QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Overview
Page 1
HPE Synergy 20G Interconnect Link Module
The HPE Synergy 20Gb Interconnect Link Module, satellite module, is designed for Composable Infrastructure. Based on
management at scale while consuming fewer ports at the data center aggregation layer.
Figure 1 HPE Synergy 20G Interconnect Link Module Bezel
1.
UID LED
3.
Interconnect Link Ports
2.
Health LED
disaggregated, rack-scale design, it uses a master/satellite architecture to consolidate data center network connections, reduce
hardware and scale network bandwidth across multiple HPE Synergy Frames. This module extends HPE composable fabric up to
two additional satellite frames with 20Gb connectivity to Synergy Compute Modules and replaces fixed ratio of interconnects in
each frame by extending the fluid pool of network resources.
The master module contains intelligent networking capabilities that extend connectivity to frames equipped with satellite modules.
This reduces the need for top of rack switches and substantially decreases cost. The reduction in components simplifies fabric
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Platform Information
2
Models
HPE Synergy 20Gb Interconnect Link Module
779218-B21
HPE Synergy 20Gb TAA-compliant Interconnect Link Module
779218-B22
NOTE: TAA in the name of this product provides that this product meets the US Trade Agreements Act (19 U.S.C & 2501-
2581) and is compliant for resale on GSA (General Services Administration) agreements or contracts.
NOTE:
Agreement
GSA (General Services Administration), the “final products” that we sell through your GSA Schedule are manufactured or
substantially transformed
complete TAA
NOTE:
product options and become a TAA approved solutions when substantially transformed/integrated at a designated HPE TAA
Compliant Factory.
compliance.
Compatibility
HPE Synergy 20G Interconnect Link Module supports the following hardware.
HPE Servers
HPE Synergy Compute Modules
HPE Interconnects
HPE Synergy Interconnect Modules
HPE Network
Converged Network Adapter:
HPE now includes TAA products and options for the Synergy line of product solutions. TAA refers to the US Trade
s Act (19 U.S.C & 2501-2581). TAA compliance for HPE simply means that as a product manufacturer or reseller on
in a TAA-compliant country. HPE Synergy TAA products are aligned for the configuration of a
-compliant solution or subsets of the complete solution.
HPE Synergy 12000 TAA Configure-To-Order Frames may include TAA specific, naturally compliant, or standard
Please look for TAA in the name when defining HPE Synergy Options or Solutions that may require TAA
• HPE Synergy 480 Gen9 Compute Module
• HPE Synergy 620 Gen9 Compute Module
• HPE Synergy 660 Gen9 Compute Module
• HPE Synergy 680 Gen9 Compute Module
• HPE Synergy 480 Gen10 Compute Module
• HPE Synergy 660 Gen10 Compute Module
• HPE Virtual Connect SE 40GB F8 Module for HPE Synergy
• HPE Synergy 40Gb F8 Switch Module
Adapters
• HPE Synergy 3820C 10/20Gb Converged Network Adapter
NOTE: Consult individual compute module QuickSpecs for specific adapter support.
Page
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Platform Information
Page 3
Supported Configurations
HPE Synergy 12000 Frame - Rear View
Mezzanines
Port Mapping
Port mapping differs slightly between full height and half-height server compute modules due to the support for
additional Mezzanine cards on the full height version.
HPE 12000 Synergy Frame
NOTE:
HPE 20Gb ILM
Frame 1
[ICB 1]
HPE VC SE 40Gb F8
->
HPE 20Gb ILM
[ICB 4]
HPE Synergy 20Gb CNA
[ICB 2]
Empty/Interconnect
->
Empty/Interconnect
[ICB 5]
Empty/Adapter
[ICB 3]
Empty/Interconnect
->
Empty/Interconnect
[ICB 6]
Empty/Adapter
Frame 2
[ICB 1]
HPE 20Gb ILM
->
HPE VC SE 40Gb F8
[ICB 4]
HPE Synergy 20Gb CNA
[ICB 2]
Empty/Interconnect
->
Empty/Interconnect
[ICB 5]
Empty/Adapter
[ICB 3]
Empty/Interconnect
->
Empty/Interconnect
[ICB 6]
Empty/Adapter
Frame 1
[ICB 1]
HPE VC SE 40Gb F8
->
HPE 20Gb ILM
[ICB 4]
HPE Synergy 20
[ICB 2]
Empty/Interconnect
->
Empty/Interconnect
[ICB 5]
Empty/Adapter
Empty/Interconnect
[ICB 6]
Empty/Adapter
Shown below are 2 frame and 3 Synergy frame examples when using the HPE VC SE 40Gb F8 module in conjunction with
Interconnect Module Configurations Compute Module Network Adapters Used
[ICB 3] Empty/Interconnect ->
Gb CNA
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Platform Information
Page 4
Frame 2
[ICB 1]
HPE 20Gb ILM
->
HPE VC SE 40Gb F8
[ICB 4]
HPE Synergy 20
[ICB 2]
Empty/Interconnect
->
Empty/Interconnect
[ICB 5]
Empty/Adapter
[ICB 3]
Empty/Interconnect
->
Empty/Interconnect
[ICB 6]
Empty/Adapter
Frame 3
[ICB 1]
HPE 20Gb ILM
->
HPE 20 ILM
[ICB 4]
HPE Synergy 20
[ICB 2]
Empty/Interconnect
->
Empty/Interconnect
[ICB 5]
Empty/Adapter
[ICB 3]
Empty/Interconnect
->
Empty/Interconnect
[ICB 6]
Empty/Adapter
Gb CNA
Gb CNA
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Standard Features
5
Product Features
Performance
• Centralized configuration of boot from Fibre Channel network storage via OneView
• 12 x 20Gb Ethernet downlinks to compute module mezzanine adapters
• Each 20Gb downlink supports up to 3 FlexNICs and 1 FlexHBA or 4 FlexNICs
• Each FlexHBA can be configured to transport either Fiber Channel over Ethernet/CEE or Accelerated
iSCSI protocol.
• Each FlexNIC and FlexHBA is recognized by the server as a PCIe physical function device with
adjustable speeds from 200Mb to 20Gb in 100Mb increments when connected to a 2-port
FlexFabric Converged Network Adapter and from 1Gb to 20Gb in 200Mb increments when
connected to Dual-Port 10/20Gb Converged Network Adapter
Management
• Integrated Synergy composer with HPE OneView included with every frame, providing out-of-the-
box management of Interconnect Link Modules.
• Pre-configure server I/O configurations prior to server installation for easy deployment
• Move, add, or change server network connections on the fly without impacting LAN and SAN
administrator
• Provisioned storage resource is associated directly to a specific virtual machine - even if the virtual
server is re-allocated within stacking domain comprising of Master and Satellite modules
Page
QuickSpecs
Service and Support
6
HPE Care Pack and Warranty Information
Service and
Advise, transform,
HPE Technology Services helps you get the most out of what you have today and transition to HPE Synergy,
approach, customers can deploy faster. DC-IA delivers support to customers to enable infrastructure as code
Support
HPE Synergy 20Gb Interconnect Link Module
HPE Technology Services offers you a rich portfolio of consulting and support services designed to add value
to our core products and solutions. We have the know-how and experience to put technology to work for you.
We work closely with you, as your strategic partner, leveraging our full services portfolio to make sure that
everything works to help optimize your enterprise.
Choose from services aligned to our product offerings and lifecycle. From proactive onsite services to
innovative support when your products are connected to Hewlett Packard Enterprise, you choose the precise
level of attention and support your business demands.
HPE Technology Services for HPE Synergy
HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and stability.
Connect to Hewlett Packard Enterprise to help prevent problems and solve issues faster. Our support
technology lets you to tap into the knowledge of millions of devices and thousands of experts to stay informed
and in control, anywhere, any time.
Protect your business beyond warranty with HPE Support Services
HPE support services offer complete care and support expertise with committed response choices that are
designed to meet your IT and business needs.
HPE Foundation Care services offer scalable reactive support-packages for HPE Synergy and software. You
choose the type and level of service that is most suitable for your IT and business needs.
HPE Proactive Care keeps your system stable and reliable helping to prevent problems and reduce outages
through proactive service management and enhanced technical response.
integrate, support,
automate, and flex
a composabe infrastructure, at your pace and from wherever you are on the journey.
Start with the HPE Transformation Workshop to ensure that your business and IT organizations collaborate,
define the topline strategy for composable, software-defined, cloud-ready infrastructure and kick-start your
projects confidently. This workshop clarifies your business requirements and the issues that IT and operations
teams must resolve in order to meet these requirements. A detailed executive briefing or high-level report
summarizes the strategies, high-level plan and functional requirements.
HPE Modernization and Migration Services helps you choose the right platform for the right workload at the
right cost and evolve your IT infrastructure, processes and organization taking advantage of “on-hybrid
infrastructure” innovations such as composable, converged, software-defined, technologies. Hewlett Packard
Enterprise experts advise, transform, integrate and implement for platform refresh, datacenter consolidation
virtualization, migration and automation projects.
HPE Flexible Capacity is a pay per use model for on premise infrastructure. This offers needed HPE Synergy
capacity in the datacenter, plus a buffer of additional capacity. As HPE Synergy will be a dynamic environment,
this provides enough room to grow your environment, but only pay for actual metered use. Technology
transitions and refresh can be built in, infrastructure and services are billed monthly, enabling you to align costs
to business use.
HPE Datacenter Care Infrastructure Automation: HPE Synergy with OneView embedded helps enable
infrastructure automation and is integrated with tools such as those from Chef, Puppet, and Docker, to enable
rapid bare metal provisioning. With DC-IA, HPE service experts provide advice, support, best practices, for these
tools that work with OneView to help create a fast, agile, and reliable automated IT environment. With this
Page
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Service and Support
Page 7
and agile processes as part of the service. Customers schedule quarterly reviews and reports with HPE Center
Optimized Support
Standard Support
HPE Proactive Care with 24x7 coverage, three year Support Service
Deploy and
HPE Factory Express Initial Frame Service for Synergy
HPE Education
Training your IT staff is critical to help drive the value of HPE Synergy with increased efficiencies and better
Parts and
Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain
of Expertise, as well as having access to these experts when needed, for automation development and code
coaching.
Choose the right support to maximize uptime, free up your resources, and achieve improved value—as you get
the most out of the existing IT assets while accelerating time-to-revenue.
HPE Proactive Care Advanced - 24x7 coverage, three year Support Service
Builds and incorporates on Proactive Care and also gives customers personalized technical and operational
advice from an assigned, local Account Support Manager for personalized technical collaboration, flexible
access to specialist skills to help optimize business critical IT, and Critical Incident Management to help so the
business is not affected if there is a system or device outage. This recommendation provides 24x7 coverage
with four-hour response for hardware and Basic Software Support and Collaborative Call Management for
selected non-HPE software that offers two-hour callback for supported software issues.
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA5-3259ENW.pdf
Hardware and software support services designed specifically for your technology with rapid access to
Advanced Solution Center specialists for start to finish case management plus proactive reports and
recommendations for firmware and software management and best practice advice. This recommendation
provides 24x7 coverage with four-hour response for hardware and Basic Software Support and Collaborative
Call Management for selected non-HPE software that offers two-hour callback for supported software issues.
https://www.hpe.com/h20195/v2/GetPDF.aspx/4AA3-8855ENW.pdf
integrate
Factory Express allows a customers’ configurations to be pre-configured in the HPE Integration center with an
implementation project manager to manage the deployment end to end. The project manager will act as a
single point of contact to coordinate the build, delivery and onsite installation and commissioning of the
solution. In addition to the configuration and deployment activities, your HPE Synergy configuration goes
through comprehensive testing and a detailed documentation package on the configuration and settings of the
delivered solution will be provided.
HPE Factory Express Synergy Additional Frame Service for Synergy
Add additional frames to your HPE Synergy Factory Express service or expand your existing HPE Synergy
Infrastructure.
HPE Synergy First Frame Installation and Startup - Provides for hardware installation (HPE Synergy
compute modules, Storage Modules, Virtual Connect modules, Interconnect Link Modules, Frame Link Modules,
and HPE Synergy D3940 Storage Modules) and software startup for the first frame of your HPE Synergy
deployment. Additional frames can be added using the HPE Synergy Additional Frame Installation and Startup
Service.
HPE Synergy Additional Frame Installation and Startup Service - Add additional frames to your HPE
Synergy First Frame Startup service or expand your existing HPE Synergy Infrastructure.
business outcomes. Training is key to the transformation and management of HPE Synergy.
Materials
the covered hardware product in operating condition, including parts and materials for available and
recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage
limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Service and Support
Page 8
data sheet will not be provided, repaired, or replaced as part of these services.
For more
information
Additional Support Services can be found at HPE Support Services Central
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced
by Hewlett Packard Enterprise due to malfunction.
http://ssc.hpe.com/portal/site/ssc
QuickSpecs
Related Options
9
CXP DAC Cables
HPE Synergy Interconnect Link 1.1m Direct Attach Copper Cable
804095-B21
HPE Synergy Interconnect Link 1.6m Direct Attach Copper Cable
804098-B21
HPE Synergy Interconnect Link 2.1m Direct Attach Copper Cable
804155-B21
CXP AOC Cables
HPE Synergy Interconnect Link 3m Active Optical Cable
804101-B21
HPE Synergy Interconnect Link 5m Active Optical Cable
804104-B21
HPE Synergy Interconnect Link 10m Active Optical Cable
804107-B21
HPE Synergy Interconnect Link 15m Active Optical Cable
804110-B21
HPE Synergy
HPE Synergy Proactive Care Services
HPE 3 Year Proactive Care 24x7 Synergy Interconnect Link Mod Service
H0WD9E
HPE 3 Year Proactive Care 24x7 with CDMR Synergy Interconnect Link Mod Service
H0WE1E
HPE 3 Year Proactive Care Advanced 24x7 Synergy Interconnect Link Mod Service
H0WE2E
HPE 3 Year Proactive Care Advanced 24x7 with CDMR Synergy Interconnect Link Mod
H0WE4E
Deployment/Installation & Start-up Services
HPE Factory Express Synergy Initial Frame Package 4 Service
HA454A1-300
HPE Factory Express Synergy Add-on Frame Package 4 Service
HA454A1-301
HPE Synergy First Frame Startup Service
U8JM3E
HPE Synergy Additional Frame Startup Service
U8JM4E
Services
HPE Synergy 20Gb Interconnect Link Module
Service
Page
QuickSpecs
HPE Synergy 20Gb Interconn
ect Link Module
Technical Specifications
10
System Unit
Shipping Dimensions
Length
19.53 in (496 mm)
Width
15.67 in (398 mm)
Height
5.88 in (149.5 mm)
Shipping Weight
Approximately 3.0 Kg (6.2 Lbs)
Product
Performance
Non-blocking architecture
Connectors and Cabling
12 x 20Gb downlinks through the midplane
2 x 120Gb interconnect link ports
Indicators
Health LED
UID LED
Link cable port LEDs
Compute Module Link LEDs
Weight
2.81Kg (6.2 Lbs)
Latency
Low-latency design (<5ns round trip)
Environmental Ranges
Temperature Range
Specification
10° to 35°C
Temperature Range
Operating
10° to 35°C (50° to 95°F)
Shipping
Shipping -40°C to 60°C
(-40°F to 140°F)
Storage
-20°C to 60°C
(-4F to 140°F)
Maximum wet bulb
temperature
30C (80F)
Relative Humidity
(noncondensing)
Operating
10% to 90%
Shipping
10% to 90%
NOTE: All temperature ratings shown are for sea level. An altitude derating of 1°C
per 304.8 m (1.8°F per 1,000 ft) to 3048 m (10,000 ft) is applicable. No direct
sunlig
Upper non
NOTE:
45°C (113°F). Altitude maximum fo
70 KPa.
Power Specification
12V @ 1.4A (17 W max)
Safety and
Safety Certifications
UL/CUL Recognition to UL/CSA 60950-1
TUV to EN 60950-1
CB report and certificate to IEC 60950-1 with all
country deviations
CE Marking
Specifications
Hardware
(50° to 95°F)*
ht allowed. Upper operating limit is 3,048m (10,000 ft) or 70 Kpa/10.1 psia.
-operating limit is 9,144 m (30,000 ft) or 30.3 KPa/4.4 psia.
Storage maximum humidity of 90% is based on a maximum temperature of
Compliance
r storage corresponds to a pressure minimum of
Page
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Technical Specifications
Page 11
Electromagnetic
FCC Part 15 Class A
EN 55022 Class A (CISPR22 Class A)
VCCI Class A
CE Marking
FCC
ICES (Canada)
VCCI (Japan)
RCM (Australia/NZ)
KCC (Korea)
BSMI (Taiwan)
Environment-
End-of-life
Hewlett Packard Enterprise offers end-of-life Hewlett Packard Enterprise product
return, trade
information, please go
product, please go
Hewlett Packard Enterprise
Enterprise
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment
info
(product disassembly instructions)
site
recyclers and other WEEE treatment facilities as well as
OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.
Emissions
Certifications FCC
Part 15 Class A
friendly Products
and Approach
Management and
Recycling
-in, and recycling programs in many geographic areas. For trade-in
to: http://www.hpe.com/info/recycle. To recycle your
to: http://www.hpe.com/info/recycle or contact your nearest
sales office. Products returned to Hewlett Packard
will be recycled, recovered or disposed of in a responsible manner.
rmation for each product type for use by treatment facilities. This information
is posted on the Hewlett Packard Enterprise web
at: http://www.hpe.com/info/recycle. These instructions may be used by
Hewlett Packard Enterprise
QuickSpecs
HPE Synergy 20Gb Interconnect Link Module
Summary of Changes
12
Date
Version History
Action
Description of Change
11-Jul-2017
From Version 5 to 6
Changed
Overview and Platform Information sections were updated.
Added
SKU added in Models – Platform Information section:
779218-B22
08-May-2017
From Version 4 to 5
Changed
Related Options, and Technical Specifications sections were updated.
Added
SKUs added in Related Options section:
804104-B21, 804107-B21.
18-Nov-2016
From Version 3 to 4
Changed
Models, Related Options and Service and Support sections were updated,
29-Jul-2016
From Version 2 to 3
Changed
QuickSpecs updated.
31-Mar-2016
From Version 1 to 2
Changed
Overview, Supported Products, Standard Features, Related Options,
Service and Support and Technical Specifications sections were updated.
Added
SKUS were added in Overview and Related Options Sections:
7792
804104
H0WE2E, H0WE4E, HA454A1-300, HA454A1-301, U8JM3E, U8JM4E.
1-Dec-2015
Version 1
Created
New QuickSpecs
Sign up for updates
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties for Hewlett Packard Enterp
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not be liable for technical or
c04815119
18-B21, 804095-B21, 804098-B21, 804155-B21, 804101-B21,
-B21, 804107-B21, 804110-B21, H0WD9E, H0WE1E,
rise products and
editorial errors or omissions contained herein.
- 15411 - Worldwide – V6 - 11-Jul-2017
Page
Loading...
