QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
1
HPE FlexFabric 12900E Switch Series
Models
HPE FlexFabric 12916E Switch Chassis
JH103A
HPE FlexFabric 12908E Switch Chassis
JH255A
HPE FlexFabric 12904E Switch Chassis
JH262A
HPE FlexFabric 12902E Switch Chassis
JH345A
HPE FlexFabric 12901E Switch Chassis
JH951A
HPE FlexFabric 12910 Switch AC Chassis
JG619A
Key features
• Nonblocking, lossless Clos architecture
Product overview
The HPE FlexFabric 12900E Switch Series is a next-generation modular data center core switch designed to support virtualized
data centers and the evolving needs of private and public cloud deployments.
• VxLAN, IRF, and TRILL support for virtualized and cloud deployments
• High GbE, 10GbE, 40GbE, and 100GbE density across 46 Tb/s switch fabric
• Enhanced modularity with control and data plane separation
• SDN-enabled with OpenFlow1.3 support
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
2
The FlexFabric 12900E switch delivers unprecedented levels of performance, buffering, scale, and availability with high-density
GbE, 10GbE, 40GbE and 100GbE. The HPE FlexFabric 12900 Switch Series includes 16
Software
advanced features such as Virtual Extensible LAN (VxLAN), TRansparent Interconnection of Lots of Links (TRILL) and Intelligen
Resilient Fabric (IRF), which provide the ability to build large, resilient switching fabrics. Th
also supports fully redundant and hot-swappable components to complement its other enterprise-class capabilities.
Features and benefits
Product architecture
Performance
Data center optimized
Virtual Application Network innovation that provides a Layer 2 extension across the data
and IEEE 802.1Qbb Priority Flow Control (PFC) for converged fabrics
-, 10-, 8- 4-, 2-, and 1-slot chassis.
-defined networking (SDN) enabled with OpenFlow 1.3, the switch supports full Layer 2 and 3 features, including
t
e HPE FlexFabric 12900 Switch Series
• Modern scalable system architecture
provides nonblocking, lossless Clos architecture with VOQs and large buffers with the flexibility and scalability for future
growth
• Distributed architecture with separation of data and control planes
delivers enhanced fault tolerance and facilitates continuous operation and zero service disruption during planned or
unplanned control-plane events
• Advanced Comware modular operating system
brings native high-stability, independent process monitoring, and restart through the modular design and multiple
processes of Hewlett Packard Enterprise (HPE) Comware v7 software; supports enhanced serviceability functions
• In-Service Software Upgrade (ISSU)
provides an IRF-based upgrade for seamless maintenance with minimal disruption
• Multitenant Device Context (MDC)
virtualizes a physical switch into multiple logical devices, with each logical switch having its own processes, configuration,
and administration
• High-performance fully distributed architecture
delivers up to 184 Tbps (bi-directional) switching capacity and 92.16 Bpps throughput with non-blocking wire speed
performance
• High-density 1, 10, 40 and 100GbE interface connectivity
offers up to 16 interface module slots to scale up to 768 1/10GbE, 576 40GbE, 128 100GbE ports or a combination
• Low latency and consistent performance
Under 5 microsecond latency (64-byte packets) and consistent performance for broad range of applications typical of a
data center including mixed traffic loads of real-time, multicast, and storage traffic
• Distributed scalable fabric architecture
offers up to six fabric modules to deliver more than 2 Tb per slot bandwidth
• Virtual Extensible LAN (VxLAN)
provides wire-rate support for seamless Layer 2 connectivity across Layer 3 networks enabling virtual machine mobility
and cloud deployments
• Scalable Layer 2 fabrics
builds flexible, resilient, and scalable Layer 2 fabrics with TRILL and Hewlett Packard Enterprise IRF
• Hewlett Packard Enterprise Ethernet Virtual Interconnect (EVI)
is an Hewlett Packard Enterprise
center to simplify the interconnectivity of geographically disperse data centers
• Edge Virtual Bridging (EVB) with Virtual Ethernet Port Aggregator (VEPA)
provides connectivity into the virtualization-ready data center environment
• Data Center Bridging (DCB) protocols
provides support for IEEE 802.1Qaz Data Center Bridging Exchange (DCBX), Enhanced Transmission Selection (ETS),
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
3
• Fibre Channel over Ethernet (FCoE) features
Resiliency and high availability
using standard LACP for automatic load balancing and high availability; can eliminate the need for complex protocols like
Layer 2 switching
increases security by isolating ports within a VLAN while still allowing them to communicate with other VLANs
deliver support for FCoE, including expansion, fabric, trunk VF and N ports, and aggregation of E-port and N-port
virtualization
• Front-to-back airflow chassis available
accommodates deployment in data centers utilizing hot-cold aisles
• Intelligent Resilient Fabric (IRF)
creates virtual resilient switching fabrics, where two or more switches perform as a single L2 switch and L3 router;
switches do not have to be co-located and can be part of a disaster-recovery system; servers or switches can be attached
Spanning Tree Protocol, Equal-Cost Multipath (ECMP), or VRRP, thereby simplifying network operation
• Redundant/load-sharing fabrics, management, fan assemblies, and power supplies
increase total performance and power availability while providing hitless, stateful failover
• Hot-swappable modules
allows replacement of modules without any impact on other modules
• Graceful restart
allows routers to indicate to others their capability to maintain a routing table during a temporary shutdown, which
significantly reduces convergence times upon recovery; supports OSPF, BGP, and IS-IS
• Virtual Router Redundancy Protocol (VRRP)
allows groups of two routers to back each other up dynamically to create highly available routed environments
• Device Link Detection Protocol (DLDP)
monitors link connectivity and shuts down ports at both ends if unidirectional traffic is detected, preventing loops in STPbased networks
• Hitless patch upgrades
allows patches and new service features to be installed without restarting the equipment, increasing network uptime and
facilitating maintenance
• IEEE 802.3ad Link Aggregation Control Protocol (LACP)
supports up to 1024 trunk groups and up to 16 members per trunk; supports static or dynamic groups and a userselectable hashing algorithm
• Passive design system
delivers increased system reliability as the backplane has no active components
• Ultrafast protocol convergence (subsecond) with standard-based failure detection—Bidirectional Forwarding
Detection (BFD)
enables link connectivity monitoring and reduces network convergence time for RIP, OSPF, BGP, IS-IS, VRRP, MPLS, and
IRF
• VLAN
supports up to 4,094 port-based or IEEE 802.1Q-based VLANs
• Bridge Protocol Data Unit (BPDU) tunneling
transmits Spanning Tree Protocol BPDUs transparently, allowing correct tree calculations across service providers, WANs,
or MANs
• Port mirroring
duplicates port traffic (ingress and egress) to a local or remote monitoring port; supports four mirroring groups, with an
unlimited number of ports per group
• Multiple VLAN Registration Protocol (MVRP)
helps to maintain VLAN configuration dynamically based on current network configurations
• Port mirroring
duplicates port traffic (ingress and egress) to a local or remote monitoring port; supports four mirroring groups, with an
unlimited number of ports per group
• Port isolation
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
4
• Internet Group Management Protocol (IGMP) and Multicast Listener Discovery (MLD) protocol snooping
Layer 3 routing
IS routing and extended
RFC 2547bis multiple autonomous system VPNs for added flexibility
controls and manages the flooding of multicast packets in a Layer 2 network
• Spanning Tree Protocol (STP)
supports standard IEEE 802.1D STP, IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) for faster convergence, and
IEEE 802.1s Multiple Spanning Tree Protocol (MSTP)
• IEEE 802.1ad QinQ and selective QinQ
increase the scalability of an Ethernet network by providing a hierarchical structure; connect multiple LANs on a highspeedcampus or metro network
• Open shortest path first (OSPF)
delivers faster convergence; uses this link-state routing Interior Gateway Protocol (IGP), which supports ECMP, NSSA, and
MD5 authentication for increased security and graceful restart for faster failure recovery
• Intermediate system to intermediate system (IS-IS)
uses a path vector Interior Gateway Protocol (IGP), which is defined by the ISO organization for ISby IETF RFC 1195 to operate in both TCP/IP and the OSI reference model (Integrated IS-IS)
• Border Gateway Protocol 4 (BGP-4)
delivers an implementation of the Exterior Gateway Protocol (EGP) utilizing path vectors; uses TCP for enhanced
reliability for the route discovery process; reduces bandwidth consumption by advertising only incremental updates;
supports extensive policies for increased flexibility; scales to very large network
• Multiprotocol Label Switching (MPLS)
uses BGP to advertise routes across Label Switched Paths (LSPs), but uses simple labels to forward packets from any
Layer 2 or Layer 3 protocol, which reduces complexity and increases performance; supports graceful restart for reduced
failure impact; supports LSP tunneling and multilevel stacks
• Dual IP stack
maintains separate stacks for IPv4 and IPv6 to ease the transition from an IPv4-only network to an IPv6-only network
desig
• Equal-Cost Multipath (ECMP)
enables multiple equal-cost links in a routing environment to increase link redundancy and scale bandwidt
• Policy-based routing
makes routing decisions based on policies set by the network administrator
• Static IPv4 routing
provides simple manually configured IPv4 routing
• Routing Information Protocol (RIP)
uses a distance vector algorithm with UDP packets for route determination; supports RIPv1 and RIPv2 routing; includes
loop protection
• IP performance optimization
provides a set of tools to improve the performance of IPv4 networks; includes directed broadcasts, customization of TCP
parameters, support of ICNP error packets, and extensive display capabilities
• Unicast Reverse Path Forwarding (uRPF)
limits erroneous or malicious traffic in accordance with RFC 3074
• Static IPv6 routing
provides simple manually configured IPv6 routing
• Routing Information Protocol next generation (RIPng)
extends RIPv2 to support IPv6 addressing
• OSPFv3
provides OSPF support for IPv
• IS-IS for IPv6
extends IS-IS to support IPv6 addressing
• BGP+
extends BGP-4 to support Multiprotocol BGP (MBGP), including support for IPv6 addressing
• Multiprotocol Label Switching (MPLS) Layer 3 VPN
allows Layer 3 VPNs across a provider network; uses MP-BGP to establish private routes for increased security; supports
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
5
• Multiprotocol Label Switching (MPLS) Layer 2 VPN
Q
Layer 3 services
determines the MAC address of another IP host in the same subnet; supports static ARPs; gratuitous ARP allows detection
Management
reduces training time and expenses, and increases productivity in multivendor installations
establishes simple Layer 2 point-to-point VPNs across a provider network using only MPLS Label Distribution Protocol
(LDP); requires no routing and therefore decreases complexity, increases performance, and allows VPNs of non-routable
protocols; uses no routing information for increased security; supports Circuit Cross Connect (CCC), Static Virtual Circuits
(SVCs), Martini draft, and Kompella-draft technologies
• Virtual Private LAN Service (VPLS)
establishes point-to-multipoint Layer 2 VPNs across a provider network
• IPv6 tunneling
provides an important element for the transition from IPv4 to IPv6; allows IPv6 packets to traverse IPv4-only networks by
encapsulating the IPv6 packet into a standard IPv4 packet; supports manually configured, 6to4, Intra-Site Automatic
Tunnel Addressing Protocol (ISATAP) tunnels, and IPv6 on VPN to Provider Edge (6VPE) router tunnel
uality of Service (QoS)
• IEEE 802.1p prioritization
delivers data to devices based on the priority and type of traffic
• Flexible classification
creates traffic classes based on access control lists (ACLs), IEEE 802.1p precedence, IP, and DSCP or Type of Service
(ToS) precedence; supports filter, redirect, mirror, remark, and logging
• Bandwidth shaping
− Port-based rate limiting
provides per-port ingress-/egress-enforced increased bandwidth
− Classifier-based rate limiting
uses an access control list (ACL) to enforce increased bandwidth for ingress traffic on each port
− Reduced bandwidth
provides per-port, per-queue egress-based reduced bandwidth
• Broad QoS feature set
provides support for Strict Priority Queuing (SP), Weighted Fair Queuing (WFQ), Weighted Deficit Round Robin(WDRR),
SP+WDRR together, configurable buffers, Explicit Congestion Notification (ECN), and Weighted Random Early Detection
(WRED)
• Traffic policing
supports Committed Access Rate (CAR) and line rate
• Address Resolution Protocol (ARP)
• User Datagram Protocol (UDP) helper
• Dynamic Host Configuration Protocol (DHCP)
• Management interface control
• Industry-standard CLI with a hierarchical structure
of duplicate IP addresses; proxy ARP allows normal ARP operation between subnets or when subnets are separated by a
Layer 2 network
redirects UDP broadcasts to specific IP subnets to prevent server spoofing
simplifies the management of large IP networks and supports client and server; DHCP Relay enables DHCP operation
across subnets
enables or disables each of the following interfaces depending on security preferences: console port, Telnet port, or reset
button
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
6
• SNMPv1, v2, and v3
based wirespeed network monitoring and accounting with no impact on network performance; this
analyzes network performance and service quality by sending test packets, and provides network performance and service
Connectivity
detects data link layer problems that occurred in the "last mile" using the IEEE 802.3ah OAM standard; monitors the status
Security
eases switch security access administration by using a password authentication server
provide complete support of SNMP; provide full support of industry-standard Management Information Base (MIB) plus
private extensions; SNMPv3 supports increased security using encryption
• sFlow (RFC 3176)
provides scalable ASICallows network operators to gather a variety of sophisticated network statistics and information for capacity planning and
real-time network monitoring purposes
• Remote monitoring (RMON)
uses standard SNMP to monitor essential network functions; supports events, alarm, history, and statistics group plus a
private alarm extension group
• Debug and sampler utility
supports ping and traceroute for both IPv4 and IPv6
• Network Time Protocol (NTP)
synchronizes timekeeping among distributed time servers and clients; keeps timekeeping consistent among all clockdependent devices within the network so that the devices can provide diverse applications based on the consistent time
• Network Quality Analyzer (NQA)
quality parameters such as jitter, TCP, or FTP connection delays and file transfer rates; allows a network manager to
determine overall network performance and to diagnose and locate network congestion points or failures
• Information center
provides a central repository for system and network information; aggregates all logs, traps, and debugging information
generated by the system and maintains them in order of severity; outputs the network information to multiple channels
based on user-defined rules
• IEEE 802.1AB Link Layer Discovery Protocol (LLDP)
advertises and receives management information from adjacent devices on a network, facilitating easy mapping by
network management applications
• Jumbo frames
• Loopback
• Ethernet operations, administration and maintenance (OAM)
• Monitor link
• Packet storm protection
• Flow control
• Access control list (ACL)
• Remote Authentication Dial-In User Service (RADIUS)
allows high-performance backups and disaster-recovery systems with frame sizes of up to 10,000 bytes
supports internal loopback testing for maintenance purposes and an increase in availability; loopback detection protects
against incorrect cabling or network configurations and can be enabled on a per-port or per-VLAN basis for added
flexibility
of the link between two devices
collects statistics on performance and errors on physical links, increasing system availability
protects against unknown broadcast, unknown multicast, or unicast storms with user-defined thresholds
provides back pressure using standard IEEE 802.3x, reducing congestion in heavy traffic situations
supports powerful ACLs for both IPv4 and IPv6; ACLs are used for filtering traffic to prevent unauthorized users from
accessing the network, or for controlling network traffic to save resources; rules can either deny or permit traffic to be
forwarded; rules can be based on a Layer 2 header or a Layer 3 protocol header; rules can be set to operate on specific
dates or times
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Overview
7
• Terminal Access Controller Access-Control System (TACACS+)
Multicast support
Warranty and support
; for details on the software releases
HPE Recommended Options have the best performance, value and availability.
Recommended Options
workloads and market segments.
provide the best fit with timely availability.
Extended Options
requiring the utmost in performance or value.
Options represent great value and performance but typically have a longer lead-time.
delivers an authentication tool using TCP with encryption of the full authentication request, providing additional security
• Secure shell (SSHv2)
uses external servers to securely log in to a remote device; with authentication and encryption, it protects against IP
spoofing and plain-text password interception; increases the security of Secure FTP (SFTP) transfers
• DHCP snooping
helps ensure that DHCP clients receive IP addresses from authorized DHCP servers and maintain a list of DHCP entries
for trusted ports; prevents reception of fake IP addresses and reduces ARP attacks, improving security
• IP Source Guard
filters packets on a per-port basis, which prevents illegal packets from being forwarded
• ARP attack protection
protects against attacks that use a large number of ARP requests, using a host-specific, user-selectable threshold
• Port security
allows access only to specified MAC addresses, which can be learned or specified by the administrator
• Internet Group Management Protocol (IGMP)
utilizes Any-Source Multicast (ASM) or Source-Specific Multicast (SSM) to manage IPv4 multicast networks; supports
IGMPv1, v2, and v3
• Protocol Independent Multicast (PIM)
defines modes of Internet IPv4 and IPv6 multicasting to allow one-to-many and many-to-many transmission of
information; PIM Dense Mode (DM), Sparse Mode (SM), and Source-Specific Mode (SSM) are supported
• 1-year warranty
See http://www.hpe.com/networking/warrantysummary
product purchase.
• Software releases
to find software for your product, refer to http://www.hpe.com/networking/support
available with your product purchase, refer to http://www.hpe.com/networking/warrantysummary
have been selected by Hewlett Packard Enterprise experts to provide the right technology for a range of
Fully integrated into the ProLiant management and security experience, Recommended Options
View the list for your region.
provide an extended catalog of products tailored for customers in specific markets or with specific workloads,
Fully integrated into the ProLiant management and security experience, Extended
for warranty and support information included with your
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
8
Build To Order
Shippable solution.
HPE FlexFabric 12901E Switch Chassis
JH951A
•
• 2U Height Rack
HPE FlexFabric 12902E Switch Chassis
JH345A
•
• 3U Height Rack
HPE FlexFabric 12904E Switch Chassis
JH262A
•
• 6U Height Rack
HPE FlexFabric 12908E Switch Chassis
JH255A
•
• 12U Height Rack
HPE FlexFabric 12916E Switch Chassis
JH103A
•
• Must select Min 1 Fabric Module
: BTO is a standalone unit with no integration. BTO products ship standalone are not part of a CTO or Rack-
Integrated MPU
• 1 - Integrated Fabric Module(No separate Fabric Module required)
• 1 - I/O module slots
• Must select Min 1 Power Supply
• Must select Min 2 Fan Trays
2 - MPUx (Management Ports)
• 2 - I/O module slots
• 2 - Integrated Fabric modules(No separate Fabric Module required)
• Must select min 1 Management Module
• Must select min 2 Power Supplies
• Must select Min 2 Fan Trays
2 - MPUx (Management Ports)
• 4 - I/O module slots
• 6 - Fabric module slots
• Must select min 1 Management Module
• Must select min 2 Power Supplies
• Must select Min 1 Fabric Module
• Must select Min 2 Fan Trays
2 - MPUx (Management Ports)
• 8 - I/O module slots
• 6 - Fabric module slots
• Must select min 1 Management Module
• Must select min 2 Power Supplies
• Must select Min 1 Fabric Module
• Must select Min 2 Fan Trays
2 - MPUx (Management Ports)
• 16 - I/O module slots
• 6 - Fabric module slots
• Must select min 1 Management Module
• Must select min 2 Power Supplies
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
9
•
• 21U Height Rack
Remarks:
OCA Only Model Selection Form HPE Offering >
12900 Switch Series
Modules
Fabric Modules
JG619A, JH113A, System (std 0 // max 6) User Selection (min 4 // max 6) per Switch
JH262A, JH255A, JH103A System (std 0 // max 6) User Selection (min 1 // max 6) per switch enclosure
JH345A System (std 2 // max 2) User Selection (min 0 // max 0) per switch enclosure
HPE FlexFabric 12904E 2.5Tbps Type F Fabric Module
JH264A
See Configuration
NOTE: 1, 4
HPE 12904E 7.2Tbps Type H Fabric Mod
JH364A
See Configuration
NOTE:
, 9
HPE 12908E 14.4Tbps Type H Fabric Mod
JH362A
See Configuration
NOTE: 1, 5, 7. 10
HPE FlexFabric 12908E 5.0Tbps Type F Fabric Module
JH257A
See Configuration
1, 5
HPE FlexFabric 12910 1.92Tbps Type A Fabric Module
JG622A
See Configuration
NOTE: 1, 2, 8
HPE FlexFabric 12910 3.84Tbps Type B Fabric Module
JG623A
See Configuration
NOTE: 1, 2, 8
HPE FlexFabric 12916E 10.0Tbps Type F Fabric Module
JH252A
See Configuration
NOTE: 1, 6
HPE FlexFabric 12916E 21.6Tbps Type H Fabric Module
JH361A
See Configuration
NOTE: 1, 6, 7, 11
HPE FlexFabric 12916E 43.2Tbps Type H Fabric Module
JH435A
Must select Min 2 Fan Trays
DataCenter Networing > FlexFabric Switches - Core:
1, 4, 7
NOTE:
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
10
See Configuration
NOTE: 1, 6, 7, 11
Configuration Rules:
Note 1
If more than 1 Fabric Module is selected, they must be of the same Type.
Note 2
This Fabric Module is only supported on switch JG619A.
Note 3
This Fabric Module is only supported on switch JG632A.
Note 4
This Fabric Module is only supported on switch JH262A.
Note 5
This Fabric Module is only supported on switch JH255A.
Note 6
This Fabric Module is only supported on switch JH103A.
Note 7
Only H Series I/O Modules are supported
Note 8
Only EA/EB/EC Series I/O Modules are supported
Note 9
If a 12904E Switch Chassis is configured with a Type H Fabric Module, then qty 2 of the
following High Speed Fan Tray must be selected:
HPE FlexFabric 12904E High Speed Fan Tray Assembly
JH448A
Note 10
If a 12908E Switch Chassis is configured with a Type H Fabric Module, then qty 2 of the
following High Speed Fan Tray must be selected:
HPE FlexFabric 12908E Spare High Speed Fan Tray Assembly
JH424A
Note 11
If a 12916E Switch Chassis is configured with a Type H Fabric Module, then qty 2 of the
following High Speed Fan Tray must be selected:
HPE FlexFabric 12916E Spare High Speed Fan Tray Assembly
JH423A
Management Modules
System (std 0 // max 2) User Selection (min 1 // max 2) per Switch
HPE FlexFabric 12910 Main Processing Unit
JG621A
•
See Configuration
NOTE: 1
HPE FlexFabric 12902E Main Processing Unit
JH346A
•
See Configuration
NOTE: 5
HPE FlexFabric 12904E v2 Main Processing Unit
JH668A
•
See Configuration
NOTE: 4
HPE FlexFabric 12900E v2 Main Processing Unit
JH669A
•
See Configuration
NOTE: 3
No supported Transceivers
No supported Transceivers
No supported Transceivers
No supported Transceivers
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
11
Configuration Rules:
Note 1
The following Switches support this Module:
HPE FlexFabric 12910 Switch AC Chassis
JG619A
Note 3
The following Switches support this Module:
HPE FlexFabric 12908E Switch Chassis
JH255A
HPE FlexFabric 12916E Switch Chassis
JH103A
Note 4
The following Switches support this Module:
HPE FlexFabric 12904E Switch Chassis
JH262A
Note 5
The following Switches support this Module:
HPE FlexFabric 12902E Switch Chassis
JH345A
Accessory
HPE FlexFabric 12900E LPU Adapter
JH107A
See Configuration
NOTE: 1, 2
Configuration Rules
Note 1
This Adapter is REQUIRED if any FX/FE I/O module is added to the below switches: (1 per module)
HPE FlexFabric 12904E Switch Chassis
JH262A
HPE FlexFabric 12908E Switch Chassis
JH255A
HPE FlexFabric 12916E Switch Chassis
JH103A
Note 2
This Adapter is not compatible with the following switch:
HPE FlexFabric 12902E Switch Chassis
JH345A
I/O Modules
JG619A, JH113A - System (std 0 // max 10) User Selection (min 1 // max 10)
JG632A - System (std 0 // max 16) User Selection (min 1 // max 16)
12904E (std 0 // max 4) User Selection (min 1 // max 4) per switch enclosure
12908E (std 0 // max 8) User Selection (min 1 // max 8) per switch enclosure
12916E (std 0 // max 16) User Selection (min 1 // max 16) per switch enclosure
JH345A (std 0 // max 2) User Selection (min 1 // max 2) per switch enclosure
JH951A (std 0 // max 1) User Selection (min 0 // max 1) per switch enclosure
HPE FlexFabric 12900 48-port GbE SFP EB Module
JG855A
•
See Configuration
1, 6
HPE FlexFabric 12900 48-port 10/100/1000BASE-T EB Module
JG856A
• No supported Transceiver
See Configuration
6
HPE FlexFabric 12900 48-port 10/100/1000BASE-T FX Module
JH242A
Min 0 // Max 48 SFP+ Transceivers
NOTE:
NOTE:
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
12
See Configuration
NOTE: 6
HPE FlexFabric 12900 48-port 1/10GBASE-T FX Module
JH007A
See Configuration
NOTE: 6, 11
HPE FlexFabric 12900 48-port GbE SFP FX Module
JH241A
See Configuration
1, 6
HPE FlexFabric 12900 48-port 10GbE SFP+ EA Module
JG624A
• Min 0 // Max 48 SFP+ Transceivers
See Configuration
1, 2, 4, 6
HPE FlexFabric 12900 48-port 1/10GbE SFP+ EC Module
JG626A
• Min 0 // Max 48 SFP+ Transceivers
See Configuration
1, 2, 4, 6
HPE FlexFabric 12900 48-port 1/10GbE SFP+ FE Module
JH249A
•
See Configuration
,
13
HPE FlexFabric 12900 36-port 40GbE QSFP+ FX Module
JH045A
•
See Configuration
NOTE: 3, 6, 11
HPE 12900E 36p 100GbE QSFP28 HB Mod
JH357A
• Min 0 // Max 36 QSFP+/QSFP28 Transceivers
See Configuration
3, 10, 11,
14, 16, 19
HPE 12900E 48p 40GbE QSFP+ HB Mod
JH359A
•
See Configuration
3, 10, 11,
16
HPE 12900E 48p 10G/2p 100G HB Mod
JH360A
•
See Configuration
NOTE:
1, 2, 10, 11, 13, 14,
15, 16, 19
HPE FlexFabric 12900E 18-port 100G QSFP28/18-port 40G QSFP+ HB Module
JH422A
•
See Configuration
NOTE:
,
19
HPE FlexFabric 12900E 18-port 100G QSFP28/18-port 40G QSFP+ HF Module
JH425A
• No supported Transceivers
• No supported Transceivers
• Min 0 // Max 48 SFP Transceivers
Min 0 // Max 48 SFP+ Transceivers
Min 0 // Max 36 QSFP+ Transceivers
NOTE:
NOTE:
NOTE:
NOTE: 1, 2, 6, 11
NOTE:
Min 0 // Max 48 QSFP+ Transceivers
Min 0 // Max 2 QSFP+/QSFP28 Transceivers
• Min 0 // Max 48 SFP/SFP+ Transceivers
Min 0 // Max 18 QSFP28 100G Transceivers
• Min 0 // Max 18 QSFP+ 40G Transceivers
NOTE:
3, 10, 11, 14, 16
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
13
•
See Configuration
NOTE:
3, 10, 11, 14, 16
HPE FlexFabric 12900E 24p 10G/2p 40G HB 59xx Slot Module
JH953A
•
See Configuration
NOTE:
15,
16, 17, 22
HPE FlexFabric 12900E 48-port 10GbE SFP+ HF Module
JQ061A
•
See Configuration
NOTE:
10, 11, 16, 20, 22
HPE FlexFabric 12900 24-port 40GbE QSFP+ FE Module
JH250A
See Configuration
NOTE: 3, 6, 11
HPE FlexFabric 12900 48-port 1/10GbE SFP+ FX Module
JG888B
•
See Configuration
,
13
HPE FlexFabric 12900 24-port 40GbE QSFP+ FX Module
JG889B
See Configuration
NOTE: 3, 6, 11
HPE FlexFabric 12900 16-port 40GbE QSFP+ EA Module
JG625A
• Min 0 // Max 16 QSFP+ Transceivers
See Configuration
, 6
HPE FlexFabric 12900 12-port 40GbE QSFP+ EC Module
JG857A
• Min 0 // Max 12 QSFP+ Transceivers
See Configuration
, 6
HPE FlexFabric 12900 12-port 40GbE QSFP+ FX Module
JH005A
•
See Configuration
NOTE: 3, 6, 11
HPE FlexFabric 12900E 24-port 10GbE and 4-port 100GbE HD 59xx Slot Module
JH954A
•
•
See Configuration
1, 10, 11,
13, 14, 16, 18, 22
HPE FlexFabric 12900 4-port 100GbE CFP EC Module
JG858A
• Min 0 // Max 4 CFP Transceivers
See Configuration
, 6
HPE FlexFabric 12900 8-port 100GbE CXP FX Module
JH006A
Min 0 // Max 18 QSFP28 100G Transceivers
• Min 0 // Max 18 QSFP+ 40G Transceivers
Min 0 // Max 1 59XX Module
• Min 0 // Max 24 SFP+ 10G Transceivers
• Min 0 // Max 2 QSFP+ 40G Transceivers
Min 0 // Max 48 SFP+ 10G Transceivers
• Min 0 // Max 24 QSFP+ Transceivers
Min 0 // Max 48 SFP+ Transceivers
1, 10, 11, 13,
NOTE: 1, 2, 6, 11
• Min 0 // Max 24 QSFP+ Transceivers
Min 0 // Max 12 QSFP+ Transceivers
Min 0 // Max 1 59XX Module
• Min 0 // Max 24 SFP/SFP+ Transceivers
Min 0 // Max 4 QSFP28 Transceivers
NOTE: 3
NOTE: 3
NOTE:
NOTE: 5
Page
QuickSpecs
HPE FlexFabric 12900E Switch Series
Configuration
14
See Configuration
NOTE: 6, 7, 11
HPE FlexFabric 12900 8-port 100GbE CFP2 FX Module
JH288A
See Configuration
NOTE: 6, 11, 12
Configuration Rules
Note 1
The following Transceivers install into this Module:
HPE X120 1G SFP LC LH100 Transceiver
JD103A
HPE X125 1G SFP LC LH40 1310nm Transceiver
JD061A
HPE X120 1G SFP LC LH40 1550nm Transceiver
JD062A
HPE X120 1G SFP RJ45 T Transceiver
JD089B
HPE X120 1G SFP LC SX Transceiver
JD118B
HPE X120 1G SFP LC LX Transceiver
JD119B
HPE X125 1G SFP LC LH70 Transceiver
JD063B
HPE X120 1G SFP LC BX 10-U Transceiver
JD098B
HPE X120 1G SFP LC BX 10-D Transceiver
JD099B
Note 2
The following Transceivers install into this Module:
HPE X130 10G SFP+ LC SR Transceiver
JD092B
HPE X130 10G SFP+ LC LR Transceiver
JD094B
HPE X130 10G SFP+ LC SR Data Center Transceiver
JL437A
HPE X130 10G SFP+ LC LR Data Center Transceiver
JL439A
HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
JD095C
HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
JD096C
HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
JD097C
HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JG081C
HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable
JC784C
HPE X130 10G SFP+ LC ER 40km Transceiver
JG234A
HPE X130 10G SFP+ LC LH 80km Transceiver
JG915A
HPE X2A0 10G SFP+ to SFP+ 7m Active Optical Cable
JL290A
HPE X2A0 10G SFP+ to SFP+ 10m Active Optical Cable
JL291A
HPE X2A0 10G SFP+ to SFP+ 20m Active Optical Cable
JL292A
Note 3
The following 40G Transceivers install into this Module:
HPE X140 40G QSFP+ LC LR4 SM 10km 1310nm Transceiver
JG661A
HPE X140 40G QSFP+ LC BiDi 100m MM Transceiver
JL251A
HPE X140 40G QSFP+ MPO SR4 Transceiver
JG325B
HPE X140 40G QSFP+ MPO MM 850nm CSR4 300m Transceiver
JG709A
HPE X140 40G QSFP+ LC ER4 40km SM Transceiver
JL306A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 1m Direct Attach Copper Cable
JG326A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 3m Direct Attach Copper Cable
JG327A
HPE FlexNetwork X240 40G QSFP+ QSFP+ 5m Direct Attach Copper Cable
JG328A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 1m Direct Attach Copper Splitter Cable
JG329A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 3m Direct Attach Copper Splitter Cable
JG330A
HPE FlexNetwork X240 40G QSFP+ to 4x10G SFP+ 5m Direct Attach Copper Splitter Cable
JG331A
HPE X140 40G QSFP+ LC LR4L 2km SM Transceiver
JL286A
HPE X2A0 40G QSFP+ to QSFP+ 7m Active Optical Cable
JL287A
HPE X2A0 40G QSFP+ to QSFP+ 10m Active Optical Cable
JL288A
HPE X2A0 40G QSFP+ to QSFP+ 20m Active Optical Cable
JL289A
• Min 0 // Max 8 CXP Transceivers
• Min 0 // Max 8 CFP2 Transceivers
Page
Loading...
