HP Workstation xw6200 Quickspecs

1.

Monitor (sold separately)

7.

4 PCI, 1 PCI Express 8x prime slots

2.

2004 Standard Keyboard

8.

1 PCI Express x16 Graphics Bus

3.

2-Button Scroll Mouse

9.

6 USB 2.0, 1 standard serial port, 1 parallel port, 2 PS/2, 1 RJ-45,
audio in/out

4.

Front IO: 2 USB 2.0, IEEE-1394 (requires optional PCI card to enable),
headphone and microphone

10.

Dual Intel® Xeon™ processors

5.

3.5" external bay for optional diskette drive or other 3.5" device

11.

500 watt power supply

6.

2 internal 3.5" bays, 2 external 5.25" bays

At A Glance

Choice of operating systems:
Microsoft Windows XP Professional
Red Hat Enterprise Linux Workstation 3
HP Linux Installer Kit (see

http://www.hp.com/workstations/software/linux/

for details)
Intel® Xeon™ processors with EM64T technology
Up to 8 GB of DDR-2 memory
PCI-Express I/O and graphics
Integrated Broadcom NetXtreme Gigabit ethernet
800 MHz processor front side bus support
Intel Hyper-Threading technology support
SATA and Ultra 320 SCSI drives
Digital AC97 integrated audio with internal speaker
Pre-loaded Manageability tools
Energy Star compliance with energy-saving features
Protected by HP Services, including a 3-3-3 standard warranty. Terms and conditions vary by country. Certain restrictions and exclusions
apply.

QuickSpecs

HP Workstation xw6200

Overview

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 1

Processor and Speed

–

One of the following

Intel Xeon Processor

with 800 MHz Front Side Bus, 1 MB L2 cache

2.8 GHz

3.0 GHz – available in Fall 2004

3.2 GHz

3.4 GHz

3.6 GHz

2nd Intel Xeon Processor

with 800 MHz Front Side Bus, 1 MB L2 cache

2.8 GHz

3.0 GHz – available in Fall 2004

3.2 GHz

3.4 GHz

3.6 GHz

Operating System

–

One of the following

Microsoft Windows XP Professional
Red Hat Enterprise Linux Workstation 3 32-bit version (Update 2 in 32- and 64-bit available as aftermarket option)
HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions)

1st Hard Disk Drive

–

One of the following

40 GB 7200 rpm Serial ATA drive (2 MB cache)
80 GB 7200 rpm Serial ATA drive (8 MB cache)
160 GB 7200 rpm Serial ATA drive (8 MB cache)
250 GB 7200 rpm Serial ATA drive (8 MB cache)
400 GB 7200 rpm Serial ATA drive (8 MB cache) – available in Winter 2004
36 GB 10K rpm Serial ATA drive (8 MB cache)
74 GB 10K rpm Serial ATA drive (8 MB cache)
73 GB 10K Ultra320 SCSI drive
300 GB 10K Ultra320 SCSI drive
36 GB 15K Ultra320 SCSI drive
73 GB 15K Ultra320 SCSI drive
146 GB 15K Ultra320 SCSI drive

2nd Hard Disk Drive

–

One of the following

2nd hard drive, 40 GB 7200 rpm Serial ATA drive (2 MB cache)
2nd hard drive, 80 GB 7200 rpm Serial ATA drive (8 MB cache)
2nd hard drive, 160 GB 7200 rpm Serial ATA drive (8 MB cache)
2nd hard drive, 250 GB 7200 rpm Serial ATA drive (8 MB cache)
2nd hard drive, 400 GB 7200 rpm Serial ATA drive (8 MB cache) – available in Winter 2004
2nd hard drive, 36 GB 10K rpm Serial ATA drive (8 MB cache)
2nd hard drive, 74 GB 10K rpm Serial ATA drive (8 MB cache)
2nd hard drive, 73 GB 10K Ultra320 SCSI drive
2nd hard drive, 300 GB 10K Ultra320 SCSI drive
2nd hard drive, 36 GB 15K Ultra320 SCSI drive
2nd hard drive, 73 GB 15K Ultra320 SCSI drive
2nd hard drive, 146 GB 15K Ultra320 SCSI drive

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 2

3rd Hard Disk Drive

–

One of the following

3rd hard drive, 73 GB 10K Ultra320 SCSI drive
3rd hard drive, 300 GB 10K Ultra320 SCSI drive
3rd hard drive, 36 GB 15K Ultra320 SCSI drive
3rd hard drive, 73 GB 15K Ultra320 SCSI drive
3rd hard drive, 146 GB 15K Ultra320 SCSI drive

Drive controllers

Integrated serial ATA controller
Optional Ultra 320 SCSI controller (required if HDs are SCSI) – basic
Optional Ultra 320 SCSI controller (required if HDs are SCSI) – advanced, with RAID support and external connector

Memory

–

One of the following

256 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (1 x 256 MB)
512 MB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 256 MB)
1 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 512 MB)
2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB)
2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 512 MB)
3 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 1 GB + 2 x 512 MB)
4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB)
4 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 1 GB)
6 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (2 x 2 GB + 2 x 1 GB)
8 GB DDR-2 PC2-3200 (400 MHz) ECC Registered (4 x 2 GB)

Removable Storage

1.44-MB Diskette Drive
48X CD-ROM Drive
48X/32X/48X CD-RW Drive
16X/40X DVD-ROM Drive
48X/32X/48X/16X Combo CD-RW/DVD-ROM Drive
8X DVD+R/RW Drive

2nd Removable Storage

48X/32X/48X CD-RW Drive
16X/40X DVD-ROM Drive
48X/32X/48X/16X Combo CD-RW/DVD-ROM Drive
8X DVD+R/RW Drive

Keyboard

–

One of the following

PS/2 Standard Keyboard
USB Standard Keyboard

Mouse

–

One of the following

PS/2 2-Button Scroll Mouse
PS/2 3-Button Mouse
USB 2-Button Optical Scroll Mouse
USB 3-Button Optical Mouse

Audio

Integrated Digital AC97 audio with internal speaker
Sound Blaster Audigy 2 ZS PCI

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 3

NIC

Broadcom 5782 10/100/1000 (PCI)

Graphics

NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI – up to 2 of these two cards can be integrated in the factory)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro NVS 280 PCI Express (64 MB, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

Miscellaneous

Solenoid lock and hood sensor
IEEE 1394 PCI Card

Software

Symantec Norton AntiVirus 2004 (optional)*
HP Performance Tuning Framework*
Altiris Recovery*
HP Client Manager Software v6.0*

* Not available with Linux Operating System

QuickSpecs

HP Workstation xw6200

Standard Features - Custom Components

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 4

Operating System (choice)

Microsoft Windows XP Professional*
OR Red Hat Enterprise Linux Workstation 3 Update 2 (32-bit only)
OR HP Installer Kit for Linux (includes drivers for both 32-bit & 64-bit OS versions on xw8200, xw6200, xw4200)

Form factor

Minitower

Color

Carbonite/Alloy metallic

System Board Form Factor

Non-standard ATX

Processor

Single or dual Intel Xeon processors (Nocona) with EM64T and Hyper-Threading Technology

CPU Bus Speed Supported

800 MHz FSB

Standard L2 Cache

1 MB L2 cache

Chipset

Intel E7525

Memory Expansion Slots

4 DIMM's

Memory Type Supported

DDR-2 (ECC registered)

Memory Speed Supported

DDR-2 Synch DRAM PC2-3200 (400 MHz) Registered ECC

Maximum Memory

8 GB (4 DIMMs slots, 2 GB DIMMs required to meet maximum configurations)

Network controller

Integrated Broadcom 5751 10/100/1000 for HP

Audio

Integrated AC'97 digital audio with S/PDif 6-channel pass-through, stereo microphone, and Yamaha XG Lite Softsynth
support

PCI slots

4 PCI slots (full-height)
1 PCI Express (x8 mechanically, x4 electrically)
1 PCI Express x16 graphics

AGP slot

none

Bays

Total Bays = 5

Internal Bays

Two 3.5 inch bays with acoustic dampening rail assemblies

External Bays

Two 5.25 inch full length 2003 mm maximum device depth (top bay is limited to 198 mm depth when optional
smart cover solenoid lock is installed). Bottom bay can be converted to an internal 3.5 inch 3rd Hard Drive bay
using optional bracket
One 3.5 inch bay for optional floppy drive

Parallel Port

1

Serial Port

1

Front I/O

2 USB 2.0, Headphone, Microphone, optional IEEE 1394

Rear I/O

6 USB 2.0, 1 standard serial port, 1 parallel port, PS/2 keyboard and mouse, 1 RJ-45 to integrated Gigabit LAN, Audio
In, Audio Out, Mic In

USB Keyboard

Optional

USB Mouse

Optional

PS/2 Keyboard

1

PS/2 Mouse

1

Chassis Dimensions
(H x W x D)

17.3 x 6.5 X 17.3 in (44.1 x 16.5 x 44.0 cm)

System weight

Standard config – 35 lb

Shipping weight

Varies by region

Temperature

Operating

40° to 95° F (5° to 35° C)

Non-operating

-40° to 140° F (-40° to 60° C)

Humidity

Operating

8% to 85%

Non-operating

8% to 90%

Maximum Altitude
(nonpressurized)

Operating

10,000 ft (3,000 m)

Non-operating

30,000 ft (9,100 m)

Power Supply

500W wide-ranging, active Power Factor Correction

Interfaces Supported

1 SATA interface (2 serial-ATA connectors), 1 EIDE interface (2 EIDE connectors) for optical drives, optional multi­bay interface

Hard Drive Controller (PCI)
Supported

Ultra160 or Ultra320, or SATA RAID, or Ultra320 RAID

QuickSpecs

HP Workstation xw6200

Standard Features - Specs

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 5

Preinstalled Software

HP Client Manager Software v6.0*
Altiris Local Recovery*
Alert Standard Format specification*
Norton AntiVirus 2004 (optional preinstall)*
CD/DVD software dependent on optical drive choices

* Not available on Linux

QuickSpecs

HP Workstation xw6200

Standard Features - Specs

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 6

xw6200X/XD2.8/B80/
H1.0/280E/dF/s

Processor

Intel Xeon processor 2.80 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD2.8/B80/H1.0/280E/dF/s Country Code Key
N. America

PD896AW#ABA

Switzerland

(German/French)

PD896AW#AR8

Fr. Canadian

PD896AW#ABC

Switzerland

(Italian/English)

PD896AW#ACN

L. America

PD896AW#ABM

Dutch

PD896AW#ABH

Japan

(English)

PD896AW#ACF

Denmark

PD896AW#ACE

Japan

(Japanese)

PD896AW#ABJ

Asia/Pacific

(English)

PD896AW#AB4

UK

PD896AW#ABU

Korea

PD896AW#AB1

Germany

PD896AW#ABD

China

PD896AW#AB2

France

PD896AW#ABF

Taiwan

PD896AW#AB0

Italy

PD896AW#ABZ

India

PD896AW#ACJ

Spain

PD896AW#ABE

Australia

PD896AW#ABG

Europe

PD896AW#AK6

Thailand

PD896AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 7

xw6200X/XD3.2/C74/
H1.0/280E/dF/s

Processor

Intel Xeon processor 3.20 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.2/C74/H1.0/280E/dF/s Country Code Key
N. America

PM199AW#ABA

Switzerland

(German/French)

PM199AW#AR8

Fr. Canadian

PM199AW#ABC

Switzerland

(Italian/English)

PM199AW#ACN

L. America

PM199AW#ABM

Dutch

PM199AW#ABH

Japan

(English)

PM199AW#ACF

Denmark

PM199AW#ACE

Japan

(Japanese)

PM199AW#ABJ

Asia/Pacific

(English)

PM199AW#AB4

UK

PM199AW#ABU

Korea

PM199AW#AB1

Germany

PM199AW#ABD

China

PM199AW#AB2

France

PM199AW#ABF

Taiwan

PM199AW#AB0

Italy

PM199AW#ABZ

India

PM199AW#ACJ

Spain

PM199AW#ABE

Australia

PM199AW#ABG

Europe

PM199AW#AK6

Thailand

PM199AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 8

xw6200X/XD3.2+/B80/
H1.0/280E/dF/s

Processor

Dual Intel Xeon processors 3.20 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.2+/B80/H1.0/280E/dF/s Country Code Key
N. America

PD898AW#ABA

Switzerland

(German/French)

PD898AW#AR8

Fr. Canadian

PD898AW#ABC

Switzerland

(Italian/English)

PD898AW#ACN

L. America

PD898AW#ABM

Dutch

PD898AW#ABH

Japan

(English)

PD898AW#ACF

Denmark

PD898AW#ACE

Japan

(Japanese)

PD898AW#ABJ

Asia/Pacific

(English)

PD898AW#AB4

UK

PD898AW#ABU

Korea

PD898AW#AB1

Germany

PD898AW#ABD

China

PD898AW#AB2

France

PD898AW#ABF

Taiwan

PD898AW#AB0

Italy

PD898AW#ABZ

India

PD898AW#ACJ

Spain

PD898AW#ABE

Australia

PD898AW#ABG

Europe

PD898AW#AK6

Thailand

PD898AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 9

xw6200X/XD3.4/C74/
H1.0/280E/dF/s

Processor

Intel Xeon processor 3.40 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.4/C74/H1.0/280E/dF/s Country Code Key
N. America

PM200AW#ABA

Switzerland

(German/French)

PM200AW#AR8

Fr. Canadian

PM200AW#ABC

Switzerland

(Italian/English)

PM200AW#ACN

L. America

PM200AW#ABM

Dutch

PM200AW#ABH

Japan

(English)

PM200AW#ACF

Denmark

PM200AW#ACE

Japan

(Japanese)

PM200AW#ABJ

Asia/Pacific

(English)

PM200AW#AB4

UK

PM200AW#ABU

Korea

PM200AW#AB1

Germany

PM200AW#ABD

China

PM200AW#AB2

France

PM200AW#ABF

Taiwan

PM200AW#AB0

Italy

PM200AW#ABZ

India

PM200AW#ACJ

Spain

PM200AW#ABE

Australia

PM200AW#ABG

Europe

PM200AW#AK6

Thailand

PM200AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 10

xw6200X/XD3.4+/B80/
H1.0/280E/dF/s

Processor

Dual Intel Xeon processors 3.40 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.4+/B80/H1.0/280E/dF/s Country Code Key
N. America

PD900AW#ABA

Switzerland

(German/French)

PD900AW#AR8

Fr. Canadian

PD900AW#ABC

Switzerland

(Italian/English)

PD900AW#ACN

L. America

PD900AW#ABM

Dutch

PD900AW#ABH

Japan

(English)

PD900AW#ACF

Denmark

PD900AW#ACE

Japan

(Japanese)

PD900AW#ABJ

Asia/Pacific

(English)

PD900AW#AB4

UK

PD900AW#ABU

Korea

PD900AW#AB1

Germany

PD900AW#ABD

China

PD900AW#AB2

France

PD900AW#ABF

Taiwan

PD900AW#AB0

Italy

PD900AW#ABZ

India

PD900AW#ACJ

Spain

PD900AW#ABE

Australia

PD900AW#ABG

Europe

PD900AW#AK6

Thailand

PD900AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 11

xw6200X/XD3.4+/C74/
H2/280E/dF/s

Processor

Dual Intel Xeon processors 3.40 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

2 GB (2x1GB) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.4+/B80/H1.0/280E/dF/s Country Code Key
N. America

PR845AW#ABA

Switzerland

(German/French)

PR845AW#AR8

Fr. Canadian

PR845AW#ABC

Switzerland

(Italian/English)

PR845AW#ACN

L. America

PR845AW#ABM

Dutch

PR845AW#ABH

Japan

(English)

PR845AW#ACF

Denmark

PR845AW#ACE

Japan

(Japanese)

PR845AW#ABJ

Asia/Pacific

(English)

PR845AW#AB4

UK

PR845AW#ABU

Korea

PR845AW#AB1

Germany

PR845AW#ABD

China

PR845AW#AB2

France

PR845AW#ABF

Taiwan

PR845AW#AB0

Italy

PR845AW#ABZ

India

PR845AW#ACJ

Spain

PR845AW#ABE

Australia

PR845AW#ABG

Europe

PR845AW#AK6

Thailand

PR845AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 12

xw6200X/XD3.6/C74/
H1.0/280E/dF/s

Processor

Intel Xeon processor 3.60 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.6/C74/H1.0/280E/dF/s Country Code Key
N. America

PM201AW#ABA

Switzerland

(German/French)

PM201AW#AR8

Fr. Canadian

PM201AW#ABC

Switzerland

(Italian/English)

PM201AW#ACN

L. America

PM201AW#ABM

Dutch

PM201AW#ABH

Japan

(English)

PM201AW#ACF

Denmark

PM201AW#ACE

Japan

(Japanese)

PM201AW#ABJ

Asia/Pacific

(English)

PM201AW#AB4

UK

PM201AW#ABU

Korea

PM201AW#AB1

Germany

PM201AW#ABD

China

PM201AW#AB2

France

PM201AW#ABF

Taiwan

PM201AW#AB0

Italy

PM201AW#ABZ

India

PM201AW#ACJ

Spain

PM201AW#ABE

Australia

PM201AW#ABG

Europe

PM201AW#AK6

Thailand

PM201AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 13

xw6200X/XD3.6+/B80/
H1.0/280E/dF/s

Processor

Dual Intel Xeon processors 3.60 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

1 GB (2x512) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

80 GB SATA/150 7200 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.6+/B80/H1.0/280E/dF/s Country Code Key
N. America

PD902AW#ABA

Switzerland

(German/French)

PD902AW#AR8

Fr. Canadian

PD902AW#ABC

Switzerland

(Italian/English)

PD902AW#ACN

L. America

PD902AW#ABM

Dutch

PD902AW#ABH

Japan

(English)

PD902AW#ACF

Denmark

PD902AW#ACE

Japan

(Japanese)

PD902AW#ABJ

Asia/Pacific

(English)

PD902AW#AB4

UK

PD902AW#ABU

Korea

PD902AW#AB1

Germany

PD902AW#ABD

China

PD902AW#AB2

France

PD902AW#ABF

Taiwan

PD902AW#AB0

Italy

PD902AW#ABZ

India

PD902AW#ACJ

Spain

PD902AW#ABE

Australia

PD902AW#ABG

Europe

PD902AW#AK6

Thailand

PD902AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 14

xw6200X/XD3.6+/C74/
H2/280E+/dF/s
– Trader station

Processor

Dual Intel Xeon processors 3.60 GHz 1 MB/800 MHz FSB with EM64T

OS

Microsoft Windows XP Professional

Cache Memory

1 MB L2 per processor

Memory

2 GB (2x1) DDR2-400 ECC Registered

Optical Drive

16X DVD-ROM

Hard Drive

74 GB SATA/150 10,000 rpm (1st)

Graphics

NVIDIA Quadro NVS 280 PCI Express included in base configuration - Alternative
graphics card options should be ordered separately - they are listed below:
NVIDIA Quadro NVS 280 PCI (64 MB, VGA & DVI, can be added as second card)
NVIDIA Quadro NVS 400 PCI (64 MB, quad head, VGA & DVI)
NVIDIA Quadro FX 330 PCI Express (64 MB)
ATI FireGL V3100 PCI Express (128 MB)
NVIDIA Quadro FX 1300 PCI Express (128 MB)
ATI FireGL V5100 PCI Express (128 MB) (available September 2004)
NVIDIA Quadro FX 3400 PCI Express (256 MB)

NOTE:

Please see Part Numbers in After market options/Standalone accessories

section.

Mouse

HP scroll mouse (PS/2)

Other

Includes Floppy Drive and Standard PS/2 Keyboard

xw6200X/XD3.6+/C74/H2/280E+/dF/s Country Code Key
N. America

PM202AW#ABA

Switzerland

(German/French)

PM202AW#AR8

Fr. Canadian

PM202AW#ABC

Switzerland

(Italian/English)

PM202AW#ACN

L. America

PM202AW#ABM

Dutch

PM202AW#ABH

Japan

(English)

PM202AW#ACF

Denmark

PM202AW#ACE

Japan

(Japanese)

PM202AW#ABJ

Asia/Pacific

(English)

PM202AW#AB4

UK

PM202AW#ABU

Korea

PM202AW#AB1

Germany

PM202AW#ABD

China

PM202AW#AB2

France

PM202AW#ABF

Taiwan

PM202AW#AB0

Italy

PM202AW#ABZ

India

PM202AW#ACJ

Spain

PM202AW#ABE

Australia

PM202AW#ABG

Europe

PM202AW#AK6

Thailand

PM202AW#AKL

QuickSpecs

HP Workstation xw6200

Standard Features - Preconfigured Global Models

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 15

Processors

2nd Intel Xeon™ processor with EM64T extensions and Hyper-Threading

Intel Xeon processor at 2.8 GHz with 800 MHz FSB & 1 MB of L2 cache

DY665A

Intel Xeon processor at 3.0 GHz with 800 MHz FSB & 1 MB of L2 cache

DY666A

Intel Xeon processor at 3.2 GHz with 800 MHz FSB & 1 MB of L2 cache

DY667A

Intel Xeon processor at 3.4 GHz with 800 MHz FSB & 1 MB of L2 cache

DY668A

Intel Xeon processor at 3.6 GHz with 800 MHz FSB & 1 MB of L2 cache

DY669A

Operating Systems

Red Hat Enterprise Linux Workstation 3 Update 2 (32-bit)

PD862A

Red Hat Enterprise Linux Workstation 3 Update 2 (64-bit)

PD863A

Graphics

Multi display solutions

PCI

PCI-

Express

NVIDIA Quadro NVS 280 (64 MB, VGA & DVI)

X

AA932A

NVIDIA Quadro NVS 400 (64 MB, quad head, VGA & DVI)

X

AA605A

Quadro NVS 400 DVI cables

NA

AA606A

NVIDIA Quadro NVS 280 PCI-E (64 MB, VGA & DVI)

X

DY650A

DMS-59 to Dual DVI Cable for NVS cards

X X

DL139A

NVIDIA Quadro FX 330 (64 MB)

X

PB332A

ATI FireGL V3100 (128 MB)

X

PE949A

NVIDIA Quadro FX 1300 (128 MB)

X

PB331A

ATI FireGL V5100 (128 MB)

X

PB330A

NVIDIA Quadro FX 3400 (256 MB)

X

PB329A

Hard Drives

SATA Hard Drives

40 GB SATA/150 Hard Drive (7200 rpm)

PB371A

80 GB SATA/150 Hard Drive (7200 rpm)

DE705A

160 GB SATA/150 Hard Drive (7200 rpm)

DE706A

250 GB SATA/150 Hard Drive (7200 rpm)

DS702A

36 GB SATA/150 Hard Drive (10,000 rpm)

DU962A

74 GB SATA/150 Hard Drive (10,000 rpm)

DX760A

SATA power cable kit (2 per kit)

DN733A

xw6200 SATA data cable

DY662A

SCSI Hard Drives

73 GB Ultra320 SCSI Hard Drive (10,000 rpm)

AA613A

300 GB Ultra320 SCSI Hard Drive (10,000 rpm)

DY672A

36 GB Ultra320 SCSI Hard Drive (15,000 rpm)

AA616A

73 GB Ultra320 SCSI Hard Drive (15,000 rpm)

AA617A

146 GB Ultra320 SCSI Hard Drive (15,000 rpm)

DY671A

Bracket HDD 3.5to5.25 xw6200

DY659A

Cable, 3 port SCSI xw4200/6200

DY661A

QuickSpecs

HP Workstation xw6200

After-Market Options

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 16

Controllers

SCSI Controllers

PCI

PCI-

Express

U320 SCSI Controller RAID 0,1 & external connector

X

DZ554A

Ultra320 SCSI RAID Adaptec 2120S (Windows only, includes external
connector)

X

AA850A

Storage devices

256 MB USB 2.0 Drive Key II (Available Fall 2004)

PH657A

1.44 MB Internal Floppy Drive

DY670A

Input/Output Devices

Keyboards

HP PS/2 Standard Keyboard (Carbonite/Silver)

DT527A

HP USB Standard Keyboard (Carbonite/Silver)

DT528A

HP USB 2004 Modular Keyboard

DT530A

Pointing Devices

HP PS/2 2-Button Scroll Mouse (Carbonite)

DD440B

HP USB 2-Button Optical Scroll Mouse (Carbonite/Silver)

DC172B

HP PS/2 3-Button Mouse

AA778A

HP USB Optical 3-button mouse

DY651A

USB Spaceball 5000

DV675A

USB SpaceMouse

DZ203A

Networking

NICs

PCI

PCI-

Express

Intel Pro/1000MT

X

DC193A

HP Gigabit by Broadcom (BCM5782)

X

DC194A

Memory

(DIMMs)

400 MHz DDR-2 PC2-3200 ECC Registered DIMMs

256 MB DDR-2 PC2-3200 (400 MHz) ECC Registered

DY656A

512 MB DDR-2 PC2-3200 (400 MHz) ECC Registered

DY658A

1 GB DDR-2 PC2-3200 (400 MHz) ECC Registered

DY655A

2 GB DDR-2 PC2-3200 (400 MHz) ECC Registered

DY657A

Monitors

TFTs

HP TFT L2335 (23-inch)

P9615W#

HP TFT L2035 (20.1-inch)

P9614W#

HP TFT L1925 (19.1-inch)

P9626A

CRTs

HP P1230 (22-inch)

P9613A

Multimedia

PCI

PCI-

Express

IEEE1394 Firewire PCI card (Windows only)

X

PA997A

QuickSpecs

HP Workstation xw6200

After-Market Options

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 17

Optical Drives

DVD-ROM Drive

16X/40X DVD-ROM w/ +R read

AA620A

CD-ROM Drive

48X Max CD-ROM Drive

DC143B

CD-RW Drive

48X/32X/48X CD-RW Drive

DE205A

Combo Drive

48X/32X Combo DVD-ROM/CD-RW Drive

DE206A

DVD+R/+RW Drive

8X 4.7GB DVD+R/+RW Drive (Windows version)

DS703A

8X 4.7GB DVD+R/+RW Drive (Linux version)

DT839A

1.44MB Internal Floppy Disk Drive

D5710B

Removable Storage

256 MB USB 2.0 II Drive Key

PH657A

HP DAT24i Internal DDS3 tape drive

C1555D

HP DAT24e External DDS3 tape drive

C1556D

HP DAT40i Internal DDS4 tape drive

C5686B

HP DAT40e External DDS4 tape drive

C5687C

HP DAT72i Internal DAT72 tape drive

Q1522A

HP DAT72e External DAT72 tape drive

Q1523A

Security

Chassis clamp lock, universal, no cable

DE817A

Chassis clamp lock, universal, with cable

DE818A

Brackets/Stands

xw6200 sliding rack kit

DY663A

Depth Adjustable Rails (stationary)

332558-B21

Sliding Shelf kit

234672-B21

Fixed shelf kit

253449-B21

Other Devices

IDE Cable Kit xw62/82 (2nd)

DY660A

Front Card Guide and Fan Kit

DY648A

Software

HP Remote Graphics V2 LTU for HP WS

PE672A

HP Remote Graphics V2 LTU for non-HP

PE673A

HP Remote Graphics V2 Rcvr LTU

PE674A

HP Remote Graphics V2 software media

PE675A

Remote Workstation Sender SW Module

DM497A

Remote Workstation Receiver SW Module

DM498A

QuickSpecs

HP Workstation xw6200

After-Market Options

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 18

E7525 chipset
DDR-2 SDRAM ECC REGISTERED MEMORY

It is not necessary to add memory in pairs. Memory upgrades are accomplished by adding single or multiple DIMMs of the same or varied sizes. This
chart does not represent all possible memory configurations. The Intel E7525 chipset supports ECC Registered 400 MHz (PC2-3200) DDR-2 memory
only.
If only using one DIMM, install it in socket 1. Additional DIMM slots should be populated consecutively; socket 2, then 3, 4, etc. For best performance
install memory in pairs (a pair would be considered to be the DIMMs in sockets 1 & 2, 3 & 4) and do not mix speeds. It is always best to load the
memory in pairs rather than as single DIMMs (two 512 MB DIMMs will have better performance than a single 1 GB DIMM). For efficient dual-channel
performance, each pair of DIMMs must be same size and same DRAM technology. If mixing single sided and double sided memory, load the double
sided DIMM pairs first. ECC Registered memory must be used.

MAXIMUM MEMORY

Supports up to 8 GB of DDR SDRAM

POSSIBLE MEMORY CONFIGURATIONS

Not all memory configurations possible are represented below.

DIMM Size

Slot

1 2 3 4
256 MB 256 MB
512 MB 512 MB
512 MB 256 MB 256 MB

1 GB 1 GB
1 GB

256 MB 256 MB 256 MB 256 MB
2 GB 1 GB 1 GB
2 GB

512 MB 512 MB 512 MB 512 MB
4 GB 1 GB 1 GB 1 GB 1 GB
8 GB 2 GB 2 GB 2 GB 2 GB

QuickSpecs

HP Workstation xw6200

Memory

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 19

Tower configuration

Quantity Supported

Position Supported

Controller

Convertible Minitower

Optional Diskette Drive

1 3

Diskette

5.25" Storage Drive Bays (position 1
drive bay is limited to 198 mm depth
when optional smart cover solenoid
lock is installed; position 2 drive bay
can be converted to an internal 3.5"
3rd hard drive bay with optional
bracket)

2 1, 2

IDE

3.5" Storage Drive Bays with
acoustic dampening rail assemblies

2 (3)

4, 5 (and 2, for 3rd drive using

optical bay)

SATA or optional SCSI

QuickSpecs

HP Workstation xw6200

Storage

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 20

System Board

Architecture

Xeon EM64T/PCI-E

Chipset

Intel E7525/ICH5R Chipset

Super I/O Controller

SMSC LPC47B397

System Board Form Factor

ATX (slightly larger than standard ATX)

Processor Socket

Dual 604 Pin ZIF

DIMM Connectors (DDR2,

1.8V)

4

AGP Connector (1.5V)

None

Integrated Graphics

None

PCI Connectors (5.0V)

4 full length 33 MHz 32-bit

PCI Express Connectors

1 x16

1 x8 (with x4 electricals)

PCI card guide

Optional, tool-free support for all full-length cards with PCI extender

Flash ROM

Yes

AC97 integrated audio

Yes

CD ROM IN (Audio)

Yes

AUX IN (Audio)

Yes

Clear CMOS Button

Yes

CPU Fan Header

Yes

Chassis Fan Header

Yes

Chassis Speaker Header

Yes

CMOS Battery Holder –
Lithium

Yes

Hood Lock Header

Yes

Hood Sensor Header

Yes

Multibay Header

Yes

Hard drive acoustic
dampening rails

Standard in 2 internal 3.5" bays, tool-free

Integrated SATA RAID

RAID 0 and RAID 1
Supports one RAID array on 2 ports
Creation of 2 drive HDD array

Integrated Broadcom

Yes

NetXtreme Gigabit Ethernet for
HP

Yes

Wake-On-Lan®

Yes

ASF 1.0 (Alert Standard
Format)

Yes

Power Supply Header

Yes

Power Switch, Power LED
& Hard Drive LED Header

Yes

Password Clear Header

Yes

Riser Connector

None

HDD activity LED Header

Yes, 2 & 4 pin

PCI extender that connects to
System Board

None

QuickSpecs

HP Workstation xw6200

Additional Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 21

Cooling

Cooling Solutions Supported

Yes

Power Supply Fan (Variable
Speed)

92 x 25 mm

Processor Fan-Heatsink
(Variable Speed)

70 x 15 mm

Chassis Fan (front)

One 92 x 25 mm (optional)

Chassis Fan (rear)

Two 92 x 25 mm (standard)

Internal Speaker

Standard

Power Supply

Full Ranging Input

Yes

Active Power Factor
Correction (APFC) (Input
Current is nearly 1/2 a non­APFC PS)

Yes

Passive Power Factor
Correction (PFC)

No

Operating Voltage Range

90 - 264 VAC/118 VAC

Rated Voltage Range

100 – 240 VAC

Rated Line Frequency

50-60 Hz/400Hz

Operating Line Frequency
Range

47 – 66 Hz/393 – 407Hz

Rated Input Current

9A/9A

Maximum Rated Power

500 W

Heat Dissipation

Typical 1228.9 btu/hr

Maximum 1706 btu/hr

PS Size (wide x high x deep)

150 mm x 98 mm x 168 mm

Energy Star Compliant

Yes

FEMP Standby Power
Compliant (<2W in S5 - Power
Off)

No

Surge Tolerant Full Ranging
Power Supply

Withstands power surges up to 2000V

Typical configuration power
consumption

2 processors (2x3.6GHz Xeon), 1 GB memory (2x512 MB)

Two hard drives (2xSATA 40 GB), DVD-ROM drive

PCI-Express Graphics Card (FX 1300)

Floppy, Monitor

Input Power consumption

@ 120Vac/60Hz

Typical operating mode

(system busy)

360 W

= 1228.9 btu/hr

Windows XP Idle

201 W

= 685.9 btu/hr

Hibernate mode (S4)

6.4 W

= 21.84 btu/hr

Power Off (S5)

6.4 W

= 21.84 btu/hr

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 22

ROM Features

Description

Instantly Available PC

Allows for very low power consumption with quick resume time

ROM Based F10 Setup and
diagnostics

Review and customize BIOS settings

Remote System Installation via
F12 (PXE) (Remote Boot from
Server)

Allows a new or existing system to boot over the network and download software, including the operating system

System/Emergency ROM Flash
Recovery with Video

Recovers corrupted system BIOS

ROM revision levels

Identifies system ROM revision levels and reports in ROM-based F10 setup
Version is stored in an industry standard memory location (SMBIOS) so that management SW applications can
use and report this information

System board revision level

Allows management SW to read the revision level of the system board
Revision level is digitally encoded into the hardware and cannot be modified

Auto Setup when New
Hardware Installed

System automatically detects addition of new hardware

Serial, Parallel, USB, Audio,
Network, Enable/Disable Port
Control

Enable or disables serial, parallel, USB, audio, and network ports

Removable Media Write/
Boot Control

Prevents ability to boot from removable media on supported devices (and can disable writes to media)

Power-On Password

Prevents an unauthorized person from booting up the computer

Setup Password

Prevents an unauthorized person from changing the system configuration

Replicated Setup

Saves BIOS settings to diskette or USB disk-on-key in human readable file. Repset.exe utility can then replicate these
settings on machines being deployed without entering ROM-based F10 setup

Memory Change Alert
(Requires HP Client Manager
Software)

Alerts management console if memory is removed or changed

Thermal Alert (Requires HP
Client Manager Software)

Monitors the temperature state within the chassis. Three modes:

NORMAL – normal temperature ranges
ALERTED – excessive temperatures are detected. Raises a flag so action can be taken to avoid shutdown or
provide for a smoother system shutdown
SHUTDOWN – excessive temperatures are encountered. Automatically shuts down the computer without
warning before hardware component damage occurs

Master Boot Record Security

Detects changes to MBR and optional restoration, useful in protecting from viruses

Remote ROM Flash

Provides secure, fail-safe ROM image management from a central network console

Remote Wakeup/shutdown

System administrators can power on, restart, and power off a client computer from a remote location.
Enables cost-effective power consumption when the administrator needs to distribute software, perform
security management, or update the ROM

ACPI (Advanced Configuration
and Power Management
Interface)

Allows the system to wake from a low power mode
Controls system power consumption, making it possible to place individual cards and peripherals in a low­power or powered-off state without affecting other elements of the system
Supports ACPI 2.0 for full compatibility with 64-bit operating systems

Keyboard-less Operation

The system can be operated without a keyboard

SMBIOS

System Management BIOS 2.3.5, previously known as DMI BIOS, for system management information

Localized ROM Setup

Common BIOS image supports configuration (Setup) in 11 languages, with local keyboard mappings

Asset tag

Allows user or MIS to set unique tag string in ROM

Ownership tag

Allows user or MIS to set unique tag string in ROM

Memory Scrubbing

Allows memory controller to transparently correct transient ECC errors in the background

Memory Remapping

Allows system memory lost to PCI devices to be reclaimed above 4 GB, for use with operating systems that support
more than 4 GB (Windows XP 64-bit edition, Linux)

Per-slot control

Allows individual slot configuration (option ROM., latency)

Adaptive cooling

Fan control parameters are set according to detected hardware configuration for optimal acoustics

Pre-boot diagnostics

Early (pre-video) critical errors are reported via beeps and blinks on the power LED

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 23

Other deployment &
management features

HP Client Management
Solutions

HP Client Management Solutions help simplify management of Workstations and significantly reduce total ownership
costs. These solutions share a common design and are highly integrated due to the extensive work between HP and
its partner Altiris.

HP Client Manager Software is included free with all HP business PCs and Workstations. It enables central tracking,
monitoring, and management of the hardware aspects of HP client systems:

Get valuable hardware information such as CPU, memory, video, and security settings
Monitor system health to fix problems before they occur
Install drivers and BIOS updates without visiting each PC
Remotely configure BIOS and security settings
Automate processes to quickly resolve hardware problems

Additional Altiris solutions (fee-based) are available to address Workstation management challenges through the
entire IT lifecycle including:

Inventory assessment
Software license compliance
Personality migration
Software image deployment
Software distribution
Asset management
Client backup and recovery
Problem resolution

Visit

http://www.hp.com/go/easydeploy

for more information, to download HP Client Manager Software, and to

evaluate the Altiris solutions.

System Software Manager
(free)

A free utility that detects and updates BIOS, device drivers, and management agent versions on your networked PCs
and workstations

Altiris Local Recovery

Provides data and system file protection for HP business PCs to enable fast recovery of information that is
accidentally deleted or if the system becomes corrupted. Designed for disconnected or seldom-connected users,
Local Recovery protects your HP computer's data and system state by taking scheduled snapshots, which are then
stored in a protected area on the local hard disk. System backup and disaster recovery is now simple and fast for all
users, regardless of connectivity

Replicated Setup

Saves BIOS settings to diskette or USB disk-on-key in human readable file. Repset.exe utility can then replicate these
settings on machines being deployed without entering ROM-based F10 setup

Software Restore CD

Restores computer to its original factory shipping image

Asset Tag

Repository for storing company-specific property asset numbers for easy tracking
Initially set equal to the system serial number
Stored in a protected section of non-volatile memory that can be accessed and modified with the F10 Setup
program

DIMM Serial Presence Detect

Detects whether or not memory DIMMs are present and their type

Hard drive serial number,
model, and manufacturer

Hard drive manufacturer, model, and serial number is stored in the hard drive firmware and reported in ROM-based
F10 setup

System serial number, model,
& manufacturer

System serial number, model, & manufacturer stored in a non-volatile memory and can be retrieved with management
SW or viewed in ROM-based F10 setup

ROM revision levels

Identifies system ROM revision levels and reports in ROM-based F10 setup
Version is stored in an industry standard memory location (SMBIOS) so that management SW applications can use
and report this information

Memory Change Alert
(Requires HP Client Manager
Software)

Alerts management console if memory is removed or changed

Ownership Tag

A user-defined string stored in non-volatile memory that is displayed in the BIOS splash screen

Hard drive interface Integrity
Monitoring
(CRC Checking)

A feature of SATA and SCSI, Cyclic Redundancy Checking provides data transfer verification and proactive
notification of hard drive data transmission problems with recommendations for enhancing system performance. It
detects all the following errors' types:

single bit errors
double bit errors

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 24

an odd number of errors
error bursts up to 32-bits long

Drive Self Tests (DPS)

Drive Protection System (Adaptec and LSI SCSI controllers do not offer DPS)
A diagnostic hard drive self test. It scans critical physical components and every sector of the hard drive for
physical faults and then reports any faults to the user.
Running independently of the operating system, it can be accessed through the computer's setup procedure.
It produces an evaluation on whether the hard drive is the source of the problem and needs to be replaced.

The system expands on the Self-Monitoring, Analysis, and Reporting Technology (SMART), a continuously running
systems diagnostic that alerts the user to certain types of failures
DPS Access through F10 Setup during Boot (F10 diagnostic access not available with SCSI drives)

SMART Technology
(Self-Monitoring, Analysis and
Reporting Technology)

Allows hard drives to monitor their own health and to raise flags if imminent failures were predicted
Predicts failures before they occur. Tracks fault prediction and failure indication parameters such as re-allocated
sector count, spin retry count, calibration retry count
By avoiding actual hard drive failures, SMART hard drives act as "insurance" against unplanned user downtime and
potential data loss from hard drive failure
SMART I – Drive Failure Prediction
SMART II – Off-Line Data Collection
SMART III – Off-Line Read Scanning with Defect Reallocation

Security Features

Access panel key lock
(standard)

Prevents removal of the access panel and all internal components including optical and floppy drives

Smart Cover solenoid lock
(optional)

Prevents removal of the access panel and all internal components including optical and floppy drives. Eliminates the
need for a physical key by enabling password-protected locking & unlocking by a local or remote user.

Padlock (optional)

Prevents entire system theft and discourages access panel removal. 7mm diameter padlock loop at rear of system.

Kensington Cable Lock
(optional)

Prevents entire system theft only. 3mm x 7mm slot at rear of system.

Universal chassis clamp lock
(optional)

The version without a cable discourages access panel removal and prevents theft of IO devices. The version with a
cable additionally prevents entire system theft and allows multiple systems to be secured with a single cable.

Intrusion Sensor (optional)

Notifies a local or remote user when the chassis access panel has been opened.

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 25

Serviceability Features of
System

Access panel

Tool-less, one-handed

Optical drives

Tool-less

Floppy drive

Tool-less

Hard drives

Tool-less

Expansion cards

Tool-less

Chassis fan removal

Tool-less

Green user touch points

Yes, on tool-free internal chassis mechanisms

Color-coordinated cables and
connectors

Yes

Memory

Tool-less, can be upgraded without removing any internal components

CPUs

Tool-less, can be upgraded without removing any internal components

Power supply diagnostic LED

Yes, dual function: AC OK & power OK

Power Button

Yes, ACPI multi-function

Power LED

Yes, dual color LED indicates normal operation and faults.

Hard drive activity LED

Yes

Internal speaker

Yes, used for pre-boot diagnostic beep codes

Dual Color Power and HD LED
on Front of Computer
(Indicates Normal Operations
and Fault Conditions)

green – normal
red – fault

System/Emergency ROM Flash
Recovery
with Video

Recovers corrupted system BIOS.

Configuration Record SW

Yes

Over-Temp Warning on
Screen (Requires IM Agents)

Yes

OS CD (Restore OS CD)

Restores computer to its original factory shipping image

Restore CD

Restores the computer to its original factory shipping image

Flash ROM

Yes

3.3V Aux Power LED on
System PCA

Yes

Dual Function 5V Aux Power
LED (ON)/PS_ON LED (OFF)
on System PCA

Yes

Diagnostic Power Switch LED
on board

Yes

Clear Password Jumper

Yes

Clear CMOS Button

Yes

CMOS Battery Holder for easy
Replacement

Yes

Processor ZIF Socket for easy
Upgrade

Yes

DIMM Connectors for easy
Upgrade

Yes

NIC LEDs (integrated) (Green
& Amber)

Used to determine NIC status

ASF 1.0 support (Alert
Standard Format)

Industry-standard specification for network alerting in operating system-absent environments

Dual function front power
switch

Also acts as a reset switch when held for 4 seconds

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 26

Service and Support

On-site Warranty and Service

(Note 1)

: This three-year, limited warranty and service offering delivers three years of

on-site, next business-day

(Note 2)

service for parts and labor and includes free telephone support

(Note 3)

24 x 7.

Global coverage

(Note 2)

ensures that any product purchased in one country and transferred to another, non-

restricted country will remain fully covered under the original warranty and service offering.

NOTE 1:

Terms and conditions may vary by country. Certain restrictions and exclusions apply.

NOTE 2:

On-site service may be provided pursuant to a service contract between HP and an authorized HP third­party provider, and is not available in certain countries. Global service response times are based on commercially
reasonable best effort and may vary by country.

NOTE 3

: Technical telephone support applies only to HP-configured, HP and HP-qualified, third-party hardware and

software. Toll-free calling and 24 x 7 support may not be available in some countries.

QuickSpecs

HP Workstation xw6200

Technical Specifications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 27

AC97 Integrated ADI 1981B
Audio

Type

Integrated

AC ‘97 Stereo Codec

Yes

FM Synthesis Support

Yes – Yamaha XG Lite

OPL3 FM Synthesis
Support

Yes

Sound Blaster
Compatibility

Yes

Audio Jacks

Microphone-In (20-K ohm Input Impedance); rear stereo and front analog microphone
ports

Line-In (12-K ohm Input Impedance)
Line-Out * (less than 800 ohms Output Impedance, expects at least a 10-K ohm load)
Headphone-Out (2.5 Ohms Output Impedance, expects at least a 32 ohm load)

NOTE:

*Internal Speaker Amplifier is for Internal Speaker only. External Speakers need to be powered externally.

Sampling

7 kHz – 48 kHz

Wavetable Syntheses

(software)

Yes – GM and FM Midi Support, Direct Music and Down Loadable Soundset (4 Meg
DLS Level 1 and 2 Support)

3D Positional Sound

No

Digital Audio

Yes

Analog Audio

Yes

Number of Channels on
Line-Out

(mono/stereo)

Stereo (Left & Right channels)

Internal Audio Speaker
Power Rating

3W

Internal Speaker

Yes

Hardware Equalizer for
Internal Speaker

Fixed 7 Band ParametricEQ

External Speaker Jack

(Line-Out)

Yes

QuickSpecs

HP Workstation xw6200

Technical Specifications - Audio

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 28

HP Gigabit by Broadcom

(BCM5782)

NIC

Connector

RJ-45

Controller

Broadcom 5782 PCI LAN Controller

Memory

Integrated 96Kb frame buffer memory

Data rates supported

10/100/1000 Mbps

Compliance

IEEE 802.1A, 802.1P, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,

802.3x flow control

Bus architecture

PCI 2.2

Data path width

32-bit, 33/66 MHz bus interface

Data transfer mode

Bus-master DMA

Hardware certifications

FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union

Power requirement

1.48 watts @ +3.3V AUX supply with 5V tolerance

Boot ROM support

Yes

Network transfer rate

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T, 1000 Mbps

Environmental

Operating temperature

32° to 131° F (0° to 55° C)

Operating humidity

85% at 131° F (55° C)

Dimensions

4.7 x 2.0 x 0.08 in (12 x 5 x 1.9 cm)

Operating system driver
support

Microsoft Windows NT 4.0, Microsoft Windows 98, Microsoft 2000, Microsoft XP,
Linux 2.2, Linux 2.4

Management capabilities

ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Broadcom mgmt utility

Alerting

ASF 1.0

Kit contents

Broadcom 5782, CD, Broadcom Gigabit Ethernet for HP, drivers, quick install guide,
product warranty statement

QuickSpecs

HP Workstation xw6200

Technical Specifications - Communications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 29

Intel Pro 1000 MT Gigabit
NIC

Connector

RJ-45

Controller

Intel 82540EM Gigabit Controller

Memory

Integrated 96Kb frame buffer memory

Data rates supported

10/100/1000 Mbps

Compliance

IEEE 802.1A, 802.1P, 802.1P, 802.1Q, 802.2, 802.3, 802.3AB and 802.3u compliant,

802.3x flow control

Bus architecture

PCI 2.2

Data path width

32-bit, 33/66 MHz bus interface

Data transfer mode

Bus-master DMA

Hardware certifications

FCC, B, CE, TUV- cTUVus Mark Canada and United States, TUV- GS Mark for
European Union

Power requirement

1.48 watts @ +3.3V AUX supply with 5V tolerance

Boot ROM support

Yes

Network transfer rate

10BASE-T (half-duplex) 10 Mbps
10BASE-T (full-duplex) 20 Mbps
100BASE-TX (half-duplex) 100 Mbps
100BASE-TX (full-duplex) 200 Mbps
1000BASE-T, 1000 Mbps

Environmental

Operating temperature

32° to 131° F (0° to 55° C)

Operating humidity

85% at 131° F (55° C)

Dimensions

6.4 x 4.8 x 0.8 in (16.3 x 12.1 x 1.9 cm)

Operating system driver
support

Microsoft® Windows® NT® 4.0, Microsoft Windows 98, Microsoft 2000, Microsoft XP,
Linux 2.2, Linux 2.4

Management capabilities

ACPI, WOL and DMI 2.0, PXE 2.0, WfM 2.0, Intel PROset II utility

Kit contents

The Intel Pro 1000 MT NIC, CD containing Intel PROset II NIC drivers, quick install guide,
product warranty statement

QuickSpecs

HP Workstation xw6200

Technical Specifications - Communications

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 30

LSI Logic LSI20320
Ultra320 SCSI single
channel host adapter

Bus architecture

PCI-X (backward compatible with PCI)

Number of supported
devices

Up to 15 SCSI devices

Interface protocol

64 bit, 133MHz PCI-X

Host bus transfer rate

Up to 1MB/s

SCSI data transfer rate

Up to 320MB/s per channel

SCSI Bus

Wide Ultra320, Low Voltage Differential, and Ultra Wide Single-Ended

Internal connector

68-pin HD

External connector

68 pin VHDCI

Total connectors

2

Plug and Play Support

No

Dimensions

(H x L)

6.6 x 2.5 in (16.9 x 6.4 cm)

Approvals

CE, VCCI, Canada, C-Tick, FCC class B, UL 94VO

Operating system support

Microsoft® Windows® XP

Kit contents

Controller card, driver CD, LED cables, user documentation and warranty card.

Adaptec SCSI RAID 2120S
Card

Dimensions

(H x D)

2.5 x 6.6 in (6.4 x 16.8 cm) Low profile card

RAID level

0, 1, 10, 5, 50, JBOD

Data Transfer Rate

Up to 320 MB/s

Cache Memory

64 MB (onboard)

Device Support

Up to 15 SCSI devices

Bus Type

64-bit/66 MHz PCI
(Also support 32-bit/33 MHz PCI)

Internal Connectors

One 68-pin high-density

External Connectors

One 68-pin VHDCI

System Requirements

Intel PC or equivalent with available PCI slot

Operating Temperature

32° to 131° F (0° to 55° C)

Power Requirements

4 amps @ +5V

Operating System Support

Windows® 2000 Professional, Windows XP Professional

Other

Optimized disk utilization
Online RAID Level Migration
Online capacity expansion
Immediate RAID availability (background initialization)
S.M.A.R.T. support

Kit Contents

Controller card, driver CD, LED cables, user documentation and warranty card.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Controllers

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 31

7200 rpm Serial ATA Hard
Drives

40GB

Capacity

40020664320 bytes

Height

1 in (2.6 cm)

Width

Media diameter: 3.5 in (8.9.x cm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

2 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

1.0 ms

Average

8.5 ms

Full-Stroke

18.0 ms

Rotational Speed

7,200 rpm

Logical Blocks

78,165,360

Operating Temperature

32° to 140° F (0° to 60° C)

80GB

Capacity

80026361856 bytes

Height

1 in (2.6 cm)

Width

Media diameter: 3.5 in (8.9.x cm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

8 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

1.0 ms

Average

8.5 ms

Full-Stroke

18 ms

Rotational Speed

7,200 rpm

Logical Blocks

156,301,488

Operating Temperature

32° to 140° F (0° to 60° C)

160GB

Capacity

160041885696 bytes

Height

1 in (2.6 cm)

Width

Media diameter: 3.5 in (8.9.x cm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

8 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

1.0 ms

Average

8.5 ms

Full-Stroke

18 ms

Rotational Speed

7,200 rpm

Logical Blocks

312,581,808

Operating Temperature

32° to 140° F (0° to 60° C)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Hard Drives

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 32

250GB

Capacity

250059350016 bytes

Height

1 in (2.6 cm)

Width

Media diameter: 3.5 in (8.9 cm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

8 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.8 ms

Average

<9.0 ms

Full-Stroke

<

17 ms

Rotational Speed

7,200 rpm

Logical Blocks

488,397,168

Operating Temperature

41° to 131°F (5° to 55°C)

10,000 rpm SATA Hard
Drives

36GB

Capacity

37,019,566,080 bytes

Height

1.0 in (2.54 mm)

Width

Media diameter: 3.3 in (84mm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

8 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 ms

Average

4.5 ms

Full-Stroke

10.2 ms

Rotational Speed

10,000 rpm

Logical Blocks

72,303,840

Operating Temperature

41° to 131° F (5 to 55° C)

74GB

Capacity

74,355,769,344 bytes

Height

1.0 in (2.54 mm)

Width

Media diameter: 3.3 in (84mm)
Physical size: 4 in (10.2 cm)

Interface

Serial ATA

Synchronous Transfer
Rate

(Maximum)

150 MB/s

Buffer

8 MB

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 ms

Average

4.5 ms

Full-Stroke

10.2 ms

Rotational Speed

10,000 rpm

Logical Blocks

145,226,112

Operating Temperature

41° to 140° F (5 to 60° C)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Hard Drives

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 33

Ultra320 SCSI Hard Drives

(10,000 rpm)

73GB

Capacity

73,407,865,856 bytes

Height

1.0 in (2.54 cm)

Width

3.5 in (8.9 cm)

Interface

68 pin LVD SCSI

Synchronous Transfer
Rate

(Maximum)

320 MB/s

Buffer

8 Mbytes

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 msec

Average

<4.5 msec

Full-Stroke

<11.0 msec

Rotational Speed

10,000 rpm

Logical Blocks

143,374,738

Operating Temperature

40° to 130° F (5° to 55° C)

300GB

Capacity

300,000,000,000 bytes

Height

1.0 in (2.54 cm)

Width

3.5 in (8.9 cm)

Interface

68 pin LVD SCSI

Synchronous Transfer
Rate

(Maximum)

320 MB/s

Buffer

8 Mbytes

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 msec

Average

<4.5 msec

Full-Stroke

<11.0 msec

Rotational Speed

10,000 rpm

Logical Blocks

585,937,500

Operating Temperature

40° to 130° F (5° to 55° C)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Hard Drives

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 34

Ultra320 SCSI Hard Drives

(15,000 rpm)

36GB

Capacity

36,420,075,520 bytes

Height

1.0 in (2.54 cm)

Width

3.5 in (8.9 cm)

Interface

68 pin LVD SCSI

Synchronous Transfer
Rate

(Maximum)

320 MB/s

Buffer

8 Mbytes

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 msec

Average

<4.5 msec

Full-Stroke

<11.0 msec

Rotational Speed

15,000 rpm

Logical Blocks

71,132,960

Operating Temperature

40° to 130°F (5° to 55°C)

73GB

Capacity

73,407,865,856 bytes

Height

1.0 in (2.54 cm)

Width

3.5 in (8.9 cm)

Interface

68 pin LVD SCSI

Synchronous Transfer
Rate

(Maximum)

320 MB/s

Buffer

8 Mbytes

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 msec

Average

<4.5 msec

Full-Stroke

<11.0 msec

Rotational Speed

15,000 rpm

Logical Blocks

143,374,738

Operating Temperature

40° to 130°F (5° to 55° C)

146GB

Capacity

146,815,737,856 bytes

Height

1.0 in (2.5 cm)

Width

3.5 in (8.9 cm)

Interface

68 pin LVD SCSI

Synchronous Transfer
Rate

(Maximum)

320 MB/s

Buffer

8 Mbytes

Seek Time

(typical reads,
includes controller overhead,
including settling)

Single Track

0.3 msec

Average

<4.5 msec

Full-Stroke

<11.0 msec

Rotational Speed

15,000 rpm

Logical Blocks

143,374,738

Operating Temperature

40° to 130°F (5° to 55°C)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Hard Drives

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 35

USB Disk on Key

Dimensions

(HxWxD)

0.9 x 0.7 x 3.9 in (2.3 x 1.8 x 9.8 cm)

Weight

0.05 lb (0.02 kg)

USB Specification

1.1 and 2.0

Transfer Rate

Read-1023 KB/Sec; Write-850 KB/Sec

Storage Media

Solid state flash memory, no moving parts

Power Supply

USB Bus-powered, no external power required

Capacity

256 MB

QuickSpecs

HP Workstation xw6200

Technical Specifications - Removable Storage

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 36

PS/2 OR USB '04 Standard
Keyboard

Physical
characteristics

Keys

104, 105, 106, 107, 109 layout (depending upon
country)

Dimensions

(L x W x H)

18.0 x 6.4 x 0.98 in (45.8 x 16.3 x 2.5 cm)

Weight

2 lb (0.9 kg) minimum

Electrical

Operating voltage

+ 5VDC ± 5%

Power consumption

50-mA maximum (with three LEDs ON)

ESD

CE level 4, 15-kV air discharge

EMI - RFI

Conforms to FCC rules for a Class B computing device

Microsoft® PC 99 - 2001

Functionally compliant

Mechanical

Languages

38 available

Keycaps

Low-profile design

Switch actuation

55-g nominal peak force with tactile feedback

Switch life

20 million keystrokes (using Hasco modified tester)

Switch type

Contamination-resistant switch membrane

Key-leveling mechanisms

For all double-wide and greater-length keys

Cable length

6 ft (1.8 m)

Microsoft PC 99 - 2001

Mechanically compliant

Acoustics

43-dBA maximum sound pressure level

Environmental

Operating temperature

50° to 122° F (10° to 50° C)

Non-operating
temperature

-22° to 140° F (-30° to 60° C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

40 g, six surfaces

Non-operating shock

80 g, six surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Drop

(out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop

(in box)

42 in (107 cm) on concrete, 16-drop sequence

Operating system support

Windows® 2000 and Windows XP

Approvals

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC

Ergonomic compliance

ANSI HFS 100, ISO 9241-4, and TUVGS

Kit contents

Keyboard, keyboard software media, installation guide, warranty card, safety and
comfort

QuickSpecs

HP Workstation xw6200

Technical Specifications - Input/Output Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 37

USB Modular Keyboard

Physical
characteristics

Keys

104, 105, 106, 107, 109 layout (depending upon
country)

Dimensions

(L x W x H)

18.59 x 6.73 x 0.90 in (472 x 170 x 23 mm) with
numeric pad attached

Weight

2 lb (0.9 kg) minimum

Electrical

Operating voltage

+ 5VDC ±5%

Power consumption

50-mA maximum (with three LEDs ON)

System interface

USB Type A plug connector

ESD

CE level 4, 15-kV air discharge

EMI - RFI

Conforms to FCC rules for a Class B computing device

Microsoft® PC 99 - 2001

Functionally compliant

Mechanical

Languages

38 available

Keycaps

Low-profile design

Switch actuation

55-g nominal peak force with tactile feedback

Switch life

20 million keystrokes (using Hasco modified tester)

Switch type

Contamination-resistant switch membrane

Key-leveling mechanisms

For all double-wide and greater-length keys

Cable length

6 ft (1.8 m)

Microsoft PC 99 - 2001

Mechanically compliant

Acoustics

43-dBA maximum sound pressure level

Environmental

Operating temperature

50° to 122°F (10° to 50°C)

Non-operating
temperature

-22° to 140°F (-30° to 60°C)

Operating humidity

10% to 90% (non-condensing at ambient)

Non-operating humidity

20% to 80% (non-condensing at ambient)

Operating shock

40 g, six surfaces

Non-operating shock

80 g, six surfaces

Operating vibration

2-g peak acceleration

Non-operating vibration

4-g peak acceleration

Drop

(out of box)

26 in (66 cm) on carpet, six-drop sequence

Drop

(in box)

442 in (107 cm) on concrete, 16-drop sequence

Operating system support

Windows® 2000 and Windows XP

Approvals

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BSMI, C-Tick, MIC, USB-IF

Ergonomic compliance

ANSI HFS 100, ISO 9241-4, and TUVGS

Kit contents

Keyboard, numerical keypad, USB cable, I/O Security Software & Documentation CD
including Modular Access Keyboard software & installation guide, warranty card,
safety and comfort guide

QuickSpecs

HP Workstation xw6200

Technical Specifications - Input/Output Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 38

2-Button Scroll Mouse

(PS/2)

Scroll Wheel

8 mm

Maximum Rotation Speed

30 mm/s

Switch Type

Light force micro-switch

Switch Life

1 million operations

Mechanical Life

Minimum 200,000 revolutions

Environmental

Operating Temperature

50° to 122° F (10° to 50° C)

Non-operating
Temperature

-22° to 140° F (-30° to 60° C)

Operating Humidity

10% to 90% (non condensing at ambient)

Non-operating Humidity

20% to 80% (non condensing at ambient)

Operating Shock

40 g, 6 surfaces

Non-operating Shock

80 g, 6 surfaces

Operating Vibration

2 g peak acceleration

Non-operating Vibration

4 g peak acceleration

Mechanical

Resolution

400 ± 20% DPI

Tracking Speed

10 in/s maximum

Acceleration

100 in/s

Switch Actuation

85 g nominal peak force

Switch Life

1,000,000 operations (using Hasco modified tester)

Cable Length

2 m

PC98-99

Mechanically compliant

Regulatory Approvals

UL, CSA, FCC, CE Mark, TUV, TUV GS, VCCI, BCIQ, C-Tick

HP Optical Scroll Mouse

(USB)

Dimensions

(H x L x W)

1.5 x 4.5 x 2.5 in (3.8 x 11.6 x 6.3 cm)

Weight

0.27 lb (0.12 kg)

Cable length

72.8 in (185 cm)

System requirements

Microsoft® Windows® 95, 98, 2000, Me, and XP

HP 3-Button Mouse

(PS/2)

Dimensions/Weight

Height

1.42 in (3.6 cm)

Length

4.17 in (10.7 cm)

Width

2.87 in (7.4 cm)

Weight

5.20 oz (150 g)

Environmental

Operating temperature

32° to 104° F (0° to 40° C)

Non-operating
temperature

-4° to 140° F (-20° to 60° C)

Operating humidity

10% to 90% (non condensing at ambient)

Mechanical

Resolution

400 20% DPI

Tracking speed

10 in/s Maximum

Switch life

1,000,000 operations (using Hasco modified tester)

Switch type

Micro-switches

Tracking mechanism life

155 miles (250 km) at average speed of 10 in/s

Cable length

6 ft (1.8 m)

PC98-99

Mechanically compliant

QuickSpecs

HP Workstation xw6200

Technical Specifications - Input/Output Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 39

Spaceball 5000

(USB)

Physical characteristics

Dimensions

(H x W x D)

3.0 x 6.0 x 8.4 in (7.6 x 15.2 x 21.3 cm)

Ball Diameter

2.2 in (5.6 cm)

Weight

2.1 lb (9.94 kg)

Features

Six degrees of freedom motion control through the X,
Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC applications

Environmental

Operating temperature

50° to 104° F (10° to 40° C)

Non-operating
temperature

43° to 140° F (6° to 60° C)

Operating humidity

8% to 80% (non-condensing at ambient)

Non-operating humidity

5% to 80% (non-condensing at ambient)

Mechanical

Buttons

12 programmable (unshifted)

Ball Force Range

0.5 - 8.2N/1.8 - 29.5 oz

Ball Torque Range

0.085 – 0.33 oz-in. (6.91 Nmm)

Resolution

10 bits

Serial Specifications

Connector

USB 1.1 or greater

Cable Length

12.8 ft. (3.9 m)

Data Rate

USB model – 16 msec

Flow Control

Xon/Xoff (on PS/2 model only)

Software Drivers Available

USB model

Microsoft Windows XP

System Requirements

Disk Space

10 MB free disk space

Regulatory Approvals

UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN 50082, IEC 1000
4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick

HP SpaceMouse Plus USB

Physical characteristics

Dimensions

(H x W x D)

7.4 x 4.72 x 1.73 in (18.8 x 12.0 x 4.4 cm)

Cap Diameter

2 x 6.5 x 6.6 mm

Weight

1.5 lb (0.68 kg)

Features

Six degrees of freedom motion control through the X,
Y, Z axis (pitch, roll, yaw)
Certified for leading CAD and DCC applications

Environmental

Operating temperature

41° to 140° F (5° to 60° C)

Non-operating
temperature

-13° to 158° F (-25° to 70° C)

Operating humidity

10 to 98 % RH (non-condensing)

Non-operating humidity

10 to 98 % RH (non-condensing)

Mechanical

Buttons

11 programmable (unshifted)

Cap Force Range

0.2 N – 4.5 N

Cap Torque Range

4 Nmm to 100 Nmm

Resolution

8 bit

USB Specifications

Connector

USB 1.1 or greater

Cable Length

2 m

Data Rate

16 msec

Software Drivers Available

Microsoft Windows XP

System Requirements

Disk Space

10 MB free disk space

Regulatory Approvals

UL, cUL, EN 950, EN 60950, CSA, FCC, CE Mark, TUV, CISPR 22, EN 50082, IEC 1000
4-2, IEC 1000-4-3, AS/NZS, VCCI, BSMI, C-Tick

QuickSpecs

HP Workstation xw6200

Technical Specifications - Input/Output Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 40

1394 Firewire FH/LP Card

(PCI)

Device Interface Protocol

IEEE-1394a

Data Rate

100Mbits/s, 200Mbit/s and 400Mbits/s

Devices Supported

IEEE-1394 compliant devices

Connectors

Two IEEE1394 6-Pin Connector (Bracket Side)
One 10-Pin (9 Contacts) Custom Connector (Internal)

Bus Interface

PCI

Physical

Low profile PCI card with a full height bracket

Environmental

Operating temperature

32° to 104° F (0° to 50° C)

Non-operating
temperature

-13° to 158° F (-25° to 70° C)

Relative humidity

5% to 95%

Ports

3 cable ports

Minimum System
Requirements

Microsoft XP Professional or Red Hat Linux 7.3/9.0 (Class Driver)
Pentium II 266 or faster
64-MB RAM
Available PCI slot
CD-ROM drive

Regulatory Agency
Approval

FCC Part 15B, cULus 60950, CE Mark EN55022B(1995)/EN55024-1998 STD, Taiwan
BSMI CNS13438, Korea MIC

QuickSpecs

HP Workstation xw6200

Technical Specifications - Input/Output Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 41

48X CD-ROM Drive

Capacity

700 MB CD disc

Dimensions

(HxWxD)

1.63 x 5.83 x 7.27 in (4.13 x 14.6 x 18.5 cm)

Weight

1.76 lb (0.8 kg)

Interface

ATAPI/EIDE

Mounting Orientation

Horizontal or vertical

Data Transfer Rates - Read

Digital audio extraction (minimum) – 1,200 KB/s (8X)
CD read – up to 7,200 KB/s (48X)

Media and Formats - Read

Formats

: CD-DA, CD-ROM (Mode 1 and 2), CD-XA Ready, Photo CD (Single and
Multi-session), Mixed Mode (Audio and Data combined), CD-I (FMV), CD Plus, CD­Extra;

Media

: stamped, CD-R, CD-RW

Data Transfer Modes

PIO Mode 4 (16.6 MB/s); Multi-word DMA mode 2 (16.6 MB/s); UltraDMA Mode 0 (16.7
MB/s); UltraDMA Mode 2 (33.3 MB/s)

Access Times

(typical)

Random

< 75 ms @ 48x

Full-Stroke

< 150 ms

Start-up Time

(typical)

< 7 s (single session)

< 30 s (multisession)

Stop Time

(typical)

< 4 s

Read Buffer size

128 KB (minimum)

Audio Output

Line-Out

0.7 VRMS

Signal-to-Noise Ratio

80 dB

Channel Separation

65 dB

Configuration Jumper
Block

Master, slave, and cable select modes

Operating Conditions

Temperature

41° to 122° F (5° to 50° C)

Humidity

10% to 80%

Approvals/
Environmental

UL 1950 (US and Canada), CSA, SEMKO, TUV; CE, FDA, FCC, IC, C-TICK

Operating Systems
Supported

Microsoft Windows 2000 and Microsoft Windows XP

Supplied Software

None

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 42

16X/40X DVD-ROM Drive
with +R Read Support

Height

5.25-in, half-height, tray load

Interface Type

ATAPI/EIDE

Dimensions

(W x H x D)

5.88 x 1.71 x 7.87 [max] in (149.5 x 43.25 x 200.0 [max] mm) (external, excluding
bezel)

Disc Formats

DVD-ROM (single and dual layer); DVD-video; DVD-R version 1.0 and 2.0; DVD-RW
version 1.0 and 1.1; DVD-R multi-border; DVD+RW; DVD+R ; CD-ROM Mode 1 and 2;
CD-DA; CD-ROM XA Mode 2, Form 1 and 2; CD-extra; CD-text; CD-I Mode 2, Form 1
and 2; CD-I ready; video CD, CD-bridge; PhotoCD (single and multi-session); CD-R; CD­RW

Disc Capacity

DVD-ROM

4.7 GB (DVD-5), 8.54 GB (DVD-9), 9.4 GB (DVD-10),

3.95 GB (DVD-R version 1.0), 4.7 GB (DVD-R version

2.0), 4.7 GB (DVD-RW version 1.0 and 1.1), 4.7 GB
(DVD+RW), 4.7G (DVD+R)

CD-ROM

540 MB (Mode 1, 12 cm), 640 MB (Mode 2, 12 cm), 700
MB (80 minimum CD-R and CD-RW), 180 MB (8 cm)

Access Times

(typical reads, including
settling)

DVD-ROM Single Layer

120 ms

CD-ROM Mode 1

90 ms

Full Stroke DVD

240 ms (seek)

Full Stroke CD

160 ms (seek)

Startup Time

< 10 seconds (typical)

Stop Time

< 4 seconds

Data Transfer Modes

PIO Mode 4 (16.6 MB/s); Multi-word DMA mode 2 (16.6
MB/s); UltraDMA Mode 3 (44.4 MB/s)

Maximum Data Transfer
Rates

CD-ROM Read

6000 KB/s (40X) Max

DVD-ROM Read

21,600 KB/s (16X) Max

Digital Audio Extraction

6000 KB/s (40X) Max

Power

Source

Four-pin, DC power receptacle

DC Power Requirement

5 VDC ± 5% – 100 mV ripple p-p
12 VDC ± 5% – 200 mV ripple p-p

DC Current

5 VDC – <800 mA typical,
< 1000 mA maximum

12 VDC – < 870 mA typical,
<1800 mA maximum

Audio Output

Line-Out

0.7 VRMS

Signal-to-Noise Ratio

85 dB

Channel Separation

65 dB

Configuration Jumper
Block

Master, slave, and cable select modes

Data Interface Connector

40-pin, shrouded and keyed, flat ribbon

Operating Environmental

(all conditions non­condensing)

Temperature

(operating)

41° to 122° F (5° to 50° C)

Relative Humidity

(operating)

10% to 85%

Maximum Wet Bulb
Temperature

(operating)

86° F (30° C)

Certifications, Approvals

MMC II support, multi-read certification, Microsoft WHQL certification, ACA AS/NZS
3548 class B, CNS 13438, C.I.S.P.R. Pub 22, TUV or VDE EN60950, EN 55022,
EN55024, EMKO EN60950, EN 60825-1, UL 60950, CSA C22.2 60950-2000, CFR 21
part 1040 class 1, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, ANSI C63.4-1992

Operating Systems
Supported

Microsoft Windows 2000, Windows XP Professional

Kit Contents

16X/40X DVD-ROM Drive, InterVideo WinDVD MPEG Movie Playback software, audio
cable, and installation guide.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 43

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 44

HP 48X CD-RW

Height

5.25-inch, half-height, tray-load

Mounting Orientation

Horizontal or vertical

Interface

ATAPI/EIDE

Dimensions

(HxWxD)

1.63 x 5.75 x 7.27 [max] in (4.13 x 14.6 x 18.5 [max] cm) (external, excluding bezel)

Weight

(max)

2.0 lb (0.9 kg)

Read Only Disc
Parameters

Data Transfer Rates –
Read

Digital audio extraction (minimum) – 1,800 KB/s (12X)
CD read – up to 7,200 KB/s (48X)

Media and Formats – Read

Formats:

CD-DA, CD-ROM (Mode 1 and 2), CD-ROM
XA (Mode 2, Form 1 and 2), Mixed Mode, CD-Plus, CD­Extra, CD-I FMV, Video CD, CD-Text, Photo CD (single
and multisession)

Media:

stamped, CD-R, CD-RW

Writeable Disc Parameters

Data Transfer Rates –
Write

CD-R write – 2100 KB/s (14X) to 7200 KB/s (40X)
CD-RW write – 600 KB/s (4X)
CD-RW write (high speed) – 1500 KB/s (10X) to 1800

KB/s (12X)
CD-RW write (ultra high speed) – 2400 KB/s (16X) to

4800 KB/s (32X)

Media and Formats – Write

Formats:

CD-DA, CD-ROM (Mode 1 and 2), CD-ROM
XA (Mode 2, Form 1 and 2), Mixed Mode, CD-Plus, CD­Extra, CD-I FMV, Video CD, CD-Text

Media:

CD-R, CD-RW (including ultra-speed)

Write Methods

Disc-at-once, session-at-once,, track-at-once,
incremental fixed and variable packet, multisession

Access Times

(typical reads, including
settling)

CD-ROM Mode 1

125 ms

Full Stroke CD

210 ms (seek)

Start-up Time

(typical)

<7 s (single session), <30 s (multisession)

Stop Time

(typical)

<4 s

Write Buffer Size

2 MB

Data Transfer Modes

PIO Mode 4 (16.6 MB/s); Multi-word DMA mode 2 (16.6
MB/s); UltraDMA Mode 2 (33.3 MB/s)

Power

Source

Four-pin, DC power receptacle

DC Power Requirement

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p

DC Current

5 VDC (< 1000 mA typical, < 1600 mA maximum)
12 VDC (< 600 mA typical, < 1400 mA maximum)

Total Drive Power

(standby mode)

< 2.5 Watt

Audio Output

Line-Out

0.7 VRMS

Signal-to-Noise Ratio

74 dB

Channel Separation

65 dB

Configuration Jumper
Block

Master, slave, and cable select modes

Operating Conditions

Temperature

41° to 122° F (5° to 50° C)

Humidity

10% to 90%10% to 90%

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 45

Approvals/
Environmental

MPC-3 compliant, multi-read requirements, ATA Spec X3T9.2, ATAPI Spec SFF-8020,
ANSI C63.4-1992, UL 1950, ACA AS/NZS 3548, CB Bulletin No. 96A, CSA C22.2 No.
950-1995, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, EMKO-TSE 07/94, TUV
EN60950, EN60825-1, MIC, BSMI-CNS 13438, CE, Microsoft ®PC2001 certification,
Microsoft Logo for Windows® XP and 2000.

Operating Systems
Supported

Microsoft Windows® 2000, Windows XP Professional

Supplied software

Roxio Easy CD & DVD Creator: Create or copy CDs and DVDs, including music and
data CDs, and data DVDs

Dantz Retrospect Express: Back up systems to CD, DVD, or tape media.

48X Combo CD-RW/DVD­ROM

Height

5.25-inch, half-height, tray-load

Mounting Orientation

Either horizontal or vertical

Interface Type

ATAPI/EIDE

Dimensions

(W x H x D)

5.77 x 1.71 x 7.87 [max] in (14.66 x 4.34 x 20.0 [max] cm) (external, excluding bezel)

Weight

(max)

2.6 lb (1.2 kg)

Read Only Disc
Parameters

Formats and Modes
Supported

CD-ROM-Mode 1; CD-ROM XA-Mode 2 (forms 1 and 2);
CD-Bridge; CD digital audio; CD Extra; CD-I-Mode 2
(forms 1 and 2) and CD-I-Ready; Photo CD (single and
multi-session); video CD; DVD (single- and double­layer); DVD-R; DVD-RW; DVD-RW Multi-Border;
DVD+R; DVD+R Multisession , and DVD+RW

Capacity

180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650
MB (mode 2, 12 cm); 700 MB (Mode 2, 12 cm); 4.7 GB
(DVD-5); 8.54 GB (DVD-9); 9.4 GB (DVD-10)

CD-ROM, CD-R, CD-RW read

7200 KB/s (48X) Max

DVD ROM read

21,632 KB/s (16X ) Max

Writeable Disc Parameters

Disc Type

CD-R and CD-RW

Write Methods

Disc at Once, Track at Once, Session at Once,
Variable Packet, Fixed Packet

Format and Modes
Supported

CD-ROM (mode 1); CD-ROM XA (mode 2, forms 1 and

2); CD digital audio, CD-I (mode 2, forms 1 and 2);
video CD; CD-Bridge; Video CD

Capacity

180 MB (mode 2, 8 cm); 540 MB (mode 1, 12 cm); 650
MB (mode 2, 12 cm); 700 MB (mode 2, 12 cm)

CD-R write

7200 KB/s (48X) Max

CD-RW write

4800 KB/s (32X) Max

Access Times

(typical reads, including
settling)

Random DVD

< 140 ms (typical)

Random CD

< 125 ms, (typical)

Full Stroke DVD

< 250 ms (seek)

Full Stroke CD

< 210 ms (seek)

Startup Time (single)

< 7 seconds (typical)

Startup Time (multi­session)

< 30 seconds (typical)

Stop Time

< 4 seconds

Cache Buffer

2 MB (minimum)

Data Transfer Modes

ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA
mode 2 (16.7 MB/s); ATA UltraDMA Mode 3 44
Mbytes/s (default)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 46

Power

Source

Four-pin, DC power receptacle

DC Power Requirement

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 5%-200 mV ripple p-p

DC Current

5 VDC (< 1000 mA typical, < 1600 mA maximum)
12 VDC (< 600 mA typical, < 1400 mA maximum)

Total Drive Power

(standby mode)

< 2.5 Watt

Audio Output

Line-Out

0.7 VRMS

Signal-to-Noise Ratio

74 dB

Channel Separation

65 dB

Configuration Jumper
Block

Master, slave, and cable select modes

Data Interface Connector

40-pin, shrouded and keyed, flat ribbon

Operating Environmental

(all conditions non­condensing)

Temperature

41° to 122° F (5° to 50° C)

Relative humidity

10% to 90%

Maximum wet bulb
temperature

86° F (30° C)

Certifications,
Requirements

MPC-3 compliant, multi-read requirements, ATA Spec X3T9.2, ATAPI Spec SFF-8020,
ANSI C63.4-1992, UL 1950, ACA AS/NZS 3548, CB Bulletin No. 96A, CSA C22.2 No.
950-1995, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, EMKO-TSE 07/94, TUV
EN60950, EN60825-1, MIC, BSMI-CNS 13438, CE, Microsoft® PC2001 certification,
Microsoft Logo for Windows® XP and 2000.

Operating Systems
Supported

Microsoft Windows 2000, Windows XP Professional

Option Kit Contents

48X Combo CD-RW/DVD-ROM Drive, Roxio Easy CD & DVD Creator, InterVideo
WinDVD MPEG Movie Playback software, Dantz Retrospect Express Backup
software, audio cable, and installation guide.

8X DVD+R/+RW

Height

5.25-inch, half-height, tray-load

Orientation

Either horizontal or vertical

Interface Type

ATAPI/EIDE

Disc Recording Capacity

4.7 GB

Dimensions

(W x H x D)

5.9 x 1.7 x 8.0 in (15.0 x 4.4 x 20.3 cm)

Weight

(max)

2.6 lb (1.2 kg)

Recording Method

Disc-at-once, Track-at-once, and Session-at-once; Variable Packet and Fixed Packet

Write Support

DVD+R, DVD+RW, CD-R, CD-RW

Read Support

DVD-ROM (single- and dual-layer), DVD-Video, DVD+R (include multisession),
DVD+RW, DVD-R (incl. multiborder), DVD-RW;
CD-ROM Mode 1, CD-ROM XA (Mode 2, forms 1 and 2), CD-TEXT, Photo CD single­and multi-session), CD-DA (Audio CD), CD-Extra, CD-R, CD-RW (supports AM2), VCD

Write Speed

(max)

DVD+R

8X CLV (10800 KB/s)

DVD+RW

4X CLV (5400 KB/s)

CD-R

24X CLV (3600 KB/s)

CD-RW

10X CLV (1500 KB/s)

Read Speed

(max)

DVD-ROM

12X CAV (6750 to 16200 KB/s)

DVD+R, DVD+RW,

8X CAV (5400 to 10800 KB/s)

CD-ROM, CD-R, CD-RW, CD­Audio

40X CAV (2550 to 6000 KB/s)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 47

Access Time

(typical reads,

including settling)

Random DVD

< 140 ms (typical)

Random CD

< 125 ms, (typical)

Full Stroke DVD

< 250 ms (seek)

Full Stroke CD

< 210 ms (seek)

Startup Time

(single)

< 7 seconds (typical)

Startup Time

(multi-session)

< 30 seconds (typical)

Stop Timex

< 4 seconds

Cache Buffer

2 MB (minimum)

Data Transfer Modes

ATA PIO mode 4 (16.7 MB/s); ATA Multi-word DMA
mode 2 (16.7 MB/s); ATA UltraDMA Mode 2 33
Mbytes/s (default)

Power

Source

Four-pin, DC power receptacle

DC Power Requirement

5 VDC ± 5%-100 mV ripple p-p
12 VDC ± 10%-200 mV ripple p-p

DC Current

5 VDC (< 2000 mA typical, < 2500 mA maximum)
12 VDC (< 700 mA typical, < 2000 mA maximum)

Total Drive Power

(standby mode)

< 2.5 Watt

Audio Output

Line-Out

0.7 VRMS

Signal-to-Noise Ratio

75 dB

Channel Separation

55 dB

Operating Environmental

(all conditions non­condensing)

Temperature

41° to 122° F (5° to 50° C)

Relative humidity

10% to 90%

Maximum wet bulb
temperature

86° F (30° C)

System Configuration

Intel® Pentium® III Processor or later with 128 MB of memory (required); 256 MB
recommended 2-D or 3-D graphics cards on primary disk drive for operating system
and application software; second disk drive for audio and video data

Operating Systems
Support

Microsoft® Windows® 2000, Windows XP Professional, Windows XP Home

Regulatory Approvals

MPC-3 compliant, multi-read requirements, ATA Spec X3T9.2, ATAPI Spec T13.1153D,
ANSI C63.4-1992, UL 1950, ACA AS/NZS 3548, CB Bulletin No. 96A, CSA C22.2 No.
950-1995, CFR 47 C.I.S.P.R. Pub 22 Class B, DHHS/FDA, EMKO-TSE 07/94, TUV
EN60950, EN60825-1, MIC, BSMI-CNS 13438, CE, Microsoft® PC2001 certification,
Microsoft Logo for Windows® XP and 2000.

Option Kit contents

DVD+R/+RW Drive, InterVideo WinDVD, InterVideo WinDVD Creator, Roxio Easy CD
Creator, Dantz Retrospect Express Backup Software, installation guide, and DVD+R
media.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Optical Devices

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 48

NVIDIA Quadro NVS 280

(PCI)

Form Factor

ATX

Graphic Controller

Integrated Quadro 280 2-D graphics processor unit (GPU)

VGA controller

Integrated into the Quadro GPU

Bus type

PCI

RAMDAC

Dual 350 MHz

Memory

64 MB DDR with frame buffer and Texture storage

Connector

Single High-density Flex Connector

Dimensions

Low-profile, 2.586 x 6.6 in (6.57 x 16.76 cm)

Controller clock speed

275 MHz

Color planes

32-bit color buffer

Overlay planes

1 16-bit Video overlay plane

Maximum vertical refresh
rate

120 Hz

Maximum pixel clock

350 MHz

Multi-monitor support

Dual analog or digital monitors

Single DVI Support

Yes

Dual DVI Support

Yes

High-definition Video
Processor

(HDVP)

Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Available graphics drivers

Microsoft Windows 2000 and Microsoft Windows XP (Provides full native Dual View
mode, Span or Big Desktop mode, and Clone mode)

Red Hat Linux
HP qualified drivers may be preloaded or available from the HP support web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 49

NVIDIA Quadro NVS 280
Graphics Card

(PCI-

Express)

Form Factor

ATX

Graphics Controller

Integrated Quadro 280 2-D graphics processor unit (GPU)

VGA controller

Integrated into the Quadro GPU

Bus Type

PCI-Express x16 or PCI

RAMDAC

Dual 350 MHz integrated

Memory

64 MB 000 MHz DDR SDRAM unified frame buffer, Z-buffer and Texture storage

Connectors

Single High-density Flex Connector

Multi-monitor support

Dual integrated analog display controllers supporting up to two analog displays at
1920 x1200 @ 85Hz or two digital displays at 1600x1200 @ 60Hz

Additional product
features

Controller clock speed

250 MHz

Color planes

32-bit color buffer

Overlay planes

1 16-bit Video overlay plane

Maximum vertical refresh
rate

120 Hz

Maximum pixel clock

350 MHz

Single DVI Support

Yes

Dual DVI Support

Yes

High-definition Video
Processor

(HDVP)

Full-screen, full-frame video playback of HDTV and
DVD content

DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and

4:2:0)
IDCT motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

PCI-Express

Supports X16 PCI-E

Available graphics drivers

Microsoft Windows® XP or Windows 2000 (Provides full native Dual View mode,
Span or Big Desktop mode, and Clone mode)

HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 50

NVIDIA Quadro4 NVS 400
Graphics Card

Form Factor

ATX

Graphics Controller

Integrated Quadro4 2D/3D 128-bit graphics processor unit (GPU)

Bus Type

PCI

RAMDAC

Dual 350 MHz

Memory

64 MB 220 MHz, 4mx 32 DDR per GPU, 32-MB per GPU unified frame buffer

Connectors

Dual LFH-60

Dimensions

Low-profile form factor

Multi-monitor support

1 to 4 displays with nView – with two cards (1 PCI per card), up to 8 monitors can be
driven

nView Hardware
Architecture

32-bit color
2048x1536 @ 75Hz maximum resolution
Dual 350 MHz RAMDACs
Integrated TMDS
Digital Vibrance Control (DVC)
High-performance 2D rendering engine
Optimized for 32-, 24-, 16-, 15- and 8-bpp modes

High-definition video
processor

(HDVP)

Full-screen, full-frame video playback of HDTV and DVD content
DVD-ready motion compensation for MPEG-2
Independent hardware color controls for video overlay
Hardware color-space conversion (YUV 4:2:2 and 4:2:0)
IDCT Motion compensation
5-tap horizontal by 3-tap vertical filtering
8:1 up/down scaling

Supported graphics APIs

Fully compliant with OpenGL 1.3 and DirectX 8.1

Available graphics drivers

Microsoft Windows XP and Microsoft Windows 2000, Linux
See:

http://www.hp.com/support/workstation_drivers/

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 51

NVIDIA Quadro FX 330
Graphics Card

Form Factor

ATX

Graphics Controller

NVIDIA Nv37GL

Bus Type

PCI-Express x16

Memory

64 MB 000 MHz DDR SDRAM unified frame buffer, Z-buffer and Texture storage

Connectors

DMS-59 output supporting up to two analog or digital (with optional cable) displays

Multi-monitor support

Dual integrated analog display controllers supporting up to two analog displays at
2048 x1536 @ 60Hz or two digital displays at 1600x1200 @ 60Hz

RAMDAC

Dual 350 MHz integrated

Architecture features

64-bit memory interface
128-bit IEEE floating-point precision graphics pipeline
128-bit color precision
12-bit sub-pixel precision
4x FSAA at 1024x768
Hardware accelerated antialiased points and lines
Hardware OpenGL overlay planes
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
Hardware accelerated occlusion culling
3D volumetric texture support

Shading architecture

Fully programmable GPU
Optimized compilers for Cg, OpenGL shading language, and Microsoft HLSL

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

HP-tested: Microsoft Windows® XP, Windows 2000, and Linux
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

Maximum Resolution

Dual DVI-I output with optional cable – drives dual digital displays at resolutions up to
1600x1200 @ 60Hz

Internal 350MHz RAMDACs – drives dual analog displays up to 2048x1536 @ 60Hz
each

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 52

ATI FireGL V3100 Graphics
Card

Form Factor

ATX

Graphics Controller

RV370

Bus Type

PCI-Express x16

Memory

128MB 200MHz DDR unified frame buffer, Z-buffer and Texture storage

Connectors

1 DVI-I analog/digital and 1 VGA analog monitor output

Multi-monitor support

Dual integrated display controllers supporting up to 2048x1536 @ 85Hz on both
displays

RAMDAC

Dual 400 MHz integrated

Architecture features

128-bit memory interface
128-bit IEEE floating-point precision
24-bits per RGBA color precision
4-bit sub-pixel precision
2 parallel geometry engines
4 parallel pixel pipelines
2x/4x/6x FSAA
Hardware accelerated antialiased points and lines
Hardware OpenGL overlay planes
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
Hardware accelerated occlusion culling
Hardware accelerated clip planes

Shading architecture

Smartshader™ technology
Programmable pixel and vertex shaders
16 textures per pass
Pixel shaders up to 160 instructinos with 32-bit floating point precision for each RGBA
component
Multiple render target support
Shadow volume rendering acceleration
High precision 10-bit per channel frame buffer support

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

HP-tested: Microsoft Windows® XP, Windows 2000, and Linux
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

Maximum Resolution

DVI-I output – drives digital display at resolutions up to 1600x1200
Internal 400MHz RAMDACs – drives dual analog displays up to 2048x1536 @ 85Hz

each

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 53

NVIDIA Quadro FX 1300
Graphics Card

Form Factor

ATX

Graphics Controller

NVIDIA NV38GL

Bus Type

PCI-Express x16

Memory

128 MB 275 MHz DDR SDRAM unified frame buffer, Z-buffer and Texture storage

Connectors

2 DVI-I analog/digital monitor outputs, 1 3-pin Mini DIN stereo output

Multi-monitor support

Dual integrated analog display controllers supporting up to two analog displays at
2048x1536 @ 60Hz on both displays or dual digital displays at 1600x1200 @ 60Hz

NVIEW advanced multi-display desktop and application management seamlessly
integrated into Microsoft Windows

RAMDAC

Dual 400 MHz integrated

Architecture features

256-bit memory interface
128-bit IEEE floating-point precision graphics pipeline
128-bit color precision
12-bit sub-pixel precision
4x FSAA at 1280x1024
Hardware accelerated antialiased points and lines
Hardware OpenGL overlay planes
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
Hardware accelerated occlusion culling
3D volumetric texture support
Quad-buffered stereo

Shading architecture

Fully programmable GPU
Optimized compilers for Cg, OpenGL shading language, and Microsoft HLSL

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

HP-tested: Microsoft Windows® XP, Windows 2000, and Linux
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

Maximum Resolution

Dual DVI-I output – drives dual digital displays at resolutions up to 1600x1200 @ 60Hz
Internal 400MHz RAMDACs – drives dual analog displays up to 2048x1536 @ 75Hz

each

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 54

NVIDIA Quadro FX 3400
Graphics Card

Form Factor

ATX

Graphics Controller

NVIDIA NV45GL

Bus Type

PCI-Express x16

Memory

256 MB 450 MHz GDDR3 SDRAM unified frame buffer, Z-buffer and Texture storage

Connectors

2 DVI-I (one dual-link/one single-link) analog/digital monitor outputs,
1 3-pin Mini DIN stereo output

Multi-monitor support

Dual integrated analog display controllers supporting up to two analog displays at
2048x1536 @ 85Hz on both displays or dual digital displays at 1600x1200 (single-link)
and 3840x2400 (dual-link).

NVIEW advanced multi-display desktop and application management seamlessly
integrated into Microsoft Windows

RAMDAC

Dual 400 MHz integrated

Architecture features

256-bit memory interface
128-bit IEEE floating-point precision graphics pipeline
128-bit color precision
12-bit sub-pixel precision
8x FSAA at 1920x1200, 4x at 2048x1536, rotated grid FSAA sampling algorithm
Hardware accelerated antialiased points and lines
Hardware OpenGL overlay planes
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
3rd generation occlusion culling
3D volumetric texture support
Quad-buffered stereo
Dual Link DVI enabling driving digital displays up to 3840x2400 (24Hz)

Shading architecture

Fully programmable GPU
Long fragment programs (up to 65,536 instructions)
Long vertex programs (up to 65,536 instructions)
Looping and subroutines (up to 256 loops per vertex program)
Dynamic flow control
Conditional execution

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

HP-tested: Microsoft Windows® XP, Windows 2000, and Linux
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

Maximum Resolution

Dual DVI-I output – drives dual digital displays at resolutions up to 1600x1200 @ 60Hz
(single-link) and 3840x2400 @ 24Hz (dual-link).

Internal 400MHz RAMDACs – drives dual analog displays up to 2048x1536 @ 75Hz
each

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 55

ATI FireGL V5100
PCI-Express Graphics
Controller

Form Factor

ATX

Graphics Controller

RV423

Bus Type

PCI-Express x16

Memory

128 MB 350MHz DDR unified frame buffer, Z-buffer and Texture storage

Connectors

2 DVI-I analog/digital monitor outputs, 1 3-pin Mini DIN stereo output

Multi-monitor support

Dual integrated display controllers supporting up to two analog displays at 2048x1536
@ 85Hz on both displays.

RAMDAC

Dual 400 MHz integrated

Architecture features

256-bit memory interface
128-bit IEEE floating-point precision
24-bits per RGBA color precision
8-bit sub-pixel precision
6 parallel geometry engines
12 parallel pixel pipelines
2x/4x/6x FSAA
Hardware accelerated antialiased points and lines
Hardware OpenGL overlay planes
Hardware accelerated two-sided lighting
Hardware accelerated clipping planes
Hardware accelerated occlusion culling
Hardware accelerated clip planes
Quad-buffered stereo

Shading architecture

Smartshader™ technology
Programmable pixel and vertex shaders
16 textures per pass
Pixel shaders up to 160 instructions with 32-bit floating point precision for each RGBA
component
Multiple render target support
Shadow volume rendering acceleration
High precision 10-bit per channel frame buffer support

Supported graphics APIs

OpenGL 1.5
DirectX 9.0

Available graphics drivers

HP-tested: Microsoft® Windows® XP, Windows 2000, and Linux
HP qualified drivers may be preloaded or available from the HP support Web site:

http://welcome.hp.com/country/us/eng/software_drivers.html

.

Maximum Resolution

DVI-I output – drives digital displays at resolutions up to 1600x1200
Internal 400MHz RAMDAC – drives dual analog displays up to 2048x1536 @ 85Hz

each

QuickSpecs

HP Workstation xw6200

Technical Specifications - Graphics

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 56

HP CRT Monitor p1230

Tube

Type

Diamondtron NF Aperture Grille CRT

Tube Size

(diagonal)

22 in (55 cm)

Viewable Image Area

(diagonal)

20 in (51 cm)

Aperture Grille Pitch

0.24 mm

Screen Curvature

Flat

Signal Interface/
Performance

Horizontal Frequency

30 to 140 kHz

Vertical Frequency

50 to 160 Hz

Maximum Resolution

2048 x 1536 @ 85 Hz (GTF)

Recommended Resolution

1600 x 1200 @ 85 Hz or 1280 x 1024 @ 85 Hz

Preset VESA Graphic
Modes

(non-interlaced)

1920 x 1440 @ 60 Hz, 75 Hz
1792 x 1344 @ 60 Hz, 75 Hz
1600 x 1200 @ 75 Hz, 85 Hz
1280 x 1024 @ 60 Hz, 75 Hz, 85
1024 x 768 @ 75 Hz, 85 Hz
800 x 600 @ 75 Hz, 85 Hz
640 x 480 @ 60 Hz, 85 Hz

Preset MAC Mode

1152 x 870 @ 75 Hz

Preset VGA Mode

640 x 480 @ 60 Hz and 720 x 400 @ 70 Hz

Maximum Pixel Clock
Speed

420 MHz

User Programmable
Modes

15 (10 preset modes and 5 additional modes)

Anti-Glare

Yes

Anti-Static

Yes

AssetControl

Yes

Default Color
Temperature

9300 K

On Screen Display

(OSD)

Controls

Buttons or Switches

OSD menu, brigthness, contrast, Super Bright, dual
input, power on/off

Languages

English, Spanish, French, German, Italian, Japanese

User Controls

Brightness, contrast, pincushion, pincushion balance,
trapezoid, tilt (rotation), color temperature, degauss,
parallelogram, individual color control, zoom, moiré
cancellation, convergence, corner purity, image
control, language, OSD control, factory reset

Video Input

Plug and Play

Yes, DDC/CI compatible

Input Signal

Two 15-pin D-sub connections

Input Impedance

75 ohms

Sync Input

Separate sync (HSYNC/VSYNC)

Video Cable

Detachable 15-pin D-sub mini connector (included)

Video Cable Length

70 in (1.8 m); non-captive

Power

Power Supply

Universal 100-120/220-240 VAC

Frequency

50/60 Hz

Maximum

135 watts

Power Saving

2 watts maximum

Off Mode

0 watts

Power Cable Length

70 in (1.8 m); non-captive

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 57

Mechanical

Dimensions

(H x W x D)

Unpacked (including
pedestal)

19.1 x 19.5 x 18.8 in (48.6
x 49.5 x 47.7 cm)

Packaged

25.6 x 25.0 x 25.4 in (65.1
x 63.6 x 64.6 cm)

Unpacked

66.1 lb (30 kg)

Packaged

77.1 lb (35 kg)

Tilt Range

10° upward and 5° downward

Swivel Range

90°either side of center

Environmental

Temperature - Operating

41° to 90° F (5° to 35° C) non-condensing

Temperature ­Non-operating

-4° to 140° F (-20 to 60° C)

Humidity - Operating

10% to 90% non-condensing

Humidity ­Non-operating

10% to 90%

Altitude - Operating

0 to 7,200 ft (0 to 2,195 m)

Altitude ­Non-operating

0 to 30,000 ft (0 to 9,144 m)

Other

Accessories Included

Power cable, video cable (D-sub to D-sub),
documentation kit

User Guide Languages

English, French, German, Spanish, Italian, Dutch,
Brazilian Portuguese, Danish, Finnish, Greek,
Japanese, Korean, Latin American Spanish,
Norwegian, Polish, Russian, Slovenian, Turkish,
Swedish, Traditional Chinese, Simplified Chinese

Warranty Languages

English, French, Spanish, Brazilian Portuguese, Danish,
German, Castilian Spanish, French, Italian, Dutch,
Norwegian, Finnish, Swedish, Bahasa Indonesian,
Japanese, Korean, T. Chinese, S. Chinese

Color

Carbon and silver

Certification and
Compliance

MPR-II (Low Emissions), TCO '03, *Energy Star Compliant, UL Listing, ISO9241-3 VOT
Guidelines Approval, FCC Approval, CE Mark (including PFC), GS Mark

* Energy Star Compliant available summer of 2004.

Compatibility

Compatible with platforms using the VESA standard video modes and HP Compaq
Business Desktops d500, d300, and d200 Series, Compaq Evo Desktops, HP
workstations, and HP Business Desktops d300 series.

Service and Warranty

Limited three-year parts and repair labor, service provider labor, and on-site service.
Next business day advanced exchange direct replacement service available during
warranty period. Certain restrictions and exclusions apply.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 58

HP Flat Panel Monitor
L1925

Panel

Type

Thin film transistor (TFT)

Viewable Image Area

(diagonal)

19 in (48.25 cm) maximum viewable

Screen Opening

(WxH)

14.9 x 11.9 in (37.8 x 30.3 cm)

Viewing Angle

(typical)

170 degrees horizontal/170 degrees vertical
(10:1 minimum contrast ratio)

Brightness

(typical)

Up to 250 nits (cd/m2)

Contrast Ratio

(typical)

Up to 500:1 (typical)

Response Rate

(typical)

<20 ms (typical rise + fall)

Pixel Pitch

0.294 mm

Color Depth Support

16.7 million colors

Video Input

Plug and Play

Yes (supports VESA DDC2B; PC2001 compliant)

Input Signal

Two connectors: one 15-pin mini D-sub analog VGA;
and one DVI-I (VGA analog or digital)

Input Impedance

75 ohms ± 2%

Sync Input

Separate sync (HSYNC/VSYNC); composite sync,
Sync on Green

Video Cable

VGA and DVI-D

Video Cable Length

78 in (2.0 m)

Signal Interface/
Performance

Horizontal Frequency

30 to 82 kHz

Vertical Frequency

56 to 75 Hz

Graphics Controller

Pixelworks 131

Native Resolution

1280 x 1024 @ 75 Hz analog
1280 x 1024 @ 60 Hz digital

Maximum Resolution

(Analog)

1280 x 1024 @ 75 Hz analog

Maximum Resolution

(Digital)

1280 x 1024@75Hz analog

On Screen Display

(OSD)

Controls

Preset VESA Graphic
Modes

(non-interlaced)

640 x 480 @ 60 Hz, 72 Hz, 75 Hz
800 x 600 @ 60 Hz, 72 Hz, 75 Hz
1024 x 768 @ 60 Hz, 75 Hz
1280 x 1024 @ 60 Hz, 75 Hz

Preset MAC Mode

832 x 624 @ 75 Hz
1152 x 870 @75 Hz

Preset VGA Mode

640 x 480 @ 60 Hz, 72 Hz

Preset SUN Mode

1152 x 900 @ 66 Hz

Fail Safe Mode

Yes (limits out of range signal messages)

Maximum Pixel Clock
Speed

140 MHz

User Programmable
Modes

Yes, 10

Anti-Glare

Yes

Anti-Static

Yes

AssetControl

Yes (accessible on HP/Compaq desktops featuring
Intelligent Manageability)

Default Color
Temperature

Yes (6500k, 9300k, Custom User)

Buttons or Switches

Power on/off; 4-button OSD; second level OSD buttons
include auto adjust and dual-input switch

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 59

Languages

English, Spanish, French, German, Dutch, Italian

User Controls

Size and Positioning
Contrast
Brightness
Clock, Clock Phase
Selectable Color Temperature
Input Selection
Factory Reset
Individual Color Contrast

Power

Power Supply

Auto-ranging, 90 to 265 VAC; internal power supply,

47.5-63 Hz

Input Power

100 ~ 240 VAC

Nominal Current

1.5 A maximum

Frequency

50 ~ 60 Hz

Average

33 W when displaying standard office software

Maximum

< 40 W

Power Saving

< 2 W

Off Mode

< 1 W (switch off)

Power Cable Length

70 in (1.8 m); non-captive

Mechanical

Dimensions

(H x W x D)

Unpacked with stand
minimum height

14.8 x 16.4 x 8.2 in
(39.8 x 41.6 x 20.8 cm)

Unpacked with stand
maximum height

20 x 16.4 x 8.2 in
(50.8 x 41.6 x 20.8 cm)

Base Area

(Footprint d x w)

8.2 x 12.2 in
(20.8 x 30.9 cm)

Panel only

(without

stand) (h x w x d)

13.5 x 16.4 x 2.6 in
(34.2 x 41.6 x 6.6 cm)

Weight

Unpacked with stand

17.6 lb (8 kg)

Unpacked without
stand

12 lb (5.5 kg)

Packaged

23.5 l (10.7 kg)

Tilt Range

-5° to +20°

Swivel Range

± 45° horizontal swivel

Height Adjustable

Yes (4.3 in/110 mm adjustment range)

Pivot Rotation

Yes, 90 °

Base

Ships attached and is removable after installation

Environmental

Temperature – Operating

41° to 95° F (5° to 35° C)

Temperature – Non­operating

-4° to 140° F (-20° to 60° C)

Humidity – Operating

20% to 80%

Humidity – Non-operating

5% to 95%

Altitude – Operating

0 to 13,000 ft (0 to 4,000 m)

Altitude – Non-operating

0 to 40,000 ft (0 to 12,192 m)
Full-screen Resolution

Options

PC Comm Station

Communication/audio hub that includes two stereo
speakers (8 PMPO each), integrated microphone/dual
function headset (phone and PC support), and USB
port. Optional, part number 304251-008 (US) or
P8814A (EMEA).

Other

Accessories Included

VGA cable, DVI-D cable, user CD-ROM with Portrait
software

User Guide Languages

English

Warranty Languages

English

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 60

Color

Carbon/Silver

VESA Mounting

Yes (swing arm/ wall mount not included; base is
shipped attached and must be removed for mounting
options)

VESA External Mounting

Yes (Standard 4 hole pattern, 100 mm)

Kensington Lock-ready

Yes

Certification and
Compliance

VESA Video Signal Standard (VSIS) Compliant video cards have been tested and
proven compatible for use with the HP Flat Panel Monitor L1925. The HP L1925 has
been tested for use with HP Workstations, Compaq Evo PCs and Thin Clients and
Compaq D315 Business PCs.

NOTE:

Features are subject to change without notice.

Service and Warranty

Limited three-year parts and repair labor, service provider labor, and on-site service.
Next Business Day advanced exchange direct replacement service available during
warranty period. Certain restrictions and exclusions apply. For details, contact HP
Customer Support at 1-800-HP-INVENT (USA and Canada).

HP Flat Panel Monitor
L2035

Panel

Type

20-inch Active Matrix TFT (thin film transistor)

Viewable Image Area

(diagonal)

20.1 in (51 cm)

Screen Opening

(W x H)

16.2 x 12.17 in (41.1 x 30.9 cm)

Viewing Angle

(typical)*

Up to 170° H/170° V (10:1 minimum contrast ratio)

Brightness

(typical*

Up to 250 nits (cd/m2)

Contrast Ratio

(typical)*

Up to 400:1

Response Rate

(typical)*

16 ms (typical, rise + fall)

Pixel Pitch

0.255 mm

Color Depth Support

16.7 million colors

*All specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component
manufacturers' typical level specifications for performance. Actual performance may
vary either higher or lower.

On Screen Display

(OSD)

Controls

Buttons or Switches

PiP (Picture in Picture), Input select, auto adjust, OSD
up, OSD down, OSD menu select, power

Languages

English, French, German, Spanish, Italian

User Controls

Brightness, contrast, positioning, color temperature,
individual color control, serial number display, full
screen resolutions, clock, clock phase, video picture­in-picture (size and position), input selection (includes
separate direct access key for dedicated swap
between inputs 1 and 2), factory reset

Signal Interface/
Performance

Horizontal Frequency

30 to 94 kHz (VGA input); 30 to 92 KHz (DVI input) (for
modes with pixel clock less than 157 MHz)

Vertical Frequency

48 to 85 Hz (VGA input); 30 to 92 KHz (DVI input) (for
modes with pixel clock less than 157 MHz)

Graphics Controller

Pixelworks PW171

Native Resolution

1600 x 1200 @ 60 Hz (recommended)

Preset VESA Graphic
Modes

(non-interlaced)

1600 x 1200 @ 60 Hz, 75 Hz (VGA input)
1280 x 1024 @ 60 Hz, 75 Hz, 85 Hz
1280 x 960 @ 60 Hz
1152 x 900 @ 66 Hz
1024 x 768 @ 60 Hz, 75 Hz, 85 Hz
800 x 600 @ 60 Hz, 85 Hz
640 x 480 @ 60 Hz, 75 Hz, 85 Hz

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 61

Text Mode

720 x 400 @ 70 Hz

Mac Mode

1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz

Sun Mode

1152 x 900 @ 66 Hz

Maximum Pixel Clock
Speed

202 MHz (VGA input); 162 MHz (DVI input)

User Programmable
Modes

Yes, 10

Anti-Glare

Yes

Anti-Static

Yes

Default Color
Temperature

6500 K

Video Input

Plug and Play

Yes

Input Signal

Four connectors, including one 15-pin mini D-sub VGA,
one DVI-I (VGA analog and digital input), one
composite video, and one s-video

Input Impedance

75 ohms ± 10%

Sync Input

Separate sync (HSYNC/VSYNC); composite sync,
Sync on Green

Video Cable

VGA to VGA; VGA to DVI-I; DVI-D to DVI-I

Video Cable Length

5.9 ft (1.8 m)

Power

Input Power

Auto-Ranging, 90 to 132 VAC and 195 to 265 VAC;
internal power supply, 50 Hz/60 Hz

Frequency

47.5 to 63 Hz

Maximum

< 75 W

Power Saving

< 5 W

Power Cable Length

5.9 ft (1.8 m)

Mechanical

Dimensions

(H x W x D)

Unpacked with stand

17.36 to 20.9 x 17.8 x 8.27
in
(44.1 to 53.1 x 45.2 x 21.0
cm)

Unpacked without
stand

(head only)

14.29 x 17.8 x 3.19 in
(36.3 x 45.2 x 8.1 cm)

Packaged

11.5 x 21.9 x 23.9 in
(29.2 x 55.6 x 60.6 cm)

Weight

Unpacked

With stand: 20.28 lb (9.2
kg);
Without stand: 12.35 lb
(5.6 kg)

Packaged

26.9 lb (12.2 kg)

Tilt Range

-5° to + 25° vertical

Swivel Range

-35° to + 35°

Height Adjustable

Yes, range 3.54 in (9.0 cm)

Pivot Rotation

Yes

Base

Attached

Environmental

Temperature – Operating

46° to 95° F (10° to 35° C)

Temperature – Non­operating

6° to 140° F (-10° to 60° C)

Humidity – Operating

20% to 80% non-condensing

Humidity – Non-operating

5% to 85%

Altitude – Operating

+12,000 ft (+3,657.6 m)

Altitude – Non-operating

+40,000 ft (+12,192 m)

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 62

Options

HP Desktop Access
Center

Sold separately, the HP Desktop Access Center
features integrated microphone/headset jacks, dual
function headset for phone/PC support, a MultiBay slot
for adding an optical drive (sold separately), and four
USB ports for easy integration of third-party digital
solutions; part number DK985A. For more information,
refer to the HP Desktop Access Center QuickSpecs.

Other

Accessories Included

VGA to VGA cable – connects the graphic card's VGA
analog connector to the monitor's input #1 (VGA
analog) connector

VGA to DVI-I cable – connects the graphic card's VGA
connector to the monitor's input #2 (DVI-I analog)
connector

DVI-D to DVI-I cable – connects the graphic card's DVI­D digital connector to the monitor's input #2 (DVI-I
digital) connector

User Guide Languages

English, B. Portuguese, French, LA Spanish, Korean,
S. Chinese, T. Chinese, Bahasa, Japanese, Danish,
Finnish, German, Norwegian, Spanish, Swedish,
Greek, Polish, Russian, Slovenian, Turkish

Warranty Languages

English, Canadian French, LA Spanish, Brazilian
Portuguese, Danish, German, Castilian Spanish,
French, Italian, Dutch, Norwegian, Finnish, Swedish,
Bahasa Indonesian, Korean, T. Chinese, S. Chinese

Color

Carbonite/Silver

VESA External Mounting

Yes (Standard 4 hole pattern, 100 mm)

Kensington Lock-Ready

Yes

Certification and
Compliance

Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE
Approval, CISPR Requirements, Eastern European Approvals, *Energy Star Compliant,
FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3,7,8 VDT
Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC
Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko,
Demko, Semko), PC2001 Compliant, PC99 Certified, S. Korean MIC Approval, Taiwan
BSMI Approval, TCO 03 (emissions, ergonomics, environment), TUV-Ergo, UL Listed,
VCCI Approvals, Windows Certification (Microsoft® Windows® 98, Microsoft
Windows 2000, and Microsoft Windows XP)

* Energy Star Compliant available summer 2004.

Compatibility

Compatible with platforms using the VESA standard video modes and HP Compaq
Business Desktops d500, d300, and d200 Series, Compaq Evo Desktops, and HP
Workstations

Service and Warranty

Limited three years parts, labor, and on-site service, including backlight. Availability
varies by region. Certain restrictions and exclusions apply. Consult HP Customer
Service for details.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 63

HP Flat Panel Monitor
L2335

Panel

Type

23-inch Active Matrix TFT (thin film transistor)

Viewable Image Area

(diagonal)

23 in (58.4 cm)

Screen Opening

(W x H)

19.53 x 12.24 in (49.6 x 31.1 cm)

Viewing Angle

(typical)*

Up to 170° H/170° V (10:1 minimum contrast ratio)

Brightness

(typical)*

Up to 250 nits (cd/m2)

Contrast Ratio

(typical)*

Up to 500:1

Response Rate

(typical)*

16 ms (typical, rise + fall)

Pixel Pitch

0.258 mm

Color Depth Support

16.7 million colors

* All specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component
manufacturers' typical level specifications for performance. Actual performance may
vary either higher or lower.

On Screen Display

(OSD)

Controls

Buttons or Switches

PiP (Picture in Picture), Input Select, Auto Adjust, OSD
Up, OSD Down, OSD Menu Select, Power

Languages

English, French, German, Spanish, Italian

User Controls

Brightness, contrast, positioning, color temperature,
individual color control, serial number display, full
screen resolutions, clock, clock phase, video picture­in-picture (size and position), input selection (includes
separate direct access key for dedicated swap
between inputs 1 and 2), factory reset

Signal Interface/
Performance

Horizontal Frequency

30 to 94 kHz (VGA input); 30 to 92 KHz (DVI input) (for
modes with pixel clock less than 157 MHz)

Vertical Frequency

48 to 85 Hz (VGA and DVI input)

Graphics Controller

Pixelworks PW172

Native Resolution

1920 x 1200 @ 60 Hz (recommended)

Preset VESA Graphic
Modes

(non-interlaced)

1920 x 1200 @ 60Hz
1600 x 1200 @ 60 Hz, 75 Hz
1280 x 1024 @ 60 Hz, 75Hz, 85 Hz
1280 x 960 @ 60 Hz
1152 x 900 @ 66 Hz
1024 x 768 @ 60 Hz, 75 Hz, 85 Hz
800 x 600 @ 60 Hz, 75Hz
640 x 480 @ 60 Hz, 75 Hz

Text Mode

720 x 400 @ 70 Hz

Mac Mode

1152 x 870 @ 75 Hz and 832 x 624 @ 75 Hz

Sun Mode

1152 x 900 @ 66 Hz

Maximum Pixel Clock
Speed

202 MHz (VGA input); 162 MHz (DVI input)

User Programmable
Modes

Yes, 10

Anti-Glare

Yes

Anti-Static

Yes

Default Color
Temperature

6500 K

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 64

Video Input

Plug and Play

Yes

Input Signal

Five connectors, including one 15-pin mini D-sub VGA,
one DVI-I (VGA analog and digital input), one
composite video, one s-video, component video

Input Impedance

75 ohms ± 10%

Sync Input

Separate sync (HSYNC/VSYNC); composite sync,
Sync on Green

Video Cable

VGA to VGA; VGA to DVI-I; DVI-D to DVI-I

Video Cable Length

5.9 ft (1.8 m)

Power

Input Power

Auto-Ranging, 90 to 132 VAC and 195 to 265 VAC;
internal power supply, 50 Hz/60 Hz

Frequency

47.5 to 63 Hz

Maximum

< 100 W

Power Saving

< 5 W

Power Cable Length

5.9 ft (1.8 m)

Mechanical

Dimensions

(H x W x D)

Unpacked

17.36 (min) to 20.9 (max) x

21.46 x 8.27 in (44.1 (min)
to 53.1 (max) x 54.5 x 21.0
cm)

Unpacked withou stand

(head only)

14.57 x 21.46 x 3.35 in
(37.0 x 54.5 x 8.5 cm)

Packaged

11.5 x 25.75 x 23.86 in
(29. 2 x 65.4 x 60.6 cm)

Weight

Unpacked

22.27 lb (10.1 kg)

Packaged

30.87 lb (14.0 kg)

Tilt Range

-5° to + 25° vertical

Swivel Range

-35° to + 35°

Height Adjustable

Yes, range 3.54 in (9.0 cm)

Pivot Rotation

Yes

Base

Attached

Environmental

Temperature –
Operating

46° to 95° F (10° to 35° C)

Temperature –
Non-operating

6° to 140° F (-10° to 60° C)

Humidity – Operating

20% to 80% non-condensing

Humidity –
Non-operating

5% to 85%

Altitude – Operating

+12,000 ft (+3,657.6 m)

Altitude –
Non-operating

+40,000 ft (+12,192 m)

Options

HP Desktop Access
Center

Sold separately, the HP Desktop Access Center
Features integrated microphone/headset jacks, dual
function headset for phone/PC support, a MultiBay slot
for adding an optical drive (sold separately), and four
USB ports for easy integration of third-party digital
solutions; part number DK985A. For more information,
refer to the HP Desktop Access Center QuickSpecs.

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 65

Other

Accessories Included

VGA to VGA cable – connects the graphic card's VGA
analog connector to the monitor's input #1 (VGA
analog) connector

VGA to DVI-I cable – connects the graphic card's VGA
connector to the monitor's input #2 (DVI-I analog)
connector

DVI-D to DVI-I cable – connects the graphic card's DVI­D digital connector to the monitor's input #2 (DVI-I
digital) connector

User Guide Languages

English, B. Portuguese, French, LA Spanish, Korean,
S. Chinese, T. Chinese, Bahasa, Japanese, Danish,
Finnish, German, Norwegian, Spanish, Swedish,
Greek, Polish, Russian, Slovenian, Turkish

Warranty Languages

English, Canadian French, LA Spanish, Brazilian
Portuguese, Danish, German, Castilian Spanish,
French, Italian, Dutch, Norwegian, Finnish, Swedish,
Bahasa Indonesian, Korean, T. Chinese, S. Chinese

Color

Carbonite/silver

VESA External Mounting

Yes (Standard 4 hole pattern, 100 mm)

Kensington Lock-Ready

Yes

Certification and
Compliance

Australian ACA Approval, Canadian Requirements/CSA, CE Marking, China CCIB/CCEE
Approval, CISPR Requirements, Eastern European Approvals, *Energy Star Compliant,
FCC Approval, German Ergonomic (TUV and GS Mark), ISO 9241-3,7,8 VDT
Guidelines, ISO 13406-2 Pixel Defect Guidelines, Mexican NOM Approval, MIC
Requirements (New Zealand), MPR-II Compliant, Nordic Approvals (Nemko, Fimko,
Demko, Semko), PC2001 Compliant, PC99 Certified, S. Korean MIC Approval, Taiwan
BSMI Approval, TCO 03 (emissions, ergonomics, environment), TUV-Ergo, UL Listed,
VCCI Approvals, Windows Certification (Microsoft® Windows® 98, Microsoft
Windows 2000, and Microsoft Windows XP).

* Energy Star Compliant available summer 2004.

Compatibility

Compatible with platforms using the VESA standard video modes and HP Compaq
Business Desktops d500, d300, and d200 Series, Compaq Evo Desktops, and HP
Business Desktops d300 series.

Service and Warranty

Limited three years parts, labor, and on-site service, including backlight. Availability
varies by region. Certain restrictions and exclusions apply. Consult HP Customer
Service for details.

© Copyright 2004 Hewlett-Packard Development Company, L.P.

All rights reserved. HP and the HP logo are trademarks of the Hewlett Packard Company in the U.S. and/or other countries.

Microsoft and Windows are trademarks of Microsoft Corporation in the U.S. and/or other countries. NVIDIA and Quadro are trademarks of NVIDIA
Corporation. All other product names mentioned herein may be trademarks of their respective companies.

HP shall not be liable for technical or editorial errors or omissions contained herein. The information is provided as is without warranty of any kind and
is subject to change without notice. The warranties for HP products are set forth in the express limited warranty statements accompanying such
products. Nothing herein should be construed as constituting an additional warranty

QuickSpecs

HP Workstation xw6200

Technical Specifications - Monitors

DA - 11975 Worldwide — Version 10 — November 1, 2004

Page 66
