QuickSpecs
HP MPX200 Multifunction Router
Overview
10GbE-1GbE blade shown in this picture
1.
Two 10GbE (10GbE blade) or two 1GbE ports (1GbE blade)
2.
Management ports, serial, 1GbE, and USB (not used)
3.
Two 8Gb/s Fibre Channel (FC) ports
As mid-range and enterprise businesses grow and deploy more physical/virtual servers and storage arrays, the amount of information
required to manage, share, and protect IT resources continues to grow. The HP MPX200 Multifunction Router provides multi-protocol
flexibility and unified SAN-based block storage which includes 10GbE and 1GbE iSCSI target support ( 3PAR StoreServ 10000/7000, TClass/F-Class, P6000/EVA, XP24000/20000), 8Gb FC connectivity, and FCoE target support (3PAR StoreServ 10000/7000, T-Class/FClass, , P6000/EVA) in one integrated solution. Multiprotocol connectivity is available for multiple 3PAR StoreServ 10000/7000, TClass/F-Class, P6000/EVA, and P9000/XP storage systems, without incurring additional software management costs. The MPX200
includes 1GbE Fibre Channel over IP (FCIP) for remote replication with 3PAR StoreServ Storage Remote Copy and P6000/EVA/
P9000/XP Continuous Access. Adding FCIP support is easy with an optional license. In addition, FCoE for converged infrastructure trials
and beta testing or live deployment is enabled on MPX200, at no charge. MPX200 delivers high-speed, up to 8TB/Hr per chassis,
online/offline heterogeneous data migration for 3PAR StoreServ 10000/7000, T-Class/F-Class Storage, P6000/EVA, P9000/XP, SVSP
and more. The MPX200 Data Migration License provides a powerful tool for migrating data from old to new arrays, from other vendors
to HP. The Data Migration capability also provides the capability to migrate normal provisioned (thick) LUNs to thin provisioned storage
saving space while reducing storage costs. The MPX200 enables modular multi-protocol SAN designs with increased scalability,
stability, ROI and simpler to manage, secure storage solutions for virtualized server environments. The MPX200 scales from SMB to
enterprise-class providing high-availability with dual hot-pluggable power supplies, fans, non-disruptive code load and dual router
blades for no single point of failure. The MPX200 1U design allows for integration the same rack with a P6000/EVA storage system and
other HP or non-HP arrays. IT environments can connect up to 4 3PAR StoreServ 10000/7000, T-Class/F-Class, P6000/EVA, or
XP24000/20000 storage systems to a single MPX200 for iSCSI, reducing the complexity and cost of iSCSI connectivity. Modular multiprotocol SAN designs using the MPX200 increase scalability, stability, and ROI of your storage infrastructure.
4.
Two 1GbE ports
5.
Optional Licensing: FCIP and Data Migration
The MPX200 Multifunction Router enables organizations to integrate and consolidate low-cost Ethernet connected servers with 3PAR
StoreServ 10000/7000, T-Class/F-Class, P6000/EVA, and XP24000/20000 arrays by bridging the iSCSI protocol to the Fibre Channel
protocol. This capability allows iSCSI servers to leverage shared SAN resources, improving asset utilization and application deployment
while reducing costs. P6000/EVA with multi-protocol support and unique integration with HP P6000 Command View provides network
storage at reduced infrastructure costs. Small and medium businesses now have a lower entry point to take advantage of SAN
benefits. Large enterprises can deploy multi-protocol SANs easier and cost effectively in departments and remote offices.
New RoHS compliant HP Multifunction Router
NOTE: Restriction of Hazardous Substances Directive or RoHS is a directive adopted by the European Union that restricts the use of
certain hazardous materials in the manufacture of various types of electronic and electrical equipment. The ROHS compliant products
with new part numbers listed in this document are functionally equivalent to the corresponding products with old part numbers and are
fully interchangeable.
Key Benefits:
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 1
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP MPX200 Multifunction Router
Overview
Delivering SAN-like benefits over the Ethernet IP network, the HP MPX200 Multifunction Router enables access to block storage
across up to 4 3PAR StoreServ 10000/7000, T-Class/F-Class, P6000/EVA, or XP24000/20000 storage systems from an Ethernet
IP network.
Provides IT with a flexible and cost effective way to connect stranded servers to existing Fibre Channel storage, increasing return
on investment.
Enterprise-class high availability design for no single point of failure featuring non-disruptive code load, dual hot-pluggable
power supplies, fans and router blades.
Modular software and hardware design with easy licensing makes it easy to upgrade and enable additional protocols or add
more ports when needed.
Unmatched performance: 8 Gb/s Fibre Channel, 1 GbE and 10 GbE iSCSI/ FCoE ports deliver best in class performance in MB/s and
IOPs.
FCoE for converged infrastructure and connectivity support for legacy Fibre Channel SANs
Advanced installation and configuration wizards allow set up in less than 25 minutes.
Power efficient: typically dissipates 200W for a dual blade configuration.
Extend access to FC SANs across Ethernet networks with the virtues of a FC SAN including:
Consolidated storage
Improved disk utilization
Improved IT efficiency
FCIP for SAN over WAN: The MPX200 includes Fibre Channel over IP (FCIP) functionality enabling IT to implement low cost remote
data replication over IP networks for 3PAR StoreServ 10000/7000, T-Class/F-Class Remote Copy and P6000/EVA, P9000/XP
Continuous Access. IT can deploy MPX200 to provide iSCSI and FCIP connectivity simultaneously with an optional license
Data Migration: Highly available and high speed block-based data migration between heterogeneous storage systems (online
and offline, FC and iSCSI) that is easy to manage and saves time with low risk data migration with optional license
Key iSCSI/FCoE Features
3PAR StoreServ 10000/7000, T-Class/F-Class Storage, 1 GbE and 10 GbE iSCSI/FCoE support
XP24000/20000, 1GbE and 10 GbE iSCSI support
P6000/EVA, 1GbE and 10 GbE iSCSI/FCoE support
Provides four Ethernet and two Fibre Channel ports per MPX200 blade
Increases the flexibility of 3PAR StoreServ 10000/7000, T-Class/F-Class , P6000/EVA, and XP24000/20000 storage for
integrated iSCSI support
Delivers the benefits of SAN storage at a significant discount to FC SAN storage
Supports Fabric Attach and Direct Connect (iSCSI/FCoE configurations) attachment to the 3PAR StoreServ 10000/7000, TClass/F-Class , P6000/EVA, and XP24000/20000
Concurrent FC and IP traffic is managed with high throughput enabling access for 300-600 iSCSI servers and 4096 LUNS per
MPX200 chassis
Unique and full integration with P6000/EVA and MPX200 management with Command View EVA
iSCSI ready for the following operating systems:
Microsoft Windows, Hyper-V
VMware
Linux Red Hat
Linux SUSE
Oracle VM Server
Apple Mac OS X (via iSCSI Initiator from ATTO Technology)
Sun Solaris
NOTES:
StoreServ 10000/7000, T-Class/F-Class Storagesupported for iSCSI with Citrix XEN, Microsoft Windows, Oracle
VM Server
Red Hat/SUSE Linux and Sun Solaris . XP arrays supported for iSCSI with Microsoft Windows and Red Hat/SUSE Linux. See
HP SPOCK for most current configurations.
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 2
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP MPX200 Multifunction Router
Overview
Supports High Availability Multi-path Options for Linux, Microsoft Windows, Sun Solaris, and VMware.
Fibre Channel over IP (FCIP for SAN over WAN connectivity) Optional License
Supports 3PAR StoreServ Remote Copy
Supports FCIP for SAN over WAN remote data replication using HP Continuous Access P6000 andP9000/XP software.
1GbE FCIP routes. Note: For 10GbE blades, only 1GbE ports can be configured for FCIP routes
Up to 4 FCIP Routes per MPX200 chassis.
High Performance FCIP SAN Extension
Software compression to maximize IP link utilization
Throttle bandwidth on FCIP Routes.
Consolidate iSCSI and SAN extension capabilities into single chassis.
Save 50% on cables, SFP's and rack space with only one piece of hardware to manage
Ability to connect to an HP IP Distance Gateway remotely for lower overall cost of the solution.
FCIP support for 3PAR StoreServ 10000/7000, T-Class/F-Class , P6000/EVA, P9000/XP
Managed using the MPX200 CLI
FCIP diagnostics feature to monitor WAN link quality and throughput
Heterogeneous Data Migration Optional License
Easy to use data migration GUI with intuitive wizards to simplify use.
SAN based, block level, HA and high performance data migration platform.
Supports online* and offline heterogeneous data migration at very high-speeds, up to 8TB/Hr.
Supports data migration between two data centers via FCIP or native IP.
Remote online/offline data migration for support between two data centers
Migrates normal provisioned storage to thin provisioned storage.
SVSP data migration to another HP array including 3PAR StoreServ 10000/7000, T-Class/F-Class , P6000/EVA, or P9000/XP
P63x0/P65x0/EVA destination or source array support.
Data scrubbing capability also supported.
No downtime required to plan & configure, migrations reduce implementation time and saves money.
Application performance preservation: Array bandwidth throttling capability.
CLI-based tool for powerful scripted use.
Destination Arrays: P63x0/P65x0/EVA6400/8400/4400/4000/4100/6000/6100/8000/8100 models, XP10000/12000, XP
20000/24000, P9500, HP 3PAR StoreServ 10000/7000 Storage, 3PAR F-Class/T-Class on FC, P4000(online/offline Fibre Channel
to iSCSI and iSCSI to iSCSI). P2000 G3 FC.
Source Arrays: HP P63x0/P65x0/ EVA6400/8400/4400/4000/4100/6000/6100/8000/8100/5000/3000, MSA1000/1500/2000 ;
XP 10000/12000, XP20000/24000, P9500,3PAR S-Class, and SVSP, IBM - DS3000, DS4000, DS5000, D6000, D8000 Series, XIV,
nlStorwize V7000; EMC CX Series, AX Series, Symmetrix DMX, VMAX SE, VNX5500; Fujitsu ETERNUS DX400, DX440 S2, DX8400.
HDS - AMS Family, WMS Family, USP, VSP families, Lightning 99xx V series, Thunder 95xx V series,TagmaStore Network
StorageController model NSC55; NetApp FAS family (FC and iSCSI), Dell EquiLogic (iSCSI). Compellent Series 30/40. NEC DSeries. Xiotech Emprise 5000, Mag3D 4000.
MPX200 heterogeneous data migration services are available through HP Services Storage and Data Migration Service, or data
migration licenses can be purchased from HP or an authorized HP Partner to perform customer initiated data migration.
NOTEs:
*Online data migration means a customer will not experience any downtime before and during the time data migration takes
place between an older and newer storage system. A reboot is required to configure access to the new storage system.
*Please check HP SPOCK for all current support, operating system, multipathing support matrix.
*Data Scrubbing licenses available from Qlogic
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 3
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP MPX200 Multifunction Router
Overview
What's new
New RoHS compliant HP Multifunction Router
NOTE:
Restriction of Hazardous Substances Directive or RoHS is a directive adopted by the European Union that restricts the use of
certain hazardous materials in the manufacture of various types of electronic and electrical equipment. The ROHS compliant products
with new part numbers listed in this document are functionally equivalent to the corresponding products with old part numbers and
are fully interchangeable.
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 4
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Models
HP MPX200 Multifunction
Router
Hardware SKU's and Enablement Options
HP MPX200 Multifunction Router 1 GbE Base Chassis
Includes:
HP MPX200 Multifunction Router 1 GbE Upgrade Blade
Includes:
For multi-path (redundant blade for high availability) order both part numbers. The
second hardware blade installs into the chassis that is included with AP771B or AP773B.
NOTE:
option type (1 GbE or 10GbE - 1GbE) in a common chassis to ensure balanced
performance in a redundant configuration
HP MPX200 Multifunction Router 10GbE - 1 GbE Base Chassis
Includes:
HP MPX200 Multifunction Router
AP771B
(1) chassis
(1) 1 GbE blade with (4) 1 GbE Ports and (2) 8Gb/s Fibre Channel Ports
rail kit
accessory kit
documentation
Includes redundant power supplies.
AP772B
(1) 1 GbE blade with (4) 1 GbE Ports and (2) 8Gb/s Fibre Channel Ports
accessory kit
documentation
When configured for iSCSI bridging, HP recommends use of the same blade
AP773B
(1) chassis
(1) 10GbE - 1 GbE blade with (2) 10 GbE Ports , (2) 1 GbE Ports and (2) 8Gb/s Fibre
Channel Ports
rail kit
accessory kit
documentation
Includes redundant power supplies.
NOTE:
The name 10GbE -1 GbE denotes that the 10 GbE Blade includes (2) 10GbE ports
and (2) 1 GbE ports
HP MPX200 Multifunction Router 10GbE - 1 GbE Upgrade Blade Includes:
(1) 10GbE - 1 GbE blade with (2) 10 GbE Ports , (2) 1 GbE Ports and (2) 8Gb/s Fibre
Channel Ports
accessory kit
documentation
For multi-path (redundant blade for high availability) order both part numbers. The
second hardware blade installs into the chassis that is included with AP773B or AP771B.
NOTE:
HP recommends use of the same blade option type (1 GbE or 10GbE - 1GbE) in a
common chassis to ensure balanced performance in a redundant configuration.
AP774B
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 5
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Models
HP MPX200 Half Chassis or single blade FCIP License
Includes:
HP MPX200 Full Chassis or dual blades FCIP License
includes:
NOTE:
TA767A.
NOTE:
second blade, a second half-chassis license is required.
Data Migration Software SKU's
HP MPX200 1TB Full Chassis Data Migration License
Includes:
HP MPX200 Multifunction Router
TA766A
License to enable FCIP functionality in one out of two bays (slots) in a MPX200
Chassis
TA767A
License to enable FCIP functionality for both bays (slots) in a MPX200 Chassis
For multi-path (redundant blade for high availability) order full chassis license
If you install a single blade and a half-chassis license initially, and then install a
TA762A
License to migrate 1 TB of data using a MPX200 Chassis
1 License Entitlement Certificate
1 License Key Request Form
5GB of data migration is complementary; this is useful for DM testing,
demos, etc, without using capacity from acquired licenses
Includes one year of HP software support 9x5 (software technical support and
software product and documentation updates)
NOTE:
To add additional 1TB licenses order as many 1TB TA762A licenses as needed.
HP MPX200 5TB Full Chassis Data Migration License
Includes:
License to migrate 5 TB of data using a MPX200 Chassis
1 License Entitlement Certificate
1 License Key Request Form
Includes one year of HP software support 9x5 (software technical support and
software product and documentation updates)
NOTE:
To add additional 5B licenses order as many 5TB TA763A licenses as needed.
HP MPX200 Full Chassis 1 Array Data Migration License
Includes:
TA763A
TA764A
License to migrate data from or to a single array using a MPX200 Chassis
1 License Entitlement Certificate
1 License Key Request Form
Includes one year of HP software support 9x5 (software technical support and
DA - 13338 Worldwide — Version 22 — May 9, 2014
Page 6
Loading...
