QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
1
HPE FlexFabric 7900 Switch Series
Models
HPE FlexFabric 7904 Switch Chassis
JG682A
HPE FlexFabric 7910 Switch Chassis
JG841A
Key features
• Nonblocking and lossless Clos architecture
Product overview
HPE FlexFabric 7900 Switch Series is the next-generation compact modular data center core switch designed to support
virtualized data centers and evolution needs of private and public clouds deployments.
The 7900 delivers unprecedented levels of performance, buffering, scale, and availability with high
100GbE interfaces using
The switch supports full Layer 2 and 3 features along with advanced data center features including TRILL, IRF, VxLAN and open
standards-based programmability with OpenFlow support
Features and benefits
Product architecture
Performance
• Low latency and consistent performance
• Large Layer 2 scaling with TRILL and HPE IRF
• VxLAN support for virtualized and cloud deployments
• SDN-enabled with OpenFlow1.3 support
• High 10GbE, 40GbE and 100GbE density across 9.6 Tbps switch fabric
only a fraction of the foot print used by traditional chassis.
-density 10GbE, 40GbE and
• Modern scalable system architecture
provides nonblocking, lossless Clos architecture with VOQs and large buffers with the flexibility and scalability for future
growth
• Distributed architecture with separation of data and control planes
delivers enhanced fault tolerance and facilitates continuous operation and zero service disruption during planned or
unplanned control-plane events
• Advanced Comware modular operating system
brings native high stability, independent process monitoring, and restart through the modular design and multiple
processes of Hewlett Packard Enterprise Comware v7 software; supports enhanced serviceability functions
• High-performance fully distributed architecture
delivers up to 9.6 Tb/s switching capacity and 5.94 Bpps throughput with nonblocking wirespeed performance
• High-density 1/10GbE, 40GbE and 100GbE interface connectivity
offers up to 10 interface module slots to scale up to 120 40GbE or 20 100GbE or 480 10GbE or 240 1/10GbE interface
or a combination
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
2
under 5 microsecond latency (64-byte packets) and consistent performance for broad range of applications typical of a
Data center optimized
is an Hewlett Packard Enterprise Virtual Application Network innovation that provides a Layer 2 extension across the data
Resiliency and high availability
reates virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router; servers
Layer 2 switching
• Port isolation
data center including mixed traffic loads of real-time, multicast, and storage traffic
• Distributed scalable fabric architecture
with integrated fabric and management modules to deliver more than 1 Tb per slot bandwidth
VXLAN Routing/Bridging provides wire-rate support to build overlay networks enabling virtual machine mobility and
cloud deployments
• Scalable Layer 2 fabric functionality
builds flexible, resilient, and scalable Layer 2 fabrics with TRILL and Hewlett Packard Enterprise IRF
• Hewlett Packard Enterprise Ethernet Virtual Interconnect (EVI)
center to simplify the interconnectivity of geographically disperse data centers
• Front-to-back airflow design
• Virtual Extensible LAN (VxLAN)
accommodates deployment in data centers utilizing hot-cold aisles
• Intelligent Resilient Fabric (IRF)
c
or switches can be attached using standard LACP for automatic load balancing and high availability there by eliminating
the need for complex protocols and simplifying network operations
• Redundant/load-sharing fabrics, management, fan assemblies and power supplies
increase total performance and power availability while providing hitless, stateful failover
• Hot-swappable modules
allows replacement of modules without any impact on other modules
• Graceful restart
allows routers to indicate to others their capability to maintain a routing table during a temporary shutdown, which
significantly reduces convergence times upon recovery; supports OSPF, BGP, and IS-IS
• Virtual Router Redundancy Protocol (VRRP)
allows groups of two routers to dynamically back each other up to create highly available routed environments
• Device Link Detection Protocol (DLDP)
monitors link connectivity and shuts down ports at both ends if unidirectional traffic is detected, preventing loops in STP
based networks
• IEEE 802.3ad Link Aggregation Control Protocol (LACP)
supports up to 1024 trunk groups and up to 16 members per trunk; supports static or dynamic groups and a userselectable hashing algorithm
• Mid-plane free chassis design
delivers increased system reliability and optimal airflow as the chassis has no mid-plane and line cards connect directly to
the onboard fabric card
• Bidirectional Forwarding Detection (BFD)
ultrafast sub second protocol convergence with standards based failure detection which enables link connectivity
monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS and VRRP
• VLAN
supports up to 4,094 port-based or IEEE 802.1Q-based VLANs
• Port mirroring
duplicates port traffic (ingress and egress) to a local or remote monitoring port; supports four mirroring groups, with an
unlimited number of ports per group
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
3
increases security by isolating ports within a VLAN while still allowing them to communicate with other VLANs
Layer 3 routing
IS routing and extended
• Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping
controls and manages the flooding of multicast packets in a Layer 2 network
• Spanning Tree Protocol (STP)
supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
• Open shortest path first (OSPF)
• Intermediate system to intermediate system (IS-IS)
• Border Gateway Protocol 4 (BGP-4)
• Dual IP stack
• Multiprotocol Label Switching (MPLS) Layer 3 VPN
• Equal-Cost Multipath (ECMP)
• Unicast Reverse Path Forwarding (uRPF)
• Routing Information Protocol (RIP)
• IP performance optimization
• Unicast Reverse Path Forwarding (uRPF) for IPv4
• BGP+
• IPv6 tunneling
• IS-IS for IPv6
• OSPFv3
• Routing Information Protocol (RIP)
• RIPng
• Static IPv4 routing
• Static IPv6 routing
delivers faster convergence; uses this link-state routing Interior Gateway Protocol (IGP), which supports ECMP, NSSA, and
MD5 authentication for increased security and graceful restart for faster failure recovery
uses a path vector Interior Gateway Protocol (IGP), which is defined by the ISO organization for ISby IETF RFC 1195 to operate in both TCP/IP and the OSI reference model (Integrated IS-IS)
delivers an implementation of the Exterior Gateway Protocol (EGP) utilizing path vectors; uses TCP for enhanced
reliability for the route discovery process; reduces bandwidth consumption by advertising only incremental updates;
supports extensive policies for increased flexibility; scales to very large networks
maintains separate stacks for IPv4 and IPv6 to ease the transition from an IPv4-only network to an IPv6-only network
design
allows Layer 3 VPNs across a provider network; uses MP-BGP to establish private routes for increased security; supports
RFC 2547bis multiple autonomous system VPNs for added flexibility
enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidth
limits erroneous or malicious traffic in accordance with RFC 3074
uses a distance vector algorithm with UDP packets for route determination; supports RIPv1 and RIPv2 routing; includes
loop protection
provides a set of tools to improve the performance of IPv4 networks; includes directed broadcasts, customization of TCP
parameters, support of ICNP error packets, and extensive display capabilities
limits erroneous or malicious traffic in accordance with RFC 3074 for IPv4 traffic
extends BGP-4 to support Multiprotocol BGP (MBGP), including support for IPv6 addressing
allows a smooth transition from IPv4 to IPv6 by encapsulating IPv6 traffic over an existing IPv4 infrastructure
extends IS-IS to support IPv6 addressing
provides OSPF support for IPv6
uses a distance vector algorithm with UDP packets for route determination; supports RIPv1 and RIPv2 routing; includes
loop protection
extends RIPv2 to support IPv6 addressing
provides simple manually configured IPv4 routing
provides simple manually configured IPv6 routing
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
4
Quality of Service (QoS)
Layer 3 services
determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection
Management
t on network performance; this
Network Time Protocol (NTP)
• IEEE 802.1p prioritization
delivers data to devices based on the priority and type of traffic
• Flexible classification
creates traffic classes based on access control lists (ACLs), IEEE 802.1p precedence, IP, and DSCP or Type of Service
(ToS) precedence; supports filter, redirect, mirror, remark, and logging
• Bandwidth shaping
– Port-based rate limiting
provides per-port ingress-/egress-enforced increased bandwidth
– Classifier-based rate limiting
uses an access control list (ACL) to enforce increased bandwidth for ingress traffic on each port
– Reduced bandwidth
provides per-port, per-queue egress-based reduced bandwidth
• Broad QoS feature set
provides support for Strict Priority Queuing (SP), Weighted Fair Queuing (WFQ), Weighted Deficit Round Robin(WDRR),
SP+WDRR together, configurable buffers and Explicit Congestion Notification (ECN)
• Traffic policing
supports Committed Access Rate (CAR) and line rate
• Address Resolution Protocol (ARP)
• User Datagram Protocol (UDP) helper
• Dynamic Host Configuration Protocol (DHCP)
• Management interface control
• Industry-standard CLI with a hierarchical structure
• SNMPv1, v2, and v3
• sFlow (RFC 3176)
• Remote monitoring (RMON)
• Debug and sampler utility
•
of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a
Layer 2 network
redirects UDP broadcasts to specific IP subnets to prevent server spoofing
simplifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation
across subnets
enables or disables each of the following interfaces depending on security preferences: console port, Telnet port, or reset
button
reduces training time and expenses, and increases productivity in multivendor installations
provide complete support of SNMP; provide full support of industry-standard Management Information Base (MIB) plus
private extensions; SNMPv3 supports increased security using encryption
provides scalable ASIC-based wirespeed network monitoring and accounting with no impac
allows network operators to gather a variety of sophisticated network statistics and information for capacity planning and
real-time network monitoring purposes
uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a
private alarm extension group
supports ping and traceroute for both IPv4 and IPv6
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
5
synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clock
d service quality by sending test packets, and provides network performance and service
Connectiv
Security
werful ACLs for both IPv4 and IPv6; filters traffic to prevent unauthorized users from accessing the network, or
Multicast support
dependent devices within the network so that the devices can provide diverse applications based on the consistent time
• Network Quality Analyzer (NQA)
analyzes network performance an
quality parameters such as jitter, TCP, or FTP connection delays and file transfer rates; allows a network manager to
determine overall network performance and to diagnose and locate network congestion points or failures
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications
ity
• Jumbo frames
allows high-performance backups and disaster-recovery systems with a maximum frame size of 12288 bytes
• Loopback
supports internal loopback testing for maintenance purposes and an increase in availability; loopback detection protects
against incorrect cabling or network configurations and can be enabled on a per-port or per-VLAN basis for added
flexibility
• Monitor link
collects statistics on performance and errors on physical links, increasing system availability
• Packet storm protection
protects against unknown broadcast, unknown multicast, or unicast storms with user-defined thresholds
• Flow control
provides back pressure using standard IEEE 802.3x, reducing congestion in heavy traffic situations
• Access control list (ACL)
supports po
controls network traffic to save resources; rules can either deny or permit traffic to be forwarded; rules can be based on
Layer 2 header or Layer 3 protocol header; rules can be set to operate on specific dates or times
• Remote Authentication Dial-In User Service (RADIUS)
eases switch security access administration by using a password authentication server
• Secure shell (SSHv2)
uses external servers to securely log in to a remote device; with authentication and encryption, it protects against IP
spoofing and plain-text password interception; increases the security of Secure FTP (SFTP) transfers
• DHCP snooping
helps ensure that DHCP clients receive IP addresses from authorized DHCP servers and maintain a list of DHCP entries
for trusted ports; prevents reception of fake IP addresses and reduces ARP attacks, improving security
• IP Source Guard
filters packets on a per-port basis, which prevents illegal packets from being forwarded
• ARP attack protection
protects against attacks that use a large number of ARP requests, using a host-specific, user-selectable threshold
• Internet Group Management Protocol (IGMP)
utilizes Any-Source Multicast (ASM) or Source-Specific Multicast (SSM) to manage IPv4 multicast networks; supports
IGMPv1, v2, and v3
• Protocol Independent Multicast (PIM)
defines modes of multicasting to allow one-to-many and many-to-many transmission of information; PIM Dense Mode
(DM), Sparse Mode (SM), and Source-Specific Mode (SSM) are supported
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Overview
6
Warranty and support
; for details on the software releases
• 1-year warranty
see http://www.hpe.com/networking/warrantysummary
product purchase.
• Software releases
to find software for your product, refer to http://www.hpe.com/networking/support
available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary
for warranty and support information included with your
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
7
Build To Order
Shippable solution.
Switch Chassis
HPE FlexFabric 7910 Switch Chassis
JG841A
•
• 5U - Height
HPE FlexFabric 7904 Switch Chassis
JG682A
• Must select min 1 Power Supply
Modules
Fabric/Management Modules
HPE FlexFabric 7910 7.2Tbps Fabric/Main Processing Unit
JG842A
See Configuration
NOTE: 1, 3
HPE FlexFabric 7910 2.4Tbps Fabric/Main Processing Unit
JH001A
See Configuration
NOTE: 1, 3
Configuration Rules:
Note 1
No mixing of any type of Fabric/Management Modules. Must all be the same sku
Note 3
If Qty 2X of JG843A HPE FF 7910 Frt(Prt)-Bck(Pwr) Fan Tray is selected, then Fabric/Management Modules is
Min 2 / Max 2
Remarks:
These modules can only be inserted into Slots 10 and 11.
Ethernet Modules
JG682A - System (std 0 // max 4) User Selection (min 1 // max 4) per enclosure
JG841A - System (std 0 // max 10) User Selection (min 1 // max 10) per enclosure
HPE FlexFabric 7900 12-port 40GbE QSFP+ FX Module
JG683B
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
Must select min 1 Power Supply
• Must select min 1 Fan Tray
• Must select Min 1 Ethernet Module
• Must select Min 1 Fabric/Management Module
• Must select min 1 Fan Tray
• Must select Min 1 Ethernet Module
• 2U - Height
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
8
• min=0 \ max=12 QSFP+ Transceivers
See Configuration
1
HPE FlexFabric 7900 24-port 1/10GbE SFP+ FX Module
JG845A
See Configuration
NOTE: 2, 3, 6
HPE FlexFabric 7900 2-port 100GbE CXP/6-port 40GbE QSFP+/4-port 10GbE SFP+ FX Module
JH002A
•
• min=0 \ max=4 SFP+ Transceivers
See Configuration
1, 2, 3, 4, 6, 7
Configuration Rules:
Note 1
The following 40G QSFP+Transceivers install into this Module:
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver
JG661A
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
JL251A
HPE X140 40G QSFP+ MPO SR4 Transceiver
JG325B
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
JG709A
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
JL306A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
JG326A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
JG327A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
JG328A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
JG329A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
JG330A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
JG331A
HPE X140 40G QSFP+ MPO SR4 Campus-Transceiver
JH679A
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Campus-Transceiver
JH677A
HPE X240 40G QSFP+ to QSFP+ 1m Direct Attach Copper Campus-Cable
JH697A
HPE X240 40G QSFP+ to QSFP+ 3m Direct Attach Copper Campus-Cable
JH698A
HPE X240 40G QSFP+ to QSFP+ 5m Direct Attach Copper Campus-Cable
JH699A
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Campus-Cable
JH700A
HPE X140 40G QSFP+ LC BiDi 100m MM Campus-Transceiver
JH678A
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Campus-Transceiver
JH681A
Note 2
The following SFP Transceivers install into this Module:
HPE X170 1G SFP LC LH70 1550 Transceiver
JD109A
HPE X170 1G SFP LC LH70 1570 Transceiver
JD110A
HPE X170 1G SFP LC LH70 1590 Transceiver
JD111A
HPE X170 1G SFP LC LH70 1610 Transceiver
JD112A
HPE X170 1G SFP LC LH70 1510 Transceiver
JD115A
HPE X120 1G SFP LC LH100 Transceiver
JD103A
HPE X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HPE X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X125 1G SFP LC LH70 Transceiver
JD063B
HPE X120 1G SFP LC BX 10-U Transceiver
JD098B
HPE X120 1G SFP LC BX 10-D Transceiver
JD099B
HPE X120 1G SFP RJ45 T Transceiver
JD089B
• min=0 \ max=24 SFP+ Transceivers
min=0 \ max=2 CXP Transceivers
• min=0 \ max=6 QSFP+ Transceivers
NOTE:
NOTE:
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
9
Note 3
The following SFP+ Transceivers install into this Module:
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LRM Transceiver
JD093B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X130 10G SFP+ LC SR Data Center Transceiver
JL437A
HPE X130 10G SFP+ LC LRM Data Center Transceiver
JL438A
HPE X130 10G SFP+ LC LR Data Center Transceiver
JL439A
HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
JD095C
HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
JD096C
HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
JD097C
HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JG081C
HPE X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Campus-Cable
JH693A
HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Campus-Cable
JH694A
HPE X240 10G SFP+ to SFP+ 3m Direct Attach Copper Campus-Cable
JH695A
HPE X240 10G SFP+ to SFP+ 7m Direct Attach Copper Campus-Cable
JH696A
HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable
JC784C
HPE X130 10G SFP+ LC ER 40km Transceiver
JG234A
Note 4
The following CXP Transceivers install into this Module:
HPE X150 100G CXP MPO SR 100m Multimode Transceiver
JG881A
HPE X2A0 100G CXP CXP 10m Active Optical Cable
JG882A
HPE X2A0 100G CXP CXP 30m Active Optical Cable
JG883A
Note 6
The following Transceivers install into this Module:
HPE X130 10G SFP+ LC LH80 tunable Transceiver
JL250A
HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable
JL290A
HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable
JL291A
HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable
JL292A
Note 7
The following 40G Transceivers install into this Module:
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable
JL287A
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable
JL288A
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable
JL289A
Transceivers
SFP Transceivers
HPE X120 1G SFP RJ45 T Transceiver
JD089B
HPE X120 1G SFP LC BX 10-U Transceiver
JD098B
HPE X120 1G SFP LC BX 10-D Transceiver
JD099B
HPE X120 1G SFP LC LH100 Transceiver
JD103A
HPE X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HPE X125 1G SFP LC LH70 Transceiver
JD063B
HPE X170 1G SFP LC LH70 1550 Transceiver
JD109A
HPE X170 1G SFP LC LH70 1570 Transceiver
JD110A
HPE X170 1G SFP LC LH70 1590 Transceiver
JD111A
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
10
HPE X170 1G SFP LC LH70 1610 Transceiver
JD112A
HPE X170 1G SFP LC LH70 1510 Transceiver
JD115A
SFP+ Transceivers
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LRM Transceiver
JD093B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X130 10G SFP+ LC SR Data Center Transceiver
JL437A
HPE X130 10G SFP+ LC LRM Data Center Transceiver
JL438A
HPE X130 10G SFP+ LC LR Data Center Transceiver
JL439A
HPE X130 10G SFP+ LC ER 40km Transceiver
JG234A
HPE X130 10G SFP+ LC LH80 tunable Transceiver
JL250A
HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
JD095C
HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
JD096C
HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
JD097C
HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JG081C
HPE X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Campus-Cable
JH693A
HPE X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Campus-Cable
JH694A
HPE X240 10G SFP+ to SFP+ 3m Direct Attach Copper Campus-Cable
JH695A
HPE X240 10G SFP+ to SFP+ 7m Direct Attach Copper Campus-Cable
JH696A
HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable
JC784C
HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable
JL290A
HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable
JL291A
HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable
JL292A
QSFP+ Transceivers
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver
JG661A
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
JL251A
HPE X140 40G QSFP+ MPO SR4 Transceiver
JG325B
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
JG709A
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
JL306A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
JG326A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
JG327A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
JG328A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
JG329A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
JG330A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
JG331A
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable
JL287A
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable
JL288A
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable
JL289A
HPE X140 40G QSFP+ MPO SR4 Campus-Transceiver
JH679A
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Campus-Transceiver
JH681A
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Campus-Transceiver
JH677A
HPE X140 40G QSFP+ LC BiDi 100m MM Campus-Transceiver
JH678A
HPE X240 40G QSFP+ to QSFP+ 1m Direct Attach Copper Campus-Cable
JH697A
HPE X240 40G QSFP+ to QSFP+ 3m Direct Attach Copper Campus-Cable
JH698A
HPE X240 40G QSFP+ to QSFP+ 5m Direct Attach Copper Campus-Cable
JH699A
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
11
HPE X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Campus-Cable
JH700A
CXP Transceivers
HPE X150 100G CXP MPO SR 100m Multimode Transceiver
JG881A
HPE X2A0 100G CXP CXP 10m Active Optical Cable
JG882A
HPE X2A0 100G CXP CXP 30m Active Optical Cable
JG883A
Cables
MPO Cables
HPE Multi Fiber Push On to 4 x Lucent Connector 5m Cable
K2Q46A
HPE Multi Fiber Push On to 4 x Lucent Connector 15m Cable
K2Q47A
Internal Power Supplies
JG682A
JG841A - System (std 0 // max 4) User Selection (min 1 // max 4)
HPE FlexFabric 7900 1800w AC Power Supply Unit
JG840A
• includes 1 x c15, 1800w
See Configuration
1
PDU Cable NA/MEX/TW/JP
JG840A#B2B
• C15 PDU Jumper Cord (NA/MEX/TW/JP)
PDU Cable ROW
JG840A#B2C
•
High Volt Switch to Wall Power Cord
JG840A#B2E
• NEMA L6-20P Cord (NA/MEX/JP/TW)
Configuration Rules:
Note 1
Localization (Wall Power Cord) required on orders without #B2B, #B2C (PDU Power Cord)
or #B2E. (See Localization Menu)
Remarks:
Drop down under power supply should offer the following options and results:
Switch to PDU Power Cord - #B2B in North America, Mexico, Taiwan, and Japan or #B2C ROW. (Watson Default
B2B or B2C for Rack Level
Switch to Wall Power Cord
High Volt Power Electrical Module to Wall Power Cord
Taiwan, and Japan)
Switch Enclosure Options
- System (std 0 // max 2) User Selection (min 1 // max 2)
NOTE:
C15 PDU Jumper Cord (ROW)
CTO)
- Localized Option (Watson Default for BTO and Box Level CTO)
- #B2E Option. (Offered only in North America, Mexico,
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
12
Fan Trays
JG682A, JG841A
HPE FlexFabric 7904 Front (Port Side) to Back (Power Side) Airflow Fan Tray
JG684A
See Configuration
NOTE: 1, 3
HPE FlexFabric 7904 Back (Power Side) to Front (Port Side) Airflow Fan Tray
JG839A
See Configuration
NOTE: 1, 3
HPE FlexFabric 7910 Front (Port Side) to Back (Power Side) Airflow Fan Tray
JG843A
See Configuration
2, 4, 5
HPE FlexFabric 7910 Back (Power Side) to Front (Port Side) Airflow Fan Tray
JG844A
See Configuration
NOTE: 2, 4, 5
Configuration Rules:
Note 1
Only supported on JG682A
Note 2
Only supported on JG841A
Note 3
The JG684A and JG839A cannot be mixed in the same chassis.
Note 4
If 2x 7910 Fabrics/Management Modules are selected then 7910 Fan Trays is Min2/Max2
Note 5
The JG843A and JG844A cannot be mixed in the same chassis.
Mounting Kit
HPE X421 Chassis Universal 4-post Rackmount Kit
JC665A
See Configuration
NOTE: 1
HPE FlexFabric 7910 Bottom Support Rails
JH042A
See Configuration
NOTE: 2
Configuration Rules:
Note 1
This item is optional and used by customers to allow the chassis to slide in and out of the
rack
Note 2
Only supported on JG841A
Remarks:
Default a quantity of 1 JC665A when Switch JG682A is selected.
- System (std 0 // max 2) User Selection (min 1 // max 2) per switch
NOTE:
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Configuration
13
Default a quantity of 1 JH042A when Switch JG841 is selected.
Configurator Blue Text:
JH042A is recommended for JG841A. JC665A is also supported with JG841A but
additional 2 RUs rack space.
Cable Management Kit
HPE FlexFabric 7910 Cable Management Frame
JH041A
See Configuration
NOTE: 1
Configuration Rules:
Note 1
Only supported on JG841A
Remarks:
Default a quantity of 1 when Switch is selected.
takes
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
14
HPE FlexFabric 7904 Switch Chassis (JG682A)
I/O ports and slots
4 I/O module slots
ports, or a combination
Power supplies
2 power supply slots
1 minimum power supply required (ordered separately)
Fan tray
2 fan tray slots
JG684A for Front to Back airflow
Physical characteristics
Dimensions
17.32(w) x 28.35(d) x 3.47(h) in (44 x 72 x 8.81 cm) (2U height)
Weight
39.46 lb (17.9 kg)
Full configuration weight
87.7 lb (39.78 kg)
Memory and processor
Management module
Dual Core MIPS64 @ 1.2 GHz, 512 MB flash, 4 GB DDR2 SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch rack or other equipment cabinet (hardware included); Horizontal
surface mounting only
Performance
Throughput
up to 2.3 Bpps (64-byte packets)
Switching capacity
3.8 Tbps
Routing table size
32768 entries (IPv4), 8192 entries (IPv6)
MAC address table size
262144 entries
Reliability
Availability
99.999%
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
10% to 95%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 13,123 ft (4 km)
Acoustic
Low-speed fan: 59.8 dB, High-speed fan: 76.3 dB
Airflow direction
Front-to-back or back-to-front (Determined by fan installed fans)
Electrical characteristics
Voltage
100 - 120 / 200 - 240 VAC, rated
Current
16/60 A
Power output
1800 W
Frequency
50/60 Hz
Notes
Based on a common power supply of 1,800 W (AC)
Safety
UL 60950-1; CAN/CSA 22.2 No. 60950-1; IEC 60950-1; EN 60950-1; FDA 21 CFR Subchapter J;
AS/NZS 60950-1; RoHS Compliance EN 50581
Emissions
VCCI Class A; EN 55022 Class A; CISPR 22 Class A; IEC/EN 61000-3-2; IEC/EN 61000-3-3; ICES-003
386
Immunity
Generic
EN 55024
Management
IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-
Services
Refer to the Hewlett Packard Enterprise website at: http://www.hpe.com/networking/services for
details on the service-level descriptions and product numbers. For details about services and response
Supports a maximum of 48 40GbE ports or 192 10GbE ports or 96 1/10GbE ports or 8 100GbE
humidity
Class A; AS/NZS CISPR 22 Class A; FCC (CFR 47, Part 15) Class A; ETSI EN 300
232C); SNMP Manager; Telnet; terminal interface (serial RS-232C); modem interface; IEEE 802.3
Ethernet MIB; Ethernet Interface MIB
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
15
times in your area, please contact your local Hewlett Packard Enterprise sales office.
HPE FlexFabric 7910 Switch Chassis (JG841A)
I/O ports and slots
10 I/O module slots
ports, or a combination
Power supplies
4 power supply slots
Fan tray
2 fan tray slots
JG843A for Front to Back airflow OR JG844A for Back to Front airflow
Physical characteristics
Dimensions
17.32(w) x 29.92(d) x 8.66(h) in (43.99 x 76 x 22 cm) (5U height)
Weight
63.49 lb (28.8 kg)
Full configuration weight
156.97 lb (71.2 kg)
Memory and processor
Management module
Dual Core MIPS64 @ 1.0 GHz, 1 GB flash, 8 GB DDR2 SDRAM
Mounting and enclosure
Mounts in an EIA standard 19-inch rack or other equipment cabinet (hardware included); Horizontal
surface mounting only
Performance
Throughput
up to 5.8 Bpps (64-byte packets)
Switching capacity
9.6 Tbps
Routing table size
32768 entries (IPv4), 8192 entries (IPv6)
MAC address table size
262144 entries
Reliability
Availability
99.999%
Environment
Operating temperature
32°F to 104°F (0°C to 40°C)
Operating relative
humidity
10% to 95%, noncondensing
Nonoperating/Storage
temperature
-40°F to 158°F (-40°C to 70°C)
Nonoperating/Storage
relative humidity
5% to 95%, noncondensing
Altitude
up to 13,123 ft (4 km)
Acoustic
Low-speed fan: 47.9 dB, High-speed fan: 77.9 dB
Airflow direction
Front-to-back or back-to-front (Determined by fan installed fans)
Electrical characteristics
Voltage
100 - 240 VAC, rated
Current
13 A
Power output
1800 W
Frequency
50/60 Hz
Notes
Based on a common power supply of 1,800 W (AC)
Safety
UL 60950-1; CAN/CSA 22.2 No. 60950-1; IEC 60950-1; EN 60950-1; FDA 21 CFR Subchapter J;
AS/NZS 60950-1; RoHS Compliance EN 50581
Emissions
VCCI Class A; EN 55022 Class A; CISPR 22 Class A; IEC/EN 61000-3-2; IEC/EN 61000-3-3; ICES-003
Immunity
Generic
EN 55024
Management
IMC - Intelligent Management Center; command-line interface; out-of-band management (serial RS-
Ethernet MIB; Ethernet Interface MIB
Services
Refer to the Hewlett Packard Enterprise website at http://www.hpe.com/networking/services for
times in your area, please contact your local Hewlett Packard Enterprise sales office.
Supports a maximum of 120 40GbE ports or 480 10GbE ports or 240 1/10GbE ports or 20 100GbE
1 minimum power supply required (ordered separately)
Class A; AS/NZS CISPR 22 Class A; FCC (CFR 47, Part 15) Class A; ETSI EN 300 386
232C); SNMP Manager; Telnet; terminal interface (serial RS-232C); modem interface; IEEE 802.3
details on the service-level descriptions and product numbers. For details about services and response
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
16
Standards and protocols (applies to all products in series)
BGP
RFC 1771 BGPv4
RFC 4456 BGP Route Reflection: An Alternative to Full Mesh Internal BGP (IBGP)
Denial of service
Automatic filtering of well-known denial-of-service packets
Rate Limiting by ACLs
Device Management
RFC 1157 SNMPv1/v2c
SSHv1/SSHv2 Secure Shell
General Protocols
IEEE 802.1p Priority
RFC 791 IP
RFC 1772 Application of the BGP
RFC 1997 BGP Communities Attribute
RFC 1998 An Application of the BGP Community Attribute in Multi-home Routing
RFC 2385 BGP Session Protection via TCP MD5
RFC 2439 BGP Route Flap Damping
RFC 2796 BGP Route Reflection
RFC 2858 BGP-4 Multi-Protocol Extensions
RFC 2918 Route Refresh Capability
RFC 3065 Autonomous System Confederations for BGP
RFC 3392 Capabilities Advertisement with BGP-4
RFC 4271 A Border Gateway Protocol 4 (BGP-4)
RFC 4272 BGP Security Vulnerabilities Analysis
RFC 4273 Definitions of Managed Objects for BGP-4
RFC 4274 BGP-4 Protocol Analysis
RFC 4275 BGP-4 MIB Implementation Survey
RFC 4276 BGP-4 Implementation Report
RFC 4277 Experience with the BGP-4 Protocol
RFC 4360 BGP Extended Communities Attribute
protection
CPU DoS Protection
RFC 1305 NTPv3
RFC 1902 (SNMPv2)
RFC 2579 (SMIv2 Text Conventions)
RFC 2580 (SMIv2 Conformance)
RFC 2819 (RMON groups Alarm, Event, History and Statistics only)
HTTP, SSHv1, and Telnet
Multiple Configuration Files
Multiple Software Images
IEEE 802.1Q VLANs
IEEE 802.1s Multiple Spanning Trees
IEEE 802.1w Rapid Reconfiguration of Spanning Tree
IEEE 802.1X PAE
IEEE 802.3ab 1000BASE-T
IEEE 802.3ac (VLAN Tagging Extension)
IEEE 802.3ad Link Aggregation Control Protocol (LACP)
IEEE 802.3ae 10-Gigabit Ethernet
IEEE 802.3ah Ethernet in First Mile over Point to Point Fiber - EFMF
IEEE 802.3ba 40 and 100 Gigabit Ethernet Architecture
IEEE 802.3x Flow Control
IEEE 802.3z 1000BASE-X
RFC 768 UDP
RFC 783 TFTP Protocol (revision 2)
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
17
RFC 792 ICMP
RFC 5130 A Policy Control Mechanism in IS-IS Using Administrative Tags
IP Multicast
RFC 2236 IGMPv2
RFC 2283 Multiprotocol Extensions for BGP-4
RFC 793 TCP
RFC 826 ARP
RFC 854 TELNET
RFC 894 IP over Ethernet
RFC 950 Internet Standard Subnetting Procedure
RFC 959 File Transfer Protocol (FTP)
RFC 1027 Proxy ARP
RFC 1035 Domain Implementation and Specification
RFC 1042 IP Datagrams
RFC 1058 RIPv1
RFC 1142 OSI IS-IS Intra-domain Routing Protocol
RFC 1195 OSI ISIS for IP and Dual Environments
RFC 1213 Management Information Base for Network Management of TCP/IP-based internets
RFC 1305 NTPv3
RFC 1350 TFTP Protocol (revision 2)
RFC 1393 Traceroute Using an IP Option
RFC 1519 CIDR
RFC 1531 Dynamic Host Configuration Protocol
RFC 1533 DHCP Options and BOOTP Vendor Extensions
RFC 1591 DNS (client only)
RFC 1624 Incremental Internet Checksum
RFC 1701 Generic Routing Encapsulation
RFC 1721 RIP-2 Analysis
RFC 1723 RIP v2
RFC 1812 IPv4 Routing
RFC 2082 RIP-2 MD5 Authentication
RFC 2091 Trigger RIP
RFC 2131 DHCP
RFC 2138 Remote Authentication Dial In User Service (RADIUS)
RFC 2236 IGMP Snooping
RFC 2338 VRRP
RFC 2453 RIPv2
RFC 2644 Directed Broadcast Control
RFC 2763 Dynamic Name-to-System ID mapping support
RFC 2784 Generic Routing Encapsulation (GRE)
RFC 2966 Domain-wide Prefix Distribution with Two-Level IS-IS
RFC 2973 IS-IS Mesh Groups
RFC 3022 Traditional IP Network Address Translator (Traditional NAT)
RFC 3277 IS-IS Transient Blackhole Avoidance
RFC 3567 Intermediate System to Intermediate System (IS-IS) Cryptographic Authentication
RFC 3719 Recommendations for Interoperable Networks using Intermediate System to Intermediate
System (IS-IS)
RFC 3784 ISIS TE support
RFC 3786 Extending the Number of IS-IS LSP Fragments Beyond the 256 Limit
RFC 3787 Recommendations for Interoperable IP Networks using Intermediate System to
Intermediate System (IS-IS)
RFC 3847 Restart signaling for IS-IS
RFC 4251 The Secure Shell (SSH) Protocol Architecture
RFC 4486 Subcodes for BGP Cease Notification Message
RFC 4941 Privacy Extensions for Stateless Address Autoconfiguration in IPv6
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
18
RFC 2362 PIM Sparse Mode
RFC 5059 Bootstrap Router (BSR) Mechanism for Protocol Independent Multicast (PIM)
IPv6
RFC 1886 DNS Extension for IPv6
RFC 4862 IPv6 Stateless Address Auto-configuration
MIBs
RFC 1156 (TCP/IP MIB)
RFC 2013 SNMPv2 MIB for UDP
RFC 3376 IGMPv3
RFC 3973 PIM Dense Mode
RFC 4541 Considerations for Internet Group Management Protocol (IGMP) and Multicast Listener
Discovery (MLD) Snooping Switches
RFC 4601 PIM Sparse Mode
RFC 4604 Using Internet Group Management Protocol Version 3 (IGMPv3) and Multicast Listener
Discovery Protocol Version 2 (MLDv2) for Source-Specific Multicast
RFC 4605 IGMP/MLD Proxying
RFC 4607 Source-Specific Multicast for IP
RFC 1887 IPv6 Unicast Address Allocation Architecture
RFC 1981 IPv6 Path MTU Discovery (v2 models only)
RFC 2080 RIPng for IPv6
RFC 2081 RIPng Protocol Applicability Statement
RFC 2292 Advanced Sockets API for IPv6
RFC 2373 IPv6 Addressing Architecture
RFC 2375 IPv6 Multicast Address Assignments
RFC 2460 IPv6 Specification
RFC 2461 IPv6 Neighbor Discovery
RFC 2462 IPv6 Stateless Address Auto-configuration
RFC 2463 ICMPv6
RFC 2464 Transmission of IPv6 over Ethernet Networks
RFC 2473 Generic Packet Tunneling in IPv6
RFC 2529 Transmission of IPv6 Packets over IPv4
RFC 2545 Use of MP-BGP-4 for IPv6
RFC 2553 Basic Socket Interface Extensions for IPv6
RFC 2710 Multicast Listener Discovery (MLD) for IPv6
RFC 2740 OSPFv3 for IPv6
RFC 2893 Transition Mechanisms for IPv6 Hosts and Routers
RFC 3056 Connection of IPv6 Domains via IPv4 Clouds
RFC 3307 IPv6 Multicast Address Allocation
RFC 3315 DHCPv6 (client and relay)
RFC 3484 Default Address Selection for IPv6
RFC 3513 IPv6 Addressing Architecture
RFC 3736 Stateless Dynamic Host Configuration Protocol (DHCP) Service for IPv6
RFC 3810 MLDv2 for IPv6
RFC 4214 Intra-Site Automatic Tunnel Addressing Protocol (ISATAP)
RFC 4443 ICMPv6
RFC 4861 IPv6 Neighbor Discovery
RFC 1157 A Simple Network Management Protocol (SNMP)
RFC 1215 A Convention for Defining Traps for use with the SNMP
RFC 1493 Bridge MIB
RFC 1573 SNMP MIB II
RFC 1643 Ethernet MIB
RFC 1657 BGP-4 MIB
RFC 1907 SNMPv2 MIB
RFC 2011 SNMPv2 MIB for IP
RFC 2012 SNMPv2 MIB for TCP
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
19
RFC 2096 IP Forwarding Table MIB
Network Management
IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
ANSI/TIA-1057 LLDP Media Endpoint Discovery (LLDP-MED)
OSPF
RFC 1245 OSPF protocol analysis
RFC 2370 OSPF Opaque LSA Option
RFC 2233 Interface MIB
RFC 2452 IPV6-TCP-MIB
RFC 2454 IPV6-UDP-MIB
RFC 2465 IPv6 MIB
RFC 2466 ICMPv6 MIB
RFC 2571 SNMP Framework MIB
RFC 2572 SNMP-MPD MIB
RFC 2573 SNMP-Notification MIB
RFC 2573 SNMP-Target MIB
RFC 2578 Structure of Management Information Version 2 (SMIv2)
RFC 2580 Conformance Statements for SMIv2
RFC 2618 RADIUS Client MIB
RFC 2620 RADIUS Accounting MIB
RFC 2665 Ethernet-Like-MIB
RFC 2668 802.3 MAU MIB
RFC 2674 802.1p and IEEE 802.1Q Bridge MIB
RFC 2787 VRRP MIB
RFC 2819 RMON MIB
RFC 2925 Ping MIB
RFC 2932IP (Multicast Routing MIB)
RFC 2933 IGMP MIB
RFC 3414 SNMP-User based-SM MIB
RFC 3415 SNMP-View based-ACM MIB
RFC 3417 Simple Network Management Protocol (SNMP) over IEEE 802 Networks
RFC 3418 MIB for SNMPv3
RFC 3595 Textual Conventions for IPv6 Flow Label
RFC 3621 Power Ethernet MIB
RFC 3813 MPLS LSR MIB
RFC 3814 MPLS FTN MIB
RFC 3815 MPLS LDP MIB
RFC 3826 AES for SNMP's USM MIB
RFC 4133 Entity MIB (Version 3)
RFC 4444 Management Information Base for Intermediate System to Intermediate System (IS-IS)
RFC 1155 Structure of Management Information
RFC 1157 SNMPv1
RFC 1448 Protocol Operations for version 2 of the Simple Network Management Protocol (SNMPv2)
RFC 2211 Controlled-Load Network
RFC 2819 Four groups of RMON: 1 (statistics), 2 (history), 3 (alarm) and 9 (events)
RFC 3176 sFlow
RFC 3411 SNMP Management Frameworks
RFC 3412 SNMPv3 Message Processing
RFC 3414 SNMPv3 User-based Security Model (USM)
RFC 3415 SNMPv3 View-based Access Control Model VACM)
RFC 1246 Experience with OSPF
RFC 1765 OSPF Database Overflow
RFC 1850 OSPFv2 Management Information Base (MIB), traps
RFC 2154 OSPF w/ Digital Signatures (Password, MD-5)
RFC 2328 OSPFv2
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Technical Specifications
20
RFC 3101 OSPF NSSA
RFC 4940 IANA Considerations for OSPF
QoS/CoS
IEEE 802.1p (CoS)
RFC 2598 DiffServ Expedited Forwarding (EF)
Security
IEEE 802.1X Port Based Network Access Control
MPLS
RFC 2205 Resource ReSerVation Protocol
RFC 5036 LDP Specification
RFC 3137 OSPF Stub Router Advertisement
RFC 3623 Graceful OSPF Restart
RFC 3630 Traffic Engineering Extensions to OSPFv2
RFC 4061 Benchmarking Basic OSPF Single Router Control Plane Convergence
RFC 4062 OSPF Benchmarking Terminology and Concepts
RFC 4063 Considerations When Using Basic OSPF Convergence Benchmarks
RFC 4222 Prioritized Treatment of Specific OSPF Version 2 Packets and Congestion Avoidance
RFC 4577 OSPF as the Provider/Customer Edge Protocol for BGP/MPLS IP Virtual Private Networks
(VPNs)
RFC 4811 OSPF Out-of-Band LSDB Resynchronization
RFC 4812 OSPF Restart Signaling
RFC 4813 OSPF Link-Local Signaling
RFC 1349 Type of Service in the Internet Protocol Suite
RFC 2211 Specification of the Controlled-Load Network Element Service
RFC 2212 Guaranteed Quality of Service
RFC 2474 DSCP DiffServ
RFC 2475 DiffServ Architecture
RFC 2597 DiffServ Assured Forwarding (AF)
RFC 1321 The MD5 Message-Digest Algorithm
RFC 2082 RIP-2 MD5 Authentication
RFC 2104 Keyed-Hashing for Message Authentication
RFC 2408 Internet Security Association and Key Management Protocol (ISAKMP)
RFC 2409 The Internet Key Exchange (IKE)
RFC 2865 RADIUS Authentication
RFC 2866 RADIUS Accounting
RFC 2868 RADIUS Attributes for Tunnel Protocol Support
RFC 2869 RADIUS Extensions
Access Control Lists (ACLs)
Guest VLAN for 802.1X
MAC Authentication
SSHv1/SSHv2 Secure Shell
RFC 2209 Resource ReSerVation Protocol (RSVP)
RFC 2283 Multiprotocol Extensions for BGP-4
RFC 2961 RSVP Refresh Overhead Reduction Extensions
RFC 3031 Multiprotocol Label Switching Architecture
RFC 3032 MPLS Label Stack Encoding
RFC 3107 Carrying Label Information in BGP-4
RFC 3479 Fault Tolerance for the Label Distribution Protocol (LDP)
RFC 3564 Requirements for Support of Differentiated Service-aware MPLS Traffic Engineering
RFC 4364 BGP/MPLS IP Virtual Private Networks (VPNs)
RFC 4379 Detecting Multi-Protocol Label Switched (MPLS) Data Plane Failures
RFC 4447 Pseudowire Setup and Maintenance Using LDP
RFC 4448 Encapsulation Methods for Transport of Ethernet over MPLS Networks
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Accessories
21
HPE FlexFabric 7900 Switch Series accessories
Modules
HPE FlexFabric 7900 12-port 40GbE QSFP+ FX Module
JG683B
HPE FlexFabric 7900 24-port 1/10GbE SFP+ FX Module
JG845A
HPE FlexFabric 7900 2-port 100GbE CXP/6-port 40GbE QSFP+/4-port 10GbE SFP+ FX Module
JH002A
Transceivers
HPE X140 40G QSFP+ MPO SR4 Transceiver
JG325B
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
JG709A
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
JL306A
HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver
JL286A
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver
JG661A
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
JL251A
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable
JL287A
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable
JL288A
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable
JL289A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
JG326A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
JG327A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
JG328A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
JG329A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
JG330A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
JG331A
HPE X150 100G CXP MPO SR 100m Multimode Transceiver
JG881A
HPE X2A0 100G CXP CXP 10m Active Optical Cable
JG882A
HPE X2A0 100G CXP CXP 30m Active Optical Cable
JG883A
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X130 10G SFP+ LC ER 40km Transceiver
JG234A
HPE X130 10G SFP+ LC LH 80km Transceiver
JG915A
HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable
JL290A
HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable
JL291A
HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable
JL292A
HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
JD095C
HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
JD096C
HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
JD097C
HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JG081C
HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable
JC784C
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X120 1G SFP LC BX 10-U Transceiver
JD098B
HPE X120 1G SFP LC BX 10-D Transceiver
JD099B
HPE X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HPE X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HPE X125 1G SFP LC LH70 Transceiver
JD063B
HPE X170 1G SFP LC LH70 1510 Transceiver
JD115A
HPE X170 1G SFP LC LH70 1550 Transceiver
JD109A
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Accessories
22
HPE X170 1G SFP LC LH70 1570 Transceiver
JD110A
HPE X170 1G SFP LC LH70 1590 Transceiver
JD111A
HPE X170 1G SFP LC LH70 1610 Transceiver
JD112A
HPE X120 1G SFP LC LH100 Transceiver
JD103A
Power Supply
HPE FlexFabric 7900 1800w AC Power Supply Unit
JG840A
Mounting Kit
HPE X421 Chassis Universal 4-post Rackmount Kit
JC665A
HPE FlexFabric 7904 Switch Chassis (JG682A)
HPE FlexFabric 7904 Front (Port Side) to Back (Power Side) Airflow Fan Tray
JG684A
HPE FlexFabric 7904 Back (Power Side) to Front (Port Side) Airflow Fan Tray
JG839A
HPE FlexFabric 7910 Switch Chassis (JG841A)
HPE FlexFabric 7910 7.2Tbps Fabric/Main Processing Unit
JG842A
HPE FlexFabric 7910 2.4Tbps Fabric/Main Processing Unit
JH001A
HPE FlexFabric 7910 Front (Port Side) to Back (Power Side) Airflow Fan Tray
JG843A
HPE FlexFabric 7910 Back (Power Side) to Front (Port Side) Airflow Fan Tray
JG844A
HPE FlexFabric 7910 Cable Management Frame
JH041A
HPE FlexFabric 7910 Bottom Support Rails
JH042A
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Summary of Changes
23
Date
Version History
Action
Description of Change
18-Apr-2017
From Version 16 to
Added
SKUs added on the Configuration section: JH693A, JH694A,
JH697A, JH698A, JH699A, JH700A, JL437A, JL438A, JL439A
07-Nov-2016
From Version 15 to
16
Added
SKU added: JL306A
30-Sep-2016
From Version 14 to
15
Changed
Configuration section updated.
01-Aug-2016
From Version 13 to
14
Added
JL290A, JL291A, JL292A, JL287A, JL288A, JL289A, JL286A
Changed
Standards and protocols updated.
06-Jun-2016
From Version 12 to
Added
SKU added: JG844A
Changed
Features and benefits and Technical Specifications updated
22-Apr-2016
From Version 11 to
12
Changed
SKUs descriptions updated on all document, minor changes
made on Technical Specifications and Features and Benefits
16-Feb-2016
From Version 10 to
11
Added
SKUs added:
JL251A
17-Dec-2015
From Version 9 to 10
Changed
Technical Specifications updated
01-Dec-2015
From Version 8 to 9
Added
SKUs added:
JG839A, JG882A, JG883A
Changed
QuickSpecs name changed to HPE FlexFabric 7900 Switch
Series
28-Sep-2015
From Version 7 to 8
Changed
Updated Overview, Features and Benefits, Technical
Specification and Accessories section
01-Jun-2015
From Version 6 to 7
Added
SKUs Added:
JH002A, JG881A
Changed
Updated Overview, Technical Specification and Accessories
section
30-Mar-2015
From Version 5 to 6
Added
Added new SKUs and supported transceivers:
JD116A, JG325B, K2Q46A, K2Q47A
17-Feb-2015
From Version 4 to 5
Removed
Removed supported transceivers from the Configuration section
01-Dec-2014
From Version 3 to 4
Added
Added 1 New model JG841A
Changed
Updated Key features, Product overview, Features and benefits
03-Jul-2014
From Version 2 to 3
Changed
Switch Chassis, Internal Power Supplies, and Fan Trays were
revised in Configuration.
26-Jun-2014
From Version 1 to 2
Changed
Updated the Power Supply specifications.
17
JH695A, JH696A, JH679A, JH681A, JH677A, JH678A,
13
JG683B, JG845A, JD092B, JD093B, JD094B, JG234A, JD095C,
JD096C, JD097C, JG081C, JC784C, JD089B, JD098B, JD099B,
JD103A, JD062A, JD118B, JD119B, JD061A, JD063B, JD109A,
JD110A, JD111A, JD112A, JD113A, JD114A, JD115A,
Page
QuickSpecs
HPE FlexFabric 7900 Switch Series
Summary of Changes
24
Sign up for updates
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterprise products and
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should
shall not be liable for technical or editorial errors or omissions contained herein.
To learn more, visit:
c04293387
be construed as constituting an additional warranty. Hewlett Packard Enterprise
http://www.hpe.com/networking
- 14944 - Worldwide - V17 - 18-April-2017
Page
Loading...
