QuickSpecs
HPE OfficeConnect 1920S Switch Series
Overview
1
HPE OfficeConnect 1920S Switch Series
Models
HPE OfficeConnect 1920S 8G Switch
JL380A
HPE OfficeConnect 1920S 24G 2SFP Switch
JL381A
HPE OfficeConnect 1920S 48G 4SFP Switch
JL382A
HPE OfficeConnect 1920S 8G PPoE+ 65W Switch
JL383A
HPE OfficeConnect 1920S 24G 2SFP PPoE+ 185W Switch
JL384A
HPE OfficeConnect 1920S 24G 2SFP PoE+ 370W Switch
JL385A
HPE OfficeConnect 1920S 48G 4SFP PPoE+ 370W Switch
JL386A
Key features
• Customized operation using intuitive Web interface
• 8-, 24- and 48-port non-PoE+ models are fanless for quiet operation
• Layer 3 static routing with 32 routes for network segmentation and expansion
• Access control lists for granular security control
• Spanning Tree Protocol: STP, RSTP, and MSTP
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Overview
2
• HPE Limited Lifetime warranty
Product overview
The HPE OfficeConnect 1920S Switch Series consists of advanced smart-managed fixed-configuration Gigabit switches designed
for small businesses in an easy
The series consists of seven switches including 8
models of which half the ports are POE+ capable.
ports. All ports provide non
-
and 48
sup
port Gigabit Ethernet model can
be powered by an upstream Power over Ethernet switch for environments where no lline power is available.
The series is part of the OfficeConnect portfolio of Hewlett Packard Enterprise small business networking products. These switches
provide a great value, and includes features to satisfy even the most advanced small business networks. Customizable features
include basic Layer
and IPv6 Host mode, ACLs, and Spanning Tree Protocols. HPE OfficeConnect 1920S Switch Series includes a Limited Lifetime
Warranty.
Features and benefits
Management
Quality of Service (QoS)
-to-administer solution.
- 24- and 48-port Gigabit Ethernet switches and 8-, 24- and 48-port PoE+
An additional 24-port PoE+ model is available that provides PoE+ on all 24-
-blocking Gigabit per performance. Some models include SFP ports for fiber connectivity and the 8-, 24
-port non PoE+ models are fanless, making them ideal for office deployments. All HPE OfficeConnect 1920S Switches
port flexible installation options, including mounting on wall, under table, or on desktop. The 8-
2 features like VLANs and link aggregation, as well as advanced features such as Layer 3 static routing, IPv4
• Simple Web management
Allows for easy management of the switch—even by nontechnical users—through an intuitive Web GUI; supports HTTP
and HTTP Secure (HTTPS)
• SNMPv1, v2c, and v3
Facilitate management of the switch, as the device can be discovered and monitored from an SNMP management station
• Complete session logging
Provides detailed information for problem identification and resolution
• Port mirroring
Enables traffic on a port or VLAN to be simultaneously sent to a network analyzer for monitoring
• Dual flash images
Provide independent primary and secondary operating system files for backup while upgrading
• Network Time Protocol (NTP)
Synchronizes timekeeping among distributed time servers; keeps timekeeping consistent among all clock-dependent
devices within the network so that the devices can provide diverse applications based on the consistent time
• Manual network time configuration
Manually set the date and time on the switch in the absence of an NTP server
• Default DHCP client mode
Allows the switch to be directly connected to a network, enabling plug-and-play operation; in absence of a DHCP server
on the network, the switch falls back to the static address 192.168.1.1
• FTP and TFTP
Provides different mechanisms for configuration updates; FTP allows bidirectional transfers over a TCP/IP network; trivial
FTP (TFTP) is a simpler method using user Datagram Protocol (UDP)
• Remote monitoring (RMON)
Remote monitoring (RMON) provides advanced monitoring and reporting capabilities for statistics, history, alarms and
events. RMON data is retrieved from the switch through a network management platform over SNMP.
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Overview
3
•
Connectivity
24 are PoE/PoE+ capable on the HPE OfficeConnect 1920S
hour day. The scheduler enables the flexibility to select individual days of a week as well as reoccurrence on a weekly
• IEEE 802.1p/Q VLAN tagging
• Advanced classifier based QoS
• Packet storm protection
• Rate limiting
• Class of Service (CoS)
• Powerful QoS feature
• IPv6 host
• IEEE 802.3X Flow Control
• IEEE 802.3at Power over Ethernet (PoE+)
• PoE+ port availability
• Auto-PoE power configuration
• PoE shut down mode
• PoE power allocation
• SPF ports for fiber connectivity
• Loop protection
• Auto MDI/MDI-X
Traffic prioritization
Provides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p
classification; packets are mapped to six hardware queues for more effective throughput
Delivers data to devices based on the priority and type of traffic; supports IEEE 802.1Q
Classifies traffic using multiple match criteria based on Layer 2, 3, and 4 information.
Protects against unknown unicast, broadcast and multicast storms with user-defined thresholds
Sets per-port ingress enforced maximums or percent minimum bandwidth per queue
Sets the IEEE 802.1p priority tag based on IP address, IP Type of Service (ToS), Layer 3 protocol, TCP/UDP port number
or source port
Supports the following congestion actions: strict priority queuing (SP) or weighted round robin (WRR) queuing. SP and
WRR queuing can be configured on individual switch ports.
Enables switches to be managed and deployed at the IPv6 network’s edge
Provides a flow throttling mechanism propagated through the network to prevent packet loss at a congested node
Provides up to 30 W per port, which allows support of the latest PoE+ capable devices such as Video IP phones, wireless
access points, and advanced pan/tilt/zoom security cameras, as well as any 15.4 W IEEE 802.3af-compliant end device;
mitigates the cost of additional electrical cabling and circuits that would otherwise be necessary in IP phone and WLAN
deployments
Ports 1–4 are PoE/PoE+ capable on the HPE OfficeConnect 1920S 8G PPoE+ 65W switch; ports 1–12 are PoE/PoE+
capable on the HPE OfficeConnect 1920S 24G 2SFP PPoE+ 185W switch; all ports provide PoE/PoE+ on the HPE
OfficeConnect 1920S 24G 2SFP PoE+ 370W switch; ports 1–
48G 4SFP PPoE+ 370W switch
The switch automatically assigns the required power to a port for a PD device based on Link Layer Discovery Protocol
(LLDP). Optionally, the switch permits manual, per port, PoE power configuration
A PoE scheduler provides the ability to define the hours of PoE power being supplied to a group of switch ports based on
a 24basis with a start and end date.
Support multiple methods (automatic, IEEE 802.3af class, LLDP-MED, or user-specified) to allocate PoE power for more
efficient energy savings
Provides fiber connections for uplinks and other connections across longer distances than copper cabling can support;
SFP ports are in addition to available copper Ethernet ports, providing a higher total number of available ports. Two SFP
ports available on 24 and four SFP ports on 48 port models
If the switch detects a loop, it disables the source port from forwarding data packets originating from the switch to avoid
broadcast storms
Adjusts automatically for straight-through or crossover cables on all 10/100/1000 ports
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Overview
4
•
Security
Performance
erformance by selecting the number of queues and associated memory buffering that best meet the
Layer 2 switching
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
Energy Efficient Ethernet (EEE)
Compliant with IEEE 802.3az standard requirements to save energy during periods of low data activity
• Auto-port shut down
The switch saves power by automatically shutting down power to inactive ports. Power is restored on a port upon link
detection
• Energy savings status
The switch provides an estimated cumulative energy savings due to green Ethernet features being enabled
• Energy-efficient cooling
Includes variable speed fans operating only at the speed necessary to maintain operating temperature to reduce excess
noise and power consumption by the switch
• Access Control Lists (ACLs)
Enables network traffic filtering by creating an ACL, add rules and match criteria to an ACL, and apply the ACL to permit
or deny on one or more interfaces or a VLAN. Up to 50 inbound entries may be configured based on IPv4 source and
destination IP and MAC address, Layer 4 ports and protocol type of the IPv4 packet.
• RADIUS
The switch support RADIUS authentication and configuration of up to 8 RADIUS servers
• RADIUS Accounting
A robust set of attributes and statistics are available for collecting information from the switch
• IEEE 802.1X access control
Authentication of network users on a per port basis prior to permitting network access. Port VLAN includes RADIUS
VLAN assignment, dynamic VLAN creation, guest VLAN or into an unauthenticated VLAN.
• Switch 802.1X supplicant
Enables the switch to authenticate itself to a RADIUS server
• Port isolation
Ports in a port isolation group are restricted from forwarding Layer 2 traffic between ports in that group; provides data
privacy and security
• Automatic denial-of-service protection
Monitors for malicious attacks and protects the network by blocking the attacks
• Management password
Provides security so that only authorized access to the Web browser interface is allowed
• Secure Sockets Layer (SSL)
Encrypts all HTTP traffic, secure access to the browser-based management of the switch
• Half-and full-duplex auto-negotiating capability on every port
doubles the throughput of every port
• Selectable queue configurations
Allows for increased p
requirements of the network applications
• IGMP snooping
Improves network performance through multicast filtering, instead of flooding traffic on all ports
• SFP fiber uplinks
Provides greater distance connectivity using Gigabit fiber uplinks
• Spanning Tree Protocol (STP)
Supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Overview
5
•
Layer 3 services
Layer 3 routing
traffic bottlenecks. The 8 port models support 4 trunks, 16 and 24 port models support 8 trunks, 48 port models support
Convergence
Warranty and support
BPDU filtering
Drops BPDU packets when STP is enabled globally but disabled on a specific port
• Jumbo frame support
Supports up to 9216 bytes frame size to improve the performance of large data transfers
• VLAN support and tagging
Support for IEEE 802.1Q; 256 VLANs with a VLAN ID range of 2-4093
• Address Resolution Protocol (ARP)
Displays the MAC address of another IP host in the same subnet; supports static ARPs; proxy ARP allows normal ARP
operation between subnets or when subnets are separated by a Layer 2 network
• DHCP relay
Simplifies management of DHCP addresses in networks with multiple subnets
• Static IPv4 routing
• Link aggregation
• LLDP-MED (Media Endpoint Discovery)
• Auto voice VLAN
• Limited Lifetime Warranty
Provides basic routing supporting up to 32 static routes to allow manual routing configuration
Groups together multiple ports up to a maximum of eight ports per trunk either automatically using Link Aggregation
Control Protocol (LACP), or manually, to form an ultra-high-bandwidth connection to the network backbone; help prevent
16 trunks.
Defines a standard extension of LLDP that stores values for parameters such as QoS and VLAN to configure network
devices such as IP phones automatically
Recognizes IP phones and automatically assigns voice traffic to dedicated VLAN for IP phones
See http://www.hpe.com/officeconnect/support
for warranty and support information included with your product
purchase.
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Configuration
6
Build To Order
Shippable solution.
HPE OfficeConnect 1920S 8G Switch
JL380A
•
• 1U - Height (Desktop Model)
See Configuration
No Power Cord
JL380A#AC3
•
HPE OfficeConnect 1920S 8G PPoE+ 65W Switch
JL383A
•
• 1U - Height (Desktop Model)
See Configuration
PDU Cable NA/MX/TW/JP
JL383A#B2B
• C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW
JL383A#B2C
•
No Power Cord
JL383A#AC3
• No Localized Power Cord Selected
HPE OfficeConnect 1920S 24G 2SFP Switch
JL381A
•
• 1U - Height
See Configuration
PDU Cable NA/MX/TW/JP
JL381A#B2B
• C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW
JL381A#B2C
• C15 PDU Jumper Cord (ROW)
No Power Cord
JL381A#AC3
• No Localized Power Cord Selected
HPE OfficeConnect 1920S 24G 2SFP PPoE+ 185W Switch
JL384A
•
• 1U - Height
See Configuration
PDU Cable NA/MX/TW/JP
JL384A#B2B
•
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
8 RJ-45 autosensing 10/100/1000 ports
No Localized Power Cord Selected
4 RJ-45 autosensing 10/100/1000 PoE+ ports
• 4 RJ-45 autosensing 10/100/1000 ports
NOTE: 2
NOTE: 2
C15 PDU Jumper Cord (ROW)
24 RJ-45 autosensing 10/100/1000 ports
• 2 SFP 100/1000 Mbps ports (min=0 \ max=2 SFP Transceivers)
12 RJ-45 autosensing 10/100/1000 PoE+ ports
• 12 RJ-45 autosensing 10/100/1000 ports
• 2 SFP 100/1000 Mbps ports (min=0 \ max=2 SFP Transceivers)
NOTE: 2, 3
NOTE: 2, 3
C15 PDU Jumper Cord (NA/MX/TW/JP)
Page
QuickSpecs
HPE OfficeConnect 1920S Switch Series
Configuration
7
PDU Cable ROW
JL384A#B2C
• C15 PDU Jumper Cord (ROW)
No Power Cord
JL384A#AC3
• No Localized Power Cord Selected
HPE OfficeConnect 1920S 24G 2SFP PoE+ 370W Switch
JL385A
•
• 1U - Height
See Configuration
PDU Cable NA/MX/TW/JP
JL385A#B2B
• C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW
JL385A#B2C
• C15 PDU Jumper Cord (ROW)
No Power Cord
JL385A#AC3
•
HPE OfficeConnect 1920S 48G 4SFP Switch
JL382A
•
• 1U - Height
See Configuration
PDU Cable NA/MX/TW/JP
JL382A#B2B
• C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW
JL382A#B2C
• C15 PDU Jumper Cord (ROW)
No Power Cord
JL382A#AC3
• No Localized Power Cord Selected
HPE OfficeConnect 1920S 48G 4SFP PPoE+ 370W Switch
JL386A
•
• 1U - Height
See Configuration
PDU Cable NA/MX/TW/JP
JL386A#B2B
• C15 PDU Jumper Cord (NA/MX/TW/JP)
PDU Cable ROW
JL386A#B2C
• C15 PDU Jumper Cord (ROW)
No Power Cord
JL386A#AC3
• No Localized Power Cord Selected
24 RJ-45 autosensing 10/100/1000 PoE+ ports
• 2 SFP 100/1000 Mbps ports (min=0 \ max=2 SFP Transceivers)
No Localized Power Cord Selected
NOTE:2, 3
48 RJ-45 autosensing 10/100/1000 ports
• 4 SFP 100/1000 Mbps ports (min=0 \ max=4 SFP Transceivers)
24 RJ-45 autosensing 10/100/1000 PoE+ ports
• 24 RJ-45 autosensing 10/100/1000 ports
• 4 SFP 100/1000 Mbps ports (min=0 \ max=4 SFP Transceivers)
NOTE:2, 3
NOTE:2, 3
Page
Loading...
