QuickSpecs
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Overview
The HP 4400 Scalable NAS File Services offers scalable file serving performance for medium-sized customers that cannot afford any downtime for their business-critical applications. The HP 4400 Scalable NAS File Services is a fully factory configured storage solution that includes an HP Enterprise Virtual Array 4400 (EVA4400) with dual array controllers and up to 12TB of storage standard, two high performance file serving nodes, redundant Fibre Channel switches, management and replication software, and support for Windows or Linux. The HP 4400 Scalable NAS File Services does not have a single point of failure. It allows customers to transparently increase application throughput far in excess of traditional NAS products and easily grow storage capacity online without service disruption. The HP 4400 Scalable NAS File Services offers great total cost of ownership with a low initial purchase price and a shared data architecture that yields lower management expenses from a single shared pool of file serving nodes and storage.
At the heart of the HP 4400 Scalable NAS File Services is a truly symmetrical cluster file system, with high availability services and cluster storage management services, which allow file server nodes and storage to be added to linearly scale file serving throughput performance or storage capacity. The HP 4400 Scalable NAS File Services integrates various file serving protocols including Network File System (NFS) functionality, Common Internet File System (CIFS) or SAN-Direct I/O protocol. The product can aggregate up to 16 Windows or Linux file server nodes for high-performance, fault-tolerant file serving with a EVA4400 storage.
The EVA4400, used by the HP 4400 Scalable NAS File Services, delivers all the business benefits of virtualization such as ease of management, superior capacity utilization, and self-tuning performance that have made the EVA product family one of best selling arrays in its class. The EVA4400 provides broad operating system support and is built on the EVA4400/6400/8400 architecture with dual-redundant design and offering 99.999% availability. Plus, it supports the robust local and remote replication capabilities of Business Copy and Continuous Access EVA allowing 4400 Scalable NAS File Services customers to configure for disaster tolerance and the ability to easily keep applications on-line during backup and restore.
HP offers a full spectrum of complimentary HP hardware, software product, solutions and HP services. In addition, the HP 4400 Scalable NAS File Services warranty offering -provides the base level of service to which you can add appropriate service option. HP Services provide additional offerings up to Critical Service, the support for mission critical environments.
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 1
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Product Highlights
Maximum number of File Server nodes
Maximum number of File Server nodes
Maximum number of File Server nodesMaximum number of File Server nodes High Availability Type
High Availability Type
High Availability TypeHigh Availability Type File System Size (max)
File System Size (max)
File System Size (max)File System Size (max) Maximum number of File Systems
Maximum number of File Systems
Maximum number of File SystemsMaximum number of File Systems File Protocol Support
File Protocol Support
File Protocol SupportFile Protocol Support Number of File Server nodes standard
Number of File Server nodes standard
Number of File Server nodes standardNumber of File Server nodes standard File Server Operating Systems
File Server Operating Systems
File Server Operating SystemsFile Server Operating Systems
Application Environment
Application Environment
Application EnvironmentApplication Environment Local Data Replication - HP Business Copy EVA
Local Data Replication - HP Business Copy EVA
Local Data Replication - HP Business Copy EVALocal Data Replication - HP Business Copy EVA File Based Replication
File Based Replication
File Based ReplicationFile Based Replication Remote Data Replication - HP Continuous Access EVA
Remote Data Replication - HP Continuous Access EVA
Remote Data Replication - HP Continuous Access EVARemote Data Replication - HP Continuous Access EVA Easy array management and configuration - HP Command View
Easy array management and configuration - HP Command View
Easy array management and configuration - HP Command ViewEasy array management and configuration - HP Command View EVA
EVA
EVAEVA Application block and file storage
Application block and file storage
Application block and file storageApplication block and file storage RAID supported
RAID supported
RAID supportedRAID supported Number of array controllers
Number of array controllers
Number of array controllersNumber of array controllers Cache (per controller pair)
Cache (per controller pair)
Cache (per controller pair)Cache (per controller pair) Block Host Connectivity
Block Host Connectivity
Block Host ConnectivityBlock Host Connectivity Switched drive shelves
Switched drive shelves
Switched drive shelvesSwitched drive shelves Drives per enclosure
Drives per enclosure
Drives per enclosureDrives per enclosure Drive types (mixed in enclosure)
Drive types (mixed in enclosure)
Drive types (mixed in enclosure)Drive types (mixed in enclosure)
Host Ports
Host Ports
Host PortsHost Ports
Supported disks, min-max
Supported disks, min-max
Supported disks, min-maxSupported disks, min-max Capacity
Capacity
CapacityCapacity Drive capacities and speeds
Drive capacities and speeds
Drive capacities and speedsDrive capacities and speeds
Array controller Battery Backup for Cache
Array controller Battery Backup for Cache
Array controller Battery Backup for CacheArray controller Battery Backup for Cache Drive Interface
Drive Interface
Drive InterfaceDrive Interface
Redundant Blowers
Redundant Blowers
Redundant BlowersRedundant Blowers Environmental Monitoring Unit
Environmental Monitoring Unit
Environmental Monitoring UnitEnvironmental Monitoring Unit Regulatory approvals
Regulatory approvals
Regulatory approvalsRegulatory approvals Management Software
Management Software
Management SoftwareManagement Software
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
16
Fully Symmetrical Active/Active
128 TB (Linux); 32 TB (Windows)
512 (Linux); 256 (Windows)
NFS, CIFS, HTTP, FTP, HTTPS
2, X5500 Network Storage Gateway servers
Windows Storage Server x64 2003 R2 or SUSE Linux v10
Enterprise Edition
Oracle, SAP, Microsoft Exchange, SQL
Yes
Yes, Linux version
Yes
up to 16 EVAs, per instance of Command View
Yes
Vraid1, Vraid 0+1, Vraid5, Vraid6
2
4GB
Fibre Channel, Direct Connect, iSCSI
1 to 8
12
High Performance Fibre Channel and Fibre Attached Technology
Adapted (FATA)
4 or 2 embedded FC switches with ten 8Gb/s FC SAN ports per
controller
12 to 96
1 to 96TB
72GB SSD 400 GB 10K rpm 450 GB 10K rpm 600 GB 10K rpm 146 GB 15K rpm 300 GB 15K rpm 450 GB 15K rpm
1TB FATA
Up to 96 hours
Two 4 Gb/s FC-AL ports per controller in redundant pairs, two
paths to each dual ported HDD
Yes
Yes. Monitors Power and Temperature
UL, CSA, TUV, FCC, CE MARK, CTICK, BSMI, VCCI
Scalable NAS File Serving Software and Command View EVA
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 2
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Product Highlights
Scalability
Scalability
ScalabilityScalability
High Availability
High Availability
High AvailabilityHigh Availability
Data Integrity
Data Integrity
Data IntegrityData Integrity
Performance
Performance
PerformancePerformance
Industry standards
Industry standards
Industry standardsIndustry standards
Flexibility
Flexibility
FlexibilityFlexibility
Manageability
Manageability
ManageabilityManageability
Lower Cost
Lower Cost
Lower CostLower Cost
Scale from 2 to 16 nodes with a linear increase in file serving performance and throughput. Depending on number of HDDs and application workload Support for 128 TB per file system for Linux and 32 TB per file system for Windows. The Linux version provides scalable NFS file serving and transparent failover for NFS clients with no need to remount in the event of one or more node failures. This feature is unique in the industry. The Linux version also supports CIFS file serving in a non scalable mode via Samba. The Windows version provides scalable CIFS file serving and transparent failover for CIFS clients with no need to reconnect in the event of one or more node failures. The Windows version also supports NFS file serving in a non scalable mode via Hummingbird NFS Maestro™
Fully symmetrical file system architecture means that all nodes see the same file system and that means no hot spots or bottlenecks. Hardware node failures are detected and failed over to all remaining nodes in as little as 5 seconds.
99.999 continuous availability
Complete session state, data and cache coherency is maintained among all nodes in the cluster. Both the Windows and Linux versions support scalable SAN-Direct I/O.
The performance of each node can provides up to 170 MB/second of sequential write throughput; approximately 190 MB/second sequential read throughput regardless of the base OS selected.
NOTE:
NOTE:
NOTE:NOTE: system.
SUSE Linux v10 Enterprise edition is the supported Linux File Server node OS versions. Windows Storage Server x64 2003 R2 is the supported Windows File Server node OS version.
Though the HP 4400 Scalable NAS File Services comes standard with an EVA4400 array storage system, it can also use any HP of SAN storage product including MSA, EVA and XP storage arrays. Utilize existing data center tools and solutions for backup, management and anti-virus protection that support the OS you have selected.
The HP 4400 Scalable NAS File Services includes pre-loaded and pre-configured file serving and array management software. Perform rolling upgrades of individual file server nodes by removing nodes from the cluster and then re-inserting them into the cluster. This can be done without any disruption to clients or concern about data integrity with the failover over capabilities that are part of the architecture.
Purchase the file serving needs for today confident that you can add additional file serving throughout put and performance as your needs grow. There is no need for a "forklift upgrade" in the future. By building the solution with industry standard components flexibility can be maintained in the infrastructure - no need to buy proprietary hardware and software. Integration in the data center is straight forward as there no need to specialized training to learn about custom hardware and proprietary software.
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Overall file serving throughput is dependent on the number of HDDs configured in the
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 3
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Product Highlights
Integrated File and Block
Integrated File and Block
Integrated File and BlockIntegrated File and Block storage services
storage services
storage servicesstorage services
Designed for No-Single-
Designed for No-Single-
Designed for No-Single-Designed for No-Single­Point-of-Failure
Point-of-Failure
Point-of-FailurePoint-of-Failure
The HP 4400 Scalable NAS File Services supports both file and block storage access. For host block storage access the HP 4400 Scalable NAS File Services provides support for industry-leading Operating System platforms including: HP-UX, HP OpenVMS, Windows 2008, Windows 2003 Professional, Windows 2003 Standard/Enterprise (32/64-bit) and Extended (32/64-bit), /DataCenter (64-bit), Sun Solaris, Linux, IBM AIX, Novell NetWare, VMware and Apple Mac OS X.
NOTE:
NOTE:
See the EVA Family Operating System, Cluster and High Availability Compatibility matrix for
NOTE:NOTE: Operating System version details.
The HP 4400 Scalable NAS File Services redundant architecture is designed to eliminate single-points-of­failure.
Each EVA4400 Dual array controller has ten FC host ports per controller; twenty per controller pair and two device ports per controller, four per controller pair.
Each EVA4400 controller pair interfaces with the M6412 drive enclosures. With two device ports per controller and dual FC I/O modules per drive enclosure, each controller has two connections to each FC drive A and B port. So each controller has a redundant path to each drive.
Each X5500 Network Storage Gateway node has a dual port HBA. Each HP 4400 Scalable NAS File Services system includes dual 10 port enabled FC switches. With two FC ports per HBA and two FC host ports per array controller, each node and array controller connects to each FC switch. So each node has a redundant path to each array controller and each drive within the array.
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
On the EVA4400, each port connects to one FC I/O module on a drive enclosure. Up to eight drive enclosures can be connected in a FC loop arrangement with a controller pair and connect to one port of up to 96 drives. With the two FC ports per controller, each controller can connect to both ports on up to 96 disk drives for redundant paths to all 96 drives.
The EVA4400 controller also has dual redundant hot plug power supplies and dual redundant hot plug blowers. Each controller has hot plug cache batteries to maintain cache contents for up to 96 hours in case of a total power failure.
The M6412 FC drive enclosure has dual redundant hot plug FC I/O modules that allow the controllers to distribute I/Os between the two modules and provides redundant paths should either FC I/O module become unavailable. The enclosure also has dual redundant hot plug power supplies and dual hot plug blowers. Environmental Monitoring Unit (EMU) functionality is built into the I/O module in the enclosure and monitors and reports the condition of the power supplies and fans.
The FC and FATA disk drives have dual FC ports which can be redundantly accessed by each controller. The drives are hot plug. Drives can be configured, using redundant Vraid1 or Vraid5 protection, so that a drive failure will not cause loss of data. Optional virtual sparing can be configured so that a drive failure will trigger an automatic rebuild of the Vraid1 or Vraid5 protection using the virtual spare.
All EVAs have dual redundant power distribution. Two independent power cords distribute power through two Power Distribution Units (PDUs) to each side of the EVA cabinets and to each power supply of the controllers and to each power supply of the drive enclosures Each cabinet power cord can be connected to independent power sources. For maximum availability, a customer should provide redundant power from independent power circuit breakers, independent power lines from the power company and even independent power companies.
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 4
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Product Highlights
Installation and Startup
Installation and Startup
Installation and StartupInstallation and Startup
The HP 4400 Scalable NAS File Services includes Installation and Startup (I&S). Though the HP 4400 Scalable NAS File Services is completely pre-configured at the factory, I&S service is used to adapt the HP 4400 Scalable NAS File Services the customer specific IP infrastructure and to provide general product training.
However for more complex environments additional Installation & Start-up services are recommended or may be required. HP recommends the purchase of the following Installation & Startup services when configuring or using:
Continuous Access configurations*. Purchase the HP Data Replication Solution Service ­Continuous Access EVA. HP's Remote Support Pack (RSP) for remote connectivity to HP. Purchase the HP Remote Connectivity Installation & Start-up service.
* In Americas the Replication Workload Profiler (RWP) process is also required.
NOTE:
NOTE:
Customers who have completed the necessary training or who have gained the necessary
NOTE:NOTE: experience with these environments may decide to not purchase the recommended Installation and Startup service.
HP requires the purchase of Installation & Startup services when using:
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Remote Replication
Remote Replication
Remote ReplicationRemote Replication Solutions
Solutions
SolutionsSolutions (Software options)
Storage Essentials. Purchase the Storage Essentials Solution Service.
A comprehensive list of Installation & Start-up services can be found at:
HP Continuous Access provides disaster tolerant replication across a Fibre Channel SAN. Continuous Access EVA performs real-time replication between the HP 4400 Scalable NAS File Services systems. Continuous Access EVA provides the highest level of FC SAN data protection to customers in order to meet disaster tolerant business continuity implementation goals. For additional information about Continuous Access EVA visit:
The Linux version of the HP 4400 Scalable NAS includes a file-based replication feature that enables asynchrous replication between HP 4400 Scalable NAS system.
HP Disaster Tolerant Solution for mySAP Business Suite on EVA offers a business continuance solution for SAP environments, where data integrity and value added functionality are high priorities. Best practices for implementing remote mirroring of an SAP database as part of an overall data protection strategy with SAP applications can be found at:
121.html
http://h18006.www1.hp.com/storage/software.html
http://h71028.www7.hp.com/enterprise/cache/231355-0-0-0-
www.hp.com/hps/storage
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 5
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Product Highlights
Local Replication
Local Replication
Local ReplicationLocal Replication Solutions
Solutions
SolutionsSolutions
Hard Drive Support
Hard Drive Support
Hard Drive SupportHard Drive Support
FATA Drive Support
FATA Drive Support
FATA Drive SupportFATA Drive Support
The HP 4400 Scalable NAS File Services includes HP Business Copy, which is a local replication application for the EVA4400. It incorporates Virtually Capacity-free Snapshot (Vsnaps), standard snapshots and Snapclone capabilities. Business Copy EVA creates point-in-time copies of storage volumes, called Business Continuance Volumes (BCVs) using the snapshot and cloning capabilities of the array firmware and provides multi-array local mirror management. This product is indispensable for critical data center operations such as non-disruptive backups, frequent snapshots of high value databases, and data mining. The bottom line benefits include improved disk capacity utilization and increased business continuity, data availability, and productivity savings. Additional features include licensing based on replicated (not total raw) capacity and a new improved management interface.
The HP 4400 Scalable NAS File Services will support up to 96 disk drives. The EVA4400 array will support single or mixed drive capacities and types (high performance and FATA) within an enclosure. HP recommends using the same drive type (the same capacity) within a disk group because virtualization allocates space proportionate to the highest capacity drive with in the group.
The HP 4400 Scalable NAS File Services supports 1TB dual ported 4 Gb/s Fibre Attached Technology Adapted (FATA) disk. It can be configured with any combination of FATA and Fibre Channel disk drives; total raw capacity will vary based upon the redundancy (Vraid) selected. A minimum of eight FATA drives are required in a configuration, if this drive type is chosen.
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Fibre Channel Technology
Fibre Channel Technology
Fibre Channel TechnologyFibre Channel Technology
Factory pre-installation
Factory pre-installation
Factory pre-installationFactory pre-installation and pre-configuration
and pre-configuration
and pre-configurationand pre-configuration
FATA drives are designed for lower duty cycle applications such as near on-line data replication for back-up. These drives should not be used as a replacement for high performance, standard duty cycle, Fibre Channel drives. Doing so could shorten the life of the drive.
Please see the following URL for more information on FATA drives, their uses and their benefits
http://h71028.www7.hp.com/erc/downloads/5982-7353en.pdf
When providing host block storage services, the HP 4400 Scalable NAS File Services takes advantage of the benefits of Fibre Channel (FC) in distance, performance and connectivity. The use of optical Fibre cabling allows distances between connected segments of a SAN to be up to 500 meters @ 1 Gb/s; 300 meters @ 2 Gb/s using short wave multi-mode, 150 meters @ 4 Gb/s and up to 10 kilometers (6.21 miles) @ 1 Gb/s when using long wave cable. Storage Area Networks (SANs) can be constructed using FC switches/directors for fabric connectivity. HP SAN B-series and C-series switches and directors provide exceptional connectivity while increasing the effective bandwidth of the network. Supported SAN features include Zoning for communication isolation and Inter-Switch Links (hops) up to 10 km.
For more information on specific support specifications see the following SAN Infrastructure URL:
http://h18006.www1.hp.com/storage/saninfrastructure/switches.html
The HP 4400 Scalable NAS File Services ships from the factory fully configured. This includes the pre­configuration of storage, file serving and storage management software. After unpacking, it can be plugged into power sources, connected to the IP network, and it is ready for use. The included Installation and start-up service is provided to help change the factory preset IP addresses.
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 6
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Service and Support, HP Care Pack, and Warranty Information
Warranty and Services
Warranty and Services
Warranty and ServicesWarranty and Services Included with the Product
Included with the Product
Included with the ProductIncluded with the Product
For increased uptime, productivity and ROI -HP Care Pack packaged services for Storage
For increased uptime, productivity and ROI -HP Care Pack packaged services for Storage
For increased uptime, productivity and ROI -HP Care Pack packaged services for StorageFor increased uptime, productivity and ROI -HP Care Pack packaged services for Storage These days, you need to get the most out of your storage investment-you can't afford not to. When you buy HP storage products and solutions, it's also a good time to think about what levels of service and support you may need. To help take the worry out of deploying, designing, maintaining, and managing your environment, we've designed a portfolio of service options that are as: flexible, reliable and scalable as your storage. Unlike storage-only vendors, we take a holistic approach to your entire environment, bridging storage, servers, blades, software and network infrastructures with our HP Care Pack packaged services for Storage.
Protect your business beyond the warranty When it comes to robustness and reliability, standard warranties on today's computing equipment have matured just as the technologies have matured. Good news on some fronts-but also a source of potential problems and subsequent consequences that come from depending on standard warranties alone. Standard warranty protects against product defects and some causes of downtime- but not the business. By using a standard approach to warranty uplifts, such as HP Care Pack Services, you can reduce downtime risks and be more certain of operational consistency for both mission-critical and standard business computing. Simply put, HP Care Pack Services normalize the warranty of combined products - helping you proactively guard against unplanned downtime.
Comes with a 3-year HP's Global Limited Warranty and Technical Support, which includes 3 years 9x5 hardware support, with next business day (NBD) response.
HP's warranty and support features:
Online Business Support Center and IT Resource Center Remote Support Technical Phone Support Customer Self Repair (see list below) Software Limited Warranty On-site Warranty Service
Extending warranties with HP Care Pack Services
Extending warranties with HP Care Pack Services
Extending warranties with HP Care Pack ServicesExtending warranties with HP Care Pack Services For cost-effective upgrading or extending your standard warranty, HP Care Pack Services offer a suite of standard reactive hardware and software support services that are sold separately, or combined as with our Support Plus and Support Plus 24 services. The portfolio also provides a combination of proactive and reactive services, such as Proactive 24 Service and Critical Service. In addition, with HP Proactive Select we offer an innovative approach to service delivery that gives you the flexibility to acquire the specific proactive services you need today, then add services as your needs evolve. HP Proactive Select offers a broad set of technical or per-event type service options - including server, storage, and network, SAN device, and software, environment, installation and education services. Services that you can mix and match depending on your specific requirements, from preliminary planning and equipment delivery to installation, configuration, integration, and testing, through every level of ongoing support. Our HP Care Pack packaged services for Storage assures help when you need it most. And for many products, post-warranty HP Care Pack Services are available when your original warranty has expired.
HP Storage Services: Offering reliability, flexibility and value-just like your storage
HP Storage Services: Offering reliability, flexibility and value-just like your storage
HP Storage Services: Offering reliability, flexibility and value-just like your storageHP Storage Services: Offering reliability, flexibility and value-just like your storage HP Storage Services offers a full spectrum of customer care, from technology support to complex migrations to complete completely managed services. HP Factory Express provides customization, integration and deployment services for turnkey solutions. HP Education offers flexible, comprehensive training on storage networking, disk storage systems, and storage software to help your IT staff get the most out of your investments. And HP Financial solutions extend innovative financing and asset management programs to cost-effective buy, manage and eventually retire your older equipment.
HP Storage Services, the trusted business technology experts who manage your technology in action, because when technology works, business works.
NOTE:
NOTE:
Care Pack Services availability may vary by product and country.
NOTE:NOTE:
http://www.hp.com/hps/storage
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 7
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Service and Support, HP Care Pack, and Warranty Information
HP Care Pack Services are sold by HP and HP Authorized Service Partners:
Services for customers purchasing from HP or an enterprise reseller are quoted using HP order configuration tools. Customers purchasing from a commercial reseller can find HP Care Pack Services at:
http://h30125.www3.hp.com/csn/salesmktg/elfpack/elf_nonlkup_ctrylang.asp?code=ELNL
Recommended HP Care Pack Services for optimal satisfaction with your HP product.
Recommended HP Care Pack Services for optimal satisfaction with your HP product.
Recommended HP Care Pack Services for optimal satisfaction with your HP product.Recommended HP Care Pack Services for optimal satisfaction with your HP product.
Recommended Support
Recommended Support
Recommended SupportRecommended Support
3-Year HP Support Plus 24
3-Year HP Support Plus 24
3-Year HP Support Plus 243-Year HP Support Plus 24 For a higher return on your storage investment, HP Support Plus 24 provides integrated hardware and
software support services designed specifically for your technology. Available 24x7, this 3-year combined reactive support option delivers onsite hardware support and over-the-phone software support around­the-clock. Leverage the full strength of HP Technology Services - customers can trust the services professionals at HP to work collaboratively with them, putting our strategic and technical know-how to work across their entire infrastructure.
Improve uptime with responsive hardware and software services Cost-effectively obtain expert multivendor support Enjoy consistent service coverage across geographically dispersed sites Update HP and selected third-party software at a predictable cost Take advantage of subscription savings on software updates Increase revenue-with access to world-class expertise without headcount implications Increase customer satisfaction-with no interoperability gaps
http://h20195.www2.hp.com/V2/GetPDF.aspx/5981-6638EN.pdf
Related HP Care Pack Services that will enhance your HP product experience.
Related HP Care Pack Services that will enhance your HP product experience.
Related HP Care Pack Services that will enhance your HP product experience.Related HP Care Pack Services that will enhance your HP product experience.
Related Services
Related Services
Related ServicesRelated Services
HP Data Migration Service
HP Data Migration Service
HP Data Migration ServiceHP Data Migration Service For customers who need to safely transport mission critical data with minimal impact to their operations:
You need to move your critical enterprise data to your new HP SAN platform. And you need to accomplish that without losing data. And without interrupting your ongoing business operations.
HP Data Migration Service helps you lessen the risk of data loss, minimize threats to data integrity, and avoid productivity-sapping performance slowdowns during data transport. A highly experienced HP Services storage specialist works with you to rapidly and securely migrate mission-critical business information across your data center or around the globe - regardless of the complexity of your environment.
http://h20195.www2.hp.com/v2/GetPDF.aspx/5982-4107EN.pdf
HP Proactive Select Service
HP Proactive Select Service
HP Proactive Select ServiceHP Proactive Select Service For customers who need to improve IT performance and manageability through the use of cost effective
flexible proactive services:
Proactive Select - increased flexibility, minimal complexity -- Select what works for you - your package Delivery planning + Proactive Service Credits
Credits are used to redeem proactive services
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 8
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
Three 'predefined' service credit levels - 30, 60,180 credits Additional credits available Available in 1,3, 4 & 5 year packages Reactive Utilize existing reactive services products - ranging from Next Day, through 24x7, to 6 Hour Call to Repair
http://h20195.www2.hp.com/v2/GetPDF.aspx/4AA2-3842ENN.pdf
eSupport
eSupport
eSupporteSupport
HP eSupport is a portfolio of technology-based services that assist you with managing your business environment - from the desktop to the data center.
Support Portal The HP support portal provides one-stop access to the information, tools and services you need to manage the daily operations of your IT environment.
Features include:
Access to self-solve tools (including search technical knowledge base) Efficient logging and tracking of support cases Collaboration with other business and IT professionals Download of patches and drivers Access to diagnostic tools Proactive notification of relevant information
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Customer Technical
Customer Technical
Customer TechnicalCustomer Technical Training
Training
TrainingTraining
Access to certain features of the support portal requires an HP service agreement. To access the support portal, visit:
Remote Support Technology (RST)-HP Remote Support Pack Taking a more proactive approach to IT support, the HP Remote Support pack plug-in module easily integrates with HP Systems Insight Manager to provide a powerful, unified "single pane of glass" solution for onsite and remote management.
HP Remote Support Pack enhances HP Systems Insight Manager with intelligent event diagnosis plus the automatic submission of hardware event notifications securely to HP support, including acknowledgment and status returns. It adds remote configuration collections to allow the delivery of assessment and proactive services for your SAN storage and HP-UX environments.
Consider education as an integral part of your strategy to get the best return on investment for your HP storage solution. HP offers a variety of training courses on storage software, networking, archiving and disk storage systems. Our classes are available in many delivery modalities from traditional instructor-led courses at one of our 80 training centers worldwide to on-site training customized to your needs or online.
http://www.hp.com/support
www.hp.com/learn/storage
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 9
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Service and Support, HP Care Pack, and Warranty Information
HP Services Awards
HP Services Awards
HP Services AwardsHP Services Awards
Additional Services
Additional Services
Additional ServicesAdditional Services Information
Information
InformationInformation
HP Services continues to be recognized for service and support excellence by customers, partners, industry organizations and publications around the world. Recent honors and award reflect our services team's dedications, technical expertise, professionalism and uncompromising commitment to customer satisfaction. For a list of all our awards, please visit:
http://h20219.www2.hp.com/services/cache/433028-0-0-225-121.htm
For more information about HP Care Pack Services for Storage, please visit:
http://www.hp.com/hps/storage
If you have specific questions, contact your local HP representative. Contact information for a representative in your area can be found at "Contact HP"
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
http://www.hp.com
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 10
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Configuration Information and Configuration Rules
Step 1 - Choose a HP 4400 Scalable NAS File Services Base Model
Step 1 - Choose a HP 4400 Scalable NAS File Services Base Model
Step 1 - Choose a HP 4400 Scalable NAS File Services Base ModelStep 1 - Choose a HP 4400 Scalable NAS File Services Base Model
HP 4400 Scalable NAS
HP 4400 Scalable NAS
HP 4400 Scalable NASHP 4400 Scalable NAS File Services for Windows
File Services for Windows
File Services for WindowsFile Services for Windows
or
or
oror HP 4400 Scalable NAS
HP 4400 Scalable NAS
HP 4400 Scalable NASHP 4400 Scalable NAS File Services for Linux
File Services for Linux
File Services for LinuxFile Services for Linux
HP 4400 Scalable NAS for Windows includes
EVA4400 Dual Controller with Embedded SW M6412A FC HDD Enclosure Two HP DL360G6-Windows X5500 Network Storage GatewayNodes w/24 GB RAM each HP Procurve Switch 2910 Command View for EVA Unlimited License Business Copy for EVA and 1 TB License 42U 10000 Series Rack TFT7600 Rackmount Keyboard and Monitor SmartStart for HP EVA Storage
Short Wave Transceivers, Ethernet interconnect cables and FC interconnect cables. Factory Integration and pre-configuration.
NOTE:
NOTE:
Installation and Startup is included.
NOTE:NOTE:
HP 4400 Scalable NAS for Linux includes
EVA4400 Dual Controller w/Embedded SW M6412A FC HDD Enclosure Two HP DL360G6 Linux X5500 Network Storage Gateway Nodes w/24 GB RAM each HP Procurve Switch 2910 Command View for EVA Unlimited License Business Copy for EVA and 1 TB License 42U 10000 Series Rack TFT7600 Rackmount Keyboard and Monitor SmartStart for HP EVA Storage
AN595B
AN596B
Short Wave Transceivers, Ethernet interconnect cables and FC interconnect cables. Factory Integration and pre-configuration.
NOTE:
NOTE:
Installation and Startup is included.
NOTE:NOTE:
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 11
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Configuration Information and Configuration Rules
Step 2 - Pick Initial Hard Disk Drives
Step 2 - Pick Initial Hard Disk Drives
Step 2 - Pick Initial Hard Disk DrivesStep 2 - Pick Initial Hard Disk Drives
The 4400 Scalable NAS File Services requires that 12 hard disk drives be ordered, with the Base Model (AN595B or AN596A), from the list below:.
HP FC and FATA Drives
HP FC and FATA Drives
HP FC and FATA DrivesHP FC and FATA Drives
Step 3 - Software
Step 3 - Software
Step 3 - SoftwareStep 3 - Software
Snapshot Software
Snapshot Software
Snapshot SoftwareSnapshot Software
HP EVA M6412A 300GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 400GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 450GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 600GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 300GB 15K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 450GB 15K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 1TB FATA Fibre Channel Dual Port Hard Disk Drive
NOTE:
NOTE:
0D1 will appear after this part number to indicate factory integration where
NOTE:NOTE: appropriate. The 72 GB SSD and 146 GB Fibre Channel Disk Drive are not supported as an initial drive choice.
The HP 4400 Scalable NAS comes standard with a 1 TB license of HP Business Copy EVA for taking Snapshots. It is strongly recommended that if more storage is ordered, that the HP Business Copy Unlimited Capacity LTU be ordered as well.
HP Business Copy Unlimited Software License.
OPTIONAL SOFTWARE:
OPTIONAL SOFTWARE:
OPTIONAL SOFTWARE:OPTIONAL SOFTWARE:
http://h18006.www1.hp.com/storage/software.html
EVA4400 optional software can be found at the following URL:
AP766B
AJ711B AP731B AP732B
AG690B AG803B AG691B
T5477A
Step 4 - Hard Disk Drives
Step 4 - Hard Disk Drives
Step 4 - Hard Disk DrivesStep 4 - Hard Disk Drives
Drives and drive enclosures are orderable at the time the 4400 Scalable NAS File Services is purchased, or can be added in the future when additional capacity is required. Use these SKUs whenever ordering hard disk drives for the 4400 Scalable NAS File Services or EVA4400. Note that these SKU's apply ONLY to the HP 4400 Scalable NAS File Services or EVA4400 and can't be used with other EVA models.
Drive Enclosure
Drive Enclosure
Drive EnclosureDrive Enclosure
HP FC and FATA Drives
HP FC and FATA Drives
HP FC and FATA DrivesHP FC and FATA Drives
M6412A drive enclosures can be ordered to expand a HP 4400 Scalable NAS File Services configuration. The M6412A is a 2U dual-redundant FC Loop 12-bay disk enclosure with mounting hardware, and the necessary copper FC cables for connecting to an EVA4400 Controller pair.
*0D1 will appear after this part number to indicate factory integration where appropriate.
NOTE:
NOTE:
A minimum of eight (8) high performance FC or FATA or 6 solid state disks
NOTE:NOTE: drives are required per HP 4400 Scalable NAS or EVA4400.
HP 72GB 4Gb dual port FC EVA M6412A SSD HP EVA M6412A 300GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 400GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 450GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 600GB 10K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 146GB 15K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 300GB 15K 4Gb Fibre Channel Dual Port Hard Disk Drive HP EVA M6412A 450GB 15K 4Gb Fibre Channel Dual Port Hard Disk Drive
AG638B
AR055B AP766B
AJ711B AP731B AP732B
AG556B AG690B AG803B
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 12
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Configuration Information and Configuration Rules
HP EVA M6412A 1TB FATA Fibre Channel Dual Port Hard Disk Drive
NOTE:
NOTE:
0D1 will appear after this part number to indicate factory integration where
NOTE:NOTE: appropriate.
Step 5 - Cables and SFPs
Step 5 - Cables and SFPs
Step 5 - Cables and SFPsStep 5 - Cables and SFPs
FC cable - Copper SFP
FC cable - Copper SFP
FC cable - Copper SFPFC cable - Copper SFP
8 Gb/s SFP
8 Gb/s SFP
8 Gb/s SFP8 Gb/s SFP (Small Form- Factor
(Small Form- Factor
(Small Form- Factor(Small Form- Factor Profile) Transceiver
Profile) Transceiver
Profile) TransceiverProfile) Transceiver FC cable - 1 Gb to 2
FC cable - 1 Gb to 2
FC cable - 1 Gb to 2FC cable - 1 Gb to 2 Gb/s (optional)
Gb/s (optional)
Gb/s (optional)Gb/s (optional) (LC to SC)
(LC to SC)
(LC to SC)(LC to SC)
FC cable - 2Gb/s to
FC cable - 2Gb/s to
FC cable - 2Gb/s toFC cable - 2Gb/s to 2Gb/s (optional)(LC to
2Gb/s (optional)(LC to
2Gb/s (optional)(LC to2Gb/s (optional)(LC to LC)
LC)
LC)LC)
The following cables are used with the M6412 drive enclosure but are not necessary for new installations. These cables are for use inside the cab between the controllers and drive enclosures if replacement cables are required.
Cable FC Copper SFP .6m Cable FC Copper SFP 2m HP 8Gb Short Wave B-series FC SFP 1 Pack.
NOTE:
NOTE:
Before selecting the FC cables to connect between the controllers and the
NOTE:NOTE: switches, check to see what kind of connectors are on the switches that will be connected to the controllers. The SFP connector can support 8Gb I/Os, 4Gb I/Os, 2Gb I/Os and/or 1Gb I/Os.
NOTE:
NOTE:
One of these cables (either LC to SC or LC to LC) is required per FC port of
NOTE:NOTE: each HSV controller.
FC Short Wave 2-Meter Cable, LC/SC (1Gb to 2Gb) FC Short Wave 5-Meter Cable, LC/SC (1Gb to 2Gb) FC Short Wave 15-Meter Cable, LC/SC (1Gb to 2Gb) FC Short Wave 30-Meter Cable, LC/SC (1Gb to 2Gb) FC Short Wave 50-Meter Cable, LC/SC (1Gb to 2Gb)
NOTE:
NOTE:
SFP - Small Form-Factor Profile on the ports of the EVA4x00/6x00/8x00. One
NOTE:NOTE: of these cables (LC to LC) is required per FC port of each HSV controller.
2-meter LC-LC Multi-Mode Fibre Cable 5-meter LC-LC Multi-Mode Fibre Cable 15-meter LC-LC Multi-Mode Fibre Cable 30-meter LC-LC Multi-Mode Fibre Cable 50-meter LC-LC Multi-Mode Fibre Cable
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
AG691B
321624-B21 324394-B21
AJ716A
221691-B21 221691-B22 221691-B23 221691-B26 221691-B27
221692-B21 221692-B22 221692-B23 221692-B26 221692-B27
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 13
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Technical Specifications
Operating Temperature
Operating Temperature
Operating TemperatureOperating Temperature Shipping Temperature
Shipping Temperature
Shipping TemperatureShipping Temperature Humidity
Humidity
HumidityHumidity Shipping Humidity
Shipping Humidity
Shipping HumidityShipping Humidity Altitude
Altitude
AltitudeAltitude Air Quality
Air Quality
Air QualityAir Quality
Power Data
Power Data
Power DataPower Data
AC plug type
AC plug type
AC plug typeAC plug type (quantity 2)
Number of phases
Number of phases
Number of phasesNumber of phases Rated current
Rated current
Rated currentRated current Nominal Line Voltage
Nominal Line Voltage
Nominal Line VoltageNominal Line Voltage
Range Line Voltage
Range Line Voltage
Range Line VoltageRange Line Voltage Line Frequency
Line Frequency
Line FrequencyLine Frequency
(North America/Europe/Japan)
50° to 95° F (10° to 35° C) - Reduce rating by 1° F for each 1000 ft altitude (1.8° C/1,000 m)
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
EVA4400
EVA4400
EVA4400EVA4400
-40° to 150° F (-40° to 66° C) 10% to 90% non-condensing
5% to 90% non-condensing
Up to 8,000 ft (2,400 m)
Not to exceed 500,000 particles per cubic foot of air at a size of 0.5 micron or larger
maximum configuration
maximum configuration
maximum configurationmaximum configuration
EVA4400
EVA4400
EVA4400EVA4400
North America-3 wire NEMA No. L6-30P, 30 Amp (208 to 240V, 50-60Hz 30A)
Europe - 3 wire, 2 pole IEC 309, 30 amp, (220 to 240V 50Hz 32A)
Single
17A @ 200V-240V AC, 60Hz total, 4.25 A per power cord
North America - 208 or 230V
Europe - 230V
Japan - 206V
Latin America - 208 or 240V
187 to 256V
North America 60Hz, Europe 50Hz, Japan 50 or 60 Hz,. Latin American 60K or 50Hz
Enterprise Virtual Array 4400
Enterprise Virtual Array 4400
Enterprise Virtual Array 4400Enterprise Virtual Array 4400
NOTE:
NOTE:
This data represents fully populated
NOTE:NOTE: drive shelves with 15K rpm disk drives under typical performance. Other drive types may vary slightly. Note, at idle, the system operates at approx. 15% less power than at typical.
Typical
Typical
TypicalTypical
Failover
Failover
FailoverFailover Mode
Mode
ModeMode
NOTE:
NOTE:
Typical is described as a system in normal steady state operation. (I.e., both PDUs operating normally, the array
NOTE:NOTE: reading/writing to disk drives in a production environment)
Total System Wattage
Total System Wattage
Total System WattageTotal System Wattage Total System BTU/hour
Total System BTU/hour
Total System BTU/hourTotal System BTU/hour Input Current (A) -
Input Current (A) -
Input Current (A) -Input Current (A) ­Typical per system
Typical per system
Typical per systemTypical per system In Rush Current (A)
In Rush Current (A)
In Rush Current (A)In Rush Current (A) Input Current (A) -
Input Current (A) -
Input Current (A) -Input Current (A) ­Maximum per system
Maximum per system
Maximum per systemMaximum per system
2C1D
2C1D 2C2D
2C1D2C1D
424 728
1447 2485 3522 4560 5597 6635 7872 8710
1.6/1.5 2.6/2.4 3.5/3.3 4.4/4.3 5.5/5.2 6.5/6.1 7.4/7.0 8.4/8.0
98/10498
2.7/2.6 4.3/4.1 5.9/5.5
132/147 170/190 220/244 250/272 280/311 321/357 363/403
208 Volts
208 Volts 230 Volts
208 Volts208 Volts
2C2D 2C3D
2C2D2C2D
2C3D 2C4D
2C3D2C3D
1032 1336 1640 1944 2248 2552
2C4D 2C5D
2C4D2C4D
7.57.8/7.3
9.4/8.8
2C5D 2C6D
2C5D2C5D
2C6D 2C7D
2C6D2C6D
11.0/10.0 12.6/11.9 14.2/13.7
230 Volts
230 Volts230 Volts
2C7D 2C8D
2C7D2C7D
2C8D
2C8D2C8D
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 14
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Technical Specifications
Enterprise Virtual Array EVA4400 Product Dimensions, Weight and Clearance
Enterprise Virtual Array EVA4400 Product Dimensions, Weight and Clearance
Enterprise Virtual Array EVA4400 Product Dimensions, Weight and ClearanceEnterprise Virtual Array EVA4400 Product Dimensions, Weight and Clearance
Physical Dimensions
Physical Dimensions
Physical DimensionsPhysical Dimensions
EVA4400 2C8D Config.
EVA4400 2C8D Config.
EVA4400 2C8D Config.EVA4400 2C8D Config. (42U Graphite cab)
(42U Graphite cab)
(42U Graphite cab)(42U Graphite cab) EVA4400 Dual Controller
EVA4400 Dual Controller
EVA4400 Dual ControllerEVA4400 Dual Controller Enclosure
Enclosure
EnclosureEnclosure M6412 Drive Enclosure
M6412 Drive Enclosure
M6412 Drive EnclosureM6412 Drive Enclosure
X5500 Storage Gateway
X5500 Storage Gateway
X5500 Storage GatewayX5500 Storage Gateway
Height
Height
HeightHeight
in/cm
in/cm
in/cmin/cm
78.75 (200.03)
78.75 (200.03)
78.75 (200.03)78.75 (200.03)
3.5/8.89
3.5/8.89
3.5/8.893.5/8.89
3.5/8.89
3.5/8.89
3.5/8.893.5/8.89
Dimensions
Dimensions
DimensionsDimensions (with bezel)
Weight
Weight
WeightWeight (approximate)
Input Requirements
Input Requirements
Input RequirementsInput Requirements (for Standard 460W PSU, see power specifications tables for detail on 460W, 750W and 1200W power supplies)
BTU Rating
BTU Rating
BTU RatingBTU Rating
Power Specifications
Power Specifications
Power SpecificationsPower Specifications
(H x W x D)
Width
Width
WidthWidth in/cm
in/cm
in/cmin/cm
23.7 (60.3)
23.7 (60.3)
23.7 (60.3)23.7 (60.3)
17.6/44.70
17.6/44.70
17.6/44.7017.6/44.70
17.6/44.70
17.6/44.70
17.6/44.7017.6/44.70
Depth
Depth
DepthDepth in/cm
in/cm
in/cmin/cm
40.2 (102.2)
40.2 (102.2)
40.2 (102.2)40.2 (102.2)
24.5/62.3
24.5/62.3
24.5/62.324.5/62.3
23.75/60.33
23.75/60.33
23.75/60.3323.75/60.33
1.70 x 16.78 x 27.25 in (4.32 x 42.62 x 69.22 cm)
Maximum (all hard drives, power supplies, and processors installed)
Minimum (one hard drive, power supply, and processor installed)
Rated Line Voltage
Rated Input Current
Rated Input Frequency
Maximum
To review typical system power ratings use the HP Power Advisor which is available via the online tool located at URL:
energy-efficient
or
www.hp.com/go/hppoweradvisor
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
Max Weight
Max Weight
Max WeightMax Weight
lb/kg
lb/kg
lb/kglb/kg
860 (390.09)
860 (390.09)
860 (390.09)860 (390.09)
48/21.8
48/21.8
48/21.848/21.8
57/25.86
57/25.86
57/25.8657/25.86
39.5 lb (17.92 kg)
32 lb (14.51 kg)
100 to 240 VAC
4.5 Amps (at 120VAC) to 2.2 Amps (at 240 VAC)
50 to 60 Hz
1773 BTU / hr (at 120 VAC), 1715 (at 240 VAC)
Req. Front
Req. Front
Req. FrontReq. Front Clearance
Clearance
ClearanceClearance
in/cm
in/cm
in/cmin/cm
30 (76.2)
30 (76.2) 30 (76.2)
30 (76.2)30 (76.2)
N/A
N/A N/A
N/AN/A
N/A
N/A N/A
N/AN/A
www.hp.com/go/proliant-
Req. Rear
Req. Rear
Req. RearReq. Rear
Clearance
Clearance
ClearanceClearance
in/cm
in/cm
in/cmin/cm
30 (76.2)
30 (76.2)30 (76.2)
N/A
N/AN/A
N/A
N/AN/A
Power Supply Output
Power Supply Output
Power Supply OutputPower Supply Output (per power supply)
System Inlet Temperature
System Inlet Temperature
System Inlet TemperatureSystem Inlet Temperature
DA - 13115 Worldwide — Version 9 — August 9, 2011
- Click on the system of interest. Example: DL360 G6
- Follow the instructions of the next screens. Rated Steady-State Power
Maximum Peak Power
Operating
460 W (at 100 VAC), 460 W (at 200 VAC)
460 W (at 100 VAC), 460 W (at 200 VAC) NOTE: See Power Supply Specifications tables for complete details on 460W PSU and optional 750W and 1200W Power Supply Options.
10° to 35° C (50° to 95° F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8° F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10° C/hr (18° F/hr). The upper limit may be limited by the type and number of options
Page 15
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
QuickSpecs
Technical Specifications
Relative Humidity
Relative Humidity
Relative HumidityRelative Humidity (non-condensing)
Altitude
Altitude
AltitudeAltitude
Acoustic Noise
Acoustic Noise
Acoustic NoiseAcoustic Noise
Emissions Classification
Emissions Classification
Emissions ClassificationEmissions Classification (EMC)
(EMC)
(EMC)(EMC)
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File Services
HP 4400 Scalable NAS File ServicesHP 4400 Scalable NAS File Services
installed. System performance may be reduced if operating with a fan fault or above 30° C (86° F).
Non-operating
Operating
Non-operating
Operating
Non-operating
Listed are the declared A-Weighted sound power levels (LWAd) and declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23° C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74) and declared in accordance with ISO 9296 (ECMA 109).
Idle
Idle
IdleIdle
L WAd
L pAm
Operating
Operating
OperatingOperating
L WAd
L pAm FCC Rating Normative Standards
NOTE:
NOTE:
Product conformance to cited product specifications is based on
NOTE:NOTE: sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and statements.
-40° to 70° C (-40° to 158° F). Maximum rate of change is 20° C/hr (36° F/hr).
10 to 90% relative humidity (Rh), 28° C (82.4° F) maximum wet bulb temperature, non­condensing.
5 to 95% relative humidity (Rh), 38.7° C (101.7° F) maximum wet bulb temperature, non­condensing.
3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
6.4 B 49 dBA
6.4 B 49 dBA Class A CISPR 22; EN55022; EN55024; FCC CFR 47,
Pt 15; ICES-003; CNS13438; GB9254; K22; K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC 60950-1
© Copyright 2011 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
DA - 13115 Worldwide — Version 9 — August 9, 2011
Page 16
Loading...
