QuickSpecs
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Overview
The SN6000C 8Gb Fabric Switch (MDS 9148) is a high-performance, flexible, cost-effective platform providing high-density, line-rate 8Gbps ports for storage networking deployments in small, medium-sized, and large enterprise environments. The SN6000C switch
offers outstanding value by providing high-availability, security, and ease of use at a cost-effective price in a compact one-rack-unit
(1RU) form factor. With the flexibility to expand from 16 to 48 ports in 8-port increments, the SN6000C offers the densities required to
scale from an entry-level departmental switch to top-of-the-rack switch to edge connectivity in enterprise SANs. The SN6000C delivers
a non-blocking architecture, with all 48 1/2/4/8-Gbps ports operating at line rate concurrently.
The SN6000C supports the C-series Device Manager quick configuration wizard, which allows it to be deployed quickly and easily in
networks of any size. Powered by C-series MDS 9000 NX-OS Software, it includes advanced storage networking features and functions
and is compatible with C-series SN8000C (MDS 9500) and SN8500C (MDS 9700) Series Multilayer Directors and C-series MDS 9100 and
9200 Series Multilayer Fabric Switches, providing transparent, end-to-end service delivery in core-edge deployments.
HP SN6000C Fibre Channel Switch
Key Features and Benefits
High Performance with exceptional flexibility
Up to 768 Gbps of aggregate bandwidth in a 1 rack unit (RU)
Up to 48 autosensing Fibre channel ports capable of speeds of 1/2/4/8 Gbps
Pay as you grow flexibility with on-demand port activation licenses
Intelligent storage networking services at a cost effective price
No additional cost for storage networking features like virtual SANs (VSANs), Inter-VSAN Routing (IVR) readiness,
PortChannels, quality of service (QoS), and security
N-Port ID Virtualization (NPIV) technology to provide independent management for each virtual machine
N-Port Virtualization (NPV) and fabric-port (F-port) channeling features to enable scaling of SANs without reaching Fibre
Channel domain ID limits
FlexAttach feature enables transparent server deployment and movement without SAN reconfiguration
High Availability Platform
Designed for environments in which downtime is unacceptable
Non-disruptive software upgrades, dual hot swappable power supplies, and hot swappable fans
VSANs for fault isolation and PortChannels for Inter-Switch Link (ISL) resiliency
Simplified Management
Supports SAN plug and play capability
Built in storage network management
Reduced total cost of ownership
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 1
QuickSpecs
Product Highlights
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Configuration support
Industry leading 8-Gb
Performance Capability
Scalability
Cost Effective Intelligent
Storage networking
Please see the following Web site for configuration support at:
http://h18000.www1.hp.com/products/storageworks/san/documentation.html
The switch offers full non-blocking 8-Gbps Fibre Channel performance on 48 line-rate ports and an
aggregate bandwidth of 768 Gbps full duplex in a 1 Rack unit form factor.
The SN6000C switch comes in two preconfigured models of 16 or 32 ports. These models may be
upgraded onsite to enable additional ports by adding 8-port On-Demand Port Activation licenses for total
scalability of 48 ports.
The SN6000C switch comes standard with advanced features in a compact, extremely cost-effective
design that simplifies deployment and administration of small and medium-scale storage-area networks
(SANs) and as an edge switch in a larger enterprise.
N-Port ID Virtualization NPIV)
N-Port ID Virtualization (NPIV), a standard Fibre Channel protocol feature, individual virtual machines
assume a full identity on the SAN so that Fibre Channel services such as zoning, Quality of Service (QoS),
performance monitoring, and security can be provided to each virtual machine.
VSANs
:
:
VSAN, an industry standard for fabric virtualization capabilities, enables more efficient storage network
use by creating hardware-based isolated environments within a single physical SAN fabric or switch. Up to
32 VSANs are supported per switch. Each VSAN can be zoned as a typical SAN and maintains its own fabric
services and management domains for added scalability and resilience. VSANs allow the cost of SAN
infrastructure to be shared among more users, while helping ensure segregation of traffic and retaining
independent control of configuration on a VSAN-by-VSAN basis.
PortChannels
PortChannels allow users to aggregate up to 16 physical ISLs into a single logical bundle, providing
optimized bandwidth use across all links. The bundle can consist of any port from the switch, helping
ensure that the bundle remains active even in the event of a port failure.
N-Port Virtualization (NPV)
The number of Fibre Channel domain IDs in a Fibre Channel SAN environment is limited. N-Port
Virtualization (NPV) enables organization to scale there SANs without reaching these Fibre Channel domain
ID limits because and switch with NPV does not use a Fibre Channel domain ID. NPV aggregates locally
connected hosts into one or more uplinks to core switches in a pass through manner without using a Fibre
Channel domain ID.
FlexAttach
The C-series FlexAttach feature gives SN6000C switch customers the flexibility to add, move, or replace
servers easily without the need to reconfigure SAN switches or storage arrays. It provides this flexibility by
:
:
:
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 2
QuickSpecs
Product Highlights
virtualizing the SAN identity of a server, which enables a server to retain its SAN identity even if the server
is moved or replaced.
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
High Availability
Quality of Service (QoS)
The Quality of Service (QoS) feature allows traffic to be classified into four distinct levels for service
differentiation. QoS can be applied to help ensure that Fibre Channel data traffic for latency-sensitive
applications receives higher priority over throughput-intensive applications such as data warehousing.
F-port trunking and channeling
The F-port trunking feature enables multiple VSANs to be transported on the uplink from a SN6000C
switch operating in NPV mode to the core switch. This feature will allow the consolidation of uplinks ports
necessary for extending VSAN connectivity to the NP device.
The F-port channeling feature enables up to 16 physical uplinks between a SN6000C switch operating in
NPV mode and the core switch to be bundled into a PortChannel.
IVR
(MDS 9000 NX-OS Software Release 5.1(0) or later:
VSANs and Inter-VSAN routing (IVR) enable deployment of large-scale multisite and heterogeneous SAN
topologies. Integrated VSANs in port-level hardware allow any port in a system or in a fabric to be
partitioned into any VSAN. Integrated IVR provides line-rate routing between any of the ports in a system
or in a fabric without the need for external routing appliances.
The SN6000C switch is designed for environments in which downtime is unacceptable. It offers:
:
:
Non-disruptive software upgrades
Process monitoring and stateful process restart
Per-VSAN fabric services
Redundant, hot-swappable power supply and redundant, hot-swappable power supply and fan
trays
Hot-swappable C-series SFP and SFP+ optics
PortChannels for Inter-Switch Link (ISL) resiliency
F-port Channeling for resiliency on uplinks from a SN6000C switch operating in NPV mode
Online diagnostics
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 3
QuickSpecs
Product Highlights
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Simplified Storage
Management
Interoperability
Diagnostics
The SN6000C comes standard with three principal modes of management: the C-series MDS 9000 Family
CLI, the Quick Configuration Wizard, and the Cisco Data Center Network Manager (DCNM).
Command Line Interface (CLI)
The C-series MDS 9000 Family CLI is easy to learn and delivers broad management capabilities. The Cseries MDS 9000 Family CLI is an extremely efficient and direct interface designed to provide optimal
capabilities to administrators in enterprise environments.
Quick Configuration Wizard
The Quick Configuration Wizard helps eliminate management complexity and creates a readily available
SAN environment for small- and midsized-business (SMB) applications. The wizard allows server access to
storage to be set up quickly and easily in a single step using an intuitive GUI.
Offers compatibility with a broad range of HP servers and operating systems, as well as disk and tape
storage devices; see current compatibility matrix.
Embedded diagnostics
Network analysis
:
:
Software Components, Included
NX-OS
Cisco Data Center
Network Manager
SN6000C includes the Cisco MDS 9000 NX-OS Software operating system version 5.2(1) or higher with a
complete set of security features, Cisco Data Center Network Manager, a full suite of configuration,
maintenance and diagnostics tools. It also includes VSAN support, PortChannels, extended fabrics, per
VSAN-based access control, hardware-enforced zoning, Port Security and Host/Switch Authentication (DHCHAP), RADIUS and TACACS+ and Advanced Encryption Standard (AES) and non-disruptive firmware
upgrade capability.
Cisco Data Center Network Manager is a responsive, easy-to-use Java application that simplifies
management across multiple switches and fabrics. Cisco Data Center Network Manager enables
administrators to perform vital tasks such as topology discovery, fabric configuration and verification, LUN
security, monitoring, and fault resolution. All functions are available through a secure interface, which
enables remote management from any location. Cisco Data Center Network Manager may be used
independently or in conjunction with third-party management applications. Cisco provides an extensive
API for integration with third-party and user developed management tools.
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 4
QuickSpecs
Product Highlights
Software Components, Optional
8-Port Upgrade License
HP StoreFabric Data
Center Network Manager
Package
HP MDS 9100 Enterprise
Package License
The flexibility of the SN6000C switch is provided by the C-series SN6000C On-Demand Port Activation
license, which allows the addition of 8-Gbps ports.
The "Standard" Cisco Data Center Network Manager software that is included at no charge with the
SN6000C Switch provides basic switch configuration and troubleshooting capabilities. HP's C-series
StoreFabric Data Center Network Manager (DCNM) Package (for the SN6000C Fabric Switches) extends
Cisco Data Center Network Manager by providing historical performance data collection for network traffic
hot-spot analysis, centralized management services and advanced application integration.
HP's C-series MDS switches have a set of advanced traffic engineering and advanced security features that
are recommended for all Enterprise SANs. These features are bundled together in a management
application called the HP MDS 9100 Enterprise Package.
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 5
QuickSpecs
Service and Support and Warranty Information
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Warranty
Service and Support
Discover, plan, and design
(1-1-1) Hardware Warranty; 1-year parts; 1-year on-site (8x5, next business day response) and 1-year
labor.
NOTE:
The hardware warranty covers firmware and embedded non-saleable software. For extended
hardware installation information, click the link below:
www.hp.com/services/deployment
NOTE:
Certain restrictions and exclusions apply. Consult the Customer Support Center for details.
Hardware or Software product installation is not included in the warranty, but is available and highly
recommended.
Services to accelerate time to results
HP Storage Services bring you a rich portfolio of consulting and support services designed to add value to
our core storage products and solutions. We have the know-how and experience to put storage technology
to work for you. We work closely with you as your strategic partner, leveraging our full services portfolio
to make sure that everything works to optimize your enterprise.
Choose from services aligned to our storage product offerings and lifecycle. From mission-critical onsite
services to innovative web-based remote support, you choose the precise level of attention and support
your business demands.
Choose from a rich portfolio of services to make the most of HP StoreFabric Storage, so you can efficiently
and affordably consolidate, manage, and extract value from unstructured data.
Deploy and integrate
HP Services can help you discover needs and create a plan for simplifying the environment, reducing
risk, and maximizing your storage investments
HP Storage Efficiency Analysis -
their storage infrastructure and operating environment, highlighting recommendations for improvements.
The report provides extensive insight about the existing storage environment, opportunities for efficiency
gains, asset aging and replacement through interaction with key decision makers.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-6727ENW.pdf
HP Storage Impact Analysis (SIA):
engagement with executive summary presentation. The goal of this service is to help provide customers
guidance on storage related issues and develop remediation plans.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-1174ENW.pdf
HP Storage Modernization Service:
defines the customer's envisioned target storage environment based on a proven solution design
methodology. HP architects will quickly perform tool-assisted automatic discovery and facilitate a twoday strategy workshop with all key stakeholders involved in the storage infrastructure initiative.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-4620ENW.pdf
We can help you configure, set up, and efficiently use your HP SN8500C Director as well as help
migrate data, improve capacity utilization, and establish information management standards used
The HP Storage Efficiency Analysis provides customers with a view of
The HP Storage Impact Analysis service provides a 2-4 week discovery
The HP Storage Modernization service is a 4-6 week service that
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 6
QuickSpecs
Service and Support and Warranty Information
across backup, replication, and archiving needs.
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Operate and support
HP Enhanced Implementation Service for SANs -
implementation support for Fibre Channel, FCoE, FCIP, SAS, and iSCSI SAN connectivity components.
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-8527EN.pdf
HP Storage Data Migration Services -
assessment, planning, and design, completely customizable to your organization's storage area network
or network attached storage environment and using innovative software to help you migrate to HP
storage quickly and efficiently.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-0774ENW.pdf
HP Storage and Data Consultant Residency Service -
environment with HP resources who become your trusted advisor to provide answers that are right for
your storage and backup environment.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA3-9481ENW.pdf
HP Proactive Select -
of HP Proactive Select event and technical services, such as onsite firmware upgrades, health checks,
assessments, and education.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENW.pdf
Choose the right support to maximize uptime, free up your resources, and achieve improved value-as
you get the most out of the existing IT assets while accelerating time-to-revenue.
HP Proactive Care 24x7 -
technology with rapid access to Advanced Solution Center Specialists plus firmware and software
management and best practice advice.
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA3-8855ENW.pdf
A flexible way to purchase services to fit your environment with an extensive menu
Hardware and software support services designed specifically for your
End-to-end data migration service providing seamless discovery,
Select this service for complete design and
Strategic augmentation of your current
HP Proactive Care Personalized Support -
personalization of the Proactive Care support experience through the assignment of an Account Service
Manager (ASM) who provides IT best practice advice to help address IT issues and projects.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-3446ENW.pdf
HP Foundation Care 24x7 -
on resolving issues with hardware onsite response within four hours and software call back within two
hours after opening your case.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA4-0226ENW.pdf
HP Education Services -
designed to expand your skills and keep you up to speed with the latest storage and virtualization
technology from HP Storage.
http://education.hp.com/curr-storsan.htm
DA - 13638 Worldwide — Version 12 — April 7, 2014
HP Foundation Care 24x7 connects you to HP around the clock for assistance
Comprehensive training for new, as well as experienced, storage administrators
An option-if you have HP Proactive Care- to bring increased
Page 7
QuickSpecs
Service and Support and Warranty Information
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Optimized Care -
the highest levels of
performance and stability
through deployment and
proactive management
practices
Standard Care -
high level of uptime, along
with expert help to cut the
cost and complexity of
implementation and
support
Basic Care -
recommended support
For more information
Delivers
maintains
Minimum
Choose from three levels of operate and support care
HP Proactive Care 24x7-Plus, 20 credits per year
Additional options -
environment), an additional day of HP Personalized Support, and 10 additional HP Proactive Select credits
per year.
HP Proactive Care 24x7-Plus, 10 credits per year
Additional options -
environment), an additional day of HP Personalized Support, and 10 additional HP Proactive Select credits
per year.
HP Foundation Care 24x7
Additional options -
www.hp.com/services/storage
To learn more on HP Storage Services, please contact your HP sales representative or HP Authorized
Channel Partner
HP Proactive Care Personalized Support (once per Proactive Care support new
HP Proactive Care Personalized Support (once per Proactive Care support new
10 HP Proactive Select credits per year.
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order
configuration tools.
Customers purchasing from a commercial reseller can find HP Care Pack Services at
www.hp.com/go/lookuptool
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 8
QuickSpecs
Family Information
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Introduction
Date
Switch Type
Maximum ports
Number of
slots per
chassis
HP StoreFabric
SN8500C 8-slot
16Gb FC
Director
August 2013
Multilayer
Director
384 Fibre
Channel
Eight
HP SN8000C
13-Slot
Supervisor 2A
Fabric3
Director
May 2012 May 2011 May 2011
Multilayer
Director
528 Fibre
Channel, 44 IP
ports
Thirteen
SN8000C 9-Slot
Director w/
Dual
Supervisor 2A
Multilayer
Director
336 Fibre
Channel,
28 IP ports
Nine
SN8000C 6-Slot
Director
w/Dual
Supervisor 2A
Multilayer
Director
192 Fibre
Channel,
16 IP ports
Six
SN6000C 8Gb
Fabric Switch
June 2010
Multilayer
Fabric Switch
Up to 48 Fibre
Channel ports
N/A, Fixed FRU N/A, Fixed FRU
Cisco MDS 8Gb
Fabric Switch
for HP
BladeSystem c-
Class
November 2010 November 2007
Embedded
Fabric Switch
16 Internal, 8
auto-sensing
8/4/2 Gb Fibre
Channel ports
HP MDS 9222i
Multilayer
Fabric Switch
18 fixed autosensing 4/2/1
Gbps Fibre
Channel ports, 4
1Gb Ethernet
ports
Two, One fixed
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 9
QuickSpecs
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Configuration Information
The HP SN6000C 8Gb Fabric Switch comes preconfigured with 16 or 32 autosensing Fibre Channel ports capable of 8, 4, 2, and 1 Gps in
a compact 1RU form factor chassis. An On-Demand Port Activation license is available for "pay as you grow" expansion in 8-port
increments for up to 48 Fibre Channel ports. The port slots are empty and optical transceivers are required to utilize the ports. Short,
Medium and Long Range optical transceiver options (SFPs) are available and must be ordered separately.
Step 1 - Base Configuration
Select one:
Model
HP SN6000C 16-ports
Active Fabric Switch
HP SN6000C 32-ports
Active Fabric Switch
Model Description
Base 48-Port Fabric Switch with 16 8-Gbps active ports, Dual Power Supplies, Power
Cords (configurable by ship-to country) and Fans, VSANs, PortChannels, Cisco Data
Center Network Manager, firmware, accessory kit and documentation. (no SFPs
included)
Base 48-Port Fabric Switch with 32 8-Gbps active ports, Dual Power Supplies, Power
Cords (configurable by ship-to country) and Fans, VSANs, PortChannels, Cisco Data
Center Network Manager, firmware, accessory kit and documentation. (no SFPs
included)
Part Number
AW585A
AW586A
Step 2 - Optional Software
On Demand Port Activation License
HP SN6000C 8-port Upgrade LTU
Management Software
HP StoreFabric SN6000C Data Network Manager LTU
HP MDS 9100 Enterprise Package License -1 MDS 9100 Swt LTU
8 port upgrade license for SN6000C 16 Port Switch
(AW585A) and 32 Port Switch (AW586A)
Description
TA829A
TC364A
A7515A
Step 3 - Options
Select each required option with quantities specified:
8 Gb FC Transceivers
HP MDS 9000 8Gb FC SFP+ Short Range XCVR
NOTE:
Optional - Must be ordered separately.
HP MDS 9000 8Gb FC SFP+ Long Range XCVR
NOTE:
Optional - Must be ordered separately.
4 Gb FC Transceivers
HP MDS 9000 4Gb FC SFP, 4pk Shrt Range XCVR
NOTE:
Optional - Must be ordered separately.
HP MDS 9000 4Gb FC SFP, Lng Range XCVR
NOTE:
Optional - Must be ordered separately.
NOTE:
Each port on the SN6000C may be configured to accept Short, Medium or Long Wave SFP optical transceivers. However, when
ordering the SN6000C, active ports must be populated with above SFP optical transceivers only. (No substitutes allowed) Using other
transceivers may void product warranty.
Installation Services
For complete design and implementation of Fibre Channel, FCoE, FCIP, SAS, and iSCSI SAN connectivity components, select
Enhanced Implementation Service for SANs
DA - 13638 Worldwide — Version 12 — April 7, 2014
Quantity
1 min, 48 max
1 min, 48 max
Quantity
1 min, 12 max
1 min, 48 max
AJ906A
AJ907A
AE379A
AE380A
HP
Page 10
QuickSpecs
Configuration Information
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
For basic hardware installation, select the service noted below.
Product
AW585A
AW586A
Recommended Cables
HP OM3 LC-LC Optical Cables
HP LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 2.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable
HP LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable
HP PremierFlex OM4+ Fiber Optic Cables
HP Premier Flex MPO/MPO OM4 8f 10m Cbl
HP Premier Flex MPO/MPO OM4 12f 50m Cbl
HP Premier Flex LC/LC OM4 2f 1m Cbl
HP Premier Flex LC/LC OM4 2f 2m Cbl
HP Premier Flex LC/LC OM4 2f 5m Cbl
HP Premier Flex LC/LC OM4 2f 15m Cbl
HP Premier Flex LC/LC OM4 2f 30m Cbl
HP Premier Flex LC/LC OM4 2f 50m Cbl
Description
HP SN6000C 8Gb 16-port FC Switch
HP SN6000C 8GB 32-port FC Switch
NOTE:
1 per switch
Installation
2/16 FC switch Installation
2/16 FC switch Installation
HA113A#5FE
HA113A#5FE
AJ833A
AJ834A
AJ835A
AJ836A
AJ837A
AJ838A
AJ839A
QK729A
QK731A
QK732A
QK733A
QK734A
QK735A
QK736A
QK737A
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 11
QuickSpecs
Technical Specifications
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
Minimum software
requirements
Performance and port
configuration
Security
Compatibility
MDS 9000 NX-OS Software Release 5.2(1)
Port speed: 8-, 4-, 2-, and 1-Gbps autosensing with 8 Gbps of dedicated bandwidth per port
Buffer credits: Up to 128 for a group of 4 ports, with a default of 32 buffer credits per port and a
maximum of 125 buffer credits for a port
Ports per chassis: Up to 48 8-Gbps ports
Base configuration with 16 ports; additional configuration for 32 ports available.
Upgrade ports in 8-port increments from any configuration with the port activation license
PortChannel: Up to 16 ports in a PortChannel
VSANs
Zoning
Hardware-enforced zoning
Logical-unit-number (LUN) zoning and read-only zones
FC-SP for host-to-switch and switch-to-switch authentication
Port security
Management access
SSHv2
SNMPv3
IP ACLs
Fibre Channel protocols
FC-PH, Revision 4.3 (ANSI/INCITS 230-1994)
FC-PH, Amendment 1 (ANSI/INCITS 230-1994/AM1 1996)
FC-PH, Amendment 2 (ANSI/INCITS 230-1994/AM2-1999)
FC-PH-2, Revision 7.4 (ANSI/INCITS 297-1997)
FC-PH-3, Revision 9.4 (ANSI/INCITS 303-1998)
FC-PI, Revision 13 (ANSI/INCITS 352-2002)
FC-PI-2, Revision 10 (ANSI/INCITS 404-2006)
FC-PI-3, Revision 2.1 (BSR INCITS 460-200x)
FC-PI-4, Revision 8.0 (INCITS 450-2009)
FC-FS, Revision 1.9 (ANSI/INCITS 373-2003)
FC-FS-2, (BSR INCITS 424-200x)
FC-FS-3, Revision 0.9 (BSR INCITS PN-1861-D-200x)
FC-LS, Revision 1.62 (ANSI/INCITS 433-2007)
FC-AL, Revision 4.5 (ANSI/INCITS 272-1996)
FC-AL-2, Revision 7.0 (ANSI/INCITS 332-1999)
FC-AL-2, Amendment 1 (ANSI/INCITS 332-1999/AM1-2003)
FC-AL-2, Amendment 2 (ANSI/INCITS 332-1999/AM2-2006)
FC-SW-2, Revision 5.3 (ANSI/INCITS 355-2001)
FC-SW-3, Revision 6.6 (ANSI/INCITS 384-2004)
FC-SW-4, Revision 7.5 (ANSI/INCITS 418-2006)
FC-SW-5, (BSR INCITS 461-200x)
FC-GS, (ANSI INCITS 288-1999)
FC-GS-3, Revision 7.01 (ANSI/INCITS 348-2001)
FC-GS-4, Revision 7.91 (ANSI/INCITS 387-2004)
FC-GS-5, (ANSI INCITS 427-2007)
FC-GS-6, (BSR INCITS 463-200x)
FC-BB, Revision 4.7 (ANSI/INCITS 342-2001)
FC-BB-2, Revision 6.0 (ANSI/INCITS 372-2003)
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 12
QuickSpecs
Technical Specifications
Fabric Services
Advanced Services
Diagnostic and
Troubleshooting
Management
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
FC-BB-3, Revision 6.8 (ANSI/INCITS 414-2006)
FCP, Revision 12 (ANSI/INCITS 269-1996)
FCP-2, Revision 8 (ANSI/INCITS 350-2003)
FCP-3, Revision 4 (ANSI/INCITS 416-2006)
FCP-4, (BSR INCITS PN-1828-D-200x)
FC-SB-2, Revision 2.1 (ANSI/INCITS 349-2001)
FC-SB-3, Revision 1.6 (ANSI/INCITS 374-2003)
FC-VI, Revision 1.84 (ANSI/INCITS 357-2002)
FC-FLA, Revision 2.7 (INCITS TR-20-1998)
FC-PLDA, Revision 2.1 (INCITS TR-19-1998)
FC-Tape, Revision 1.17 (INCITS TR-24-1999)
FC-MI, Revision 1.92 (INCITS TR-30-2002)
FC-MI-2, Revision 2.6 (INCITS TR-39-2005)
FC-SP, Revision 1.6 (ANSI/INCITS 426-2007)
FC-DA, Revision 3.1 (INCITS TR-36-2004)
SNPing (ANSI INCITS 443-2008)
MIB-FA (INCITS/TR-32:2003 (R2008))
FAIS Revision 1
Extensive IETF-standards-based TCP/IP, SNMPv3, and Remote Monitoring (RMON) MIBs
Class of service: Classes 2, 3, and F
Fibre Channel standard port types: E, F, and FL
Fibre Channel enhanced port types: SD, and TE
Name server
Registered state change notification (RSCN)
Login services
Broadcast
In-order delivery
Name-server zoning
NPIV
VSANs
PortChannels
NPV mode
FlexAttach
F-port trunking and channeling
IVR (in Cisco MDS 9000 NX-OS Software Release 5.1(0) or later)
POST diagnostics
Online diagnostics
Internal loopbacks
SPAN
Fibre Channel traceroute
Fibre Channel ping
Fibre Channel debug
Cisco Fabric Analyzer
Syslog
Port-level statistics
Access methods
Out-of-band 10/100/1000 Ethernet port
EIA/TIA-232 serial console port
In-band Fibre Channel over IP (FCIP)
Access protocols
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 13
QuickSpecs
Technical Specifications
Management Applications
Availability
Serviceability
Environmental
Power and Cooling
Safety
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
CLI
SNMP
SMI-S
Security
RBAC using RADIUS or TACACS+ authentication, authorization, and accounting (AAA) functions
VSAN-based roles
SSHv2
SNMPv3
Zero-touch deployment with DHCP (in Cisco MDS 9000 NX-OS Software Release 5.1(0) or later)
C-series MDS 9000 Family CLI
Quick Configuration Wizard
C-series Data Center Network Manager and Device Manager
C-series StoreFabric Data Center Network Manager (optional; requires C-series StoreFabric Data
Center Network Manager license)
Nondisruptive software upgrades
Process monitoring and stateful process restart
Per-VSAN fabric services
Redundant, hot-swappable power supply and redundant, hot-swappable power supply and fan
trays
Hot-swappable SFP and SFP+ optics
PortChannels aggregating up to 16 ports
F-port Channeling
Online diagnostics
Configuration file management
Call Home
Port beaconing
System LEDs
SNMP traps for alerts
Physical dimensions (H x W x D) of 1RU: 1.72 x 17.16 x 18.89 in. (4.47 x 43.59 x 47.98 cm)
Weight of switch with dual power supplies: 22.2 lb (10 kg)
Ambient operating temperature: 32 to 104°F (0 to 40°C)
Ambient nonoperating temperature: -40 to 158°F (-40 to 70°C)
Humidity (RH), ambient (noncondensing) operating: 10 to 90%
Humidity (RH), ambient (noncondensing) nonoperating and storage: 5 to 95%
Operating altitude: -197 to 6500 ft (-60 to 2000 m)
Power supplies (300W AC) (maximum of 2 per switch)
AC Input: 100 to 240 VAC nominal (+/-10% for full range)
Frequency: 50 to 60 Hz nominal (+/-3 Hz for full range)
Maximum power consumption:
With 4-Gbps optics (48 ports fully populated): 99W with 0.89A at 110 VAC and 0.45A at 220
VAC
With 8-Gbps optics (48 ports fully populated): 101W with 0.90A at 110 VAC and 0.46A at 220
VAC
Airflow: Rear to front (toward ports)
UL 60950 -1
CAN/CSA-C22.2 No. 60950 -1
EN 60950 -1
IEC 60950 -1
AS/NZS 60950
IEC 60825
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 14
QuickSpecs
Technical Specifications
EMC
HP SN6000C 8Gb Fibre Channel Switch (MDS9148)
EN 60825
21 CFR 1040
FCC Part 15 (CFR 47) Class A
ICES-003 Class A
EN55022 Class A
CISPR22 Class A
AS/NZS CISPR22 Class A
VCCI Class A
EN55024
KN24
EN50082-1
EN61000-3-2
EN61000-3-3
EN61000-6-1
CISPR24
ETSI
ETS 300 019 Storage Class 1.1
ETS 300 019 Transportation Class 2.3
ETSI 300 019 Stationary Use Class 3.1
© Copyright 2014 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and
services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial
errors or omissions contained herein.
DA - 13638 Worldwide — Version 12 — April 7, 2014
Page 15
Loading...
