HPE 833870-B21 Getting Started Guide

QuickSpecs

HPE ProLiant DL120 Generation9 (Gen9)

Overview

Page 1

HPE ProLiant DL120 Generation9 (Gen9)

The HPE ProLiant DL120 Gen9, an enterprise class design packed in a dense 1U/1-socket form factor, powered by an Intel® Xeon® E5 traditional 1P servers making the DL120 Gen9 ideal for the growing needs of virtualization and general purpose workloads.

Front View

Access Panel

Serial label pull tab

USB 2.0 connector

UID LED

Health LED

NIC status LED

Power On/Standby button and system power LED

4LFF drive

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

-2600 v3/v4 series processor. Offering a combination of performance, redundancy, expandability as compared to the

QuickSpecs

Overview

Page 2

Rear View

Slot 3 PCIe3 x8 (8, 4, 1)

Slot 2 PCIe3 x8 (8, 4, 1)

NOTE: Slot 3 supports PCIe x16 (16, 8, 4, 1) if the GPU riser cage is installed.

Non-hot-plug power supply

Power supply power connection

Slot 1 PCIe3 x16 (16, 8, 4, 1)

UID LED

Power supply power LED

10.

USB 3.0 connectors

Embedded 2x1GbE network adapter

Video connector

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

QuickSpecs

Overview

Page 3

Internal View

Hot swappable fans (up to 5)

HPE Smart Storage Battery connector

Internal USB 3.0

SATA connector

Mini-SAS connectors

Primary PCIe riser board connector

Embedded 2x1GbE network adapter

System Battery

10.

Storage backup power connector for PCIe slots 1-2

11.

Secondary PCIe riser slot

12.

MicroSD slot

13.

Storage backup power connector for PCIe slot 3

14.

Processor heat sink (processor with HPE Smart Socket placed below heat sink)

15.

DDR4 DIMM slots (up to 8)

What's New

• Introducing new 14c 2.6GHz, E5-2690v4 processor support on DL120 Gen9

• Support for ClearOS – an easy to use OS with an application marketplace

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Power supply bay

QuickSpecs

Standard Features

NOTE: For more information regarding Intel Xeon processors, please see the following http://www.intel.com/xeon.

Processor

Model

CPU

Cores

L3 Cache

Power

QPI

DDR4 Hz

E5-2699v3

2.3GHz

45MB

145W

9.6GT/s

2133

E5-2698v3

2.3GHz

40MB

135W

9.6GT/s

2133

E5-2695v3

2.3GHz

35MB

120W

9.6GT/s

2133

E5-2660v3

2.6GHz

25MB

105W

9.6GT/s

2133

E5-2650v3

2.3GHz

25MB

105W

9.6GT/s

2133

E5-2650Lv3

1.8GHz

30MB

65W

9.6GT/s

2133

E5-2640v3

2.6GHz

20MB

90W

8.0GT/s

1866

E5-2630v3

2.4GHz

20MB

85W

8.0GT/s

1866

E5-2630Lv3

1.8GHz

20MB

55W

8.0GT/s

1866

E5-2623v3

3.0GHz

10MB

105W

8.0GT/s

1866

E5-2620v3

2.4GHz

15MB

85W

8.0GT/s

1866

E5-2609v3

1.9GHz

15MB

85W

6.4GT/s

1600

E5-2603v3

1.6GHz

15MB

85W

6.4GT/s

1600

E5-1650v3

3.5GHz

15MB

140W

0.0GT/s

2133

E5-1620v3

3.5GHz

10MB

140W

0.0GT/s

2133

E5-2699v4

2.2GHz

55MB

145W

9.6GT/s

2400

E5-2698v4

2.2GHz

50MB

135W

9.6GT/s

2400

E5-2695v4

2.1GHz

45MB

120W

9.6GT/s

2400

E5-2690v4

2.6GHz

35MB

135W

9.6GT/s

2400

E5-2660v4

2.0GHz

35MB

105W

9.6GT/s

2400

E5-2650v4

2.2GHz

30MB

105W

9.6GT/s

2400

E5-2650Lv4

1.7GHz

35MB

65W

9.6GT/s

2400

E5-2640v4

2.4GHz

25MB

90W

8.0GT/s

2133

E5-2630v4

2.2GHz

25MB

85W

8.0GT/s

2133

E5-2630Lv4

1.8GHz

25MB

55W

8.0GT/s

2133

E5-2623v4

2.6GHz

10MB

85W

8.0GT/s

2133

E5-2620v4

2.1GHz

20MB

85W

8.0GT/s

2133

E5-2609v4

1.7GHz

20MB

85W

6.4GT/s

1866

E5-2603v4

1.7GHz

15MB

85W

6.4GT/s

1866

E5-1650v4

3.6GHz

15MB

140W

0.0GT/s

2400

E5-1620v4

3.5GHz

10MB

140W

0.0GT/s

2400

Chipset

Intel® C610 Series Chipset

Intel® E5-2600v3 Processor Family

Intel® E5-2600v4 Processor Family

NOTE: For more information regarding Intel® chipsets, please see the following URL:

http://www.intel.com/products/server/chipsets/

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

One of the following depending on model

frequency

One of the following depending on model

Page

QuickSpecs

Standard Features

Page 5

On System Management Chipset

HPE iLO (Firmware HPE iLO4 2.0 or later) 2GB NAND

Memory

Type:

HPE SmartMemory

DDR4 Registered (RDIMM) or Load Reduced (LRDIMM)

DIMM Slots Available

(8 DIMM slots per processor, 4 channels per processor, 2 DIMMs per channel)

Maximum Capacity (LRDIMM)

256GB

(8 x 32GB RDIMM @2133MHz)

Maximum Capacity (RDIMM)

256GB

(8 x 32GB LRDIMM @2400MHz)

Memory Protection

Advanced ECC

Advanced ECC uses single device data correction to detect and correct single and all multibit error that occurs within a single DRAM chip.

Online Spare

Memory online spare mode detects a rank that is degrading and switches operation to the spare rank.

Network Controller

upgrade with a variety of networking options.

Expansion Slots

CPU PCIe riser slots

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Form Factor

Notes

PCIe 3.0

x16

Low profile

NOTE: Bus Width data indicates the number of physical electrical lanes running to the connector.

FlexibleLOM riser slots

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Form Factor

Notes

PCIe 3.0

Low profile

Flexible LOM

FlexibleLOM

FlexibleLOMs

CPU riser

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Form Factor

Notes

PCIe 3.0

Low profile

PCIe 3.0

Full-height, half-

length slot

GPU riser

Expansion

Slots #

Technology

Bus

Width

Connector

Width

Form Factor

Notes

PCIe 3.0

x16

Full-height, full-

length slot

GPU

Storage Controller

Entry Models

HPE Dynamic Smart Array B140i Controller

Base Models

HPE H240 FIO Smart Host Bus Adapter

NOTE:

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

NOTE: Read and learn more in the iLO QuickSpecs.

One of the following depending on model

(Option 1)

PCIe slots (Option 2)

(Option 3)

HPE Ethernet 1Gb 2-port Adapter The HPE ProLiant DL120 Gen9 server offers the customer a dual-port NIC standard with the option to

can only be used for

One of the following depending on model

NOTE: B140i provides support for up to 8 SATA drives and supports RAID 0, 1, 1+0 & 5.

H240 provides support for up to 8 SAS/SATA drives and supports RAID 0, 1, 1+0 & 5.

QuickSpecs

Standard Features

Page 6

Internal Storage

Optical Drive

Optional: DVD-ROM, DVD-RW

Hard Drives

None ship standard

Hard Drive Bays

8 SFF drive bays total with Optical Bay

4 LFF drive bays total with Optical Bay

NOTE:

replacement HDD blanks for their server.

Maximum Internal

CAPACITY

CONFIGURATION

Hot Plug SFF SAS

16.0TB

8x2TB

Hot Plug SFF SATA

16.0TB

8x2TB

Hot Plug LFF SAS

40.0TB

40x10TB

Hot Plug LFF SATA

40TB

4x10TB

Hot Plug SFF SAS SSD

30.72TB

8x3.84TB

Hot Plug SFF SATA SSD

30.72TB

8x3.84TB

Hot Plug LFF SATA SSD

15.36TB

4x3.84TB

Power Supply

HPE 550W FIO Power Supply

HPE 900W Redundant Power Supply

Looking for high-efficiency power solutions at an entry-level price for your ProLiant Gen9 Essential

replacement.

System Fans

Non-redundant

Redundant

1P model

3 fans

5 fans

NOTE:

Interfaces

Video

1 (Vaux Support)

USB

4 USB ports (standard)

Internal: 1x USB 3.0

Micro SD Slot

1 Micro SD

NOTE: The SD slot is not a hot-pluggable device. Customers should not attempt to plug an SD card

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Devices

One of the following depending on model

HPE ProLiant DL120 Gen9 server offers both SFF and LFF versions. The Optical Drive bay is available with both models. NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional hard drive blanks, they can order more using either HPE SFF Gen9 Hard Drive Blank Kit (666987-B21) or HPE LFF Gen9 Hard Drive Blank Kit (666986-B21). These part numbers for single HDD blanks below are also provided should the customer require

Storage

One of the following depending on model

Server? HPE Entry-Level Power Supplies offer an optimized set of features with options for both redundant and non-redundant power configurations.

The HPE 550W FIO Power Supply offers Silver-certified 80 Plus power efficiency (up to 89%) with an optimized set of features for non-redundant power configurations.

The HPE 900W AC 240VDC Power Input Module with Power Backplane can be configured to support power redundancy in ProLiant servers that offer only a single power supply bay, providing additional protection against power loss. With an 80 Plus Gold power efficiency rating (up to 92%), this power option helps to reduce operating expenses while protecting against trapped power capacity in the data center. Hot-plug AC power input modules allow for better serviceability with fast and easy deployment and

One of the following depending on model

NOTE: Redundant fan option kit (765513-B21) can be bought separately if redundancy is required with configurations.

Fan redundancy is not supported for processors exceeding 105W.

Front: 1xUSB 2.0 std Rear: 2xUSB 3.0

QuickSpecs

Standard Features

Page 7

into the SD slot while the server is powered.

Operating Systems

Microsoft Windows Server

Red Hat Enterprise Linux (RHEL)

SUSE Linux Enterprise Server (SLES)

Oracle Linux

VMware

ClearOS

NOTE: ClearOS allows you to build a fully functional server that is just right for you at no upfront cost.

ClearOS, please visit http://www.hpe.com/servers/clearos.

NOTE: For more information on the Hewlett Packard Enterprise Certified and Supported ProLiant

download page

Upgradeability

FlexibleLOM slot for 1GbE or 10GbE or QDR/FDR InfiniBand Networking Options

Up to 8 SFF Hard Drive Bays; or 4 LFF Hard Drive Bays

Up to 8 DIMM slots

Redundant Power Supply

Optical Drive Bay (8 SFF/4 LFF)

Industry Standard

ACPI 2.0b Compliant

PCIe 3.0 Compliant

PXE Support

WOL Support

Microsoft® Logo certifications

USB 3.0 Support

ASHRAE A3

NOTE: Refer to technical specifications section for more details.

Graphics

Integrated Matrox G200eH2 video standard

• 1920 x 1200 (16 bpp)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

and Virtualization Software Support for ProLiant Servers

It is available via CTO preload, Intelligent Provisioning or via download. For more information on

Servers for OS and Virtualization Software and latest listing of software drivers available for your server, please visit our Support Matrix at: http://www.hpe.com/info/ossupport and our driver

One of the following depending on model

Compliance

HPE Server UEFI/Legacy ROM

• 1280 x 1024 (32 bpp)

Unified Extensible Firmware Interface (UEFI) is an industry standard that provides better manageability and more secured configuration than the legacy ROM while interacting with your server at boot time. HPE ProLiant Gen9 platform defaults to UEFI and can be factory or field configured for Legacy BIOS Boot Mode.

NOTE: The UEFI System Utilities function is analogous to the HPE ROM-Based Setup Utility (RBSU) of legacy BIOS. For more information, please visit http://www.hpe.com/servers/uefi.

UEFI enables numerous new capabilities specific to HPE ProLiant servers such as:

• Secure Boot

• Operating system specific functionality

• Support for > 2.2 TB (using GPT) boot drives

• USB 3.0 Stack

QuickSpecs

Standard Features

Page 8

• Embedded UEFI Shell

factory for your HPE ProLiant Gen9 Server.

Form Factor

1U Rack form factor

8SFF and 4LFF version:

1.69" (4.29cm) Height x 17.11" (43.46cm) Width x 23.9" (60.7cm) Length

Embedded

HPE Integrated

(HPE iLO)

Monitor your servers for ongoing management, service alerting, reporting and remote

UEFI

http://www.hpe.com/servers/uefi

RESTful API

RESTful API for iLO 4 is Redfish 1.0 conformance for simplified server management

Provisioning

http://www.hpe.com/servers/intelligentprovisioning

Embedded

http://www.hpe.com/info/insightonline/explore.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

• Mass Configuration Deployment Tool using RESTful API for iLO 4

• PXE boot support for IPv6 networks

• Boot support for option cards that only support a UEFI option ROM

• Network Stack configurations

NOTE: For UEFI Boot Mode, boot environment and OS image installations should be configured properly to support UEFI. NOTE: UEFI FIO Setting (758959-B22) can be selected to configure the system in Legacy mode in the

One of the following depending on model

Management

Lights-Out

Intelligent

Remote Support

management with HPE iLO. Learn more at http://www.hpe.com/info/ilo.

Configure and boot your servers securely with industry standard Unified Extensible Firmware Interface (UEFI). Learn more at

such as configuration and maintenance tasks based on modern industry standards. Learn more at http://www.hpe.com/info/restfulapi.

Hassle free server and OS provisioning for 1 or few servers with Intelligent Provisioning. Learn more at

The Hewlett Packard Enterprise embedded remote support, when used with Insight Online direct connect or HPE Insight Remote Support, allows HPE ProLiant servers to transmit hardware events directly to Hewlett Packard Enterprise or a Hewlett Packard Enterprise Authorized Partner for automated phone home support. Learn more at

QuickSpecs

Standard Features

Page 9

Server utilities

Smart Update

Optimize firmware and driver updates with Smart Update solutions including Smart

http://www.hpe.com/servers/smartupdatemanager.

HPE Systems

SIM)

HPE SIM allows you to monitor the health of your HPE ProLiant Servers and HPE

Scripting Tool

PowerShell

Provision 1 to many servers using your own scripts to discover and deploy them with

http://www.hpe.com/servers/powershell.

RESTful

http://www.hpe.com/info/resttool.

HPE iLO Mobile

Enables the ability to access, deploy, and manage your server anytime from anywhere

http://www.hpe.com/info/ilo/mobileapp.

HPE Insight

HPE Insight Online, available at no additional cost as part of your Hewlett Packard

http://www.hpe.com/info/insightonline/explore

Security

Power-on password

Serial interface control

Administrator's password

TPM 2.0

UEFI

Warranty

This product is covered by a global limited warranty and supported by HPE Services and a worldwide

http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Update Manager (SUM) and Service Pack for ProLiant (SPP). Learn more at

Insight Manager (HPE

Kit and Windows

Interface Tool

Application

Online

Integrity Servers, and also provides you with basic support for non-HPE servers. HPE SIM also integrates with Smart Update Manager to provide quick and seamless firmware updates. Learn more at http://www.hpe.com/servers/hpsim

Scripting Tool Kit (STK) for Windows and Linux or Scripting Tools for Windows PowerShell. Learn more at

http://www.hpe.com/servers/proliant/stk or

RESTful Interface tool is a scripting tool to provision using RESTful API for iLO 4 to discover and deploy servers at scale. Learn more at

from select smartphones and mobile devices. For additional information please visit:

Enterprise warranty or contractual support agreement with Hewlett Packard Enterprise, is a personalized dashboard for simplified tracking of IT operations and support information from anywhere, anytime. Learn more at

network of HPE Authorized Channel Partners resellers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HPE Pointnext operational services or customized service agreements. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.

NOTE: Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response. Warranty repairs may be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have Hewlett Packard Enterprise replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:

QuickSpecs

Optional Features

Embedded

iLO Essentials

HPE iLO Essentials is the preferred license for small and medium business that offers full

iLO Scale-Out

HPE iLO Scale-Out is the preferred license built for web hosting, cloud service providers,

http://www.hpe.com/servers/iLO/scale-out

iLO Advanced

HPE iLO Advanced licenses offer smart remote functionality without compromise, for all

http://www.hpe.com/servers/iloadvanced

Server Management

HPE Insight

HPE Insight Control, lets you deploy, migrate, monitor, remote control, and optimize your

see http://www.hpe.com/info/insightcontrol.

Rack and Power

HPE Rack and Power Infrastructure products and services create highly efficient and intelligent solutions

Learn more at HPE Rack and Power Infrastructure.

High Performance

HPE Cluster Platforms are specifically engineered, factory-integrated large-scale ProLiant clusters

https://www.hpe.com/us/en/solutions/hpc-high-performance-computing/hpc-software.html

HPC Interconnects

NOTE: High Performance Computing (HPC) interconnect technologies are available for this server

Storage Software

Data Protection and Recovery Software

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Management

Control

remote server management capabilities for small and medium business via the Integrated Remote Console (IRC), virtual media, and e-mail based alerts. Learn more about HPE iLO Essentials at

http://www.hpe.com/servers/iLO/essentials.

and high performance computing data centers, managing massive scale out environments for the DL 100 and 10 series servers, not available for ML servers. This license offers sophisticated scripting tools that provides remote access through Text Console via SSH, Dynamic power capping, Email-based Alerting and proactive notifications. For more information, visit

HPE ProLiant servers. The license includes the full integrated remote console, virtual keyboard, video, and mouse (KVM), multi-user collaboration, console record and replay, and GUI-based and scripted virtual media and virtual folders. You can also activate the enhanced security and power management functionality. Learn more about HPE iLO Advanced at

IT infrastructure through a single, simple management console. For more information,

Infrastructure

for existing or new IT data centers. HPE Rack and Power infrastructure solutions – rack infrastructure, power protection and management, performance optimized data centers (PODs) – are the foundation you are looking for to help secure your long-term IT success. These products are designed to help you react to changes in the industry. They deliver efficient, easy-to-use capabilities to manage, monitor, deploy and provision infrastructure from entry to enterprise. As an industry leader, Hewlett Packard Enterprise uniquely positioned to address the key concerns of power, cooling, cable management and system access.

Clusters

optimized for High Performance Computing, with a choice of servers, networks and software. Operating system options include specially priced offerings for Red Hat Enterprise Linux and SUSE Linux Enterprise Server, as well as Microsoft Windows HPEC Server. A Cluster Platform Configurator simplifies ordering.

under the HPE Cluster Platform product portfolio. These high-speed interconnects are fully supported by Hewlett Packard Enterprise when they are part of these configure to order clusters. Solutions can be defined with a lot of flexibility with the help of configuration tools. Please visit the following URL to configure HPEC Clusters with InfiniBand Interconnects: https://www.hpe.com/info/hpc/solutions.

Whether you need to solve a specific data protection, archiving, or storage command and control challenge, or deliver on strategic consolidation, compliance, or continuity initiatives, look no further than Hewlett Packard Enterprise storage software. Our storage software helps you reduce costs, simplify storage infrastructure, protect vital assets and respond faster to business opportunities. Storage software that gets the job done:

•

Page

QuickSpecs

Optional Features

Page 11

Whether you're a large enterprise or a smaller business, Hewlett Packard Enterprise data

https://www.hpe.com/us/en/storage/software-defined.html.

ClearOS

HPE and ClearCenter will help you lower the cost of building on-premise solutions without sacrificing

or scaling, you decide what applications you need and pay as you grow.

One Config Simple

SCE is a guided self-service tool to help sales and non-technical people provide customers with initial

http://ocs.ext.hpe.com/.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

protection and recovery software will cost-effectively protect you against disaster and ensure business continuity.

• Data Archive and Migration Software

Hewlett Packard Enterprise storage software enables you to comply with data retention and retrieval requirements, improve application performance, and reduce costs by efficiently migrating

infrequently accessed or less valuable data to lower cost storage.

• Storage Resource Management Software (SRM)

Hewlett Packard Enterprise storage resource management software reduces operational costs and provides the command and control foundation you need to efficiently manage and visualize

your physical and virtual environments.

• Data Replication Software

Hewlett Packard Enterprise offers array-based and host-based replication software for use in disaster recovery, testing, application development and reporting.

• Storage Device Management Software

Maximize your investment in Hewlett Packard Enterprise storage and networking with software that enables hardware-specific configuration, performance tuning and connectivity management.

• HPE StoreVirtual VSA

With HPE StoreVirtual VSA you can use the power of virtualization to create a virtual array within your host server. Manage it as a single pool of shared storage capacity, and scale it to match your evolving needs. HPE ProLiant Gen9 servers include a 3-year limited license for HPE StoreVirtual VSA software with 1TB of capacity at no extra cost. Simply select to install HPE StoreVirtual VSA software during server setup within Intelligent Provisioning. More information, instructional videos, and free console management software are available at http://www.hpe.com/info/vsa1TB

NOTE: For more information about Storage Software including QuickSpecs, please see:

security and ease of use. HPE ProLiant servers with ClearOS give you a simple, secure, and affordable

(SCE)

operating system with an intuitive web based graphical user interface that provides a cloud-like experience on- premise, and an Application Marketplace with over 100 apps and growing. Whether you’re starting out

configurations in 3 to 5 minutes. You may then send the configuration on for configuration help, or use in your existing ordering processes. If you require "custom" rack configuration or configuration for products not available in SCE, please contact Hewlett Packard Enterprise Customer Business Center or an

Authorized Partner for assistance.

QuickSpecs

Service and Support

HPE Support

HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and stability.

purchase your new server, giving you full entitlement to the support for need for your IT and business.

Connect your

Unlock all of the benefits of your technology investment by connecting your products to Hewlett Packard

matic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE Datacenter Care

Recommended

Standard: HPE Foundation Care 24x7, three-year Support Service

https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf

Parts and Materials

Hewlett Packard Enterprise will provide Hewlett Packard Enterprise-supported replacement parts and

replaced by Hewlett Packard Enterprise due to malfunction.

Related Services

HPE Server Hardware Installation

HPE Virtual Connect modules (Ethernet and Fibre Channel), Ethernet network interconnects, and

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Services

devices

Support

Connect to Hewlett Packard Enterprise to help prevent problems and solve issues faster. HPE Support Services enable you to choose the right service level, length of coverage and response time as you

Enterprise. Achieve up to 77%1 reduction in down time, near 100%2 diagnostic accuracy and a single consolidated view of your environment. By connecting, you will receive 24x7monitoring, pre-failure alerts, auto Service customers will also benefit from proactive activities to help prevent issues and increase optimization. All of these benefits are already available to you with your server storage and networking products, securely connected to Hewlett Packard Enterprise support.

1- IDC 2 – HP CSC reports 2014 - 2015

HPE Foundation Care 24x7 gives you access to Hewlett Packard Enterprise 24 hours a day, seven days a week for assistance on resolving issues. This service includes need based Hardware onsite response within four hours. In addition, collaborative software support is included in this service that provides troubleshooting assistance on industry leading software running on your HPE server. Simplify your support experience and make Hewlett Packard Enterprise your first call to help resolve hardware or software problems.

https://www.hpe.com/h20195/V2/GetDocument.aspx?docname=4AA4-8876ENW&cc=us&lc=en

Optimized: HPE Proactive Care* with 24x7 coverage, three year Support Service

HPE Proactive Care gives customers an enhanced call experience. When your products are connected to Hewlett Packard Enterprise, Proactive Care helps prevent problems and maintains IT stability by utilizing personalized proactive reports with recommendations and advice. This service combines three years proactive reporting and advice with our 24x7 coverage, four hour hardware response time when there is a problem. This service also includes collaborative software support for Independent Software Vendors (ISVs), (Red Hat, VMWare, Microsoft, etc.) running on your HPE servers.

materials necessary to maintain the covered hardware product in operating condition, including parts and materials for available and recommended engineering improvements.

Parts and components that have reached their maximum supported lifetime and/or the maximum usage limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product data sheet will not be provided, repaired, or replaced as part of these services.

The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives

Provides for the basic hardware installation of Hewlett Packard Enterprise branded servers, storage devices and networking options to assist you in bringing your new hardware into operation in a timely and professional manner.

https://www.hpe.com/h20195/V2/GetPDF.aspx/5981-9356EN.pdf

HPE Installation and Startup Service

Provides for the installation and startup of Hewlett Packard Enterprise technology including BladeSystems, C-Class enclosure, HPE ProLiant c-Class and Integrity server blades, storage blades, SAN switch blades,

Page

QuickSpecs

Servi

Page 13

InfiniBand, as well as the installation of one supported operating system type (Windows® or Linux).

to your dynamic business.

HPE Education

Book

http://www.hpe.com/ww/learn

HPE Support Center

The HPE Support Center is a personalized online support portal with access to information, tools and

For more information: http://www.hpe.com/services

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

ce and Support

HPE Technology Services Support Credits

Offer flexible services and technical skills to meet your changing IT demands. With a menu of service that is tailored to suit your needs, you get additional resources and specialist skills to help you maintain peak performance of your IT. Offered as annual credits, you can plan your budgets while proactively responding

Keep your IT staff trained making sure they have the right skills to deliver on your business outcomes.

Services

on a class today and learn how to get the most from your technology investment.

experts to support Hewlett Packard Enterprise business products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access support resources or collaborate with peers.

Learn more

http://www.hpe.com/support/hpesc

The Hewlett Packard Enterprise Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for live support. Now, you can get access to personalized IT support anywhere, anytime. HPE Insight Remote Support and HPE Support Center are available at no additional cost with a Hewlett Packard Enterprise warranty, HPE Support Service or Hewlett Packard Enterprise contractual support agreement.

NOTE: *HPE Support Center Mobile App is subject to local availability.

QuickSpecs

tion9 (Gen9)

Pre

For the Standard Features shipped in the "Factory Integrated Models", please see the "Configuration Information - Factory

Please refer to your installation instructions for proper tools and number of people to use for any installation.

Entry Models

[SKU Number]

830011-B21

833870-B21

777424-B21

777425-B21

Model Name

HPE ProLiant DL120

Gen9 E5

550W PS Entry Server

HPE ProLiant DL120

550W PS Entry Server

HP ProLiant DL120

Entry Server

HP ProLiant DL120

Entry Server

Processor

Intel® Xeon® E5-

Intel® Xeon® E5-2630v3

Number of Processors

One

Network Controller

HPE Embedded Dual Port 361i Adapter Network Interface

Storage Controller

HPE Dynamic Smart

Array B140i

HPE H240 Smart Host

Bus Adapter

HPE Dynamic Smart

Array B140i

HPE H240 Smart Host

Bus Adapter

Hard Drive

None ship standard

Internal Storage

4 LFF HDD Bays

8 SFF HDD Bays

4 LFF HDD Bays

8 SFF HDD Bays

Optical Drive Bay

1; (Optional: DVD-ROM, DVD-RW)

PCI-Express Slots

1 PCIe LP standard/up to 3 PCIe slots (optional)

Power Supply

(1) HPE 550W FIO Power Supply

Fans

3 hot swap fans, non-redundant

Management

out

(optional only for DL), iLO Advanced (optional)

Form Factor

Rack (1U), HPE Easy Install Rails

Warranty

Server Warranty includes 3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day

response.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Genera

-configured Models

Integrated Models" section.

1. Pre-configured models ship with the configurations below. Options can be selected from the Core or Additional options section of this QuickSpecs.

2. Hewlett Packard Enterprise does not allow factory integration of options into pre-configured models. Any additional options purchased will be shipped separately.

3. If you desire a custom configuration please see "Configuration Information - Factory Integrated Models" section of this QuickSpecs.

NOTE: All Pre-configured Models come populated with some hard drive blanks installed. Should the customer need additional hard drive blanks, they can order more using either HPE SFF Hard Drive Blank Kit (666987-B21) or HPE LFF Hard Drive Blank Kit (666986-B21). NOTE: All pre-configured servers ship with a standard 6-foot IEC C-13/C-14 jumper cord (A0K02A). This jumper cord is also included with each standard AC power supply option kit. If a different power cord is required, please check the ProLiant Power Cables web page.

CAUTION: Hewlett Packard Enterprise recommends that a minimum of two people are required for all Rack Server installations.

Memory

-2603v4 8GB-

R B140i 4LFF SATA

2603v4

8GB (1x8GB Registered DIMMs, 2400 MHz) 4GB (1x4GB Registered

Gen9 E5-2630v4

8GB-R H240 8SFF

2630v4

Gen9 E5-2603v3 4GB-

R B140i 4LFF 550W PS

2603v3

DIMMs, 2133 MHz)

Gen9 E5-2630v3 8GB-R

H240 8SFF 550W PS

8GB (1x8GB Registered

DIMMs, 2133 MHz)

iLO Management (standard), Intelligent Provisioning (standard), iLO Essentials (optional), iLO Scale-

Page

QuickSpecs

Smart Buy

[SKU Number]

839295-S01

839296-S01

860069-S01

Model Name

HP ProLiant DL120 Gen9 E5-

HPE ProLiant DL120 Gen9 E5-

Processor

Intel® Xeon® E5-2609v4

Intel® Xeon® E5-2620v4

Intel® Xeon® E5-1620v4

Number of Processors

One

Memory

8GB (1x8GB Registered

8GB (1x8GB Registered DIMMs,

Network Controller

HPE Embedded Dual Port 361i Adapter Network Interface

Storage Controller

HPE Dynamic Smart Array B140i

Hard Drive

None ship standard

Internal Storage

8 SFF HDD Bays

Optical Drive Bay

PCI-Express Slots

1 PCIe LP standard/up to 3 PCIe slots (optional)

Power Supply

One (1) HPE 550W FIO Power

One (1) 900W Redundant Capable Power Supply Kit

Fans

3 hot swap fans, non-redundant

Management

Standard: iLO Management

Optional: iLO Essentials, iLO Advanced, Insight Control

Form Factor

Rack (1U), HPE Easy Install Rails

Warranty

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Models

2609v4 1.7GHz 8-core 8GB-R

B140i 8SFF 550W PS

USServer/S-Buy

DIMMs, 2400MHz)

NOTE: DIMMs will operate at

1866MHz with this processor.

None Included; (Optional: DVD-ROM, DVD-RW)

Supply

2620v4 2.1GHz 8-core 8GB-R

H240 8SFF 550W PS

USServer/S-Buy

DIMMs, 2400MHz)

NOTE: DIMMs will operate at

2133MHz with this processor.

1620v4 3.5GHz 4-core 8GB-R

SFF US Server/S-Buy

2400MHz)

NOTE: DIMMs will operate at

2400MHz with this processor.

3-Year Parts, 1-Year Labor, 1-Year Onsite support with next business day response.

Page

QuickSpecs

Configuration Information

Step 1: Base Configuration (choose one of the following configurable models)

CTO Server

HPE ProLiant DL120 Gen9 8SFF

HPE ProLiant DL120 Gen9

SKU Number

777426-B21

777427-B21

777428-B21

Processor

1 1 1

DIMM Slots

8 DIMM slots for RDIMM, LRDIMM DDR4 Memory

Storage Controller

HPE Dynamic Smart Array B140i

PCIe

1 PCIe LP standard/up to 3 PCIe slots (optional)

Drive Cage

8SFF Hot Plug

4LFF Hot Plug

4LFF Non Hot Plug

Network Controller

HPE Embedded Dual Port 361i Adapter Network Interface

Fans

3 hot swap fans, non-redundant

Management

iLO Management (standard), Intelligent Provisioning (standard)

USB

1 front, 1 internal, 2 rear

Ears

HPE Thumbscrew Ears

NOTE: HPE ProLiant DL120 Gen9 Non-hot plug CTO Server (754525-B21) supports both 4LFF and 8LFF configurations. NOTE: Thumb screw ears are not supported on Hot Plug LFF CTO Server.

Step 2: Choose Required Options (only one of the following from each list unless otherwise noted)

HPE Processors

E5-2600v4 series Processors

HPE DL120 Gen9 Intel® Xeon® E5-2620v4 (2.1GHz/8-core/20MB/85W) FIO Processor Kit

803116-L21

HPE DL120 Gen9 Intel® Xeon® E5-2623v4 (2.6GHz/4-core/10MB/85W) FIO Processor Kit

803117-L21

HPE DL120 Gen9 Intel® Xeon® E5-2609v4 (1.7GHz/8-core/20MB/85W) FIO Processor Kit

803118-L21

HPE DL120 Gen9 Intel® Xeon® E5-2603v4 (1.7GHz/6-core/15MB/85W) FIO Processor Kit

803119-L21

HPE DL120 Gen9 Intel® Xeon® E5-2650Lv4 (1.7GHz/14-core/35MB/65W) FIO Processor Kit

803120-L21

HPE DL120 Gen9 Intel® Xeon® E5-2630Lv4 (1.8GHz/10-core/25MB/55W) FIO Processor Kit

803121-L21

HPE DL120 Gen9 Intel® Xeon® E5-2660v4 (2.0GHz/14-core/35MB/105W) FIO Processor Kit

803112-L21

HPE DL120 Gen9 Intel® Xeon® E5-2650v4 (2.2GHz/12-core/30MB/105W) FIO Processor Kit

803113-L21

HPE DL120 Gen9 Intel® Xeon® E5-2640v4 (2.4GHz/10-core/25MB/90W) FIO Processor Kit

803114-L21

HPE DL120 Gen9 Intel® Xeon® E5-2690v4 (2.6GHz/14-core/35MB/135W) FIO Processor Kit

870694-L21

HPE DL120 Gen9 Intel® Xeon® E5-2695v4 (2.1GHz/18-core/45MB/120W) FIO Processor Kit

803123-L21

HPE DL120 Gen9 Intel® Xeon® E5-2698v4 (2.2GHz/20-core/50MB/135W) FIO Processor Kit

803125-L21

HPE DL120 Gen9 Intel® Xeon® E5-2699v4 (2.2GHz/22-core/55MB/145W) FIO Processor Kit

803127-L21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

- Factory Integrated Models

This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are ordered, Hewlett Packard Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for information on configurable product offerings and requirements.

1. Factory Integrated Models must start with a CTO Server.

2. FIO indicates that this option is only available as a factory installable option.

3. All Factory Integrated Models will be populated with sufficient hard drive blanks based on the number of initial hard drives ordered with the server.

4. Some options may not be integrated at the factory. Contact your local sales representative for additional information.

Configure-to-order Server

4LFF Configure-to-order Server

Non-hot Plug 4LFF Configure-

to-order Server

Page

QuickSpecs

Configuration Information

Page 17

HPE DL120 Gen9 Intel® Xeon® E5-2630v4 (2.2GHz/10-core/25MB/85W) FIO Processor Kit

803115-L21

E5-1600v4 series Processors

HPE DL120 Gen9 Intel® Xeon® E5-1620v4 (3.5GHz/4-core/10MB/140W) Processor Kit

803133-L21

HPE DL120 Gen9 Intel® Xeon® E5-1650v4 (3.6GHZ/6-core/15MB/140W) Processor Kit

803135-L21

NOTE: Only one processor is supported on the HPE ProLiant DL120 Gen9

NOTE: DDR speed is the maximum memory speed of the processor. Actual memory speed may depend on

the quantity and type of DIMMs installed.

NOTE: When v4 Processor is selected, then only PC4-2400T Memory Kit can be selected.

NOTE:

Processor SKU, x = L for low power SKUs and v# (not yet designated) = version number.

NOTE: Processor upgrade from E5-2600v3 to E5-2600v4 is supported for processors up to 105W. Please refer to DL120 Gen9 User Guide for more details.

HPE Memory

NOTE: Select one or more memory kits from below.

NOTE: LRDIMM, RDIMM are all distinct memory technologies and cannot be mixed within a server. The

NOTE: HPE memory from previous generation servers are not qualified or warranted with this HPE

enhanced functionality listed in this document for Gen9.

Features, see: http://www.hp.com/go/proliant-energy-efficient.

NOTE: Depending on the memory configuration and processor model, the memory speed may run at

Online Memory Configuration Tool at: http://www.hpe.com/servers/ddr4memoryconfig.

Registered DIMMs (RDIMMs) for E5-2600v4 Series

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805347-B21

HPE 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805349-B21

HPE 16GB (1x16GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

836220-B21

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805351-B21

Load Reduced DIMMs (LRDIMMs) for E5-2600v4 Series

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit

805353-B21

HPE Standard Memory for E5-2600v4 Series

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Standard Memory Kit

851353-B21

NOTE: Standard Memory DIMMs have no SmartMemory features.

HPE Power

NOTE: Prior to selecting a power supply option, it is highly recommended that you review your server

configuration. The HPE Power Advisor is located at: http://www.hpe.com/info/hppoweradvisor.

NOTE: By selecting RPS Enablement Kit power options, mixing of power supplies in the same RPS

experience operational issues with your server

HPE Entry-Level Power Supplies

HP 550W FIO Power Supply Kit

730941-B21

HPE 900W AC 240VDC Power Input Module FIO Kit

828734-B21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

- Factory Integrated Models

For the Intel® C600 Chipset E5-2600 Series, the letter preceding the model number indicates the

Product Line (E3, E5, E7); 2600x v#, 2 = number of CPUs in a Node, 6 is socket/segment designation, 00 =

majority of ProLiant Gen9 servers support LRDIMM and RDIMM.

ProLiant Server. HPE SmartMemory is required to realize the memory performance improvements and

NOTE: If only one processor is installed, only half of the total DIMM slots are available. When populating with two processors all DIMM slots are available.

NOTE: Kits described as LP include Low Power DIMMs. For more information on ProLiant Energy Efficient

2400MHz, 2133MHz, 1866MHz, 1600MHz or 1333MHz. Please see Memory Population Table or the

Supplies

configuration in the HPE Power Advisor tool to determine the right size power supply for your server

enablement kit is not supported. All power supplies must be of the same input voltage, output rating, and efficiency rating. If non-matching power supplies are installed, you may receive an error message and/or

QuickSpecs

Configuration Information

Page 18

NOTE: RPS Backplane is mandatory to be chosen with this power input module.

HPE 900W AC 240VDC RPS Power Backplane FIO Kit

NOTE: This RPS backplane is mandatory to be chosen along with 900W RPS input module.

828735-B21

HPE I/O Expansion Kits

HP DL60/120 Gen9 CPU1 Riser FIO Kit

765508-B21

HPE Security Kits

HP DL120 Gen9 Quick Release Ear FIO Kit

787194-B21

HP DL120 Gen9 Thumbscrew Ear FIO Kit

787198-B21

Step 3: Choose Additional Factory Integratable Options (only one of the following from each list unless otherwise noted)

HPE Storage

NOTE: If not using the embedded B140i controller as primary controller, must select one of the following

HP Storage Controllers noted below depending on CTO Server model selected in Step 1.

HPE Smart Array Controllers

HP Smart Array P440/4GB FBWC 12Gb 1-port Int FIO SAS Controller

DL120 Gen9 8SFF CTO Server (777426-B21) is selected in Step 1.

761872-B21

HPE Smart Host Bus Adapters

NOTE: May be selected instead of embedded B140i controller.

761873-B21

HPE Cable Options

using the embedded B140i controller as the primary storage controller

777331-B21

HP DL120 Gen9 8SFF Smart Array B140i Cable FIO Kit

using the embedded B140i controller as the primary storage controller

777415-B21

BIOS Mode

Setting.

758959-B22

Controller State

792962-B21

HP AHCI-Enable FIO Setting

NOTE: If B140i is the primary controller then RAID is not allowed with this selection.

801845-B21

HPE Insight Software

HP Insight Control including 1yr 24x7 Support ProLiant ML/DL/BL-bundle Single Server FIO

C6N36A

HPE Converged

HPE OneView Advanced (with HPE iLO Advanced)

HP OneView for ProLiant DL Server incl 3yr 24x7 Supp FIO Bundle Physical 1 Svr Lic

E5Y43A

HPE OneView Advanced (without HPE iLO Advanced)

HP OneView w/o iLO including 3yr 24x7 Support FIO 1 Server LTU

P8B31A

Step 4: Choose Additional Options for Factory Integration from Core and Additional Options Sections below

CAUTION: Hewlett Packard Enterprise recommends that a minimum of two people are

proper tools and number of people to use for any installation.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

- Factory Integrated Models

Controllers

NOTE: If HPE ProLiant DL120 Gen9 4LFF CTO Server (777427-B21) or HPE ProLiant

HP H240 12Gb 1-port Int FIO Smart Host Bus Adapter

HP DL60/80/120 Gen9 4LFF Cable FIO Kit

NOTE: Must be selected with HPE ProLiant DL120 Gen9 4LFF CTO Server (777427-B21) if

NOTE: Must be selected with HPE ProLiant DL120 Gen9 8SFF CTO Server (777426-B21) if

HP Legacy FIO Mode Setting

NOTE: If B140i is the primary storage controller, then this option cannot be selected.

NOTE: Selecting this option will change the default UEFI BIOS Setting into Legacy BIOS

HP Mfg FIO Enable HBA Mode Setting

NOTE: Can only be selected with H240 FIO Smart Host Bus Adapter.

NOTE: If H240 is the primary controller then RAID is not allowed with this selection.

License

Infrastructure Management Software

required for all Rack Server installations. Please refer to your installation instructions for

QuickSpecs

ProLiant DL120 Generation9 (Gen9)

Core Options

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard

information.

HPE Unique Options

HP DL60/120 Gen9 FlexibleLOM Riser Kit

765509-B21

Memory Selection

recommends memory from the list located here: http://www.hpe.com/products/recommend.

HPE Memory

Registered DIMMs (RDIMMs) for E5-2600v4 Series

HP 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805347-B21

HP 16GB (1x16GB) Single Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805349-B21

HPE 16GB (1x16GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

836220-B21

HP 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Registered Memory Kit

805351-B21

HPE 8GB (1x8GB) Single Rank x8 DDR4-2400 CAS-17-17-17 Registered Standard Memory Kit

851353-B21

Registered DIMMs (RDIMMs) for E5-2600v3 Series

HP 4GB (1x4GB) Single Rank x8 DDR4-2133 CAS-15-15-15 Registered Memory Kit

726717-B21

HPE 4GB (1x4GB) Single Rank x8 DDR4-2133 CAS-15-15-15 Registered Standard Memory Kit

803026-B21

HP 8GB (1x8GB) Single Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit

726718-B21

HP 8GB (1x8GB) Dual Rank x8 DDR4-2133 CAS-15-15-15 Registered Memory Kit

759934-B21

HPE 8GB (1x8GB) Single Rank x4 DDR4-2133 CAS-15-15-15 Registered Standard Memory Kit

803028-B21

HP 16GB (1x16GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit

726719-B21

HP 32GB (1x32GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Registered Memory Kit

728629-B21

Load Reduced DIMMs (LRDIMMs) for E5-2600v4 Series

HPE 32GB (1x32GB) Dual Rank x4 DDR4-2400 CAS-17-17-17 Load Reduced Memory Kit

805353-B21

Load Reduced DIMMs (LRDIMMs) for E5-2600v3 Series

HP 16GB (1x16GB) Dual Rank x4 DDR4-2133 CAS-15-15-15 Load Reduced Memory Kit

726720-B21

HP 32GB (1x32GB) Quad Rank x4 DDR4-2133 CAS-15-15-15 Load Reduced Memory Kit

726722-B21

HPE Optical Drives

HPE 9.5mm SATA DVD-ROM JackBlack Gen9 Optical Drive

726536-B21

HPE 9.5mm SATA DVD-RW JackBlack G9 Optical Drive

726537-B21

HPE Drives

SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870753-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872475-B21

HPE 300GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD

759208-B21

HPE 300GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD

785067-B21

HPE 450GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD

759210-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870757-B21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE

Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional

To streamline the configuration process for HPE ProLiant Gen9 servers and to provide the best product availability, HPE

Page

QuickSpecs

Core Options

Page 20

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

870763-B21

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty HDD

759212-B21

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872477-B21

HPE 600GB SAS 12G Enterprise 10K SFF (2.5in ) SC 3yr Wty HDD

781516-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

870759-B21

HPE 900GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

870765-B21

HPE 900GB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD

785069-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty Digitally Signed Firmware HDD

872479-B21

HPE 1.2TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty HDD

781518-B21

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

872481-B21

HPE 1.8TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e HDD

791034-B21

HPE 2.4TB SAS 12G Enterprise 10K SFF (2.5in) SC 3yr Wty 512e Digitally Signed Firmware HDD

881457-B21

SAS Hot Plug SFF (2.5-inch) Midline (MDL) Drives

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

832514-B21

SAS Hot Plug LFF (3.5-inch) Enterprise (ENT) Drives

HPE 300GB SAS 12G Enterprise 15K LFF (3.5in) SCC 3yr Wty HDD

737261-B21

HPE 450GB SAS 12G Enterprise 15K LFF (3.5in) SCC 3yr Wty HDD

737394-B21

HPE 600GB SAS 12G Enterprise 15K LFF (3.5in) SC 3yr Wty HDD

765424-B21

SAS Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HPE 1TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

846524-B21

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872485-B21

HPE 2TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

818365-B21

HPE 3TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

846528-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872487-B21

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

818367-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

846514-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819201-B21

HPE 8TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

861590-B21

HPE 10TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857644-B21

SATA Hot Plug SFF (2.5-inch) Midline (MDL) Drives

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty Digitally Signed Firmware HDD

655710-B21

SATA Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861691-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872489-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861676-B21

HPE 3TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

861693-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

872491-B21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

QuickSpecs

Core Options

Page 21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861752-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty HDD

861678-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861750-B21

HPE 6TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Digitally Signed Firmware HDD

846510-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

861594-B21

HPE 8TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

819203-B21

HPE 10TB SATA 6G Midline 7.2K LFF (3.5in) SC 1yr Wty Helium 512e Digitally Signed Firmware HDD

857648-B21

SATA Non-Hot Plug LFF (3.5-inch) Midline (MDL) Drives

HPE 1TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD

801882-B21

HPE 2TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD

801884-B21

HPE 4TB SATA 6G Midline 7.2K LFF (3.5in) RW 1yr Wty HDD

801888-B21

6G SATA Hot Plug SFF (2.5-inch) SC 512e Drives

HPE 1TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765453-B21

HPE 2TB SATA 6G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765455-B21

SSD Selection

http://www.hpe.com/products/recommend

12G SAS Hot Plug SFF (2.5-inch) Mixed Use SC Solid State Drives

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873359-B21

HPE 400GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872374-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873363-B21

HPE 800GB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872376-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873365-B21

HPE 1.6TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872382-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873367-B21

HPE 3.2TB SAS 12G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872386-B21

12G SAS Hot Plug LFF (3.5-inch) Mixed Use SC Solid State Drives

HPE 800GB SAS 12G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872378-B21

12G SAS Hot Plug SFF (2.5-inch) SC Midline 512e Drives

HPE 600GB SAS 12G Enterprise 15K SFF (2.5in) SC 3yr Wty 512e HDD

748387-B21

HPE 1TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e Digitally Signed Firmware HDD

765464-B21

HPE 2TB SAS 12G Midline 7.2K SFF (2.5in) SC 1yr Wty 512e HDD

765466-B21

12G SAS Hot Plug LFF (3.5-inch) SC 512e Performance Drives

HPE 4TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861756-B21

HPE 6TB SAS 12G Midline 7.2K LFF (3.5in) SC 1yr Wty 512e HDD

861754-B21

12G SAS Hot Plug SFF (2.5-inch) SC Read Intensive Solid State Drives

HPE 480GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875311-B21

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872390-B21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

To streamline the configuration process for HPE ProLiant Gen9 servers and to provide the best product availability, HPE recommends SSDs from the list located here:

QuickSpecs

Core Options

Page 22

HPE 960GB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875313-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872392-B21

HPE 1.92TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875326-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872394-B21

HPE 3.84TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875330-B21

SSD

12G SAS Hot Plug SFF (2.5-inch) SC Write Intensive Solid State Drives

HPE 400GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873351-B21

HPE 800GB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873355-B21

HPE 1.6TB SAS 12G Write Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

873357-B21

6G SATA Hot Plug SFF (2.5-inch) Write Intensive Solid State Drives

HPE 400GB SATA 6G WI SFF SC DS SSD

872355-B21

HPE 800GB SATA 6G WI SFF SC DS SSD

872359-B21

HPE 1.6TB SATA 6G WI SFF SC DS SSD

872363-B21

6G SATA Hot Plug SFF (2.5-inch) Mixed Use Solid State Drives

HPE 240GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

880295-B21

HPE 240GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875483-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877776-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875470-B21

HPE 480GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872344-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877782-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872348-B21

HPE 960GB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875474-B21

HPE 1.6TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty SSD

804631-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877788-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

872352-B21

HPE 1.92TB SATA 6G Mixed Use SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875478-B21

6G SATA Hot Plug LFF (3.5-inch) Write Intensive Solid State Drives

HPE 400GB SATA 6G WI LFF SCC DS SSD

872357-B21

HPE 800GB SATA 6G WI LFF SCC DS SSD

872361-B21

HPE 1.6TB SATA 6G WI LFF SCC DS SSD

872365-B21

6G SATA Hot Plug LFF (3.5-inch) Mixed Use Solid State Drives

HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

875472-B21

HPE 480GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872346-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

877784-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

875476-B21

HPE 960GB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

872350-B21

HPE 1.6TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty SSD

804634-B21

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

877790-B21

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

HPE 7.68TB SAS 12G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware

870144-B21

QuickSpecs

Core Options

Page 23

HPE 1.92TB SATA 6G Mixed Use LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

875480-B21

6G SATA Hot Plug SFF (2.5-inch) SC Read Intensive Solid State Drives

HPE 150GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869374-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877740-B21

HPE 240GB SATA 6G RI SFF SC DS SSD

868814-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869376-B21

HPE 240GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875503-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877746-B21

HPE 480GB SATA 6G RI SFF SC DS SSD

868818-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869378-B21

HPE 480GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875509-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877752-B21

HPE 960GB SATA 6G RI SFF SC DS SSD

868822-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869384-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

875511-B21

HPE 960GB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty SSD

871768-B21

HPE 1.6TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

869386-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877758-B21

HPE 1.92TB SATA 6G RI SFF SC DS SSD

868826-B21

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

871770-B21

SSD

HPE 3.84TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware SSD

877764-B21

HPE 3.84TB SATA 6G RI SFF SC DS SSD

868830-B21

6G SATA Hot Plug LFF (3.5-inch) SC Read Intensive Solid State Drives

HPE 480GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

877748-B21

HPE 480GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

869380-B21

SSD

HPE 1.6TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

869388-B21

HPE 1.92TB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware SSD

877760-B21

Read Intensive - 6G SATA - M.2 - Solid State Drives

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

HPE 1.92TB SATA 6G Read Intensive SFF (2.5in) SC 3yr Wty Digitally Signed Firmware

HPE 960GB SATA 6G Read Intensive LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware

875513-B21

877754-B21

QuickSpecs

Core Options

Page 24

HPE 150GB SATA 6G Read Intensive M.2 2280 3yr Wty Digitally Signed Firmware SSD

875317-B21

M.2 SSD

HPE Universal SATA HHHL 3yr Wty M.2 Kit

878783-B21

HP DL60/120 Gen9 M.2 Cable Kit

805283-B21

NOTE: M.2 drives go in PCIe slot and use B140i SATA controller.

Hard Drive Blank Kits

HPE Large Form Factor Hard Drive Blank Kit

666986-B21

HPE Small Form Factor Hard Drive Blank Kit

666987-B21

HPE Networking

1 Gigabit Ethernet adapters

HPE Ethernet 1Gb 4-port 331T Adapter

647594-B21

HPE Ethernet 1Gb 2-port 332T Adapter

615732-B21

HPE Ethernet 1Gb 2-port 361T Adapter

652497-B21

HPE Ethernet 1Gb 4-port 366T Adapter

811546-B21

10 Gigabit Ethernet adapters

HPE Ethernet 10Gb 2-port 530SFP Adapter

652503-B21

HPE Ethernet 10Gb 2-port 530T Adapter

656596-B21

HPE Ethernet 10Gb 2-port 546SFP+ Adapter

779793-B21

HPE Ethernet 10Gb 2-port 546FLR-SFP+ Adapter

779799-B21

HPE Ethernet 10Gb 2-port 560SFP+ Adapter

665249-B21

HPE Ethernet 10Gb 2-port 561T Adapter

716591-B21

HPE Ethernet 10Gb 2-port 562SFP+ Adapter

727055-B21

NOTE: A minimum of two Gigabytes (2 GB) of server memory is required per each

below.

25 Gigabit Ethernet adapters

HPE Ethernet 4x25Gb 1-port 620QSFP28 Adapter

817762-B21

FlexibleLOM Adapters

HPE Ethernet 1Gb 4-port 331FLR Adapter

629135-B22

HPE Ethernet 1Gb 4-port 366FLR Adapter

665240-B21

HPE FlexFabric 10Gb 2-port 533FLR-T Adapter

700759-B21

HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter

700751-B21

HPE FlexFabric 10Gb 4-port 536FLR-T Adapter

764302-B21

HPE Ethernet 10Gb 2-port 560FLR-SFP+ Adapter

665243-B21

HPE Ethernet 10Gb 2-port 561FLR-T Adapter

700699-B21

HPE Ethernet 10Gb 2-port 562FLR-SFP+ Adapter

727054-B21

NOTE: Please see the QuickSpecs for Technical Specifications and additional information: http://www.hpe.com/servers/ProLiantNICs.

HPE InfiniBand

HPE InfiniBand FDR/Ethernet 10Gb/40Gb 2-port 544+QSFP Adapter

764284-B21

NOTE: Please see the HPE InfiniBand Options for HP ProLiant and Integrity Servers

QuickSpecs for additional information.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

NOTE: 805283-B21 cable kit is a mandatory option required to support M.2 SSDs.

adapter. NOTE: Direct Attach Cable (DAC) for copper environments or fiber transceivers and cables for fiber-optic environments must be purchased separately. See cables/options

NOTE: FlexibleLOM riser kit (765509-B21) is required when any FlexibleLOM is selected.

QuickSpecs

Core Options

Page 25

HPE I/O Expansion

HP DL60/120 Gen9 FlexibleLOM Riser Kit

765509-B21

HP DL60/120 Gen9 Full Height Half Length PCIe Riser Kit

765510-B21

HP DL120 Gen9 GPU Enablement Kit

779611-B21

HPE Power

HPE Entry-Level Power Supplies

HPE 900W Standard AC 240VDC Power Input Module

775595-B21

HPE 900W Standard AC 240VDC RPS Power Backplane

814835-B21

HPE 900W Standard AC 240VDC Redundant Power Supply Kit

820792-B21

HP DL60/120 Gen9 Redundant Fan Kit

765513-B21

NOTE: Fan redundancy is not supported for processors exceeding 105W.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Options

Supplies

NOTE: This part number can only be bought standalone and is for field integration only. NOTE: RPS Backplane is mandatorily needed with this power input module.

NOTE: This part number can only be bought standalone and is for field integration only. NOTE: This RPS backplane is mandatorily needed with 900W RPS input module.

NOTE: This Redundant Power supply kit includes 2 power supply input module and 1

backplane kit.

NOTE: This part number is both factory installed option and filed integrable option. NOTE: This Power supply supports both 100-240V AC and 240V DC. NOTE: Supports Gold-level efficiency (92%) with a standard C14 inlet connector. No

support for HPE Power Discovery Services. Only compatible with select HPE ProLiant Gen9 Essential servers. NOTE: HPE 900W Gold (Redundant) AC 240VDC Power Input Module (775595-B21) must be used with Power Backplane (814835-B21). NOTE: Each Redundant Power Supply Backplane can support up to two (2) power input modules. NOTE: Redundant AC Power Input Modules do not share power. Redundant AC Power Input Module #1 is the primary AC Power Input Module. Redundant AC Power Input Module #2 is the backup AC Power Input Module. NOTE: Mixing of power supplies in the same server is not supported. All power supplies must be of the same input voltage, output rating, and efficiency rating. If non-matching power supplies are installed, you may receive an error message and/or experience operational issues with your server. NOTE: Prior to selecting a power supply option, it is highly recommended that you review your server configuration in the HPE Power Advisor tool to determine the right size power supply for your server configuration. The HPE Power Advisor is located at:

http://www.hpe.com/info/hppoweradvisor.

HPE Cooling Options

NOTE: Includes two fans and is required to move from non-redundant to redundant

configurations.

QuickSpecs

Additional Options

NOTE: Some options may not be integrated at the factory. To ensure only valid configurations are ordered, Hewlett Packard

information.

HPE Insight

HPE Insight Control including 1yr 24x7 Technical Support and Updates 1-server LTU

C6N27A

HPE Insight Control including 1yr 24x7 TSU E-LTU

C6N28ABE

HPE Insight Control Upgrade from iLO Advanced including 1yr 24x7 Support E-LTU

C6N38ABE

NOTE: For additional license options please see the HPE Insight Control QuickSpecs.

Embedded

HPE iLO Advanced

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates 1-server LTU

512485-B21

HPE iLO Advanced including 3yr 24x7 Tech Support and Updates 1-server LTU

BD505A

HPE iLO Advanced including 1yr 24x7 Technical Support and Updates E-LTU

E6U59ABE

HPE iLO Advanced including 3yr 24x7 Technical Support and Updates E-LTU

E6U64ABE

HPE iLO Essentials

HPE iLO Essentials including 3yr 24x7 Tech Support and Updates 1-server LTU

BD774A

HPE iLO Essentials including 1yr 24x7 Tech Support and Updates 1-server LTU

BD775A

HPE iLO Essentials including 3yr 24x7 Technical Support and Updates E-LTU

E6U61ABE

HPE iLO Essentials including 1yr 24x7 Technical Support and Updates E-LTU

E6U62ABE

HPE iLO Scale-out

HPE iLO Scale-Out 3yr 24x7 Tech Support and Updates Flexible Quantity LTU

BD776A

HPE iLO Scale-Out including 3yr 24x7 Tech Support and Updates Tracking LTU

BD777A

HPE iLO Scale-Out 1yr 24x7 Tech Support and Updates Flexible Quantity LTU

BD778A

HPE iLO Scale-Out including 1yr 24x7 Tech Support and Updates Flex Qty E-LTU

BD778AAE

HPE iLO Scale-Out including 1yr 24x7 Tech Support and Updates Tracking LTU

BD779A

HPE OneView Advanced (with HPE iLO Advanced)

HPE OneView including 3yr 24x7 Support Physical 1-server LTU

E5Y34A

HPE OneView including 3yr 24x7 Support Flexible Quantity E-LTU

E5Y35AAE

HPE OneView Physical Media Kit LTU

E5Y37A

HPE OneView Advanced (without HPE iLO Advanced)

HPE OneView w/o iLO including 3yr 24x7 Support 1-server LTU

P8B24A

HPE OneView w/o iLO including 3yr 24x7 Support Track 1-server LTU

P8B25A

HPE OneView w/o iLO including 3yr 24x7 Support Flexible Quantity E-LTU

P8B26AAE

NOTE: Full licenses of HPE OneView Advanced also provide the right-to-use HPE Insight

part of HPE OneView Advanced and provides multi-server OS and driver provisioning.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Enterprise recommends the use of an HPE approved configurator. Contact your local sales representative for additional

HPE Insight Control

Software

NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single

activation key. NOTE: Customer will receive a license entitlement certificate. The license entitlement certificate must be redeemed online or via fax in order to obtain the license activation key(s). Includes one year of 24x7 HPE Software Technical Support and Update Service. NOTE: Licenses ship without media. The HPE Insight Control Media Kit can be ordered separately, or can be downloaded at: https://www.hpe.com/info/insightmanagement.

Management

HPE Converged Infrastructure Management Software

Control without additional charge. NOTE: Server provisioning (via 'HPE Insight Control server provisioning') is licensed as

Page

QuickSpecs

Additional Options

Page 27

Media kit #BD883A can be ordered for a physical copy of this software (USB flash drive).

HPE Security

HPE Trusted Platform Module 2.0 Kit

745823-B21

HPE Trusted Platform Module Option

488069-B21

HPE 1U Security Bezel Kit

664918-B21

NOTE: Quick Release Ear FIO option kit (787194-B21) is required for installing security bezel.

HPE Storage

SAS Controllers

HPE Smart Array Controllers

HPE Smart Array P440/4GB FBWC 12Gb 1-port Int SAS Controller

726821-B21

HPE Smart Array P440/2GB FBWC 12Gb 1-port Int SAS Controller

820834-B21

NOTE: Includes the HPE Smart Storage Battery.

HPE Smart Array P441/4GB FBWC 12Gb 2-ports Ext SAS Controller

726825-B21

HPE Smart Host Bus Adapters

HPE H240 12Gb 2-ports Int Smart Host Bus Adapter

726907-B21

HPE H241 12Gb 2-ports Ext Smart Host Bus Adapter

726911-B21

HPE Cable Options

HP DL60/120 Gen9 4LFF Smart Array P440 SAS Cable Kit

777382-B21

HP DL60/120 Gen9 4LFF Smart HBA H240 SAS Cable Kit

777385-B21

HP DL120 Gen9 8SFF Smart Array P440 SAS Cable Kit

777418-B21

HP DL120 Gen9 8SFF Smart HBA H240 SAS Cable Kit

777421-B21

B140i SATA controller.

Optional Software

HPE Smart Array SR SmartCache (Single Key/Single Server) LTU

D7S26A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) LTU

D7S27A

HPE Smart Array SR SmartCache (Single Key/Multiple Servers) E-LTU

D7S27AAE

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

NOTE: Licenses ship without media. The HPE OneView Media Kit can be ordered

separately, or can be downloaded at: http://www.hpe.com/info/hpeoneview NOTE: Electronic and Flexible-Quantity licenses can be used to purchase multiple licenses with a single activation key.

NOTE: HPE Trusted Platform Module 2.0 Option works with Gen9 servers with UEFI Mode not Legacy Mode. It is not compatible with HPE ProLiant Gen8 servers or earlier generation variants. NOTE: HPE Gen9 servers purchased earlier may need the latest firmware update to be compatible with the TPM 2.0 Option. NOTE: HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced with any other TPM module.

NOTE: The HPE Trusted Platform Module Option (488069-B21) is the TPM 1.2 version. Compatible server platforms include Gen8 and Gen9 servers. NOTE: HPE server systems can have a TPM module (of any type) installed only once. It cannot be replaced with any other TPM module.

Controllers

NOTE: One of the above cables is required to be selected depending on the combination

of server model and storage controller. Cable option kit descriptions include the right server model and storage controllers names.

NOTE: NHP server model includes SATA cables required to connect drives to embedded

NOTE: HPE SmartCache is supported when one of the supported Smart Array

Controllers is installed in the server.

QuickSpecs

Additional Options

Page 28

HPE Smart Array SR Secure Encryption (Data at Rest Encryption/per Server Entitlement) E-LTU

Q2F26AAE

Optional Upgrades

HP 96W Smart Storage Battery with 145mm Cable for DL/ML/SL Servers

727258-B21

NOTE: This option is mandatorily required with HPE Smart Array controllers. One server

HPE Smart Array controllers.

HPE Tape Backup

NOTE: For the complete range of tape drives, autoloaders, libraries and media see:

as well.

Tape Drives

SAS Rack-Mount Tape Solutions

HPE StoreEver LTO-7 Ultrium 15000 Internal Tape Drive

BB873A

HPE StoreEver LTO-7 Ultrium 15000 External Tape Drive

BB874A

HPE StoreEver MSL LTO-7 Ultrium 15000 SAS Drive Upgrade Kit

N7P37A

HPE StoreEver MSL LTO-7 Ultrium 15000 FC Drive Upgrade Kit

N7P36A

HPE StoreEver LTO-6 Ultrium 6250 Tape Drive in a 1U Rack Mount Kit

C0L99A

HPE StoreEver LTO-6 Ultrium 6250 External Tape Drive

EH970A

HPE StoreEver MSL LTO-6 Ultrium 6250 SAS Drive Upgrade Kit

C0H27A

HPE StoreEver MSL LTO-6 Ultrium 6250 Fibre Channel Drive Upgrade Kit

C0H28A

HPE StoreEver LTO-5 Ultrium 3000 SAS Tape Drive in a 1U Rack Mount Kit

EJ014B

HPE StoreEver LTO-5 Ultrium 3000 SAS External Tape Drive

EH958B

HPE StoreEver MSL LTO-5 Ultrium 3000 SAS Drive Upgrade Kit

BL540B

HPE StoreEver LTO-4 Ultrium 1760 SAS (1) in a 1U Rack Mount Kit

EH946C

HPE StoreEver LTO-4 Ultrium 1760 SAS External Tape Drive

EH920B

HPE StoreEver 1U SAS Rack Mount Kit

AE459B

HPE DAT Autoloader

HPE StoreEver 1/8 G2 LTO-7 Ultrium 15000 SAS Tape Autoloader

N7P35A

HPE StoreEver 1/8 G2 LTO-7 Ultrium 15000 FC Tape Autoloader

N7P34A

HPE StoreEver 1/8 G2 LTO-6 Ultrium 6250 Fibre Channel Tape Autoloader

C0H19A

HPE StoreEver 1/8 G2 LTO-5 Ultrium 3000 SAS Tape Autoloader

BL536B

HPE MSL2024 Tape Library

HPE StoreEver MSL2024 0-drive Tape Library

AK379A

HPE MSL4048 Tape Library

HPE StoreEver MSL4048 0-drive Tape Library

AK381A

HPE StoreEver MSL6480

HPE StoreEver MSL6480 Scaleable Expansion Module

QU626A

HPE StoreEver MSL6480 Scalable Base Module

QU625A

NOTE:

HPE StoreEver MSL6480 Tape Library QuickSpecs for Technical

Specifications and additional information).

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

can accommodate only 1 Smart Storage Battery that would suffice the requirement of all

http://www.hpe.com/storage/storeever. For hardware and software compatibility of HPE tape backup

products http://www.hpe.com/storage/BURAcompatibility. NOTE: For Internal drives to be connected to DL servers please make sure that you order rack mount kit

Please see the

QuickSpecs

Additional Options

Page 29

HPE Disk Backup

HPE RDX Removable Disk Backup System

HPE RDX 4TB USB 3.0 Internal Disk Backup System

Q2R32A

HPE RDX 4TB USB 3.0 External Disk Backup System

Q2R33A

HPE RDX 3TB USB 3.0 Internal Disk Backup System

P9L71A

HPE RDX+ 3TB USB 3.0 External Disk Backup System

P9L72A

HPE RDX 2TB USB3.0 External Disk Backup System

E7X53B

HP RDX+ 1TB External Backup System

B7B69B

HP RDX+ 500GB External Backup System

B7B66B

HPE RDX+ External Docking System

C8S07B

HPE D3700 Enclosure

QW967A

HPE D3600 Enclosure

QW968A

HPE StoreOnce Backup systems

HPE StoreOnce 5100 48TB System

BB915A

HPE StoreOnce 3540 24TB System

BB914A

HPE StoreOnce 3520 12TB System

BB922A

HPE StoreOnce 3100 8TB System

BB913A

additional part numbers, Technical Specifications, and additional information

HPE Storage

Emulex Fibre Channel HBAs

HPE 82E 8Gb 2-port PCIe Fibre Channel Host Bus Adapter

AJ763B

HPE 81E 8Gb 1-port PCIe Fibre Channel Host Bus Adapter

AJ762B

HPE StoreFabric SN1100E 16Gb Dual Port Fibre Channel Host Bus Adapter

C8R39A

HPE StoreFabric SN1100E 16Gb Single Port Fibre Channel Host Bus Adapter

C8R38A

QLogic Fibre Channel HBAs

HPE 82Q 8Gb 2-port PCIe Fibre Channel Host Bus Adapter

AJ764A

HPE 81Q 8Gb 1-port PCIe Fibre Channel Host Bus Adapter

AK344A

HPE StoreFabric SN1000Q 16GB 1-port PCIe Fibre Channel Host Bus Adapter

QW971A

HPE StoreFabric SN1000Q 16GB 2-port PCIe Fibre Channel Host Bus Adapter

QW972A

Converged Network Adapter

HPE StoreFabric CN1200E 10Gb Converged Network Adapter

E7Y06A

HPE StoreFabric CN1100R Dual Port Converged Network Adapter

QW990A

HPE StoreFabric CN1200E 10GBASE-T Dual Port Converged Network Adapter

N3U51A

HPE StoreFabric CN1100R 10GBASE-T Dual Port Converged Network Adapter

N3U52A

HPE Advanced Series Racks

HPE 42U 600mm x 1075mm Advanced Pallet Rack

H6J65A

HPE 42U 600mm x 1075mm Advanced Shock Rack

H6J66A

HPE 42U 600mm x 1200mm Advanced Pallet Rack

H6J67A

HPE 42U 600mm x 1200mm Advanced Shock Rack

H6J68A

HPE 36U 600mm x 1075mm Advanced Pallet Rack

H6J77A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Options

NOTE: For the complete range of RDX drives and media see:

https://www.hpe.com/us/en/product-catalog/storage/disk-based-backupsystems.html. For hardware and software compatibility of HPE disk backup products

see: http://www.hpe.com/storage/spock.

NOTE: Please see the HPE RDX Removable Disk Backup System QuickSpecs for

HPE Data Center Racks

QuickSpecs

Additional Options

Page 30

HPE 36U 600mm x 1075mm Advanced Shock Rack

H6J78A

HPE 14U 600mm x 1075mm Advanced Shock Rack

H6J82A

HPE 22U 600mm x 1075mm Advanced Pallet Rack

H6J83A

HPE 22U 600mm x 1075mm Advanced Shock Rack

H6J84A

HPE 48U 600mm x 1075mm Advanced Pallet Rack

H6J87A

HPE 48U 600mm x 1075mm Advanced Shock Rack

H6J88A

NOTE: Please see the HPE Advanced Series Racks QuickSpecs for information on additional racks options and rack specifications.

HPE Enterprise Series Racks

HPE 42U 600mm x 1075mm Enterprise Pallet Rack

BW903A

HP 42U 600mm x 1075mm Enterprise Shock Rack

BW904A

HP 42U 600mm x 1200mm Enterprise Pallet Rack

BW907A

HP 42U 600mm x 1200mm Enterprise Shock Rack

BW908A

HP 47U 600mm x 1075mm Enterprise Pallet Rack

BW911A

HP 47U 600mm x 1075mm Enterprise Shock Rack

BW912A

HP 47U 600mm x 1200mm Enterprise Pallet Rack

BW913A

HP 47U 600mm x 1200mm Enterprise Shock Rack

BW914A

HP 42U 800mm x 1075mm Enterprise Pallet Rack

BW917A

HP 42U 800mm x 1075mm Enterprise Shock Rack

BW918A

additional racks options and rack specifications.

CAUTION:

people to use for any installation.

HPE Power

HPE Basic Power Distribution Units (PDU)

HPE 800VA - 277V Input / 230V Output NA Rack Mount Transformer

H3X09A

NOTE: Please see the HPE Basic Power Distribution Units (PDU) QuickSpecs for information on additional options and product specifications.

HPE Metered Power Distribution Units (PDU)

HPE Metered 2.8kVA/L5-30P 24A/120V Outlets (12) 5-20R/Horizontal NA/JP PDU

D9N43A

HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (12) C13/Horizontal WW PDU

D9N46A

HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (12) C13/Horizontal NA/JP PDU

D9N44A

HPE Metered 3.6kVA/60320 C20 Detachable 16A/230V Outlets (16) C13/Vertical WW PDU

D9N45A

HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (12) C13/Vertical NA/JP PDU

G9Z05A

HPE Metered 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (4) C19/Vertical NA/JP PDU

D9N47A

HPE Metered 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13 (3) C19/Vertical NA/JP PDU

D9N51A

HPE Metered 3Ph 8.6kVA/L21-30P 24A/120-208V Outlets (18) C13 (3) C19 (3) 520R/Vertical NA/JP PDU

D9N53A

HPE Metered 8.3kVA/CS8265C 40A/208V Outlets (30) C13 (3) C19/Vertical NA PDU

D9N49A

HPE Metered 3Ph 14.4kVA/CS8365C 40A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N58A

HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (30) C13 (3) C19/Vertical NA/JP PDU

D9N61A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Distribution Units (PDUs)

NOTE: Please see the HPE Enterprise Series Racks QuickSpecs for information on

Hewlett Packard Enterprise recommends that a minimum of two people are required for all

Rack Server installations. Please refer to your installation instructions for proper tools and number of

QuickSpecs

Additional Options

Page 31

HPE Metered 3Ph 16.6kVA/60309 32A-30A 5-wire 24A/230V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N62A

HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (24) C13 (3) C19/Vertical NA/JP PDU

D9N54A

HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

D9N59A

HPE Metered 3Ph 17.3kVA/60309 60A 4-wire 48A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

G9Z07A

HPE Metered 3Ph 19.9kVA/L22-30P 24A/277V Outlets (30) RF-203P-HP/Vertical NA PDU

D9N63A

HP Environmental Sensor for Remote Monitored and Managed PDUs

E2D53A

NOTE: Please see the HPE Metered Power Distribution Units (PDU) QuickSpecs for information on additional options and product specifications.

HPE Intelligent Power Distribution Unit (PDU)

HPE Intelligent Modular 4.9kVA/L6-30P 24A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF520A

HPE Intelligent Modular 8.3kVA/CS8265C 40A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF521A

HPE Intelligent Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF522A

HPE Intelligent Modular 3Ph 17.3kVA/60309 60A 4-wire 48A/208V (6) C19/Horizontal NA/JP PDU

AF523A

HPE Intelligent Modular 3Ph 17.3kVA/60309 30A 5-wire 24A/240V (6) C19/Horizontal NA/JP PDU

AF901A

HPE Intelligent Modular 3Ph 17.3kVA/IEC 60309 60A 4-wire 48A/208V (12) C19/Horizontal NA/JP PDU

AF535A

HPE Intelligent Modular 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (6) C19/Horizontal NA/JP PDU

AF531A

HPE Intelligent Modular 3Ph 8.6kVA/L15-30P 24A/208V Outlets (20) C13 (6) C19/Horizontal NA/JP PDU

AF532A

HPE Intelligent Modular 3Ph 14.4kVA/CS8365C 40A/208V Outlets (6) C19/Horizontal NA/JP PDU

AF533A

HPE 5xC13 Intelligent PDU Extension Bar G2 Kit

AF547A

HPE 5xC13 Outlets Power and UID LEDs Pair Standard Extension Bar

AF528A

NOTE: Please see the HPE Intelligent Power Distribution Unit (PDU) QuickSpecs for information on additional options and product specifications.

HPE Metered and Switched Power Distribution Units (PDU)

HPE Metered Switched 2.8kVA/L5-30P 24A/120V Outlets (24) 5-20R /Vertical NA/JP PDU

H8B48A

HPE Metered Switched 3.6kVA/60320 C20 Detachable 16A/230V Outlets (7) C13 (1) C19/Vertical WW PDU

H8B49A

HPE Metered Switched 4.9kVA/L6-30P 24A/208V Outlets (20) C13 (4) C19/Vertical NA/JP PDU

H8B50A

HPE Metered Switched 3Ph 8.6kVA/L15-30P 24A/208V Outlets (18) C13 (6) C19/Vertical NA/JP PDU

H8B52A

HPE Metered Switched 3Ph 8.6kVA/L21-30P 24A/208V Outlets (20)C13 (3)C19 (1)520R/Vertical NA/JP PDU

H8B53A

HPE Metered Switched 3Ph 14.4kVA/CS8365C 40A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

H8B55A

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

QuickSpecs

Additional Options

Page 32

HPE Metered Switched 3Ph 17.3kVA/60309 4-wire 48A/208V Outlets (12) C13 (12) C19/Vertical NA/JP PDU

H8B56A

NOTE: Please see the HPE Metered and Switched Power Distribution Units (PDU)

QuickSpecs

NOTE: To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web

page

HPE Location Discovery Services

HPE Location Discovery Services LCD8500 Kit

TL052A

HPE Rack Mount Consoles

HP LCD8500 1U US Rackmount Console Kit

AF630A

HP LCD8500 1U US TAA Rackmount Console Kit

AF645A

HPE KVM Switches

HP 0x1x8 G3 KVM Console Switch

AF651A

HP 0x2x16 G3 KVM Console Switch

AF652A

HP TAA 0x2x16 G3 KVM Console Switch

AF653A

HP USB Remote Access Key for G3 KVM Console Switches

AF650A

HP KVM Console USB Interface Adapter

AF628A

HP 0x2x16 KVM Server Console Switch G2 with Virtual Media CAC Software

AF618A

HP 0x2x32 KVM Server Console Switch G2 with Virtual Media CAC Software

AF619A

HP KVM Console USB 2.0 Virtual Media CAC Interface Adapter

AF629A

HP 1x4 USB/PS2 KVM Console Switch

AF611A

HP 1x1Ex8 KVM IP Console Switch G2 with Virtual Media CAC Software

AF620A

HP 2x1Ex16 KVM IP Console Switch G2 with Virtual Media CAC Software

AF621A

HP 4x1Ex32 KVM IP Console Switch G2 with Virtual Media CAC Software

AF622A

NOTE: To learn more, please visit the HPE KVM Switches web page.

HPE USB Keyboard and Mouse

HPE USB US Keyboard/Mouse Kit

631341-B21

Rail Kits

HP 1U Small Form Factor Easy Install Rail Kit

734807-B21

HPE 1U Cable Management Arm for Easy Install Rail Kit

734811-B21

HP 1U Short Friction Rail Kit

775612-B21

HPE Other Options

HPE Rack LED Light Kit

BW939A

HP Kit LCD 1.83m Latch Display Port Cable

G7T29A

HP ConvergedSystem Door Branding Kit

TK815A

HP ConvergedSystem Rack Light Kit

TK816A

HP ConvergedSystem Rack Side Panel 1075mm Kit

TK817A

HPE

HPE DirectFlow Three Phase UPS

Power Unit (1U UPS)

HPE R12000 DirectFlow - 1U Rackmount Uninterruptible Power System

G9Y75A

HPE R12000 DirectFlow - POD 1U Rackmount Uninterruptible Power System

AF478A

Input/Output Module Options for 1U UPS

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

for information on additional options and product specifications.

HPE Rack Mount Consoles, KVM Switches, and Keyboards

NOTE: Please see the HPE Location Discovery Services QuickSpecs for information

on additional options and product specifications.

Uninterruptible Power Systems (UPS)

QuickSpecs

Additional Options

Page 33

HPE 30A 400-415 Volt Three Phase NA R10000 DirectFlow UPS IEC309 Input/Output Module

AF489A

HPE 30A 480 Volt Three Phase NA R12000 DirectFlow UPS L22-30 Input/Output Module

AF491A

HPE 30A 480 Volt Three Phase NA R12000 DirectFlow UPS IEC309 Input/Output Module

AF492A

HPE 30A 400-415 Volt Three Phase NA R12000 DirectFlow UPS IEC309 Input/Output Module

G9Y76A

HPE DirectFlow UPS Management Card

AF493A

Power Unit (2U UPS)

HPE R18000 DirectFlow - 2U Rackmount Uninterruptible Power System

AF479A

Input/Output Module Options for 2U UPS

HPE 30A 480 Volt Three Phase NA R18000 DirectFlow UPS IEC309 Input/Output Module

AF486A

HPE 30A 480 Volt Three Phase NA R18000 DirectFlow UPS IEC309 Input/Output Module

AF487A

HPE 30A 400 Volt Three Phase NA R18000 DirectFlow UPS IEC309 Input/Output Module

D9Q02A

HPE 30A 400-415V Three Phase NA R18000 DirectFlow UPS 1:1 IEC309 Input/Output Module

AF484A

NOTE: All Input/Output Modules support dual output outlets except the AF484A.

Battery Pack Options

HPE DirectFlow UPS - 1U Rackmount Lithium-ion Battery Pack

AF480A

HPE DirectFlow UPS - 3U Rackmount VRLA Battery Pack

AF482A

HPE WW DirectFlow Secondary Battery Cable

AF497A

NOTE: Please see the HPE DirectFlow Three Phase Uninterruptible Power System

QuickSpecs for information on additional options and product specifications.

HPE Tower UPS

HPE T750 G4 UPS Models

HPE T750 G4 NA/JP Uninterruptible Power System

J2P85A

HPE T1000 G4 UPS Models

HPE T1000 G4 NA/JP Uninterruptible Power System

J2P86A

HPE T1500 G4 UPS Models

HPE T1500 G4 NA/JP Uninterruptible Power System

J2P87A

HPE Rack/Tower UPS

HPE R/T2200 G4 UPS Models

HPE R/T2200 G4 NA/JP Uninterruptible Power System

J2R00A

HPE R/T3000 G4 UPS Models

HPE R/T3000 G4 Low Voltage NA/JP Uninterruptible Power System

J2R01A

HPE R/T3000 G4 High Voltage NA/JP Uninterruptible Power System

J2R02A

R1500 G4 Models

HPE R1500 G4 NA Uninterruptible Power System

J2Q99A

R7000 Uninterruptible Power System (UPS)

HPE R7000 4U 50A High Voltage NA/JP Uninterruptible Power System

AF462A

R5000 Uninterruptible Power System (UPS)

HPE R5000 3U L630 High Voltage NA/JP Uninterruptible Power System

AF460A

NOTE: Please see the HPE Line Interactive Single Phase UPS QuickSpecs for

HPE UPS Options

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

information on additional options and product specifications.

QuickSpecs

Additional Options

Page 34

HPE R/T2200 G4 Extended Runtime Module

J2R09A

HPE R/T3000 G4 Extended Runtime Module

J2R10A

HPE 2U Rack/Tower UPS Shipping Kit

L4Q11A

NOTE: To learn more, please visit the HPE Uninterruptible Power Systems (UPS) web

page.

HPE USB and SD

HPE Enterprise Mainstream Flash Media Kits for Memory Cards

HPE 32GB microSD Mainstream Flash Media Kit

700139-B21

HPE Dual 8GB microSD Enterprise Midline USB Kit

741279-B21

HPE 8GB microSD Enterprise Mainstream Flash Media Kit

726116-B21

HPE 8GB USB Enterprise Mainstream Flash Media Drive Key Kit

737953-B21

Foundation Care

HPE 3 year Foundation Care 24x7 DL120 Gen9 Service

U7VP0E

HPE 3 year Foundation Care 24x7 wDMR DL120 Gen9 Service

U7VP1E

HPE 3 year Foundation Care 24x7 wCDMR DL120 Gen9 Service

U7VP2E

Proactive Care

HPE 3 year Proactive Care 24x7 DL120 Gen9 Service

U7VR7E

HPE 3 year Proactive Care 24x7 with DMR DL120 Gen9 Service

U7VR8E

HPE 3 year Proactive Care 24x7 with CDMR DL120 Gen9 Service

U7VR9E

HPE Installation DL320e/DL120 Service

U6F51E

HPE Startup DL320e/DL120 Service

U6F53E

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Options

HPE Support Services

Installation & Start-up Services

QuickSpecs

Memory

Memory Population

General Memory Population Rules and Guidelines

Place the DIMMs with the highest number of ranks in the white slot when mixing DIMMs of different ranks on the same channel.

Do not mix RDIMMs or LRDIMMs.

Quad rank RDIMMs are not supported in HPE ProLiant DL120 Gen9 servers.

DIMMs of different speeds may be mixed in any order; the server will select a common optimal speed.

The maximum memory speed is a function of the memory type, memory configuration, and processor model.

The maximum memory capacity is a function of the memory type and number of installed processors.

To realize the performance memory capabilities listed in this document, HPE SmartMemory is required.

Intel Gen9 Supported Memory Bandwidth for HPE ProLiant Gen9 Intel® Xeon® E5-2600v3 Series Processor Family

Memory Bandwidth and Capacity

[DIMM Type]

Registered DIMMs (RDIMMs)

Load Reduced (LRDIMMs)

HPE SKU P/N

726717-B21

726718-B21

759934-B21

726719-B21

728629-B21

726720-B21

726722-B21

DIMM Rank

Single Rank

Dual Rank

Quad Rank

DIMM Capacity

4GB

8GB

16GB

32GB

16GB

32GB

Voltage

1.2V

DRAM Depth [bit]

512M

DRAM Width [bit]

DRAM Density

4Gb

8Gb

CAS Latency

15-15-15

DIMM Native Speed (MT/s)

2133

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

guidelines

Std Voltage

Page

QuickSpecs

Memory

Page 36

SLOTS THAT CAN BE POPULATED

8 slot servers

8 8 8 8 8 8 8

MAXIMUM CAPACITY (GB)

128

256

128

256

POPULATED DIMM SPEED (MT/s)

1 DIMM Per Channel

2133

2 DIMM Per Channel

2133

3 DIMM Per Channel

n/a

NOTE: DL120 has 2 DIMMs per channel and hence 3 DIMMs per channel memory speeds are not applicable on DL120.

Intel Gen9 Supported Memory Bandwidth for HPE ProLiant Gen9 Intel® Xeon® E5-2600v4 Series Processor Family

Memory Bandwidth and Capacity

[DIMM Type]

Registered DIMMs (RDIMMs)

Load Reduced

HPE SKU P/N

805347-B21

805349-B21

836220-B21

805351-B21

805353-B21

DIMM Rank

Single Rank

Dual Rank

DIMM Capacity

8GB

16GB

32GB

Voltage

Std Voltage 1.2V

DRAM Depth [bit]

DRAM Width [bit]

DRAM Density

8Gb

4Gb

8Gb

CAS Latency

17-17-17

DIMM Native Speed (MT/s)

2400

SLOTS THAT CAN BE POPULATED

8 slot servers

8 8 8 8 8

MAXIMUM CAPACITY (GB)

128

256

POPULATED DIMM SPEED (MT/s)

1 DIMM Per Channel

2400

2 DIMM Per Channel

2133

2400

3 DIMM Per Channel

n/a

NOTE: DL120 has 2 DIMMs per channel and hence 3 DIMMs per channel memory speeds are not applicable on DL120.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

(LRDIMMs)

QuickSpecs

Memory

Page 37

DIMM slot and

DIMM slot and configuration diagrams

Basic memory slot & population diagram

• Population order; start with "A" first, "B" second, "C" third, etc.

CPU 1

Slot #

Population order

Chnl 2 3

B3 4 F4

CPU 1

Slot #

Population order

Chnl 4 5

H5 6 D6

CPU 1

Slot #

Population order

Chnl 3 7

Memory Speed

Processor Models

Supported Memory Speeds

E5-2603v3, E5-2609v3

1600MT/s

E5-2620v3, E5-2630v3, E5-2640v3, E5-2630Lv3, E5-2623v3

1866MT/s

E5-2650v3, E5-2660v3, E5-2650Lv3, E5-2699v3, E5-2698v3, E5-2695v3, E5-1650v3, E5-1620v3

2133MT/s E5-2603v4, E5-2609v4

1866MT/s

E5-2630Lv4, E5-2620v4, E5-2623v4, E5-2630v4, E5-2640v4

2133MT/s

E5-2650Lv4, E5-2650v4, E5-2660v4, E5-2690v4,

E5-1650v4

2400MT/s

Standard and Maximum Memory

Pre Configured Models

Standard Memory

Maximum Memory Plus Optional Memory

Standard Memory Replaced with Optional Memory

E5-2630v4, E5-2630v3, E5-2603v4

8GB (1x8GB)

232GB (7x32GB, 1x8GB)

256GB (8x32GB) E5-2603v3

4GB (1x4GB)

228GB (7x32GB, 1x4GB)

256GB (8x32GB)

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

configuration diagram

by Processor Model

Capacity (Preconfigured Models)

E5-2695v4, E5-2698v4, E5-2699v4, E5-1620v4,

QuickSpecs

Memory

Page 38

DDR4 memory options part number decoder

• 64GB = 65,536MB

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

NOTE: Capacity references are rounded to the common gigabyte (GB) values.

• 2GB = 2,048MB

• 4GB = 4,096MB

• 8GB = 8,192MB

• 16GB = 16,384MB

• 32GB = 32,768MB

QuickSpecs

Storage

1-8

8 x SFF SATA/SAS/SSD Hot Pluggable Hard

8-bay LFF hot-plug drive model

1-4

4 x LFF SATA/SAS/SSD Hot Pluggable Hard

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Drive Bays

Drives Bays

Page

QuickSpecs

(Gen9)

Technical Specifications

System Unit

Dimensions

8 SFF - 1.69 x 17.11 x 23.90 inches (4.29 x 43.46 x 60.76 cm)

4 LFF - 1.69 x 17.11 x 23.90 inches (4.29 x 43.46 x 60.76 cm)

Weight

Maximum:

supplies, and processors

37.44 Ib (17kg)

Minimum:

19.82 lb (9kg)

Input Requirements

Rated Line Voltage

100 to 240 VAC

Rated Input Current

For 550W Power Supply:

6.7 A (at 100 VAC)

3.3 A (at 100 VAC)

Rated Input Frequency

47 to 63 Hz

Rated Input Power

For 550 W Power Supply:

< 670 W (at 100 VAC)

< 660 W (at 200 VAC)

BTU Rating

Maximum

For 550 W Power Supply:

2201 BTU/hr (at 100 VAC)

2153 BTU/hr (at 200 VAC)

To review typical system power ratings use the Power Advisor which is

interest. Example: DL120 Gen9- Follow the instructions of the next screens.

Power Supply Output

Rated Steady-State

For 550 W Power Supply:

550 W (at 100 VAC)

550 W (at 200 VAC)

Maximum Peak Power

For 550 W Power Supply:

550 W (at 100 VAC)

550 W (at 200 VAC)

System Inlet Temperature

Standard Operating

10° to 35°C (50° to 95°F) at sea level with an

may be limited by the type and number of options

with a fan fault or above 30°C (86°F).

Extended Ambient

For approved hardware configurations, the

(10,000 ft). The approved hardware

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9

(H x W x D)

(approximate)

(all hard drives, power

installed)

(one hard drive, power supply, and processor installed)

Power Specifications

available via the online tool located at URL: http://www.hpe.com/info/hppoweradvisor - Click on the system of

Power

Support

altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 20°C/hr (36°F/hr). The upper limit and rate of change

installed. System performance during standard operating support may be reduced if operating

Operating Support

supported system inlet range is extended to be: 5° to 10°C (41° to 50°F) and 35° to 40°C (95° to 104°F) at sea level with an altitude derating of

1.0°C per every 175 m (1.8°F per every 574 ft) above 900 m (2953 ft) to a maximum of 3048 m

Page

QuickSpecs

Technical Specifications

Page 41

configurations for this system are listed at the

Non-operating

-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).

Relative Humidity

Operating

Minimum to be the higher (more moisture) of Non-operating

5% to 95% relative humidity (Rh), 38.7°C

condensing.

Altitude

Operating

3048 m (10,000 ft). This value may be limited by

m/min (1500 ft/min).

Non-operating

9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).

Acoustic Noise

Listed are the declared A-Weighted sound power levels (LWAd) and

and declared in accordance with ISO 9296 (ECMA 109).

Idle

LWAd

Entry 4.9 B

Base 5.4 B

LpAm

Entry 33.0 dBA

Base 35.0 dBA

Operating

LWAd

Entry 5.7 B

Base 5.8 B

LpAm

Entry 38.0 dBA

Base 39.0 dBA

Emissions Classification

FCC Rating

Class A

60950-1

NOTE: Product conformance to cited product specifications is based on

statements.

HPE Dynamic Smart

Number of PCI links

Four

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

URL: http://www.hpe.com/servers/ashrae

System performance may be reduced if operating in the extended ambient operating range or with a fan fault.

NOTE: Supports A3 and A4 extended ambience.

12°C (10.4°F) dew point or 8% relative humidity. Maximum to be the lower (less moisture) of 24°C (75.2°F) dew point or 90% relative humidity.

(non-condensing)

(101.7°F) maximum wet bulb temperature, non-

the type and number of options installed. Maximum allowable altitude change rate is 457

declared average bystander position A-Weighted sound pressure levels (LpAm) when the product is operating in a 23°C ambient environment. Noise emissions were measured in accordance with ISO 7779 (ECMA 74)

(EMC)

Normative Standards CISPR 22; EN55022; EN55024; FCC CFR 47, Pt

sample (type) testing, evaluation, or assessment. This product or family of products is eligible to bear the appropriate compliance logos and

15; ICES-003; CNS13438; GB9254; K22;K24; EN 61000-3-2; EN 61000-3-3; EN 60950-1; IEC

QuickSpecs

Technical Specifications

Page 42

Array B140i

PCI link rate

4Gb/s

Storage protocol support

SATA

SAS/SATA peak data transfer rate

6Gb/s Number of SAS/SATA links

10 links

SAS/SATA connectivity

2x4 connectors; 2x1 connectors

Expander support

Drives supported (max)

Up to 10 Internal Drives

RAID support

0, 1, 10, 5 SATA

Software management

HPE SSA, SMH, SIM

Warranty

Server warranty

HPE Secure Encryption license

Not Supported HPE SmartCache License

Not Supported

Administrator

Supported

HPE Embedded Dual

Network Interface

10Base-T/100Base-TX/1000Base-TX

Compatibility

IEEE 802.3 10Base-T

IEEE 802.3ab 1000Base-T

IEEE 802.3u 100Base-TX

IEEE 1588, IEEE 802.1AS

IEEE 802.3az - Energy Efficient Ethernet (EEE)

Data Transfer Method

PCI Express v 2.0, 5.0 GT/s, two lanes (x2)

Controller

Intel I350 Powerville

Network Transfer Rate

10Base-T (Half-Duplex)

10 Mb/s per port, 40 Mb/s combined

10Base-T (Full-Duplex)

20 Mb/s per port, 80 Mb/s combined

100Base-TX (HalfDuplex)

100 Mb/s per port, 400 Mb/s combined 100Base-TX (Full-Duplex)

200 Mb/s per port, 800 Mb/s combined

1000Base-TX (Half and Full-Duplex)

1000 Mb/s per port, 4000 Mb/s combined Connector

Two RJ-45

Cable Support

10 Base-T

Categories 3, 4 or 5 UTP; up to 328 ft (100 m)

10/100/1000 Base-TX

Category 5 or higher UTP; up to 328 ft (100 m)

Environment-

End-of-life Management and

Hewlett Packard Enterprise offers end-of-life product return, trade-in, and

recyclers and other WEEE treatment facilities as well as Hewlett Packard

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Controller

Port 361i Adapter

HPE Smart Storage

friendly Products

Recycling

and Approach

recycling programs, in many geographic areas, for our products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.

http://www.hpe.com/recycle

The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard Enterprise web site. These instructions may be used by

QuickSpecs

Technical Specifications

Page 43

Enterprise OEM customers who integrate and re-sell Hewlett Packard

http://www.hpe.com/recycle

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Enterprise equipment.

QuickSpecs

Summary of Changes

Date

Version History

Action

Description of Change

2-Oct-2017

From Version 26 to 27

Changed

Configuration Information – Factory Integrated Models section was revised.

25-Sep-2017

From Version 25 to 26

Added

New SSD offering was added. Added new Storage options.

Changed

Core Options and Additional Options were revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

7-Aug-2017

From Version 24 to 25

Added

Added new Solid State Drives to the HPE Drives section.

11-Jul-2017

From Version 23 to 24

Changed

Operating Systems and Virtualization Software Support for ProLiant Servers section was revised.

5-Jun-2017

From Version 22 to 23

Added

Added new Solid State Drives offering to the HPE Drives section.

8-May-2017

From Version 21 to 22

Added

Added support for ClearOs.

Changed

Operating Systems and Virtualization Software Support for ProLiant Servers Drives were revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

27-Mar-2017

From Version 20 to 21

Added

Added new Hard Drives.

17-Feb-2017

From Version 19 to 20

Changed

HPE Memory section under Core Options was revised.

13-Feb-2017

From Version 18 to 19

Added

Added new HDD and SSD offering to the HPE Drives section.

28-Nov-2016

From Version 17 to 18

Added

Added new Hard Drives offering.

Changed

Maximum Internal Storage was revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

28-Oct-2016

From Version 16 to 17

Removed

Obsolete Hard Drives were removed from the QuickSpecs.

26-Sep-2016

From Version 15 to 16

Added

Added new LFF 10TB SATA hard drives offering.

Changed

Maximum Internal Storage section was revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

19-Aug-2016

From Version 14 to 15

Changed

Smart Buy Models section was updated for the NA version only.

6-Jun-2016

From Version 13 to 14

Added

Added new HPE Memory, new HPE Drives offering, and new HPE Disk Backup options.

Changed

HPE Processors, Upgradeability, and HPE Memory sections were revised.

8-Apr-2016

From Version 12 to 13

Changed

HPE Processors section was revised.

31-Mar-2016

From Version 11 to 12

Added

Added new HPE DDR4 2400 MHz Memory modules, Intel Xeon E5 new HPE Trusted Platform Module (TPM) 2.0, ne 900W AC/ 240VDC power supply, new HDD offering.

Changed

Maximum Internal Storage, Power Supply, Upgradeability, Embedded Management, Service and Support, Pre and Memory sections were revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

, HPE Processors, HPE

-2600v4 processor support, w

-configured Models, HPE Security,

Page

QuickSpecs

Summary of Changes

Page 45

16-Feb-2016

From Version 10 to 11

Added

New HDD offering was added to HPE Drives.

Changed

HPE Power Supplies, HPE Disk Backup, HPE Data Center Racks, and HPE Power Distribution Units (PDUs) were revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

1-Dec-2015

From Version 9 to 10

Added

New HDD offering was added to HPE Drives.

New options were added to HPE Security, HPE Tape Backup, HPE Rack Mount Consoles, and KVM Switches, and Keyboards.

Changed

On System Management Chipset, Maximum Internal Storage, Embedded Management, and Server utilities were revised.

Product images were updated.

Removed

Obsolete SKUs were removed from the QuickSpecs.

23-Oct-2015

From Version 8 to 9

Changed

System Fans, HP Cooling Options, and HP Security were revised.

28-Sep-2015

From Version 7 to 8

Added

Added new 6Gb SATA Solid State Drives.

Added new HPE OneView management software.

Removed

Obsolete SKUs were removed from the QuickSpecs.

17-Aug-2015

From Version 6 to 7

Added

New Solid State Drives offering was added to Core Options.

Changed

Maximum Internal Storage was revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

1-Jun-2015

From Version 5 to 6

Added

New Hard Drives were added to Core Options.

New options added to HPE Power Supplies.

HPE OneView LTUs added to HPE Converged Infrastructure Management Software.

New RDX+ external backup options were added.

Changed

Pre-configured Models section was revised.

Removed

Obsolete SKUs were removed from the QuickSpecs.

24-Apr-2015

From Version 4 to 5

Added

Added 813534-B21 and 813535-B21 to HPE Power Supplies.

16-Apr-2015

From Version 3 to 4

Changed

PCIe slots was changed to “1 PCIe LP standard / up to 3 PCIe slots (optional)” for Entry models a CTO models.

30-Mar-2015

From Version 2 to 3

Added

Added HPE Storage Options to Additional Options.

Added new Hard Drives to Core Options.

Added Optional Software to HPE Storage Controllers.

Changed

HPE Processors, HPE Memory, HPE Hard Drives, HPE were revised.

9-Feb-2015

From Version 1 to 2

Added

Added HPE Insight Software section and Network controller sections.

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

Networking, and HPE USB and SD Options

QuickSpecs

Summary of Changes

Page 46

Added new HPE Drives, HPE Disk Backup, and new G4 UPS models.

Changed

HPE Memory, HPE Drives, HPE Tape Backup, HPE Rack Mount Consoles, KVM Switches, and Keyboards, and HPE Uninterruptible Power Systems (UPS) sections were revised.

© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is subject to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the express warranty be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or omissions contained herein.

Intel® and Xe

Microsoft®, Windows®, and Windows Server® are U.S. registered trademarks of the Microsoft group of companies.

For hard drives, 1GB = 1 billion bytes. Actual formatted c

c04447808 - 15087 – North America - V27 - 2-October-2017

RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may

have older product names and model numbers that differ from current models.

HPE ProLiant DL120 Generation9 (Gen9)

statements accompanying such products and services. Nothing herein should

on® are registered trademarks of Intel Corporation in the U.S. and other countries.

apacity is less

HPE 833870-B21 Getting Started Guide

Specifications and Main Features

Frequently Asked Questions

User Manual
