QuickSpecs
HPE ProLiant ML30 Gen10 Server
Overview
1
HPE ProLiant ML30 Gen10 Server
The HPE ProLiant ML30 Gen10 Server is a powerful yet affordable tower server designed for small offices, remote and branch offices
to run on
ity at a
lower cost.
4 LFF Model
8 SFF Model
Front View (details for 4LFF and 8SFF)
1.
Four (4) LFF or Eight (8) SAS/SATA HDD cage
5.
USB 2.0 port
2.
Media drive bay 2 (blank shown)
6.
Power On/Standby button and system power LED
3.
Media drive bay 1 (optional slim-line DVD shown)
7.
Health LED
4.
USB 3.0 port
-premises and hybrid cloud solutions, delivering enterprise-class performance, security, reliability, and expandabil
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Overview
2
Rear View
1.
PCI slots (slots 1-4)
7.
Power supply power connector
2.
Dedicated iLO management port (optional)
8.
Power cord clip
3.
Four (4) USB 3.0 ports
9.
Padlock eye
4.
VGA port
10.
Kensington security slot
5.
Serial port (optional)
11.
NIC1/shared iLO port (upper), NIC2 port (lower)
6.
Power supply bay (one optional redundant power supply
with enablement kit and blank shown)
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Overview
3
Internal View
1.
System fan
7.
One (1) internal USB 3.0 port
2.
Power supply
8.
Six (6) SATA ports
3.
One (1) processor and heatsink/fan
9.
One (1) M.2 slot (optional module shown)
4.
Four (4) DDR4 DIMM slots
10.
TPM connector
5.
Bezel lock
11.
Four (4) PCIe expansion slots
6.
Front PCI fan (optional or included, depending on models)
What’s New
•
•
•
•
•
•
•
for you
http://www.hpe.com/servers/clearos
Supports Intel® Xeon® E processors up to 6 cores and up to 80W, 8th Core™ i3 and Pentium® G processors.
2666 MT/s HPE DDR4 Standard Memory UDIMM offering 8GB, 16GB. Max 64GB memory capacity.
Four expansion slots for more flexible usage - two x16 and two x8 connectors.
Onboard M.2 NVMe SSD support.
Dedicated iLO port & serial port option kit.
SMB Offering to match different workloads.
ClearOS, an easy to use OS with an application marketplace, allows you to build a fully functional server that is just right
at no upfront cost. To learn more on what you can do, please visit
.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Overview
4
Platform Information
Form Factor
NOTE: Sliding Shelf - 874578-B21 is optional to support rack form factor.
Chassis Types
2 LFF NHP HDD
cage kits
System Fans
B21) which is included in SMB Performance
2. Must be selected in 4LFF NHP CTO Server and SMB Entry Model if M.2 SSD or any PCIe card (NIC, Smart Array Controller,
graphic card, etc.) is selected except 1Gb network adapters.
4U Tower
8 SFF chassis and 2 half-height (5.25”) media drive bays with optional 1 slim-line DVD bay kit option
4 LFF chassis and 2 half-height (5.25”) media drive bays with optional 1 slim-line DVD bay kit option
4 LFF NHP chassis and 2 half-height (5.25”) media drive bays with optional 1 slim-line DVD bay kit option or up to
1 Default system fan module (92 x 32 mm)
1 Default PCI fan module (92 x 32 mm) depending on models
NOTE: PCI fan module is part of HPE ML30 Gen10 PCI Fan and Baffle Kit (P06303and Solution Models.
NOTE: HPE ML30 Gen10 PCI Fan and Baffle Kit (P06303-B21) is required as follows:
1. Must be selected in 4LFF Hot Plug CTO Server and 8SFF Hot Plug CTO Server.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
5
Processor
effectiveness.
NOTE:
http://www.intel.com/xeon.
SGX
Xeon E-2176G
3.7 GHz
6
12 MB
80W
2666 MT/s
Yes
Xeon E-2174G
3.8 GHz
4
8 MB
71W
2666 MT/s
Yes
Xeon E-2144G
3.6 GHz
4
8 MB
71W
2666 MT/s
No
Xeon E-2136
3.3 GHz
6
12 MB
80W
2666 MT/s
No
Xeon E-2134
3.5 GHz
4
8 MB
71W
2666 MT/s
No
Xeon E-2126G
3.3 GHz
6
12 MB
80W
2666 MT/s
No
Xeon E-2124
3.3 GHz
4
8 MB
71W
2666 MT/s
No
Core i3-8300
3.7 GHz
4
8 MB
62W
2400 MT/s
No
Pentium G5400
3.7 GHz
2
4 MB
58W
2400 MT/s
No
Chipset
On System Management Chipset
NOTE: Read and learn more in the HPE iLO QuickSpecs.
Memory
Type:
HPE DDR4 Standard Memory, Unbuffered (UDIMM)
DIMM Slots Available
4
4 DIMMs (2 Channels/ 2 DIMMs per channel)
Maximum Capacity (UDIMM)
64GB
(4 x 16GB UDIMM @2666 MT/s)
NOTE: The maximum memory speed depends on processor model.
Memory Protection
Network Controller
Intel® Xeon® E Processor is designed to deliver the best combination of performance, built-in capabilities, and costThis product also supports Intel® Pentium® and Intel® Core™ i3 processors.
Choose one of the following processors based on the model:
For more information regarding Intel Xeon processors, please see the following
Model CPU Frequency Cores L3 Cache Power DDR4
Intel® C246 Chipset
NOTE: For more information regarding Intel® chipsets, please see the following
URL: http://www.intel.com/products/server/chipsets/
HPE iLO 5 ASIC
ECC
Embedded 2-Port 1GbE HPE Ethernet 332i Adapter, optional 1/10Gb standup card
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
6
Expansion Slots
Expansion Slots #
Technology
Bus Width
Connector Width
Form Factor
Notes
1
PCIe 3.0
x16
x16
Full height, full length
Processor
2
PCIe 3.0
X4
X8
Full height, half length
PCH
3
PCIe 3.0
X4
X16
Full height, full length
PCH
4
PCIe 3.0
X4
X8
Full height, half length
PCH
NOTE:
Storage Controller
The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed
HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an additional controller
SR Gen10 SW RAID is off by default and must be enabled. For enabling please
source software to
NOTE: Performance RAID Controllers require the HPE Smart Storage Battery (P01366-B21) which is sold separately.
Internal Storage Devices
Optical Drives
None ship standard
Optional: SATA 9.5mm DVD-RW/DVD-ROM Optical Drive
Hard Drives
None ship standard
Bus Width indicates the number of physical electrical lanes running to the connector.
breakout of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.
Software RAID
HPE Smart Array Gen10 SW RAID
NOTE:
will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22.
NOTE: For CTO orders, HPE Smart Array S100i
select HPE FIO Enable Smart Array SW RAID (784308-B21).
NOTE: For BTO orders, HPE Smart Array S100i SR Gen10 SW RAID is on by default.
NOTE: The S100i supports 4 SATA ports for drive cage and additional 2 SATA ports for drives from media drive bays.
NOTE: The S100i only supports Windows. For Linux users, HPE offers a solution that uses in-distro open-
create a two-disk RAID 1 boot volume. For more information visit:
https://downloads.linux.hpe.com/SDR/project/lsrrb/
Essential RAID Controller
HPE Smart Array E208i-p SR Gen10 Controller
HPE Smart Array E208e-p SR Gen10 Controller
Performance RAID Controller
HPE Smart Array P408i-p SR Gen10 Controller
HPE Smart Array P408e-p SR Gen10 Controller
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
7
Maximum Internal Storage
Capacity
Configuration
Hot Plug LFF SAS
48 TB
4 x 12 TB
Hot Plug LFF SATA
48 TB
4 x 12 TB
Hot Plug SFF SAS
19.2 TB
8 x 2.4 TB
Hot Plug SFF SATA
16 TB
8 x 2 TB
Non Hot Plug LFF SATA
24 TB
4 x 4 TB + 2 x 4 TB (with additional optional LFF drive enablement kits)
Hot Plug LFF SATA SSD
7.68 TB
4 x 1.92 TB
Hot Plug SFF SAS SSD
3.2 TB
8 x 400 GB
Hot Plug SFF SATA SSD
61.44 TB
8 x 7.68 TB
M.2 NVMe SSD
480 GB
1 x 480 GB
NOTE: M.2 SSD is applicable to all models.
Power Supply
cost options for customers trying to balance their need for enterprise class efficiency
Level power supply options have been designed
redundant AC power supply option for most HPE ProLiant Gen10 Essential
series tower
ess
efficiency operation and
is flexibility
a
For information on power specifications and technical content visit HPE Server power supplies.
Interfaces
VGA Port
1 standard (rear)
Serial Port
1 optional (rear)
Network Port (RJ-45)
2 x 1 Gb ports as standard (rear, 1 shared for HPE iLO)
Dedicated iLO Management Port (RJ-45)
1 optional (rear)
USB 3.0 Port
6 (1 front, 4 rear, 1 internal)
USB 2.0 Port
1 (1 front)
HPE 350W E-star 1.0 Power Supply FIO Kit
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Redundant Power Supply
NOTE: Available in 94% efficiency.
HPE Entry-Level Power Supplies provide lowerand reliability while maintaining lowest possible hardware costs. All Entryspecifically for HPE ProLiant Gen10 Essential Series servers.
The HPE 350W FIO Power Supply is the standard, nonservers. It features Bronze-level (85%) certified power efficiency with a set of features optimized for the Gen10 Essentialservers.
HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-l
installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for highoffer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. Th
helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.
All pre-configured servers ship standard with one or more country-specific 6 ft/1.83m C-13 power cords depending on regions. If
different power cord is required, please check the HPE Power Cords and Cables web page.
To review the power requirements for your selected system, please use the HPE Power Advisor Tool.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
8
Operating Systems and Virtualization Software Support for ProLiant Servers
premise solutions without sacrificing security and ease of use. HPE
based graphical user
premise, and an Application Marketplace with over 100 apps and growing.
testing and enablement applicable to
For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization
https://www.hpe.com/us/en/servers/server-operating-systems.html.
Industry Standard Compliance
NOTE:
Graphics
Microsoft Windows Server 2016
Red Hat Enterprise Linux (RHEL) 7.5
SUSE Linux Enterprise Server (SLES) 12 SP3 and 15
VMware ESXi 6.5 U2 and 6.7
NOTE: VMware supported only with Intel® Xeon® E processors, not supported with Intel® Core™ or Pentium® processors.
ClearOS
HPE and ClearCenter will help you lower the cost of building onProLiant servers with ClearOS give you a simple, secure, and affordable operating system with an intuitive webinterface that provides a cloud-like experience onWhether you’re starting out or scaling, you decide what applications you need and pay as you grow.
NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information on
ClearOS, please visit http://www.hpe.com/servers/clearos.
CentOS
NOTE: CentOS not directly supported / Community Supported (Based on RHEL so RHEL
CentOS) CentOS 7.5.
NOTE:
Software and latest listing of software drivers available for your server.
ACPI 6.1 Compliant
PCIe 3.0 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
VGA Port
USB 3.0 Compliant
USB 2.0 Compliant
SMBIOS 3.1
UEFI 2.6
ASHRAE A3/A4
NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please visit:
http://www.hpe.com/servers/ashrae.
UEFI (Unified Extensible Firmware Interface Forum)
UEFI is the default for the ML30 Gen10. Legacy mode can be selected in the field or as a CTO option (758959-B22)
Integrated Vdeo Standard
• Video modes up to 1920 x 1200 @60Hz (32 bpp)
• 16MB Video Memory
HPE iLO 5 On System Management Memory
• 32 MB Flash
• 4 Gbit DDR 3 with ECC protection
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
9
HPE Server UEFI/Legacy ROM
Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured
ss
Based Setup Utility (RBSU) of legacy BIOS. For more
B22) can be selected to configure the system in Legacy mode in the factory for your HPE
ProLiant Gen10 Server.
Embedded Management
service alerting, reporting and remote management with HPE iLO. Learn more
http://www.hpe.com/info/ilo
UEFI
Interface (UEFI). Learn more
Intelligent Provisioning
http://www.hpe.com/servers/intelligentprovisioning.
iLO RESTful API
automation such as configuration and
http://www.hpe.com/info/restfulapi
configuration than the legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI Cla
2 implementation and support both UEFI Mode (default) and Legacy BIOS Mode.
NOTE: The UEFI System Utilities function is analogous to the HPE ROMinformation, please visit http://www.hpe.com/servers/uefi.
UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:
• Secure Boot and Secure Start enable for enhanced security
• Operating system specific functionality
• Support for > 2.2 TB (using GPT) boot drives
• USB 3.0 Stack
• Embedded UEFI Shell
• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant
• PXE boot support for IPv6 networks
• Workload Profiles for simple performance optimization
UEFI Boot Mode only:
• TPM 2.0 Support
• iSCSI Software Initiator Support.
• HTTP/HTTPs Boot support as a PXE alternative.
• Boot support for option cards that only support a UEFI option ROM
NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI.
NOTE: Legacy FIO Setting (758959-
HPE Integrated Lights-Out (HPE iLO)
Monitor your servers for ongoing management,
at
.
Configure and boot your servers securely with industry standard Unified Extensible Firmware
at http://www.hpe.com/servers/uefi.
Hassle free server and OS provisioning for 1 or few servers with Intelligent Provisioning. Learn more at
iLO RESTful API is Redfish API conformance and offers simplified server management
maintenance tasks based on modern industry standards. Learn more at
.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
10
Server Utilities
Active Health System
mponent of the iLO management portfolio that provides continuous,
http://www.hpe.com/servers/ahs
Active Health System Viewer
Smart Update
Keep your servers up to date with the HPE Smart Update solution by using Smart Update Manager (SUM) to optimize the firmware
and driver updates of the Service Pack for ProLiant (SPP). Learn more at http://www.hpe.com/info/smartupdate.
iLO Amplifier Pack
e,
ower to discover, inventory and update Gen8, Gen9 and Gen10 HPE
servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more
at http://www.hpe.com/servers/iLOamplifierpack.
HPE iLO Mobile Application
s.
For additional information please visit: http://www.hpe.com/info/ilo/mobileapp.
RESTful Interface Tool
to discover and deploy servers at scale. Learn more
at http://www.hpe.com/info/resttool.
Scripting Tools
Provision one to many servers using your own scripts to discover and deploy with Scripting Tool (STK) for Windows and Linux or
http://www.hpe.com/servers/stk
http://www.hpe.com/servers/powershell
HPE OneView Standard
nitor
defined
functionality is not available. Learn more at http://www.hpe.com/info/oneview.
HPE Systems Insight Manager (HPE SIM)
asic
http://www.hpe.com/servers/hpsim
The HPE Active Health System (AHS) is an essential co
proactive health monitoring of HPE servers. Learn more at
Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed problem resolution with HPE selfrepair recommendations, to learn more visit: http://www.hpe.com/servers/ahsv
.
Designed for large enterprise and service provider environments with hundreds of HPE servers, the iLO Amplifier Pack is a fre
downloadable open virtual application (OVA) that delivers the p
.
Enables the ability to access, deploy, and manage your server anytime from anywhere from select smartphones and mobile device
RESTful Interface tool is a scripting tool to provision using RESTful API for iLO 4
Scripting Tools for Windows PowerShell. Learn more at
or
.
HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting without additional fees. It can mo
multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-
NOTE: HPE OneView Standard support on ML30 Gen10 will begin in early 2019.
HPE SIM allows you to monitor the health of your HPE ProLiant Servers and HPE Integrity Servers, and also provides you with b
support for non-HPE servers.
HPE SIM also integrates with Smart Update Manager to provide quick and seamless firmware updates. Learn more at
.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Standard Features
11
Security
NOTE: Intel® SGX is supported in selective processors, please refer to the Standard Features – Processor section.
Warranty
Hewlett Packard
Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of
vices
ar or
Year Onsite support with next business day response. Warranty
repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1)
rts are designed for easy replacement. A travel and labor charge will result when customers decline to replace
a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity.
replace Optional CSR parts at no charge. 3) Non CSR parts must be
Additional information regarding worldwide limited warranty and technical
NOTE: Warranty does not cover support for ClearOS. Support for ClearOS is provided by ClearCenter.
UEFI Secure Boot and Secure Start support
Immutable Silicon Root of Trust
FIPS 140-2 validation
Common Criteria certification
Configurable for PCI DSS compliance
Ability to rollback firmware
Secure erase of NAND/User data
TPM (Trusted Platform Module) 1.2 option
TPM (Trusted Platform Module) 2.0 option
Front bezel key-lock feature, standard
Padlock slot, standard
Kensington Lock slot, standard
Intel® SGX (Software Guard Extensions)
This product is covered by a global limited warranty and supported by HPE Pointnext and a worldwide network of
Enterprise
purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty ser
are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one ye
three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE: Server Warranty includes 3-Year Parts, 1-Year Labor, 1-
Mandatory CSR pa
Customers may choose to have Hewlett Packard Enterprise
serviced by a trained authorized service engineer.
support is available at: http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Optional Features
12
Server Management
iLO Advanced
udes
lay,
based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management
http://www.hpe.com/servers/iloadvanced
HPE iLO Advanced Premium Security Edition
end security modes, unique
ed
http://www.hpe.com/servers/ilopremium
One Config Simple (SCE)
configurations in 3 to 5 minutes.
stom"
tt Packard Enterprise Customer Business
http://ocs.ext.hpe.com/
HPE iLO Advanced licenses offer smart remote functionality without compromise, for all HPE ProLiant servers. The license incl
the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and rep
and GUIfunctionality. Learn more about HPE iLO Advanced at
HPE iLO Advanced Premium Security Edition for iLO 5 includes iLO Advanced License plus highsecurity capabilities, like Automatic FW recovery; Runtime FW verification, and Secure erase. Learn more about HPE iLO Advanc
Premium Security Edition at:
.
SCE is a guided self-service tool to help sales and non-technical people provide customers with initial
You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "cu
rack configuration or configuration for products not available in SCE, please contact Hewle
Center or an Authorized Partner for assistance.
.
.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Service and Support
13
HPE Pointnext - Service and Support
Protect your business beyond warranty with HPE Pointnext Operational Service
Services
ervices
the transformation and creating a solution roadmap. Professional Servicesspecializes in creative configurations
budget execution. Finally, operationalservices provides innovative new approaches
Capacity and Datacenter Care, to keep your business at peakperformance. HPE is ready to bring together all the pieces
Connect your devices:
r technology investment by connecting your products to Hewlett Packard Enterprise. Achieve up to
diagnostic accuracy and a single consolidated view of your environment. Byconnecting, you
failure alerts, automatic call logging, and automatic parts dispatch. HPEProactive Care Service and
tion. All
-
Recommended Services
Basic: HPE Foundation Care NBD, three-year Support Service
HPE Foundation Care Next Business Day connects you to Hewlett Packard Enterprise during business hours for assistance on
This service features need based next business day hardware onsite response and software call back within two
ng on
. Simplify your support experience and make Hewlett Packard Enterprise your first call to help resolve hardware or
Standard: HPE Foundation Care 24x7, three-year Support Service
HPE Foundation Care 24x7 gives you access to Hewlett Packard Enterprise 24 hours a day, seven days a week for assistance on
issues. This service includes need based Hardware onsite response within four hours. In addition, collaborative software
server.
implify your support experience and make Hewlett Packard Enterprise your first call to help resolve hardware or software
Optimized: HPE Proactive Care* with 24x7 coverage, three year Support Service
helps
service
ing the onsite
coverage window to begin hardware maintenance service the next coverage day after the service requesthas been logged. This
ft, etc.)
HPE Pointnext provides a comprehensive portfolio including Advisory and Transformational, Professional, and Operational
to help accelerate your digital transformation. From the onset of your transformation journey, Advisory andTransformational S
focus on designing
with flawless and on-time implementation, and onlike Flexible
of the puzzle for you, with an eye on the future, and make thecomplex simple.
Unlock all of the benefits of you
77%1 reduction in down time, near 100%2
will receive 24x7monitoring, preHPE Datacenter Care Service customers will also benefit from proactive activities to help preventissues and increase optimiza
of these benefits are already available to you with your server storage and networkingproducts, securely connected to HPE support.1
IDC 2 - -- HP CSC reports 2014 - -- 2015Learn more about getting connected at http://www.hpe.com/services/getconnected.
resolving issues –
hours. In addition, Collaborative software support and provides troubleshooting assistance on industry leading software runni
your HPE server
software problems.https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en
resolving
support is included in this service that provides troubleshooting assistance on industry leading software running on your HPE
S
problems.https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en
HPE Proactive Care gives customers an enhanced call experience. When your products are connected to HPE, Proactive Care
prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice.This
combines three years of Hardware Support where an HPE authorized representative will arrive at the Customer'ssite dur
service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat,VMWare, Microso
running on your HPE servers
.https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf
*HPE Proactive Care and HPE Proactive Care Advanced require that the customer connect their devices to make the most of
these services and receive all the deliverables.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Service and Support
14
Parts and Materials
supported replacement parts and materials necessary to maintain the covered
ed their maximum supported lifetime and/or the maximum usage limitations as set forthin
r
Hewlett Packard
Other related Services
HPE Server Hardware Installation
installation of HPE branded servers, storage devices and networking options to assist you
HPE Installation and Startup Service
very
a LAN as appropriate and enable remote support to allow for automatic casecreation for
indows®
HPE Factory Express for Servers and storage
HPE Factory Express offers configuration, customization, integration and deployment services for HPE servers and
Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed. Factory
well as
actory services, such as image loading, asset tagging, and custom packaging. HPE products supported through Factory
Express include a wide array of servers and storage: HPE Integrity, HPE ProLiant, HPE Apollo, HPE ProLiant Server Blades, HPE
PE 9000 servers as well as the MSAxxxx3PAR suite, XP, rackable tape libraries and configurable network switches.
HPE Service Credits
ice that is
IT.
HPE Education Services
Hewlett Packard Enterprise will provide HPEhardware product inoperating condition, including parts and materials for available and recommended engineering improvements.
Parts and components that have reach
the manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided, repaired,o
replaced as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced by
Enterprise due tomalfunction.
Provides for the basic hardware
inbringing your new hardware into operation in a timely and professional manner
.https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf
Provides for the installation of your HPE hardware according to product specifications including options. The HPE servicedeli
technician will connect the product to
hardware failures. Installation and start up services also includes the installation of one supported operating systemtype (W
or Linux).
NOTE: HPE Startup services does not include support for ClearOS. ClearOS is supported by ClearCenter.
storageproducts.
Express offers service packages for simple configuration, racking, installation, complex configuration and design services as
individual f
BladeSystem, H
HPE Service Credits offers flexible services and technical skills to meet your changing IT demands. With a menu of serv
tailored to suit your needs, you get additional resources and specialist skills to help you maintain peak performance of your
Offered as annual credits, you can plan your budgets while proactively responding to your dynamic business.
Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes. Book on a class today and
learn how to get the most from your technology investment.http://www.hpe.com/ww/learn
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Service and Support
15
HPE Support Center
The HPE Support Center is a personalized online support portal with access to information, tools and experts to support
rt. Now, you
can get access to personalized IT support anywhere, anytime.HPE Insight Remote Support and HPE Support Center are available at
Mobile
support
that are compatible with your product will becovered under
needed.
HERE
HPEbusiness products. Submit support cases online, chat with HPE experts, access support resources or collaborate with peers.
Learn more http://www.hpe.com/support/hpesc.
HPE's Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live suppo
no additional cost with a HPE warranty, HPE SupportService or HPE contractual support agreement.*HPE Support Center
App is subject to local availability.For more information: http://www.hpe.com/services.
NOTE: HPE ProLiant ML30 Gen10 Server is covered under the HPE Service Contract applied to the HPE ProLiant Server.
No separate HPE support services need to be purchased.
Warranty and Support Services will extend to include HPE options configured with your server or storage device. The price of
service is not impacted by configuration details. HPE sourced options
your server support at the same level of coverage allowing you to upgrade freely. Installation for HPE options isavailable as
To keep support costs low for everyone, some high value options will require additional support. Additional
support is only required on select high value workload accelerators, fibre switches, InfiniBand and UPS batteries over 12KVA. See
the specific high value options that require additional support
.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
SMB
16
Entry Models
Performance Models
Solution Models
[SKU Number]
P06781-XXX
P06785-XXX
P06789-XXX
P06793-XXX
Model Name
HPE ProLiant ML30
U S100i
Entry Server
HPE ProLiant ML30
Perf Server
HPE ProLiant ML30
Perf Server
HPE ProLiant ML30
Solution Server
Processor
Intel® Xeon® E-2124
Intel® Xeon® E-2124
Intel® Xeon® E-2134
Intel® Xeon® E-2134
Number of
Processors
Memory
8 GB UDIMM DDR4
2666 MT/s (1 x 8 GB)
16 GB UDIMM DDR4
2666 MT/s (1 x 16 GB)
16 GB UDIMM DDR4
2666 MT/s (1 x 16 GB)
16 GB UDIMM DDR4
2666 MT/s (1 x 16 GB)
Network Controller
Embedded 2-Port 1GbE HPE Ethernet 332i Adapter
Storage Controller
Embedded S100i SW
(812248-B21).
Hard Drive
None ship as standard
Internal Storage
4 LFF HDD Bays
1x M.2 PCIe 3.0 x2 slot
4 LFF HDD Bays
1x M.2 PCIe 3.0 x2 slot
8 SFF HDD Bays
1x M.2 PCIe 3.0 x2 slot
Optical Drive Bay
Optional Slimline ODD Bay Kit (P06309-B21) for SATA DVD-ROM/DVD-RW optical drive up to 1,
Media drive bay for internal RDX or tape/LTO devices up to 1
Optical Drive
None ship as standard
PCI-Express Slots
4 PCIe 3.0 slots
Power Supply
(1) 350W ATX Power Supply
(1) 500W HPE Flex Slot Power Supply
to get 1+1 power redundancy feature.
Fans
1 non-hot plug, non-
redundant system fan
1 non-hot plug, non-redundant system fan
1 non-hot plug, non-redundant PCI fan
Management
HPE iLO Standard with Intelligent Provisioning (embedded), HPE OneView Standard (requires download),
NOTE: HPE OneView support on ML30 Gen10 begin in early 2019.
Form Factor
Tower (4U)
Warranty
3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response.
support with next business day response.
Models
Gen10 E-2124 3.3GHz
4-core 1P 8GB-
4LFF NHP 350W PS
(4-Core, 3.3 GHz, 71W)
RAID with 4 SATA ports
NOTE: Field
upgradeable to 6 ports
by selecting drive
enablement kits
(Non Hot Plug)
Gen10 E-2124 3.3GHz
4-core 1P 16GB-U
S100i 4LFF 350W PS
(4-Core, 3.3 GHz, 71W)
Gen10 E-2134 3.5GHz
4-core 1P 16GB-U
S100i 4LFF 500W RPS
(4-Core, 3.5 GHz, 71W)
One
Embedded S100i SW RAID with 4 SATA ports
NOTE: Field upgradeable to SAS by selecting HPE
Smart Array controller.
(Hot Plug)
Gen10 E-2134 3.5GHz
4-core 1P 16GB-U
S100i 8SFF 500W RPS
(4-Core, 3.3 GHz, 71W)
Embedded S100i SW
RAID with 4 SATA ports
NOTE: Field
upgradeable to SAS/8
ports by selecting HPE
Smart Array controller.
(Hot Plug)
NOTE: Add a second 500W Flex Slot Power Supply
HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced
(require licenses)
NOTE: AP, Japan, India, and PRC Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Service and Support
17
Country Code Key
XXX = S01
US
XXX = 425
EU/UK
XXX = 375
AP
XXX = 291
Japan
XXX = 371
India
XXX = AA1
PRC
NOTE: Not all models are available in all regions. Check with your local country Hewlett Packard Enterprise offices for availability.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Configuration Information
18
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative
ks based on the number of initial hard drives ordered
4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.
Step 1: Base Configuration (choose one of the following configurable models)
CTO Server
HPE ProLiant ML30 Gen10
4 LFF Non Hot Plug CTO Server
HPE ProLiant ML30 Gen10
4 LFF Hot Plug CTO Server
HPE ProLiant ML30 Gen10
8 SFF Hot Plug CTO Server
SKU Number
P06760-B21
P06761-B21
P06762-B21
Processor Socket
1 1 1
Processor
Not included as standard
Not included as standard
Not included as standard
DIMM Slots
4 DIMM slots for UDIMM DDR4 Memory
Storage Controller
Embedded S100i SW RAID with 4
SATA ports
Embedded S100i SW RAID with 4 SATA ports, choice of HPE Smart
Array controller
PCIe
4 PCIe 3.0 slots
Drive Cage
4 LFF Non Hot Plug
4 LFF Hot Plug
8 SFF Hot Plug
M.2 Slot
1 M.2 PCIe 3.0 x2 slot
1 M.2 PCIe 3.0 x2 slot
1 M.2 PCIe 3.0 x2 slot
Network Controller
Embedded 2-Port 1GbE HPE Ethernet 332i Adapter, optional 1/10Gb standup card
Fans
1 non hot plug, non-redundant system fan
Management
HPE iLO Standard with Intelligent Provisioning (embedded),
(require licenses)
USB
2 front, 4 rear, 1 internal
Step 2a: Choose Required Options - Processors
(only one of the following from each list unless otherwise noted)
Intel® Xeon® E Processor
HPE ML30 Gen10 Intel Xeon E-2124 (3.3GHz/4-core/8MB/71W) FIO Processor Kit
P06535-L21
HPE ML30 Gen10 Intel Xeon E-2134 (3.5GHz/4-core/8MB/71W) FIO Processor Kit
P06537-L21
HPE ML30 Gen10 Intel Xeon E-2136 (3.3GHz/6-core/12MB/80W) FIO Processor Kit
P06547-L21
HPE ML30 Gen10 Intel Xeon E-2144G (3.6GHz/4-core/8MB/71W) FIO Processor Kit
P06539-L21
HPE ML30 Gen10 Intel Xeon E-2126G (3.3GHz/4-core/12MB/80W) FIO Processor Kit
P06543-L21
HPE ML30 Gen10 Intel Xeon E-2174G (3.8GHz/4-core/8MB/71W) FIO Processor Kit
P06541-L21
HPE ML30 Gen10 Intel Xeon E-2176G (3.7GHz/6-core/12MB/80W) FIO Processor Kit
P06549-L21
Intel® 8th Gen Core™ i3 Processors
HPE ML30 Gen10 Intel Core i3-8300 (3.7GHz/4-core/8MB/62W) FIO Processor Kit
P06557-L21
Intel® Pentium® Processor G Series
HPE ML30 Gen10 Intel Pentium G5400 (3.7GHz/2-core/4MB/58W) FIO Processor Kit
P06551-L21
ordered,
for information on configurable product offerings and requirements.
1. Factory Integrated Models must start with a CTO Server.
2. FIO indicates that this option is only available as a factory installable option.
3. All Factory Integrated Models will be populated with sufficient hard drive blan
with the server.
HPE OneView Standard (requires download, available in early 2019),
HPE iLO Advanced, HPE iLO Advanced Premium Security Edition, and HPE OneView Advanced
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Configuration Information
19
Step 2b: Choose Memory Options
Please select one or more memory from below.
NOTE: With one processor installed, four DIMMs slots are available.
NOTE: The maximum memory speed is a function of the memory type, memory configuration, and processor model.
Memory
HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879505-B21
HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879507-B21
Step 2c: Choose Power Supplies
NOTE: Mixing of 2 different power supplies is NOT allowed.
NOTE:
HPE Power Advisor Tool.
Power Supplies
HPE ML30 Gen9 350W E-star 1.0 FIO Power Supply Kit
820303-B21
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
865408-B21
Step 3: Choose additional options for Factory Integration from Core and Additional
Options sections below
NOTE: Selection of two HPE Flex Slot power supplies provides 1+1 power redundancy.
To review the power requirements for your selected configuration, please use the
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Core Options
20
NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard
configurator. Contact your local sales representative for additional
information.
HPE Unique Options
HPE ML30 Gen10 Slimline Optical Disk Drive Enablement Kit
P06309-B21
NOTE: Required if ODD is in the order.
HPE ML30 Gen10 Front PCI Fan and Baffle Kit
P06303-B21
NOTE: Included in SMB Performance and Solution Models.
Model if M.2 SSD or any PCIe card (NIC, Smart
Array controller, graphic card, etc.) is selected except 1Gb network adapters.
HPE ML30 Gen10 Mini SAS Cable Kit
P06307-B21
NOTE: Required if P408i-p/E208i-p is selected. Select one cable kit for 4LFF Hot Plug Server, two for 8SFF Hot
Plug Server.
HPE ML30 Gen10 4U RPS Enablement Kit
P06305-B21
NOTE: Required for HPE 500W Flex Slot Power Supply.
HPE DL20/ML30 Gen10 M.2/Dedicated iLO and Serial Port Kit
P06687-B21
NOTE: This kit includes one dedicated iLO module and one serial port cable, with one M.2 slot on the module for
HPE ML30 Gen9 350W E-star 1.0 FIO Power Supply Kit
820303-B21
HPE ML Gen10 Tower to Rack Conversion Kit with Sliding Rail Rack Shelf and Cable Management Arm
874578-B21
NOTE: Easy install rack rail tray which takes up 1U height in a standard rack facility. This conversion kit only
provides shelf function for ML30 Gen10 and does not support Cable Management Arm.
HPE Legacy FIO Mode Setting
758959-B22
NOTE: UEFI is the default, this FIO part can be used for CTO to enable Legacy mode.
Memory Selection
To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability,HPE
.Best product availability is limited to
US, Canada, and Latin America at this time.
Unbuffered DIMMs (UDIMMs)
HPE 8GB (1x8GB) Single Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879505-B21
HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666 CAS-19-19-19 Unbuffered Standard Memory Kit
879507-B21
NOTE: Running at 2400 MT/s with i3-8300 and G5400 due to processor limitation.
Enterprise recommends the use of an HPE approved
NOTE: Must be selected in 4LFF Hot Plug CTO Server and 8SFF Hot Plug CTO Server.
NOTE: Must be selected in 4LFF NHP CTO Server and SMB Entry
M.2 SSD installation.
NOTE: M.2 SSD is supported with or without this option on ML30 Gen10.
recommends memory from the list located here: http://www.hpe.com/products/recommend
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Core Options
21
HPE Optical Drives
HPE 9.5mm SATA DVD-ROM Optical Drive
726536-B21
NOTE: The HPE ML30 Gen10 Slim Optical Disk Drive Enablement Kit (P06309-B21) is required for this option.
HPE 9.5mm SATA DVD-RW Optical Drive
726537-B21
NOTE: The HPE ML30 Gen10 Slim Optical Disk Drive Enablement Kit (P06309-B21) is required for this option.
HPE Mobile USB DVD-RW Optical Drive
701498-B21
HPE Drives
Enterprise - 12G SAS - SFF Drives
HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
870753-B21
HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872475-B21
HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872477-B21
HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
870759-B21
HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD
872479-B21
HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD
872481-B21
HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD
881457-B21
Enterprise - 12G SAS - LFF Drives
HPE 900GB SAS 12G Enterprise 15K LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware HDD
870761-B21
Midline - 12G SAS - SFF Drives
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD
832514-B21
HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD
765464-B21
HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD
765466-B21
Midline - 12G SAS - LFF Drives
HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
833926-B21
HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
833928-B21
HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD
834031-B21
HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD
857646-B21
HPE 12TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD
881781-B21
HPE 1TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
846526-B21
HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD
861748-B21
HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD
861746-B21
Midline - 6G SATA - SFF Drives
HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD
655710-B21
HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD
765455-B21
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Core Options
22
Midline - 6G SATA - LFF Drives
HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861686-B21
HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861681-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Digitally Signed Firmware HDD
861683-B21
HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e HDD
861742-B21
HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty 512e Digitally Signed Firmware HDD
834028-B21
HPE 12TB SATA 6G Midline 7.2K LFF (3.5in) LP 1yr Wty Helium 512e Digitally Signed Firmware HDD
881787-B21
6G SATA - LFF NHP/Raw Drives
HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD
801882-B21
HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD
801888-B21
SSD Selection
To streamline the configuration process for HPE ProLiant Gen10 servers and to provide the best product availability,HPE
.Best product availability is limited to
http://ssd.hpe.com.
Write Intensive - -- 12G SAS - SFF - Solid State Drives
HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
873351-B21
Read Intensive - 6G SATA - SFF - Solid State Drives
HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04556-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04474-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06194-B21
HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04560-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04476-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06196-B21
HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04564-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04478-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06198-B21
HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04566-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04480-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04570-B21
HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P06200-B21
HPE 7.68TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
P04482-B21
Read Intensive - 6G SATA - LFF - Solid State Drives
HPE 480GB SATA 6G Read Intensive LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD
P04499-B21
HPE 1.92TB SATA 6G Read Intensive LFF (3.5in) LPC 3yr Wty Digitally Signed Firmware SSD
P04501-B21
Mixed Use - 12G SAS - SFF - Solid State Drives
HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD
873359-B21
Write Intensive - NVMe - M.2 - Solid State Drives
HPE 400GB NVMe x4 Lanes Mixed Use M.2 22110 3yr Wty Digitally Signed Firmware SSD
875583-B21
NOTE: M.2 SSD can be installed either on system board or on dedicated iLO module (P06687-B21).
NOTE:
recommends memory from the list located here: http://www.hpe.com/products/recommend
US, Canada, and Latin America at this time.To further assist with configuration, HPE also offers an SSD Selector Tool located
here:
NOTE: Running at PCIe 3.0 x2 speed on ML30 Gen10.
NOTE: HPE ML30 Gen10 Front PCI Fan and Baffle Kit (P06303-B21) is required to support these drives.
Not supported by HPE Smart Array controllers.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Core Options
23
Read Intensive - NVMe - M.2 - Solid State Drives
HPE 480GB NVMe x4 Lanes Read Intensive M.2 22110 3yr Wty Digitally Signed Firmware SSD
875579-B21
NOTE: M.2 SSD can be installed either on system board or on dedicated iLO module (P06687-B21).
NOTE: Not supported by HPE Smart Array controllers.
Hard Drive Kits
HPE Small Form Factor Hard Drive Blank Kit
666987-B21
HPE Gen9 LFF HDD Spade Blank Kit
807878-B21
HPE ML10v2 Drive Enablement Kit
812248-B21
NOTE: Only compatible with Non Hot Plug chassis and supports additional NHP LFF Hard Disk up to 2 pcs.
HPE Networking
1 Gigabit Ethernet adapters
HPE Ethernet 1Gb 4-port 331T Adapter
647594-B21
HPE Ethernet 1Gb 4-port 366T Adapter
811546-B21
HPE Ethernet 1Gb 2-port 332T Adapter
615732-B21
HPE Ethernet 1Gb 2-port 361T Adapter
652497-B21
10 Gigabit Ethernet adapters
NOTE: HPE ML30 Gen10 Front PCI Fan and Baffle Kit (P06303-B21) is required.
HPE Ethernet 10Gb 2-port 530T Adapter
656596-B21
HPE Ethernet 10Gb 2-port 535T Adapter
813661-B21
HPE Ethernet 10Gb 2-port 530SFP Adapter
652503-B21
NOTE: HPE ML30 Gen10 Front PCI Fan and Baffle Kit (P06303-B21) is required.
HPE Ethernet 10Gb 2-port 521T Adapter
867707-B21
HPE Ethernet 10Gb 2-port 562T Adapter
817738-B21
HPE Ethernet 10Gb 2-port 562SFP+ Adapter
727055-B21
HPE Power Supplies
HPE ML30 Gen9 350W E-star 1.0 FIO Power Supply Kit
820303-B21
NOTE: Up to one is allowed.
HPE 500W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit
865408-B21
NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14
power inlet connector.
HPE ML30 Gen10 4U RPS Enablement Kit
P06305-B21
NOTE: Required for HPE 500W Flex Slot Power Supply.
HPE Cooling Options
HPE ML30 Gen10 Front PCI Fan and Baffle Kit
P06303-B21
NOTE: Included in SMB Performance and Solution Models.
Must be selected in 4LFF NHP CTO Server and SMB Entry Model if M.2 SSD or any PCIe card (NIC, Smart
Array controller, graphic card, etc.) is selected except 1Gb network adapters.
NOTE: Running at PCIe 3.0 x2 speed on ML30 Gen10.
NOTE: HPE ML30 Gen10 Front PCI Fan and Baffle Kit (P06303-B21) is required to support these drives.
NOTE: Must be selected in 4LFF Hot Plug CTO Server and 8SFF Hot Plug CTO Server.
NOTE:
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Additional Options
24
NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard
dditional
information.
Embedded Management
HPE iLO Advanced
HPE iLO Advanced 1-server License with 1yr Support on iLO Licensed Features
512485-B21
HPE iLO Advanced Flexible Quantity License with 1yr Support on iLO Licensed Features
512486-B21
HPE iLO Advanced AKA Tracking License with 1yr Support on iLO Licensed Features
512487-B21
HPE iLO Advanced Electronic License with 1yr Support on iLO Licensed Features
E6U59ABE
HPE iLO Advanced Electronic License with 3yr Support on iLO Licensed Features
E6U64ABE
HPE iLO Advanced 1-server License with 3yr Support on iLO Licensed Features
BD505A
HPE iLO Advanced Flexible Quantity License with 3yr Support on iLO Licensed Features
BD506A
HPE iLO Advanced AKA Tracking License with 3yr Support on iLO Licensed Features
BD507A
HPE iLO Advanced Security
HPE iLO Advanced Premium Security Upgrade Electronic License with 3yr Support on Licensed Features
Q7E12AAE
HPE iLO Advanced Premium Security Edition License with 1yr Support on Licensed Features
Q7E31A
HPE iLO Advanced Premium Security Flex Qty License with 1yr Support on Licensed Features
Q7E32A
HPE iLO Advanced Premium Security Edition Electronic License with 1yr Support on Licensed Features
Q7E32AAE
HPE iLO Advanced Premium Security Edition License with 3yr Support on Licensed Features
Q7E33A
HPE iLO Advanced Premium Security Flex Qty License with 3yr Support on Licensed Features
Q7E34A
HPE iLO Advanced Premium Security Edition Electronic License with 3yr Support on Licensed Features
Q7E34AAE
HPE iLO Advanced Premium Security AKA Tracking License with 1yr Support on Licensed Features
Q7E35A
HPE iLO Advanced Premium Security AKA Tracking License with 3yr Support on Licensed Features
Q7E36A
HPE Security
HPE Trusted Platform Module 2.0 Gen10 Option
864279-B21
NOTE: HPE Trusted Platform Module 2.0 option works with Gen10 servers with UEFI Mode not LegacyMode. It
can have a TPM module (of any type) installed only once. It cannot be replacedwith any other TPM module.
HPE Gen10 TPM 1.2 FIO Setting
872108-B21
NOTE:
the TPM 2.0
NOTE: This option must be selected only with TPM 2.0 Gen10 Option (864279-B21).
HPE Smart Array Controllers
The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed
Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for a
is not compatible with HPE ProLiant Gen8 servers or earlier generation variants.NOTE: HPE server systems
This is a FIO setting to allows
module to operate in a TPM 1.2 mode.
breakout of the available Gen10 Smart Array controllers visit the HPE Smart Array Gen10 Controllers Data Sheet.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Additional Options
25
Performance RAID Controllers
NOTE: All performance RAID controllers require the HPE Smart Storage Battery (P01366-B21), which
supports multiple devices and is sold separately.
HPE Smart Array P408i-p SR Gen10 (8 Internal Lanes/2GB Cache) 12G SAS PCIe Plug-in Controller
830824-B21
NOTE: Must select 1pc of Mini SAS Cable Kit (P06307-B21) for 4LFF Hot Plug Server.
NOTE: Must select 2pcs of Mini SAS Cable Kit (P06307-B21) for 8SFF Hot Plug Server.
HPE Smart Array P408e-p SR Gen10 (8 External Lanes/4GB Cache) 12G SAS PCIe Plug-in Controller
804405-B21
Essential RAID Controllers
HPE Smart Array E208i-p SR Gen10 (8 Internal Lanes/No Cache) 12G SAS PCIe Plug-in Controller
804394-B21
NOTE: Must select 1pc of Mini SAS Cable Kit (P06307-B21) for 4LFF Hot Plug Server.
NOTE: Must select 2pcs of Mini SAS Cable Kit (P06307-B21) for 8SFF Hot Plug Server.
HPE Smart Array E208e-p SR Gen10 (8 External Lanes/No Cache) 12G SAS PCIe Plug-in Controller
804398-B21
Optional Upgrades
HPE 96W Smart Storage Battery (up to 20 Devices) with 145mm Cable Kit
P01366-B21
NOTE: Provides backup power for multiple HPE Smart Array controllers or other devices. Is required with
NOTE: A Battery holder is required: HPE Gen9 Smart Storage Battery Holder Kit (786710-B21).
HPE Tape Backup
NOTE: For the complete range of tape drives, autoloaders, libraries and mediasee:
HPE Tape Drives
HPE StoreEver LTO-5 Ultrium 3000 SAS Internal Tape Drive
EH957B
HPE StoreEver LTO-5 Ultrium 3000 SAS External Tape Drive
EH958B
HPE LTO-6 Ultrium 6250 Internal Tape Drive
EH969A
HPE StoreEver LTO-6 Ultrium 6250 External Tape Drive
EH970A
HPE LTO-7 Ultrium 15000 Internal Tape Drive
BB873A
HPE StoreEver LTO-7 Ultrium 15000 External Tape Drive
BB874A
NOTE: Only 1pc of internal tape drive is supported.
B21) with a
p to
NOTE:
performance RAID controllers.
https://www.hpe.com/us/en/storage/storeever-tape-storage.html.
For hardware and softwarecompatibility of Hewlett Packard Enterprise tape backup products
http://www.hpe.com/storage/BURAcompatibility
.
NOTE: Internal LTO tape drive requires 1pc of HPE ML30 Gen9 Tape Drive Cable Kit (851615-
350W Power Supply (820303-B21) configuration.
NOTE: Cannot share SAS controller with SAS drives. Must select additional internal SAS controller E208isupport internal SAS tape drive.
Internal LTO tape drive cannot be selected in Non Hot Plug Server.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Additional Options
26
HPE Tape Backup Products
HPE StoreEver MSL2024 0-drive Tape Library
AK379A
HPE StoreEver 1/8 G2 LTO-5 Ultrium 3000 SAS Tape Autoloader
BL536B
HPE StoreEver MSL LTO-5 Ultrium 3000 SAS Drive Upgrade Kit
BL540B
HPE StoreEver 1/8 G2 LTO-6 Ultrium 6250 SAS Tape Autoloader
C0H18A
HPE StoreEver MSL LTO-6 Ultrium 6250 SAS Drive Upgrade Kit
C0H27A
HPE StoreEver 1/8 G2 LTO-7 Ultrium 15000 SAS Tape Autoloader
N7P35A
HPE StoreEver MSL LTO-7 Ultrium 15000 SAS Drive Upgrade Kit
N7P37A
HPE StoreEver Mini-SAS High Density to 4-lane Mini-SAS External Fanout 2m Cable
K2R09A
HPE StoreEver Mini-SAS High Density to 4-lane Mini-SAS External Fanout 4m Cable
K2R10A
HPE Disk Backup
NOTE: For the complete range of RDX drives and media see:
for additional part numbers,
technical specifications, and additional information.
HPE RDX Removable Disk Backup System
HPE RDX External Docking Station
C8S07B
HPE RDX 1TB External Disk Backup System
B7B69B
HPE RDX 2TB External Disk Backup System
E7X53B
HPE RDX 3TB External Disk Backup System
P9L72A
HPE RDX 4TB External Disk Backup System
Q2R33A
HPE RDX Internal Docking Station
C8S06A
HPE RDX 1TB Internal Disk Backup System
B7B67A
HPE RDX 2TB Internal Disk Backup System
E7X52A
HPE RDX 3TB Internal Disk Backup System
P9L71A
NOTE: Only 1pc of internal RDX is supported, sharing the same internal USB port with USB flash drives.
B21) with a 350W Power
Supply (820303-B21) configuration.
HPE USB Options
HPE Enterprise Mainstream Flash Media Kits for Memory Cards
HPE 8GB microSD Flash USB Drive
737953-B21
HPE 8GB Dual microSD Flash USB Drive
741279-B21
HPE Uninterruptible Power Systems (UPS)
NOTE: To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web page.
https://www.hpe.com/us/en/product-catalog/storage/disk-based-backup-systems.html.
For hardware and software compatibility of HPE disk backup products
see: http://www.hpe.com/storage/spock.
NOTE: Please see the HPE RDX Removable Disk Backup System QuickSpecs
NOTE: Internal RDX requires 1pc of HPE ML30 Gen9 Tape Drive Cable Kit (851615-
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Additional Options
27
HPE Rack Options
Rail Kits
HPE ML Gen10 Tower to Rack Conversion Kit with Sliding Rail Rack Shelf and Cable Management Arm
874578-B21
HPE Support Services
Installation & Start-up Services
HPE Installation ML/DL Series 10 Service
U7WZ5E
HPE Startup ML/DL Series 10 Service
U7WZ7E
Foundation Care
HPE 3 year Foundation Care Next business day ML30 Gen10 Service
HC5X5E
HPE 3 year Foundation Care Next business day with DMR ML30 Gen10 Service
HC5X6E
HPE 3 year Foundation Care Next business day with CDMR ML30 Gen10 Service
HC5X7E
HPE 3 year Foundation Care 24x7 ML30 Gen10 Service
HC5Y6E
HPE 3 year Foundation Care 24x7 with DMR ML30 Gen10 Service
HC5Y7E
HPE 3 year Foundation Care 24x7 with CDMR ML30 Gen10 Service
HC5Y8E
Proactive Care
HPE 3 year Proactive Care 24x7 ML30 Gen10 Service
HC5Y9E
HPE 3 year Proactive Care 24x7 with DMR ML30 Gen10 Service
HC5Z0E
HPE 3 year Proactive Care 24x7 with CDMR ML30 Gen10 Service
HC5Z1E
NOTE: For a full list of packaged support services, please visit http://www.hpe.com/services/ssc
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Storage
28
HPE Standard Memory
HPE Standard Memory offers the best combination of pricing, quality, reliability and compatibility for HPE ProLiant servers; designed
affordable solutions. It delivers the ideal value that small businesses
level businesses with affordable server memory that
andard Memory is outstanding for businesses looking for memory with a low
acquisition cost, exceptional performance, optimized compatibility, assured reliability, and comprehensive management.
Memory Population guidelines
General Memory Population Rules and Guidelines:
to help your business achieve powerful results with right-sized
require to smoothly run a small network server environment and provides entryhas been optimized for HPE entry-level servers. HPE St
The HPE ProLiant ML30 Gen10 Server has four memory slots.
Only ECC UDIMMs are supported on ML30 Gen10. No support for non-ECC UDIMMs.
There are two channels per processor with two DIMM slots per channel.
Memory channel 1 consists of the two DIMMs that are closest to the processor.
Memory channel 2 consists of the two DIMMs that are farthest from the processor.
A white DIMM slot indicates the first slot of a channel (3-A, 1-B).
Memory speed support depends on the type of processor installed. For more information, see the
technical specification of the installed processor.
The server supports up to 2666 MT/s ECC UDIMMs (Unbuffered DIMMS).
The server supports up to 64 GB (4 x 16 GB) UDIMMs.
The server does not support Non-ECC UDIMMs, RDIMMs, and LRDIMMs
Populate the DIMM on slots in this sequence: 3-A, 1-B, 4-C, 2-D.
Always use HPE qualified DIMMs.
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Storage
29
DIMM Type
Unbuffered with ECC DIMMs (UDIMMs)
HPE SKU P/N
879505-B21
879507-B21
SKU Description
HPE 8GB (1x8GB) Single Rank x8 DDR4-2666
CAS-19-19-19 Unbuffered Standard Memory Kit
HPE 16GB (1x16GB) Dual Rank x8 DDR4-2666
CAS-19-19-19 Unbuffered Standard Memory Kit
DIMM Rank
Single Rank (1R)
Dual Rank (2R)
DIMM Capacity
8 GB
16 GB
Voltage
1.2V
1.2V
CAS Latency
19-19-19
19-19-19
DIMM Native Speed
2666 MT/s
2666 MT/s
32 GB (4 x 8 GB)
64 GB (4 x 16 GB)
HPE Server Memory Speed: Intel® Xeon® E processors
1 DIMM Per Channel
2666 MT/s
2666 MT/s
2 DIMM Per Channel
2666 MT/s
2666 MT/s
HPE Server Memory Speed: Intel® Core™ i3-8300, Pentium® G5400 processors
1 DIMM Per Channel
2400 MT/s
2400 MT/s
2 DIMM Per Channel
2400 MT/s
2400 MT/s
DDR4 memory options part number decoder
NOTE: Capacity references are rounded to the common gigabyte (GB) values.
4 LFF Non-Hot-Plug Drive Model
4 LFF Hot-Plug Drive Model
8 SFF Hot-Plug Drive Model
1-4
1-4
1-8
4 x LFF SATA
4 x LFF SAS/SATA/SSD
8 x SFF SAS/SATA/SSD
Maximum Capacity
o 8GB = 8,192 MB
o 16GB = 16,384 MB
o 32GB = 32,768 MB
o 64GB = 65,536 MB
For more information on memory, please visit the HPE DDR4 Standard Memory web site.
non-hot-plug hard drive bays
hot pluggable hard drive bays
hot pluggable hard drive bays
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Technical Specifications
30
System Unit
Dimensions
14.50 (H) x 6.89 (W) x 18.70 (D) in (36.83 x 17.50 x 47.50 cm)
Weight
Minimum:
22.1 lb
10.1 kg
4 NHP LFF chassis with 1x LFF HDD, 1x processor including heatsink, 1x
DIMM, 1x ATX power supply, cables for the above.
Maximum:
38.7 lb
Fully loaded - 4 Hot-plug LFF chassis with 4x LFF HDDs, 1x DVD-RW, 1x
,
cables for the above.
Input Requirements
(per power supply)
Rated Line Voltage
100 to 120 VAC
BTU Rating
Maximum
For 350W Power Supply: 1452 BTU/hr (at 100 VAC), 1544 BTU/hr (at 200
BTU/hr (at 200
VAC), 1832 BTU/hr (at 240 VAC)
Power Supply
Rated Steady-State Power
For 350W Power Supply: 350W (at 100 to 230 VAC)
For 500W Power Supply: 500W (at 100 VAC), 500W (at 240 VAC)
Maximum Peak Power
For 350W Power Supply: 350W (at 100 to 230 VAC)
0
VAC)
System Inlet
Standard Operating
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per
every 304.8 m (1.8°F per every 1000 ft) above sea level to a maximum of
3048 m (10,000 ft), no direct sustained sunlight. Maximum rate of change
imit may be limited by the type and number
System performance may be reduced if operating with a fan fault or above
30°C (86°F).
Extended Ambient Operating
For approved hardware configurations, the supported systeminlet range is
extended to be: 5° to 10°C (41° to 50°F) and 35°to 40°C (95° to 104°F) at
sea level with an altitude derating of1.0°C per every 175 m (1.8°F per every
574 ft) above 900 m(2953 ft) to a maximum of 3050 m (10,000 ft). The
For approved hardware configurations, the supported systeminlet range is
el with an altitude
derating of 1.0°C per every 125 m(1.8°F per every 410 ft) above 900 m
(2953 ft) to a maximumof 3050 m (10,000 ft). The approved hardware
System performance may be reduced if operating in theextended ambient
operating range or with a fan fault.
Non-operating
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
Relative Humidity
Operating
8% to 90% - Relative humidity (Rh), 28°C maximum wet bulbtemperature,
non-condensing.
Non-operating
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet
bulbtemperature, non-condensing..
(approximate)
Output
(per power supply)
Temperature
Temperature
Temperature
17.6 kg
tape drive, 1x processor including heatsink, 4x DIMMs, 2x power supplies
200 to 240 VAC
VAC)
For 500W Power Supply: 1902 BTU/hr (at 100 VAC), 1840
For 500W Power Supply: 500W (at 100 to 127 VAC), 500W (at 200 to 24
is 10°C/hr (18°F/hr). The upper l
of options installed.
approvedhardware configurations for this system are listed at the
URL:http://www.hpe.com/servers/ashrae
extended to be: 40° to 45°C (104° to 113°F) atsea lev
configurationsfor this system are listed at the URL:
http://www.hpe.com/servers/ashrae
(non-condensing)
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Technical Specifications
31
Altitude
Operating
3048 m (10,000 ft). This value may be limited by the type and number of
options installed. Maximum allowable altitude change rate is 457 m/min
(1500 ft/min).
Non-operating
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min
(1500 ft/min).
Acoustic Noise
Listed are the declared A-Weighted sound power levels (L
) and declared average bystander position A-
environment.
declared in accordance with
shipping configurations. Additional options
information from the HPE
EMESC website for further technical details regarding the configurations listed below.
Idle
LWAd
4.3 Bels (Entry)
3.6 Bels (Performance)
LpAm
28 dBA (Entry)
23 dBA (Performance)
Operating
LWAd
4.3 Bels (Entry)
3.8 Bels (Performance)
LpAm
28 dBA (Entry)
23 dBA (Performance)
NOTE: Acoustics levels presented here are generated by the test configuration only. Acoustics levelswill
notification andare for
Product conformance to cited product specifications is based on sample (type) testing,evaluation,
or assessment. This product or family of products is eligible to bear the appropriatecompliance logos and
The Listed sound levels apply to standard shipping configurations. Additional options may result
in increased sound levels.
Emissions Classification (EMC) - -- Regulatory Information
the Safety and Compliance Informationfor Server, Storage, Power,
http://www.hpe.com/support/Safety-Compliance-EnterpriseProducts
Environment-friendly Products and Approach - End-of-life Management and Recycling
, inmany geographic areas, for our
manufacturers to provide treatment information foreach product type for use by
. These
er WEEE treatment facilities as well as Hewlett Packard Enterprise OEM customers
who integrateand re-sell Hewlett Packard Enterprise equipment.
WAd
Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient
Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and
ISO 9296 (ECMA 109). The listed sound levels apply to standard
may result in increased sound levels. Please have your HPE representative provide
vary depending on system configuration. Values are subject to change without
reference only.
NOTE:
statements.
NOTE:
To view the regulatory information for your product, view
Networking, and Rack Products, available at the Hewlett PackardEnterprise Support Center:
Hewlett Packard Enterprise offers end-of-life product return, trade-in, and recycling programs
products. Products returned to Hewlett Packard Enterprise will berecycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires
treatment facilities. This information (product disassembly instructions) isposted on the Hewlett Packard Enterprise web site
instructions may be used by recyclers andoth
Page
QuickSpecs
HPE ProLiant ML30 Gen10 Server
Summary of Changes
32
Date
Version History
Action
Description of Change
05-Nov-2018
Version 1
New
New QuickSpecs.
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development LP. The information contained herein is subject
to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set
forth in the express warranty statements accompanying such pr
be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for
technical or editorial errors or omissions contained herein.
Intel® and Xeon® are registered trademarks of Intel Corporation in the U.S. and other countries.
Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of
companies.
For hard drives, 1GB = 1 billion bytes. Actual
a00053821enw - 16303 - Worldwide - V1 - 05-November-2018
oducts and services. Nothing herein should
formatted capacity is less
Page
Loading...
