HP ProCurve Networking
Networking solutions for small and growing businesses
A network you can depend on ................................2
Essential network connectivity ..................................3
Improved network performance
for growing businesses ...........................................4
Increased security ..................................................5
Flexible wireless connectivity ...................................6
Converged communications ....................................9
HP ProCurve Customer Care .................................10
Page 2
Your company’s competitive advantage?
A network you can depend on.
Driving the success and growth of small- to medium-sized businesses
presents a unique set of challenges—not the least of which is installing
a reliable, no-nonsense network. As the backbone of your business,
it will seamlessly connect your employees, vendors, and customers;
protect and enable the sharing of company-critical information; increase
productivity; position your organization for growth; and keep the
competition on their toes.
HP ProCurve Networking understands completely. For more than
25 years, ProCurve has delivered reliable, plug-and-play network
solutions to small- and medium-sized businesses throughout the world.
With enterprise quality at an affordable price, HP ProCurve solutions
can help take you as far as you want to go.
Consider these questions:
• Is your network limiting productivity?
• Are you concerned that your company or customer data is vulnerable?
• Do you need to give your workers greater wireless flexibility?
• Do you have confidence in your network’s reliability?
• Are you installing a network for the first time?
• Are you considering deploying networked voice and video applications?
Whatever your business objectives and challenges, HP ProCurve has
a portfolio of solutions specifically designed for your company or
organization. Choosing HP ProCurve as your trusted partner lets you
focus your expertise and time where it belongs—on your business.
Page 3
Essential network connectivity
Share files. Share knowledge. Share resources. Bottom line: increase productivity.
Scenario:
Your company is growing—more employees, more
computers, more printers. Without a network,
employees are unable to access each other via email,
share files, share printers, or access the Internet,
limiting productivity.
HP ProCurve Switch 1710-24
HP ProCurve Wireless
Access Point 10ag
Solution:
The benefits of creating a network for your business
are far reaching. An HP ProCurve network allows
your company to:
• Exchange ideas and documents over email
• Access the Internet for quick and easy research
• Share a high-performance print device and eliminate
individual desktop printers for each employee
• Easily add an HP ProCurve wireless access
point, if mobile workers or guests require
wireless connectivity
Internet
HP ProCurve Switch 2510-24
Servers
Wireless users
Essential network connectivity products:
• HP ProCurve Switch 2510 Series: ideal for managed
10/100 connectivity
– Fully managed, yet easy to set up and configure
– Provides choice of simple Web configuration,
more comprehensive command line interface (CLI)
configuration, or network-wide configuration and
monitoring using HP ProCurve Manager (PCM)
– Security via network segmentation, management,
and authentication
– Quiet, fanless design of the 24-port model is
ideal for open-office deployments
Storage/
Backup device
Network printers
• HP ProCurve Switch 1700 Series: ideal
for basic capabilities and management
– Web-managed switches configured through an
intuitive Web management interface
– Quiet, fanless design is ideal for open-
office deployments
– 1700 series offers 10/100 connectivity
• HP ProCurve Wireless Access Point 10ag: ideal for
deploying wireless connectivity that is easy to set up
and manage
– Basic, secure, reliable IEEE 802.11a and
802.11b/g wireless connectivity
– Quick deployment using a simple, streamlined,
and intuitive Web interface
3
Page 4
Improved network performance for growing businesses
Is your business pushing the limits of its existing network? It’s time to upgrade to Gigabit.
Scenario:
Your employees need to share data and large files
with each other and between numerous printers,
scanners, data storage devices, and servers. It seems
that network traffic is always heavy. Employees—and
clients—are getting frustrated with the slow network.
Solution:
Improve the performance of your network to help
employees connect with each other and to network
resources quickly and easily with HP ProCurve Gigabit
switches. HP ProCurve Gigabit network performance
HP ProCurve Switch 1810G-24 HP ProCurve Switch 2510G-24
is all about greater efficiency, greater productivity,
investment protection, and the ability to improve
customer service.
• Exchange large files without hesitation—and without
a wait on the part of recipients.
• Handle bandwidth-hungry applications such as
graphical data, video streams, large databases,
and data storage with ease.
• Realize greater performance from any Gigabitenabled devices that are connected to the network,
including PCs, laptops, printers, and servers.
Internet
Servers
Gigabit-enabled
laptops
Improved network performance products:
• HP ProCurve Switch 2810 Series: ideal for small and
midsized businesses that require more advanced
network monitoring and configuration
– Sophisticated network monitoring using sFlow and
HP ProCurve Network Immunity Manager
– Scalability with support for 256 VLANs and more
granular QoS priority
– Advanced security with support for source
port filtering
– Optional redundant power supply
• HP ProCurve Switch 2510G Series: ideal for small
and midsized businesses that are ready to upgrade
to managed Gigabit
– Offers a reliable and affordable path for
upgrading to increased network performance
– Facilitates large file transfers and high-bandwidth
applications, such as graphical data, video
streams, large databases, and data storage
Storage/
Gigabit-enabled
desktops
Backup device
Network printers
– Secure connectivity with multiple authentication
methods and protected ports to segment
network traffic
– Fully managed, yet easy to set up and configure
– Provides choice of simple Web configuration, more
comprehensive CLI configuration, or network-wide
configuration and monitoring using HP ProCurve
Manager and other SNMP-based applications
• HP ProCurve 1810G Switch Series: ideal for basic
capabilities and management
– Web-managed switches configured through an
intuitive Web management interface
– Quiet, fanless design is ideal for open-
office deployments
– 8-port version can be powered by PoE for flexible
deployment options
• HP ProCurve Switch 1400 Series: ideal for basic,
unmanaged connectivity
– Plug-and-play Gigabit, with no
configuration capabilities
4
Page 5
Increased security
How do you control who has access to your network? Is your sensitive data secure?
Scenario:
As an online retailer, you worry about protecting
your customers’ most valued asset—their private
data. You have heard about hackers stealing credit
card numbers and other valuable data, but you are
unsure of how to prevent such an attack on your
own network.
HP ProCurve Switch 2610-24/12PWR
HP ProCurve
Wireless Access
Point 10ag
HP ProCurve Switch 2610-24
Solution:
HP ProCurve protects your information and assets
with trusted industry-standards-based security solutions
for wired and wireless networking. HP ProCurve
weaves security capabilities throughout its network
infrastructure—security is built in, not bolted on; and
ProCurve puts more intelligence and security at the
edge of the network—the first line of defense where
users connect.
Internet
Servers
Storage/
Backup device
Remote employees
Wireless users
Increased security products:
• HP ProCurve Switch 2610 Series: ideal for
businesses that require flexible, full-featured
network connectivity
– Robust security capabilities to control who has
network access and what business assets each
user should have permission to access
– Options for protecting your network, including
access control lists (ACLs) and port monitoring for
detecting and mitigating network threats using
HP ProCurve Network Immunity Manager
Network printers
• HP ProCurve Wireless Access Point 10ag: ideal
for deploying wireless connectivity with easy setup
and management
– Basic, secure, reliable IEEE 802.11a and
802.11b/g wireless connectivity
– Quick deployment using a simple, streamlined,
and intuitive Web interface
– Supports industry-standard wireless security
protocols such as WEP and WPA/WPA2 to
help ensure that only authorized users can
access the network
5
Page 6
Flexible wireless connectivity
Wireless connectivity allows you to avoid the cost and hassle of running wires throughout your building, while
allowing your clients, vendors, and employees easy and secure access to the Internet and connection to the
network regardless of which building or conference room they may be in.
Scenario:
Your company has four branch offices with more
than 60 employees. You have vendors and clients
who often need Internet access while in your offices
for meetings. You want to give employees, vendors,
and clients the flexibility to connect wirelessly from
anywhere within the office while still protecting your
network and company data.
Solution: simple wireless connectivity
HP ProCurve’s mobility solutions encompass an
integrated set of products, providing design,
deployment, and management that is secure and
Independent access point-based deployment
HP ProCurve 2520-24-PoE Switch
HP ProCurve Wireless
Access Point 10ag
Wireless users
HP ProCurve Switch 2610-24-PWR
HP ProCurve Wireless
Access Point 10ag
Wireless visitors
fast, and which provides appropriate levels of access
for wireless network users.
• Increase employee productivity and flexibility
by supporting wireless laptops, PDAs, and
mobile devices
• Enable employees to connect to the company
network easily and access the information they
need—regardless of which building or conference
room they are in
• Allow visitors to log on as well, with the network
providing the appropriate level of access, while still
safeguarding areas of the network that are intended
exclusively for employees
Internet
Remote employees
HP ProCurve M110
Access Point
Mobile IP
phones
Wireless handheld
devices
Servers
Storage/
Backup device
Network printers
6
Simple wireless connectivity products:
• HP ProCurve Switch 2610 Series: ideal for
businesses that require flexible, full-featured
network connectivity
– Power over Ethernet (PoE) capability eases physical
deployment limitations for wireless access points
due to lack of a nearby power outlet
– Flexible PoE options with standard 24- and
48-port PoE models and a hybrid switch with
12 ports of 10/100 PoE and 12 standard
Ethernet ports
• HP ProCurve 2520 Switch Series: ideal for
businesses that need cost-effective PoE for their
wireless deployments
– PoE capability eases physical deployment
limitations for wireless access points due to lack of
a nearby power outlet
– Provides choice of either Gigabit or Fast Ethernet
connectivity in 8- or 24-port form factors
– Security via network segmentation, management,
and authentication
• HP ProCurve M110 Access Point: ideal for simple,
secured wireless connectivity with easy setup
and management
– Single-radio IEEE 802.11a/b/g wireless
connectivity with robust security
– Flexible power options using either the standard
AC power or IEEE 802.3af PoE
– Easy to set up and configure
• HP ProCurve Wireless Access Point 10ag: ideal
for deploying wireless connectivity with easy setup
and management
– Basic, secure, reliable IEEE 802.11a and
802.11b/g wireless connectivity
– Quick deployment using a simple, streamlined,
and intuitive Web interface
Page 7
Scenario:
Your business is growing. You want a scalable
wireless solution that protects your existing product
investment and offers easy migration to highperformance IEEE 802.11n wireless connectivity when
your business demands it. You also want an easy way
to manage guest users as well as a secured wireless
network for employees, customers, and visitors who
access your network.
Solution: flexible, scalable, and secure
wireless connectivity
HP ProCurve’s scalable mobility solution provides
cost-effective mobility with a smooth technology
upgrade path. You can start by deploying intelligent
MultiService Mobility (MSM) access points in a
standalone network configuration. Then, as business
growth requires more access points, you can add an
MSM controller for easy centralized management of
Controller-based deployment
HP ProCurve MSM710
Mobility Controller
the entire wireless network. Your initial investment is
protected, because MSM access points are easily
reconfigured to work with the controller. The controller
solution features easy deployment and management,
investment protection, and rock-solid security.
• Scalable, distributed wireless architecture with
intelligent access points gives you the flexibility
to convert from independent access points to an
advanced, centrally managed mobility solution
• The intelligent access points forward wireless traffic
directly without rerouting to the controller and thus
provide high performance and an easy migration
path to IEEE 802.11n technology
• Simplified and central management of your access
points by the HP ProCurve MSM710 Mobility
Controller reduces the complexity of managing
your wireless network
Internet
HP ProCurve 2520-24-PoE Switch
HP ProCurve MSM310
Access Point a/b/g
Wireless users
HP ProCurve Switch 2610-24-PWR
HP ProCurve MSM310
Access Point a/b/g
Wireless visitors
Flexible, scalable, secure wireless
connectivity products:
• HP ProCurve Switch 2610 Series: ideal for
businesses that require flexible, full-featured
network connectivity
– Power over Ethernet (PoE) capability eases physical
deployment limitations for wireless access points
due to lack of a nearby power outlet
– Flexible PoE options with standard 24- and
48-port PoE models and an affordable hybrid
switch with 12 ports of 10/100 PoE and
12 standard Ethernet ports
• HP ProCurve 2520 Switch Series: ideal for
businesses that need cost-effective PoE for their
wireless deployments
Remote employees
HP ProCurve MSM410
Access Point (802.11n)
Mobile IP
phones
Wireless handheld
devices
Guest management
software
Servers
Storage/
Backup device
Network printers
– PoE capability eases physical deployment
limitations for wireless access points due to lack of
a nearby power outlet
– Provides choice of either Gigabit or Fast Ethernet
connectivity in 8- or 24-port form factors
• HP ProCurve Switch 2510 Series: ideal for
businesses that do not require PoE for their
wireless deployments
– Fully managed, yet easy to set up and configure
– Provides choice of simple Web configuration,
more comprehensive command line interface
configuration, or network-wide configuration and
monitoring using HP ProCurve Manager Plus
– Security via network segmentation, management,
and authentication
7
Page 8
• HP ProCurve MSM310 Access Point: ideal for
businesses that require scalable, high-performance
IEEE 802.11a/b/g wireless connectivity yet simple
plug-and-play deployment
– Power options using either standard AC power or
IEEE 802.3af PoE
– Can be centrally managed by the
MSM710 controller
• HP ProCurve MSM410 Access Point: ideal for
businesses that require scalable high-performance
IEEE 802.11n wireless connectivity yet simple
plug-and-play deployment
– Flexible power option with IEEE 802.3af PoE
– Integrated antennas provide robust
wireless coverage
– Can be centrally managed by the
MSM710 controller
• HP ProCurve MSM710 Mobility Controller: ideal for
businesses that require central management, guest
access, roaming, robust security, easy setup and
deployment of their wireless network
– Scalable, distributed wireless architecture
furnishes excellent investment protection for
IEEE 802.11n deployments
– Low deployment and operational cost
• Guest management software: ideal for businesses
that require a secure yet simple way to create and
manage guest-user accounts
– Intuitive user interface allows authorized user
with minimal training to create and monitor
guest accounts, thus freeing technology staff to
concentrate on strategic tasks
– Customized printing of the guest session vouchers
8
Page 9
Converged communications
Considering implementing IP phones, wireless access points, or video cameras? You’ll need a convergence
solution that allows you to transmit voice, video, and data on the same network—that means choosing smarter
switches with a slightly more robust feature set.
Scenario:
The network requirements are increasing for your
growing business—you want to integrate more things
onto one converged network. You have customerfacing needs such as integrated point of sale and
wireless scanners. In the back office you need desktop
computers, wireless laptop computers, printers, and
digital inventory control. And there’s building access
control, security cameras, and Voice over IP telephony.
Can your current network handle the load?
HP ProCurve 2520-24-PoE Switch
VoIP
phones
PC with soft phone
Laptop
HP ProCurve 2520G-8-PoE
HP ProCurve
Wireless Access
Point 10ag
Solution:
HP ProCurve offers a simplified network infrastructure
design that accommodates cost-effective voice,
video, and data applications. It delivers robust
reliability through open-standards technology and
enables secure deployment of both existing and
emerging applications.
By using your data network to transmit voice and
video, you may achieve significant long-term cost
savings. Industry estimates show that implementing
a VoIP solution can actually reduce intra-office
communications costs by as much as 60%. In addition
to cost savings, IP networks can be easier to maintain
than voice networks.
IP PBX
Video security
cameras
Servers
Internet
Wireless users
Converged communications products:
• HP ProCurve Switch 2610 Series: ideal for
businesses that require flexible, full-featured
network connectivity
– Supports key convergence capabilities such as
Power over Ethernet (PoE), multicast, and advanced
quality of service (QoS)
– Enables convergence applications such as IP
telephony, wireless access points, and video
streaming for security camera deployment
– Available in 24- and 48-port models with and
without PoE
• HP ProCurve 2520 Switch Series: ideal for
businesses looking for cost-effective PoE solutions
– Supports key convergence capabilities such as
PoE, multicast, and basic quality of service
Storage/
Mobile IP
phones
Backup device
Network
printers
– Enables voice, video, and wireless applications
requiring PoE connectivity
– Available in both Fast Ethernet and Gigabit models
in both 8- and 24-port form factors
• HP ProCurve Wireless Access Point 10ag: ideal
for deploying wireless connectivity with easy setup
and management
– Provides basic, secure, reliable IEEE 802.11a and
802.11b/g wireless connectivity
– Quick deployment using a simple, streamlined,
and intuitive Web interface
– Easy and flexible power options using either a
standard AC power outlet or PoE provided by
the connecting switch
9
Page 10
HP ProCurve Customer Care
HP ProCurve warranty
HP ProCurve networking products come with
hardware warranties you would expect from HP.
Our industry-leading HP ProCurve Lifetime Warranty
features next-business-day advance replacement
(available in most countries)*, and includes coverage
for fans and power supplies for the entire warranty
period. HP ProCurve products have legendary
HP quality, and our warranty is one way of
demonstrating it.
HP ProCurve support
Our warranty, though, is just the beginning of what we
include with our products. To help make it easier for
you to implement, use, and maintain our products, we
also include many support features with our products
such as self-help tools, which are available 24 x 7 on
the Web, telephone support, email support, electronic
case submission, and software releases.
Refer to the HP website at
www.hp.com/go/procurve/contact-support for details
on how to contact HP ProCurve technical support via
telephone and at
www.hp.com/go/procurve/email-support for email
support and electronic case submission.
HP network services
Today’s enterprise businesses, regardless of their
size, are under increasing pressure to reduce the
cost and complexity of supporting their network
infrastructures. The benefits of the ProCurve Lifetime
♦
Warranty
provide a robust foundation for significantly
reducing and, in many cases, eliminating ongoing
network support costs. However, many customers have
advanced support needs. HP offers an affordable,
comprehensive portfolio of networking services for
organizations of all sizes. HP provides customers
with a unique services advantage. HP is the only
technology vendor that can provide integrated support
for your entire technology infrastructure, including
multivendor networking, servers, and storage, to help
you grow your business with expert support that is
affordable, personal, and scaled to your needs.
♦
♦
HP Care Pack Services provide an easy-to-buy, easyto-use portfolio of packaged services that extend and
enhance the warranty coverage on HP hardware—at
a price you can afford. We scale enterprise-strength
expertise to provide you with everything from
supplemental service to a virtual technology staff.
When we care about technology, you gain peace of
mind. And that frees you up to do what really matters:
run your business.
Deployment and Installation Care Pack Services
• Factory Express Service
• Installation
• Installation and Startup Service
Hardware Support Care Pack Services
• Next Business Day Exchange
• Next Business Day Onsite
• 4-Hour Same Business Day Onsite (13x5)
• 4-Hour 24x7 Same Day Onsite
• 6-Hour Call-to-Repair
Software Support Care Pack Services
• 24x7 or 9x5 Software Technical Phone Support
• Software Subscription Services
Combination Hardware and Software Support
Care Pack Services
• Support Plus
• Support Plus 24
Mission Critical Support
• Proactive 24
• HP Critical Service
To get more details on HP Network Services
available in your country, please visit the Web at
www.hp.com/go/procurve/services or contact
your local HP ProCurve reseller.
♦
For as long as you own the product, with next-business-day advance replacement (available in most countries). The following hardware products have a five-year hardware warranty
for the disk drive and lifetime hardware warranty (for as long as you own the product) for the rest of the module: HP ProCurve ONE Services zl Module, HP ProCurve Threat Management
Services zl Module, and HP ProCurve MSM765zl Mobility Controller. The following hardware products and their related series modules have a one-year hardware warranty with extensions
available: HP ProCurve Routing Switch 9300m series, HP ProCurve Switch 8100fl series, HP ProCurve Network Access Controller 800, and HP ProCurve DCM Controller. The following
hardware products have a one-year hardware warranty with extensions available: HP ProCurve M111 Client Bridge, HP ProCurve MSM3xx-R Access Points, HP ProCurve MSM7xx Mobility
and Access Controllers, HP ProCurve RF Manager IDS/IPS Systems, HP ProCurve MSM Power Supplies, HP ProCurve 1-Port Power Injector, HP ProCurve CNMS Appliances, and HP ProCurve
MSM317 Access Device. Standalone software, upgrades, or licenses may have a different warranty duration. For details, refer to the ProCurve Software License, Warranty, and Support booklet
at www.procurve.com/warranty.
* Response times are based on local standard business days and working hours. Response times begin once HP has completed confirming the warranty failure and identifying the replacement part.
Response time is based on commercially reasonable effor t and subject to a daily shipment cutoff time. In some countries and regions and under certain supplier constraints, response time may
vary. If your location is outside the customary service zone, response time may be longer. Contact your local HP service organization for response time availability in your area.
10
Page 11
10/100 fixed Gigabit Multi-speed chassis
Managed Power over Ethernet (PoE) Power over Ethernet (PoE)
Layer 3
Layer 2
HP ProCurve Switch
2610-48
(J9088A)
HP ProCurve Switch
2610-24
(J9085A)
HP ProCurve Switch
2510-48 (J9020A)
HP ProCurve Switch
2510-24 (J9019B)
HP ProCurve Switch
2610-48-PWR
(J9089A)
HP ProCurve Switch
2610-24-PWR
(J9087A)
HP ProCurve Switch
2610-24/12PWR
(J9086A)
HP ProCurve
2520-8-PoE
Switch (J9137A)
HP ProCurve
2520-24-PoE
Switch (J9138A)
HP ProCurve
2910al-48G Switch
(J9147A)
HP ProCurve
2910al-24G Switch
(J9145A)
HP ProCurve Switch
2810-48G (J9022A)
HP ProCurve Switch
2810-24G (J9021A)
HP ProCurve Switch
2510G-48 (J9280A)
HP ProCurve
2910al-48G-PoE+
Switch (J9148A)
HP ProCurve
2910al-24G-PoE+
Switch (J9146A)
HP ProCurve
2520G-24-PoE
Switch (J9299A)
HP ProCurve
2520G-8-PoE
Switch (J9298A)
HP ProCurve Switch
4200vl Series (J8770A/
J8772A/J8773A/
J8775A/J9064A/J9030A)
Ready to buy?
The following table provides
part numbers for all the
HP ProCurve products ideal for
small and growing businesses.
To purchase a ProCurve
solution, including those we’ve
outlined, simply contact your
local ProCurve Partner, or visit
www.procurve.com.
Web managed
Unmanaged
HP ProCurve Switch
1700-24 (J9080A)
HP ProCurve Switch
1700-8 (J9079A)
HP ProCurve Switch
2124 (J4868A)
HP ProCurve Switch
408 (J4097C)
HP ProCurve Switch
2510G-24 (J9079A)
HP ProCurve 1810G-24
Switch (J9449A)
HP ProCurve 1810G-8
Switch (J9450A)
HP ProCurve Switch
1400-24G (J9078A)
HP ProCurve Switch
1400-8G (J9077A)
HP ProCurve Wireless
Access Point 10ag
(J9140A/J9141A)
HP ProCurve MSM310
Access Point (J9374A)
HP ProCurve MSM710
Mobility Controller
(J9325A)
HP ProCurve M110
Access Point (J9385A)
HP ProCurve MSM410
Access Point (J9426A)
11
Page 12
Technology for better business outcomes
To learn more, visit www.hp.com/go/procurve
© Copyright 2008, 2009 Hewlett-Packard Development Company, L.P. The information contained herein
is subject to change without notice. The only warranties for HP products and services are set forth in
the express warranty statements accompanying such products and services. Nothing herein should be
construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or
omissions contained herein.
4AA1-6948ENW Rev. 3, October 2009
Loading...
