HP ProLiant WS460c Generation 6 (G6) Workstation
Blade
HP ProLiant WS460c G6 Workstation Blade
1.
Two (2) mezzanine I/O expansion slots
2.
Internal USB connector
3.
Twelve (12) DDR3 Registered or Unbuffered DIMM Memory Slots
4.
HP Smart Array P410i Controller
5.
Two (2) small form factor (SFF) hot-plug drive bays
6.
Local I/O Connector
7.
Internal SD card slot
8.
Up to two (2) Intel® Xeon® 5500 series processors
9.
Access Panel
At A Glance
This document covers the HP ProLiant WS460c G6 workstation blade only. For more information on HP BladeSystem c-Class Infrastructure and HP BladeSystem c-Class Interconnect Components, please see the following QuickSpecs:
HP BladeSystem c-Class Enclosures QuickSpecs: HP BladeSystem c3000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12790_div/12790_div.html
HP BladeSystem c7000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12810_div/12810_div.html
HP BladeSystem c-Class Interconnect Components QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12524_div/12524_div.html
The HP ProLiant WS460c G6 provides greater 2P x86 server blade density without compromise and maximum power-efficiency with flexibility and choice.
HP ProLiant WS460c G6 workstation blade includes:
Processor
Memory
: Up to two (2) Intel® Xeon® 5500 Series processors Intel® 5500 Chipset
: Twelve (12) DIMM slots Up to 96GB, using PC3-10600 DDR3 Registered (RDIMM) memory
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 1
QuickSpecs
Overview
Up to 24GB, using PC3-10600 DDR3 Unbuffered (UDIMM) memory, operating at 1066MHz when fully populated at 2 DIMMs per Channel in 12 slot
Storage Controller
HP Smart Array P410i Controller (RAID 0/1) with optional 256MB or 512MB Battery-Backed Write Cache (BBWC)
Internal Drive Support
Up to two (2) small form factor (SFF) SAS hot plug hard disk drives
Network Controller
Embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapter
NOTE: supported. Requires 1Gbps only interconnect switches in enclosure.
One (1) additional 10/100 server adapter dedicated to iLO 2 Management
Mezzanine Support
Two (2) I/O expansion or graphics adapter mezzanine slots Supports up to (2) mezzanine cards
Graphics adapter mezzanine (NVIDIA Quadro FX 770M or FX 3600M) Dual-Port Fibre Channel Mezzanine options for SAN connectivity (Choice of Emulex or QLogic)
Graphics Adapter
Professional 2D & 3D graphics with hardware acceleration via graphics subsystem NVIDIA Quadro FX 770M with 256MB (Single or dual cards configuration capable)
For professional 2D graphics & entry 3D graphics application 256 MB (GDDR3) memory Supports up to four displays with dual card configuration Mezzanine card which occupies one or two of the mezzanine slots
NVIDIA Quadro FX 770M with 512MB (Single card configuration only)
For mid-range 3D graphics application 512 MB (GDDR3) memory Supports up to two displays Mezzanine card which occupies one of the mezzanine slots
NVIDIA Quadro FX 3600M (Single card configuration only)
For professional high-end 3D graphics application 512 MB (GDDR3) memory Supports up to two displays
Mezzanine card which occupies mezzanine slot 2 Workstation Blade Graphics Software Environment (when combined with HP gt7725 Thin Client and HP Remote Graphics Software as access client system)
Quad-display capable on remote access client system
Displays may be oriented in landscape or portrait mode. May also be tiled in matrices
Resolution: Max width 7680 pixels (@7680x1200), max height 7680 pixels (@1200x7680)
Unified graphics driver for FX 770M, FX 3600M
Ports
:
One (1) internal USB 2.0 connector for security key devices and USB drive keys One (1) internal SD-HC Card slot
Form Factor
HP ProLiant WS460c G6 is a half-height server blade that plugs into the HP BladeSystem c3000 and c7000 enclosures
Infrastructure Management
Convenient slide-out Systems Insight Display for quick and easy front view server diagnostics, along with status LEDs, Automatic Server Recovery (ASR), ROM Based Setup Utility (RBSU) HP ProLiant Onboard Administrator (powered by the Integrated Light-Out 2 management processor) for simplified server setup, health monitoring and recovery, power and thermal control, and lights-out remote administration HP Insight Control (ICE) suites, as product options, deliver essential infrastructure management that can help save time and money by making it easy to deploy, monitor, control and optimize your IT infrastructure through a single, simple
:
:
:
Initially at time of product launch, device driver will only support 1Gbps speed and Flex-10 will not be
:
:
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
:
:
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 2
QuickSpecs
Overview
management console.
NOTE:
Operating Systems
Supports following: (Not preinstalled or preloaded)
Enclosures
HP offers three different c-Class workstation blade enclosures to meet your individual needs:
Workstation blades, server blades, storage blades, interconnect modules, power supplies, fans, and redundant Onboard Administrator modules are all designed to fit into the c3000 and c7000 enclosures. For additional enclosure information, please see:
http://h18004.www1.hp.com/products/blades/components/enclosures/c-class/index.html
HP Workstation Blade Solution
HP ProLiant WS460c G6 Workstation Blade is one component of the several key components for the HP Workstation Blade Solution. For additional information, please see:
http://h71028.www7.hp.com/enterprise/437520-0-0-225-121.html
Warranty
This product is covered by a global limited warranty and supported by HP Services and a worldwide network of HP Authorized Channel Partners. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Enhancements to warranty services are available through HP Care Pack services or customized service agreements. Certain restrictions and exclusions apply. Hard drives have either a one year or three year warranty; refer to the specific hard drive QuickSpecs for details.
NOTE: be accomplished through the use of Customer Self Repair (CSR) parts. These parts fall into two categories: 1) Mandatory CSR parts are designed for easy replacement. A travel and labor charge will result when customers decline to replace a Mandatory CSR part; 2) Optional CSR parts are also designed for easy replacement but may involve added complexity. Customers may choose to have HP replace Optional CSR parts at no charge. Additional information regarding worldwide limited warranty and technical support is available at:
http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
ICE-Linux is not supported in the WS460c G6.
:
Genuine Microsoft® Windows Vista® Business (32-bit and 64-bit)
Genuine Microsoft® Windows® XP Professional 32-bit SP3
Genuine Microsoft® Windows® XP Professional x64 Edition with SP2
RedHat Enterprise Linux version 4.8 or 5.3 (64-bit)
:
The HP BladeSystem c7000 rack enclosure is 10U high and holds up to sixteen (16) ProLiant WS460c G6
workstations plugged vertically.
The HP BladeSystem c3000 rack enclosure is 6U high and holds up to eight (8) HP ProLiant WS460c G6
workstations plugged horizontally.
The HP BladeSystem c3000 tower enclosure is designed with casters for sites without racks and holds up to eight
(8) HP ProLiant WS460c G6 workstations plugged vertically.
:
Server/Workstation warranty includes 3 year Parts, 3 year Labor, 3-year on-site support. Warranty repairs may
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
.
:
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 3
QuickSpecs

Standard Features

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Processor
Quad-Core Processors Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800) Intel® Xeon® Processor E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800) Intel® Xeon® Processor L5530 (2.40 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2) Intel® Xeon® Processor L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800) Dual-Core Processors Intel® Xeon® Processor E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)
NOTE: NOTE: Technology, with 4, 3, 2, and 1 cores active. NOTE: on the quantity and type of DIMMs installed. NOTE: performance/wattage of the processor. "X" denotes High Performance/Wattage; "E" denotes Enterprise Performance/Wattage (Mainstream); and "L" denotes Lower Wattage.
HT indicates that the processor model supports Intel® Hyper-Threading Technology. Turbo indicates the maximum potential frequency increment when using Intel® Turbo Boost
DDR3 speed is the maximum memory speed of the processor. Actual memory speed may depend
For the Intel 5500 Series, the letter preceding the model number indicates the
Upgradeability
Cache Memory
Chipset
Upgradeable to two (2) processors
4MB shared L3 cache 8MB shared L3 cache
Intel® 5500 Chipset
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 4
QuickSpecs
Standard Features
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Memory
Type Standard
Maximum (RDIMM) Maximum (UDIMM)
NOTE: Depending on the memory configuration and processor model the memory speed may run at 1333MHz, 1066MHz or 800MHz. Please see the Online Memory Configuration Tool for details:
www.hp.com/go/ddr3memory-configurator
DDR3 Registered (RDIMM) 2GB (2 x 1GB) UDIMM 4GB (4 x 1GB) UDIMM 96GB (12 x 8 GB) for Registered Memory configurations 24 GB (12 x 2 GB) for Unbuffered Memory configurations
DDR3 memory options part number decoder
Network Controller
I/O Expansion Slots
Graphics Adapter (mezzanine card)
Embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapter
NOTE: not be supported. Requires 1Gbps capable interconnect switches in enclosure.
One (1) additional 10/100 NIC dedicated to iLO 2 Management
Two (2) I/O expansion mezzanine slots (x8 PCI Express)
NVIDIA Quadro FX 770M graphics (via graphics mezzanine card)
NOTE: on HP WS460c G6 only. Not compatible and supported with HP ProLiant BL server blades.
Memory size / type Memory interface Precision Number of displays
Graphics driver NVIDIA Quadro FX 3600M graphics (via graphics mezzanine card)
NOTE: G6 only. Not compatible and supported with HP ProLiant BL server blades.
Memory size / type Memory interface Precision
Initially at time of product launch, device driver will only support 1Gbps speed and Flex-10 will
Workstation class performance for professional 2D graphics, entry/mid 3D graphics. Supported
256 MB / DDR3 or 512MB / DDR3 128-bit 128-bit color Up to two displays per FX 770M 256MB. May be configured with two
cards. Single, unified driver compatible with FX 770M and FX 3600M
Workstation class performance for professional 3D graphics. Supported on HP ProLiant WS460c
512MB / DDR3 256-bit 128-bit color
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 5
QuickSpecs
Standard Features
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Integrated Manageability
Storage Controller
Maximum Internal Storage
Graphics
Graphics Resolution Supported
Number of displays Graphics driver
ProLiant Onboard Administrator (powered by the Integrated Lights-Out 2 management processor)
Type Available Options: 256MB cache, Battery-Backed Write Cache (BBWC) module for 256MB cache,
512MB cache with Battery Backed Write Cache (BBWC).
NOTE: NOTE: NOTE:
Hot Plug SAS
Integrated ATI RN-50, 32 MB video memory (On-board)
Resolution Color Depths
3Gb (6Gb Capable) SAS / 1.5Gb (3Gb Capable) SATA. Supports two (2) Small Form Factor (SFF) Hot Plug drive bays. HP Smart Array Advanced Pack not supported on WS460c G6.
Up to two displays Single, unified driver compatible with FX 770M and FX 3600M
HP Smart Array P410i Controller (RAID 0/1)
1TB
1600 x 1200, 64K, 256, 16 1280 x 1024, 16.7M, 64k, 256, 16 1024 x 768, 16.7M, 64k, 256,16 800 x 600, 16.7M, 64k, 256, 16 640 x 480, 16.7M, 64k, 256, 16
NOTE: remote console is 1280 x 1024. NOTE:
Maximum resolution available via ProLiant Onboard Administrator
On-board graphics.
2 x 500GB Serial SCSI
Fibre Channel Support
Two (2) optional Fibre Channel HBAs are supported by the HP ProLiant WS460c G6. Both mezzanine circuit boards connect directly to the server blade system board. These Fibre Channel HBAs are available via option kits and must be ordered separately.
HBA mezzanine card option kits:
Emulex LPe1105-HP 4Gb FC HBA (403621-B21)
Based on the same field-proven ASIC, firmware, and driver technology as Emulex's renowned LPe1150 HBA, the Emulex LPe1105-HP is fully driver compatible with all Emulex HBAs
QLogic QMH2462 4Gb FC HBA (403619-B21)
Uses common drivers which means that customers can standardize on one QLogic driver whether they are using the QMH2462 or other HBAs powered by QLogic
Emulex and QLogic Fibre Channel HBAs for HP BladeSystem c-Class feature:
Optimal performance utilizing PCI Express 4/2/1Gb/s auto negotiating speeds (4Gb HBAs) Dual-ports for redundant path connections Optimized for HP StorageWorks and supported by third party SAN vendors Support for Microsoft® Windows® 32-bit and Linux 64-bit operating system environments
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 6
QuickSpecs
Standard Features
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Compatible SAN
Core Infrastructure Management
Operating Systems Support for HP ProLiant Workstations
Availability
HP ProLiant WS460c G6 workstation blades are optimized for HP StorageWorks MSA, EVA and XP.
HP ProLiant 460c G6 server blades are compatible with select 3rd party SANs (please see blade storage page for more details:
class/storage.html
NOTE:
ProLiant Onboard Administrator
Microsoft Windows Vista Business SP2 (32-bit & 64-bit) Microsoft Windows XP Professional SP3 (32-bit) Microsoft Windows XP Professional x64 edition with SP2
Red Hat Enterprise Linux
HP ProLiant WS460c G6 does not support boot from SAN.
(RHEL) 4.8 and 5.3 (64-bit only)
Dual-Port Fibre Channel Mezzanine Card options for redundant SAN connection Two (2) hot-plug SAS hard drive bays and integrated RAID (HP Smart Array P410i Controller) Optional Battery-backed write cache module for integrated RAID controller Redundant ROM Advanced ECC Memory
http://h18000.www1.hp.com/products/servers/proliant-bl/c-
HP ProLiant Onboard Administrator (powered by the HP Integrated Lights-Out 2 management processor) simplifies server setup, health monitoring, power and thermal control, and lights-out remote administration. HP ProLiant Onboard Administrator functions without additional software, and can be accessed from any location via a web browser. See
www.hp.com/go/ProLiantOA
Industry Standard Compliance
Security
PCI 2.2 Compliant WOL Support SB 2.0 Support
Power-on password Administrator's password Integrated Lights-Out 2 has 12 customizable user accounts and SSL encryption Integrated Lights-Out 2 can be disabled via a Global Setting
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 7
QuickSpecs
Standard Features
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Factory Express Portfolio for Servers and Storage
HP Enterprise Configurator
Service and Support
HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.
Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSAxxxx, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.
For more information on Factory Express services on your specific server model please contact your sales representative or go to:
The HP e-Configure Enterprise Configurator now provides factory default racking for our HP hardware portfolio. This approach is aligned with our strategic direction to meet the needs and expectations of our valued customers. If you require "custom" rack configuration, please contact HP's Customer Business Center or an Authorized Partner for assistance.
HP Care Pack services provide total care and support expertise with committed response designed to meet your IT and business needs.
http://www.hp.com/go/factory-express
http://www.hp.com/products/configurator
.
The HP Care Pack service for HP ProLiant BL c-Class workstation blades, cover the workstation blade and all HP branded hardware options qualified for the workstation, purchased at the same time or afterwards, internal to the workstation.
To fully capitalize on your HP BladeSystem workstations' capabilities requires a service partner who thoroughly understands your workstation technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a HP BladeSystem server support offer to help you speedily deploy and maximize system uptime.
Recommended Service
Support Service Deployment Service
Enhanced Service
Support Service Deployment Service
Installation & Start-Up service for HP BladeSystem Infrastructure plus HP BladeSystem Enhanced Network Installation and Start-UP as per the Customer Description and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excluding HP holidays.
- Simplify ProLiant solution implementation, maintenance and management.
- 4-Hour Response Coverage, 3-Year, 24 x 7, Same Business Day
- Installation and Start Up for HP BladeSystem Infrastructure
- Optimize service level to increase IT performance and availability
- HP Proactive BladeSystem Service, 1-Year
- Enhanced Network Installation and Start-up for HP BladeSystem Switches
For a complete listing of service offerings and information visit:
http://www.hp.com/services/bladesystemservices http://www.hp.com/go/proliant/carepack
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 8
QuickSpecs

Models

FX 770M graphics preconfigured models
HP WS460c G6 E5540 4GB (1P) Dual FX770M (quad display) 580641-B21
HP WS460c G6 E5530 2GB (1P) Single FX770M (dual display) 580640-B21
Processor(s)
One of the following depending on model
Cache Memory Memory
One of the following depending on model
Graphics Adapter Network Adapter
Storage Controller Hard Drives
Internal Storage Optical Drive Operating System
Form Factor
(1) Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) (1) Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2)
8MB shared L3 cache 4 GB (4 x 1 GB) PC3-10600 (DDR3-1333) Unbuffered DIMMs
2GB (2 x 1 GB) PC3-10600 (DDR3-1333) Unbuffered DIMMs
(1 or 2) NVIDIA Quadro FX 770M with 256MB memory Embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapter
and one (1) additional 10/100 server adapter dedicated to iLO 2 management
NOTE: 1Gbps speed and Flex-10 will not be supported. Requires 1Gbps only interconnect switches in enclosure.
HP Smart Array P410i Controller with 512MB Battery-Backed Write Cache None ship standard
NOTE: capacity/performance drives separately.
SAS: 1TB (2 x 500GB SAS) - Maximum None None
NOTE:
Up to eight (8) half-height blades supported in the HP BladeSystem c3000 Enclosure Up to sixteen (16) half-height blades supported in HP BladeSystem c7000 Enclosure
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Initially at time of product launch, device driver will only support
Client operating systems require local hard disk drives. Order desired
Client OS license and software not included.
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 9
QuickSpecs

Configuration Information - Factory Integrated Models

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
NOTE: ordered, HP recommends the use of an HP approved configurator. Contact your local sales representative for information on CTO product offerings and requirements. NOTE: Configure-to-order server blades must start with a CTO Blade. NOTE:
This section lists some of the steps required to configure a Factory Integrated Model. To ensure only valid configurations are
HP does not allow factory integration of options into standard models listed above.
FIO indicates that this option is a Factory Installable Option.
Step 1: Base Server Blade Configuration (Select a configurable Blade)
Models
HP ProLiant WS460c G6 CTO Blade Configurable Model ships with: Embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapter and one
(1) additional 10/100 server adapter dedicated to iLO 2 management
NOTE: and Flex-10 will not be supported. Requires 1Gbps only interconnect switches in enclosure.
Integrated Lights-Out 2 Standard Blade Edition
Initially at time of product launch, device driver will only support 1Gbps speed
580139-B21
Step 2: Choose Required Options (one of the following from each list unless otherwise noted)
HP Processors
For single processor configuration choose:
NOTE: server.
Quad-Core Processor Option Kits Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT,
Turbo 2/2/3/3) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT, Turbo 2/2/3/3) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor L5530 (2.40 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT, Turbo 1/1/2/2) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT, Turbo 1/1/2/2) BL460c G6 Kit, FIO
NOTE:
HP ProLiant WS460c G6 shares same processor modules with BL460c G6
If two processors are desired, select one 507791-L21 and one 507791-B21.
If two processors are desired, select one 507792-L21 and one 507792-B21.
If two processors are desired, select one 507793-L21 and one 507793-B21.
If two processors are desired, select one 507794-L21 and one 507794-B21.
If two processors are desired, select one 507795-L21 and one 507795-B21.
If two processors are desired, select one 507797-L21 and one 507797-B21.
If two processors are desired, select one 507798-L21 and one 507798-B21.
If two processors are desired, select one 507799-L21 and one 507799-B21.
507791-L21
507792-L21
507793-L21
507794-L21
507795-L21
507797-L21
507798-L21
507799-L21
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 10
QuickSpecs
Configuration Information - Factory Integrated Models
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
HP Memory
Intel® Xeon® processor HP L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® processor HP E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800) BL460c G6 Kit, FIO
NOTE:
Intel® Xeon® processor HP E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800) BL460c G6 Kit, FIO
NOTE:
Dual-Core Processor Option Kits Intel® Xeon® processor HP E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)
BL460c G6 Kit, FIO
NOTE:
Registered DIMMS (RDIMMs) HP 2GB 2Rx8 PC3-10600R -9 Kit HP 4GB 2Rx4 PC3-10600R-9 Kit HP 4GB 4Rx8 PC3-8500R-7 LP Kit HP 8GB 2Rx4 PC3-10600R-9 Kit HP 8GB 2Rx4 PC3-8500R-7 Kit Unbuffered with ECC DIMMs (UDIMMs) HP 1GB 1Rx8 PC3-10600E-9 Kit HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE: memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE: ProLiant Energy Efficient Features, see:
If two processors are desired, select one 513859-L21 and one 513859-B21.
If two processors are desired, select one 507800-L21 and one 507800-B21.
If two processors are desired, select one 507801-L21 and one 507801-B21.
If two processors are desired, select one 507802-L21 and one 507802-B21.
All DDR3 memory option kits consist of one DIMM per kit. For detailed
www.hp.com/go/ddr3memory-configurator
Kits described as LP include Low Power DIMMs. For more information on
www.hp.com/go/proliant-energy-efficient
.
.
513859-L21
507800-L21
507801-L21
507802-L21
500656-B21 500658-B21 500660-B21 500662-B21 516423-B21
500668-B21 500670-B21
Step 3: Choose Additional Factory Integratable Options (one of the following from each list unless otherwise noted)
HP Storage Controllers
HP Graphics Options
256 MB Cache Module Battery Kit Upgrade (for BBWC)
NOTE:
512 MB BBWC Cache Module
NVIDIA Quadro FX 770M(256MB) graphics single card kit, FIO only NVIDIA Quadro FX 770M(256MB) graphics dual-card kit, FIO only NVIDIA Quadro FX 770M(512MB) graphics single card kit, FIO only NVIDIA Quadro FX 3600M(512MB) graphics single card kit, FIO only
NOTE: the access client using HP Remote Graphics Software. NOTE: the access client using HP Remote Graphics Software.
Requires 256 MB Cache Module.
Single card kit can support up to two displays as dual-display configuration on
Dual card kit can support up to four displays as quad-display configuration on
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
462968-B21 462969-B21
462967-B21
580135-B21 580136-B21 580137-B21 580138-B21
Page 11
HP ProLiant WS460c Generation 6 (G6)
QuickSpecs
Workstation Blade
Configuration Information - Factory Integrated Models
Step 4: Choose Additional Options for Factory Integration
NOTE: including server blade enclosures interconnect options and power subsystem options; please see the Core Options and Additional sections below; or the following QuickSpecs: HP BladeSystem c-Class Enclosures QuickSpecs: HP BladeSystem c3000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12790_div/12790_div.html
HP BladeSystem c7000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12810_div/12810_div.html
and HP BladeSystem c-Class Interconnect Components QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12524_div/12524_div.html
For additional options, please refer to the "Core Options" and "Additional Options" section below. For additional options,
.
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 12
QuickSpecs

Core Options

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
HP Processors
Quad-Core Process Option Kits Intel® Xeon® Processor X5570 (2.93 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT,
Turbo 2/2/3/3) BL460c G6 Kit Intel® Xeon® Processor X5560 (2.80 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT,
Turbo 2/2/3/3) BL460c G6 Kit Intel® Xeon® Processor X5550 (2.66 GHz, 8MB L3 Cache, 95W, DDR3-1333, HT,
Turbo 2/2/3/3) BL460c G6 Kit Intel® Xeon® Processor E5540 (2.53 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT,
Turbo 1/1/2/2) BL460c G6 Kit Intel® Xeon® Processor L5530 (2.40 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT,
Turbo 1/1/2/2) BL460c G6 Kit Intel® Xeon® Processor E5530 (2.40 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT,
Turbo 1/1/2/2) BL460c G6 Kit Intel® Xeon® Processor L5520 (2.26 GHz, 8MB L3 Cache, 60W, DDR3-1066, HT,
Turbo 1/1/2/2) BL460c G6 Kit Intel® Xeon® Processor E5520 (2.26 GHz, 8MB L3 Cache, 80W, DDR3-1066, HT,
Turbo 1/1/2/2) BL460c G6 Kit Intel® Xeon® processor HP L5506 (2.13 GHz, 4MB L3 Cache, 60W, DDR3-800)
BL460c G6 Kit Intel® Xeon® processor HP E5506 (2.13 GHz, 4MB L3 Cache, 80W, DDR3-800)
BL460c G6 Kit Intel® Xeon® processor HP E5504 (2.00 GHz, 4MB L3 Cache, 80W, DDR3-800)
BL460c G6 Kit Dual-Core Process Option Kits Intel® Xeon® processor HP E5502 (1.86 GHz, 4MB L3 Cache, 80W, DDR3-800)
BL460c G6 Kit
507791-B21
507792-B21
507793-B21
507794-B21
507795-B21
507797-B21
507798-B21
507799-B21
513859-B21
507800-B21
507801-B21
507802-B21
HP Memory
Registered DIMMS (RDIMMs) HP 2GB 2Rx8 PC3-10600R-9 Kit HP 4GB 2Rx4 PC3-10600R-9 Kit HP 4GB 4Rx8 PC3-8500R-7 LP Kit HP 8GB 2Rx4 PC3-10600R-9 Kit HP 8GB 2Rx4 PC3-8500R-7 Kit Unbuffered with ECC DIMMs (UDIMMs) HP 1GB 1Rx8 PC3-10600E-9 Kit HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE: memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
NOTE: ProLiant Energy Efficient Features, see:
http://h18004.www1.hp.com/products/servers/platforms/energyefficient/
All DDR3 memory option kits consist of one DIMM per kit. For detailed
www.hp.com/go/ddr3memory-configurator
Kits described as LP include Low Power DIMMs. For more information on
.
.
500656-B21 500658-B21 500660-B21 500662-B21 516423-B21
500668-B21 500670-B21
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 13
QuickSpecs
Core Options
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
HP Hard Drives
HP Fiber Channel Mezzanine Options
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives HP 300GB 3G SAS 10K SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive HP 146GB 3G SAS 15K SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive HP 146GB 3G SAS 10K SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive HP 72GB 3G SAS 15K SFF (2.5-inch) Dual Port Enterprise 3yr Warranty Hard Drive
NOTE: hard drive QuickSpecs for details. Please see QuickSpecs for Technical Specifications and additional information:
http://h18000.www1.hp.com/products/quickspecs/12244_div/12244_div.html
(Worldwide) NOTE:
Emulex LPe1105 FC Dual Channel 4Gb, PCI-E-to-Fibre Channel Host Bus Adapter QLogic QMH2462 4Gb FC HBA for HP c-Class BladeSystem
NOTE:
Hard drives have either a one year or three year warranty; refer to the specific
The hard drive options are not required when configuring a Drive-less Model.
Boot from SAN functionality not supported.
492620-B21 504062-B21 418367-B21 418371-B21
403621-B21 403619-B21
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 14
QuickSpecs

Additional Options

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
HP Remote Access
HP Resource Brokering
HP Remote Graphics Software (RGS) v5.3.0
NOTE: WS460c G6. NOTE: later is required. NOTE: Remote Graphics in:
HP RGS Desktop E-LTU/E-Media; North America & EMEA only HP RGS Desktop License Entitlement Certificate and CD-ROM Media; Latin America &
Asia-Pacific/Japan HP RGS Desktop LTU and CD-ROM Media; Japan Only HP RGS Desktop 1 Year Software Assurance RGS Desktop 1 Yr Software Assurance; Japan Only HP 1- year 9x5 3-Incident Remote Graphics SW phone Technical Support; NA only
HP PC Session Allocation Manager (SAM)
NOTE: WS460c G6. NOTE: regular deployment with managed blades exceeding 30 blades will require matching number of license to the total number of blades being managed by SAM. NOTE:
http://h71028.www7.hp.com/enterprise/downloads/SAM_21_WP_Oct07.pdf
HP PC Session Allocation Manager (SAM) license HP 1-year 9x5 3 Incident SAM SW Technical Support HP 1-year 9x5 10 Incident SAM SW Technical Support HP 1-year 9x5 25 Incident SAM SW Technical Support HP 1-year 9x5 Unlimited SAM SW Technical Support
HP RGS is a licensed software sold separately. Not bundled with HP
For remote access to Windows Vista OS on blade, HP RGS version 5.3 or
For more information on HP Remote Graphics Software, please find HP
http://www.hp.com/go/rgs
HP SAM is a licensed software sold separately. Not bundled with HP ProLiant
Evaluation provision is included for trial use up to 30 managed blades. Any
For more information on HP SAM, refer to HP SAM White Paper:
AW684AAE
AW684AA
AW686AA AW685AA AW692AA
UE345E
AW189AA
UE392E UE393E UE394E UE395E
HP Storage Controllers
HP InfiniBand Mezzanine Options
Optional Upgrades 256 MB Cache Module Battery Kit Upgrade (for BBWC)
NOTE:
512 MB BBWC Cache Module
NOTE: information:
http://h18000.www1.hp.com/products/quickspecs/13203_div/13203_div.html
(Worldwide)
HP 4X QDR IB Dual Port Mezzanine HCA for HP BladeSystem c-Class HP 4X DDR IB Dual Port Mezzanine HCA for HP BladeSystem c-Class
Requires 256 MB Cache Module.
Please see the QuickSpecs for Technical Specifications and additional
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
462968-B21 462969-B21
462967-B21
492303-B21 448262-B21
Page 15
QuickSpecs
Additional Options
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
HP StorageWorks SB40c Storage Blade
HP Expansion Blade
HP USB and SD Options
HP Care Pack Services
HP StorageWorks SB40c Storage Blade
NOTE: information:
http://h18000.www1.hp.com/products/quickspecs/12587_div/12587_div.html
(Worldwide)
HP PCI Expansion Blade
NOTE: connect board which requires installation. NOTE: information:
http://h18000.www1.hp.com/products/quickspecs/12753_div/12753_div.html
HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)
NOTE: workstation blades, cover the workstation blade and all HP branded hardware options qualified for the workstation, purchased at the same time or afterwards, internal to the workstation.
Hardware Services On-site Service 4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years, Electronic 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic 6-Hour Call to Repair, On-site Service, 7-Day x 24-Hour Coverage, 3 Years,
Electronic
Please see the QuickSpecs for Technical Specifications and additional
Ships with one pre-installed PCI-X connect board. Also includes one PCIe
Please see the QuickSpecs for Technical Specifications and additional
The HP Care Pack service part numbers below for ProLiant BL c-Class
411243-B21
448018-B21
DC172B
UR334E UR336E UR338E
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 16
QuickSpecs

Memory

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
NOTE:
Memory Population Guidelines For detailed memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
www.hp.com/go/ddr3memory-configurator
Some DIMM installation guidelines are summarized below:
Memory configurations listed do not apply to "Factory Integrated Models".
For the HP ProLiant WS460c G6 server with twelve (12) memory slots:
There are three (3) channels per processor; six (6) channels per server There are two (2) DIMM slots for each memory channel; twelve (12) total slots. Memory channel 1 consists of the two (2) DIMMs that are closest to the processor
Memory channel 3 consists of the two (2) DIMMs that are furthest from the processor DIMM slots that are white should be populated first Do not mix Unbuffered memory (UDIMMs) with Registered memory (RDIMMs). Do not install DIMMs if the corresponding processor is not installed If only one processor is installed in a 2CPU system, only half of the DIMM slots are available To maximize performance, balance the total memory capacity between all installed processors It is not required, but it is recommended to load the channels similarly if possible You can only have up to eight (8) ranks installed per channel You can only install two quad-rank DIMMs per channel You can only install two UDIMMs per channel; if available, the third slot in the channel must remain empty Populate DIMMs from heaviest load (quad-rank) to lightest load (single-rank) within a channel Heaviest load (DIMM with most ranks) within a channel goes furthest from the chipset For memory mirroring mode, channel 3 must be unpopulated. Channels 1 and 2 are populated identically For lock-step mode, channel 3 must be unpopulated. DIMMs in channels 1 and 2 will be installed in pairs. The paired slots will be 1,4; 2,5; 3;6 on a 3DPC system or 1,4; 2,5; on a 2DPC system No mixing DIMM voltage; all DIMMs must be the same voltage
DIMM Type
DIMM Rank DIMM Capacity DIMM Native Speed (MHz)
12 slot servers
24 48 96 96 48
1 DIMM Per Channel 2 DIMM Per Channel 3 DIMM Per Channel
NOTES:
Mixing DIMM speeds is allowed, but the system processor speed rules always override the DIMM capabilities If you do mix DIMM speeds, the memory bus will default to the minimum clock rate of all DIMMs in the system - even if the slower DIMM is on the other processor If you install 1x 1066MHz DIMM in channel 1 and 1x 1333MHz DIMM in channel 2, you still run at 1066MHz If you install 1x 1066MHz DIMM in channel 1 and 5x 1333MHz DIMMs with 1 DIMM Per Channel (DPC) in each of the other channels, you run at 1066MHz If you install 3DPC in one channel (if applicable) and 1DPC in all other channels, you run at 800MHz
2GB 4GB 8GB 8GB 4GB
1333 1333 1066 1333 1066
12 12 12 12 12
1333 1333 1066 1333 1066
1066
*
800 800 800 800
Registered DIMMS (RDIMMs)
Dual Rank (2R)
1066
*
1066 1066
*
Quad Rank
(4R)
800
not supported
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 17
HP ProLiant WS460c Generation 6 (G6)
QuickSpecs
Workstation Blade
Memory
95 Watt CPU's are required for 1333MHz DIMM speeds References to the above MHz speeds are for the various speeds of DDR3 DIMMs; 1333 refers to DDR3-1333, etc.
HP ProLiant WS460c G6 Workstation Blade DIMM slot and configuration diagrams Basic memory slot and population diagram
Population order; start with "A" first, "B" second, "C" third, etc.
12 DIMM SLOTS (6 per CPU node)
Chnl 1
Chnl 2
Chnl 3
slot #
1 2
3 4
5 6
CPU1 CPU2
population order
D A
E B
F
C
slot #
1 2
3 4
5 6
population order
D A
E B
F
C
Chnl 1
Chnl 2
Chnl 3
HP ProLiant WS460c G6 Server Blade (1P Model) Standard memory configuration (1 CPU model)
2GB (2 x 1GB) of PC3-10600 (DDR3-1333) UDIMMs or 4GB (4 x 1GB) of PC3-10600 (DDR3-1333) UDIMMs
Chnl 1
Chnl 2
Chnl 3
Standard Memory Plus Optional Memory (1 CPU model)
slot #
1
2
3 4
5
6
CPU1 CPU2
population order
D: 1GB DIMM (if
4GB model)
A: 1GB DIMM
E: empty
B: 1GB DIMM
F: empty
C: 1GB DIMM (if
4GB model)
slot #
1
2
3 4
5
6
population order
D: empty
A: empty
E: empty
B: empty
F: empty
C: empty
Chnl 1
Chnl 2
Chnl 3
10 GB of PC3-10600 (DDR3-1333) UDIMMs (2 x 1GB plus 4 x 2GB); (2GB memory standard model) 8GB of PC3-10600 (DDR3-1333) UDIMMs (4 x 1GB plus 2 x 2GB); (4GB memory standard model)
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 18
QuickSpecs
Memory
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Chnl 1
Chnl 2
Chnl 3
UDIMM maximum configuration (1 CPU model); Standard Memory Replaced with Optional Memory (1 CPU model)
12GB, consisting of six (6) 2GB dual-rank PC3-10600 UDIMMs
slot #
1
2
3 4
5
6
CPU1 CPU2
population order
D: 1GB DIMM (if
4GB model),
2GB DIMM (if 2GB
model)
A: 1GB DIMM
E: 2GB DIMM B: 1GB DIMM
F: 2GB DIMM
C: 1GB DIMM (if
4GB model),
2GB DIMM (if 2GB
model)
slot #
1
2
3 4
5
6
population order
D: empty
A: empty
E: empty
B: empty
F: empty
C: empty
Chnl 1
Chnl 2
Chnl 3
Chnl 1
Chnl 2
Chnl 3
RDIMM maximum configuration (2 CPU model)
96GB, consisting of twelve (12) 8GB dual-rank PC3-8500 RDIMMs
Chnl 1
Chnl 2
Chnl 3
slot #
1 2
3 4
5 6
slot #
1 2
3 4
5 6
CPU1 CPU2
population order
D: 2GB DIMM A: 2GB DIMM
E: 2GB DIMM B: 2GB DIMM
F: 2GB DIMM
C: 2GB DIMM
CPU1 CPU2
population order
D: 8GB DIMM A: 8GB DIMM
E: 8GB DIMM B: 8GB DIMM
F: 8GB DIMM
C: 8GB DIMM
slot #
1 2
3 4
5 6
slot #
1 2
3 4
5 6
population order
D: empty A: empty
E: empty
B: empty
F: empty
C: empty
population order
D: 8GB DIMM A: 8GB DIMM
E: 8GB DIMM B: 8GB DIMM
F: 8GB DIMM
C: 8GB DIMM
Chnl 1
Chnl 2
Chnl 3
Chnl 1
Chnl 2
Chnl 3
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 19
QuickSpecs
Memory
UDIMM maximum configuration (2 CPU model)
24GB, consisting of twelve (12) 2GB dual-rank PC3-10600 UDIMMs
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Chnl 1
Chnl 2
Chnl 3
NOTE:
Following are memory options available from HP: HP Memory
Capacity references are rounded to the common Gigabyte values.
1GB = 1024MB 2GB = 2048MB 4GB = 4096MB 8GB = 8192MB
slot #
1 2
3 4
5 6
Registered DIMMs (RDIMMs) HP 2GB 2Rx8 PC3-10600R-9 Kit HP 4GB 2Rx4 PC3-10600R-9 Kit HP 4GB 4Rx8 PC3-8500R-7 LP Kit HP 8GB 2Rx4 PC3-10600R-9 Kit HP 8GB 2Rx4 PC3-8500R-7 Kit Unbuffered with ECC DIMMs (UDIMMs) HP 1GB 1Rx8 PC3-10600E-9 Kit HP 2GB 2Rx8 PC3-10600E-9 Kit
NOTE: memory configuration rules and guidelines, please use the Online DDR3 Memory Configuration Tool:
CPU1 CPU2
population order
D: 2GB DIMM A: 2GB DIMM
E: 2GB DIMM B: 2GB DIMM
F: 2GB DIMM
C: 2GB DIMM
All DDR3 memory option kits consist of one DIMM per kit. For detailed
www.hp.com/go/ddr3memory-configurator
slot #
1 2
3 4
5 6
population order
D: 2GB DIMM A: 2GB DIMM
E: 2GB DIMM B: 2GB DIMM
F: 2GB DIMM
C: 2GB DIMM
.
Chnl 1
Chnl 2
Chnl 3
500656-B21 500658-B21 500660-B21 500662-B21 516423-B21
500668-B21 500670-B21
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 20
HP ProLiant WS460c Generation 6 (G6)
QuickSpecs
Workstation Blade

Storage

1-2
2 x SFF SAS Hot Plug Hard Drives
Hard Drives
NOTE: operate at the same data transfer rate or the system bandwidth will be negotiated down to an acceptable level for all components.
SAS Hot Plug SFF (2.5-inch) Enterprise (ENT) Drives
300GB 3G SAS 10K 146GB 3G SAS 15K 146GB 3G SAS 10K 72GB 3G SAS 15K 72GB 3G SAS 10K
The components of a storage subsystem (e.g. the drive, the HBA/controller, firmware, and the server backplane) should
Quantity
Supported
2
Position
Supported
1-2
Controller HP Smart Array P410i Controller
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 21
QuickSpecs

Technical Specifications

HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
System Unit
Dimensions (with bezel)
Weight (approximate)
Power Specifications
System Inlet Temperature
(H x W x D)
7.154 x 2.19 x 20.058 in (18.17 x 5.56 x 50.95 cm)
Maximum (all hard drives and processors installed)
Minimum (one hard drive and processor installed)
For power specifications including Input Requirements, BTU Rating, and Power Supply Output, please see the HP BladeSystem c-Class Enclosures QuickSpecs located at URL: HP BladeSystem c3000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12790_div/ 12790_div.html
HP BladeSystem c7000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12810_div/ 12810_div.html
To review typical system power ratings use the HP BladeSystem Power Sizer which is available via the online tool located at URL:
http://www.hp.com/go/bladesystem/powercalculator
Operating
14.20 lb (6.44 kg)
10.75 lb (4.87 kg)
10° to 35°C (50° to 95°F) at sea level with an altitude derating of 1.0°C per every 305 m (1.8°F per every 1000 ft) above sea level to a maximum of 3050 m (10,000 ft), no direct sustained sunlight. Maximum rate of change is 10°C/hr (18°F/hr). The upper limit may be limited by the type and number of options installed.
Relative Humidity (non-condensing)
Altitude
Acoustic Noise
System performance may be reduced if operating with a fan fault or above 30°C (86°F).
Non-operating
Operating
Non-operating
Operating
Non-operating
For acoustic noise specifications, please see the HP BladeSystem c-Class Enclosures QuickSpecs located at URL: HP BladeSystem c3000 Enclosure QuickSpecs:
-30° to 60°C (-22° to 140°F). Maximum rate of change is 20°C/hr (36°F/hr).
10 to 90% relative humidity (Rh), 28°C (82.4°F) maximum wet bulb temperature, non-condensing.
5 to 95% relative humidity (Rh), 38.7°C (101.7°F) maximum wet bulb temperature, non­condensing.
3050 m (10,000 ft). This value may be limited by the type and number of options installed. Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
9144 m (30,000 ft). Maximum allowable altitude change rate is 457 m/min (1500 ft/min).
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 22
QuickSpecs
Technical Specifications
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
http://h18000.www1.hp.com/products/quickspecs/12790_div/ 12790_div.html
HP BladeSystem c7000 Enclosure QuickSpecs:
http://h18000.www1.hp.com/products/quickspecs/12810_div/ 12810_div.html
HP Smart Array P410i Controller
Embedded NC532i Dual Port Flex-10 10GbE Multifunction Server Adapter
Disk Drive Interface
Server Interface Cache Memory
Logical Drives Supported Maximum Logical Drive
Capacity Host Memory Addressing RAID Support
Upgradeable Firmware
Type Network Processor Data Transfer Method Network Transfer Rate
IEEE Compliance
3Gb (6Gb Capable) SAS (Serial Attached SCSI)
1.5Gb (3Gb Capable) SATA (Serial Advanced Technology Attachment) x4 PCI Express host interface 0 MB (none) standard
Optional 256MB or 512MB Cache Memory 2 (with standard 0MB cache) 32 (with optional 256MB cache)
64 (with optional 512MB cache) 64-bit, supporting servers memory space greater than 4 GB RAID 1( Mirroring)
RAID 0 (Striping) Controller: Upgradeable Firmware with Recovery ROM feature
Online Drive Flash (with SAS drives) requires 256MB or 512MB module
Integrated dual-port KR 10GbE Broadcom 57711 x4 PCI Express Generation 2 Two ports, each at 20 Gbps full duplex; 40 Gbps aggregate full duplex
theoretical bandwidth
NOTE: 1 Gb HP BladeSystem c-Class interconnect components. NOTE: 20 Gbps (theoretical) full duplex. NOTE: 1Gbps speed and Flex-10 will not be supported. Requires 1Gbps capable interconnect switches in enclosure.
802.1p, 802.1q, 802.3u, 802.3ad, 802.3ae, 802.3ap (10GBase-KX4),
802.3x and 802.3z
Each port is autosensing 1 Gb / 10 Gb, and can interoperate with
Each port on the NC532i adapter transmits from the server at only
Initially at time of product launch, device driver will only support
NVIDIA Quadro FX 770M graphics adapter
Memory size Memory type Memory interface Card type I/O interface Max power consumption Precision API Upgradeable Firmware
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
256 MB or 512MB GDDR-3 128-bit MXM-II form factor PCIe (x16); Note: HP WS460c G6 I/O slot is PCIe x8 35W (256MB), 38W (512MB) 128-bit color, 12-bit sub-pixel, 4X Full-Scene Anti-Aliasing DirectX 10, Shader Model 4.0; OpenGL2.1 Upgradeable Firmware
Page 23
QuickSpecs
Technical Specifications
HP ProLiant WS460c Generation 6 (G6)
Workstation Blade
Environment-friendly Products and Approach
© Copyright 2010 Hewlett-Packard Development Company, L.P.
The information contained herein is subject to change without notice.
Microsoft and Windows NT are US registered trademarks of Microsoft Corporation. Intel, the Intel logo, Xeon and Xeon Inside are trademarks of Intel Corporation in the U.S. and other countries.
End-of-life Management and Recycling
Hewlett-Packard offers end-of-life HP product return, trade-in, and recycling programs in many geographic areas. For trade-in information, please go to:
http://www.hp.com/go/green http://www.hp.com/go/green
Products returned to HP will be recycled, recovered or disposed of in a responsible manner.
The EU WEEE directive (2002/95/EC) requires manufacturers to provide treatment information for each product type for use by treatment facilities. This information (product disassembly instructions) is posted on the Hewlett Packard web site at: be used by recyclers and other WEEE treatment facilities as well as HP OEM customers who integrate and re-sell HP equipment.
http://www.hp.com/go/green
. To recycle your product, please go to: or contact your nearest HP sales office.
. These instructions may
The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein.
For hard drives, 1GB = 1 billion bytes. Actual formatted capacity is less.
DA - 13429 Worldwide QuickSpecs — Version 3 — 2.16.2010
Page 24
Loading...
