HP ProCurve 4148gl, ProCurve 4104gl, ProCurve 4160gl, J4887A, J4861A Specifications

ProCurve Switch 4100gl Series

The ProCurve Switch 4100gl series is convergence-ready and easy to use, and is
available in compact 8-slot and 4-slot modular form factors. Based on ProCurve
Fast Path Technology, these switches provide reliable, high-performance,
high-density 10 Mbit, 100 Mbit, or Gigabit connectivity for a growing network.
The ProCurve 4100gl series is the low-cost, modular alternative to stackable
switches and includes a lifetime warranty.

ProCurve Switch 4104gl
(J4887A)

ProCurve Switch 4140gl
(J8151A)

ProCurve Switch 4160gl
(J8152A)

ProCurve Switch 4108gl
Bundle (J4861A)

ProCurve Switch 4148gl
(J4888A)

ProCurve Switch 4108gl
(J4865A)

ProCurve Switch 4100gl Series

Features and benefits

Performance

• Fast Path Technology: wire-speed switching of

intra-module traffic for up to 31.9 million pps
throughput; fully loaded 8-slot chassis capable of
switching 255 million pps

• Fast switch fabric: inter-module traffic

switching of up to 2.97 million pps

Resiliency and high availability

• IEEE 802.3ad Link Aggregation Control

Protocol (LACP) and ProCurve trunking:

support up to 6 trunks, each with up to 4 links
(ports) per trunk; trunking across modules is
supported

• IEEE 802.1w Rapid Convergence Spanning

Tree Protocol: increases network uptime through

faster recovery from failed links

• Optional redundant power supply: provides

uninterrupted power; allows hot-swapping of one
of the two supplies when installed

Security

• Port security: allows access only to specified

MAC addresses, which can be learned or
specified by the administrator

• IEEE 802.1X and RADIUS network login and

OpenVLAN: control port-based access for

authentication and accountability

• TACACS+: eases switch management security

administration by using a password
authentication server

• Secure Shell (SSHv2): encrypts all transmitted

data for secure, remote command-line interface
(CLI) access over IP networks

• Secure Sockets Layer (SSL): encrypts all HTTP

traffic, allowing secure access to the
browser-based management GUI in the switch

• Secure management access: all access

methods--CLI, GUI, or MIB--are securely
encrypted through SSHv2, SSL, and/or SNMPv3

• Hot-swappable modules: permit modules,

mini-GBICs, and one of the power supplies in a
redundant power supply configuration to be
added or swapped without interrupting the
network

Layer 2 switching

• VLAN support and tagging: supports the IEEE

802.1Q (4,096 VLAN IDs) and 30 VLANs
simultaneously

• GARP VLAN Registration Protocol: allows

automatic learning and dynamic assignment of
VLANs

Layer 3 routing

• Basic IP routing: enables automatic routing to

the connected VLANs and up to 16 static
routes--including one default route--in IP
networks

Convergence

• IEEE 802.1AB Link Layer Discovery Protocol

(LLDP): automated device discovery protocol for

easy mapping by network management
applications

• Stacking capability: single IP address

management for a virtual stack of up to 16
switches, including the ProCurve 2500 series,
2510 series, 2600 series, 2800 series, 2810 series,
2900 series, 3400cl series, 3500yl series, 4200vl
series, 6108, 6200yl-24G-mGBIC, and 6400cl
series

Quality of Service (QoS)

• Traffic prioritization (IEEE 802.1p): allows

real-time traffic classification into 8 priority
levels mapped to 4 queues

2

ProCurve Switch 4100gl Series

Manageability

• RMON: provides advanced monitoring and

reporting capabilities for statistics, history,
alarms, and events

• Friendly port names: allow assignment of

descriptive names to ports

• ProCurve/IEEE Auto-MDIX: automatically

adjusts for straight-through or crossover cables
on all 10/100/1000 ports

• Dual flash images: provides independent

primary and secondary OS files for backup while
upgrading

Industry-leading warranty

• Lifetime warranty: for as long as you own the

product, with next-business-day advance
replacement (available in most countries)

Services

ProCurve Switch 4104gl

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE241E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE242E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE243E)

• 3-year, 24x7 SW phone support, software

updates (UE263E)

• Installation with minimum configuration,

system-based pricing (U4827E)

• Installation with HP-provided configuration,

system-based pricing (U4831E)

ProCurve Switch 4108gl Bundle

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE244E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE245E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE246E)

• 3-year, 24x7 SW phone support, software

updates (UF787E)

• Installation with minimum configuration,

system-based pricing (U4827E)

• Installation with HP-provided configuration,

system-based pricing (U4831E)

ProCurve Switch 4140gl

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE241E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE242E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE243E)

• 3-year, 24x7 SW phone support, software

updates (UE263E)

• Installation with minimum configuration,

system-based pricing (U4827E)

• Installation with HP-provided configuration,

system-based pricing (U4831E)

ProCurve Switch 4148gl

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE241E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE242E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE243E)

• 3-year, 24x7 SW phone support, software

updates (UE263E)

• Installation with minimum configuration,

system-based pricing (U4827E)

• Installation with HP-provided configuration,

system-based pricing (U4831E)

ProCurve Switch 4160gl

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE244E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE245E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE246E)

• 3-year, 24x7 SW phone support, software

updates (UF787E)

• Installation with minimum configuration,

system-based pricing (U4827E)

3

ProCurve Switch 4100gl Series

• Installation with HP-provided configuration,

system-based pricing (U4831E)

ProCurve Switch 4108gl

• 3-year, 4-hour onsite, 13x5 coverage for

hardware (UE244E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware (UE245E)

• 3-year, 4-hour onsite, 24x7 coverage for

hardware, 24x7 software phone support
(UE246E)

• 3-year, 24x7 SW phone support, software

updates (UF787E)

• Installation with minimum configuration,

system-based pricing (U4827E)

• Installation with HP-provided configuration,

system-based pricing (U4831E)

4

ProCurve Switch 4100gl Series

Specifications

Included accessories

Ports

ProCurve Switch 4104gl
(J4887A)

4 open module slots 4 open module slots 2 open module slots

1 RS-232C DB-9 console port 1 RS-232C DB-9 console port 1 RS-232C DB-9 console port

Supports a maximum of 96
auto-sensing 10/100 ports or 80
Gigabit ports plus 8 mini-GBICs,
or a combination

ProCurve Switch 4108gl
Bundle (J4861A)

3 ProCurve Switch gl 24-Port
10/100-TX Module (J4862B)
1 ProCurve Switch gl Transceiver
Module (J4864A)

Supports a maximum of 168
auto-sensing 10/100 ports or 80
Gigabit ports plus 8 mini-GBICs,
or a combination

72 auto-sensing 10/100 ports
(IEEE 802.3 Type 10Base-T, IEEE

802.3u Type 100Base-TX); Media
Type: ProCurve Auto-MDIX;
Duplex: half or full

3 transceiver ports

ProCurve Switch 4140gl
(J8151A)

2 ProCurve Switch gl 20-Port
10/100/1000 Module (J4908A)

Supports a maximum of 48
auto-sensing 10/100 ports or 80
Gigabit ports plus 8 mini-GBICs,
or a combination

40 auto-sensing 10/100/1000
ports (IEEE 802.3 Type 10Base-T,
IEEE 802.3u Type 100Base-TX,
IEEE 802.3ab Type 1000Base-T);
Media Type: IEEE Auto-MDIX;
Duplex: 10Base-T/100Base-TX:
half or full; 1000Base-T: full only

4 open mini-GBIC (SFP) slots

Physical characteristics

Dimensions

Weight

Memory and processor

Fabric

Module

Mounting

Performance

Latency

Throughput

15.3(d) x 17.4(w) x 5.25(h) in.
(38.86 x 44.2 x 13.34 cm) (3U
height)

14.77 lb. (6.7 kg), Fully loaded 22.93 lb. (10.4 kg), Fully loaded 22.93 lb. (10.4 kg), Fully loaded

Motorola PowerPC @ 200 MHz, 8
MB flash, 32 MB SDRAM

IDT MIPS32 @ 125 MHz, 512 KB
flash; packet buffer size: 512 KB

8 MB SDRAM 8 MB SDRAM

Mounts in an EIA-standard 19 in.
telco rack or equipment cabinet
(hardware included); horizontal
surface mounting only

< 10.2 µs (FIFO 64-byte packets) < 10.2 µs (FIFO 64-byte packets) < 10.2 µs (FIFO 64-byte packets)

Gbps Gbps Gbps

up to 35.7 million pps up to 71.4 million pps up to 35.7 million pps

15.3(d) x 17.4(w) x 8.75(h) in.
(38.86 x 44.2 x 22.23 cm) (5U
height)

Motorola PowerPC @ 200 MHz, 8
MB flash, 32 MB SDRAM

IDT MIPS32 @ 125 MHz, 512 KB
flash, 512 KB SRAM; packet buffer
size: 1 MB

Mounts in an EIA-standard 19 in.
telco rack or equipment cabinet
(hardware included); horizontal
surface mounting only

15.3(d) x 17.4(w) x 5.25(h) in.
(38.86 x 44.2 x 13.34 cm) (3U
height)

Motorola PowerPC @ 200 MHz, 8
MB flash, 32 MB SDRAM

IDT MIPS32 @ 125 MHz, 512 KB
flash; packet buffer size: 512 KB

Mounts in an EIA-standard 19 in.
telco rack or equipment cabinet
(hardware included); horizontal
surface mounting only

5
