HPE ProLiant ML110 Gen10 Server

Overview

Page 1

HPE ProLiant ML110 Gen10 Server

The HPE ProLiant ML110 Gen10 delivers a performance that meets the growing needs of the SMB. The server is a single processor, manageability. The

ons and workloads a with this right

Front View (details for 8LFF and 16SFF)

Drive Cage 1

Drive Cage 2 (optional)

Optical drive (optional)

Power button/ LED

Health LED

NIC status LED

USB 3.0 (2) connectors

iLO Service Port

4.5U Tower Server that is designed to provide enterprise class features such as redundancy, reliability, and server delivers the right size Tower with performance and expandability that covers a wide range of applicati

nd addresses our customers from SMB to enterprise class server ROBO environments. Accelerate your business

-sized compute.

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Overview

Page 2

Rear View

PCIe3.0 Slots (Slots 1-5)

USB 3.0 (2) connectors

USB 2.0 (2) connectors

Network RJ-45 ports (2)

Video connector

UID button/LED

Power supply bay

Power supply power connection

iLO management port

10.

Serial port (optional)

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Overview

Page 3

Internal View

System Fan (92x32mm default)

Power Supply

Six (6) DDR4 DIMM slots

One (1) processor and heatsink

Front Bezel Lock

X4 SATA Port 2 (5-8)

X4 SATA Port 1 (1-4)

PCIe fan (92x32mm default)

Front USB 3.0 connector

10.

SATA Port 9

11.

SATA Port 10

12.

MicroSD slot

13.

Five (5) PCIe3.0 expansion slots

14.

Internal USB 2.0 connector

15.

Internal USB 3.0 connector

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Overview

Page 4

What’s New:

New SMB SKU Offerings

• Security features: iLO 5 (Security Root of Trust)

•

• NVIDIA Quadro P2000 GPU Module (optional)

• HPE 12TB SAS/ SATA 7.2K LFF HDD

• Intel® Xeon® Scalable processors , up to 14 cores, up to 105W

• Redundant Fan Kit (optional)

• Support up to 8 LFF NHP SATA HDDs

• HPE DDR4 SmartMemory up to 2666 MT/s

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Platform Information

Page 5

Platform Information

Form Factor

Tower (4.5U)

NOTE:

System Fans

1 Default system fan module (92 x 32 mm)

4. When the system requirements are to meet the A3 extended operating environment.

Sliding Shelf - 874578-B21 is optional to support rack form factor.

1 Default PCIe fan module (92 X 32 mm)

NOTE: When one of the following scenarios occurs, the server requires a Redundant Fan with a 800W Redundant Power Supply to be installed.

1. When a second HDD cage is installed and the SAS HDDs are running at 15K RPM.

2. When a SAS SSD is installed.

3. If one fan fails, the system will be required to continue operating with a Redundant Fan. This condition is indicated by a flashing amber Health LED.

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 6

Standard Features

Processors – One of the following depending on model.

Gold Processors

Gold 5122 Processor

3.6 GHz

16.50 MB

105W

2 @ 10.4 GT/s

2666 MT/s

192 GB

Gold 5120 Processor

2.2 GHz

19.25 MB

105W

2 @ 10.4 GT/s

2400 MT/s

192 GB

Silver Processors

Silver 4112 Processor

2.6 GHz

8.25 MB

85W

2 @ 9.6 GT/s

2400 MT/s

192 GB

Silver 4110 Processor

2.1 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

192 GB

Silver 4108 Processor

1.8 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2400 MT/s

192 GB

Bronze 3106 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

192 GB

Bronze 3104 Processor

1.7 GHz

11.00 MB

85W

2 @ 9.6 GT/s

2133 MT/s

192 GB

NOTE: Gold – 5100 Series - Supports 6-Channel DDR4 @ 2400 MT/s of SKU 5120 and @2666 MT/s of SKU 5122 providing up

512(1x 512-bit FMA), 48 lanes PCIe 3.0, standard RAS supported.

Chipset

Intel C621 Chipset

NOTE: For more information regarding Intel® chipsets, please see the following URL: http://www.intel.com/products/server/chipsets/

On System Management Chipset

HPE iLO 5 ASIC

NOTE: Read and learn more in the iLO QuickSpecs.

Memory

Type:

HPE SmartMemory and Standard Memory DDR4 Registered (RDIMM)

DIMM Slots Available

6 DIMM slots per processor, 6 channels per processor, 1 DIMM per channel

Maximum capacity (RDIMM)

192 GB

6 x 32 GB RDIMM @ 2666 MT/s

NOTE: LRDIMM is not qualified by this server. This server does not support mixing LRDIMMs and RDIMMs. Attempting to

NOTE:

Memory Protection

For details on the HPE Server Memory Options RAS feature, visit: http://www.hpe.com/docs/memory-ras-feature.

NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.

Intel Xeon Models

CPU

Frequency

Cores L3 Cache Power UPI DDR4

Memory

per socket

Bronze Processors

to 192 GB memory capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA) (SKU 5122 supports 2x 512 bit FMA), 48 lanes PCIe 3.0, advanced RAS supported. NOTE: Silver – 4100 Series -6-Channel DDR4 @ 2400 MT/s providing up to 192 GB memory capacity. Intel Turbo Boost Technology, Intel Hyper-Threading Technology, Intel AVX-512(1x 512-bit FMA), 48 lanes PCIe 3.0, standard RAS supported. NOTE: Bronze – 3100 Series - Supports 6-Channel DDR4 @ 2133 MT/s providing up to 192GB memory capacity. Intel AVX-

mix any combination of these DIMMs can cause the server to halt during BIOS installation. All memory installed in the server must be of the same type.

The maximum memory speed is a function of the memory type, memory configuration, and processor model.

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 7

Expansion Slots

Slots #

Technology

Bus

Width

Connector Width

Slot Form Factor

Notes

PCIe 3.0

Full-height,

half-length slot

PCH 4

PCIe 3.0

X16

Full-height,

full-length slot

Proc 1

PCIe 3.0

Full-height,

half-length slot

Proc 1

PCIe 3.0

Full-height,

half-length slot

Proc 1

PCIe 3.0

X16

Full-height,

Proc 1

NOTE: Bus Width Indicates the number of physical electrical lanes running to the connector.

Slot 2 and Slot 5 will be least recommended for usage.

Storage Controllers

The Gen10 controller naming framework has been updated to simplify identification as depicted below. For a more detailed

HPE Smart Array Gen10 Controllers Data Sheet.

One of the following depending on model

Software RAID

HPE Smart Array S100i SR Gen10 SW RAID

NOTE: HPE Smart Array S100i SR Gen10 SW RAID will operate in UEFI mode only. For legacy support an additional

Essential RAID

HPE Smart Array E208i-p SR Gen10 Controller

HPE Smart Array E208e-p SR Gen10 Controller

Performance RAID

HPE Smart Array P408i-p SR Gen10 Controller

HPE Smart Array P408e-p SR Gen10 Controller

NOTE: Performance RAID Controllers require the HPE Smart Storage Battery (P01367-B21-B21) which is sold separately.

Internal Storage Devices

One of the following depending on model

Optical Drive

Optional SATA 9.5mm DVD-ROM Optical Drive

Optional SATA 9.5mm DVD RW Optical Drive

NOTE: Optical is optional in BTO models.

Hard Drives

None ship standard

Hard Drive Bays

Up to 8 Non-hot plug SATA 3.5-inch drives

807878-B21 for the HPE LFF HDD Blank Kit or P/N 666987-B21 for

¾ length

(up to 9.5") Slot

NOTE: Although the Speed of slot is designed for 32Gb/s, the actual running speed will be lower than it was designed.

Hence

breakout of the available Gen10 Smart Array controllers visit the

controller will be needed, and for CTO orders please also select the Legacy mode settings part, 758959-B22. NOTE: HPE Smart Array S100i SR Gen10 SW RAID is off by default and must be enabled. For enabling please select HPE FIO Enable Smart Array SW RAID (784308-B21).

NOTE: The S100i supports 10 ports as 2 additional ports are leveraged to support the M.2 option.

NOTE: For Linux users, HPE offers a solution that uses in-distro open-source software to create a two-disk RAID 1 boot

volume. For more information visit: https://downloads.linux.hpe.com/SDR/project/lsrrb/

Controller

NOTE: Mixing drive cage types is not allowed. NOTE: All Pre-configured Models come populated with hard drive blanks

installed. The 4LFF configurations includes 3 blanks and 8SFF includes 7 blanks. Additional hard drive blanks can be ordered using either P/N

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 8

the HPE SFF HDD Blank Kit. These part numbers for single HDD blanks

8 Hot plug SFF SAS/SATA HDD bays; upgradable to 16

Maximum Internal Storage

CAPACITY

CONFIGURATION

Hot Plug LFF SAS

96 TB

8 x 12 TB

Hot Plug LFF SATA

96 TB

8 x 12 TB

Hot Plug SFF SAS

38.4 TB

16 x 2.4 TB

Hot Plug SFF SATA

32 TB

16 x 2 TB

Non Hot Plug LFF SATA

32 TB

8 x 4 TB

Hot Plug LFF SATA SSD

30.72 TB

8 x 3.84 TB

Hot Plug SFF SAS SSD

61.44 TB

16 x 3.84 TB

Hot Plug SFF SATA SSD

61.44 TB

16 x 3.84 TB

Power Supply

HPE ML110 Gen10 350W ATX Power Supply Kit

HPE ML110 Gen10 550W ATX Power Supply Kit

HPE Entry-Level Power Supplies provide lower-cost options for customers trying to balance their need for enterprise class

Essential-series rack and tower servers.

HPE 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit

NOTE: Flex Slot Platinum power supplies support power efficiency of up to 94% and include a standard C-14 power inlet

NOTE:

HPE Flexible Slot (Flex Slot) Power Supplies share a common electrical and physical design that allows for hot plug, tool-less

For information on power specifications and technical content visit HPE Server power supplies.

Interfaces

Video

1 standard ( at system rear)

Network RJ-45 (Ethernet)

2 standard ( at system rear) Serial

1 optional ( at system rear)

below are also provided should you require replacement HDD blanks for your server.

NOTE: NHP SATA is limited to S100i controller.

4 Hot plug LFF SAS/SATA HDD bays; upgradable to 8

NOTE: ATX power supply will not support redundant fan option.

efficiency and reliability while maintaining lowest possible hardware costs. All Entry-Level power supply options have been designed specifically for HPE ProLiant Gen10 Essential Series servers.

The HPE 550W ATX Power Supply is the standard, non-redundant AC power supply option for most HPE ProLiant Gen10 Essential servers. It features Silver-level (88%) certified power efficiency with a set of features optimized for the Gen10

connector.

NOTE: The 800W Flex Slot Platinum Hot Plug Low Halogen Power Supply Kit requires the RPS Enablement Kit.

The RPS Enablement kit will support two power supplies.

installation into HPE ProLiant Gen10 Performance Servers. Flex Slot power supplies are certified for high-efficiency operation and offer multiple power output options, allowing users to "right-size" a power supply for specific server configurations. This flexibility helps to reduce power waste, lower overall energy costs, and avoid "trapped" power capacity in the data center.

This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.

To review the power requirements for your selected system, please use the HPE Power Advisor Tool.

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 9

iLO Management Port

1 standard (at system rear)

iLO Service Port

1 standard (at system front)

MicroSD Slot

1 standard (at system internal)

NOTE: The MicroSD slot is not hot-pluggable, please power down server before installation or removal.

USB 3.0 USB 2.0

5 (2 front, 2 rear, 1 internal) 3 (2 rear, 1 internal)

Operating Systems and Virtualization Software Support for ProLiant Servers

Microsoft Windows Serve

Red Hat Enterprise Linux (RHEL)

SUSE Linux Enterprise Server (SLES)

VMware

ClearOS

HPE and ClearCenter will help you lower the cost of building on-premise solutions without sacrificing security and ease of use.

and growing. Whether you’re starting out or scaling, you decide what applications you need and pay as you grow.

NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost. For more information on ClearOS, please visit http://www.hpe.com/servers/clearos.

CentOS

NOTE: CentOS not directly supported / Community Supported (Based on RHEL so RHEL testing and enablement applicable

server. http://h20566.www2.hpe.com/portal/site/hpsc/public/psi/home?sp4ts.oid=1010026818.

Industry Standard Compliance

ACPI 6.1 Compliant

PCIe 3.0 Compliant

WOL Support

Microsoft® Logo certifications

Novell Certified

PXE Support VGA Port

USB 3.0 Compliant

USB 2.0 Compliant

Energy Star 2.1

SMBIOS 3.1

UEFI 2.6

ASHRAE A3

NOTE: For additional technical thermal details regarding ambient temperatures, humidity and features support please

http://www.hpe.com/servers/ashrae

UEFI (Unified Extensible Firmware Interface Forum)

NOTE: UEFI is the default for the ML110 Gen10. Legacy mode can be selected in the field or as a CTO option

(758959-B22).

HPE ProLiant servers with ClearOS give you a simple, secure, and affordable operating system with an intuitive web-based graphical user interface that provides a cloud-like experience on-premise, and an Application Marketplace with over 100 apps

to CentOS) CentOS 6.9 / CentOS 7.3, 7.4. NOTE: For more information on Hewlett Packard Enterprise Certified and Supported ProLiant Servers for OS and Virtualization Software and latest listing of software drivers available for your

visit:

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 10

Graphics

Integrated Video Standard

• Video modes up to 1920 x 1200 @60Hz (32 bpp)

• 16MB Video Memory

HPE iLO 5 on system management memory

• 32 MB Flash

• 4 Gbit DDR 3 with ECC protection

HPE Server UEFI/Legacy ROM

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured

ProLiant Gen10 Server.

Embedded Management

HPE Integrated Lights-

(HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and remote

UEFI

Configure and boot your servers securely with industry standard Unified Extensible Firmware

http://www.hpe.com/servers/uefi

Intelligent Provisioning

Hassle free server and OS provisioning for 1 or more servers with Intelligent Provisioning.

http://www.hpe.com/servers/intelligentprovisioning

iLO RESTful API

iLO RESTful API is Redfish API conformance and offers simplified server management

http://www.hpe.com/info/restfulapi

configuration than the legacy ROM while interacting with your server at boot time. HPE ProLiant Gen10 servers have a UEFI Class 2 implementation and support both UEFI Mode (default) and Legacy BIOS Mode.

NOTE: The UEFI System Utilities tool is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more information, please visit http://www.hpe.com/servers/uefi.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot and Secure Start enable for enhanced security

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

• Embedded UEFI Shell

• Mass Configuration Deployment Tool using iLO RESTful API that is Redfish API Conformant

• PXE boot support for IPv6 networks

• Workload Profiles for simple performance optimization

UEFI Boot Mode only:

• TPM 2.0 Support

• iSCSI Software Initiator Support.

• HTTP/HTTPs Boot support as a PXE alternative.

• Boot support for option cards that only support a UEFI option ROM

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI. NOTE: UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the factory for your HPE

Out

management with HPE iLO. Learn more at http://www.hpe.com/info/ilo.

Interface (UEFI). Learn more at

Learn more at

automation such as configuration and maintenance tasks based on modern industry standards. Learn more at

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 11

Server Utilities

Active Health System

The HPE Active Health System (AHS) is an essential component of the iLO management

at http://www.hpe.com/servers/ahs.

Active Health System

Use the Active Health System Viewer, a web-based portal, to easily read AHS logs and speed

visit: http://www.hpe.com/servers/ahsv.

Smart Update

Keep your servers up to date with the HPE Smart Update solution by using Smart Update

(SPP). Learn more at http://www.hpe.com/info/smartupdate.

iLO Amplifier Pack

Designed for large enterprise and service provider environments with hundreds of HPE

http://www.hpe.com/servers/iLOamplifierpack

HPE iLO Mobile

Enables the ability to access, deploy, and manage your server anytime from anywhere from

http://www.hpe.com/info/ilo/mobileapp

RESTful Interface Tool

RESTful Interface tool (iLOREST) is a single scripting tool to provision using iLO RESTful API

http://www.hpe.com/info/resttool

Scripting Tools

Provision one to many servers using your own scripts to discover and deploy with Scripting

http://www.hpe.com/servers/stk

http://www.hpe.com/servers/powershell

HPE OneView Standard

HPE OneView Standard can be used for inventory, health monitoring, alerting, and reporting

http://www.hpe.com/info/oneview

HPE Systems Insight

Ideal for environments already using HPE SIM, it allows you to monitor the health of your HPE

Security

UEFI Secure Boot and Secure Start support

Immutable Silicon Root of Trust

FIPS 140-2 validation (iLO 5 certification in progress)

Common Criteria certification (iLO 5 certification in progress)

Configurable for PCI DSS compliance

Ability to rollback firmware

Secure erase of NAND/User data

TPM (Trusted Platform Module) 1.2 option

portfolio that provides continuous, proactive health monitoring of HPE servers. Learn more

Viewer

Application

problem resolution with HPE self-repair recommendations, to learn more

Manager (SUM) to optimize the firmware and driver updates of the Service Pack for ProLiant

servers, the iLO Amplifier Pack is a free, downloadable open virtual application (OVA) that delivers the power to discover, inventory and update Gen8, Gen9 and Gen10 HPE servers at unmatched speed and scale. Use with an iLO Advanced License to unlock full capabilities. Learn more at

select smartphones and mobile devices. For additional information please visit:

to discover and deploy servers at scale. Learn more at

Tool (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at

without additional fees. It can monitor multiple HPE server generations. The user interface is similar to the HPE OneView Advanced version, but the software-defined functionality is not available. Learn more at

Manager (HPE SIM)

ProLiant Servers and HPE Integrity Servers. Also provides you with basic support for non-HPE servers. HPE SIM also integrates with Smart Update Manager to provide quick and seamless firmware updates. Learn more at

http://www.hpe.com/info/hpesim.

QuickSpecs

HPE ProLiant ML110 Gen10 Server

Standard Features

Page 12

TPM (Trusted Platform Module) 2.0 option

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide network of HPE

at: http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.

Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE: Server Warranty includes 3-Year Parts, 3-Year Labor, 3-Year Onsite support with next business day response. Exceptions may apply to certain regions or countries. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity; 3) Non CSR parts must be serviced by a trained authorized service engineer. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available

+ 25 hidden pages
