QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 1

HPE ProLiant DL380 Gen10 Server

Adaptable for diverse workloads and environments, the secure 2P 2U HPE ProLiant DL380 Gen10 delivers world-class performance with the right balance of backed by a comprehensive warranty make it ideal for multiple environments from Containers to Cloud to Big Data. Standardize on the industry’s most trusted compute platform.

Front View – SFF chassis with optional Universal Media bay with optical and 2 NVME plus 16 NVMe shown

Quick removal access panel

10.

UID button

Optional Universal Media bay. 2 USB 2.0 and Display port standard (8 SFF bay or 6 SFF+2NVMe or 8NVMe optional)

11.

iLO Front Service Port

Optional Optical drive. Requires Universal Media bay

12.

USB 3.0

Optional 2 SFF HDD, requires optional Universal Media bay

13.

Serial label pull tag

Drive Bay 2. NVMe shown (8 SFF, 6SFF+2NVMe or 8 NVMe PCIe SSD optional)

14.

Box 3

8 SFF Drive Cage Bay

15.

Box 2

Power On/Standby button and system power LED button

16.

Box 1

Health LED

17.

Optional front display port (Via Universal Media Bay)

NIC status

18.

Optional USB 2.0 (via Universal Media Bay)

expandability and scalability. Designed for supreme versatility and resiliency while being

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 2

Front View – 8LFF chassis with Universal media bay and optional 2SFF and optical drive shown

UID button

iLO Front Service Port

Health LED

Serial label pull tag

NIC status

Optional optical drive shown (blank as standard)

Power On/Standby button and system power LED button

Optional 2 SFF Drive bay, 2 NVMe shown

Front display port

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 3

Internal View 8SFF chassis – with optional 2nd CPU, FlexLOM, Smart array shown

Fan cage shown with 6 standard Hot-plug fans (High Performance temperature fans optional)

9..

(Under) Hot Plug redundant HPE Flexible Slot Power supplies

2 Processors, heatsink showing

10.

Connection for second (optional) riser (Requires second CPU)

Optional HPE Smart Hybrid Capacitor or HPE Smart Storage Battery

11.

Embedded 4x1Gbe NIC (if equipped)1

DDR4 DIMM slots. Shown fully populated in 24 slots (12 per processor)

12.

Primary PCIe riser, standard (Optional double wide GPU riser)

MicroSD card slot (Optional Dual Micro-SD option)

13.

FlexibleLOM slot (Optional, depending on model selected)

Internal USB 3.0 connector

14.

X4 SATA ports (1, 2 and 3)

Chassis intrusion detection connector

15.

Clear air baffle

Optional HPE Smart Array (P408i-a shown)Clear air baffle

Notes:

Order (BTO) models; Configure networking adapters NIC adapters. See “FlexibleLOM Adapters” and/or “HPE Networking” sections for available options.

Networking Choice (NC) models do not include an embedded NIC and have a FlexibleLOM pre-selected for Build-to-

-to-Order (CTO) models require a primary networking choice of FlexibleLOM or select

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 4

Rear View – With optional FlexLOM, Rear drives and Serial port shown.

Primary Riser. PCI Slots (Slots 1-3 top to bottom, riser shipped standard, not shown), optional 2SFF rear drives

Power supply Power LED

Secondary Riser. PCI Slots (Slots 4-6top to bottom, not shown, requires second riser card, and second processor). Showing optional 2 SFF rear

10.

HPE Flexible Slot Power Supply bay 2 (800W shown)

Optional serial port

11.

VGA connector

Tertiary Riser (Slots 7-8). Optional rear 2 SFF HDD (supported in 24 SFF or 12 LFF front end)

12.

Embedded 4 x 1GbE Network Adapter (if equipped) 1

Power supply Power connection

13.

Dedicated iLO management port

Power supply Power LED

14.

USB connectors 3.0 (2)

HPE Flexible Slot Power Supply bay 1 (800W shown)

15.

Unit ID LED

Power supply Power connection

16.

FlexibleLOM ports (4 x 1GbE shown); optional, depending on model

Notes:

Order (BTO) models; networking adapters NIC adapters. See “FlexibleLOM Adapters” and/or “HPE Networking” sections for available options.

What’s New:

https://www.hpe.com/us/en/about/environment/msds-specs-more.html

• New HPE NVIDIA Tesla V100S PCIe 32GB

• Additional primary networking choices for HPE ProLiant DL380 Gen10 Networking Choice (NC) Configure-to-Order

• New LFF SAS Mixed-Use SSD (800GB/960GB/1.92TB)

• New LFF SATA Mixed-Use SSD (480GB/1.92TB)

• New LFF SAS HDD 7.2K (2TB)

• New SFF QLC-NAND SATA Very Read-Optimized SSD (1.92TB/3.84TB/7.68TB)

• New SFF SATA Mixed-Use SSD (480GB/960GB/1.92TB/3.84TB)

• New SFF SATA Read-Intensive SSD (240GB/480GB/960GB/1.92TB/3.84TB/7.68TB)

• New SFF NVMe Read-Intensive SSD (960GB/1.92TB/3.84TB/7.68TB)

• New SFF SAS Write-Intesive SSD (400GB/800GB/1.6TB)

• New SFF SAS Read-Intensive SSD (960GB/1.92TB/3.84TB/7.68TB/15.3TB)

• New M.2 2280 SATA Read-Intensive SSD (240GB/480GB/960GB)

• New UFF SCM M.2 Dual Read-Intensive SSD (2x240GB/2x480GB)

• European Union (EU) Lot 9 regulation. For more information please visit:

Networking Choice (NC) models do not include an embedded NIC and have a FlexibleLOM pre-selected for Build-to-

Configure-to-Order (CTO) models require a primary networking choice of FlexibleLOM or select

(CTO) Chassis. In addition to FlexibleLOMs, select stand-up card networking options noted in “HPE Networking” section, add flexibility in the primary networking choice when configuring a DL380 Gen10 NC CTO Chassis.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Overview

Page 5

Platform Information

Form Factor

Chassis Types

Notes:

System Fans

Notes:

- High performance fan kits are required for rear drives, Graphics (GPU) card or NVMe configurations.

• 2U rack

• 8 SFF with optional Universal Media Bay, and optional SFF or NVMe drive bay options

• 24 SFF bay with additional 6SFF rear drive bay option to total 30 SFF drives

• 8 LFF with Universal Media Bay

• 12 LFF with optional 4 LFF mid-plane and optional 3LFF + 2 SFF rear drive bay to total 19 LFF drives + 2 SFF drives

The 3 LFF rear drive box will consume space for the secondary and tertiary riser. The 8 and 12 LFF chassis also supports the 2 SFF rear drive box which allows for the user to attach a secondary or tertiary

riser.

The 8 NVMe drive option (826689-B21) can only be leveraged in the SFF chassis and replaces Box 1, 2 or 3, however there

is a maximum of 20 NVMe drives supported with Partial population of Box 1.

The Premium cage (826690-B21, 6 SAS/SATA+2 NVMe) can only be leveraged in the SFF chassis and replaces Box 1, 2 or

The Universal Media Bay (826708-B21) not available with the LFF chassis or the 24 SFF front end, and can only be

populated in Box 1.

The 8 SFF can be upgraded with additional 8SFF drive box to total 16 or 24 SFF drives. For optimal upgrade Box 2 should

be populated second, with Box 1 the last to be populated for a field upgrade to 24 SFF. For CTO builds requiring 24 SFF please use the 24 SFF chassis (868704-B21). Note a field upgrade to 24 SFF will require a High Performance fan kit (867810-B21).

The 8 LFF chassis cannot be upgraded to 12 LFF front in the field; however the 4-LFF Mid plane (826686-B21) is

supported, but will also require a performance fan kit (867810-B21).

The 8LFF chassis ships with 6-standard fans. All models come with the S100i Smart Array Controller with embedded software RAID support for 12 drives. The S100i

uses 14 embedded SATA ports, but only 12 ports are accessible as 2 are leveraged to support the 2 M.2 options on the primary riser.

• Standard – fan types included

1P models typically ship with 4 standard fans. The second processor option kit contains 2 additional fans. 1P Models have

(4) (N+1 redundancy standard).

2P models typically ship with 6 standard fans. 2P Models have (6) (N+1 redundancy standard). The 12 LFF and 24 SFF chassis ship with 6 High performance fans as standard. The 8LFF chassis ships with 6 standard fans as standard. High performance fan kit is available to meet ambient temperature environments.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard

Features

Page 6

Processors

This table covers the public Intel offering only.

Intel Xeon processors

Processor Suffix

Description

Offering

Large memory tier

Up to 4.5 TB addressable memory per socket

Medium memory tier

Up to 2.0 TB addressable memory per socket (up to 1.5TB for 1st

suffix)

NFV Optimized

Targeted at Network Function Virtualization (NFV) workloads. Intel®

details to be provided in upcoming documentation.

Search Optimized

Optimized base frequency to address ‘search’ workloads. Other

upcoming documentation.

1 Socket Optimized

Focused on single socket (1P) configurations, delivering performance

arrangements.

VM Optimized

Fosters enhanced VM density, allowing to support more/largervirtual machines per host.

Speed Select

Intel® SST-PP increases base frequency when fewer cores are

longevity.

Notes:More than 1.5 TB memory per socket requires memory higher than 128 GB capacity

2nd Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU Frequency

Cores

L3 Cache (MB)

Power

UPI

DDR4

Memory per socket

Platinum 8280M Processor

2.7GHz

38.5

205W

3 @ 10.4 GT/s

2933 MT/s

2TB

Platinum 8280L Processor

2.7GHz

38.5

205W

3 @ 10.4 GT/s

2933 MT/s

4.5TB

Platinum 8280 Processor

2.7GHz

38.5

205W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8276M Processor

2.2GHz

38.5

165W

3 @ 10.4 GT/s

2933 MT/s

2TB

Platinum 8276L Processor

2.2GHz

38.5

165W

3 @ 10.4 GT/s

2933 MT/s

4.5TB

Platinum 8276 Processor

2.2GHz

38.5

165W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8270 Processor

2.7GHz

35.75

205W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8268 Processor

2.9GHz

35.75

205W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8260Y Processor

2.4/2.5 /2.7GHz

24/20/16

35.75

165W

3 @ 10.4 GT/s

2933 MT/s

1TB Platinum 8260M Processor

2.4GHz

35.75

165W

3 @ 10.4 GT/s

2933 MT/s

2TB

Platinum 8260L Processor

2.4GHz

35.75

165W

3 @ 10.4 GT/s

2933 MT/s

4.5TB

Platinum 8260 Processor

2.4GHz

35.75

165W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8256 Processor

3.8 GHz

16.5

105W

3 @ 10.4 GT/s

2933 MT/s

1TB

Platinum 8253 Processor

2.2GHz

125W

3 @ 10.4 GT/s

2933 MT/s

1TB

– Up to 2 of the following depending on model. The 2nd digit of the processor model number “x1xx” and “x2xx” is used to denote the processor generation (i.e. 1=1st generation and 2=2nd generation)

Notes:Field upgrades from 1st generation processors (x1xx) to 2nd generation processors (x2xx) not supported. “U” processors (i.e. 6212U) only supported in single socket configurations

For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon

generation Intel Xeon Scalable Processors denoted with the “M”

SST-BF improves performance by directing base frequency to high priority/bottleneck cores. Other workloads may see throttling, more

workloads may see throttling, more details to be provided in

at competitive price points. Does not support two socket (2P)

enabled. Allows greater flexibility, deployment options and platform

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 7

Notes:

Channel DDR4 @ 2933 MT/s providing up to 1TB memory capacity

heatsink. All other will processors will ship with the Standard heatsink.

1st Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU

Cores

L3 Cache

Power

UPI

DDR4

Memory per

Platinum 8180M Processor

2.5 GHz

38.5

205W

3 @ 10.4 GT/s

2666 MT/s

1.5TB

Platinum 8180 Processor

2.5 GHz

38.5

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8176 Processor

2.1 GHz

38.5

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8170 Processor

2.1 GHz

35.75

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8168 Processor

2.7 GHz

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8165 Processor

2.3 GHz

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8164 Processor

2.0 GHz

35.75

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8160 Processor

2.1 GHz

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8158 Processor

3.0 GHz

24.75

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8156 Processor

3.6 GHz

16.5

105W

3 @ 10.4 GT/s

2666 MT/s

768GB

Platinum 8153 Processor

2.0 GHz

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

heatsink. All other will processors will ship with the Standard heatsink.

2nd Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU

Cores

L3 Cache

Power

UPI

DDR4

Memory per

Gold 6262V Processor

1.9GHz

135W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6258R Processor

2.7GHz

38.5

205W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6256 Processor4

3.6GHz

205W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6254 Processor

3.1GHz

24.75

200W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6252N Processor

2.3GHz

35.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6252 Processor

2.1GHz

35.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6250 Processor4

3.9GHz

35.75

185W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6248R Processor

3.0GHz

35.75

205W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6248 Processor

2.5GHz

27.5

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6246R Processor

3.4GHz

35.75

205W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6246 Processor

3.3GHz

24.75

165W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6244 Processor

3.6GHz

24.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6242R Processor

3.1GHz

35.75

205W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6242 Processor

2.8GHz

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6240Y Processor

2.6/2.8/

3.1 GHz

18/14/8

24.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB Gold 6240M Processor

2.6GHz

24.75

150W

3 @ 10.4 GT/s

2933MT/s

2TB

- Platinum – 8200 Series – 2 Socket supports supports 6-

per socket (up to 2TB/socket on M series and up to 4.5TB/socket on L series); HPE Persistent Memory featuring Intel® Optane™ DC persistent memory (select skus), Vector Neural Network Instructions (VNNI) for inference acceleration, Intel Turbo Boost Technology, Intel Hyper-Threading Technology Intel AVX-512 (2x 512-bit FMA). 48 lanes PCIe 3.0, advanced RAS

- Processors with 130W TDP or higher and the 8256, 8156, 6128, 5222, and 5122 will ship with the High Performance

Frequency

(MB)

socket

Notes:

- Platinum – 8100 Series –2 Socket supports 2UPI, supports 6-Channel DDR4 @ 2666 MT/s providing up to 768GB memory

capacity (1.5 TB on select processor skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology supported. Intel AVX-512 (2x 512-bit FMA), 48 lanes PCIe 3.0, advanced RAS.

- Processors with 130W TDP or higher and the 8256, 8156, 6128, 5222, and 5122 will ship with the High Performance

Frequency

(MB)

(TDP)

socket

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 8

Gold 6240L Processor

2.6GHz

24.75

150W

3 @ 10.4 GT/s

2933MT/s

4.5TB

Gold 6240R Processor

2.4GHz

35.75

165W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6240 Processor

2.6GHz

24.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6238R Processor

2.2GHz

38.5

165W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6238M Processor

2.1GHz

30.25

140W

3 @ 10.4 GT/s

2933MT/s

2TB

Gold 6238L Processor

2.1GHz

30.25

140W

3 @ 10.4 GT/s

2933MT/s

4.5TB

Gold 6238 Processor

2.1GHz

30.25

140W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6234 Processor

3.3GHz

24.75

130W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6230R Processor

2.1GHz

35.75

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6230N Processor

2.3GHz

27.5

125W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6230 Processor

2.1GHz

27.5

125W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6226R Processor

2.9GHz

150W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6226 Processor

2.7GHz

19.25

125W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6222V Processor

1.8GHz

27.5

115W

3 @ 10.4 GT/s

2933MT/s

1TB

Gold 6212U Processor

2.4GHz

35.75

165W

2933MT/s

1TB

Gold 6210U Processor

2.5GHz

27.5

150W

2933MT/s

1TB

Gold 6209U Processor

2.1GHz

27.5

125W

2933MT/s

1TB

Gold 6208U Processor

2.9GHz

150W

2933MT/s

1TB

Gold 5222 Processor1

3.8GHz

16.5

105W

2 @ 10.4 GT/s

2933MT/s

1TB

Gold 5220S Processor

2.7GHz

24.75

125W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5220R Processor

2.2GHz

35.75

150W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5220 Processor

2.2GHz

24.75

125W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5218R Processor

2.1GHz

27.5

125W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5218N Processor3

2.3GHz

110W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5218B Processor 2

2.3GHz

125W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5218 Processor

2.3GHz

125W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5217 Processor

3.0GHz

115W

2 @ 10.4 GT/s

2666MT/s

1TB

Gold 5215M Processor

2.5GHz

13.75

85W

2 @ 10.4 GT/s

2666MT/s

2TB

Gold 5215L Processor

2.5GHz

13.75

85W

2 @ 10.4 GT/s

2666MT/s

4.5TB

Gold 5215 Processor

2.5GHz

13.75

85W

2 @ 10.4 GT/s

2666MT/s

1TB

Configuration support and facilities-requirements matrix for Gold Processor 6256 and Gold Processor 6250 listed below:

Notes:

Gold Processor 5222 supports 2933 DDR4 and 2 512-bit FMA units

Gold Processor 5218B has consistent features with the 5218 processor but is from a different die. Mixing both 5218B &

5218 in a system is not supported

Gold Processor 5218N processor available April 2019, Intel® Speed Select Technology-Base Frequency enablement via

System ROM upgrade targeting June 2019

- Processors with 130W TDP or higher and the 8256, 8156, 6128, 5222, and 5122 will ship with the High Performance

heatsink. All other processors will ship with the Standard heatsink.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 9

Intel Xeon Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix

DL380 Gen10

6250 (3.9GHz/8c/185W)

6256 (3.6GHz/12c/205W)

High Perf. fans

Mandatory

NVMe SSDs

Not supported

Rear 2SFF

Not supported

GPUs

Not supported

4LFF mid-tray

Not supported

Max inlet temp.

Without DIMM blanks

With DIMM blanks kit1

Without DIMM blanks

With DIMM blanks kit1

8SFF

Up to 30°C / 86°F

Up to 35°C / 95°F1

Up to 30°C / 86°F

Up to 35°C / 95°F1

16SFF + front 2SFF

Up to 25°C / 77°F

Up to 30°C / 86°F1

Up to 30°C / 86°F

Up to 35°C / 95°F1

16SFF + 8NVMe

Not Supported

24SFF

Up to 25°C / 77°F

Up to 30°C / 86°F1

Up to 30°C / 86°F

Up to 35°C / 95°F1

24SFF + rear SFF

Not Supported

8LFF

Up to 25°C / 77°F

Up to 30°C / 86°F1

Up to 30°C / 86°F

Up to 35°C / 95°F1

12LFF

Up to 20°C / 68°F

Up to 25°C / 77°F1

Up to 20°C / 68°F

Up to 25°C / 77°F1

12LFF + rear 2SFF

Not Supported

Notes:

1st Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU

Cores

L3 Cache

Power

UPI

DDR4

Memory

Gold 6154 Processor

3.0 GHz

24.75

200W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6152 Processor

2.1 GHz

30.25

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6150 Processor

2.7 GHz

24.75

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6148 Processor

2.4 GHz

27.5

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6146 Processor

3.2 GHz

24.75

165W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6144 Processor

3.5 GHz

24.75

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6143 Processor

2.8 GHz

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6142 Processor

2.6 GHz

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6140 Processor

2.3 GHz

24.75

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6138 Processor

2.0 GHz

27.5

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6137 Processor

3.9 GHz

24.75

205W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6136 Processor

3.0 GHz

24.75

150W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6134M Processor

3.2 GHz

24.75

130W

3 @ 10.4 GT/s

2666 MT/s

1.5TB

Gold 6134 Processor

3.2 GHz

24.75

130W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6132 Processor

2.6 GHz

19.25

140W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6130 Processor

2.1 GHz

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6128 Processor

3.4 GHz

19.25

115W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 6126 Processor

2.6 GHz

19.25

125W

3 @ 10.4 GT/s

2666 MT/s

768GB

Gold 5122 Processor

3.6 GHz

16.5

105W

2 @ 10.4 GT/s

2666 MT/s

768GB

Gold 5120 Processor

2.2 GHz

19.25

105W

2 @ 10.4 GT/s

2400 MT/s

768GB

Gold 5118 Processor

2.3 GHz

16.5

105W

2 @ 10.4 GT/s

2400 MT/s

768GB

Gold 5117 processor

2.0 GHz

19.25

105W

2 @ 10.4 GT/s

2400 MT/s

768GB

Gold 5115 Processor

2.4 GHz

13.75

85W

2 @ 10.4 GT/s

2400 MT/s

768GB

skus), Vector Neural Network Instructions (VNNI) for inference acceleration.

Must install DDR4 DIMM blanks (P07818-B21) on all empty DIMM slots

Frequency

(MB)

per socket

Notes:

- Gold - 6200 & 5200 Series - 6-Channel DDR4 @ 2933 MT/s (6200 & 5222 skus only) or 2666 MT/s (all Gold 5200 skus

except 5222 @ 2933 MT/s); providing up to 1TB memory capacity per socket (up to 2TB/socket on M series and up to

4.5TB/socket on L series); Support for HPE Persistent Memory featuring Intel® Optane™ DC persistent memory (select

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 10

- Intel Turbo Boost Technology, Intel Hyper-Threading Technology Intel AVX-512 (2x 512-bit FMA for 6200 series and

heatsink. All other will processors will ship with the Standard heatsink.

2nd Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU Frequency

Cores

L3 Cache (MB)

Power

UPI

DDR4

Memory per socket

Silver 4216 Processor

2.1GHz

100W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4215R Processor4

3.2GHz

130W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4215 Processor4

2.5GHz

85W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4214R Processor

2.4GHz

16.5

100W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4214Y Processor

2.2/2.3/2.4 GHz

12/10/8

16.5

85W

2 @ 9.6 GT/s

2400 MT/s

1TB Silver 4214 Processor

2.2GHz

16.5

85W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4210R Processor

2.4GHz

10-core

13.75

100W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4210 Processor

2.2GHz

13.75

85W

2 @ 9.6 GT/s

2400 MT/s

1TB

Silver 4208 Processor

2.1GHz

85W

2 @ 9.6 GT/s

2400 MT/s

1TB

1st Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU Frequency

Cores

L3 Cache (MB)

Power

UPI

DDR4

Memory per socket

Silver 4116 Processor

2.1 GHz

16.50 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4114 Processor

2.2 GHz

13.75 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4112 Processor

2.6 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4110 Processor

2.1 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Silver 4108 Processor

1.8 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

768GB

Threading

3.0, standard RAS supported.

2nd Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU Frequency

Cores

L3 Cache (MB)

Power

UPI

DDR4

Memory per socket

Bronze 3206R Processor

1.9GHz

85W

2 @ 9.6 GT/s

2133MT/s

1TB

Bronze 3204 Processor

1.9GHz

8.25

85W

2 @ 9.6 GT/s

2133MT/s

1TB

3.0, standard RAS

5222; 1 x 512-bit FMA for 5200 series, except for 5222) 48 lanes PCIe 3.0, advanced RAS

- Gold – 5100, 6100 Series - 2 Socket supports 2UPI, supports 6-Channel DDR4 @ 2400 MHz (SKU 5122=supports 2666)

providing up to 768GB memory capacity (1.5 TB on select skus). Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA) (SKU 5122 supports 2x 512 bit FMA), 48 lanes PCIe 3.0, advanced RAS supported.

- Processors with 130W TDP or higher and the 8256, 8156, 6128, 5222, and 5122 will ship with the High Performance

Notes:

Silver Processors 4215R and 4215 support HPE Persistent Memory featuring Intel® Optane™ DC persistent memory

Notes:

- Silver – 4200 Series - 6-Channel DDR4 @ 2400 MT/s, providing up to 1TB memory capacity per socket; Support for: Intel®

Vector Neural Network Instructions (VNNI) for inference acceleration; Intel Turbo Boost Technology, Intel HyperTechnology Intel AVX-512 (1x 512-bit FMA).48 lanes PCIe 3.0, standard RAS

- Silver – 4100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, 6-Channel DDR4 @ 2400 MHz providing up to 768 GB memory

capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA), 48 lanes PCIe

Notes:Bronze – 3200 Series - 6-Channel DDR4 @ 2133 MT/s, providing up to 1TB memory capacity per socket; Support for: Intel® Vector Neural Network Instructions (VNNI) for inference acceleration; Intel AVX-512 (1x 512-bit FMA); 48 lanes PCIe

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 11

1st Generation Intel® Xeon® Scalable Processor Family

Intel Xeon Models

CPU Frequency

Cores

L3 Cache (MB)

Power

UPI

DDR4

Memory per socket

Bronze 3106 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768GB

Bronze 3104 Processor

1.7 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2133 MT/s

768GB

768GB memory capacity. Intel AVX-512(1x 512-bit FMA), 48 lanes PCIe 3.0, standard RAS supported.

Chipset

For more information regarding Intel® chipsets, please see the following URL: http://www.intel.com/products/server/chipsets/

On System Management Chipset

iLO QuickSpecs

Memory

One of the following depending on model

Type

HPE DDR4 SmartMemory,

DIMM Slots Available

12 DIMM slots per processor, 6 channels per processor, 2 DIMMs per channel

Maximum capacity (LRDIMM)

3.0 TB

Maximum capacity (RDIMM)

1.54 TB

Maximum capacity (HPE Persistent Memory)

6.0 TB

Maximum capacity (NVDIMM)

192 GB

generation processors supporting 2 TB or 4.5 TB per

- For additional information, please see the HPE DDR4 SmartMemory QuickSpecs.

Memory Protection

Notes:Bronze – 3100 Series - 2 Socket supports 2UPI @ 9.6 GT/s, supports 6-Channel DDR4 @ 2133 MHz providing up to

Intel C621 Chipset

HPE iLO 5 ASIC Read and learn more in the

Notes:

- HPE Persistent Memory featuring Intel® Optane™ DC persistent memory only supported with select 2nd generation Intel

Xeon Scalable Series Processors ONLY ((82xx/62xx/52xx/4215) and can only be mixed with either RDIMMs or LRDIMMs.

- NVDIMMs are only supported on 1st generation Intel Xeon Scalable Series Processors and can only be mixed with RDIMMs.

- Maximum memory per socket is dependent on processor selection. 2

CPU are indicated by the “M” and “L” in the processor model names (i.e. 8276M and 8276L). 1st generation processors supporting 1.5 TB per CPU are indicated by the “M” in the processor model names (ie 8160M)

- Maximum memory per socket is dependent on processor selection. Processors supporting 1.5 TB per CPU is indicated by

the “M” in the processor model names (i.e. 8160M).

- Mixing of RDIMM and LRDIMM memory is not supported.

- For General Server Memory and NVDIMM Population Rules and Guidelines for Gen10 see details here:

http://www.hpe.com/docs/memory-population-rules

- For details on the HPE Server Memory speed, visit: https://www.hpe.com/docs/memory-speed-table

- To realize the performance memory capabilities listed in this document, HPE DDR4 SmartMemory is required.

Registered (RDIMM), Load Reduced (LRDIMM)

24 x 128 GB LRDIMM @ 2933 MT/s

24 x 64 GB RDIMM @ 2933 MT/s

12 X 512 GB Memory Modules @ 2666 MT/s

12 x 16 GB NVDIMM @ 2666 MT/s

For details on the HPE Server Memory Options RAS feature, visit: http://www.hpe.com/docs/memory-ras-feature.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 12

Expansion Slots

Primary Riser

Slots #

Technology

Bus Width

Connector Width

Slot Form Factor

Notes

PCIe 3.0

Full-height, full-length slot

Proc 1

PCIe 3.0

X16

Full-height, full-length slot

Proc 1

PCIe 3.0

Full-height, half-length slot

Proc 1

Riser options and specifications noted in the “Riser Information” table within this document.

Secondary Riser

Slots #

Technology

Bus Width

Connector Width

Slot Form Factor

Notes

PCIe 3.0

Full-height, full-length slot

Proc 2

PCIe 3.0

X16

Full-height, full-length slot

Proc 2

PCIe 3.0

Full-height, half-length slot

Proc 2

options and specifications noted in the “Riser Information” table within this document.

Tertiary Riser

Slots #

Technology

Bus Width

Connector Width

Slot Form Factor

Notes

PCIe 3.0

Full-height, full-length slot

Proc 2

PCIe 3.0

Full-height, full-length slot

Proc 2

specifications noted in the “Riser Information” table within this document

Graphics

• 4 Gbit DDR 3 with ECC protection

Notes:

- Bus Width Indicates the number of physical electrical lanes running to the connector.

- The specifications above correspond with the default primary riser which also supports dual m.2 cards. Additional Primary

Notes:

- Bus Width Indicates the number of physical electrical lanes running to the connector.

- The Secondary Riser requires Processor 2 to be populated 870548-B21

- The specifications above correspond with the x8/x16/x8 Secondary Riser Kit (870548-B21). Additional Secondary Riser

Notes:

- Bus Width Indicates the number of physical electrical lanes running to the connector.

- The Tertiary Riser requires Processor 2 to be populated

- The specifications above correspond with the 2x8 Tertiary Riser Kit (875780-B21). Additional Tertiary Riser options and

Integrated Video Standard

HPE iLO 5 on system management memory

• Video modes up to 1920 x 1200@60Hz (32 bpp)

• 16MB Video Memory

• 32 MB Flash

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 13

Maximum Internal Storage

Drive

Capacity

Configuration

Hot Plug SFF SAS HDD

72.0 TB

24+6 x 2.4 TB* (with optional rear SFF drive cage)

Hot Plug SFF SATA HDD

60.0 TB

24+6 x 2 TB (with optional SFF drive cage)

Hot Plug LFF SAS HDD

311.68 TB

12+4+3 x 16 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive

Hot Plug LFF SATA HDD

311.68 TB

12+4+3 x 16 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug SFF SAS SSD

459 TB

24+6 x 15.3 TB (with optional rear SFF drive cage)

Hot Plug SFF SATA SSD

115.2 TB

24+6 x 3.84 TB (with optional rear SFF drive cage)

Hot Plug LFF SATA SSD

80.64 TB

12+4+3 x 3.84 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug LFF SAS SSD

44.16 TB

12+4+3 x 1.92 TB + 2 x 3.84 TB (with optional mid –tray and rear LFF drive cage, plus 2 SFF SSD rear)

Hot Plug SFF NVMe PCIe SSD

153.6 TB

20 x 7.68 TB NVMe

- UFF drives are also supported.

Power Supply

HPE Server power supplies.

Internal Storage Devices

None ship standard

cage, plus 2 SFF SSD rear)

Notes:

- 2x m.2 drives are supported on the Primary Riser.

• HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Notes:Available in 94% efficiency.

• HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Notes:

- Available in 94% and 96% efficiency.

- Also available in -48VDC and 227VAC/380VDC power inputs.

• HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Notes:1 papailable in 94% efficiency.

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.

All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page. o review the power requirements for your selected system, please use the HPE Power Advisor Tool. For information on power specifications and technical content visit

One of the following depending on model

• Optical Drive

Ships standard in Performance Models Optional: DVD-ROM, DVD-RW

• Hard Drives

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 14

Storage Controllers

Interfaces

Serial

Optional, rear

Display Port

1 (SFF 1 front, optional via Universal Media Bay, 826708-B21), 8 LFF chassis standard

Network Ports

4 x 1GbE embedded (if equipped/depending on model)

HPE iLO Remote Management Network Port

1 Gb Dedicated

Front iLO Service Port

1 standard (Not available on 12 LFF chassis or when SID is ordered, note iLO dongle required, 880123-B21)

Micro SD Slot

1 Micro SD

an SD card into the SD slot while the server is powered.

USB 3.0

Up to 5 total: 1 front, 2 rear, 2 internal (secure), 2 optional USB 2.0 front via Universal Media Bay, or standard on 8LFF chassis

SID

Optional

B21).

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet One of the following depending on model

Software RAID

• HPE Smart Array S100i SR Gen10 SW RAID

Notes:

- HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an additional

controller will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.

- HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled.

- The S100i uses 14 embedded SATA ports, but only 12 ports are accessible as 2 are leveraged to support the 2 M.2

options on the primary riser.

- The S100i supports windows only

- For Linux users, HPE offers a solution that uses in-distro open-source software to create a two-disk RAID 1 boot

volume. For more information visit: https://downloads.linux.hpe.com/SDR/project/lsrrb/

Essential RAID Controller

• HPE Smart Array E208i-a SR Gen10 Controller

• HPE Smart Array E208i-p SR Gen10 Controller

• HPE Smart Array E208e-p SR Gen10 Controller

Performance RAID Controller

• HPE Smart Array P408i-a SR Gen10 Controller

• HPE Smart Array P408i-p SR Gen10 Controller

• HPE Smart Array P408e-p SR Gen10 Controller

• HPE Smart Array P816i-a SR Gen10 Controller

Notes:

- Performance RAID Controllers require the HPE Smart Hybrid Capacitor (P02377-B21) or the HPE Smart Storage

Battery (P01366-B21) which are sold separately. For additional details, please see HPE Smart Array Gen10 Controllers Data Sheet

One (1) FlexibleLOM slot available on all chassis types (supporting various NIC adapters)

Notes:The Micro SD slot is not a hot-pluggable device. Customers should not attempt to plug

(Systems Insight Display)

Notes:Not shipping as standard. Available as a CTO option or as a field upgrade (826703-

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 15

UEFI Boot Mode only:

ProLiant Gen10 Server.

Operating Systems and Virtualization Software Support for ProLiant Servers

Software and latest listing of software drivers available for your server http://www.hpe.com/info/ossupport

• TPM 2.0 Support

• iSCSI Software Initiator Support.

• NVMe Boot Support

• HTTP/HTTPs Boot support as a PXE alternative.

• Platform Trust Technology (PTT) can be enabled.

• Boot support for option cards that only support a UEFI option ROM

Notes:

- For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI.

- UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the factory for your HPE

2nd Generation Intel® Xeon® Scalable Processor Family

• Windows Server 2019: Essentials, Standard, Datacenter

• Windows Server 2016: Essentials, Standard, Datacenter

• Windows Server 2012 R2: Essentials, Standard, Datacenter

• Microsoft Hyper-V Server: 2012 R2, 2016 & 2019

• VMware vSphere 6.0 U3, 6.5 U2 & 6.7 U1

• ClearOS: 7.6 & 8.0

• Red Hat Enterprise Linux (RHEL) 7.6 w/ Kbase & 8 **

• SUSE Linux Enterprise Server (SLES) 12 SP3, SP4 and 15 SP1 (includes Xen) **

1st Generation Intel® Xeon® Scalable Processor Family

• Windows Server 2019: Essentials, Standard & Datacenter

• Windows Server 2016 : Essentials, Standard & Datacenter

• Windows Server 2012 R2: Essentials, Standard & Datacenter

• Micrsoft Hyper-V Server: 2012 R2, 2016 & 2019

• VMware vSphere 6.0 U3, 6.5 & 6.7

• ClearVM: 2.0

• Red Hat Enterprise Linux (RHEL) 6.9, 7.3 w/ Errata, & 8 **

• SUSE Linux Enterprise Server (SLES) 11 SP4, 12 SP2 & 15 (includes Xen) **

Notes:** 64-bit only;includes KVM

• ClearOS

Hewlett Packard Enterprise and ClearCenter will help you lower the cost of building on-premise solutions without sacrificing security and ease of use. HPE ProLiant servers with ClearOS give you a simple, secure, and affordable operating system with an intuitive web based graphical user interface that provides a cloud-like experience on- premise, and an Application Marketplace with over 100 apps and growing. Whether you’re starting out or scaling, you decide what applications you need and pay as you grow. ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information on ClearOS, please visit http://www.hpe.com/servers/clearos.

Notes:

- For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 16

HPE Server UEFI/Legacy ROM

legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI Class

• Workload Profiles for simple performance optimization

Embedded Management

Security

• Secure Recovery – recover critical firmware to known good state on detection of compromised firmware

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured configuration than the 2 implementation and support both UEFI Mode (default) and Legacy BIOS Mode.

Notes:The UEFI System Utilities tool is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more information, please visit http://www.hpe.com/servers/uefi.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot and Secure Start enable for enhanced security

• Embedded UEFI Shell

• Operating system specific functionality

• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant

• Support for > 2.2 TB (using GPT) boot drives

• PXE boot support for IPv6 networks

• USB 3.0 Stack

HPE Integrated Lights-Out (HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and remote management with HPE iLO. Learn more at http://www.hpe.com/info/ilo.

UEFI

Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI). Learn more at http://www.hpe.com/servers/uefi.

Intelligent Provisioning

Hassle free server and OS provisioning for 1 or more servers with Intelligent Provisioning. Learn more at http://www.hpe.com/servers/intelligentprovisioning..

iLO RESTful API

iLO RESTful API is Redfish API conformance and offers simplified server management automation such as configuration and maintenance tasks based on modern industry standards. Learn more at http://www.hpe.com/info/restfulapi

• UEFI Secure Boot and Secure Start support

• Tamper-free updates – components digitally signed and verified

• Immutable Silicon Root of Trust

• Ability to rollback firmware

• FIPS 140-2 validation

• Secure erase of NAND/User data

• Common Criteria certification

• TPM (Trusted Platform Module) 1.2 option

• Configurable for PCI DSS compliance

• TPM (Trusted Platform Module) 2.0 option

• Advanced Encryption Standard (AES) and Triple Data Encryption Standard (3DES) on browser

• Bezel Locking Kit option

• Support for Commercial National Security Algorithms (CNSA)

• Chassis Intrusion detection option

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 17

Industry Standard Compliance

for more information regarding

B22).

Warranty

http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.

• ACPI 6.1 Compliant

• PCIe 3.0 Compliant

• WOL Support

• Microsoft® Logo certifications

• PXE Support

• VGA/Display Port

Notes:This support is on the optional Universal Media Bay.

• USB 3.0 Compliant (internal)

• USB 2.0 Compliant (external ports via SUV)

Notes:This support is on the optional Universal Media Bay.

• Energy Star

• SMBIOS 3.1

• Redfish API

• IPMI 2.0

• Secure Digital 4.0

• TPM 1.20 and 2.0 Support

• Advanced Encryption Standard (AES)

• Triple Data Encrytion Standard (3DES)

• SNMP v3

• TLS 1.2

• DMTF Systems Management Architecture for Server Hardware Command Line Protocol (SMASH CLP)

• Active Directory v1.0

• ASHRAE A3/A4

Notes:For additional technical, thermal details regarding ambient temperature, humidity, and feature support, please visit http://www.hpe.com/servers/ashrae products, known as Lot 9, go into effect on March 1st, 2020. Among other requirements, for servers this directive establishes power thresholds for idle state, as well as efficiency and performance in active state which vary among configurations. HPE ProLiant Gen10 servers are compliant with Lot9 requirements. Please visit: https://www.hpe.com/us/en/about/environment/msds-specs-more.html HPE Lot 9 conformance.

• UEFI (Unified Extensible Firmware Interface Forum) 2.6

Notes:UEFI is the default for the DL380 Gen10. Legacy mode can be selected in the field or as a CTO option (758959-

European Union (EU) eco-design regulations for server and storage

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of Hewlett Packard Enterprise Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

Notes:Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Standard Features

Page 18

Server Utilities

http://www.hpe.com/info/hpesim

Active Health System

The HPE Active Health System (AHS) is an essential component of the iLO management portfolio that provides continuous, proactive health monitoring of HPE servers. Learn more at http://www.hpe.com/servers/ahs

Active Health System Viewer

Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE selfrepair recommendations, to learn more visit: http://www.hpe.com/servers/ahsv

Smart Update

Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware and driver updates of the Service Pack for ProLiant (SPP).

iLO Amplifier Pack

Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier Pack is a free, downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HPE servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more at http://www.hpe.com/servers/iLOamplifierpack

HPE iLO Mobile Application

Enables the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile devices. For additional information please visit: http://www.hpe.com/info/ilo/mobileapp

RESTful Interface Tool

RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API to discover and deploy servers at scale. Learn more at http://www.hpe.com/info/resttool

Scripting Tools

Provision one to many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at http://www.hpe.com/servers/powershell

HPE OneView Standard

HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting without additional fees. It can monitor multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-defined functionality is not available. Learn more at http://www.hpe.com/info/oneview

HPE Systems Insight Manager (HPE SIM)

Ideal for environments already using HPE SIM, it allows you to monitor the health of your HPE ProLiant Servers and HPE Integrity Servers. Also provides you with basic support for non-HPE servers. HPE SIM also integrates with Smart Update Manager to provide quick and seamless firmware updates. Learn more at

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Optional Features

Page 19

Server Management

user collaboration, console record and

featured licenses which can

Accelerator and GPGPU Information

One Config Simple (SCE)

https://h22174.www2.hpe.com/SimplifiedConfig/Welcome#

HPE iLO Advanced

HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multireplay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality.

HPE OneView Advanced

HPE OneView brings a new level of automation to infrastructure management by taking a template driven approach to provisioning, updating, and integrating compute, storage, and networking infrastructure. It provides fullbe purchased for managing Gen8, Gen9 and Gen10 servers. To learn more visit http://www.hpe.com/info/oneview.

HPE InfoSight for Servers

HPE InfoSight for Servers combines the cloud-based machine learning of InfoSight with the health and performance monitoring of Active Health System (AHS) and iLO to optimize performance and predict and prevent problems. The end result is an intelligent environment that modernizes IT operations and enhances the support experience by predicting and preventing the infrastructure issues that lead to application disruptions, wasted IT staff time and missed business opportunities. Learn more at https://www.hpe.com/servers/infosight

HPE Insight Cluster Management Utility (CMU)

HPE Insight Cluster Management Utility is a HyperScale management framework that includes software for the centralized provisioning, management and monitoring of nodes and infrastructure. Learn more at http://www.hpe.com/info/cmu

Hewlett Packard Enterprise supports various accelerators on select HPE Proliant servers to support different workloads. The accelerators enable seamless integration of GPU computing with HPE ProLiant servers for high-performance computing, large data center graphics, deep learning and virtual desktop deployments. These accelerators deliver all of the standard benefits of GPU computing while enabling maximum reliability and tight integration with system monitoring and management tools such as HPE Insight Cluster Management Utility.

SCE is a guided self-service tool to help sales and non-technical people provide customers with initial configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business Center or an Authorized Partner for assistance.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Optional Features

Page 20

Rack and Power Infrastructure

HPE G2 Advanced and Enterprise Racks are perfect for the server room or today’s modern data center with enhanced airflow and

coded outlets and

HPE Rack and Power Infrastructure

The story may end with servers, but it starts with the foundation that makes compute go – and business grow. We’ve reinvented our entire portfolio of rack and power products to make IT infrastructure more secure, more practical, and more efficient. In other words, we’ve created a stronger, smarter, and simpler infrastructure to help you get the most out of your IT equipment. As an industry leader, Hewlett Packard Enterprise is uniquely positioned to address the key concerns of power, cooling, cable management and system access.

thermal management, flexible cable management, and a 10 year Warranty to support higher density computing.

HPE G2 PDUs offer reliable power in flexible form factors that operate at temperatures up to 60°C, include colorload segments and a low-profile design for optimal access to the rack and support for dense rack environments.

HPE Uninterruptible Power Systems are cost-effective power protection for any type workload. Some UPSs include options for remote management and extended runtime modules so you’re critical dense data center is covered in power outages. HPE KVM Solutions include a console and switches designed to work with your server and IT equipment reliably. We’ve got a costeffective KVM switch for your first rack and multiple connection IP switches with remote management and security capabilities to keep your data center rack up and running. Learn more about HPE Racks, KVM, PDUs and UPSs at

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Service and Support

Page 21

HPE Pointnext - Service and Support

Protect your business beyond warranty with HPE Pointnext Operational Service

HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational Services to help accelerate your digital transformation. From the onset of your transformation journey, Advisory and Transformational Services focus on designing the transformation and configurations with flawless and on innovative new approaches like Flexible Capacity and Datace Packard Enterprise is ready to bring together all the pieces of the puzzle for you, with an eye on the future, and make the c simple.

Connect your devices:

f your technology investment by connecting your products to Hewlett Packard Enterprise. Achieve up to

http://www.hpe.com/services/getconnected.

Recommended Services

ble servers. This service also includes collaborative software support for

most of these services and receive all the deliverables.

creating a solution roadmap. Professional Services specializes in creative

-time implementation, and on-budget execution. Finally, operational services provides nter Care, to keep your business at peak performance. Hewlett

omplex

Unlock all of the benefits o 77%1 reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, pre-failure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and increase optimization. All of these benefits are already available to you with your server storage and networking products, securely connected to HPE support.

Notes:

IDC

HP CSC reports 2014 – 2015

Learn more about getting connected at

HPE Proactive Care* with 6 hour call-to-repair commitment, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. This Service combines three years’ proactive reporting and advice with our highest level of hardware support – the HPE 24x7, six hour hardware call-to-repair. Hewlett Packard Enterprise is the only leading manufacturer who makes this level of coverage available as a standard service offering for your most valua Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

HPE Proactive Care* with 24x7 coverage, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice This Service combines three years proactive reporting and advice with our 24x7 coverage, four hour hardware response time whe there is a problem. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

HPE Proactive Care* - Next Business Day service, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. This service combines three years of Hardware Support where a Hewlett Packard Enterprise authorized representative will arrive at the Customer's site during the onsite coverage window to begin hardware maintenance service the next coverage day after the service request has been logged. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Notes:*HPE Proactive Care and HPE Proactive Care Advanced require that the customer connect their devices to make the

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Service and Support

Page 22

Other related Services

HPE Installation and Startup Service

(Windows® or Linux).

HPE Datacenter Care service

wherever you are on your IT journey. With HPE Datacenter Care, you benefit from a personalized relationship with

http://www.hpe.com/services/datacentercare

HPE GreenLake Flex Capacity

DC for Hyperscale

HPE Factory Express for Servers and storage

vices as

des,

switches.

HPE Service Credits

Offered as annual credits, you can plan your budgets while proactively responding to your dynamic business.

HPE Education Services

HPE Server Hardware Installation

Provides for the basic hardware installation of HPE branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.

https://h20195.www2.hpe.com/v2/Getdocument.aspx?docname=5981-9356enw

Provides for the installation of your HPE hardware according to product specifications including options. The HPE service delivery technician will connect the product to a LAN as appropriate and enable remote support to allow for automatic case creation for hardware failures. Installation and start up services also includes the installation of one supported operating system type

HPE Datacenter Care helps improve IT stability and security, increase the value of IT, and enable agility and innovation. It is a structured framework of repeatable, tested, and globally available services “building blocks.” You can deploy, operate, and evolve your datacenter HPE via a single point of accountability for HPE and others’ products. For more information, visit:

With HPE GreenLake Flex Capacity, you get the speed, scalability, and economics of the public cloud in the privacy of your data center. Gain the advantages of the public cloud—consumption-based payment, rapid scalability without worrying about capacity constraints. Reduce the “heavy lifting” needed to operate a data center. And retain the advantages that IT provides the business (i.e., control, security). Deliver the right user experience, choose the right technology for the business, manage privacy and compliance, and manage the cost of IT. And, you have the option to use the public cloud when needed.

Datacenter Care for Hyperscale is available for Service Providers and HPC customers who use a scale out approach to computing with a high volume homogenous infrastructure and resilient architecture can take advantage of this environment support tailored to their operating model.

HPE Factory Express offers configuration, customization, integration and deployment services for HPE servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed. Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design ser well as individual factory services, such as image loading, asset tagging, and custom packaging. HPE products supported through Factory Express include a wide array of servers and storage: HPE Integrity, HPE ProLiant, HPE Apollo, HPE ProLiant Server Bla HPE BladeSystem, HPE 9000 servers as well as the MSAxxxx3PAR suite, XP, rackable tape libraries and configurable network

HPE Service Credits offers flexible services and technical skills to meet your changing IT demands. With a menu of service that is tailored to suit your needs, you get additional resources and specialist skills to help you maintain peak performance of your IT.

Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. Book on a class today and learn how to get the most from your technology investment. http://www.hpe.com/ww/learn

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Service and Support

Page 23

HPE Support Center

the specific high value options that require additional support here.

Parts and Materials

Enterprise due to malfunction.

The HPE Support Center is a personalized online support portal with access to information, tools and experts to support HPE business products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access support resources or collaborate with peers.Learn more http://www.hpe.com/support/hpesc.

The HPE Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you can get access to personalized IT support anywhere, anytime.

HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE warranty, HPE Support Service or HPE contractual support agreement.

Notes:

- *HPE Support Center Mobile App is subject to local availability.

- For more information: http://www.hpe.com/services.

- HPE ProLiant DL380 Gen10 Server is covered under the HPE Service Contract applied to the HPE ProLiant Server. No

separate HPE support services need to be purchased.

Warranty and Support Services will extend to include HPE options configured with your server or storage device. The price of support service is not impacted by configuration details. HPE sourced options that are compatible with your product will be covered under your server support at the same level of coverage allowing you to upgrade freely. Installation for HPE options is available as needed. To keep support costs low for everyone, some high value options will require additional support. Additional support is only required on select high value workload accelerators, fibre switches, InfiniBand and UPS batteries over 12KVA. See

Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by Hewlett Packard

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 24

Worldwide & Japan BTO Networking Choice (NC) Models

SKU Number

P20182-xx1

P20172-xx1

P20174-xx1

Model Name

HPE ProLiant DL380 Gen10

NC 8LFF 500W PS Server

HPE ProLiant DL380 Gen10

a NC 12LFF 800W RPS

Server

HPE ProLiant DL380 Gen10

500W PS Server

Chassis

8LFF NC Chassis (P19717-B21)

12LFF NC Chassis (P19718B21)

8SFF NC Chassis (P19720B21)

Processor

3204 (6 core, 1.9GHz, 85W)

4208 (8 core, 2.1GHz, 85W)

4210 (10 core, 2.2GHz, 85W)

Number of Processors

One with standard heatsink

Memory

16 GB RDIMM 2R 2933 MT/s

processor limitation

32 GB RDIMM 2R 2933MT/s

2400MT/s due to

processor limitation

32 GB RDIMM 2R 2933 MT/s

to processor limitation

Network Controller

HPE Ethernet 1Gb 4-port

networking

Storage Controller

S100i embedded SW RAID with

accessible)

P816i-a/4GB with Smart

P408i-a/2GB with Smart

Hard Drive

None Included

Internal Storage

8 LFF chassis, with 2 SFF bays

12 LFF chassis, with 2 SFF bays

8 SFF Chassis (upgradeable to

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

1x HPE 500W Flex Slot

Power Supply Kit

2x HPE 800W Flex Slot

Power Supply Kit

1x HPE 500W Flex Slot

Halogen Power Supply Kit

Fans

6 - Standard

6 - Performance

4 - Standard

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

LFF Easy Install Rail Kit; cable management arm not included

LFF Easy Install Rail Kit with Cable Management Arm

SFF Easy Install Rail Kit with Cable Management Arm

Energy Star

Energy Star 3.0

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:

Notes:The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

3204 1.9GHz 6-core 1P 16GBR S100i

(1x 16 GB)

Notes:Runs at 2133MT/s due to

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded networking

14 SATA ports (12-ports

optional (upgradeable to 15LFF with 4LFF mid and 3LFF rear + 2SFF rear)

4208 2.1GHz 8-core 1P 32GBR P816i-

(1x 32 GB)

Notes:Runs at

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded networking

Storage Battery

optional (upgradeable to 19LFF with 4LFF mid and 3LFF rear + 2SFF rear)

4210 2.2GHz 10-core 1P 32GB-R P408i-a NC 8SFF

(1x 32GB)

Notes:Runs at 2400MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded

Storage Battery

24 SFF front + 6SFF rear)

Platinum Hot Plug Low Halogen

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

- Network Choice (NC) models do not include an embedded NIC. A pre-selected FlexibleLOM is included in the configuration

with additional options available via stand-up card NIC adapters listed in the “HPE Networking” section.

- UEFI is the standard default for all SMB models.

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

Platinum Hot Plug Low

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 25

SMB Networking Choice (NC) Models

SKU Number

P23465-xx1

P24840-xx1

P24841-xx1

Model Name

HPE ProLiant DL380 Gen10

Server

HPE ProLiant DL380 Gen10

800W PS Server

HPE ProLiant DL380 Gen10

800W PS Server

Chassis

8SFF NC Chassis (P19720-B21)

24SFF NC Chassis (P19719B21)

8SFF NC Chassis (P19720B21)

Processor

4208 (2.1GHz, 8 core, 85W)

4210R (2.4GHz, 10 core, 100W)

Number of Processors

One with standard heatsink

Memory

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

Network Controller

HPE Ethernet 1Gb 4-port

networking

Storage Controller

P408i-a w/2GB cache (804331-

(P01366-B21) included.

P408i-a w/2GB cache

Hard Drive

None ship as standard

Internal Storage

8 SFF (upgradeable to 24 SFF front + 6SFF rear)

24 SFF (upgradeable + 6SFF rear)

8 SFF (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

1x HPE 500W Flex Slot

1x HPE 800W Flex Slot

(865414-B21)

Fans

4-standard fans

6 - Performance

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy install rail kit (73360-B21) with Cable Management Arm (733664-B21)

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

Notes:

4208 2.1GHz 8-core 1P 32GB-R P408i-a NC 8SFF 500W PS

(1x 32 GB; P00924-B21)

Notes:Runs at 2400 MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded networking

B21)

Notes:8-Port modular Smart Array. Notes:Smart Storage battery (P01366-B21) included.

4210R 2.4GHz 10-core 1P 32GB-R P408i-a NC 24SFF

(1x 32 GB; P00924-B21)

Notes:Runs at 2400 MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded networking

B21) + HPE 12Gb SAS Expander Card Kit w/ cables (870549-B21)

Notes:8-Port modular Smart Array. Notes:Smart Storage battery

4210R 2.4GHz 10-core 1P 32GB-R P408i-a NC 8SFF

(1x 32 GB; P00924-B21)

Notes:Runs at 2400 MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded

(804331-B21)

Notes:8-Port modular Smart Array. Notes:Smart Storage battery (P01366-B21) included.

Platinum Hot Plug Low Halogen Power Supply Kit (865408-B21)

Platinum Hot Plug Low Halogen Power Supply Kit (865414-B21)

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

Platinum Hot Plug Low Halogen Power Supply Kit

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 26

SMB Networking Choice (NC) Models

SKU Number

P24842-xx1

P24844-xx1

P24845-xx1

Model Name

HPE ProLiant DL380 Gen10

PS Server

HPE ProLiant DL380 Gen10

PS Server

HPE ProLiant DL380 Gen10

Server

Chassis

8SFF NC Chassis (P19720-B21)

Processor

4214R (2.4GHz, 12 core, 100W)

5218R (2.1GHz, 20 core, 125W)

5222 (3.8GHz, 4 core, 105W)

Number of Processors

One with standard heatsink

One with performance heatsink

Memory

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

Network Controller

HPE Ethernet 1Gb 4-port

HPE Ethernet 10Gb 2-port

networking

Storage Controller

P408i-a w/2GB cache (804331-

(P01366-B21) included.

S100i embedded SW RAID with

S100i embedded SW RAID

Hard Drive

None ship as standard

Internal Storage

8 SFF (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit (865414-B21)

Fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Rail Kit

SFF Easy install rail kit (73360-B21) with Cable Management Arm (733664-B21)

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

4214R 2.4GHz 12-core 1P 32GB-R P408i-a NC 8SFF 800W

(1x 32 GB; P00924-B21)

Notes:Runs at 2400 MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded networking

B21)

Notes:8-Port modular Smart Array. Notes:Smart Storage battery

5218R 2.1GHz 20-core 1P 32GB-R S100i NC 8SFF 800W

(1x 32 GB; P00924-B21)

Notes:Runs at 2666 MT/s due

562FLR-SFP+ Adapter (727054-B21) plus optional stand-up card

Notes:No embedded networking

14 SATA ports (12-ports accessible)

5222 3.8GHz 4-core 1P 32GBR S100i NC 8SFF 800W PS

(1x 32 GB; P00924-B21)

562FLR-SFP+ Adapter (727054-B21) plus optional stand-up card

Notes:No embedded

with 14 SATA ports (12-ports accessible)

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView Advanced (require licenses)

Notes:UEFI is the standard default for all SMB models.

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 27

SMB Networking Choice (NC) Models

SKU Number

P24846-xx1

P24847-xx1

P24848-xx1

Model Name

HPE ProLiant DL380 Gen10

PS Server

HPE ProLiant DL380 Gen10

PS Server

Chassis

8SFF NC Chassis (P19720-B21)

Processor

6226R (2.9GHz, 16 core, 150W)

6234 (3.3GHz, 8 core, 130W)

4215R (3.2GHz, 8 core, 130W)

Number of Processors

One with performance heatsink

Memory

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

Network Controller

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter (727054-B21) plus optional stand-up card

Notes:No embedded networking

Storage Controller

S100i embedded SW RAID with 14 SATA ports (12-ports accessible)

Hard Drive

None ship as standard

Internal Storage

8 SFF (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit (865414-B21)

Fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy install rail kit (73360-B21) with Cable Management Arm (733664-B21)

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

Notes:

6226R 2.9GHz 16-core 1P 32GB-R S100i NC 8SFF 800W

(1x 32 GB; P00924-B21)

6234 3.3GHz 8-core 1P 32GBS100i NC 8SFF 800W PS Server

(1x 32 GB; P00924-B21)

4215R 3.2GHz 8-core 1P 32GB-R S100i NC 8SFF 800W

(1x 32 GB; P00924-B21)

Notes:Runs at 2400 MT/s due

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 28

SMB Networking Choice (NC) Models

SKU Number

P24849-xx1

P24850-xx1

Model Name

HPE ProLiant DL380 Gen10 6248R 3.0GHz 24core 1P 32GB-R S100i NC 8SFF 800W PS Server

HPE ProLiant DL380 Gen10 6250 3.9GHz 8core 1P 32GB-R S100i NC 8SFF 800W PS Server

Chassis

8SFF

Processor

6248R (3.0GHz, 24 core, 205W)

6250 (3.9GHz, 8 core, 185W) 1

Number of Processors

One with performance heatsink

Memory

32 GB RDIMM 2R 2933 MT/s (1x 32 GB; P00924-B21)

Network Controller

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter (727054-B21) plus optional stand-up card

Notes:

Storage Controller

S100i embedded SW RAID with 14 SATA ports (12-ports accessible)

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

1x HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit (865414-B21)

Fans

4-standard fans

6-high performance fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy install rail kit (73360-B21) with Cable Management Arm (733664-B21)

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:

No embedded networking

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

- UEFI is the standard default for all SMB models.

Not supported with NVMe SSDs, nor 2SFF HDD kits (826687-B21; 826688-B21) installed in rear, nor GPUs, nor 4LFF midtray. Detailed configuration and facilities requirements can be found under “Intel Xeon Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix” with this document.

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

Notes:The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 29

SMB Networking Choice (NC) Models

SKU Number

P20245-xx1

P20248-xx1

P20249-xx1

Model Name

HPE ProLiant DL380 Gen10

Server

HPE ProLiant DL380 Gen10

Server

HPE ProLiant DL380 Gen10

800W PS Server

Chassis

8SFF

Processor

6242 (16C, 2.8GHz, 150W)

5220 (18C, 2.2GHz, 125W)

5218 (16 core, 2.3 GHz, 125W)

Number of Processors

1 1 1

Memory

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

Network Controller

HPE Ethernet 10/25Gb 2-port

HPE Ethernet 1Gb 4-port

networking

Storage Controller

P408i-a w/2GB cache

Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual

configuration

3-slots (x8, x16, x8 with dual

configuration

3-slots (x8, x16, x8 with dual

configuration

Power Supply

1x HPE 800W Flex Slot

Fans

4-standard fans

6-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy install rails with Cable Management Arm

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

Notes:

6242 2.8GHz 16-core 1P 32GBR P408i-a NC 8SFF 800W PS

(1x 32 GB)

640FLR-SFP28 FlexibleLOM Adapter (817749-B21) plus optional stand-up card

Notes:No embedded networking

Notes:

- 8-Port modular Smart Array.

5220 2.2GHz 18-core 1P 32GBR P408i-a NC 8SFF 800W PS

(1x 32 GB)

Notes:Runs at 2666 MT/s due

640FLR-SFP28 FlexibleLOM Adapter (817749-B21) plus optional stand-up card

Notes:No embedded networking

5218 2.3GHz 16-core 1P 32GB-R P408i-a NC 8SFF

(1x 32 GB)

Notes:Runs at 2666 MT/s due

366FLR FlexibleLOM Adapter (665240-B21) plus optional stand-up card

Notes:No embedded

m.2) as standard; upgradeable to 8-slots in a 2 processor

Platinum Hot Plug Low Halogen Power Supply Kit

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

m.2) as standard; upgradeable to 8-slots in a 2 processor

Platinum Hot Plug Low Halogen Power Supply Kit

m.2) as standard; upgradeable to 8-slots in a 2 processor

Platinum Hot Plug Low Halogen Power Supply Kit

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 30

SMB Models

SKU Number

P02463-xx1

Model Name

HPE ProLiant DL380 Gen10 4208 2.1GHz 8-core 1P 16GB-R S100i 12LFF 500W PS Server

Chassis

12LFF

Processor

4208 (8 core, 2.1 GHz, 85W)

Number of Processors

One with standard heatsink

Memory

16 GB RDIMM 2R 2933 MT/s (1x 16 GB)

Notes:

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card

Storage Controller

S100i embedded SW RAID with 14 SATA ports (12-ports accessible)

Hard Drive

None ship as standard

Internal Storage

12 LFF chassis, with 2 SFF bays optional (upgradeable to 19LFF with 4LFF mid and 3LFF rear + 2SFF rear)

Optical Drive

None included

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2-processor configuration

Power Supply

1x HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

Fans

6-performance fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

LFF Easy Install rails without Cable Management Arm

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all pre-configured models.

Notes:

Runs at 2400 MT/s due to processor limitation

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 31

SMB Models

SKU Number

P02462-xx1

P02464-xx1

P02465-xx1

Model Name

HPE ProLiant DL380 Gen10

PS Server

Chassis

8SFF

Processor

4208 (8 core, 2.1GHz, 85W)

4210 (10 core, 2.2 GHz, 85W)

5218 (16 core, 2.3 GHz, 125W)

Number of Processors

1 1 2

Memory

16 GB RDIMM 2R 2933 MT/s

to processor limitation.

32 GB RDIMM 2R 2933 MT/s

to processor limitation.

64 GB RDIMM 2R 2933 MT/s

to processor limitation.

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card

Storage Controller

P408i-a w/2GB cache

Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24 SFF front + 6SFF rear)

PCIe Slots

3-slots (x8, x16, x8 with dual

configuration

3-slots (x8, x16, x8 with dual

configuration

3-slots (x8, x16, x8 with dual

Power Supply

1x HPE 500W Flex Slot

1x HPE 800W Flex Slot

Fans

4-standard fans

6-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy install rails with Cable Management Arm

Energy Star

3.0 Certified

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

4208 2.1GHz 8-core 1P 16GBP408i-a 8SFF 500W PS Server

(1x 16 GB)

Notes:Runs at 2400 MT/s due

Notes:

- 8-Port modular Smart Array.

m.2) as standard; upgradeable to 8-slots in a 2 processor

Platinum Hot Plug Low Halogen Power Supply Kit

4210 2.2GHz 10-core 1P 32GBR P408i-a 8SFF 800W PS Server

(1x 32 GB)

Notes:Runs at 2400 MT/s due

m.2) as standard; upgradeable to 8-slots in a 2 processor

Platinum Hot Plug Low Halogen Power Supply Kit

5218 2.3GHz 16-core 2P 64GB-R P408i-a 8SFF 800W

(2x 32 GB)

Notes:Runs at 2666 MT/s due

m.2) as standard; upgradeable to 8-slots

Platinum Hot Plug Low Halogen Power Supply Kit

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 32

SMB Models

SKU Number

P02466-xx1

P02467-xx1

P02468-xx1

Model Name

HPE ProLiant DL380 Gen10

RPS Server

HPE ProLiant DL380 Gen10

Server

HPE ProLiant DL380 Gen10

PS Server

Chassis

8SFF

24SFF

12LFF

Processor

6230 (20-core 2.1GHz, 125W)

4208 (8 core, 2.1GHz, 85W)

4214 (12 core, 2.2GHz, 85W)

Number of Processors

1 1 1

Memory

64 GB RDIMM 2R 2933MT/s

32 GB RDIMM 2R 2933 MT/s

processor limitation.

16 GB RDIMM 2R 2933 MT/s

Network Controller

HPE 1Gb Ethernet 4-Port 331i

Storage Controller

P816i-a/4GB with Smart

P408i-a/2GB with Smart

P816i-a/4GB with Smart

Hard Drive

None Included

Internal Storage

8 SFF Chassis (upgradeable to

24 SFF Chassis (upgradeable

12 LFF chassis, with 2 SFF bays

PCIe Slots

3-slots (x8, x16, x8 with dual m.2) as standard; upgradeable to 8-slots in a 2 processor configuration

Power Supply

2x HPE 800W Flex Slot

Power Supply Kit

1x HPE 800W Flex Slot

Power Supply Kit

1x HPE 800W Flex Slot

Halogen Power Supply Kit

Fans

4 - Standard

6 - Performance

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Rail Kit

SFF Easy Install with Cable

LFF Easy Install with Cable

Energy Star

Energy Star 3.0

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

6230 2.1GHz 20-core 1P 64GB-R P816i-a 8SFF 800W

(2x 32 GB)

Adapter

Storage Battery

24 SFF front + 6SFF rear)

Platinum Hot Plug Low Halogen

4208 2.1GHz 8-core 1P 32GBR P408i-a 24SFF 800W PS

(2x 16GB)

Notes:Runs at 2400MT/s due to

Adapter

Storage Battery

+6SFF rear)

Platinum Hot Plug Low Halogen

4214 2.2GHz 12-core 1P 16GB-R P816i-a 12LFF 800W

(1x 16 GB)

Notes:Runs at 2400MT/s.

Adapter

Storage Battery

optional (upgradeable to 19LFF with 4LFF mid and 3LFF rear + 2SFF rear)

Platinum Hot Plug Low

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

Management Arm

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 33

Entry Models

[SKU Number]

868709-xx1

826564-xx1

Model Name

Entry LFF

Entry SFF

Processor

3106 (8-Core, 1.7 GHz, 85W)

Number of Processors

One processor with standard heatsink

Memory

16 GB RDIMM DR 2600 MT/s (1x 16 GB)

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus

Storage Controller

Embedded 14-Port S100i

Notes:

Embedded 14-Port S100i

Notes:

Hard Drive

None ship as standard

Internal Storage

8 LFF chassis, with 2 SFF bays optional

rear + 2SFF rear)

8 SFF Chassis (upgradeable to 24 SFF front +

Optical Drive Bay

Optional via Universal Media Bay (included)

Optional Universal Media Bay (826708-B21)

Optical Drive

None ship as standard

PCI-Express Slots

3-slots (x8, x16, x8) as standard

Power Supply

1x 500W HPE FlexSlot Platinum Power Supply

Fans

6-standard fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Energy Star

3.0 Certified

Form Factor

2U Rack, Easy Install rails without CMA

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:running at 2133 MT/s due to Processor limitation.

optional HPE FlexibleLOM or stand up card

(upgradeable to 15LFF with 4LFF mid and 3LFF

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

SATA only, 12-PORT accessible.

Notes:running at 2133 MT/s due to Processor limitation.

optional HPE FlexibleLOM or stand up card

SATA only, 12-PORT accessible.

6SFF rear)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 34

Base Models

[SKU Number]

826565-xx1

Model Name

Base SFF

Processor

4114 (10-Core, 2.2 GHz, 85W)

Number of Processors

One processor

Memory

32 GB RDIMM DR 2600 MT/s (2x 16 GB)

Notes:running at 2400 MT/s due to Processor limitation.

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card

Storage Controller

P408i-a

- Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24 SFF front + 6SFF rear)

Optical Drive BayOptical Drive Bay

Optional Universal Media Bay (826708-B21)

Optical Drive

None ship as standard

PCI-Express Slots

3-slots (x8, x16, x8) as standard

Power Supply

1x 500W HPE FlexSlot Platinum power supply

Fans

4-standard fans

Management

HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires

Advanced (require licenses)

Energy Star

3.0 Certified

Form Factor

2U Rack, Easy install rails with CMA

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response

Notes:

- 8-Port modular Smart Array.

download); HPE iLO Advanced, HPE iLO Advanced Premium Security Edition and HPE OneView

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 35

Performance Models

High Performance Models

[SKU Number]

826566-xx1

826567-xx1

879938-xx1

Model Name

Performance

High-Perferformance

Processor

5118 (12-Core, 2.3 GHz, 105W)

6130 (16-Core, 2.1 GHz, 120W)

Number of Processors

Two processors

Memory

64 GB RDIMM DR 2666 MT/s

due to processor limitation.

64 GB RDIMM DR 2666 MT/s

Network Controller

HPE 1Gb Ethernet 4-Port 331i

SFP28 Adapter (817749-B21)

HPE 1Gb Ethernet 4-Port 331i

SFP28

Adapter (817749-B21)

HPE 1Gb Ethernet 4-Port 331i

(817709-B21)

Storage Controller

P408i-a

Smart Storage battery included.

P408i-a

Smart Storage battery included.

P408i-a

Smart Storage battery included.

Hard Drive

None ship as standard

Internal Storage

8 SFF Chassis (upgradeable to 24 SFF front + 6SFF rear)

Optical Drive BayOptical Drive Bay

Universal Media Bay

Optical Drive

DVD-RW

PCI-Express Slots

6 total: 3-slots (x8, x16, x8 with

(x8, x16, x8)

6 total: 3-slots (x8, x16, x8 with

(x8, x16, x8)

6 total: 3-slots (x8, x16, x8 with

(x8, x16, x8)

Power Supply

2x 800W HPE FlexSlot Platinum power supply

Fans

6-standard fans

Management

HPE iLO Advanced with Intelligent Provisioning, HPE OneView Standard (requires download) Energy Star

3.0 Certified

Form Factor

2U Rack, Easy Install rails with CMA

Warranty

3-3-3

Country Code Key

(2x 32 GB)

Notes:running at 2400 MT/s

Adapter plus HPE Ethernet 10/25 Gb 2-port 640FLR-

Notes:

8-Port modular Smart Array.

(826708-B21)

m.2) as standard, plus 3 PCIe

(2x 32 GB)

Adapter plus HPE Ethernet 10/25 Gb 2-port 640FLR-

Notes:

8-Port modular Smart Array.

(826708-B21)

m.2) as standard, plus 3 PCIe

(2x 32 GB)

Adapter plus HPE Ethernet 25 Gb 2-port 631FLR Adapter

Notes:

8-Port modular Smart Array.

(826708-B21)

m.2) as standard, plus 3 PCIe

Optional (require licenses): HPE iLO Advanced Premium Security Edition, HPE OneView Advanced

xx1 = B21 Worldwide xx1 = 291 Japan

Notes:The -B21 WW SKU is to be ordered in all countries other than Japan.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 36

SMB Models

4. If you desire to custom configure an SMB Model please consult your preferred reseller.

SMB Models

SKU Number

P06419-xx1

P06420-xx1

Model Name

HPE ProLiant DL380 Gen10 3104 1.7GHz 6-core

Server

HPE ProLiant DL380 Gen10 4110 2.1GHz 8-

Performance Server

Chassis

8LFF

8SFF

Processor

3104 (6 core, 1.7 GHz, 85W)

4110 (8 core, 2.1 GHz, 85W)

Number of Processors

One processor With standard heatsink

Memory

16 GB RDIMM 2R 2666 MT/s

limitation.

16 GB RDIMM 2R 2666 MT/s

limitation.

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter

Storage Controller

Embedded 14-port S100i

Notes:

SATA only, 12-port accessible.

P408i-a/2GB with Smart Storage Battery

Hard Drive

None included

Optical Drive

None included

PCIe Slots

3 PCIe: 2 x16, 1 x8

Power Supply

1x 500W

Fans

4 - Standard

Management

HPE iLO 5

Rail Kit

LFF Easy Install w/o CMA

SFF Easy Install with CMA

Energy Star

Energy Star 3.0

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

1. New SMB focused offers regionally released as “Smart Buy Express” in the U.S. and Canada, “Top Value” in Europe, and

“Intelligent Buy” in Asia Pacific and Japan”.

2. SMB Models ship with the configurations below. Options can be selected from the Core or Additional options section of

this QuickSpecs.

3. Hewlett Packard Enterprise does not provide factory integration of options into SMB Models. Any additional options

purchased will be shipped separately and would need to be field integrated.

1P 16GB-R S100i 8LFF 500W PS Entry SATA

(1x 16 GB)

Notes:Runs at 2133 MT/s due to processor

core 1P 16GB-R P408i-a 8SFF 500W PS

(1x 16 GB)

Notes:Runs at 2400 MT/s due to processor

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 37

SMB Models

SKU Number

P06421-xx1

P06422-xx1

P06423-xx1

Model Name

HPE ProLiant DL380 Gen10

PS Performance Server

HPE ProLiant DL380 Gen10

RPS Performance Server

HPE ProLiant DL380 Gen10

RPS Performance Server

Chassis

8SFF

Processor

4114 (10 core, 2.2 GHz, 85W)

5118 (12 core, 2.3 GHz, 105W)

6130 (16 core, 2.1 GHz, 125W)

Number of Processors

One processor With standard heatsink

Memory

32 GB RDIMM 2R 2666 MT/s

to processor limitation.

64 GB RDIMM 2R 2666 MT/s

to processor limitation.

64 GB RDIMM 2R 2666 MT/s

to processor limitation

Network Controller

HPE 1Gb Ethernet 4-Port 331i

Storage Controller

P408i-a/2GB with Smart Storage Battery

Hard Drive

None included

Optical Drive

None included

PCIe Slots

3 PCIe: 2 x16, 1 x8

Power Supply

1x 800W

2x 800W

Fans

4 - Standard

Management

HPE iLO 5

Rail Kit

SFF Easy Install with CMA

Energy Star

Energy Star 3.0

Form Factor

2U Rack

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

4114 2.2GHz 10-core 1P 32GB-R P408i-a 8SFF 800W

(1x 32 GB)

Notes:Runs at 2400 MT/s due

Adapter

5118 2.3GHz 12-core 1P 64GB-R P408i-a 8SFF 800W

(2x 32 GB)

Notes:Runs at 2400 MT/s due

Adapter

6130 2.1GHz 16-core 1P 64GB-R P408i-a 8SFF 800W

(2x 32 GB)

Notes:Runs at 2666 MT/s due

Adapter

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Pre

-configured Models

Page 38

SMB Solution Models

SKU Number

P05524-xx1

Model Name

HPE ProLiant DL380 Gen10 4110 2.1GHz 8-core 1P 16GB-R P408i-a 8SFF 500W RPS Solution Server

Chassis

8SFF

Processor

4110 (8 core, 2.1 GHz, 85W)

Number of Processors

One processor

Memory

16 GB RDIMM 2R 2666 MT/s

Notes:Runs at 2400 MT/s due to processor limitation.

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter

Storage Controller

P408i-a/2GB with Smart Storage Battery

Hard Drive

None included

Optical Drive

None included

PCIe Slots

3 PCIe: 2 x16, 1 x8

Power Supply

2x 500W

Fans

4 - Standard

Management

HPE iLO 5

Rail Kit

SFF Easy Install with CMA

Energy Star

Energy Star 3.0

Form Factor

2U Rack

Operating System

ClearOS/VM Installer (USB)

Warranty

3-year parts, 3-year labor, 3-year onsite support with next business day response.

Notes:UEFI is the standard default for all SMB models.

Country Code Key

xx1 = B21 Worldwide xx1 = 291 Japan

Notes:The -B21 WW SMB SKU is to be ordered in all countries other than Japan or PRC.

With standard heatsink

(1x 16 GB)

Notes:ClearOS, an easy to use OS with an application marketplace, allows you to build a fully functional server that is just right for you at no upfront cost. To learn more on what you can do, please visit http://www.hpe.com/servers/clearos.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 39

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are

Step 1: Base Configuration

Networking Choice

HPE ProLiant DL380

SKU Number

P19717-B21

P19718-B21

P19720-B21

P19719-B21

TAA Instruction

P19713-B21

Processor

Not included as standard

DIMM Slots

24-DIMM slots

Storage Controller

Embedded SW RAID with 14 SATA ports (12-ports accessible), choice of HPE modular Smart Array and PCIe plug-in controller

PCIe

Three standard in primary riser (with dual M.2 support)

Drive Cage - included

8 LFF

12 LFF

8 SFF

24 SFF

Network Controller

Choice of either HPE FlexibleLOM or select stand-up network adapters for primary networking

Notes:No embedded networking

Fans

6-Standard

6-Performance

4-Standard

6-Performance

Management

HPE iLO with Intelligent Provisioning (standard), iLO Advances and OneView (optional)

USB

1x 3.0 standard plus iLo front service port

None as standard

1x 3.0 standard plus iLo front service port

- All CTO servers are Energy Star 3.0 compliant.

ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.

1. Factory Integrated Models must start with a CTO Server.

2. FIO indicates that this option is only available as a factory installable option.

3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives

ordered with the server.

4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.

(choose one (1) of the following eight (8) configurable server models from the tables below) The below (4) CTO server models denoted with “NC” in the SKU description, provide flexibility in the networking choice and require a FlexibleLOM Adapter be selected.

CTO Server Models

Notes:

- Network Choice (NC) server models require a networking selection of a FlexibleLOM from the options listed in the

“FlexibleLOM Adapter” section or select network adapters in the “HPE Networking” section.

- Network Choice (NC) server models must be selected for 2nd Generation Intel® Xeon® Scalable “Refresh” (R) Processors

- HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government

customers. These products are either manufactured or substantially transformed in a designated country. TAA compliance is only provided when HPE options are included as part of factory integrated orders (CTO).

- To select a TAA model from the above, first select a CTO server, then add the TAA Instruction SKU, available in October

2019. The DL380 Gen10 TAA Instruction SKU is only applicable to NC server models. Non-NC server models have individual TAA server model SKUs in table below.

- The HPE ProLiant DL380 Gen10 12 LFF CTO Server ships with the cable required for the P816i-a installation.

Gen10 8LFF NC CTO Server

Gen10 12LFF NC CTO Server

Gen10 8SFF NC CTO Server

selection plus additional/optional stand-up network adapters

Gen10 24SFF NC CTO Server

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 40

The below (4) CTO server models come standard with an embedded HPE 1Gb Ethernet 4-port 331i adapter.

Embedded LOM

HPE ProLiant DL380

CTO Server

HPE ProLiant DL380

CTO Server

HPE ProLiant DL380

CTO Server

HPE ProLiant DL380

CTO Server

SKU Number

868706-B21

868705-B21

868703-B21

868704-B21

TAA Server SKU

875784-B21

875785-B21

875782-B21

875783-B21

Processor

Not included as standard

DIMM Slots

24-DIMM slots

Storage Controller

Embedded SW RAID with 14 SATA ports (12-ports accessible), choice of HPE modular Smart Array and PCIe plug-in controller

PCIe

Three standard in primary riser (with dual M.2 support)

Drive Cage - included

8 LFF

12 LFF

8 SFF

24 SFF

Network Controller

HPE 1Gb Ethernet 4-Port 331i Adapter plus optional HPE FlexibleLOM or stand up card Fans

6-Standard

6-Performance

4-Standard

6-Performance

Management

HPE iLO with Intelligent Provisioning (standard), iLO Advances and OneView (optional)

USB

1x 3.0 standard plus iLo front service port

None as standard

1x 3.0 standard plus iLo front service port

select a TAA model from the above, select the TAA Server

- All CTO servers are Energy Star 3.0 compliant.

CTO Server

8 SFF CTO Chassis

24 SFF CTO Chassis

8 LFF CTO Chassis

12 LFF CTO Chassis

Included Drive Cage

8 SFF SAS/SATA

3x 8 SFF SAS/SATA

8 LFF + UMB

12 LFF Chassis

Universal Media Bay

1 Optional

Not available

1 Included

Not available

ODD

1 Optional with UMB

Not available

1 Optional

Not available

8 SFF Drive Cage

Up to 2 Optional

Not available

8 NVME/SAS Bay

Up to 3 Optional

Not available

8 NVME Cage

Up to 3 Optional

Not available

2 SFF SAS/SATA (Front)

1 Optional with UMB

Not available

1 Optional

Not available

2 SFF SAS/SATA (Rear)

1 Optional

2 NVMe (Front)

1 Optional with UMB

Not available

1 Optional

Not available

4 LFF Mid-plane

Not available

1 Optional

3 LFF Rear

Not available

1 Optional

CTO Server Models

Gen10 8LFF

Gen10 12LFF

Gen10 8SFF

Gen10 24SFF

Notes:

- 2nd Generation Intel® Xeon® Scalable “Refresh” (R) Processors not qualified

- HPE offers multiple Trade Agreement Act (TAA) compliant configurations to meet the needs of US Federal Government

- TAA chassis are only orderable in North America and Canada. To

SKU associated with the respective model of choice.

- he HPE ProLiant DL380 Gen10 12 LFF CTO Server ships with the cable required for the P816i-a installation.

Notes:

- This applies to CTO configurations; field upgrades may differ depending on field configuration. 3x 8 NVMe option on SFF will only allow for partial population of Box1 to max 20 NVMe.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 41

Step 2a: Choose Required Options - Processors

k plus SKUs 8156, 6128, 5122 as noted below.

All other will processors will ship with the Standard heat sink.

Processor Option Kits

- All the below models ships with Performance Heatsink.

Intel Xeon-Platinum 8280M (2.7GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02535-L21

Intel Xeon-Platinum 8280L (2.7GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02540-L21

Intel Xeon-Platinum 8280 (2.7GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02527-L21

Intel Xeon-Platinum 8276M (2.2GHz/28-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02534-L21

Intel Xeon-Platinum 8276L (2.2GHz/28-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02539-L21

Intel Xeon-Platinum 8276 (2.2GHz/28-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02526-L21

Intel Xeon-Platinum 8270 (2.7GHz/26-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02525-L21

Intel Xeon-Platinum 8268 (2.9GHz/24-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02524-L21

Intel Xeon-Platinum 8260Y (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02508-L21

Intel Xeon-Platinum 8260M (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02532-L21

Intel Xeon-Platinum 8260L (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02538-L21

Intel Xeon-Platinum 8260 (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02521-L21

Intel Xeon-Platinum 8256 (3.8GHz/4-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02519-L21

Intel Xeon-Platinum 8253 (2.2GHz/16-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02518-L21

Notes:Do not ship with Performance Heatsink.

1st Generation Intel Xeon-Platinum

Notes:All the below models ships with Performance Heatsink.

Intel Xeon-Platinum 8180M (2.5GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

874752-L21

Intel Xeon-Platinum 8180 (2.5GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

871619-L21

Intel Xeon-Platinum 8176 (2.1GHz/28-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

871618-L21

Intel Xeon-Platinum 8170 (2.1GHz/26-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

871617-L21

Intel Xeon-Platinum 8168 (2.7GHz/24-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

869089-L21

Intel Xeon-Platinum 8165 (2.3GHz/24-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

879423-L21

Notes:

- To enable this feature an iLO Advanced, or iLO Advanced Premium Security edition License are required.

(only one of the following unless otherwise noted) Please select one –L21 processor required below. For second processor, please select the same processor model with –B21 from Core Options – HPE Processors section. For example: first processor, select 874752-L21 then for second processor, select 874752-B21.

Notes:

- 8SFF CTO 1P models ship with 4 standard fans. The second processor option kit contains 2 additional fans. 12 LFF and 24

SFF CTO Servers ship with 6 High performance fans included; 8LFF CTO Servers ship with 6 Standard fans included. High performance fan kit is available to meet ambient temperature environments and are required for rear drives or NVMe configurations.

- Maximum memory capacity per processor is dependent on processor models. All processors support up to 768 GB max

memory per processor except “M” model processors will support up to 1.5 TB max memory per processor.

- Mixing of 2 different processor models are NOT allowed.

- DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the quantity and type

of DIMMs installed.

- Processors with 130W or higher will ship with the High Performance heat sin

(Required Processor)

2nd Generation Intel Xeon-Platinum

Notes:

- Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

- Supports “Core boosting” Learn more http://www.hpe.com/info/ist.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 42

Intel Xeon-Platinumn 8164 (2.0GHz/26-core/145W) FIO Processor Kit for HPE ProLiant DL380 Gen10

869088-L21

Intel Xeon-Platinum 8160 (2.1GHz/24-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

869086-L21

Intel Xeon-Platinum 8158 (3.0GHz/12-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

869090-L21

Intel Xeon-Platinum 8153 (2.0GHz/16-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826890-L21

Notes:Do not ship with Performance Heatsink.

2nd Generation Intel Xeon-Gold

Notes:

- All the below models ship with Performance Heatsink.

Intel Xeon-Gold 6262V (1.9GHz/24-core/135W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11822-L21

Intel Xeon-Gold 6258R (2.7GHz/28-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24474-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6256 (3.6GHz/12-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24476-L21

Notes:

tray. Detailed configuration and facilities requirements can be found under “Intel Xeon

Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix” with this document.

Intel Xeon-Gold 6254 (3.1GHz/18-core/200W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02517-L21

Intel Xeon-Gold 6252N (2.3GHz/24-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11829-L21

Intel Xeon-Gold 6252 (2.1GHz/24-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02516-L21

Intel Xeon-Gold 6250 (3.9GHz/8-core/185W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24475-L21

Notes:

ilities requirements can be found under “Intel Xeon

Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix” with this document.

Intel Xeon-Gold 6248R (3.0GHz/24-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24473-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6248 (2.5GHz/20-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02514-L21

Intel Xeon-Gold 6246R (3.4GHz/16-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24472-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

HPE DL380 Gen10 Intel Xeon-Gold 6246 (3.3GHz/12-core/165W) FIO Processor Kit

P15758-L21

Intel Xeon-Gold 6244 (3.6GHz/8-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02512-L21

Intel Xeon-Gold 6242R (3.1GHz/20-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24471-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6242 (2.8GHz/16-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02510-L21

Intel Xeon-Gold 6240R (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24470-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6240L (2.6GHz/18-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02537-L21

Intel Xeon-Gold 6240M (2.6GHz/18-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02528-L21

Intel Xeon-Gold 6240Y (2.6GHz/18-14-8-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02507-L21

Intel Xeon-Gold 6240 (2.6GHz/18-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02509-L21

Intel Xeon-Gold 6238R (2.2GHz/28-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24469-L21

- Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

- Requires high performance fan kit (867810-B21), unless 24SFF or 12LFF server models are selected,

which provide high performance fans as the default.

- Not supported with NVMe SSDs, nor 2SFF HDD kits (826687-B21; 826688-B21) installed in rear, nor

GPUs, nor 4LFF mid-

- Requires high performance fan kit (867810-B21), unless 24SFF or 12LFF server models are selected,

which provide high performance fans as the default.

- Not supported with NVMe SSDs, nor 2SFF HDD kits (826687-B21; 826688-B21) installed in rear, nor

GPUs, nor 4LFF mid-tray. Detailed configuration and fac

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 43

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6238L (2.1GHz/22-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02536-L21

Intel Xeon-Gold 6238M (2.1GHz/22-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02529-L21

Intel Xeon-Gold 6238 (2.1GHz/22-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02504-L21

Intel Xeon-Gold 6234 (3.3GHz/8-core/130W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02503-L21

Intel Xeon-Gold 6230R (2.1GHz/26-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24468-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6230 (2.1GHz/20-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02502-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6230N (2.3GHz/20-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11830-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6226R (2.9GHz/16-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24467-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6226 (2.7GHz/12-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02501-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6222V (1.8GHz/20-core/115W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11823-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6212U (2.4GHz/24-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11825-L21

Notes:2-processor configurations NOT supported with this processor; secondary and tertiary risers not supported

Intel Xeon-Gold 6210U (2.5GHz/20-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11826-L21

Notes:2-processor configurations NOT supported with this processor; secondary and tertiary risers not supported

Intel Xeon-Gold 6209U (2.1GHz/20-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11827-L21

Notes:

- Do not ship with Performance Heatsink.

Intel Xeon-Gold 6208U (2.9GHz/16-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24477-L21

Intel Xeon-Gold 5222 (3.8GHz/4-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02500-L21

Intel Xeon-Gold 5220S (2.7GHz/18-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11824-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5220R (2.2GHz/24-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P23553-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 5220 (2.2GHz/18-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02499-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5218R (2.1GHz/20-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24466-L21

Notes:

- Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 5218N (2.3GHz/16-core/110W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P11831-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5218B (2.3GHz/16-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P12513-L21

- 2-processor configurations NOT supported with this processor; secondary and tertiary risers not

supported

- Do not ship with Performance Heatsink.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 44

Notes:

- Do not ship with Performance Heatsink.

Intel Xeon-Gold 5218 (2.3GHz/16-core/125W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02498-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5217 (3.0GHz/8-core/115W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02497-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215M (2.5GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02530-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215L (2.5GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02533-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215 (2.5GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02496-L21

Notes:Do not ship with Performance Heatsink.

1st Generation Intel Xeon-Gold

Notes:All the below models ships with Performance Heatsink.

Intel Xeon-Gold 6154 (3.0GHz/18-core/200W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826888-L21

Intel Xeon-Gold 6152 (2.1GHz/22-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826886-L21

Intel Xeon-Gold 6150 (2.7GHz/18-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826884-L21

Intel Xeon-Gold 6148 (2.4GHz/20-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826882-L21

Intel Xeon-Gold 6146 (3.2GHz/12-core/165W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826868-L21

Intel Xeon-Gold 6144 (3.5GHz/8-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826860-L21

Intel Xeon-Gold 6143 (2.8GHz/16-core/205W) FIO Processor Kit for HPE ProLiant DL380 Gen10

879424-L21

Notes:

- To enable this feature an iLO Advanced, or iLO Advanced Premium Security edition License are required.

Intel Xeon-Gold 6142 (2.6GHz/16-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826880-L21

Intel Xeon-Gold 6140 (2.3GHz/18-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826878-L21

Intel Xeon-Gold 6138 (2.0GHz/20-core/125W)FIO Processor Kit for HPE ProLiant DL380 Gen10

826876-L21

Intel Xeon-Gold 6137 (3.9GHz/8-core/205W) Financial Sector FIO Processor Kit for HPE DL380 Gen10

880168-L21

Notes:

https://h20195.www2.hpe.com/v2/Getdocument.aspx?docname=a00039606enw

Intel Xeon-Gold 6136 (3.0GHz/12-core/150W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826874-L21

Intel Xeon-Gold 6134 (3.2GHz/8-core/130W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826872-L21

Intel Xeon-Gold 6134M (3.2GHz/8-core/130W) FIO Processor Kit for HPE ProLiant DL380 Gen10

873645-L21

Intel Xeon-Gold 6132 (2.6GHz/14-core/140W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826870-L21

Intel Xeon-Gold 6130 (2.1GHz/16-core/120W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826866-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6128 (3.4GHz/6-core/115W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826864-L21

- 5218B has consistent features with the 5218 processor but from a different die. Mixing both 5218B &

5218 in a system is not supported

- Supports “Core boosting” Learn more http://www.hpe.com/info/ist.

- High frequency bin targeting FSI workloads. Configuration restrictions will apply, support on 8SFF only.

- The system inlet ambient temperature is restricted at 22C.

- NVMe drives CANNOT be ordered with this Processor.

- HPE DL38X Gen10 High Performance Temperature Fan Kit (867810-B21) to be selected.

- No rear drives are supported with this processor.

- No Graphic cards (GPUs) are available with this processor selection.

- For additional details on this processor please visit:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 45

Intel Xeon-Gold 6126 (2.6GHz/12-core/120W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826862-L21

Intel Xeon-Gold 5122 (3.6GHz/4-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826858-L21

Intel Xeon-Gold 5120 (2.2GHz/14-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826856-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5118 (2.3GHz/12-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826854-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5117 (2.0GHz/14-core/105W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P00756-L21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5115 (2.4GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

876562-L21

Notes:Do not ship with Performance Heatsink.

2nd Generation Intel Xeon-Silver

Notes:

- All the below models do not ship with Performance Heatsink unless otherwise noted

Intel Xeon-Silver 4216 (2.1GHz/16-core/100W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02495-L21

Intel Xeon-Silver 4215R (3.2GHz/8-core/130W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P24465-L21

Notes::

- Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4215 (2.5GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02494-L21

Intel Xeon-Silver 4214R (2.4GHz/12-core/100W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P23550-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4214Y (2.2GHz/12-10-8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02506-L21

Intel Xeon-Silver 4214 (2.2GHz/12-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02493-L21

Intel Xeon-Silver 4210R (2.4GHz/10-core/100W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P23549-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4210 (2.2GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02492-L21

Intel Xeon-Silver 4208 (2.1GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02491-L21

1st Generation Intel Xeon-Silver

Notes:All the below models do not ship with Performance Heatsink.

Intel Xeon-Silver 4116 (2.1GHz/12-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826852-L21

Intel Xeon-Silver 4114 (2.2GHz/10-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826850-L21

Intel Xeon-Silver 4112 (2.6GHz/4-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

873647-L21

Intel Xeon-Silver 4110 (2.1GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826846-L21

Intel Xeon-Silver 4108 (1.8GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

826848-L21

2nd Generation Intel Xeon-Bronze

Notes:

- All the below models do not ship with Performance Heatsink.

Intel Xeon-Bronze 3206R (1.9GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P23547-L21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Bronze 3204 (1.9GHz/6-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

P02489-L21

1st Generation Intel Xeon-Bronze

Intel Xeon-Bronze 3106 (1.7GHz/8-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

873643-L21

- Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

- Ships with Performance Heatsink.

- Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 46

Intel Xeon-Bronze 3104 (1.7GHz/6-core/85W) FIO Processor Kit for HPE ProLiant DL380 Gen10

873641-L21

Notes:Processors with 130W or higher will ship with the High Performance heatsink plus SKUs 8256, 8156, 6128, 5222, 5122 as noted below. All other will processors will ship with the Standard heat sink.

Step 2b: Choose Memory Options

rrored

Memory Kits are only supported with 1st Generation Intel Xeon Scalable Series Processors.

Registered DIMMs (RDIMMs)

HPE 8GB (1x8GB) Single Rank x8 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00918-B21

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815097-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00920-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815098-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00922-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00924-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815100-B21

HPE 64GB (1x64GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00930-B21

Load Reduced DIMMs (LRDIMMs)

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2933 CAS-21-21-21 Load Reduced Smart Memory Kit

P00926-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit

815101-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2933 CAS-24-21-21 Load Reduced 3DS Smart Memory Kit

P00928-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Memory Kit

815102-B21

HPE Persistent Memory (Intel Optane)

HPE 128GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835804-B21

HPE 256GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835807-B21

HPE 512GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835810-B21

Notes:

http://www.hpe.com/info/persistentmemory

HPE Persistent Memory (NVDIMM)

HPE 16GB NVDIMM Single Rank x4 DDR4-2666 Module Kit

845264-B21

Notes:

Please select one or more memory from below. For new Gen10 memory population rule whitepaper and optimal memory performance guidelines, please go to:

https://www.hpe.com/docs/memory-population-rules

For Gen10 memory speed table, please go to: https://www.hpe.com/docs/memory-speed-table For memory Reliability, Accessibility, Serviceability (RAS) features whitepaper like Gen10 Fast Fault Tolerance and legacy mi memory feature etc. please go to: http://www.hpe.com/docs/memory-ras-feature

Notes:

- The maximum memory speed and capacity is a function of the memory type, memory configuration, and processor model.

- DDR4-2933 Memory Kits are only supported with 2nd Generation Intel Xeon Scalable Series Processors and DDR4-2666

- A maximum of 12 HPE Persistent Memory DIMMs supported with select 2nd Generation Intel Xeon Scalable Series

Processors ONLY (82xx/62xx/52xx/4215) and can only be mixed with either RDIMMs or LRDIMMs.

- For configurations exceeding 1TB/socket, the “M” series (2TB/socket) or “L” series processors (4.5TB/socket) are

required. For information regarding HPE Persistent Memory visit:

- A maximum of 12 NVDIMMs supported.

- Can only be mixed with RDIMMs.

- For General Server Memory and NVDIMM Population Rules and Guidelines for Gen10 see details here:

http://www.hpe.com/docs/memory-population-rules

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 47

- For details on the HPE Server Memory speed, visit: https://www.hpe.com/docs/memory-speed-table

- For additional information, please see the HPE DDR4 SmartMemory QuickSpecs.

Step 2c: Choose Power Supplies

Notes:

HPE Flex Slot Power Supplies

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

Step 3: Choose Additional Factory Integratable Options

One of the following from each list may be selected if desired at time of factory integration

HPE Security Options

HPE iLO Common Password FIO Setting

P08040-B21

Notes:

Express Integration Services

HPE Trusted Platform Module 2.0 Gen10 Option

864279-B21

Notes:

any other TPM module.

HPE Gen10 TPM 1.2 FIO Setting

872108-B21

Notes:TPM 2.0 is set as default, for 1.2 TPM setting instead, please select this option.

Factory Instructions and Server Settings

HPE DL38X Gen10 4 NVMe Box 1 FIO Option

878186-B21

HPE DL38X Gen10 2 NVMe FIO Option

878189-B21

Notes:

- This will connect 2 SFF cage installed in the front of the chassis to NVMe.

HPE DL380X/Apollo 6500 Gen10 6+2 NVMe FIO Option

878192-B21

Notes:

- Indicates the cage will also have an NVMe connection.

HPE DL38X Gen10 8 SFF Front Cage Removal FIO Option

873763-B21

Notes:

- Will remove the Primary 8SFF cage in Box 3 of the 8SFF and replace with a Box blank.

HPE DL38X Gen10 Primary Riser Removal FIO Option

873766-B21

- To realize the performance memory capabilities listed in this document, HPE DDR4 SmartMemory is required.

Select one or two power supplies from below.

Mixing of 2 different power supplies is NOT allowed.

- Replaces iLO default randomized password by an HPE defined common password. HPE highly

recommends changing this password immediately after the initial onboarding process.

- Customers who want to choose their own custom iLO default password should use the HPE Factory

- HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy Mode. It is

not compatible with HPE ProLiant Gen8 servers or earlier generation variants.

- HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced with

- This is a factory integrated only option.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Configuration Information

Page 48

Notes:

HPE Legacy FIO Mode Setting

758959-B22

Notes:UEFI is the default, this FIO part can be used for CTO to enable Legacy mode.

HPE Smart Memory Fast Fault Tolerance FIO Setting

875293-B21

Notes:Fast Fault Tolerance is a new feature in Gen10 server memory that enables the system to boot with full memory performance while monitoring for DRAM device failures.

HPE 2U Bezel Air Filter NEBS-compliant Kit

P05420-B21

HPE Converged Infrastructure Management Software

HPE OneView for ProLiant DL Server including 3yr 24x7 Support FIO Bundle Physical 1-server LTU

E5Y43A

HPE OneView w/o iLO including 3yr 24x7 Support 1-server FIO LTU

P8B31A

vSAN ReadyNode

Server 6.7 Update 1.

Step 4: Choose additional options for Factory Integration from Core and Additional Options sections below

- This is a factory integrated only option.

Will remove the Primary shipping PCIe riser.

• 3, 6, 8 or 16 node vSAN Clusters (3 node minimum)

• HW is optimized for vSAN

• VMware vSAN Advanced LTU bundled

Notes:Software Requirements: VMware vSphere 6.7 Update 1, VMware vSphere with Operations Management™ 6.1 (any edition), VMware vCloud Suite 6.0 (any edition updated with 6.5) or VMware vCenter

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 49

Some options may not be integrated at the factory. To ensure only valid configurations are ordered, recommends the use of an HPE approved

Notes:The http://www.hpe.com/info/CablingMatrixGen10 can help to explain the cable routing for each option:

HPE DL38X NVMe 8 Solid State Drive Express Bay Enablement Kit

826689-B21

Notes:

partially populated with four drives if Box 2 and Box 3 are fully

- There are limitations on GPU support with the NVMe bay installed.

HPE DL38X Gen10 Universal Media Bay Kit

826708-B21

Notes:

- This is a SFF model option only.

HPE DL38X Gen10 SFF Box1/2 Cage/Backplane Kit

826691-B21

Notes:Supports 8 SAS/SATA SFF drives in Box 1 or 2 to a max of 24 SFF SAS/SATA front.

HPE DL38X Gen10 Premium 6 SFF SAS/SATA + 2 NVMe or 8 SFF SAS/SATA Bay Kit

826690-B21

Notes:

- When adding to Box 1 the addition of the High Performance Fan kit (867810-B21) is required.

HPE DL380 Gen10 High Performance Heat Sink Kit

826706-B21

Notes:

- This kit contains 2 High Performance Heatsinks.

HPE DL38X Gen10 High Performance Temperature Fan Kit

867810-B21

Notes:

- This kit is required when Box 1, 2 and 3 are populated.

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

Notes:

- Supports UFF SCM drives.

HPE DL38X Gen10 2SFF Premium HDD Front NVMe or Front/Rear SAS/SATA Kit

826687-B21

Notes:

- Supports UFF SCM drives.

Hewlett Packard Enterprise

configurator. Contact your local sales representative for additional information.

This option provides support for up to 8 NVMe drives, and can only be populated in Box 1, Box 2 and Box

3 of the SFF chassis, note Box 1 can only be populated with NVMe drives.

The HPE DL380 Gen10 High Performance fan kit is required for NVMe support (867810-B21). The HPE DL38X Gen10 4-port 8 NVMe SlimSAS Riser (867807-B21) is required to support this.

The HPE DL380 Gen10 Universal Media bay provides front Display Port and 2xUSB 2.0; plus support for

2x SFF front drives or 2 NVME front drives (826687-B21, riser required) and ODD support (Not included); and can only be located in Box1 in either an 8 SFF or 8+8 SFF model.

This kit can be supported in Box 1, 2 or 3 and provides support for up to 6 SAS/SATA + 2 NVMe or 8 SFF

SAS/SATA drives per Box. If only populating SFF SAS/SATA, the HPE DL38X Gen10 SFF Box1/2 Cage/Backplane Kit (826691-B21) is the more appropriate option.

With NVMe drives a specific riser is required.

Required for GPU installations. Processor kits above 130W include a High Performance Heatsink, along with the 8156, 6128 and 5122.

This kit is required for specific Ambient temperature environments This kit is also required to support GPUs configurations. This is required for NVMe configurations. This kit provides maximum cooling for your Server.

2 SFF in the rear is only supported with a 24 SFF model or 12 LFF model. In the rear this leaves 1x16 slot accessible. Rear drives require the addition of the High Performance Fan kit (867810-B21).

HPE DL38X Gen10 Universal Media Bay Kit (826708-B21). NVMe drives require the addition of the High Performance Fan kit (867810-B21). NVMe drives require the addition of an NVMe capable riser. Drive cage can be used in the rear of the chassis, but will not support NVMe drives rear.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 50

HPE DL38X Gen10 8LFF Front 2NVMe HDD Bay Kit

873781-B21

Notes:

- NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE DL38X Gen10 12Gb SAS Expander Card Kit with Cables

870549-B21

Notes:SAS expander to enable 24 SFF field upgrade.

HPE DL380 Gen10 SFF Systems Insight Display Kit

826703-B21

Notes:

- Primary population in slot 3 of the primary riser.

HPE DL3XX Gen10 Rear Serial Cable and Enablement Kit

873770-B21

HPE DL38X Gen10 8LFF Front 2SFF SAS/SATA HDD Kit

867805-B21

Notes:HPE ProLiant DL380 Gen10 8LFF with Universal Media Bay Configure-to-order Server (868706-B21).

HPE 2U Bezel Air Filter NEBS-compliant Kit

P05420-B21

HPE Processors

Processor Option Kits 2

Notes:

- All the below models ship with Performance Heatsink unless otherwise noted.

Intel Xeon-Platinum 8280L (2.7GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P02540-B21

Intel Xeon-Platinum 8280M (2.7GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P02535-B21

Intel Xeon-Platinum 8280 (2.7GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P02527-B21

Intel Xeon-Platinum 8276M (2.2GHz/28-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02534-B21

Intel Xeon-Platinum 8276L (2.2GHz/28-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02539-B21

Intel Xeon-Platinum 8276 (2.2GHz/28-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02526-B21

Intel Xeon-Platinum 8270 (2.7GHz/26-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P02525-B21

Intel Xeon-Platinum 8268 (2.9GHz/24-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P02524-B21

Intel Xeon-Platinum 8260M (2.4GHz/24-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02532-B21

Intel Xeon-Platinum 8260L (2.4GHz/24-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02538-B21

Intel Xeon-Platinum 8260Y (2.4GHz/24-20-16-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02508-B21

Intel Xeon-Platinum 8260 (2.4GHz/24-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P02521-B21

Intel Xeon-Platinum 8256 (3.8GHz/4-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

P02519-B21

Intel Xeon-Platinum 8253 (2.2GHz/16-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P02518-B21

Notes:Do not ship with Performance Heatsink.

1st Generation Intel Xeon-Platinum

Intel Xeon-Platinum 8180M (2.5GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

874752-B21

Intel Xeon-Platinum 8180 (2.5GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

871619-B21

Intel Xeon-Platinum 8180 (2.5GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

871619-B21

Intel Xeon-Platinum 8176 (2.1GHz/28-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

871618-B21

Intel Xeon-Platinum 8170 (2.1GHz/26-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

871617-B21

Intel Xeon-Platinum 8168 (2.7GHz/24-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

869089-B21

Intel Xeon-Platinum 8165 (2.3GHz/24-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

879423-B21

Supports 2 NVMe in the Universal Media bay (included) on the 8 LFF model. For support of the 2 NVMe drives this will require the addition of the HPE DL38X Gen10 x8/x8/x8 1-port

2 NVMe SlimSAS Riser (867806-B21); or the HPE DL38X Gen10 2-port 4 NVMe SlimSAS Riser (867808B21).

Systems Insight Display does not ship standard but is available as a Factory Integrated or field upgrade

option.

Generation Intel Xeon-Platinum

Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 51

Notes:

- To enable this feature an iLO Advanced, or iLO Advanced Premium Security edition License are required.

Intel Xeon-Platinum 8164 (2.0GHz/26-core/145W) Processor Kit for HPE ProLiant DL380 Gen10

869088-B21

Intel Xeon-Platinum 8160 (2.1GHz/24-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

869086-B21

Intel Xeon-Platinum 8158 (3.0GHz/12-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

869090-B21

Intel Xeon-Platinum 8153 (2.0GHz/16-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

826890-B21

Notes:Do not ship with Performance Heatsink

2nd Generation Intel Xeon-Gold

Notes:

- All the below models ship with Performance Heatsink unless otherwise noted.

Intel Xeon-Gold 6262V (1.9GHz/24-core/135W) Processor Kit for HPE ProLiant DL380 Gen10

P11822-B21

Intel Xeon-Gold 6258R (2.7GHz/28-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P24474-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6256 (3.6GHz/12-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P24476-B21

Notes:

tray. Detailed configuration and facilities requirements can be found under “Intel Xeon

Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix” with this document.

Intel Xeon-Gold 6254 (3.1GHz/18-core/200W) Processor Kit for HPE ProLiant DL380 Gen10

P02517-B21

Intel Xeon-Gold 6252N (2.3GHz/24-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P11829-B21

Intel Xeon-Gold 6252 (2.1GHz/24-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02516-B21

Intel Xeon-Gold 6250 (3.9GHz/8-core/185W) Processor Kit for HPE ProLiant DL380 Gen10

P24475-B21

Notes:

ements can be found under “Intel Xeon

Scalable Series 6250 and 6256 Configuration and Facilities Requirements Matrix” with this document.

Intel Xeon-Gold 6248R (3.0GHz/24-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P24473-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6248 (2.5GHz/20-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02514-B21

Intel Xeon-Gold 6246R (3.4GHz/16-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P24472-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

HPE DL380 Gen10 Intel Xeon-Gold 6246 (3.3GHz/12-core/165W) Processor Kit

P15758-B21

Intel Xeon-Gold 6244 (3.6GHz/8-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02512-B21

Intel Xeon-Gold 6242R (3.1GHz/20-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

P24471-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6242 (2.8GHz/16-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02510-B21

Intel Xeon-Gold 6240R (2.4GHz/24-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P24470-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6240L (2.6GHz/18-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02537-B21

Intel Xeon-Gold 6240M (2.6GHz/18-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02528-B21

Intel Xeon-Gold 6240 (2.6GHz/18-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02509-B21

Intel Xeon-Gold 6240Y (2.6GHz/18-14-8-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P02507-B21

Intel Xeon-Gold 6238R (2.2GHz/28-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P24469-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Supports “Core boosting” Learn more http://www.hpe.com/info/ist.

Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

Requires high performance fan kit (867810-B21), unless 24SFF or 12LFF server models are selected,

which provide high performance fans as the default.

Not supported with NVMe SSDs, nor 2SFF HDD kits (826687-B21; 826688-B21) installed in rear, nor

GPUs, nor 4LFF mid-

Requires high performance fan kit (867810-B21), unless 24SFF or 12LFF server models are selected,

which provide high performance fans as the default.

Not supported with NVMe SSDs, nor 2SFF HDD kits (826687-B21; 826688-B21) installed in rear, nor

GPUs, nor 4LFF mid-tray. Detailed configuration and facilities requir

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 52

Intel Xeon-Gold 6238L (2.1GHz/22-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

P02536-B21

Intel Xeon-Gold 6238M (2.1GHz/22-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

P02529-B21

Intel Xeon-Gold 6238 (2.1GHz/22-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

P02504-B21

Intel Xeon-Gold 6234 (3.3GHz/8-core/130W) Processor Kit for HPE ProLiant DL380 Gen10

P02503-B21

Intel Xeon-Gold 6230R (2.1GHz/26-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P24468-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6230 (2.1GHz/20-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P02502-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6230N (2.3GHz/20-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P11830-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6226R (2.9GHz/16-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P24467-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 6226 (2.7GHz/12-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P02501-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6222V (1.8GHz/20-core/115W) Processor Kit for HPE ProLiant DL380 Gen10

P11823-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6212U (2.4GHz/24-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

P11825-B21

Notes:

Xeon Scalable Series processor.

Intel Xeon-Gold 6210U (2.5GHz/20-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P11826-B21

Notes:

Xeon Scalable Series processor.

Intel Xeon-Gold 6209U (2.1GHz/20-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P11827-B21

Notes:

- Do not ship with Performance Heatsink.

Intel Xeon-Gold 6208U (2.9GHz/16-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P24477-B21

Notes:

Xeon Scalable Series processor.

Intel Xeon-Gold 5222 (3.8GHz/4-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

P02500-B21

Intel Xeon-Gold 5220S (2.7GHz/18-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P11824-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5220R (2.2GHz/24-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

P23553-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 5220 (2.2GHz/18-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P02499-B21

Notes:Do not ship with Performance Heatsink.

2-processor configurations not supported with this processor; secondary and tertiary risers not supported Field upgrades from 1

This standalone option kit is intended to upgrade a system originally installed with a 2

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

generation Intel

2-processor configurations NOT supported with this processor; secondary and tertiary risers not supported Field upgrades from 1

This standalone option kit is intended to upgrade a system originally installed with a 2

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

generation Intel

2-processor configurations NOT supported with this processor; secondary and tertiary risers not supported Field upgrades from 1

This standalone option kit is intended to upgrade a system originally installed with a 2

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

generation Intel

Xeon Scalable Series processor.

2-processor configurations NOT supported with this processor; secondary and tertiary risers not supported Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

This standalone option kit is intended to upgrade a system originally installed with a 2nd generation Intel

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 53

Intel Xeon-Gold 5218R (2.1GHz/20-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P24466-B21

Notes:

- Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Gold 5218B (2.3GHz/16-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P12513-B21

Notes:

- Do not ship with Performance Heatsink.

Intel Xeon-Gold 5218N (2.3GHz/16-core/110W) Processor Kit for HPE ProLiant DL380 Gen10

P11831-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5218 (2.3GHz/16-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

P02498-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5217 (3.0GHz/8-core/115W) Processor Kit for HPE ProLiant DL380 Gen10

P02497-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215L (2.5GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02533-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215M (2.5GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02530-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5215 (2.5GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02496-B21

Notes:Do not ship with Performance Heatsink.

1st Generation Intel Xeon-Gold

Intel Xeon-Gold 6154 (3.0GHz/18-core/200W) Processor Kit for HPE ProLiant DL380 Gen10

826888-B21

Intel Xeon-Gold 6152 (2.1GHz/22-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

826886-B21

Intel Xeon-Gold 6150 (2.7GHz/18-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

826884-B21

Intel Xeon-Gold 6148 (2.4GHz/20-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

826882-B21

Intel Xeon-Gold 6146 (3.2GHz/12-core/165W) Processor Kit for HPE ProLiant DL380 Gen10

826868-B21

Intel Xeon-Gold 6144 (3.5GHz/8-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

826860-B21

Intel Xeon-Gold 6143 (2.8GHz/16-core/205W) Processor Kit for HPE ProLiant DL380 Gen10

879424-B21

Notes:

- To enable this feature an iLO Advanced, or iLO Advanced Premium Security Edition License are required.

Intel Xeon-Gold 6142 (2.6GHz/16-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

826880-B21

Intel Xeon-Gold 6140 (2.3GHz/18-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

826878-B21

Intel Xeon-Gold 6138 (2.0GHz/20-core/125W) Processor Kit for HPE ProLiant DL380 Gen10

826876-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 6137 (3.9GHz/8-core/205W) Financial Sector Processor Kit for HPE DL380 Gen10

880168-B21

Notes:

https://h20195.www2.hpe.com/v2/Getdocument.aspx?docname=a00039606enw

Intel Xeon-Gold 6136 (3.0GHz/12-core/150W) Processor Kit for HPE ProLiant DL380 Gen10

826874-B21

Intel Xeon-Gold 6134M (3.2GHz/8-core/130W) Processor Kit for HPE ProLiant DL380 Gen10

873645-B21

Intel Xeon-Gold 6134 (3.2GHz/8-core/130W) Processor Kit for HPE ProLiant DL380 Gen10

826872-B21

Do not ship with Performance Heatsink.

5218B has consistent features with the 5218 processor but from a different die. Mixing both 5218B &

5218 in a system is not supported

Supports “Core boosting” Learn more http://www.hpe.com/info/ist.

High frequency bin targeting FSI workloads. Configuration restrictions will apply, support on 8SFF only. The system inlet ambient temperature is restricted at 22C. NVMe drives CANNOT be ordered with this Processor. Requires HPE DL38X Gen10 High Performance Temperature Fan Kit (867810-B21) be selected. No rear drives are supported with this processor. No Graphic cards (GPUs) are available with this processor selection. For additional details on this processor please visit:

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 54

Intel Xeon-Gold 6132 (2.6GHz/14-core/140W) Processor Kit for HPE ProLiant DL380 Gen10

826870-B21

Intel Xeon-Gold 6130 (2.1GHz/16-core/120W) Processor Kit for HPE ProLiant DL380 Gen10

826866-B21

Intel Xeon-Gold 6128 (3.4GHz/6-core/115W) Processor Kit for HPE ProLiant DL380 Gen10

826864-B21

Intel Xeon-Gold 6126 (2.6GHz/12-core/120W) Processor Kit for HPE ProLiant DL380 Gen10

826862-B21

Intel Xeon-Gold 5122 (3.6GHz/4-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

826858-B21

Intel Xeon-Gold 5120 (2.2GHz/14-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

826856-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5118 (2.3GHz/12-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

826854-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5117 (2.0GHz/14-core/105W) Processor Kit for HPE ProLiant DL380 Gen10

P00756-B21

Notes:Do not ship with Performance Heatsink.

Intel Xeon-Gold 5115 (2.4GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

876562-B21

Notes:Do not ship with Performance Heatsink.

2nd Generation Intel Xeon-Silver

Notes:

- All the below models do not ship with Performance Heatsink unless otherwise noted

Intel Xeon-Silver 4216 (2.1GHz/16-core/100W) Processor Kit for HPE ProLiant DL380 Gen10

P02495-B21

Intel Xeon-Silver 4215R (3.2GHz/8-core/130W) Processor Kit for HPE ProLiant DL380 Gen10

P24465-B21

Notes:

- Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4215 (2.5GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02494-B21

Intel Xeon-Silver 4214Y (2.2GHz/12-10-8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02506-B21

Intel Xeon-Silver 4214R (2.4GHz/12-core/100W) Processor Kit for HPE ProLiant DL380 Gen10

P23550-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4214 (2.2GHz/12-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02493-B21

Intel Xeon-Silver 4210R (2.4GHz/10-core/100W) Processor Kit for HPE ProLiant DL380 Gen10

P23549-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Silver 4210 (2.2GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02492-B21

Intel Xeon-Silver 4208 (2.1GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02491-B21

1st Generation Intel Xeon-Silver

Notes:All the below models do not ship with Performance Heatsink.

Intel Xeon-Silver 4116 (2.1GHz/12-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

826852-B21

Intel Xeon-Silver 4114 (2.2GHz/10-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

826850-B21

Intel Xeon-Silver 4112 (2.6GHz/4-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

873647-B21

Intel Xeon-Silver 4110 (2.1GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

826846-B21

Intel Xeon-Silver 4108 (1.8GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

826848-B21

2nd Generation Intel Xeon-Bronze

Notes:

- All the below models do not ship with Performance Heatsink.

Intel Xeon-Bronze 3206R (1.9GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P23547-B21

Notes:Not qualified on Embedded LOM CTO Server Models.

Intel Xeon-Bronze 3204 (1.9GHz/6-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

P02489-B21

Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

Ships with Performance Heatsink.

Field upgrades from 1

generation processors (x1xx) to 2nd generation processors (x2xx) not supported.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 55

1st Generation Intel Xeon-Bronze

Notes:All the below models do not ship with Performance Heatsink.

Intel Xeon-Bronze 3106 (1.7GHz/8-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

873643-B21

Intel Xeon-Bronze 3104 (1.7GHz/6-core/85W) Processor Kit for HPE ProLiant DL380 Gen10

873641-B21

Notes:

5122.

Memory Selection

To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability, HPE recommends memory from the list located here: Best product availability is limited to US, Canada, and Latin America at this time.

Notes:

Memory Kits are only supported with 1st Generation Intel Xeon Scalable Series Processors.

HPE DDR4 Memory

Registered DIMMs (RDIMMs)

HPE 8GB (1x8GB) Single Rank x8 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00918-B21

HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815097-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00920-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815098-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00922-B21

HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

835955-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00924-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2666 CAS-19-19-19 Registered Smart Memory Kit

815100-B21

HPE 64GB (1x64GB) Dual Rank x4 DDR4-2933 CAS-21-21-21 Registered Smart Memory Kit

P00930-B21

Notes:For configurations exceeding 1TB/socket, the “M” series (2TB/socket) or “L” series processors (4.5TB/socket) are required.

Load Reduced DIMMs (LRDIMMs)

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2933 CAS-21-21-21 Load Reduced Smart Memory Kit

P00926-B21

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666 CAS-19-19-19 Load Reduced Smart Memory Kit

815101-B21

HPE 128GB (1x128GB) Quad Rank x4 DDR4-2933 CAS-21-21-21 Load Reduced Smart Memory Kit

P11040-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2666 CAS-22-19-19 3DS Load Reduced Memory Kit

815102-B21

HPE 128GB (1x128GB) Octal Rank x4 DDR4-2933 CAS-24-21-21 Load Reduced 3DS Smart Memory Kit

P00928-B21

Notes:

- Mixing of RDIMM and LRDIMM is not supported.

Up to two processors supported. HT indicates that the processor model supports Intel® Hyper-Threading Technology. Turbo2: Intel® Turbo Boost Technology 2.0 provides more computing power when you need it with

performance that adapts to spikes in your workload and delivers more performance upside than previous generation turbo technology.

DDR4 speed is the maximum memory speed of the processor. Actual memory speed may depend on the

quantity and type of DIMMs installed.

The xxxxxx-L21 is the first processor shipped, the xxxxxx-B21 is the 2nd processor and ships with 2

additional fans for factory of field installation.

Maximum memory per socket depends on the processor selected. Processors above 130W use a High Performance Heatsink, along with the 8256, 8156, 6128, 5222, and

http://www.hpe.com/products/recommend.

Maximum memory capacity and speed per processor is dependent on processor model selection or limitation. DDR4-2933 Memory Kits are only supported with 2nd Generation Intel Xeon Scalable Series Processors and DDR4-2666

Memory DIMM availability with a server platform is dependent upon completion of certification testing. The maximum memory speed is a function of the memory type, memory configuration, and processor

model.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 56

- For configurations exceeding 1TB/socket, the “M” series (2TB/socket) or “L” series processors

(4.5TB/socket) are required.

HPE Persistent Memory (Intel Optane)

HPE 128GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835804-B21

HPE 256GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835807-B21

HPE 512GB 2666 Persistent Memory Kit featuring Intel Optane DC Persistent Memory

835810-B21

Notes:

- For information regarding HPE Persistent Memory visit: http://www.hpe.com/info/persistentmemory

HPE Persistent Memory (NVDIMM)

HPE 16GB NVDIMM Single Rank x4 DDR4-2666 Module Kit

845264-B21

Notes:

- http://www.hpe.com/docs/memory-population-rules

HPE DDR-4 Blank Kit

HPE DDR4 DIMM Blank Kit

P07818-B21

HPE Optical Drives

HPE 9.5mm SATA DVD-ROM Optical Drive

726536-B21

Notes:HPE DL38X Gen10 Universal Media Bay Kit (826708-B21) is required for this option on a SFF model. No support in 12 LFF or 24 SFF models.

HPE 9.5mm SATA DVD-RW Optical Drive

726537-B21

Notes:HPE DL38X Gen10 Universal Media Bay Kit (826708-B21) is required for this option on a SFF model. No support in 12 LFF or 24 SFF models.

HPE Mobile USB DVD-RW Optical Drive

701498-B21

Notes:This is only supported on USB 3.0 ports.

Media Bay Kits

HPE DL38X Gen10 Universal Media Bay Kit

826708-B21

Notes:

- This is a SFF model option only.

A maximum of 12 HPE Persistent Memory DIMMs supported with select 2nd Generation Intel Xeon

Scalable Series Processors ONLY (82xx/62xx/52xx/4215) and can only be mixed with either RDIMMs or LRDIMMs.

For configurations exceeding 1TB/socket, the “M” series (2TB/socket) or “L” series processors

(4.5TB/socket) are required.

A maximum of 12 NVDIMMs supported with 1

Generation Intel Xeon Scalable Processors and can only be

mixed with RDIMMs.

Can only be mixed with RDIMMs. For General Server Memory and NVDIMM Population Rules and Guidelines for Gen10 see details here:

The HPE DL380 Gen10 Universal Media bay provides front Display Port and 2xUSB 2.0; plus support for

2x SFF front drives or 2 NVME front drives (826687-B21, riser required) and ODD support (Not included); and can only be located in Box1 in either an 8 SFF or 8+8 SFF model.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 57

HPE Drives

For HDDs with optimal product availability, HPE advocates HDDs from the list.

Enterprise - 12G SAS - SFF Drives

HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

881457-B21

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872481-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872479-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870759-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870757-B21

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872477-B21

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870753-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872475-B21

Midline - 12G SAS - SFF Drives

HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD

765466-B21

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

832514-B21

Midline - 12G SAS - LFF Drives

HPE 16TB SAS 12G Business Critical 7.2K LFF (3.5in) SC 1yr Wty 512e ISE HDD

P23863-B21

HPE 14TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09153-B21

HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

881779-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819201-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872487-B21

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872485-B21

Midline - 6G SATA - LFF Drives

HPE 16TB SATA 6G Business Critical 7.2K LFF (3.5in) SC 1yr Wty 512e ISE HDD

P23857-B21

HPE 14TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

P09163-B21

HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

881785-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819203-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872491-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872489-B21

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861691-B21

Midline - 6G SATA - SFF Drives

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

655710-B21

SSD Selection

For SSD selection guidance, please visit For SSDs with optimal product availability, HPE advocates SSDs from the list:

Read Intensive - 12G SAS - SFF - Solid State Drives

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04523-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04521-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04519-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04517-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06584-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06586-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06588-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06590-B21

HPE 15.3TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06592-B21

https://ssd.hpe.com/

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 58

Read Intensive - 12G SAS - SFF - SC Value SAS Digitally Signed Firmware SSD

HPE 15.36TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19911-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19909-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10446-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19907-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10444-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19905-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10442-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19903-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10440-B21

Mixed Use - 12G SAS - SFF - Solid State Drives

HPE 6.4TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19919-B21

HPE 6.4TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04539-B21

HPE 6.4TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09096-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19917-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09094-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04537-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19915-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09092-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04533-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19913-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09090-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04527-B21

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09088-B21

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04525-B21

Mixed Use - 12G SAS - SFF - SC Value SAS Digitally Signed Firmware SSD

HPE 3.84TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10460-B21

HPE 1.92TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10454-B21

HPE 960GB SAS 12G Mixed Use SC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10448-B21

Write Intensive - 12G SAS - SFF - Solid State Drives

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09102-B21

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04545-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04543-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09100-B21

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09098-B21

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04541-B21

Mixed Use - 12G SAS - LFF - Solid State Drives

HPE 1.92TB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10456-B21

HPE 960GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10450-B21

HPE 800GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P04529-B21

Mixed Use - 6G SATA - SFF - Solid State Drives

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19953-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P00896-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P21517-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18438-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05994-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19951-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07930-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 59

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18436-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09722-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05986-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19949-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07926-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18434-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09716-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05980-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD

P19947-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P07922-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18432-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P09712-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05976-B21

Mixed Use - 6G SATA - LFF - Solid State Drives

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty SSD

P19982-B21

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P09724-B21

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P07932-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P07928-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P09718-B21

HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty SSD

P19978-B21

HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P07924-B21

Very Read Optimized – QLC-NAND SATA – SFF – Solid State Drives

HPE 1.92TB SATA 6G Very Read Optimized SFF (2.5in) SC 3yr Wty SSD

P23487-B21

HPE 3.84TB SATA 6G Very Read Optimized SFF (2.5in) SC 3yr Wty SSD

P23489-B21

HPE 7.68TB SATA 6G Very Read Optimized SFF (2.5in) SC 3yr Wty SSD

P23493-B21

Read Intensive - 6G SATA - SFF - Solid State Drives

HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19945-B21

HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor

P18430-B21

HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04482-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19943-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18428-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04570-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04480-B21

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05946-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19941-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18426-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04566-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04478-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05938-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19939-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04564-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04476-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18424-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05932-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19937-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04560-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04474-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18422-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 60

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05928-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19935-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875503-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04556-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Multi Vendor SSD

P18420-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P05924-B21

Read Intensive - 6G SATA - LFF - Solid State Drives

HPE 1.92TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P09693-B21

HPE 960GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P09689-B21

HPE 480GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P09687-B21

Read Intensive - 6G SATA - M.2 - Solid State Drives

HPE 960GB SATA 6G Read Intensive M.2 2280 3yr Wty SSD

P19892-B21

HPE 480GB SATA 6G Read Intensive M.2 2280 3yr Wty SSD

P19890-B21

HPE 480GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD

875498-B21

HPE 240GB SATA 6G Read Intensive M.2 2280 3yr Wty SSD

P19888-B21

Notes:

- M.2 supports Software RAID only.

Mixed Use - 6G SATA - M.2 - Solid State Drives

HPE 480GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875490-B21

HPE 240GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875488-B21

Notes:

- M.2 supports Software RAID only.

Dual Read Intensive - 6G SATA – UFF SCM M.2 - Solid State Drives

HPE Dual 480GB SATA 6G Read Intensive M.2 - UFF to SFF SCM 3yr Wty SSD

P19896-B21

HPE Dual 240GB SATA 6G Read Intensive M.2 - UFF to SFF SCM 3yr Wty SSD

P19894-B21

Notes:SCM dual drive functionality supported on the Premium 2SFF HDD Kit (826687-B21) and 2SFF HDD Riser Kit (826688-B21). Installation on any other bay will show one M.2 drive per bay

Dual Mixed Use - 6G SATA – UFF SCM M.2 - Solid State Drives

HPE Dual 240GB SATA 6G Mixed Use M.2 - UFF to SFF SCM 3yr Wty Digitally Signed Firmware SSD

P06607-B21

Notes:SCM dual drive functionality supported on the Premium 2SFF HDD Kit (826687-B21) and 2SFF HDD Riser Kit (826688-B21). Installation on any other bay will show one M.2 drive per bay.

Read Intensive - NVMe - SFF - Solid State Drives

HPE 15.36TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07198-B21

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13682-B21

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07196-B21

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10218-B21

HPE 4TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13697-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13680-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10212-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07194-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10216-B21

HPE 2TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13695-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13678-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10214-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10210-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07192-B21

M.2 drives supported in the Primary Riser and use S100i SATA controller only.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 61

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13676-B21

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10208-B21

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07190-B21

Write Intensive - NVMe - SFF - Solid State Drives

HPE 750GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P06952-B21

HPE 375GB NVMe x4 Lanes Write Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

878014-B21

Mixed Use - 6G SATA - M.2 - Solid State Drives

HPE 240GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875488-B21

HPE 480GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875490-B21

Mixed Use - NVMe - SFF - Solid State Drives

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13674-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07185-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10226-B21

HPE 6.4TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13703-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13672-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07183-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10224-B21

HPE 3.2TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13701-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13670-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07181-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P10222-B21

HPE 1.6TB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13699-B21

HPE 800GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P13668-B21

HPE 800GB NVMe x4 Lanes Mixed Use SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07179-B21

Notes:

- NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE NVMe x8 Lanes Mixed Use HHHL

HPE 3.2TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10266-B21

HPE 1.6TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10264-B21

Hard Drive Blank Kits

HPE Universal SATA HHHL 3yr Wty M.2 Kit

878783-B21

Notes:This is a M.2 enablement standup card.

HPE Large Form Factor Hard Drive Blank Kit

666986-B21

HPE Small Form Factor Hard Drive Blank Kit

666987-B21

Hard Drive Kits

HPE DL38X Gen10 8LFF Front 2SFF SAS/SATA HDD Kit

867805-B21

Notes:For 2 SFF SAS/SATA in UMB on 8 LFF model only.

HPE DL38X Gen10 3LFF Rear SAS/SATA Drive Kit

826685-B21

Notes:

- 3 LFF rear drives will consume the 2nd riser expansion slot.

HPE DL38X Gen10 4LFF Midplane SAS/SATA HDD Kit

826686-B21

A NVME (826689-B21 or 873781-B21) or Premium (826690-B21) drive cage is required to support these drives in

conjunction with a NVMe riser kit.

HPE has qualified the NVMe drive portfolio using the Operating System inbox drivers, full detail on the

HPE Solid State Drive QuickSpecs.

NVMe drives not supported by HPE Smart Array controllers.

This is supported in the LFF model only.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 62

Notes:

- This requires High Performance Fans (867810-B21).

CPUs Supported with 4LFF mid-tray

Must install DIMM blanks on all empty DIMM Slots

System Inlet Ambient

8LFF/12LFF with 4LFF mid-tray

8LFF/12LFF + 4LFF mid-tray + any rear SAS/SATA HDDs

35C

•

• 140W (6238, 6152, 6140)

30C

•

6238R, 8176, 8170, 6150)

•

25C

•

8160, 8158, 6148, 6142, 6136)

•

20C

•

8158, 6148, 6142, 6136)

HPE DL38X Gen10 2SFF Premium HDD Front NVMe or Front/Rear SAS/SATA Kit

826687-B21

Notes:

- Drive cage can be used in the rear of the chassis, but will not support NVMe drives rear.

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

Notes:

- Supports uFF drives.

HPE DL38X NVMe 8 Solid State Drive Express Bay Enablement Kit

826689-B21

Notes:

model.

Supported with both the 8 LFF and 12 LFF models. Ships with low-profile heatsink for installation. Supporting processors below 125W. Additional processors supported with

system inlet ambient temperature limitations. See “CPUs Supported with 4LFF mid-tray” below

With this mid-tray only single-wide (8.5-inch cards with connections or less) cards are supported. This drive does support hot-swap drives.

CPU≤125W

• 135W (6262V)

• 150W (6210U)

• 165 W (8276, 8260, 8260Y, 6240R,

• 115W (5217, 6128)

• 125W (6230N)

• 130W (6234, 4215R, 6134)

• 150W (6252, 6248, 6240, 6242,

• 165W (6246, 6146)

• 200W (6254, 6154)

• 205W (8280, 8270, 8268, 8180,

HPE DL38X Gen10 Universal Media Bay Kit (826708-B21). NVMe drives require the addition of the High Performance Fan kit (867810-B21). NVMe drives require the addition of an NVMe capable riser.

140W (6132)

105W (8256, 5222, 5122, 8156)

6230R, 6226R, 6208U, 5220R, 8164,

150W (6252N, 6244, 6240Y, 6144)

8168)

CPU≤125W

• 135W (6262V)

• 140W (6238, 6152, 6140)

140W (6132)

• 150W (6210U)

• 165 W (8276, 8260, 8260Y, 6240R,

6238R, 8176, 8170, 6150)

105W (8256, 5222, 5122, 8156)

• 115W (5217, 6128)

• 125W (6230N)

• 130W (6234, 4215R 6134)

• 150W (6252, 6248, 6242, 6240, 6230R,

6226R, 6208U, 5220R, 8164, 8160,

Supports 2 SFF rear in Riser1 or 2 location – max 2 supported SFF model. Supports 2 SFF rear in Riser1 or 2 location in LFF model. Note is 3 LFF rear option is selected maximum of

one in riser 1 location.

This option provides support for up to 8NVMe drives, and can be populated in all Boxes in the 8 SFF

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 63

- A maximum of 20 NVMe drives are supported; this will mean partial population (4 drives) when the 3

- NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE DL38X Gen10 SFF Box1/2 Cage/Backplane Kit

826691-B21

Notes:Supports 8 SAS/SATA SFF drives in Box 1 or 2 to a max of 24 SFF SAS/SATA front.

HPE DL38X Gen10 Premium 6 SFF SAS/SATA + 2 NVMe or 8 SFF SAS/SATA Bay Kit

826690-B21

Notes:

HPE DL38X Gen10 8LFF Front 2NVMe HDD Bay Kit

873781-B21

Notes:

- NVMe drives require the addition of the High Performance Fan kit (867810-B21).

HPE Networking

1 Gigabit Ethernet adapters

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE Ethernet 1Gb 2-port 332T Adapter

615732-B21

HPE Ethernet 1Gb 2-port 361T Adapter

652497-B21

HPE Ethernet 1Gb 4-port 366T Adapter

811546-B21

10 Gigabit Ethernet adapters

Notes:Unless otherwise noted, one of the below 10Gb networking adapters below can be selected as

the primary networking choice (CTO) chassis. the requirement to configure with either a FlexibleLOM or select PCIe networking adapter.

HPE Ethernet 10Gb 2-port 521T Adapter

867707-B21

HPE Ethernet 10Gb 2-port 524SFP+ Adapter

P08446-B21

Notes:Legacy FIO Mode (758959-B22) not supported with this option

HPE Ethernet 10Gb 2-port 530T Adapter

656596-B21

HPE Ethernet 10Gb 2-port 530SFP Adapter

652503-B21

HPE Ethernet 10Gb 2-port 535T Adapter

813661-B21

Notes:Legacy FIO Mode (758959-B22) not supported with this option

HPE Ethernet 10Gb 2-port 537SFP+ Adapter

P08421-B21

Notes:Cannot be selected as the primary networking choice when configuring a Networking Choice

(NC) Configure-to-Order (CTO) chassis.

HPE Ethernet 10Gb 2-port 548SFP+ Adapter

P11338-B21

HPE Ethernet 10Gb 2-port 562SFP+ Adapter

727055-B21

HPE Ethernet 10Gb 2-port 562T Adapter

817738-B21

25 Gigabit Ethernet adapters

Notes:Unless otherwise noted, one of the below 10/25Gb networking adapters below can be selected

as the primary networking choice when configuring a Networking Choice (NC) Configure-to-Order

cage is populated in Box 1.

This will require the HPE DL38X Gen10 4-port 8 NVMe SlimSAS Riser (867807-B21).

This kit can be supported in Box 1, 2 or 3 and provides support for up to 6 SAS/SATA + 2 NVMe or 8 SFF

SAS/SATA drives per Box. If only populating SFF SAS/SATA, the HPE DL38X Gen10 SFF Box1/2 Cage/Backplane Kit (826691-B21) is the more appropriate option.

With NVMe drives a specific riser is required.

Supports 2 NVMe in the Universal Media bay (included) on the 8 LFF model. For support of the 2 NVMe drives this will require the addition of the HPE DL38X Gen10 x8/x8/x8 1-port

2 NVMe SlimSAS Riser (867806-B21); or the HPE DL38X Gen10 2-port 4 NVMe SlimSAS Riser (867808B21).

when configuring a Networking Choice (NC) Configure-to-Order

The DL380 Gen10 NC CTO chassis does not come with embedded networking, hence

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 64

(CTO) chassis. The DL380 Gen10 NC CTO chassis does not come with embedded networking, hence the requirement to configure with either a FlexibleLOM or select PCIe networking adapter.

HPE Ethernet 10/25Gb 2-port 621SFP28 Adapter

867328-B21

HPE Ethernet 10/25Gb 2-port 631SFP28 Adapter

817718-B21

Notes:Legacy FIO Mode (758959-B22) not supported with this option

HPE Ethernet 10/25Gb 2-port 640SFP28 Adapter

817753-B21

100 Gigabit Ethernet Adapters

HPE Ethernet 100Gb 1-port 842QSFP28 Adapter

874253-B21

Notes:

https://www.hpe.com/us/en/product adapters.4118472.html

FlexibleLOM adapters

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE Ethernet 1Gb 4-port 331FLR Adapter

629135-B22

HPE FlexFabric 10Gb 2-port 533FLR-T Adapter

700759-B21

HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter

700751-B21

HPE Ethernet 10Gb 2-port 535FLR-T Adapter

817721-B21

HPE FlexFabric 10Gb 4-port 536FLR-T Adapter

764302-B21

HPE Ethernet 10Gb 2-port 537FLR-SFP+ Adapter

P08440-B21

HPE Ethernet 10/25Gb 2-port 631FLR-SFP28 Adapter

817709-B21

HPE Ethernet 10/25Gb 2-port 640FLR-SFP28 Adapter

817749-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

HPE Ethernet 10Gb 2-port 562FLR-T Adapter

817745-B21

HPE Ethernet 10/25Gb 2-port 622FLR-SFP28 Converged Network Adapter

867334-B21

Notes:

adapters.4118472.html

HPE InfiniBand

HPE InfiniBand FDR/Ethernet 40/50Gb 2-port 547FLR-QSFP Adapter

879482-B21

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+FLR-QSFP Adapter

764285-B21

HPE InfiniBand EDR/Ethernet 100Gb 2-port 841QSFP28 Adapter

872726-B21

Notes:8SFF, 16SFF, 8LFF no restrictions; 24SFF, 12LFF supported, but limited to 25C.

HPE InfiniBand EDR 100Gb 1-port 841QSFP28 Adapter

872725-B21

HPE 100Gb 1-port OP101 QSFP28 x16 PCIe Gen3 with Intel Omni-Path Architecture Adapter

829335-B21

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter

764284-B21

HPE InfiniBand EDR/Ethernet 100Gb 1-port 840QSFP28 Adapter

825110-B21

HPE InfiniBand EDR/Ethernet 100Gb 2-port 840QSFP28 Adapter

825111-B21

HPE InfiniBand HDR100/Ethernet 100Gb 1-port 940QSFP56 Adapter

P06250-B21

The DL380 Gen10 embedded LOM chassis ships standard with 4x 1 Gb embedded A minimum of two Gigabytes (2 GB) of server memory is required per each adapter. Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be

purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

-catalog/servers/adapters/pip.models.hpe-storefabric-converged-network-

The DL380 Gen10 chassis ships with 4x 1 Gb embedded. When configuring a Networking Choice (NC) Configure-to-Order (CTO) chassis, a FlexibleLOM adapter or select stand-up

card networking adapter in the “HPE Networking” section must be selected.

Only one FlexibleLOM can be added to the server. These options are upgradeable and can be changed from the original

configuration after the server is shipped.

Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be

purchased separately. Please see the related NIC QuickSpecs for Technical Specifications and additional information:

https://www.hpe.com/us/en/product-catalog/servers/adapters/pip.models.hpe-storefabric-converged-network-

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 65

HPE InfiniBand HDR100/Ethernet 100Gb 2-port 940QSFP56 Adapter

P06251-B21

HPE InfiniBand HDR/Ethernet 200Gb 1-port 940QSFP56 Adapter

P06154-B21

Notes:Max Qty=1; Must be ordered with HPE Infiniband HDR PCIe G3 Auxiliary Card (P06154-B23)

HPE InfiniBand HDR PCIe3 Auxiliary Card with 350mm Cable Kit

P06154-B23

Notes:Max Qty=1; Must be ordered with HPE Infiniband HDR/Ethernet 200G 1p 9400QSFP56 (P06154-B21)

HPE I/O Expansion Options

Notes:

- For a Secondary/Tertiary riser, the second processor is required.

HPE DL38X Gen10 Slot 1/2 x16/x16 FIO Riser Kit

871674-B21

Notes:

- Bus width x16, x16, Connector Width x16, x16.

HPE DL38X Gen10 x16/x16 GPU Slot2/3 FIO Riser Kit

871676-B21

Notes:

- Bus width x16, x16, Connector Width x16, x16.

HPE DL38X Gen10 x8/x8/x8 1-port 2 NVMe Slim SAS FIO Riser Kit

871673-B21

Notes:

selected.

HPE DL38X Gen10 x16/x16/x16 Primary GPU FIO Riser Kit

P14374-B21

Notes:

(3) be populated.

HPE DL38X Gen10 x16/x16/x16 Secondary GPU FIO Riser Kit

P14373-B21

Notes:

must

- Bus width x8, x16, x8; Connector width x16, x16, x16

The Primary Riser shipping default in the chassis is a x8 FH, FL, x16 FH, FL and x8 FH, HL with m.2

support.

Slot 1 (Top slot) and 2 (Middle slot) available in Primary riser location Replaces the default Primary riser Max Qty=1 Double-wide Accelerator/GPU can be populated Supports Full Height and Full length cards.

Slot 2 (Middle slot) and Slot 3 (Bottom slot) available in Primary riser location Replaces the default Primary riser Max Qty=1 Double-wide Accelerator/GPU can be populated Supports Full Height and Full length cards.

Slot 1 (Top slot) and 2 (Middle Slot) and 3 (Bottom slot) available in Secondary riser location with support

for 2 NVMe drives

Supports Full Height and half-length cards. Bus width x8, x8, x8 Connector Width x8, x8, x8. If this option is selected and the Premium 2SFF HDD Kit (826687-B21) has also been ordered, then the

2SFF NVMe Instruction Spec (878189-B21) MUST be selected; does not apply to 8LFF server model

If this option is selected and HPE DL38X Gen10 Premium 6SFF SAS/SATA + 2SFF NVMe Bay Kit

(826690-B21) has also been ordered, then the 6+2 NVMe Instruction Spec (878192-B21) MUST be

Slot 1 (Top slot) and 2 (Middle Slot) and 3 (Bottom slot) available in Primary riser location and must be

populated. Supports up to (3) full-height, half-length, single-width GPU/Accelerators (depending on model)

Replaces the default Primary riser Bus width x8, x16, x8; Connector width x16, x16, x16 This is a factory-integrated only (FIO) option. All slots (3) must be populated. HPE DL38X Gen10 x16/x16/x16 Secondary GPU FIO Riser Kit must also be selected and requires all slots

Slot 1 (Top slot) and 2 (Middle Slot) and 3 (Bottom slot) available in Secondary riser location; all slots

be populated. Supports up to (3) full-height, half-length, single-width GPU/Accelerators (depending on model)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 66

- This is a factory-integrated only (FIO) option. All slots (3) must be populated.

HPE DL38X Gen10 x16/x16 Riser Kit

826694-B21

Notes:

- Bus width x16, x16, Connector Width x16, x16.

HPE DL Gen10 x8/x16/x8 Riser Kit

870548-B21

Notes:

- Bus width x8, x16, x8, Connector Width x8, x16, x8.

HPE DL38X Gen10 4-port 8 NVMe Primary Slim SAS FIO Riser

867807-B21

Notes:

- To achieve max 20 NVMe support, connect 4 NVMe drives to the tertiary riser.

HPE DL Gen10 x16/x16 GPU Riser Kit

826704-B21

Notes:

https://www.hpe.com/h20195/v2/Getdocument.aspx?docname=a00043229enw

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

826688-B21

Notes:

- Bus width x16, Connector width x16

HPE DL38X Gen10 x8/x8/x8 1-port 2 NVMe SlimSAS Riser

867806-B21

Notes:

selected.

HPE DL38X Gen10 2-port 4 NVMe SlimSAS Riser

867808-B21

Notes:Supports up to 4 NVMe drives in Tertiary riser location; All PCIe lanes dedicated to NVMe; no additional slots available for expansion via stand-up cards in the Tertiary riser location.

HPE DL38X Gen10 4-port 8 NVMe Secondary Slim SAS Riser

873732-B21

Notes:Riser supporting up to 8 NVMe drives in Secondary riser location; All PCIe lanes dedicated to NVMe; no additional slots available for expansion via stand-up cards in the Secondary riser location.

Slot 1 (Top slot) and 2 (Middle slot) available in Secondary riser location. NMax Qty=1 Double-wide Accelerator/GPU can be populated Supports Full Height and Full length cards.

Slot 1 (Top slot) and 2 (Middle slot) and 3 (Bottom slot) available in Secondary riser location. No M.2 support on this riser. Supports Full Height, Half- length cards; Full Height, Full-length cards and Full Height, Half- length cards.

Riser supporting up to 8 NVMe drives in Primary location. All PCIe lanes dedicated to NVMe; no additional

slots available for expansion via stand-up cards in the Primary riser location.

Replaces the default Primary riser This is a factory integrated only option. This can be connected to an 8SFF NVMe drive cage in box 3.

Slot 2 (Middle slot) and 3 (Bottom slot) available in Secondary riser location. Max Qty=1 Double-wide Accelerator/GPU can be populated Supports Full Height and Full length cards. Bus width x16, x16, Connector Width x16, x16. For additional details on ProLiant DL Gen10 server risers please visit:

Premium bay supporting SFF SAS/SATA; can be configured in Primary or Secondary riser location Slot 3 (Bottom slot) available in Primary or Secondary Riser location, depending on configuration

Slot 1 (Top slot) or 2 (Middle Slot) or 3 (Bottom slot) available in Secondary riser location with support for

2 NVMe drives

Supports Full Height and half-length cards. Bus width x8, x8, x8 Connector Width x8, x8, x8. If this option is selected and the Premium 2SFF HDD Kit (826687-B21) has also been ordered, then the

2SFF NVMe Instruction Spec (878189-B21) MUST be selected; does not apply to 8LFF server model

If this option is selected and HPE DL38X Gen10 Premium 6SFF SAS/SATA + 2SFF NVMe Bay Kit

(826690-B21) has also been ordered, then the 6+2 NVMe Instruction Spec (878192-B21) MUST be

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 67

HPE DL38X Gen10 2 x8 PCIe Tertiary Riser Kit

875780-B21

Notes:

- Bus width x8, x8; Connector Width x8, x8.

HPE DL38X Gen10 x16 Tertiary Riser Kit

826700-B21

Notes:

- Bus width x16; Connector Width x16.

Risers

Riser Information*

Part

Description

Riser position

Bus width (Gen3 lanes)

NVMe Direct Connect

Primary

Secondary

Tertiary

Top slot

Middle Slot

Bottom slot

Ports

Drive count

n/a

This is the default riser in the chassis

D N N

x16

x8 - -

870548-B21

HPE DL Gen10 x8/x16/x8 Riser Kit

N O N

x16

x8 - -

826704-B21

HPE DL Gen10 x16/x16 GPU Riser Kit

N O N 0 x16

x16 - -

826694-B21

HPE DL38X Gen10 x16/x16 Riser Kit

N O N

x16

x16 0 - - 867807-B21

HPE DL38X Gen10 4-port 8 NVMe Primary SlimSAS Riser

O N N 0 0 0 4 8 867808-B21

HPE DL38X Gen10 2-port 4 NVMe SlimSAS Riser

N N O 0 0 0 2

873732-B21

HPE DL38X Gen10 4-port 8 NVMe Secondary SlimSAS Riser

N O N 0 0 0 4

867806-B21

HPE DL38X Gen10 x8/x8/x8 1-port 2 NVMe SlimSAS Riser

N O N

x8 1 2

871673-B21

HPE DL38X Gen10 x8/x8/x8

Riser Kit

O N N

x8 1 2

826688-B21

HPE DL38X Gen10 2SFF HDD SAS/SATA Riser Kit

O O N 0 0

x16 - -

826700-B21

HPE DL38X Gen10 x16 Tertiary Riser Kit

N N O

X16 0 0 - -

875780-B21

HPE DL38X Gen10 2 x8 PCIe Tertiary Riser Kit

N N O

X8 0 -

871674-B21

HPE DL38X Gen10 Slot 1/2 x16/x16 FIO Riser Kit

O N N

x16

x16 0 - - 871676-B21

HPE DL38X Gen10 x16/x16 GPU Slot2/3 FIO Riser Kit

O N N 0 x16

x16 - -

P14374-B21

HPE DL38X Gen10

Kit1

O N N

x16

x8 - -

P14373-B21

HPE DL38X Gen10

FIO Kit

N O N

x16

x8 - -

Slot 1 (Top slot) and slot (2) available in Tertiary riser location.

Slot 1 (Top slot) available in Tertiary riser location. Supports Full Height and full-length card.

number

1-port 2 NVMe SlimSAS FIO

x16/x16/x16 Primary GPU FIO

x16/x16/x16 Secondary GPU

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 68

Notes:

width Accelerators/GPUs (depending

HPE Power Supplies

HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865408-B21

Notes:Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector.

HPE 800W Flex Slot Titanium Hot Plug Low Halogen Power Supply Kit

865438-B21

Notes:Flex Slot Titanium power supplies support power efficiency of up to 96% and include a standard C-14 power inlet connector.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

865414-B21

Notes:Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet connector.

HPE 800W Flex Slot -48VDC Hot Plug Low Halogen Power Supply Kit

865434-B21

Notes:Flex Slot -48VDC power supplies support power efficiency of up to 94%.

HPE 800W Flex Slot Universal Hot Plug Low Halogen Power Supply Kit

865428-B21

Notes:Flex Slot universal power supplies support power efficiency of up to 94% and support both 277VAC/380VDC power inputs.

HPE 1600W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

830272-B21

Notes:Flex Slot Platinum Plus power supplies support power efficiency of up to 94% and include a C-14 power inlet connector that can support HPE Power Discovery Services (blue connector).

P14374-B21 and P14373-B21 each support up to (3) full-height, half-length, singleon Accelerator model selected), totaling (6) Accelerators in the primary riser and seconday riser (balanced across both processors in a 2-processor configuration). Connector width = x16/x16/x16; Bus width = x8/x16/x8.

D = Default on chassis; O = Optional; N = not supported or slot/connector not present. The 826687-B21 premium 2SFF cage is leveraged both UMB, plus 2SFF rear over PS. *For additional details on ProLiant DL Gen10 server risers please

visit: https://www.hpe.com/h20195/v2/Getdocument.aspx?docname=a00043229enw

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 69

Accelerators

Accelerators Information

Part

Description

Qty

Processor

16SFF

2SFF

rear

Q1K38C

AMD Radeon Instinct MI25

165W or below

1st Gen

35C

25C

25C1

25C

25C1

N/S*

Q9B37C

Intel Arria 10

Accelerator

205W or

1st and

35C

30C

25C

R0X82C

Intel FPGA

Accelerator

205W or

2nd Gen

30C

N/S*

20C

N/S*

N/S* Q7G75C

NEC Vector

Module

165W or

2nd Gen

30C

N/S*

R2U55C

HPE NVIDIA

205W or

2nd Gen

35C

35C1

35C

35C1

35C

35C1

R1F95C

HPE NVIDIA

GPU Module

205W or

2nd Gen

35C

35C1

35C

35C1

30C

30C1 R0Z45C

HPE NVIDIA

6000

205W or

1st and

35C

25C

R1F97C

HPE NVIDIA

GPU Module

205W or

2nd Gen

35C

30C

30C Q0J62C

NVIDIA Tesla

Module2

165W or

1st Gen

Gen

35C

25C1

35C

30C

30C1

Q0V80C

NVIDIA Tesla

Module

165W or

1st and

35C

25C

25C1

25C

25C1

20C

20C1

R0W29C

NVIDIA Tesla

Computational Accelerator

205W or

1st and

35C

N/S*

≤ 30C

≤20C

≤ 20C

N/S*

Q9U36C

HPE NVIDIA

Module

165W or

1st and

30C

20C

20C1

20C

20C1

N/S*

R4D73C

HPE NVIDIA

Module

165W or

2nd Gen

30C

20C

20C1

20C

20C1

N/S*

number

GX FPGA

PAC D5005 (Stratix 10 SX) FPGA

Engine Accelerator

Quadro P2200 GPU Module

Quadro RTX4000

supported

below

Generation

2nd Gen

SFF 8 LFF

+UMB with

SFF +8NVMe

SFF

SFF +SFF

LFF

LFF+ 2SFF

Quadro RTX

Quadro RTX8000

M10 32GB

P40 24GB

T4 16GB

Tesla V100 PCIe 32GB

Tesla V100S PCIe 32GB

below

2nd Gen

below

and 2nd

2nd Gen

below

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 70

Notes:

B21

HPE Computation and Graphics Accelerators

HPE Intel FPGA PAC D5005 Accelerator

R0X82C

Notes:

be added.

Intel Arria 10 GX FPGA Accelerator

Q9B37C

Notes:

- Max Qty=5 per server

HPE NEC Vector Engine Accelerator Module

Q7G75C

Notes:

- Only supported on 8SFF server models

*Not Supported

Invalid configuration or no HW support may apply to multiple GPUs installed. HW limitation may not be a thermal limitation.

Only 2xM10 can be supported (on any x16 slot 2, 5 or 7) due to system running out of PCIe lanes.

Within the column labeled “Processor Generation Supported”, “1st Gen” and/or “2nd Gen” denotes which generation of Intel

Scalable Series processors is supported on the respective GPU/FPGA; for reference, the 2nd digit of the processor model number “x1xx” and “x2xx” is used to identify the processor generation (i.e. 1=1st generation and 2=2nd generation)

1x 1600W PS recommended, but this card will work with 1x800W PS (per GPU). However check the power usage via the

HPE Power Advisor Tool located at http://www.hpe.com/info/hppoweradvisor.

Performance fans (867810-B21) are required for all GPU installations (Note these ship as standard with the 24SFF and

12LFF models).

Performance Heatsinks (826706-B21) are required for Double Wide GPU installations (Note these ship as standard on

Processors over 130W processors and the 8256, 8156, 6128, 5222 and 5122)

Mixing of GPUs is not supported. With the Standard Primary Riser the top x8 PCIe Slot connector will not be accessible with the installation of a doublewide

GPU.

Only 2 SFF rear drives supported over Power Supply as would require Riser 1 and Riser 2 for GPU support. 4 LFF mid-tray will not support any GPU cards. The M10 is limited to a max memory support of under 1TB. Any GPU installation does not meet Energy Star requirements. Installations with Graphics cards do not support Microsoft Windows Server 2012 R2 installations. For Graphics cards there is a limitation of 1 single wide GPU on the slot 2/3 riser (826704-B21 Secondary and 871676-

Primary).

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21).

System Memory Restriction <128TB This GPU requires Pwr Cable Kit (871830-B21) to also be selected. One Pwr Cable Kit can support multiple (max=3) GPUs. Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx” A Max Qty=3 per server; Max Qty=1 per riser. Only supported on 8SFF server models; an additional 8SFF drive bay and Universal Media Bay + 2SFF may

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21).

System Memory Restriction <128TB

This requires the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21. *One Pwr Cable Kit can support

multiple (max=3) Accelerators.

Only supported on 8SFF server models. 3 of these cards are supported. NEC VE requires “Max Cooling” settings in current ROM. This option requires the High Performance Fan Kit (867810-B21) and the High Performance Heatsink

(826706-B21).

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 71

- Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx”

HPE NVIDIA Quadro P2200 Graphics Accelerator

R2U55C

Notes:

- Mixing of GPUs is not supported

HPE NVIDIA Quadro RTX 6000 Graphics Accelerator

R0Z45C

Notes:

- One Pwr Cable Kit can support multiple (max=3) GPUs.

HPE NVIDIA Quadro RTX 4000 Graphics Accelerator

R1F95C

Notes:

B21) to also be selected. One Pwr Cable Kit can support multiple

- Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx”

HPE NVIDIA Quadro RTX 8000 Graphics Accelerator

R1F97C

Notes:

multiple (max=3) Accelerators.

HPE NVIDIA Tesla T4 16GB Computational Accelerator

R0W29C

Notes:

- System Memory Restriction <128TB

NVIDIA Tesla M10 Quad GPU Module

Q0J62C

Notes:

- System Memory Restriction <1TB. No support on 12LFF chassis

Max Qty=5 per server This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21); heatsink rule does not apply if ordering processors above 126W or higher.

System Memory Restriction <128TB. Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx”

Max Qty=2 per server This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21).

This GPU requires Pwr Cable Kit (871830-B21) to also be selected.

Max Qty=5 per server. This GPU requires Pwr Cable Kit (P03849-

(max=3) Accelerators.

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21)

Max Qty=2 per server This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21)

System Memory Restriction <128TB; Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx” This GPU requires Pwr Cable Kit (871830-B21) to also be selected. One Pwr Cable Kit can support

Max Qty=7 per server; Requires selection of 3x16 Primary and Secondary GPU Risers (P14374-B21,

P14373-B21) for Qty=6; Requires the addition of x16 Tertiary Riser for Qty=7. If ordering with a 24SFF CTO server model (868704-B21, or 875783-B21, or P19719-B21), the HPE DL380 Gen10 Tertiary x16 Riser (826700-B21) is required. To achieve a max of 7 with 24SFF model, the pre-selected HPE Smart Array P408i and SAS Expander must be replaced with HPE Smart Array P816i-a SR Gen10 Ctrlr (804338B21). Otherwise, Max Qty=6 for 24SFF CTO server models.

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21)

This required the HPE DL380 Gen10 8P Cable Kit 871828-B21. *One Pwr Cable Kit can support multiple

(Max=3) Accelerators.

Only 2x M10 can be supported (on any x16 slot 2, 5 or 7) due to system running out of PCIe lanes. 2 of these cards are supported with a processor 165W or below. GRID License required.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 72

HPE NVIDIA Tesla P40 24GB Computational Accelerator

Q0V80C

Notes:

(826706-B21)

HPE NVIDIA Tesla V100 PCIe 32GB Computational Accelerator

Q9U36C

Notes:

(826706-B21)

NVIDIA Tesla V100S 32GB Computational Accelerator

R4D73C

Notes:

- Only Supported with 2nd Generation Intel Scalable Series Processors "x2xx”

Graphics Cable Kits

HPE DL38x GPU 6px6p Y-Power Cable Kit

874212-B21

HPE DL38x Gen10 8-pin Cable Kit

871828-B21

HPE DL38x Gen10 8-pin Keyed Cable Kit

871829-B21

HPE GPU 2x 8-pin Cable Kit

P03849-B21

HPE DL38x Gen10 8x 6-pin Cable Kit

871830-B21

This required the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21. *One Pwr Cable Kit can support

multiple (Max=3) Accelerators.

3 of these cards are supported with a processor 165W or below. System Memory Restriction <128TB. This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21)

5 of these cards are supported. GRID License required. System Memory Restriction <128TB. Not supported on 12LFF chassis. This requires the Power Cable Kit P03849-B21. *One Pwr Cable Kit can support multiple (Max=3

Doublewide or Max=6 Singlewide) Accelerators.

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

3 of these cards are supported with a processor 165W or below. System Memory Restriction <128TB. No support on 12LFF chassis. V100 requires “Max Cooling” settings required in ROM. Exception: the need for max cooling with the V100

is not required with the 2.16 ROM [or higher/later] which added thermal support to cool the V100 with normal cooling algorithms. Reference 2.16 U30 release notes.

This requires the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21 This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

3 of these cards are supported with a processor 165W or below. System Memory Restriction <128TB. No support on 12LFF chassis. This requires the HPE DL380 Gen10 8P Keyed Cable Kit 871829-B21

This option requires the High Performance Fan Kit (867810-B21), and the High Performance Heatsink

(826706-B21)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Core Options

Page 73

HPE Cooling Options

HPE DL38X Gen10 High Performance Temperature Fan Kit

867810-B21

Notes:

h Performance fan kit is needed to support certain Passive GPGPU (Graphics cards) configurations;

This kit is required for specific Ambient temperature environments. High Performance fan kit consists of 6 fans, these will need to replace all the standard fans in the unit, and

fill all 6 fan cages.

The 12 LFF and 24 SFF models (including field upgrades to 24 SFF) will already include 6 High

Performance fan kits.

The Hig

or ASHRAE operating environments. For elevated ambient temperature support please see: http://www.hpe.com/servers/ashrae.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 74

Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional information.

Embedded Management

HPE iLO Common Password FIO Setting

P08040-B21

Notes:

Express Integration Services

HPE iLO Advanced

HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features

E6U59ABE

HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features

512485-B21

HPE iLO Advanced Flexible Quantity License with 1yr Support on iLO Licensed Features

512486-B21

HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features

512487-B21

HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features

E6U64ABE

HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features

BD505A

HPE iLO Advanced Flexible Quantity License with 3yr Support on iLO Licensed Features

BD506A

HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features

BD507A

HPE Converged Infrastructure Management Software

HPE OneView Physical Media Kit LTU

E5Y37A

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU

P8B24A

HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU

P8B25A

HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU

P8B26AAE

Notes:Licenses ship without media. The HPE OneView Media Kit can be ordered separately, or can

downloaded.

HPE PCIe Workload Accelerator Options

HPE 750GB PCIe x4 Lanes Write Intensive HHHL 3yr Wty Digitally Signed Firmware Card

878038-B21

Notes:Please see the HPE PCIe Workload Accelerators for ProLiant Servers QuickSpecs for Technical Specifications and additional information.

HPE Security

HPE iLO Common Password FIO Setting

P08040-B21

Notes:

Express Integration Services

HPE Gen10 2U Bezel Kit

867809-B21

875519-B21

Notes:Requires the bezel kit

- Replaces iLO default randomized password by an HPE defined common password. HPE highly

recommends changing this password immediately after the initial onboarding process.

- Customers who want to choose their own custom iLO default password should use the HPE Factory

- Replaces iLO default randomized password by an HPE defined common password. HPE highly

recommends changing this password immediately after the initial onboarding process.

- Customers who want to choose their own custom iLO default password should use the HPE Factory

HPE Bezel Lock Kit

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 75

HPE Gen10 Chassis Intrusion Detection Kit

867824-B21

Notes:This provides a physical connection from the chassis board and hood and detects any physical intrusion

and operation.

HPE Trusted Platform Module 2.0 Gen10 Option

864279-B21

Notes:

any other TPM module.

HPE Gen10 TPM 1.2 FIO Setting

872108-B21

Notes:This is a FIO setting to allow the TPM 2.0 module to operate in a TPM 1.2 mode.

HPE Smart Array Controllers

HPE Smart Array Gen10 Controllers Data Sheet

HPE Flexible Smart Array Performance RAID Controllers

- Flexible Smart Array controllers do not consume a PCIe slot.

HPE Smart Array P816i-a SR Gen10 (16 Internal Lanes/4GB Cache/SmartCache) 12G SAS Modular Controller

804338-B21

Notes:

- The P816i-a cable ships in the 12LFF chassis only (868705-B21).

HPE Smart Array P408i-a SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS Modular Controller

804331-B21

HPE Flexible Smart Array Essential Controllers

HPE Smart Array E208i-a SR Gen10 (8 Internal Lanes/No Cache) 12G SAS Modular Controller

804326-B21

Performance RAID Controllers

B21) or HPE Smart Storage Battery (P01366-B21), which support multiple devices and are sold separately.

HPE Smart Array P408i-p SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS PCIe Plug-in Controller

830824-B21

HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller

804405-B21

HPE Smart Array P824i-p MR Gen10 (24 Internal Lanes/4GB Cache/CacheCade) 12G SAS PCIe Controller

870658-B21

into the chassis, providing security during the entire supply chain process of shipping, receiving, distribution,

- HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not Legacy Mode. It is

not compatible with HPE ProLiant Gen8 servers or earlier generation variants.

- HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced with

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed breakout of the available Gen10 Smart Array controllers visit the

Notes:

- All performance RAID controllers are supported by the HPE Smart Storage Hybrid Capacitor (P02377-

B21) or HPE Smart Storage Battery (P01366-B21), which supports multiple devices and are sold separately.

- Includes SmartCache license.

Notes:All performance RAID controllers are supported by the HPE Smart Storage Hybrid Capacitor (P02377-

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 76

Essential RAID Controllers

HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804394-B21

HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller

804398-B21

HPE Cable Options

HPE DL380 SFF Smart Array HBA H200/P400 Series SAS Cable Kit

786092-B21

HPE DL38X Gen10 2 Drive NVMe Slim SAS Cable Kit

871827-B21

HPE DL380 Gen10 Mini SAS 3POS Cable Kit

826709-B21

HPE DL38X/560/580/ML350 Gen10 P824i-p Cable Kit

P00614-B21

Notes:For details on cabling options, additional information available here:

http://www.hpe.com/info/CablingMatrixGen10

Optional Software

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

HPE Smart Array SR SmartCache (Single Key/Single Server) LTU

D7S26A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) LTU

D7S27A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) E-LTU

D7S27AAE

Notes:SmartCache is offered on HPE Smart Array performance RAID controllers and comes standard (no licensing is required) if the HPE Smart Array P816i-a SR Gen10 Controller is installed in the server.

Optional Upgrades

HPE 96W Smart Storage Lithium-ion Battery with 145mm Cable Kit

P01366-B21

HPE Smart Storage Hybrid Capacitor with 145mm Cable Kit

P02377-B21

Notes:Provides backup power for multiple HPE Smart Array controllers or other devices. Is required with performance RAID controllers.

HPE Tape Backup

HPE Storage Options

Emulex Fibre Channel HBAs

HPE StoreFabric SN1200E 16Gb Single Port Fibre Channel Host Bus Adapter

Q0L13A

HPE StoreFabric SN1200E 16Gb Dual Port Fibre Channel Host Bus Adapter

Q0L14A

HPE StoreFabric SN1600E 32Gb Single Port Fibre Channel Host Bus Adapter

Q0L11A

HPE StoreFabric SN1600E 32Gb Dual Port Fibre Channel Host Bus Adapter

Q0L12A

QLogic Fibre Channel HBAs

HPE StoreFabric SN1100Q 16Gb Single Port Fibre Channel Host Bus Adapter

P9D93A

HPE StoreFabric SN1100Q 16Gb Dual Port Fibre Channel Host Bus Adapter

P9D94A

HPE StoreFabric SN1600Q 32Gb Single Port Fibre Channel Host Bus Adapter

P9M75A

HPE StoreFabric SN1600Q 32Gb Dual Port Fibre Channel Host Bus Adapter

P9M76A

HPE SN1610Q 32Gb 1-port Fibre Channel Host Bus Adapter

R2E08A

HPE SN1610Q 32Gb 2-port Fibre Channel Host Bus Adapter

R2E09A

For the complete range of tape drives, autoloaders, libraries and media see:

https://www.hpe.com/us/en/storage/storeever-tape-storage.html For hardware and software compatibility of Hewlett Packard Enterprise tape backup products http://www.hpe.com/storage/BURAcompatibility.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 77

Converged Network Adapters

HPE StoreFabric CN1100R Dual Port Converged Network Adapter

QW990A

HPE StoreFabric CN1100R 10GBASE-T Dual Port Converged Network Adapter

N3U52A

HPE StoreFabric CN1200E 10Gb Converged Network Adapter

E7Y06A

HPE StoreFabric CN1200E 10GBASE-T Dual Port Converged Network Adapter

N3U51A

HPE StoreFabric CN1200R 10GBASE-T Converged Network Adapter

Q0F26A

HPE StoreFabric CN1300R 10/25Gb Dual Port Converged Network Adapter

Q0F09A

HPE Racks

HPE Power Distribution Units (PDUs)

information on these products and their specifications.

their specifications.

HPE Uninterruptible Power Systems (UPS)

HPE Line Interactive Single Phase UPS QuickSpecs

HPE Rack Options

HPE KVM Switches web page

Rail Kits

HPE 2U Small Form Factor Easy Install Rail Kit

733660-B21

Notes:Does not include CMA (733664-B21).

HPE 2U Large Form Factor Easy Install Rail Kit

733662-B21

Notes:Does not include CMA (733664-B21).

HPE 2U Cable Management Arm for Easy Install Rail Kit

733664-B21

HPE 2U Small Form Factor Ball Bearing Rail Kit

720863-B21

Notes:Does not include CMA (720865-B21).

HPE 2U Large Form Factor Ball Bearing Rail Kit

720864-B21

Notes:Does not include Cable Management Arm (720865-B21).

HPE 2U Cable Management Arm for Ball Bearing Rail Kit

720865-B21

Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications. Please see the HPE Enterprise Series Racks QuickSpecs for information on additional racks options and rack specifications. Please see the HPE Standard Series Racks QuickSpecs for information on additional racks options and rack specifications.

Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs for information on these products and their specifications. Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs for information on these products and their specifications. Please see the HPE Metered and Switched Power Distribution Units (PDU) QuickSpecs for information on these products and

To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page. Please see the HPE DirectFlow Three Phase Uninterruptible Power System QuickSpecs for information on these products and their specifications. Please see the

Please see the

for information on these products and their specifications.

Ball bearing and Easy Install rail kits contain telescoping rails which allow for in-rack serviceability. To assist in the installation of the server into the rack an optional installation tool is available by contacting your local services representative (695539-001).

Notes:Hewlett Packard Enterprise recommends that a minimum of two people are required for all Rack Server installations. Please refer to your installation instructions for proper tools and number of people to use for any installation.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 78

HPE USB and SD Options

HPE Enterprise Mainstream Flash Media Kits for Memory Cards

HPE 32GB microSD RAID 1 USB Boot Drive

P21868-B21

HPE 32GB microSD Flash Memory Card

700139-B21

HPE 8GB microSD Flash Memory Card

726116-B21

HPE 8GB microSD Flash USB Drive

737953-B21

HPE 8GB Dual microSD Flash USB Drive

741279-B21

HPE Support Services

Installation & Startup Services

HPE Install ProLiant DL38x(p) Service

U4554E

HPE Installation and Startup DL38x(p) Service

U4555E

Proactive Care

HPE 3 Year Proactive Care 24x7 DL380 Gen10 Service

H8QQ0E

HPE 3 Year Proactive Care 24x7 with DMR DL380 Gen10 Service

H8QQ1E

HPE 3 Year Proactive Care 24x7 with CDMR DL380 Gen10 Service

H8QQ2E

HPE 3 Year Proactive Care Call-To-Repair DL380 Gen10 Service

H8QQ9E

HPE 3 Year Proactive Care Call-To-Repair 24x7 with DMR DL380 Gen10 Service

H8QR0E

HPE 3 Year Proactive Care Call-To-Repair with CDMR DL380 Gen10 Service

H8QR1E

Notes:For a full listing of support services available for this server, please visit https://ssc.hpe.com/

HDD Options

The options below are compatible to the sever and available for specific customer profiles:

Enterprise - 12G SAS - LFF Drives

HPE 300GB SAS 12G Enterprise 15K LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware HDD

P04693-B21

HPE 600GB SAS 12G Enterprise 15K LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware HDD

P04695-B21

Midline - 12G SAS - LFF Drives

HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857644-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861754-B21

Midline - 6G SATA - LFF Drives

HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857648-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861750-B21

SSD Options

The options below are compatible to the sever and available for specific customer profiles:

Mixed Use - 6G SATA – SFF - Solid State Drives

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P13658-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P13660-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P13662-B21

HPE 3.84TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P13664-B21

Read Intensive - 6G SATA – SFF - Solid State Drives

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06194-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06196-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06198-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Additional Options

Page 79

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06200-B21

Read Intensive - 6G SATA - M.2 - Solid State Drives

HPE 960GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD

875500-B21

Mixed Use - 6G SATA - M.2 - Solid State Drives

HPE 960GB SATA 6G Mixed Use M.2 2280 3yr Wty Digitally Signed Firmware SSD

875492-B21

Dual Read Intensive - 6G SATA – UFF SCM M.2 - Solid State Drives

HPE Dual 480GB SATA 6G Read Intensive M.2 - UFF to SFF SCM 3yr Wty Digitally Signed Firmware SSD

P06609-B21

Notes:SCM dual drive functionality supported on the Premium 2SFF HDD Kit (826687-B21) and 2SFF HDD Riser Kit (826688-B21). Installation on any other bay will show one M.2 drive per bay.

Read Intensive - 12G SAS – SFF – Solid State Drives

HPE 15.36TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty SSD

P19911-B21

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06590-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06588-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06586-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P06584-B21

Write Intensive - 12G SAS – SFF – Solid State Drives

HPE 3.2TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04547-B21

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04545-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04543-B21

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

P04541-B21

HPE NVMe x8 Lanes Mixed Use HHHL

HPE 6.4TB NVMe x8 Lanes Mixed Use HHHL 3yr Wty Digitally Signed Firmware Card

P10268-B21

Mixed Use - 12G SAS – LFF – Solid State Drives

HPE 1.92TB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10456-B21

HPE 960GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Value SAS Digitally Signed Firmware SSD

P10450-B21

HPE 800GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

P04529-B21

Read Intensive - NVMe – SFF – Solid State Drives

HPE 7.68TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07196-B21

HPE 3.84TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07194-B21

HPE 1.92TB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07192-B21

HPE 960GB NVMe x4 Lanes Read Intensive SFF (2.5in) SCN 3yr Wty Digitally Signed Firmware SSD

P07190-B21

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 80

Memory Population guidelines

HPE ProLiant Gen10 DL360 / DL380 / DL560

Notes:*

HPE ProLiant Gen10 12 slot per CPU

DIMM population order 1 DIMM

2 DIMM s

3 DIMM s

10 12

4 DIMM s

3 5 8

5 DIMM s*

3 5 8

10 12

6 DIMM s

1 3 5 8

10 12

7 DIMM s*

1 3 5 7 8

10 12

8 DIMM s

3 4 5 6 7 8 9

9 DIMM s*

1 3 5 7 8 9

10 DIMM s*

1 3 4 5 6 7 8 9

10 12

11 DIMM s*

1 3 4 5 6 7 8 9

12 DIMM s

1 2 3 4 5 6 7 8 9

Notes:*Unbalanced, not recommended

General Memory Population Rules and Guidelines:

HPE DDR4 SmartMemory QuickSpecs

Servers Front Server2 Slots per Channel

• Install DIMMs only if the corresponding processor is installed.

• If only one processor is installed in a two-processor system, only half of the DIMM slots are available.

• To maximize performance, it is recommended to balance the total memory capacity between all installed processors.

• When two processors are installed, balance the DIMMs across the two processors.

• White DIMM slots denote the first slot to be populated in a channel.

• Mixing of DIMM types (UDIMM, RDIMM, and LRDIMM) is not supported.

• The maximum memory speed is a function of the memory type, memory configuration, and processor model.

• The maximum memory capacity is a function of the number of DIMM slots on the platform, the largest DIMM capacity

qualified on the platform, and the number and model of installed processors qualified on the platform.

• For details on the HPE Server Memory Options Population Rules, visit:

http://www.hpe.com/docs/memory-population-rules

• To realize the performance memory capabilities listed in this document, HPE DDR4 SmartMemory is required. For

additional information, please see the

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 81

DIMM Type

Registered DIMM (RDIMM)

HPE SKU P/N

815097-B21

815098-B21

835955-B21

815100-B21

SKU Description

HPE 8GB (1x8GB)

Memory Kit

HPE 16GB (1x16GB)

Memory Kit

HPE 16GB (1x16GB)

Memory Kit

HPE 32GB (1x32GB)

Memory Kit

DIMM Capacity

8GB

16GB

32GB

DIMM Rank

Single Rank (1R)

Dual Rank (2R)

Voltage

1.2 V

DRAM Depth [bit]

DRAM Width [bit]

DRAM Density

8Gb

CAS Latency

19-19-19

DIMM Native Speed

2666 MT/s

Processors Officially Supported Memory Speed:

Intel Xeon®Platinum/Gold 81xx/61xx

1 RDIMM Per Channel

2666 MT/s

2 RDIMMs Per Channel

2666 MT/s

Intel Xeon®Gold/Silver 51xx/41xx

1 RDIMM Per Channel

2400 MT/s

2 RDIMMs Per Channel

2400 MT/s

Intel Xeon®Bronze 31xx

1 RDIMM Per Channel

2133 MT/s

2 RDIMMs Per Channel

2133 MT/s

HPE Server Memory Speed: Intel Xeon® Platinum/Gold 81xx/61xx Processors *

1 RDIMM Per Channel

2666 MT/s

2 RDIMMs Per Channel

2666 MT/s

HPE Server Memory Speed: Intel Xeon® Gold/Silver 51xx/41xx Processors *

1 RDIMM Per Channel

2400 MT/s

2 RDIMMs Per Channel

2400 MT/s

HPE Server Memory Speed: Intel Xeon® Bronze 31xx Processors *

1 RDIMM Per Channel

2133 MT/s

2 RDIMMs Per Channel

2133 MT/s

Notes:The maximum memory speed is a function of the memory type, memory configuration, and processor model.

Single Rank x8 DDR42666 CAS-19-19-19 Registered Smart

Single Rank x4 DDR42666 CAS-19-19-19 Registered Smart

Dual Rank x8 DDR42666 CAS-19-19-19 Registered Smart

Dual Rank x4 DDR42666 CAS-19-19-19 Registered Smart

For details on the HPE Server Memory speed, visit: https://www.hpe.com/docs/memory-speed-table

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 82

DIMM Type

Load Reduced DIMM (LRDIMM)

HPE SKU P/N

815101-B21

815102-B21

SKU Description

HPE 64GB (1x64GB) Quad Rank x4 DDR4-2666

HPE 128GB (1x128GB) Octal Rank x4 DDR4-

Kit

DIMM Capacity

64GB

128GB

DIMM Rank

Quad Rank (4R)

Octal Rank (8R)

Voltage

1.2 V

DRAM Depth [bit]

DRAM Width [bit]

DRAM Density

8Gb

CAS Latency

19-19-19

22-19-19

DIMM Native Speed

2666 MT/s

Processors Officially Supported Memory Speed:

Intel Xeon® Platinum/Gold 81xx/61xx

1 LRDIMM Per Channel

2666 MT/s

2 LRDIMMs Per Channel

2666 MT/s

Intel Xeon® Gold/Silver 51xx/41xx

1 LRDIMM Per Channel

2400 MT/s

2 LRDIMMs Per Channel

2400 MT/s

Intel Xeon® Bronze 31xx

1 LRDIMM Per Channel

2133 MT/s

2 LRDIMMs Per Channel

2133 MT/s

HPE Server Memory Speed: Intel Xeon® Platinum/Gold 81xx/61xx Processors *

1 LRDIMM Per Channel

2666 MT/s

2 LRDIMMs Per Channel

2666 MT/s

HPE Server Memory Speed: Intel Xeon® Gold/Silver 51xx/41xx Processors *

1 LRDIMM Per Channel

2400 MT/s

2 LRDIMMs Per Channel

2400 MT/s

HPE Server Memory Speed: Intel Xeon® Bronze 31xx Processors *

1 LRDIMM Per Channel

2133 MT/s

2 LRDIMMs Per Channel

2133 MT/s

Notes:The maximum memory speed is a function of the memory type, memory configuration, and processor model.

For details on the HPE Server Memory speed, visit: https://www.hpe.com/docs/memory-speed-table

CAS-19-19-19 Load Reduced Smart Memory Kit

2666 CAS-22-19-19 3DS Load Reduced Memory

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 83

DIMM type

RDIMM

HPE SKU P/N

P00918-B21

P00920-B21

P00922-B21

P00924-B21

P00930-B2

SKU description

HPE 8GB 1Rx8 PC4-2933Y-R

HPE 16GB 1Rx4 PC4-2933Y-R

HPE 16GB 2Rx8 PC4-2933Y-R

HPE 32GB 2Rx4 PC4-2933Y-R

HPE 64GB 2Rx4 PC4-2933Y-R

DIMM rank

Single rank (1R)

Dual rank (2R)

DIMM capacity

8 GB

16 GB

32 GB

64 GB

Voltage

1.2V

DRAM depth

1 Gb

2 Gb

1 Gb

2 Gb

4 Gb

DRAM width (bit)

DRAM density

8 Gb

16 Gb

CAS latency

21-21-21

DIMM native speed

2933

2933 Maximum capacity (GB)

16-slot servers

128

256

512

1024

24-slot servers

192

384

768

1536

48-slot servers

384

768

1536

3072

HPE Server Memory speed (MT/s): Intel Xeon Platinum/Gold 82xx/62xx processors*

1 DIMM per channel

2933

2 DIMM per channel

2933

HPE Server Memory speed (MT/s): Intel Xeon Gold 52xx processors*

1 DIMM per channel

2666

2 DIMM per channel

2666

HPE Server Memory speed (MT/s): Intel Xeon Silver 42xx processors

1 DIMM per channel

2400

2 DIMM per channel

2400

HPE Server Memory speed (MT/s): Intel Xeon Bronze 32xx processors

1 DIMM per channel

2133

2 DIMM per channel

2133

Notes*:

memory speed is 2666 MT/s.

(MT/s)

- Intel Xeon Gold 52xx processors support 2933 MT/s.

- HPE ProLiant DL560 and DL580 servers do not support 32xx or 42xx processors.

- Memory DIMM availability and maximum memory speed with a server platform is dependent upon completion of

certification testing.

- The maximum memory speed is a function of the memory type, memory configuration, and processor model.

- When HPE Persistent Memory for second-generation Intel Xeon Scalable processors is installed, the maximum supported

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 84

DIMM type

LRDIMM

HPE SKU P/N

P00926-B21

P00928-B21

P11040-B21

SKU description

HPE 64GB 4Rx4 PC4-2933Y-L Smart Kit

HPE 128GB 8Rx4 PC4-2933YL 3DS

HPE 128GB 4Rx4 PC4-2933YL Smart Kit

DIMM rank

Quad rank (4R)

Octal rank (8R)

Quad rank (4R)

DIMM capacity

64 GB

128 GB

Voltage

1.2V

DRAM depth

2 Gb

4 Gb

DRAM width (bit)

DRAM density

8 Gb

16 Gb

CAS latency

21-21-21

24-21-21

21-21-21

DIMM native speed

2933

2933 Maximum capacity (GB)

16-slot servers

1024

2048

24-slot servers

1536

3072

48-slot servers

3072

6144

HPE Server Memory speed (MT/s): Intel Xeon Platinum/Gold 82xx/62xx processors*

1 DIMM per channel

2933

2 DIMM per channel

2933

HPE Server Memory speed (MT/s): Intel Xeon Gold 52xx processors*

1 DIMM per channel

2666

2 DIMM per channel

2666

HPE Server Memory speed (MT/s): Intel Xeon Silver 42xx processors

1 DIMM per channel

2400

2 DIMM per channel

2400

HPE Server Memory speed (MT/s): Intel Xeon Bronze 32xx processors

1 DIMM per channel

2133

2 DIMM per channel

2133

memory speed is 2666 MT/s.

(MT/s)

- Intel Xeon Gold 52xx processors support 2933 MT/s.

- HPE ProLiant DL560 and DL580 servers do not support 32xx or 42xx processors.

- Memory DIMM availability and maximum memory speed with a server platform is dependent upon completion of

certification testing.

- The maximum memory speed is a function of the memory type, memory configuration, and processor model.

- When HPE Persistent Memory for second-generation Intel Xeon Scalable processors is installed, the maximum supported

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Memory

Page 85

Standard and Maximum Memory Capacity (Pre-configured Models)

Pre Configured Models

Standard Memory

Maximum Memory Plus

Standard Memory Replaced

3106

16 GB (1x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

4110

32 GB (2x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

4114

32 GB (2x16 GB RDIMM DR)

384 GB (24x 16 GB)

3072 GB (24x 128 GB)

5118

64 GB (2x32 GB RDIMM DR)

768 GB (24x 32 GB)

3072 GB (24x 128 GB)

6130

64 GB (2x32 GB RDIMM DR)

768 GB (24x 32 GB)

3072 GB (24x 128 GB)

DDR4 memory options part number decoder

Notes:

Capacity references are rounded to the common gigabyte (GB) values.

For more information on memory, please see the Memory Quickspecs: HPE DDR4 SmartMemory

Memory Speed Table for HPE ProLiantDL380 Gen 10

For details on the HPE Server Memory speed, please visit: https://www.hpe.com/docs/memory-speed-table

8GB = 8,192 MB 16GB = 16,384 MB 32GB = 32,768 MB 64GB = 65,536 MB

Optional Memory

with Optional Memory

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Storage

Page 86

8LFF chassis with Universal media bay and optional 2SFF and optical drive shown

12 LFF + 3 rear LFF drives

12 LFF + 2 rear SFF drives

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Storage

Page 87

6 rear SFF drives

24 SFF + rear 2 SFF drives

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 88

System Unit

Input Requirements

• 500W (Platinum) Power Supply: 100-240 VAC

BTU Rating

For 800W (Titanium) Power Supply: 2905 BTU/hr (at 200 VAC), 2899 BTU/hr (at 220 VAC), 2893 BTU/hr (at 240 VAC)

• For 500W (Platinum) Power Supply: 1902 BTU/hr (at 100 VAC), 1840 BTU/hr (at 200 VAC), 1832 BTU/hr (at 240 VAC)

Dimensions

• SFF Drives:

8.73 x 44.54 x 67.94 cm / 3.44 x 17.54 x 26.75 in

• LFF Drives:

8.73 x 44.54 x 73.02 cm / 3.44 x 17.54 x 28.75 in

Weight (approximate)

• Minimum: 8 SFF chassis with 1x SFF HDD and 7 HDD blanks, 2x Drive Bay blanks, 1x processor including standard

heatsink, 1x power supply (plus blank), 1x Smart Array, 1x Riser installed, cables for the above)

- Maximum:

19.5 kg / 43.00 lbs

- Minimum:

14.9 kg / 32.75 lbs

• Maximum: 12 LFF hard drives (no rear drives), 2x processors, 2x power supplies, 1x Smart Array, 2x Risers installed)

- Maximum:

24.5 kg / 54 lbs

- Minimum:

17.1 kg / 37.75 lbs

Rated Line Voltage

• For 1600W (Platinum): 200-240 VAC

• For 800W (Titanium) Power Supply: 200-240 VAC

• For 800W (Platinum): 100-240 VAC

• For 800W (Universal) Power Supply: 200-277 VAC

• For 800W (-48VDC): -40 Vdc to -72 Vdc

Maximum

• For 1600W Power Supply: 5918 BTU/hr (at 200 VAC), 5888 BTU/hr (at 220 VAC), 5884 BTU/hr (at 240 VAC)

•

• For 800W (Platium) Power Supply: 3067 BTU/hr (at 100 VAC), 2958 BTU/hr (at 200 VAC), 2949 BTU/hr (at 240 VAC)

• For 800W (Universal) Power Supply: 2964 BTU/hr (at 200 VAC), 2951 BTU/hr (at 230 VAC), 2936 BTU/hr (at 277

• For 800W-(48Vdc) Power Supply: 2983 BTU/hr (at -40 Vdc), 2951 BTU/hr (at -48Vdc), 2912 BTU/hr (at -72Vdc)

(per power supply)

VAC)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 89

Power Supply Output

• For 500W (Platinum) Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W (at 240 VDC) input for China only

System Inlet Temperature

at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above

35° to 40°C (95° to 104°F) at sea level with an altitude derating of 1.0°C per every 175 m (1.8°F per every 574 ft) above

-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).

Relative Humidity

5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non-condensing..

Rated Steady-State Power

• For 1600W Power Supply: 1600W (at 240 VAC), 1600W (at 240 VDC) for China only

• For 800W (Titanium) Power Supply: 800W (at 200 VAC), 800W (at 240 VAC), 800W (at 240 VDC) for China only

• For 800W (Platinum) Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W (at 240 VDC) input for China only

• For 800W (Universal) Power Supply: 800W (at 200 VAC), 800W (at 277 VAC)

• For 800W (-48VDC) Power Supply: 800W (at -40 Vdc), 800W (at -72Vdc)

• For 500W (Platinum) Power Supply: 500W (at 100 VAC), 500W (at 240 VAC), 500W (at 240 VDC) input for China only

Maximum Peak Power

• For 1600W Power Supply: 1600W (at 240 VAC), 1600W (at 240 VDC) for China only

• For 800W (Titanium) Power Supply: 800W (at 200 VAC), 800W (at 240 VAC), 800W (at 240 VDC) for China only

• For 800W (Platinum) Power Supply: 800W (at 100 VAC), 800W (at 240 VAC), 800W (at 240 VDC) input for China only

• For 800W (Universal) Power Supply: 800W (at 200 VAC), 800W (at 277 VAC)

• For 800W (-48VDC) Power Supply: 800W (at -40 Vdc), 800W (at -72Vdc)

• Standard Operating Temperature

10° to 35°C (50° to 95°F) sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate of change may be limited by the type and number of options installed. System performance during standard operating support may be reduced if operating with a fan fault or above 30°C (86°F).

• Extended Ambient Operating Temperature

For approved hardware configurations, the supported system inlet range is extended to be: 5° to 10°C (41° to 50°F) and

(per power supply)

900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

For approved hardware configurations, the supported system inlet range is extended to be: 40° to 45°C (104° to 113°F)

http://www.hpe.com/servers/ashrae

at sea level with an altitude derating of 1.0°C per every 125 m (1.8°F per every 410 ft) above 900 m (2953 ft) to a maximum of 3050 m (10,000 ft). The approved hardware configurations for this system are listed at the URL:

http://www.hpe.com/servers/ashrae

System performance may be reduced if operating in the extended ambient operating range or with a fan fault.

• Non-operating

• Operating

8% to 90% - Relative humidity (Rh), 28°C maximum wet bulb temperature, non-condensing.

• Non-operating

(non-condensing)

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 90

Altitude

9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

Acoustic Noise

- The Listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels.

Emissions Classification (EMC) – Regulatory Information

http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts

HPE Smart Array

their QuickSpecs. (E208i-a,E208i-p,E208e-p,P408i-a,P408i-p,P408e-p,P816i-a)

• Operating

3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

• Non-operating

Listed are the declared A-Weighted sound power levels (L pressure levels (L accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109). The listed sound levels apply to standard shipping configurations. Additional options may result in increased sound levels. Please have your HPE representative provide information from the HPE EMESC website for further technical details regarding the configurations listed below.

Idle

• LWAd

• LpAm

Operating

• LWAd

• LpAm

Notes:

- Acoustics levels presented here are generated by the test configuration only. Acoustics levels will vary depending on

system configuration. Values are subject to change without notification and are for reference only.

- Product conformance to cited product specifications is based on sample (type) testing, evaluation, or assessment. This

product or family of products is eligible to bear the appropriate compliance logos and statements.

) when the product is operating in a 23°C ambient environment. Noise emissions were measured in

pAm

- 4.8 B Entry

- 4.4 B Base

- 4.6 B Perf

- 37 dBA Entry

- 31 dBA Base

- 31 dBA Perf

- 4.8 B Entry

- 4.4 B Base

- 4.6 B Perf

- 37 dBA Entry

- 31 dBA Base

- 31 dBA Perf

) and declared average bystander position A-Weighted sound

WAd

To view the regulatory information for your product, view the Safety and Compliance Information for Server, Storage, Power, Networking, and Rack Products, available at the Hewlett Packard Enterprise Support Center:

For latest information on HPE Smart Array Gen10 Controllers for HPE ProLiant DL, ML and Apollo Servers please refer to

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Technical Specifications

Page 91

Environment-friendly Products and Approach End-of-life Management and Recycling

customers who integrate and re-sell Hewlett Packard Enterprise equipment.

Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs, in many geographic areas, for our products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Summary of Changes

Page 92

Date

Version History

Action

Description of Change

04-May-2020

Version 36

Changed

Pre-configured Models, Core Options and Additional Options sections were updated.

06-Apr-2020

Version 35

Changed

Overview, Standard Features, Pre-configured Models, Configuration Information and Core Options sections were updated

16-Mar-2020

Version 34

Changed

Configuration Information and Core Options sections were updated.

02-Mar-2020

Version 33

Changed

Standard Features, Configuration Information, Core Options and Additional Options sections were updated

24-Feb-2020

Version 32

Changed

Standard Features, Pre-configured Models, Configuration Information, Core Options and Additional Options sections were updated

03-Feb-2020

Version 31

Changed

Overview, Core Options, and Aditional Options . sections were updated. Obsolete SKUs were removed.

20-Jan-2020

Version 30

Changed

Standard Features, Pre-configured Models and Configuration Information sections were updated.

02-Dec-2019

Version 29

Changed

Overview, Standard Features, Configuration Information, Core Options and

Obsolete SKUs were removed.

07-Oct-2019

Version 28

Changed

Overview, Standard Features, Pre-configured Models, Core Options and

Obsolete SKU was removed.

16-Sep-2019

Version 27

Changed

Configuration Information section was updated. Obsolete SKU was removed

03-Sep-2019

Version 26

Changed

Overview, Configuration Information - Factory Integrated Models, Pre-

Obsolete SKUs were removed.

12-Aug-2019

Version 25

Changed

Overview,Standard Features,Pre-configured Models,Configuration Information

Additional Options

Obsolete SKUs were removed.

01-Jul-2019

Version 24

Changed

Pre-Configured models section was updated.

the Worldwide QuickSpecs for latest information

03-Jun-2019

Version 23

Changed

Overview, Standard Features, Configuration Information, Core Options, and

Obsolete SKUs were removed.

15-Apr-2019

Version 22

Changed

Standard Features section was updated

02-Apr-2019

Version 21

Changed

Overview, Standard Features,Pre-configured Models, Configuration

updated

04-Feb-2019

Version 20

Changed

Overview, Core Options and Optional Features sections were updated.

03-Dec-2018

Version 19

Changed

Overview, Standard Features, Core Options and Storage sections were Updated.

15-Oct-2018

Version 18

Changed

Configuration Information, Core Options and Additional Options sections were updated

01-Oct-2018

Version 17

Changed

Overview, Standard Features, Preconfigured Models, Configuration

Obsolete SKUs were removed.

13-Aug-2018

Version 16

Changed

Core Options and Additional Options were revised.

Additional Options sections were updated.

configured Models, Core Options, and Additional Options sections were updated.

- Factory Integrated Models,Core Options, SMB Models and sections were updated.

The 5218N wattage has changed from 105 to 110W TDP. The U.S. version of QuickSpecs is no longer being updated, please reference

Additional Options sections were updated. SKU descriptions were updated.

Information, Core Options, Aditional Options and Memory sections were

Information, Core Options, Additional Options, and Memory sections were updated. SKU descriptions were updated.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Summary of Changes

Page 93

06-Aug-2018

Version 15

Changed

Added new Solid State Drives offering,

11-Jun-2018

Version 14

Changed

Smart Buy Models section for the NA version was revised.

04-Jun-2018

Version 13

Changed

Added new SSDs offering to the HPE Drives section.

07-May-2018

Version 12

Changed

New SMB Models offering was added.

02-Apr-2018

Version 11

Changed

SKUs description were updated. 05-Mar-2018

Version 10

Removed

Obsolete SKUs were removed from the QuickSpecs.

05-Feb-2018

Version 9

Added

Added new SATA SSDs, NVMe drives, and PCIe accelerator cards.

18-Dec-2017

Version 8

Changed

Weight specifications were revised.

04-Dec-2017

Version 7

Changed

Added HPE Scalable Persistent Memory.

Factory Integrated Models, Core Options, and Additional Options were revised.

23-Oct-2017

Version 6

Changed

Memory speed table was updated to display the 61XX processors running at 2666MT/s.

16-Oct-2017

Version 5

Changed

8GB Dual Rank Memory was added.

25-Sep-2017

Version 4

Changed

Added new 128GB GB DIMM.

04-Sep-2017

Version 3

Changed

Smart Buy models section was revised (NA version only).

07-Aug-2017

Version 2

Changed

Added new Solid State Drives offering to the HPE Drives section.

11-Jul-2017

Version 1

New

New QuickSpecs.

Added new GPU option. Configuration Information - Factory Integrated Models, Core Options, and Additional Options were revised. Obsolete SKUs were removed from the QuickSpecs.

Core Options, Additional Options, and Memory were updated. Obsolete SKUs were removed from the QuickSpecs.

Riser Information was revised. Obsolete SKUs were removed from the QuickSpecs.

Obsolete SKUs were removed from the QuickSpecs.

Added HPE Specific IST Processor offering Gold 6143 and Platinum 8165 bins. Added Large capacity 15.3TB SSDs. Added new AMD and NVIDIA Graphics card options. Processors, Memory, Maximun Internal Storage, Configuration Information -

Riser table was added under Core Options. Platform Information, FlexibleLOM adapters, GPGPU table under Core Options, HPE Computation and Graphics Accelerators, and HPE Smart Array Controllers were revised.

Additional Intel® Xeon® Processor Scalable Family processor bins were added. Added new NVIDIA GPU cards. Added new drive options offering (SSD, m.2, NVMe). Memory, Standard Features, Configuration Information - Factory Integrated Models, Core Options, Additional Options, and Technical Specifications were revised. Obsolete SKUs were removed from the QuickSpecs.

Platform Information, Standard Features, Optional Features, Pre-configured Models, Configuration Information - Factory Integrated Models, Core Options, and Additional Options section were revised.

QuickSpecs

HPE ProLiant DL380 Gen10 Server

Copyright

Page 94

Make the right purchase decision. Contact our presales specialists.

Chat Email

Call

© Copyright 2020 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty statements accompanying such pr should be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Intel® and Xeon® are registered trademarks of Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of companies. For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less

a00008180enw - 15930 - Worldwide - V36 - 04-May-2020

updates

Get

oducts and services. Nothing herein

Intel Corporation in the U.S. and other countries.

HPE L385 Gen10 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Overview

Optional Features

Service and Support

Configuration Information

Core Options

Additional Options

Memory

Storage

Technical Specifications

Summary of Changes

Copyright

a00008180enw - 15930 - Worldwide - V36 - 04-May-2020
