QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Overview
Page 1
The HPE 570SFP+ is a dual-port 10Gb Ethernet Onload server adapter is based on Solarflare's second generation 10GbE controller,
over standard Ethernet along with the lowest
TCP and UDP checksum offloading, MSI-X, NIC teaming (bonding), Receive Side Scaling (RSS), jumbo frames, and PXE boot.
HPE 570SFP+ - Low profile bracket
HPE 570SFP+ - Standard bracket
Models
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
HPE Ethernet 10Gb 2-port 570SFP+ Adapter
Solarflare™ SFC9020, and delivers unmatched message rates with low latency and jitter
CPU utilization and power consumption, enabling the industry's best performance and scalability for financial services and other
enterprise data centers.
The HPE 570SFP+ comes with both low profile and standard brackets and has two SFP+ cages that enable connections with DACs
as well as SR fiber optic modules. It supports high performance networking features such as VLAN tagging, low latency interrupts,
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Overview
Page 2
HPE Ethernet 10Gb 2-port 570SFP+ Adapter
718904-B21
Kit contents
• HPE Ethernet 10Gb 2-port 570SFP+ Adapter
• Product warranty statement
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
• Full height bracket (installed on card)
• Low-profile bracket
• Quick install card
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Compatibility
Page 3
ProLiant DL (rack-optimized):
NOTE: This is a list of Supported Servers. Some may be discontinued.
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Servers
• HPE ProLiant DL360p Gen8
• HPE ProLiant DL380p Gen8
• HPE ProLiant DL560 Gen8
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Standard Features
Page 4
The 20,000 Mbps full duplex Ethernet transfer rate per port (40 Gbps aggregate full duplex) delivers
The HPE 570SFP+ Adapter is designed with an eight lane (x8) PCI Express bus based on the PCIe v2.0
The HPE 570SFP+ Adapter supports jumbo frames (also known as extended frames), permitting up to a 9K
For overall improved system response, the HPE 570 SFP+ adapter supports standard TCP/IP offloading
Interrupt coalescing (interrupt moderation) groups multiple packets, thereby reducing the number of interrupts
IEEE 802.1Q virtual local area network (VLAN) protocol allows each physical port of the HPE 570SFP+ adapter
performance. VLANs increase security by isolating traffic between users. Limiting the broadcast traffic to within
Management
Like all HPE ProLiant server adapters, the HPE 570 SFP+ adapter ships with agents that can be managed from
The HPE 570SFP+ Adapter is a validated, tested, and qualified solution that is optimized for HPE ProLiant
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Dual-port 10
Gigabit Ethernet
Throughput
PCI Express
Interface
Jumbo Frames
outstanding network performance that improves response time and removes bottlenecks for the next
generation data center. 10 Gigabit Ethernet bandwidth is ideal for financial services, high performance
computing, database clusters, iSCSI storage, storage backups, grid systems, virtualization, server and I/O
consolidation, fabric consolidation, and more.
standard. The adapter is backward compatible with four lane (x4) PCI Express, automatically auto-sensing
between x8 and x4 slots.
byte (KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over 5X the size of a standard
1500-byte Ethernet frame. With jumbo frames, networks can achieve higher throughput performance and
greater CPU utilization. These attributes are particularly useful for database transfer and tape backup
operations.
TCP/IP Stateless
Offloading
techniques including:
• TCP/IP checksum offload (TCO) moves the TCP and IP checksum offloading from the CPU to the
• Large Send Offload (LSO) or TCP Segmentation Offload (TSO) allows the TCP segmentation to be
Interrupt
Coalescing
sent to the host. This process optimizes host efficiency, leaving the CPU available for other duties.
802.1p QoS
Tagging
to be separated into multiple virtual NICs for added network segmentation and enhanced security and
the same VLAN domain also improves performance. The HPE 570SFP+ Adapter provides support for 802.1Q
(VLAN).
Network Management
Support
HPE Systems Insight Manager or other management application that support SNMP.
network adapter.
handled by the adapter rather than the CPU.
Server Integration
servers. Hewlett Packard Enterprise validates a wide variety of major operating systems drivers with the full
suite of web-based enterprise management utilities including HPE Intelligent Provisioning and HPE Systems
Insight Manager that simplify network management.
This approach provides a more robust and reliable networking solution than offerings from other vendors and
provides users with a single point of contact for both their servers and their network adapters.
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Standard Features
Page 5
Each HPE 570SFP+ Adapter ships with a suite of operating system-tailored configuration utilities that allow the
LED Indicators
Bracket LED indicators show link integrity and network activity for easy troubleshooting.
The HPE 570SFP+ Adapter is SR-IOV capable in hardware (requires server FW, SW and OS support).
Preboot eXecution
Support for pre-boot execution environment (PXE) enables automatic deployment of computing resources
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Configuration
Utilities
SR-IOV
user to enable initial diagnostics and configure adapter teaming. This includes a teaming GUI for Microsoft
Windows operating systems. Additionally, support for scripted installations of teams in a Microsoft Windows
environment allow for unattended OS installations.
Environment
(PXE)
Warranty
remotely from anywhere. It allows a new or existing server to boot over the network and download software,
including the operating system, from a management/ deployment server at another location on the network.
Additionally, PXE enables decentralized software distribution and remote troubleshooting and repairs.
Maximum: The remaining warranty of the HPE product in which it is installed (to a maximum three-year,
limited warranty).
Minimum: One year limited warranty.
Additional information regarding worldwide limited warranty and technical support is available at:
http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/index.aspx#.V4e3tPkrJhE
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Service and Support
Page 6
Technology Services offers you consultants and support experts to solve your most complex infrastructure
Recommended
3-Year HPE 24x7 4 hour Response, Hardware Support Onsite Service
http://h20566.www2.hpe.com/portal/site/hpsc?ac.admitted=1467740454177.125225703.1938120508
re problem resolution, and basic
n
HPE ProLiant Server Hardware Installation
servers, storage devices and
Related Services
3-Year HPE 24x7 4 hour Response, Proactive Care or Critical Advantage
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
Service and
Support
HPE Technology Services
HPE
problems. We help keep your business running, boost availability, and avoid downtime.
Protect your business beyond warranty with HPE Pointnext operational services
When you buy HPE Options, it's also a good time to think about what level of service you may need. HPE
Pointnext operational services provide total care and support expertise with committed response choices
designed to meet your IT and business need.
HPE Foundation Care services deliver scalable support-packages for Hewlett Packard Enterprise industrystandard servers and software. You can choose the type and level of service that is most suitable for your
business needs. New to this portfolio is HPE Collaborative Support. If you are running business critical
environments, Hewlett Packard Enterprise offers Proactive Care or Critical Advantage. These services help you
deliver high levels of application availability through proactive service management and advanced technical
response.
Here is the support service recommendation from the Foundation Care and Proactive Care portfolio. For
customized support service solution, Hewlett Packard Enterprise can work with you to tailor a service solution
for your unique support requirements using broader services portfolio of Foundation Care and Proactive Care.
Recommended HPE Pointnext operational services for optimal satisfaction with your HPE
product
Services
Provides you with rapid remote support and if required an Hewlett Packard Enterprise Authorized
representative who will arrive on site any time and day of the year to begin hardware maintenance service
within 4 hours of the service request being logged.
OR
3-Year HPE 24x7 4 hour Response, HPE Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardwa
software problem diagnosis, fault isolation, and resolution if available to HPE. If the problem is with HPE HW,
the representative will arrive on site any time and day of the year to begin hardware maintenance service withi
4 hours of the service request being logged. In case, the issue is with HPE or supported third-party software
product and cannot be resolved by applying known fixes, Hewlett Packard Enterprise will contact the thirdparty vendor and create a problem incident on your behalf.
Provides for the basic hardware installation of Hewlett Packard Enterprise branded
networking options to assist you in bringing your new hardware into operation in a timely and professional
manner
https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=5981-9356EN
Related HPE Pointnext operational services to enhance your HPE product experience
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Service and Support
Page 7
Helps optimize your systems and delivers high levels of application availability through proactive service
Provides 24 X 7 remote monitoring, proactive notifications, and problem resolution. Learn more
Personalized online support portal with access to information, tools and experts to support Hewlett Packard
Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to maintain
For ProLiant servers and storage systems, this service covers HPE-branded hardware options qualified for the
server, purchased at the same time or afterward, internal to the enclosure, as well as external monitors up to 22"
exceeded. Coverage of the UPS battery is not included; standard warranty terms and conditions apply.
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
management and advanced technical response. A skilled Technical Manager will own your query or issue end
to end until resolved, delivering a single point of contact for you
http://h20566.www2.hpe.com/portal/site/hpsc?ac.admitted=1467740454177.125225703.1
OR
3-Year HPE 6-hour Onsite Call-to-Repair, HPE Collaborative Support
Offers customers a single point of contact for server problem diagnosis, hardware problem resolution to return
the hardware in operating condition within 6 hours of the initial service request to the HPE Global Solution
Center, and basic software problem diagnosis, fault isolation, and resolution if available to HPE. In case, the
issue is with HPE or supported third-party software product and cannot be resolved by applying known fixes,
Hewlett Packard Enterprise will contact the third-party vendor and create a problem incident on your behalf.
HPE Proactive Select Service
Provides a flexible way to purchase HPE best-in-class consultancy and technical services. You can buy
Proactive Select Service Credits when you purchase your hardware and then use the credits over the next 12
months.
8855ENW&search=4AA3-8855ENW
https://www.hpe.com/h20195/v2/GetDocument.aspx?docname=4AA3-
Insight Remote
Support
http://www.hpe.com/info/insightremotesupport
HPE Support
Center
Enterprise business products. Submit support cases online, chat with HPE experts, access support resources or
collaborate with peers. Learn more
http://h20564.www2.hpe.com/hpsc/doc/public/display?docId=c04844073
The HPE Support Center Mobile App* allows you to resolve issues yourself or quickly connect to an agent for
live support. Now, you can get access to personalized IT support anywhere, anytime.
HPE Insight Remote Support and HPE Support Center are available at no additional cost with a HPE warranty,
HPE Care Pack or Hewlett Packard Enterprise contractual support agreement.
*The Hewlett Packard Enterprise Support Center Mobile App is subject to local availability
Parts and
materials
the covered hardware product in operating condition, including parts and materials for available and
recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage
limitations as set forth in the manufacturer's operating manual, product QuickSpecs, or the technical product
data sheet will not be provided, repaired, or replaced as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced
by HPE due to malfunction.
Warranty /
Service Coverage
and tower UPS products; these items will be covered at the same service level and for the same coverage
period as the server unless the maximum supported lifetime and/or the maximum usage limitation has been
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Service and Support
Page 8
To learn more on services for HPE ESSN Options, please contact your Hewlett Packard Enterprise sales
https://www.hpe.com/us/en/servers
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives replaced
by HPE due to malfunction. It does not apply to any exchange of Disk or SSD/Flash Drives that have not failed.
SSD/Flash Drives that are specified by HPE as consumable parts and/or that have exceeded maximum
supported lifetime and/or the maximum usage limit as set forth in the manufacturer's operating manual or the
technical data sheet are not eligible for the defective media retention service feature option.
For more
information
representative or Hewlett Packard Enterprise Authorized Channel Partner. Or visit:
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Related Options
Page 9
Direct Attach
C
HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 0.5m Direct Attach Copper Cable
487649-B21
HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 1m Direct Attach Copper Cable
487652-B21
HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 3m Direct Attach Copper Cable
487655-B21
HPE BladeSystem c-Class 10GbE SFP+ to SFP+ 5m Direct Attach Copper Cable
537963-B21
HPE FlexNetwork X240 10G SFP+ to SFP+ 0.65m Direct Attach Copper Cable
JD095C
HPE FlexNetwork X240 10G SFP+ to SFP+ 1.2m Direct Attach Copper Cable
JD096C
HPE FlexNetwork X240 10G SFP+ to SFP+ 3m Direct Attach Copper Cable
JD097C
HPE FlexNetwork X240 10G SFP+ to SFP+ 5m Direct Attach Copper Cable
JG081C
HPE FlexNetwork X240 10G SFP+ SFP+ 7m Direct Attach Copper Cable
JC784C
NOTE:
environments.
Fiber Optic
Modules
HPE BladeSystem c-Class 10Gb SFP+ SR Transceiver
455883-B21
HPE BladeSystem c-Class 10Gb SFP+ LR Transceiver
455886-B21
HPE BladeSystem c-Class Virtual Connect 1G SFP SX Transceiver
453151-B21
NOTE:
environments.
Fiber Optic Cables
HPE LC to LC Multi-mode OM3 2-Fiber 0.5m 1-Pack Fiber Optic Cable
AJ833A
HPE LC to LC Multi-mode OM3 2-Fiber 1.0m 1-Pack Fiber Optic Cable
AJ834A
HPE LC to LC Multi-mode OM3 2-Fiber 5.0m 1-Pack Fiber Optic Cable
AJ836A
HPE LC to LC Multi-mode OM3 2-Fiber 15.0m 1-Pack Fiber Optic Cable
AJ837A
HPE LC to LC Multi-mode OM3 2-Fiber 30.0m 1-Pack Fiber Optic Cable
AJ838A
HPE LC to LC Multi-mode OM3 2-Fiber 50.0m 1-Pack Fiber Optic Cable
AJ839A
NOTE:
environments.
Gigabit Server
Adapters
HPE NC365T 4-port Ethernet Server Adapter
593722-B21
HPE Ethernet 1Gb 4-port 331T Adapter
647594-B21
HPE Ethernet 1Gb 2-port 332T Adapter
615732-B21
HPE Ethernet 1Gb 2-port 361T Adapter
652497-B21
10 Gigabit Server
Adapters
HPE Ethernet 10Gb 2-port 530SFP Adapter
652503-B21
HPE Ethernet 10Gb 2-port 530T Adapter
656596-B21
HPE Ethernet 10Gb 2-port 560SFP+ Adapter
665249-B21
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
able
Direct Attach Cable (DAC) must be purchased separately for copper
Fiber transceivers and cables must be purchased separately for fiber-optic
Fiber transceivers and cables must be purchased separately for fiber-optic
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Related Options
Page 10
HPE Ethernet 10Gb 2-port 561T Adapter
716591-B21
FlexibleLOM
Adapters
NOTE:
adapter.
Ethernet Adapters
HPE Ethernet 1Gb 4-port 366FLR Adapter
665240-B21
HPE Ethernet 10Gb 2-port 530FLR-SFP+ Adapter
647581-B21
HPE Ethernet 10Gb 2-port 560FLR-SFP+ Adapter
665243-B21
HPE Ethernet 10Gb 2-port 561FLR-T Adapter
700699-B21
HPE Ethernet 10Gb 2-port 570FLR-SFP+ Adapter
717491-B21
FlexFabric Adapters
HPE FlexFabric 10Gb 2-port 533FLR-T Adapter
700759-B21
HPE FlexFabric 10Gb 2-port 534FLR-SFP+ Adapter
700751-B21
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
A minimum of two Gigabytes (2 GB) of server memory is required per each
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Technical Specifications
Page 11
Solarflare (SFC9020)
Data rate
Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex theoretical
bandwidth.
Bus type
PCI-e v2.0 at 5 GT/s, x8
Standard and low profile adapter compliant with the PCIe standard
IEEE Compliance
Solarflare (SF 9020)
802.3, 802.1ab, 802.3x, 802.3ad, 802.3p, 802.1q, 802.3ae
Temperature
41° to 131° F (5° to 55° C)
Humidity
5% to 95% non-condensing
Power
7.5W maximum (5.9W Typical)
5 of 6
Red Hat Enterprise Linux 5.8, 5.9, 6.2 and 6.3
SLES 10 SP4 and 11SP2
Hewlett Packard Enterprise offers end-of-life Hewlett Packard Enterprise product
return
information, please go to:
product, please go to:
Hewlett Packard Enterprise sales
Enterprise will
The EU WEEE directive (2002/95/EC) requires manufacturers to provide
treatment information for each product type for use by treatment facilities. This
information (pro
Enterprise
may be used by recyclers and other WEEE treatment facilities as wel
customers who integrate and re-sell Hewlett Packard Enterprise equipment.
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
General
Specifications
Network Processor
Form factor
Power and
Environmental
Specifications
Operating
System
Support
Environmentfriendly
Products and
Approach
Operating
RoHS Compliance
NOTE: For more Linux OS support & certification information, please visit our the ProLiant & BladeSystem
Server Linux matrix:
http://h17007.www1.hpe.com/us/en/enterprise/servers/supportmatrix/redhat_linux.aspx#.V4e8tPkrJD8
End-of-life Management
and Recycling
, trade-in, and recycling programs in many geographic areas. For trade-in
http://www.hpe.com/info/recycle. To recycle your
http://www.hpe.com/info/recycle or contact your nearest
office. Products returned to Hewlett Packard
be recycled, recovered or disposed of in a responsible manner.
duct disassembly instructions) is posted on the Hewlett Packard
web site at: http://www.hpe.com/info/recycle. These instructions
l as HPE OEM
QuickSpecs
HPE Ethernet 10Gb 2P 570SFP+ Adapter
Summary o
Page 12
Date
Version History
Action
Description of Change
23-Oct-2017
From Version 5 to 6
Changed
Care Pack naming and Service and Support- Parts and Materials updated.
26-Aug-2016
From Version 4 to 5
Changed
Standard Features section was updated.
Removed
Obsolete SKUs were deleted:
489892-B21, 581201-B21, 614203-B21, 629135-B21, 629138-B21, 629142-B21.
10-Sep-2013
From Version 3 to 4
Changed
Compatibility, 10 Gigabit Server Adapters, and FlexibleLOM Servers were
revised.
03-May-2013
From Version 2 to 3
Changed
Updated the Overview Section
Technical Specifications- General Specifications
25-Mar-2013
From Version 1 to 2
Changed
Corrected a spelling error in the title.
Sign up for updates
© Copyright 2017 Hewlett Packard Enterprise Development LP. The information contained herein is
subject to change without notice. The only warranties
services are set forth in the express warranty statements accompanying such products and services.
Nothing herein should be construed as constituting an additional warranty. Hewlett Packard Enterprise
shall not
Windows is a US registered trademark of Microsoft Corporation.
c04123188
RETIRED: Retired products sold prior to the November 1, 2015 separation of Hewlett-Packard Company into Hewlett Packard Enterprise Company and HP Inc. may
have older product names and model numbers that differ from current models.
f Changes
221691-B21, 221691-B22, 221691-B23, 221692-B21, 221692-B22, 221692-B23,
221692-B26, 221692-B27, 503746-B21, 412648-B21, 435508-B21, 394791B21, 394793-B21, 538696-B21, 458492-B21, 468332-B21, 593717-B21,
Standard Features- Network Management
for Hewlett Packard Enterprise products and
be liable for technical or editorial errors or omissions contained herein.
- 14544 - Worldwide - V6 - 23-October-2017
Loading...
