HP vf51 User Manual

hp pavilion vf51

15-inch

LCD Monitor

(15-inch Viewable Image)

User’s Guide

Select Language

The information in this document is subject to change without notice.
Hewlett-P a ckard® Company (hereafter HP Company) makes no warranty of any kind with regard

to this material, including, but not limited to, the implied warranties of merchantability and fitness
for a particular purpose.

HP shall not be liable for errors contained herein or for incidental or consequential damages in
connection with the furnishing, performance, or use of this material.

HP assumes no responsibility for the use or reliability of its software on equipment that is not
furnishing by HP.

This document contains proprietary information that is protected by copyright. All rights are
reserved. No part of this document may be photocopied, reproduced, or translated to another
language without the prior written consent of HP.

Hewlett-Packard Company
Business Desktop Division
5, avenue Raymond Chanas – Eybens
38053 Grenoble Cedex 9
France

Printed in Taiwan
©Copyright Hewlett-Packard Company, 2002. All right reserved.
Hewlett-Packard is a registered trademark of Hewlett-Packard Company in the United State of

America and other countries.

Windows is a registered trademark of Microsoft, Inc.

Other brand or product names are trademarks of their respective holders.

ii

MAIN PAGE

Contents

Introduction ……………………………..………… 1

Features ……………………………………………………… 1
For Your Safety ……………………………………………… 2

Working in Comfort …………………………………………… 2

Installation ………………………………………… 3

Unpacking the Monitor ………………………………………. 3
Locations and Functions of Controls ……………………… 3
Connecting Your Monitor …………………………………… 4

How to Install the Drivers ……………………… 6

Windows 2000 Users ……..……............…...……………… 6

Windows Me Users ……..……............……...……………… 6

Windows XP Users ……..……............……...……………… 7

Using Your Monitor ……………………………… 8

Turning the Monitor On and Off ……..……...……………… 8
Tilting the Monitor …………………………………………… 9

Setting the Video Mode …………………………………… 9

Setting the Refresh Rate …………………………………… 9
Minimizing Power Consumption ……………………………. 10
Caring for and Cleaning the Monitor ……………………… 10

Adjusting Your Monitor …………….…………… 12

Summary of Control Buttons ……………………………… 12
Displaying the OSD Main Menu …………………………… 12
Selecting Items in the OSD Menu ………………………… 14
Making Adjustments in the OSD Menu …………………… 14
Using the Direct Keys ……………………………………… 20

Troubleshooting ……………………………… 22

LCD Monitor Quality and Pixel Policy for vf51

Monitor

………………………………………… 23

Technical Information …………………………. 24

Monitor Information …………………….………………… 24
Video Modes ………………………………………………. 25
Unknown Video Modes .…………………………………… 26

iii

Select Language

Declaration of Conformity …………………………………… 27
FCC Statement ……………………………………………….. 28
Declaration of VCCI Class B Compliance …………………. 28
Notice for Korea (Class B) ………………………………… 28
DOC Statement (Canada Only) …………………………….. 29
Environmental Information ………………………………… 29
ENERGY STAR Compliance ……………………………… 29

TCO 99 Compliance ………………………………………… 30

iv

MAIN PAGE

Introduction

This latest LCD monitor has a 15-inch active matrix TFT (thin film transistor) liquid crystal display
module. It is designed for use with any Windows®-based PC. The monitor’s compact design
provides great space savings on your computer desk.

Features

Important features include:

 Automatic configuration to the PC video settings with maximum XGA (1024 x 76 8) resolution .
 Three control buttons, plus OSD (on-screen display) for easy monitor settings adjustment and

configuration with instant feedback.

 Support analog video input for direct and immediate replacement of CRT displays.
 Tilt feature to optimize viewing position.
 Compliant with VESA Mounting standard for easy mounting on wall or mechanical arms.
 Anti-glare coating on the panel to reduce the reflection of ambient light.
 Flicker-free performance across all recommended video modes.
 Support for high refresh rates up to 75 Hz.
 VESA DDC2B Plug-and-Display compliant.
 A Power-saving feature that is compatible with Microsoft
 This monitor is compliant with ISO 13406-2 guidelines for reduced electromagnetic

emissions.

 Compliant with TCO99. (European Union Only)

®

Windows

Note: The lighting flash with the arrowhead symbol inside an equilateral triangle is intended to

alert the user to the pre sence of u ninsulate d, dange rous voltage which may be of suffic ient
magnitude to constitute a risk of electric shock.

The exclamation point within an equilateral triangle is intended to alert the user to the

presence of important operating and servicing instructions in the literature accompanying

the appliance.

1

MAIN PAGE

r

For Your Safety

Wa rning

To completely disconnect power from your displ ay, you must remove the powe
cord from the wall outlet and then remove the power cable from the display.

Only use with the power adapter supplied with the product. To avoid electrical

shock, do not open the power adapter. There are no user-serviceable parts
inside. Refer servicing to qualified service personnel.

For your safety and the protection of your monitor, follow these precautions:

 Use only the factory-supplied power cord that shipped with your monitor.
 To prevent electrical shock, do not disassemble the display. The cover should be removed only

by qualified service personnel.

 Do not cover the air vents.
 To avoid the risk of damage to the display and electrical shock to yourself, do not expose the

display to rain or moisture.

 Make sure the computer is tur ned off before conn ecting or disconnecting a display peripheral.
 If you are in any doubt that you can lift the equipment safely , do not tr y to move it without help.

If any of the following conditions occur, unplug the display and contact qualified service personnel:

 The power cord or plug is frayed or damaged.
 You have spilled liquid into the display.
 The display has been exposed to rain or water.
 The display does not operate correctly when the operating instructions are followed.
 The display has been dropped or the cabinet has been damaged.

Working in Comfort

To optimize your comfort and productivity , it’s important that you set up your work area correctly
and use your HP equipment properly. With that in mind, we have developed some setup and use
recommendations for you to follow based on established ergonomic principles.

You can consult the online version of Working in Comfort preloaded on the hard disk of HP
computers, or visit HP’s Working in Comfort Web site at:

http://www.hp.com/ergo

2

MAIN PAGE

Installation

Please follow the instructions in this chapter to install your LCD monitor.

Note: Before connecting your monitor, first read through the instructions in this chapter and the

safety precautions in the previous chapter.

Unpacking the Monitor

When you are unpacking the monitor, make sure that you have the following items:

 The LCD monitor
 AC power adapter with attached DC power cable
 A power cord
 Analog video signal cable
 CD with User's Guide and Driver
 Quick Start Guide
 Warranty Booklet

Note: Place the monitor on a flat, sturdy surface. Choose an area free from excessive heat,

moisture, and sunlight.

Locations and Functions of Controls

There are three control buttons and one power button on the front panel of the monitor, as well as
an LED for power status indication.

3

MAIN PAGE

Use the power button located at the lower middle of the front panel of your monitor to turn on and
off the monitor.

Three control buttons are also located at the lower middle of the front panel of your monitor. Their
functions are described below:

Button Function Description

Select

(1) Opens the OSD Main Menu.
(2) Selects item for user adjustment.

(1) Moves upward through items in the OSD Main

Up (▲)

Menu, or increases user-adjustable values.

(2) Opens Brightness Menu (Direct-key function).
(1) Moves downward through items in the OSD Main

Down (▼)

Menu, or decreases user-adjustable values.

(2) Auto Configuration (Direct-key function).

Connecting Your Monitor

Before connecting any cables, make sure that the computer and monitor are turned off.
To connect the power and video signal cables:

1. Locate the AC power adapter with attached DC power cable.

2. Connect the DC power cable to the power jack on the back of the monitor (as shown below).

3. Plug the power cord into the AC adapter and then into the main power source.

4

MAIN PAGE

4. Plug the analog video signal cable into the Analog Video Input port on the back of the monitor
(as shown above).

5. Connect the other end of the video cable int o yo ur compu ter’s video port. (Please check your
computer’s documentation for port location.)

Note: For best monitor performanc e, it is strongly recomm ended that you use Auto Configurati on

to automatically configure your monitor’s settings.

5

MAIN PAGE

How to Install the Drivers

The HP monitor comes with driver software that allows you to take advantage of the Plug and Play
feature of the Windows ® Me, Windows 2000, or Windows XP operating system. This software
enables the computer to communicate with the monitor and use all the monitor features. W ithout
this software, the monitor settings and display images will not be correct.

NOTE: HP computers may ship with the Plug and Play drivers preinstalled. If you have an older

computer, these drivers may not be preinstalled and you may need to install the drivers
from the CD-ROM disc that came with the monitor.

You can also download the latest version of a driver from the HP Monitor Support Web site at:

http://www.hp.com/go/monitorsupport/

Windows 2000 Users

NOTE: The procedure for installing the driver for your operating system may vary.

To install the driver for your monitor:

1.

Click Start, select Settings, and then click Control Panel.

2.

Double-click Display.

3.

Click the Settings tab.

4.

Click Advanced Properties or Advanced, and select the Monitor tab.

5.

Click Properties.

6.

Click the Driver tab.

7.

Click Update Driver and click Next.

8.

Select the recommended option and then click Next.

9.

Select the Specify a Location box.

10.

Find and open the vf51.inf file on the CD-ROM disc in the Drivers directory, and click OK.

11.

Click Next to install the selected monitor.

Windows Me Users

NOTE: The procedure for installing the driver for your operating system may vary.

To install the driver for your monitor:

1. Click Start, select Settings, and then click Control Panel

2. Click Display.

6

MAIN PAGE

3. Select the Settings tab.

4. Click Advanced button.

5. Select the Monitor tab.

6. Click the Change button.

7. Select the Specify a Location box.

8. Find and open the vf51.inf file on the CD-ROM disc in the Drivers directory, and click OK.

9. Click Next to install the selected monitor.

Windows XP Users

NOTE: The procedure for installing the driver for your operating system may vary.

To install the driver for your monitor:

1. Click Start.

2. Click Control Panel.

3. Click Appearance and Themes.

4. Clicks Display.

5. Select the Settings tab.

6. Click the Advanced button.

7. Select the Monitor tab.

8. Click Properties.

9. Select the Driver tab.

10. Click Update Driver and click Next.

11. Select the recommended option and then click Next.

12. Select the Specify a Location box.

13. Find and open the vf51.inf file on the CD-ROM disc in the Drivers directory, and click OK.

14. Click Next to install the selected monitor.

7

MAIN PAGE

Using Yo ur Monitor

This chapter contains information about using your LCD monitor.

Turning the Monitor On and Off

Use the power button located at the lower middle of the front panel of the monitor to turn the
monitor on and off. When the monitor is on, the light (LED) near the Power button is illuminated.
The light is green when both the monitor and PC are active, and amber when the monitor is in a
reduced power mode.

If your PC sends power saving signals to the monitor, the monitor’s power management features
reduce power consumption to low levels when your PC goes into its power-saving mode. See the
“Minimizing Power Consumption” section for more information.

If your PC doesn’t use industry standard power-save signaling techniques, you can reduce power
consumption by turning off the monitor when it won ’t be used for an extended period. You can turn
the monitor off even if you leave your PC running.

Note:

Because of the technology used in LCD panels, screen savers will not prolong the life of
your monitor. So if t he monitor will not be used f or an extende d period, be su re to turn it off.

Wa rning

To completely disconnect power from your display, you must
remove the power cord from the wall outlet and then remove
the power cable from the display.

8

MAIN PAGE

Tilting the Monitor

The monitor has a tilt feature that allows you to tilt the monitor back and forth to find the most
comfortable viewing position. To tilt the monitor, grasp the sides and push the monitor back or pull
it toward you until it is in the desired position. The monitor can be tilted 20º backward and 5º
forward.

Note: Do not tilt the monitor by grasping the top edge.

Setting the Video Mode

Since the inherent format of this monitor is 1024 pixels by 768 lines, the monitor will perform best
when your PC is set to a screen resolution of 1024 x 768. If you use a lower resolution (such as 640
x 480), the image is expanded to fill the screen but with a slightly degraded image quality.

Your monitor supports many common video modes, as shown in the “Video Modes” section.
Check the documentation supplied with your PC and video adapter card to find out which modes
they support.

To view the video mode in Microsoft Windows, check the Windows settings in your PC.

Setting the Refresh Rate

The image refresh rate is the number of times per second that the image is refreshed; it is also
known as the vertical frequency.

Although your LCD monitor supports up to 75 Hz for analog video input, we recommend that you

9

MAIN PAGE

use 60 Hz refresh rate for best performance. The table in the “Video Mode” section shows the
image refresh rates supported by the monitor at different screen resolutions.

T o set the refresh rate with a standard Windows installation, consult your Windows or graphics card
documentation.

Minimizing Power Consumption

Many PCs support industry standard power-save signaling techniques. Power management
features reduce the monitor’s power consumption after a period of keyboard and mouse inactivity .

When the monitor is in a power-saving mode, the screen is blank and the power indicator turns
amber . P ressing a key on the keyboard or moving the mouse r estores the image in several seconds.
Consult your PC documentation for information about setting the power-saving modes.

The monitor accepts the signals for the three standard power-saving modes – Standby, Suspend,
and Sleep – from your PC. For any of these conditions, the monitor will go into Sleep mode.

Caring for and Cleaning the Monitor

To maximize screen life and prevent damage to the LCD panel, we recommend that you:

 Use the monitor power management system (if available on your PC).
 If you don’t use a power management system, t u rn off the monitor when you won’t be using it

for an extended period.

 Don’t press, rub, or poke the monitor with your finger or other object.
 Handle your monitor with care.

Your LCD module is a high-quality optical device that requires special care when cleaning.

Wa rning

Don’t use liquid, aerosol, or abrasive cleaning solutions to
clean the screen.

To clean the screen:

1. Shut down the PC.

2. Turn off and unplug the monitor.

3. Gently dust the screen with a dry, soft, lint-free cloth.

10

MAIN PAGE

Note: If the screen is still dirty, you can dampen the cloth with several drops of distilled water.

Make sure the LCD panel is completely dry before you turn the monitor back on.

4. Plug in the monitor.

5. Turn on your PC and monitor.

11

MAIN PAGE

Adjusting Your Monitor

This chapter contains information about how to change display settings for your LCD Monitor . It is
designed with an On-Screen Display (OSD) menu to help you easily adjust to its optimum
performance.

Note: You must perform Auto Configuration before making any adjustment.

Summary of Control Buttons

There are three control buttons located at the low er middle part of the front panel of your monitor:

 Select: Displays the OSD Main Menu and selects items for user adjustment.

 Up (▲): Moves upward through the choice in the OSD Main Menu. If an adjustment bar is

displayed, this button increases the setting value.

Note: This key is also used as a direct key. When the OSD Main Menu is inactive, press this key

to open the OSD Brightness Menu.

 Down (

▼): Moves downward through the cho ice in the OS D Main Me nu. If an adjustment bar

is displayed, this button decreases the setting value.

Note: This ke y is also used as a direct key. When the OSD Main Menu is inact ive, press this key to

perform the Auto Configuration function.

Displaying the OSD Main Menu

You can use the OSD features to change the screen settings of your monitor. To display the OSD
Main Menu, press the Select button.

12

MAIN PAGE

The following table briefly describes each of the items in the OSD Main Menu.

Item Description

H POSITION

V POSITION

CLOCK

PHASE

Adjusts the horizontal (H) position of the displayed image. The default
setting of H position is in the middle.

Adjusts the vertical (V) position of the displayed image. The default setting
of V position is in the middle.

Adjusts the timing clock setting of the display. The default setting of the
timing clock is in the middle (50).

Adjusts the phase setting of the display. The optimum phase setting will be
different for different PCs.

AUTO Performs image auto adjustment function.

COLOR

Opens the COLOR submenu where you can select BLUISH, WHITE,
REDDISH, or USER RGB SAVE options.

CONTRAST Adjusts the level of difference between light and dark areas of the image.

BRIGHTNESS

Controls the brightness of the display by adjusting the light output of the
backlight.

OSD

MANAGER

Opens the OSD MANAGER submenu where you can select OSD
TIMEOUT, INFORM ON-OFF, H POSITION, or V POSITION options for
further adjusting.

MODE RECALL Recalls the manufacturing factory settings for current mode.

BACKLIGHT

Displays the elapsed turn-on time of the backlight.

INFO

SERIAL NUMBERDisplays the serial number of your monitor.

MODE INFO

LANGUAGE

EXIT

Displays the associated information of current mode used by your display.
Also, it contains the supported modes of this monitor.

Opens the LANGUAGE submenu where you can select ENGLISH,
DEUTSCH, FRANÇAIS, ITALIANO or ESPANOL options.

Exits the Main Menu.

13

MAIN PAGE

Selecting Items in the OSD Menu

To select a specific item in the OSD Main Menu, or a specific item in the OSD submenu, use the
Up (▲) and Down (▼) buttons to move to that item, and then select it by pressing the Select

button.

Making Adjustments in the OSD Menu

Adjusting the Positions of the Displayed Images

To adjust the horizontal (or vertical) positions of the displayed images, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (
V POSITION) icon and highlight it.

3. Press the Select button to select it. This will open the H POSITION (or V POSITION) bar with the
associated numeric value for your adjustment onscreen.

▲) or Down (▼) buttons to move forward or backwar d to the H P OSI TIO N (or

4. Press the Up (
to 100. The Up (▲) button will increase the numeric value of the setting and the Down (▼)

button will decrease it.

▲) or Down (▼) buttons to adjust its value. The range for adjustment is from 0

Adjusting the Clock and Phase Settings

To adjust the clock (or phase) setting, follow the steps below:

14

MAIN PAGE

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forward or backward to the CLOCK (or PHASE)
icon and highlight it.

3. Press the Select button to select it. This will open the CLOCK (or PHASE) bar with the associated
numeric value for you r adjustment onscreen.

4. Press the Up (
to 100. The Up (▲) button will increase the numeric value of the setting and the Down (▼)

button will decrease it.

▲) or Down (▼) buttons to adjust its value. The range for adjustment is from 0

Tip: If Auto Configuration does not produce a clear image, try adjusting the PHASE setting.

Performing Auto Configuration in the OSD Menu

To perform auto adjustment in the OSD menu, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (
highlight it.

3. Press the Select button to select it. This will open the AUTO CONFIG submenu and start the
auto adjustment function.

▲) or Down (▼) buttons to move forward or backward to the AUTO icon and

After the auto adjustment is complete, the OSD will close.

Configuring Colors

To configure the color settings for your preference, follows the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forward or backward to the COL OR icon and

15

MAIN PAGE

highlight it.

3. Press the Select button to select it. This will open the COLOR submenu with four options in it:
BLUISH, WHITE, REDDISH, and USER RGB SAVE.

4. Press the Up (▲) or Down (▼) buttons to select the setting.
As you choose an item, the color setting of your display immediately updates to reflect this

setting.

Yo u may also set your own color definitions. To do this, move to the USER RGB SAVE option,
and then press the Select button. This will open the USER RGB SAVE submenu.

Press the Up (

▲) or Down (▼) buttons to choose and move to one of the f ive options (R, G , B,

EXIT AND SAVE, and EXIT WITHOUT SAVE) and then press the Select button to select it.
If the R, G or B options are selected, the foreground color Yellow will be changed to White (the

color of background is Pink). Then you may adjust its setting by pressing the Up (

▲) or Down

(▼) buttons. This control may be helpful in achieving a more natural appearance in graphic
images and closer color matching between the printer and the monitor.

After you are finished adjusting the settings, save the new settings by choosing the EXIT AND
SAVE option. Or you may cancel the settings by choosing the EXIT WITHOUT SAVE option.

16

MAIN PAGE

Adjusting Contrast and Brightness

To adjust the contrast (or brightness) of the displayed images, follow the steps below:

1. Open the OSD Main Menu by selecting the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forward or backward to the CONTRAST (or
BRIGHTNESS) icon and highlight it.

3. Press the Select button to select it. This will open the CONTRAST (or BRIGHTNESS) bar with
associated numeric value for your adjustment onscreen.

4. Press the Up (▲) or Down (▼) buttons to adjust its value. The range for adjustment is from 0
to 100. Pr essing the Up (
the Down (▼) button will decrease it.

▲) button will increase the numeric value of the setting and pressing

Adjusting the OSD Display

To adjust the OSD display, follow the steps below:

1. Open the OSD Main Menu by selecting the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forwar d or backward to the OS D MANA GE R
icon and highlight it.

3. Press the Select button to select it. This will open the OSD MANAGER submenu with five
options in it.

Select EXIT to exit the OSD MANAGER submenu and go back to the Main Menu.

17

MAIN PAGE

You may determine how long the OSD will stay onscreen by selecting the OSD TIMEOUT
option. Increase or decrease the OSD display time by pressing the Up (▲) or Down (▼)

buttons in the OSD TIMEOUT submenu. The maximum timeout setting is 60 seconds.

You may turn on or off the displayed image information by selecting the INFORM ON-OFF
option. Turn this option on to display information onscreen that informs you when the input
signal has been changed.

If you want to put your OSD menu on a certain location on the scr een, select the H POSITION
and V POSITION options. Press the Up (▲) or Down (▼) buttons to change the OSD position

in the submenus using these two options.

Reverting to Factory Default Settings

If you have made some incorrect adjustments in the OSD menus and you don’t know how to get
back to a good setting, don’t worry. The MODE RECALL feature will return you to a good starting
point: the factory settings. To do a MODE RECALL, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (
icon and highlight it.

3. Press the Select button to select it. This will return you to the factory settings immediately.

▲) or Down (▼) buttons to move forward or backward to the MODE RECALL

Tip: MODE RECALL will return you the following settings:

H POSITION and V POSITION of the displayed image and OSD menu, BRIGHTNESS
and CONTRAST, CLOCK AND PHASE. COLOR will be set to WHITE and LANGUAGE
will set to ENGLISH.

18

MAIN PAGE

Checking Other Information about Your Monitor

There is some useful information available to you with the OSD display. These include BAC KLIGHT
INFO, SERIAL NUMBER and MODE INFO.

BACKLIGHT INFO tells you the total accumulat ed time the backlight has been turned on. To show
this information, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (
icon and highlight it.

3. Press the Select button to select it. This will open the submenu.

SERIAL NUMBER tells you the identification number of your monitor. To show this information,
follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forward or backward to the SERIAL NUMBER
icon and highlight it.

3. Press the Select button to select it. This will open the submenu.

MODE INFO tells you information about the mode displayed currently. Also, it will show you the
preset modes and currently saved user modes. To show this information, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button. Press the Up (▲) or Down (▼)
buttons to move forward or backward to the MODE INFO icon and highlight it.

▲) or Down (▼) buttons to move forward or backward to the BAC KLIGHT INFO

2. Press the Select button to select it. This will open the submenu.

3. Press the Up (
two additional submenus, PRESET and USER, which give you information about th e preset and
user modes currently supported in your display.

▲) or Down (▼) buttons select options in the MO DE INFO submenu. There are

19

MAIN PAGE

Choosing Your Native or Preferred Language for the OSD Display

There are five language options for the OSD display: English, Deutsch, Français, Italiano, and
Español. To make your choice, follow the steps below:

1. Open the OSD Main Menu by pressing the Select button.

2. Press the Up (▲) or Down (▼) buttons to move forward or backward to the LANGUA GE icon
and highlight it.

3. Press the Select button to select it. This will open the LANGUAGE submenu.

4. Press the Up (▲) or Down (▼) buttons to select the language you prefer.

Tip: As you choose an item, your OSD information displayed immediately updates to reflect this

setting.

Exiting the OSD Menu

In the OSD Main Menu, just press the Up (▲) or Down (▼) buttons to move forward or backward
to the EXIT icon, highlight it, and select it by pressing the Select button. The OS D menu will close.

Using the Direct Keys

There are two direct keys that function while the OSD Main Menu is inactive: one executes Auto
Configuration and the other opens the OSD BRIGHTNESS submenu.

Performing Auto Configuration Using the Direct Key

Use Auto Configuration whenever you apply a new vid eo mode or chan ge the refresh rate. While
the Auto Configuration routine is running, you should have a stable image displayed on the screen.
Do not move items around the screen, changing display mode, play games, or view video during
Auto Configuration.

For display image with black background, such as DOS mode, please do not perform Auto
Configuration.

20

MAIN PAGE

Note: Auto Configuration uses state-of-the-art signal proces sing algorithm s based on the im age

displayed on your screen. Therefore, you should not change the image on your screen
while Auto Configuration is running.

Once you have executed Auto Configuration for a particular mode, the monitor will store the new
values in its permanent memory.

To execute Auto Configuration using the Direct Key function:

1. Make sure the OSD Main Menu is not displayed onscreen. Press the Down (▼) button to open
the AUTO CONFIG submenu and start running Auto Configuration.

2. After Auto Configuration has finished, you should have a stable and clear image.

Adjusting Brightness Using the Direct Key

To adjust brightness directly:

1. Make sure the OSD Main Menu is not displayed onscreen. Pr ess the Up (▲) button to open the
BRIGHTNESS submenu.

2. Press the Up (

3. Press the Select button to close and exit the BRIGHTNESS menu.

▲) or Down (▼) buttons to increase or decrease the brightness setting.

21

MAIN PAGE

Troubleshooting

This chapter contains information about how to troubleshoot your LCD Monitor. If you have tried
all of the items listed below, please contact a qualified service technician.

A. My monitor doesn’t work, even though the computer appears to

work.

1. Make sure the power cable is securely plugged into the monitor.

2. Make sure the monitor is turned on.

3.

Try turning the monitor off and then turning it on again.

4.

Make sure the monitor’s power cord is plugged into a power outlet and into the AC power
adapter. Check to see whether the outlet works by plugging another device (such as a lamp)
into the outlet. (If the light on the front of the monitor is lit, it is getting po wer. Try the next item
on this procedure.)

5.

Check the cable connection between the monitor and the computer. The cable connectors
must be pushed in all the way.

B. The message “No Signal” appears on my monitor.

This message appears when the video cable is not properly connected to the computer.

1. Make sure the analog video cable is plugged into the Analog Video Input port on the back of

the monitor.

2. Make sure the other end of the analog video cable is plugged into the PC’s video port.

C. The image is very unstable.

1. Set your PC to a supported video mode, preferably 1024 x 768 at 60 Hz . See the “Setting the
Video Mode” section.

2. Restore the original factory settings by choosing MODE RECALL in the OSD Main Menu.

3. Perform the Auto Configuration function. See the “Performing Auto Configuration Using the
Direct Key” section.

22

MAIN PAGE

LCD Monitor Quality and Pixel Policy for
vf51 Monitor

vf51 15-inch monitor

The HP vf51 TFT monitor uses high-precision technology, manufactured according to HP
standards, to guarantee trouble-free performance. Nevertheless, the monitor may have cosmetic
imperfections that appear as small bright or dark spots. This is common to all LCD monitors used
in products supplied by all vendors and is not specific to the HP P4824A LCD. One or more
defective pixels or sub-pixels cause these imperfections.

• A pixel consists of one red, one green, and one blue sub-pixel.

• A defective whole pixel is always on (a bright spot on a dark background), or it is always off (a

dark spot on a bright background). The first is the more visible of the two.

• A defective sub-pixel (dot defect) is less visible than a defective whole pixel and is small and only

visible on a specific background.
The HP P4824A monitor does not have more than:

• 10 total dot defects.

• 10 defective full pixels.

• 10 defective red sub-pixels.

• 4 defective green sub-pixels (green is most visible).

• 10 defective blue sub-pixels.

• No more than two adjacent (less than 2.5 mm edge-to-edge) and defective pixels.

• No more than two pairs of two adjacent defective pixels.

To locate defective pixels, the monitor should be viewed under normal operating conditions, in
normal operating mode at a supported resolution and refresh rate, from a distance of
approximately 50 cm (16 in.).

HP expects that, over time, the industry will continue to improve its ability to produce LCDs with
fewer cosmetic imperfections and HP will adjust guidelines as improvements are made.

23

MAIN PAGE

Technical Information

This chapter contains technical information about your LCD Monitor.

Monitor Information

LCD Module 15-in (38.1 cm), active matrix TFT, anti-glare coating, 0.297 mm pixel pitch
Display Size 304.1 mm x 228.1 mm
Viewing Angle

Left/Right
Up/Down

Luminance
Contrast Ratio

Display Colors 16.7 Millions
AC Adapter

Input
Output

Power consumption Operating mode: 30W max.

Signal Input

Video Signal
Sync signals

Line (horizontal)
frequency

-60° ~ 60°

-55° ~ 45°

2

220 cd/m
350 : 1 (Typical)

100 ~ 240 V
12 VDC, 3.3 A

Sleep mode: 2W max.

RGB positive 0.7VPP, 75 ohm
Separate, TTL Level

30 kHz ~ 63 kHz

(Typical)

Full Range, 50/60 Hz. < 1.2 A @ 110V; < 0.6 A @ 230 V

AC

Raster (vertical)
frequency

Pixel dot clock 80 MHz (maximum)
Recommended mode1024 x 768 @ 60 Hz
Pedestal tilt

Dimensions
(W x H x D)

Net weight
Gross weight

56 Hz ~ 75 Hz

20° forward, -5°backward

341mm x 317.43mm x 140mm
341mm x 338.1 mm x 67.6 mm (pedestal fold)

3.0 kg

4.5 kg

24

MAIN PAGE

Operating
Conditions

Temperature

5° ~ 40°C at altitude 0 ~ 2000m
5° ~ 30°C at altitude 2000 ~ 3000m

Humidity
Altitude

20% ~ 85% RH, non-condensing
3000m Max.

Storage Conditions

Temperature
Humidity
Altitude

-20° ~ 60°C
5% ~ 95% RH

10000m Max.

Video Modes

Your LCD monitor supports the following industry -standard combinations of screen resolution and
refresh rates. Other combinations are possible, but may require adjustments to the image.

For optimum performance, set your PC to a screen resolution of 1024 x 768 at a 60 Hz refresh
rate.

Supported Resolution

(dots x lines)

VGA 640 x 350

640 x 480
640 x 480
640 x 480
640 x 480

Vertical Frequency

(Refresh Rate)

70 Hz

(1)

60 Hz
70 Hz
72 Hz
75 Hz

SVGA 800 x 600

800 x 600
800 x 600
800 x 600
800 x 600

XGA 1024 x 768

1024 x 768
1024 x 768
1024 x 768

56 Hz
60 Hz
70 Hz
72 Hz
75 Hz

60 Hz
70 Hz
72 Hz

75 Hz
US TEXT 720 x 400 70 Hz
Power MAC 640 x 480

832 x 624

(1)

This display mode is supported without extend to full screen.

25

67 Hz

75 Hz

MAIN PAGE

Unknown Video Modes

Like all other monitors, your LCD monitor is designed to work with standard video modes. However,
not all video/graphics cards use only standard display modes.

Y our LCD monitor uses state-of-the-art technology , which is designed to automatically synchronize
to any display mode listed in the above table. We recommend you choose one of the supported
modes listed above. If you choose an unknown mode, you will need to manually adjust the cloc k,
phase, and image position and may still get a bad display.

If you must use a display mode beyond the above list, you should run Auto Configuration first. If
Auto Configuration doesn’t provide adequate image adjustment, then you must manually adjust
the clock, phase, horizontal position, and vertical position. If this still not work, please choose a
recommended mode.

26

MAIN PAGE

DECLARATION OF CONFORMITY

According to ISO/IEC Guide 22 and CEN/CENELEC EN 45014

Manufacturer's name: HEWLETT-PACKARD France
Manufacturer's address: 5 Avenue Raymond Chanas-Eybens

38053 GRENOBLE Cedex 09 - FRANCE

Declares that the product :
Product Name HP LCD 15” Monitor
Model Name vf51
Product Number P4824** (Where * can be any alphanumeric character or blank)

Conforms to the following Product Specifications:

 SAFETY

- International: IEC 60950:1991 +A1 +A2 +A3 +A4 / GB4943-1995.

- Europe : EN 60950:1992 +A1 +A2 +A3 +A4 +A11.

 ELECTRO-MAGNETIC COMPATIBILITY

- CISPR22:1997 / EN55022:1998 Class B

- CISPR24:1997 / EN55024:1998

- IEC 61000-3-3:1994 / EN61000-3-3:1995

- GB9254-1998

- FCC Title 47 CFR, Part 15 Class B

- ICES-003, Issue 3

- VCCI-B

- AS/NZ 3548:1995

Products bearing the CE marking

IEC 61000-3-2:1995 / EN 61000-3-2:1995. + A14

Those products comply with the requirements of the following Directives and carry the CE-marking
accordingly: EMC Directive 89/336/EEC and Low Voltage Directive 73/23/EEC, both amended by
the Directive 93/68/EEC.

(1)

This device complies with Part 15 of the FCC rules. Operation is subject to the following two

(2)

All products sold in the European Economic Area (EEA) bear the CE marking.

(1)

(2)

also comply with:

conditions:
a- This device may not cause harmful interference, and
b- This device must accept any interference received, including interference that may cause

undesired operation.

Grenoble Benoit MONTFORT
June 2002 Quality Manager

For Compliance Information ONLY, contact :

USA contact : Hewlett Packard Company, Corporate Product Regulations Manager
3000 Hanover Street, Palo Alto, CA 94304.

(Phone (+1) [phone])

27

MAIN PAGE

FCC Statement

This equipment has been tested and found to comply with the limits for a Class B digital device
pursuant to P art 15 of the FCC Rules. These limits are designed to provide reasonable protectio n
against harmful interference in a residential installation. This equipment generates, uses, and can
radiate radio frequency energy . If not installed and used in accordance with the instructions, it can
cause harmful interference to radio communicati ons. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can b e determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:

■

Reorient or relocate the receiving antenna.

■

Move the monitor and the PC away from the radio or television.

■

Plug the monitor and PC into a different electrical outlet so that the monitor and PC and the radio
or television are on separate electrical circuits.

■

Make sure that all peripheral devices are also FCC Class B-c ertified.

■

Consult a PC dealer, HP, or an experienced radio/TV technician for help.

Note: HP’s system verification tests were conducted with HP-supported peripheral devices and

HP-shielded cables, such as those you received with your system. Cables used with this
monitor must be properly shielded to comply with FCC requirements.

Changes or modifications not expressly approved by HP could void the user’s authority to operate
the equipment.

Declaration of VCCI Class B Compliance

Notice for Korea (Class B)

28

MAIN PAGE

DOC Statement (Canada Only)

This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.

Cet appareil numérique de la Classe(*) est conforme à la norme NMB-003 du Canada

Environmental Information

HP has a strong commitment toward the environment. Your HP monitor has been designed to
respect the environment as much as possible.

HP can also take back your old monitor for recycling when it reaches the end of its useful life.
HP has a product take-back program in several countries/regions. The collected equipment is sent

to one of HP’s recycling facilities in Europe or the USA. As many parts as possible are reused. The
remainder is recycled. Special care is taken for batteries and other potentially toxic substances,
which are reduced to non-harmful components through a special chemical process. If you require
more details about HP’s product take-back program, contact your dealer or your nearest HP Sales
Office.

This hp product contains the following materials that may require special handling at end-of-life:
mercury in the liquid crystal display.

ENERGY STAR Compliance

Hewlett-Packard Pavilion PCs and Monitors marked with the ENERGY STAR®
logo on the packaging box qualify with the U.S. Environmental Protection
Agency ’s ENERGY STAR guidelines for energy efficiency.

Products with the ENERGY STAR label are designed to use less energy, help you
save money on utility bills, and help protect the environment.

ENERGY STAR

®

is a registered trademark owned by the U.S. government.

29

MAIN PAGE

Congratulations!

You have just purchased a TCO'99 approved and labelled product! Your choice has provided you with
a product developed for professional use. Your purchase has also contributed to reducing the burden
on the environment and also to the further development of environmentally adapted electronics
products.

This product meets the requirements for the TCO'99 scheme which provides for an international
environmental and quality labelling of personal computers. The labelling scheme was developed as a
joint effort by the TCO (The Swedish Confederation of Professional Employees), Svenska
Naturskyddsforeningen (The Swedish Society for Nature Conservation), Statens Energimyndighet
(The Swedish National Energy Administration) and SEMKO AB.

The requirements cover a wide range of issues: environment, ergonomics, usability, reduction of
electric and magnetic fields, energy consumption and electrical safety.

Why do we have environmentally labelled computers?

In many countries, environmental labelling has become an established method for encouraging the
adaptation of goods and services to the environment. The main problem, as far as computers and other
electronics equipment are concerned, is that environmentally harmful substances are used both in the
products and during their manufacture. Since it is not so far possible to satisfactorily recycle the
majority of electronics equipment, most of these potentially damaging substances sooner or later enter
nature.

There are also other characteristics of a computer, such as energy consumption levels, that are
important from the viewpoints of both the work (internal) and natural (external) environments. Since
all methods of electricity generation have a negative effect on the environment (e.g. acidic and
climate-influencing emissions, radioactive waste), it is vital to save energy. Electronics equipment in
offices is often left running continuously and thereby consumes a lot of energy.

What does the environmenal labelling involve?

The environmental demands has been developed by Svenska Naturskyddsforeningen (The Swedish
Society for Nature Conservation). These demands impose restrictions on the presence and use of
heavy metals, brominated and chlorinated flame retardants, CFCs (freons) and chlorinated solvents,
among other things. The product must be prepared for recycling and the manufacturer is obliged to
have an environmental policy which must be adhered to in each country where the company
implements its operational policy.

The energy requirements include a demand that the computer and/or display, after a certain period of
inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of
time to reactivate the computer shall be reasonable for the user.

29 January, 1999

MAIN PAGE

Below you will find a brief summary of the environmental requirements met by this product. The
complete environmental criteria document may be ordered from:

TCO Development
SE-114 94 Stockholm, Sweden
Fax: [phone]

Email (Internet): [e-mail]
Current information regarding TCO'99 approved and labelled products may also be
obtained via the Internet, using the address: http://www.tco-info.com/

Environmental requirements

Flame retardants

Flame retardants are present in printed circuit boards, cables, wires, casings and housings. Their
purpose is to prevent, or at least to delay the spread of fire. Up to 30% of the plastic in a computer
casing can consist of flame retardant substances. Most flame retardants contain bromine or chloride,
and those flame retardants are chemically related to another group of environmental toxins, PCBs.
Both the flame retardants containing bromine or chloride and the PCBs are suspected of giving rise to
severe health effects, including reproductive damage in fish-eating birds and mammals, due to the bio­accumulative
disturbances in foetus development may occur.

The relevant TCO'99 demand requires that plastic components weighing more than 25 grams must not
contain flame retardants with organically bound bromine or chlorine. Flame retardants are allowed in
the printed circuit boards since no substitutes are available.

*

processes. Flame retardants have been found in human blood and researchers fear that

Cadmium**

Cadmium is present in rechargeable batteries and in the colour-generating layers of certain computer
displays. Cadmium damages the nervous system and is toxic in high doses. The relevant TCO'99
requirement states that batteries, the colour-generating layers of display screens and the electrical or
electronics components must not contain any cadmium.

Mercury**

Mercury is sometimes found in batteries, relays and switches. It damages the nervous system and is
toxic in high doses. The relevant TCO'99 requirement states that batteries may not contain any
mercury. It also demands that mercury is not present in any of the electrical or electronics components
associated with the labelled unit. There is however one exception. Mercury is, for the time being,
permitted in the back light system of flat panel monitors as there today is no commercially available
alternative. TCO aims on removing this exception when a mercury free alternative is available.

CFCs (freons)

The relevant TCO'99 requirement states that neither CFCs nor HCFCs may be used during the
manufacture and assembly of the product. CFCs (freons) are sometimes used for washing printed
circuit boards. CFCs break down ozone and thereby damage the ozone layer in the stratosphere,
causing increased reception on earth of ultraviolet light with e.g. increased risks of skin cancer
(malignant melanoma) as a consequence.

Lead**

Lead can be found in picture tubes, display screens, solders and capacitors. Lead damages the nervous
system and in higher doses, causes lead poisoning. The relevant TCO´99 requirement permits the
inclusion of lead since no replacement has yet been developed.

*

Bio-accumulative is defined as substances which accumulate within living organisms

**

Lead, Cadmium and Mercury are heavy metals which are Bio-accumulative.

29 January, 1999

MAIN PAGE
