Single Controller Installation Instructions
These instructions appl y on ly when insta lling an HP SureStor e E Di s k Array 12H with a single controller. I f you a re
inst alling a sin gl e controller disk array, read this sheet an d follow the in s truction s carefull y.
Single Controller Slot Selection
A single controller should be installed in slot X as shown in the following figure.
Single Controller Installation Instructions
Customer part number:
A3700-90903
Printed in U.S.A.
June 1999
Edition 2
E0699
CONTINUE ON REVERSE
Part Number
' $(&#&'
*A3700-96019*
Page 2
Suppressing Single-Controller Warning Messages
When a single controller disk array is turned on for the first time, the control panel may display a “System Warning”
error message, which occurs because only one controller is installed. By default, the disk array assumes there should
be two controllers installed, and therefore it will generate single-controller error messages until you suppress them.
If a “System Warning” error message is displayed on the front panel, you must first verify that it is caused by the
detection of a single controller. Use the control panel keys to verify the source of the message by using the following
key sequence:
KEY DISPLAY
CANCEL CANCEL “System Warning”
MENU “Language”
– “View Settings”
ENTER “System S tate: System Warnin g”
+ “Warning: Single Controller”
NOTE. If you do not see the Single Contr oller warning message and the disk array continues to
display a System War ning, refer to the
Service Manual
To avoid futur e singl e -controller warning messa ges, you c an suppres s them using the arraymgr ARM command
line utility. The ARM utilities are installed with the AutoRAID Manager software. If the software has not been
installed on the host, refer to the HP SureStore E Disk Array 12H System Admini st rato r’s Guid e for instructions.
for assistance in interpreting the warni ng.
HP SureStore E Disk Array 12H User’s and
To suppress single-controller warning messages, type the following command from the host:
arraymgr -J SingleController <array-id>
<array-id> can cont ain the disk array serial n umber or an alia s tex t string assigned to th e di s k array.
