including search technical knowledge base) Efficient logging and tracking of support cases Collaboration with other business and IT professionals Download of patches and drivers Access to diagnostic tools Proactive notification of relevant information

Access to certain features of the support portal requires an HP service agreement. To access the support portal, visit

http://www.hp.com/support

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 8

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Service and Support, HP Care Pack, and Warranty Information

Support Services

Support ServicesSupport Services

Components

ComponentsComponents

HP Services provides up to a three-year, limited warranty, fully supported by a worldwide network of resellers and service providers and 9x5 hardware technical phone support during the warranty period. In addition, available service offerings include a full range of optional packaged hardware and software services:

Installation and start up Extended coverage hours and enhanced response times System management and performance services Availability and recovery services

The following brick level options/components do not have individual HP Care Pack Services. These items will be included in product HP Care Pack Services into which they are installed.

Disk Drives Bus Converters

Tape Drives Backplane RAID

Controllers

CD/DVD ROM Power Supplies

SCSI Hubs in SBBs Cabling

Adapters Fans

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 9

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Configuration Information

NOTE:

The HP StorageWorks MSL2024 Tape Library comes standard as a one or two drive, 24-slot unit which is shipped rack-

NOTE:NOTE: ready; a racking kit is included in the box. Each library includes a US power cord (C13, 10A) and PDU power cord (C13/C14, 10A). For additional or specific regional power cord requirements, a separate power cord must be ordered.

Step 1 – Base Configuration

Step 1 – Base ConfigurationStep 1 – Base Configuration

Select one:

Select one:Select one: Model Name

Model Name

Model NameModel Name HP StorageWorks

HP StorageWorks

HP StorageWorksHP StorageWorks MSL2024 Tape Library

MSL2024 Tape Library

MSL2024 Tape LibraryMSL2024 Tape Library

Model Description

Model DescriptionModel Description HP MSL2024 1 LTO-4 Ultrium 1840 FC Tape Library HP MSL2024 1 LTO-4 Ultrium 1840 SCSI Tape Library HP MSL2024 1 LTO-4 Ultrium 1760 SAS Tape Library HP MSL2024 1 LTO-4 Ultrium 1760 SCSI Tape Library HP MSL2024 1 LTO-3 Ultrium 960 FC Tape Library HP MLS2024 1 LTO-3 Ultrium 960 SCSI Tape Library HP MSL2024 1 LTO-3 Ultrium 920 SAS Tape Library AH559A HP MSL2024 1 LTO-3 Ultrium 920 SCSI Tape Library HP MSL2024 2 LTO-3 Ultrium 920 SCSI Tape Library HP MSL2024 1 LTO-2 Ultrium 448 SCSI Tape Library HP MSL2024 0-drive, 24 Slot Tape Library

NOTE:

NOTE: NOTE:

Kit Contents

Kit ContentsKit Contents

For channel configuration in EMEA only.

(for each library):

Part Number

Part NumberPart Number

AJ034A AJ033A

AK378A

AJ817A

AG326B

AG115A

AH169A AH170A

AG116A

AK379A

SCSI Models:

SCSI Models:SCSI Models:

One 1.83M US Power Cord, C13, 10A One 2.5M PDU Power Cord, C13/C14, 10A One 6 ft VHDCI to HDTS68 SCSI cable per tape drive One .5M LVD HDTS to LVD HDTS daisy chain cable (2 drive LTO-2 Ultrium 448 configuration only) One HDTS68 SCSI terminator per SCSI tape drive One RJ-45 Ethernet cable Rack mount hardware Documentation kit including User & Service Guide (CD) and Getting Started Poster

SAS Model:

SAS Model:SAS Model:

One 1.83M US Power Cord, C13, 10A One 2.5M PDU Power Cord, C13/C14, 10A One RJ-45 Ethernet cable Rack mount hardware Documentation kit including User & Service Guide (CD) and Getting Started Poster

Fibre Channel Models:

Fibre Channel Models:Fibre Channel Models:

One 1.83M US Power Cord, C13, 10A One 2.5M PDU Power Cord, C13/C14, 10A One RJ-45 Ethernet cable Rack mount hardware Documentation kit including User & Service Guide (CD) and Getting Started Poster

0-Drive Models

0-Drive Models0-Drive Models

One 1.83M US Power Cord, C13, 10A One 2.5M PDU Power Cord, C13/C14, 10A One RJ-45 Ethernet cable

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 10

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Configuration Information

Rack mount hardware Documentation kit including User & Service Guide (CD) and Getting Started Poster

Step 2 – Required Options

Step 2 – Required OptionsStep 2 – Required Options

Select each required option with quantities specified:

Select each required option with quantities specified:Select each required option with quantities specified: Power Cord

Power Cord

Power CordPower Cord

Description

DescriptionDescription Power Cord, US, C13, 10A, 1.83m

NOTE:

NOTE: NOTE: can be used to connect the rack-mounted device to PDUs with NEMA 5-15R receptacles.

PDU Power Cord, C13/C14, 10A, 2.5m

NOTE:

NOTE: NOTE: can be used to connect the rack-mounted device to PDUs with IEC320 receptacles.

Power Cord, Euro, C13, 10A, 1.83m Power Cord, UK, C13, 10A, 1.83m Power Cord, Danish, C13, 10A, 1.83m Power Cord, Swiss, C13, 10A, 1.83m Power Cord, Italian, C13, 10A, 1.83m Power Cord, South Africa, C13, 10A, 2.5m Power Cord, Taiwan, C13, 12A, 1.83m Power Cord, China, C13, 10A 1.83m Power Cord, Japan, C13, 12A, 2.0m Power Cord, Australia, C13, 10A, 2.5m Power Cord, Argentina, C13, 10A, 2.5m Power Cord, Brazil, C13, 10A, 1.83m Power Cord, Korea, C13, 10A, 1.83m Power Cord, Israel, C13, 10A, 1.83m Power Cord, India, C13, 10A, 2.0m

NOTE:

NOTE:NOTE: WARNING:

WARNING:

WARNING:WARNING: geographic region. Use of a non-HP approved power cord may result in: 1) not meeting individual country specific safety requirements; 2) insufficient conductor amperage that could result in overheating with potential personal injury and/or property damage; and 3) an unapproved power cord could fracture resulting in the internal contacts being exposed, which potentially could subject the user to a shock hazard. HP disclaims all liability in the event a non-HP approved power cord is used.

This cord ships standard with each MSL2024 Tape Library;

One power cord is required; please select the correct power cord for your geographical location.

This product can ONLY be used with an HP approved power cord for your specific

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Quantity

QuantityQuantity

1 each

1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each 1 each

Part Number

Part NumberPart Number

AF556A

142257-002

AF568A AF570A AF566A AF565A AF571A AF567A AF561A AF557A AF572A AF569A AF558A AF559A AF560A AF564A AF562A

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 11

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Related Options

Factory Racking

Factory RackingFactory Racking

Tape Drives

Tape DrivesTape Drives

Factory integrate the MSL2024 Tape Library with other HP products such as HP ProLiant Servers.

NOTE:

NOTE: NOTE: order if HP factory integration is indicated.

HP MSL2024/4048 LTO-2 Ultrium 448 SCSI Drive Upgrade Kit

NOTE:

For use with the MSL2024 LTO-2 Ultrium 448 Drive Library; maximum of two

NOTE:NOTE: LTO-2 Ultrium 448 SCSI drives per MSL2024 Tape Library. Drive kit includes a tape drive, SCSI cable, SCSI terminator, and documentation.

HP MSL2024/4048 LTO-3 Ultrium 920 SCSI Drive Upgrade Kit

NOTE:

For use with the MSL2024 LTO-3 Ultrium 920 Drive Library; maximum of two

NOTE:NOTE: LTO-3 Ultrium 920 SCSI drives per MSL2024 Tape Library. Drive kit includes a tape drive, SCSI cable, SCSI terminator, and documentation.

HP MSL2024/4048/8096 LTO-3 Ultrium 920 SAS Drive Upgrade Kit

NOTE:

NOTE: NOTE: two LTO-3 Ultrium 920 SAS drives per MSL2024 Tape Library. Drive kit includes a tape drive and documentation.

HP MSL2024/4048/8096 LTO-3 Ultrium 960 SCSI Drive Upgrade Kit

NOTE:

For use with the MSL2024 Tape Library to upgrade to LTO-3 Ultrium 960

NOTE:NOTE: SCSI tape technology; maximum of one LTO-3 Ultrium 960 SCSI drive per MSL2024 Tape Library. Drive kit includes a tape drive, SCSI cable, SCSI terminator, and documentation.

HP MSL2024/4048/8096 LTO-3 Ultrium 960 4Gb FC Drive Upgrade Kit

NOTE:

For use with the MSL2024 Tape Library to upgrade to LTO-3 Ultrium 960

NOTE:NOTE: 4Gb FC tape technology; maximum of one LTO-3 Ultrium 960 4Gb FC drive per MSL2024 Tape Library. Drive kit includes a tape drive and documentation.

HP MSL2024/4048 LTO-4 Ultrium 1760 SCSI Drive Upgrade Kit

NOTE:

NOTE: NOTE: tape technology; maximum of two LTO-4 Ultrium 1760 SCSI drives per MSL2024 Tape Library. Drive kit includes a tape drive, SCSI cable, SCSI terminator, and documentation.

HP MSL2024/4048/8096 LTO-4 Ultrium 1760 SAS Drive Upgrade Kit

NOTE:

NOTE: NOTE: tape technology; maximum of two LTO-4 Ultrium 1760 SAS drives per MSL2024 Tape Library. Drive kit includes a tape drive and documentation.

HP MSL2024/4048/8096 LTO-4 Ultrium 1840 SCSI Drive Upgrade Kit

NOTE:

For use with the MSL2024 Tape Library to upgrade to LTO-4 Ultrium 1840

NOTE:NOTE: tape technology; maximum of one LTO-4 Ultrium 1840 drive per MSL2024 Tape Library. Drive kit includes a tape drive, SCSI cable, SCSI terminator, and documentation.

HP MSL2024/4048/8096 LTO-4 Ultrium 1840 4Gb FC Drive Upgrade Kit

NOTE:

For use with the MSL2024 Tape Library to upgrade to LTO-4 Ultrium 1840

NOTE:NOTE: 4Gb FC tape technology; maximum of one LTO-4 Ultrium 1840 4Gb FC drive per MSL2024 Tape Library. Drive kit includes a tape drive and documentation.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

#0D1 will appear after the MSL2024 Tape Library part number on the sales

For use with the MSL2024 LTO-3 Ultrium 920 SAS Drive Library; maximum of

For use with the MSL2024 Tape Library to upgrade to LTO-4 Ultrium 1760

#0D1

AG118A

AH173A

AH562A

AG327A

AG328B

AJ819A

AK383A

AJ041A

AJ042A

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 12

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Related Options

Magazine Kits

Magazine KitsMagazine Kits

Rack-to-Tabletop

Rack-to-TabletopRack-to-Tabletop Conversion Kit

Conversion Kit

Conversion KitConversion Kit

Fibre Connectivity

Fibre ConnectivityFibre Connectivity

Encryption

EncryptionEncryption

HP MSL2024 Ultrium Left Magazine Kit

NOTE:

NOTE: NOTE: which includes an import/export slot.

HP MSL2024/4048/8096 Ultrium Right Magazine Kit

NOTE:

For use only on the right side of the MSL2024; additional 12-slot magazine.

NOTE:NOTE:

HP MSL2024 Rack-to-Tabletop Conversion Kit

NOTE:

For use in converting the rack-ready MSL2024 Tape Library into a tabletop

NOTE:NOTE: model.

HP N1200-320 4Gb Network Storage Router

NOTE:

For use in connecting a MSL2024 SCSI Tape Library to a SAN; reference the

NOTE:NOTE: EBS compatibility matrix for the most up-to-date configuration information at:

http://www.hp.com/go/ebs

HP 1/8 G2 & MSL Tape Library LTO-4 Encryption Kit

NOTE:

For use with new or installed LTO-4 Ultrium 1/8 G2 Tape Autoloaders and

NOTE:NOTE: MSL2024/4048/8096 Tape Libraries. The encryption token will generate and retain encryption keys for HP LTO-4 Ultrium tape drives in the autoloader or library.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

For use only on the left side of the MSL2024; additional 12-slot magazine

AG119A

AG120A

AG121A

AG314A

AM495A

Host Bus Adapters

Host Bus AdaptersHost Bus Adapters

Cable Kits

Cable KitsCable Kits

HP SC44Ge Host Bus Adapter

NOTE:

Serial-attached SCSI (SAS) HBA that enables HP StorageWorks MSL Tape

NOTE:NOTE: Libraries to connect with HP ProLiant servers.

HP U320e SCSI Host Bus Adapter

NOTE:

Dual channel PCI-Express (PCI-e) SCSI Ultra320 HBA that enables HP

NOTE:NOTE: StorageWorks MSL Tape Libraries to connect with HP ProLiant servers.

Reference the EBS compatibility matrix for the most up-to-date HBA compatibility information at:

6 ft VHDCI/HDTS68 SCSI Cable Kit 12 ft VHDCI/HDTS68 SCSI Cable Kit

0.5m HDTS68/HDTS68 Daisy Chain Cable Kit

NOTE:

NOTE: NOTE: configuration.

2m External Infiniband (SFF8470) to 4 Mini SAS (SFF8088) 1x SAS Cable Kit

NOTE:

NOTE:NOTE:

2m External Mini-SAS to 4x1 Mini-SAS Cable Kit

NOTE:

NOTE: NOTE:

4m External Mini-SAS to 4x1 Mini-SAS Cable Kit

NOTE:

NOTE: NOTE:

2m SW LC/SC FC Cable Kit 5m SW LC/SC FC Cable Kit 15m SW LC/SC FC Cable Kit 2m SW LC/LC FC Cable Kit

This cable ships standard with every MSL2024 2 drive LTO-2 Ultrium 448

One cable is required for every four drives.

http://www.hp.com/go/ebs

416096-B21

AH627A

341176-B21 341177-B21

C2978B

AH587A

AN975A

AN976A

221691-B21 221691-B22 221691-B23 221692-B21

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 13

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Related Options

5m SW LC/LC FC Cable Kit 15m SW LC/LC FC Cable Kit

Rack Cabinets

Rack CabinetsRack Cabinets

10622 (22U) Universal Rack Cabinet - Shock Pallet 10636 (36U) Universal Rack Cabinet - Shock Pallet 10636 (36U) Universal Rack Cabinet with extension - Shock Pallet 10642 (42U) Universal Rack Cabinet - Shock Pallet 10642 (42U) Universal Rack Cabinet with extension - Shock Pallet

NOTE:

NOTE: NOTE: include a shock pallet. It is mandatory to use a shock pallet in order to ship racks with equipment installed.

5642 (42U) Rack Cabinet

NOTE:

NOTE: NOTE: industry standard 19" wide rack with side panels and rear doors; it does not ship with the front door or casters.

NOTE:

For additional HP ProLiant rack information, visit:

NOTE:NOTE:

http://h18004.www1.hp.com/products/servers/proliantstorage/racks/index.html

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

The MSL2024 Tape Library is certified to ship in HP 10000 series racks which

This rack ships unassembled and boxed on a standard size pallet. It is an

221692-B22 221692-B23

AF022A AF012A AF014A AF002A AF004A

358254-B21

Media

MediaMedia

HP LTO4 Ultrium 1.6TB RW Data Cartridge (1 pack) HP LTO4 Ultrium 1.6TB WORM Data Cartridge (1 pack) HP Ultrium 800GB RW Data Cartridge (1 pack) HP Ultrium 800GB WORM Data Cartridge (1 pack) HP Ultrium 400GB Data Cartridge (1 pack) HP Ultrium 200GB Data Cartridge (1 pack) HP Ultrium Universal Cleaning Cartridge (1 pack) HP LTO4 Ultrium RW Bar Code Labels (100 pack) HP LTO4 Ultrium WORM Bar Code Labels (100 pack) HP Ultrium 3 RW Bar Code Labels (100 pack) HP Ultrium 3 WORM Bar Code Labels (100 pack) HP Ultrium 2 Bar Code Labels (100 pack) HP Ultrium 1 Bar Code Labels (100 pack) Non-Custom Labeled Data Cartridges

Non-Custom Labeled Data Cartridges

Non-Custom Labeled Data CartridgesNon-Custom Labeled Data Cartridges

NOTE:

Non-Custom labels will come pre-labeled with a pre-determined number

NOTE:NOTE: sequence

HP LTO4 Ultrium 1.6TB RW Non-Custom Labeled Data Cartridge (20 pack) HP Ultrium 800GB RW Non-Custom Labeled Data Cartridge (20 pack) HP Ultrium 400GB Non-Custom Labeled Data Cartridge (20 pack) HP Ultrium 200GB Non-Custom Labeled Data Cartridge (20 pack) Custom Labeled Data Cartridges

Custom Labeled Data Cartridges

Custom Labeled Data CartridgesCustom Labeled Data Cartridges

NOTE:

Custom labeled products allow customers to customize a specific sequence

NOTE:NOTE: printed on each label.

HP LTO4 Ultrium 1.6TB RW Custom Labeled Data Cartridge (20 pack) HP LTO4 Ultrium 1.6TB WORM Custom Labeled Data Cartridge (20 pack)

C7974A

C7974W

C7973A

C7973W

C7972A C7971A

C7978A Q2009A Q2010A Q2007A Q2008A Q2002A Q2001A

C7974AN C7973AN C7972AN C7971AN

C7974AL

C7974WL

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 14

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Related Options

HP Ultrium 800GB RW Custom Labeled Data Cartridge (20 pack) HP Ultrium 800GB WORM Custom Labeled Data Cartridge (20 pack) HP Ultrium 400GB Custom Labeled Data Cartridge (20 pack) HP Ultrium 200GB Custom Labeled Data Cartridge (20 pack) Storage Media Kits

Storage Media Kits

Storage Media KitsStorage Media Kits

NOTE:

Kit includes 20 data cartridges, one cleaning cartridge, 20 colored labels, a

NOTE:NOTE: protective carrying case that can be used to securely store or transport data cartridges, one copy of "The Essentials of Successful Tape Backup," and one copy of HP StorageWorks Data Protector Express Evaluation Software (60 day free trial).

HP Ultrium 800GB Storage Media Kit HP Ultrium 400GB Storage Media Kit HP Ultrium 200GB Storage Media Kit

HP Care Pack Options

HP Care Pack OptionsHP Care Pack Options

Same Day Response

Same Day ResponseSame Day Response Warranty upgrade to 1-year, 13x5, 4 hour response/onsite, electronic Warranty upgrade to 1-year, 24x7, 4 hour response/onsite, electronic Warranty upgrade to 1-year, 24x7, call-to-repair, 6 hour response/onsite, electronic Warranty upgrade to 3-year, 13x5, 4 hour response/onsite, electronic Warranty upgrade to 3-year, 24x7, 4 hour response/onsite, electronic Warranty upgrade to 3-year, 24x7, call-to-repair, 6 hour response/onsite, electronic Warranty upgrade to 4-year, 13x5, 4 hour response/onsite, electronic Warranty upgrade to 4-year, 24x7, 4 hour response/onsite, electronic Warranty upgrade to 5-year, 13x5, 4 hour response/onsite, electronic Warranty upgrade to 5-year, 24x7, 4 hour response/onsite, electronic Next Business Day Response

Next Business Day Response

Next Business Day ResponseNext Business Day Response Warranty upgrade to 1-year next business day/onsite, electronic Warranty upgrade to 3-year next business day/parts exchange, electronic Warranty upgrade to 3-year next business day/onsite, electronic Hardware Services

Hardware Services

Hardware ServicesHardware Services Installation services, electronic SAN installation & startup service, electronic

NOTE:

NOTE: NOTE: ownership, Hewlett-Packard recommends the 3-year, 24 x 7 service options. These offerings will ensure that any product issue can be tackled when they occur (most back up issues will occur outside standard business hours) and that the service coverage regarding period, covers the minimum expected life of the host system.

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

In order to maximize ROI and product uptime, and minimize the cost of

C7973AL

C7973WL

C7972AL C7971AL

C8017A

C8014A

C8013A

UE290E UE291E UE292E UE295E UE296E UE308E UE298E UE299E UE300E UE301E

UE289E UE293E UE294E

U4823E UA871E

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 15

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

Technical Specifications

Drive Technology

Drive TechnologyDrive Technology

Number of Drives

Number of DrivesNumber of Drives Number of Slots

Number of Slots

Number of SlotsNumber of Slots Drive Interface

Drive Interface

Drive InterfaceDrive Interface

Capacity

CapacityCapacity

Maximum

MaximumMaximum Transfer

Transfer

TransferTransfer Rate

Rate

RateRate

Dimensions

DimensionsDimensions

Weight

WeightWeight

Reliability

ReliabilityReliability

Cartridge Swap Time

Cartridge Swap TimeCartridge Swap Time Initialization Time

Initialization Time

Initialization TimeInitialization Time Inventory Time

Inventory Time

Inventory TimeInventory Time Connectors

Connectors

ConnectorsConnectors

Native

NativeNative Compressed

Compressed

CompressedCompressed (2:1)

(2:1)

(2:1)(2:1) Native

Native

NativeNative

Compressed

CompressedCompressed (2:1)

(2:1)

(2:1)(2:1)

MSL2024 LTO-4

MSL2024 LTO-4MSL2024 LTO-4

Ultrium 1840

Ultrium 1840Ultrium 1840

LTO-4 Ultrium

1840

4Gb Native Fibre

Channel

Ultra320 LVD SCSI

19.2 TB 19.2 TB

38.4 TB 38.4 TB 19.2 TB 19.2 TB

432 GB/hr 288 GB/hr

864 GB/hr 576 GB/hr

Out-of-Box (HxWxD) Shipping (HxWxD) Out-of-Box Shipping MSBF (mean swaps

between failures) MTBF (mean time between

failures) 45 sec (drive to slot, slot to drive) 65 to 80 seconds 1:20 minutes (using bar code labeled cartridges) Mini-SAS (located on back of MSL2024 SAS models only)

68-pin HDTS (located on back of MSL2024 SCSI models only) LC Optical Fibre (located on back of MSL2024 FC model only)

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

MSL2024 LTO-4

MSL2024 LTO-4MSL2024 LTO-4

Ultrium 1760

Ultrium 1760Ultrium 1760

LTO-4 Ultrium

1760

24 24 24 24 24

1 or 2

3Gb/sec SAS

Ultra320 LVD SCSI

(1 drive)

576 GB/hr

(2 drives)

(1 drive)

1.152 TB/hr (2 drives)

3.4 x 18.9 x 31.7 in (8.7 x 48 x 80.6 cm)

10.7 x 23.2 x 38.9 in (27.1 x 58.9 x 98.7 cm)

32.9 lb (14.9 kg)

56.9 lb (25.8 kg) 2 Million robot load/unload cycles

100,000 hours (based on 1M MSBF)

MSL2024 LTO-3

MSL2024 LTO-3MSL2024 LTO-3

Ultrium 960

Ultrium 960Ultrium 960

LTO-3 Ultrium 960 LTO-3 Ultrium 920 LTO-2 Ultrium 448

4Gb Native Fibre

Channel

Ultra320 LVD SCSI

9.6 TB 9.6 TB 4.8 TB

288 GB/hr 216 GB/hr

576 GB/hr 432 GB/hr

MSL2024 LTO-3

MSL2024 LTO-3MSL2024 LTO-3

Ultrium 920

Ultrium 920Ultrium 920

1 or 2 1 or 2

3Gb/sec SAS

Ultra320 LVD SCSI

(1 drive)

432 GB/hr

(2 drives)

(1 drive)

864 GB/hr

(2 drives)

MSL2024 LTO-2

MSL2024 LTO-2MSL2024 LTO-2

Ultrium 448

Ultrium 448Ultrium 448

Ultra160 LVD SCSI

9.6 TB

86.4 GB/hr (1 drive)

172.8 GB/hr (2 drives)

172.8 GB/hr

(1 drive)

345.6 GB/hr (2 drives)

LED Indicators

LED IndicatorsLED Indicators (on front panel)

Management Interface

Management InterfaceManagement Interface Power

Power

PowerPower Input Requirements

Input Requirements

Input RequirementsInput Requirements

(1) RJ-45 (located on back of MSL2024) (1) USB port (located on back of MSL2024)

Ready LED (Green): shows ready status information Clean LED (Amber): shows fault status information Attention LED (Amber): shows fault status information Error LED (Amber): shows fault status information

10/100 Mbytes/second, auto-configuring interface. RJ-45 connection. Https configurable. 168 Watts (max) 100 to 240 VAC, 50 to 60 Hz, 1.3 to 0.7 Amperes

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 16

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

QuickSpecs

HP StorageWorks MSL2024 Tape Library

HP StorageWorks MSL2024 Tape LibraryHP StorageWorks MSL2024 Tape Library

Technical Specifications

Relative Humidity

Relative HumidityRelative Humidity (non-condensing)

Temperature Range

Temperature RangeTemperature Range (wet bulb)

Altitude

AltitudeAltitude

The information contained herein is subject to change without notice.

The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.

For tape drives and media, 1 GB = 1 billion bytes. Actual formatted capacity is less.

Operating Shipping Operating Shipping

NOTE:

Library operating temperature limits are based on the industry standard tape limit.

NOTE:NOTE:

Operating Shipping

20% to 80% 20% to 90% 50° to 95° F (10° to 35° C)

-22° to 140° F (-30° to 60° C)

15,000 ft (4,575 m) 35,000 ft (10,675 m)

DA - 12383 Worldwide — Version 27 — November 14, 2008

Page 17

HPE M9A07A Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
