HPE 5800 TAA-compliant
Switch Series

Data sheet

Key features

• For enterprise core, distribution, data center

• Flex chassis with modular resiliency

• Support for up to 84 ports

• OAA module for flexible deployment

• Redundant, hot-swappable power supplies, fans

Product overview

HPE 5800 TAA-compliant Switch Series oers
an unmatched combination of Gigabit and
10 Gigabit Ethernet port density, high-availability
architecture, and full Layer 2 and Layer 3
dual-stack IPv4 and IPv6 capabilities. In
addition to wire-speed line-rate performance
on all ports, the switches include patented
Intelligent Resilient Framework (IRF)
technology and Rapid Ring Protection
Protocol (RRPP), which allow local or
geographically distributed HPE 5800 switches
to be interconnected for higher resiliency and
performance. Available in PoE and non-PoE
models as well as 1 RU and 2 RU form-factor
configurations, HPE 5800 switches are built
on open standards and include an open
application architecture (OAA) module slot
that enables flexible deployment options for

new services. These versatile switches are
ideal for use in the network core of buildings
or departments, or as high-performance
switches in the convergence layer or network
edge of enterprise campus networks.

Features and benefits

Quality of service (QoS)

• Powerful QoS feature

Creates traic classes based on access control
lists (ACLs), IEEE 8021p precedence, IP, and
DSCP or Type of Service (ToS) precedence;
supports filter, redirect, mirror, or remark;
supports the following congestion actions:
strict priority (SP) queuing, weighted round
robin (WRR), weighted fair queuing (WFQ),
weighted random early discard (WRED),
weighted deficit round robin (WDRR), and
SP+WDRR

• Integrated network services

With support for open application architecture
(OAA) modules, extends and integrates
application capability into the network

• Ring Resiliency Protection Protocol (RRPP)

Provides fast recovery for ring Ethernet-based
topology; provides consistent application
performance for applications such as VoIP

Data sheet

Page 2

Management

• Remote configuration and management

Enables configuration and management
through a secure Web browser or a CLI
located on a remote device

• IEEE 8021AB LLDP discover y

Advertises and receives management
information from adjacent devices on a
network, facilitating easy mapping by
network management applications

• USB support

– File copy

Allows users to copy switch files to and
from a USB flash

• Drive DHCP options

– DNS Relay and SMTP Redirection

– DHCP Server (RFC 2131), Client, and

Option-82 Relay (RFC 3046)

• sFlow®

Provides scalable ASIC-based network
monitoring and accounting; this allows
network operators to gather a variety of
sophisticated network statistics and
information for capacity planning and
real-time network monitoring purposes

• SNMPv1, v2c, and v3

Facilitate centralized discovery, monitoring,
and secure management of networking
devices

• Network Time Protocol (NTP)

Synchronizes timekeeping among distributed
time servers and clients; keeps timekeeping
consistent among all clock-dependent
devices within the network so that the
devices can provide diverse applications
based on the consistent time

Connectivity

• High-density port connectivity

Supports up to 841-Gigabit Ethernet ports
per unit (612 per stack)

• Auto-MDIX

Automatically adjusts for straight-through or
crossover cables on all 10/100 ports

• Jumbo frames

Are supported on 10GbE and GbE ports,
with a maximum frame size of 9K; allow
high-performance backups and
disaster-recovery systems

• IEEE 8023af Power over Ethernet (PoE)

Provides up to 154 W per port to IEEE
8023af-compliant PoE-powered devices
such as IP phones, wireless access points,
and security cameras

• IEEE 8023at Power over Ethernet (PoE+)

Provides up to 30 W per port that allows
support of the latest PoE+-capable devices
such as IP phones, wireless access points,
and security cameras, as well as any IEEE
8023af-compliant end device; obviates
the cost of additional electrical cabling and
circuits that would otherwise be necessary in
IP phone and WLAN deployments

• IPv6 native support

– IP v6 host

Enables switches to be managed and
deployed at the IPv6 network’s edge

– Dual stack (IPv4/IPv6)

Transitions from IPv4 to IPv6, supporting
connectivity for both protocols

– MLD snooping

Forwards IPv6 multicast traic to the
appropriate interface

– IPv6 ACL/QoS

Supports ACL and QoS for IPv6 network
traic, preventing traic flooding

– IPv6 routing

Supports IPv6 static routes and IPv6
versions of RIP, OSPF, IS-IS, and BGP
routing protocols

Performance

• Hardware-based wire-speed access control
list s (ACLs)

Help provide high levels of security and ease
of administration without impacting network
performance with a feature-rich TCAM-based
ACL implementation

• Unique versatile architecture

Supports the best of both fixed-port and
modular configurations

Manageability

• Full-featured console

Provides complete control of the switch with
a familiar CLI

• Web interface

Allows configuration of the switch from any
Web browser on the network

Data sheet

Page 3

• RMON and sFlow

Provide advanced monitoring and
reporting capabilities for statistics, history,
alarms, and events

• Multiple configuration files

Allow multiple configuration files to be
stored to a flash image

• Troubleshooting

– Ingress and egress port monitoring

Enable network problem solving

– Traceroute and ping

Enable testing of network connectivity

– Virtual cable tests

Provide visibility to cable problems

Layer 2 switching

• GARP VLAN Registration Protocol

Allows automatic learning and dynamic
assignment of VLANs

• 32K MAC addresses

Provide access to many Layer 2 devices

• 4094 port-based VLANs

Provide security between workgroups

• IEEE 8021ad QinQ and selective QinQ

Increase the scalability of an Ethernet
network by providing a hierarchical
structure; connect multiple LANs on a
high-speed campus or metro network

• Gigabit Ethernet port aggregation

Allows grouping of ports to increase overall
data throughput to a remote device

• 10GbE port aggregation

Allows grouping of ports to increase overall
data throughput to a remote device

• Spanning Tree/MSTP, RSTP, and STP root
guard

Prevent network loops

• IPFIX/sFlow

Allows traic sampling

Layer 3 services

• Address Resolution Protocol (ARP)

Determines the MAC address of another IP
host in the same subnet; supports static ARPs;
gratuitous ARP allows detection of duplicate
IP addresses; proxy ARP allows normal ARP
operation between subnets or when subnets
are separated by a Layer 2 network

• Dynamic Host Configuration Protocol
(DHCP)

Simplifies the management of large IP
networks and supports client and server;
DHCP Relay enables DHCP operation across
subnets

Layer 3 routing

• Layer 3 IPv4 routing

Provides routing of IPv4 at media speed;
supports static routes, RIP and RIPv2, OSPF,
IS-IS, and BGP

• RIP and RIPng support

Provides complete support of RIP for both
IPv4 and IPv6

• OSPF and OSPFv3 support

Provides complete support of OSPF for both
IPv4 and IPv6

• IS-IS and IS-ISv6 support

Provides complete support of IS-IS for both
IPv4 and IPv6

• Layer 3 IPv6 routing

Provides routing of IPv6 at media speed;
supports static routes, RIPng, OSPFv3,
IS-ISv6, and BGP4+

• Bidirectional Forwarding Detection (BFD)

Enables link connectivity monitoring and
reduces network convergence time for RIP,
OSPF, BGP, IS-IS, VRRP, MPLS, and IRF

• Virtual Router Redundancy Protocol (VRRP)
and VRRP Extended

Allow quick failover of router ports

• Policy-based routing

Makes routing decisions based on policies
set by the network administrator

Data sheet

Page 4

• IGMPv1, v2, and v3

Allow individual hosts to be registered on a
particular VLAN

• PIM-SSM, PIM-DM, and PIM-SM (for IPv4
and IPv6)

Support IP multicast address management
and inhibition of DoS attacks

• Equal-Cost Multipath (ECMP)

Enables multiple equal-cost links in a routing
environment to increase link redundancy
and scale bandwidth

• MPLS support

Provides extended support of MPLS,
including MPLS VPNs and MPLS Traic
Engineering (MPLS TE)

• VPLS support

Provides extended support of VPLS for
data center to data center communication
at Layer 2; provides support of hierarchical
VPLS for scalability

Security

• Unicast Reverse Path Forwarding (URPF)

Allows normal packets to be forwarded
correctly, but discards the attaching packet
due to lack of reverse path route or incorrect
inbound interface; prevents source spoofing
and distributed attacks; supports distributed
URPF

• Port isolation

Secures and adds privacy, and prevents
malicious attackers from obtaining user
information

• MAC-based authentication

Allows or denies access to the switch based
on a client MAC address

• IP source guard

Helps prevent IP spoofing attacks

• HTTPS management

Provides secure Web management

• Multi-Customer Edge (MCE)-Multicast
Virtual Routing and Forwarding (MVRF)

Provide MPLS Edge router support

• Public Key Infrastructure (PKI)

Is used to control access

• RADIUS/HWTACACS

Eases switch management security
administration by using a password
authentication server

• Secure shell (SSHv2)

Encrypts all transmitted data for secure,
remote CLI access over IP networks

• IP source guard

Filters packets on a per-port basis, which
prevents illegal packets from being forwarded

• Defense-in-depth security

Provides integrated and distributed security
enforcement that can be managed from a
central location, such as the HPE Intelligent
Management Center (IMC)

• Advanced processor queuing mechanism

Helps prevent denial of service (DoS)
attacks, while DHCP snooping helps
facilitate that devices can only receive an
IP address from a legitimate DHCP Server
on the network

• IEEE 8021X-based dynamic delivery of
QoS, ACLs, and VLANs

Allows complete control over user network
access

• Guest VLAN

Provides a browser-based environment
to authenticated clients that is similar to
IEEE 8021X

Convergence

• Voice VLAN

Automatically assigns VLAN and priority for
IP phones, simplifying network configuration,
and maintenance

• Internet Group Management Protocol (IGMP)

Utilizes Any-Source Multicast (ASM) or
Source-Specific Multicast (SSM) to manage
IPv4 multicast networks; supports IGMPv1,
v2, and v3

• Protocol Independent Multicast (PIM)

Defines modes of Internet multicasting
to allow one-to-many and many-to-many
transmission of information; supports PIM
Dense Mode (DM), Sparse Mode (SM), and
Source-Specific Mode (SSM)

• LLDP-MED (Media Endpoint Discovery)

Defines a standard extension of LLDP
that stores values for parameters such as
QoS and VLAN to automatically configure
network devices such as IP phones

Data sheet

Page 5

Monitor and diagnostics

• Port mirroring

Enables traic on a port to be
simultaneously sent to a network analyzer
for monitoring

• OAM (IEEE 8023ah)

Operations, administration, and maintenance
(OAM) management capability detects data
link layer problems that occurred in the
“last mile”; monitors the status of the link
between the two devices

• CFD (IEEE 8021ag)

Connectivity fault detection (CFD) provides
a Layer 2 link OAM mechanism used for link
connectivity detection and fault locating

Additional information

• HPE Intelligent Resilient Framework (IRF)

– Creates virtual resilient switching fabrics,

where two or more switches perform as a
single Layer 2 switch and Layer 3 router

– Does not require switches to be co-located

and allows them to be part of a
disaster-recovery system

– Allows servers or switches to be attached

using standard LACP for automatic load
balancing and high availability

– Simplifies network operation by helping

eliminate the complexity of Spanning Tree
Protocol, ECMP, or VRRP

• OAA modules

Support wireless network management and
high-performance security applications;
leverage network infrastructure investment

• Green IT and power

Improves energy eiciency through
the use of the latest advances in silicon
development; shuts o unused ports and
utilizes variable-speed fans, reducing
energy costs

• High scalability with IRF

HPE Intelligent Resilient Framework (IRF)
technology simplifies the architecture
of server access networks; up to nine
5800 switches can be combined to deliver
unmatched scalability of virtualized access
layer switches and flatter, two-tier FlexFabric
networks using IRF, which reduces cost
and complexity

Warranty and support

• 1-year warranty

See hpe.com/networking/
warrantysummary for warranty and
support information included with your
product purchase

• Software releases

To find software for your product, refer to
hpe.com/networking/support; for details
on the software releases available with
your product purchase, refer to hpe.com/

networking/warrantysummary

Data sheet

HPE 5800 TAA-compliant Switch Series

Specifications

Page 6

HPE 5800 -24G- PoE+ TAA-co mpliant Switch
(JG254B)

I/O ports and s lots 24 RJ-45 autosensing 10/100/1000 ports

Power supplies Included Included 2 power supply slots

Physical characteristics

Dimensions

Weight

Memory and processor 2048 MB SDRAM , 512 MB flash;

Performance

Latency

Throughput

Routing/Switching capacity

Routing table size

MAC address tab le size

(IEEE 8023 Type 10BASE-T, IEEE 8023u
Type 100BASE-TX, IEEE 8023ab Type
1000BASE-T); Duplex: 10B ASE-T/100BASE-TX:
half or full; 1000BASE-T: full only

1 extende d module slot

4 fixed 1000/10000 SFP+ ports

1 RJ-45 ser ial console p ort

173(w) x 168(d) x 171(h) in.
(4394 x 4267 x 434 cm) (1U height)

1764 lb (8 kg)

packet buer size: 4 MB

402 µs (Store and For ward) (64-byte packets)

155 million pps

208 Gbp s

16000 entries (IPv4)

32000 entries

HPE 5800 -24G TAA-com pliant Switc h
(JG255B)

24 RJ-45 autosensing 10/100/1000 ports
(IEEE 8023 Type 10BASE-T, IEEE 8023u
Type 100BASE-TX, IEEE 023ab Type
1000BASE-T); Duplex: 10B ASE-T/100BASE-TX:
half or full; 1000BASE-T: full only

1 extende d module slot

4 fixed 1000/10000 SFP+ ports

1 RJ-45 ser ial console port

1732(w) x 1435(d) x 172(h) in.
(4399 x 3645 x 437 cm) (1U height)

1323 lb (6 kg)

2048 MB SDRAM , 512 MB flash;
packet buer size: 4 MB

402 µs (Store and For ward) (64-byte packets)

155 million pps

208 Gbp s

16000 entries (IPv4)

32000 entries

HPE 5800 -24G- SFP TAA-compliant Switch
with 1 Interface Slot (JG256B)

24 SFP fixed Gigabit Ethernet SFP ports

1 extende d module slot

4 fixed 1000/10000 SFP+ ports

1 RJ-45 ser ial console p ort

1 minimum power supply required
(ordered separately)

1732(w) x 1681(d) x 172(h) in.
(4399 x 427 x 437 cm) (1U height)

1874 lb (85 kg)

2048 MB SDRAM , 512 MB flash;
packet buer size: 4 MB

402 µs (Store and For ward) (64-byte packets)

155 million pps

208 Gbp s

16000 entries (IPv4)

32000 entries

Environment

Operating temperature

Operating relative humidity

Acoustic

Electrical characteristics

Frequency

Maximum heat dissipation

AC voltage

Safety UL 60950-1; EN 60825-1 Safety of Laser

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 475 dB,
High-speed fan: 524 dB

50/60 Hz

2968 BTU/hr (313124 kJ/hr)

100 –120/200 –240 VAC

Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950-1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 423 dB,
High-speed fan: 529 dB

50/60 Hz

358 BTU/hr (37769 kJ/hr)

100 –120/1 20–240 VAC

UL 60950-1; EN 60825-1 Safety of Laser
Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950 -1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 496 dB,
High-speed fan: 581 dB

50/60 Hz

498 BTU/hr (52539 kJ/hr)

100 –120/200 –240 VAC

UL 60950-1; EN 60825-1 Safety of Laser
Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950 -1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

Data sheet

Specifications (continued)

Page 7

HPE 5800 -24G- PoE+ TAA-co mpliant Switch
(JG254B)

Emissions VCCI Class A; EN 55022 Class A;

Immunity

Generic

EN

ESD

Radiated

EFT/Burst

Surge

Conducted

Power frequency magnetic field

Voltage dips and interruptions

Harmonics

Flicker

Management IMC—Intelligent Management Center;

Notes N/A N/A Customer must order a power supply, as the

ICES-0 03 Class A; ANSI C6342003; AS/
NZS CISPR 22 Class A ; EN 61000-3-22006;
EN 61000-3-31995 + A12001 + A22005;
EMC Directive 2004/108/EC; FCC (CFR 47,
Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

HPE 5800 -24G TAA-com pliant Switc h
(JG255B)

VCCI Class A; EN 55022 Class A;
ICES-0 03 Class A; ANSI C6342003; AS/
NZS CISPR 22 Class A ; EN 61000-3-22006;
EN 61000-3-31995 + A12001 + A22005;
EMC Directive 2004/108/EC; FCC (CFR 47,
Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

IMC—Intelligent Management Center;
command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

HPE 5800 -24G- SFP TAA-compliant Switch
with 1 Interface Slot (JG256B)

VCCI Class A; EN 55022 Class A;
ICES-0 03 Class A; ANSI C6342003; AS/
NZS CISPR 22 Class A ; EN 61000-3-22006;
EN 61000-3-31995 + A12001 + A22005;
EMC Directive 2004/108/EC; FCC (CFR 47,
Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

IMC—Intelligent Management Center;
command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

device doe s not come with a P SU. At least
one JD362A/JD362B or JD366A/JD366B
is required.

Services

Refer to the Hew lett Packard Enterprise
website at hpe.com/networking/services for
details on th e service -level des criptions and
product numbers. For details about services,
and response times in your area, please
contact your local Hewlett Packard Ente rprise
sales oice.

Refer to the Hew lett Packard Enterprise
website at hpe.com/networking/services for
details on th e service -level des criptions and
product numbers. For details about services,
and response times in your area, please
contact your local Hewlett Packard Ente rprise
sales oice.

Refer to the Hew lett Packard Enterprise
website at hpe.com/networking/services for
details on th e service -level des criptions and
product numbers. For details about services,
and response times in your area, please
contact your local Hewlett Packard Ente rprise
sales oice.

Data sheet

HPE 5800 TAA-compliant Switch Series

Specifications

Page 8

HPE 5800 -48G-PoE+ TAA-comp liant Switch
with 1 Interface Slot (JG257B)

I/O ports and s lots 48 RJ-45 au tosensing 10/100/1000 ports

Power supplies Included Included 2 power supply slots

Physical characteristics

Dimensions

Weight

Memory and processor 2048 MB SDRAM , 512 MB flash; packet

(IEEE 8023 Type 10BASE-T, IEEE 8023u
Type 100BASE-TX, IEEE 8023ab Type
1000BASE-T); Duplex: 10B ASE-T/100BASE-TX:
half or full; 1000BASE-T: full only

1 extende d module slot

4 fixed 1000/10000 SFP+ ports

1 RJ-45 ser ial console p ort

1732(w) x 1681(d) x 172(h) in.
(4399 x 427 x 437 cm) (1U height)

1874 lb (85 kg)

buer size: 8 MB

HPE 5800 -48G TAA-compliant Switch
with 1 Interface Slot (JG258B)

48 RJ-45 au tosensing 10/100/1000 ports
(IEEE 8023 Type 10BASE-T, IEEE 8023u
Type 100BASE-TX, IEEE 8023ab Type
1000BASE-T); Duplex: 10B ASE-T/100BASE-TX:
half or full; 1000BASE-T: full only

1 extende d module slot

4 fixed 1000/10000 SFP+ ports

1 RJ-45 ser ial console port

1732(w) x 1445(d) x 172(h) in.
(4399 x 367 x 437 cm) (1U height)

1433 lb (65 kg)

2048 MB SDRAM , 512 MB flash; packet
buer size: 8 MB

HPE 5800 -48G-PoE+ TAA-comp liant Switch
with 2 Interface Slots (J G242B)

48 RJ-45 au tosensing 10/100/1000 ports
(IEEE 8023 Type 10BASE-T, IEEE 8023u
Type 100BASE-TX, IEEE 8023ab Type
1000BASE-T); Duplex: 10B ASE-T/100BASE-TX:
half or full; 1000BASE-T: full only

2 extende d module slots

1 open module slot

4 SFP fixed Gig abit Ethernet SFP port s

1 RJ-45 ser ial console port

1 minimum power supply required
(ordered separately)

1732(w) x 1831(d) x 339(h) in.
(440 x 465 x 861 cm) (2U height)

397 lb (180 kg)

2048 MB SDRAM , 512 MB flash; packet
buer size: 8 MB

Performance

Latency

Throughput

Routing/Switching capacity

Routing table size

MAC address tab le size

Environment

Operating temperature

Operating relative humidity

Acoustic

402 µs (Store and For ward)
(64-byte packets)

190 million pps

256 Gbps

16000 entries (IPv4)

32000 entries

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 505 dB,
High-speed fan: 579 dB

402 µs (Store and For ward)
(64-byte packets)

190 million pps

256 Gbps

16000 entries (IPv4)

32000 entries

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 453 dB,
High-speed fan: 565 dB

402 µs (Store and For ward)
(64-byte packets)

211 million pps

284 Gbps

16000 entries (IPv4)

32000 entries

32°F to 113°F (0°C to 45°C)

10% to 90%

Low-speed fan: 54 dB,
High-speed fan: 585 dB

Data sheet

Specifications (continued)

Page 9

HPE 5800 -48G-PoE+ TAA-comp liant Switch
with 1 Interface Slot (JG257B)

Electrical characteristics

Frequency

Maximum heat dissipation

AC voltage

Safety UL 60950-1; EN 60825-1 Safety of Laser

Emissions VCCI Class A; EN 55022 Class A; ICES-003 Class A;

Immunity

Generic

EN

ESD

Radiated

EFT/Burst

Surge

Conducted

Power frequency magnetic field

Voltage dips and interruptions

Harmonics

Flicker

50/60 Hz

3320 BTU/hr (35026 kJ/hr)

100 –120/200 –240 VAC

Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950-1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

ANSI C6342003; AS/NZS CISPR 22 Class A;
EN 61000-3-22006; EN 61000-3-31995 +
A12001 + A22005; EMC Directive 2004/108/EC;
FCC (CFR 47, Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

HPE 5800 -48G TAA-compliant Switch
with 1 Interface Slot (JG258B)

50/60 Hz

557 BTU/hr (58764 kJ/hr)

100 –120/200 –240 VAC

UL 60950-1; EN 60825-1 Safety of Laser
Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950-1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

VCCI Class A; EN 55022 Class A; ICES-003 Class A;
ANSI C6342003; AS/NZS CISPR 22 Class A;
EN 61000-3-22006; EN 61000-3-31995 +
A12001 + A22005; EMC Directive 2004/108/EC;
FCC (CFR 47, Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

HPE 5800 -48G-PoE+ TAA-comp liant Switch
with 2 Interface Slots (J G242B)

50/60 Hz

6278 BTU/hr (662329 kJ/hr)

100 –120/200 –240 VAC

UL 60950-1; EN 60825-1 Safety of Laser
Products-Part 1; EN 60825-2 Safet y of
Laser Produ cts-Par t 2; IEC 60950-1; CAN/
CSA-C222 No. 60950-1; Anatel; ULAR; GOST;
EN 60950-1/A11; FDA 21 CFR Subchapter J;
NOM; ROHS Compliance

VCCI Class A; EN 55022 Class A; ICES-003 Class A;
ANSI C6342003; AS/NZS CISPR 22 Class A;
EN 61000-3-22006; EN 61000-3-31995 +
A12001 + A22005; EMC Directive 2004/108/EC;
FCC (CFR 47, Part 15) Class A

ETSI EN 300386 V133

EN 550241998 + A12001 + A22003

EN 61000-4-2; IEC 61000-4-2

EN 61000-4-3; IEC 61000-4-3

EN 61000-4-4; IEC 61000-4-4

EN 61000-4-5; IEC 61000-4-5

EN 61000-4-6; IEC 61000-4-6

IEC 61000-4-8; EN 61000-4-8

EN 61000-4-11; IEC 61000 -4-11

EN 61000-3-2; IEC 61000-3-2

EN 6100 0-3-3 ; IEC 610 00 -3-3

Management IMC—Intelligent Management Center;

Notes N/A N/A Customer must order a p ower supply, as the

Services

command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

Refer to the Hew lett Packard Enterprise website
at hpe.com/networking/services for details
on the ser vice-level descriptions and product
numbers . For details about services, and response
times in your area, please contact your local
Hewlett Packard Enterprise sales oice.

IMC—Intelligent Management Center;
command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

Refer to the Hew lett Packard Enterprise website
at hpe.com/networking/services for details
on the ser vice-level descriptions and product
numbers . For details about services, and response
times in your area, please contact your local
Hewlett Packard Enterprise sales oice.

IMC—Intelligent Management Center;
command- line interf ace; Web browse r;
SNMP Manage r; Telnet; HTTPS; RM ON1; FTP

device doe s not come with a P SU. At least one
JC087A/JC090A/JC089A is required.

For the switch to provide Power over Ethernet, at
least one Po E power supply (JC089A) is needed,
along with the PoE TAA-compliant module
(JG26 0A).

Refer to the Hew lett Packard Enterprise website
at hpe.com/networking/services for details
on the ser vice-level descriptions and product
numbers . For details about services, and response
times in your area, please contact your local
Hewlett Packard Enterprise sales oice.

Data sheet

Standards and Protocols

(applies to all products in series)

Page 10

General protocols IEEE 8021ag Service Layer OAM

IEEE 8021D MAC Bri dges

IEEE 8021p Priority

IEEE 8021Q VLANs

IEEE 8021s (MSTP)

IEEE 8021v VLAN classificati on by Protocol
and Port

IEEE 8021w Rapid Reconfiguration of
Spanning Tree

IEEE 8021X PAE

IEEE 8023ad Link Aggregation Control
Protocol (LACP)

IP multicast RFC 2934 Protocol Indep endent Multicast

MIB for IPv4

RFC 3376 IGMPv3 (host joins only)

IPv6 RFC 2080 RIPng for IPv6

RFC 2460 IPv6 Specification

RFC 2710 Multicast Liste ner Discover y (MLD)
for IPv6

RFC 2740 OSPFv3 for IPv6

RFC 2925 Remote Operations MIB (Ping only)
RFC 3019 MLDv1 MIB

RFC 3162 RADIUS and IPv6

MIBs IEEE 8021-PAE-MIB

IEEE 8023-L AG-MIB

RFC 1213 MIB II

RFC 1493 Bridge MIB

RFC 1657 BGP-4 MIB

RFC 1724 RIPv2 MIB

RFC 1850 OSPFv2 MIB

RFC 2011 SNMPv2 MIB for IP

RFC 2013 SNMPv2 MIB for UDP

RFC 2233 Interface MIB

RFC 2273 SNMP-Notification-MIB

RFC 2452 IPv6-TCP-MIB

IEEE 8023ae 10-Gigabit Ethernet

IEEE 8023x Flow Control

RFC 768 UDP

RFC 792 ICMP

RFC 793 TCP

RFC 826 ARP

RFC 854 TELNET

RFC 925 Multi-L AN Address Resolution

RFC 951 BOOTP

RFC 1058 RIPv1

RFC 1350 TFTP Protocol (revision 2)

RFC 3618 Multicast Source Discover y Protocol
(MSDP)

RFC 3973 Draft 2 PIM Dense Mode

RFC 3315 DHCPv6 (client and relay)

RFC 3315 DHCPv6 (client only)

RFC 3810 MLDv2 (host joins only)

RFC 4022 MIB for TCP

RFC 4251 SSHv6 Architecture

RFC 4252 SSHv6 Authenticati on

RFC 4253 SSHv6 Transport Layer

RFC 2454 IPv6-UDP-MIB

RFC 2465 IPv6 MIB

RFC 2466 ICMPv6 MIB

RFC 2571 SNMP Framework MIB

RFC 2572 SNMP-MPD MIB

RFC 2573 SNMP-Noti fication MIB

RFC 2618 RADIUS Client MIB

RFC 2620 RADIUS Accounting MIB

RFC 2665 Ethernet-Li ke-MIB

RFC 26748021p and IEEE 8021Q Bridge MIB

RFC 2688 MAU-MIB

RFC 2787 VRRP MIB

RFC 1519 CIDR

RFC 1542 BOOTP Extensi ons

RFC 2131 DHCP

RFC 2453 RIPv2

RFC 3046 DHCP Rel ay Agent Information Optio n

RFC 3576 Ext to RADIUS (CoA only)

RFC 3768 VRRP

RFC 4675 RADIUS VLAN & Pri ority
8021r—GARP Proprietary Attribute Registration
Protocol (GPRP)

RFC 4601 PIM Sparse Mode

RFC 4254 SSHv6 Connection

RFC 4293 MIB for IP

RFC 4419 Key Exchange for SSH

RFC 4443 ICMP v6

RFC 4541 IGMP & MLD Snooping Switch

RFC 4861 IPv6 Neigh bor Discover y

RFC 4862 IPv6 Stateless Address
Auto-configuration

RFC 2819 RMON MIB

RFC 2925 Ping MIB

RFC 3414 SNMP-User-based-SM MIB

RFC 3415 SNMP-View-based-ACM MIB

RFC 3418 MIB for SNMPv3

RFC 3621 Power Ethernet MIB

RFC 3826 AES for SNMP’s USM MIB

RFC 4133 Entity MIB (version 3)

LLDP-EXT-DOT1-MIB

LLDP-EXT-DOT3-MIB

LLDP-MIB

Network management IEEE 8021AB Link Layer Discove ry Protocol

(LLDP)

OSPF RFC 2328 OSPFv2 RFC 3101 OSPF NSSA

Security IEEE 8021X Port Based Network Access

Control

RFC 1492 TACACS+

RFC 2819 four groups of RMON: 1 (statistics),
2 (history), 3 (alarm), and 9 (events)

RFC 3176 sFlow

RFC 2865 RADIUS (client only)

RFC 2866 RADIUS Accounting

ANSI/TIA-1057 LLDP Media Endpoint
Discovery (LLDP-MED)

SNMPv1/v2c/v3

Secure Sockets Layer (SSL)

SSHv2 Secure Sh ell

Data sheet

HPE 5800 TAA-compliant Switch Series accessories

(applies to all products in series)

Transceivers HPE X1251G SFP LC LH401310nm Transceiver (JD061A)

HPE X1201G SFP LC LH401550nm Transceiver (JD062A)

HPE X1251G SFP LC LH70 Transceiver (JD063B)

HPE X13010G SFP+ LC SR Transceiver (JD092B)

HPE X13010G SFP+ LC LRM Transceiver (JD093B)

HPE X13010G SFP+ LC LR Transceiver (JD094B)

HPE X13010G SFP+ LC ER 40km Transceiver (JG234A)

HPE X110100M SFP LC FX Transceiver (JD102B)

HPE X1201G SFP LC SX Transce iver (JD118B)

HPE X1201G SFP LC LX Transceiver (JD119B)

HPE X110100M SFP LC LX Transceiver (JD120B)

HPE X24010G SFP+ to SFP+ 065m Direct Attach Copper Cable (JD095C)

HPE X24010G SFP+ to SFP+ 12m Direct Attach Copper Cab le (JD096C)

HPE X24010G SFP+ to SFP+ 3m Direct At tach Copper C able (JD097C)

HPE X24010G SFP+ to SFP+ 5m Direct At tach Copper Cable (JG081C)

HPE X1201G SFP RJ45 T Transceiver (JD089B)

Cables HPE Premier Flex LC/LC Multi-mode OM42 fiber 1m Cab le (QK732A)

HPE Premier Flex LC/LC Multi-mode OM42 fiber 2m Cable (QK733A)

HPE Premier Flex LC/LC Multi-mode OM42 fiber 5m Cab le (QK734A)

HPE Premier Flex LC/LC Multi-mode OM42 fiber 15m Cab le (QK735A)

HPE Premier Flex LC/LC Multi-mode OM42 fiber 30m Cable (QK736A)

HPE Premier Flex LC/LC Multi-mode OM42 fiber 50m C able (QK737A)

Page 11

Power supply HPE RPS 800 Redundant Power Supply (JD183A)

HPE RPS1600 Redun dant Power System (JG136A)

HPE RPS16001600W AC Power Supply (JG137A)

HPE 5800 -48G-PoE+ TAA-comp liant Switch with 2 Interface
Slots (JG242B)

HPE 5800 -24G- PoE+ TAA-co mpliant Switch (JG254B) HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 5800 -24G TAA-com pliant Switc h (JG255B) HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE 5800300W AC Powe r Supply (JC087A)

HPE 5800750W AC Power Supply (JC089A)

HPE 5800300W D C Power Supply (JC090A)

HPE 5800 PoE TAA-compliant Modul e (JG260A)

HPE 58002RU Spare Fan Assembly (JC096A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE 58001RU Spare Fan Assembly (JC098A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE 58001RU Spare Fan Assembly (JC098A)

Data sheet

(applies to all products in series)

HPE 5800 -24G- SFP TAA-compliant Switch with 1 I nterface Sl ot
(JG256B)

HPE 5800 -48G-PoE+ TAA-comp liant Switch with 1 Interface
Slot (JG257B)

HPE 5800 -48G TAA-compliant Switch with 1 Inte rface Slot
(JG258B)

(continued)

Learn more at

hpe.com/networking

HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE X361150W AC Power Supply (JD362B)

HPE X361150W DC Power Supp ly (JD366B)

HPE 58001RU Spare Fan Assembly (JC098A)

HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE 58001RU Spare Fan Assembly (JC098A)

HPE 58004-p ort 10GbE SFP+ Mo dule (JC091A)

HPE 58002-por t 10GbE SFP+ Modul e (JC092B)

HPE 580016-port Gig-T Module (JC094A)

HPE 580016-port SFP Module (JC095A)

HPE 58001RU Spare Fan Assembly (JC098A)

Sign up for updates

© Copyright 2011–2012, 2014–2016 Hewlett Packard Enterprise Development LP. The information contained herein is subject to
change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty
statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

sFlow is a registered trademark of InMon Corp.

4AA3-3791ENW, October 2016, Rev. 8
