QuickSpecs
HPE Hard Disk Drives
Overview
1
HPE Hard Disk Drives
HPE Hard Disk Drives (HDDs) are engineered to deliver optimum performance, reliability, compatibility, and data security across
HPE server and storage platforms making them the preferred choice for workloads ranging from small businesses to large enterprise.
Performance
Reliability
Compatibility
Security
HPE HDDs are available for three
Critical, and Entry
HPE HDD portfolio: Proven performance for every workload
Class
Enterprise
Midline
Entry*
Workload
High
Medium
Low
Mission-critical, high I/O:
customer relationship management (CRM)
High capacity, high availability storage:
SAS 12Gb
SATA 6Gb
RPM
Form factor
Capacities
Up to 900GB
Up to 2.4TB
Up to 12TB
Up to 4TB
Warranty
NOTE:* Supported on select HPE ProLiant servers only.
:
• HPE HDDs are tuned and tested with on-going quality monitoring throughout their lifecycle
• HPE optimizes HDD firmware for predictable and consistent HDD performance
• Full portfolio of high-performance Mission Critical and high-capacity Business Critical drive solutions
:
• HPE’s industry-leading rigorous testing and qualification program, backed by 2.4 million test hours
• Pre-failure Alerts with HPE Smart Array Controller, Systems Insight Manager, and HPE Smart firmware
• 3x faster firmware and software updates with HPE Service Pack for ProLiant (HPE SPP)
• Best-in-class supply assurance program reduces downtime due to product delays
:
• Simplify HDD planning and standardize HDDs across HPE server and storage solutions
• Common HDD carriers mean re-purposing drives in other servers is a snap
:
• HPE Digitally Signed Firmware helps prevent against malicious attacks
• HPE Smart Array SR Secure Encryption
solution for data-at-rest on all SAS/SATA drives
• HPE Smart Carriers
report drive activity and health
is a FIPS 140-2 Level 1 validated enterprise class controller-based encryption
1
types of workloads: Enterprise high-performance Mission Critical, Midline high-capacity Business
-level storage solutions
Usage
Interface
Email, enterprise resource planning (ERP),
SAS 12Gb
Backup, archive, reference
Low I/O:
Boot and backup
SATA 6Gb
15000 10000 7200 7200
SFF & LFF SFF SFF & LFF LFF
3 years 3 years 1 year 1 year
Page
QuickSpecs
HPE Hard Disk Drives
Overview
2
What's New
• HPE 600GB Enterprise 15K SAS 12G LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware HDD
HPE Recommended Options
HPE recommended options have best performance, value and availability.
Recommended
the best fit with timely availability.
Extended
customers in specific markets or with specific workloads,
great value and performance but typically have a longer lead-time
Firmware Updates:
• HPE 300GB Enterprise 15K SAS 12G LFF (3.5in) SCC 3yr Wty Digitally Signed Firmware HDD
Offering the best combination of performance, value and availability, Recommended Options have been selected by HPE
experts to provide the right technology for a range of workloads and market segments. Fully integrated into the ProLiant
management and security experience, Recommended Options provide
Extended Options provide an extended catalog of products tailored for
requiring the utmost in performance or value. Fully integrated into the ProLiant management and security experience,
Extended Options represent
.
HPE Recommended Options – View the list for your region
• Digitally Signed Firmware – Prevent unauthorized access to your data with the expansion of integrated HPE Digitally
Signed Firmware (DS) on new drives; providing the security and assurance that drive firmware comes from a trusted
source and protects against malicious attacks.
• For advanced data protection and encryption, customers should consider HPE Smart Array Controllers with HPE Smart
Array Secure SR Encryption. It is a controller-based data encryption solution for HPE servers that protect data-at-rest on
any bulk attached storage. This solution meets stringent compliance regulations such as HIPAA and Sarbanes-Oxley.
Page
QuickSpecs
HPE Hard Disk Drives
Overview
3
Recommended Models
Offering the best combination of performance, value and availability, Recommended Options have been selected by HPE experts to
provide the right technology for a range of workloads and market
Fully integrated into the ProLiant management and security experience, Recommended Options provide the best fit with timely
availability.
Standard Carrier
SKU
segments.
Category Interface
Enterprise
(15K rpm)
SAS 12G
Enterprise
(10K rpm)
Midline
(7.2K rpm)
SAS 12G
Form
factor
LFF
SFF
LFF
Format Capacity
300GB P04693-B21 (SCC)
600GB P04695-B21 (SCC)
300GB 870753-B21 -
512n
600GB 870757-B21
900GB 870759-B21
300GB 872475-B21 -
600GB 872477-B21 -
1.2TB 872479-B21 -
1.8TB 872481-B21 -
512e
2.4TB 881457-B21 -
2TB 872485-B21 833926-B21
512n
4TB 872487-B21 833928-B21
8TB 819201-B21 834031-B21 858384-B21
512e
10TB 857646-B21He
12TB 881781-B21
HDD Carrier
Smart Carrier SKU Low Profile SKU
SFF
512n
512n
2TB 765466-B21 -
1TB 832514-B21 -
1TB 861691-B21 861686-B21
4TB 872491-B21 861683-B21
6TB 861750-B21 861742-B21
LFF
Midline
(7.2K rpm)
SATA 6G
512e
8TB 819203-B21 834028-B21
10TB 857650-B21He
12TB 881787-B21He
SFF
512n
2TB 765455-B21 -
1TB 655710-B21 -
Page
QuickSpecs
HPE Hard Disk Drives
Overview
4
Recommended Models
HDD Carrier
No Carrier SKU (Raw/Non-Hot Plug)
Entry
(7.2K)
NOTE:
NOTE:
SATA 6G LFF
He
Helium Drive.
512n 1TB 801882-B21
Refer to the appropriate Server QuickSpecs for full compatibility details.
Page
QuickSpecs
HPE Hard Disk Drives
Standard Features
5
What is HPE Hard disk
Hewlett Packard Enterprise drives are tuned to deliver optimum performance for HPE Servers. They
Tower Servers, Apollo family, Blade and Synergy Platforms.
Drive Quality and
While selecting the drives in our Enterprise portfolio, only those drives with a performance level
workload (less than 40% I/O) environments.
Pre-Failure Alert
When used in conjunction with a SMART Array Controller and Systems Insight Manager, the SMART
Services section below for additional services.
Smart Carriers
HPE Hard Drives with smart carriers are designed to provide an interface to communicate critical
cause data loss.
Helium Drives
Although hard drives are sealed, they have air inside. Air can create turbulence-induced risk vibrations
turbulence also means helium drives tend to use less power, and run cooler and quieter.
Support Matrix
Please see the following URL for the latest list of supported servers and
https://www.hpe.com/us/en/servers/server-options.html
Warranty
Enterprise hard drives have a 3 year limited warranty regardless of the warranty period for the system
which they are installed.
drive?
Performance
undergo an intense qualification process to eliminate firmware and O/S incompatibilities. HPE drive
firmware is designed to maximize both functionality and compatibility with HPE ProLiant Rack and
suitable for an enterprise environment are selected through the Hewlett Packard Enterprise
qualification process and are labeled "best-in-class." HPE Midline drives undergo a similar qualification
process to ensure that you get the economical reliability and performance you need for your low
capable firmware in HPE hard drives enables extensive fault prediction capabilities. If potential
problems develop in one of the drives, the Smart Array Controller, Systems Insight Manager and/or
SMART hard disk drive lets you know in advance so you can have the drive replaced, before it fails,
under warranty.
NOTE: All drives are protected by a Pre-Failure Alert when used with a HPE Smart Array controller
and Systems Insight Manager, allowing hard drives to be replaced before failure under warranty. In
addition, all drives are covered by a one or three-year limited on-site warranty period for the
system in which they are installed. The drive warranty is automatically uplifted when used in a
server or MSA for which a HPE Pointnext service contract is purchased. Please see the Support
status and management information. System status LED icons and a spinning activity ring reflecting
the data-writing process notify users of the current system status. A blue LED located behind the
handle can be activated remotely to guide users to a specific drive tray, while a do-not-remove icon
positioned on the tray’s eject button lights up to warn users when the removal of the drive would
which can limit the storage density of HDDs. Newer helium-filled drives virtually eliminate turbulence
because helium is 1/7th as dense as air. This lower density allows the read/write mechanism to spin
more easily and precisely, with less drag. Less internal turbulence means the drive platters can be
closer together, allowing more platters and increasing the capacity potential in the same space. Less
enclosures:
in which they are installed.
Midline hard drives have a 1 year limited warranty regardless of the warranty period for the system in
Page
QuickSpecs
HPE Hard Disk Drives
Service and Support
6
Service and Support
HPE Technology Services for Industry Standard Servers
ProLiant Server. No separate HPE Pointnext s need to be purchased.
Connect your devices to
Unlock all of the benefits of your technology investment by connecting your products to Hewlett
2. HPE CSC Reports 2014-2015
HPE Support Center
Personalized online support portal with access to information, tools and experts to support HPE
HPE Support Center Mobile App allows you to resolve issues yourself or quickly connect to an agent for
HPE Insight Remote Support and HPE Support Center are available at no additional cost with a Hewlett
NOTE: HPE Support Center Mobile App above is subject to local availability.
Parts and materials
Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to
Parts and components that have reached their maximum supported lifetime and/or the maximum usage
replaced by Hewlett Packard Enterprise due to malfunction.
HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and
stability powered by a rich portfolio of consulting and support services designed to add value to our
core products and solutions connect to Hewlett Packard Enterprise to help prevent problems and solve
issues faster. Our support technology lets you to tap into the knowledge of millions of devices and
thousands of experts to stay informed and in control, anywhere, any time.
Protect your business beyond warranty with HPE Support Services
HPE support services offer complete care and support expertise with committed response choices that
are designed to meet your IT and business needs.
NOTE: HPE Hard drives are covered under the HPE Pointnext /Service Contract applied to the HPE
HPE
Packard Enterprise. Achieve up to 77%1 reduction in down time, near 100%2 diagnostic accuracy and a
single consolidated view of your environment. By connecting, you will receive 24x7monitoring, prefailure alerts, automatic call logging, and automatic parts dispatch. HPE Proactive Care Service and HPE
Datacenter Care Service customers will also benefit from proactive activities to help prevent issues and
increase optimization.
All of these benefits are already available to you with your server storage and networking products,
securely connected to HPE support.
1. IDC Whitepaper
business products. Submit support cases online, chat with Hewlett Packard Enterprise experts, access
support resources or collaborate with peers. Learn more
https://support.hpe.com/hpesc/public/home
live support. Now, you can get access to personalized IT support anywhere, anytime.
Packard Enterprise warranty, HPE Support Services or HPE contractual support agreement.
maintain the covered hardware product in operating condition, including parts and materials for
available and recommended engineering improvements.
limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical
product data sheet will not be provided, repaired, or replaced as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
Page
QuickSpecs
HPE Hard Disk Drives
Technical Specifications
– Recommended Portfolio
7
Service Coverage
For ProLiant servers and storage systems, the service on the main product covers HPE-branded
reached this limit will not be eligible for services coverage.
For more information
To learn more on services for HPE Server Options, please contact your Hewlett Packard Enterprise sales
representative or Hewlett Packard Enterprise Authorized Channel Partner. Or
visit:
or https://www.hpe.com/us/en/integrated-systems/bladesystem.html
hardware options not designated by Hewlett Packard Enterprise as requiring separate coverage, that
are qualified for the server, purchased at the same time or afterward and internal to the enclosure.
These items will be covered at the same service level and for the same coverage period as the server
unless the maximum supported lifetime and/or the maximum usage limitation has been reached.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
replaced by Hewlett Packard Enterprise due to malfunction. It does not apply Disk or SSD/Flash Drives
that have not failed. SSD/Flash Drives that are specified by Hewlett Packard Enterprise as consumable
parts and/or that have reached maximum supported lifetime and/or the maximum usage limits as set
forth in the manufacturer's operating manual, the product QuickSpecs, or the technical data sheet are
not eligible for the defective media retention service feature option.
Subject to: Maximum supported lifetime: This is a period in years set to equal the warranty for the
specific drive. After this period no further service coverage will be available for the drive. Maximum
usage limit: This is the maximum amount of data that can be written to the drive. Drives that have
https://www.hpe.com/us/en/product-catalog/servers/proliant-servers.html
Page
QuickSpecs
HPE Hard Disk Drives
Service and Support
8
HDD Selection
Supporting Helpful Links
http://www.hpe.com/info/rackandpower
http://www.hpe.com/info/poweradvisor
http://www.hpe.com/info/infrastructurearchitect
https://www.hpe.com/us/en/storage/entry-level.html
To streamline the configuration process for HPE ProLiant servers and to provide the best product availability, HPE recommends
HDDs from the list located here: http://www.hpe.com/products/recommend
Best product availability is limited to US, Canada, and Latin America at this time.
Page
QuickSpecs
HPE Hard Disk Drives
Technical Specifications
9
Recommended Portfolio
Form Factor
SFF (2.5”)
Carrier
Smart Carrier (SC)
Rotational Speed
15000 rpm
Dimensions
Interface
SAS
Height
0.62 in (15.6 mm)
Transfer Rate Synchronous (Max)
12Gb/sec
Width
2.98 in (75.7 mm)
Bytes/Sector
512
Depth
4.67 in (118.7 mm)
Operating Temperature
50° to 95° F (10° to 35°C)
Enterprise (15K rpm)
SKU
870753-B21
870757-B21
SKU Description
HPE 300GB SAS 12G
Enterprise 15K SFF
(2.5in) SC 3yr Wty
Digitally Signed
Firmware HDD
HPE 600GB SAS 12G
Enterprise 15K SFF
(2.5in) SC 3yr Wty
Digitally Signed
Firmware HDD
(MiB/s)
WT (IOPs)
OD Media Rate, Max
Sequential Throughput
128Kib Random Rd (IOPs)
128Kib Random 70% RD/ 30%
128Kib Random 50% RD/ 50%
WT (IOPs)
Power Idle Time (Watts)
(Watts)
Power Sequential Read
Power Random R/W (Watts)
260 220 220 220 2.6 3.6 4.4 3.9
260 220 220 220 4.7 6.1 6.3 6.3
(Watts)
Power Sequential Write
HPE 900GB SAS 12G
Enterprise 15K SFF
870759-B21
(2.5in) SC 3yr Wty
Digitally Signed
Firmware HDD
260 220 220 220 4.7 6.1 6.3 6.3
Page
QuickSpecs
HPE Hard Disk Drives
Technical Specifications
10
Recommended Portfolio
Form Factor
LFF (3.5”)
Carrier
Smart Carrier Converter (SCC)
Rotational Speed
15000 rpm
Dimensions
Interface
SAS
Height
1.06 in (26.8 mm)
Transfer Rate Synchronous (Max)
12Gb/sec
Width
4.16 in (105.8 mm)
Bytes/Sector
512
Depth
6.69 in (170.0 mm)
Operating Temperature
50° to 95° F (10° to 35°C)
HPE 300GB SAS 12G Enterprise
Digitally Signed Firmware HDD
HPE 600GB SAS 12G Enterprise
Digitally Signed Firmware HDD
Enterprise (15K rpm)
SKU SKU DESCRIPTION
P04695-B21
P04693-B21
15K LFF (3.5in) SCC 3yr Wty
15K LFF (3.5in) SCC 3yr Wty
(MiB/s)
WT (IOPs)
OD Media Rate, Max
Sequential Throughput
128Kib Random Rd (IOPs)
128Kib Random 70% RD/ 30%
128Kib Random 50% RD/ 50%
WT (IOPs)
Power Idle Time (Watts)
Power Random R/W (Watts)
(Watts)
Power Sequential Read
260 220 220 220 5.6 7.2 7.7 6.2
260 220 220 220 4.3 6.9 7.0 6.4
(Watts)
Power Sequential Write
Page
QuickSpecs
HPE Hard Disk Drives
Technical Specifications
11
Recommended Portfolio
Form Factor
SFF (2.5”)
Carrier
Smart Carrier (SC)
Rotational Speed
10000 rpm
Dimensions
Interface
SAS
Height
0.62 in (15.6 mm)
Transfer Rate
Synchronous (Max)
12Gb/sec
Width
2.98 in (75.7 mm)
Bytes/Sector
512
Depth
4.67 in (118.7 mm)
Operating Temperature
50° to 95° F (10° to 35°C)
HPE 300GB SAS 12G
Firmware HDD
HPE 600GB SAS 12G
Firmware HDD
HPE 1.2TB SAS 12G Enterprise
Digitally Signed Firmware HDD
HPE 1.8TB SAS 12G
Firmware HDD
HPE 2.4TB SAS 12G Enterprise
512e Digitally Signed Firmware
HDD
Form Factor
LFF (3.5”)
Carrier
Smart Carrier (SC)
Rotational Speed
7200 rpm
Dimensions
Interface
SAS
Height
1.06 in (26.8 mm)
Transfer Rate Synchronous (Max)
12Gb/sec
Width
4.16 in (105.8 mm)
Bytes/Sector
512
Depth
6.69 in (170.0 mm)
Operating Temperature
50° to 95° F (10° to 35°C)
Enterprise (10K rpm)
SKU SKU Description
872475-B21
872477-B21
872479-B21
872481-B21
881457-B21
Enterprise 10K SFF (2.5in) SC
3yr Wty Digitally Signed
Enterprise 10K SFF (2.5in ) SC
1yr Wty Digitally Signed
10K SFF (2.5in) SC 3yr Wty
Enterprise 10K SFF (2.5in) SC
3yr Wty 512e Digitally Signed
10K SFF (2.5in) SC 3yr Wty
(MiB/s)
WT (IOPs)
OD Media Rate, Max
Sequential Throughput
128Kib Random Rd (IOPs)
128Kib Random 70% RD/ 30%
128Kib Random 50% RD/ 50%
WT (IOPs)
Power Idle Time (Watts)
Power Random R/W (Watts)
(Watts)
Power Sequential Read
Power Sequential Write
195 180 180 180 3.8 6.9 6.1 5.3
195 165 165 165 3.9 6.9 6.1 5.0
195 165 165 165 4.0 7.1 6.4
5.5
230 165 170 185 2.6 3.6 4.4 3.9
255 160 180 195 4.8 6.0 7.8 6.6
(Watts)
Midline (7.2K rpm)
Page
Loading...
