HP-UX

HP StorageWorks Disk Array XP

operating system

configuration guide

XP128

XP1024 XP10000 XP12000

sixth edition (July 2005)

part number: A5951-96015

This guide describes the requirements and procedures for connecting the XP family of disk arrays to an HP-UX system and configuring the new disk array for operation with HP-UX.

to, the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard. The information contained in this document is subject to change without notice.

HP-UX is a registered trademark of Hewlett-Packard Company. All other product names mentioned herein may be trademarks of their respective companies. Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard Company products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

sixth edition (July 2005) part number: A5951-96015

2 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

About this guide 7

Intended audience 7 Prerequisites 7 Disk arrays 7 Related documentation 8 HP storage website 8 HP sales and authorized resellers 8 HP technical support 9 Document conventions 10 Revision history 11

Warranty statement 12

1 Installation 15

Features and requirements 16

Fibre Channel interface 17 Device emulation types 18 Failover 18 SNMP configuration 19

RAID Manager command devices 19 Installation procedures 20 Install and configure the disk array 21

Setting the host mode for the disk array ports 21

Setting the System Option Modes 23

Configuring the Fibre Channel ports 24 Install and configure the host 26

Loading the OS and software 26

Installing and configuring the HBAs 26

Clustering and fabric zoning 27

Fabric zoning and LUN security for multiple operating systems 28

Contents 3

Connect the disk array 29

Defining the paths 29 Verifying HBA installation 31 Verifying device recognition 32

Configure disk array devices 35

Verifying the device files and drivers 36 Creating the device files 38 Creating the physical volumes 41 Creating new volume groups 42 Creating logical volumes 45 Creating the file systems 47 Setting the I/O timeout parameter 49 Creating the mount directories 50 Mounting and verifying the file systems 51 Setting and verifying the auto-mount parameters 52

2 Troubleshooting 55

Error conditions 56 Calling the HP support center 59

A Worksheets 61

Path worksheet 62

B Disk array device emulations 63

Supported emulations 64 Device type specifications 65 LUSE device parameters 68 SCSI TID map for Fibre Channel adapters 71

C Reference information for SAM 73

Configuring the devices using SAM 74 Setting the maximum number of volume groups using SAM 76

Glossary 77

Index 81

4 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

About this guide

This guide provides information about:

• Requirements and procedures for connecting an XP disk array to a

• Configuring the disk array for use with the HP-UX operating system

Intended audience

This guide is intende d for syst em administrator s with knowledge of the host server, the operating system, and XP disk arrays.

Prerequisites

Prerequisites for installing and confi gur ing this product include knowledge of:

• Disk arrays and RAID technology

• Operating system commands and utilities

host system

Disk arrays

Unless otherwise noted, the term disk array refers to these disk arrays:

HP StorageWorks Disk ArrayXP 128 HP StorageWorks Disk Array XP1024 HP StorageWorks XP10000 Disk Array HP StorageWorks XP12000 Disk Array

About this guide 7

HP storage website

For the most current information about HP StorageWorks XP products, visit:

For information about product availa bili ty, configuration, and connecti vity, contact your HP support representative.

http://h18006.www1.hp.com/storage/arraysystems.html

HP sales and authorized resellers

To reach HP sales or find a local authorized reseller of HP products, call 1-800-282-6672 or visit the HP How To Buy web site:

http://welcome.hp.com/country/us/en/howtobuy.html

You can also find HP sales and resellers at Contact HP.

8 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

http://www.hp.com

. Click

HP technical support

In North America, call technical support at 1-800-633-3600, available 24 hours a day, 7 days a week.

Outside North America, call technical support at the location nearest you. The HP web site lists telephone numbers for worldwide technical support at:

Collect the following information before calling:

For continuous quality improvement, calls may be recorded or monitored.

HP strongly recommends that customers sign up online using the Subscriber’s choice web site at Subscribing to this service provides you with email updates on the latest product enhancements, newest drivers, and firmware documentation updates as well as instant access to numerous other product resources.

http://www.hp.com/support

• Technical support registration number (if applicable)

• Product serial numbers

• Product model names and numbers

• Applicable error message s

• Operating system type and revision level

• Detailed questions

. From this web site, select your country.

http://www.hp.com/go/e-updates

About this guide 9

Document conventions

Convention Element

Blue text (Figure 1) Blue text represen ts a cro ss-refe rence. In the onlin e version of this guide,

the reference is linked to the target.

Bold Bold text represents application names, file names, menu items, dialog

box titles, buttons, key names, field names, and literal values that you type exactly as shown.

Italics Italic type indica te s th at you must supply a value. It al ic type is also used

for manual titles.

Blue underlined sans serif font (www.hp.com

monospace font Monospace font deno tes use r inpu t and s ystem re spo nses, s uch as o utp ut

)

Underlined, blue text represents a website on the Internet. In the online version of this guide, the reference is linked to the target.

and messages.

Example

The word “example” in italics denotes an example of input or output. [ ] Square brackets indicate an optional parameter. { } Braces indicate that you must specify at least one of the listed options. | A vertical bar separates alternatives in a list of options.

10 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Revision history

September 1999 Open-8 emulation added.

January 2000 Content extensively revised and reorganized.

June 2000 Added support for XP512.

Content reorganized and revised.

February 2001 Added appendixes C, D, E, and F.

Added glossary.

April 2003 Changed brand name to St orageWorks.

Added support for OPEN-L and OPEN-V. Changed CVS to VCS.

November 2003 Revised I/O timeout procedure. Minor update.

August 2004 Updated for XP12000.

July 2005 Updated to include XP10000, Command View XP

Advanced Edition, and Remote Web Console XP.

About this guide 11

Warranty statement

HP warrants that for a period of ninety calendar days from the date of purchase, as evidenced by a copy of the invoice, the media on which the Software is furnished (if any) will be free of defects in materials and workmanship under normal use.

DISCLAIMER. EXCEPT FOR THE FOREGOING AND TO THE EXTENT ALLOWED BY LOCAL LAW, THIS SOFTWARE IS PROVIDED TO YOU “AS IS” WITHOUT WARRANTIES OF ANY KIND, WHETHER ORAL OR WRITTEN, EXPRESS OR IMPLIED. HP SPECIFICALLY DISCLAIMS ANY IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY, SATISFACTORY QUALITY, NON-INFRINGEMENT, TITLE, ACCURACY OF INFORMATIONAL CONTENT, AND FITNESS FOR A PARTICULAR PURPOSE. Some jurisdictions do not allow exclusions

of implied warranties or conditions, so the above exclusion may not apply to you to the extent prohibited by such local laws. You may have other rights that vary from country to country, state to state, or province to province.

WARNING! YOU EXPRESSLY ACKNOW LEDGE AND AGREE THAT USE OF THE SOFTWARE IS AT YOUR SOLE RISK. HP DOES NOT WARRANT THAT THE FUNCTIONS CONTAINED IN THE SOFTWARE WILL MEET YOUR REQUIREMENTS, OR THAT THE OPERATION OF THE SOFTWARE WILL BE UNINTERRUPTED, VIRUS-FREE OR ERROR-FREE, OR THAT DEFECTS IN THE SOFTWARE WILL BE CORRECTED. THE ENTIRE RISK AS TO THE RESULTS AND PERFORMANCE OF THE SOFTWARE IS ASSUMED BY YOU. HP DOES NOT WARRANT OR MAKE ANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE SOFTWARE OR RELATED DOCUMENTATION IN TERMS OF THEIR CORRECTNESS, ACCURACY, RELIABILITY, CURRENTNESS, OR OTHERWISE. NO ORAL OR WRITTEN INFORMATION OR ADVICE GIVEN BY HP OR HP’S AUTHORIZED REPRESENTATIVES SHALL CREATE A WARRANTY.

12 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

LIMITATION OF LIABILITY. EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW, IN NO EVENT INCLUDING NEGLIGENCE WILL HP OR ITS SUBSIDIARIES, AFFILIATES, DIRECTORS, OFFICERS, EMPLOYEES, AGENTS OR SUPPLIERS BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL, PUNITIVE OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR DOWNTIME COSTS), ARISING OUT OF THE USE, INABILITY TO USE, OR THE RESULTS OF USE OF THE SOFTWARE, WHETHER BASED IN WARRANTY, CONTRACT, TORT OR OTHER LEGAL THEORY, AND WHETHER OR NOT ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. Your use of the

Software is entirely at your own ris k. Shoul d th e Soft war e prove defective, you assume the entire cost of all service, repair or correction. Some jurisdictions do not allow the exclusion or limitation of liability for incidental or conse quenti al damag es, so t he above limit atio n may not a pply to you to the extent prohibited by such local laws.

NOTE. EXCEPT TO THE EXTENT ALLOWED BY LOCAL LAW, THESE WARRANTY TERMS DO NOT EXCLUDE, RESTRICT OR MODIFY, AND ARE IN ADDITION TO, THE MANDATORY STATUTORY RIGHTS APPLICABLE TO THE LICENSE OF THE SOFTWARE TO YOU;

PROVIDED, HOWEVER, THAT THE CONVENTION ON CONTRACTS FOR THE INTERNATIONAL SALE OF GOODS IS SPECIFICALLY DISCLAIMED AND SHALL NOT GOVERN OR APPLY TO THE SOFTWARE PROVIDED IN CONNECTION WITH THIS W ARRANTY STATEMENT.

About this guide 13

14 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Installation

You and your HP service representative each play a role in installation. Your HP service representative is responsible for installing the disk array and formatting the disk devices. You are responsible for configuring the host server for the new devices with assistance from your HP service representative.

Installation 15

Features and requirements

Ask your HP service represent ative about the lat est supporte d hardware and software.

The disk array and host have the following features:

• Storage capacity. The storage capacity for each model is listed

below:

XP128: From 8 to 128 drives for up to 18 TB, 48 FC ports XP1024: From 8 to 1024 drives for up to 149 TB, 64 FC ports XP10000: Up to 240 drives for up to 69.2 TB, 48 FC ports XP12000: Up to 1152 drives for up to 165 TB, 128 FC ports

• Server support. HP-UX-supported processor

• Operating system support. HP-UX, version 10.20, 11.0, or 11i v2

with the latest patches (if any)

Before installing the disk array, ensure the environment conforms to these requirements:

• Host Bus Adapters (HBAs) Install HBAs and all utilities and

drivers. Refer to the adapter documentation for installation details.

• (Recommended) HP StorageWorks Remote Web Console XP,

Command V iew XP Advanc ed Editi on or Command View XP with LUN management feature for configuring disk array ports and paths

• (Recommended) HP StorageWorks LUN Configuration and

Security Manager XP

16 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Fibre Channel interface

The XP fami ly of disk arrays support s these Fibre Channel elements:

• (Optional) Other available XP software (some may not be supported by your array:

HP StorageWorks Business Copy XP HP StorageWorks Continuous Access XP HP StorageWorks Continuous Access Extension XP HP StorageWorks Auto LUN XP HP StorageWorks Data Exchange XP HP StorageWorks Resource Manager XP HP StorageWorks RAID Manager XP HP StorageWorks Cache LUN XP HP StorageWorks Auto Path XP HP StorageWorks Cluster Extension XP HP StorageWorks Performance Advisor XP

• Connection speed of 1 Gbps and 2 Gbps

• Short-wave non-OFC (open fiber control) optical interface

• Multimode optical cables with SC or LC connectors

• Public or private arbitrated loop (FC-AL) or direct fabric attach

• Fibre Chan nel switches

Even though the interface is Fibre Chann el, this gui de uses the term “SCSI disk” because disk array devices are defined to the host as SCSI disks.

Installation 17

Device emulation types

The XP family of disk arrays supports these device emulation types:

• OPEN-K/3/8/9/E devices: OPEN-x logical units represent disk

devices. Except for OPEN-V, these devices are based on fixed sizes. OPEN-V is a user-defined size. Supported emulations include OPEN-3, OPEN-8, OPEN-9, OPEN-E, OPEN-L, and OPEN-V devices.

• LUSE devices (OPEN-x*n): Logical Unit Size Expansion (LUSE)

devices combine 2 to 36 OPEN-x devices to create expanded LDEVs larger than standard OPEN-K/3/8/9/E disk devices. For example, an OPEN-x LUSE volume created from ten OPEN-x volumes is designated as OPEN-x*10.

• CVS devices (OPEN-x CVS): Volume Size Configuration (VSC)

defines custom volumes (CVS) that are smaller than normal fixed-sized logical disk devices (volumes). (OPEN-V is a CVS-based custom disk size that you dete rmine. OPEN- L does not support CVS.)

• LUSE (expanded) CVS devices (OPEN-x*n CVS): LUSE CVS

combines CVS devices to create an expanded device. This is done by first creating CVS custom-sized devices and then using LUSE to combine from 2 to 36 CVS devices. For example, if three OPEN-9 CVS volumes are combined to create an expande d device, this device is designated as OPEN-9*3-CVS.

Failover

The XP family of disk arrays supports many standard software products that provide host, application, or I/O path failover and management.

The following are supported for HP-UX:

• HP Multi-C omputer/Serv iceGuard (MC/ServiceGuard) software for application failover

• Alternate link for I/O path failover (included in HP-UX)

• Logical volume management (included in HP-UX)

18 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

SNMP configuration

The XP family of disk arrays supports standard Simple Network Management Protocol (SNMP) for remotely managing the disk array. The SNMP agent on the SVP performs error-reporting operations requested by the SNMP manager. SNMP properties are usually set from the SVP but they can also be set remotely using Remote Web Console XP, Command View XP, or Command View XP Advanced Edition. Refer to the applicable user’s guide for procedures.

RAID Manager command devices

RAID Manager manages Business Copy (BC) or Continuous Access (CA) operations from a host server. To use RAID Manager with BC or CA, you use Remote Web Console, Command View, or Command View XP Advanced Edition to designate at least one LDEV as a command device. Refer to the app li cab le user’s guide f or information about how t o designate a command device.

Installation 19

Installation procedures

Perform these actions to install and configure the disk array:

1. Install and configure the disk array (see page 21)

• Setting the host mode for the disk array ports

• Setting the System Option Modes

• Configuring the Fibre Channel ports

2. Install and configure the host (see page 26)

• Loading the OS and software

• Installing and configuring the HBAs

• Clustering and fabric zoning

• Fabric zoning and LUN security for multiple operating systems

3. Connect the disk array (see page 29)

• Defining the paths

• Verifying HBA installation

• Verifying device recognition

4. Configure disk array devices (see page 35)

• Verifying the device files and drivers

• Creating the device files

• Creating the physical volumes

• Creating new volume groups

• Creating logical volumes

• Creating the file systems

• Setting the I/O timeout parameter

• Creating the mount directories

• Mounting and verifying the file systems

• Setting and verifying the auto-mount parameters

20 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Install and configure the disk array

The HP service represen tative perf orms these ta sks:

• Assembling hardware and installing software

• Loading the microcode updates

• Installing the channel adapters (CHAs) and cabling

• Installing and formatting devices

After these tasks are finished, you will use Remote Web Console, Command View, Command View XP Advanced Edition, or LUN Configuration and Securi ty Man ager to complete the remai ning t asks li sted below. If you do not have these programs, your HP service representative can perform these tasks for you.

Setting the host mode for the disk array ports

The disk array ports have host modes that must be set depending on the host you use. After the disk array is installed use LUN Manager in Remote Web Console XP (shown), Command View XP, or Command View XP Advanced Edition to set t he host mode f or e ach por t. The host mode se ttin g for HP-UX is 08.

Installation 21

For the XP1024/XP128 arrays, the host mode can also be set at the port information window in Command View XP AE.

22 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Setting the System Option Modes

The HP service r epresentat ive set s the S ystem Op tion Mode( s) based on the operating system and software configuration of the host.

Mode Level

140 Optional None ON: Response to the Inquiry command is

HA Software

Description and Usage

changed, and the vol ume can be used from VeritasNetBackUP in heterogeneous OS configuration, such as HP-UX.

OFF: Normal response to the Inquiry command.

186 Mandatory Verita s

Database Editions/ Advanced Cluster

254 Optional Verita s

Database Editions

280 Optional HP-UX Ghost LUN Remove

ON: Mandatory setting when VERITAS Database Editions/Advanced Cluster is connected.

OFF: VERIT A S Dat abase Edit ion s /Adv ance d Cluster should not be connected with this setting.

Change the response of re serve conflict status to Read Capacity, Verify, and Start Stop Unit.

ON: Normal end is reported. OFF: Reserve conflict status is reported.

OS version: HP-UX 11.0 and later.

ON: When the host scans the LUNS on the port, the disk a rray is not represen ted in the device list for HP-UX.

OFF: When the host scans the LUNS on the port, the disk array is represented in the d ev ice list for HP-UX.

Installation 23

Configuring the Fibre Channel ports

Configure the disk array Fibre Channel ports by using Remote Web Console (shown), Command View, or Command View XP AE. Select the settings for each port based on your storage area network topology. Use switch zoning if you connect different types of hosts to the array through the same switch.

Fibre Address

In fabric environments, the port addresses are assigned automatically. In arbitrated loop environments, set the port addresses by selecting a unique arbitrated loop physical address (AL-PA) or loop ID for each port.

24 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Fabric and Connection parameter settings

Set each array port to FABRIC ON or OFF with connections of POINT-TO-POINT or FC-AL as shown in the following table and figures. For detailed topology information, refer to the HP StorageWorks SAN Design Reference Guide on the

hp.com

website.

Fabric parameter

Connection parameter

Provides

ON FC-AL Not supported ON Direct Fabric Attach F-port (fabric port) OFF FC-AL AL-port (private arbi tr at ed loop) OFF Direct Fabric Attach Not supported

Installation 25

Install and configure the host

This section explains how to install and configure the host and host bus adapters (HBAs) that connect the host to the disk array.

Loading the OS and software

Follow the manufacturer’s instructions to load the operating system and software onto the host. Load all OS patches and configuration utilities supported by HP and the HBA manufacturer.

Installing and configuring the HBAs

Install and configure the host bus adapters using the HBA manufacturer’s instructions.

26 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Clustering and fabric zoning

If you plan to use clustering, install and configure the clustering software on the servers.

Clustering is the organization of multiple servers into groups. Within a cluster, each server is a node. Multiple clusters compose a multi-cluster environment. The following example shows a multi-cluster environment with three clusters, each containing two nodes. The nodes share access to the disk array.

Within the Storage Area Network (SAN), the clusters may be homogeneous (all the same operating system) or they may be heterogeneous (mixed operating systems). How you configure LUN Security and fabric zoning depends on the operating system mix and the SAN configuration.

Installation 27

Fabric zoning and LUN security for multiple operating systems

You can connect multiple clus te rs of various operating systems to the sa me switch and fabric using appropriate zoning and LUN security as follows:

• Host zones must contain only homogeneous operating systems.

• Storage port zones may overlap if more than one operating system

needs to sh are an array port.

• Heterogeneous operating systems may share an XP array port if you

use Secure Manager and set the appropriate host group and mode. All others must connect to a dedicated XP array port.

• Use Secure Manager for LUN i sol at io n when multiple hosts conne ct

through a shared array port. Secure Manager provides LUN security by allowing you to restrict which LUNs each host can access.

Environment OS Mix Fabric Zoning LUN Security

Standalone SAN (non-clustered)

Clustered SAN homogeneous (a single OS

Multi-Cluster SAN

homogeneous (a single OS type present in the SAN)

heterogeneous (more than one OS type present in the SAN)

type present in the SAN) heterogeneous (more than one

OS type present in the SAN) homogeneous (a single OS

type present in the SAN) heterogeneous (more than one

OS type present in the SAN)

Not required Must be used when multiple

hosts connect through a

Required

shared po rt

Not required Must be used when multiple

cluster nodes conne ct thr ough

Required

a shared port

Not required Must be used when multiple

cluster nodes conne ct thr ough

Required

a shared port

28 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Connect the disk array

The HP service representative connects the disk array to the host by:

1. V eri fying operational sta tus of the disk array c hannel adapters, LDEVs, and paths.

2. Connecting the Fibre Channel cables between the disk array and the fabric switch or host.

3. Verifying the ready status of the disk array and peripherals.

Defining the paths

Use Remote Web Console (shown), Command View, or Command View XP AE to define paths (LUNs) between hosts and volumes in the disk array.

This process is also called “LUN mapping.” In Remote Web Console and Command View, LUN mapping includes:

• Configuring ports

• Setting LUN security

• Creating host groups

• Assigning host bus adapter WWNs to host groups

• Mapping volumes to host groups (by assigning LUNs)

Installation 29

In Command View XP AE, LUN mapping includes:

• Configuring ports

• Creating storage groups

• Mapping volumes and WWN/host access permissions to the storage groups

For details see LUN Configuration and Security Manager User’s Guide or Command Vi ew XP Advanced Editi on Device Manag er Web Client User’s Guide. Note the LUNS and t heir ports , WWNs, ni cknames, and LDEVs for later use in verifying host and device configuration.

30 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Verifying HBA installation

After configuring the ports on the disk array, verify that the HBAs are installed properly.

Use the ioscan –f command, and verify that the rows shown in the ex ample are displayed. If these rows are not di splayed, check the host adapter installation (hardware and driver installation) or the host configuration.

Example

# ioscan -f

Class I H/W Path Driver S/W StateH/W Type Description

=============================================================================================== ...

fc 0 8/12 fcT1 CLAIMED INTERFACE HP Fibre Channel Mass Storage Adapter

lan 1 8/12.5 fcT1_cntl CLAIMED INTERFACE HP Fibre Channel Mass Storage Cntl

fcp 0 8/12.8 fcp CLAIMED INTERFACE FCP Protocol Adapter

ext_bus 2 8/12.8.0.255.0 fcpdev CLAIMED INTERFACE FCP Device Interface

...

Installation 31

Verifying device recognition

Verify that the HP-UX system recognizes the new devices on the disk array.

If the SCSI paths were defined after the system is powered on, you must halt and restart the system to allow the system to recognize the new devices.

To verify device recognition:

1. Log in to the system as root.

2. Display the device data to verify that the system recognizes the newly

installed devices on the disk array. Use the ioscan –fn command to display the device data.

On a system with a large LUN configuration, HP-UX may not build device files on all LUNs. Enter insf –e to build all mi ssing d evice file s.

Example

# ioscan -fn class I H/W Path Driver S/W State H/W Type Description

==========================================================================

bc 6 14 ccio CLAIMED BUS_NEXUS I/O Adapter HP Fibre Channel Mass fc 1 14/12 fcT1 CLAIMED INTERFACE Storage Adapter HP Fibre Channel Mass lan 2 14/12.5 fcT1_cntl CLAIMED INTERFACE Storage Cntl /dev/fcms2 fcp 1 14/12.8 fcp CLAIMED INTERFACE FCP Protocol Adapter HP A3308 FCP-SCSI MUX ext_bus 6 14/12.8.0.0.0 fcpmux CLAIMED INTERFACE Interface target 9 14/12.8.0.0.0.0 tgt CLAIMED DEVICE disk 4 14/12.8.0.0.0.0.0 sdisk CLAIMED DEVICE HP OPEN-9 /dev/dsk/c6t0d0/dev/rdsk/c6t0d0 disk 5 14/12.8.0.0.0.0.1 sdisk CLAIMED DEVICE HP OPEN-9*2 /dev/dsk/c6t0d1 /dev/rdsk/c6t0d1 ext_bus 7 14/12.8.0.255.0 fcpdev CLAIMED INTERFACE FCP Device Interface target 10 14/12.8.0.255.0.0 tgt CLAIMED DEVICE ctl 5 14/12.8.0.255.0.0.0 sctl CLAIMED DEVICE HP HPA3308 /dev/rscsi/c7t0d0

In the example: HP OPEN-9 device: SCSI bus numb er = 14/12, bus insta nce = 6, SCSI

target ID = 0, LUN = 0. HP OPEN-9*2 device: SCSI bus number = 14/12, bus instance = 6,

SCSI target ID = 0, LUN = 1. If UNKNOWN is displayed fo r a disk, t he HP 9000 system may not be

configured properly. Refer to the HP documentation or contact HP

32 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Example

customer support for assistance with the HP 9000 system or the HP-UX operating system.

3. Enter the device data for each disk array device in a table. See “Path worksheet” on page 62.

4. Construct the device file name for each device, using the device information, and enter the file names in your table. Use the following formula to construct the device file name:

cxtydz

where

x = SCSI bus instance number y = SCSI target ID z = LUN

c stands for controller, t stands for target ID, and d stands for device. The numbers x, y, and z are hexadecimal.

SCSI bus instance number Hardware path SCSI TID LUN File name

00 14/12.6.0 6 0 c6t0d0 00 14/12.6.1 6 1 c6t0d1

5. Verify that the SCSI TIDs correspond to the assigned port address for all connected ports ( see ma pping t ables on

page 63 in Appendix B, for

values). If so, the logical devices are recognized properly. If the logical devices are not recognized properly:

• Check the AL-PA for each port using the LUN Manager software.

• If the same port address is set for multiple ports on the same loop

(AL with HUB), all port addresses except one changed to another value, and the relationship between AL-PA and TID does not correspond to the mapping given in

Installation 33

Appendix B (page 63), set a

different address for each port, reboot the server, and then verify new device recognition again.

• If unused device information remains, the TID-to-AL-PA mapping will not correspond to the mappi ng given in

Appendix B (pag e 63). Renew the device information, and then verify new device recognition again.

34 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Configure disk array devices

Disk arrays are configured using the same procedure for configuring any new disk on the host. This includes the following procedures:

1. Verifying the device files and drivers (see page 36)

2. Creating the device files (see page 38)

3. Creating the physical volumes (see page 41)

4. Creating new volume groups (see page 42)

5. Creating logical volumes (see page 45)

6. Creating the file systems (see page 47)

7. Setting the I/O timeout parameter (see page 49)

8. Creating the mount directories (see page 50)

9. Mounting and verifying the file systems (see page 51)

10. Setting and verifying the auto-mount parameters (see page 52)

The HP-UX system uses the Logical Volume Manager (LVM) to manage the OPEN-x devices on the disk array. The instructions in this section do not explicitly cover all LVM configuration issues. For further information on LVM configuration, see the HP-UX user documentation.

HP System Administrator Manager (SAM) can be used instead of UNIX commands to configure SCSI disk devices. See further information.

Installation 35

appendix C (page 73) for

Verifying the device files and drivers

The device files for new devices are usually created automatically during HP-UX startup. Each device must have a block-type device file in the /dev/dsk directory and a character-type device file in the /dev/rdsk directory.

However, some HP-compatible systems do not create the device files automatically. If verification shows that the device files were not created, follow the instruct ions i n device files manually.

This procedure verifies both types of device files.

To verify that the device files for the disk array devices were created:

1. Display the block-type device files in the /dev/dsk directory using the ls –l command with the output piped to more. Verify there is one

block-type device file for each disk array device.

“Creating the devic e fi les” (page 38) to crea te the

Example

# ls –l /dev/dsk | more

Total 0

brw-r - - - - - 1 bin sys 28 0x006000 Dec 6 15:08 c6t0d0

brw-r - - - - - 1 bin sys 280 0x06100 Dec 6 15:08 c6t0d1

2. Verify that the block-type device file name for each device is correct.

3. Display the character -type device fil es in the /dev/rdsk directory using the ls –l command with the output piped to more. Verify that there is one character-type device file for each disk array device.

36 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Example

# ls –l /dev/rdsk | more

Total 0

crw-r - - - - - 1 bin sys 177 0x006000 Dec 6 15:08 c6t0d0

crw-r - - - - - 1 bin sys 177 0x006100 Dec 6 15:08 c6t0d1

4. Use the device data table you created to verify that the character-type device file name for each device is correct.

This task c an also be accomplished with the lssf command.

5. After verifying the block-type and cha racter-type device files, verify the HP-UX driver for the disk array using the ioscan –fn command.

Example

# ioscan -fn

Class I H/W Path Driver S/W State H/W Type Description

============================================================================================= bc 0 root CLAIMED BUS_NEXUS

bc 1 8 bc CLAIMED BUS_NEXUS Bus Converter

fc 0 8/12 fcT1 CLAIMED INTERFACE HP Fibre Channel Mass Storage

fcp 0 8/12.8 fcp CLAIMED INTERFACE FCP Protocol Adapter

ext_bus 2 8/12.8.0.255.0 fcpdev CLAIMED INTERFACE FCP Device Interface

disk 3 8/12.8.8.255.0.6.0 sdisk CLAIMED DEVICE HITACHI OPEN-9

/dev/dsk/c2t6d0 /dev/rdsk/c2t6d0

disk 4 8/12.8.8.255.0.6.1 sdisk CLAIMED DEVICE HITACHI OPEN-9

/dev/dsk/c2t6d1 /dev/rdsk/c2t6d1

disk 5 8/12.8.8.255.0.8.0 sdisk CLAIMED DEVICE HITACHI 3390*3B

/dev/dsk/c2t8d0 /dev/rdsk/c2t8d0

Installation 37

Creating the device files

If the device files were not created automatically when the system was restarted, use th e insf – e command in the /dev director y to create t he devic e files. After this command i s exe cuted, repea t the proced ures in the pr evious section driver.

(page 36) to verify new device recognition and the device files and

Example

# insf -e

insf: Installing special files for mux2 instance 0 address 8/0/0

: : : :

Failure of the insf –e command indicates a SAN problem.

If the device files for the new disk array devices cannot be created automatically, you must create the device files manually using the mknod command as follows:

1. Retrieve the device information you recorded earlier.

2. Construct the device file name for each device, using the device information, and enter the file names in your table. Use the following formula to construct the device file name:

cxtydz

where

x = SCSI bus instance number y = SCSI target ID z = LUN

c stands for controller, t stands for target ID, and d stands for device. The numbers x, y, and z are hexadecimal.

38 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

3. Construct the minor number for each device, using the device information, and enter the file names in your table. Use the following formula to construct the minor number:

0xxxyz00

where

xx = SCSI bus instance number y = SCSI target ID z = LUN

4. Display the driver inform ation for the system using the lsdev command.

Example

# lsdev

Character Block Driver Class

: : : :

188 31 sdisk disk

5. Enter the major numbers f or the device drivers into the t able. Y ou should now have all required de vice and driver information in the table.

6. Create the device files for all disk array devices (SCSI disk and multiplatform devices) using the mknod command. Create the block-type device f iles in the /dev/dsk directory an d the charac ter-t ype device files in the /dev/rdsk directory.

# cd /dev/dskGo to /dev/dsk directory.

# mknod /dev/dsk/c2t6d0 b 31 0x026000

Create block-type file.

File name, b=block-type, 31=major #, 0x026000= minor #

# cd /dev/rdskGo to /dev/rdsk directory.

# mknod /dev/rdsk/c2t6d0 c 188 0x026000

Installation 39

Create character-type file.

File name, c=character-type, 177=major #, 0x026000=minor #

# The character-type device file is required for volumes used as raw

devices (for example, 33 90-3A/B/ C). Th e block- type devi ce fil e is no t required for volumes used as raw devices.

If you need to delete a device file, use the rm –i command.

Example of a completed device data table

Major #

Bus

no.

Instance

(XX)

Disk

no.

H/W path Driver

Device

type

TID

(Y)

LUN

(Z)

Device

file

Minor #

0xXXYZ00

for char.

files

8/12 02 3 8/12.8.8.255.0.6.0 sdisk OPEN-9 6 0 c2t6d0 0x026000 188 31 8/12 02 4 8/12.8.8.255.0.6.1 sdisk OPEN-9 6 1 c2t6d1 0x026100 188 31 8/12 02 5 8/12.8.8.255.0.8.0 sdisk 3390-3B 8 0 c2t8d0 0x028000 188 31

Major #

for block

files

40 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Creating the physical volumes

A physical volume must be created for each new SCSI disk device.

To c reate the physical volum es:

1. Use the pvcreate command to create the physical volumes with the character-type device file as the argument. Specify the /dev/rdsk directory.

Example

# pvcreate /dev/rdsk/c6t0d0

Physical volume "/dev/rdsk/c6t0d0" has been successfully created.

# pvcreate /dev/rdsk/c6t0d1

Physical volume "/dev/rdsk/c6t0d1" has been successfully created.

Do not use the –f option with the pvcreate command. This option creates a new physical volume forcibly and overwrites the existing volume. If you accidentally enter the character-type device file for an existing volume, you will lose the data on that volume.

2. Repeat step 1 for each OPEN-x device on the disk array.

Installation 41

Creating new volume groups

You must create new volume groups for the new physical volumes. If desired, you can also add any of the volumes on the disk array to existing volume groups using the vgextend command. The physical volumes that make up one volume group can be located either in the same disk array or in other disk arrays.

To allow more volume groups to be created, use SAM to modify the HP-UX system kernel configuration. See

To create volume groups:

1. Use the vgdisplay command to display the existing volume groups.

2. Choose a unique name for the new volume group (for exa mple : vg06) .

3. Create the directory for the new volume group.

appendix C (page 73) for details.

Example

# mkdir /dev/vg06

4. Use the ls –l command (with the output piped to grep to display only

the files containing “group”) to display the minor numbers for the existing group files.

# ls –1 /dev/vg* | grep group

crw-rw-rw 1 root root 64 0x0000000 Nov7 08:13 group

5. Choose a unique minor number for th e new group file in sequential order (for example, when exi sting volume groups are vg00-vg05 and the next group name is vg06, use minor number 06 for the vg06 group file).

The minor numbers are hexadecimal (for example, the 10th minor number is 0x0a0000).

6. Use mknod to create the group file for the new directory. Specify the volume group name, major number, and minor number. The major number for all group files is 64.

42 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Example In this exampl e: gro up name = vg06, maj or number of group file = 64,

minor number of existing group file = 06 (which must be unique for each volume group), and c = character.

# mknod /dev/vg06/group c 64 0x060000 :

7. Create the volume group. To allocate more than one physical volume to the new volume group,

add the other physical volumes, separated by a space.

Example

# vgcreate /dev/vg06 /dev/dsk/c6t0d0

Volume group "/dev/vg06" has been successfully created.

Volume group configuration for /dev/vg06 has been saved in /etc/1vmconf/vg06.conf.

For Logical Unit Size Expansion (LUSE) volumes that contain more than 17 OPEN-8/9 LDEVs or more than 7043 MB (OPEN-8/9*n-CVS), use the –s and –e physical extent (PE) parameters of t h e vgcreate command. See

“LUSE device parameters”

(page 68).

If you need to dele te a volume grou p, use the vgremove command (for example, vgremove /dev/vgnn). If the vgremove command does not work because the volume group is not active, use the vgexport command (for example, vgexport /dev/vgnn).

8. Use the vgdisplay command to verify that the new directory was created.

9. Use vgdisplay –v to verify that t he volume group was created correctly. The –v option displays the detailed volume group information.

Installation 43

Example

# vgdisplay –v /dev/vg06

- - - Volume groups - - -

VG Name /dev/vg06 VG Write Access read/write VG Status available Max LV 255 Cur LV 0 Open LV 0 Max PV 16 Cur PV 1 Act PV 1 Max PE per PV 1016 VGDA 2 PE Size (Mbytes) 4 Total PE 586 Alloc PE 0 Free PE 586 Total PVG 0

- - Physical Volumes - - PV Name /dev/dsk/c6t0d0 PV Status available Total PE 586 Free PE 586

44 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Creating logical volumes

Use these commands for logical volume configuration:

lvremove Deletes a logical volume.

lvextend Increases the size of an existing logical volume.

lvreduce Decreases the size of an existing logical volume.

Caution Data within the file system can be lost after execution of lvreduce.

Any file system attached to the logical volume must be unmounted before executing the lvremove command.

Example:

Any file system attached to the logical volume must be unmounted before executing the lvreduce command.

Example:

lvremove /dev/vgnn/lvolx

lvextend –L size /dev/vgnn/lvolx

lvreduce –L size /dev/vgnn/lvolx

Create logical volumes after you create volume groups. A logical volume must be created for each new SCSI disk device

To c reate logical volumes:

1. Use the lvcreate –L command to create a logical volume. Specify the volume size (in megabytes) and the volume group for the

new logical volume. HP-UX assigns the logical volume numbers automatically (lvol1, lvol2, lvol3). Use the following capacity values for the size parameter:

OPEN-K = 1740 OPEN-3 = 2344 OPEN-8 = 7004 OPEN-9 = 7004 OPEN-E = 13888

Installation 45

OPEN-L = 34756 OPEN-V = 61432

To calculate S1 for CVS, LUSE, and CVS LUSE volumes, first use the vgdisplay command to display the physical extent size (PE Size) and usable number of physical extents (Free PE) for the volume. Calculate the maximum size value (in MB) as follows:

S1 = (PE Size) × (Free PE) Logical volumes can span multiple physical volumes. Use the

diskinfo command for extended LUNs.

Example Create an OPEN-3 logical volume the size of the physical volume,

using 2344 for the size parameter. An OPEN-9 volume uses 7040 for the size parameter to create a logical volume the size of the physical volume.

# lvcreate –L 2344 /dev/vg06

Logical volume "/dev/vg06/lvol1" has been successfully created with character device "/dev/vg06/rlvol1".

Logical volume "/dev/vg06/lvol1" has been successfully extended.

Volume Group configuration for /dev/vg06 has been saved in /etc/1vmconf/vg06.cof.

2. Use the lvdisplay command to verify that the logical volume was

created correctly.

46 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Example

# lvdisplay /dev/vg06/lvol1

- - - Logical volume - - LV Name /dev/vg06/lvol1 VG Name /dev/vg06 LV Permission read/write LV Status available/syncd Mirror copies 0 Consistency Recovery MWC Schedule parallel LV Size (Mbytes) 2344 Current LE 586 Allocated PE 586 Stripes 0 Stripe Size (Kbytes) 0 Bad block on Allocation strict

3. Repeat steps 1 and 2 for each logical volume to be created. You can create only one logical volume at a time. However, you can

verify multiple logical volumes at a time.

Creating the file systems

Create the file system for each new logical volume on the disk array. The default file system types are:

• HP-UX OS version 10.20 = hfs or vxfs, depending on entry in the

/etc/defaults/fs file

• HP-UX OS version 11.0 = vxfs

• HP-UX OS version 11.i = vxfs

To create file systems:

1. Use the newfs command to create the file system using the logical volume as the argument.

Installation 47

Example

# newfs /dev/vg06/rlvol1

newfs: /etc/default/fs is used for determining the file system type

mkfs (hfs): Warning -272 sectors in the last cylinder are not allocated.

mkfs (hfs): /dev/vg06/rlvol1 - 2400256 sectors in 3847 cylinders of 16 tracks, 2547.9MB in 241 cyl groups (16 c/g, 10.22Mb/g, 1600 ig/g)

Super block backups (for fsck -b) at:

16, 10040, 20064, 30038, 40112, 50136, 60160, 70184, 80208, 90232, . . . 2396176

Example

# newfs /dev/vg06/rlvol1Create file system

newfs: / etc/default/fs is used for determining the file system type

mkfs (hfs): ...

7188496, 7198520, 7208544

# newfs -F vxfs /dev/vg06/rlvol1Specify file system type

# newfs -F hfs /dev/vg06/rlvol2

2. Repeat step 1 for each logical volume on the disk array.

48 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Setting the I/O timeout parameter

Set the I/O timeout value for each disk device to 30 seconds.

To change the I/O timeout parameter:

1. Verify the current I/O timeout value using the pvdisplay command:

Example

# pvdisplay /dev/dsk/c0t6d0

This causes current values to be displayed:

--- Physical volumes --PV Name /dev/dsk/c0t6d0 VG Name /dev/vg06 PV Status available Allocatable yes VGDA 2 Cur LV 1 PE Size (Mbytes) 4 Total PE 586 Free PE 0 Allocated PE 586 [OPEN-9] Stale PE 0 IO Timeout (Seconds) default [I/O timeout value]

2. If the I/O timeout value is not 30, change the value to 30 using the pvchange -t command:

# pvchange -t 30 /dev/dsk/c0t6d0

This result is displayed:

Physical volume "/dev/dsk/c0t6d0" has been successfully changed. Volume Group configuration for /dev/vg06 has been saved in /etc/lvmconf/vg06.cof

3. V eri fy that the new I/O timeou t value is 30 seconds using the pvdisplay command:

Example

# pvdisplay /dev/dsk/c0t6d0

Current values are now displ ayed, confirming that the new I/O timeout value is 30 seconds:

Installation 49

--- Physical volumes --PV Name /dev/dsk/c0t6d0 VG Name /dev/vg06 PV Status available : Stale PE 0 IO Timeout (Seconds) 30 [New I/O timeout value]

4. Repeat the above steps for each new di sk that is connected to the system.

Creating the mount directories

Create a mount directory for each logical volume. Choose a unique name for each mount directory that identifies the logical volume.

Example The following example shows the root directory as the location for the

mount directories.

To create a mount directory for each logical volume:

1. Use mkdir with the new mount directory na me as the argument to create

the mount directory.

# mkdir /AHPMD-LU00

2. Use the ls –x command to verify the new mount directory.

# ls -x

AHPMD-LU00 bin dev device etc export

floppy home hstsboof kadb kernel lib

3. Repeat steps 1 and 2 for each logical volume on the di sk array.

50 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Mounting and verifying the file systems

After the mount directories have been created, mount and verify the file system for each logical volume.

To mount and verify the file systems:

1. Use mount to mount the file system for the volume.

Example

# mount /dev/vg06/lvol1 /AHPMD-LU00

2. Repeat step 1 for each logical volume on the disk array. If you need to unmount a file system, use the unmount command.

3. Use the bdf command to verify that the file systems are correct. The capacity is listed under Kbytes.

# bdf Filesystem Kbytes used avail %used Mounted on /ldev/vg00/lvol1 59797 59364 0 100% / : /ldev/vg06/lvol1 2348177 9 2113350 0% /AHPMD-LU00

4. As a final verification, perform some basic UNIX operations (for example file creation, cop yin g, and delet ion) on ea ch logic al device to make sure that the devices on the disk array are fully operational.

#cd /AHPMD-LU00

#cp /bin/vi /AHPMD-LU00/vi.back1

#ls -l

drwxr-xr-t 2 root root 8192 Mar 15 11:35 lost+found

-rwxr-xr-x 1 root sys 217088 Mar 15 11:41 vi.back1

#cp vi.back1 vi.back2

#ls -l

Installation 51

drwxr-xr-t 2 root root 8192 Mar 15 11:35 lost+found

-rwxr-xr-x 1 root sys 217088 Mar 15 11:41 vi.back1

-rwxr-xr-x 1 root sys 217088 Mar 15 11:52 vi.back2

Setting and verifying the auto-mount parameters

Set up and verify the auto-mount parameters for each new volume. The /etc/checklist file (which can also be cal l ed the /etc/fstab file) contains the auto-mount parameters for the logical volumes.

To set up and verify the auto-mount parameters:

1. Edit the /etc/checklist (/etc/fstab) file to add a line for each

OPEN-x device on the disk arra y . This example an d the following tabl e show the auto-mount parameters.

Example

#cp -ip /etc/checklist /etc/checklist.standard #vi /etc/checklist

/dev/vg00/lvol1 / hfs rw 0 1 # root /dev/vg00/lvol2 swap ignore rw 0 0 # primary swap : /dev/vg06/lvol1 /AHPMD-LU00 hfs defaults 0 2 # AHPMD-LU00 /dev/vg06/lvol2 /AHPMD-LU01 hfs defaults 0 2 # AHPMD-LU01

P1 P2 P3 P4 P5 P6 P7

52 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Parameter Name Enter

Device to mount Block-type device file name Mount point Mount directory name File system Type of file system (for example,

hfs, vxfs)

Mount options “defaults” or other appropriate

Enhance 0 File system check

(fsck pass) Comments Comment statement

mount options

Order for performing f ile system checks

2. Reboot the system.

3. Use the bdf command to verify the file system again.

Installation 53

54 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Troubleshooting

This section includes resolutions for various error conditions you may encounter.

If you are unable to resolve an error condition, ask your HP support representative for assistance. See

page 59.

“Calling the HP support center” on

Troubleshooting 55

Error conditions

Depending on your system configuration, you may be able to view error messages as follows:

• In Remote Web Console (Status tab)

• In Command View Advanced Edition (“Alerts” panel).

• In Command View (Event History or Event Notification panels).

Error Condition Recommended Action

The logical devices are not recognized by the host.

The host does not reboot properly after hard shut down.

Verify that the READY indicator lights on the disk array are ON.

Verify that fiber cables are correctly installed and firmly connected.

Verify that the target IDs are properly configured. The LUNs for each TID must start at 0 and continue sequentially without skipping any numbers.

Verify that the TIDs/WWNs on each bus are unique . Do not in stall t wo devices with the same ID on the same bus.

Recheck the buses for new devices.

Verify that LUSE devices are n ot int ermixed wit h normal LUNs o n the same port.

Verify that the maximum number of LUSE devices per port has not been exceeded.

Verify that the disk a rray host mode is set correctly. If you power off t he host without executing t he shutdown proc ess, wait

three minutes to allow the disk array’s internal timeout process to purge queued commands. If the host restarts while the disk array is processing queued commands, the host may not reboot successfully.

56 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Error Condition Recommended Action

Physical volumes cannot be created (pvcreate).

Volume group cannot be created (vgcreate).

Logical volumes cannot be created (lvcreate).

Verify that the disk array logical devices are correctly formatted.

Verify that the character-t ype device file exists.

Verify that the correct character-type device file name is used with pvcreate (for example, /dev/rdsk/...).

Verify that the directory for the new volume group exists.

Verify that the control file exists.

Verify that the correct major number (64) and minor number are used with mknod.

Verify that the block-type device file exists and is entered correctly with vgcreate.

Verify that the physical volume is not already allocated to another volume group.

Verify that the volume capacity for OPEN-x volumes is not greater than the maximum capacity allowed. See the Device Emulations Appendix.

Verify that the capacity of the volume group is not less than the total capacity of the partitioned logical volume.

The file system cannot be created (newfs command).

A file system is not mounted

Verify that the character-type device file is entered correctly with newfs (for example, /dev/vg01/r/vo/x).

Verify that the host was restarted correctly.

after rebooting.

Verify that the file system attributes are correct.

Verify that the auto-mount inform ation in the /etc/checklist (/etc/fstab) file is correct.

Troubleshooting 57

Error Condition Recommended Action

The disk array performs a self reboot because the disk array was busy or it l ogged a panic message.

The disk array responds “Not Ready” or the disk array has displayed “Not Ready” and timed out.

The host detects a parity error.

The host hangs or devi ces are declared and the host hangs.

Reboot the host.

Contact HP.

Check the HBA and make sure it was installed properly.

Reboot the host. Make sure there are no duplicate disk array TIDs and that disk array

TIDs do not conflict with any host TIDs.

58 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Calling the HP support center

If you are unable to resolve an error condition, contact the HP support center for assistance.

Contact Information

In North America, call technical support at 1-800-633-3600, available 24 hours a day, 7 days a week.

Outside North America, call technical support at the location nearest you. The HP web site lists telephone numbers for worldwide technical support at:

http://www.hp.com/support

Before you call

Be sure to have the following information available:

• Technical support registration number (if applicable)

• Product serial numbers

• Product model names and numbers

• Applicable error message s

. From this web site, select your country.

• Operating system type and revision level

• Detailed, specific questions

Troubleshooting 59

60 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Worksheets

Worksheets 61

Path worksheet

Bus no.

Instance (XX)

Disk

H/W path Driver Device

no.

type

TID (Y)

LUN (Z)

Device file

Minor # 0xXXYZ00

Major # for char. files

Major # for block files

62 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Disk array device emulations

This appendix provides infor mation about support ed emulations and devi ce type specifications. Some parameters may not be relevant to your array. Consult your HP representative for information about supported configurations for your system.

Disk array device emulations 63

Supported emulations

XP Model

XP128 OPEN-9 Yes Yes Yes Yes XP1024 OPEN-E Yes Yes Yes Yes XP10000 OPEN-K XP12000 OPEN-L Yes Yes

OPEN Emulation Type

OPEN-3 Yes Yes Yes Yes OPEN-8 Yes Yes Yes Yes

OPEN-M OPEN-V Yes Yes

OPEN Emulation Supported

LUSE CVS

LUSE & CVS

64 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Device type specifications

Sector

Note 4

Size (bytes)

# of Cylinders

512 Note 5 15 128 Note 6

Heads

Device Type

(Note 1)

OPEN-3 SCSI disk 4806720 512 3338 15 96 2347 OPEN-8 SCSI disk 14351040 512 9966 15 96 7007 OPEN-9 SCSI disk 14423040 512 10016 15 96 7042 OPEN-E SCSI disk 28452960 512 19759 15 96 13893 OPEN-L SCSI disk 71192160 512 49439 15 96 34761 OPEN-V SCSI disk max=125827200 512 Note 5 15 128 Note 6

LUSE

OPEN-3*n SCSI disk 4806720*n 512 3338*n 15 96 2347*n OPEN-8*n SCSI disk 14351040*n 512 9966*n 15 96 7007*n OPEN-9*n SCSI disk 14423040*n 512 10016*n 15 96 7042*n OPEN-E*n SCSI disk 28452960*n 512 19759*n 15 96 13893*n OPEN-L*n SCSI disk 71192160*n 512 49439*n 15 96 34761*n OPEN-V*n SCSI disk max=125827200

CVS

OPEN-3 CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-8 CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-9 CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-E CVS SCSI disk Note 4 512 Note 5 15 96 Note 6

CVS LUSE

OPEN-3*n CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-8*n CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-9*n CVS SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-E* n C V S SCSI disk Note 4 512 Note 5 15 96 Note 6 OPEN-V*n SCSI disk Note 4 512 Note 5 15 128 Note 6

LUSE device parameters

Device type

Physical extent size (PE)

Max physical extent size (MPE)

OPEN-K/3/8/9/E OPEN-3/K*n (n= 2 to 36 ) OPEN-3/K-CVS OPEN-3/K*n-CVS (n = 2 to 36)

OPEN-8/9*n n = 2 to 17 default default

n = 18 8 15845 n = 19 8 16725 n = 20 8 17606 n = 21 8 18486 n = 22 8 19366 n = 23 8 20247 n = 24 8 21127 n = 25 8 22007 n = 26 8 22888 n = 27 8 23768 n = 28 8 24648 n = 29 8 25529 n = 30 8 26409 n = 31 8 27289

default default

n = 32 8 28170 n = 33 8 29050 n = 34 8 29930 n = 35 8 30810 n = 36 8 31691

68 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Max

Physical extent

Device type

OPEN-E*n n = 2 to 9 default default

n = 10 8 17366 n = 11 8 19102 n = 12 8 20839 n = 13 8 22576 n = 14 8 24312 n = 15 8 26049 n = 16 8 27786 n = 17 8 29522 n = 18 8 31259 n = 19 8 32995 n = 20 8 34732 n = 21 8 36469 n = 22 8 38205

size (PE)

physical extent size (MPE)

n = 23 8 39942 n = 24 8 41679 n = 25 8 43415 n = 26 8 45152 n = 27 8 46889 n = 28 8 48625 n = 29 8 50362 n = 30 8 52098 n = 31 8 53835 n = 32 8 55572

Disk array device emulations 69

Max

Physical extent

Device type

n = 33 8 57308 n = 34 8 59045 n = 35 8 60782 n = 36 8 62518

OPEN-L*n n = 2 to 3 default default

size (PE)

physical extent size (MPE)

OPEN-8/9/E-CVS OPEN-V

OPEN-8/9/E*n-CVS OPEN-V*n (n = 2 to 36)

N1 = [ VCS volume capacity (in MB) from Remote Console PC ] × n

N2 = ↑ N1 / PE ↑ (↑ means round up to next integer)

Example: CVS vo lume capacity is 6000 MB for OPEN-9*22-CVS volume:

N1 = 6000 × 22 = 132000

N2 = ↑ 132000/8 ↑ = 16500

70 to 119731(MB) × N1 8 default

119732 to (MB) × N1 8 N2

default default

70 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

SCSI TID map for Fibre Channel adapters

When an arbitrated loop (AL) is established or reestablished, the port addresses are assigned automatically to prevent duplicate TIDs. With the SCSI over Fibre Channel protocol (FCP), there is no longer a need for target IDs in the traditional se nse.

SCSI is a bus-oriented protocol requiring each device to have a unique address since all commands go to all devices. For Fibre Channel, the AL-PA is used instead of the TID to direct packets to the desired destination.

Unlike traditional SCSI, when control of the loop is acquired, a point-to-point connection is established from initiator to target. To enable transparent use of FCP, the operating system maps a TID to each AL-PA.

The host maps SCSI protocol to Fibre Channel protocol and detects and accesses Fibre Channel-connected devices using device files (/dev/dsk/c*t*d* and /dev/rdsk/c*t*d*) in the same way as for SCSI-connected devices. The device files for Fibre Channel-connected devices are configured in a different way from SCSI-connected devices, because Fibre Channel supports 126 addresses per path while SCSI supports 16 TIDs per path.

The following table identifies the fixed mappings between the TID (drive) values assigned by the operating system and the Fibre Channel native addresses (AL_PA/SEL_ID) for Fibre Channel adapt ers. The controller number (the dks value in /dev/dsk/dks*d*l*s*) depends on the server configuration, and a different value is assigned per each column.

Disk array device emulations 71

The mapping cannot be done when these conditions exist:

• disk array devices and other types of devices are connected in the same loop

• information for unused devices remains in the server system

• multiple ports participate in the same arbitrated loop

AL- PAt

EF 0 CD 0 B2 0 98 0 72 0 55 0 3A 0 25 0 E8 1 CC 1 B1 1 97 1 71 1 54 1 39 1 23 1 E4 2 CB 2 AE 2 90 2 6E 2 53 2 36 2 1F 2 E2 3 CA 3 AD 3 8F 3 6D 3 52 3 35 3 1E 3 E1 4 C9 4 AC 4 88 4 6C 4 51 4 34 4 1D 4 E0 5 C7 5 AB 5 84 5 6B 4 4E 5 33 5 1B 5 DC 6 C6 6 AA 6 82 6 6A 6 4D 6 32 6 18 6 DA 7 C5 7 A9 7 81 7 69 7 4C 7 31 7 17 7 D9 8 C3 8 A7 8 80 8 67 8 4B 8 2E 8 10 8 D6 9 BC 9 A6 9 7C 9 66 9 4A 9 2D 9 0F 9 D5 10 BA 10 A5 10 7A 10 65 10 49 10 2C 10 08 10 D4 11 B9 11 A3 11 79 11 63 11 47 11 2B 11 04 11 D3 12 B6 12 9F 12 76 12 5C 12 46 12 2A 12 02 12 D2 13 B5 13 9E 13 75 13 5A 13 45 13 29 13 01 13 D1 14 B4 14 9D 14 74 14 59 14 43 14 27 14 00 – CE 15 B3 15 9B 15 73 15 56 15 3C 15 26 15

value

AL- PAt

value

AL- PAt

value

AL- PAt

value

AL- PAt

value

AL- PAt

value

AL- PAt

value

AL- PAt

value

72 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Reference information for SAM

The HP System Administrator Manager (SAM) is used to perform HP-UX system administration functions, including:

• setting up users and groups

• configuring the disks and file systems

• performing auditing and security activities

• editing the system kernel configuration

This appendix provides instructions for:

• using SAM to configure the disk devices

• using SAM to set the maximum number of volume groups

Reference information for SAM 73

Configuring the devices using SAM

The SAM Areas window displays the system administration functions and allows you to select the desired function. The Disks and File Systems function allows you to configure new disk devices for LVM operations.

To configure the newly installed SCSI disk devices:

1. Select Disks and File Systems, then select Disk Devices.

74 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

2. V eri fy that the n ew disk array device s are displayed i n the Disk Devices

window.

3. Select the device to confi gure, select the Actions menu, select Add, and then select Using the Logical Volume Manager.

4. In the Add a Disk Using LVM window, select Create... or Extend a Volume Group.

5. In the Create a Volume Group windo w, enter the name of the new or existing volume group to assign the new device to, and then click OK twice. The Add a Disk Using LVM window now displays the volume group name.

6. Select Add New Logical Volume to open the Create New Logical Volumes window.

7. In the Create New Logical Volumes window, enter the name, size in megabytes, and mount directory for the new logical volume. Select Add, and then click OK twice.

8. Repeat steps 3 through 7 for each new disk device on the disk array.

Reference information for SAM 75

Setting the maximum number of volume groups using SAM

The HP-UX kernel specifies the maximum number of volume groups that can be created. The default is 10. You may need to change this number to accommodate new devices on the disk array. To change this number, use the Kernel Configuration function.

To change the maximum number of volume groups:

1. Select the Kernel Configuration f unction, then select Configurable Parameters.

2. In the Configurable Parameters window, select the maxvgs parameter, select the Actions menu, and then select Modify Configurable Parameter.

3. In the Modify Configurable Parameter window, enter the desired maximum number of volume groups in the Formula/Value field, and then click OK.

4. In the Configurable Parameters window, make sure that none of the parameters are selected. Then select the Actions menu, and select Create New Kernel.

5. When the configuration window opens, click Yes to create the new kernel (or click No to return to the Configurable Parameters window .)

6. When the Reboot the System window opens, click OK to move the new kernel into place and reboot the system.

76 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Glossary

AL Arbitrated loop.

AL-PA Arbitrated loop physical address. array group A group of 4 or 8 physical hard disk drive s (HDDs) inst al le d in an XP disk

array and assigned a common RAID level. RAID1 array groups are made up of 4 HDDs (2D+2D). A RAID1 group is two 4 HDD array groups concatenated togeth er (4D+ 4D). RAID 5 array g roups a re made up of 4 or 8 HDDs, depending on whether they are RAID5 3D+1P or RAID5 7D+1P, respectively. All RAID6 array groups are made up of 8 HDDs (6D+2P).

BC HP StorageWorks Business Copy XP. BC lets you maint ain u p to ni ne lo cal

copies of logical volumes on the disk array.

CA HP StorageWorks Continuous Access XP. CA lets you create and maintain

duplicate copies of local logical volumes on a remote disk array.

Command View (CVXP)

Command View XP Advanced Edition (CVXP AE)

command device A volume on the disk array that accepts Continuous Acc ess or Business Copy

CU Control Unit. Contains LDEVs and is approximately equivalent to SCSI

Glossary 77

HP StorageW o rks Command V iew XP, a software product for managing XP arrays. Command V iew runs on a W indows-based management workstati on.

HP StorageWorks Command View XP Advanced Edition, installs on the user-provided Device Manager server and provides a browser-based platform from which you can manage the XP family of disk arrays—even globally distributed arrays.

control operations which are then executed by the disk array.

Target ID.

CVS Custom volume size. CVS devices (OPEN-x CVS) are custom volumes

configured using array management software to be smaller than normal fixed-size OPEN system volumes. Synonymous with volume size customization (VSC).

DKC (disk controller unit)

DKU

The array cabinet that houses the channel adapters and service processor (SVP).

The array cabinets that house the disk array physical disks.

(disk cabinet unit) emulation modes The logical devices (LDEVs) a ssociated with ea ch RAID group are as signed

an emulation mode that mak es the m operat e lik e OPEN syst em disk drives . The emulation mode determines the size of an LDEV:

OPEN-3: 2.46 GB OPEN-8: 7.38 GB OPEN-9: 7.42 GB OPEN-E: 13.56 GB OPEN-L: 36 GB OPEN-V: User-defined custom size

failover Disconnecting a failed unit or path and replacing it with an alternative unit

or path in order to continue functioning.

FC Fibre Channel.

FC-AL Fibre Channel arbitrated loop.

FCP Fibre Channel Protocol.

GB Gigabytes

HBA Host bus adapter.

host mode Each port can be configured for a particular host type. These modes are

represented as two- digit hexadecimal number s. For example, host mode 08 represents an HP-UX host.

78 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

LDEV Logical device. An LDEV is creat ed when a RAID group is carved into pieces

according to the selected host emulation mode (that is, OPEN-3, OPEN-8, OPEN-L). The number of resulting LDEVs depends on the selected emulation mode. The term LDEV is o ften used synonymously wi th the t erm volume.

LUN Logical unit number. A LUN results from mapping a SCSI logical unit

number, port ID, and LDEV ID to a RAID group. The size of the LUN is determined by the emulatio n mode of the LDEV and the number of LDEVs associated with the LUN. For example, a LUN associated with two OPEN3 LDEVs has a size of 4,693 MB.

LUSE A LUN is normally associated with o nly a s ingle L DEV. The LUSE f eature

allows a LUN to be a ssociated with 1 to 36 LDEVs. Essentially , LUSE makes it possible for applica tions to access a single large poo l of storage. The LUSE feature is available when the HP StorageW orks LUN Configuration Manager product is installed.

OFC Open Fibre Control. OPEN-x A general term describing any one of the supported OPEN emulation

modes (for example, OPEN-L).

OS O perating system.

PA Physical address.

path “Path” and “LUN” are synonymous. Paths are created by associating a por t,

a target, and a LUN ID with one or more LDEVs.

port A physical connection that allows data to pass between a host and the disk

array. The number of ports on an XP disk array depends on the number of supported I/O slots and the number of ports available per I/O adapter. The XP family of disk arrays supports Fib re Channel (FC) port s as well as other port types. Ports are named by port group and port letter, such as CL1-A. CL1 is the group, and A is the port letter.

RAID Redundant array of independent disks.

remote console PC The PC running HP StorageWorks Remote Control XP.

Glossary 79

Remote Control (RC) HP StorageWorks Remote Control XP. A software product used for

managing XP arrays.

Remote W eb Console (RWC)

HP StorageWorks XP Remote Web Console. A browser-based program installed on the SVP that al lows you to configure an d manage the disk array.

R-SIM Remote service information message.

SCSI Small computer system interface.

SIM Service information message.

SNMP Simple Network Management Protocol.

SVP S ervice processor, which is the PC built into the disk controll er. The SVP

provides a direct interface into the disk array. SVP use is reserved for HP support re presentatives only .

TB Terabyte.

TID Target ID.

Volume On the XP array, a volume is a uniquely identified virtual storage device

composed of a control unit (CU) component and a logical device (LDEV) component separated by a colon. For example 00:00 and 01:00 are two uniquely identified volumes; one is identified as CU = 00 and LDEV = 00, and the other as CU = 01 and LDEV = 00; t hey are two unique separate virtual storage devices within the XP array.

VSC Volume size customization. Synonymous with CVS.

WWN World Wide Name. A unique i den ti fi er as si gned to a Fibre Channe l devi ce.

80 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

Index

arbitrated-loop physical address 24 authorized resellers 8 Auto LUN XP 17 Auto Path XP 17 auto-mount parameters, setting 52

Business Copy XP 17, 19

Cache LUN XP 17 Cluster Extension XP 17 clustering 27, 28 command device(s)

designate at least one LDEV as a 19

RAID Manager 19 Command View 16, 19, 21, 24 Command View XP Advanced Edition 16, 19,

21, 24, 30 configuration

device 35

emulation types 18 recognition 32

using SAM 74 Fibre Channel ports 24 HBAs 26

host 26 host mode, setting 21 I/O timeout parameter 49 mount directories, creating 50 port 24

System Option Mode 23 Continuous Access Extension XP 17 Continuous Access XP 17, 19

Data Exchange XP 17 device(s)

configuration 35

using SAM 74 emulations 18 files

creating 38

verifying 36 logical, not recognized by host 56 LUSE device parameters 68 recognition 32 specifications 65 type specificatio ns 65 verifying 32

directories, mount 50 disk array(s)

connecting 29

Index 81

device types 65 features 16 installation overview 20 not ready message 58 operating system versio ns 16 requirements 16 self reboot 58 server support 16 storage capacity 16 supported 7 times out 58

documentation

related 8

emulation(s)

device emulation types 18 supported 64

error conditions 56

fabric environment

parameter settings 25 port addresses 24

zoning 27, 28 failover 18 Fibre Channel

adapters, SCSI TID map 71

connection speed 17

parameter settings 25

ports, configuring 24

supported elements 17

topology example 25 file system(s)

cannot be created 57

for logical volumes 47

mounting 51

not mounted after rebooting 57 verifying 36, 51

glossary 77

HBA(s)

configuring 26 installation, verifying 31

host

configuration 26 doesn’t reboot properly after hard

shutdown

hangs up 58 logical devices not recognized 56

parity error 58 host bus adapters, see "HBAs" host mode, setting 21 HP

service representative tasks 21

technical support 59 HP-UX, supported versions 16

I/O timeout parameter, setting 49 installation

connecting disk array 29

HBA, verifying 31

HP service representative tasks 21

overview 20

LDEV(s)

designate at least one as a command

device

logical volume(s)

auto-mount parameters 52

82 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

cannot be created 57 creating 45 file systems 47, 51

LUN Configuration and Security Manager

16, 21, 29, 30

LUN(s)

creating 29 mapping 29 security 27

LUSE device parameters 68

mount directories, creating 50 multi-cluster environment 27

operating system(s)

loading 26 LUN securit y for 28 multiple, fa bric zoning f or 28 supported versions of HP-UX 16

parity error 58 path(s)

defining 29

worksheet 62 Performance Advisor XP 17 physical volume(s)

cannot be created 57

creating 41

creating groups 42 port(s)

address 24

Fibre Channel 24

host mode, setting 21

RAID Manager command devices 19 RAID Manager XP 17 Remote Web Console 16, 19, 21, 24 resellers, authorized 8 Resource Manager XP 17

SAM (HP System Administrator Manager)

configuring devices using 74 reference i nformation 73 volume groups, setting maximum

number

SCSI disk, Fibre Channel interface and term

"SCSI disk"

SCSI TIP map 71 Secure Manager XP 28 security, LUN 27, 28 server support 16 SNMP configuration 19 software, optional 17 storage capacity 16 StorageWorks, supported arrays 7 system administrator, required knowledge 7 System Option Mode, setting 23

technical support 9, 59 topology, fabric 25 troubleshooting 55

error conditions 56 technical support 59

Unix, supported versions HP-UX 16

volume(s)

Index 83

groups

cannot be created 57 creating 42 setting maximum number 76

logical

auto-mount parameters 52 cannot be created 57 creating 45 file systems 47, 51

physical

cannot be created 57 creating 41 creating groups 42

warranty 12 web site

HP storage 8

worksheet, path 62

XP family

optional software 17 storage capacity 16

zoning, fabric 27, 28

84 HP StorageWorks Disk Array XP Operating System Configuration Guide: HP-UX

HP XP12000 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About this guide

Intended audience

Prerequisites

Disk arrays

Related documentation

HP storage website

HP sales and authorized resellers

HP technical support

Document conventions

Revision history

Warranty statement

Installation

Features and requirements

Fibre Channel interface

Device emulation types

Failover

SNMP configuration

RAID Manager command devices

Installation procedures

Install and configure the disk array

Setting the host mode for the disk array ports

Setting the System Option Modes

Configuring the Fibre Channel ports

Install and configure the host

Loading the OS and software

Installing and configuring the HBAs

Clustering and fabric zoning

Fabric zoning and LUN security for multiple operating systems

Connect the disk array

Defining the paths

Verifying HBA installation

Verifying device recognition

Configure disk array devices

Verifying the device files and drivers

Creating the device files

Creating the physical volumes

Creating new volume groups

Creating logical volumes

Creating the file systems

Setting the I/O timeout parameter

Creating the mount directories

Mounting and verifying the file systems

Setting and verifying the auto-mount parameters

Troubleshooting

Error conditions

Calling the HP support center

Path worksheet

Supported emulations

Device type specifications

LUSE device parameters

SCSI TID map for Fibre Channel adapters

Configuring the devices using SAM

Setting the maximum number of volume groups using SAM

Glossary

Index
