QuickSpecs
HP StoreOnce B6200 Backup
Overview
Longing to take the pain out of backup and disaster recovery across your enterprise? You need a scale-out disk backup solution that
reduces management overheads, cuts storage costs and keeps pace with data growth.
HP StoreOnce B6000 Backup takes HP StoreOnce across the enterprise, providing efficient disk backup with data deduplication for cost
effective on site data retention, remote office data protection and off site disaster recovery. Highly scalable, the B6200 offers up to
768 TB of capacity and achieves speeds of up to100 TB/hr* with StoreOnce Catalyst to match enterprise performance requirements
and meet ever shrinking backup windows. HP StoreOnce B6000 Backup also offers rapid data recovery, to provide fast access to data.
Integrating seamlessly into your current IT environment, you can simplify data movement across the enterprise with the StoreOnce
Catalyst backup target. Manage multi site data protection, or backup over the WAN from a single pane of glass.
Part of HP's Converged Storage platform it is designed with autonomic restart , no single point of failure, and hot add capability, you
can be confident in a highly available system and the availability of your backup.
* Actual performance is dependent upon configuration, data set type, compression levels, number of data streams, number of devices
emulated and number of concurrent tasks, such as housekeeping or replication.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 1
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Overview
HP StoreOnce B6200 48TB Backup
HP StoreOnce B6200 48TB Backup in a 42U rack with HP
StoreOnce B6200 Switch Assembly and 3x B6200 Upgrade Kits
What's New
HP StoreOnce Catalyst for up to 100TB/hr performance* and simple and seamless management of data movement via a single
pane of glass for remote and multisite data protection.
HP Data Protector 7, delivering HP StoreOnce and StoreOnce Catalyst functionality for smaller offices and server-only
installations
*Actual performance is dependent upon configuration data set type, compression levels, number of data streams, number of devices
emulated and number of concurrent tasks, such as housekeeping or replication.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 2
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
For more detail please refer to the special features section below.
Scale out capacity for the
enterprise
Industry-leading
performance to meet
shrinking backup
windows
Reduce your backup data
storage needs with HP
StoreOnce deduplication
Consolidate and
automate daily backup to
free-up IT resources
Lower the cost of disaster
recovery and remote
office data protection
Scale your backup to keep pace with data growth. Scale-out from 48TB out to 768TB of raw capacity (32TB
to 512TB usable), by using a simple capacity upgrade for a lower cost alternative to purchasing additional
systems.
Backup big data within short backup windows with the HP StoreOnce B6200's high performance multistreaming capability. Consolidate multiple parallel backup streams via standard Ethernet or Fibre Channel
network to a single disk-based system to achieve industry-leading aggregate backup speeds of up to
100TB* per hour with HP StoreOnce Catalyst.
*Actual performance is dependent upon configuration data set type, compression levels, number of data
streams, number of devices emulated and number of concurrent tasks, such as housekeeping or
replication.
HP StoreOnce deduplication reduces the disk space required to store backup data sets by typically 20x
without impacting backup performance. Retaining more backup data on disk for longer, enables greater
data accessibility for rapid restore of lost or corrupt files and reduces impact on business productivity
while providing cost savings in disk storage, IT resource, physical space, and power requirements. Using
HP StoreOnce deduplication with a fully configured HP StoreOnce B6200, can provide extended data
retention on the same disk footprint for up to 10 PBs of backup data.
Consolidate and automate your backup processes using a single HP StoreOnce B6200, allowing you to
reduce the time spent managing multiple data protection devices and processes. The HP StoreOnce B6200,
can span multiple enterprise network platforms to consolidate your backup in one. With HP StoreOnce
Catalyst movement of deduplicated data across the enterprise is simple, and seamlessly controlled by
your backup application.
HP StoreOnce deduplication also enables network efficient offsite data replication. The HP StoreOnce
B6200 uses StoreOnce data deduplication to significantly reduce the amount of data that needs to be
replicated, enabling the use of lower bandwidth, lower cost links to transmit data offsite.
With StoreOnce Catalyst you can use your backup application to control data movement between
StoreOnce powered systems in its deduplicated state, no need to rehydrate the data.
HP StoreOnce B6200 Backup
Reliable remote office
data protection
StoreOnce enabled replication opens the way to cost-effective centralized backup from remote sites or
branch offices, and delivers a consolidated disaster recovery solution for the data center.
Centralize the backup of multiple remote sites, The HP StoreOnce B6200 allows a fan-in of up to 384
backup streams to a single target system at the data center. With HP StoreOnce Catalyst the movement of
data between sites is seamlessly controlled by your backup application, supporting a range of flexible
configurations that enable the concurrent movement of data from one site to multiple sites, and the ability
to cascade data around the enterprise (sometimes referred to as multi-hop).
Replication licensing requirements grow as your system grows. Purchasing either a Replication license, or
a StoreOnce Catalyst license (which include replication), is on a per target backup system basis. Unlike
competitor offerings, you won't add to the cost no matter how many remote offices you need to replicate
to a single HP StoreOnce B6200.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 3
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
Highly available solution
increases backup
reliability
Simplify remote
management
Seamlessly integrates
into your environment
Autonomic restart and no single point of failure in your backup process and redundancy at every level:
The HP StoreOnce B6200 offers an intuitive web-based browser interface allowing you to monitor your
backup systems, locally or remotely, to view results or change settings across the enterprise. This selfmanaging device also reduces your routine maintenance.
StoreOnce Catalyst enables seamless control of data movement across the enterprise via your backup
application.
The HP StoreOnce B6200 offers virtual tape library (VTL), NAS and StoreOnce Catalyst targets for backup
applications allowing for ease of use and integration in to existing IT environments. The HP StoreOnce
B6200s are pre-integrated into HP extended depth 42U racks for efficient use of space in the data center
and remote offices. Supported by all leading backup applications, this allows each Backup System to be
installed and used without additional investment in software.
HP StoreOnce B6200 Backup
Autonomic restart and node failover - simply swap to the other node in the couplet if one node fails.
The backup application will continue to retry backup jobs.
Built-in hardware redundancy - dual path disk arrays, dual path internal network, dual power
supplies throughout.
Dual fabric support for the backup jobs to the system via bonded Ethernet connections and dual
fibre channel ports per node.
Hot add server nodes and storage without the need to have scheduled maintenance.
Includes hardware RAID 6 to reduce the risk of data loss due to disk failures.
Special Features
Scale-out, future-ready
design to deliver leading
capacity and performance
The HP StoreOnce B6200s are designed to deliver a resilient solution to provide enterprise wide data
protection. Scale-out capacity and performance to keep pace with shrinking backup windows, reliable
disaster recovery, simplified protection of remote offices and rapid file restore to meet today's SLAs.
Customers can start out by purchasing one HP StoreOnce B6200 48TB system consisting of two nodes
connected in failover configuration as a couplet. This is delivered pre-integrated into HP extended depth
42U racks which also contains the necessary networking capabilities for future expansion within the entire
rack using an HP StoreOnce B6200 switch assembly.
To scale-out in terms of capacity, simply add up to 3 capacity upgrade kits to each couplet. Each upgrade
kit comprises 2 shelves which are added symmetrically, both sides of the couplet. Each shelf contains 12x
1TB or 2TB disks, giving 24TB or 48TB raw capacity (16- 32TB usable), allowing up to a maximum of 192TB
raw capacity (128TB usable) associated with the original node.
Capacity upgrade kits can be added to the couplet while the Backup System is online in order to reduce
unnecessary downtime.
A fully configured couplet with 3 capacity upgrade kits, can be managed as a single file system of up to
192TB raw capacity (128TB usable), however to optimize performance within a couplet, capacity usage
should be balanced across both nodes within a couplet.
To scale-out in terms of performance, add in one more HP StoreOnce B6200 48TB system and again scale
up by adding capacity upgrade kits. This gives you a maximum configuration of two fully configured HP
StoreOnce B6200 48TB system of two couplets with a total capacity of 384TB raw capacity (256TB usable)
in a single rack.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 4
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
To scale-out to 768TB raw (514TB usable) purchase a second rack with expansion switch assembly, and
populate as before.
HP StoreOnce
deduplication
- extend data retention
on disk
Data deduplication is a method of reducing storage needs by eliminating redundant data so that over time
only one unique instance of the data is actually retained on disk. As a result, typically 20x more backup
data can be retained in the same disk footprint.
Adding data deduplication to disk-based backup delivers a number of benefits:
HP StoreOnce B6200 Backup
A cost effective way of keeping your backup data on disk for a number of weeks or even months.
More efficient use of disk space effectively reduces the cost-per-gigabyte of storage and the need
to purchase more disk capacity.
Making file restores fast and easy from multiple available recovery points. By extending data
retention periods on disk, your backup data is more accessible for longer periods of time, before
archiving to tape. In this way, lost or corrupt files can be quickly and easily restored from backups
taken over a longer time span.
Ultimately, data deduplication makes the replication of backup data over lower bandwidth WAN
links financially viable (providing offsite protection for backup data) as only changed data is sent
across the connection to a second device (either a second identical device or one that comes from
this product family).
HP StoreOnce deduplication
HP StoreOnce deduplication software simplifies the deployment of deduplication technology across IT
infrastructures. With explosive data growth driving IT sprawl, deduplication technology is quickly
becoming a requirement for many customers to help reduce the capacity required to store information.
Traditional deduplication technologies tend to approach the problem from a fragmented
perspective and this results in multiple deduplication methodologies being deployed adding to the
management complexity of the infrastructure. HP StoreOnce is different; as a next generation
deduplication architecture, it is not sold as standalone software, but rather is a portable engine that
can be consistently embedded in multiple products, eliminating the complexity of first generation
deduplication. HP StoreOnce uses patented innovation and features designed by HP Labs to
maximize backup and restore performance while minimizing management and hardware overhead.
How it works
Deduplication works by examining the data stream as it arrives at the storage appliance, checking for
blocks of data that are identical and eliminating redundant copies. If duplicate data is found, a pointer is
established to the original set of data as opposed to actually storing the duplicate blocks, removing or
"deduplicating" the redundant blocks from the volume. The key here is that the data deduplication is being
done at the block level to remove far more redundant data than deduplication done at the file level where
only duplicate files are removed.
Data deduplication is especially powerful when it is applied to backup, since most backup data sets have a
great deal of redundancy. The amount of redundancy will depend on the type of data being backed up, the
backup methodology and the length of time the data is retained.
Example. Backing up a large customer database that gets updated with new orders throughout the day.
With the typical backup application you would normally have to back up, and store the entire database.
Even incremental backups will result in storing the full database to disk once again, taking up increasing
amounts of disk space with almost identical backup data sets. With block-level deduplication, you can
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 5
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
backup the same database to the device on two successive nights and, due to its ability to identify
redundant blocks, only the blocks that have changed will be stored. All the redundant data will have
pointers established.
The HP approach to deduplication
HP StoreOnce deduplication software simplifies the deployment of deduplication technology across IT
infrastructures. With explosive data growth driving IT sprawl, deduplication technology is quickly
becoming a requirement for many customers to help reduce the capacity required to store information.
Traditional deduplication technologies tend to approach the problem from a fragmented perspective and
this results in multiple deduplication methodologies being deployed adding to the management
complexity of the infrastructure. HP StoreOnce is different; as a next generation deduplication
architecture, it is not sold as standalone software, but rather is a portable engine that can be consistently
embedded in multiple products, eliminating the complexity of first generation deduplication. HP
StoreOnce uses patented algorithms and features designed by HP Labs to maximize backup and restore
performance while minimizing management and hardware overhead.
HP Backup systems feature HP StoreOnce deduplication which uses an optimized in-line process to
provide enhanced performance and is architected to be portable to other HP products in the future.
NOTE:
increased performance in large scale Fibre Channel deployments. StoreOnce and VLS deduplication
platforms are not compatible. They use different technologies that cannot be used together.
HP StoreOnce B6200 Backup
The HP VLS product family uses a post-process, object-level data deduplication scheme for
For more information on HP StoreOnce deduplication refer to the white papers available on
http://www.hp.com/go/StoreOnce
What deduplication ratio can I expect?
The actual data deduplication ratio you can expect will depend on a number of factors including: the type
of data, the backup methodology used, and the length of time you retain your data. However, assuming
standard business data mix and extended on disk retention (periods of more than 12 weeks) you could
expect to see 20:1 deduplication ratio assuming a weekly full and daily incremental backup model
Is there likely to be any impact on performance?
The actual performance achieved using an HP StoreOnce B6200 is dependent upon a number of factors
including data set type, compression levels, number of data streams, number of devices emulated and
number of concurrent tasks, such as backup and deduplication, housekeeping, and replication. In general,
the more process steps, the longer it may take. Consequently, when compared to backup without
deduplication, a reduced amount of data will be backed up AND replicated within the same timeframe.
For help with choosing the most appropriate HP StoreOnce B6000 configuration for your specific
environment, we recommend you talk to your HP partner or sales advisor about using the HP storage
Sizing Tool which can be downloaded from the Downloads section of
Making use of the backup systems ability to run multiple backups in parallel can substantially improve
aggregate throughput. This and a number of other best practices can help you to optimize the
performance of a StoreOnce Backup System, Please refer to: "Best Practices for configuring HP StoreOnce
B6200"/documentation which will be available in Spring 2012 at:
http://bizsupport2.austin.hp.com/bc/docs/support/SupportManual/c03121413/c03121413.pdf
www.hp.com/go/d2dsizer
For more information on achieving deduplication ratios go to:
DA - 14153 Worldwide — Version 9 — December 12, 2012
www.hp.com/go/deduplication
Page 6
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
Data
replication network efficient
disaster recovery
Data replication is the process of making a duplicate copy of a data set across a network to a "target site".
It is generally used to transmit backup data sets off-site to provide disaster recovery (DR) protection in the
event of catastrophic data loss at the "source site"
Replicating large volumes of data backup over a typical WAN is expensive. However, today's products with
data deduplication have made it possible to replicate data over lower bandwidth links for a more costeffective, network efficient replication solution that provides a practical disaster recovery solution and an
ideal solution for centralizing the backup of remote offices.
Data deduplication shrinks the amount of backup data that needs to be replicated from the source HP
appliance, and as a result significantly reduces replication bandwidth requirements. Once a replica of the
data backup set has been created on a remote HP target appliance all that is required to keep the replica
identical to the source is the automatic, periodic copying and movement of the new data segments which
are created during each backup. With such small amounts of data being transmitted asynchronously,
lower bandwidth networks offer sufficient performance and a much lower cost solution.
NOTE:
D2D and HP StoreOnce B6200, but not VLS.
HP StoreOnce B6200 Backup
Replication of data can only occur between devices within the same product family ie. HP StoreOnce
HP StoreOnce Catalyst seamless data movement
across the enterprise
HP's data replication feature includes replication bandwidth limiting functionality, restricting the amount
of bandwidth being used when replicating data for even more network-efficient replication. Without
replication bandwidth limiting, a replication job could use as much bandwidth as is available, potentially
making other network activities unresponsive. Replication bandwidth limiting is customer configurable at
the appliance level via the graphical user interface and is set as a percentage of the available network
bandwidth.
HP delivers replication by license, either as a standalone replication solution, or as part of the HP
StoreOnce Catalyst licensing (see the following section below). For the HP StoreOnce B6200, a total of 96
source appliances can replicate to a single HP StoreOnce B6200 48TB target, this increases to 384 when 4
couplets are used. Once licensing has been applied, configuring and using replication is made
straightforward by the graphical user interface and configuration wizard on the HP appliance.
Replication licensing requirements grow as you system grows. Licensing is per target backup system, so
you won't add to the cost no matter how many remote offices you need to replicate to a single HP
StoreOnce B6200 Backup. Each couplet being used as a replication target within the backup system
requires a replication license.
See the 'Related Options - Replication licenses' section of these QuickSpecs for more details.
HP StoreOnce Catalyst brings the HP StoreOnce vision of a single, integrated enterprise-wide
deduplication algorithm a step closer. It allows the seamless movement of deduplicated data across the
enterprise to other StoreOnce Catalyst systems without rehydration. This means that you can benefit
from:
Simplified management of data movement from a single pane of glass: tighter integration with your
backup application to centrally manage file replication across the enterprise.
Seamless control across complex environments: supporting a range of flexible configurations that
enable the concurrent movement of data from one site to multiple sites, and the ability to cascade
data around the enterprise (sometimes referred to as multi-hop).
Enhance performance: distributed deduplication processing using StoreOnce Catalyst stores on the
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 7
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
*Actual performance is dependent upon configuration data set type, compression levels, number of data
streams, number of devices emulated and number of concurrent tasks, such as housekeeping or
replication.
HP StoreOnce Catalyst is currently available for customers of the HP StoreOnce B6200 with HP Data
Protector 7 or Symantec Backup Exec and NetBackup software via OST. The license means that you can
now select StoreOnce Catalyst as a backup target, in a similar way to NAS or VTL. A StoreOnce Catalyst
license is required wherever it is used. It enables you to both store and replicate data to StoreOnce
Catalyst stores, i.e. a separate replication license is not required.
Replication licensing requirements grow as you system grows. Replication licensing is per target backup
system, so you won't add to the cost no matter how many remote offices you need to replicate to a single
HP StoreOnce B6200. HP StoreOnce B6200 can support a total of 96 source appliances replicating to a
single HP StoreOnce B6200 48TB target, this increases to 384 when 4 couplets are used. Electronic
licenses are available and delivered via http://www.webware.hp.com
HP StoreOnce B6200 Backup
B6200 and on multiple servers can optimize loading and utilization of backup hardware, network
links and backup servers for faster deduplication and backup performance.
Faster time to backup to meet shrinking backup windows: up to 100TB/hour *aggregate
throughput, 4x faster than backup to a NAS target
HP Replication Manager
HP StoreOnce Replication Manager 2.0 is available with HP StoreOnce B6200 Replication licenses. It allows
users to monitor, report and manage multiple StoreOnce backup systems' GUI's through a single
management console. Replication Manager 2.0 provides an easier way to monitor backup targets, showing
trends analysis, enhanced topology view and email alert notification for up to 400 StoreOnce backup
systems, being replicated to a central site. Replication Manager 2.0 provides basic trends analysis of
capacity usage, replication up times and utilization analysis. This analysis can be exported in CSV format.
Replication Manager 2.0 includes real time graphical views (with auto refresh), active directory group
setting, firmware identification, and a Command Line Interface. Replication Manager 2.0 supports windows
32 and 64 bit support.
Replication Manager software is available with the following replication license (EJ026A) .
In order to benefit from Replication manger, StoreOnce backup systems require the latest firmware, which
can be obtained via a free firmware upgrade by following the "Support & Drivers" link on
www.hp.com/go/B6000
or by following the "HP Support & Drivers" link from:
www.hp.com
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 8
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Features and Benefits
Highly Available data
protection
HP StoreOnce B6200s are highly available solutions designed with no single point of hardware failure.
The hardware of the HP StoreOnce B6200's couplet handles any one component failing. This means the
following high availability features:
HP StoreOnce B6200 Backup
Autonomic Restart and node failover
RAID storage, with RAID6 as the minimum redundancy level (so each RAID set can survive a double
disk failure)
The front-end controllers (nodes) within a couplet are configured in failover mode so that if one
controller fails all critical non-replaceable aspects of that controller are transparently moved to
another controller and the failed controller is disabled.
Dual storage controllers (RAID and JBOD), with cache mirroring between the RAID controllers (so
that if a controller fails the data is preserved and is still written to media by the other controller)
Dual paths to the disk drives
Power failure protection for all caching within the storage
Dual power supplies, such that the hardware will continue operating at full performance if one
power supply is offline.
Redundant fans, such that the hardware will continue operating at full performance if one fan is
offline
Mirrored system disks in each controller (node) to store the device operating system and software
Front-end high availability (dual fabric support): each controller will have at least two front-end
ports per port type to support the customer's external LAN/SAN fabrics. Thus if any external fabric
fails there is still full access to every node in the device.
Hot add additional storage or server nodes without scheduled downtime.
A single GUI/CLI interface is presented from any one node in the system, if that controller fails then
the GUI will automatically move to a different controller whilst still being presented at the same
network address.
Data protection for
complex and
heterogeneous
environments
HP StoreOnce B6200s are capable of supporting VTL, NAS and StoreOnce Catalyst targets for backup
applications on a single platform.
The device will present standard NAS protocols over the front-end 10Gb LAN ports of the device, thus
providing a LAN backup target (with deduplication) that can be used transparently with qualified enterprise
backup application
Models
For help with configuring the most appropriate HP StoreOnce B6200 for your specific environment, we recommend you talk to your HP
partner or sales advisor about using the HP Storage Sizing Tool which can be downloaded from the Downloads section of
www.hp.com/go/d2dsizer
HP StoreOnce B6200 48TB
Backup
HP StoreOnce B6200 takes HP StoreOnce to the enterprise, providing disk based backup with
deduplication for cost effective, longer term on site data retention and off site disaster recovery. These
highly scale out solutions offer from 32TB to 512TB of usable capacity and industry-leading aggregate
speeds of up to 100TB/hr*with StoreOnce Catalyst to match enterprise performance requirements and
meet ever shrinking backup windows.
*Actual performance is dependent upon configuration, data set type, compression levels, number of data
streams, number of devices emulated and number of concurrent tasks, such as housekeeping or
replication.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 9
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Compatibility
HP extensive compatibility testing program assures that your HP Backup Systems work with leading servers, operating systems, and
backup applications, including those not manufactured by HP.
Server Compatibility
OS Support
Software Support
HP StoreOnce B6200s are supported on servers that use Microsoft Windows or Linux operating systems,
including HP ProLiant, HP Integrity Servers and a variety of third-party servers.
For compatibility details on specific servers, refer to our website for the latest hardware compatibility
information:
HP StoreOnce B6200s are supported with Microsoft Windows, Linux, HP-UX and Solaris operating systems.
For more details, refer to our website for the latest information:
HP StoreOnce B6200s are supported by a range of popular backup applications, including HP Data
Protector software.
HP StoreOnce B6200s with StoreOnce Catalyst are supported on HP Data Protector 7 and Symmantec
BackupExec and NetBackup software with an OST.
http://www.hp.com/go/ebs
http://www.hp.com/go/ebs
Network Compatibility
SAN Compatibility
Tape compatibility migrating data to Tape
For details of specific backup application compatibility, refer to our website for the latest information:
http://www.hp.com/go/ebs
For the best performance, HP StoreOnce B6200s should be connected to the servers it protects via a 10Gb
(gigabit) Ethernet network. It is supported on all 10Gb Ethernet network interface cards (NICs) and
switches, dependent on product. 1Gb Ethernet network connections are also supported for sites without
10Gb Ethernet networks (with reduced performance)
HP StoreOnce B6200s are also supported on 100 base-T Ethernet networks, for connection for the Web
GUI and CLI access, such as a management network in a Data Centre.
This product is not supported on networks using slower Ethernet technology.
HP StoreOnce B6200s support a variety of Fibre Channel switches and HBAs.
For more details of SAN compatibility, refer to our website for the latest information:
http://www.hp.com/go/ebs
HP StoreOnce B6200s are an excellent solution for regular and daily backup with data deduplication
allowing more data to be retained on disk for longer, and enabling network-efficient data replication to
deliver a cost-effective off-site disaster recovery solution.
Using the device should enable a significant reduction in the amount of data stored on physical tape, so
that for example, there is no longer any need to store daily incremental backups on tape. However, HP still
recommends periodic off-load to tape as the most cost-effective, energy efficient and robust solution for:
1.
Long-term archival of data to meet regulatory requirements
2.
Or off-site storage for disaster recovery where data replication is not an option
HP StoreOnce B6200s7 do not support direct attach to tape. However, there are two methods available to
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 10
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Compatibility
migrate data to tape:
For highest performance, create a separate physical tape backup. This uses the backup application to
create a completely separate tape backup from the server to a physical tape drive or library in parallel to
the HP StoreOnce backup system. However, this will require the user to periodically manage two separate
backup processes (HP StoreOnce Backup system on a daily basis, and both HP StoreOnce Backup system
and Tape where archival is being prepared).
For a straight-forward and easier to manage solution, and where performance is less of an issue, use
backup application copy. This uses the backup application to copy cartridges or NAS file shares that have
been backed up to the target device to a physical tape drive or library that is connected elsewhere in the
storage network either directly connected to a media server or on a Fibre Channel SAN. This method may
have a performance impact, as the data has to be re-assembled on the backup system for copy and
performance depends on the number of streams read/copied in parallel.
1.
2.
HP StoreOnce B6200 Backup
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 11
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
Service and Support
Technology Services for increased uptime, productivity and ROI
TRUST HP storage technology experts for every level of service and support. Our integrated portfolio of
Services for storage help customers reduce costs, optimize data, streamline storage management, and
improve backup and recovery. Capitalizing on HP Storage Systems' capabilities requires a service partner
who understands your increasingly complex environment. Team with the people who know HP
infrastructure hardware and software best-the experienced professionals at HP Services.
Protect your business beyond warranty
Warranty protects against manufacturer defects, however warranty uplifts, such as HP Care Pack Services
protect the business-by reducing downtime risks and providing operational consistency for missioncritical and standard business computing.
What HP Storage Technology Services can do for you
HP Storage Technology Services can help you design, deploy, test, integrate, support, and manage IT and
infrastructure solutions. HP storage lifecycle support services offers a full spectrum of customer carefrom technology support to complex migrations to complete managed services.
Choose the right level of support, deployment and integration services
HP support recommendations are designed to help you enhance technology operations and lower risk-and
make it easier for you to seek the right balance between affordability and service-level commitments.
Depending on your individual support needs, choose from three levels of care that cover the entire
lifecycle to better address your needs-Optimized Care, Standard Care, and Basic Care. If none of our
support recommendations meet your needs, we can tailor a service solution for your unique support
requirements. Only HP brings together deep expertise, proactive and business critical support and a strong
partner network-plus, a full set of infrastructure services designed to power a Converged Infrastructure.
HP StoreOnce B6200 Backup
Optimized Care-
best performance and
stability through
deployment and proactive
management practices
Standard Care-
high level of uptime, along
with expert help to cut the
cost and complexity of
implementation and
support
Basic Care-
recommended support
delivers
maintains
Minimum
HP Proactive Care 24x7-
and software support services designed specifically for your technology; rapid access to Advanced
Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can
optimize the return on their IT investment and realize the advantage of running their business critical
applications on virtualized/x86 infrastructure. Plus,40 credits per year, select from an extensive menu of
consultancy and technical services, such as onsite firmware upgrades, health checks, assessments, and
education.
HP Proactive Care 24x7-
and software support services designed specifically for your technology; rapid access to Advanced
Solution Center Specialists plus, Firmware/Software management and best practice advice. Customers can
optimize the return on their IT investment and realize the advantage of running their business critical
applications on virtualized/x86 infrastructure. Plus, 10 credits per year, select from an extensive menu of
consultancy and technical services, such as onsite firmware upgrades, health checks, assessments, and
education.
Support Plus 24
integrated hardware and software support services designed specifically for your technology. Available
24x7, this 3-year combined reactive support option delivers onsite hardware support and over-the-phone
software support around-the-clock. Leverage the full strength of HP Technology Services - customers can
trust the services professionals at HP to work collaboratively with them, putting our strategic and
technical know-how to work across their entire infrastructure.
Plus, 10 credits per year,
onsite firmware upgrades, health checks, assessments, and education
-For a higher return on your server and storage investment, HP Support Plus 24 provides
for a higher return on your storage investment, Proactive Care delivers hardware
for a higher return on your storage investment, Proactive Care delivers hardware
select from an extensive menu of consultancy and technical services, such as
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 12
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
Implementation
Additional services to
meet your needs
Remote
Support Tools
For more information
Installation:
service deployment, installation verification testing (IVT), and an orientation session to facilitate
deployment of the features and functionality of HP B6000 Backup Systems.
Data sheet:
HP Backup and Recovery Solution Service.
customer's business needs and implementation. Benefits-HP's expertise with backup helps to reduce
project executive time and lower risk to the storage environment.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5982-7442EN.pdf
HP Storage technical assistance (HK947A1)
HP Proactive Select:
HP Proactive Select is a flexible way to purchase services to fit your particular environment or situation.
Working with an HP Account Support Manager, you select a 'package' of services, from a wide range of
proactive services offered by HP spanning many technologies and processes-- such as onsite firmware
upgrades, health checks, assessments, and education. You tailor the service delivery to improve time-toproduction, optimize performance, or build in continuous improvements
The link to the datasheet is as follows:
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA2-3842ENW.pdf
HP Insight Remote Support-
service agreement customers, uses proven technology to deliver secure, reliable 24x7 remote monitoring,
diagnosis and problem resolution.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-4676ENW.pdf
To learn more on HP Storage Services, please contact your HP sales representative or HP Authorized
Channel Partner
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
HP B6000 StoreOnce Backup System Installation and Startup Service Provides planning,
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-7608ENW.pdf
Professional backup and recovery planning that aligns with
Accelerate the ROI of your technology investment
Available at no additional cost to all warranty, HP Care Pack Service and
HP StoreOnce B6200 Backup
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order
configuration tools.
Customers purchasing from a commercial reseller can find HP Care Pack Services at
www.hp.com/go/lookuptool
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 13
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Configuration Information
Step 1 - Select a Configuration
The HP StoreOnce B6000 StoreOnce Backup Planning Guide helps you select the correct options for power and connectivity for your
data centre environment. It will also help you plan for a successful and smooth installation of the B6200.
It can be downloaded from:
Select one:
HP StoreOnce B6200 48TB Backup
HP StoreOnce B6200 24TB Upgrade Kit
HP StoreOnce B6200 48 TB Upgrade Kit
http://bizsupport1.austin.hp.com/bc/docs/support/SupportManual/c03116530/c03116530.pdf
Part Number
EJ022A
HP StoreOnce B6200 with 48 TB of disk storage
Contents:
HP B6200 Processing Nodes (2 off)
HP B6200 Storage Controllers (2 off)(each with 12 * 2TB HDDs)
8 * 0.5m Mini SAS cables
8 x Power cords (with IEC 320 C13 plug for Rack PDU)
Installation Guide
EJ024A
HP StoreOnce B6200 24TB upgrade kit, offering additional 24 TB of disk storage
Contents:
HP B6200 Storage JBODs (2 off)(each with 12 * 1TB HDDs)
4 * 0.5m Mini SAS cables
4 x Power cords (with IEC 320 C13 plug for Rack PDU)
Installation Guide
HP B6200 24TB Capacity Upgrade License Entitlement Certificate
HP B6200 Storage JBODs (2 off)(each with 12 * 1TB HDDs)
4 * 0.5m Mini SAS cables
EJ025A
HP StoreOnce B6200 48TB upgrade kit, offering additional 48 TB of disk storage
Contents:
HP B6200 Storage JBODs (2 off)(each with 12 * 2TB HDDs)
4 * 0.5m Mini SAS cables>>
4 x Power cords (with IEC 320 C13 plug for Rack PDU)
Installation Guide
HP B6200 24TB Capacity Upgrade License Entitlement Certificate
HP B6200 Storage JBODs (2 off)(each with 12 * 2TB HDDs)
4 * 0.5m Mini SAS cables
Step 2 - Related Options
Replication Licenses
HP B6200 StoreOnce Replication LTU
HP B6200 StoreOnce Replication E-LTU
These licenses enable an appliance to host replication targets. (No license is
DA - 14153 Worldwide — Version 9 — December 12, 2012
EJ026A
EJ026AAE
Page 14
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Configuration Information
HP StoreOnce Catalyst
License
HP StoreOnce Catalyst OST E-LTU for StoreOnce B6200
HP StoreOnce Catalyst DP E-LTU for StoreOnce B6200
HP StoreOnce B6200 Backup
required for appliances which only act as replication sources)
Licensing is "per couplet" i.e. A single license is required to enable a couplet to
host it's replication targets
A total of 96 source appliances can replicate to a single HP StoreOnce B6200
48TB target. This increases to 384 when a 4 couplet configuration is used.
Each couplet being used as a replication target within the backup system
requires a replication license.
Licenses are delivered via
appliance serial number (and are not transferable)
Licenses include an account providing authorization to download the HP
StoreOnce Replication Manager 2.0 which provides an easier way to monitor
backup targets showing trends analysis, enhanced topology view and email alert
notification for up to 400 StoreOnce backup systems, being replicated to a
central site.
Download instructions of the HP StoreOnce Replication Manager 2.0 are included
when the replication license is downloaded
StoreOnce Catalyst is a licensed feature, every B6200 that uses StoreOnce
Catalyst requires a license
Licenses enable a B6200 to create StoreOnce Catalyst targets for backup.
StoreOnce Catalyst also provides seamless control of data movement across the
organization and better utilization of servers, network bandwidth.
The license type is linked to the backup application being used
Currently 2 are supported:
HP B6200 StoreOnce Catalyst OST E-LTU (enables use of catalyst with
Symantec NetBackup and BackupExec)
HP B6200 StoreOnce Catalyst DP E-LTU (enables use of catalyst with Data
Protector)
www.webware.hp.com
and are node-locked by
TC396AAE
TC397AAE
10GbE Connectivity
10GbE Fibre Optic
Modules
HP ProCurve 10GbE
Connectivity
Direct Attach Copper
Cables
HP BladeSystem c-Class 10Gb Short Range Small Form-Factor Pluggable Option
NOTE:
Fibre transceivers and cables must be purchased separately for fibre-optic
environments - 4 transceivers are required for each couplet.
The following cables are recommended for 10GbE connectivity with HP ProCurve
network switches
HP X242 10G SFP+ to SFP+ 1m Direct Attach Copper Cable
HP X242 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
HP X242 10G SFP+ to SFP+ 7m Direct Attach Copper Cable
HP X244 10G XFP to SFP+ 1m Direct Attach Copper Cable
HP 10G X244 XFP to SFP+ 3m Direct Attach Copper Cable
NOTE:
Direct Attach Cable (DAC) must be purchased separately for copper
environments. They do not require fibre optic modules
DA - 14153 Worldwide — Version 9 — December 12, 2012
455883-B21
J9281B
J9283B
J9285B
J9300A
J9301A
Page 15
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Configuration Information
Fiber Optic Cables
Direct Attach Cable
HP .5m Premier Flex LC/LC 1 Pack Optical Cable
HP 1m Premier Flex LC/LC 1 Pack Optical Cable
HP 2m Premier Flex LC/LC 1 Pack Optical Cable
HP 5m Premier Flex LC/LC 1 Pack Optical Cable
HP 15m Premier Flex LC/LC 1 Pack Optical Cable
HP 30m Premier Flex LC/LC 1 Pack Optical Cable
HP .5m Premier Flex LC/LC 1 Pack Optical Cable
NOTE:
environments.
The following cables are available for connectivity with other 10GbE switch
environments
HP BladeSystem c-Class Small Form-Factor Pluggable .5m 10GbE Copper Cable
HP BladeSystem c-Class Small Form-Factor Pluggable 1m 10GbE Copper Cable
HP BladeSystem c-Class Small Form-Factor Pluggable 3m 10GbE Copper Cable
HP BladeSystem c-Class Small Form-Factor Pluggable 5m 10GbE Copper Cable
HP BladeSystem c-Class Small Form-Factor Pluggable 7m 10GbE Copper Cable
NOTE:
environments.
HP StoreOnce B6200 Backup
Fibre transceivers and cables must be purchased separately for fibre-optic
Direct Attach Cable (DAC) must be purchased separately for copper
BK837A
BK838A
BK839A
BK840A
BK841A
BK842A
BK837A
487649-B21
487652-B21
487655-B21
537963-B21
487658-B21
Fiber Optic Cables
2M LC-SC Cable Kit (2Gb to 1Gb)
5M LC-SC Cable Kit (2Gb to 1Gb)
15M LC-SC Cable Kit (2Gb to 1Gb)
2m LC-LC FC Cable Kit
5m LC-LC FC Cable Kit
15m LC-LC FC Cable Kit
30m LC-LC FC Cable Kit
50m LC-LC FC Cable Kit
HP LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable
NOTE:
Fiber transceivers and cables must be purchased separately for fiber-optic
environments.
HP B6000 StoreOnce Backup Systems Configurations -
NOTE:
THE STORAGE SIZER TOOL MUST ALSO BE USED TO CORRECTLY SIZE A DEDUPLICATION AND REPLICATION ENABLED SYSTEM!
221691-B21
221691-B22
221691-B23
221692-B21
221692-B22
221692-B23
221692-B26
221692-B27
AJ833A
AJ834A
AJ836A
AJ837A
AJ838A
AJ839A
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 16
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Configuration Information
Use the steps below as a guide, but TO PLACE ACTUAL ORDERS USE WATSON and CLIC TO CONFIGURE A SYSTEM
THIS IS ESPECIALLY TRUE FOR THE CUSTOMERS 1st or 3rd B6200 (EJ022A) WHICH REQUIRES MANDATORY FACTORY EXPRESS
INTEGRATION INTO THE EXTENDED DEPTH 42U RACK WHICH DOES NOT NEED TO BE ORDERED SEPARATELY, BUT IS AUTOMATICALLY
ADDED THE ORDER CONFIGUARTION WHEN THE ASSOCIATED EJ021A OR EJO27A SWITCH KITS ARE ORDERED.
WHEN WISHING TO EXPAND AN EXISTING SYSTEM THE CUSTOMERS 2ND or 4TH B6200 (EJ022A) IS NOT FACTORY INTEGRATED AND CAN
BE ORDERED WITHOUT THE #OD1 OPTION OR SWITCH KITS, AS THE 1ST AND 3RD B6200S ARE ALREADY HOUSED IN THE 42U RACKS
AND HAVE BEEN FACTORY INTEGRATED WITH SWITCH KITS REQUIRED.
The HP StoreOnce B6000 StoreOnce Backup Planning Guide helps you select the correct options for power and connectivity for your
data centre environment. It will also help plan for a successful and smooth installation of the B6200.
It can be downloaded from:
Step 1 - Configurations
CUSTOMERS 1ST AND 3RD B6200)
NOTE:
The B6200 MUST be factory integrated into the 42U extended depth rack. Non factory integration into a standard 42U rack, is
not supported.
http://bizsupport1.austin.hp.com/bc/docs/support/SupportManual/c03116530/c03116530.pdf
(Option #0D1 must be added to products listed for essential factory integration, I.E. THE
For the most accurate sizing of the solution necessary for your environment please be sure that your sales rep or partner utilizes the
HP Sizer tool. This is especially important when considering deduplication and replication.
StoreOnce B6000 Configurations - (EJ022A) based configurations
Factory Integrated Clusters
Switch kit (required)
42U extended depth rack
StoreOnce B6200 48TB Backup
Add capacity
Add capacity
Add capacity
Couplet 1 Couplet 2 Couplet 3 Couplet 4
Qty 1 - EJ021A
not to be ordered separately, but is
automatically added to Config when EJ021A
ordered)
Qty 1 - EJ022A#0D1 Qty 1 - EJ022A#0D1
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Not required
FOR 1ST
CONFIGURATION ONLY
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1 - EJ027A
(not to be ordered separately, but is
automatically added to Config when EJ027A
ordered)
Qty 1 - EJ022A#0D1 Qty 1 - EJ022A#0D1
CONFIGURATION AND
COUPLETS 3&4 TO AN
EXISITNG SYSTEM
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Qty 1
EJ024A
24TB
Not required
(FOR 1ST
WHEN ADDING
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
Qty 1
EJ025A
48TB
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 17
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Configuration Information
Replication license
Switch kit (required)
StoreOnce B6200 48TB Backup
Add capacity
24TB/48TB
Add capacity
24TB/48TB
Add capacity
24TB/48TB
Standard Rack
Qty 1 - EJ026A Qty 2 - EJ026A Qty 3 - EJ026A Qty 4 - EJ026A
Factory Integrated Clusters
Form Factors
Couplet 1 Couplet 2 Couplet 3 Couplet 4
2U 2U
8U 8U 8U 8U
4U 4U 4U 4U 4U 4U 4U 4U
4U 4U 4U 4U 4U 4U 4U 4U
4U 4U 4U 4U 4U 4U 4U 4U
42U 42U 42U 42U
Step 2 - Select appropriate Services/Support (optional)
Determine whether you require services via HP direct/HP authorized enterprise resellers or HP authorized commercial resellers.
Choose Installation or Installation and Startup service desired. HP recommends Installation and Startup. (Details of specific part
numbers in service section.)
Choose support uplift type. There are different service uplifts uplifting years of service, hours of availability and response time.
HP recommends three year 24X7 support uplifts. (Details of specific part numbers in service section.)
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 18
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Technical Specifications
StoreOnce B6200 maximum RAW capacity TB
Base couplet
1 24TB expansion kit
2 24TB expansion kit
3 24TB expansion kit
Or…
1 48TB expansion kit
2 48TB expansion kit
3 48TB expansion kit
NOTE:
A mixture of 24 or 48TB expansion kits can be used up to a maximum of 3 per couplet.
Base couplet
1 24TB expansion kit
2 24TB expansion kit
3 24TB expansion kit
Or…
1 48TB expansion kit
2 48TB expansion kit
3 48TB expansion kit
Data Deduplication
Usable capacity using data
deduplication at 20:1
Actual results of data deduplication will vary with data type, change rates over time and backup methodologies used. Assuming
standard business data mix and extended on-disk retention, typically a 20:1
NOTE:
A mixture of 24 or 48TB expansion kits can be used up to a maximum of 3 per couplet
*
1 couplet 2 couplet 3 couplet 4 couplet
48 96 144 192
72 144 216 288
96 192 288 384
120 240 360 480
96 192 288 384
144 288 432 576
192 384 576 768
StoreOnce B6200 maximum usable capacity TB
1 couplet 2 couplet 3 couplet 4 couplet
32 64 96 128
48 96 144 192
64 128 192 256
80 160 240 320
64 128 192 256
96 192 288 384
128 256 384 512
2.5 PB 5.1 PB 7.7 PB
10.2 PB
Replication
Targets for backup
applications
Supports data replication. Replication is automatic and appliances may function as both replication targets
and sources simultaneously with licensing only being required for any appliance acting as a target.
Replication of data can occur between devices within the same product family i.e. between HP StoreOnce
D2D and HP StoreOnce B6200s.
HP StoreOnce Catalyst is available to license, providing seamless control of data movement across the
organization and better utilization of servers, network bandwidth and the HP StoreOnce B6200 for
optimum backup performance.
HP StoreOnce Catalyst, Virtual Tape Library (VTL) and NAS
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 19
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Technical Specifications
Maximum aggregate performance by
configuration
1 Base couplet
2 Base couplet
3 Base couplet
4 Base couplet
1 Base couplet with StoreOnce Catalyst
2 Base couplet with StoreOnce Catalyst
3 Base couplet with StoreOnce Catalyst
4 Base couplet with StoreOnce Catalyst
* Assumes VTL target for backup and use of maximum upgrade kits to achieve maximum performance. Actual performance is
dependent upon configuration, data set type, compression levels, number of data streams, number of devices emulated and number
of concurrent tasks, such as housekeeping or replication.
To optimize the performance of a StoreOnce Backup System, Please refer to: "Best Practices for configuring HP StoreOnce B6200"
documentation:
http://bizsupport2.austin.hp.com/bc/docs/support/SupportManual/c03121413/c03121413.pdf
*
*
*
*
Up to 10 TB/hr
Up to 20 TB/hr
Up to 30 TB/hr
Up to 40 TB/hr
B6200 EJ022A with StoreOnce Catalyst
Licenses TC396AAE TC397AAE
Up to 25 TB/hr
Up to 50 TB/hr
Up to 75 TB/hr
Up to 100 TB/hr
B6200 EJ022A
2776 MB/s
5552 MB/s
8328 MB/s
11104 MB/s
7000 MB/s
14000 MB/s
21000 MB/s
28000 MB/s
Number of Virtual Tape
Libraries and NAS backup
targets (combined)
Maximum number of cartridges
emulated per Virtual Tape
Libraries
Maximum number of source
appliances per target appliance
(fan in)
Number of Virtual Tape Drives
Maximum Number of Cartridges
Emulated
Targets for backup
Tape Devices Emulated (check)
Interface
HP StoreOnce B6200 Backup
per node
48 96 384
48 96 384
192 384 1536
786432
N/A
N/A
N/A
per couplet (2x nodes)
16384
1572864 6291456
VTL, NAS and StoreOnce
Catalyst
HP LTO- 2 Ultrium Tape Drive /LTO-3 Ultrium Tape Drive/LTO-4
Ultrium Tape Drive/LTO-5 Ultrium Tape Drive in, MSL2024 Tape
Library, MSL4048 Tape Library, MSL8096 Tape Library, HP
StoreOnce D2D Backup system Generic Library with HP Ultrium
Generic tape drive
8x 1Gb Ethernet Ports per
couplet, plus
4x 10Gb Ethernet Ports per
per cluster (4x couplets)
VTL, NAS and StoreOnce
Catalyst
N/A
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 20
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP StoreOnce B6200 Backup
Technical Specifications
couplet, plus
4x 8Gb Fibre Channel Ports per
couplet
RAID Level
Power Consumption by component
HP StoreOnce B6200 48TB Backup System - EJ022A
HP StoreOnce B6200 24TB StoreOnce Upgrade Kit - EJ024A
HP StoreOnce B6200 48TB StoreOnce Upgrade Kit - EJ025A
HP StoreOnce B6000 Switch Assembly for StoreOnce B6200 Backup - EJ021A
HP StoreOnce B6000 Expansion Switch Assembly for StoreOnce B6200 Backup - EJ022A
RAID 6
Dimensions and Physical Characteristics
NOTE:
The B6200 MUST be factory integrated into the 42U extended depth rack. All dimensions shown below are for the Backup
Systems and capacity Upgrade kits not the 42U rack which is required to house them.
3312 W
912 W
912 W
396 W
748 W
The HP StoreOnce B6000 StoreOnce Backup Planning Guide helps you select the correct options for configuration. It will also help plan
for a successful and smooth installation of the B6200.
It can be downloaded from:
HP StoreOnce B6200 48TB
Backup EJ022A
HP StoreOnce B6200 24TB
Upgrade Kit - EJ024A
http://bizsupport1.austin.hp.com/bc/docs/support/SupportManual/c03116530/c03116530.pdf
Form Factor
Dimensions (server x2)
Weight (server x2)
Dimensions (expansion
shelf x2)
Weight (expansion shelf
x2)
Form Factor
Dimensions
Weight
8U
Physical Dimensions
(HxWxD)
Shipping
Out of Box Weight
Shipping Weight
Physical Dimensions
(HxWxD)
Shipping
Out of Box Weight
Shipping Weight
4U
Physical Dimensions
(HxWxD)
Shipping
Out of Box Weight
Shipping Weight
(HxWxD)
(HxWxD)
(HxWxD)
14.4 x 30 x 19.6 in (36 x 75 x 49cm)
41.6 x 54.4 x 41.6 in(104 x 136 x 104 cm)
328 lb (149Kg)
361 lb (164Kg)
7.2 x 24 x 19.6 in (18 x 60 x 49cm)
27.2 x 42.4 x 29.2 in (68x106x73cm)
141 lb (64 Kg)
154 lb (70 Kg)
7.2 x 19.6 x 24in (18 x 49 x 60cm)
27.2 x 42.4 x 29.2 in (68x106x73cm)
141 lb (64 Kg)
154 lb (70 Kg)
HP StoreOnce B6200 48TB
Upgrade Kit - EJ025A
Form Factor
DA - 14153 Worldwide — Version 9 — December 12, 2012
4U
Page 21
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Technical Specifications
Upgrade Kit - EJ025A
Environmental
Worldwide Product Safety
and EMC Approvals
NOTE:
For country specific compliance contact your local sales representative
Dimensions
Weight
Operating temperature
range
Shipping temperature
range
Operating Humidity
condensing)
Safety: Worldwide compliance to 60950-1
(non-
Physical Dimensions
(HxWxD)
Shipping
Out of Box Weight
Shipping Weight
50°F to 95°F (10°C to 35°C)
-40°F to 150°F (-40°C to 66°C)
15 to 80% Relative Humidity
(HxWxD)
HP StoreOnce B6200 Backup
7.2 x 19.6 x 24 in (18 x 49 x 60cm)
27.2 x 42.4 x 29.2 in (68x106x73cm)
141 lb (64 Kg)
154 lb (70 Kg)
© Copyright 2012 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
For hard drives, 1 GB = 1 billion bytes. Actual formatted capacity is less.
DA - 14153 Worldwide — Version 9 — December 12, 2012
Page 22
Loading...
