QuickSpecs
HPE Ethernet 10Gb 2-port 570FLB Adapter
Overview
Page 1
HPE Ethernet 10Gb 2-port 570FLB Adapter
The HPE Ethernet 10Gb 2-port 570FLB Onload server adapter is based on Solarflare's next generation 10GbE controller,
(bonding), Wake-on-LAN, Receive Side Scaling (RSS), jumbo frames, EEE 1588, PXE boot.
HPE Ethernet 10Gb 2-port 570FLB Adapter
Models
HPE Ethernet 10Gb 2-port 570FLB Adapter
718939-B21
HPE Ethernet 10Gb 2-port 570FLB FIO Adapter
718940-B21
NOTE: The HPE 570FLB on each server blade connects to a 10Gb interconnect in bays 1-2 (HPE
BladeSystem c7000 Enclosure) or bay 1 (
NOTE:
NOTE:
NOTE:
Kit contents
• HPE Ethernet 10Gb 2-port 570FLB Adapter
• Product warranty statement
Solarflare™ SFC9120, and delivers unmatched message rates with low latency and jitter over standard Ethernet along with the
lowest CPU utilization and power consumption, enabling the industry's best performance and scalability for financial services and
other enterprise data centers.
The HPE 570FLB supports enterprise class features such as VLAN tagging, adaptive interrupt coalescing, MSI-X, NIC teaming
HPE BladeSystem c3000 Enclosure).
The 570FLB requires a minimum of 2 GB of server memory.
The 570FLB supports linking at 1000Mbps or 10000Mbps when not connected to a Flex-10 device.
The 570FLB will only support 1000Mbps when connected to a 1Gb Ethernet interconnect.
• Quick install card
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Standard Features
2
Product Features
• Dual-port 10GbE FlexibleLOM network adapter that provides the flexibility to choose the type of LOM
Dual-port 10
The HPE 570FLB adapter delivers 20,000 Mbps full duplex Ethernet transfer rate per port (40 Gbps aggregate
Jumbo Frames
The HPE 570FLB adapter supports jumbo frames (also known as extended frames), permitting up to a 9K byte
Interrupt
Interrupt coalescing (interrupt moderation) groups multiple packets, thereby reducing the number of interrupts
802.1p QoS
IEEE quality of service (QoS) 802.1p tagging allows the adapter to mark or tag frames with a priority level
802.1Q VLANs
IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of the HPE 570FLB adapter
TCP/IP Stateless
TCP, IP, UDP checksum offload, Large Send Offload (LSO), TCP, Segmentation Offload (TSO). These features
Optimized for
I/O Virtualization support for VMware NetQueue , Microsoft's VMQ and Intel's VMDq technologies help meet the
Compliant with Single-Root I/O Virtualization (SR-IOV), accommodating multiple Virtual Machines (VMs) to
to meet growing infrastructure needs
• Industry-leading throughput and latency performance
• Up to 40Gb/s bi-directional near line rate throughput
• Hardware and software acceleration and offloads for stateless TCP/IP
• Supports Wake-on-LAN ( at 1 Gb)
NOTE: Wake-on-LAN is supported only on Port1 from system power state S5.
• Improved small packet performance
• " Interrupt Coalescing
• Support for Preboot eXecution Environment (PXE)
• Integrated PHY and MAC
• Uses an x8 PCI Express 2.0 compliant compatible Bus Interface
Gigabit Ethernet
Throughput
(theoretical
bandwidth)
MSI and MSI-X
Coalescence
Tagging
full duplex), providing the network performance needed to improve response times and alleviate bottlenecks.
10Gb Ethernet bandwidth is ideal for high performance computing, database clusters.
(KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over 5X the size of a standard 1500byte Ethernet frame. With jumbo frames, networks can achieve higher throughput performance and greater
CPU utilization. These attributes are particularly useful for database transfer and tape backup operations.
Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load balancing
interrupts between CPUs/cores
sent to the host. This process optimizes host efficiency, leaving the CPU available for other duties.
across a QoS-aware network for improved traffic flow.
to be separated into multiple virtual NICs for added network segmentation and enhanced security and
performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to within
the same VLAN domain also improves performance.
Offloading
Virtualization
optimize host efficiency, leaving the CPU available for other duties.
performance demands of consolidated virtual workloads.
Page
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Standard Features
Page 3
share single PCIe resources. The device is capable of SR-IOV, and requires Firmware, Software and OS support.
IEEE 1588 &
Support hardware-enabled IEEE 1588, a standard that defines PTP (Precision Time Protocol), a high-precision
RDMA
Not Supported
iSCSI
The HPE 570FLB does not support accelerated iSCSI or iSCSI boot.
Ease of Deployment and Management
PXE Boot Support
Supports the Preboot eXecution Environment (PXE) allows the server to boot over the network and download
FlexibleLOM slot
Compatible with HPE FlexibleLOM slot for c-Class Gen8 blade servers
Network Adapter
The HPE 570FLB adapter support for NIC teaming helps IT administrators increase network fault tolerance and
Management
The HPE 570FLB adapter can be administered from HPE Systems Insight Manager (SIM). The adapters can be
HPE Sea of
Support for HPE's Sea of Sensors which is a collection of 32 sensors that automatically track thermal activity -
Warranty
Hewlett Packard Enterprise branded hardware options qualified for BladeSystem c-Class and p-Class servers
at: http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/index.aspx#.V4e3tPkrJhE
802.1AS
Compatibility
Teaming
time protocol for clock synchronization used in measurement and control systems.
software residing in the network.
improve workload balance. These capabilities optimize availability, improve performance and help reduce costs
Support
managed individually or in teams, providing SNMP based statistics for reporting purposes. The 570FLB adapter
can also be managed by other applications with SNMP support.
Sensors 3D
heat - across the server. When temperatures get too high, sensors can kick on fans and make other adjustments
to reduce energy usage. What makes it better is the upgrade from all six fans kicking on at one time to a new
system where only one kicks on - the one in proximity of the area that started heating up - thus reducing the
amount of energy used for cooling.
are covered by a global limited warranty and supported by HPE Services and a worldwide network of Hewlett
Packard Enterprise Authorized Channel Partners. The Hewlett Packard Enterprise branded hardware option
diagnostic support and repair is available for one year from date of purchase, or the length of the server they are
attached to, whichever is greater. Support for software and initial setup is available for 90 days from date of
purchase. Additional support may be covered under the warranty or available for an additional fee.
Enhancements to warranty services are available through HPE Care Pack services or customized service
agreements.
Additional information regarding worldwide limited warranty and technical support is available
QuickSpecs
port 570FLB Adapter
Compatibility
4
HPE ProLiant
• HPE ProLiant BL460c Gen8
Supported
• HPE 6120XG Blade Switch
limited to 1Gb per port connection.
Server Support
HPE Ethernet 10Gb 2-
Interconnect
Modules
• HPE 6120G/XG Blade Switch
• HPE 1:10Gb Ethernet BL-c Switch
• Cisco Catalyst 3120G Blade Switch for HPE
• Cisco Catalyst 3120X Blade Switch for HPE
• Cisco Catalyst 3020 Blade Switch
• Cisco Fabric Extender B22HP for HPE
• HPE GbE2c Layer 2/3 Ethernet Blade Switch
• HPE 1GbE Pass Thru Module
• 10GbE Ethernet Pass-Thru Module
• HPE 6125G Ethernet Blade Switch
• HPE 6125G/XG Ethernet Blade Switch
NOTE: Except for the HPE 6120XG and the Cisco B22 Fabric Extender, all other supported interconnects are
Page
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Service and Support
5
Service and
HPE Technology Services
Recommended
Recommended HPE Care Pack Services for optimal satisfaction with your HPE product
HW, the
Related Services
Related HPE Care Pack Services to enhance your HPE product experience
3-Year HPE 6-hour Onsite Call-to-Repair, HPE Collaborative Support
Support
HPE Technology Services offers you consultants and support experts to solve your most complex infrastructure
problems. We help keep your business running, boost availability and avoid downtime.
Protect your business beyond warranty with HPE Care Pack Services
When you buy HPE Options, it's also a good time to think about what level of service you may need. HPE Care
Pack services provide total care and support expertise with committed response choices designed to meet your
IT and business need.
HPE Foundation Care services deliver scalable support-packages for Hewlett Packard Enterprise industrystandard servers and software. You can choose the type and level of service that is most suitable for your
business needs. New to this portfolio is HPE Collaborative Support. If you are running business critical
environments, Hewlett Packard Enterprise offers Proactive Care or Critical Advantage. These services help you
deliver high levels of application availability through proactive service management and advanced technical
response.
Here is the support service recommendation from the Foundation Care and Proactive Care portfolio. For
customized support service solution, Hewlett Packard Enterprise can work with you to tailor a service solution
for your unique support requirements using broader services portfolio of Foundation Care and Proactive Care.
Services
3-Year HPE 24x7 4 hour Response, Hardware Support Onsite Service
Provides you with rapid remote support and if required an Hewlett Packard Enterprise Authorized
representative who will arrive on site any time and day of the year to begin hardware maintenance service
within 4 hours of the service request being logged.
http://h20566.www2.hpe.com/portal/site/hpsc?ac.admitted=1467740454177.125225703.1938120508
OR
3-Year HPE 24x7 4 hour Response, HPE Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution, and basic
software problem diagnosis, fault isolation, and resolution if available to HPE. If the problem is with HPE
representative will arrive on site any time and day of the year to begin hardware maintenance service within 4
hours of the service request being logged. In case, the issue is with HPE or supported third-party software
product and cannot be resolved by applying known fixes, Hewlett Packard Enterprise will contact the thirdparty vendor and create a problem incident on your behalf.
HPE ProLiant Server Hardware Installation
Provides for the basic hardware installation of Hewlett Packard Enterprise branded servers, storage devices and
networking options to assist you in bringing your new hardware into operation in a timely and professional
manner.
https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=5981-9356EN
3-Year HPE 24x7 4 hour Response, Proactive Care or Critical Advantage
Helps optimize your systems and delivers high levels of application availability through proactive service
management and advanced technical response. A skilled Technical Manager will own your query or issue end to
end until resolved, delivering a single point of contact for you.
http://h20566.www2.hpe.com/portal/site/hpsc?ac.admitted=1467740454177.125225703.1
OR
Page
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Service and Support
Page 6
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to return
. In case, the issue
Hewlett
class consultancy and technical services. You can buy Proactive
Insight Remote
Support
Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn
the hardware in operating condition within 6 hours of the initial service request to the HPE Global Solution
Center, and basic software problem diagnosis, fault isolation, and resolution if available to HPE
is with HPE or supported third-party software product and cannot be resolved by applying known fixes,
Packard Enterprise will contact the third-party vendor and create a problem incident on your behalf.
HPE Proactive Select Service
Provides a flexible way to purchase HPE best-inSelect Service Credits when you purchase your hardware and then use the credits over the next 12 months.
http://h20195.www2.hp.com/V2/GetPDF.aspx/4AA2-3842ENN.pdf
more http://h20564.www2.hpe.com/hpsc/doc/public/display?docId=c04844073
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Related Options
7
Additional c-Class
BladeSystem Gen8
Adapters
Flexible LOM Adapters
HP FlexFabric 10Gb 2-port 534FLB Adapter
700741-B21
HP FlexFabric 10Gb 2-port 554FLB Adapter
647586-B21
HP Flex-10 10Gb 2-port 530FLB Adapter
656590-B21
HP Ethernet 10Gb 2-port 560FLB Adapter
655639-B21
Mezzanine Adapters
HP FlexFabric 10Gb 2-port 534FLB FIO Adapter
700742-B21
HP Flex-10 10Gb 2-port 530M Adapter
631884-B21
HP Flex-10 10Gb 2-port 552M Adapter
674764-B21
HP Ethernet 1Gb 4-port 366M Adapter
615729-B21
HP FlexFabric 10Gb 2-port 534FLB FIO Adapter
700742-B21
HP Flex-10 10Gb 2-port 530M Adapter
631884-B21
HPE c-Class
BladeSystem
Interconnect
Options
HP 6120XG Blade Switch
516733-B21
HP Cisco B22HP Fabric Extender for BladeSystem c-Class
641146-B21
HP GbE2c Ethernet Blade Switch for HP c-Class BladeSystem
410917-B21
HP 1GB Ethernet Pass-Thru Module for c-Class BladeSystem
406740-B21
HP 1GB Ethernet Pass-Thru Module for c-Class BladeSystem
406740-B21
HP 6125G Ethernet Blade Switch
658247-B21
HP 6125G/XG Ethernet Blade Switch
658250-B21
Page
QuickSpecs
port 570FLB Adapter
Technical Specifications
8
General
Network processor
Solarflare™ SFC9120Ethernet Controller
Data rate
Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex theoretical
bandwidth.
Bus type
PCI Express v3.0 (Gen 3) x8
Form factor
FlexibleLOM
IEEE Compliance
802.3, , 802.3x, 802.3ad, 802.3p/802.1q, 802.3ae
Power and
Operating
Temperature
0°C to 55°C / 32°F to 131°F
Humidity
10% to 90% non-condensing
Power requirement
<8W
Emissions
classification
FCC Class A
Agency Approvals
USA: FCC Part 15 Class A
Korea: KN22 Class A, KN24
RoHS Compliance
6 of 6
Safety
UL Mark (USA and Canada)
CE Mark
EN 60590
Operating System
Red Hat Enterprise Linux 5. 8, 5.9, 6.2, 6.3 and 7.2
Environment-
End-of-life
Hewlett Packard Enterprise offers end-of-life Hewlett Packard Enterprise product
OEM customers who integrate and re-sell Hewlett Packard Enterprise equipment.
Specifications
HPE Ethernet 10Gb 2-
Environmental
Specifications
Support
SLES 10 SP4 and 11SP2
Canada: ICES=--3, Issue 4
Japan: VCCI V3 (2010.04) Class A
International: EN55022:2006 + A1:2007 Class A
International: EN55024:1998+A1:2011+A2; EN61000-3-2:2006, EN61000-3-3:2008
Taiwan: BSMI, CNS13438 (2006) Class A
Australia/New Zealand (AS/NZS): EN55022:2006+A12007 class A
friendly Products
and Approach
Management and
Recycling
return, trade-in, and recycling programs in many geographic areas. For trade-in
information, please go to:
http://www.hpe.com/info/recycle. To recycle your product,
please go to: http://www.hpe.com/info/recycle or contact your nearest Hewlett
Packard Enterprise sales office. Products returned to Hewlett Packard Enterprise will
be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment
information for each product type for use by treatment facilities. This information
(product disassembly instructions) is posted on the Hewlett Packard Enterprise web
http://www.hpe.com/info/recycle. These instructions may be used by
site at:
recyclers and other WEEE treatment facilities as well as Hewllet Packard Enterprise
Page
QuickSpecs
HPE Ethernet 10Gb 2-
port 570FLB Adapter
Summary of Changes
9
Date
Version History
Action
Description of Change
05-Dec-2016
From Version 2 to
Changed
Related Options and Technical Specifications sections were updated.
Removed
Obsolete SKU was deleted:
647590-B21
20-May-2016
From Version 1 to
Changed
Sections were updated in QuickSpecs
Removed
Obsolete SKUs were deleted:
Sign up for updates
© Copyright 2016 Hewlett Packard Enterprise Development LP. The information contained herein is subject to
change without notice. The only warranties for Hewlett Packard Enterprise products and services are set forth in the
express warranty statements accompanying such pr
constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for technical or editorial errors or
omissions contained herein.
Windows is a US registered trademark of Microso
c04312718
3
2
498358-B21, 438031-B21, 451438-B21, 451439-B21, 410916-B21.
oducts and services. Nothing herein should be construed as
ft Corporation.
- 14970 - Worldwide - V3 - 5-December-2016
Page
Loading...
