Owner’s Guide

fifth edition (July 2005)

part number: A7906-96012

This guide describes the general operations, components, specifications, and options for the HP StorageWorks Disk Array XP128 and Disk Array XP1024.

the implied warranties of merchantability and fitness for a particular purpose. Hewlett-Packard shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.

This document contains proprietary information, which is protected by copyright. No part of this document may be photocopied, reproduced, or translated into another language without the prior written consent of Hewlett-Packard. The information contained in this document is subject to change without notice.

HP-UX is a registered trademark of Hewlett-Packard Company. All other product names mentioned herein may be trademarks of their respective companies. Hewlett-Packard Company shall not be liable for technical or editorial errors or omissions contained herein. The

information is provided “as is” without warranty of any kind and is subject to change without notice. The warranties for Hewlett-Packard Company products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty.

Printed in the U.S.A.

HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

fifth edition (July 2005) part number: A7906-96012

2 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

About this guide 7

Related information 7 Document conventions and symbols 8 HP technical support 8 HP storage website 9 HP sales and authorized resellers 9 Helpful web sites 9

Revision history 10

1 Overview 11

Continuous data availability 12 Nondisruptive service and upgrades 13 Connectivity 14

Fibre Channel connectivity 14 ESCON connectivity 15 FICON connectivity 15

iSCSI connectivity 16 Data integrity 17 Summary of features 19

2 XP128 hardware 23

General safety guidelines 24 Physical components 26 Control panel 29 Emergency power-off 34 Normal operations 36

Contents 3

Powering down the disk array 37

Emergency power-off 37 Planned power-off 37

Recovering from a power outage to the disk array 39

Manual restart of the disk array after power is restored 39 Automatic power on restart 40

Specifications 41

Temperature 41 Humidity 41 Mechanical vibration 42 AC line voltage 42

Web site 44

3 XP1024 hardware 45

General safety guidelines 46 Physical components 48 Disk control frame 51

Control panel 52 Service processor 52

Disk array frames 53

Available disk drives 54 RAID options 55

Device Manager server (optional) 55 Control panel 57 Emergency power-off 62 Normal operations 64 Powering down the disk array 65

Emergency power-off 65

Planned power-off 66 Recovering from a power outage to the disk array 67

Manual restart of the disk array after power is restored 68

Automatic power on restart 69 Specifications 70

Temperature 70

AC line voltage requirements for the HP Disk Array XP1024

(DKC) 71

AC line voltage requirements for the HP Disk Array XP1024

(DKU) 73

4 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

4 Optional software products 77

XP array management 78

HP StorageWorks XP Remote Web Console and Command View

Advanced Edition (AE) 78

Storage management and LUN security 79

HP StorageWorks LUN Configuration and Security Manager XP 79

Remote and local data replication 80

HP StorageWorks Continuous Access XP 80 HP StorageWorks Continuous Access Extension XP 80 HP StorageWorks Business Copy XP 80

Failover and load balancing 81

HP StorageWorks Auto Path XP 81 HP StorageWorks Secure Path 81

Performance management 82

HP StorageWorks Cache LUN XP 82 HP StorageWorks Auto LUN XP 82 HP StorageWorks Performance Advisor XP 82 HP StorageWorks Application Policy Manager XP 83

Network management products 84

HP OpenView SPI for XP Disk Arrays 84 HP OpenView SPI for HP storage devices 84

Mainframe solutions 85

HP StorageWorks Resource Manager XP 85 HP StorageWorks Data Exchange XP 85

5 Troubleshooting 87

Monitoring and reporting 88 Troubleshooting flow diagram 89

6 Regulatory statements 91

FCC EMC Statement (USA) 92 IEC Statement (Worldwide) 93 EMC Statement (Canada) 94 Spécification ATI Classe A (France) 95 VCCI EMC Statement (Japan) 96 BSMI EMC Statement (Taiwan) 97 RRL EMC Statement (Korea) 98 Harmonics Conformance (Japan) 99 German Noise Declaration 100 Laser Safety 101 Japan DENAN law cordset caution 102

Contents 5

XP128 Declaration of Conformity 103 XP1024 Declaration of Conformity 104 European WEEE statements 105

Glossary 113

Index 121

6 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

About this guide

This guide is for use by system administrators who have expertise in:

• Disk arrays and RAID technology

• Operating system commands and utilities

• Data processing concepts

• Direct-access storage device subsystems and their basic functions

This document describes the general operations, components, specifications, and options for the HP StorageWorks Disk Array XP128 and XP1024.

Unless otherwise noted, the term disk array refers to the HP StorageWorks XP128 and/or XP1024 Disk Array.

Related information

In addition to this guide, please refer to other documents for this product:

• HP StorageWorks Command View XP for XP Disk Arrays: User Guide

• HP StorageWorks Disk Array XP128 Site Preparation Guide

• HP StorageWorks Disk Array XP1024 Site Preparation Guide

• HP StorageWorks XP Remote Web Console User Guide

• HP StorageWorks Command View XP Advanced Edition for XP Disk Arrays User Guide

• HP StorageWorks Disk Array XP Operating System Configuration Guide (various operating systems)

To locate these documents, to learn more about HP software products, or to obtain software updates, visit the HP web site:

http://h18006.www1.hp.com/storage/xparrays.html

About this guide 7

Document conventions and symbols

Table 1. Document conventions

Convention Element

Blue text (Figure 1) Cross-reference links

Bold Menu items, button names, key names, tab names, and group box names Italics Text emphasis and document titles

Blue underlined sans serif font (www.hp.com

)

Caution Indicates that failure to follow directions could result in damage to

equipment or data.

Warning

Indicates that failure to follow directions could result in injury or death.

HP technical support

In North America, call technical support at 1-800-633-3600, available 24 hours a day, 7 days a week.

Outside North America, call technical support at the location nearest you. The HP web site lists telephone numbers for worldwide technical support at:

Web site addresses

http://www.hp.com/support

. From this web site, select your country.

Collect the following information before calling:

• Technical support registration number (if applicable)

• Product serial numbers

• Product model names and numbers

• Applicable error messages

8 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

• Operating system type and revision level

• Detailed questions

For continuous quality improvement, calls may be recorded or monitored.

HP strongly recommends that customers sign up online using the Subscriber’s choice web site at Subscribing to this service provides you with email updates on the latest product enhancements, newest versions of drivers, and firmware documentation updates as well as instant access to numerous ohter product resources.

HP storage website

For the most current information about HP StorageWorks XP products, visit:

http://h18006.www1.hp.com/storage/arraysystems.html

For information about product availability, configuration, and connectivity, contact your HP support representative.

HP sales and authorized resellers

http://www.hp.com/go/e-updates

To reach HP sales or find a local authorized reseller of HP products, call 1-800-282-6672 or visit the HP How To Buy web site:

http://welcome.hp.com/country/us/en/howtobuy.html

You can also find HP sales and resellers at Contact HP.

http://www.hp.com

. Click

Helpful web sites

For third party product information, see the following web sites:

http://www.hp.com/go/storage

http://www.hp.com/support

About this guide 9

Revision history

May 2002 First Edition

Oct. 2002 Second Edition

May 2004 Third Edition

May 2005 Fourth Edition

July 2005 Fifth Edition

10 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Overview

The Disk Array XP128 and Disk Array XP1024 are part of the HP StorageWorks Disk Array family of products. These disk arrays provide reliable and secure data storage and protection, featuring redundant circuitry and RAID storage options for data security. These disk arrays also support multiple operating systems, platforms, and RAID groups. The advantages include:

• Continuous data availability

• Nondisruptive service and upgrades

• Connectivity

• Scalability

• Data integrity

Overview 11

Continuous data availability

The HP StorageWorks Disk Array XP family are the first RAID disk arrays to provide truly continuous data availability. They are designed for nonstop operation and continuous access to all user data.

HP StorageWorks Disk Array XP128 and XP1024 disk arrays have no single point of component failure, which enables uninterrupted access to data.

The disk array has component and function redundancy, providing full fault tolerance for disk array microprocessors, control storage, control and data buses, power supplies, and cooling fans. The disk array can sustain multiple component failures and still continue to provide full access to your stored data.

While access to your data is never compromised, the failure of a key component can cause a temporary reduction in disk array performance.

12 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Nondisruptive service and upgrades

Monitoring software detects internal hardware component problems and notifies the HP Storage Technology Center automatically. At the support center, the problem is verified and the appropriate maintenance activity is executed by an HP service representative. The are no user serviceable components. Only an HP service representative should open the cabinets.

All hardware subassemblies can be removed, serviced, repaired, or replaced non-disruptively during disk array operation. All microcode upgrades can be performed during normal disk array operations (provided array connectivity infrastructure requirements are satisfied), using your disk array’s built-in service processor (SVP). Alternate paths can be set by host failover software and/or alternate Fibre Channel paths.

Overview 13

Connectivity

The HP StorageWorks Disk Array XP128 and HP StorageWorks Disk Array XP1024 are connected to host systems using one of these types of connections:

• Fibre Channel

•ESCON

•FICON

• iSCSI

Fibre Channel connectivity

HP StorageWorks Disk Array XP128

The XP128 supports a maximum of three pairs of channel adapters that can support up to 48 Fibre Channel ports. Your disk array can support up to 8,192 LDEVs which can be configured as up to 24,576 LUNs through the Fibre Channel. The Fibre Channel provides data transfer rates up to 2GB/sec depending on which Fibre Channel interface option is installed. The disk array can support Fibre Channel Arbitrated Loop (FC-AL) and Fabric Fibre Channel topologies.

HP StorageWorks Disk Array XP1024

The XP1024 supports a maximum of four pairs of channel adapters that can support up to 64 Fibre Channel ports. Your disk array can support up to 8,192 LDEVs which can be configured as up to 32,768 LUNs through the Fibre Channel. The Fibre Channel provides data transfer rates up to 2GB/sec depending on which Fibre Channel interface option is installed. The disk array can support Fibre Channel Arbitrated Loop (FC-AL) and Fabric Fibre Channel topologies.

14 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

ESCON connectivity

FICON connectivity

HP StorageWorks Disk Array XP128

The XP128 supports a maximum of three pairs of channel adapters that can support 24 ESCON ports for connection to mainframe hosts. The disk array can support up to 8,192 LDEVs.

HP StorageWorks Disk Array XP1024

The XP1024 supports a maximum of six pairs of channel adapters that can support 48 ESCON ports for connection to mainframe hosts. The disk array can support up to 8,192 LDEVs.

Note: When more than four pairs of ESCON channel adapters are configured, the number of disk drives that can be installed is reduced. Other restrictions may apply, depending on what other types of channel adapters are installed.

HP StorageWorks Disk Array XP128

The XP128 supports a maximum of three pairs of channel adapters that can support up to 24 FICON ports. The disk array can support up to 8,192 LDEVs.

HP StorageWorks Disk Array XP1024

The XP1024 supports a maximum of four pairs of channel adapters that can support up to 32 FICON ports. The disk array can support up to 8,192 LDEVs.

Overview 15

iSCSI connectivity

HP StorageWorks Disk Array XP128

The XP128 supports a maximum of three pairs of channel adapters that can support up to 24 iSCSI ports. The disk array can support up to 6,144 LDEVs through iSCSI.

HP StorageWorks Disk Array XP1024

The XP1024 supports a maximum of four pairs of channel adapters that can support up to 32 iSCSI ports. Your disk array can support up to 8,192 LDEVs through iSCSI.

16 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Data integrity

HP disk arrays provide the highest levels of data integrity. This is accomplished using RAID technologies, together with redundant hardware throughout the disk array. The following hardware features allow the HP StorageWorks Disk Array XP family to achieve its high availability and data integrity:

•RAID1, RAID5

• Mirrored write cache

• Dual channel adapters (CHAs) and array control processors (ACPs)

• Dual and concurrently active data and control paths through the array

• Split power domains on internal data paths

• Hot-pluggable boards

• Hot-pluggable fans, power supplies, and controllers

• Online upgradable firmware

Overview 17

Some of the available software features and products that complement the disk array hardware are listed below:

• HP StorageWorks Disk Array XP128 support “Phone Home” capability to the multidisciplinary Storage Technology

Center advanced remote diagnostics full solution (Host-SAN-Storage) support

• Full software and solution integration local and remote mirroring for online backup and disaster recovery

(HP StorageWorks Business Copy XP and Continuous Access XP) security for multiple server consolidation (HP StorageWorks LUN

Configuration and Security Manager XP) zero downtime backup (HP OmniBack, Exchange, Oracle, or SAP) centralized resource management (HP StorageWorks Remote Web

Console XP, HP StorageWorks Command View XP, HP StorageWorks SAN Manager LM/DM, Performance Advisor XP and Auto LUN XP)

• I/O path failover and load balancing (HP StorageWorks AutoPath XP).To obtain updates to the software, go to the following main web site and access the appropriate support product:

http://www.hp.com

18 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Summary of features

Table 2. XP128 and XP1024 Features

Feature XP128 XP1024

with XP1024 & XP512 DKU Support

Power Single-phase or

3-phase

DKC/DKU Single cabinet unit

only (no expansion)

One DKC with either: 1 or 2 XP1024 DKUs, and

XP1024 XP1024 DKU Support

Single-phase or 3-phase

One DKC cabinet with 1 to 4 XP1024 DKU cabinets

1 to 3 XP512 DKUs

Maximum hard disk

128 768 1024

drives

Maximum spare disk

4 16 16

drives

Maximum parity

31 191 255

groups/subsystem

Maximum Disk Drive

36 TB 121 TB 149 TB

Capacity

Max. cache 64 GB 128 GB 128 GB

(continued)

Overview 19

Table 2. XP128 and XP1024 Features (Continued)

Feature XP128 XP1024

with XP1024 & XP512 DKU Support

Available hard disk drives

73GB 10K rpm Fibre Channel disk drive

36GB 15K rpm Fibre Channel disk drive

73GB 15K rpm Fibre Channel disk drive

146GB 10K rpm Fibre Channel disk drive

300GB 10K rpm Fibre Channel disk drive

73GB 10K rpm Fibre Channel disk drive

47GB 10K rpm Fibre Channel disk drive1

18GB 10K rpm Fibre Channel disk drive1

18GB 15K rpm Fibre Channel disk drive1

181GB 7200 rpm Fibre Channel disk drive1

36GB 15K rpm Fibre Channel disk drive2

XP1024 XP1024 DKU Support

73GB 10K rpm Fibre Channel disk drive

36GB 15K rpm Fibre Channel disk drive

73GB 15K rpm Fibre Channel disk drive

146GB 10K rpm Fibre Channel disk drive

300GB 10K rpm Fibre Channel disk drive

73GB 15K rpm Fibre Channel disk drive2

146GB 10K rpm Fibre Channel disk drive2

300GB 10K rpm Fibre Channel disk drive2

1XP512 DKU Only 2XP1024 DKU Only

Max shared memory 4.0 GB 4.0 GB 4.0 GB

(continued)

20 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Table 2. XP128 and XP1024 Features (Continued)

Feature XP128 XP1024

with XP1024 & XP512 DKU Support

XP1024 XP1024 DKU Support

Max ACP pairs 2 4 4

Max CHIP pairs 3

4 4

2 if >1 ACP pair installed

Configuration disk XP128-specific XP1024-specific XP1024-specific

SVP code XP128-specific XP1024-specific XP1024-specific

High Availability SVP Optionally Available Optionally Available Optionally Available RAID level RAID 1 (2D+2D)

RAID 1 (4D+4D) RAID 5 (3D+1P) RAID 5 (7D+1P)

RAID 1 (2D+2D) RAID 1 (4D+4D)* RAID 5 (3D+1P) RAID 5 (7D+1P)*

RAID 1 (2D+2D) RAID 1 (4D+4D) RAID 5 (3D+1P) RAID 5 (7D+1P)

Maximum LDEV # 8192 8192 8192

Available LUNs 24,576 32,768 32,768

Maximum LU #/port 512 512 512

*XP1024 DKU supported only.

Overview 21

22 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

XP128 hardware

XP128 hardware 23

General safety guidelines

Read the following safety guidelines carefully and follow them when you work with the HP StorageWorks Disk Array XP128 disk array.

• Remember that the maintenance of your machine must be done only by trained and qualified HP field engineers. Only an HP service representative can power off the disk array in a non-emergency situation.

• Please read and follow the safety guidelines and procedures in this manual and you other disk array manuals.

• In this manual and on the machine, hazard warnings are provided to aid you in preventing or reducing the risk of death, personal injury, or product damage. Understand and follow these hazard warnings fully.

• The hazard warnings that appear on the warning labels on the machine or in the manual have one of the following alert headings consisting of an alert symbol and a signal word, “Warning,” or “Caution”:

Warning

This indicates a potentially hazardous situation which, if not avoided, can result in death or serious injury.

Caution This indicates a hazardous situation which, if not avoided, will or can result

in serious damage to the product or loss of data.

• The signal word “NOTICE” is used to present warnings that are not directly related to personal injury hazards.

• When warning labels become dirty or start peeling off, replace them.

• If any physical accident such as abnormal noise, smell, or smoke occurs on the disk array while it is running, immediately power off the disk array by pulling the UNIT EMERGENCY POWER OFF switch on the disk array.

24 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

• Do not power off the system unless it is an emergency power-off situation.

• Keep the front and rear doors closed at all times.

• Keep the tops and sides of the cabinets clear to allow air to flow properly.

• Do not perform any procedures not described in this document. If you have any questions or concerns, please contact your HP service representative.

Warning

Do not touch areas marked HAZARDOUS, even with the power off. These areas contain high-voltage power.

Keep in mind that the hazard warnings in this manual or on the machine cannot cover every possible case, as it is impossible to predict and evaluate all circumstances before hand.

Follow the procedures in this guide carefully and always be alert for any unusual equipment indications or behavior. If you have any questions, contact your HP service representative.

XP128 hardware 25

Physical components

The HP StorageWorks Disk Array XP128 is a high-performance disk array system. It is used to store large quantities of data in an efficient and secure manner.

Figure 1. HP StorageWorks Disk Array XP128

Your disk array has the following major hardware components:

• Disk array cabinet The single disk array frame cabinet contains the control panel,

connection hardware, the service processor, control boards and hard disk drives.

• One service processor (SVP) The service processor (SVP) is a built-in PC inside the disk array

cabinet. The SVP gives your HP service representative a method of accessing the software system on the disk array.

Your HP service representative uses the SVP to configure, maintain, and upgrade your disk array software and hardware. The service

26 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

processor also collects performance data about the disk array for diagnostic testing and analysis.

To ensure data security, the SVP does not have access to any user data stored on the disk array.

•(Optional) second service processor

This is available for users with extreme high availability requirements. This is not a required feature.

• Control panel The control panel is your view of the disk array. Once the disk array is

powered on and running normally, there are no user operations required at the control panel, except in the case of a power failure recovery. The control panel is discussed in further detail on

page 29.

• Hard disk drives The disk array uses 3.5-inch disk drives, and different disk capacities

are available. Ask your HP service representative about currently available disk drives or visit the XP128 web site at

http://www.hp.com. Any of the disk drives in the disk array frames can

be replaced without disrupting user activity. The disk array automatically detects and corrects disk errors.

•(Optional) Device Manager server The Device Manager server is attached to your disk array by a local

area network (LAN) connection. The Device Manager server runs HP Command View XP and/or Command View XP Advanced Edition which, combined with other optional applications, allows you to monitor and manage disk array operations.

The following figure illustrates how the Device Manager server and host connect to the XP128.

XP128 hardware 27

Device Manager server

XP128 Disk Array

Host

Figure 2. The XP128 connections

1. The management station connects to the XP128 by means of a public LAN connection. The XP128 has an Ethernet connection for this purpose.

2. The host server uses a Fibre Channel, FICON, iSCSI, or ESCON connection.

The hardware requirements for your Device Manager server, such as the required processor speed, storage capacity, and memory, will vary depending on the optional software that you use and the number of disk array frames you have connected to the system.

To ensure data security, neither edition of HP Command View software (CVXP or CVXP AE) has access to any user data stored on the disk array.

There is no single point of failure in the disk array. It is designed with redundant logic assemblies, disk drives and power supplies, all of which can be removed or replaced without interrupting access to your data.

Caution Only your HP service representative can remove or replace hardware.

28 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Control panel

Figure 3 and Table 3 on page 30 show the control panel and its functions,

respectively.

SUB-SYSTEM

READY

ALARM

MESSAGE

STORAGE CLUSTER 1

U L

STORAGE CLUSTER 2

U L

BS-ON

PS-ON

RESTART

POWER SW

ENABLE

EMERGENCY

UNIT EMERGENCY POWER OFF

REMOTE

MAINTENANC PROCESSING

ENABLE

DISABLE

CA B

QN P

CA B

QN P

HGE F

MLJ K

HGE F

MLJ K

OFF

POWER

REMOTE

LOCAL

LED TEST

CHK RST

Figure 3. Control Panel

XP128 hardware 29

Table 3. Control or indicator function on control panel

Item Label Indicator Description

1 SUBSYSTEM READY LED

(Green)

2 SUBSYSTEM ALARM LED

(Red)

3 SUBSYSTEM

MESSAGE

LED (Amber)

Indicates that channel interface input/output operations are enabled. If the LED is off, the system is not accepting data.

Indicates DC under voltage, DC over current, abnormally high temperature, or an unrecoverable failure. If your disk array is set up to report messages to the remote center, your HP service representative is notified automatically. If the disk array is not set up to report messages to the remote center, you should place a service call to HP to have the message evaluated to determine if any action is required.

ON: Indicates that a message has been issued from either cluster. If your disk array is set up to report messages to the remote center, your HP service representative is notified automatically. If your disk array is not set up to report messages to the remote center, you should place a service call to HP to have the message evaluated to determine if any action is required.

Blinking: Indicates the internal service processor has failed. The disk array will continue to operate normally. You should place a service call to HP to ensure notification. Service processor failures might not be reported automatically to the remote center.

4 SUBSYSTEM

RESTART

Switch Used to unfence the fenced drive path and to release

Write Inhibit. There is a blocked path somewhere between a host and a disk drive. By restarting the subsystem, a soft reset will be performed to try to recover. If system restart does not unblock the path, an HP service representative will be notified.

30 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Table 3. Control or indicator function on control panel (Continued)

Item Label Indicator Description

5 REMOTE

MAINTENANCE PROCESSING

6 REMOTE

MAINTENANCE ENABLE/DISABLE

7 STORAGE CLUSTER 1

CHANNEL A-M

U: UPPER

L: LOWER

LED (Amber)

Indicates remote maintenance activity. An HP service representative is checking your system, but the system is online and accepting data.

Switch Used to permit remote service maintenance.

Disable: Enable:

No one can provide maintenance

HP service representative can provide

maintenance.

LED

Serial Channel/Fibre Channel:

(Green)

(1) On: Indicates some of the logical paths are established.

(2) Fast blinking: Indicates the corresponding channel route is executing the channel command. (Only Serial Channel)

(3) Slow blinking: Indicates none of the logical paths are established.

(4) Off: Indicates the corresponding channel route is not enabled.

XP128 hardware 31

Table 3. Control or indicator function on control panel (Continued)

Item Label Indicator Description

8 STORAGE CLUSTER 2

LED (Green)

CHANNEL A-M

U: UPPER

L: LOWER

9 BS ON LED

(Yellow)

10 PS ON LED

(Green)

Serial Channel/Fibre Channel:

(1) On: Indicates some of the logical paths are established.

(2) Fast blinking: Indicates the corresponding channel route is executing the channel command. (Only Serial Channel)

(3) Slow blinking: Indicates none of the logical paths are established.

(4) Off: Indicates the corresponding channel route is not enabled.

When the LED is on, unit is plugged in and receiving power from either AC power source. The SVP is receiving power from the outlet.

If BS is off, the disk array is not receiving power from either AC power source. Check the electrical outlets in your building.

When the LED is on power is on and the array is ready to process data.

Off means the disk array power is off. The disk array is not ready to process data.

32 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Table 3. Control or indicator function on control panel (Continued)

Item Label Indicator Description

11 PWR SW ENABLE Switch Used to enable the PWR on/off switch. To enable the

PWR on/off switch, turn the PWR SW ENABLE switch to the ENABLE position. If the automatic power on restart feature is not being used, this switch should be in the DISABLE (opposite of ENABLE) position during normal operation.

12 PWR ON/PWR OFF Switch To switch on/off the subsystem, use this switch while

the PWR SW ENABLE switch is in the ENABLE position. This switch only performs this function when the REMOTE/LOCAL switch is set to the LOCAL position.This switch should be in the PWR ON position during normal operation. The position of this switch should only be changed when directed by HP service personnel.

13 EMERGENCY POWER

OFF

14 PWR ON/PWR OFF

REMOTE/LOCAL

15 LED TEST/CHK

RESET

Switch Used to power off the storage subsystem in an

emergency situation.

Switch Determines how the disk array is powered on or off.

REMOTE: Disk array power on/off is controlled by the power control interface to the CPU (mainframe only).

LOCAL: Disk array power on/off is controlled by the PWR ON/PWR OFF switch,

Switch LED TEST position: The LEDs on the panel go on.

CHK RESET position: The PS ALARM and TH ALARMS are reset.

XP128 hardware 33

Emergency power-off

A switch is provided on the control panel for an emergency powering off. See Figure 4 on page 35.

If you detect an abnormal sound, smell, or smoke, power off the disk subsystem by operating the UNIT EMERGENCY POWER OFF switch following the procedure below. The procedure for operating the switch is as follows:

1. Push the operator panel cover at the location where PUSH is marked, open the operator panel cover, then operate the EMERGENCY POWER OFF switch.

2. In using a UNIT EMERGENCY POWER OFF switch, first pull it up and then pull it toward you as illustrated in the figure below.

Caution Pulling the UNIT EMERGENCY POWER OFF switch on the disk array

cabinet instantly shuts down the array, neglecting the system’s power-off sequence. Jobs in process are aborted and their integrity after recovery is not guaranteed. Therefore, this method should be used only in an emergency and not in normal operation.

Caution The UNIT EMERGENCY POWER OFF switch on the disk array cabinet

only partially removes power from the array. AC input power remains present at the primary circuit. Therefore, do not use the Emergency Power-Off switch unless you need to power off of the unit as an emergency measure.

When pulled, a UNIT EMERGENCY POWER OFF switch locks itself to prevent further powering on and requires a trained and qualified HP field engineer for recovery. Any time the unit Emergency/Only OFF switch is pulled, place a service call to Hewlett-Packard to have the switch reset and have the disk array restored to service.

34 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Figure 4. Pulling Unit Emergency Power OFF Switch

XP128 hardware 35

Normal operations

The disk array does not require user intervention. The disk array automatically reports any remote system information messages (R-SIMs) to your Device Manager server running HP Command View XP or Command View XP Advanced Edition, to the internal disk array service processor, and also to the HP Service Center. For more information on SIMs, see Chapter 5, "Troubleshooting" on page 87.

36 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Powering down the disk array

Situations may arise in the operation of the disk array that require you to power down the disk array. These situations include:

• Emergency power-off

• Planned power-off

Emergency power-off

An emergency is a critical situation such as a physical plant catastrophe. In an emergency, the critical need is to quickly remove power from the disk array. A quick restart is not necessary.

In an emergency, the operator should trip the Emergency Power-Off (EPO) switch. The disk array emergency power-off (EPO) switch is located on the control panel.

Caution Use this switch only in case of an emergency. An HP service representative

is required to reset the EPO and to power-on the disk array.

To power off the disk array in an emergency:

1. Open the control panel cover by pushing on the point marked PUSH.

2. Pull the emergency power-off switch up and then out towards you as illustrated on the switch. See

3. Call the HP support center. The EPO switch must be reset by an HP service representative before the disk array can be powered on again.

Figure 4 on page 35.

Planned power-off

There may be times when a site power outage is planned. These situations would include alterations to the data center, inspections, or work by the electric company. If a scheduled power outage affects an HP StorageWorks Disk Array XP128, the power down of the disk array must be scheduled with a trained HP support representative.

XP128 hardware 37

Caution Only a trained HP representative can shut down and power-off a disk

array. Shutting down and powering off a disk array is not a customer activity. A user should not attempt to power down the disk array at any time other than an emergency.

When planning for your planned power outage, please contact your HP CE to schedule a customer visit.

38 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Recovering from a power outage to the disk array

If AC input power is lost, the disk array maintains its state and recovers when power is restored. The array cache is backed up by batteries that will maintain its state for a minimum of 48 hours. This length of time will provide coverage for most outages. In cases where the outage will extend beyond 48 hours, the batteries can be replaced by a HP to extend the time, if necessary. To extend the backup time beyond 48 hours, you must notify HP support in time to receive service.

Manual restart of the disk array after power is restored

Caution Before you restore power to the disk array after an outage, HP recommends

you have an electrician check the power to ensure it is stable and clean.

You may opt to call a trained HP representative or you may restore power to the disk array yourself:

1. Move the ENABLE/DISABLE switch to the ENABLE position. Move the PWR ON/OFF switch to the PWR ON position ( items 11 & 12)

Figure 3 on page 29,

2. The following LED sequence will occur: The BS-ON LED (Figure 3 on page 29, item 9) will turn amber and

the PS ON LED (10, Figure 3 on page 29, item 10) will turn green. The CHANNEL LED (Figure 3 on page 29, item 7) will light green

for every adapter installed. The MESSAGE LED (Figure 3 on page 29, item 3) may turn amber if

your disk array is not configured for automatic maintenance notification, signifying a SIM was generated (because the disk array went down unexpectedly).

Finally, the Ready LED (Figure 3 on page 29, item 1) will light green when the system is ready, which may take up to 10 minutes, depending on the number of disks installed in your disk array.

3. Move the ENABLE/DISABLE switch to the DISABLE position.

XP128 hardware 39

Automatic power on restart

Caution As with all sophisticated electronic equipment, unstable power during a

restart can induce problems. Hewlett-Packard recommends automatic power on restart only when the power to the disk array is conditioned to ensure stability (for example, using a UPS). If your site does not have a UPS, HP recommends configuring the disk array for manual restart by keeping the ENABLE/DISABLE switch in the DISABLE position and using the manual restart procedure when power has been restored and verified.

Your disk array will automatically restart and return to service when power is restored. To enable this feature, place the ENABLE/DISABLE switch in the ENABLE position and the PWR ON/OFF switch in the PWR ON position (Figure 3 on page 29, items 11 & 12). When power is restored, your disk array will restart and the following LED sequence will occur:

The BS-ON LED (Figure 3 on page 29, item 9) will turn amber and the PS ON LED (10, Figure 3 on page 29, item 10) will turn green.

The CHANNEL LED (Figure 3 on page 29, item 7) will light green for every adapter installed.

The MESSAGE LED (Figure 3 on page 29, item 3) may turn amber if your disk array is not configured for automatic maintenance notification, signifying a SIM was generated (because the disk array went down unexpectedly).

Finally, the Ready LED (Figure 3 on page 29, item 1) will light green when the system is ready, which may take up to 10 minutes, depending on the number of disks installed in your disk array.

40 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Specifications

Temperature

Some of the HP StorageWorks Disk Array XP128 disk array specifications are listed in this section. For a complete set of environmental specifications, refer to the web site and access the appropriate support product:

Table 4. Temperature Specifications

Temperature Specification (Degrees F = 1.8 x Degrees C + 32)

HP Disk Array XP128 Site Prep Guide on the following main

http://www.hp.com

Humidity

Nonoperating temperature Range Operating Temperature Recommended Operating Temperature Range Shipping and storage temperature Temperature Shock Immunity—Maximum rate of

change Over-Temperature shutdown

Table 5. Humidity Specifications

Humidity Specification

Nonoperating/storage Humidity Range 8% to 90% RH Operating Humidity Range at 22 Recommended Operating Humidity Range at 22 Procedure for recovery from moisture condensation None

° C

–10

° to +43° C

° to + 32° C

+16

° to +24° C

+21

° to 60° C

–25

° C per hour

Shutdown at 60

20% to 80 % RH 50% to 55 % RH

° C

XP128 hardware 41

Mechanical vibration

Table 6. Mechanical vibration

Mechanical vibration

AC line voltage

Maximum Operating

0.05G at a frequency range of 10 to 300 Hz

Acceleration

The following AC power recommendations for the HP StorageWorks Disk Array XP128 are for each power cord. Each array frame has two power cords (with the AC power cord option there are four cords). In case of a failure of the power source for one cord, the power requirements and the current requirement for the remaining power cord will double.

Table 7 (page 42) lists the basic AC power requirements for a 50-amp

single-phase XP128 DKU. Table 8 (page 43) lists the basic AC power requirements for a 30-amp single-phase XP128 DKU.

Table 7. 50-Amp, 50 or 60 Hz, Single-Phase DKU Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per

200 208* 220 230 240

16.2 15.1 14.9 14.3 13.8

power cord (Arms) Number of power cords22222 Number of circuit

22222

breakers

50A 50A 50A 50A 50A

Recommended circuit breakers

* 60 Hz only.

42 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Table 8. 30-Amp, 50 or 60 Hz, Single-Phase DKC Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per

200 208* 220 230 240

10.2 9.5 9.4 9.0 8.7

power cord (Arms) Number of power cords 4 4 4 4 4 Number of circuit breakers 4 4 4 4 4

30A 30A 30A 30A 30A

Recommended circuit breakers

* 60 Hz only.

Table 9 (page 43) lists the basic AC power requirements for three-phase

operation of the XP128 DKC.

Table 9. 30-Amp, 50 or 60 Hz, Three-Phase DKU Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per

200 208*220 230 240 380 400 415

11.1 10.7 10.0 9.6 9.1 6.0 5.5 5.3

power cord (Arms) Number of power

2 2 2 2 2 2 2 2

cords Number of circuit

2 2 2 2 2 2 2 2

breakers Recommended

30 A 30 A 30 A 30 A 30 A 30 A 30 A 30 A

circuit breakers

* 60 Hz only.

XP128 hardware 43

Web site

For the most current support information on the HP StorageWorks Disk Array XP128, please visit the following main web site and access the appropriate support product:

http://www.hp.com

44 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

XP1024 hardware

XP1024 hardware 45

General safety guidelines

Read the following safety guidelines carefully and follow them when you work with your XP1024 disk array.

• Remember that maintenance of your machine must be done only by trained and qualified HP field engineers. Only an HP service representative can power off the disk array.

• Please read and follow the safety guidelines and procedures in this manual and any of your related manuals.

• The hazard warnings that appear on the warning labels on the machine or in the manual have one of the following alert headings consisting of an alert symbol and a signal word, “

Warning

This indicates a potentially hazardous situation which, if not avoided, can result in death or serious injury.

Warning,” or “Caution”:

Caution This indicates a hazardous situation which, if not avoided, will or can result

in serious damage of product or loss of data.

• The signal word “NOTICE” is used to present warnings that are not directly related to personal injury hazards.

• When warning labels become dirty or start peeling off, replace them.

• If any physical accident such as abnormal noise, smell, or smoke occurs on the disk subsystem while running, immediately power off

46 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

the disk subsystem by pulling the UNIT EMERGENCY POWER OFF switch on the disk subsystem.

• Do not power off the system unless it is in an emergency power-off state.

• Keep the front and rear doors closed at all times.

• Keep the tops and sides of the cabinets clear to allow air to flow properly.

• Do not perform any procedures not described in this document. If you have any questions or concerns, please contact your HP service representative.

Warning

Do not touch areas marked HAZARDOUS, even with the power off. These areas contain high-voltage power.

Keep in mind that the hazard warnings in this manual or on the machine cannot cover every possible case, as it is impossible to predict and evaluate all circumstances before hand.

Be alert and use your common sense. If you have any questions, contact your HP service representative.

XP1024 hardware 47

Physical components

The HP Disk Array XP1024 is a high-performance RAID-capable disk array system. It is used to store large quantities of data in an efficient and secure manner.

Minimum Disk Su bsystem

DKU frame DKU frame DKC DKU frame DKU frame

Figure 5. HP StorageWorks 1024 Disk Array

48 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Minimum Disk Subsystem

DKU frame

(L3)

5th DKU

DKU frame

(L2)

4th DKU

DKU frame

(L1)

3rd DKU

DKC

frame

DKU frame

(R1)

1st DKU

DKU frame

(R2)

2nd DKU

Figure 6. HP Disk Array XP1024 with HP Disk Array XP512 DKUs

The maximum HDD configuration for an XP1024 with XP512 DKUs is

768. This is due to specifications for the 3 XP512 DKUs, which can contain a total of 256 HDDs (96+96+64).

XP1024 hardware 49

The disk array has the following major hardware components:

• One disk control frame (DKC) The single disk control frame cabinet contains the control panel,

connection hardware, the service processor, and control boards for the disk arrays.

• One to four XP1024 disk array frames (DKU) or

• One to two XP1024 disk array frames and one to three XP512 DKU frames.

The DKU cabinets contain your disk drives. When using only XP1024 DKUs, you can connect up to 4 DKUs. When connecting XP512 DKUs to the XP1024 disk array, the

supported configuration is a maximum of 2 XP12024 DKUS on the right, and a maximum of 3 XP512 DKUs on the left.

Warning

XP1024 and XP512 DKUs may not be configured on the same side of the DKC. Only XP1024 DKUs may be installed on the right of the DKC and only XP512 DKUs may be installed on the left of the DKC in configurations that support both types of DKUs.

• One service processor (SVP) The SVP is an internally mounted notebook computer used for

maintenance. The SVP is located in the disk control frame cabinet. The SVP is used by your HP service representative only.

•(Optional) second service processor This is available for users with extreme availability requirements. This

is not a required feature.

50 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Disk control frame

The disk control frame controls your disk array. It provides you with a control panel, power supplies, controller boards, and your service processor. See Figure 7.

Control Panel

Figure 7. Disk Control Frame

There is no single point of failure in the disk array. It is designed with redundant controllers and redundant power supplies, all of which can be removed or replaced without interrupting access to your data. Only your HP service representative can remove or replace hardware.

XP1024 hardware 51

Control panel

Service processor

The control panel is your view to the disk array. Once the disk array is powered on and running normally, there are no user operations required at the control panel, except in case of a power failure recovery. The control panel will be discussed in further detail later in this chapter.

The service processor (SVP) is a built-in PC connected inside the disk control frame. The SVP gives your HP service representative a method to access the software system on the disk array.

Your HP service representative uses the SVP to configure, maintain, and upgrade your disk array software and hardware. The service processor also collects performance data on the disk array for diagnostic testing and analysis.

To protect the user’s security, the SVP does not have access to any user data stored on the disk array.

An optional service processor is available for users with extreme availability requirements. This is not a required feature.

52 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Disk array frames

The disk array frames are where the physical disk drives, the disk groups, and any dynamic spare disk drives are located. You must have at least one disk array frame to operate the system, and you may have up to a maximum of four disk array frames installed on your system. If you have four disk array frames that are fully populated with disk drives, you will have a maximum of 149 TB. You may also have one to two XP1024 disk array frames grouped with one to three XP512 DKU frames.

DKU frame (L2)

Figure 8. XP1024 Disk Array Frames

XP1024 hardware 53

DKU frame (L1)

DKU frame (R1)

DKU frame (R2)

Figure 9. XP1024 and XP512 Disk Array Frames

Available disk drives

The disk array uses 3.5-inch disk drives, and a variety of disk capacities are available. Ask your HP service representative about currently available disk drives. Any of the disk drives in your disk array frames can be replaced without disrupting user activity. The disk array automatically detects and corrects disk errors. All HP Disk Array XP512 disk drives are supported in XP512 DKU frames.

XP512 DKUs can be used in conjunction with the XP1024.

DKU frame

(L3)

5th DKU

DKU frame

(L2)

4th DKU

DKU frame

(L1)

3rd DKU

DKU frame

(R1)

1st DKU

DKU frame

(R2)

2nd DKU

54 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

RAID options

Any of your spare disk drives can back up any other disk drive of the same or lesser capacity (and equal rotational speed), in any DKU frame, even if the failed disk and the spare disk are in different array domains, whether you are using RAID1 or RAID5 array groups.

XP512 DKU Supported disk drives must have a spare drive in the XP512 DKU domain(s).

Your disk arrays can be configured with a minimum of one and a maximum of 16 spare disk drives.

Device Manager server (optional)

The Device Manager server is for user access to the system software. Your Device Manager server runs a main remote control application and other standard and optional software to manage and monitor the disk array. The Device Manager server can be connected to multiple disk arrays using a special LAN connection. See Figure 10. See Table 10 on page 56.

Figure 10. XP1024 Disk Array

XP1024 hardware 55

Table 10. Connections to the XP1024 Disk Array

Callout in figure 10 (page 55)

Connecting Type

1 A DKC to a DKU;

Fibre Channel

A DKU to another DKU

2 The DKC to the server host Fibre Channel

ESCON FICON iSCSI

3 DKC to the Management

LAN

Console

The specific hardware requirements for your Device Manager server, such as the required processor speed, storage capacity, and memory, vary depending on the optional software that you use and the number of disk array frames you have connected to the system.

To protect your user’s security, neither edition of HP Command View software for the Device Manager server (CVXP or CVXP AE) has access to any user data stored on the disk array.

There is no single point of failure in the disk array. It is designed with redundant logic assemblies, disk drives, and the power supplies, all of which can be removed or replaced without interrupting access to your data.

Caution Only your HP service representative can remove or replace hardware.

56 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Control panel

Figure 11 and Table 11 on page 58 show the control panel and its functions,

respectively.

SUB-SYSTEM

READY

ALARM

MESSAGE

STORAGE CLUSTER 1

STORAGE CLUSTER 2

BS-ON

PS-ON

RESTART

POWER SW

ENABLE

EMERGENCY

UNIT

EMERGENCY

POWER OFF

REMOTE

MAINTENANC

PROCESSING

ENABLE

DISABLE

CA B

QN P

CA B

QN P

HGE F

MLJ K

HGE F

MLJ K

OFF

POWER

REMOTE

LOCAL

LED TEST

CHK RST

Figure 11. Control panel

XP1024 hardware 57

Table 11. Control panel functions

Item Label Indicator Description

1 SUBSYSTEM READY LED

(Green)

2 SUBSYSTEM ALARM LED

(Red)

3 SUBSYSTEM

MESSAGE

LED (Amber)

Indicates that input/output operation on the channel interface is enabled. If the LED is off, the system is not accepting data.

Indicates DC under voltage, DC over current, abnormally high temperature, or an unrecoverable failure has occurred. If your disk array is set up to report messages to the remote center, your HP service representative is notified automatically. If your disk array is not setup to report messages to the remote center, you should place a service call to HP to have the message evaluated to determine if any action is required.

ON: Indicates a message has been issued from either Cluster. If your disk array is set up to report messages to the remote center, your HP service representative is notified automatically. If your disk array is not set up to report messages to the remote center, you should place a service call to HP to have the message evaluated to determine if any action is required.

Blinking: Indicates the internal service processor has experienced a failure. The disk array will continue to operate normally.You should place a service call to HP to ensure notification. Service processor failures may not be reported automatically to the remote center.

4 SUBSYSTEM

RESTART

Switch Used to unfence the fenced drive path and to release

5 REMOTE

MAINTENANCE PROCESSING

58 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

LED (Amber)

Indicates remote maintenance is being processed. An HP service representative may be working on your system, but the system is online and accepting data.

Table 11. Control panel functions

Item Label Indicator Description

6 REMOTE

MAINTENANCE ENABLE/DISABLE

7 STORAGE CLUSTER 1

CHANNEL A-R ENABLE

8 STORAGE CLUSTER 2

CHANNEL A-R ENABLE

Switch Used to permit remote service maintenance.

Disable: No one can provide maintenance Enable: HP service representative can provide

maintenance.

LED

Serial Channel/Fibre Channel:

(Green)

(1) On: Indicates some of the logical paths are established.

(2) Fast blinking: Indicates the corresponding channel route is executing the channel command. (Only Serial Channel)

(3) Slow blinking: Indicates none of the logical paths are established.

(4) Off: Indicates the corresponding channel route is not enabled.

LED

Serial Channel/Fibre Channel:

(Green)

(1) On: Indicates some of the logical paths are established.

(2) Fast blinking: Indicates that the corresponding channel route is executing the channel command. (Only Serial Channel)

(3) Slow blinking: Indicates none of the logical paths are established.

(4) Off: Indicates that the corresponding channel route is not enabled.

XP1024 hardware 59

Table 11. Control panel functions

Item Label Indicator Description

9 BS ON LED

(Yellow)

When the LED is on, unit is plugged in and receiving power from the primary AC outlet. The SVP is receiving power from the outlet.

If BS is off, then the disk array is not receiving power from the primary AC outlet. Check the electrical outlets in your building.

10 PS ON LED

(Green)

When the LED is on power switch is on, the array is ready to receive data.

Off means the power switch is off; the disk array is not powered on and is not ready to receive data.

11 PWR SW ENABLE Switch Used to enable the PWR on/off switch. To enable the

12 PWR ON/PWR OFF Switch To switch on/off the subsystem, use this switch while

turning the PWR SW ENABLE switch is in the ENABLE position. This switch only performs this function when the REMOTE/LOCAL switch is set to the LOCAL position.This switch should be in the PWR ON position during normal operation. The position of this switch should only be changed when directed by HP service personnel.

13 EMERGENCY POWER

OFF

60 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Switch Used to power off the storage subsystem in an

emergency situation.

Table 11. Control panel functions

Item Label Indicator Description

14 PWR ON/PWR OFF

REMOTE/LOCAL

15 LED TEST/CHK

RESET

Switch Determines how the disk array is powered on or off.

REMOTE: Disk array is powered on/off by the instructions of the host power control interface (mainframe only).

LOCAL: Disk array is powered on/off by the PWR ON/PWR OFF switch,

Switch LED TEST position: The LEDs on the panel go on.

CHK RESET position: The PS ALARM and TH ALARMS is reset.

XP1024 hardware 61

Emergency power-off

A switch is provided on the operator panel on the front side of the disk control frame (DKC) for turning power off in an emergency.

If you encounter any abnormality such as an abnormal sound, smell, or smoke, power off the disk subsystem by operating the UNIT EMERGENCY POWER OFF switch following the procedure below. The procedure for operating the switch is as follows:

1. Push the operator panel cover at the location where PUSH is marked, open the operator panel cover, then operate the EMERGENCY POWER OFF switch.

2. In using a UNIT EMERGENCY POWER OFF switch, first pull it up and then pull it toward you as illustrated in the figure below.

Caution Pulling a UNIT EMERGENCY POWER OFF switch on the disk controller

instantly shuts down, neglecting the system’s power-off sequence. Jobs in process are aborted and their integrity after recovery is not guaranteed. Therefore, this method should be used only in an emergency and not in usual maintenance.

Caution The UNIT EMERGENCY POWER OFF switch on the disk controller only

provides partial power-off capability. AC input power remains present at the primary circuit. Therefore, do not use the switches on these units unless you need to power off of the unit as an emergency measure.

When pulled, the UNIT EMERGENCY POWER OFF switch mechanically locks itself in the off position to prevent restoring power in a potentially hazardous situation. A qualified HP service representative is required on site to restore power. Any time the unit Emergency/Only OFF switch is pulled, place a service call to Hewlett-Packard to have the switch reset and have the disk array restored to service.

62 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Figure 12. Pulling Unit Emergency Power OFF Switch

XP1024 hardware 63

Normal operations

The disk array does not require intervention from the user. The disk array reports any remote system information messages (R-SIMs) to your Device Manager server running HP Command View XP or Command View XP Advanced Edition. The internal disk array service processor also sends the report to the HP Service Center automatically. For more information on SIMs, see Chapter 5, "Troubleshooting" on page 87

64 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Powering down the disk array

Situations may arise in the operation of the disk array that require the user to power down the disk array. These situations include:

• Emergency power-off

• Planned power-off

Emergency power-off

An emergency is a critical situation such as a physical plant catastrophe. In an emergency, the critical need is to quickly remove power from the disk array. A quick restart is not necessary.

In an emergency, you should trip the Emergency Power-Off (EPO) switch, which is located on the control panel.

Caution Use this switch only in case of an emergency. An HP service representative

is required to reset the EPO and to power-on the disk array.

To power off the disk array in an emergency:

1. Open the control panel cover by pushing on the point marked PUSH.

2. Pull the emergency power-off switch (Figure 12 on page 63) up and then out towards you as illustrated on the switch.

3. Call the HP support center. The EPO switch must be reset by an HP service representative before the disk array can be powered on again.

XP1024 hardware 65

Planned power-off

Caution Only a trained HP representative may shut-down and power-off a disk

There may be times when a site power outage is planned, such as to make alterations to the data center, do inspections, or to allow work by the electric company. If a scheduled power outage affects an HP Disk Array XP1024, the power down of the disk array must be scheduled with a trained HP support representative.

array. Shutting down and powering off a disk array should not be done by customers except in an emergency.

When planning for your planned power outage, please contact your HP customer engineer to schedule a customer visit.

66 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Recovering from a power outage to the disk array

If a power outage to the array occurs, the disk array will maintain its state and recover when power is restored. The array cache is backed up by batteries that will maintain its state for a minimum of 48 hours. This length of time will provide coverage for most outages. In cases where the outage will extend beyond 48 hours, the batteries can be replaced by an HP CE which will extend the time, if necessary. You must notify HP support if your power outage is expected to extend beyond the backup time.

XP1024 hardware 67

Manual restart of the disk array after power is restored

Caution Before restoring power to the disk array, HP recommends that an

electrician check the input power to ensure it is stable and clean.

You may call a trained HP representative or you may use the following procedure yourself to recover the disk array from a power failure:

1. Move the ENABLE/DISABLE switch to the ENABLE position. Move the PWR ON/OFF switch to the PWR ON position. (

page 57, item 11/12)

2. The following LED power sequence will occur: The BS-ON (Figure 11 on page 57, item 9) will turn amber and the PS

ON LED (Figure 11 on page 57, item 10) will turn green. The CHANNEL LED (Figure 11 on page 57, item 7) will light green

for every adapter installed. The MESSAGE LED (Figure 11 on page 57, item 3) may turn amber,

if your disk array is not configured for automatic maintenance notification, signifying a SIM was generated (because the disk array went down unexpectedly).

Figure 11 on

Finally, the READY LED (Figure 11 on page 57, item 1) will light green signifying the system is ready. Powering on the disk array may take up to 10 minutes, depending on the number of disks installed in the disk array. Power-on is complete only when the READY LED turns green.

3. Move the ENABLE/DISABLE switch to the DISABLE position.

68 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Automatic power on restart

Caution As with all sophisticated electronic equipment, unstable power conditions

during a restart can induce problems. HP recommends automatic power on restart only when power to the disk array is conditioned to ensure it is stable, such as by using a UPS. If your site does not have a UPS, HP recommends the disk array be configured for manual restart by keeping the ENABLE/DISABLE switch in the DISABLE position and using the manual restart procedure when power has been restored and verified.

The disk array will automatically restart and return to service when power is restored. To enable this feature, place the ENABLE/DISABLE switch in the ENABLE position and the PWR ON/OFF switch in the PWR ON position. (Figure 11 on page 57, item 11/12). When power is restored, your disk array will restart and the following LED power sequence will occur:

The BS-ON (Figure 11 on page 57, item 9) will turn amber and the PS ON LED (Figure 11 on page 57, item 10) will turn green.

The CHANNEL LED (Figure 11 on page 57, item 7) will light green for every adapter installed.

The MESSAGE LED (Figure 11 on page 57, item 3) may turn amber, if your disk array is not configured for automatic maintenance notification, signifying a SIM was generated (because the disk array went down unexpectedly).

Finally, the READY LED (Figure 11 on page 57, item 1) will light green when the system is ready, which may take up to 10 minutes, depending on the number of disks installed in the disk array.

XP1024 hardware 69

Specifications

Some of the XP1024 disk array specifications are listed in this section. Refer to the HP Disk Array XP1024 Site Prep Guide on the XP1024 web site at on the following main web site and access the appropriate product for a complete set of XP1024 specifications:

http://www.hp.com

Temperature

Table 12. Temperature Specifications

Temperature Specifications (Degrees F = 1.8 x Degrees C + 32)

Nonoperating/storage Temperature Range Operating Temperature Recommended Operating Temperature Range Shipping and storage temperature Temperature Shock Immunity—Maximum rate of

change Over-Temperature shutdown

Table 13. Humidity Specifications

Humidity Specifications

Nonoperating/storage Humidity Range 5% to 95 % RH Non-operating humidity range 8% to 90% Operating Humidity Range at 22

Recommended Operating Humidity Range at 22

° C

–10

° to +43° C

° to + 32° C

+16

° to +24° C

+21

° to 60° C

–25

° C per hour

Shutdown at 60

20% to 80 % RH 50% to 55 % RH

° C

Procedure for recovery from moisture condensation None

Table 14. Mechanical Vibration Specification

Mechanical Vibration Specifications

Maximum Operating Acceleration

70 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

0.05 G at a frequency range of 10 to 300 Hz

AC line voltage requirements for the HP Disk Array XP1024 (DKC)

Table 15 (page 71) lists the basic AC power requirements for a 40-amp,

single-phase XP1024 DKC.

Table 15. 40-Amp, 50 or 60 Hz, Single-Phase DKC Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per power cord

200 208* 220 230 240

8.0 7.7 7.2 7.0 6.6

(Arms) Number of power cords 22222 Number of circuit breakers 22222 Recommended circuit breakers 40 A 40A 40A 40A 40A * 60 Hz only.

Table 16 (page 71) lists the basic AC power requirements for a 30-amp,

single-phase, XP1024 DKC.

Table 16. 30-Amp, 50 or 60 Hz, Single-Phase DKC Operation

Nominal Rated Voltage (VAC

Parameter

Rated line current per power cord

200 208* 220 230 240

4.0 3.9 3.6 3.5 3.3

(Arms) Number of power cords 44444 Number of circuit breakers 44444 Recommended circuit breakers 30 A 30 A 30 A 30 A 30 A * 60 Hz only.

XP1024 hardware 71

Table 17 (page 72) lists the basic AC power requirements for a 30-amp,

three-phase XP1024 DKC.

Table 17. 30-Amp, 50 or 60 Hz, Three-Phase DKC Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per power cord (Arms)

Number of power cords

Number of circuit breakers

Recommended circuit breakers

* 60 Hz only.

200 2081220 230 240 380 400 415

5.2 5.0 4.7 4.6 4.3 2.7 2.6 2.5

22222222

30 A 30 A 30 A 30 A 30 A 30 A 30 A 30 A

72 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

AC line voltage requirements for the HP Disk Array XP1024 (DKU)

Table 18 (page 73) lists the basic AC power requirements for a 50-amp,

single-phase, XP1024 DKU.

Table 18. 50-Amp, 50 or 60 Hz, Single-Phase DKU Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per power cord

200 208* 220 230 240

22.3 21.6 20.3 19.4 18.6

(Arms) Number of power cords 22222 Number of circuit breakers 22222 Recommended circuit breakers 50 A 50 A 50 A 50 A 50 A * 60 Hz only.

Table 19 (page 73) lists the basic AC power requirements for a 30-amp,

single-phase XP1024 DKU.

Table 19. 30-Amp, 50 or 60 Hz, Single-Phase DKU Operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per power cord

200 208* 220 230 240

13.5 13.0 12.3 11.7 11.2

(Arms) Number of power cords 44444 Number of circuit breakers 44444 Recommended circuit breakers 30 A 30 A 30 A 30 A 30 A * 60 Hz only.

XP1024 hardware 73

Table 20 (page 74) lists the basic AC power requirements for a 60-amp,

three-phase XP1024 R1 DKU.

Table 20. 60-Amp, 50 or 60 Hz, three-phase R1 DKU operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per

200 2081220 230 240 380 400 415

19.0 18.2 17.2 16.6 15.7 10.7 10.2 9.8

power cord (Arms) Number of power

22222222

cords Number of circuit

22222222

breakers Recommended

circuit breakers

1. 60 Hz only.

2. 30-amp breakers ar e adequate at 380, 400 , and 415 VAC, because the current drawn at these voltages is considerably less than at the lower voltages.

60 A 60 A 60 A 60 A 60 A 30 A

min

30 A min

Table 21 (page 74) lists the basic AC power requirements for 60-amp,

three-phase, R2, L1, and L2 XP1024 DKUs. Unlike the first DKU (R1), DKUs R2, L1, and L2 do not provide AC power to the DKC.

Table 21. 60-Amp, 50 or 60 Hz, three-phase, R2, L1, and L2 DKU operation

Nominal Rated Voltage (VAC)

Parameter

200 2081220 230 240 380 400 415

Rated line current per

19.0 18.2 17.2 16.6 15.7 10.7 10.2 9.8

power cord (Arms) Number of power

22222222

cords Number of circuit

22222222

breakers Recommended

circuit breakers

1. 60 Hz only.

2. 30-amp breakers are adeq uate at 380, 400, a nd 415 VAC, because the current drawn at these voltages is considerably less than at the lower voltages.

74 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

60 A 60 A 60 A 60 A 60 A 30 A

min

30 A min

Table 22 (page 75) lists the basic AC power requirements for a 30-amp,

three-phase XP1024 DKU.

Table 22. 30-Amp, 50 or 60 Hz, three-phase DKU operation

Nominal Rated Voltage (VAC)

Parameter

Rated line current per

200 208* 220 230 240 380 400 415

15.0 14.4 13.6 13.0 12.5 8.8 8.4 8.1

power cord (Arms) Number of power

22222222

cords Number of circuit

22222222

breakers Recommended

30 A 30 A 30 A 30 A 30 A 30 A 30 A 30 A

circuit breakers

* 60 Hz only.

If you intend to use HP Disk Array XP512 DKUs with your HP XP1024 Disk Array, see the

Guide

for power requirements information for these DKUs.

HP StorageWorks Disk Array XP512 Site Preparation

XP1024 hardware 75

76 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Optional software products

Several optional HP software packages are available to increase your data accessibility and enable continuous access to user data on the disk array. This chapter describes how these optional software applications can help you run your disk array system.

Before installing the optional software packages, refer to the package’s manual to verify equipment requirements.

Optional software products 77

XP array management

HP StorageWorks XP Remote Web Console and Command View Advanced Edition (AE)

Remote Web Console (RWC) is the standard management software package for the XP disk array. It provides a web-based interface for managing one disk array and is built into the SVP. To access RWC, you open a browser and enter the IP address of the SVP.

RWC allows you to install and manage the disk array but does not allow you to manage multiple arrays. To manage multiple XP disk arrays, install the Command View XP Advanced Edition optional software.

Command View XP Advanced Edition (CVXP AE) provides a browser-based common management platform from which you can manage the XP family of disk arrays. CVXP AE installs on a Device Manager server that you provide and from there can manage multiple XP arrays-even globally distributed arrays.

Remote Web Console XP and/or Command View XP Advanced Edition provide:

• Web-browser based GUI interface

• Visual representation and management of host and storage resources

• Common user interface for launching XP management applications

• Security through authentication, authorization, and encryption

• Event level integration into the leading network and system management solutions such as OpenView Network Node Manager, CA Unicenter TNG, Tivoli, and BMC Patrol

78 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Storage management and LUN security

HP StorageWorks LUN Configuration and Security Manager XP

LUN Configuration Manager comes with three applications that are executed from Remote Web Console XP or StorageWorks Command View XP.

LUN Configuration Manager enables:

• LUN creation and port assignment

• consolidation of LUNs (up to 36 LUNs can be combined)

• creation of small size LUNs to accommodate data place in cache

Security Manager establishes security at the LUN level, allowing you to enable secure multiple server connectivity to the disk array. Secure Manager XP enables the disk array to hide LUNs assigned to one server from other servers.

Optional software products 79

Remote and local data replication

Continuous Access XP, Continuous Access Extension XP, and Business Copy XP are valuable tools for creating copies of data for testing, backup, and disaster recovery.

HP StorageWorks Continuous Access XP

Continuous Access allows you to make ongoing synchronous copies of disk array data to a remote site 27 miles (43 kilometers) away.

HP StorageWorks Continuous Access Extension XP

Continuous Access Extension XP is similar to Continuous Access XP, but operating in asynchronous mode. This can produce increased performance in remote copying. Copy operations are sequenced-stamped to ensure they are executed and sorted correctly at the remote disk array.

You must purchase Continuous Access Extension as an upgrade if you are currently using the Continuous Access XP in synchronous mode, but would prefer to use asynchronous mode.

HP StorageWorks Business Copy XP

Business Copy allows you to make up to nine ongoing copies of data. These copies are maintained on the local disk array. Use Business Copy for non-production activities such as backup, batching, and system testing.

80 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Failover and load balancing

HP StorageWorks Auto Path XP

Using Auto Path XP, you can enable Windows NT server I/O path failover and load balancing control for dual path connections. You can configure up to eight multiple paths per LUN that will provide automatic and transparent failover in the event of path failure. You can also enable dynamic, multi-path load balancing to prevent overloaded I/O operations.

HP StorageWorks Secure Path

HP StorageWorks Secure Path is a family of high availability multi-pathing software products providing continuous data access from the disk array to host servers running Windows Server 2003, Windows 2000, Windows NT, Linux, Sun Solaris, Novell NetWare, IBM AIX, and HP-UX.

Redundant hardware, advanced RAID technology and Secure Path’s automated failover capability enhance fault tolerance and availability. Secure Path effectively eliminates controllers, disk drives, interconnect hardware and host bus adapters as single points of failure. Secure Path:

• Ensures increased business efficiency by maintaining high availability of business critical data and by simplifying the task of path management.

• Monitors path status, and in the case of a path failure, automatically re-routes data to an alternate path.

• Allows easy path management from a single application with graphical displays and task automation.

Optional software products 81

Performance management

HP StorageWorks Cache LUN XP

Cache LUN XP enables you to reserve disk array cache memory for storing high-use data, greatly increasing access speed to that data.

HP StorageWorks Auto LUN XP

Auto LUN XP provides monitoring and disk usage analysis for your disk array based on user thresholds. Auto LUN develops a plan to migrate impacted data volumes to lower usage LUNs, using the data acquired during monitoring. You can perform the migration manually or automatically.

HP StorageWorks Performance Advisor XP

HP StorageWorks Performance Advisor XP is an Internet application used to monitor real-time performance of the HP StorageWorks XP family of disk array products. Using a simple, browser-based interface, you can quickly customize performance data collection and set performance alarms. Performance Advisor provides real-time and historical data on:

• LDEV I/Os

• front-end and back-end port utilization

• internal bus utilization

• cache usage

You can easily integrate with VantagePoint’s DSI log and user PerfView to view your performance metrics.

82 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

HP StorageWorks Application Policy Manager XP

HP StorageWorks Application Policy Manager XP is a performance allocation and management tool for XP disk arrays. It lets you allocate storage performance resources to hosts by means of policies you define.

It ensures that critical business processes have all the XP disk array performance they need to meet business objectives. You can ensure that processes such as backups and data warehouse loads get the array bandwidth necessary to meet deadlines. Application Policy Manager enables sophisticated service provider solutions based on distinct levels of service.

Application Policy Manager has a rich feature set for flexible policy definition, scheduling, monitoring, and analysis.

Optional software products 83

Network management products

HP OpenView SPI for XP Disk Arrays

HP OpenView SPI for XP Disk Arrays establishes an agent that monitors XP disk arrays, provides a correlation of events on the disk arrays, and then forwards those events to the OpenView Operations management console.

HP OpenView SPI for HP storage devices

The OpenView SPI solutions enable integration of the XP disk array infrastructure into the OpenView Operations and OpenView Service Navigator, providing you with the ability to integrate storage into your service level agreements. These solutions perform the following functions:

• Intercept and filter over 1,000 events from the XP disk array

• Show associations and dependencies existing between XP components

• Isolate root causes of failures and predict results

• Enable management of globally distributed XP disk arrays from the OpenView management console

84 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Mainframe solutions

HP StorageWorks Resource Manager XP

HP StorageWorks Resource Manager XP allows you to share data stored on the disk array with mainframe systems and open system servers. This can reduce and optimize your storage maintenance and management overhead.

HP StorageWorks Resource Manager XP allows an XP array to connect to a mainframe system via an ESCON link.

HP StorageWorks Data Exchange XP

Data Exchange XP provides high-speed bidirectional data sharing between mainframe systems and open systems. File translations are provided through a file conversion utility.

Together, these products can free your network of host-to-host data conversion traffic.

Optional software products 85

86 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Troubleshooting

This chapter explains the monitoring and reporting capabilities and the flow of troubleshooting used on the HP StorageWorks Disk Array family of disk arrays.

Troubleshooting 87

Monitoring and reporting

The disk array generates service information messages (SIMs) to identify normal operations, service requirements, and failures. SIMs can be generated on the disk array by the CHIP (Client Host Interface Processor) and ACP (Array Control Processor) microprocessors and by the internal service processor (SVP). Your HP service representative will use the SIMs to monitor and troubleshoot your disk array.

88 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Troubleshooting flow diagram

When the system encounters trouble, it will report the trouble to the HP Storage Technology Center.

If a failure occurs in the disk array, it is detected and reported to the system log, the SIM log, and the HP Storage Technology Center. Figure 13 is a flow diagram that explains the progress of error detection and reporting.

1. A failure is detected in your disk array.

2. The failure is reported to the system.

3. The system stores the failure information in the system log. The generated SIMs are stored on your disk array’s SVP for use by HP

personnel. The Continuous Track remote maintenance software tool also reports SIMs to the HP Storage Technology Center. When a SIM is generated, the amber message LED on your disk array control panel turns on if the disk array is not configured to automatically phone the HP Storage Technology Center. In this case, call HP to determine the reason for the message.

SIMs are classified according to severity: service, moderate, serious, or acute. Service-level and moderate-level SIMs do not require immediate attention and are addressed during routine maintenance. These failures are often corrected before the failure actually occurs.

Serious-level and acute-level SIMs are reported to the HP Storage Technology Center immediately to ensure that the problem is addressed as soon as possible. Your HP service representative will configure your modem during installation.

4. The Continuous Track remote maintenance tool reports the SIMs to the HP Storage Technology Center through a dedicated dial up connection.

The HP Storage Technology Center then takes action to correct the failure.

Troubleshooting 89

HP Storage

Stress Free

Technology Center

Central

Failure

Figure 13. Error Detection and Reporting

SSB

SSB Log

SSB

SIM

SIM Log

SIM RC

90 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Regulatory statements

The following regulatory statements apply to the HP Disk Array XP128 and XP1024.

Regulatory statements 91

FCC EMC Statement (USA)

This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his or her own expense. The end user of this product should be aware that any changes or modifications made to this equipment without the approval of Hewlett-Packard could result in the product not meeting the Class A limits, in which case the FCC could void the user’s authority to operate the equipment.

Hewlett-Packard’s device certification tests were conducted with HP computer systems and HP shielded cables, such as those you received with your product. Changes or modifications not expressly approved by Hewlett-Packard could void the user’s authority to operate the equipment. Cables used with this device must be properly shielded to comply with the requirements of the FCC.

92 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

IEC Statement (Worldwide)

This is a Class A product. In a domestic environment this product may cause radio interference, in which case the user may be required to take adequate measures.

Regulatory statements 93

EMC Statement (Canada)

This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.

Cet appareil numérique de la Classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.

94 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Spécification ATI Classe A (France)

DECLARATION D'INSTALLATION ET DE MISE EN EXPLOITATION d'un matériel de traitement de l'information (ATI), classé A en fonction des niveaux de perturbations radioélectriques émis, définis dans la norme européenne EN 55022 concernant la Compatibilité Electromagnétique.

Regulatory statements 95

VCCI EMC Statement (Japan)

96 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

BSMI EMC Statement (Taiwan)

Regulatory statements 97

RRL EMC Statement (Korea)

98 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Harmonics Conformance (Japan)

Regulatory statements 99

German Noise Declaration

XP10000: Schalldruckpegel Lp = 70 dB(A)

Am Arbeitsplatz (operator position)

Normaler Betrieb (normal operation)

Nach ISO 7779:1988 / EN 27779:1991 (Typprüfung)

100 HP StorageWorks Disk Arrays XP128/XP1024 Owner’s Guide

Hp XP1024, XP128 User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

Contents

About this guide

Related information

Document conventions and symbols

HP technical support

HP storage website

HP sales and authorized resellers

Helpful web sites

Revision history

Overview

Continuous data availability

Nondisruptive service and upgrades

Connectivity

Fibre Channel connectivity

ESCON connectivity

FICON connectivity

iSCSI connectivity

Data integrity

Summary of features

XP128 hardware

General safety guidelines

Physical components

Control panel

Emergency power-off

Normal operations

Powering down the disk array

Emergency power-off

Planned power-off

Recovering from a power outage to the disk array

Manual restart of the disk array after power is restored

Automatic power on restart

Specifications

Temperature

Humidity

Mechanical vibration

AC line voltage

Web site

XP1024 hardware

General safety guidelines

Physical components

Disk control frame

Control panel

Service processor

Disk array frames

Available disk drives

RAID options

Device Manager server (optional)

Control panel

Emergency power-off

Normal operations

Powering down the disk array

Emergency power-off

Planned power-off

Recovering from a power outage to the disk array

Manual restart of the disk array after power is restored

Automatic power on restart

Specifications

Temperature

AC line voltage requirements for the HP Disk Array XP1024 (DKC)

AC line voltage requirements for the HP Disk Array XP1024 (DKU)

Optional software products

XP array management

HP StorageWorks XP Remote Web Console and Command View Advanced Edition (AE)

Storage management and LUN security

HP StorageWorks LUN Configuration and Security Manager XP

Remote and local data replication

HP StorageWorks Continuous Access XP

HP StorageWorks Continuous Access Extension XP

HP StorageWorks Business Copy XP

Failover and load balancing

HP StorageWorks Auto Path XP

HP StorageWorks Secure Path

Performance management

HP StorageWorks Cache LUN XP

HP StorageWorks Auto LUN XP

HP StorageWorks Performance Advisor XP
