QuickSpecs
HPE OfficeConnect 1850 Switch Series
Overview
1
HPE OfficeConnect 1850 Switch Series
Models
HPE OfficeConnect 1850 6XGT and 2XGT/SPF+ Switch
JL169A
HPE OfficeConnect 1850 24G 2XGT Switch
JL170A
HPE OfficeConnect 1850 48G 4XGT Switch
JL171A
HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch
JL172A
HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch
JL173A
Key features
• 10-Gigabit 10GBASE-T on all models for high-speed interconnect
Product overview
HPE OfficeConnect 1850 Switch Series devices are basic smart-managed, fixed-configuration Gigabit plus 10 Gigabit Ethernet
Layer 2 switches designed for small businesses looking for high performance in an easy
administer solution. The series is part of
the OfficeConnect portfolio of Hewlett Packard Enterprise small busines
The series consists of five switch models. Four are Gigabit switches each with 10
port
10
at 10-Gigabit speeds. Non-PoE and PoE+ models are available. The 24 port models include 2 10GBASE-T ports; the 48 port
• Non-PoE and PoE+ 24- and 48 port models
• 8 port 10GBASE-T switch with 2 SFP+ dual-personality ports
• Intuitive Web management interface for easy switch configuration
• Limited Lifetime Warranty
-to-
s networking products.
-Gigabit 10GBASE-T uplink ports. One is an 8-
-Gigabit aggregator switch. Together, you can build a high bandwidth network with Gigabit edge port switches interconnected
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Overview
2
models include 4 10GBASE-T ports and an 8 port model includes 8 10GBASE-T ports with 2 dual-personality SFP+ ports. All HPE
OfficeConnect 1850 Switches support flexible installation options including mounting on wall, under table, or on a desktop.
These Gigabit switches are plug
a simple web browser
agg
Ethernet (EEE) and idle
maintain
Series includes a Limited Lifetime Warranty.
Features and benefits
Management
play operation; in absence of a DHCP server on
Quality of Service (QoS)
Connectivity
provides up to 30W per port, which allows support of the latest PoE+-capable devices such as IP phones, wireless access
regation trunking and DSCP QoS policies. All models include the latest energy-saving capabilities, including Energy Efficient
• Simple Web management
• SNMPv1, v2c
• Port mirroring
• Dual flash images
• Network Time Protocol (NTP)
• Manual network time configuration
• Default DHCP client mode
-and-play out of the box, yet network operation can be fine-tuned through features available from
-based GUI, if necessary. Customizable features include VLANs, Rapid Spanning Tree, IGMP Snooping, link
-port power down. All models include variable speed fans operating only at the speed necessary to
operating temperature to reduce excess noise and power consumption by the switch. HPE OfficeConnect 1850 Switch
allows for easy management of the switch—even by nontechnical users—through an intuitive Web GUI; supports HTTP
and HTTP Secure (HTTPS)
enables devices to be discovered and monitored from an SNMP management station
enables traffic on a port to be simultaneously sent to a network analyzer for monitoring
provides independent primary and secondary operating system files for backup while upgrading
synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clockdependent devices within the network
manually set the date and time on the switch in the absence of an NTP server
allows the switch to be directly connected to a network, enabling plug-andthe network, the switch falls back to a default, fixed IP address
• Traffic prioritization
provides time-sensitive packets (like VoIP and video) with priority over other traffic based on DSCP or IEEE 802.1p
classification; packets are mapped to eight hardware queues for more effective throughput
• Broadcast control
allows limiting of broadcast traffic rate to reduce unwanted network broadcast traffic
• IEEE 802.1p/Q
delivers data to devices based on the priority and type of traffic; supports IEEE 802.1Q Virtual LANs (VLANs)
• Auto-MDI/MDIX
automatically adjusts for straight-through or crossover cables on all ports
• IEEE 802.3X flow control
provides a flow throttling mechanism propagated through the network to prevent packet loss at a congested node
• Loop protection
if the switch detects a loop, it disables the source port from forwarding data packets originating from the switch to avoid
broadcast storms.
• IEEE 802.3at Power over Ethernet (PoE+)
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Overview
3
points, and security cameras, as well as any IEEE 802.3af-compliant end device; lowers the cost of additional electrical
ll models include variable speed fans operating only at the speed necessary to maintain operating temperature to reduce
Security
Performance
Layer 2 switching
Resiliency and hig
cabling and circuits that would otherwise be necessary in IP phone and WLAN deployments
• PoE+ port availability
ports 1 – 12 provide PoE+ on the HPE 1850 24G 2XGT PoE+ 185W Switch. Ports 1-24 provide PoE+ on the HPE 1850
48G 4XGT PoE+ 370W Switch.
• Auto PoE power configuration
the switch automatically assigns the required power to a port for a PD device based on LLDP (Link Layer Discovery
Protocol). Optionally, the switch permits manual, per port, PoE power configuration.
• PoE shut down mode
a PoE scheduler provides the ability to define the hours of PoE power being supplied on a group of switch ports based on
a 24 hour day. The scheduler enables the flexibility to select individual days of a week as well as reccurrence on a weekly
basis with a start and end date
• Energy Efficient Ethernet
compliant with IEEE 802.3az standard requirements to save energy during periods of low data activity.
• Auto port shut-down
the switch saves power by automatically shutting down power to inactive ports. Power is restored on a port upon link
detection
• Energy efficient cooling
a
excess noise and power consumption by the switch
• Energy savings status
the switch provides an estimated cumulative energy savings due to green Ethernet features enabled
• Secure Socket Layer (SSL)
encrypts all HTTP traffic, allowing secure access to the browser-based management GUI in the switch.
• Automatic denial-of-service protection
monitors nine types of malicious attacks and protects the network by blocking these attacks
• Management password
provides security so that only authorized access to the Web browser interface is allowed
• Half- and full-duplex auto-negotiating capability on every port
doubles the throughput of every port
• IGMP snooping
improves network performance through multicast filtering, instead of flooding traffic to all ports.
• VLAN support and tagging
supports up to 64 port-based VLANs and dynamic configuration of IEEE 802.1Q VLAN tagging, providing security
between workgroups
• Jumbo packet support
improves the performance of large data transfers; supports frame size of up to 9220 bytes
• IEEE 802.1D Spanning Tree Protocol (STP) and IEEE 802.1W Rapid Spanning Tree Protocol (RSTP)
provides redundant links while preventing network loops
• Link aggregation
brings together groups of ports automatically using Link Aggregation Control Protocol (LACP) or, manually, to form an
h availability
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Overview
4
ultra-high-bandwidth connection to the network backbone; helps prevent traffic bottlenecks; the 8 port model supports 4
Ease of use
Flexibility
Warranty and support
trunks, the 24-port models support 8 trunks and the 48-port models support 16 trunks. The 8- and 24-port switches can
support up to 4 ports per trunk, the 48-port switches can support up to 8 ports per trunk
• Locator LED
allows users to set the locator LED on a specific switch to either turn on, blink, or turn off; simplifies troubleshooting by
making it easy to locate a particular switch within a rack of similar switches
• Comprehensive LED display with per-port indicators
provides an at-a-glance view of status, activity, speed, and full-duplex operation.
• Flexible installation
allows mounting on wall, desktop, or under-table with supplied hardware
• Rack mountable
all models include rack-mounting hardware for mounting in a standard 19 inch telco rack.
• Limited Lifetime Warranty
See http://www.hpe.com/officeconnect/support
purchase.
for warranty and support information included with your product
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Configuration
5
Build To Order
Shippable solution.
HPE OfficeConnect 1850 6XGT and 2XGT/SPF+ Switch
JL169A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL169A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL169A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL169A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL169A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 24G 2XGT Switch
JL170A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL170A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL170A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL170A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL170A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 48G 4XGT Switch
JL171A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL171A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL171A#B2C
• C13 PDU Jumper Cord (ROW)
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
6 RJ-45 1/10GBASE-T ports
• 2 Dual Personality SFP+ 1/10GBASE-T ports (min=0 \ max=2 SFP/SFP+ Transceivers)
NOTE:1, 2
24 RJ-45 autosensing 10/100/1000 ports
• 2 RJ-45 1/10GBASE-T ports
48 RJ-45 autosensing 10/100/1000 ports
• 4 RJ-45 1/10GBASE-T ports
NOTE: 2
NOTE: 2
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Configuration
6
High Volt Switch to Wall Power Cord
JL171A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL171A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch
JL172A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL172A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL172A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL172A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL172A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch
JL173A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL173A#B2B
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL173A#B2C
• C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL173A#B2E
• HPE 2.5m C15 to NEMA 6-20P 250V Non-locking Power Cord (JL336A)
No Power Cord
JL173A#AC3
• No Localization Power Cord Selected
Configuration Rules:
Note 1
The following Transceivers install into this switch:
Aruba 1G SFP LC SX 500m MMF XCVR
J4858D
Aruba 1G SFP LC LX 10km SMF XCVR
J4859D
12 RJ-45 autosensing 10/100/1000 PoE+ ports
• 12 RJ-45 autosensing 10/100/1000 ports
• 2 RJ-45 1/10GBASE-T ports
NOTE: 2
24 RJ-45 autosensing 10/100/1000 PoE+ ports
• 24 RJ-45 autosensing 10/100/1000 ports
• 4 RJ-45 1/10GBASE-T ports
NOTE: 2
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Configuration
7
Aruba 10G SFP+ LC SR 300m MMF XCVR
J9150D
Aruba 10G SFP+ LC LR 10km SMF XCVR
J9151D
Aruba 10G SFP+ LC LRM 220m MMF XCVR
J9152D
Aruba 10G SFP+ to SFP+ 1m DAC Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m DAC Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m DAC Cable
J9285D
Note 2
Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) or #B2E. (See
Localization Menu)
If #AC3 is selected then no Localized Power Cord is required.
Remarks:
OCA Only Model Selection Form HPE Offering > Aruba > OfficeConnect
HPE OfficeConnect 1850 Switch Series
Rack Level Integration CTO Models
HPE OfficeConnect 1850 24G 2XGT Switch
JL170A
•
•
See Configuration
PDU Cable NA/MEX/TW/JP
JL170A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL170A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL170A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL170A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 48G 4XGT Switch
JL171A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL171A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL171A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL171A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL171A#AC3
• No Localization Power Cord Selected
24 RJ-45 autosensing 10/100/1000 ports
• 2 RJ-45 1/10GBASE-T ports
1U - Height
- Smart Web Managed Switch:
NOTE:2, 3
48 RJ-45 autosensing 10/100/1000 ports
• 4 RJ-45 1/10GBASE-T ports
NOTE: 2, 3
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Configuration
8
HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch
JL172A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL172A#B2B
• C13 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL172A#B2C
• C13 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL172A#B2E
• HPE 2.3M C13 to NEMA L6-20P Power Cord(J9936A)
No Power Cord
JL172A#AC3
• No Localization Power Cord Selected
HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch
JL173A
•
• 1U - Height
See Configuration
PDU Cable NA/MEX/TW/JP
JL173A#B2B
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JL173A#B2C
• C15 PDU Jumper Cord (ROW)
High Volt Switch to Wall Power Cord
JL173A#B2E
• HPE 2.5m C15 to NEMA 6-20P 250V Non-locking Power Cord (JL336A)
No Power Cord
JL173A#AC3
• No Localization Power Cord Selected
Configuration Rules:
Note 2
Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord) . (See Localization
Menu)
REMARK: When Switches/Routers are Factory Racked, Then #B2B, or #B2C should be the
Cable option on the Switches/Routers.
If #AC3 is selected then no Localized Power Cord is required.
Note 3
If this switch is factory installed in any HP Racks, Then the J9583A#0D1 is required.
Remarks
Drop down under power cords should offer the following options and results:
Switch/Router/Power Supply to PDU Power Cord
#B2C ROW. (Watson Default B2B or B2C for Rack Level CTO)
24 RJ-45 autosensing 10/100/1000 PoE+ ports
• 24 RJ-45 autosensing 10/100/1000 ports
• 2 RJ-45 1/10GBASE-T ports
NOTE: 2, 3
48 RJ-45 autosensing 10/100/1000 PoE+ ports
• 48 RJ-45 autosensing 10/100/1000 ports
• 4 RJ-45 1/10GBASE-T ports
NOTE: 2, 3
Defaulted Power
- #B2B in North America, Mexico, Taiwan, and Japan or
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Configuration
9
Switch/Router/Power Supply to Wall Power Cord - #B2C Localized Option (Watson Default for BTO and Box
Level CTO)
High Volt Switch/Router/Power Supply to Wall Power Cord
Mexico, Taiwan, and Japan)
No Power Cord - #AC3 Option
Enter the following menu selections as integrated to the CTO Model X server above if order is factory built.
Transceivers
SFP Transceivers
Aruba 1G SFP LC SX 500m MMF XCVR
J4858D
Aruba 1G SFP LC LX 10km SMF XCVR
J4859D
Aruba 10G SFP+ LC SR 300m MMF XCVR
J9150D
Aruba 10G SFP+ LC LR 10km SMF XCVR
J9151D
Aruba 10G SFP+ LC LRM 220m MMF XCVR
J9152D
Cables
Multi-Mode Cables
Aruba 10G SFP+ to SFP+ 1m DAC Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m DAC Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m DAC Cable
J9285D
Switch Enclosure Options
Rail Kit
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
• Supported on JL170A, JL171A, JL172A, JL173A
See Configuration
NOTE:1
Configuration Rules:
Note 1
If this Rail Kit is order with #0D1 then it integrates to the HPE Network Rack. (not the switch)
- #B2E Option. (Offered only in North America,
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
10
HPE OfficeConnect 1850 6XGT and 2XGT/SPF+ Switch (JL169A)
I/O ports and slots
6 RJ-45 1/10GBASE-T ports
2 dual-personality ports; each port can be used as either an RJ-45 1/10GBASE-T port or an SFP+
Physical characteristics
Dimensions
9.96(w) x 10.26(d) x 1.73(h) in (25.3 x 26.07 x 4.4 cm) (1U height)
Weight
3.84 lb (1.74 kg)
Memory and processor
BCM53412 embedded ARM Cortex-A9 @ 600 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 2 MB
Performance
100 Mb Latency
< 6.8 µs (64-byte packets)
1000 Mb Latency
10 Gbps Latency
< 6.8 µs (64-byte packets)
Throughput
up to 119 Mpps
Switching capacity
160 Gbps
MAC address table size
16000 entries
Reliability
MTBF (years)
64.5
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Acoustic
Power: 45 dB
Airflow direction
Side-to-side
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 127 / 200 - 240 VAC, rated
Current
.9/.5 A
Maximum power rating
42.8 W
Idle power
19.4 W
Notes
Idle power is the actual power consumption of the device with no ports
equipped), 100% traffic, all ports plugged in, and all
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032:
Immunity
Generic
EN 55024, CISPR 24
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
fixed 1000/10000 slot
< 2.9 µs (64-byte packets)
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if
modules populated.
2015/CISPR-32
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
11
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Web browser
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE OfficeConnect 1850 24G 2XGT Switch (JL170A)
I/O ports and slots
24 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
2 RJ-45 1/10GBASE-T ports
Physical characteristics
Dimensions
17.42 (w) x 9.7(d) x 1.73(h) in (44.25 x 24.64 x 4.4 cm) (1U height)
Weight
5.86 lb (2.66 kg)
Memory and processor
BCM53346 embedded ARM Cortex-A9 @ 400 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 1.5
MB
Performance
100 Mb Latency
< 9.1 µs (64-byte packets)
1000 Mb Latency
10 Gbps Latency
< 3.7 µs (64-byte packets)
Throughput
up to 65 Mpps (64-byte packets)
Switching capacity
88 Gbps
MAC address table size
16000 entries
Reliability
MTBF (years)
99
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Acoustic
Power: 36 dB
Airflow direction
Side-to-side
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 120 / 200 - 240 VAC, rated (200 - 240 VAC, max)
Current
.6/.4 A
Maximum power rating
29.5 W
Idle power
19.1 W
Notes
Idle power is the actual power consumption of the device with no ports
connected.
details on the service-level descriptions and product numbers. For details about services and response
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full;
1000BASE-T: full only
< 3.7 µs (64-byte packets)
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
12
Maximum power rating and maximum heat dissipation are the worst-case
equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032:
Immunity
Generic
EN 55024, CISPR 24
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
IEC 61000-4-8
Voltage dips and
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Web browser
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE OfficeConnect 1850 48G 4XGT Switch (JL171A)
I/O ports and slots
48 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
1000BASE-T: full only
4 RJ-45 1/10GBASE-T ports
Physical characteristics
Dimensions
17.42(w) x 9.7(d) x 1.73(h) in (44.25 x 24.64 x 4.4 cm) (1U height)
Weight
7.05 lb (3.2 kg)
Memory and processor
BCM53346 embedded ARM Cortex-A9 @ 400 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 3 MB
Performance
100 Mb Latency
1000 Mb Latency
< 3.7 µs (64-byte packets)
10 Gbps Latency
Throughput
up to 131 Mpps (64-byte packets)
Switching capacity
176 Gbps
MAC address table size
16000 entries
Reliability
MTBF (years)
79.4
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if
2015/CISPR-32
magnetic field
interruptions
details on the service-level descriptions and product numbers. For details about services and response
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full;
< 9.7 µs (64-byte packets)
< 3.7 µs (64-byte packets)
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
13
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Acoustic
Power: 34 dB
Airflow direction
Side-to-side
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 127 / 200 - 240 VAC, rated
Current
1/.6 A
Maximum power rating
49.3 W
Idle power
30 W
Notes
Idle power is the actual power consumption of the device with no ports
equipped), 100% traffic, all ports plugged in, and all
modules populated.
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032:
2015/CISPR-32
Immunity
Generic
EN 55024, CISPR 24
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Web browser
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch (JL172A)
I/O ports and slots
12 RJ-45 auto-negotiating 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
T/100BASE-TX: half or full; 1000BASE-T: full only
12 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
1000BASE-T: full only
2 RJ-45 1/10GBASE-T ports
Physical characteristics
Dimensions
17.42(w) x 9.7(d) x 1.73(h) in (44.25 x 24.64 x 4.4 cm) (1U height)
Weight
7.28 lb (3.3 kg)
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if
interruptions
details on the service-level descriptions and product numbers. For details about services and response
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE, IEEE 802.3at); Duplex: 10BASE-
100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full;
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
14
Memory and processor
BCM53346 embedded ARM Cortex-A9 @ 400 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 1.5
MB
Performance
100 Mb Latency
< 8.6 µs (64-byte packets)
1000 Mb Latency
10 Gbps Latency
< 3.6 µs (64-byte packets)
Throughput
up to 65 Mpps (64-byte packets)
Switching capacity
88 Gbps
MAC address table size
16000 entries
Reliability
MTBF (years)
71.4
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% @ 104°F (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Acoustic
Power: 44 dB
Airflow direction
Side-to-side
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 127 / 200 - 240 VAC, rated
Current
2.5/1.3 A
Maximum power rating
222.9 W
Idle power
24.4 W
PoE power
185 W PoE+
Notes
Idle power is the actual power consumption of the device with no ports
equipped), 100% traffic, all ports plugged in, and all
supplemented with the use of an External Power Supply (EPS).
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032:
Immunity
Generic
EN 55024, CISPR 24
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
IEC 61000-4-8
< 3.6 µs (64-byte packets)
2015/CISPR-32
connected.
Maximum power rating and maximum heat dissipation are the worst-case
theoretical maximum numbers provided for planning the infrastructure
with fully loaded PoE (if
modules populated.
PoE Power is the power supplied by the internal power supply, it is
dependent on the type and quantity of power supplies and may be
magnetic field
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
15
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Web browser
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch (JL173A)
I/O ports and slots
24 RJ-45 auto-negotiating 10/100/1000 PoE+ ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
T/100BASE-TX: half or full; 1000BASE-T: full only
24 RJ-45 auto-negotiating 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type
100BASE-TX, IEEE 802.3ab Type 1000BASE-T)
4 RJ-45 1/10GBASE-T ports
Physical characteristics
Dimensions
17.42(w) x 12.7(d) x 1.73(h) in (44.25 x 32.26 x 4.4 cm) (1U height)
Weight
10.3 lb (4.67 kg)
Memory and processor
BCM53346 embedded ARM Cortex-A9 @ 400 MHz, 128 MB DDR3 SDRAM; Packet buffer size: 3 MB
Performance
100 Mb Latency
< 10 µs (64-byte packets)
1000 Mb Latency
10 Gbps Latency
< 3.8 µs (64-byte packets)
Throughput
up to 131 Mpps (64-byte packets)
Switching capacity
176 Gbps
MAC address table size
16000 entries
Reliability
MTBF (years)
57.1
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
15% to 95% (40°C), noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
15% to 95% @ 149°F (65°C), noncondensing
Altitude
up to 9,842 ft (3 km)
Acoustic
Power: 40 dB
Airflow direction
Side-to-side
Electrical characteristics
Frequency
50/60 Hz
Voltage
100 - 127 / 200 - 240 VAC, rated
Current
5/2.4 A
Maximum power rating
446.4 W
Idle power
46.5 W
PoE power
370 W PoE+
Notes
Idle power is the actual power consumption of the device with no ports
theoretical maximum numbers provided for planning the infrastructure
details on the service-level descriptions and product numbers. For details about services and response
100BASE-TX, IEEE 802.3ab Type 1000BASE-T, IEEE 802.3af PoE, IEEE 802.3at); Duplex: 10BASE-
< 3.8 µs (64-byte packets)
connected.
Maximum power rating and maximum heat dissipation are the worst-case
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Technical Specifications
16
with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all
supplemented with the use of an External Power Supply (EPS).
Safety
UL 60950-1; IEC 60950-1; EN 60950-1; CAN/CSA-C22.2 No. 60950-1; EN 60825-1
Emissions
VCCI Class A; CNS 13438; ICES-003 Issue5 Class A; FCC CFR 47 Part 15, Class A ; EN 55032:
2015/CISPR-32
Immunity
Generic
EN 55024, CISPR 24
EN
EN 55024, CISPR 24
ESD
IEC 61000-4-2
Radiated
IEC 61000-4-3
EFT/Burst
IEC 61000-4-4
Surge
IEC 61000-4-5
Conducted
IEC 61000-4-6
Power frequency
magnetic field
IEC 61000-4-8
Voltage dips and
interruptions
IEC 61000-4-11
Harmonics
EN 61000-3-2, IEC 61000-3-2
Flicker
EN 61000-3-3, IEC 61000-3-3
Management
Web browser
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
Standards and protocols
Denial of service protection
modules populated.
PoE Power is the power supplied by the internal power supply, it is
dependent on the type and quantity of power supplies and may be
details on the service-level descriptions and product numbers. For details about services and response
(applies to all products in
series)
CPU DoS Protection
General protocols
IEEE 802.1AB-2005 Link Layer Discovery Protocol (LLDP) I
IEEE 802.1D Spanning Tree Protocol
IEEE 802.1p Priority
IEEE 802.1Q VLANs
IEEE 802.1W Rapid Spanning Tree Protocol
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3x Flow Control
RFC 1534 DHCP/BOOTP Interoperation
RFC 2030 Simple Network Time Protocol (SNTP) v4
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Accessories
17
HPE OfficeConnect 1850 Switch Series accessories
HPE OfficeConnect 1850 6XGT and 2XGT/SPF+ Switch (JL169A)
Aruba 1G SFP LC SX 500m OM2 MMF Transceiver
J4858D
Aruba 1G SFP LC LX 10km SMF Transceiver
J4859D
Aruba 10G SFP+ LC SR 300m OM3 MMF Transceiver
J9150D
Aruba 10G SFP+ LC LR 10km SMF Transceiver
J9151D
Aruba 10G SFP+ LC LRM 220m OM2 MMF Transceiver
J9152D
Aruba 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
J9281D
Aruba 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
J9283D
Aruba 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
J9285D
HPE OfficeConnect 1850 24G 2XGT Switch (JL170A)
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
HPE OfficeConnect 1850 48G 4XGT Switch (JL171A)
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
HPE OfficeConnect 1850 24G 2XGT PoE+ 185W Switch (JL172A)
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
HPE OfficeConnect 1850 48G 4XGT PoE+ 370W Switch (JL173A)
HPE X410 1U Universal 4-post Rackmount Kit
J9583A
Page
QuickSpecs
HPE OfficeConnect 1850 Switch Series
Summary of Changes
18
Date
Version History
Action
Description of Change:
07-May-2018
Version 3
Changed
Accessories updated
04-Sep-2017
Version 2
Changed
Updates made on Features and benefits
07-Nov-2016
Version 1
Created
Document creation
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accomp
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or editorial errors or omissions contained herein.
Intel, Core, Pentium, and Xeon
Microsoft is a U.S. registered trademark of the Microsoft group of companies.
To learn more, visit:
c05279017
anying such products and services.
are trademarks of Intel Corporation in the U.S. and other countries.
http://www.hpe.com/networking
- 15735 - Worldwide - V3 - 07-May-2018
Page
Loading...
