Overview
Page 1
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
The HPE Ethernet 1Gb adapters deliver full line-rate performance across all ports with low power consumption, providing Ethernet
connectivity ideal for virtualization, security, server consolidation, and network segmentation. These are ideal for virtuali
security, server consolidation, network segmentation, and other applications requiring maximum throughput and port density.
zation,
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Platform Information
Page 2
Models
HPE Ethernet 1Gb 4-port 331FLR Adapter
629135-B22
HPE Ethernet 1Gb 4-port 331T Adapter
647594-B21
HPE Ethernet 1Gb 4-port 366FLR Adapter
665240-B21
HPE Ethernet 1Gb 4-port 366T Adapter
811546-B21
Kit Contents Table
SKU
629135-B22
647594-B21
665240-B21
811546-B21
Description
HPE Ethernet 1Gb 4port 331FLR Adapter
HPE Ethernet 1Gb 4-
port 331T Adapter
HPE Ethernet 1Gb 4port 366FLR Adapter
HPE Ethernet 1Gb 4-
port 366T Adapter
Quick install card
√ √ √
√
Product warranty statement
√ √ √
√
Low profile bracket
√
√
Servers Support Table
SKU
629135-B22
647594-B21
665240-B21
811546-B21
Description
HPE Ethernet 1Gb 4port 331FLR Adapter
HPE Ethernet 1Gb 4-
port 331T Adapter
HPE Ethernet 1Gb 4port 366FLR Adapter
HPE Ethernet 1Gb 4-
port 366T Adapter
HPE ProLiant DL20 Gen9
HPE ProLiant DL360 Gen9
HPE ProLiant DL380 Gen9
HPE Apollo 4200 Gen9
√ √ √
HPE Apollo 6500 XL270d Gen9
√
√
HPE ProLiant DL20 Gen10
√
HPE ProLiant DL120 Gen10
√ √ √
√
HPE ProLiant DL160 Gen10
√ √
√ √
HPE ProLiant DL180 Gen10
√ √ √
√
HPE ProLiant DL325 Gen10
√ √ √
√
HPE ProLiant DL360 Gen10
√ √ √
√
HPE ProLiant DL380 Gen10
√ √ √
√
HPE ProLiant DL385 Gen10
√ √ √
√
HPE ProLiant DL560 Gen10
√ √ √
√
HPE ProLiant DL580 Gen10
√ √ √
√
HPE Apollo 2000 XL170r Gen10
√ √ √
√
HPE Apollo 2000 XL190r Gen10
√ √ √
√
HPE Apollo 4500 XL450 Gen10
√ √ √
√
HPE ProLiant ML30 Gen10
√ √
HPE ProLiant ML110 Gen10
√ √
HPE ProLiant ML350 Gen10
√
√
HPE Apollo 6000 XL230k Gen10
√
√
√ √ √ √
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Standard Features
Page 3
SKU
629135-B22
647594-B21
665240-B21
811546-B21
Description
HPE Ethernet 1Gb 4port 331FLR Adapter
HPE Ethernet 1Gb 4-
port 331T Adapter
HPE Ethernet 1Gb 4port 366FLR Adapter
HPE Ethernet 1Gb 4-
port 366T Adapter
Active Health System
√ √ √
√
Auto-negotiation
√ √ √
√
Configuration Utilities
√ √ √ √
DMA Coalescing
HPE Sea Of Sensors 3D
√ √ √ √
LED Indicators
√ √ √
√
Load Balancing
Message Signaled Interrupt
(Extended) (MSI-X)
√ √ √
√
Network Adapter Teaming
√ √ √
√
Optimized for Virtualization
√ √ √
√
Preboot eXecution
Environment (PXE)
√ √ √ √
TCP/UDP/IP
√ √ √
√
Precision Time Protocol
(IEEE 1588 PTP)
√ √ √
√
Server Integration
√ √ √
√
VMware New Queue and
Microsoft Virtual Machine
Queue (VMQ)
Wake-on-LAN
Active Health System
Supports HPE Active Health System - monitors and records changes in the server hardware and
configuration enabling customers to have accurate information that will assist in diagnosing problems
and delivering rapid resolution when server failures occur.
Auto-negotiation
This adapter automatically senses the speed of the device to which it is attached. It also automatically
to the adapter.
Configuration Utilities
This adapter ships with a suite of operating system-tailored configuration utilities that allow the user to
enable initial diagnostics and configure adapter teaming. This includes a patented teaming GUI for
Microsoft Windows environment allow for unattended OS installations.
DMA Coalescing
Supports DMA Coalescing, the incoming data packets and interrupts associated with these DMA calls
are intelligently batched to keep the system devices in lower power states.
HPE Sea of Sensors3D
Support for the HPE Sea of Sensors which is a collection of 32 sensors that automatically track thermal
Jumbo Frames
This adapter supports Jumbo Frames (also known as extended frames), permitting up to a 9,500 byte
standard 1500-byte Ethernet frame. With Jumbo Frames, networks can achieve higher throughput
configures for half or full duplex, depending on the duplex mode of the switch, hub, or router connected
Microsoft Windows operating systems. Additionally, support for scripted installations of teams in a
activity - heat - across the server. When temperatures get too high, sensors can initiate fans and make
other adjustments to reduce energy usage. A significant improvement lies in the ability to apply fan speed
increases only to the portion of the system that is rising in temperature, rather than all six fans in unison,
which reduces the amount of energy used for cooling.
(KB) transmission unit (MTU) when running Ethernet I/O traffic. This is over five times the size of a
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Standard Features
Page 4
performance and greater CPU utilization. These attributes are particularly useful for database transfer
and tape backup operations.
LED Indicators
LED indicators show link integrity and network activity for easy troubleshooting.
Load Balancing
Transmit Load Balancing (TLB) and Switch-assisted Load Balancing (SLB) are two advanced features
full-duplex transmissions.
Message Signaled
Interrupt
(Extended)(MSI-X)
Message Signaled Interrupt (Extended) provides performance benefits for multi-core servers by load
Network Adapter
Teaming
This adapter support for NIC teaming helps IT administrators increase network fault tolerance and
availability, improve performance and help reduce costs.
Network Fault Tolerance
(NFT)
Network Fault Tolerance, sometimes called "failover" or "NIC Redundancy," allows for the installation of
Optimized for
Virtualization
I/O Virtualization support for VMware NetQueue and Microsoft VMQ helps meet the performance
Preboot eXecution
Environment (PXE)
Support for PXE enables automatic deployment of computing resources remotely from anywhere. It
Additionally, PXE enables decentralized software distribution and remote troubleshooting and repairs.
Precision Time Protocol
(IEEE 1588 PTP)
Synchronization of system clocks throughout a network, achieving clock accuracy in the sub-
Server Integration
This adapter is a validated, tested, and qualified solution that is optimized for HPE ProLiant servers.
for both their servers and their network adapters.
TCP/UDP/IP
For overall improved system response, this adapter supports standard TCP/IP offloading techniques
TCP segmentation to be handled by the adapter rather than the CPU.
VMware NewQueue and
Microsoft Virtual
Machine Queue (VMQ)
VMware NetQueue is technology that significantly improves performance of 10 Gigabit Ethernet network
filtering to deliver packet data from an external virtual machine network directly to virtual machines,
system to the virtual machine.
that customers can use to build a bigger pipe for improved networking bandwidth. These port-bonding
techniques enable users to install up to four dual-port HPE 361T adapters (total of 8 ports) in a HPE
ProLiant server and aggregate their throughput up to a theoretical maximum of 16 Gigabits per second
balancing interrupts between CPUs/cores.
increased network bandwidth, the team of adapters can work together as a single virtual adapter,
providing support for several different types of teaming enabling IT administrators to optimize
multiple server adapters so that the active device can be backed up by a redundant adapter to improve
availability. The Hewlett Packard Enterprise teaming utility also allows users to specify that when a failed
adapter is fixed and replaced, the original adapter resumes its function as the primary network
connection.
demands of consolidated virtual workloads.
allows a new or existing server to boot over the network and download software, including the operating
system, from a management/ deployment server at another location on the network.
microsecond range, making it suitable for measurement and control systems.
Hewlett Packard Enterprise validates a wide variety of major operating systems drivers with the full suite
of web-based enterprise management utilities including HPE Intelligent Provisioning and HPE Systems
Insight Manager that simplify network management. This approach provides a more robust and reliable
networking solution than offerings from other vendors and provides users with a single point of contact
including: TCP/IP, UDP checksum offload (TCO) moves the TCP and IP checksum offloading from the
CPU to the network adapter. Large send offload (LSO) or TCP segmentation offload (TSO) allows the
adapters in virtualized environments. Windows Hyper-V VMQ (VMQ) is a feature available on servers
running Windows Server 2008 R2 with VMQ-enabled Ethernet adapters. VMQ uses hardware packet
which reduces the overhead of routing packets and copying them from the management operating
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Standard Features
Page 5
Wake-on-LAN
This adapter provides Wake-on-LAN (WoL) support through the PCI Express bus. A system that
the machine.
Warranty
Maximum: The remaining warranty of the HPE product in which it is installed (to a maximum three-year,
http://h17007.www1.hpe.com/us/en/enterprise/servers/warranty/index.aspx#.V4e3tPkrJhE
supports Wake-on-LAN cfaan remain available to the systems administrator during its normal downtime.
Once the machine is awakened, the systems administrator can remotely control, audit, debug, or manage
limited warranty).
Minimum: One year limited warranty.
NOTE: Additional information regarding worldwide limited warranty and technical support is available
at:
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Service and
Support
Page 6
Service and Support
NOTE: This adapter is covered under HPE Support Services/ Service Contract applied to the HPE
conditions apply.
Warranty and Support
Services
Warranty and Support Services will extend to include HPE options configured with your server or storage
terms and conditions apply.
Protect your business
beyond warranty with
HPE Support Services
HPE Technology Services delivers confidence, reduces risk and helps customers realize agility and
Protect your product, beyond warranty.
Parts and Materials
Hewlett Packard Enterprise will provide HPE-supported replacement parts and materials necessary to
replaced by Hewlett Packard Enterprise due to malfunction.
For more information
Visit the Hewlett Packard Enterprise Service and Support website.
ProLiant Server or enclosure. No separate HPE Support Services need to be purchased.
Most HPE branded options sourced from HPE that are compatible with your product will be covered
under your main product support at the same level of coverage, allowing you to upgrade freely. Additional
support is required on select workload accelerators, switches, racks and UPS options 12KVA and over.
Coverage of the UPS battery is not included under HPE support services; standard warranty terms and
device. The price of support service is not impacted by configuration details. HPE sourced options that
are compatible with your product will be covered under your server support at the same level of coverage
allowing you to upgrade freely. Installation for HPE options is available as needed. To keep support costs
low for everyone, some high value options will require additional support. Additional support is only
required on select high value workload accelerators, fibre switches, InfiniBand and UPS options 12KVA
and over. Coverage of the UPS battery is not included under TS support services; standard warranty
stability. Connect to HPE to help prevent problems and solve issues faster. HPE Support Services enable
you to choose the right service level, length of coverage and response time as you purchase your new
server, giving you full entitlement to the support you need for your IT and business.
maintain the covered hardware product in operating condition, including parts and materials for available
and recommended engineering improvements.
Parts and components that have reached their maximum supported lifetime and/or the maximum usage
limitations as set forth in the manufacturer's operating manual, product quick-specs, or the technical
product data sheet will not be provided, repaired, or replaced as part of these services.
The defective media retention service feature option applies only to Disk or eligible SSD/Flash Drives
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Technical Specifications
Page 7
SKU
629135-B22
647594-B21
665240-B21
811546-B21
Description
HPE Ethernet 1Gb 4-port
HPE Ethernet 1Gb 4-port
HPE Ethernet 1Gb 4-port
HPE Ethernet 1Gb 4-port
Bus Type
PCIe 2.0X4
PCIe 2.0X4
PCIe 2.0X4
PCIe 2.0
Data Rate
4 port, each at 2 Gb bi-
4 port, each at 2 Gb bi-
4 port, each at 2 Gb bi-
4 port, each at 2 Gb bi-
Form Factor
FlexibleLOM
Stand up
FlexibleLOM
Stand up
Humidity
Operating 10% to 90% non-condensing
Non-operating 5% to 95% non-condensing
IEEE
Compliance
802.3, 802.3ab, 802.3u,
802.3, 802.3ab, 802.3u,
802.3, 802.3ab, 802.3u,
802.3, 802.3ab, 802.3u,
Jumbo
Frames
9,000 KB
9,000 KB
9,500 KB
9,500 KB
Network
Processor
Broadcom BCM5719
Broadcom BCM5719
Intel® I350
Intel® I350
Power
5.5W max
4.3W max
1.0W min
5.5W max
5.5W max
Temperature
Operating 0° to 55°C (32° to 131°F)
Non-Operating
Operating System and Virtualization Support
The Operating Systems supported by this adapter are based on the server OS support. Please refer to the OS Support Matrix
at
Environment-friendly Products and Approach - End-of-life Management and Recycling
Hewlett Packard Enterprise offers end
products. Products returned to Hewlett Packard Enterprise will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE Directive (2012/19/EU) requires manufacturers to provide treatment information f
treatment facilities. This information (product disassembly instructions) is posted on the
These instructions may be used by recyclers and other WEEE treatment facilities as well as Hewlett Packard Enterprise OEM
customers who integrate and re-sell Hewlett Packard Enterprise equipment.
331FLR Adapter
directional, 8 Gb bi-
directional per adapter
802.3x, 802.3ad, 802.1q,
802.3az, 1588, 802.1as
331T Adapter
directional, 8 Gb bi-
directional per adapter
802.3x, Dynamic 802.3ad,
802.1q, 802.3az, 1588,
802.1as
366FLR Adapter
directional, 8 Gb bi-
directional per adapter
802.3x, 802.3ad, 802.1q,
802.3az, 1588, 802.1as
I350-T4V2
366T Adapter
directional, 8 Gb bi-
directional per adapter
802.3x, 802.3ad, 802.1q,
802.3az, 1588, 802.1as,
802.1p
I350-T4V2
-65° to 85° C (-85° to 185° F)
https://www.hpe.com/us/en/servers/server-operating-systems.html
-of-life product return, trade-in, and recycling programs, in many geographic areas, for our
or each product type for use by
Hewlett Packard Enterprise web site.
QuickSpecs
HPE Ethernet 1Gb Adapters
Technical Specifications
Page 8
Models
HPE Ethernet 1Gb 2-port 332T Adapter
615732-B21
HPE Ethernet 1Gb 2-port 361T Adapter
652497-B21
Kit Contents Table
SKU
615732-B21
652497-B21
Description
HPE Ethernet 1Gb 2-port 332T Adapter
HPE Ethernet 1Gb 2-port 361T Adapter
Quick install card √ √
Product warranty statement
√
√
Low profile bracket √ √
Servers Support Table
SKU
615732-B21
652497-B21
Description
HPE Ethernet 1Gb 2-port 332T Adapter
HPE Ethernet 1Gb 2-port 361T Adapter
HPE ProLiant DL20 Gen9
HPE ProLiant DL360 Gen9
HPE ProLiant DL380 Gen9
HPE Apollo 4200 Gen9
√
√
HPE Apollo 6500 XL270d Gen9
√ √
HPE ProLiant DL20 Gen10
√
√
HPE ProLiant DL120 Gen10
√
√
HPE ProLiant DL160 Gen10
√
√
HPE ProLiant DL180 Gen10
√
√
HPE ProLiant DL325 Gen10
√
√
HPE ProLiant DL360 Gen10
√
√
HPE ProLiant DL380 Gen10
√
√
HPE ProLiant DL385 Gen10
√
√
HPE ProLiant DL560 Gen10
√
√
HPE ProLiant DL580 Gen10
√
√
HPE Apollo 2000 XL170r Gen10
√
√
HPE Apollo 2000 XL190r Gen10
√
√
HPE Apollo 4500 XL450 Gen10
√
√
HPE ProLiant ML3
HPE ProLiant ML110 Gen10
√
√
HPE ProLiant ML350 Gen10
√
√
HPE Apollo 6000 XL230k Gen10
√ √
0 Gen10
√ √
√ √
QuickSpecs
HPE Ethernet 1Gb Adapters
Technical Specifications
Page 9
Standard Features Table
SKU
615732-B21
652497-B21
Description
HPE Ethernet 1Gb 2-port 332T Adapter
HPE Ethernet 1Gb 2-port 361T Adapter
Active Health System
√
√
Auto-negotiation
√
Configuration Utilities
√
√
DMA Coalescing
√
HPE Sea Of Sensors 3D
√
√
LED Indicators
√
√
Load Balancing
√
Message Signaled Interrupt
(Extended) (MSI-X)
√
√
Network Adapter Teaming
√
√
Optimized for Virtualization
√
√
Preboot eXecution
Environment (PXE)
√
√
TCP/UDP/IP
√
√
Precision Time Protocol
(IEEE 1588 PTP)
√ √
Server Integration
√ √
VMware New Queue and
Microsoft Virtual Machine
Queue (VMQ)
√
Wake-on-LAN
√
QuickSpecs
HPE Ethernet 1Gb Adapters
Technical Specifications
Page 10
Technical Specifications Table
SKU
615732-B21
652497-B21
Description
HPE Ethernet 1Gb 2-port 332T Adapter
HPE Ethernet 1Gb 2-port 361T Adapter
Bus Type
PCIe 2.0x1
PCIe 2.0
Data Rate
2 port, each at 2 Gb bi-directional, 4 Gb bi-
2 port, each at 2 Gb bi-directional, 4 Gb bi-
Form Factor
Stand up
Stand up
Humidity
Operating 10% to 90% non-condensing
IEEE Compliance
802.3, 802.3ab, 802.3u, 802.3x, 802.3ad,
802.3, 802.3u, 802.3x, 802.3ab, 802.3ad,
Jumbo Frames
9,000 KB
9,500 KB
Network Processor
Broadcom BCM5720
Intel® Ethernet I350 Controller
Power
2.2W max
1.7W min
3.2W min
4.2W max
Temperature
Operating 0° to 55°C (32° to 131°F)
Non-Operating
directional per adapter
Non-operating 5% to 95% non-condensing
802.1q, 802.3az, 1588, 802.1as, 802.1p
-65° to 85° C (-85° to 185° F)
directional per adapter
802.1p, 802.1Q, 802.3az, 1588
I350-T2V2
QuickSpecs
HPE Ethernet 1Gb Adapters
HPE ProLiant DL, ML & Apollo
Summary of Changes
Page 11
Date
Version History
Action
Description of Change
1-Oct-2018
Version 3
Changed
Platform Information & Standard Features Sections were updated
13-Aug-2018
Version 2
Changed
Platform Information Section was Updated
02-Jul-2018
Version 1
New
New QuickSpecs
Sign up for updates
© Copyright 2018 Hewlett Packard Enterprise Development L.P. The information contained herein is subject
to change without notice. The only warranties for Hewlett Packard Enterprise products and services are set
forth in the express warranty statements acc
be construed as constituting an additional warranty. Hewlett Packard Enterprise shall not be liable for
technical or editorial errors or omissions contained herein.
a00047730enw
ompanying such products and services. Nothing herein should
- 16267 - Worldwide - V3 - 1-October-2018
Loading...
